X4
USER GUIDE
ENGLISH
WELCOME
In The Box 2
Charging / Battery Status 3
Pairing 5
Finding Your Perfect Fit 7
Choosing Your Setup 7
Over-ear fit 8
Under-ear fit 11
DETAILED INSTRUCTIONS
Button Functionality 14
The Jaybird App 17
Multipoint - Connection to multiple devices 18
Smartwatches 19
Troubleshooting 20
Specifications 21
Warranty, Warnings & Safety 22
WELCOME
JAYBIRD X4
RUGGED VERSATILITY
RUN ANYWHERE
For detailed video instructions please visit jaybirdsport.com/support/
8 HOURS PLAYTIME
SWEAT & WATERPROOF (IPX7)
SPORT FIT - SECURE & COMFORTABLE
10 MIN = 1 HR OF PLAYTIME
Please refer to the safety warnings for important product safety information prior to installation or use of the product.
SPEED CINCH
PREMIUM SOUND WITH CUSTOM EQ
MUSIC & CALLS
IN THE BOX
2
Middle Button
Volume
Comply Ultra Ear Tips (Size 1 / 2)
Wireless Headphones
L
R
+
Volume
–
MicrophoneLED
Silicone Ear Tips (Size 1 / 2)
L
Speed Cinch
Shirt Clip
R
L
R
Silicone Ear Fins ( Size 1 / 2 / 3)
Integrated USB
Charging Cradle
Carry Pouch
CHARGING/BATTERY STATUS
We recommend you charge your earbuds through any 5V 500mA USB power source. Wall/car adapters/chargers that
supply more than 5.5 Volt will damage your Jaybird earbuds and should not be used.
3
A B
Take the included USB
charging cradle and plug it
into a USB power source.
2 hours charging gives
8 hours of playtime.
10 mins charging gives
1 hour playtime.
The red LED will show when
charging, and will turn solid
green when fully charged.
CHARGING/BATTERY STATUS
54%10:23 AM
+
WARMTH
JAYBIRD SIGNATURE
JAYBIRD ENHANCED
CUSTOMIZE
Each time you turn on your
earbuds you will hear a battery
level announcement. The battery
4
WARMTH
REMOVE SHARPNESS
EXTENDED LISTENING
R & B FREAK
Jaybird X4
87%
level announcements is rounded to
the closest 20%.
Your phone and the Jaybird app
will also indicate the battery level.
The Jaybird app will indicate the
battery level to within 1%.
PAIRING
5
Searching...
A
On your phone/music device,
turn Bluetooth® on and ensure
it is actively searching for
Bluetooth devices.
With your X4 earbuds turned
off, press and hold the Middle
Button until you see the LED
blinking red/green. You will
hear the “READY TO PAIR.
DOWNLOAD THE JAYBIRD APP
FOR AN ASSISTED SETUP”
voice prompt.
B
PAIRING
6
Jaybird X4
C
Select “Jaybird X4” in the
list of discovered devices.
Once your X4 earbuds have
D
connected to your phone/
music device you will hear
the “Connected” voice
prompt. You are now ready
to listen to your music.
If the pairing is not successful, switch off your earbuds by pressing the
Middle Button until the red LED illuminates and you hear a descending
“Power off” tone. Once your earbuds have powered off repeat steps A-D.
NOTE: When you turn your X4 earbuds on for the first time or after a reset,
they will be in pairing mode.
FINDING YOUR PERFECT FIT
Under-ear
CHOOSING YOUR SETUP BASED ON USE
We recommend choosing a fit based on
7
how you plan to use your Jaybird X4.
If you intend to use the
Jaybird X4 for sport use, we
recommend the over-ear setup.
Over-ear
FINDING YOUR PERFECT FIT
1. SET UP YOUR FINS
L2
8
A
Lay your X4 in front
of you with the
remote on the left
hand side. Swap the
fins to the opposite
side so the fin with
the ‘L’ is now on
the side with the
headphone remote.
L
Rotate the fins so
R
B C
they are pointing
towards the cable,
as shown.
Place your X4 over
your ear with the
remote on
your left side.
FINDING YOUR PERFECT FIT
2. FINDING THE RIGHT SIZED TIPS AND FINS
9
A
Starting with the size 1 tips
and size 2 fins attached, try
placing your earbuds firmly
within your ear while in the
over-ear position.
Left
Ear
Right
Ear
B
If your earbuds are not
comfortable, or feel loose,
try alternative sized tips
and/or fins. You can also try
the ComplyTM foam tips or
remove the fins completely.
