QuickSpecs

HP Z840 Workstation

Overview

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 1

HP Z840 Workstation

Slimline Optical Drive Bay

HDD Activity LED

2 External 5.25” Bays

Front I/O: 4 USB 3.0 (Top Port has Charging Capability), 1

Power Button

Headset, 1 Microphone

QuickSpecs

HP Z840 Workstation

Overview

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 2

Choice of 850W, 88% or 1125W, 90% Efficient Power Supplies

11.

2 Intel Xeon Processors E5-2600 v3 family

16 DIMM Slots for DDR4 ECC Memory

12.

 Slot 1: PCIe Gen3 x4  Slot 2: PCIe Gen3 x16  Slot 3: PCIe Gen3 x8 - Available ONLY when 2nd

processor is installed

 Slot 4: PCIe Gen3 x16 - Available ONLY when 2nd

processor is installed

 Slot 5: PCIe Gen2 x4 when 1 CPU is installed.

Transforms to PCIe Gen3 x8 when 2nd CPU is installed

 Slot 6: PCIe Gen3 x16  Slot 7: PCIe Gen2 x1

2 External 5.25” Bays

4 Internal 3.5” Bays

10.

Rear I/O: Rear Power Button 4 USB 3.0 2 USB 2.0 1 Serial PS/2 keyboard and mouse 2 RJ-45 to integrated Gigabit LAN 1 Audio Line-In (can be retasked as microphone) 1 Audio Line-Out

13.

6 SATA, 8 SAS Ports

14.

2 USB 2.0 Ports, 1 USB 3.0 Port

QuickSpecs

HP Z840 Workstation

Overview

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 3

Form Factor

Rackable Tower

Operating Systems

Preinstalled:

 Windows 7 Professional 64-bit  Windows 8.1 Pro 64-bit downgrade to Windows 7 Professional 64-bit**  Windows 8.1 Pro 64-bit OS  Windows 8.1 Emerging Market  Ubuntu 14.04  HP Installer Kit for Linux (includes drivers for 64-bit OS versions of RHEL 6 & 7, SUSE Linux

Enterprise Desktop 11 and Ubuntu 14.04)

 Red Hat Enterprise Linux (RHEL) Workstation (Paper license with 1 year support; no

preinstalled OS)

Supported:

 Windows 7 Enterprise 64-bit  Windows 8/8.1 Enterprise 64-bit

NOTES: For detailed OS/hardware support information for Linux, see:

http://www.hp.com/support/linux_hardware_matrix

Available Processors

Name

Clock

Speed

(GHz)

Cores

Cache

(MB)

Memory

Speed

(MHz)

QPI Speed (GT/s)

Hyper

Threading

Featuring

Intel® vPro™

Technology

Intel® Turbo

Boost

Technology1

TDP (W)

INTEL® XEON® E5-2699 v3 processor

2.3

2133

9.6

YES

5/13

145

INTEL® XEON® E5-2697 v3 processor

2.6

2133

9.6

YES

5/10

145

INTEL® XEON® E5-2695 v3 processor

2.3

2133

9.6

YES

5/10

120

INTEL® XEON® E5-2687W v3 processor

3.1

2133

9.6

YES

1/4

160

INTEL® XEON® E5-2690 v3 processor

2.6

2133

9.6

YES

5/9

135

INTEL® XEON® E5-2667 v3 processor

3.2 8 20

2133

9.6

YES

2/4

135

INTEL® XEON® E5-2683 v3 processor

2.0

2133

9.6

YES

5/10

120

INTEL® XEON® E5-2680 v3 processor

2.5

2133

9.6

YES

4/8

120

INTEL® XEON® E5-2670 v3 processor

2.3

2133

9.6

YES

3/8

120

INTEL® XEON® E5-2643 v3 processor

3.4 6 20

2133

9.6

YES

2/3

135

INTEL® XEON® E5-2660 v3 processor

2.6

2133

9.6

YES

3/7

105

INTEL® XEON® E5-2650 v3 processor

2.3

2133

9.6

YES

3/7

105

INTEL® XEON® E5-2637 v3

3.5 4 15

2133

9.6

YES

1/2

135

Overview

QuickSpecs

HP Z840 Workstation

Overview

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 4

processor

INTEL® XEON® E5-2640 v3 processor

2.6 8 20

1866

8.0

YES

2/8

INTEL® XEON® E5-2630 v3 processor

2.4 8 20

1866

8.0

YES

2/8

INTEL® XEON® E5-2623 v3 processor

3.0 4 10

1866

8.0

YES

3/5

105

INTEL® XEON® E5-2620 v3 processor

2.4 6 15

1866

8.0

YES

2/8

INTEL® XEON® E5-2609 v3 processor

1.9 6 15

1600

6.4

YES

N/A

INTEL® XEON® E5-2603 v3 processor

1.6 6 15

1600

6.4

YES

N/A

The specifications shown in this column represent the following: (all core maximum turbo steps, one core maximum turbo

