Fruit & Nut
Fastbake breadmaker
Please read and keep these instructions
getting the best from your
new breadmaker...
Accurate measuring is essential
It is essential to measure ingredient quantities carefully, even slight changes may effect loaf quality, use the measuring spoon’s and cup provided.
Yeast content
If loaf rises too high and then collapses ensure the ingredients were measured accurately. If problem persists, reduce yeast by a quarter of a teaspoon.
www.morphyrichards.co.uk
Important safety instructions
The use of any electrical appliance requires the following of basic common sense safety rules.
Primarily there is danger of personal injury and secondly the danger of damage to property and the appliance. These are indicated in the text by the following two conventions:
WARNING: Danger of personal injury
IMPORTANT: Damage to the appliance
In addition we offer the following essential safety advice.
Location
•Always locate your appliance away from the edge of a worktop.
•Ensure that the appliance is used on a firm, flat surface.
•Do not use outdoors.
Mains lead
•The mains lead should reach from the socket to the base unit without straining the connections.
•Do not let the mains lead hang over the edge of a worktop where a child could reach it.
•Do not let the lead run across an open space e.g. between a low socket and table.
•Do not let the lead run across a cooker or toaster or other hot area which might damage the cable.
Your safety
•WARNING: Do not touch hot surfaces. Use oven mitts or oven gloves when removing the hot bread pan. Do not cover the steam vent openings under any circumstances.
•WARNING: Avoid contact with moving parts.
•To protect against electrical shock, do not immerse cord or plug in water or other liquid.
•Extreme caution must be observed when moving an appliance with hot contents.
•Do not use breadmaker for storage purposes nor insert any utensils, as they may create a fire or electric shock hazard.
•Do not use use the appliance with wet or moist hands.
Children
Never allow a child to operate this appliance. Children are vulnerable in the kitchen particularly when unsupervised and if appliances are being used or cooking is being carried out.
Teach children to be aware of dangers in the kitchen, warn them of the dangers of reaching up to areas where they cannot see properly or should not be reaching.
Other safety considerations
•If the mains lead of this appliance is damaged do not use it. The lead may only be replaced by Morphy Richards Ltd or an agent of the company, since special purpose tools are required. Telephone Morphy Richards helpline for advice.
•The use of accessory attachments not recommended by the manufacturer may cause damage to the breadmaker.
•Do not place the appliance on or near heat sources such as gas or electric stove ovens, or burners.
•To avoid damaging the appliance, do not place the baking pan or any object on top of the unit.
•Do not clean with scouring pads. Do not wash the baking pan, kneading blade measuring cup or spoon in a dishwasher.
•Keep the appliance and the cable away from heat, direct sunlight, moisture, sharp edges and the like.
•The baking pan must be in place prior to switching on the appliance.
•Always remove the plug from the socket whenever the machine is not in use, when attaching accessory parts, cleaning the machine or whenever a disturbance occurs. Pull on the plug, not the cable.
2
Operating instructions
Important safety instructions |
2 |
Introduction |
4 |
Before first use |
4 |
Electrical requirements |
4 |
About this breadmaker |
4 |
About the recipes |
4 |
Components |
5 |
Control panels buttons, display and functions |
6 |
Program descriptions |
7 |
Using your breadmaker |
8 |
Using the fruit and nut dispenser |
9 |
Using the timer |
9 |
Beeper |
9 |
Power interuption |
9 |
Slicing and storing bread |
9 |
Care and cleaning |
10 |
Storing the unit |
10 |
Know your ingredients |
11 |
Measuring ingredients |
12 |
Ingredient temperatures |
13 |
Creating your own yeast breads |
13 |
Special glazes for yeast breads |
13 |
Other tips |
13 |
Recipes |
|
Basic breads |
|
Basic white bread |
14 |
Softgrain bread |
14 |
Brown loaf |
14 |
Italian herb bread |
14 |
Cheese & onion bread |
14 |
Raisin bread |
14 |
Sun-dried tomato loaf |
14 |
Malt loaf |
15 |
Olive bread |
15 |
Pizza loaf |
15 |
Cheddar pepper bread |
15 |
Peanut butter bread |
15 |
Nut and honey bread |
15 |
Orange bread |
15 |
Wholewheat breads |
|
Wholewheat bread |
15 |
Granary loaf |
16 |
French bread |
|
French bread |
16 |
Rapide |
|
Basic white bread |
16 |
Soft grain bread |
16 |
Contents |
|
Sweet |
|
Mixed fruit loaf |
16 |
Chocolate bread |
16 |
Cakes |
|
Madeira cake |
17 |
Mixed fruit cake |
17 |
Banana and nut loaf |
17 |
Parkin |
17 |
Pasta |
|
Pasta |
17 |
Fast bake |
|
Fast bake white |
17 |
Softgrain |
18 |
Dough recipes |
|
White bread rolls |
18 |
Wholewheat bread rolls |
18 |
Hot cross buns |
18 |
Pizza base |
18 |
Russian Kulich |
18 |
Raspberry braid |
19 |
Jams |
|
Marmalade |
19 |
Raspberry and apple |
19 |
Plum |
19 |
Gluten free recipes |
|
Gluten free loaf |
20 |
Gluten free madeira cake |
20 |
Further information |
|
Baking cycle times |
21 |
Need help? (questions and answers) |
22-23 |
Troubleshooting |
24-25 |
3
Introduction
The smell of homemade bread wafting around the home is one of those great smells. Bread, fresh out of the oven, with melting butter is a memorable taste sensation. The Morphy Richards automatic breadmaker can create that experience every morning.
