Jonsered CS 2150 User Manual

Oper ator ′ s manual
Please read the oper ator’s manual carefully and make sure you understand the instructions before using the machine.
2
W
KEY T O SYMBOLS

Symbols on the mac hine:

ARNING! Chain saws can be dangerous! Careless or incorrect use can result in serious or fatal injury to the operator or others.
Please read the operator’s manual carefully and make sure you understand the instructions before using the machine.
Always wear:
Approved protective helmet
Approved hearing protection
Protective goggles or a visor
This product is in accordance with applicable EC directives.
Noise emission to the environment according to the European Community’s Directive. The machine’s emission is specified in chapter Technical data and on label.

Symbols in the operator’ s manual:

Switch off the engine b y moving the stop switch to the STOP position before carrying out any checks or maintenance.
Always wear approved protective gloves.
Regular cleaning is required.
Visual check.
Protective goggles or a visor must be worn.
Refuelling.
Other symbols/decals on the mac hine refer to special certification requirements for certain markets.
Filling with oil and adjusting oil flow.
The chain brake must be engaged when the chain saw is started.
WARNING! Kickback may occur when the nose or tip of the guide bar touches an object, and cause a lightning fast reverse reaction, kicking the guide bar up and towards the operator. May cause serious personal injury.
English
ST
W
T

CONTENTS

Contents
KEY TO SYMBOLS
Symbols on the machine: .............................................. 2
Symbols in the operator’s manual: ................................ 2
CONTENTS
Contents ....................................................................... 3
INTR ODUCTION
Dear Customer , ............................................................. 4
WHA T IS WHAT?
What is what on the chain sa w? ................................... 5
GENERAL SAFETY PRECA UTIONS
Bef ore using a new chain saw ...................................... 6
Important ....................................................................... 6
Always use common sense .......................................... 6
Personal protective equipment ...................................... 7
Machine ′ s safety equipment ......................................... 7
Cutting equipment ......................................................... 10
ASSEMBL Y
Fitting the bar and chain ............................................... 16
FUEL HANDLING
Fuel ............................................................................... 17
Chain oil ........................................................................ 17
Fuelling ......................................................................... 18
Fuel safety .................................................................... 18
Transport and storage ................................................... 18
Long-term storage ........................................................ 18
ARTING AND STOPPING
Star ting and stopping .................................................... 19
ORKING TECHNIQUES
Bef ore use: .................................................................... 21
General working instructions ........................................ 21
How to avoid kickback ................................................... 28
MAINTENANCE
Gener al ......................................................................... 29
Carburettor adjustment ................................................. 29
Checking, maintaining and servicing chain saw safety
equipment ..................................................................... 30
Muffler ........................................................................... 32
Starter ........................................................................... 32
Air filter .......................................................................... 33
Spark plug ..................................................................... 33
Lubricating the bar tip sprocket ..................................... 34
Needle bearing lubrication ............................................ 34
Adjustment of the oil pump ........................................... 34
Cooling system ............................................................. 34
”Air Injection” centrifugal cleaning ................................. 35
Winter use ..................................................................... 35
Maintenance schedule .................................................. 36
TECHNICAL D ATA
echnical data ............................................................... 37
Bar and chain combinations ......................................... 38
Saw chain filing and file gauges .................................... 38
EC-declaration of conformity ......................................... 39
English
– 3
4
INTR ODUCTION