steps). Turbo boost stepping occurs in 100MHz increments. Processors that do not have turbo functionality are denoted as N/A. E5-2687Wv3, E5-2690v3, E5-2695v3, E5-2697v3 and E5-2699v3 REQUIRE the 1125W (1450W at 200V Input Voltage) Power Supply Option.

Disclaimers

When ordering two processors, the second processor must be the same as the first. Intel processor numbers are not a measurement of higher performance. Processor numbers differentiate features within each processor family, not across different processor families. See:

http://www.intel.com/products/processor_number/ for details.

Quad-Core, Six-Core, Eight-Core , 10-Core, 12-Core, 14-Core, 16-Core and 18-Core technologies are designed to improve performance of multithreaded software products and hardware-aware multitasking operating systems and may require appropriate operating system software for full benefits; check with software provider to determine suitability; Not all customers or software applications will necessarily benefit from use of these technologies.

64-bit computing on Intel® 64 architecture requires a computer system with a processor, chipset, BIOS, operating system, device drivers, and applications enabled for Intel® 64 architecture. Processors will not operate (including 32-bit operation) without an Intel® 64 architecture-enabled BIOS. Performance will vary depending on your hardware and software configurations. See:

http://www.intel.com/info/em64t for more information.

Intel® Xeon® processors E5-2637v3, E5-2643v3, E5-2670v3,E5-2680v3, E5-2683v3, E5-2667v3, E52687Wv3, E5-2690v3, E5-2695v3, E5-2697v3 and E5-2699v3 REQUIRE the 1125W (1450W at 200V Input Voltage) Power Supply Option.

Form Factor

Tower

Color

Black /Hematite

I/O Slots (see system board section for more details)

Slot 1: PCIe Gen3 x4 Slot 2: PCIe Gen3 x16 Slot 3: Gen3 x8 - Available ONLY when 2nd processor is installed Slot 4: Gen3 x16 - Available ONLY when 2nd processor is installed Slot 5: PCIe Gen2 x4 when 1 CPU is installed. Transforms to PCIe Gen3 x8 when 2nd CPU is installed Slot 6: PCIe Gen3 x16 Slot 7: PCle Gen 2x1

The PCIe x8 connectors are open ended, allowing a PCIe x16 card to be seated in the slot.

Bays (see storage section

Total Bays = 7

QuickSpecs

HP Z840 Workstation

Overview

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 5

for more details)

4 Internal 3.5" storage bays 2 External 5.25" bays 1 External Slim-line Optical bay

Internal Bays

4 internal 3.5" bays (All 4 include acoustic dampening rail assemblies)

External Bays

2 external 5.25" bays

 Top bay device depth limit: 206mm  Bottom bay device depth limit: 206mm

Front I/O

 4 USB 3.0  1 Combo Headset  1 Microphone

Rear I/O

 4 USB 3.0  2 USB 2.0  1 Serial  PS/2 keyboard and mouse  2 RJ-45 to integrated Gigabit LAN  1 Audio Line-In (can be retasked as microphone)  1 Audio Line-Out

Internal USB

 2 USB 2.0 ports available with a single 2x5 header.  1 USB 3.0 port available with a shrouded 20-pin connector.

The 2x5 header can be converted to a standard (Type-A) USB connector through the use one HP Internal USB Port Kit (EM165AA). This port kit uses one half of the 2x5 header.

Chassis Dimensions (H x W x D)

Footprint Dimensions:

H: 17.5" [444.5mm] W: 8.0" [203.2mm] D: 20.7" [525.8mm] (measured to the rear of service panel)

Maximum Dimensions:

H: 17.5" [444.5mm] W: 8.0" [203.2mm] D: 20.9" [530.9mm] (measured to the embossment for the rear chassis fans)

Rack Dimensions: 5U

System Weight

Exact weights depend upon configuration.

 Minimum config: 21.1kg (46.7lbs.)  Typical config: 22.8kg (50.4lbs.)  Maximum config: 29.2kg (64.3lbs.)