Be patient, it may take some
time to get the perfect fit.
C
Once you are happy with
the fit, move onto step 3.
R
R
2
2
FINDING YOUR PERFECT FIT
3. SPEED CINCH
The speed cinch helps to keep the cord off your neck
and shoulders, which is especially useful for the overear fit.
10
A
B
Place your X4 earbuds in your ears.
Grab the cord beneath the cinch with one
hand. With your other hand adjust the cinch
up or down until you find the right cord length
to get a snug fit with no excessive slack.
FINDING YOUR PERFECT FIT
Over-ear
11
If you intend to use the Jaybird
X4 for casual use, we recommend
the under-ear setup.
Under-ear
FINDING YOUR PERFECT FIT
1. FINDING THE RIGHT SIZED TIPS AND FINS
12
A
Left
Ear
With the size 1 tips and size 2
fins attached, place your earbuds
firmly within your ear while in the
under-ear position. The remote
Right
Ear
B
R
If your earbuds are not
comfortable, or feel loose, try
alternative sized tips and/or fins.
You can also try the Comply
R
2
2
TM
foam
C
Once you are happy with the
fit, you are good to go.
should be on the right side.
tips or remove the fins completely.
Be patient, it may take some time
to get the perfect fit.
FINDING YOUR PERFECT FIT
2. SHIRT CLIP
Use the included shirt clip to secure your X4 earbuds to
the back of your shirt.
Prior to using the shirt clip, remove, if
A
B
necessary, the speed cinch.
Attach the shirt clip to your shirt with the long
side of the clip on the outside of your shirt.
13
14
DETAILED INSTRUCTIONS
BUTTON FUNCTIONALITY
ONOFF
Turn your earbuds ON: press and hold the
Middle Button until you hear an ascending
“Power on” tone and the LED blinks green.
LONG PRESS
Turn your earbuds OFF: press and hold the
Middle Button until you hear a descending
“Power off” tone and the LED illuminates
red before turning off.
15
DETAILED INSTRUCTIONS
PLAYING MUSIC
VOLUME UP SKIP FORWARD
PLAY PAUSE VOICE ASSISTANT
VOLUME DOWN SKIP BACKWARD
PRESS LONG PRESS
Play or pause, a song or video with a singel press and release of the Middle Button.
To skip a song, long press the Vol. + Button.
To go backwards, long press the Vol. – Button.
To change the volume + or , press the Vol. + or Vol. – Button.
To activate voice assistant, (Siri or Google Now), long press the Middle Button.
16
DETAILED INSTRUCTIONS
PHONE CALLS
VOLUME +
ACCEPT END A CALL DECLINE A CALL REDIAL
VOLUME MUTE UNMUTE
PRESS DOUBLE PRESSLONG PRESS
Accept a phone call: press the Middle Button.
To decline a phone call: long press the Middle Button.
To mute or unmute a call: long press the Vol – Button.
To redial: a phone number you can double press the Middle Button.*
To change the volume + or –: press the Vol + or Vol – Button.
*Standby Mode: Powered and not playing music or on a phone call.
DETAILED INSTRUCTIONS
THE JAYBIRD APP
17
54%10:23 AM
+
The Jaybird App lets you customize the sound profile of your X4 earbuds.
You can also enable Find My Buds to track your buds if lost. Connect your
buds to the Jaybird app to see if a firmware update is available.
Your new sound settings are saved on your earbuds, so you can take
your custom sound with you no matter where you go with any device
you use.
WARMTH
JAYBIRD SIGNATURE
WARMTH
REMOVE SHARPNESS
CUSTOMIZE
JAYBIRD ENHANCED
EXTENDED LISTENING
R & B FREAK
Jaybird X4
87%
DETAILED INSTRUCTIONS
MULTIPOINT CONNECTION TO MULTIPLE DEVICES
Multipoint allows you to be connected to two devices simultaneously. You can for instance
be connected to your laptop and your mobile phone. While listening to music on your laptop
you will be able to accept an incoming call on your phone.
18
1
Ensure your earbuds are up to date. Connect to the
Jaybird app to see if a firmware update is available.
Ensure your X4 earbuds are paired and connected to
2
both devices. Follow pairing instructions on page 5-6.
Make sure that only the two devices you want to
3
connect to are turned on and in proximity
Your X4 can remember up to eight paired Bluetooth® devices
and can be actively connected two devices at a time.
