52" LCD Display Monitor
USER’S MANUAL
BEDIENERHANDBUCH
MANUAL DEL USUARIO
MANUEL UTILISATEUR
MANUALE UTENTE
GEBRUIKERSHANDLEIDING
Index
Important Information ................................................................................................................................... English-2
Safety Precautions, Maintenance & Recommended Use ........................................................................... English-4
Contents ....................................................................................................................................................... English-5
Parts Name and Functions .......................................................................................................................... English-6
Buttons, Switch, and Indicator ....................................................................................................... English-6
Connectors and Terminals .............................................................................................................. English-7
Wireless Remote Control ............................................................................................................... English-8
< Operating Range for the Remote Control > ........................................................................... English-9
< Handling the remote control > ............................................................................................... English-9
CAT5 Tx BOX .................................................................................................................................. English-9
Setup Procedure .......................................................................................................................................... English-10
CAT5 video connection ................................................................................................................... English-12
How to Mount and Attach Options to the LCD Monitor ............................................................................... English-14
Connections ................................................................................................................................................. English-15
Wiring Diagram ............................................................................................................................... English-15
Connecting a Personal Computer .................................................................................................. English-16
Connecting with Digital Interface Equipment ................................................................................ English-17
Connecting a DVD Player with component out/HDMI out/DVI out ................................................ English-18
Connecting to a VCR/Stereo Amplifi er ........................................................................................... English-19
Basic Operation ............................................................................................................................................ English-20
Power ON and OFF Modes ............................................................................................................ English-21
Power Indicator ............................................................................................................................... English-21
Using Power Management ............................................................................................................ English-21
Selecting a video source ................................................................................................................ English-21
Picture Size .................................................................................................................................... English-21
Picture Mode .................................................................................................................................. English-21
Audio Source Switching ................................................................................................................. English-21
Information OSD ............................................................................................................................. English-22
OSD (On-Screen-Display) Controls .............................................................................................................. English-23
PICTURE ......................................................................................................................................... English-24
SCREEN .......................................................................................................................................... English-26
AUDIO ............................................................................................................................................. English-27
PICTURE IN PICTURE .................................................................................................................... English-27
CONFIGURATION 1 ........................................................................................................................ English-28
CONFIGURATION 2 ........................................................................................................................ English-29
ADVANCED OPTION ...................................................................................................................... English-30
NOTE .............................................................................................................................................. English-32
< IMAGE PERSISTENCE > ....................................................................................................... English-32
< For long life use of Public Display > ...................................................................................... English-32
< HOW TO SETUP SCHEDULE > ............................................................................................. English-32
< PIP, POP and SIDE BY SIDE > ............................................................................................... English-33
< Supplemental information of the auto brightness function > ................................................ English-33
< Remote control numbering function > ................................................................................... English-34
Controlling the LCD monitor via RS-232C/RS-485 Remote Control .......................................................... English-35
Features ........................................................................................................................................................ English-37
Troubleshooting ............................................................................................................................................ English-38
Specifi cations .............................................................................................................................................. English-40
Pin Assignment ............................................................................................................................................ English-41
English
English-1
Important Information
DECLARATION OF CONFORMITY
This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions. (1) This device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may
cause undesired operation.
U.S. Responsible Party: Mitsubishi Digital Electronics America, Inc.
Address: 9351 Jeronimo Road,
Irvine, California 92618 U.S.A.
Tel. No.: +1 - (949) 465-6000
Type of Product: Computer Monitor
Equipment Classifi cation: Class B Peripheral
Model: MDT521S (DT851)
We hereby declare that the equipment specifi ed above
conforms to the technical standards as specifi ed in the FCC Rules.
Windows is a registered trademark of Microsoft Corporation. All other brands and product names are trademarks or registered trademarks of their respective owners.
HDMI, the HDMI logo and High-Defi nition Multimedia Interface are trademarks or registered trademarks of HDMI
Licensing LLC.
Canadian Department of Communications Compliance Statement
DOC: This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.
C-UL: Bears the C-UL Mark and is in compliance with Canadian Safety Regulations according to CAN/CSA C22.2 No.
60950-1.
FCC Information
1. Use the attached specifi ed cables with the MDT521S (DT851) color monitor so as not to interfere with radio and television
reception.
(1) Please use the supplied power cord or equivalent to ensure FCC compliance.
(2) Please use the supplied shielded video signal cable, 15-pin mini D-SUB to 15-pin mini D-SUB.
2. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy, and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult your dealer or an experienced radio/TV technician for help.
If necessary, the user should contact the dealer or an experienced radio/television technician for additional suggestions.
The user may fi nd the following booklet, prepared by the Federal Communications Commission, helpful: “How to Identify
and Resolve Radio-TV Interference Problems.” This booklet is available from the U.S. Government Printing Offi ce,
Washington, D.C., 20402, Stock No. 004-000-00345-4.
English-2
Important Information
WARNING
TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. ALSO, DO NOT USE THIS
UNIT’S POLARIZED PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLETS UNLESS THE PRONGS CAN BE
FULLY INSERTED.
REFRAIN FROM OPENING THE CABINET AS THERE ARE HIGH VOLTAGE COMPONENTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
English
CAUTION
TO REDUCE THE RISK OF ELECTRIC SHOCK, MAKE SURE POWER CORD IS UNPLUGGED FROM
WALL SOCKET. TO FULLY DISENGAGE THE POWER TO THE UNIT, PLEASE DISCONNECT THE
POWER CORD FROM THE AC OUTLET. DO NOT REMOVE COVER (OR BACK). NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This symbol warns user that uninsulated voltage within the unit may have suffi cient magnitude to cause
electric shock. Therefore, it is dangerous to make any kind of contact with any part inside this unit.
This symbol alerts the user that important literature concerning the operation and maintenance of this unit
has been included. Therefore, it should be read carefully in order to avoid any problems.
This LCD Monitor uses a lamp that contains mercury. Disposal of the lamp or the LCD Monitor with the lamp
may be regulated due to environmental considerations. For disposal or recycling information, please contact
your local authorities or the Electronic Industries Alliance: www.eiae.org. (For US only).
Declaration
We hereby certify that the color monitor
is in compliance with
Council Directive 2006/95/EC:
– EN 60950-1
Council Directive 2004/108/EC:
– EN 55022
– EN 61000-3-2
– EN 61000-3-3
– EN 55024
CAUTION
Declaration of the Manufacturer
MDT521S (DT851)
and marked with
Mitsubishi Electric Corporation
2-7-3, Marunouchi,
Chiyoda-Ku
Tokyo 100-8310, Japan
Declaration of the Manufacturer
Note: This symbol mark is for EU countries only.
This symbol mark is according to the directive 2002/96/EC Article 10 Information for users and
Annex IV, and/or to the directive 2006/66/EC Article 20 Information for end-users and Annex II.
Your MITSUBISHI ELECTRIC product is designed and manufactured with high quality
materials and components which can be recycled and/or reused.
This symbol means that electrical and electronic equipment, batteries and accumulators,
at their end-of-life, should be disposed of separately from your household waste.
If a chemical symbol is printed beneath the symbol shown above, this chemical symbol means that the
battery or accumulator contains a heavy metal at a certain concentration. This will be indicated as follows:
Hg: mercury (0,0005%), Cd: cadmium (0,002%), Pb: lead (0,004%)
In the European Union there are separate collection systems for used electrical and electronic products,
batteries and accumulators.
Please, dispose of this equipment, batteries and accumulators correctly at your local community waste
collection/recycling centre.
Please, help us to conserve the environment we live in!
English-3
Safety Precautions, Maintenance & Recommended Use
FOR OPTIMUM PERFORMANCE, PLEASE NOTE
THE FOLLOWING WHEN SETTING UP AND USING
THE LCD COLOR MONITOR:
• DO NOT REMOVE MONITOR BACK COVER. There are
no user serviceable parts inside and opening or removing
covers may expose you to dangerous shock hazards or
other risks.
Refer all servicing to qualifi ed service personnel.
• Do not spill any liquids into the cabinet or use your
monitor near water.
• Do not insert objects of any kind into the cabinet slots, as
they may touch dangerous voltage points, which can be
harmful or fatal or may cause electric shock, fi re or
equipment failure.
• Do not place any heavy objects on the power cord.
Damage to the cord may cause shock or fi re.
• Do not place this product on a sloping or unstable cart,
stand or table, as the monitor may fall, causing serious
damage to the monitor.
• When operating the LCD monitor with an AC 100-120V
power supply in North America, use a power supply cord
provided with this monitor.
• When operating the LCD monitor with an AC 220-240V
power supply in Europe, use a power supply cord
provided with this monitor.
• In UK, use a BS-approved power cord with molded plug
having a black (10A) fuse installed for use with this
monitor.
If a power cord is not supplied with this monitor, please
contact your supplier.
• When operating the LCD monitor with a 220-240V AC
power supply in Australia, use the power cord provided
with this monitor.
If a power cord is not supplied with this monitor, please
contact your supplier.
• For all othercase, use a power cord that matches the AC
voltage of the power outlet and has been approved by
and complies with the safety standard of your particular
country.
• Do not place any objects onto the monitor and do not use
the monitor outdoors.
• The inside of the fl uorescent tube located within the LCD
monitor contains mercury. Please follow the laws or rules
of your municipality to dispose of the tube properly.
• Do not bend power cord.
• Do not use monitor in high temperature, humid, dusty, or
oily areas.
• If monitor or glass is broken, do not come in contact with
the liquid crystal and handle with care.
• Allow adequate ventilation around the monitor, so that
heat can properly dissipate. Do not block ventilated
openings or place the monitor near a radiator or other
heat sources.
Do not put anything on top of the monitor.
• The power cable connector is the primary means of
detaching the system from the power supply. The monitor
should be installed close to a power outlet, which is easily
accessible.
• Handle with care when transporting. Save packaging for
transporting.
• Please clean the holes of back cabinet to reject dirt and
dust at least once a year because of set reliability.
• If using the cooling fan continuously, it’s recommended to
wipe holes a minimum of once a month.
• When installing the remote control batteries;
- Align the batteries according to the (+) and (-)
indications inside the case.
- Align the (-) indication of the battery fi rst inside the
case.
CAUTION:
Immediately unplug your monitor from the wall outlet and refer
servicing to qualifi ed service personnel under the following
conditions:
• When the power supply cord or plug is damaged.
• If liquid has been spilled, or objects have fallen into the
monitor.
• If the monitor has been exposed to rain or water.
• If the monitor has been dropped or the cabinet damaged.
• If the monitor does not operate normally by following
operating instructions.
Recommended Use
CAUTION:
• For optimum performance, allow 20 minutes for warm-up.
• Rest your eyes periodically by focusing on an object at
least 5 feet away. Blink often.
• Position the monitor at a 90° angle to windows and other
light sources to minimize glare and refl ections.
• Clean the LCD monitor surface with a lint-free, nonabrasive cloth. Avoid using any cleaning solution or glass
cleaner!
• Adjust the monitor’s brightness, contrast and sharpness
controls to enhance readability.
• Avoid displaying fi xed patterns on the monitor for long
periods of time to avoid image persistence (after image
effects).
• Get regular eye checkups.
Ergonomics
To realize the maximum ergonomic benefi ts, we recommend
the following:
• Use the preset Size and Position controls with standard
signals.