Dear Customer ,

Cong ratulations on your choice to buy a Jonsered product!
We are convinced that you will appreciate with great satisfaction the quality and performance of our product for a very long time to come. The purchase of one of our products gives you access to professional help with repairs and service whenever this may be necessary. If the retailer who sells your machine is not one of our authorised dealers, ask for the address of your nearest service workshop.
It is our wish that you will be satisfied with your product and that it will be your companion for a long time. Think of this operator ′ s manual as a valuable document. By following its of the machine can be extended. If you will sell this machine, make sure that the buyer will get the operator
Good luck on using your Jonsered machine!
Jonsered has a policy of continuous product development and therefore reserves the right to modify the design and appearance of products without prior notice.
content (using, service, maintenance etc) the life span and the second-hand value
s manual.
English
1
WHA T IS WHA T?
What is what on the c hain saw?
Cylinder cover
2 Front handle
3 Front hand guard
4 Starter
5 Chain oil tank
6 Starter handle
7 Adjuster screws carburettor
8 Choke control/Start throttle lock
9 Rear handle
10 Stop switch (Ignition on/off switch.)
11 Fuel tank
12 Muffler
13 Bar tip sprocket
14 Chain
15 Bar
16 Spike bumper
17 Chain catcher
18 Clutch cover
19 Rear handle with right hand guard
20 Throttle control
21 Throttle lock
22 Decompression valve (CS 2145, CS 2150)
23 Combination spanner
24 Chain tensioning screw
25 Operator ′ s manual
26 Bar guard
27 Oil pump adjustment screw
28 Information and warning decal
29 Product and serial number plate
English
– 5
6
W
W
W
W
W
W
GENERAL SAFETY PRECA UTIONS

Bef ore using a new chain saw

Please read this manual carefully.
Check that the cutting equipment is correctly fitted and
adjusted. See instructions under the heading Assembly.
Refuel and start the chain saw. See the instructions under
the headings Fuel Handling and Starting and Stopping.
Do not use the chain saw until sufficient chain oil has
reached the chain. See instructions under the heading Lubricating cutting equipment.
Long-term exposure to noise can result in permanent
hearing impairment. So always use approved hearing protection.
ARNING! Under no circumstances may the
design of the machine be modified without
!
the permission of the manufacturer. Always use genuine accessories. Non-authorized modifications and/or accessories can result in serious personal injury or the death of the operator or others.
ARNING! A chain saw is a dangerous tool
if used carelessly or incorrectly and can
!
cause serious, even fatal injuries. It is very important that you read and understand the contents of this operator’s manual.

Impor tant

IMPOR TANT!
The machine is only designed for cutting wood.
You should only use the saw with the bar and chain combinations we recommend in the chapter Technical data.
Never use the machine if you are fatigued, while under the influence of alcohol or drugs, medication or anything that could affect your vision, alertness, coordination or judgement.
Wear personal protective equipment. See instructions under the heading Personal protective equipment.
Do not modify this product or use it if it appears to have been modified by others.
Never use a machine that is faulty. Carry out the checks, maintenance and service instructions described in this manual. Some maintenance and service measures must be carried out by trained and qualified specialists. See instructions under the heading Maintenance.
Never use any accessories other than those recommended in this manual. See instructions under the headings Cutting equipment and Technical data.
CAUTION! Always wear protective glasses or a face visor to reduce the risk of injury from thrown objects. A chain saw is capable of throwing objects, such as wood chips, small pieces of wood, etc, at great force. This can result in serious injury, especially to the eyes.
ARNING! The inside of the muffler contain
chemicals that may be carcinogenic. Avoid
!
contact with these elements in the event of a damaged muffler.
ARNING! Long term inhalation of the
engine’s exhaust fumes, chain oil mist and
!
dust from sawdust can represent a health risk.
ARNING! Running an engine in a confined
or badly ventilated area can result in death
!
due to asphyxiation or carbon monoxide poisoning.
ARNING! Faulty cutting equipment or the
wrong combination of bar and saw chain
!
increases the risk of kickback! Only use the bar/saw chain combinations we recommend, and follow the filing instructions. See instructions under the heading Technical data.

