POD GO EDIT
PILOT'S GUIDE
A guide to the features and functionality of the Line 6 POD Go Edit application
Rev. C (v1.11) www.line6.com/manuals © 2020 Yamaha Guitar Group, Inc. All rights reserved.
Contents
Workflow 2
What’s in it for Me? 2
Marketplace 2
Workow Overview 2
Computer Connectivity 3
Compatibility with Other Line 6 Products 3
GUI Overview 4
Resizing the Application Window 4
Application Menus 5
Preferences, Help & Account Options 6
Factory & User Setlists 7
Premium Marketplace Presets 7
Selecting, Loading, and Saving Presets 7
Importing and Exporting Preset Files 8
Renaming, Reordering, Copying, and Pasting Presets 8
Importing and Exporting Setlists 8
Impulses List 9
What are Impulse Responses? 9
Importing and Exporting Impulse Responses 9
Premium Marketplace IRs 10
Renaming, Copying, Pasting & Clearing IRs 10
IR File Reference 11
Working in the Editor 12
Naming & Saving the Preset 13
Conguring & Managing Snapshots 13
Undo / Redo 15
Editing the Tap Tempo 15
Creating & Restoring Complete Device Backups 16
Signal Flow Panel 18
Block Types 18
Bypassing Blocks 19
Copying, Pasting, & Clearing Blocks 19
Bypass Assignment Indicators 19
Edit/Model Select Panels 21
Editing Model Parameters 21
Selecting Models 23
DSP Management & Model Availability 23
Bypass & Controller Assignment 24
The Bypass/Control Window 24
Clearing Existing Assignments 25
Auto Assign Feature 28
Creating a Controller Assignment 28
Global EQ Window 31
Adjusting Global EQ Parameters 31
Preferences and About Box 32
The Preferences Window 32
The About/Legal Box and Help Options 33
Marketplace & Account Options 34
Marketplace 34
The My Account Menu Options 35
Sign In / Sign Out 35
Authorize / Deauthorize Your Computer 36
Model Lists 37
Eects Block Models 37
Wah and Volume Block Models 41
FX Loop Block 42
Amp/Preamp Block Models 43
Cab/IR Block Speaker Cabinet Models 45
Microphone Models 46
Keyboard Shortcuts 48
Additional Mouse Behaviors 57
Firmware Updater & Additional
Resources 58
POD Go Device Firmware Updater 58
Using the Line 6 Updater App 60
Additional Resources 61
© 2020 Yamaha Guitar Group, Inc. All rights reserved.
Line 6, the Line 6 logo, POD, POD Go, Ampeg, Powercab, Helix, HX Stomp, and HX Eects are trademarks or registered trademarks of Yamaha Guitar Group, Inc. in the U.S. and/or other jurisdictions. Apple,
Mac and macOS are trademarks of Apple, Inc. registered in the U.S. and other countries. Apple is not responsible for the operation of this product or its compliance with safety and regulatory standards.
Windows is a registered trademark of Microsoft Corporation in the United States and/or other countries.
Workflow
Welcome to the POD Go Edit Pilot’s Guide. This guide contains details of the POD
Go Edit v.1.11 application’s features and functionality with Line 6® POD® Go devices.
All behaviors are the same on Mac and PC computers unless otherwise noted. It is
recommended that you also check out the handy Cheat Sheet included with your
device, and the Owner’s Manual for details on using your POD Go.
Marketplace
Be sure to visit the Line 6 Marketplace online shop, where you'll nd 3rd-party
add-on assets that further enhance the functionality of POD Go and Helix® family
products! Check back often on Marketplace for product news and announcements.
An Internet connection is required for the computer on which you'll be using the POD
Go Edit app to authorize it for the use of Marketplace premium assets. Please see
“Marketplace & Account Options” on page 34.
IMPORTANT: It is required that your POD Go device’s rmware be updated to
version 1.11 (or later) to be fully functional with the POD Go Edit application.
See “Firmware Updater & Additional Resources” on page 58 for how to check and
update your device’s rmware.
What’s in it for Me?
POD Go Edit is a simple, but powerful, editor, preset librarian, and IR manager
application. It allows you to easily customize, back up, and manage your tone presets
and setlists, as well as manage the Impulse Responses on your Line 6 POD Go
device. Essentially, the POD Go Edit app allows you to access the features in your
device conveniently, taking full advantage of your computer’s large screen, keyboard,
and ample storage space!
POD Go Edit is the editor/librarian software for use with POD Go devices running
rmware version 1.11 (or later).* For best performance, it is recommended to use
the latest available version of both the POD Go Edit application, drivers, and
device rmware.* If for any reason you wish to return to an earlier rmware for your
device, or an earlier POD Go Edit software version, you'll need to be sure the release
versions of the rmware and software match for full functionality. Please refer to
“Firmware Updater & Additional Resources” on page 58 for details.
*NOTE: If on Windows®, you’ll need to install the Line 6 POD Go drivers to be
able to use POD Go Edit—all drivers are already selected to be installed by
default when you run the Windows POD Go Edit installer. The Windows drivers also
provide ASIO, low latency, 24-bit/44.1khz, 48kHz, 88.2kHz, and 96kHz sample rate
operation, allowing you to utilize POD Go as a USB audio interface for all popular
Windows audio applications.
For Mac computers, no driver installation is necessary for use of POD Go devices
with POD Go Edit app, as well as for USB MIDI and low latency, 24-bit/48kHz audio
operation.
The latest POD Go Edit application and driver installers are available at
line6.com/software/. For details on application and driver support with the latest
Windows and Mac operating systems, please be sure to check any driver’s Release
Notes, or visit line6.com/support/.
Workflow Overview
Once the POD Go Edit app is launched, it automatically syncs all presets and IRs
from your device's internal memory, displaying them within the Librarian panel at the
left of the application window. This allows you to export presets and IRs to create a
virtually unlimited library on your computer, and then import them onto your device
at any time. The Librarian panel also allows you to easily rename and reorder your
presets and IRs, and the Create & Restore Backup feature makes it simple to create
full backups that can be restored to your POD Go hardware in minutes.
You will also see your currently loaded preset's contents displayed in the Editor
panels on the right. This allows you to load & fully customize your presets, congure
bypass & controller assignments, and create & edit snapshots. While connected,
communication between the application and your connected device’s internal memory
is instantaneous. Changes you make to any parameters in the Signal Flow or Edit
panels, as well as any changes to presets, setlists and IRs within the Librarian, are
immediately reected on the device, and vice-versa.
This interactive communication allows you to tweak your presets and setlists in real
time, without the need to manually sync to the device.
WARNING: Please be aware that when overwriting presets or Impulse Responses,
these changes cannot be reverted! You can use the Create & Restore Backups
feature to back up your device's contents before making changes. See “Creating &
Restoring Complete Device Backups” on page 16.
2
Computer Connectivity
To put the POD Go Edit application to work, connect POD Go to your computer’s USB
port. As mentioned above, for Windows computers it is necessary to install the Line
6 POD Go drivers (included and installed by default with the POD Go Windows app
installer) to be able to use the POD Go Edit application with your device.
Exit any other Line 6 or audio applications that may be running. With your POD Go
device powered on, launch POD Go Edit.
• Mac: Go to Applications > Line 6 > POD Go Edit
• Windows: Go to the Start button menu > All Apps (or Programs) > Line 6 >
POD Go Edit
Upon launch, the application will detect your connected POD Go hardware and
automatically retrieve and display its on-board presets & Impulse Responses. This
may take a moment to download all of the preset information.
If a connected POD Go device is not detected by your computer, you’ll see the “No
device” indicator appear at the top left of the application.
No Device Connected indicator
If you see this indicator, check to make sure your POD Go device is powered on and
connected to your computer’s USB port. If on Windows, be sure you have the Line 6
POD Go driver installed.
The Update available indicator also appears at the bottom of the main application
window if a rmware update is available. You can optionally click this button to launch
the Firmware Updater.
Compatibility with Other Line 6 Products
POD Go presets, setlists, or backup les are not compatible with other Line 6
hardware and software products at this time. However, POD Go supports the same
format Impulse Response (IR) les as Line 6 Helix and HX™ devices and the Helix
Native plug-in. This means that you can essentially obtain IRs that any vendor oers
for Line 6 Helix/HX devices and import them directly into the POD Go Edit Impulses
Library!
TIP: A great selection of POD Go presets and IRs are available right now in the
Line 6 Marketplace online shop!
Automatic Firmware Update Check
Upon launch of POD Go Edit, it will automatically check the Line 6 online server for
a newer rmware version for your connected POD Go device (if you have an active
Internet connection, and have signed in within POD Go Edit). If a rmware update is
available, you’ll see a pop-up alert shortly after launching the application.
Firmware update available pop-up alert
Choosing Update Now launches the built in Firmware Updater and walks you
through the update process painlessly - see page 58 for details. Or you can click to
read the available rmware’s Release Notes, or choose to Remind Me Later and just
use the application without updating your device.
3
GUI Overview
POD Go Edit has a very intuitive, easy-to-use interface. The application automatically
detects your connected POD Go device and displays all its options within the main
application window, where the navigation is divided into three main sections:
The Librarian Panel - For managing presets, setlists, and Impulse Response (IR)
les.
The Signal Flow Panel - Where you can add and move amp, eects, FX loop, and
looper models and customize your complete signal path routing.
The Inspector - Edit/Model Select Panel - This lower portion of the Editor
window serves as an Inspector panel for the block selected within the Signal Flow
panel. Here you can choose from two display modes: The Edit panel for editing a
block’s parameters and bypass & control assignments, or the Model Select panel
for choosing the desired models for each of the blocks within the Signal Flow.
The Edit/Model Select panel display can be switched via the toggle button at the top
of the panel.
Edit/Model Select Panel Toggle Button
Setlist Library
Buttons
LIBRARIAN
My Account/Preferences Options
Impulses Library
Button
The POD Go Edit main application window
Signal Flow
Panel
Inspector - Edit Panel Displayed
EDITOR
The Edit/Model Select panel - Model Select panel displayed
Additionally, bypass, control, and snapshot assignment options can be accessed
from multiple points within the Editor window, allowing you to easily create, edit, and
manage the preset’s footswitch and pedal assignments - see “Bypass & Controller
Assignment” on page 24 for details.
Resizing the Application Window
The POD Go Edit main application window is resizable, allowing you to adjust it to
best t your screen size and workow. Simply click and drag any corner or edge of
the window to adjust to the preferred size, or click the “Maximize” button at the top of
the window to use it in full screen mode.
4
Application Menus
At the top of your computer screen (Mac) or top of the application window (Windows),
you'll nd the familiar application menu bar. Note that the available commands dier
within the File and Edit menus depending on the application window, panel and/or
specic control that currently has “focus.” The window focus is indicated by a blue
triangle appearing at the top left of the main Librarian, Signal Flow, or Inspector
windows. To change focus, simply click within the desired panel, or use the TAB key.
To follow are descriptions of the included application menu commands for Mac and
Windows. Also see “Keyboard Shortcuts” on page 48 for additional information.
POD Go Edit (Mac only)
• About POD Go Edit - Launches the About box screen, which displays
software and device rmware version info, and legal credits.
• Preferences - Launches the Preferences window, where you can select
application and hardware settings—see page 32. You can also launch the
Preferences window by clicking on the “gear icon” button at the bottom left, or
on the “POD Go” logo at the top left of the application window.
• Quit POD Go Edit - Exits the application.
File
When a preset within the Factory or User setlist currently has focus (or, when a setlist
is displayed and focus is within any other window), the following commands are
selectable:
• Save Preset - Saves changes for the currently loaded preset to the device's
Preset library.
• Save Preset As - Displays the Save As window, allowing you to choose the
desired setlist (Factory or User) and Preset library location where to save the
current tone. Note that choosing an occupied preset location will overwrite the
existing preset within the location on your device.
• Import Preset - Imports any .pgp preset le (or les) from your computer,
replacing the currently selected library preset(s).
• Export Preset - Exports the currently selected preset (or presets) and saves
each to your computer as a .pgp le.
• Import Setlist - Imports any .pgs setlist le from your computer, replacing the
current setlist on your device.
• Export Setlist - Exports the current setlist and saves it to your computer as
an .pgs setlist le.
When an IR slot within the Impulses library currently has focus (or, when the impulses
library is displayed, and focus is within any other window), the following commands
are selectable:
• Import IR - Imports an Impulse Response (IR) le (or les) from your
computer, replacing the currently selected library IR(s).
• Export IR - Exports the currently selected IR(s) and saves each to your
computer.
• Save Preset - Saves changes to the currently loaded preset.
• Save Preset As - Displays the Save As window, allowing you to choose the
desired setlist and preset index location where to save the current tone.
TIP: Please see “Factory & User Setlists” on page 7 and “Impulses List”
on page 9 for details these File menu commands.
The following File menu commands are available regardless of window focus:
• Create Backup - Launches the Create a POD Go Backup window, where you
can export a full backup of your device's presets, IRs, and global settings—
see page 16.
• Restore From Backup - Launches the Restore From Backup window, where
you can restore all your device's presets, IRs, and global settings from a
previously created backup—see page 16.
• Preferences - (Windows only) Launches the Preferences window, where you
can access application and hardware settings—see page 32. You can also
launch the Preferences window from the “gear icon” button or the connected
device indicator at the bottom of the application window.
• Quit - (Windows only) Exits the application.
Edit
Regardless of window focus:
• Undo - Reverses the last supported edit action.
• Redo - Reverses the last performed Undo action.
TIP: Please see “Undo / Redo” on page 15 for details.
When a preset within the Factory or User setlist has focus:
• Copy Preset - Copies the selected preset(s) to the clipboard.
• Paste Preset - Pastes the last-copied preset(s), replacing the preset(s) within
the selected Preset library location(s).
• Select All Presets - Selects all presets within the current setlist.
• Rename Preset - Renames the currently loaded preset.
When an IR slot within the Impulses library has focus:
• Copy IR - Copies the selected IR(s) to the clipboard.
• Paste IR - Pastes the last-copied IR(s), replacing the IR(s) within the selected
IR library location(s).
• Clear IR - Deletes the selected the IR(s) from the Impulses library.
• Select All IRs - Selects all IRs within the Impulses library.
• Rename IR - Renames the currently selected IR.
When a block within the Signal Flow panel has focus:
• Cut Block (Eects type blocks only) - Copies the currently selected block’s
model and its settings to the clipboard and removes the model from the block.
• Copy Block - Copies the currently selected block’s model and its settings to
the clipboard.
5
• Paste Block - Pastes the last-copied block's model and its settings into the
selected block.
• Clear Block - Removes the model from the selected block (available only for
Eects type blocks).
• Rename Preset - Renames the currently loaded preset.
TIP: Please see “Copying, Pasting, & Clearing Blocks” on page 19 for
details.
Preferences, Help & Account Options
At the bottom left of the window, click on the menu buttons to access the
application’s Preferences, Help & About Box, (see page 32) and My Account
options (see page 35)
Snapshots
• Copy Snapshot - Copies the currently loaded preset's snapshot to the
clipboard.
• Paste Snapshot - Pastes the last-copied snapshot contents, replacing the
currently loaded snapshot's contents.
• Snapshots - Loads any of the current preset's four snapshots.
TIP: Please see “Conguring & Managing Snapshots” on page 13 for
details.
Window
• Show or Hide Bypass/Control - Toggles the Bypass/Control window
between shown and hidden within the Edit panel. (Note that the Edit/Model
Select panel must be displaying the Edit panel to access this command.)
See page 24.
• Global EQ - Displays the Global EQ window—see page 31.
Help
• POD Go Edit Online Help - Takes you to the Line 6 Support site where you
can nd helpful info on POD Go Edit and your POD Go device.
• POD Go Edit Application Pilot's Guide - Launches the PDF you are reading
now.
• About POD Go Edit - (Windows only) Launches the About box, which
includes the software and device rmware version info and legal credits.
Preferences Help/About Account Options
6
Factory & User Setlists
Within the Librarian panel of the POD Go Edit window, clicking on the Factory or
User setlist folder displays its presets list, which provides functionality for importing,
exporting, and managing the presets stored within your POD Go device’s internal
memory. The Factory and User setlists each include 128 preset locations.
Setlist Folders
Loaded Preset
Selected Preset
Premium Marketplace Presets
If you’ve purchased and downloaded premium POD Go presets from the Line 6
Marketplace, you must be signed in to your Line 6 account within POD Go Edit
and have your computer authorized to initially import or export these presets (as
well as for any setlists or backups that include premium presets). Please also see
“Marketplace & Account Options” on page 34.
Premium Marketplace presets are otherwise able to be utilized just like any other POD
Go presets. When imported, these premium Marketplace presets are indicated by
guitar pick “badges” to their right within the Presets panel.
The Librarian panel, with the Factory setlist selected
Note that all presets are editable, including the Factory presets originally included
with your device. Initially, the User setlist includes all “New Presets,” which consist
of the default set of Preset blocks and four empty Eects blocks, awaiting your
customization. You’ll likely nd it easiest to start with the Factory presets, tweak
the models, tone & controller settings, and then rename and save your customized
presets into the User folder.
You'll nd the commands for preset Save, Save As, Import, Export, Copy, Paste,
and Rename within the application's File & Edit menus. Preset commands are also
accessible via right-click directly on any preset within the library, as well as via handy
“Keyboard Shortcuts”. It is also possible to import and export complete setlists, using
their respective menu commands.
Right-click on a preset to quickly access available commands
TIP: Exporting a setlist or individual presets is a great way to backup and archive a
virtually unlimited number of your custom presets on your computer—also see
“Creating & Restoring Complete Device Backups” on page 16.
Premium Marketplace presets are indicated with golden guitar pick badges
Selecting, Loading, and Saving Presets
It is important to note our terminology used in this Guide when describing the
dierence between selecting versus loading a preset within a setlist. To access a
preset, choose the desired setlist (Factory or User) at the top of the Librarian panel,
then click choose any preset within the setlist.
To Select a Preset - Click once on a preset location within the setlist and you'll
see it become highlighted in gray. This indicates the preset is selected, meaning
that a preset command (Copy, Paste, Import, etc.) will act upon this preset (even if
a dierent preset is the one currently loaded within the Signal Flow).
To Load a Preset - Double-click on any preset (or click once to select it and then
hit your Enter/Return key) to load the preset—you'll see the preset name appear
with amber colored text, indicating it as the preset currently in use. Note that
File and Edit menu commands will act upon the preset that is currently selected
(highlighted) which may or may not also be the currently loaded preset.
TIP: You can also load presets by clicking on the Next/Previous Preset (up
and down arrow) buttons that appear at the top left of the Editor window.
To Save a Preset - Once a preset is loaded from the preset library and edited,
you’ll most likely want to save the preset to retain your changes.* To save the
preset to your device’s library, choose the Save or Save As option from the app’s
File menu, or click the Preset Save button that appears at the top of the Signal
Flow panel (see page 13). Also see the next section for the option to export a
preset to save it to your computer.
*TIP: Before editing a preset you may wish to rst copy it to another location in the
Presets panel, or export it, to be sure you have an original version of the preset.
7
Importing and Exporting Preset Files
Presets that reside within your device are able to be exported to your computer as
individual POD Go preset (.pgp) les, allowing you to create a vast collection of tones
that can be imported back onto your device's internal preset library at any time.
To Import a Preset File - It is recommended to select an unused, “New Preset”
location within the app’s Librarian panel and select the File menu (or the preset
slot’s right-click menu) Import Preset command. A brief dialog will inform you that
importing will overwrite any existing preset within the selected location. Click Ye s
to continue. A system window will display a le browser for selecting the preset le
you wish to import. Once imported, the preset will reside in your device's internal
memory, within the selected preset location.
To Export a Preset File - Select the preset by single-clicking on it within the current
setlist and click the File menu (or the preset slot’s right-click menu) Export Preset
command. Exporting creates a copy of the preset in its last-saved state from your
device's memory and saves it to your computer. The familiar “save” window is
presented, in which you can edit the lename and choose a destination folder.
Drag and Drop Presets
It is possible to drag and drop any preset (or multi-selected presets) directly from the
Librarian panel to perform the following actions.