DETAILED INSTRUCTIONS
SMARTWATCHES
With the right smartwatch you can leave your phone at home. Just sync music to your smartwatch and pair X4 to your
smartwatch. Use your smartwatch user manual for instructions on how to pair a Bluetooth device.
Apple WatchOS Android Wear GarminSamsung
19
TROUBLESHOOTING
Soft reset: If your earbuds are not responding, put your X4 in the charge cradle and connect the USB charging cable to a
power source. This will turn your earbuds off and perform a soft reset.
Factory reset: If this does not resolve your problem we recommend resetting your earbuds to their original factory
settings. Before starting this process please “FORGET” or “REMOVE” your X4 device in your Bluetooth list of discovered
devices in your phone or music device.
20
Put your earbuds
1 2 3
in to pairing mode.
Press and hold the
Middle Button until
the earbuds turn off.
Then press and hold
the Middle Button for
5 seconds until you
see alternating red/
green LED.
While the LED is
blinking press the
Middle Button twice.
The orange LED will
blink twice and you
should hear a ‘beep’
tone.
Now your earbuds are reset
and ready to pair. Go to
your phone’s/music device’s
Bluetooth menu and select
X4 to re-pair.
SPECIFICATIONS
Bluetooth Version 4.1, Multipoint
Codec AAC, SBC, Modified SBC
Profile Handsfree, Headset, A2DP, AVCRP, SPP
Effective Range 10 meters (30 feet)
Play Time 8 Hrs*
21
Power Bluetooth headset: 5.0V
Charging Time 2 Hrs
Quick Charge 10 Min = 1 Hr play time
Dimensions 13 x 24 mm earbud size, 490 mm cord length
Weight Approx 14.7 g (without fins and tips)
* Play time and standby time may vary due to usage conditions. Adding additional bass to your sound profile through the Jaybird app will reduce play time.
, 1A
22
WARRANTY, WARNINGS & SAFETY
Full warranty, care & maintenance details at:
jaybirdsport.com/warranty +1.866.244.3399
WARNING: Due to the isolating characteristics of these headphones do not use while driving, riding a bike or where vehicular traffic is present, or in any other activity where failure to hear surrounding sounds could be
dangerous. Use of these headphones at excessive volumes may cause permanent hearing damage. Always turn the volume down before use. Take caution in regards to inserting objects into ear canal, use at own risk. Do not
wear the device while it is connected to a power source driven from main 110V or 220V lines.
Copyright 2016 Jaybird, LLC. All rights reserved. Jaybird, and the Jaybird logo are trademarks of Jaybird, LLC. Bluetooth is a trademark owned by Bluetooth SIG, Inc. USA, and licensed to Jaybird, LLC. iPhone, iPad and iPod
are trademarks of Apple, Inc., registered in the US and other countries and App Store is a service mark of Apple Inc. All other trademarks are the property of their respective owners. Android is a trademark of Google Inc. in
the United States and other countries.
WATERPROOF
Your Jaybird X4 earbuds feature an IPX7 waterproof rating. X4 earbuds are designed to handle rain, mud and outdoor adventures.
Jaybird headphones are not designed for swimming, showering or exposure to pool or ocean water. In case of exposure to salted or chlorinated water, rinse the headphones gently with fresh water and air dry before use.
The charging cradle is not water resistant, so please ensure your headphones are completely dry before charging.
EARTIP CLEANING
Keeping your Jaybird Earbuds eartips clean is essential for safe, hygienic use.
IMPORTANT: DO NOT attempt to clean the eartips without first removing them from the headphones. Getting the delicate circuitry inside your Jaybird Earbuds wet may cause permanent damage.
1. Firmly grip the eartip with one hand and the earphone with the other. Carefully remove the eartip from the bud.
2. Use warm water and mild soap on a damp cloth to remove dirt and earwax from the eartip. Do NOT use harsh cleaning agents.
3. Rinse and completely dry your eartip before placing them back on your earbuds.
4. Carefully push the eartips back onto the earbuds.
LISTEN RESPONSIBLY
Avoid excessive volume levels and prolonged periods of listening. Prolonged listening at excessive volume levels
may cause permanent hearing disability.
Do not use around road traffic.
CARE AND MAINTENANCE
Clean eartips regularly of dirt and wax buildup. To clean, remove eartips from earbuds, then gently wipe away
dust and oil with a dry cloth, and/or use warm water and mild soap to remove buildup. Rinse and completely dry
before reattaching.
23
Before charging, ensure earbuds are completely dry of sweat and water.
Video instructions at jaybirdsport.com
Loading...
