English
Description
Espresso:
A : Espresso lid with filter storage
B : Removable espresso tank
C : Cup warming plate
D : Brewing head
E : Steam nozzle
F : Cappuccino accessory for frothing milk
G : Drip tray grid
H : Drip tray
I : Filter holder
J : 1 & 2 cup loose espresso filters
K : Espresso filter for ESE pods (Easy Serving
Espresso)
L : "CLARIS" water filter -Aqua
Filter System F088 (accessory not provided)
M : Loose coffee measuring spoon
N : Start / Stop switch for espresso with
temperature control light (blue)
O : 1 and 2 cup espresso selection button
and access to the programmed quantity
per cup:
P : Steam hot water and selection button:
S : Blue lit central display
S1 : Scroll button for setting the time and
choosing the automatic mode for the
coffee maker:
S2 : OK button:
Coffee:
a : Coffee maker lid – access to the tank and
filter holder
b : Coffee maker tank
c : Filter-holder housing
d : Filter holder with carrying handle
e : Calibrated water level indicator for the
coffee maker tank
f : Hinged lid of filter coffee jug
g : Filter coffee jug
h : Coffee warming plate
i : "Duo Filter XS 1000" water filter
(accessory not provided)
j : Start/stop filter coffee switch with blue
operating indicator
/ and
and
and
k : Selection button for programmable mode
and end-of-cycle sound signal:
l : Selection button for strong or normal
coffee strength:
or
and
Safety recommendations
• Please read these instructions carefully
before first using your espresso.The
appliance must only be connected to the
mains via an earthed plug. Check that the
voltage shown on the appliance’s indicator
plate corresponds to that of your electricity
supply. It complies with the requirements of
the EEC Directive (89/336/EEC) and (72/23/
EEC).
• Never put your espresso on a hot surface
(electric warming plate, for example) or close
to a flame. Place on a flat, stable heatresistant surface.
• Never remove the filter holder containing
the coffee grounds while water is being
passed through, since the appliance is under
pressure at this time.
• Never use the appliance if the drip tray and
the drip tray grid are not in position.
• Disconnect the electricity if there is any
problem while the coffee is brewing or prior
to cleaning your appliance.
• Never unplug the appliance by pulling on
the cord and never lay the cord across a
sharp edge or the corner of an item of
furniture.
• Do not allow the cord or your hands to
come into contact with the hot parts of the
appliance (cup warming plate, filter holder,
steam nozzle, cappuccino accessory).
• Never immerse the appliance in water.
• Keep away from children and do not allow
the cord to hang down.
• Follow the instructions given for descaling.
• Never start the machine if it is damaged or
not operating correctly or if the cord is in
poor condition.
• If the cord or any other specific part
becomes defective, these can only be
replaced by a Krups approved service centre.
You must never, under any circumstances,
open the appliance yourself, in order to
avoid any danger.
21
XP2070 anglais.P65 7/11/05, 12:3221
• Check that the filter holder is firmly in
position before starting the coffee and stop
the espresso function before releasing the
filter holder.
• Do not leave the appliance in the reach of
unsupervised children - young children and
severely handicapped persons must only use
the appliance under the supervision of a
responsible adult.
• This product has been designed for domestic
use only. Any commercial use, inappropriate
use or failure to comply with the instructions, the manufacturer accepts no
responsibility and the guarantee will not
apply.
• There is a risk of burns if the lid of the coffee
maker is removed while the coffee is
brewing.
• Never pour cold water into the coffee maker
tank immediately after the brewing cycle.
Let the appliance cool down before refilling
the tank.
• If you are unable to use the filter cartridges
recommended by Krups, only pour water
and the descaling solutions specified in the
manual into the espresso and coffee maker
water tanks.
• To disconnect, turn the switch to “OFF”,
then remove plug from wall socket.
• Do not use appliance for other than
intended use.
• Use extreme caution when dispensing hot
steam.
Espresso coffee
For optimal results, choose special ground
espresso coffee, which is ideally compacted.
Due to the pressure created by your machine’s
15-bar pump, hot water passes through this
finely ground coffee for a shorter time. The
resulting liquid is rich, dark, and extremely
flavourful and intensely aromatic: the
concentrated essence of the coffee bean.
Espresso is not served in regular coffee cups,
but in small 35ml shots. The perfect espresso
shot is topped by beautiful, thick, golden
foam known as crema, a product of the
natural oils in the coffee bean, and the source
of its rich flavour and aroma.