• Import - Drag a .pgp preset le from any computer folder and drop directly
onto a presets slot to import it into the device’s setlist. This import action
replaces and overwrites the slot’s existing preset.
• Import and Load - Dragging a preset from a computer folder and dropping it
directly into the currently loaded preset’s slot within the setlist, or dropping it
directly into the Signal Flow window, will both Import the preset and load it as
the new current tone, replacing the previous tone. (Note that if you drag and
drop a preset into a slot other than that of the currently loaded preset, this will
import the preset into the setlist, but will not load the preset.)
• Export - Drag one or multiple presets from the setlist and drop into any folder
on your computer to export a copy of the .pgp preset le(s) there. (The preset
is exported in its last-saved state.)
• Reorder - Drag to another location within the setlist to reorder the presets
within the list as desired. When the preset is dropped into the new location
slot, the surrounding presets are shifted upward or downward accordingly.
Renaming, Reordering, Copying, and Pasting Presets
These functions allow you to customize your presets within the setlist. Choose the
Edit menu (or the preset slot’s right-click menu) Rename, Copy, or Paste command
and it will act upon the selected (highlighted) preset. For most commands, it is
also possible to multi-select a number of presets by using Shift+click to select a
contiguous set of presets, or Cmd+click (Mac) or Ctrl+click (Windows) to select a noncontiguous set. Read on for more ways to accomplish these preset tasks.
Renaming a Preset
Click to select any preset within the setlist, then choose the Rename command and
type in your new desired name.
Reordering Presets
Click to select any preset within the setlist, then click and drag the preset vertically to
place it in the new index position within the setlist. You’ll see the other presets shift
up/down accordingly.
Copying & Pasting Presets
Click once on any preset within the setlist to select it, so that it is highlighted. (Note
that it does not need to be the currently loaded preset, just the highlighted preset).
Chose the Copy command to copy the preset to the clipboard. Then click to select
the desired target preset location, which can be within the current or other setlist,
and use the Paste command. Pasting a preset into a target location that is currently
occupied will result in permanently overwriting the target location’s preset.
Importing and Exporting Setlists
The Librarian panel allows you to instantly save the currently loaded setlist, including
all its saved presets, to a POD Go setlist le (.pgs). This is very handy for making a
backup of all presets within a setlist, so that one setlist can easily be loaded back into
your device in a single action (for example, you might only want to import an exported
User setlist and keep your device’s current Factory setlist intact, or vice-versa).
To Import a Setlist - Select the Import Setlist command. This will prompt you to
ensure that you wish to overwrite and replace the currently selected setlist and the
presets therein. Continue through the Open window to select the setlist you wish
to import into your connected device.
To Export a Setlist - Select the Export Setlist command to display the Save
As dialog, where you can optionally rename the setlist le and choose your save
directory.
TIP: Wanting to restore the Factory Presets & settings for your device? You can do
so by performing a Factory Restore—please see your POD Go Owner’s Manual
for details (and remember to use POD Go Edit to rst do a back up of your current
presets!)
TIP: Visit the line6.com/customtone site to share your tones and download from
the huge online library of artist and user presets. Also be sure to visit the Line 6
Marketplace online shop for professionally crafted presets and IRs!
8
Impulses List
The Librarian's Impulses list displays all Impulse Response les (along with
respective ID numbers in the left column) that currently reside on your POD Go device.
Initially, this Impulses list is empty, awaiting your import of Impulse Response les.
Impulses
Folder
IR Formats and Restrictions
The following IR le types are supported.
• Helix Impulse Response (.hir) - This is the proprietary Line 6 IR le format.
IRs purchased through the Line 6 Marketplace are of this le type, and
supported by Line 6 Helix/HX devices, Helix Native plug-in, as well as POD
Go. (Please also see “Marketplace & Account Options” on page 34.)
• WAV (.wav) - Most IR producers and vendors typically oer IRs in the .wav
format. It is possible to import a mono or stereo .wav le IR, regardless of
its bit depth, length, or sample rate frequency. While this is very convenient,
please be careful to import only .wav les that were created specically for
use as IRs, not just any audio .wav le, or you may experience unexpected
sonic results.
IR Index Numbers
The Impulses list
Helix, HX, and Helix Native Plug-in Users: Any IR les used with POD Go can
also be used by all Line 6 Helix and HX devices, as well as Helix Native plug-in!
Loaded IR
Selected IR
What are Impulse Responses?
Impulse Responses (or “IRs”) that can be used in POD Go are audio les that are the
result of capturing the sound of a test tone (frequency sweep) through a guitar or bass
amp speaker cabinet, which has been deconvolved with the original tone signal. This
represents the frequency response of the miked cabinet itself, and can be used to
simulate the way it alters the sound. This is similar to a convolution reverb, but with a
much shorter decay.
Choose the IR type category within the Cab/IR block to provide speaker cabinet
simulation for your preset. Numerous companies now oer large selections of
professionally recorded IR les that can be used in POD Go, or you can even do some
research on how to record and create your own. Feel free to jump on your favorite
guitar gear forums and join the ongoing, sometimes heated, discussions about the
best and most realistic IRs, and methods to create them.
You can also nd some IRs that were created using this convolution process to
capture the properties of acoustic guitar bodies, guitar pickups and other sources.
These IRs can certainly be used in the POD Go IR block as well, to allow even deeper
tone sculpting!
TIP: Line 6 oers a free pack of IRs from Allure. You can grab them now at http://
line6.com/allure/.
You can also nd a great selection of IRs, specically created for POD Go and Helix
family products, on the Marketplace—see page 34.
Importing and Exporting Impulse Responses
To access the IRs stored on your POD Go device, click on the Impulses folder at the
top of the Librarian panel. From here you will be presented with a list of up to 128 IR
locations and their index numbers. You’ll want to import all IRs you plan on utilizing
within your presets into this Impulses library list.
NOTE: Premium IRs purchased from Marketplace are also imported & exported
using the following steps. It is required that you have authorized your computer,
and that you are signed in to your Line 6 account in POD Go Edit to initially import or
export them. Once imported into POD Go Edit, no active Internet connection is
necessary to utilize your Marketplace IRs. Please see for “Marketplace & Account
Options” on page 34 details.
To Import an IR, rst select the desired index location in the application's Impulses
list and, from the File menu (or IR slot’s right-click menu), choose Import. Select the
desired IR le you wish to load onto your device. It is also possible to select multiple
IR les and all will be imported in one action.
To Export an IR, rst select the desired index location in the application’s Impulses
list and from the File menu (or IR slot’s right-click menu), choose Export.
You can also drag and drop to and from the Impulses list to export and import IRs—
see the following section.
NOTE: When exporting IRs from the POD Go Edit Impulses list, any
Marketplace-purchased IR is saved to your computer as a Helix IR (.hir) type
le. The .hir les are proprietary to Line 6 products, and licensed to you via the Line
6 Account on which you purchased them. Any IR that was originally imported as a
.wav le is exported as a .wav le.
TIP: Use the File menu's Create Backup & Restore From Backup options to
create a backup of your Impulses list's contents, and restore from the backup, at
any time—see “Creating & Restoring Complete Device Backups”.
9
Premium Marketplace IRs
If you’ve purchased and downloaded premium IRs from the Line 6 Marketplace (see
page 34), you must be signed in to your Line 6 account within POD Go Edit, which
authorizes your computer to allow POD Go Edit to initially import or export these IRs
(as well as for the restore of any backup that includes premium IRs).* Marketplace
premium IRs are proprietary to Line 6 POD Go and Helix family products, and are of
the .hir le type.
NOTE: When exporting IRs from the POD Go Edit Impulses list, any
Marketplace-purchased IR is saved to your computer as a Helix IR (.hir)
type le. The .hir les are proprietary to Line 6 products, and licensed to you via
the Line 6 Account on which you purchased them. Any IR that was originally
imported as a .wav le is exported as a .wav le.
• Copy - It is also possible to drag and drop IRs within the Impulses list to
create a copy of the IR in a new index location.*
*NOTE: Once you've initially imported your Marketplace assets to sync their
licenses with your account, you don't need to have POD Go Edit actively signed
in to use them—and it is not necessary to even be connected to the Internet once
your computer has been authorized. Please see “Authorize / Deauthorize Your
Computer” on page 36.
Premium Marketplace IRs are otherwise able to be utilized just like any of your other
IRs within the Impulses library. When imported, these premium Marketplace .hir IR
les are indicated by guitar pick “badges” to their right.
Premium Marketplace IRs are indicated with golden guitar pick badges
Renaming, Copying, Pasting & Clearing IRs
These actions can be performed by selecting their respective commands from the
Edit menu. You can also right-click to choose these options from the context menu of
any IR’s index slot (or use the app's “Keyboard Shortcuts”).
Drag and Drop IRs
There are several drag and drop options that allow you to import and export single,
or multiple, IR les between your computer’s directories and POD Go Edit, as listed
below.
• Import - Drag one or more IR les from your computer folder directly into
the Impulses list. When multiple les are being dragged in, they are imported
starting with the selected IR index slot.
• Export - Select one or more IR index locations and drag from the Impulses
list directly to your computer to export the IR les to the selected hard drive
folder.
*NOTE: There are no options oered to move or reorder IRs in a single
operation. Use the Copy, Paste and Clear functions to rearrange IRs within
the Impulses list as needed. (Also see the following “IR File Reference” section.)
Loading an IR in an IR Block
Once you’ve imported IR les into the IR Library, the easiest way to load an IR into
your current preset is to simply click on the Impulses folder icon to display the IR
Library, then double-click on the desired IR within the library list. This automatically
changes the Cab/IR block to the IR category within the Signal Flow (if it is not
already), and loads the selected IR le within it.
Just double-click on any IR within the Impulses list to load it in the IR block
If you select the Cab/IR block directly within the Signal Flow, and then choose the IR
category, it initially defaults to referencing the IR that resides within the #1 IR index
location. (If you have not yet imported any IR le into the referenced index location,
the “empty” IR block has no audible eect on the signal.)
NOTE: The use of an IR block requires a higher amount of Digital Signal
Processor (DSP) usage as compared to a standard Cab model. A pop-up alert
will let you know if your preset encounters the DSP limit, preventing the loading of an
IR—please see “DSP Management & Model Availability” on page 23.
10
To load an IR using the IR block’s Edit panel options, select the IR block within the
Signal Flow, then in the Edit panel, use the IR Select parameter slider (or its menu
button at the right) to select IR index number (1-128) that includes the desired IR.
Please also see “IR File Reference” for additional behaviors.
Choosing an IR by its Library (1-128) index number within the Editor
You can use the other IR block parameter sliders in the Edit panel to further shape the
IR's tone (Low Cut, High Cut, Level, etc.)—also see “Editing Model Parameters” on
page 21. Once done selecting an IR and its parameter options, be sure to save the
preset to retain your IR block settings.
Whenever you load a preset where its IR block references an empty IR index location,
or if the originally associated IR le that was last saved with this preset can no longer
be found within your IR library list, a pop-up is displayed to alert you.
IR File Reference
Once the preset’s IR block is congured to utilize an IR index slot that includes an
imported IR (.wav or .hir) le, and the preset is then saved, the preset creates a
“reference signature” to the imported IR from its le name. Therefore, if you re-order
IRs within the IR library list, your preset will still intelligently reference the originally
associated IR le, even though it now resides in a dierent IR Library index location.
The following behaviors apply:
• If you clear or replace the IR le within the IR index slot for which the preset’s
IR block is congured to use, upon the load of the preset, the IR block will rst
attempt to locate another instance of the missing, associated IR le within the
Impulses list and automatically utilize it and its residing index slot.
• If the congured IR index slot is currently empty, you’ll be alerted that the
IR block’s associated IR le cannot be found (see previous section). The IR
block continues to utilize the same (now empty) IR index slot. You’ll want to
congure the IR block to utilize an occupied IR index slot (or import an IR
into the currently referenced slot) and save the preset.
• If the original IR le is cleared from the Library and the IR index slot now
includes a dierent IR le, you’ll be alerted that the associated IR cannot be
found, and the IR block utilizes this new IR le within the congured index
slot. You’ll need to save the preset with this reference to the new IR (or
congure the IR block to use a dierent, occupied IR slot) to avoid seeing
the alert pop-up on future loads of the preset.
• Once an IR block is congured with an IR Library index selection, and the
preset is then saved, the IR (.wav or .hir) le retains this reference signature
when exported from the library—thus, even if you import the exported IR le
again into any index slot within your Impulses Library, the saved preset’s IR
block will still be able to locate and utilize it.*
Yes, the above rules all sound a bit complicated, but in typical use, all this really just
means that if you happen to move your IRs around in the IR Library list, your saved
presets will not lose their links to them!
NOTE: We highly recommend using the Create Backup feature within POD Go
Edit to make it easy to restore your complete preset and IR libraries (see page
16). Immediately after performing a Restore From Backup, it is also best to power
your device o and on again and allow all presets to “rebuild,” for best preset
performance and IR le reference functionality.
Empty or missing IR alert pop-up
To avoid seeing the above alert, the best practice is to always make sure to load an
actual IR for your IR block (rather than leave the block assigned to an “Empty” IR slot),
then save your preset.
11
Working in the Editor
The Editor portion of the POD Go Edit user interface consists of the Signal Flow and Edit/Model Select panels. The Signal Flow panel is where you'll see the signal path for your
currently-loaded preset, appearing much like the Home - Edit screen of your POD Go device. The lower Editor portion of the window contains the, Edit/Model Select panel, and the
Edit panel’s Bypass/Control inspector, all of which allow you to select models, tweak parameters, congure bypass & controllers assignments, and more. Regardless which of these
panels you have displayed, the current preset's Name Field, Save, Snapshots, Undo, & Tempo options are always available at the top of the Editor. Additionally, there is a dedicated
window for the Global EQ (see page 31), accessible from the application's Window menu. If you have not already done so, be sure to read through the in-depth information in
your device's Owner's Manual to get an understanding of the features we'll be covering in the following sections.
Next/Previous
Preset Button
Signal Flow Panel
Edit / Model Select
Panel
Preset Name
Field
Preset Save
Button
Snapshots
Menu
Undo / Redo
Buttons
Tempo
Controls
The Editor portion of the POD Go Edit application (Edit panel displayed)
12
Naming & Saving the Preset
The Preset Name eld at the top of the Editor displays the title of the currently loaded
preset. Click directly on the text here to optionally rename the preset. Whenever you
see your preset's title appearing in italicized text at the top of the Signal Flow panel, it
indicates that the preset has been edited from its last-saved state.
The Preset Save button at the top of the Editor launches the Save To Setlist window,
where you can optionally re-title the preset, and choose the desired setlist (Factory or
User) and preset location (01A - 32D) to save the currently-loaded tone, overwriting
the preset that resides within the selected location. (The currently loaded preset is
selected by default, so you can overwrite it simply by clicking the Save To Setlist
window’s OK button.)
The Preset - Save To Setlist window
Alternatively, you can choose the Preset Save or Preset Save As command from the
File menu. As covered in “Factory & User Setlists” on page 7, there are also the
Librarian panel options, Copy and Export, to create & store copies of your presets.
TIP: If you’re just wanting to save the current preset within its existing setlist
location, it is fastest to use the Command+S (Mac) or Ctrl+S (Windows) keyboard
shortcut.
There are two ways to select a snapshot within POD Go Edit: by clicking on the
Snapshots (camera icon) menu at the top of the Editor, or by using the commands
within the application's Snapshots menu.
To edit its settings, select the numbered snapshot you want as your destination, then
congure the desired block and signal ow options that you wish to be stored and
recalled this snapshot.*
The Editor Snapshots menu The menu bar's Snapshots menu
*NOTE: You can use your device's Global Settings > Preferences > Snapshot
Edits to choose between Recall (automatically stores your changes to the
current snapshot) versus Discard (does not store changes to the current snapshot).
The camera icon within the Editor's Snapshots menu is displayed in red when the
hardware's option is set to Discard.
Once your desired destination snapshot has been selected, use the following steps to
congure your settings.
To Store a Block's Bypass State Per Snapshot
Click on the Bypass button above any block within the Signal Flow and set your
desired bypass state for the block (or you can toggle the block's Bypass button
within the Edit panel). Any amp or eects block’s Bypass state will, by default, be
remembered and recalled per snapshot.
If you prefer to exclude a block from being controlled by snapshots, select the block
and set the Snapshot Bypass option from the block’s right-click menu to “O” (so
that no check mark appears at the left of the menu option). Choosing the Snapshot
Bypass option from the menu again (so that the check mark appears at the left of the
menu command), returns the block to the default snapshot behavior.
Configuring & Managing Snapshots
Your device oers the ability to congure the four snapshots within a preset, allowing
you to recall a customized set of options for your current blocks instantly, without the
brief lag time associated with changing presets! A snapshot is capable of storing the
bypass state of any block, up to 64 assigned parameter values, tempo settings and
more (please see the POD GO Owner's Manual for specics).
The Block - Snapshot Bypass option
13
To Store a Parameter's Value Per Snapshot
To store any block parameter’s value per snapshot, it is rst necessary to create
a snapshot controller assignment for the parameter (other than for the Bypass
parameter - see preceding section). Whatever specic value you set the parameter to
is then remembered and recalled per snapshot for the snapshot-assigned parameter.
There are a few ways to create a snapshot assignment within POD Go Edit (also see
“Creating a Controller Assignment” on page 28).
In the following example, we’re creating a snapshot assignment within the Edit panel
for the Amp block’s Drive parameter.
1. Double-click on the Amp block within the Signal Flow to select it and display
its parameters within the Edit panel below.
2. Left-click on the assignment indicator area to the left of the Drive slider (or
right-click directly on the slider) within the Edit panel to the display the Select
a controller panel.
5. Repeat the last step with up to all 4 snapshots, setting the desired Amp - Drive
parameter value dierently as desired for each.
Optionally, repeat the above steps to create snapshot assignments for additional
parameters, allowing all to have your determined values recalled per snapshot!
Each preset can have up to 64 controller assignments, including parameters
controlled by Snapshots. Remember to save your preset to retain your snapshot
settings. Please also see “Bypass & Controller Assignment” on page 24 for
more info.
To Remove a Snapshot Assignment from a Parameter
If you wish to stop an assigned parameter from responding to snapshot changes,
repeat the above steps and simply choose the None button within the Select
Controller panel to remove the snapshot assignment from the parameter.
NOTE: To exclude a block’s bypass state from being recalled via snapshot, use
the Snapshot Bypass option - see “To Store a Block’s Bypass State Per
Snapshot” on page 13.
NOTE: If the parameter you are conguring already has an existing footswitch or
EXP pedal assignment, you’ll see its icon displayed in the assignment indicator
area, left of the parameter. You can still click on it to display the Select a controller
panel, and make a Snapshots assignment, but this will replace the existing
assignment.
3. Click on the Snapshots Controller selector to create the assignment, and close
the Select a controller panel.
Right-click on the parameter
Left-click in
indicator area
Click the Snapshots controller selector
Creating a snapshot assignment via the Select a controller panel
TIP: Even quicker... Hold the Alt/Option key and left-click on the Drive parameter
to instantly snapshot-assign it (or to remove an existing snapshot assignment)!
4. Load the desired snapshot (see page 13) and set the Drive slider to the
value you wish to be stored with this snapshot. (Note that the camera icon
is displayed to the left of the Drive slider now to indicate the parameter is
snapshot-assigned.) These stored values are recalled when jumping from
snapshot to snapshot, and appear as you last left them per snapshot.
Copying & Pasting Snapshots
The Copy and Paste Snapshot commands are available within the app's main
Snapshots menu. Or, right-click on the Edit panel's (camera button) Snapshots menu
to access these commands.
The main Snapshots menu The “camera” icon Snapshots right-click menu
To Copy & Paste a Snapshot - It is possible to copy all the settings of one snapshot
and paste them to another snapshot within the same preset, which can be a big
time-saver if you just want to make a few changes per snapshot. Select and load
the snapshot you wish to copy and select Copy. Then select and load the target
snapshot you wish to overwrite and choose Paste to paste the clipboard contents.
NOTE: The action of pasting a copied snapshot is not tracked by the POD
Go Edit Undo / Redo feature (see next section).
NOTE: Remember that you'll need to Save before switching to another preset to
retain your edited snapshot settings within the current preset! The snapshot that
is in use when you save your preset is the one that is recalled when the preset is
loaded again.