• Use the preset Color Setting.
• Use non-interlaced signals.
• Do not use primary color blue on a dark background, as
it is diffi cult to see and may produce eye fatigue due to
insuffi cient contrast.
English-4
Contents
Your new MDT521S monitor box* should contain the following:
• LCD monitor
• Power Cord (3 m)
• Video Signal Cable (4 m)
• User’s Manual
• Wireless Remote Control and AAA Batteries
• Clamper x 2 (To prevent from falling)
• Clamper x 3 (For securing cables)
• Clamper x 2 (For securing the power cord and HDMI cable)
• Screw for Clamper (To prevent from falling) x 2
• CAT5 Tx BOX
• CD-ROM
52" LCD Display Monitor
USER’S MANUAL
BEDIENERHANDBUCH
MANUAL DEL USUARIO
MANUEL UTILISATEUR
MANUALE UTENTE
GEBRUIKERSHANDLEIDING
English
Clamper x 3
(For securing cables)
(For securing the power cord
Clamper x 2
and HDMI cable)
* The supplied power cord varies depending on destination.
For EU
For North
America
Power cord
* For all other case, use a power cord that matches the AC voltage
of the power outlet and has been approved by and complies with
the safety standard of your particular country.
User’s Manual
Screw for Clamper
(M4) x 2
Clamper x 2
(To prevent from falling)
CAT5 Tx BOX
CD-ROM
Video Signal Cable
(D-SUB to D-SUB Cable)
Wireless Remote Control
and AAA Batteries
* Remember to save your original box and packing material to transport or ship the monitor.
The following components are prepared as option.
• External Speakers
• Stand
English-5
Parts Name and Functions
Buttons, Switch, and Indicator
ON
OFF
Remote control sensor and Power indicator
Receives the signal from the remote control (when using the
wireless remote control). See also page 9.
Glows green when the LCD monitor is in active and glows
red when the LCD is in POWER OFF mode. When the LCD is
in power save mode, it will glow both green and red. When
SCHEDULE is enabled, it will blink green and glow red. See
page 21. In the case of where a failure is detected, it will blink
red.
POWER button ( )
Switches the power on/off. See also page 20.
MUTE button
Switches the audio mute ON/OFF.
INPUT button
Acts as SET button with OSD menu.
(Toggle switches between [RGB1], [RGB2], [RGB3], [RGB4],
[RGB5], [DVD/HD], [VIDEO<S>] and [VIDEO] .)
PLUS (+) button
Acts as (+) button to increase the adjustment with OSD menu.
Increase the audio output level when the OSD menu is turned
off.
MINUS (-) button
Acts as (-) button to decrease the adjustment with OSD menu.
Decreases the audio output level when the OSD menu is
turned off.
UP ( ) button
Activates the OSD menu when the OSD menu is turned-off.
Acts as
the adjustment with OSD menu.
button to move the highlighted area up to select
DOWN ( ) button
Activates the OSD menu when the OSD menu is turned-off.
Acts as
the adjustment with OSD menu.
button to move the highlighted area down to select
EXIT button
Activates the OSD menu when the OSD menu is turned-off.
Acts as EXIT button to move to previous menu with OSD
menu.
Brightness sensor (front, rear)
Sensor for the auto brightness function.
This function controls the screen brightness depending on the
ambient light for easy viewing.
In addition, it changes the screen brightness depending on
the ambient light and what are displayed on the screen to
reduce power consumption as low as possible. See page 25,
33.
Main Power Switch
On/Off Switch to turn main power on/off.
NOTE: Control Key Lock Mode
This control completely locks out access to all Control Key
functions. To activate the control key lock function, press
both of “
than 3 seconds. To resume back to user mode, press both of
” and “ ” and hold simultaneously for three (3) seconds.
“
” and “ ” and hold down simultaneously for more
English-6
Connectors and Terminals
(OUT)
(IN)
(OUT)
(IN)
(OUT)
(IN)
(IN)
(IN)
English
CAT5 input/output connectors (modular con-
nector 8 pin)
The IN (RGB5 IN) connector is for connecting the CAT5
Tx BOX or the CAT5 OUT connector of a multi-connected
MDT521S.
The OUT connector is for connecting the CAT5 (RGB5) IN
connector of a multi-connected MDT521S.
EXTERNAL CONTROL (mini D-Sub 9 pin)
Connect the IN connector with the RS-232C OUT connector
of the computer or a multi-connected MDT521S monitor.
Connect the OUT connector with the RS-232C IN connector
of a multi-connected MDT521S monitor.
VIDEO IN/OUT
VIDEO IN connector (BNC and RCA): To input a composite
video signal. BNC and RCA are not available at the same
time. (Use only one input).
VIDEO OUT connector (BNC): To output the composite
video signal from VIDEO IN connector.
S-VIDEO IN connector (MINI DIN 4 pin): To input the
S-video (Y/C separate signal).
RGB 4 / DVD/HD IN (BNC)
To input the analog RGB signals from a computer or other
RGB equipment.
Connecting equipment such as a DVD player, HDTV device,
or Laser disc player. See page 16, 18.
EXTERNAL SPEAKER TERMINAL
To output the audio signal for external speakers from AUDIO 1,
2, 3 jack or HDMI.
AUDIO OUT
To output the audio signal from the AUDIO IN 1, 2, 3 jack or
HDMI.
AUDIO IN 1, 2, 3
To input the audio signal from external equipment such as a
computer, VCR or DVD player.
RGB 1 IN (HDMI)
To input the digital RGB signals from a computer.
* This connector does not support analog input.
AUDIO is supported via HDMI.
RGB 2 IN (DVI-D)
To input the digital RGB signals from a computer.
* This connector does not support analog input.
AUDIO is supported via DVI-D.
RGB 3 IN (mini D-Sub 15 pin)
To input the analog RGB signals from a computer or other
RGB equipment.
RGB OUT (mini D-Sub 15 pin)
To output the signal from RGB 3, 4 or 5 IN.
AC IN connector
Connects with the supplied power cord.
English-7
Wireless Remote Control
POWER button
Switches the power on/off.
* If LED Power Indicator on the monitor is not glowing, then
no controls will work.
INPUT button
Selects from input signal, [RGB1] (HDMI), [RGB2] (DVI-D),
[RGB3] (D-SUB), [RGB4] (BNC), [RGB5] (CAT5), [DVD/HD]
(YPbPr), [VIDEO<S>] and [VIDEO].
PICTURE MODE button
Selects from picture mode, [HIGHBRIGHT], [STANDARD],
[sRGB], [CINEMA]. See page 21.
HIGHBRIGHT: for moving image such as Video
STANDARD: for images (Factory setting)
sRGB: for text based images
CINEMA: for movies.
DISPLAY button
To switch the information OSD on/off. See page 22.
SET button
Acts as SET button with OSD menu.
AUDIO INPUT button
Press to change the audio source for each video source. The
audio source is changed from [AUDIO1] to [AUDIO2], [AUDIO3]
and [HDMI] in order. Note that you cannot select the audio
source for [VIDEO<S>] or [VIDEO]. [HDMI] is selectable only
when the video source is [RGB 1] and [RGB 2].
PIP (Picture In Picture) button
ON/OFF button: PIP-ON/OFF. See page 27.
INPUT button: Select the “picture in picture” input signal.
CHANGE button: Replaces to the main picture and sub pic-
ture.
Note:
The “PIP” and “POP” modes do not function when the screen
size is “CUSTOM” or “REAL”.
STILL button
ON/OFF button: To switch the still picture mode on/off.
CAPTURE button: Updates the still picture.
SIZE button
Selects picture size, [FULL], [NORMAL], [CUSTOM] , [DYNAMIC] and [REAL]. See page 21.
MENU button
To switch the menu mode on/off.
UP button
Acts as button to move the highlighted area up to select
the adjustment with OSD menu.
Small screen which adjusted “PIP” mode moves up.
PLUS button increase
Acts as (+) button to increase the adjustment with OSD menu.
Small screen which adjusted “PIP” mode moves right.
EXIT button
Turn to previous menu with OSD menu.
DOWN button
Acts as button to move the highlighted area down to select
the adjustment with OSD menu.
Small screen which adjusted “PIP” mode moves down.
MUTE button
To switch the mute function on/off.
VOLUME button
Increases or decreases the audio output level.
MINUS button decrease
Acts as (-) button to decrease the adjustment with OSD menu.
Small screen which adjusted “PIP” mode moves left.
AUTO SETUP button
To enter the auto setup menu. See page 28.
English-8
< Operating Range for the Remote
CAT5 Tx BOX
Control >
Point the top of the remote control toward the LCD monitor's
remote sensor during button operation.
Use the remote control within a distance of about 7 m/23 ft.
from the front of the LCD monitor's remote control sensor
and at a horizontal and vertical angle of within 30° within a
distance of about 3 m/10 ft.
30° 30°
CAUTION:
Important, the remote control system may not function when
direct sunlight or strong illumination strikes the remote control
sensor of the LCD monitor, or when there is an object in the
path.
< Handling the remote control >
* Do not subject to strong shock.
* Do not allow water or other liquid to splash the remote
control. If the remote control gets wet, wipe it dry immedi-
ately.
* Avoid exposure to heat and steam.
* Other than to install the batteries, do not open the remote.
English
USB (B type)
Connected to the USB connector (A type) of the computer.
CAUTION:
We have checked the operation of the USB connector by
connecting it with our computers according to the USB standards.
When the CAT TX5 BOX is combined with your computer
system or USB hub system, check in advance that it operates
properly.
EXTERNAL CONTROL IN (mini D-Sub 9 pin)
Connected to the RS-232C OUT connector of the computer.
Note:
RS-232C connection isn’t necessary when the COM port
number set by the USB driver is used. Make selection using
the input select switch (USB/RS-232C), as necessary.
RGB IN (mini D-Sub 15 pin)
To input the analog RGB signals from other monitor.
RGB OUT (mini D-Sub 15 pin)
To output the analog RGB signals from a computer.
Input select switch (USB/RS-232C)
Switches the control input between the USB connector and
the RS-232C connector.
CAT5 OUT (modular connector 8 pin)
Connected to the CAT5 (RGB5) IN connector of MDT521S.
Composite sync signal level switch
Switches the composite sync signal level.
The TTL level and the 0.3V level are switched.
Auxiliary power supply input connector (DC IN
5 V)
Though the power is supplied from the above-mentioned
USB connector, an auxiliary DC power adopter (commercially
available) is also available. Power can be drawn from the USB
connector and the auxiliary power supply at the same time.
CAUTION:
The auxiliary power supply input connector isn’t intended for
general use. Commercial DC power connectors are available
in different shapes. When you want to use this connector,
consult a qualifi ed electrician in advance.
English-9
Setup Procedure
1. Determine the installation location
CAUTION:
DO NOT ATTEMPT TO INSTALL THE LCD MONITOR BY
YOURSELF.
Installing your LCD display must be done by a qualifi edtechnician. Contact your dealer for more information.
CAUTION:
MOVING OR INSTALLING THE LCD MONITOR MUST BE
DONE BY TWO OR MORE PEOPLE.
Failure to follow this caution may result in injury if the LCD
monitor falls.
CAUTION:
Do not mount or operate the display upside down, face up, or
face down.
CAUTION:
Do not install the LCD monitor where it will be exposed to
direct sunlight, as this will result in display defects.