Always use common sense

It is not possib le to cover every conceivable situation you can face when using a chain saw. Always exercise care and use your common sense. Avoid all situations which you consider to be beyond your capability. If you still feel uncertain about operating procedures after reading these instructions, you should consult an expert before continuing. Do not hesitate to contact your dealer or us if you have any questions about the use of the chain saw. We will willingly be of service and provide you with advice as well as help you to use your chain saw both efficiently and safely. Attend a training course in
English
P
GENERAL SAFETY PRECA UTIONS
Y
W
W
chain sa w usage if possible. Your dealer, forestry school or your library can provide information about which training materials and courses are available.
Work is constantly in progress to improve the design and technology - improvements that increase your safety and efficiency. Visit your dealer regularly to see whether you can benefit from new features that have been introduced.
ersonal protective equipment
ARNING! Most chain saw accidents
happen when the chain touches the
!
operator. You must use approved personal protective equipment whenever you use the machine. Personal protective equipment cannot eliminate the risk of injury but it will reduce the degree of injury if an accident does happen. Ask your dealer for help in choosing the right equipment.
Fire Extinguisher and Shovel
Generally clothes should be close-fitting without restricting your freedom of movement.
IMPOR TANT! Sparks can come from the muffler, the bar and chain or other sources. Always have fire extinguishing tools available if you should need them. Help prevent forest fires.
Mac hine ′′
In this section the machine’ s safety features and their function are explained. For inspection and maintenance see instructions under the heading Checking, maintaining and servicing chain saw safety equipment. See instructions under the heading, What is what?, to find where these parts are located on your machine.
The life span of the machine can be reduced and the risk of accidents can increase if machine maintenance is not carried out correctly and if service and/or repairs are not carried out professionally. If you need further information please contact your nearest service workshop.
!
′′
s safety equipment
ARNING! Never use a machine with defective safety components. Safety equipment must be inspected and maintained. See instructions under the heading Checking, maintaining and servicing chain saw safety equipment. If your machine does not pass all the checks, take the saw to a servicing dealer for repair.
Approved protective helmet
Hearing protection
Protective goggles or a visor
Gloves with saw protection
Trousers with saw protection
Boots with saw protection, steel toe-cap and non-slip sole
Always have a first aid kit nearby.

Chain brake and fr ont hand guard

our chain saw is equipped with a chain brake that is designed to stop the chain if you get a kickback. The chain brake reduces the risk of accidents, but only you can prevent them.
Take care when using your saw and make sure the kickback zone of the bar never touches any object.
English
– 7
GENERAL SAFETY PRECA UTIONS
8
The chain brake (A) can either be activated manually (by your left hand) or automatically by the inertia release mechanism.
The brake is applied when the front hand guard (B) is pushed forwards.
This movement activates a spring-loaded mechanism that tightens the brake band (C) around the engine drive system (D) (clutch drum).
The front hand guard is not designed solely to activate the chain brake. Another important feature is that it reduces the risk of the chain hitting your left hand if you lose grip of the front handle.
To release the chain brake pull the front hand guard backwards, towards the front handle.
Kickback can be very sudden and violent. Most kickbacks are minor and do not always activate the chain brake. If this happens you should hold the chain saw firmly and not let go.
The way the chain brake is activated, either manually or automatically by the inertia release mechanism, depends on the force of the kickback and the position of the chain saw in relation to the object that the kickback zone of the bar strikes.
If you get a violent kickback while the kickback zone of the bar is farthest away from you the chain brake is designed to be activated by the inertia in the kickback direction.
The chain brake must be engaged when the chain saw is started to prevent the saw chain from rotating.
Use the chain brake as a ”parking brake” when starting and when moving over short distances, to reduce the risk of moving chain accidentally hitting your leg or anyone or anything close by.
If the kickback is less violent or the kickback zone of the bar is closer to you the chain brake will be activated manually by the movement of your left hand.
English
GENERAL SAFETY PRECA UTIONS
No
No
No
In the felling position the left hand is in a position that makes manual activation of the chain brake impossible. With this type of grip, that is when the left hand is placed so that it cannot affect the movement of the front hand guard, the chain brake can only be activated by the inertia action.

Will m y hand always activate the chain brake during a kickback?