14
Undo / Redo
The POD Go Edit application supports Undo and Redo for most editing actions within
the Signal Flow and Edit panels of the current preset, whether the edits are made
within POD Go Edit or directly on the connected hardware, accessible via the Undo
and Redo buttons at the top of the main window (or from the Edit menu).* Your Undo
/ Redo history is retained until you load a dierent preset, exit the application, or
disconnect or power o your connected POD Go device.
*NOTE: Also see “Software Edits vs. Hardware Edits” on page 15 for
additional behavior details.
The Undo and Redo buttons
Undo is available for most actions performed within the Signal Flow and Edit
panels within POD Go Edit, including:
• Parameter changes
• Snapshot selection
• Block category and model changes
• Signal path changes (block bypass states, moving blocks, etc.)
• Hardware edits and edit actions performed via external controller and USB MIDI
CC & PC messages (see “Software Edits vs. Hardware Edits” on page 15)
Actions that are not available for Undo/Redo include the following:
• Tempo changes
• Actions performed within the Presets/Impulses Librarian panel (e.g., changing
setlists, loading a dierent preset, importing, reordering, pasting presets or
IRs, etc.)
NOTE: The application’s Undo history is cleared whenever a dierent preset
is loaded .
• Adding, editing, and removing snapshot, bypass, and controller assignments
NOTE: Note that when Undo restores the removal of a model that
includes assignments, in most cases, these assignments are restored
with the model, but in some cases may not be able to be retained.
• Pasting a copied snapshot
• Changes to any settings within the POD Go Edit Preferences and Global EQ
windows
NOTE: The Undo button and Edit menu command remain unavailable (dimmed)
until an undo-able action is performed. Likewise, Redo remains unavailable until
an Undo action is applied.
Software Edits vs. Hardware Edits
Edit actions performed within the POD Go Edit application (or “software edits”) are
tracked individually for Undo / Redo. For example, if you adjust a POD Go Edit
parameter slider, move a block, and then change a block’s model, these actions are
reverted individually—one action per each click of Undo.
Edit actions performed directly on your connected device and via footswitch/pedal
controller (or “hardware edits”) are aggregated into a separate, single undo-able action
within the Undo history. Therefore, if you perform a number of hardware edits and
then choose Undo, all such edits are reverted in one click of Undo. Likewise, selecting
Redo after performing an Undo of several hardware edits restores all the hardware edit
changes in one click of Redo.
Editing the Tap Tempo
There are a few options available for conguring the tempo, accessible from the
Tempo Controls at the top of the Signal Flow window. Any of the current preset’s
eect models set to note division values will follow this Tap Tempo value. (Note Sync
mode is available for most delay and modulation eects—see page 21.)
Tempo Select
Menu
The Tempo Controls
How the Tempo Value is Recalled
Use the Tempo Select menu to choose how the tempo value is saved and recalled
(this is the same option found in your POD Go hardware's Global Settings > MIDI/
Tempo screen):
• Per Snapshot - The tempo value is stored and recalled individually per
snapshot for the current preset.
• Per Preset - The tempo value is stored and recalled individually with this
preset.
• Global - The tempo value is used for all presets (any tempo value saved with
a preset or snapshot is ignored).
NOTE: Your POD Go device's tempo can also be congured to follow MIDI Clock
from an external (computer software - USB) source, accessed from within your
device's Global Settings > MIDI/Tempo screen.
When your device is actively following MIDI Clock, all options for the Tempo
Controls are disabled and the Tempo value displays as “[External].”
Entering a Tempo Value
To enter a value, click on the Tap Tempo button rhythmically, or right-click directly on
the Tap Tempo button and type in your desired numerical value.
Tap Tempo
Button
15
Creating & Restoring Complete Device Backups
Use the File menu's Create Backup and Restore From Backup commands to create
complete backups of your POD Go device's current Global Settings, IRs, and Presets,
and easily restore them back to your device at any time. All presets are backed up
from their last-saved state, therefore, be sure to save your currently-loaded preset
before creating your backup to include its current settings.
NOTE: If you have purchased and imported Marketplace premium IRs, your
computer must be in the Authorized state to be able to use the Create Backup
and Restore From Backup features, if the backup includes Marketplace premium
assets. See “Authorize / Deauthorize Your Computer” on page 36.
To Create a Backup
Select the Create Backup command from the File menu to launch the window.
9. Click Create Backup and you'll see the progress of your backup being created,
and a message once completed successfully (or click Cancel to exit without
creating a Backup).
You can repeat the above steps at any time to create as many individual backups
as you like. All backup les are then available within the Restore From Backup
window.
TIP: It is highly recommended to create a full Backup before installing device
rmware, and to perform backups regularly to make sure you always have copies
of your tones, IRs and settings!
To Restore From a Backup
Select the Restore From Backup command from the File menu to launch the
window.
The Create Backup window
6. Name - Your backup le is automatically named with “POD Go Backup” and
the current date. Optionally, you can click directly on the le name here and
edit it as desired.
7. Description - Optionally, type in some descriptive notes about this backup. All
text added here is saved with your backup, and viewable during the Restore
From Backup process.
8. Where - By default, your Backup le (.pgb) is saved to the following directory
on your computer:
• Mac - /Documents/Line 6/POD Go/Backups folder
• PC - \My Documents\Line 6\POD Go\Backups folder
If you wish to save to a dierent folder, click the folder button and browse to
select your preferred disk location.
The Restore From Backup window
1. Backup Folder - The default or most-recently used Backup folder is selected
here. If you want to nd a backup le in a dierent folder, click the folder
button to browse to the desired location.
16
2. Backup File - By default, the most recently created Backup le is selected.
All compatible Backup les that you created within the currently selected
directory are selectable here. When you select a backup le, the following
information is displayed so you know the details about the backup before you
choose to restore from it.
• Date: The creation date of the backup le.
• Device: The specic type of device this backup was created from (POD Go).
• Version: The rmware version installed on the device when the backup was
created.
• Description: Any notes that you entered within the Description eld when the
backup was created appear here.
3. Items to Restore - In the lower pane, you can select the individual items you
wish to be restored from the selected backup le: Global Settings, Impulse
Responses*, and Presets. Whichever items you select here will be restored,
overwriting those currently on your device.
*NOTE: If your backup includes premium Marketplace IRs within its Impulses
library, you’ll need to be Signed In within the POD Go Edit application to
allow the Marketplace-purchased IRs to be restored. Please see “Sign In / Sign
Out” on page 35.
TIP: Note that by clicking on the arrow to the left of the Presets checkbox,
you can expand the option (as pictured above) to individually choose
whichever setlist(s) you want to restore from the selected Backup!
4. Click Restore Backup and you'll see the progress of the restore process, and
then a pop-up message once completed successfully (or click Close to exit
without restoring). Do not disturb the POD Go Edit application or device until
the Restore process is complete.
TIP: If the Backup that you restored includes any presets or setlists, it is
recommended to power your device o and on again to allow it “rebuild” the
presets. This process optimizes preset loading times on the hardware.
You can repeat the above steps at any time, and select any available POD Go
Backup le stored on your computer.
17
Signal Flow Panel
The Signal Flow panel allows you to directly access all blocks within your preset and
congure your signal path routing simply by clicking and dragging. Once you select
any block within the Signal Flow, the Edit panel below provides access to all its
editable parameters. The options oered here are essentially the same as found on
your connected POD Go device’s Home - Edit screen, making editing very straightforward.
Input
Volume
(Preset)
Bypass/Control
Panel Toggle
Wah
(Preset)
Eects
FX Loop
(Preset)
Selected Block’s
Category and Model
The Signal Flow panel (Amp/Preamp block selected)
Amp/Preamp
(Preset)
Cab/IR
(Preset)
Edit/Model Select
Panel Toggle
Preset EQ
(Preset)
Eects
Block Types
The signal path of all POD Go presets include a combination of “Preset” and
“Eects” blocks, as well as Input and Output blocks. It is important to understand
the functions of these block types and their behaviors, as covered below. Also see
“Model Lists” on page 37 for the lists of all models by category.
Preset Blocks
Whenever you load any preset, you’ll see that it always includes a common set
of Preset blocks within the Signal Flow. These blocks include a dedicated model
category type or function, as described below. Even when loading a “New Preset,” it
already includes these pre-congured Preset blocks, as well as the four empty Eects
blocks, and an Input and Output block.
Note that all blocks (other than the Input and Output) can be moved left/right within
the Signal Flow, and can be bypassed/enabled, but Preset blocks are never “empty”
and oer a limited category of models. Please also see your POD Go Owner’s Manual
for more details about block and model types.
Volume - By default, this block is set for the Volume Pedal model—you can
alternatively change the model to Gain, Pan, or Stereo Width. The EXP 2 pedal is
auto congured to control the Volume’s “Position” and the Pan’s “Pan” parameters,
and the block’s Bypass is initially auto assigned to the onboard pedal’s Toe Switch.
Wah - Select your favorite Wah model and have at it. By default, the Wah block’s
Position parameter is auto assigned to the EXP 1 pedal, and its Bypass assigned
to the onboard pedal’s Toe Switch.
Output
TIP: These pre-existing EXP pedal and Toe Switch assignments can be
customized as desired—see “Bypass & Controller Assignment” on page 24.
FX Loop - Utilize the Send and Return jacks on your POD Go device to connect
to and from external gear, and this block provides control over panning and levels.
You can choose a Mono or Stereo FX Loop type block to match your jack routing,
as well as bypass or enable the block as desired.* By default, the FX Loop block’s
Bypass is assigned to Footswitch 2.
*NOTE: It is also possible to congure your Return jack as an Aux. Input, with
the device’s Global Settings > Ins/Outs > Return Type parameter. When
the Return Type parameter is set to Aux In, signal throughput from all inputs
other than the Return jack is muted when the FX Loop block is enabled (and the
Aux in itself remains active regardless of the FX Loop block’s bypass state).
Amp/Preamp - Choose any Amp or Preamp model type, or bypass the block.
Cab/IR - Choose any Speaker Cabinet model, or select the IR category to utilize IR
les that you’ve imported into your IR Library - see “Impulses List” on page 9.
Preset EQ - This yellow block is a dedicated EQ. By default, the Parametric EQ
model is loaded here (and in the bypassed state), but you can optionally choose to
load any other EQ category model type within this block. By default, the Preset EQ
block’s Bypass is assigned to Footswitch 1.
TIP: Need more EQ? You can optionally utilize any of the four Eects blocks to
load EQ category models too.
NOTE: All Distortion, Dynamics, Pitch/Synth, Amp/Preamp, Cab/IR, FX Loop,
and Looper category models (whenever the “Mono” type FX Loop or Looper is
in use) are mono. Any stereo block that is positioned to the left of one of these
mono blocks will result in its output being summed to mono when fed into the mono
block. Therefore, for your stereo eects to be heard in full stereo, you’ll want to
position them to the right of all mono blocks in the signal path. Bypassed blocks do
not collapse any stereo signal fed into them.
Effects Blocks
Clicking on any of the four Eects blocks allows you to choose from any category of
eects or a Looper. Regardless of the model type selected, Eects blocks can always
be moved and toggled between bypassed or enabled. When an Eects block is set to
None (or cleared), the signal passes through it unprocessed.
TIP: An Eects block utilizes DSP power on the device when active or bypassed,
but utilizes no DSP if set to None. Also see “DSP Management & Model
Availability” on page 23.
Input and Output Blocks
Clicking on the Input and Output blocks, just like other block types, displays their
parameters within the Edit panel below, and most parameters can also have controller
and snapshot assignments created on them. Input and Output blocks are not movable
within the Signal Flow.
18
Moving Blocks
To move blocks within the signal path, simply click and drag any block left/right to
its desired location on the signal path, and drop it there. As noted in the preceding
sections, you’ll want to take note of mono and stereo blocks and arrange your blocks
accordingly to achieve the desired mono/stereo output from your device.
TIP: A block can also be copied and then pasted into a dierent preset!
The Clear commands are handy to “reset” any of the four Eects blocks.
• Select any Eects block and use the Clear Block to remove the block’s model
and set it to None. Alternatively, use the “X” button that appears when you
hover your mouse cursor over an Eects block to clear it.
Bypassing Blocks
To toggle the bypass of any Preset or Eects type block - do any of the following:
• Hover your mouse cursor over a block within the Signal Flow and use the
Bypass button that appears above the block.
• Right-click on the block and choose Bypass from the context menu.
• Click on the desired block to select it, then use the Bypass button within the
Edit tab.
• Click on the desired block to select it and hit the Spacebar.
• A block’s bypass state, by default, is also stored and recalled with each
Snapshot (see “Conguring & Managing Snapshots” on page 13).
Copying, Pasting, & Clearing Blocks
Once you’ve selected the desired block within the Signal Flow, these commands are
accessed either from the menu bar’s Edit menu, or from a block’s (right-click) context
menu (or via keyboard shortcuts—see page 48).
Block Cut, Copy, Paste & Clear commands are available in the Edit menu or block’s context menu
Use the Copy Block command for any type of block, and then select the Paste Block
command to paste it, with all its current settings & assignments, into the same or
dierent block location, with the following results.
• Preset, Input, and Output type blocks can be copied and then pasted only
back into the same block type. For example, you can Copy your current Amp/
Preamp (Preset) block to capture all its settings, experiment with other Amp/
Preamp models and settings, and then Paste back into the Amp/Preamp
block to “restore” your copied model and settings again.
• Eects type blocks can be copied and then pasted into any other Eects type
block.
• Since only one Looper can exist within a preset, a Looper block can be
copied, but only pasted back over the existing Looper block, or pasted into
another Eects block if the original Looper block is rst cleared.
Bypass Clear
When hovering over a block, you'll see its Bypass and Clear buttons appear
NOTE: Preset type blocks cannot be cleared, therefore, you’ll see only a Bypass
button appear when hovering over any Preset type block.
Bypass Assignment Indicators
You may notice the labels oating above some blocks within the application’s Signal
Flow—this indicates when block has an existing bypass assignment, and which
footswitch it is assigned to—as well as oers access to quickly create and edit
footswitch and EXP pedal bypass assignments.
Bypass assignment indicators
For example, in the preset above, the Wah and Volume blocks’ bypass is toggled via
the pedal’s toe footswitch (EXP Toe), the FX Loop block by footswitch 2 (FS2), etc.
When you hover your mouse cursor over this indicator area of a block, you’ll see a
menu button appear (white down arrow), letting you know you can click in this area to
display the Bypass Assign panel - see the next section. For any block that does not
have an existing bypass assignment, if you hover your mouse cursor above the block,
you’ll see the [None] indicator label appear.
A menu button appears when hovering over a block’s assignment indicator area
19
Quick Bypass Assign
There are a few ways to create and edit bypass assignments for any block directly
within the Signal Flow—by using the block’s right-click menu commands, or via the
quick Bypass Assign panel. (The Edit panel’s Bypass/Control screen oers even
more options—please also see page 24.)
Bypass Assignment using the block right-click menu
Right-click on any Preset or Eects block, or directly on the assignment indicator label
above the block, and choose Bypass Assign, where you can select any footswitch or
EXP pedal to create a bypass assignment, change an existing bypass assignment, or
choose the None button to clear the block’s assignment. You’ll also see any existing
assignments within the sub-menu.
Existing bypass and
controller assignments
are shown in brackets
Bypass Assignment using the Bypass Assign panel
Right-click directly on the assignment indicator above a block within the Signal Flow
and the Bypass Assign pop-up panel will appear.
Within this panel, if a bypass assignment already exists for the block, you’ll see
its controller selector highlighted (as shown below). You can simply click on any
footswitch or EXP pedal controller selector to quickly create a bypass assignment,
change an existing bypass assignment, or choose the None button to clear a block’s
assignment.
Left-click on the assignment indicator
Right-click on
the block within
the Signal Flow
Accessing the Bypass Assign panel for a block within the Signal Flow
NOTE: You can create assignments to FS7 or FS8, but you’ll need to have the
device’s Global Settings > EXP2 FS7/8 option (see page 32) set to FS7/8
(as well as one or two external footswitches connected to your device) to be able to
utilize them.
You can also create bypass and controller assignments using the EXP Toe switch
as the footswitch.
The block right-click Bypass Assign menu
20
Edit/Model Select Panels
The Inspector portion of the Editor toggles to show either the Edit panel, where all
parameters for the currently selected block can be edited, or Model Select panel,
where any available model can be loaded for the currently selected block. At the top
of the Inspector, the Category and Model Name in use by the currently selected
block appears, followed by the Edit/Model Select toggle button. Just click on any of
these items to switch between displaying Edit or Model Select panel.
The Edit/Model Select toggle button
Inspector - Edit panel Inspector - Model Select panel
TIP: Double-click directly on any block within the Signal Flow to display the Edit
panel and the block’s parameters. Us the M shortcut key to display the Model
Select panel.
Adjusting Parameter Sliders - There are several ways to adjust slider values:
• Click on any slider and drag to the desired value.
• Click on the desired range location within a slider's path and it will jump to the
clicked value.
• While hovering your mouse cursor directly over any slider's path, use your
mouse wheel to adjust it.
• Click the up/down arrow buttons at the right for small, incremental
adjustments. If a down arrow is displayed at the right, click on it to expand its
menu.
• Right-click on any parameter to display the Select a controller panel to create
and edit controller and snapshot assignments (see page 28).
Most parameters are represented by sliders within the Edit panel, however, you’ll
see some models utilize switch type parameters, such as the Speed parameter of
some Modulation models, or the Ratio of most Compressors. All such parameters
can still be adjusted using the same functions, and can have controller and
snapshot assignments created for them.
Switch type parameters within the Edit panel
Type in a Precise Value - Double-click anywhere on a parameter, or on its value,
to manually type in a precise numerical value.
Reset Value - If you're not happy with your parameter adjustment, Cmd+Click
(Mac) or Ctrl+Click (Windows) on the slider/switch to reset it to its initial default
value.
Accessing All Parameters - Note that some model types, such as amps and
complex eects, may have more sliders and controls than you can see all at once
in the Edit panel. You can re-size the application window, or click and drag the
vertical scroll bar at the right to access all parameters (or use your mouse wheel
when hovering your mouse cursor over the scroll bar).
Editing Model Parameters
When the Edit panel is displayed, simply click on any block within the Signal Flow to
select it to display and tweak its parameters. To follow are a several editing tips (also
see “Keyboard Shortcuts”).
Toggling Block Bypass - A Bypass button is available at the top right of the
Edit panel for any block that oers a bypass option. When bypassed, the category,
model, and all parameters appear dimmed to indicate this state.
Edit panel - block enabled Edit panel - block disabled
Note Sync - Most modulation and delay eects models oer a Note Sync option,
allowing the modulation rate or delay repeat time to follow the device's main Tap
Tempo value (see “Editing the Tap Tempo” on page 15). For models that oer it,
click the Note Sync button within the Edit panel to toggle the feature on/o. When
active (the Note Sync button is lit), the parameter will change to oer note division
values within its menu, as shown below.
Note value options Note Sync (active)
A Delay block congured for Note Sync
21
Impulse Response Block Options
When an IR block is selected in the Signal Flow, you'll see IR block parameter sliders
here in the Edit panel, just like for any other block. Remember that you'll need to
import IR les into your POD Go device using the application's Impulses library for
an IR block to utilize them—see “Importing and Exporting Impulse Responses” on
page 9.
Looper Block Options
When a Looper is added within an Eects block, you’ll see several Looper parameters
within the Edit panel. However, it is not possible to toggle the Looper mode of your
connected device on and o within the POD Go Edit application.
Input and Output Block Options
When the Input or Output block is selected in the Signal Flow, you’ll see its edit
parameters available in the panel (regardless whether in the Edit or Model Select
view). These options are stored per preset.
• Input Block: Choose between the Guitar input or USB 3/4 (also see your
POD Go Owner’s Manual for the USB recording and Re-amping functionality).
The Input block’s Noise Gate On/O, Threshold, and Decay parameters are
available.
• Output Block: The Main 1/4” output’s Pan and Level options are available.