CAUTION:
This LCD has a temperature sensor and cooling fan. If the
LCD becomes too hot, the cooling fan will turn on automatically. If the LCD becomes overheated and the cooling fan
is running, the “Caution” menu will appear. If the “Caution”
menu appears, discontinue use and allow the unit to cool.
When the LCD monitor is used in an enclosure or with protection on LCD surface, please check the inside temperature of
monitor by “HEAT STATUS” (See page 31). The temperature is
too hot than normal condition, please set “cooling fan” to ON
on SCREEN SAVER function (See page 28).
IMPORTANT:
Lay the protective sheet, which was wrapped around the LCD
monitor when it was packaged, beneath the LCD monitor so
as not to scratch the panel.
• Place “AAA” batteries matching the + and - signs on each
battery to the + and - signs of the battery compartment.
• Do not mix battery types.
• Do not combine new batteries with used ones. It causes
shorter battery life or leakage of batteries.
• Remove dead batteries immediately to prevent battery
liquid from leaking into the battery compartment. Don't
touch exposed battery acid, it cause damage to your skin.
NOTE:
If you do not intend to use the Remote Control for a long
period, remove the batteries.
3. Connect external equipment
(See page15-18)
• To protect the connected equipment, turn off the main
power before making connections.
• Refer to your equipment user manual.
4. Connect the supplied power cord
• The power outlet socket should be installed as near to the
equipment as possible, and should be easily
accessible.
• Fully insert the prongs into the power outlet socket.
Loose connection may cause noise.
NOTE:
Please refer to “Safety Precautions, Maintenance &
Recommended Use” section of this manual for proper
selection of AC power cord.
2. Installing and removing the remote
control batteries
The remote control is powered by 1.5V AAA batteries.
To install or replace batteries:
How to install the batteries
1. Unlock and pull up the cover in the arrow’s direction.
2. Align the batteries according to the (+) and (–) indications
inside the case.
3. Replace the cover.
How to remove the batteries
1. Unlock and pull up the cover in the arrow’s direction.
2. Remove the batteries.
CAUTION:
Incorrect use of batteries can result in leaks or bursting.
Be careful especially about the following points.
English-10
Clamper
Use the clamper
to secure the
cable firmly.
5. Switch on the power of all the
attached external equipment
When connected with a computer, switch on the power of the
computer fi rst.
6.
Operate the attached external equipment
Display the signal on the external equipment you wish.
7. Adjust the sound
Make adjustments lowering or rising the volume as required.
8. Adjust the screen (See pages 24-34)
Make adjustments to the display position or settings if required.
9. Adjust the image (See page 24-34)
Make adjustments to brightness or contrast if required.
10. Recommended Adjustment
To reduce the risk of “image persistence”, please adjust
the following items based on the application being used.
“POWER SAVE” (See page 28), “SCREEN SAVER” (See
page 28), “SIDE BORDER COLOR”(See page 28), “DATE
AND TIME” (See page 31), “SCHEDULE”(See page 31).
11. Installing and removing the stands
The stands are prepared as option.
Refer to the user’s manual of the stand for more information.
How to install the stands
1. Please turn monitor off.
2. Fasten screws
NOTE:
Install the stands so that their longer portions come to the
front.
How to remove the stands
1. Spread the protective sheet on the fl at surface, such as a
desk.
2. Place monitor on the protective sheet.
3. Remove screws with a screwdriver and place them in a
safe place for reuse.
on both sides of the monitor.
12. Connecting HDMI cable
Clamper
English
Stands
(Longer portioncomes
to the front.)
Screws
Use the clamper
to secure the
cable firmly.
English-11
13. When MDT521S is installed in portrait
position
Conditions
MDT521S can be installed in portrait position, under the following conditions:
Caution:
Portrait position is effective only when wall-mounted or
ceiling-mounted.
The stands(legs) can not be fi tted to the monitor in portrait
position.
Placing the monitor in portrait position, will shorten the average life of the LCD backlight.
Operational Environment (Temperature) shall be limited, as
shown below:
OperationalEnvironment:
Temperature 5 - 35 °C / 41 - 95 °F
Humidity 20 - 80 % (without condensation)
Please orientate the monitor in the direction shown below:
Do not place monitor in landscape in any other manner.
Optional speakers (SP-521S) can not be attached when this
LCD monitor is installed in portrait position.
How to set-up
The “
facing the monitor.
” logo should be on the LEFT side when
Landscape
CAT5 video connection
The CAT5 video connection function is for transmitting the
analog RGB video signal of the computer and the control
signal of the monitor over a long distance using CAT5 cables.
The computer can control the monitor via the supplied CAT5
Tx BOX.
Caution:
Never connect network devices (such as a hub and a computer for LAN) to the CAT5 Tx BOX and the IN and OUT connectors of the monitor. If they are connected, the network devices
themselves, CAT5 Tx BOX, and monitor may be damaged.
1. Installation of the USB driver for CAT5
serial communication control
To connect the computer and the CAT5 Tx BOX via USB interface, it is necessary to install the USB driver to the computer
from the CD-ROM supplied with the monitor.
(When connecting the computer and the CAT5 Tx BOX via
RS-232C interface, you don’t have to install the USB driver.)
OS supported: Windows XP, Windows Vista
How to install:
1) Installation to Windows XP
Start the “PL2303-Driver_XP2K_v
Windows XP folder on the CD-ROM supplied with the monitor
and install the driver according to the instructions displayed
on the screen.
2) Installation to Windows Vista
Start the “PL2303_Prolifi c_Vista_
Windows VISTA folder on the CD-ROM supplied with the
monitor and install the driver according to the instructions
displayed on the screen.
******
®
******
®
.exe” fi le in the
.exe” fi le in the
90°
MDT521S
CounterclockwiseClockwise
2. Connection of the CAT5 video connec-
90°
MDT521S
English-12
tion function
There are two cases of connection.
1) Connection to one monitor
USB cable
Computer
CAT5 cable
CAT5Tx BOX
(supplied)
Monitor
VGA (mini D-SUB 15-pin) cable (supplied)
1. Connect the USB connector of the supplied CAT5 Tx BOX
and that of the computer using a commercially available
USB cable. (When the USB driver isn’t available, connect
an RS-232C cable in addition to the USB cable. In this
case, the RS-232C cable serves for supplying the power
to the CAT5 Tx BOX.) See page 35.
2. Connect the D-SUB input connector of the CAT5 Tx BOX
and the VGA (D-SUB) output connector of the computer
using the signal cable (mini D-SUB 15-pin cable) supplied
with the monitor.
3. Connect the modular connector of the CAT5 Tx BOX and
the CAT5 (RGB5) IN connector of the monitor using a
commercially available CAT5 cable.
2) Connection to multiple monitors
USB cable
Computer
CAT5 cable
CAT5Tx BOX
(supplied)
Monitor
VGA (mini D-SUB 15-pin)
cable (supplied)
Monitor
CAT5 cable
…
1. In addition to the connection made step 1) above, connect the CAT5 OUT connector of the fi rst monitor and the
CAT5 (RGB5) IN connector of the second monitor using a
commercially available CAT5 cable.
2. Connect the third and later monitors in the same way.
You can connect up to 5 monitors.
2) CAT5 EQ
Make adjustment so that blur and smear of the displayed letters and graphic objects are minimized.
3) CAT5 R-GAIN/G-GAIN/B-GAIN
When the displayed image is dark, increase each value.
When whites aren’t displayed as intended, adjust the R-GAIN
and B-GAIN values.
4) CAT5 R-SKEW/G-SKEW/B-SKEW
Adjust each value so that the color deviation in the displayed
letters and graphic objects is minimized.
English
Allowable cable length
Connection Max. cable length/signal timing
One monitor 150 m / 1920 x 1080 @60 Hz
Multiple moni-
tors
The lengths given above are based on the actual measurements using our standard signal source and the recommended cable as follows. Before installation, check the monitor
operation in advance by connecting it with your computer and
cables.
Recommended cable:
8-pin modular connector, straight-through, shielded, Category
5 or 5e
200 m / 1920 x 1080 @60 Hz
(Total length of the connected cables)
3. Various settings involved in the CAT5
video connection
In the case of the CAT5 video connection, confi gure the fol-
lowing settings displayed on the OSD screen. (See page 29.)
1) CAT5 CABLE LENGTH
Select the cable length, and the defaults of all the adjustment
values are automatically determined.
Select the length that is closest to the actual length of your
cable.
English-13
How to Mount and Attach Options to the LCD Monitor
You can attach mounting accessories to the LCD monitor in
one of the following two ways:
1. In the upright position
2. Lay the screen face down
Lay the protective sheet on a table, which was wrapped
around the monitor when it was packaged, beneath the
screen surface so as not to scratch the screen face.
This device cannot be used or installed without the Tabletop
Stand or other mounting accessory. Failure to follow correct
mounting procedures could result in damage to the equipment or injury to the user or installer. Product warranty does
not cover damage caused by improper installation.
Failure to follow these recommendations could result in void-
ing your warranty.
Use M8 screws (having a length 15 mm longer than the thick-
ness of the mounting bracket) and tighten them securely.
Prevent the screws from loosening using spring washers,
etc. MITSUBISHI ELECTRIC recommends using mounting
interface that comply with TÜV-GS and/or UL1678 standard
in North America.
601 601
200 200
3. Ventilation Requirements for enclosure
mounting
To allow heat to disperse, leave space between surrounding
objects as shown in the diagram below.
4. To avoid monitor from falling
When installing the monitor using the tabletop stands (optional), take measures to prevent the monitor from falling over
in case of an earthquake or other disaster to lessen the probability of injury and damage resulting from fall.
As shown in the fi gure, secure the monitor to a solid wall or
pillar using rope (commercially available) strong enough to
bear the weight of the monitor. (MDT521S: approx. 44 kg (with
the optional stands))
When you use screw hooks (commercially available), ring
screw hooks, not C-shaped screw hooks (with opening), are
recommended.
400 mm
Screw Holes
Screw hook, etc.
commercially available
349349
200200
(mm)
Table Handles Protective sheet
Caution:
For preventing the monitor from falling.
• Install the monitor with metal brackets for wall or ceiling
installation (commercially available) on your own responsibility. For detailed procedures of installation, refer to the
instructions of the metal brackets.
• To lessen the probability of injury and damage resulting
from fall of the monitor in case of earthquake or other
disaster, be sure to consult the bracket manufacturer for
installation location.
• To lessen the risk of falling of the monitor, thread commercially available rope through the handles at the right and
left of the monitor and secure the rope to the wall mount
brackets or ceiling mount brackets.
• Do not sleep where the monitor may topple over or fall in
case of an earthquake or other disaster.
Rope, etc.
commercially available
Clamper
Caution:
• The effectiveness of preventing from falling substantially
depends on the strength of brackets and base to which
prevention device from falling is attached. When you
cannot ensure suffi cient strength, provide adequate
reinforcement.
• Though the recommended prevention from falling is
intended to lessen the probability of injury and damage, it
doesn’t assure its effectiveness against any kind of
earthquake or disaster.
• Do not sleep where the monitor may topple over or fall in
case of an earthquake or other disaster.
• Before moving the monitor, remove the rope that is
securing the monitor. Failure to do so may result in injury
or breakdown of the monitor.
Screw
English-14
Connections
Before making connections:
* First turn off the power of all the attached equipment and make connections.