22
It is important to note that your espresso
coffee must be both well roasted coffee and
correctly ground. If you cannot buy ground
espresso coffee, use a coffee grinder to grind
the beans. The coffee must not be ground too
fine. It must be slightly granulated, with a
consistency somewhat between flour and
sugar. Too fine a grind results in bitter, overextracted espresso and a risk of blocking the
grid of the brewing head and the filter; too
coarse and the espresso will be weak and
under-extracted.
In addition to the coffee you use, the other
three factors that determine perfect espresso
results are water, temperature and pressure.
Your Krups machine ensures all three are
precision-controlled by expertly designed
technology. What you must ensure is that the
water you use is freshly-drawn (so that it has
not had time to stagnate in the air), without
any chlorine odour and at a fairly cold
temperature.
We recommend that you filter your water
using a commercially available KRUPS
Claris - Aqua Filter System cartridge
(reference F088).
There are a number of misconceptions
surrounding espresso. The first is that espresso
should be bitter and burnt tasting. In fact, the
ideal espresso shot should be aromatic,
bittersweet (not bitter) and assertive, with a
lingering aftertaste.
The second myth is that drinking espresso will
keep you awake all night. Actually, despite its
strong flavour, espresso contains less caffeine
than regular coffee; typically 60-80 mg per
shot compared to 80-100 mg per cup of
regular coffee due to espresso's shorter
percolation time.
And finally, many people think that espresso
takes too long to prepare. The truth is, as the
name implies, an espresso is intended to be
served quickly, without elaborate preparation.
As you will discover, your Krups espresso
maker has been intuitively designed for easy
use and built for the long term.
XP2070 anglais.P65 7/11/05, 12:3222
Getting started
To successfully enjoy the full benefits of your
new Krups espresso maker, please carefully
read these instructions in their entirety before
using this product.
• Place your espresso maker on a stable, heat
resistant surface away from water splashes
and sources of heat such as, an electrical
heating plate or near a flame.
• Ensure the drip tray and drip tray grid are in
place when using the machine.
Starting the appliance and setting the
time:
Your XP2070 combined espresso-filter coffee
maker has a central screen (S) making it easy
to use and providing a wide range of settings.
When you plug in your appliance for the first
time or after an extended power cut, you can
set the clock in European (24-hour clock) or
American (AM-PM) display mode.
not be able to access the functions of the
appliance without setting the time.
• When the appliance is switched on, the
pictograms
the display mode by pressing the scroll
button (S1) and confirm your selection by
pressing the OK button (S2).
• Once the display mode has been confirmed,
you are then prompted to set the time. The
2 “hour” digits blink. Press the scroll button
(S1) and confirm your selection by pressing
the OK button (S2). The 2 “minutes” digits
blink. Set the minutes by pressing (S1) and
then (S2) to confirm.
• The hour and the minutes can be set either
by pressing the button in succession or by
holding down the button and scrolling down
(button S1).
• To change the time setting, hold down the
button (S1) (>2 s) and proceed as above by
pressing (S1) and (S2) in succession.
• To set the automatic start time for your
coffee maker, see the FILTER COFFEE section.
, and blink. Select
You will
Espresso
Before using your machine for the first time,
clean the system completely as follows:
• Open the lid and lift out the water container
using the handle (1). Fill the water container
with fresh, cold water (2).
• Place the water container back into the
machine by positioning it firmly in the water
container compartment (3) and close the lid.
• Turn on the machine (4). The start/stop
switch (N) will blink. The appliance is ready
as soon as this blinking stops.
• Your espresso maker is equipped with
three filters designed for 1 cup, or for 2
cups of espresso using ground coffee, or
for E.S.E. (Easy Serving Espresso) pods.
The first comes in the filter holder (I),
the other two are found in the
appliance’s transport packaging.
• Choose the filter that you wish to use and
place it in the filter holder (5). Store the 2
others in the espresso lid (A).
• Then place the filter holder under the
appliance’s brewing head. To ensure that the
filter holder is in the correct position, turn
the handle so it points to the left at a 45
degree angle (6), place the filter holder flat
against the brewing head, then turn the
handle towards the right (7) as far as it can
go.
• Place a container, as large as possible,
beneath the filter holder (8).
The machine is ready to operate.
• By pressing twice on the espresso selection
button (O) so as to select the 2-cup mode
(10), the water will flow through the
pipes of the appliance.