. It takes a certain force to move the hand guard forward. If your hand only lightly touches the front guard or slips over it, the force may not be enough to trigger the chain brake. You should also maintain a firm grip of the chain saw handles while working. If you do and experience a kickback, your hand may never leave the front handle and will not activate the chain brake, or the chain brake will only activate after the saw has swung around a considerable distance. In such instances, the chain brake might not have enough time to stop the saw chain before it touches you.
There are also certain positions in which your hand cannot reach the front hand guard to activate the chain brake; for example, when the saw chain is held in felling position.

Throttle lock

The throttle lock is designed to prevent accidental operation of the throttle control. When you press the lock (A) (i.e. when you grasp the handle) it releases the throttle control (B). When you release the handle the throttle control and the throttle lock both move back to their original positions. This arrangement means that the throttle control is automatically locked at the idle setting.

Chain catcher

The chain catcher is designed to catch the chain if it snaps or jumps off. Replace it if necessary with an aluminium chain catcher (is available as spare part). This should not happen if the chain is properly tensioned (see instructions under the heading Assembly) and if the bar and chain are properly serviced and maintained (see instructions under the heading General working instructions).

Will m y inetria activated chain brake always activate during kickback in the event of a kickback?

. First your brake must be in working order. Testing the brake is simple, see instructions under the heading Checking, maintaining and servicing chain saw safety equipment. We recommend you do before you begin each work session. Second the kickback must be strong enough to activate the chain brake. If the chain brake is too sensitive it would activate all the time which would be a nuisance.

Will m y chain brake always protect me from injury in the event of a kickback?

. First, the chain brake must be in working order to provide the intended protection. Second, it must be activated during the kickback as described above to stop the saw chain. Third, the chain brake may be activated but if the bar is to close to you the brake might not have enough time to slow down and stop the chain before the chain saw hits you.
Only you and proper working technique can eliminate kickback and its danger.

Right hand guard

Apart from protecting your hand if the chain jumps or snaps, the right hand guard stops branches and twigs from interfering with your grip on the rear handle.

Vibration damping system

Your machine is equipped with a vibration damping system that is designed to minimize vibration and make operation easier.
The machines vibration damping system reduces the transfer of vibration between the engine unit/cutting equipment and the machines handle unit.
English
– 9
GENERAL SAFETY PRECAUTIONS
The body of the chain saw, including the cutting equipment, is insulated from the handles by vibration damping units.
Cutting hardwoods (most broadleaf trees) creates more vibration than cutting softwoods (most conifers). Cutting with cutting equipment that is blunt or faulty (wrong type or badly sharpened) will increase the vibration level.
WARNING! Overexposure to vibration can lead to circulatory damage or nerve damage
!
in people who have impaired circulation. Contact your doctor if you experience symptoms of overexposure to vibration. Such symptoms include numbness, loss of feeling, tingling, pricking, pain, loss of strength, changes in skin colour or condition. These symptoms normally appear in the fingers, hands or wrists. These symptoms may be increased in cold temperatures.

Stop switch

Use the stop switch to switch off the engine.
In areas with a hot, dry climate there is a high risk of fires. These areas are sometimes subject to government rules requiring among other things the muffler must be equipped with an approved type of spark arrestor mesh.
CAUTION! The muffler gets very hot during and after use. This also applies during idling. Be aware of the fire hazard, especially when working near flammable substances and/ or vapours.
WARNING! Never use a saw without a muffler, or with a damaged muffler. A
!
damaged muffler may substantially increase the noise level and the fire hazard. Keep fire fighting equipment handy. If a spark arrestor screen is required in your area, never use the saw without or with a broken spark arrestor screen.

Cutting equipment

This section describes how to choose and maintain your cutting equipment in order to:
Reduce the risk of kickback.
Reduce the risk of the saw chain breaking or jumping off the bar.
Obtain optimal cutting performance.
Extend the life of cutting equipment.
Avoid increasing vibration levels.
Muffler
The muffler is designed to keep noise levels to a minimum and to direct exhaust fumes away from the user.
WARNING! The exhaust fumes from the engine are hot and may contain sparks
!
which can start a fire. Never start the machine indoors or near combustible material!