* Refer to the user manual included with each separate piece of equipment.
Wiring Diagram
English
Monitor
Personal
computer
(analog RGB)
Personal
computer
(DVI-D)
DVD player
(HDMI)
LCD monitor (second monitor)
Stereo amplifier
VCR
(RCA)
External speaker
English-15
Connecting a Personal Computer
Connecting your computer to your LCD monitor will enable you to display your computer's screen image.
Some video cards may not display an image correctly.
Connect the LCD Monitor to a Personal Computer
• To connect the RGB 3 IN connector (mini D-sub 15 pin) on the LCD monitor, use the supplied PC - Video RGB signal cable (mini
D-sub 15 pin to mini D-sub 15 pin).
Select RGB 3 from the INPUT button on the LCD monitor or D-SUB button on the remote control.
• To connect the RGB 4 IN connector (BNC) on the LCD monitor, use a signal cable which is available separately (mini D-sub
15 pin to BNC x 5).
Select RGB 4 from the INPUT button on the LCD monitor or BNC button on the remote control.
• When connecting one or more LCD monitors, use the RGB OUT connector (mini D-sub 15 pin).
• The AUDIO IN 1, 2, 3 can be used for audio input. For connection, select AUDIO 1, 2, 3 from the AUDIO INPUT button.
• The AUDIO OUT jack outputs sound from the selected Audio input.
BNC x 5
Monitor
Mini D-sub 15 pin
PC or IBM compatible
To RGB output
Mini D-sub 15 pin
To audio output
Mini D-sub 15 pin
RCA
LCD monitor (second monitor)
RCA
Mini D-sub 15 pin
English-16
Connecting with Digital Interface Equipment
Connections can be made with equipment that is equipped with a digital interface compliant with the DVI (Digital Visual
Interface) standard.
Connect the LCD Monitor to a Computer with a Digital Output
• To connect the RGB 2 IN connector (DVI-D) on the LCD monitor, use a DVI-D cable.
Select RGB 2 from the INPUT button on the LCD monitor or DVI-D button on the remote control.
Select the “DVI INPUT MODE” to “DVI-PC“. (See page 31)
• To connect the RGB 1 IN connector (HDMI) on the LCD monitor, use a HDMI cable.
Select RGB 1 from the INPUT button on the LCD monitor or HDMI button on the remote control.
Select the “HDMI INPUT MODE” to “HDMI-PC“. (See page 31)
• The AUDIO IN 1, 2, 3 or HDMI can be used for audio input. For connection, select AUDIO 1, 2, 3 or HDMI from the AUDIO
INPUT button. You can select HDMI only when RGB 1 or 2 is selected.
• The signal input from DVI-D and HDMI connector cannot be output to the RGB OUT connector.
English
Monitor
DVI-D
HDMI
PC or IBM compatible
To RGB output
DVI-D
To audio output
PC or IBM compatible
To audio output
HDMI
To RGB output
English-17
Connecting a DVD Player with component out / HDMI out / DVI out
Connecting your DVD player to your LCD monitor will enable you to display DVD video.
Refer to your DVD player owner’s manual for more information.
Connect the LCD Monitor to a DVD Player
• To connect the DVD/HD IN connector (BNC) on the LCD monitor, use a separately available BNC connector cable. You will
need a BNC-to-RCA adapter to connect a DVD player with an RCA pin jack to the BNC connector cable (not provided).
Select DVD-HD from the INPUT button on the LCD monitor or YPbPr button on the remote control.
• To connect the RGB 1 IN connector (HDMI) on the LCD monitor, use a HDMI cable.
Select RGB 1 from the INPUT button on the LCD monitor or HDMI button on the remote control.
Select the “HDMI INPUT MODE” to “HDMI-HD“. (See page 31)
• To connect the RGB 2 IN connector (DVI-D) on the LCD monitor, use a DVI-D cable.
Select RGB 2 from the INPUT button on the LCD monitor or DVI-D button on the remote control.
Select the “DVI INPUT MODE” to “DVI-HD“. (See page 31)
• The AUDIO IN 1, 2, 3 or HDMI can be used for audio input. For connection, select AUDIO 1, 2, 3 or HDMI from the AUDIO
INPUT button. You can select HDMI only when RGB 1 or 2 is selected.
BNC x 3
Monitor
DVI-D or DVI-I
DVI-D
BNC x 3
HDMI
To video output
BNC-RCA
adapter
RCA
DVD Player
To audio outputLTo audio output
R
RCA
DVD PlayerDVD Player
HDMI
To HDMI outputTo DVI-D or DVI-I output
English-18
Connecting to a VCR / Stereo Amplifi er
You can connect your VCR / stereo amplifi er to your LCD monitor. Refer to your VCR / stereo amplifi er owner's manual for more
information.
Connect the LCD Monitor to a VCR / Stereo Amplifi er
• To connect the VIDEO IN connector (RCA, BNC or S-VIDEO) on the LCD monitor, use a video cable or S-video cable. Use a
separately available RCA cable or S-video cable.
To connect the AUDIO IN connector (RCA) on the LCD monitor, use an RCA cable.
When connect the RCA or BNC connector, select VIDEO from the INPUT button on the LCD monitor or VIDEO button on the
remote control.
When connect the S-VIDEO connector, select VIDEO<S> from the INPUT button on the LCD monitor or VIDEO(S) button on
the remote control.
• Turn on the LCD monitor and the amplifi er only after all connections have been made.
• Use an RCA cable to connect the AUDIO OUT connector (RCA) on the LCD monitor and the audio input on the amplifi er.
• Do not reverse the audio left and right jacks.
• The AUDIO IN 2 and 3 (both RCA) can be used for audio input. For connection, select [AUDIO1], [AUDIO2], [AUDIO3] from
the AUDIO INPUT button.
• The AUDIO OUT jack outputs sound from the selected Audio input.
English
BNC
RCA
Monitor
LCD monitor (second monitor)
BNC
VCR
To video output
RCA
To audio outputLTo audio output
R
RCA
RCA
RCA
RCA
To audio inputLTo audio input
R
Stereo amplifier
English-19
External
speaker
Basic Operation
Power ON and OFF Modes
The LCD monitor power indicator will turn green while powered on or red in off mode. The monitor can be powered on or off
using the following three options:
1. Pressing the Main Power Switch.
NOTE:
When the Main Power Switch is used to power off the
LCD monitor, the remote control and the power button will
not activate the on mode and both green and red power
indicator turn off. Be sure to turn the Main Power Switch
to the on mode before using these two options.
ON
OFF
2. Pressing the power button.
EXITMUTE INPUT
NOTE:
Before pressing the power button, be sure to turn on the
Main Power button on the LCD monitor.
Power indicator
3. Using the remote control.
NOTE:
Before operating the remote control, be sure to turn on
the Main Power Switch on the LCD monitor.
English-20
Power Indicator
O
Status
Power ON Green
Power OFF Red
Power Standby when
“SCHEDULE” is enable
Power Standby Red, Green
Diagnosis
(Detecting failure)
Red On
Green Blinking
Red Blinking
See troubleshooting on
*
page 38
Using Power Management
The LCD monitor follows the VESA approved DPM Power
Management function.
The power management function is an energy saving
function that automatically reduces the power consumption
of the display when the keyboard or the mouse has not been
used for a fi xed period.
The power management feature on your new display has
been set to the “ON” mode. This allows your display to enter
a Power Saving Mode when no signal is applied. This could
potentially increase the life and decrease the power
consumption of the display.
Selecting a video source
To view a video source:
Use the input button to set [VIDEO].
Use the COLOR SYSTEM menu to set [AUTO], [NTSC],
[PAL], [SECAM], [PAL60], [4.43NTSC], according to your
video format.
Picture Size
RGB 1, 2, 3, 4, 5
DVD/HD, VIDEO<S>,
VIDEO
Signal Type
FULL NORMAL CUSTOM
REAL
FULL NORMAL DYNAMIC
CUSTOMREAL
NORMAL SIZE Recommended Size
NORMAL
NORMAL: Display by the inputed signal aspect ratio by PC
signal, or display in 4:3 aspect ratio at DVD/HD or VIDEO
signal.
FULL: Display in entire screen.
DYNAMIC: Expand 4:3 pictures to the entire screen with
non-linearity. (Some round image will be cut by expansion.)
CUSTOM (ZOOM): Image can be expanded beyond the
active display area. The image which is outside of active diaplay area is not displayed.
REAL: Image will be displayed 1 by 1 pixel.
ZOOM
ZOOM
Picture Mode
RGB 1, 2, 3, 4, 5
DVD/HD, VIDEO<S>,
VIDE
HIGHBRIGHT
HIGHBRIGHT
STANDARD
STANDARD
sRGB
CINEMA
Audio Source Switching
You can switch the audio source using the AUDIO INPUT
button.
RGB 1, 2
Other than
RGB 1, 2
HDMI
AUDIO1
AUDIO1 AUDIO2 AUDIO3
AUDIO2 AUDIO3
Control Lock Mode
This function disables the operation buttons so that the adjustments you make are not changed when they are pressed.
To disable the buttons, press and hold down the
buttons together for at least 3 seconds.
To enable the buttons, press and hold down the
buttons together for at least 3 seconds again.
and
and
English
4:3
Squeeze
DYNAMIC
FULL
English-21
Information OSD
RGB1, 2, 3, 4, 5
RGB3
1024 x 768
48kHz 60Hz
AUDIO : 1
SIZE : FULL
DVD/HD
DVD/HD
AUDIO : 3
SIZE : FULL
VIDEO<S>, VIDEO
VIDEO<S>
NTSC
AUDIO : 3
SIZE : NORMAL
)
Video Input mode
Input signal Information
Audio input mode
Picture Size mode
Video Input mode
Audio input mode
Picture Size mode
Video Input mode
Input Signal Colour System mode
Audio input mode
Picture Size mode
PIP or POP
Main:RGB3
Sub:VIDEO<S>
RGB3
1024 x 768
48kHz 60Hz
AUDIO : 1
VIDEO<S>
NTSC
SIZE : FULL
Main picture Information
Sub picture Information
)
Main picture Information
English-22
OSD (On-Screen-Display) Controls
Remote Control
Control Panel
OSD screen
Press MENU button to
open Main menu. Press
UP or DOWN button to
select sub-menu.
Press EXIT button to
open Main menu.
Press UP or DOWN
button to select.
Press SET button
to decide.
Press INPUT button
to decide
Press UP or DOWN, and PLUS or
MINUS button to select function,
or control which you like.
Press SET button to decide.
Press UP or DOWN, and
PLUS or MINUS button to
select function, or control
which you like. Press INPUT
button to decide
Press MENU or
EXIT button to exit.
English
Press EXIT button
to exit.
English-23
Main-Menu
BRIGHTNESS
Adjusts the overall image and background screen brightness.
Press + button to increase brightness.
Press - button to decrease brightness.
CONTRAST
Adjusts the image brightness in relation to the input signal.
Press + button to increase contrast.
Press - button to decrease contrast.
SHARPNESS
This function is digitally capable to keep crisp image at any timings.
It is adjustable to get a distinct image or a soft one as you prefer and set independently for each picture mode.
Press + button to increase sharpness.
Press - button to decrease sharpness.
BLACK LEVEL
Adjusts the image brightness in relation to thebackground.