Repeat this process five times.
To start the coffee maker part, see the FILTER
COFFEE section.
Using the various functions of
your espresso maker
1. MAKING ESPRESSO
The appliance will pre-brew the coffee before
making each cup in order to bring out the full
flavour for a satisfying cup of coffee. The
pump will work for 3 seconds, stop for 3
seconds, then continue with the cycle until
the end of the process.
23
XP2070 anglais.P65 7/11/05, 12:3223
. WITH GROUND COFFEE
For best results, we recommend that you first
pre-heat the accessories (filter holder, filters
and cups) without putting in ground
coffee. To do this:
• Fill the water container with fresh, cold
water (1) (2) (3) and turn on the machine
(4).
• Put the filter holder and an empty filter in
place (6) (7), and place the espresso cups
underneath.
• As soon as the coffee selection buttons
begin to glow continuously, the machine is
ready to operate.
• Choose the 1 or 2 cup mode, by pressing
, or (9) (10) once or twice on the
espresso selection button (O). Take the prebrewing into account.
• The cups will fill with hot water. Once filled,
empty them.
After making your first espresso and the
machine is warmed, the espresso cups can
then be pre-heated on the cup warming plate.
. Preparing an espresso:
• Fill the water container (1) (2) (3) and turn
on the machine (4).
• Put the filter for one or two cups into the
filter holder (5).
• Place some ground coffee in the filter (1 or 2
measuring scoops), and then tamp it down
firmly; the coffee should reach the lip of the
filter (11) (12).
• Remove any ground coffee which is lying
around the filter (13).
• Replace the filter holder into the machine.
Turn the filter holder until it is firmly locked
into place (6) (7).
• Place one or two espresso cups beneath the
filter holder’s coffee outlets.
As soon as the coffee selection buttons begin
to glow continuously, the machine is ready to
operate.
Your machine is already preprogrammed for
the preparation of one or two cups of
espresso.
• Select the desired coffee quantity by
pressing the button (O) once
or
twice (9) (10). Take the pre-brewing into
account.
24
• When the programmed quantity is reached,
espresso stops running automatically (see
programming your machine).
• Remove the filter holder and the filter from
the machine and take out the coffee
grounds (14).
The filter can be refilled to make more
espressos.
Caution: if the water container is empty
and the pump is running, you will hear a
very distinct noise, which is louder than
the normal operating sound. If this
happens, press the start/stop switch (4).
Check the water container and refill as
needed.
Never let the machine run when the
water container is empty as this can
damage the pump.
.
USING THE SPECIAL “ E.S.E. “ FILTER
The E.S.E. system was designed for making
Italian-style “espresso ristreto” (squeezed).
The amount of coffee is 35 ml and the water
should take 20 seconds to run through.
“ESE”, which stands for “Easy Serving
Espresso”, is a selected measure of coffee,
ground and pressed between two filter papers
making it ready for use. This system makes it
easy for you to prepare your espresso because
you avoid the measurement and tamping
down operations and it also makes it easier
for you to clean the appliance.
We do not intend, or recommend, that
the E.S.E. servings be used for making
more then one single serving or a “long
espresso”.
We recommend that you take care when
handling and storing the E.S.E. pre-portioned
pods so that they do not become deformed.
For best results, we recommend that you preheat the accessories (filter holder, filter basket
and cups) without any coffee. To do this, see
section entitled “Espresso Making” above.
. Preparing an espresso:
• Fill the water tank (1) (2) (3) and turn on the
machine (4).
Positioning the E.S.E. pod (18).
Tear excess paper from pod at perforated
edge. Place the E.S.E. pod with the RED
MARKING FACE DOWN (bend the paper
corners down) in the E.S.E. filter holder fitted
with its own filter.
XP2070 anglais.P65 7/11/05, 12:3224
• Take care to put all the paper inside the
filter or you may get some drips.
Placing the E.S.E. pod correctly will create a
richer, thicker crema.
Locking the handle tightly and properly will
also help avoid leakage from the filter holder
and ensure a better brewing cycle.
Place the filter holder inside the brewing head
and firmly turn the handle as far right as
possible (6) (7) (8).
As soon as the coffee selection buttons
commence to glow continuously, the machine
is ready to operate.
• Press the espresso selection button (O)
once (9). Take the pre-brewing into account.
• When the recommended quantity of coffee
has been reached the appliance will stop
automatically. You can stop your machine at
any time by pressing the coffee selection
button
(9) again.