TIP: Global options are also available within your device’s Global Settings > Ins/Outs
screen
Controller Assignment Indicators
Once a snapshot, footswitch, or EXP pedal type controller has been created for a
parameter, you’ll see an assignment icon appear to the left of the slider within the
Edit panel, as well as the parameter’s values displayed in brackets and white text.
Parameters with footswitch and EXP pedal type controller assignments will also
display Min. & Max. value indicators, to allow you to adjust the control range.
Snapshot assignment Values in brackets & white text
• EXP Pedal Controller Assignment - For any controller assignment made
to an EXP pedal, you’ll see the numbered pedal icon to the left of
the parameter, numbered to indicate EXP 1 or EXP 2.
• FS Pedal Controller Assignment - For any controller assignment made
to a footswitch, you’ll see the numbered switch icon to the left of
the parameter, numbered to indicate FS1~FS8.
• Snapshot Controller Assignment - For snapshot assignment, you’ll see
the camera icon to the left of the parameter.
Not only are these indicators a nice reference to see your existing assignments while
editing, but you can also click directly on this indicator area (even if no icon appears
there) to open the Select a controller panel to quickly access controller settings.
Click to show/hide the main Bypass/Control window
Click indicator area to show
the Select a controller panel
For conguring all detailed assignment options, click the toggle button to show
the Edit panel’s larger Bypass/Control window. Note that the Bypass/Control window
appears within the Edit panel, and remains displayed until you choose to hide it—
please see “Bypass & Controller Assignment” on page 24.
TIPS:
Right-click on a parameter slider or switch to display the Select a controller panel
where you can create a controller or snapshot assignment for the parameter—also see
page 28.
Alt+Click directly on a parameter within the Edit tab to instantly create a snapshot
controller assignment for it (or to remove an existing snapshot assignment)—see page
13.
By default, all blocks’ bypass states are automatically stored and recalled per snapshot.
If you prefer, you can exclude a block’s bypass state from being recalled via snapshot
changes—see page 13.
Controller assignment (assigned to FS2) Min. & Max. indicators
Indicators for existing controller assignments within the Editor
22
Selecting Models
As mentioned above, select any block within the Signal Flow, and when the Model
Select panel is shown, you’ll see options for selecting the desired category and its list
of models. Click on the desired model to load it in the selected block.
Category
selector
Model selector
Current model’s icon
and category
The Model Select panel (Eects type block selected)
Current model’s
name
DSP Management & Model Availability
Rather than limit you to a lower number of blocks or a reducing audio quality, POD
Go utilizes a dynamic Digital Signal Processor (DSP) management system for model
selection. Some models, such as “jumped” amps and more complex reverb and delay
eects, utilize a greater amount of DSP resources. When conguring a preset with
several heavy DSP usage models, the DSP management system kicks in, allowing you
to still utilize your blocks by disallowing the addition of only the models that exceed
the DSP limit of the preset.
As in your POD Go device’s Model Select menu, when the current preset reaches a
high DSP usage, models that cannot be accommodated become unavailable. In the
POD Go Edit app’s Model Select panel, you’ll see models dimmed to indicate this, as
shown below.
What appears in the panel diers per the type of block that is selected within the
Signal Flow, as described below.
Eects type block - The full set of eects categories are displayed (as shown
above). Click on the desired category to see and choose one of the category’s
eects models. Note that you can choose the None category to clear the Eects
block.
Preset EQ, Wah, Volume, or FX Loop type block - Since these blocks include
just the one category, you’ll see no Category selectors —just the block’s available
models.
Amp/Preamp type block - The Amp and Preamp categories are shown, with
their models available within each.
Cab/IR type block - The Cab and IR categories are shown. The Cab category
includes the full list of cab models. The IR category oers a 1024 Sample IR
category, for which you can choose the desired IR le from your Impulses library.
Please see “Loading an IR in an IR Block” on page 10.
Input or Output block is selected - Whether the panel is in Edit or Model Select
view, you’ll always see the edit parameters available within the panel. See the
previous section
Unavailable models appear dimmed when the preset’s DSP limit is reached
It is also possible to encounter the DSP limit when attempting to load an IR by doing
a double-click upon an IR within the Impulses library (see”Loading an IR in an IR
Block” on page 10 ). When adding an IR to your tone this way where it would
exceed the DSP limit, you’ll be prompted with an alert that the DSP usage of the
current preset does not allow IRs to be loaded.
To free up more DSP resources for the current preset, try changing or removing some
models. The Distortion, Dynamics, EQ, as well as the “Simple” titled eects are typically the
lower DSP usage models. Using one of the Cab models rather than an IR within the Cab/IR
block can reduce DSP usage as well.
23
Bypass & Controller Assignment
Just as on your POD Go device, the POD Go Edit application oers several ways to
create and edit bypass and controller assignments to the footswitches and expression
pedals on your device. As covered in the previous chapters, bypass, snapshot, and
controller assignments can be quickly created and edited directly within the Signal
Flow and Inspector - Edit panel. Within the Edit panel, the Bypass/Control window
oers additional options for deeper work in creating and editing assignments. We’ve
included several step-by-step instructions within this chapter for assignments.
The Bypass/Control Window
When the Edit panel is displayed, you can show or hide the Bypass/Controller panel,
by clicking on the toggle button.* When the Bypass/Control window is shown, it
provides options for the block that is currently selected within the Signal Flow. For
example, in the screenshot below, the Eects block containing the Optical Trem
model is selected, and the panel shows its existing bypass assignment is set to FS6.
The panel’s Parameter menu provides access to all the Optical Trem model’s
parameters for creating and editing controller assignments.
Bypass/Control window toggle button
*NOTE: The Bypass/Control window is a sub-window of the Inspector’s Edit panel.
Therefore, the Show and Hide menu commands and shortcut are available only
when the Edit panel is displayed, and the window remains displayed until you choose to
hide it (even when toggling the Inspector display). Also, keyboard shortcuts continue to
function within the Edit panel when the Edit panel has focus—please see “Keyboard
Shortcuts”.
Practically any model’s parameters can be manually assigned to your device’s
footswitch & expression pedal controllers, for real-time, remote control. It is also
possible here to assign model parameters to be stored and recalled with snapshots.
• Bypass/Control toggle button: When the Edit panel is displayed, click
to show or hide the Bypass/Control window, or use the Window > Show/
Hide Bypass/Control menu command. The X Close button at the top right
can also be used to hide the panel. It’s typically a good practice to close the
window once done adjusting your assignment options.
• Parameter menu: Lists all parameters for the currently selected Signal
Flow block. Choose the parameter here for which you want to assign to a
footswitch, EXP pedal, or to snapshots.
• Controller selectors: Once the desired parameter is selected within the
Parameter menu, click on the preferred FS1~FS8, EXP Toe footswitch or
EXP 1 or EXP 2 pedal to which you want it assigned. Click on the Snapshots
button to allow the parameter’s value to be recalled per snapshot.* Click the
None button to clear an existing assignment. Each FS or EXP controller can
hold a maximum of eight assignments (total bypass and/or controller types).
• * The Snapshots controller selector appears within the panel when
any parameter other than Bypass is selected within the
Parameter menu—see “Creating a Snapshots Controller Assignment” on
page 30. (Note that block bypass is automatically recalled via snapshots,
so no need for you to create a snapshot assignment—see page 13).
• The FS1~FS6 controller selectors display a colored ring, just like
footswitches on your device, to indicate the model category type in use for
the existing assignment.
• The label above a controller selector changes to italicized text to indicate
it includes one or more existing assignments. Also, when hovering your
mouse cursor over a controller selector that includes assignments, a button
appears to launch its “Assignments List Window” on page 29.
• The Mode and Tap footswitches are not available for assignments.
Parameter menu Controller selectors
The Bypass/Controller panel displayed
NOTE: You can create assignments on FS7, FS8, or EXP 2, however, you will need
to have the respective external footswitches or expression pedal connected to POD
Go, and correctly congure their Device Settings (see page 32), to utilize them.
You’ll notice that all Factory Presets already include several bypass and controller
assignments. Additionally, all New Presets already include the following assignments:
• Volume and Wah blocks are assigned to the EXP Toe switch for bypass,
which toggles between enabling these two blocks
• Additionally, EXP 1 & EXP 2 pedal controller assignments are automatically
congured for Wah,Volume/Pan, and Pitch Wham block’s parameters
• The Preset EQ and FX Loop blocks are assigned to FS1 and FS2, respectively,
for bypass
24
NOTE: POD Go includes a handy Auto Assign feature, which creates bypass
assignments to FS1~FS6 as you add models to the four Eects blocks. This
feature is enabled by default - please see “Auto Assign Feature” on page 28.
TIP: You can remotely control several POD Go functions, such as Looper, Tuner,
Tempo, Bank & Preset changes, and more, via (computer - USB) MIDI. All MIDI
control assignments are pre-congured, with no steps necessary to congure them
within POD Go Edit—please see your POD Go Owner’s Manual for details.
Clearing Existing Assignments
There are a few ways to remove or “Clear” any existing bypass or controller
assignment, as we’ve covered below. In this example, we’ll remove a Wah block’s
existing bypass assignment from the Toe Switch, and its Position parameter’s
controller assignment from the EXP 1 pedal.
The fastest way to clear assignments is directly from within the Signal Flow and
Edit panels.
To remove any block’s existing bypass assignment, right-click on the desired
block within the Signal Flow (or click on the assignment indicator label above
the block) to open the quick Bypass Assign window, and then click None.
Left-click on the Assignment Indicator
Alternatively, you can utilize the Edit panel’s more advanced Bypass/Control
window to clear any type of assignment.
1. Within the Signal Flow, click on the block which includes the assignment(s) you
wish to remove (for our example, the Wah block) to select it.
2. If not already visible, click on the footswitch/pedal icon button to display the
Bypass/Control window.
3. Click on the Parameter menu to expand it, and you’ll see all existing
assignments indicated to the right of each parameter’s name. For the Wah, we
see the Bypass is assigned to the Toe Switch and Position to EXP 1.
Select Bypass within the Parameter menu.
4. Click the None button to remove the Bypass - Toe Switch assignment.
Right-click on
the block within
the Signal Flow
Signal Flow - clearing a bypass assignment in the quick Bypass Assign panel
To remove any parameter’s existing controller or snapshot assignment, rightclick on the parameter slider to open the quick Select a controller panel, and
then click None.
Right-click on the parameter
Left-click on
the parameter’s
Assignment
Indicator
Edit panel - clearing a controller assignment in the quick Select a controller panel
5. Click the Parameter menu to expand it again, and choose Position.
6. Click the None button to remove the Position - EXP 1 pedal assignment.
It is also possible to clear any assignment type by using any Controller selector’s
Assignments List window - please see page 29.
Opening a Controller selector’s Assignments List window
This completes the process for clearing the Wah block’s assignments. You can follow
these same steps to remove any block’s existing footswitch, EXP pedal, or snapshot
assignment.
25
Creating a Bypass Assignment
Create a bypass assignment for any block (except for the Input or Output block) to
allow it to be toggled on/o via one of your device's footswitches or EXP pedals.
The following steps can also be used to change an existing bypass assignment to a
dierent footswitch or pedal.
Creating a Bypass Assignment within the Signal Flow
If you just want to quickly create a bypass assignment for any block to a footswitch,
the simplest way to do so is directly within the Signal Flow—we’ve covered this in
“Quick Bypass Assign” on page 20.
Creating a Bypass Assignment using the Bypass/Control Window
The Edit panel’s Bypass/Control window oers deeper functions for creating and
editing all types of assignments. To follow are steps to create bypass assignments
that utilize a footswitch or EXP pedal.
You can also change a block’s existing bypass assignment using the above steps.
When you select a footswitch in step 4, any existing bypass is automatically moved to
your newly selected footswitch. You can also create bypass assignments for multiple
blocks to one, common footswitch—see “Bypass Assignments for Multiple Blocks”.
Creating a Bypass Assignment Using an Expression Pedal
It is also possible to assign a block's bypass to an EXP pedal. An example of this is
to congure a Wah block so that resting the pedal at the “heel” position bypasses the
eect, and then moving the pedal away from this position to use the Wah automatically
activates the eect. Set this type of conguration using the following steps.
NOTE: When conguring the Wah for pedal bypass, it is recommended to connect
an additional pedal to the POD Go EXP 2 jack, to allow the Volume Pedal block to
have its own, separate controller pedal. If you are not to be using an additional pedal, it
would be a good idea to Clear the Volume Pedal block’s existing Bypass and Position
assignments, so that the on-board pedal can be dedicated to the Wah. See the
preceding “Clearing Existing Assignments” section.
Creating a Bypass Assignment Using a Footswitch
1. Select the block within the Signal Flow for which you want to create the
bypass assignment.
2. Choose the Show Bypass/Control command from the main Window menu.
3. Click the Parameter Menu within the Bypass/Control window and choose
Bypass, if not already selected.
Choose Bypass within
the Parameter menu
Choose the desired
controller selector for
the bypass assignment
Selecting FS4 for an Eects block bypass assignment
4. A bypass assignment can utilize FS1~FS8, or the pedal’s Toe Switch. Click on
the desired footswitch controller selector within the panel and your assignment
is created. (Optionally, you can choose an EXP pedal for your bypass
assignment—see the next section.) Close the Bypass/Control window.
1. Double-click on the Wah block within the Signal Flow to access its parameters
within the Edit panel.
2. Move the on-board expression pedal forward and click the Toe Switch so that
the device’s WAH/EXP 1 LED is lit, and the Wah block is active (if it isn’t already).
3. Open the Bypass/Control window. Note that Bypass for the Wah block
is already assigned to the EXP Toe switch—this step will move its bypass
assignment to the EXP pedal instead. By default, the Wah block’s Position
parameter includes a controller assignment to the EXP 1 pedal. We’re not
going to change this, since the goal here is to have the same pedal toggle the
Wah’s bypass as well as control the Wah Position.
NOTE: When you click on and expand the Parameter menu, you may see
indicators in brackets to the right of each parameter—these tell you all existing
bypass and controller assignment for the block. For example, the Wah’s Position
menu shows that Bypass is assigned to the Toe Switch, and Position to EXP 1.
26
Click the Parameter Menu and choose Bypass, then click on the EXP 1 Controller
selector within the panel.
Choose Bypass
within the
Parameter menu
Choose an EXP
pedal for
the bypass
assignment
Conguring an EXP pedal - Bypass assignment parameters
4. Once the assignment is created, you can congure its parameter sliders that
appear at the bottom of the Bypass/Control screen, if needed.
• Position - For a bypass assignment, this determines the position of the
controller where the block's bypass is triggered. Set this slider to 5% or lower to
establish a “heel down” resting position to trigger your bypass toggle.
• Wait - Determines the duration of time for which the assigned controller must
rest at the congured Position value before the bypass is triggered. For this type
of Wah bypass assignment, 300 ms or slightly higher is generally a good setting,
since it prevents unwanted bypass triggering during the typical use of the pedal
for your Wah eect.
Once congured, you'll see that your EXP 1 pedal's heel down position toggles
the Wah block o, and as soon as you move the pedal, it activates the Wah until
you move the pedal back to the Min heel position and rest it there for 300 ms
or more (as determined by the Wait slider). You can choose to congure other
blocks’ parameters with a “pedal bypass” using these same steps as well. Close
the Bypass/Control window when your settings are complete.
TIP: A handy trick is to create a multi-bypass assignment to toggle one block o
and the other on simultaneously, such as to change between two dierent
distortions, between two dierent delays, etc. To reverse the switching, select one block
within the Signal Flow and manually click its Bypass button so that one block is the
opposite bypass state as the other. Now whenever you toggle the assigned Bypass
footswitch, both blocks' bypass states are toggled oppositely.
NOTE: If a footswitch includes multiple bypass and/or controller assignments,
you’ll see these assignments within the footswitch controller selector’s
Assignments List window, where they can also be cleared- see page 29.
The Assignments List window displays multiple assignments
Bypass Assignments for Multiple Blocks
You can only assign the Bypass toggle of any particular block to one footswitch at
a time. If a block already has an existing bypass assignment, and you change the
assignment, this will move the assignment to the newly selected footswitch or EXP
pedal. But it is possible to assign the Bypass function for multiple blocks to one
common footswitch or controller for simultaneous switching.
Each footswitch or EXP pedal can hold up to eight assignments maximum (of any
combination of bypass or controller types). A preset can include up to 64 assignments
maximum (of any combination of bypass, controller, and snapshot types).
27
Auto Assign Feature
The POD Go device’s Global Settings > Switches/Pedals > FS Auto Assign On/O
option determines whether or not POD Go automatically creates a bypass assignment
for each of the four Eects blocks (once a model is selected for the block), where a
block bypass assignment is added to the earliest empty FS1~FS6 location. FS Auto
Assign is On by default. You can also edit your bypass assignments for any block at
any time, regardless of the FS Auto Assign On/O state, as covered in the following
sections.
• For any Eects block, its bypass is auto-assigned to the earliest empty
FS1~FS6 for bypass when an initial model is added to the empty block. If the
block’s model is changed, the bypass assignment for the block remains on
the footswitch.
• Within all New Presets, the Preset EQ block’s bypass is pre-assigned to FS1,
and the FX Loop block’s bypass to FS2. However, you can Clear these blocks’
bypass assignments to free up FS1 & FS2 for auto and manual assignments
of other blocks.
NOTE: If you manually Clear the Preset EQ or FX Loop block’s bypass
assignment, and then change the model for the block, the Auto Assign
feature will again assign its block bypass to the rst non-assigned FS1~FS6.
• Wah and Volume blocks’ bypass is already pre-assigned to the pedal Toe
Switch. You can Clear these blocks’ bypass assignments if desired, but the
Auto Assign feature does not create assignments to the pedal Toe Switch. You
can manually create assignments to the Toe Switch as desired.
• Amp/Preamp, and Cab/IR blocks are not auto-assigned to footswitches, but
can be assigned manually.
• Once Auto Assign has created bypass assignments to all FS1 through FS6,
no other auto assignments are created within the preset (unless you manually
Clear assignments from FS1~FS6).
You’ll see more about these behaviors throughout this chapter, and in the POD Go
Owner’s Manual.
Creating a Controller Assignment
You can create a controller assignment for practically any block's parameter (yes,
even any Input, Output, FX Loop, or Looper block parameter!) to allow it to be
controlled by the device's footswitches or EXP Pedals. You can also congure
a snapshot assignment to allow your desired parameter settings to be stored &
recalled with a preset's snapshots. To follow are several examples for creating these
assignments.
Creating a Controller Assignment in the Edit Panel
The easiest way to create a controller assignment is directly from the parameter within the
Edit panel, such as for a Delay’s Mix parameter.
1. Click on the assignment indicator area left of the parameter (or right-click on
slider) directly within the Edit panel to display the quick Select a controller panel,
and then click on the desired controller to quickly create a controller assignment.
Right-click on the parameter
Left-click on
the assignment
indicator area
Click on the desired controller selector to create assignment
Edit panel - creating a controller assignment using the quick Select a controller panel
2. The new controller assignment is specied within the Edit panel with several
handy indicators. For our example, the Delay’s Mix parameter appears as
follows. Note that you can also adjust the Min. and Max. values to adjust the
range of control by the assigned EXP pedal or footswitch by dragging the
parameter slider’s Min. & Max. indicator arrows. (The Min. & Max. parameters
can also be accessed within the main Bypass/Control window - see next
section.)
28
Assigned controller indicator (EXP 1)
Min & Max adjustable indicators
Conguring a controller assignment’s Min. & Max. options within the Edit panel
Value in bracketed, white text
Creating a Controller Assignment using the Bypass/Control Window
The Edit panel’s Bypass/Control window oers deeper functions for creating and
editing all types of assignments. To follow are steps to create a controller assignment
that utilizes a footswitch or EXP pedal.
1. Double-click on the block within the Signal Flow that includes the parameter
for which you want to create the controller assignment. We’ll choose a Delay
block - Simple Delay model for our example.
2. Choose the Show Bypass/Control command from the main Window menu.
3. Click the Parameter Menu within the Bypass/Control window and choose the
Mix of the Simple Delay.
Parameter
menu
5. Once a controller assignment is created, you’ll see its Minimum and Maximum
sliders at the bottom of the Bypass/Control window which allow you to limit
the range of the assigned parameter as you move the pedal from minimum to
maximum position. For our example, we'll set the Max. Mix slider to 50% so that
it achieves a 50% wet/dry Mix balance when our controller is moved to full open.