Press + button to increase black level.
Press - button to decrease black level.
NOTE: sRGB picture mode is standard and cannot be changed.
NOISE REDUCTION * :
Adjusts the noise reduction level.
Press + button to increase reduction level.
Press - button to decrease reduction level.
INPUT RGB1 (HDMI INPUT MODE: HDMI-HD), RGB2 (DVI INPUT MODE: DVI-HD), DVD/HD, VIDEO<S>, VIDEO only
TINT * : INPUT RGB1 (HDMI INPUT MODE: HDMI-HD), RGB2 (DVI INPUT MODE: DVI-HD), DVD/HD, VIDEO<S>, VIDEO only
Adjust the tint of all color, or red, magenta, blue, cyan, green, and yellow individually.
Press + button the flesh tone color becomes greenish.
Press - button the flesh tone color becomes purplish.
COLOR * : INPUT RGB1 (HDMI INPUT MODE: HDMI-HD), RGB2 (DVI INPUT MODE: DVI-HD), DVD/HD, VIDEO<S>, VIDEO only
Adjust the color saturation of all color, or of red, magenta, blue, cyan, green, and yellow individually.
Press + button to increase color depth.
Press - button to decrease color depth.
COLOR TEMPERATURE
Use to adjust the color temperature.
The image becomes reddish as the color temperature decreases, and it becomes bluish as the color temperature increases.
COLOR CONTROL
The color levels of red, green, and blue are adjusted by the color bars.
R: Red, G: Green, B: Blue
GAMMA SELECTION
Selects a display gamma.
2.2, 2.4, OPTION, S gamma, Native
NOTE: sRGB picture mode is standard and cannot be changed.
English-24
AUTO BRIGHTNESS
This function controls the screen brightness depending on the ambient light for easy viewing.
In addition, it changes the screen brightness depending on the ambient light and what are displayed on the screen to
reduce power consumption as low as possible.
[AUTO BRIGHTNESS]
LOCAL: The auto brightness function is enabled.
REMOTE: The auto brightness function is enabled. Select this setting to receive data for communication control from other
device or monitor when multiple monitors are controlled collectively.
OFF: This function is disabled.
[CONTROL]
PRIMARY: Select this setting to configure the monitor as Master when controlling multiple monitors collectively.
SECONDARY: Select this setting to use the monitor alone or to configure the monitor as Slave when controlling multiple
monitors collectively.
[LIGHT FROM BACK]
YES: Select this setting when there is a light source such lighting equipment and a window behind the monitor.
NO: Select this setting when there is no light source such lighting equipment and a window behind the monitor.
[BACK WALL]
Select the following settings according to the distance between the rear of the monitor and the wall or window.
FAR: The distance is 5 meters or longer.
NEAR: The distance is 5 meters or shorter.
[FRONT SENSOR]
Select ON for normal use.
OFF: Select this setting when the sensor on the front panel is shielded.
[REAR SENSOR]
Select ON for normal use.
OFF: Select this setting when the sensor on the rear panel is shielded.
English
[SATURATION]
ON: The image saturation is adjusted depending on the ambient light.
OFF: Image saturation isn't adjusted.
[VIDEO DETECT]
ON: The screen brightness varies depending on what are displayed on the screen to reduce power consumption of the
monitor.
OFF: The screen brightness doesn’t vary and the power consumption isn’t reduced.
PICTURE RESET
Selecting Picture reset allows you to reset all OSD settings about PICTURE setting.
Select “Yes” and press “SET” button to restore to factory preset data.
Press “EXIT” button to cancel and then return to the previous menu.
English-25
Main-Menu
SCREEN
H POSITION
Controls Horizontal Image position within the display area of the LCD.
Press + button to move screen to right.
Press - button to move screen to left.
V POSITION
Controls Vertical Image position within the display area of the LCD.
Press + button to move screen to UP.
Press - button to move screen to DOWN.
CLOCK * : INPUT RGB3, 4, 5 only
Press + button to expand the width of the image on the screen the right.
Press - button to narrow the width of the image on the screen the left.
CLOCK PHASE * : INPUT RGB3, 4, 5 only
Improves focus, clarity and image stability by increasing or decreasing this setting.
ZOOM MODE
You can select “FULL”, “NORMAL” and “CUSTOM” and “REAL”. (INPUT RGB1, 2, 3, 4, 5 only) You can also select “FULL”,
“NORMAL” “DYNAMIC” and “CUSTOM” and “REAL”. (INPUT DVD/HD, VIDEO<S>, VIDEO only)
Selecting “DYNAMIC” will make the screen display panoramic with the expansion of the middle and outside of the screen
changed. (The upper and the bottom of the image will be cut by expansion.)
Dynamic image is the same as FULL size image when HDTV signal is input.
Selecting “REAL” image will be displayed 1 by 1 pixel.
CUSTOM ZOOM
“CUSTOM ZOOM” will be selected when you select “CUSTOM” on the screen “ZOOM” mode.
ZOOM: expands the horizontal and the vertical size simultaneously.
HZOOM: expands the horizontal size only.
VZOOM: expands the vertical size only.
H POSITION: moves to the right with + button. moves to the left with – button.
V POSITION: moves up with + button. moves down with – button.
H RESOLUTION * : INPUT RGB1, 2, 3, 4, 5 only
Adjusts the horizontal size by increasing or decreasing the setting.
Press + button to expand the width of the image on the screen.
Press - button to narrow the width of the image on the screen.
V RESOLUTION * : INPUT RGB1, 2, 3, 4, 5 only
Adjusts the vertical size by increasing or decreasing the setting.
Press + button to expand the height of the image on the screen.
Press - button to narrow the height of the image on the screen.
ROTATION
The OSD screen is rotated.
OFF H FLIP V FLIP
SCREEN RESET
Selecting Screen reset allows you to reset all OSD settings from PICTURE setting.
Select “Yes” and press “SET” button to restore the factory preset data.
Press “EXIT” button to cancel and then return to the previous menu.
Horizontally rotated Vertically rotated
English-26
Main-Menu
AUDIO
BALANCE
Adjust the balance of L/R volume.
Press + button to move the stereo sound image to right.
Sound of the left side will be small.
Press - button to move the stereo sound image to left.
TREBLE
To accentuate or reduce the high frequency sound.
Press + button to increase TREBLE sound.
Press - button to decrease TREBLE sound.
BASS
To accentuate or reduce the low frequency sound.
Press + button to increase BASS sound.
Press - button to decrease BASS sound.
AUDIO RESET
Selecting Audio reset allows you to reset all OSD settings from AUDIO setting.
Select “YES” and press “SET” button to restore the factory preset.
Press “EXIT” button to cancel and then return to the previous menu.
English
Main-Menu
PIP (PICTURE IN PICTURE)
Note: The “PIP” and “POP” modes do not function when the screen size is “CUSTOM” or “REAL”.
PIP SIZE
Selecting the size of picture inserted at the “Picture-in-Picture” (PIP) mode.
“Large”, “Middle” and “Small” are available.
PIP AUDIO
Selecting the sound source in PIP mode.
When selecting “MAIN AUDIO”, you will get the sound for the main picture and when selecting “PIP AUDIO”,
you will get the sound for the picture instead.
PIP RESET
Selecting PIP Reset allows you to reset all OSD settings from PIP setting.
Select “Yes” and press “SET” button to restore the factory preset data.
Press “EXIT” button to cancel and then return to the previous menu.
English-27
Main-Menu
CONFIGURATION 1
AUTO SETUP * : INPUT RGB3, 4, 5 only
Press “SET” button to automatically adjust screen size, horizontal position, vertical position, clock, clock phase,
white level and black level.
Press “EXIT” button to cancel execution AUTO SETUP and then will return to the previous menu.
AUTO ADJUST * : INPUT RGB3, 4, 5 only
Selecting the auto adjust ON/OFF.
Selecting ON when changing the timing, the horizontal position, vertical position and clock-phase will adjust automatically.
POWER SAVE
Selecting RGB “ON”, the monitor will go to power management mode when RGB1, 2, 3, 4, 5 sync is lost.
Selecting VIDEO “ON”, the monitor will go to power management mode after about 10 minutes delay from when DVD/HD,
VIDEO<S> and VIDEO input signal is lost.
LANGUAGE
OSD control menus are available in eight languages.
(English, German, Spanish, French, Italian, Swedish, Chinese and Japanese)
SCREEN SAVER
Select “SCREEN SAVER” functions to reduce the risk of the “image persistence”.
GAMMA: The display gamma is changed and fixed when selected “ON”.
COOLING FAN: The built in cooling fan is always on when set “ON”. When “AUTO” is selected, the built-in cooling fan starts
rotating automatically when the internal temperature exceeds the operation guarantee range.
BRIGHTNESS: The brightness is decreased when selected “ON”.
MOTION: Image is slightly expanded and moves 4 directions (UP, DOWN, RIGHT, LEFT) periodically
(Need setting the time for movement).
Movement area is approximately +/- 10mm from original position;
Please locate the important information such as text within 90% area of screen image.
See note (1) for this functions.
PIP and STILL will be disabled when “MOTION” is active.
COLOR SYSTEM * : INPUT VIDEO<S>, VIDEO only
Selecting the Color System depends on your input video format.
AUTO: NTSC, PAL, SECAM, PAL60 or 4.43 NTSC is automatically selected.
NTSC: Specific selection of NTSC.
PAL: Specific selection of PAL.
SECAM: Specific selection of SECAM.
PAL-60: Specific selection of PAL60.
4.43NTSC: Specific selection of 4.43 NTSC.
SIDE BORDER COLOR
Use to adjust the brightness of the black areas displayed on both sides of 4:3 image.
OFF, 50, and 100 are selectable.
CONFIGURATION RESET
Selecting the CONFIGURATION RESET allows you to reset all configuration settings.
Select “Yes” and press “SET” button to restore the factory preset data.
Press “EXIT” button to cancel and return the previous menu.
FACTORY RESET
Selecting “YES” allows you to reset PICTURE, SCREEN, AUDIO, CONFIGURATION1,2 and ADVANCED OPTION will be back
to factory settings (except LANGUAGE, DATE AND TIME, HDMI INPUT MODE, DVI INPUT MODE, DDC/CI, MONITOR ID and
SCHEDULE).
Select “YES” and press “SET” button to restore the factory preset data. Press “EXIT” button to cancel and return the
previous menu.
English-28
Main-Menu
CONFIGURATION 2
CAT5 CABLE LENGTH
[CAT5 CABLE LENGTH]
Select the cable length, and the defaults of all the adjustment values are automatically determined.
Select the length that is closest to the actual length of your cable.
[CAT5 EQ]
Make adjustment so that blur and smear of the displayed letters and graphic objects are minimized.
[CAT5 R-GAIN, G-GAIN, B-GAIN]
When the displayed image is dark, increase each value.
When whites aren't displayed as intended, adjust the R-GAIN and B-GAIN values.
[CAT5 R-SKEW, G-SKEW, B-SKEW]
Adjust each value so that the color deviation in the displayed letters and graphic objects is minimized.
SERIAL CONTROL
Select the communication interface (RS232 or RS485) for the serial communication function.
For connection of the signal cable, see page 35.
English
RS485 TERMINATION
Turn ON or OFF the termination resistance of the RS-485 interface.
ON: Select this setting to use the monitor alone or to configure the monitor as the one at the end of the connection when more
than one monitor is multi-connected.