There's very little effort on the part of the baker, because the breadmaker is a sophisticated appliance with a computer memory that does all the work for you.
It’s as simple as one-two-three.
1Put in the ingredients.
2Select program from the menus and press start.
3Wait for your bread.
But don't stop at baking bread in this appliance.
Besides being able to do all kinds of speciality breads, including wholewheat, you can also prepare doughs for bread rolls, pizza, cake and jam. Everything is easy and tastes homemade - because it is.
Before first use
Before first use, please take a few minutes to read this instruction book and to find a place to keep it handy for reference. Pay particular attention to the safety instructions.
1Carefully unpack the breadmaker and remove all packaging materials.
2Remove any dust that may have accumulated during packing.
3Wipe the baking pan, kneading blade and outside surface of the breadmaker with a clean, damp cloth. The bread pan is non-stick coated. Do not use scouring pads or any abrasives on any part of the breadmaker.
4For first time use oil, butter or margerine to grease the bread pan and bake empty for about 10 minutes (select the Extrabake program).
5Allow to cool and clean once more.
6Place the kneading blade on the axle in the baking pan.
In manufacture it is necessary to lightly grease
some parts of the appliance. This may result in the unit emitting some vapour when first used, this is normal.
7This breadmaker is fitted with mains switch at the rear of the machine, it can be left permanently switched on ready for use.
The breadmaker programme is started by the startstop button on the control panel.
If when you plug in the breadmaker and switch on at the mains there is no display, make sure the on/off switch at the rear of the breadmaker is switched to the ‘I’ ON position.
Electrical requirements
Check that the voltage on the rating plate of your appliance corresponds with your house electricity supply which must be A.C. (Alternating Current).
If the socket outlets in your home are not suitable for the plug supplied with this appliance, the plug should be removed and the appropriate one fitted.
Note: The plug removed from the mains lead, if
severed, must be destroyed as a plug with bared flexible cord is hazardous if engaged into a live socket outlet.
WARNING: THIS APPLIANCE MUST BE EARTHED.
Should the fuse in the 13 amp plug require changing a 13 amp BS1362 fuse must be fitted.
About this breadmaker
•It has two settings to make a small 680g (1.5lb) or large 909g (2lb) loaf (approx weight - depends on recipe).
•Fruit and nut dispenser automatically dispenses the fruit, nut, olives etc. into the dough at the correct time ensuring these ingredients are evenly distributed.
About the recipes
The recipes in this booklet have been thoroughly tested to ensure best results. Recipes have been created by home economists specifically for this machine and may not produce acceptable results in other similar machines.
•Always add ingredients in the order they are listed in the recipe.
•Accurate measuring of ingredients is vital. Do not use larger amounts. Use the measuring cup and spoons provided.
4
Components
Viewing window |
Fruit and nut dispenser |
Cover
Lid handle
Main body
Handle
Baking pan
Kneading blade
Rotating shaft
Control panel
Air vents
Air vents
On/off switch on rear of breadmaker
On/off switch
on rear of breadmaker
5
Control panel buttons, display & functions
Display window
Shows crust colourl selected Shows weight selected Shows the program number
Shows time left before completion (3:20, for example, is 3 hours and 20 minutes; 0:20 is 20 minutes)
Shows temperature warning - see ‘Troubleshooting’
1.5lb
2.0lb
LIGHT MEDIUM DARK
1 |
Basic |
TIMER |
|
|
|||
2 |
Wholewheat |
|
|
3 |
French |
|
|
4 |
Rapide |
|
|
5 |
Sweet |
|
|
6 |
Cake |
MENU |
|
7 |
Pasta |
||
|
|||
8 |
Fastbake |
|
|
9 |
Dough |
|
|
10 Jam |
COLOUR |
||
11 |
Extra bake |
||
|
START |
LOAF |
|
STOP |
||
|
Start
Press to start for approx 1 second, a beep sounds and the colon (:) flashes and the program starts.
Stop
Press to stop for approx 2 seconds, a beep sounds to confirm and the colon (:) stops flashing.
Timer delay buttons
Use to delay the start of bread making (all programs except Fastbake and pasta)
Menu button
For choosing the bread making program from the list 1 to 11
Colour button
For selecting crust colour from light, medium or dark (certain programs only)
Loaf size button
For selecting small (1.5lb) or large (2lb) loaf size (certain programs only)
6
1Basic white (2:50 and 2:45)
For white and brown bread. Also for flavoured breads with added herbs and raisin.
2Wholewheat (4:30 and 4:25)
For the baking of bread containing significant amounts of wholewheat. This setting has longer preheat time to allow the grain to soak up the water and expand. The kneading blade does not turn during this 30 minute rest period. It is not advised to use the delay timer as this can produce poor results. It has been found that some wholemeal flours perform better on the basic menu setting.