Minimum and
Maximum sliders
Conguring Min. & Max. options for an EXP Pedal controller assignment
If you have chosen a footswitch as your controller rather than an EXP pedal, you
can similarly congure the Min. and Max. sliders to the specic values you'd like
for the “O” and “On” footswitch states, respectively, for the assigned footswitch.
Close the Bypass/Control window when your settings are complete.
TIP: You can “reverse” the behavior of a controller by setting the Min to 100% and
the Max to 0%, such as to make an assigned Wah pedal work backwards!
Selecting a Delay's Mix parameter for controller assignment
4. With the Mix parameter selected, click on the desired controller and your
assignment is created. We'll choose EXP 1, but you can alternatively choose
EXP 2, or choose one of your footswitches, which allows you to then congure
a specic parameter value for each of the two states of the footswitch. More
on this in the nal step.
Selecting an EXP 1 pedal controller for controller assignment
Assignments List Window
Within the Edit panel’s Bypass/Control window, when any footswitch, EXP, or
snapshot controller type includes one or more assignments, you’ll see a little button
appear at the top right of the controller item when hovering your mouse cursor over
it. Clicking this button displays the Assignments List window for the controller. For
example, if the FS1 includes multiple assignments, such as bypass assignments for
two blocks, they appear in this window.
The FS1 Assignments List window
This list window oers a handy reference to see all existing assignments per controller,
as well as a few handy features for clearing assignments:
• Click the X button to the left of any individual assignment in the window to
clear it.
• Click the Clear All button to clear all assignments from the selected controller.
29
Creating a Snapshots Controller Assignment
Congure a block's parameter with a snapshots assignment to allow the parameter's
settings to be stored & recalled with a preset's snapshots. For these examples, we’ll
create a snapshots assignment for the Drive parameter of the Kinky Boost, which then
allows us to congure a dierent Drive value to be recalled for each snapshot.
Creating a Controller Assignment in the Edit Panel
The easiest way to create a controller assignment is directly within the Edit panel.
Double-click on the Kinky Boost block within the Signal Flow to show the Edit
panel, then click on the assignment indicator area left of the Drive slider (or rightclick on the slider itself) and choose Snapshots within the Select a controller
panel. Also see “Controller Assignment Indicators” on page 22.
Right-click on the parameter
Left-click on
the assignment
indicator area
Using the Edit panel’s Select a controller panel to create a Snapshots assignment
Shortcut! Even quicker... Within the Edit panel, select the desired parameter slider
using the “Alt+click” or “S” keyboard shortcut to instantly create (or clear) a
snapshots controller assignment for the parameter.
Creating a Snapshot Assignment using the Bypass/Control Window
The Edit panel’s Bypass/Control window oers deeper functions for creating and
editing all types of assignments. To follow are steps to create a Snapshots assignment
to a parameter.
1. Double-click on the Distortion - Kinky Boost block within the Signal Flow.
2. Open the Bypass/Controller Assign panel, click the Parameter menu and
choose the Drive parameter.
3. Click on the Snapshots controller button in the panel to create the assignment.
Choose Drive within
the Parameter menu
Choose the Snapshots
controller selector to
create the assignment
Selecting the Snapshots controller button to create a Snapshots assignment
4. Unlike with other assignment types, you won't see any congurable options
at the bottom of the Bypass/Control window for a snapshots controller
assignment. Close the Bypass/Control window when your settings are
complete.
With this assignment created for the parameter, simply choose the desired snapshot
1~4 from the Snapshots menu at the top of the POD Go Edit application window,
set the desired value for this parameter, and it is automatically stored and recalled
with the snapshot. This allows you to congure up to four dierent values within the
current preset—one for each available snapshot. Please see your device's Owner's
Manual for more details on using snapshots.
Multiple Controller Assignments
Just as on the hardware, you can only assign a parameter to one controller at a time.
However, it is possible to assign multiple parameters to one common controller, for
example, you could create the following controller assignments:
• Congure an EXP pedal for the Mix parameters of two dierent eects to
blend between them.
• Congure an EXP pedal to simultaneously adjust the Drive and the Level
parameters of a Distortion block inversely, to attain a dierent amount of
distortion without overall volume output changes.
• Congure changes for several parameters to create a dramatic tonal change.
As an example, for a guitar solo tone, congure a Volume and Gain boost
on a Distortion, an increase for the Mix of a Delay and Reverb, and enable a
Chorus block—all with the click of one footswitch!
You can reference all assignments per controller within each controller’s Assignments
List—see page 29.
NOTE: If a footswitch includes one or more additional block bypass and/or
controller assignments, the footswitch’s label on your POD Go device - Stomp
footswitch mode screen appears as Multiple (X), with “X” being the number of
assignments.
30
Global EQ Window
The Global EQ, accessed from the application's Window menu, oers a large
graphical interface for the POD Go device's Global EQ feature. As its name implies,
this EQ’s settings and bypass state are indeed global and not saved or recalled with
any preset or snapshot.
Reset Button
Inspector Pane Band Parameters
The Global EQ is a 5-band, parametric style equalizer, situated after all other
processing blocks of your POD Go signal path, allowing for sculpting your overall
tone just before it is sent out the device’s Main 1/4" and Headphones outputs. This is
especially handy for ne-tuning your tone to compensate for a venue's stage or room
sound, without having to go in and tweak all your presets.
Band Edit Nodes
Bypass Button
Done Button
Adjusting Global EQ Parameters
The Global EQ window oers two methods in which you can view & adjust its
settings: by dragging any band's edit “node” within the graph, or by adjusting the
selected band's parameter sliders within the lower inspector portion of the window.
The EQ processing is functional whenever its Bypass button is set to “active” in this
window (or via your device's Bypass button when viewing its Global EQ screen).
Reset - Click the Reset button to instantly return all parameters to their default,
“at” values, and the EQ enabled.
Bypass Button - Toggle the Bypass to globally enable or disable the EQ. The initial
default is that the Global EQ is enabled, with all parameters “at.”
Band Edit Nodes - Click and drag the desired band's Edit Node in the upper
graph to adjust its Frequency and Gain. You'll also see the respective parameters'
sliders move within the inspector pane while adjusting any edit node.
Inspector Pane - This lower portion of the window oers a set of adjustable
parameters for each of the EQ's ve bands.
Band Parameters - Each band has its own set of sliders. Note that the Low Cut
and High Cut are “shelving” type lters, allowing you to set the roll-o point for the
low and high frequencies, respectively. The middle 3 bands are fully parametric,
with controls for choosing the center Frequency, Gain (with a boost or cut of up
to 12 dB), and Q (the width of the frequency range aected). Adjust the sliders as
follows:
• Click and drag any slider's handle or use the Up/Down buttons at the right of
each slider
• Right-click on a slider to enter a precise value numerically
• Turn your mouse wheel while hovering your cursor over any slider
• Click on a slider and use the comma/period or -/+ shortcut keys to
incrementally adjust its value
• Double click on a slider to individually reset it to its default value
Done Button - Click to close the Global EQ window.
TIP: Try the handy keyboard shortcuts for adjusting Global EQ options—see page
48.
31
Preferences and About Box
The Preferences Window
The POD Go Edit Preferences window includes three tabbed screens to edit
application options: General, Presets/IRs, and Device Settings. This window is
accessed by either selecting Preferences from the POD Go Edit menu (Mac), Help
menu (Windows), or by clicking the Preferences button at the bottom left of the POD
Go Edit window.
Click the Preferences (gear icon button) to open the Preferences window
Presets/IRs Tab - Stereo IR Import
The Presets/IRs tab
This tab includes the Stereo IR Import option. When a stereo IR .wav le is imported,
it must be converted to mono for use with the POD Go device. This preference lets
you choose whether to take the left channel (the factory default) or right channel of the
source IR le, or to sum both channels to mono.
Restore Factory Settings
This button at the bottom left of the Preferences window resets all items within the
Presets/IRs and Device Settings tabs of the Preferences window back to their initial,
factory default settings.
NOTE: Your POD Go device also includes many additional settings within its
Global Settings screens (as well as its own Restore options)—this Restore
Factory Settings button restores only the settings shown within the application’s
Preferences window.
General Tab - Check for Updates
The General tab
Use this button to manually check for, and optionally install, any available rmware
updates for your connected POD Go device—see page 58.
Device Settings Tab - EXP 2-Footswitch 7/8
The Device Settings screen oers options for your connected device’s congurable
EXP and footswitch jack.
Device settings
For the POD Go device’s rear panel EXP 2 Footswitch 7/8 jack, the EXP 2 - FS7/8
option allows you to toggle its functionality between EXP 2 (for connecting a 2nd
expression pedal) versus FS7/8 (for connecting a single or dual footswitch). This
option is the same as found within POD Go hardware’s Global Settings > Preferences
options—please check your POD Go Owner’s Manual for details.
32
The About/Legal Box and Help Options
These options are available by:
• Selecting About POD Go Edit from the POD Go Edit menu (Mac), Help
menu (Windows)
• Selecting the Help or Pilot’s Guide options from the application’s Help menu
• Or, selecting any of these options from the ? button menu at the bottom left of
the POD Go Edit main window
Click the ? button to access the menu
About Box
Choose About at the left of the window to display the About Box screen, which
provides version information for the POD Go Edit application and for the connected
POD Go device’s rmware.
Legal Information
Choose the Legal tab at the left of the window to display the Legal screen, which lists
all the necessary trademark, copyright, and other legally required statements for the
POD Go Edit software.
Online Help
Choose the Online Help option from the menu to go directly to the Line 6 Support
website page within your browser app. Here you can nd the Community User
Forums, Knowledge Base, FAQs, videos, and more for POD Go Edit and POD Go
devices.
Pilot’s Guide
Choose the Pilot’s Guide option from the menu to open the PDF document you are
now reading.
The POD Go Edit About box screen - About tab selected
It is always recommended that you use the latest available versions of both your
device rmware and POD Go Edit application. Use the built in Firmware Updater
within POD Go Edit to install the latest rmware (see page 58). The latest POD Go
Edit application and driver installers can be downloaded free from
line6.com/software.
Please be sure to read the Release Notes available with all rmware, device
driver, and application versions before installing, since there may be specic
instructions for the order and procedure of your installations, depending on the
existing versions you already have installed.
33
Marketplace & Account Options
Marketplace
The Line 6 Marketplace online shop is where you'll nd 3rd-party, premium add-on
assets that even further enhance the functionality of your POD Go device (as
well as for Helix and HX devices and the Helix Native plug-in). As of this writing,
professionally crafted POD Go Presets and Impulse Responses (IRs) are available—
all IRs that are oered for Helix family products are also fully supported by POD Go
devices (Marketplace Helix & HX presets are not supported by POD Go devices).
New products are constantly being added, so be sure to check back often on the
Marketplace site for news and announcements. As covered within this chapter, you're
only a few clicks away from using new Marketplace Presets and IRs on your system,
right from the My Account menu in POD Go Edit.
Get Your Marketplace Assets
Access the Marketplace website by choosing the Get More Presets and Get More
IRs, commands within the My Account menu at the bottom left of the POD Go
Edit window (or go directly to https://line6.com/marketplace/). When visiting the
Marketplace site, simply sign in to your Line 6 account, choose the desired products,
add them to your cart, and check out.*
*NOTE: Be sure to log in to the same Line 6 account on which you've authorized
your computer for POD Go Edit to ensure your Marketplace purchased assets
are added to the correct account!
Once your purchase is complete, your downloadable Marketplace assets are
deposited into your Line 6 account, which include your personal license that allows
you to import them on your authorized computer system. Each Marketplace purchase
is typically downloadable as a “zip” le that you'll need to “unzip” on your local hard
drive once downloaded.
To download your purchased assets, click on the Manage Account command
within POD Go Edit app's My Account menu (or go directly to https://line6.com/
account/), sign in to your account, and select Marketplace from the Hardware &
Software section at the left.
Licenses for all your purchased assets are automatically added to your Line 6
account and “synced” the next time you use the POD Go Edit application, when
you are actively signed in to your Line 6 account from the My Account menu (see
“Sign In / Sign Out” on page 35).
Import and Utilize Your Marketplace Assets
An Internet connection is required for the computer where you'll be using the POD Go
Edit app to authorize it for the use of Marketplace premium assets, and for the sync
with your Line 6 account to initially authenticate your newly purchased Marketplace
licensed assets. Otherwise, an active Internet connections is not required for the use
of POD Go Edit. Please see the following sections for details about signing in and
authorization.
Once you've signed in and authorized your computer via POD Go Edit, your
premium Marketplace presets and IRs can then be imported and used just like any
other presets and IRs within POD Go Edit.
Once imported, premium Marketplace assets, appear with a golden guitar pick
“badge” at their right in the POD Go Edit Preset and Impulses library lists—also see
page 8 and page 9 for more about importing presets and IRs.
The golden guitar pick badges indicate premium Marketplace Presets and IRs
34
The My Account Menu Options
At the bottom left of the POD Go Edit application window, you'll see the My Account
menu and account status indicator. Initially, before you've signed in to your Line 6
online account and/or authorized your computer for Marketplace premium assets,
you'll see this menu displayed with the My Account label.
The My Account menu (not signed in or authorized)
Clicking on the My Account menu displays options for signing in & managing your Line
6 account, as well as for access to the Marketplace online shop.*
*NOTE: It is not required that your computer have an active Internet connection, nor
do you need to be signed in or authorized at all for the POD Go Edit app itself to be
functional. But an Internet connection and signing in is necessary to authorize (or
deauthorize) your computer to allow the import and export of premium assets
purchased from the online Marketplace.
Sign In / Sign Out
If you are not currently signed in, choose Sign In from the menu and enter your
Line 6 account user name and password in the Sign In window. If you have forgotten
your sign in credentials, or have not already created a Line 6 account, choose the
Forgot my password/username or Create a Line 6 account option within the
window. If you are already signed in and wish to sign out, choose the Sign Out option
from the menu.
TIP: If you plan on purchasing premium Marketplace assets, it is easiest to simply
keep POD Go Edit actively signed in, with your computer in the authorized state.
This allows the licenses for your purchased assets to automatically be “synced” from
your Line 6 account, and for the assets able to be utilized for all actions within the POD
Go Edit app. It is also necessary to be signed in to utilize the built in Firmware Updater
features within POD Go Edit (page 58)
The Line 6 account Sign In window
Computer Authorization Status Indicator
Once you've signed in, your computer is automatically authorized, as conrmed by a
pop up window letting you know the sign in and authorization were successful. You'll
see the My Account menu label display your rst name, derived from your Line 6
account, and indicate the status of your account sign in and computer authorization
(more details about authorization in the following section). Whenever signed out, the
menu button displays the “My Account” label, with no colored authorization indicator.
Signed in with computer authorized
Once you've authorized your computer, you can optionally sign out, and your computer
remains in the authorized state, allowing you to continue to perform import, export, copy
and back up actions with your Marketplace assets, even if your Internet connection is not
currently active.
Note that you will need an Internet connection to be able to sign in again to access the
Deauthorize and Authorize options from the menu, as well as to initially synchronize with
your online Line 6 account after making any new Marketplace purchase (see “License
Synchronization”).
Signed out with computer Deauthorized
35
Authorize / Deauthorize Your Computer
It is necessary for your computer to be in the authorized state for performing any POD
Go Edit Import, Export, Copy/Paste or Backup/Restore action that includes your
purchased Marketplace IRs. Simply signing in to your Line 6 account will authorize
your computer automatically.*
*NOTE: It is permitted to authorize a maximum of 4 of your computers
concurrently. If you've already authorized 4 computers, you can deauthorize
one computer to free up one of your authorizations.
Deauthorizing You Computer
While signed in to your Line 6 account, choose the Deauthorize Computer command
from the My Account menu and the brief online deauthorization process completes
automatically. You'll see a conrmation dialog appear to indicate your deauthorized
state. Additionally, deauthorizing your computer will also automatically sign you out of
your Line 6 account.
When deauthorized, the POD Go Edit application still functions to provide all preset &
IR librarian and signal ow editing tasks, however, premium Marketplace-purchased
assets are not able to be imported or exported with the POD Go Edit app. You can
choose Authorize Computer from the menu to authorize the computer again at any
time, providing you have not exceeded the 4 computer authorization limit.
Helix/HX Device & Helix Native Plug-in Owners: If you’ve already purchased
and utilized premium Marketplace IRs, please also see the Pilot's Guide for HX
Edit or Helix Native plug-in for use with those products.
License Synchronization
Whenever you make a purchase from Marketplace, a license for each product
you purchase is deposited into your online Line 6 account. For the POD Go Edit
application to access your new licenses and eectively “unlock” your purchased
assets, it needs to perform a “sync” process with your Line 6 account. You must
have an active Internet connection and be signed in within POD Go Edit on your
next use of the app after your purchase for this license synchronization to occur.
When you're signed in, this brief sync takes place automatically in POD Go Edit the
next time you launch the application, or if already running, when you next click on the
POD Go Edit app window. (Note that it may take up to 5 minutes before a sync occurs
if POD Go Edit was already running.) Once the license sync has completed, an active
Internet connection is not required for the use of these Marketplace purchased assets
within POD Go Edit, or within your Helix hardware.
Manage Account
Choose this menu option to be taken to the Line6.com My Account page, where
you can view and update your Line 6 user account—view and manage add-ons and
Marketplace purchases, register Line 6 gear, update your personal information, and
more.
36
Model Lists
To follow are the lists of all Eect, Amp, Speaker Cabinet & Microphone models included
within POD Go devices, including descriptions of the original gear they are based on.*
Models, in many cases, include some unique parameters, typically based on the controls
found on the original gear we modeled. However, you will also nd a set of options that
are common to model category types, as described in the sections that follow.
Effects Block Models
Distortion Dynamics EQ Modulation Delay Reverb Pitch/Synth Filter Looper
The following models are found within each of the device’s Eects block category
menus. The mono and stereo processing capabilities of eects models are as follows:
• Distortion, Dynamics, and Pitch/Synth category models are mono.
• EQ, Modulation, Delay, Reverb, and Filter category models are stereo.
• Looper category models are, as indicated by their names, oered in both
mono and stereo.
Mono models process in mono, as you’d expect, collapsing the stereo output of any
block preceding it to mono. Stereo models process the signal as stereo-in, stereo-out.
Bypassed blocks do not collapse any stereo signal fed into them.
Distortion Models (Mono)
Model Based On*
Kinky Boost
Deranged Master
Minotaur
Teemah!
Heir Apparent!
Alpaca Rogue
Compulsive Drive
Dhyana Drive
Valve Driver
Top Secret OD
Xotic® EP Booster
Dallas Rangemaster Treble Booster
Klon® Centaur
Paul Cochrane Timmy® Overdrive
Analogman Prince of Tone
Way Huge® Red Llama (modded)
Fulltone® OCD
Hermida Zendrive
Chandler Tube Driver
DOD® OD-250
Distortion Models (Mono)
Model Based On*
Scream 808
Hedgehog D9
Stupor OD
Deez One Vintage
Deez One Mod
Vermin Dist
KWB
Arbitrator Fuzz
Triangle Fuzz
Industrial Fuzz
Tycoctavia Fuzz
Wringer Fuzz
Thrifter Fuzz
Xenomorph Fuzz
Megaphone
Bitcrusher
Ampeg Scrambler
ZeroAmp Bass DI
Obsidian 7000
Tube Drive
Screamer
Overdrive
Classic Dist
Heavy Dist
Colordrive
Buzz Saw
Facial Fuzz
Jumbo Fuzz
Fuzz Pi
Ibanez® TS808 Tube Screamer
MAXON® SD9 Sonic Distortion
BOSS® SD-1 Overdrive
BOSS® DS-1 Distortion (Made-in-Japan)
BOSS® DS-1 Distortion (Keeley modded)
Pro Co RAT
Benadrian Kowloon Walled Bunny Distortion
Arbiter® FuzzFace
Electro-Harmonix® Big Mu Pi
Z.Vex Fuzz Factory
Tycobrahe® Octavia
Garbage's modded BOSS® FZ-2
Line 6 Original
Subdecay Harmonic Antagonizer
Megaphone
Line 6 Original
Ampeg® Scrambler Bass Overdrive
Tech 21 SansAmp Bass Driver DI V1
Darkglass® Electronics Microtubes® B7K Ultra
Chandler Tube Driver
Ibanez® Tube Screamer
DOD® Overdrive/Preamp 250
ProCo RAT
BOSS® Metal Zone
Colorsound® Overdriver
Maestro® Fuzz Tone
Arbiter® Fuzz Face
Vox® Tone Bender
Electro-Harmonix® Big Mu Pi
®
®
®
®
®
®
*See “U.S. Registered Trademarks” on page 47 All product names used in this document are trademarks of their respective owners and neither Yamaha Guitar Group nor Line 6 are associated or aliated with
them. These trademarks appear solely to identify products whose tones and sounds were studied by Line 6 during sound model development.