• Remove the filter holder from the brewing
head and throw away the used coffee pod.
2. PROGRAMMING YOUR MACHINE:
Should you wish to alter the preprogrammed
quantity (50ml per cup, default setting) of
espresso filled into one or two cups, proceed
as follows:
• Fill the water container (1) (2) (3) and turn
on the machine (4).
• Put the filter for one or two cups into the
filter holder (5).
• Place some ground coffee in the filter (1 or 2
measuring scoops), and then tamp it down
firmly; the coffee should reach the lip of the
filter (11) (12) or a E.S.E. pod in the E.S.E.
filter (18).
• Remove any ground coffee which is lying
around the filter (13).
• Replace the filter holder (6) (7).
• Place one or two cups beneath the filter
holder’s coffee outlets.
As soon as the coffee selection buttons
begin to glow continuously, the machine is
ready to operate.
• Press the espresso selection button (O) once
or twice according to your choice
,
, or
(9) (10). The start / stop switch (N)
will blink. Take the pre-brewing into
account.
• Then press the scroll button (S1) to activate
the quantity memory function. The symbol
“
” is displayed in the centre of the screen.
• When you reach the desired quantity of
coffee, stop the appliance by pressing the
espresso selection button (O) or (S2).
The quantity that just ran through into your
cup is now automatically programmed into
the machine.
3. STEAM FUNCTION
The thumping noise which occurs while steam
is being produced comes from the intermittent regulation of the pump and has no effect
on the proper working of the machine.
If you wish to make an espresso
immediately after using the steam
function, the appliance must first be allowed
to cool down in order to achieve the correct
temperature for preparing an espresso.
• As soon as you interrupt the steam cycle, the
appliance will cool down automatically by
launching an intermittent pump cycle for
40seconds. The cold water pumped through
will cool down the heating system. During
the cool down phase, the blue start/stop
operating control light blinks and the hot
water flows into the drip tray. When the
correct temperature is reached, the
appliance is ready.
Caution: during and after use, the metal
parts of the nozzle (E) and the cappuccino
accessory (F) are very hot.
. Using the Cappuccino accessory (F)
The cappuccino accessory makes it easy to
produce hot milk or frothy milk for making a
cappuccino, latte or hot chocolate, for
example.
It is preferable to use very cold, very fresh,
milk (kept in the refrigerator).
• Fill the water container with fresh, cold
water (1) (2) (3) and turn on the machine
(4).
• Put the cappuccino accessory in place on the
steam nozzle.
• Place a cup under the cappuccino accessory.
• Pour about 100 ml of cold milk into a
container.
• When your appliance is ready to make an
espresso, press the steam/hot water button
25
XP2070 anglais.P65 7/11/05, 12:3225
/
(P) once. The steam symbol appears
and the start/stop control light blinks.
Once this indicator stops blinking, your
appliance is ready to froth milk.
First, use a spare container and place it under
the accessory without touching the bottom.
Pr
ess the steam button
(P)
A small squirt of hot water will be released
which you may prefer to dispose of before
proceeding to froth your milk.
To stop, press the steam button
(P).
Next put your container under the accessory
so that the end of the accessory is plunged
into the milk, without touching the bottom
(17).
• Pr
ess the steam button
(P). The steam
symbol blinks.
• Once the desired quantity of milk froth has
been produced, press the steam button
again to stop
(P). The cool down cycle
starts.
Follow the cleaning operation below in order
to prevent the milk from drying on the
cappuccino accessory:
• Place a cup under the auto cappuccino
accessory (F).
Repeat the procedure for preparing frothy
milk, but this time with water, for
approximately 1 minute.
• Press the steam /hot water button
(P) again to stop the production of steam.
• Clean the cappuccino accessory with a damp
cloth.
• For more thorough cleaning of the auto
cappuccino accessory, please refer to the
section below entitled “Cleaning the
machine”.
4 . HOT WATER
You can prepare hot water with this machine.
• Fill the water container (1) (2) (3) and turn
on the machine (4).
• Place the cup beneath the cappuccino
accessory (F).
As soon as hot water button commences to
glow continuously, the machine is ready to
operate.
• Press the water / steam selection button
/
(15). It is normal for the steam symbol
26
and the blinking ON/OFF control light to
appear when the button is first pressed.
• When the desired quantity of water has run
through, stop the machine by pressing again
the hot water button
(P).