OFF: Select this setting to configure the monitor as other than the one at the end of the connection when more than one
monitor is multi-connected.
OSD TURN OFF
The OSD control menu will stay on as long as it is use. In the OSD Turn Off submenu, you can select how long the monitor
waits after the last touch of a button to shut off the OSD control menu.
The preset choices are 5 -120 seconds.
INFORMATION OSD
Selects the information OSD display or not.
The information OSD will display when input signal or source change or warning message like as no-signal or out-of range.
A time between 1 to 10 seconds is available.
OFF TIMER
To select OFF TIMER mode ON/OFF.
In the OFF TIMER menu, you can preset the monitor to automatically power down.
A time between 1 to 24 hours is available.
When the OFF TIMER is set, the SCHEDULE (see page 31) settings will be disabled.
OSD H POSITION
Adjusts the horizontal position of the OSD menu.
OSD V POSITION
Adjusts the vertical position of the OSD menu.
MONITOR INFORMATION
Indicates the model and serial number of your monitor.
English-29
Main-Menu
ADVANCED OPTION
INPUT RESOLUTION * : INPUT RGB3, 4, 5 only
Selects to decision of input signal about below timings, 1024x768, 1280x768 and 1360x768.
AUTO: Determines the resolution automatically.
1024x768: Determines the resolution as 1024x768
1280x768: Determines the resolution as 1280x768
1360x768: Determines the resolution as 1360x768
The setting you select becomes effective when POWER is turned OFF and ON again.
BLACK LEVEL EXPANSION
Selects a level of black expansion from “OFF”, “MIDDLE” and “HIGH.”
In case of go under the black cut-off level, please adjust the “Black level” in moderation on OSD menu.
* : INPUT RGB1 (HDMI INPUT MODE: HDMI-HD), RGB2 (DVI INPUT MODE: DVI-HD), DVD/HD, VIDEO<S>, VIDEO only
SCAN MODE * : INPUT RGB1 (HDMI INPUT MODE: HDMI-HD), RGB2 (DVI INPUT MODE: DVI-HD), DVD/HD, VIDEO<S>, VIDEO only
Changes the display area of the image.
OVERSCAN: Set to display area about 95%
UNDERSCAN: Set to display area about 100%
SCAN CONVERSION
Selects IP (Interlace to Progressive) converter function.
PROGRESSIVE: Enable the IP function, to convert interlace signal to progressive. Normally use this setting.
INTERLACE*: Disable the IP function.
*NOTE: This mode is better suited for motion pictures, but it increases chance of image retention.
* : INPUT RGB1 (HDMI INPUT MODE: HDMI-HD), RGB2 (DVI INPUT MODE: DVI-HD), DVD/HD, VIDEO<S>, VIDEO only
FILM MODE
Selects Film mode function.
AUTO: Enable the Film mode function. This mode is better suited for movies, which is converted 24 Frames/sec source
to DVD Video. We recommend to select “PROGRESSIVE” in “SCAN CONVERSION”.
OFF: Disable the Film mode function. This mode is better suited for Broadcasting or VCR source.
IR CONTROL
Selects the operation mode of the wireless remote controller when multiple MDT521S monitors are connected via RS-232C.
The item in this menu will become effective by pressing “SET” button on the selected item.
NORMAL: The monitor will be controlled normally by wireless remote controller.
PRIMARY: The first MDT521S monitor of those multi-connected via RS-232C is designated as PRIMARY.
SECONDARY: MDT521S monitors other than the first one multi-connected via RS-232C are designated as SECONDARY.
LOCK: Disable the monitor control by infrared wireless remote controller.
Keep pressing “DISPLAY” button during 5 sec or more, this setting will return to “NORMAL”.
TILING
TILING demonstrates multiple screens. This feature provides a single large screen using up to 25 monitors.
It will be able to divide up to 5 each H and V.
This requires you to feed the PC output into each of the monitors through a distributor.
H MONITORS: Select number of horizontal divide.
V MONITORS: Select number of vertical divide.
POSITION: Select a position to expand the screen.
FRAME COMP.: Works in tandem with TILING to compensate for the width of the tile bezels in order to accurately
display the image.
ENABLE: Select “YES”, the monitor will expand the selected position.
PIP and STILL will be disabled when “TILING” is activated.
English-30
HEAT STATUS
Information of status for COOLING FAN, BRIGHTNESS and TEMPERATURE.
COOLING FAN comes to run when inside temperature is over a guaranteed limit.
In this case warning is displayed on the screen.
POWER ON DELAY
Adjusts the delay time from “standby” to “power on” mode.
“POWER ON DELAY” time is selectable from 0-50 seconds.
DATE AND TIME
Adjusts the current date and time for internal clock.
You should set this function when you use “SCHEDULE”.
SCHEDULE
Programs the monitor's working schedule.
Schedule the power on and power off with hour and a day of the week. Also sets the input port.
This OSD can't remove except EXIT.
(see “HOW TO SETUP SCHEDULE” on page 32.)
HDMI INPUT MODE
Select “HDMI-PC” when PC or other computer equipment is connected via HDMI.
Select “HDMI-HD” when DVD player, which has HDMI output, is connected via HDMI.
DVI INPUT MODE
Select “DVI-PC” when PC or other computer equipment is connected via DVI-D.
Select “DVI-HD” when DVD player, which has HDMI output, is connected via DVI-D.
English
MONITOR ID
ID numbers for remote control are assigned to MDT521S monitors that are multi-connected via RS-232C.
ID numbers 1 to 26 are selectable.
DDC/CI
Use to turn ON or OFF the DDC/CI communication function. Select ON for normal use.
SYNC TYPE * : INPUT RGB3, 4 only
Select “0.3V” for 0.3 Composite Sync.
Select “TTL” for TTL Sync.
ADVANCED OPTION RESET
Selecting ADVANCED OPTION RESET allows you to reset all OSD settings from ADVANCED OPTION settings,
except for DATE AND TIME, SCHEDULE, HDMI INPUT MODE, DVI INPUT MODE, MONITOR ID, and DDC/CI.
Select “YES” and press “SET” button to restore the factory preset data.
Press “EXIT” button to cancel and then return the previous menu.
English-31
NOTE
< IMAGE PERSISTENCE >
Please be aware that LCD Technology may experience a phenomena known as Image Persistence. Image Persistence occurs
when residual or “ghost” image of a previous image remains visible on the screen. Unlike CRT monitors, LCD monitors’
image persistence is not permanent, but constant images being displayed for a long period of time should be avoided.
To alleviate image persistence, turn off the monitor for as long as the previous image was displayed. For example, if an
image was on the monitor for one hour and a residual image remains, the monitor should be turned off for one hour to erase
the image.
As with all personal display devices, MITSUBISHI ELECTRIC recommends displaying moving images and using a moving
screen saver at regular intervals whenever the screen is idle or turning off the monitor when not in use.
Please set “POWER SAVE”, “SCREEN SAVER”, “DATE AND TIME” and “SCHEDULE” functions to further reduce the risk of
Image persistence.
< For long life use of Public Display >
Image Sticking of LCD Panel
When LCD panel is operated continuously for long hours, a trace of electric charge remains near the electrode inside LCD, and
residual or “ghost” image of previous image may be observed. (Image Persistence)
Image Persistence is not permanent, but when fi xed image is displayed for long period, ionic impurities inside LCD are
accumulated along the displayed image, and it is observed permanently. (Image Sticking)
Recommendations
For preventing the fast transition to Image Sticking, and for longer life usage of LCD, following are recommended.
1. Fixed image should not be displayed for long period, and changed to another images with short cycle.
2. When no use, please turn off the monitor by remote control, or use Power Management Function of monitor or use Schedule
Function of monitor.
3. Reducing the environmental temperature is effective for long life use.
When Protection board (glass, acryl) is installed over the LCD surface, enclosed into the box / wall, or stack the monitor,
please utilize the temperature sensors inside monitor.
To reduce the environmental temperature, the monitor should be set Low Brightness or Cooling Fan “ON” by using Screen
sever Function.
4. Please use "Screen Saver Mode" of monitor.
< HOW TO SETUP SCHEDULE >
Using the “SCHEDULE” function allows you to set up to seven different scheduled time intervals when the LCD Monitor will be
activated.
You can select the time the monitor turns on and turns off, the day of week the monitor is activated, and which input source the
monitor will use for each scheduled activation period. A check mark in the box next to the number of the schedule
indicates that the selected schedule is in effect.
To select which schedule to set, use the up/down arrows to move the number (1 to 7) of the schedule.
Use the (+) and (-) buttons to move the cursor horizontally within the particular schedule. Use the (
crease time and select input port. The “SET” button is used to make a selection.
If you create a schedule but do not want to use a power on time, select “--” in the “ON” time slot.
If you do not want to use a power off time select “--” in the OFF time slot.
If there is no input selected (“--” showing in the input spot) the input from the previous schedule will be used.
The selection of EVERY DAY within a schedule takes priority over other schedules that are set up to operate weekly.
When schedules are overlapping, scheduled Power ON time has priority over scheduled Power OFF time.
If there are two schedules programmed for the same time, then the highest numbered schedule has priority.
When the “OFF TIMER” (see page 29) is set, the “SCHEDULE” function is disabled.
) and ( ) buttons to in-
English-32
< PIP, POP and SIDE BY SIDE >
The following table shows the combination of signal inputs under which the “PIP” and “POP” modes function. These modes do
not function, however, when the screen size is “CUSTOM” or “REAL”.
MAIN
SUB
RGB1 (HDMI)
RGB2 (DVI-D)
RGB3 (D-SUB)
RGB4 (BNC)
RGB5 (CAT5)
DVD/HD (YPbPr)
VIDEO<S>
VIDEO
Press the “PIP ON/OFF” buttons on the remote control to change between “PIP”, “POP” and “SIDE BY
SIDE” mode as shown in the diagram below.
PIP POP OFF
“PIP”, “POP” mode resolution (Reference)
RGB1
(HDMI)
PIP SIZE
POP SIZE
RGB2
(DVI-D)
RGB3
(D-SUB)
SMALL
MIDDLE
LARGE
RGB4
(BNC)
SIDE BY SIDE
: 450 dots X 338 dots
: 675 dots X 450 dots
: 900 dots X 675 dots
: 450 dots X 338 dots
RGB5
(CAT5)
ASPECT
DVD/HD
(YPbPr)
SIDE BY SIDE
VIDEO<S>
FULL
VIDEO
: Supported
: Not supported
English
< Supplemental information of the auto brightness function >
To control multiple monitors collectively
In such a case where the tiling function is used, you can control the auto brightness function by sharing the detection result of
the brightness sensor of a certain monitor among the connected monitors.
1. Multi-connect the monitors using RS-232C or CAT5 cables as shown by the example below.
Monitor
ID = 9
(Slave)
Monitor
ID = 6
(Slave)
Monitor
ID = 3
(Slave)
2. Assign a monitor ID to each multi-connected MDT521S using MONITOR ID.
Monitor ID is selectable from 1 to 26.
The monitor ID of the Master monitor should be “1” and those of the Slave monitors should be other than “1”.
You are recommended to assign IDs to the monitors consecutively from 1, 2, 3, and on.