37
Distortion Models (Mono)
Model Based On*
Jet Fuzz
L6 Drive
L6 Distortion
Sub Oct Fuzz
Octave Fuzz
Roland® Jet Phaser
Colorsound® Overdriver (modded)
Line 6 Original
PAiA Roctave Divider
Tycobrahe® Octavia
Effects EQ and Preset EQ Models
The following EQ models are available within any Eects blocks, as well as within
each preset’s resident Preset EQ block. There’s no dierence between choosing an
EQ model for one of the four available Eects blocks or using the Preset EQ block
(except for their respective icons, so you know which is which!).
Effects EQ Preset EQ
Dynamics Models (Mono)
Model Based On*
Deluxe Comp
Red Squeeze
Kinky Comp
Rochester Comp
LA Studio Comp
3-Band Comp
Noise Gate
Hard Gate
Autoswell
Tube Comp
Red Comp
Blue Comp
Blue Comp Treb
Vetta Comp
Vetta Juice
Boost Comp
*See “U.S. Registered Trademarks” on page 47 All product names used in this document are trademarks of their respective owners and neither Yamaha Guitar Group nor Line 6 are associated or aliated with
them. These trademarks appear solely to identify products whose tones and sounds were studied by Line 6 during sound model development.
Line 6 Original
MXR® Dyna Comp
Xotic® SP Compressor
Ashly® CLX-52 (in conjunction with bassist Billy Sheehan)
Teletronix® LA-2A
Line 6 Original
Line 6 Original
Line 6 Original
Line 6 Original
Teletronix® LA-2A
MXR® Dyna Comp
BOSS® CS-1
BOSS® CS-1 (Treble switch on)
Line 6 Original
Line 6 Original
MXR® Micro Amp
®
®
Model Based On*
Simple EQ
Low and High Cut
Low/High Shelf
Parametric
Tilt
10 Band Graphic
Cali Q Graphic
Model Based On*
Optical Trem
60s Bias Trem
Tremolo/Autopan
Harmonic Tremolo
Bleat Chop Trem
Script Mod Phase
Pebble Phaser
Ubiquitous Vibe
Deluxe Phaser
Gray Flanger
Harmonic Flanger
Courtesan Flange
Dynamix Flanger
EQ Models (Stereo)
Line 6 Original
Line 6 Original
Line 6 Original
Line 6 Original
Line 6 Original
MXR® 10-Band Graphic EQ
MESA/Boogie® Mark IV Graphic EQ
Modulation Models (Stereo)
Fender® optical tremolo circuit
Vox® AC-15 Tremolo
BOSS® PN-2
Line 6 Original
Lightfoot Labs Goatkeeper
MXR® Phase 90
Electro-Harmonix® Small Stone
Shin-ei Uni-Vibe
Line 6 Original
MXR® 117 Flanger
A/DA Flanger
Electro-Harmonix® Deluxe EM
Line 6 Original
®
38
Modulation Models (Stereo)
Model Based On*
Chorus
70s Chorus
PlastiChorus
Trinity Chorus
Bubble Vibrato
Vibe Rotary
122 Rotary
145 Rotary
Double Take
AM Ring Mod
Pitch Ring Mod
Pattern Tremolo
Panner
Bias Tremolo
Opto Tremolo
Script Phase
Panned Phaser
Barberpole
Dual Phaser
U-Vibe
Phaser
Pitch Vibrato
Dimension
Analog Chorus
Tri Chorus
Analog Flanger
Jet Flanger
AC Flanger
80A Flanger
Frequency Shift
Line 6 Original
BOSS® CE-1
Modded Arion SCH-Z chorus
Dytronics® Tri-Stereo Chorus
BOSS® VB-2 Vibrato
Fender® Vibratone
Leslie® 122
Leslie® 145
Line 6 Original
Line 6 Original
Line 6 Original
Line 6 Original
Line 6 Original
1960 Vox® AC-15 Tremolo
1964 Fender® Deluxe Reverb
MXR® Phase 90 (script logo version)
Ibanez® Flying Pan
Line 6 Original
Mu-Tron® Bi-Phase
Shin-ei Uni-Vibe
MXR® Phase 90
BOSS® VB-2
Roland® Dimension D
BOSS® CE-1
Dytronics® Tri-Stereo Chorus
MXR® Flanger
A/DA Flanger
MXR® Flanger
A/DA Flanger
Line 6 Original
Modulation Models (Stereo)
Model Based On*
Ring Modulator
Rotary Drum
Rotary Drum/Horn
Line 6 Original
Fender® Vibratone
Leslie® 145
Delay Models (Stereo)
Model Based On*
Simple Delay
Mod/Chorus Echo
Dual Delay
Multitap 4
Multitap 6
Ping Pong
Sweep Echo
Ducked Delay
®
®
Reverse Delay
Vintage Digital
Vintage Swell
Pitch Echo
Transistor Tape
Harmony Delay
Bucket Brigade
Adriatic Delay
Adriatic Swell
Elephant Man
Multi Pass
Ping Pong Legacy
Dynamic
Stereo
Digital
Dig w/Mod
Line 6 Original
Line 6 Original
Line 6 Original
Line 6 Original
Line 6 Original
Line 6 Original
Line 6 Original
TC Electronic® 2290
Line 6 Original
Line 6 Original
Line 6 Original
Line 6 Original
Maestro® Echoplex EP-3
Line 6 Original
BOSS® DM-2
BOSS® DM-2 w/ Adrian Mod
Line 6 Original
Electro-Harmonix® Deluxe Memory Man
Line 6 Original
Line 6 Original
TC Electronic® 2290
Line 6 Original
Line 6 Original
Line 6 Original
*See “U.S. Registered Trademarks” on page 47 All product names used in this document are trademarks of their respective owners and neither Yamaha Guitar Group nor Line 6 are associated or aliated with
them. These trademarks appear solely to identify products whose tones and sounds were studied by Line 6 during sound model development.
39
Delay Models (Stereo)
Model Based On*
Reverse
Lo Res
Tube Echo
Tape Echo
Sweep Echo
Echo Platter
Analog Echo
Analog w/Mod
Auto-Volume Echo
Multi-Head
Line 6 Original
Line 6 Original
Maestro® Echoplex EP-1
Maestro® Echoplex EP-3
Line 6 Original
Binson® EchoRec
BOSS® DM-2
Electro-Harmonix® Deluxe Memory Man
Line 6 Original
Roland® RE-101 Space Echo
Reverb Models (Stereo)
Model Based On*
Glitz
Ganymede
Searchlights
Plateaux
Double Tank
Plate
Room
Chamber
Hall
Echo
Tile
Cave
Ducking
Octo
'63 Spring
Spring
Particle Verb
Line 6 Original
Line 6 Original
Line 6 Original
Line 6 Original
Line 6 Original
Line 6 Original
Line 6 Original
Line 6 Original
Line 6 Original
Line 6 Original
Line 6 Original
Line 6 Original
Line 6 Original
Line 6 Original
Line 6 Original
Line 6 Original
Line 6 Original
Pitch/Synth Models (Mono)
Model Based On*
Pitch Wham
Twin Harmony
Simple Pitch
Dual Pitch
3 Note Generator
®
4 OSC Generator
Bass Octaver
Smart Harmony
Octi Synth
Synth O Matic
Attack Synth
Synth String
Growler
Digitech® Whammy
Eventide® H3000
Line 6 Original
Line 6 Original
Line 6 Original
Line 6 Original
EBS® OctaBass
Eventide® H3000
Line 6 Original
Line 6 Original
Korg® X911 Guitar Synth
Roland® GR700 Guitar Synth
Line 6 Original
®
Filter Models (Stereo)
Model Based On*
Mutant Filter
Mystery Filter
Autolter
Asheville Pattrn
Voice Box
V Tron
Q Filter
Seeker
Obi Wah
Tron Up
Tron Down
Throbber
Slow Filter
Musitronics® Mu-Tron® III
Korg® A3
Line 6 Original
Moog® Moogerfooger® MF-105M MuRF Filter
Line 6 Original
Musitronics® Mu-Tron® III
Line 6 Original
Z Vex Seek Wah
Oberheim® voltage-controlled S&H lter
Musitronics® Mu-Tron® III (up position)
Musitronics® Mu-Tron® III (down position)
Electrix® Filter Factory
Line 6 Original
*See “U.S. Registered Trademarks” on page 47 All product names used in this document are trademarks of their respective owners and neither Yamaha Guitar Group nor Line 6 are associated or aliated with
them. These trademarks appear solely to identify products whose tones and sounds were studied by Line 6 during sound model development.
40
WAH
Filter Models (Stereo)
Model Based On*
Spin Cycle
Comet Trails
Craig Anderton's Wah/Anti-Wah
Line 6 Original
Looper Models (Mono & Stereo)
Model Based On*
Volume Pedal
Gain
Pan
Stereo Width
Volume/Pan Models (Stereo)
Line 6 Original
Line 6 Original
Line 6 Original
Line 6 Original
Model Based On*
6 Switch Mono Looper
1 Switch Mono Looper
6 Switch Stereo Looper
1 Switch Stereo Looper
Line 6 Original
Line 6 Original
Line 6 Original
Line 6 Original
Wah and Volume Block Models
Wah Volume
EXP 1
VOL
EXP 2
WAH
EXP 1
EXP 2
VOL
Common FX Settings
Parameter Description
Drive
Bass
Mid
Treble
Speed
Adjusts the amount of overdrive, distortion, or fuzz.
Adjusts the bass level.
Adjusts the midrange level.
Adjusts the treble level.
Adjusts the speed of the eect, with higher settings providing faster
rates. Activate the model's Note Sync parameter to toggle
between Hz and note values. Choosing a Hz value provides a
specic modulation speed in cycles per second; choosing a note
value provides a time based on the current tempo. Not all Speed
parameters can be synced to note values, as they may be non-linear
and highly interactive.
Every preset has one Wah block (automatically assigned to EXP 1) and one Volume
block (automatically assigned to EXP 2). The following models are available for the
Wah & Volume blocks. All models within these categories are stereo.
Wah Models (Stereo)
Rate
Adjusts the rate of the eect, with higher settings providing faster
rates. Activate the model's Note Sync parameter to toggle
between Hz and note values. Not all Rate parameters can be synced
to note values, as they may be non-linear and highly interactive.
Adjusts the delay/repeat time, with higher settings providing longer
Model Based On*
UK Wah 846
Teardrop 310
Fassel
Weeper
Chrome
Chrome Custom
Throaty
Vetta Wah
Colorful
Conductor
*See “U.S. Registered Trademarks” on page 47 All product names used in this document are trademarks of their respective owners and neither Yamaha Guitar Group nor Line 6 are associated or aliated with
them. These trademarks appear solely to identify products whose tones and sounds were studied by Line 6 during sound model development.
Vox® V846
Dunlop® Cry Baby® Fasel model 310
Dunlop® Cry Baby® Super
Arbiter® Cry Baby
®
Vox® V847
Modded Vox® V847
RMC® Real McCoy 1
Line 6 Original
Colorsound® Wah-fuzz
Maestro® Boomerang
Time
Depth
Feedback
Decay
Predelay
delays. Activate the model's Note Sync parameter to toggle
between Hz and note values. Choosing a ms value provides a
specic time in milliseconds; choosing a note division value provides
a time based on the current tempo. With a note division value, this
parameter’s value is retained when changing models.
Adjusts the intensity of the modulation. Higher settings result in more
extreme pitch bending, wobble, or throb, depending on the eect.
Adjusts the amount of delayed signal fed back into the eect. Higher
settings can provide more dramatic textures.
Sets the length of time the reverb eect sustains.
Determines the time before the reverb eect is heard.
41
Parameter Description
On stereo delays, the Scale oers control over the left & right channel
repeats proportionately. The left channel repeats following the Time
Scale
Spread
Headroom
Low Cut
High Cut
Mix
Level
Trails
value and the right channel will repeat at a time that is the percentage
of the left time. For example, if a delay's Time is set for 1 second and
the Scale set to 75%, the left channel will repeat at 1 second and the
right at 750 milliseconds (ms).
Spread diers slightly among stereo delay eects. For most delays,
it adjusts how widely the repeats bounce left and right. With the Ping
Pong Delay, for example, 0 is in the middle (mono), and 10 is full left to
right panning for the repeats.
For modulated stereo delays, Spread aects the LFOs’ (low frequency
oscillators) stereo modulation behavior. At 0 the LFOs are in sync. At
10, the two LFOs are 180 degrees out of sync, so that when one side
is modulating up, the other side is modulating down.
Some mod and delay models' internal signal paths exhibit a bit of grit,
especially when placed after a high-gain amp block. Negative values
increase the perceived amount of grit; positive values clean things up
a bit. At 0dB, the model behaves like the original pedal.
Filters a portion of the block’s bass and/or treble frequencies, which
can help remove rumble and/or high-end harshness.
Blends the eected “wet” signal vs. the “dry” signal passed through
the block. When set to 0%, the path bypasses the eect completely.
When set to 100%, the entire path is fed through the eect, and no
dry thru signal is heard.
Adjusts the overall output level of the eects block. Be careful not to
boost this parameter too high on multiple blocks, as digital clipping
could occur. You should typically leave this at 0.0dB for most blocks.
Where the original pedal's level or volume knob behavior doesn't
really apply to dB values, 0.0-10 may be used.
Trails O: Any delay repeats or reverb decays are instantly muted
when the block is bypassed.
Trails On: Any delay repeats or reverb decays continue to decay
naturally when the block is bypassed or a dierent snapshot is
selected.
FX Loop Block
The FX Loop lets you dynamically insert your favorite external stompboxes (or rack
eects) into any location in your preset, via the POD Go stereo TRS Send and Return
jacks. You can select this block and set it to be Mono or Stereo as desired per preset.
FX Loop Active FX Loop Bypassed
NOTE: Within your POD Go device’s Global Settings > Ins/Outs, the FX Loop
can be set for instrument (for inserting stompboxes) or line-level operation.
FX Loop Settings
Page Knob Parameter Description
1 Send
2 Return
1
3 Mix
2 1 Trails
Adjusts the level sent to your external device.
Adjusts the level received at the Return jack.
Blends the FX loop signal vs. the dry signal passed
through the FX Loop block. When set to 0%, the path
bypasses the FX loop completely. When set to 100%,
the entire path is fed through the FX loop, and no dry
thru signal is heard.
Trails O: An external stompbox would be instantly
muted when the FX Loop block is bypassed. Trails On:
An external delay or reverb stompbox would continue to
decay naturally when the FX Loop block is bypassed or
a dierent snapshot is selected.
*See “U.S. Registered Trademarks” on page 47 All product names used in this document are trademarks of their respective owners and neither Yamaha Guitar Group nor Line 6 are associated or aliated with
them. These trademarks appear solely to identify products whose tones and sounds were studied by Line 6 during sound model development.
42
Amp/Preamp Block Models
Amp Preamp
The following guitar & bass amp and preamp models are found within the Amp/
Preamp block category menus. Use an Amp category model along with your choice
of speaker model within the Cab/IR block for a traditional amp tone.* Or, choose
a Preamp category model for tone and character of just the preamp stage of the
amplier (this can be a great option when feeding your POD Go output into an
external power amplier). All Amp and Preamp category models are mono.
*NOTE: The Link Amp/Cab option within your device’s Global Settings
> Preferences determines whether the current preset’s Cab block model
automatically changes based on the Amp model you select within the Amp/
Preamp block. If you prefer to choose your Cab block model independently
within all presets, set the Link Amp/Cab option to On. See the list of “Cab/IR
Block Speaker Cabinet Models” on page 45).
Amp & Preamp Models
Model Type Based On*
WhoWatt 100
Soup Pro
Stone Age 185
Voltage Queen
Tweed Blues Nrm
Tweed Blues Brt
Fullerton Nrm
Fullerton Brt
Fullerton Jump
Grammatico Nrm
Grammatico Brt
Grammatico Jump
US Small Tweed
US Deluxe Nrm
US Deluxe Vib
Guitar Hiwatt® DR-103 Brill
Guitar Supro® S6616
Guitar Gibson® EH-185
Guitar Victoria Vintage Queen
Guitar Fender® Bassman® (normal channel)
Guitar Fender® Bassman® (bright channel)
Guitar Fender® 5C3 Tweed Deluxe (normal channel)
Guitar Fender® 5C3 Tweed Deluxe (bright channel)
Guitar Fender® 5C3 Tweed Deluxe (jumped channels)
Guitar Grammatico® LaGrange (normal channel)
Guitar Grammatico® LaGrange (bright channel)
Guitar Grammatico® LaGrange (jumped channels)
Guitar Fender® Champ
Guitar Fender® Deluxe Reverb® (normal channel)
Guitar Fender® Deluxe Reverb® (vibrato channel)
®
Amp & Preamp Models
Model Type Based On*
US Double Nrm
US Double Vib
Mail Order Twin
Divided Duo
Interstate Zed
Derailed Ingrid
Jazz Rivet 120
Essex A15
Essex A30
A30 Fawn Nrm
A30 Fawn Brt
Matchstick Ch1
Matchstick Ch2
Matchstick Jump
Mandarin 80
Brit J45 Nrm
Brit J45 Brt
Brit Trem Nrm
Brit Trem Brt
Brit Trem Jump
Brit Plexi Nrm
Brit Plexi Brt
Brit Plexi Jump
Brit P75 Nrm
Brit P75 Brt
Brit 2204
Placater Clean
Placater Dirty
Guitar Fender® Twin Reverb® (normal channel)
Guitar Fender® Twin Reverb® (vibrato channel)
Guitar Silvertone® 1484
Guitar ÷13 JRT 9/15
Guitar Dr Z® Route 66
Guitar Trainwreck® Circuits Express
Guitar Roland® JC-120 Jazz Chorus
Guitar Vox® AC-15
Guitar Vox® AC-30 with top boost
Guitar Vox® AC-30 Fawn (normal channel)
Guitar Vox® AC-30 Fawn (bright channel)
Guitar Matchless® DC30 (channel 1)
Guitar Matchless® DC30 (channel 2)
Guitar Matchless® DC30 (jumped)
Guitar Orange® OR80
Guitar Marshall® JTM-45 (normal channel)
Guitar Marshall® JTM-45 (bright channel)
Guitar Marshall® JTM-50 (normal channel)
Guitar Marshall® JTM-50 (bright channel)
Guitar Marshall® JTM-50 (jumped)
Guitar Marshall® Super Lead 100 (normal channel)
Guitar Marshall® Super Lead 100 (bright channel)
Guitar Marshall® Super Lead 100 (jumped)
Guitar Park® 75 (normal channel)
Guitar Park® 75 (bright channel)
Guitar Marshall® JCM-800
Guitar Friedman BE-100 (clean channel)
Guitar Friedman BE-100 (BE/HBE channel)
*See “U.S. Registered Trademarks” on page 47 All product names used in this document are trademarks of their respective owners and neither Yamaha Guitar Group nor Line 6 are associated or aliated with
them. These trademarks appear solely to identify products whose tones and sounds were studied by Line 6 during sound model development.