General rules

Only use cutting equipment recommended by us! See instructions under the heading Technical data.
Keep the chain’s cutting teeth properly sharpened!
Follow our instructions and use the recommended file gauge. A damaged or badly sharpened chain increases
the risk of accidents.
Maintain the correct depth gauge setting! Follow our
instructions and use the recommended depth gauge clearance. Too large a clearance increases the risk of
kickback.
10 – English
GENERAL SAFETY PRECAUTIONS
Keep the chain properly tensioned! If the chain is slack
it is more likely to jump off and lead to increased wear on the bar, chain and drive sprocket.
Keep cutting equipment well lubricated and properly
maintained!
break and lead to increased wear on the bar, chain and drive sprocket.
A poorly lubricated chain is more likely to

Cutting equipment designed to reduce kickback

WARNING! Faulty cutting equipment or the wrong combination of bar and saw chain
!
increases the risk of kickback! Only use the bar/saw chain combinations we recommend, and follow the filing instructions. See instructions under the heading Technical data.
The only way to avoid kickback is to make sure that the kickback zone of the bar never touches anything.
By using cutting equipment with ”built-in” kickback reduction and keeping the chain sharp and well-maintained you can reduce the effects of kickback.
Bar
Length (inches/cm)
Number of teeth on bar tip sprocket (T).
Chain pitch (inches). The spacing between the drive links of the chain must match the spacing of the teeth on the bar tip sprocket and drive sprocket.
Number of drive links. The number of drive links is determined by the length of the bar, the chain pitch and the number of teeth on the bar tip sprocket.
Bar groove width (inches/mm). The groove in the bar must match the width of the chain drive links.
Bar
The smaller the tip radius the lower the chance of kickback.
Chain
A chain is made up of a number of links, which are available in standard and low-kickback versions.
IMPORTANT! No saw chain design eliminates the danger of kickback.
WARNING! Any contact with a rotating saw chain can cause extremely serious injuries.
!
Some terms that describe the bar and chain
To maintain the safety features of the cutting equipment, you should replace a worn or damaged bar or chain with a bar and chain combinations recommended by Jonsered. See instructions under the heading Technical Data for a list of replacement bar and chain combinations we recommend.
Chain oil hole and hole for chain tensioner. The bar must be matched to the chain saw design.
Chain
Chain pitch (inches)
Drive link width (mm/inches)
Number of drive links.
English – 11
GENERAL SAFETY PRECAUTIONS

Sharpening your chain and adjusting depth gauge setting

General information on sharpening cutting teeth
Never use a blunt chain. When the chain is blunt you have to exert more pressure to force the bar through the wood and the chips will be very small. If the chain is very blunt it will produce wood powder and no chips or shavings.
A sharp chain eats its way through the wood and produces long, thick chips or shavings.
The cutting part of the chain is called the cutter and consists of a cutting tooth (A) and the depth gauge (B). The cutters cutting depth is determined by the difference in height between the two (depth gauge setting).
See instructions under the heading Technical data for information about sharpening your chain.
WARNING! Departure from the sharpening instructions considerably increases the risk
!
of kickback.
Sharpening cutting teeth
To sharpen cutting teeth you will need a round file and a file gauge. See instructions under the heading Technical data for information on the size of file and gauge that are recommended for the chain fitted to your chain saw.
Check that the chain is correctly tensioned. A slack chain will move sideways, making it more difficult to sharpen correctly.
When you sharpen a cutting tooth there are four important factors to remember.
1 Filing angle
2 Cutting angle
3 File position
4 Round file diameter
It is very difficult to sharpen a chain correctly without the right equipment. We recommend that you use our file gauge. This will help you obtain the maximum kickback reduction and cutting performance from your chain.
Always file cutting teeth from the inside face. Reduce the pressure on the return stroke. File all the teeth on one side first, then turn the chain saw over and file the teeth on the other side.
File all the teeth to the same length. When the length of the cutting teeth is reduced to 4 mm (0.16") the chain is worn out and should be replaced.
12 – English
Loading...
+ 28 hidden pages