3. Set AUTO BRIGHTNESS on the OSD screen (PICTURE) as follows.
Master monitor
Slave monitors
Monitor
ID = 8
(Slave)
Monitor
ID = 5
(Slave)
Monitor
ID = 2
(Slave)
AUTO BRIGHTNESS CONTROL
LOCAL
REMOTE
Monitor
ID = 7
(Slave)
Monitor
ID = 4
(Slave)
Monitor
ID = 1
(Master)
SECONDARY
Master: Monitor configured as Master that detects
the outside light (Monitor ID is “1”.)
Slave: Monitor controlled by the Master monitor
(Monitor ID is other than “1”.)
PRIMARY
English-33
To use a computer to control the monitors
When using a computer to control the monitors, you must prepare an application software program for control by yourself.
1. Connect the RS-232C IN connector of the Master monitor shown above and the RS-232C connector of the computer using
an RS-232C cable.
Or, using a CAT5 cable, connect the RS-232C connector of the computer to the CAT5 IN connector of the Master monitor via
the CAT5-TX box.
2. Assign a monitor ID to each multi-connected MDT521S using MONITOR ID. (See step 2 above.)
3. Set AUTO BRIGHTNESS on the OSD screen (PICTURE) as follows.
AUTO BRIGHTNESS CONTROL
Master monitor
Slave monitors
REMOTE
REMOTE
SECONDARY
SECONDARY
or te se o ommniation ommans ontat or ealer
< Remote control numbering function >
B onnetin mltile MDTS monitors sin RSC ales o an ontr ol an one monitor or all te monitors one
remote ontroller
Assin aritrar ID nmer to ea o mltionnete MDTS monitors sin MONITOR ID
ID nmers to are seletale
It is reommene to assin se ential ID nmers rom an
Te remote ontrol moe o te rst MDTS monitor is set to RIMAR Y an tose o te oter monitors are set to
SECONDARY
en o iret te remote ontroller at te remote ontrol sinal sensor o te RIMARY monitor an r ess te DISLAY
tton on te remote ontroller te ID seletion OSD aears at te er let o te sreen
ID:1
ID No. :2
Diret te remote ontroller at te remote ontrol sinal sensor o te RIMARY monitor
OSD aears on te monitor avin te ID nmer o selete
ID number of the currently viewed monitor
Select the ID number of the monitor you want to control using the +/- button
on the remote controller.
The ID of the monitor you want to control is displayed at the upper left of its screen.
By selecting ALL, you can control all the multi-connected monitors.
NOTE:
en te ID seletion OSD is ein islae on te RIMAR Y monitor ress te DISLAY tton on te remote ontroller
aain to anel te ID seletion OSD an ten ontrol te monitor o selete
NOTE:
I o set te remote ontrol moe ronl an remote ontrol oer ation eomes navailale ress an tton on te ontrol
anel o te monitor to isla te OSD sr een an ane te remote ontrol moe sin AD ANCED OTION B ressin
an olin on te DIS LAY tton on te remote ontrol or seons or loner te remote ontrol moe is initialie to
NORMAL
English-34
Controlling the LCD monitor via RS-232C/RS-485 Remote Control
This LCD monitor can be controlled by the computer connected by an RS-232C cable or a CAT5 cable via the supplied CAT5 Tx
BOX.
Functions that can be controlled by a personal computer are:
• Power ON or OFF
• Switching between input signals
Connection
Connection by RS-232C (For RS-232C cable, the reverse type cable should be used.)
Monitor Monitor
English
PC
RS-232C cable RS-232C cable
Connection by CAT5 RS-485 (For CAT5 cable, the straight type cable should be used)
Type A Type B
USB cable
PC
RS-232C cable
This connection isn’t necessary when the USB COM port is used.
NOTE:
If your PC (IBM or IBM compatible) is equipped only with a 25-pin serial port connector, a 25-pin serial port adapter is required.
Contact your dealer for details.
1) Interface
PROTOCOL
BAUD RATE
DATA LENGTH
PARITY BIT
STOP BIT
FLOW CONTROL
This LCD monitor uses RXD, TXD and GND lines for RS-232C control.
To RS-232C
RS-232C/RS-485 (CAT5)
9600 [bps]
8 [bits]
NONE
1 [bits]
NONE
CAT5 Tx BOX
(supplied)
IN
To RS-232C OUTTo RS-232C IN To RS-232C OUTTo RS-232C IN
Monitor Monitor
To CAT5
OUT
CAT5 cable
To CAT5
RGB5 IN
To CAT5
OUT
CAT5 cable
To CAT5
RGB5 IN
To CAT5
OUT
2) Control command diagram
The command is structured by the address code, function code, data code and end code. The length of the command is
different for each function.
Address code
HEX
ASCII
[Address code] 30h 30h (In ASCII code, ‘0’ ‘0’) fi xed.
[Function code] A code of each fi xed control move.
[Data code] A code of each fi xed control data (number) and not always indicated.
[End code] 0Dh (In ASCII code, ‘
30h 30h
‘0’ ‘0’
Function code
Function
Function
Data code
Data
Data
‘ ) fi xed.
End code
0Dh
English-35
3) Control sequence
(1) The command from a computer to the LCD monitor will be sent in 600 ms.
(2) The LCD monitor will send a return command 600 ms* after it has received and encoded. If the command isn’t received
correctly, the LCD monitor will not send the return command.
(3) The personal computer checks the command and confi rms if the command, which has been sent, has been executed or
not.
(4) This LCD monitor sends various codes other than return code. When having a control sequence by RS-232C, reject other
codes from personal computers side.
* : The sending time of return command may delay depending on the condition (during changing of the input signal, etc.).
Example: Turn the power ON ( ’ ’ is for ASCII code)
Sending commands
from the PC
30 30 21 0D
’0’ ’0’ ’!’ ’ ’
4) Operation commands
The operation commands execute the basic operation setting of this LCD monitor.
It may not operate when changing the signal:
Operation ASCII HEX
POWER ON ! 21h
POWER OFF " 22h
INPUT RGB 1 _r1 5Fh 72h 31h
INPUT RGB 2 _r2 5Fh 72h 32h
INPUT RGB 3 _r3 5Fh 72h 33h
INPUT RGB 4 _r4 5Fh 72h 34h
INPUT RGB 5 _r5 5Fh 72h 35h
INPUT VIDEO _v1 5Fh 76h 31h
INPUT DVD/HD _v2 5Fh 76h 32h
INPUT S-VIDEO* _v3 5Fh 76h 33h
Status code from
LCD monitor
30 30 21 0D
’0’ ’0’ ’!’ ’ ’
Meaning
Command for
POWER ON
Command received
(Command echoed back)
• POWER OFF command should be operated over 1 minute after
the power is turned on.
• POWER ON command should be operated over 1 minute after
the power is turned off.
* S-VIDEO is SEPARATE only
5) Read command
Host computer sends the command without Data-code to monitor.
After receiving this command, the monitor returns the command with Data-code of current status to host computer.
Example: When Host computer ask Power status of monitor, the status of monitor is powered-on.
Command from computer
30 30 76 50 0D '0''0''v''P'[enter]
Structure of the Read-command
POWER
Input
Picture mode
Temperature
of internal
monitor
ON
OFF (stand by) 0 76 50 30
RGB-1 (HDMI) vI r1 76 49 72 31
RGB-2 (DVI-D) vI r2 76 49 72 32
RGB-3 (D-SUB) vI r3 76 49 72 33
RGB-4 (BNC)
RGB-5 (CAT5)
Video vI v1 76 49 76 31
DVD/HD vI v2 76 49 76 32
S-VIDEO vI v3 76 49 76 33
HIGHBRIGHT vM
STANDARD p2 76 4D 70 32
Around
Main board
Around
Power PCB
Command from Monitor
30 30 76 50 31 0D '0''0''v''P''1'[enter]
ASCII HEX
1 76 50 31
p1 76 4D 70 31
(ex.) +25
(ex.) +31
resolution
1 ˚C
resolution
1 ˚C
Function Data (Receive) Function Data (Receive)
vP
vP
vI r4 76 49 72 34
vI r5 76 49 72 35
vM
tc1
tc2
Detail of command
Ask about the power status of monitor
Monitor is powered-on.
74 63 31 2B 20 32 35
74 63 32 2B 20 33 31
English-36
Features
Reduced Footprint:
Provides the ideal solution for environments requiring superior image quality but with size and weight limitations.
The monitor’s small footprint and low weight allow it to be moved or transported easily from one location to another.
Color Control Systems:
Allows you to adjust the colors on your screen and customize the color accuracy of your monitor to a variety of
standards.
sRGB Color Control:
A new optimized color management standard which allows for color matching on computer displays and other
peripherals. The sRGB standard, which is based on a calibrated color space, allows for optimal color representation and
backward compatibility with other common color standards.
OSD (On-Screen-Display) Controls:
Allow you to quickly and easily adjust all elements of your screen image via simple to use on-screen menus.
Plug and Play:
The Microsoft
®
solution with the Windows
®
95/98/Me/2000/XP operating system and Windows Vista® facilitates setup and
installation by allowing the monitor to send its capabilities (such as screen size and resolutions supported) directly to your
computer, automatically optimizing display performance.
Intelligent Power Manager System:
Provides innovative power-saving methods that allow the monitor to shift to a lower power consumption level when on
but not in use, saving two-thirds of your monitor energy costs, reducing emissions and lowering the air conditioning costs
of the workplace.
Multiple Frequency Technology:
Automatically adjusts monitor to the display card’s scanning frequency, thus displaying the resolution required.
FullScan Capability:
Allows you to use the entire screen area in most resolutions, signifi cantly expanding image size.
English
Wall Mounting Interface:
Allows for the monitor to be mounted on a wall or an arm using any third party compliant device. MITSUBISHI ELECTRIC
recommends using mounting interface that comply with TÜV-GS and/or UL1678 standard in North America.
TILING, Frame compensation:
Demonstrates multiple screens with an accurate image and compensates for the bezel width.
ZOOM:
Expands the image individually for horizontal and vertical direction.
Self-diagnosis:
When an internal error should occur, a failure state will be indicated.
CAT5 Long Cable Compensation:
CAT5 long cable compensation prevents image quality degradation (color shift and dull signals) caused by long cable
lengths.
English-37
Troubleshooting
No picture
• The signal cable should be completely connected to the display card/computer.
• The display card should be completely seated in its slot.
• Front Power Switch and computer power switch should be in the ON position.
• Check to make sure that a supported mode has been selected on the display card or system being used.
(Please consult display card or system manual to change graphics mode.)
• Check the monitor and your display card with respect to compatibility and recommended settings.
• Check the signal cable connector for bent or pushed-in pins.
• If nothing is displayed on the screen when HDCP device is connected, reset the power of the device.
Power Button does not respond
• Unplug the power cord of the monitor from the AC outlet to turn off and reset the monitor.
Image persistence
• Please be aware that LCD Technology may experience a phenomenon known as Image Persistence. Image Persistence
occurs when a residual or “ghost” image of a previous image remains visible on the screen. Unlike CRT monitors, LCD
monitors’ image persistence is not permanent, but constant images being displayed for a long period of time should be
avoided. To alleviate image persistence, turn off the monitor for as long as the previous image was displayed. For example,
if an image was on the monitor for one hour and a residual image remains, the monitor should be turned off for one hour to
erase the image.