43
Amp & Preamp Models
Model Type Based On*
Cartographer
German Mahadeva
German Ubersonic
Cali Texas Ch1
Cali Texas Ch2
Cali IV Rhythm 1
Cali IV Rhythm 2
Cali IV Lead
Cali Rectire
Archetype Clean
Archetype Lead
ANGL Meteor
Solo Lead Clean
Solo Lead Crunch
Solo Lead OD
PV Panama
Revv Gen Purple
Revv Gen Red
Line 6 Elektrik
Line 6 Doom
Line 6 Epic
Line 6 2204 Mod
Line 6 Fatality
Line 6 Litigator
Line 6 Badonk
Ampeg B-15NF
Ampeg SVT Nrm
Ampeg SVT Brt
Guitar Ben Adrian Cartographer
Guitar Bogner® Shiva
Guitar Bogner® Überschall
Guitar MESA/Boogie® Lone Star (clean channel)
Guitar MESA/Boogie® Lone Star (drive channel)
Guitar MESA/Boogie® Mark IV (channel I)
Guitar MESA/Boogie® Mark IV (channel II)
Guitar MESA/Boogie® Mark IV (lead channel)
Guitar MESA/Boogie® Dual Rectier
Guitar Paul Reed Smith® Archon® (clean channel)
Guitar Paul Reed Smith® Archon® (lead channel)
Guitar ENGL® Fireball 100
Guitar Soldano SLO-100 (clean channel)
Guitar Soldano SLO-100 (crunch channel)
Guitar Soldano SLO-100 (overdrive channel)
Guitar Peavey® 5150
Guitar Revv® Generator 120 (purple/gain ch. 3)
Guitar Revv® Generator 120 (red/high gain ch. 4)
Guitar Line 6 Original
Guitar Line 6 Original
Guitar Line 6 Original
Guitar Line 6 Original
Guitar Line 6 Original
Guitar Line 6 Original
Guitar Line 6 Original
Bass Ampeg® B-15NF Portaex
Bass Ampeg® SVT® (normal channel)
Bass Ampeg® SVT® (bright channel)
Amp & Preamp Models
Model Type Based On*
Ampeg SVT-4 PRO
Woody Blue
®
®
Agua 51
Cali Bass
Cali 400 Ch1
Cali 400 Ch2
G Cougar 800
Del Sol 300
Busy One Ch1
Busy One Ch2
Busy One Jump
Studio Tube Pre
Bass Ampeg® SVT®--4 PRO
Bass Acoustic® 360
Bass Aguilar® DB51
Bass MESA/Boogie® M9 Carbine
Bass MESA/Boogie® Bass 400+ (channel 1)
Bass MESA/Boogie® Bass 400+ (channel 2)
Bass Gallien-Krueger® GK 800RB
Bass Sunn® Coliseum 300
Bass Pearce BC-1 preamp (channel 1)
Bass Pearce BC-1 preamp (channel 2)
Bass Pearce BC-1 preamp (jumped)
Mic Preamp Requisite Y7 mic preamp
Common Amp Settings
Parameter Description
®
®
Master
Sag
Hum
Ripple
Bias
Bias X
Adjusts the amount of power amp distortion. This parameter is highly
interactive with all other power amp parameters—the lower the Master
is set, the less eect the other controls will have.
Lower Sag values oer a “tighter” responsiveness for metal and djent
playing; higher values provide more touch dynamics & sustain for
blues and classic rock ris.
Controls how much heater hum and AC ripple interacts with your tone.
At higher settings, things get freaky.
Changes the Bias of the power tubes. Lower values achieve a “colder”
Class AB biasing. At maximum, the amp is operating in Class A.
Determines how the power amp tubes' voicing reacts when pushed
hard. Set low for a tighter feel. Set high for more tube compression.
This parameter is highly reactive with the Drive and Master settings.
*See “U.S. Registered Trademarks” on page 47 All product names used in this document are trademarks of their respective owners and neither Yamaha Guitar Group nor Line 6 are associated or aliated with
them. These trademarks appear solely to identify products whose tones and sounds were studied by Line 6 during sound model development.
44
Cab/IR Block Speaker Cabinet Models
Cab Impulse Response
The following guitar and bass speaker cabinet models are available within the Cab
category of the Cab/IR block.* All Cab models also include your choice of Mic model
type used on the Cab, as well as several Mic settings (see the list of “Microphone
Models” on page 46).
*NOTE: The Link Amp/Cab option within your device’s Global Settings
> Preferences determines whether the current preset’s Cab block model
automatically changes based on the Amp model you select within the Amp/
Preamp block. If you prefer to choose your Cab block model independently
within all presets, set the Link Amp/Cab option to O. See the list of “Amp/
Preamp Block Models” on page 43).
NOTE: As an alternative to using the provided Cab models, you can choose the
IR Category within the Cab/IR block and utilize your own Impulse Response les.
Please see “Impulses List” on page 9.
Cab Models
Model Type Based On*
Soup Pro Ellipse
1x8 Small Tweed
1x12 Field Coil
1x12 Fullerton
1x12 Grammatico
1x12 US Deluxe
1x12 Celest 12H
1x12 Blue Bell
1x12 Lead 80
1x12 Cali IV
1x12 Cali Ext
Guitar 1 x 6x9" Supro® S6616
Guitar
Guitarl 1x12" Gibson® EH185
Guitar 1x12" Fender® 5C3 Tweed Deluxe
Guitar 1x12" Grammatico® LaGrange
Guitar 1x12" Fender® Deluxe Oxford
Guitar 1x12" ÷13 JRT 9/15 G12 H30
Guitar 1x12" Vox® AC-15 Blue
Guitar 1x12" Bogner® Shiva CL80
Guitar 1x12" MESA/Boogie® Mk IV
Guitar 1x12" MESA/Boogie® EVM12L
1x8" Fender® Champ
Cab Models
Model Type Based On*
2x12 Double C12N
2x12 Mail C12Q
2x12 Interstate
2x12 Jazz Rivet
2x12 Silver Bell
2x12 Blue Bell
2x12 Match H30
2x12 Match G25
4x10 Tweed P10R
4x12 WhoWatt 100
4x12 Mandarin EM
4x12 Greenback25
4x12 Greenback20
4x12 Blackback30
4x12 1960 T75
4x12 Uber V30
4x12 Uber T75
4x12 Cali V30
4x12 XXL V30
4x12 SoloLead EM
1x12 Del Sol
1x15 Ampeg B-15
1x18 Del Sol
1x18 Woody Blue
2x15 Brute
4x10 Ampeg HLF
6x10 Cali Power
8x10 Ampeg SVT E
Guitar 2x12" Fender® Twin C12N
Guitar 2x12" Silvertone® 1484
Guitar 2x12" Dr Z® Z Best V30
Guitar 2x12" Roland® JC-120
Guitar 2x12" Vox® AC-30TB Silver
Guitar 2x12" Vox® AC-30 Fawn Blue
Guitar 1x12" Matchless® DC-30 G12H30
Guitar 1x12" Matchless® DC-30 Greenback 25
Guitar 4x10" Fender® Bassman® P10R
Guitar 4x12" Hiwatt® AP Fane
Guitar 4x12" Orange® Eminence
Guitar 4x12" Marshall® Basketweave G12 M25
Guitar 4x12" Marshall® Basketweave G12 M20
Guitar 4x12" Park® 75 G12 H30
Guitar 4x12" Marshall® 1960 AT75
Guitar 4x12" Bogner® Uberkab V30
Guitar 4x12" Bogner® Uberkab T75
Guitar 4x12" MESA/Boogie® 4FB V30
Guitar 4x12" ENGL® XXL V30
Guitar 4x12" Soldano
Bass 1x12" Sunn® Coliseum
Bass 1x15" Ampeg® B-15
Bass 1x18" Sunn® Coliseum
Bass 1x18" Acoustic® 360
Bass 2x15" MESA/Boogie® 2x15 EV
Bass 4x10" Ampeg® SVT® 410HLF
Bass 6x10" MESA/Boogie® Power House
Bass 8x10" Ampeg® SVT
®
®
*See “U.S. Registered Trademarks” on page 47 All product names used in this document are trademarks of their respective owners and neither Yamaha Guitar Group nor Line 6 are associated or aliated with
them. These trademarks appear solely to identify products whose tones and sounds were studied by Line 6 during sound model development.
45
Microphone Models
Model Based On*
57 Dynamic
409 Dynamic
421 Dynamic
30 Dynamic
20 Dynamic
121 Ribbon
160 Ribbon
4038 Ribbon
414 Cond
84 Cond
67 Cond
87 Cond
47 Cond
112 Dynamic
12 Dynamic
7 Dynamic
Shure® SM57
Sennheiser® MD 409
Sennheiser® MD 421-U
Heil Sound® PR 30
Electro-Voice® RE20
Royer® R-121
Beyerdynamic® M 160
Coles 4038
AKG® C414 TLII
Neumann® KM84
Neumann® U67
Neumann® U87
Neumann® U47
AKG® D112
AKG® D12
Shure® SM7
Mic Models
Cab & Mic Settings
Knob Parameter Description
1 Mic
2 Distance
3 Low Cut
4 High Cut
5 EarlyRec
6 Level
Selects one of the 16 available mic models.
Sets the distance (1 inch to 12 inches) between the mic and
the speaker grille.
Filters a portion of the cab's bass and/or treble frequencies,
which can help remove rumble and/or high-end harshness.
Sets the amount of “early reections.” Higher values add more
reective room sound to your Amp tone.
Adjusts the overall output level of the Cab.
*See “U.S. Registered Trademarks” on page 47 All product names used in this document are trademarks of their respective owners and neither Yamaha Guitar Group nor Line 6 are associated or aliated with
them. These trademarks appear solely to identify products whose tones and sounds were studied by Line 6 during sound model development.
46
U.S. Registered Trademarks
All product names used in this document are trademarks of their respective owners and neither Yamaha Guitar Group nor Line 6 are associated or aliated with them. These
trademarks appear solely to identify products whose tones and sounds were studied by Line 6 during sound model development.
5150 is a registered trademark of ELVH Inc.
Acoustic is a registered trademark of GTRC Services, Inc.
Aguilar is a registered trademark David Boonshoft.
AKG, DOD and Whammy are registered trademarks of Harman International Industries, Inc.
Arbiter is a registered trademark of Sound City Amplication LLC.
Ashly is a registered trademark of Ashly Audio, Inc.
Binson, Dytronics, LA-2A and Teletronix are registered trademarks of Universal Audio, Inc.
Beyerdynamic is a registered trademark of Beyer Dynamic GmbH & Co. KG.
Bogner and Überschall are registered trademarks of Bogner Amplication.
BOSS and Roland are registered trademarks of Roland Corporation U.S.
Carvin is a registered trademark of Kiesel Guitars.
Colorsound is a registered trademark of Sola Sound Limited Corporation, UK.
Cry Baby, Dunlop, Fuzz Face, MXR and Uni-Vibe are registered trademarks of Dunlop
Manufacturing, Inc.
Darkglass and Microtubes are registered trademarks of Darkglass Electronics, TMI
Douglas Castro.
Digitech is a registered trademark of DOD Electronics Corporation.
Dr. Z is a registered trademark of Dr. Z Amps, Inc.
EBS is a registered trademark according of EBS Holding.
EchoRec is a registered trademark of Nicholas Harris.
Electro-Harmonix and Big Mu Pi are registered trademarks of New Sensor Corp.
Electro-Voice is a registered trademark of Bosch Security Systems, Inc.
Engl is a registered trademark of Beate Ausug and Edmund Engl.
Eventide is a registered trademark of Eventide Inc.
Fane is a trademark of Fane International Ltd.
Fender, Twin Reverb, Bassman, Champ, Deluxe Reverb and Sunn are registered
trademarks of Fender Musical Instruments Corp.
Fulltone is a registered trademark of Fulltone Musical Products, Inc.
Gallien-Krueger is a registered trademark of Gallien Technology, Inc.
Gibson and Maestro are registered trademarks of Gibson Guitar Corp.
Heil Sound is a registered trademark of Heil Sound Ltd.
Hiwatt is a registered trademark of Simon Giles and Justin Harrison.
Ibanez is a registered trademark of Hoshino, Inc.
Klon is a registered trademark of Klon, LLC.
Korg is a registered trademark of Korg, Inc.
Leslie is a registered trademark of Suzuki Musical Instrument Manufacturing Co. Ltd.
Lone Star is a registered trademark of Randall C. Smith.
Marshall is a registered trademark of Marshall Amplication Plc.
Matchless is a registered trademark of Matchless, LLC.
MAXON is a registered trademark of Nisshin Onpa Co., Ltd.
Mesa/Boogie and Rectier are registered trademarks of Mesa/Boogie, Ltd.
Moog and Moogerfooger are registered trademarks of Moog Music, Inc.
Musitronics is a registered trademark of Mark S. Simonsen.
Mu-Tron is a registered trademark of Henry Zajac.
Neumann is a registered trademark of Georg Neumann GmbH.
Orange is a registered trademark of Orange Brand Services Limited.
Park is a registered trademark of AMP RX LLC.
Paul Reed Smith and Archon are registered trademarks of Paul Reed Smith Guitars, LP.
Peavey is a registered trademark of Peavey Electronics Corporation.
Revv is a registered trademark of Revv Amplication Inc.
RMC is a registered trademark of Richard McClish.
Royer is a registered trademark of Bulldog Audio, Inc. DBA Rover Labs.
Sennheiser is a registered trademark of Sennheiser Electronic GmbH & Co. KG.
Shure is a registered trademark of Shure Inc.
Silvertone is a registered trademark of Samick Music Corporation.
Supro is a registered trademark of Absara Audio LLC.
TC Electronic is a registered trademark of MUSIC Group IP Ltd.
Tech21 is a registered trademark of Tech21 Licensing Ltd.
Timmy is a registered trademark of Paul Cochrane AKA PAULCAUDIO.
Trainwreck is a registered trademark of of Scott Alan Fischer and Mona Fischer.
Tube Screamer is a registered trademark of Hoshino Gakki Co. Ltd.
Tycobrahe is a registered trademark of Kurt Stier.
Vox is a registered trademark of Vox R&D Limited.
Way Huge is a registered trademark of Saucy Inc.
Xotic is a registered trademark of Prosound Communications, Inc.
47
Keyboard Shortcuts
Tab
Shift
+
Tab
T
T
+
+
⌘
T
Ctrl
T
+
F1
?
+
<
+
Command
⌘
⌘
Q
+
The following keyboard shortcuts are available to speed up tasks when working in the POD Go Edit application. Where indicated, some shortcuts require that “focus” be placed
on a window, panel, or specic control to be able to trigger its function. To place focus within the desired window, press your Tab key to cycle focus between the Librarian, Editor
and Inspector windows—you'll see a blue indicator appear in the top left corner of the window that has focus. Additionally, any individual element that is selected within the
indicated panel also has focus and, therefore, is able to be triggered by its relevant keyboard shortcut(s). As shown in the examples below, the Librarian and its selected Factory
setlist have focus, the Signal Flow and its selected Volume block have focus, and the Inspector - Edit panel and its selected Drive parameter have focus. (Note that the Model
Select panel will have focus when it is displayed within the Inspector.)
Library focus -
Factory Setlist selected
Signal Flow focus -
Volume block selected
Amp - Drive parameter selected
Inspector focus -
Global Shortcuts
Command Mac PC Function - These shortcuts perform the following functions regardless of focus
Window Focus
(forward)
Window Focus
Toggles focus between the Librarian, Signal Flow, and Inspector—as indicated by blue triangle within the panel’s top
left corner (see above)
Performs same focus action as above, but rotates through Librarian, Signal Flow and Inspector in reverse order
(reverse)
Enter Tap Tempo
Tap Tempo Mode
Tap Tempo Value
POD Go Pilot’s
Guide
About Box Window
Command
N/A
N/A
Shift
⌘
Alt
“Tap” the key rhythmically to enter the system Tap Tempo value
Changes the Tap Tempo Mode Menu selection (Per Snapshot, Per Preset or Global)
Selects Tap Tempo value edit box for numerical value entry
Launches this PDF document you are now reading
Displays the About POD Go Edit window, containing application version information
/
POD Go Edit Menu Commands - Shortcuts (Mac only)
Command Mac PC Function - These shortcuts perform the following functions regardless of focus
Preferences
⌘
*
,
Opens Preferences window.
Quit POD Go Edit
Command
⌘
*
Quits the POD Go Edit application.
*See the File Menu Commands table for PC equivalent shortcuts.)
48
File Menu Commands - Shortcuts
⌘
S
+
S
+
Command
⌘
S
+
Shift
S
+
⌘
I
+
Ctrl
I
+
⌘
E
+
Ctrl
E
+
Command
⌘
I
+
Alt
Alt
I
+
Command
⌘
E
+
Alt
Alt
E
+
Alt
+
Return
Enter
Q
+
⌘
Z
+
Ctrl
Z
+
Command
⌘
Z
+
Shift
Z
+
⌘
X
+
Ctrl
X
+
⌘
C
+
Ctrl
C
+
Command
⌘
V
+
Ctrl
V
+
Command Mac PC Setlist Library Focus Impulses Library Focus Signal Flow Panel Focus Inspector Focus
Save Preset
Command
⌘
Ctrl
Saves the currently loaded preset into its existing Preset library location
Save Preset As
Import Preset/IR
Export Preset/IR
Import Setlist
Export Setlist
Preferences *
Quit *
Shift
Command
Command
Option
Option
⌘
+
⌘
⌘
⌘
+
⌘
+
Ctrl
+
Ctrl
+
Ctrl
+
Ctrl
Displays the Save To Setlist window, where you can choose the Setlist and Preset library location
Imports a preset into the
currently-selected Setlist slot
Exports the currently-selected
preset
Imports a setlist, replacing the
current setlist and its presets
Imports an IR into the currentlyselected IR library slot
These shortcuts are functional and act upon the
Setlist or Impulses panel that is currently displayed
Exports the currently-selected
IR
No function These shortcuts are functional whenever the Factory
or User setlist is displayed within the library
Exports the current setlist and
its presets as a setlist le to
your computer
Opens the Preferences window (use ESC to close the window)
Quits the POD Go Edit application
*See the POD Go Edit Menu Commands table for Mac equivalent shortcuts.
Edit Menu Commands - Shortcuts
Command Mac PC Setlist Library Focus Impulses Library Focus Signal Flow Panel Focus Inspector Focus
Undo
Redo
Command
Shift
⌘
⌘
+
Ctrl
+
No function No function Reverses the last supported
block or signal ow action
No function No function Reverses the last Undo
action within the signal ow
Reverses the last supported
action
Reverses the last Undo
action
Cut
Command
⌘
No function No function Copies the selected block &
its settings to the clipboard
No function
and deletes the block from
the signal ow
Copy
Paste
Command
⌘
⌘
Copies the
currently-selected preset (in
its last-saved state) to the
clipboard
Pastes the last-copied
preset from the clipboard
into the selected preset
location
Copies the
currently-selected IR (with
its current settings) to the
clipboard
Pastes the last-copied IR
from the clipboard into the
selected IR location
49
Copies the selected block
(with its current settings) to
the clipboard
Pastes the last-copied
block from the clipboard
into the selected block
location
No function
No function
Edit Menu Commands - Shortcuts
Command
⌘
⌘
+
Delete
⌘
A
+
A
+
Command
⌘
R
+
Ctrl
R
+
⌘
B
+
B
+
⌘
G
+
Ctrl
G
+
Command
⌘
C
+
Shift
C
+
Command
⌘
V
+
Shift
V
+
⌘
1
+
1
+
⌘
2
+
2
+
⌘
3
+
3
+
Command
⌘
4
+
Ctrl
4
+
Command Mac PC Setlist Library Focus Impulses Library Focus Signal Flow Panel Focus Inspector Focus
Clear
Select All
Command
Delete
⌘
Ctrl
No function Clears the selected IR
location(s)
Selects all 128 preset
locations within the current
Selects all 128 IR locations
within the Impulses list
(Eects type blocks only)
No function
Clears the block’s model
No function No function
setlist
Rename
⌘
Allows the selected preset
to be renamed
Allows the selected IR to be
renamed
Allows the currently loaded preset to be renamed
Window Menu Commands - Shortcuts
Command Mac PC Setlist or Impulses Library Focus Signal Flow Panel Focus Inspector Focus
Show or Hide
Bypass/Control
Window
Open Global EQ
Window
Command
Command
⌘
Ctrl
Shows or hides the Bypass/Control window within the Edit panel
Note that this shortcut and menu command is only available when the Edit panel is displayed within the
Inspector
⌘
Opens (and places focus in) the Global EQ window
Snapshots Menu Commands - Shortcuts
Command Mac PC Setlist Library Focus Impulses Library Focus Signal Flow Panel Focus Inspector Focus
Copy
Shift
⌘
+
Ctrl
+
Copies the currently loaded snapshot to the clipboard
Paste
Snapshot 1
Snapshot 2
Snapshot 3
Snapshot 4
Shift
Command
Command
Command
⌘
+
⌘
⌘
⌘
⌘
Ctrl
+
Ctrl
Ctrl
Ctrl
Pastes the last-copied snapshot contents from the clipboard into the current snapshot
Loads Snapshot 1
Loads Snapshot 2
Loads Snapshot 3
Loads Snapshot 4
50
Setlist & Impulses Librarian Panels - Shortcuts
F
U
I
Ctrl
+
Shift
+
Return
Enter
Shift
+
Return
Enter
+
⌘
+
+
Shift
+
Return
Enter
+
Shift
+
Return
Enter
Command Mac PC Setlist Library Focus Impulses Library Focus
Factory Setlist
Library
User Setlist
Library
Impulses Library
Displays and changes focus to the Factory Setlist Library panel
Displays and changes focus to the User Setlist Library panel
Displays and changes focus to the Impulses Library panel
Display Context
Menu
Change Setlist/
or
or
or
Displays the context menu for the selected preset location
(Navigate an open menu using Up/Down Arrow keys and
ENTER key to make selection. Use ESC key to dismiss
menu.)