You can also programme the quantity of
water:
• When your appliance is ready, press the
water / steam selection button
/
(P)
twice.
• Then press the scroll button (S1) to activate
the quantity memory function. The symbol
“
” is displayed in the centre of the screen.
When you reach the desired quantity of
water, stop the appliance by pressing the hot
water / steam button
/
(P) or (S2).
Recipes
Savour your espresso just as you like it: when
you want to relax or to round off a good
meal.
Here are a few recipes which you will be able
to create with your espresso maker.
. Original espresso
• Take one measuring spoonful of good
quality well roasted espresso coffee, and run
it directly into the pre-heated cup.
/
If you use good, finely ground coffee, the cup
will be crowned by a fine head of froth.
• Add sugar if desired and treat yourself.
Original espresso is drunk without milk but
plenty of sugar.
. Cappuccino
For a state of the art cappuccino, the ideal
quantities are as follows: 1/3 coffee, 1/3 hot
milk, 1/3 milk froth. The quantity of hot milk
+ froth obtained should be about double the
amount of coffee prepared.
• Use large cups which have been pre-heated.
• Fill them with coffee to the equivalent of
one cup of espresso and top up with milk
which has been frothed up using the
cappuccino accessory.
• Lastly, sprinkle with drinking chocolate
powder.
. Café crème
• Prepare a classic espresso in a large cup.
XP2070 anglais.P65 7/11/05, 12:3226
• Add a cloud of cream to make an espresso
with milk.
You can also replace the cream with hot milk.
. Caffe corretto *
• Prepare a cup of espresso in the normal way.
• Then slightly ‘correct’ the taste by adding
1/4 or 1/2 a glass of cognac.
You can also use anisette, grappa, Sambuco,
Kirsch or Cointreau for the same effect.
. Coffee Liqueur *
• Mix in an empty 0.75 litre bottle: 3 cups of
espresso, 250 g brown cane sugar, 1/2 litre
cognac or Kirsch.
• Leave the mixture to soak for at least 2
weeks.
You will then have a delicious liqueur,
especially for coffee lovers.
. Iced coffee à l’italienne
4 vanilla ice cubes, 2 cups of cold sugared
espresso, 1/8 litre milk, fresh cream, grated
chocolate.
• Mix the cold espresso with milk.
• Distribute the ice cubes among the glasses,
pour the coffee over them and decorate
with fresh cream and grated chocolate.
. Friesian coffee *
• Add a small glass of rum to a sugared cup of
espresso.
• Decorate with a good layer of fresh cream
and serve.
. Espresso flambé *
2 cups of espresso, 2 small glasses of cognac,
2 teaspoonfuls of brown sugar, fresh cream.
• Pour the cognac into heat-resistant glasses,
heat and flame.
• Add sugar, mix, pour the coffee and
decorate with fresh cream.
If you like, the espresso can also be diluted
with a little boiling water.
. Perfect espresso *
2 cups of espresso, 6 egg yolks, 200g sugar,
1/8 litre whipped fresh cream, 1 small glass of
orange liqueur.
• Beat the egg yolks with the sugar until it
forms a thick foamy mass.
• Add the cold espresso and orange liqueur.
• Then mix in the fresh whipped cream.
• Pour the mixture into cups or glasses.
• Put the cups into the freezer.
(*: The abuse of alcohol is dangerous to your
health).
Cleaning the machine
- Never wash your espresso maker accessories
in the dishwasher.
After use, the water tank must be emptied.
. Drip tray
If several espressos are being prepared one
after the other, the drip tray should be
emptied from time to time (about once every
7 - 8 espressos) (19). It is normal for there to
be water present; this does not indicate
that there is a leak, but that your
machine’s thermoblock is being purged. If
necessary, clean the drip tray and drip tray
grid with water and a little non-abrasive
washing-up liquid, rinse and dry. Replace it
correctly (20).
. The brewing head, the filter and the
filter holder
These must be cleaned after each use. All you
need to do is wipe with a damp cloth over the
brewing head of your machine and to wash
the other accessories in water and a little nonabrasive washing up liquid, rinse and dry.
If the brewing head is heavily clogged up,
unscrew the grid, clean it and refit it, pressing
down firmly (21).
When your espresso maker is not being
used, do not leave the filter holder on the
machine as it will cause unnecessary wear
of the gasket.
. The cup warming plate: remove this to
clean it with water and a little non-abrasive
dishwashing liquid, rinse and dry.
