Line6 G90 Wireless Receiver PILOT’S GUIDE

G90 Wireless Receiver
Pilot’s Handbook
Manuel de pilotage
Pilotenhandbuch Pilotenhandboek
Manual del Piloto
取扱説明書
See www.line6.com/manuals for Advance Guide
40-00-0234 Advanced Users Guide available @ www.line6.com/manuals Rev D
Important Safety Instructions
WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT REMOVE SCREWS. NO USER-SERVICEABLE PARTS INSIDE.
WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THE APPLIANCE TO RAIN OR MOISTURE.
C AUTIO N
RISK OF ELECTRIC
SHOCK DO NOT OPEN
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
Warning: Changes or modifications not expressly approved in writing by Line 6 may void the users authority to operate this equipment. RF Exposure Statement: This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not in-stalled and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numerique de la classe B est conforme a la norme NMB-003 du Canada.
The FCC compliance sticker is attached to the THH12 battery compartment. Remove the THH12 base by unscrewing counter clockwise to see this compliance sticker.
CERTIFICATION
N222
You should read these Important Safety Instructions. Keep these instructions in a safe place
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with dry cloth.
• Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
• Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
• This apparatus shall be connected to a MAINS socket outlet with a protective earthing connection.
• Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
• Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.
• Only use attachments/accessories specified by the manufacturer.
• Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/ apparatus combination to avoid injury from tip-over.
• Unplug this apparatus during lightning storms or when unused for long periods of time.
• Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
• The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.
• WARNING: To reduce the risk of fire or electric shock do not expose this apparatus to rain or moisture.
• The appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable.
• Connect only to AC power outlets rated: 100/120V 220/240V 50/60Hz (depending on the voltage range of the included power supply).
• Prolonged listening at high volume levels may cause irreparable hearing loss and/or damage. Always be sure to practice “safe listening.”
• Service is required when the apparatus has been damaged in any way, such as:
• power-supply cord or plug is damaged.
• liquid has been spilled or objects have fallen into the apparatus.
• the unit has been exposed to rain or moisture.
• the unit is dropped or the enclosure is damaged.
• the unit does not operate normally or changes in performance in a significant way.
Basic OperatiOn
1. Antenna A & B Input Connectors (BNC) - You can connect to either
your front (
C & D) or rear (A & B) BNC connectors. Choose what works
best for your rack.
RFBATTERYAUDIO
CABLE
CHANNEL
TONE
SELECT
TRANSMITTER
MUTE
STATUS
SELECT
EXIT
OR
WARNING/AVIS:
SERIAL NUMBER
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Patent Pending Desigined in USA Made In China
SHOCK HAZARD – DO NOT OPEN. RISQUE DE CHOC ÉLECTRIQUE – NE PAS OUVRIR. TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE. TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER. NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
ANTENNA B
TUNER/
IN
AUX OUT
OUT
IN
OUT
AES/EBU
MAIN OUT
S/PDIF
90 - 250V
10 W Max.
50 - 60Hz
~
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
ANTENNA A
A OUT B OUTA OUT B OUT
9. Antenna A/D & B/C Output Connectors (BNC) - Use the connectors
to daisy chain multiple Relay G90 receivers. The outputs can be for
Antenna A & B or C & D. It is user selectable which antennas get routed
to the outputs. Be sure each additional receiver and its transmitter are set to a different channel.
10. Tuner/Aux Out - Use this output to connect to an external tuner or
into a second audio path. The when the
Main Out is muted.
Tuner/Aux Out continues operation even
11. Main Out - Use the 1/4 inch output when connecting to an amplifier
or effects pedals. Use the balanced XLR output when connecting to studio grade equipment that supports balanced XLR connections such as mixing consoles.
RFBATTERYAUDIO
CABLE
CHANNEL
TONE
TRANSMITTER
STATUS
MUTE
SELECT
SELECT
EXIT
1. Antenna C & D Input Connectors (BNC) - For correct operation connect
the supplied detachable antenna by pressing on the BNC connector and twisting clockwise for 1/2 turn.
Biased.
2. Transmitter Status Display Audio - Green LEDs will light indicating the audio signal level.
Note: C & D Antenna inputs are not DC
Battery - All five battery LEDs will be lit to indicate full battery life.
The bottom LED will change to red once your battery life falls below two hours and flash red when it falls below one hour.
RF - When transmitter is on and has the same channel set as the
receiver, these LEDs light green to indicate signal strength/quality: from 5 Green = Data excellent, interference low to 1 Green meaning Data minimal, may have significant interference. When transmitter is off, or set to a different channel than receiver these LEDs show as follows: No LED = No data, no interference. 1 Red = No data, some interference up to 5 Red = No data, high interference.
Mute - Lit LED indicates muted transmitter.
3. Channel Select - You must have the same channel selected on the
transmitter and receiver. Both ship from the factory set to channel 1, so you’re all ready to go. To select a different channel:
• Press the
Channel Select, turn Edit knob to select a channel and
then press Edit (Push To Set) knob to commit the channel.
• Set the transmitter’s channel to match, as described in its Pilot’s Handbook.
The Scan Channel feature checks all available channels for interference,
and recommends the best channels to use:
• Press
Channel Select button, then press the Select Button.
• The Display shows all 12 possible channels. The best channels are highlighted, and if the transmitter is on there’s also indication of which channel that’s currently set to.
• Turn the
Edit knob to select one of the channels that’s highlighted
as best to use, and select that same channel on the transmitter.
4. Cable Tone - Guitar cables have a natural electrical property called
capacitance. This means that longer cables roll off more high frequencies. You can use Cable Tone to simulate the effects of different guitar cable lengths and styles.
5. Display - The display will normally show the current channel you are
receiving as well as expected battery life and signal strength of your antenna frequencies. The display also can show
Tone and Setup options.
6. Edit (Push To Set) Knob - Use this knob to adjust a currently selected
Channel Select, Cable
parameter in your display such as channel number or setup features. Push the
Edit Knob in to commit any changes made when using it.
7. Setup Buttons - Press Select Button to see the list of Setup parameters.
Turn
Edit Knob to move through the list. To edit a parameter, press
Select Button turn Edit Knob, and press Edit Knob to lock that value in.
Press
Exit to leave Setup page.
8. Power Switch - Flip this switch to turn your G90 receiver on or off.
A note about Antennas:
You must use at least one pair of antennas. Should extreme interference be encountered, adding an additional pair of antennas will turn on antenna diversity for enhanced performance.
Get advanced Guide and mOre Online at
www.line6.cOm/manuals
Get up to speed on your Relay G90 receiver’s deep editing features with our Advanced User Guide available online. While you’re online be sure to register your product or simply fill out and mail us your included registration card. Registering gets you all set up for warranty service should you have an issue with your product, and also qualifies you for contests, special offers and more.