NOTE:
As with all personal display devices, MITSUBISHI ELECTRIC recommends displaying moving images and using a moving screen
saver at regular intervals whenever the screen is idle or turning off the monitor when not in use.
Image is unstable, unfocused or swimming is apparent
• Signal cable should be completely attached to the computer.
• Use the OSD Image Adjust controls to focus and adjust display by increasing or decreasing the fi ne adjustment.
When the display mode is changed, the OSD Image Adjust settings may need to be re-adjusted.
• Check the monitor and your display card with respect to compatibility and recommended signal timings.
• If your text is garbled, change the video mode to non-interlace and use 60 Hz refresh rate.
Image of component signal is greenish
• Check to see if the DVD/HD input connector is selected.
LED on monitor is not lit (no green or red color can be seen)
• Power Switch should be in the ON position and power cord should be connected.
• Make certain the computer is not in a power-saving mode (touch the keyboard or mouse).
RED LED on monitor is blinking
• A certain failure might have occurred, please contact your nearest authorized MITSUBISHI ELECTRIC service facility.
Display image is not sized properly
• Use the OSD Image Adjust controls to increase or decrease the coarse adjustment.
• Check to make sure that a supported mode has been selected on the display card or system being used.
(Please consult display card or system manual to change graphics mode.)
Selected resolution is not displayed properly
• Use OSD Display Mode to enter Information menu and confi rm that the appropriate resolution has been selected.
If not, select corresponding option.
English-38
No Sound
• Check to see if speaker cable is properly connected.
• Check to see if mute is activated.
• Check to see if volume is set at minimum.
Remote Control is not available
• Check the Remote Control’s batteries status.
• Check if batteries are inserted correctly.
• Check if the Remote Control is pointing at the monitor’s remote sensor.
“SCHEDULE”/“OFF TIMER” function is not working properly
• The “SCHEDULE” function will be disabled when the “OFF TIMER” is set.
• If the “OFF TIMER” function is enable and the power to the LCD monitor is turned off if the power supply is interrupted
unexpectedly, then the “OFF TIMER” will be reset.
Stripe Noise
Either light vertical or horizontal stripes may appear, depending on the specifi c display pattern. This is no product fault or
degradation.
“NO SIGNAL” is displayed on the screen
Image may not be displayed right after HDCP device is connected.
English
English-39
Specifi cations
Specifi cations (MDT521S)
Product Specifications
LCD Module
Frequency
Pixel Clock
Viewable Size
Input Signal
PC-Input:
VIDEO Input:
AUDIO Input:
CAT5:
RS-232C:
Output Signal
PC-Output:
VIDEO Output:
AUDIO Output:
Speaker Output:
CAT5:
RS-232C:
Resolutions Supported
Power Supply
Power Consumption
Operational
Environment
Storage
Environment
Dimension
Weight
Wall mounting interface
Complied Regulatory
and Guidelines
Power Management
Plug & Play
Accessories
Diagonal:
Pixel Pitch:
Resolution:
Color:
Brightness:
Contrast Ratio:
Response time:
View Angle:
Horizontal:
Vertical:
Video:
Sync:
Input-terminal:
In:
In:
Video:
Sync:
Output-terminal:
Out:
Out:
Power Save:
Temperature:
Humidity:
Temperature:
Humidity:
Net:
Gross:
Net:
Gross:
Analog Input
52" / 132.2 cm
0.600 mm
1920 x 1080 dots (2070000 dots)
Over 16 million colors (depending on video card used)
700 cd/m
2000:1
8 ms (G to G)
Up and Down 178°, Left and Right 178° @CR>10
15.625 / 15.734, 31.5 - 91.1 kHz
50.0 / 58.0 - 85.0 Hz
13.5 -165.0 MHz
1152.0 x 648.0 mm / 45.4 x 25.5 inches
Analog RGB Video: 0.7 Vp-p
Input impedance 75 ohm
Separate HV sync: TTL level (Pos./Neg.), Sync-on-green, Composite Sync (0.3Vp-p)
Input Impedance 2.2K ohm
BNC (R,G,B,H,V), 15 Pin Mini D-sub
Composite: 1.0 Vp-p
Input impedance 75ohm BNC and RCA-PINJACK-INPUT
Y/C Y: 1 Vp-p C: 0.286 Vp-p Input
Impedance 75 ohm S-TERMINAL-INPUT
Component: 1.0 / 0.7 Vp-p
Input Impedance 75 ohm BNC-INPUT
RCA PIN-JACK L/R INPUT x 2, STEREO Mini Jack INPUT x 1
Modular connector 8 pin
9 Pin Mini D-sub
Analog RGB Video: 0.7 Vp-p with 75 ohm terminated
Separate HV sync: TTL level (Pos./Neg.)
15 Pin Mini D-sub
BNC-OUTPUT x 1, Composite 1.0 Vp-p with 75 ohm terminated
RCA PIN-JACK L/R OUTPUT x 1, 0.15 Vrms with 47k ohm terminated
External Speaker Jack 7 W + 7 W (8 ohm)
Modular connector 8 pin
9 Pin Mini D-sub
640 x 480 at 60 Hz to 85 Hz
800 x 600 at 50 Hz, 60Hz to 85 Hz
1024 x 768 at 50 Hz, 60Hz to 85 Hz
1280 x 768 at 50 Hz, 60Hz to 85 Hz
1360 x 768 at 50 Hz, 60Hz to 85 Hz
1280 x 1024 at 60Hz to 85 Hz
1600 x 1200 at 60 Hz
1920 x 1080 at 60Hz* ( * : Recommended Resolution)
NTSC,PAL,SECAM,4.43NTSC,PAL60 Component:480i,480p,720p,1080i,1080p
5.6 - 2.4 A @100 - 240 V AC, 50 / 60 Hz
Max 380 W
Less than 3 W (Power button OFF/Main power switch ON)
Landscape: 5 - 40 °C / 41-104 °F, Portrait : 5 - 35 °C / 41 - 95 °F, Face-up: 5 - 35 °C / 41 - 95 °F**
20 - 80 % (Without condensation)
-20 - 60 °C / -4 - 140 °F
10 - 90% (Without condensation)/90%-3.5%x(Temp-40°C) regarding over 40°C
1202 mm (W) x 698 mm (H) x 122 mm (D) / 47.32" (W) x 27.48" (H) x 4.80" (D)
1405 mm (W) x 951 mm (H) x 275 mm (D) / 55.31" (W) x 37.44" (H) x 10.83" (D)
88.2 lbs / 40 kg (Approximately)
108.0 lbs / 49 kg
8 Holes (200 mm pitches)
Optional Multi-purpose Fix Mount
UL60950-1/C-UL/TUV-GS/EN60950-1/FCC-B/DOC-B/EN55022-B
EN55024/EN61000-3-2/EN61000-3-3/C-Tick/CE/BSMI/GOST
VESA DPM
VESA DDC2B, DDC/CI
User’s Manual, Power Cord, Video Signal Cable, Remote Controller, AAA Battery x 2,
Clamper x 2 (To prevent from falling), Clamper x 3 (For securing cables), Clamper x 2
(For securing the power cord and HDMI cable), Screw for CLAMPER x 2,
CAT5-TX BOX
2
(typ.)
Digital Input
25.0 -165.0 MHz
TMDS
HDMI, DVI-D
Note: Technical specifications are subject to change without notice.
**: When installing the monitor with its screen facing up, ensure that the fan is always running.
English-40
Pin Assignment
1) Analog RGB input (Mini D-SUB 15P): RGB3
Pin No Name
1 Video Signal Red
2
3
4
5
6
7
8
9
10
11
12
13
14
15
2) Analog RGB input (CAT5): RGB5
Video Signal Green
Video Signal Blue
GND
DDC-GND
Red-GND
Green-GND
Blue-GND
+5V (DDC)
SYNC-GND
GND
DDC-SDA
H-SYNC
V-SYNC
DDC-SCL
15
Mini D-SUB 15P
5
10
1
6
11
English
Pin# at RJ45
#1
#2
#3
#4
#5
#6
#7
#8
3) Digital RGB input (HDMI): RGB1
1
TMDS Data2+
2
TMDS Data2
3
TMDS Data2-
4
TMDS Data1+
5
TMDS Data1
6
TMDS Data1-
7
TMDS Data0+
4) Digital RGB input (DVI-D): RGB2
1
TMDS Data2-
2
TMDS Data2+
3
TMDS Data2
4
NC
5
NC
6
DDC Clock
7
DDC Data
8
Analog Vertical Sync
Signal
Red Video+
Red VideoGreen Video+
Blue Video+
Blue VideoGreen VideoRJ485+
RJ485-
Pin - Assignment of HDMI connector:
Shield
Shield
Pin - Assignment of DVI-D connector:
Shield
8
9
10
11
12
13
14
9
10
11
12
13
14
15
16
Pair
TMDS Data0
TMDS Data0TMDS Clock+
TMDS Clock
TMDS ClockCEC
Reserved (N.C. on device)
TMDS Data1TMDS Data1+
TMDS Data1
NC
NC
+5V Power
Ground (return for +5V,
H-SYNC and V-SYNC)
Hot Plug Detect
Shield
Shield
Shield
15
SCL
16
SDA
17
DDC/CEC Ground
18
+5V Power
19
Hot Plug Detect
17
TMDS Data0-
18
TMDS Data0+
19
TMDS Data0
20
NC
21
NC
22
TMDS Clock
23
TMDS Clock+
24
TMDS Clock-
CAT5
1234 5678
1
Shield
Shield
HDMI
2
1
9
17
DVI-D
19
18
8
16
24
English-41
5) S-VIDEO input (MINI DIN 4P): VIDEO<S>
MINI DIN 4P
Pin No
1
2
3
4
6) RS-232C input/output
Pin No
1
2
3
4
5
6
7
8
9
Name
GND
GND
Y (Luminance)
C (Chroma)
Name
NC
RXD
TXD
NC
GND
NC
RTS
CTS
NC
Mini D-SUB 9P
1
6
5
9
English-42
North America
MESCA (Mitsubishi Electric Sales Canada Inc.)
http://www.mitsubishielectric.ca
Information Technologies Group, 4299 14th Avenue, Markham, Ontario L3R 0J2,
Canada
Sales Phone :+1-(905) 475-7728
Fax :+1-(905) 475-7958
E-mail :projectors@mitsubishielectric.ca
Technical Phone :+1-(905) 475-7728
Fax :+1-(905) 475-7958
Customer Care
E-mai
l :support@mitsubishielectric.ca
MDEA (Mitsubishi Digital Electronics America, Inc.)
(Warranty Registration)
http://www.mitsubishi-presentations.com/
Presentation Products Division, 9351 Jeronimo Road, Irvine, CA 92618 U.S.A
Phone Main Line :+1-(949) 465-6000
Technical :+1-(888) 307-0309
Product Information :+1-(888) 307-0312
Technical Suppor t
E-mail :tsupport@mdea.com
MITSUBISHI Contact Information
Europe
MEU-FRA (Mitsubishi Electric Europe B.V French Branch)
25, Boulevard des Bouvets 92 741, Nanterre CEDEX, France
Sales Phone :+33 (0)1 55-68-55-07
Fax :+33 (0)1 55-68-57-31
Technical Phone :+33 (0)1 55-68-56-42
Fax :+33 (0)1 55-68-57-31
MEU-GER (Mitsubishi Electric Europe B.V. German Branch)