3French (3:40 and 3:36)
For the baking of light weight bread such as french bread which has a crisper crust and light texture.
4Rapide (1:58 and 1:56)
For white bread that is required in a shorter time. Bread baked on this setting is usually smaller with a dense texture.
5Sweet (3:25 and 3:22)
For the baking of sweet type bread which gives a crisper crust than on basic setting. The crisper crust is produced by the sugar ‘burning’.
6Cake (1:40 and 1:34)
This setting will mix ingredients and then bake for a preset time. It is required to mix two groups of ingredients in bowls before adding to the breadmaker (see cake recipes).
7Pasta (0:13)
The pasta setting is a 13 minute knead which can be used for general mixing of other flour based recipes. Do not exceed 3 cups of dry mix.
8Fastbake (0:58)
For preparation of a 1.5lb white loaf in a reduced time period. Loaves made on this setting can be shorter and the texture more moist. Water temperature 32-38˚C.
9Dough (1:30)
This setting only makes the dough and will not bake the final bread. Remove the dough and shape it to make bread rolls, pizza, etc. Any dough can be prepared on this setting. Do not exceed 1kg (2lb) of combined ingredients.
Program descriptions
10 Jam (1:25)
Use this setting for making jam from fresh fruits and marmalade from Seville oranges. Do not increase the quantity or allow the recipe to boil over the pan into the baking chamber. Should this happen, stop the machine immediately. Remove the pan carefully, allow to cool a little and clean thoroughly.
11 Extra bake (0:10)
This setting is bake only and can be used to increase the baking time on selected settings. This is especially useful to help ‘set’ jams and marmalade. When started the default time is 10 mins (0:10) minimum and counts down in 10 minute intervals. You will have to manually switch this off by pressing the stop button, when you have completed the Extrabake process. It is advised that you check the condition of the bread or jam after 10 minutes and at 10 minute intervals.
Pressing ▲ increases the time in increments of 10 minutes.
When selecting Extrabake straight after another program, if the message E:01 is displayed, open the lid, remove the pan and allow to cool for 10 minutes. When cool, replace the baking pan and its contents, set program and press start.
Times indicated are for loaf size option, crust colour selection will vary these times. See cycle chart page 21.
7
Using your breadmaker
1Take out the pan
Open the lid and remove the pan by lifting the handle, and lifting out. Place on the work surface. It is important that the pan is filled with ingredients outside the machine so that any accidental spillage is not ignited by the heating elements.
2Attach the blade
Attach the kneading blade to the shaft by pushing on.
3Measure ingredients
Measure the ingredients required and add them all into the pan in the order listed. See later section ‘Measuring your ingredients’).
•When adding the yeast to the baking pan, take care that the yeast does not come into contact with the water or any other liquid, as it will start to activate immediately.
•Use tepid water 21-28˚C.
4Put pan back in
Place the baking pan back in the breadmaker, Press until it locks into place. Close the lid.
4a If using the fruit and nut dispenser, lift the lid of the dispenser, add the measured quantity (maximum 1/2 a cup) of fruit and nuts, olives etc. Close the lid.
5Plug in
Plug into the power supply. The breadmaker will automatically be set to basic bread menu and normal time.
•Everytime you press a button you will hear a beep to confirm.
6Select program
Choose the desired setting from the list by pressing the Menu button.
7Select weight
Press Loaf size button to choose between small or large.
8Select colour
Choose desired crust colour by pressing Colour button.
9Select the delay time
If you wish the bread to be ready later, set the time delay now, as described in next section.
10Start
Press the Start Stop button to start the machine. The remaining time will count down in one minute increments.
11Progress
The breadmaker will automatically proceed through the programmed stages as shown in the ‘Baking cycle times’ section.
•It is possible that steam will escape through the vents during baking, this is normal.
12Finish
When the program is completed and the bread is baked the display shows 0:00 and the beeper will sound.
13Keep warm
The keep warm function will circulate hot air for a further 60 minutes on most settings (see ‘Baking cycle times’ section). For best results, remove the baking pan and loaf within this period or when the initial program is completed. Beeps will be heard when the keep warm period is finished.
14Remove the food
Press Stop. Open the lid.
WARNING: Use oven gloves when removing the baking pan (taking care as it is very hot).
15Turn out the bread
Allow the bread to cool in the pan for 15 minutes, then turn the pan upside down and tap the bread from the pan onto a rack to cool. If the blade sticks in the pan, fill the pan with warm water to prevent the blade from sticking to the shaft.
•The kneading blade will stay in the loaf. Wait until the loaf is cool and then remove the blade with a wooden or plastic utensil to avoid damage to the non-stick surface.
16 Always unplug the appliance after use.
•Do not open the lid whilst the breadmaker is operating as this will affect the quality of the bread, especially its ability to rise properly.
Room temperature note
The breadmaker will work well in a wide range of temperatures, but there could be a difference in loaf size between a very warm room and a very cold room. We recommend the room temperature should be between 15˚C and 34˚C.
8