Changes focus between the Factory setlist, User setlist and Impulses library
Displays the context menu for the selected IR location
(Navigate an open menu using Up/Down Arrow keys and
ENTER key to make selection. Use ESC key to dismiss
menu.)
Impulses List
Focus
Navigate Selection
Extend Selection
Contiguous Multiselect
Non-contiguous
Multi-select
Rename Preset/IR
Command
⌘
Shift
Shift
Delay click
+
Ctrl
Navigates the preset selection within the current setlist Navigates the IR selection within the Impulses list
Extends the preset selection within the current setlist Extends the IR selection within the Impulses list
Selects contiguous multiple presets within the current
Selects contiguous multiple IRs within the Impulses list
setlist
Selects non-contiguous multiple presets within the current
Selects non-contiguous multiple IRs within the Impulses list
setlist
Renames the clicked preset (click once and then a 2nd time
1/3 of a second or later)
Renames the clicked IR (click once and then a 2nd time 1/3
of a second or later)
Signal Flow Panel - Shortcuts
Command Mac PC Function - These shortcuts perform the following functions when the Signal Flow panel has focus
Navigate Selection
Selects and cycles through blocks within the Signal Flow
Display Block
Context Menu
Block Bypass
Toggle
or
or
Ctrl
Spacebar
or
Displays the block's context menu
NOTE: Open context menus can be navigated by arrow keys, where ENTER makes a selection, and ESC dismisses the
open menu
Toggles the bypass state of the selected block
51
Signal Flow Panel - Shortcuts
A
C
V
W
F
E
1
2
3
4
I
O
M
Command Mac PC Function - These shortcuts perform the following functions when the Signal Flow panel has focus
Amp Block Select
Selects the Amp block in the current preset
Cab/IR Block
Select
Volume Block
Select
Wah Block Select
FX Loop Block
Select
Preset EQ Block
Select
1st Eects Block
Select
2nd Eects Block
Select
3rd Eects Block
Select
4th Eects Block
Select
Input Block Select
Output Block
Select
Block Select
Display Edit Panel
Single-click
Double-click
Selects the Cab/IR block in the current preset
Selects the Volume block in the current preset
Selects the Wah block in the current preset
Selects the FX Loop block in the current preset
Selects the Preset EQ block in the current preset
Selects the rst Eects block in the current preset
Selects the second Eects block in the current preset
Selects the third Eects block in the current preset
Selects the fourth Eects block in the current preset
Selects the Input block in the current preset
Selects the Output block in the current preset
Click on any block to select it
Double-click on any block (or select a block and hit the Enter/Return key) to display the Edit panel within the Inspector,
with the current model’s parameters displayed for editing
Display Model
Selector
Displays the Model Selector panel within the Inspector to choose a model for the selected block
52
Edit Panel - Shortcuts
M
⌘
B
+
B
+
Shift
+
Alt
⌘
+
+
+
-
+
Return
Enter
Return
N
Command Mac PC Inspector - Edit Panel Focus*
Display Model
Displays the Model Selector panel within the Inspector
Selector
Show or Hide
Bypass/Control
Window
Change Focus
Command
⌘
Ctrl
Displays and closes the Bypass/Control window
Note that this command is only available while the Inspector is displaying the Edit panel, and not when the Model
Select panel is displayed.
Moves the focus between the Edit panel’s parameters and the Bypass/Control window options (when displayed)
Between Edit Panel
and Bypass/Control
Window
Edit Panel - Parameter Shortcuts
Command Mac PC
Select Previous/Next
Individual Parameter Focus: The parameter that has focus is indicated by the parameter name in white text, and
with a turquoise colored arrow to the right of its text label
Selects the previous or next parameter
Snapshot Assign
Reset to Default
Adjust Value
Fine
Adjust Value
Coarse
Edit Numerical Value
Open the
Select a Controller
Panel
Note Sync On/O
Command
+
⌘
Shift
or
Ctrl
+
=
_
-
Alt+Click directly on any parameter to quickly assign its value to a Snapshots controller (or to clear an existing
Snapshot assignment). Alternatively, press S to assign or unassign the currently selected parameter
Click on any parameter slider to reset it to its default value. Alternatively, press D to reset the currently selected
parameter
Increments/decrements parameter value - ne adjustment
Increments/decrements parameter value - coarse adjustment
or
=
+
+
Enter
_
or
Edits a parameter’s numerical value or shows the drop-down menu, if available, for discrete parameter choices.
(Navigate an open menu using Up/Down Arrow keys and ENTER key or double-click to make selection. Use ESC
key to dismiss menu.)
Opens the selected parameter’s Select a controller panel for quick controller assignment options
Shift
Double-click
Shift
or
Right-click
For “Note Sync” capable parameters (indicated by the button to the right of the slider), this toggles the
functionality between Note Sync and ms/Hz
53
Edit Panel - Bypass/Control Window Shortcuts
Shift
+
Return
Enter
A
Individual Control Focus: The individual control within the Bypass/Control window that has focus is indicated
Command Mac PC
Change Focus
Within Window
Parameter Menu
Open - Accept
Navigate Parameter
Menu List
Open Controller
Assignments List
with a turquoise colored arrow to its left, or an outline. Note that many of the Edit panel - parameter shortcuts in
table above also work on controls within this window, where applicable.
Moves the focus between the dierent types of controls within the Bypass/Control window—Parameter menu,
Controller selectors, and parameter sliders
Use Shift + Left Arrow to move focus back to the Edit panel’s parameters
When the Parameter menu has focus, press to open menu. Use Up/Down Arrow keys to navigate the open
menu’s list (see next item), press Enter/Return to accept the highlighted menu item
Use ESC to dismiss the open menu
When the Parameter menu has focus, these keys navigate the menu list:
-When menu is closed, the next/previous menu item is selected.
-When menu is open, the keys navigate the menu list options, and you can use Enter/Return to accept the current
menu list item
When Min., Max., Position, or Wait parameter slider has focus, these keys adjust the value
When any FS or EXP Controller selector has focus, use A to open the controller’s Assignments List window
Use Enter/Return or ESC to close the Assignments List window
Model Select Panel - Shortcuts
Command Mac PC Inspector - Model Select Panel Focus
Display Edit Panel
Change Focus
Between Model and
Category Lists
Select Previous/Next
(horizontally)
Select Previous/Next
(vertically)
Double-click
+
Shift
Double-click on any model within the Model Select panel, or on any block within the Signal Flow to display the Edit
panel within the Inspector, with the current model’s parameters displayed for editing
Moves the focus between the Model grid list and the Category list, which then allows you to use the left and right
arrow keys to select a model or category (see next item)
NOTE: A turquoise triangle appears at the left of the Category list when it has focus
Selects the previous or next model (horizontally within the Model grid, when it has focus), or previous or next
category (when the Category list at the top of the panel has focus)
Selects the previous or next model (vertically within the model grid, when it has focus)
54
Block - Category Shortcuts
A
+
Shift
P
+
Shift
C
+
I
+
D
+
Shift
Y
+
E
+
M
+
L
+
R
+
Shift
P
+
F
+
O
+
⌘
G
+
Ctrl
G
+
Tab
Shift
+
Tab
R
B
When an Amp/Preamp, Cab/IR, or any one of the four Eects blocks is selected within the Signal Flow, and then focus placed specically on the Category list at the top of the
Model Select panel, you can use the following shortcuts to choose the block’s category, and display the category’s models.
Amp/Cab Category - Shortcuts
Mac or PC
Shift
When the Amp/Cab block is selected, and the Category list has
focus
Selects Amp category
Selects Preamp category
Cab/IR Category - Shortcuts
Mac or PC When Cab/IR block is selected, and the Category list has focus
Selects Cab category
Shift
Selects IR category
Mac or PC
Shift
Shift
Shift
Shift
Shift
Selects Distortion category
Selects Dynamics category
Selects EQ category
Selects Modulation category
Selects Delay category
Selects Reverb category
Effects Category - Shortcuts
When any one of the four Eects Blocks is selected, and the
Category list has focus
Selects Pitch/Synth category
Shift
Shift
Selects Filter category
Selects Looper category
Global EQ & Preferences Window Shortcuts
Focus is automatically placed within the Global EQ and Preferences windows whenever they are opened, allowing selection navigation and adjustment of most controls.
Command Mac PC Function
Any Control Has Focus
Open Global EQ
Command
⌘
Focus Next
Focus Previous
Reset
Bypass
Global EQ Window - Shortcuts
Opens the Global EQ Window
You can use ESC to close the open Global EQ window
Moves focus to next control
Moves focus to previous control
Invokes the Reset button to set all parameters “at”
Toggles the Global EQ Bypass
55
Command Mac PC Function
1
2
3
4
5
Shift
+
Tab
Q
Q
+
Ctrl
Q
+
Shift
Q
+
Return
Enter
Return
Enter
EQ Graph Pane Focus
Low Cut
Selects the Low Cut node
Global EQ Window - Shortcuts
Low Peak
Mid Peak
High Peak
High Cut
Adjust Edit Node -
Fine
Adjust Edit Node -
Coarse
Increment Q Value
- Fine
Increment Q Value
- Coarse
Shift
Decrement Q Value
- Fine
Decrement Q Value
- Coarse
Control-Specic Focus (as indicated)
Ctrl
Reset
Selects the Low Peak node
Selects the Mid Peak node
Selects the High Peak node
Selects the High Cut node
Adjusts the selected edit node in small increments
Use the numbered keys above to select the desired node, then use Up/Down keys to edit Gain and Left/Right arrow keys
to edit Frequency
Adjusts the selected edit node in large increments
Use the numbered keys above to select the desired node, then use Up/Down keys to edit Gain and Left/Right arrow keys
to edit Frequency
Increments the selected node's Q parameter value by 0.1
Increments the selected node's Q parameter value by 1.0
Decrements the selected node's Q parameter value by 0.1
Decrements the selected node's Q parameter value by 1.0
+
When the Reset button has focus—Resets all parameters to default “at” values
Bypass
Close Window
Spacebar
When the Bypass button has focus—Toggles Global EQ Bypass
When the Done button has focus—Triggers the Done button to exit the Global EQ window. Optionally, you can use the
ESC key to close the window
56
Command Mac PC Function
⌘
+
<
Alt
Return
+
Enter
Return
Enter
Open Window
Command
⌘
,
Opens the Preferences window
Preferences Window - Shortcuts
Close Window
When the Preferences window is open, triggers the Close button to exit the window. You can also use the ESC key to
close the window
Additional Mouse Behaviors
But wait, there's more! To follow are additional time-saving gestures using your mouse wheel or mouse buttons.
• Hover your mouse cursor over any block within the Signal Flow to access its Bypass and Clear buttons
• Use your mouse wheel while hovering over...
• Any parameter slider and adjust its value
• Any scroll bar to scroll the panel's contents, such as within the Presets and Impulses lists and Edit and Bypass/Controller Assign tabs
• The Snapshots menu to load a dierent snapshot
• The numerical Tap Tempo control to increment/decrement the tempo value
• The Setlist menu to load a dierent setlist
• Within the Presets library list, Alt/Option + Left-click (Mac) or Ctrl + Left-click (PC) and drag and drop any preset (or multiple selected presets) to copy into new preset slot
locations, overwriting the presets that currently exist there. (Dragging and dropping a preset without using a modier key moves the preset and reorders them within your
setlist.)
• Just try right-clicking (or Ctrl+Left-clicking on Mac) on dierent items within the application, and you may just discover a handy menu of commands you didn’t know about!
57
Firmware Updater & Additional Resources
POD Go Device Firmware Updater
For your convenience, a Firmware Updater is built right in to the POD Go Edit
application! With your POD Go device connected and an active Internet connection,
when you launch POD Go Edit it will automatically check to see if your device has the
latest available rmware installed, and you’ll be prompted to update your device, if
needed. You can also access the Check for Updates button within the POD Go Edit
Preferences window at any time - see page 32. It is highly recommended to always
use the latest versions of device rmware and POD Go Edit software to benet from
the latest features and the smoothest product compatibility.
To Update your Device Firmware
Connect your POD Go device to your Mac or PC, launch POD Go Edit, and proceed
with the following steps.
NOTE: If you wish to install any rmware version on your device other than the
latest, and/or have no Internet connection on your current computer, you must
use the separate Line 6 Updater application—see page 60.
Sign In: If you have not already signed in, click the My Account button at the
lower left of the POD Go Edit window and choose Sign In, enter your line6.com
account Username and Password, and click Sign in. If you have not yet created
an account, click Create a Line 6 Account in the Sign In window to go to the
line6.com website and create your free account, and then return to POD Go Edit
and sign in.
Upon launch of POD Go Edit (or once you’ve signed in within POD Go Edit), if the
app nds a newer rmware version for your device online, you’ll see a pop-up
window. Here you can choose to Remind Me Later, read the Release Notes, or
click Update Now to proceed and update your device.
*IMPORTANT! Please be sure to read the Release Notes for all Line 6
application and device driver installations rst, before performing
updates or installations. There may be specic instructions for the order
and procedure to perform the update, depending on the existing version
you already have installed.
Also, whenever a newer rmware is available, you’ll see a notication at the bottom
right of the POD Go Edit app window. You can also launch the Firmware Updater
by clicking on this indicator.
Choosing OK in the above Update Available window launches the Updater, which
walks you through the simple backup and rmware update process, as described
in the following steps.
• Create Backup - You are prompted to create a backup, which includes all
your device’s presets, setlists, IRs and global settings. Click OK to continue
Signing in to your Line 6 account within POD Go Edit
58
• Optionally, you can customize the title, description, and save location for your
Backup le within the Create Backup window (see page 16 for details).
Click the Create Backup button to proceed.
• End User License Agreement: - You must agree to the terms of the License
Agreement to perform the rmware installation - read and click OK to
continue.
• Update Device: Click Update and the Updater does its thing—simply sit back
and wait for the update to run, as indicated by the status bar at the bottom of
the window. It is especially important not to disturb the device’s controls
and cable connections until the update fully completes!
• Update Complete: Once nished, you’ll see the Update Complete screen.
Just click Back to POD Go Edit and wait for your device to restart and rebuild
all presets. You’ll then be reconnected to the POD Go Edit app—ready to start
using the new rmware!
59
While the presets on your device will not be altered, some minor sonic changes
may still occur with some rmware updates, as noted within any rmware’s Release
Notes.
TIP: Alternatively, you can manually check for available rmware updates
anytime by clicking the Check For Updates button found within the
Preferences window—see page 32.
Using the Line 6 Updater App
As mentioned in the previous section, for updating to the latest available
POD Go device rmware, it is recommended to use the built in Firmware
Updater within POD Go Edit. If for any reason you wish to “roll back” to or
install an older rmware version, you must use the separate Line 6 Updater
application. The free Line 6 Updater software is available from line6.com/software/.
IMPORTANT! Please be sure to carefully read the Release Notes for all
Line 6 application and device driver installations rst, before performing
updates or installations. Also read the Release Notes and Special Instructions
displayed within the Line 6 Updater application when starting a rmware
update (see the following steps). There may be specic instructions for the
order and procedure to perform the update, depending on the existing version
you already have installed.
• When ready click Next and Line 6 Updater software will assist you in
performing the update in minutes. It is especially important not to disturb
the device’s controls and cable connections until the update fully
completes!
While the presets on your device will not be altered, some minor sonic changes may
still occur with rmware updates, as noted within any rmware's Release Notes.
Using Line 6 Updater in Ofine Mode
If the computer you are using to run the Line 6 Updater app is not connected to
the Internet, you can use the app’s Oine Mode to update your POD Go device’s
rmware, as follows.
• You’ll need to rst obtain the latest rmware for your POD Go device by
downloading it from the line6.com/software/ web page, then manually copy
the downloaded (.hxf) le to your computer where you’ll be running Line 6
Updater. Connect your device directly to the computer’s USB port.
TIP: It is always a good idea to create a backup of your device's contents before
performing a rmware update! The best procedure is to perform the backup in
your existing POD Go Edit version rst—then update to the latest device rmware and
POD Go Edit versions. See “Creating & Restoring Complete Device Backups” on
page 16.
To use the Line 6 Updater application - With your POD Go device connected
and powered on, quit all other Line 6 and audio applications and launch the Line 6
Updater application.
On Mac - Go to Applications > Line 6 > Line 6 Updater
On Windows® - Go to the Start button menu > All Apps (or Programs) > Line 6 >
Line 6 Updater
• Once you’ve launched the Line 6 Updater app, you will be asked to sign into
your Line 6 account.* If you do not have an account, you must rst create one.
Follow the prompts through to the quick online registration.
NOTE: If the computer you are using is not connected to the Internet, it is still
possible to use Line 6 Updater in “Oine Mode” to update your device.
Please see the steps at the end of this section for details.
• Once logged in, any USB-connected and supported Line 6 products
(including POD Go) will appear in the main view of the Line 6 Updater
application. Click on the device you wish to update and your device's current
rmware version and available updates are displayed.
• Select the desired rmware version and click the Update button.
• The rmware’s Release Notes are shown before continuing with the update
process. Read them for important details.*
• The License Agreement is displayed next. Read through the agreement and
Click Accept to agree to the terms and conditions and start the update
process.
• You'll then see the rmware's Special Instructions displayed. Be sure to read
all instructions here carefully and follow the steps.
NOTE: While on the Line 6 software page, it is highly recommended that you
fully read the Release Notes for the rmware version that you are about to
download before running Line 6 Updater. These notes may include important
details on the steps for your specic update!
• Launch Line 6 Updater. Rather than logging in, press the Oine Mode button.
• Choose the device that you wish to update (POD Go).
• Click the Choose File button to browse your computer and select the POD
Go (.hxf) rmware le you obtained in the rst step.
• Now just press the Next button and proceed with the update, carefully
following all the screen instructions until the process completes.
TIP: Whenever installing rmware, you must be sure to also install the matching
version number of the POD Go Edit application. Please visit line6.com/software/
to nd the correct application version.
60
Additional Resources
Looking for more info? We’ve got plenty of online resources, just a click away.
• To get acquainted with POD Go, we recommend you visit line6.com/meet-
pod-go/.
• Additional Help documentation covering POD Go is available on the Line 6
Support site at Line 6 Product Manuals.
• Visit the Line 6 CustomTone site where you can share your presets with the
world, and download free presets created by Line 6 and other users just like
you.
• Looking for some professionally crafted presets and Impulse Responses?
Check out the Line 6 Marketplace, and be sure to check back often for
news and product announcements. (Note that all IRs oered for Helix family
products are also fully compatible with POD Go.)
• Can’t get enough Line 6 gear & accessories? Head on over to the Line 6
Online Shop.
• Check out the Line 6 Support page for access to helpful tips, videos,
discussion forums, or to contact Line 6 Technical Support.
61
®
Loading...