. The cappuccino accessory
For more thorough cleaning the auto cappuccino accessory can be dismantled from the
machine.
Clean it with water, a little non-abrasive
washing up liquid and a small brush. Rinse
and dry it.
Before putting it back in place, make sure that
the air inlet holes (on both sides of the little
metal tube) are not blocked by residues of
milk. Unblock them with a needle if necessary
(22).
27
XP2070 anglais.P65 7/11/05, 12:3227
Descaling
Descaling is necessary to keep your espresso
maker running efficiently.
• Your espresso maker should be descaled on
a regular basis.
• Use caution when descaling your espresso
maker as the acid substance within the
descaling powder may damage worktops or
any other surface it comes in contact with.
• The warranty of this machine does not
include espresso makers that do not
function, or do not function properly,
because descaling has not been carried
out.
We would advise you to use the Krups
descaling solution that is available from Krups.
Descaling depends on the hardness of the
water, but also on the frequency of use.
- To descale follow the following method:
• Remove the Claris-Aqua Filter System
cartridge (accessory not provided) if you
have fitted one.
• Unscrew the grid from the head of the
machine and clean it (21).
• Dissolve a packet of KRUPS descaling
solution in 500 ml of lukewarm water and
pour the whole batch into the empty water
container.
• Start the machine (4).
• Place a container, as large as possible,
beneath the auto cappuccino accessory.
As soon as the start/stop switch begins to
glow continuously, the machine is ready.
• Press twice the steam / hot water button
/
(P), and run through 1/3 of the liquid.
• Press the hot water / steam button again
/
(P) to stop.
• Move the container under the brewing
head.
• Run the second third of the liquid
immediately by pressing the coffee button
(9) as many times as necessary.
• Stop the machine by pressing the start/stop
switch
to allow the descaler to take effect.
• Next, start the machine again
allow the rest of the liquid to run through by
28
(N) and wait for 10 - 15 minutes
(N) and
pressing the coffee button (9) as many
times as necessary.
• Then rinse with two water containers of
fresh water, clean the brewing head and
replace the grid on the head of the machine
(see section on Cleaning the Machine).
Troubleshooting
Problems Probable causes Corrective actions
Espresso not hot Cups, filter and Preheat the
enough filter holder accessories (cups,
are cold. filter, filter holder)
See paragraph
“Preparing an
espresso”.
Coffee leaks The filter holder See paragraph
around the filter is not mounted “Preparing an
holder correctly or has espresso”.
not been tightened
sufficiently.
There are coffee Clean around the
grounds on the filter and the
edge of the filter. gasket.
The brewing head Clean the gasket
gasket is dirty. with a damp cloth.
The brewing Contact an
head gasket approved Krups
is defective. service centre.
Pump is very noisy No water in the Fill the water tank.
water tank.
Water tank incor- Press firmly down
rectly mounted. on the water tank.
Coffee grounds Use fresh coffee.
too old or very dry
and the pump
cannot produce
pressure.
Water does not No water in the Fill the water tank.
run through. water tank.
Water tank incor- Press firmly down
rectly mounted. on the water tank.
The filter is Clean the filter and
blocked, the coffee the grid on the
grounds are too brewing head.
fine or tamped See the paragraph
down too hard. “Maintenance” and
try a coarser coffee.
Brewing head Put the grid to
grid is encrusted. soak in descaling
solution.
See paragraph
“Maintenance”.
XP2070 anglais.P65 7/11/05, 12:3228
Appliance needs See paragraph
descaling. “Descaling”.
Water runs Coffee grounds too Try a finer coffee.
through too coarse.
quickly.
Quantity of Use the spoon
ground coffee provided to
is insufficient. measure out the
Coffee grounds not Tamp down the
tamped down coffee again.
firmly enough.
The espresso has Coffee grounds Try a finer-ground
no crema (froth too coarse. coffee.
on coffee).
Coffee grounds Tamp down the
not tamped. coffee again.
Coffee grounds Use fresh coffee.
stale or too dry.
The milk is not Auto Cappuccino See paragraph
very frothy. accessory blocked
Milk not fresh. Use fresh milk.
Milk is lukewarm. Put milk in
Milk is not suitable. Try another brand.
Lots of water on Grounds not Tamp down the
coffee grounds. properly tamped grounds.
down.
Insufficient quantity Increase the
of ground coffee. quantity of ground.
coffee.
“Maintenance”
refrigerator.
Filter coffee
. Setting the time for a preprogrammed
start
You can set the preprogrammed start time at
any moment.
• Make sure that your appliance is switched
off - the indicators for the espresso (N) and
coffee (j) ON/OFF buttons are not on – and
that the clock of your appliance is showing
the correct time (see section “Getting
started; starting the appliance and setting
the time”).
• Holding down (> 2 seconds) the programmable mode button (k)
access the programming for the automatic
start time.
allows you to
• You are prompted to set the time. The
2 “hour” digits blink. Press the scroll button
(S1) and confirm your selection by pressing
the OK button (S2). The 2 “minutes” digits
blink. Set the minutes by pressing (S1) and
then (S2) to confirm.
Before first use
• Operate the coffee machine for the first time
with 1 litre of water, without any grounds.
Making coffee
The quality of the water that you use
determines the taste of your coffee. You must
ensure that the water is freshly drawn from
the tap (so that it has not had the time to
stagnate in the air), that it does not smell of
chlorine and that it is at a fairly cold
temperature.
We recommend that you filter your water
using a Krups Duo Filter cartridge,
reference XS 1000.
• Follow the illustrations from 23 to 29.
• Use only cold water and a N° 4 filter paper
or a permanent filter.
• The coffee maker is fitted with a drip-stop
device, allowing you to serve coffee before
the water has finished running through.
Replace the jug quickly to avoid overflow.
• Do not exceed the maximum capacity of the
water tank as shown by the water level
indicator (e).
Your coffee maker is equipped with a
flavour selector (h) (according to model):
This device enables you to obtain more
strongly flavoured coffee, for 1, 2 or 3 cups
(30). The more strongly flavoured coffee is
produced using a slower cycle of water.
• With your appliance switched on in filter
coffee mode (J), press the selection button (l)
for a normal or strong coffee
. Preprogrammed start and alarm
You can choose to activate the
preprogrammed start mode and/or the alarm
mode which gives a sound signal when your
coffee is ready (31).
.
XP2070 anglais.P65 7/11/05, 12:3229
29
Your appliance is switched on in filter coffee
mode. Holding down (> 2s) the programmable mode button (k) allows you to access the
preprogrammed start
sound signal
, or the two functions ,
, the end-of-cycle
at the same time.
Make and confirm your choice using the scroll
(S1) and OK (S2) buttons.
• Without any action on your part, your
appliance keeps the coffee hot for 2 hours
and switches itself off automatically.
• Wait for a few minutes before making
coffee a second time.
• The jug (g) and its lid (f) may be used for
warming up coffee in the microwave. Never
put the empty jug in the microwave.
Cleaning
• To dispose of the used grounds, lift the filter
holder out of the coffee maker (32).
• Unplug the appliance.
• Do not clean the appliance while hot.
• Clean with a damp cloth or sponge.
• Never immerse the appliance in water or put
it under running water.
• The glass coffee jug, the lid and the filter
holder can be washed in the dishwasher.
Descaling
Number of cycles between 2 descaling operations
Without Duo Filter With Duo Filter
Soft water 60 120
Hard water 40 80
You may use:
• either a sachet of descaler diluted in 250 ml
of water,
• or 250 ml of white vinegar.
• Pour into the tank (b) and start the coffee
maker (without coffee).
• Allow half the liquid to run into the coffee
jug (g), then switch off.
• Leave to work for one hour.
• Restart the coffee maker to complete the
run-through.
30
• Rinse the coffee maker by running it 2 or 3
times with 1 Litre of clean water.
The guarantee does not cover coffee
makers that fail or work badly, due to
scale.
In the event of a problem
- Check:
• that the appliance is properly connected,
• that the switch is in the “I” position.
- There seems to be a leak
• Check if the water tank has been filled
above the maximum level.
- The time taken for the water to run
through is too long and the appliance is
very noisy:
• descale your coffee maker.
Your appliance still does not work?
Contact a Krups approved service centre.
HELPLINE:
If you have any product problems or queries,
please contact our Customer Relations Team
first for expert help and advice:
0845 602 1454 - UK
(01) 4751947 - Ireland
Or consult our website - www.krups.co.uk
Environment protection
first!
Your appliance contains valuable materials
which can be recovered or recycled.
Leave it at a civic waste collection point.
XP2070 anglais.P65 7/11/05, 12:3230
Loading...