Temperature

Operating: 5° to 35°C (40° to 95°F) Non-operating: -40° to 70°C (-40° to 158°F)

Humidity

Operating: 8% to 85% Non-operating: 8% to 90%

Operating: 3,000 m; 10,000 feet

QuickSpecs

HP Z840 Workstation

Overview

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 6

Non-operating: 9,100 m; 30,000 feet

Maximum Altitude (nonpressurized)

Operating: 3,048m (10,000feet) Non-operating: 9,100m (30,000feet)

Power Supply

Choice of:

• 850W 88% Efficient wide-ranging, active Power Factor Correction

• 1125W 90% Efficient wide-ranging, active Power Factor Correction

NOTE: The 1125W (1450W at 200V Input Voltage) power supply can also supply 1275W of output power when the input voltage is greater than 105V. If the input voltage is less than 105V, but greater than 90V for any reason, the maximum power that can be drawn is 1125W. An uninterruptible power supply (UPS) is highly recommended if 1275W output power is desired. The 1125W Power Supply can also supply 1450W of output power when the input voltage is greater than 200V under all conditions.

The Z820 power supply efficiency reports can be found at these links: 850W - http://www.plugloadsolutions.com/psu_reports/HEWLETT%20PACKARD_719798-

001_850W_ECOS%203882_Report.pdf

1125W - http://www.plugloadsolutions.com/psu_reports/HEWLETT%20PACKARD_719799-

001_1125W_ECOS%203883_Report.pdf

Interfaces Supported

 6 channel SATA 6.0 Gb/s interface  8-channel 6 Gb SAS interface

o 8 SAS connectors on the motherboard, SAS ports can be ported externally by using

the SAS Bulkhead and/or Back Panel connector Kits

 Factory integrated RAID available for SATA/SAS drives (RAID 0, 0 Data, 1, 5, and 10)  USB 3.0, USB 2.0

Hard Drive Controller Supported

SATA and SAS controllers

Workstation ISV Certifications

See the latest list of certifications at

http://www.hp.com/united-states/campaigns/workstations/partnerships.html

QuickSpecs

HP Z840 Workstation

Supported Components

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 7

Processors*

Factory

Configured

Option

Kit

Option Kit

Part

Number

Support

Notes

Z840 Intel Xeon E5-2600 v3 Series CPU

Xeon E5-2603 v3 1.6 1600 6C CPU

J9V77AA

Xeon E5-2609 v3 1.9 1600 6C CPU

J9V76AA

Xeon E5-2620 v3 2.4 1866 6C CPU

J9V75AA

Xeon E5-2623 v3 3.0 1866 4C CPU

J9Q18AA

Xeon E5-2630 v3 2.4 1866 8C CPU

J9Q17AA

Xeon E5-2637 v3 3.5 2133 4C CPU

J9Q15AA

Xeon E5-2640 v3 2.6 1866 8C CPU

J9Q16AA

Xeon E5-2643 v3 3.4 2133 6C CPU

J9Q12AA

Xeon E5-2650 v3 2.3 2133 10C CPU

J9Q14AA

Xeon E5-2660 v3 2.6 2133 10C CPU

J9Q13AA

Xeon E5-2667 v3 3.2 2133 8C CPU

J9Q08AA

Xeon E5-2670 v3 2.3 2133 12C CPU

J9Q11AA

Xeon E5-2680 v3 2.5 2133 12C CPU

J9Q10AA

Xeon E5-2683 v3 2.0 2133 14C CPU

J9Q09AA

Xeon E5-2687Wv3 3.1 2133 10C CPU

J9Q06AA

Xeon E5-2690 v3 2.6 2133 12C CPU

J9Q07AA

Xeon E5-2695 v3 2.3 2133 14C CPU

J9Q05AA

Xeon E5-2697 v3 2.6 2133 14C CPU

J9Q04AA

Xeon E5-2699 v3 2.3 2133 18C CPU

J9Q03AA

Intel® Xeon® processors E5-2637v3, E5-2643v3, E5-2670v3,E5-2680v3, E5-2683v3, E5-2667v3, E52687Wv3, E5-2690v3, E5-2695v3, E5-2697v3 and E5-2699v3 REQUIRE the 1125W Power Supply Option.

Factory

Configured

Option

Kit

Option Kit Part Number

Support

Notes

HP Z Display Z22i 21.5-inch IPS LED Backlit Monitor

D7Q14A8

HP Z Display Z23i 23-inch IPS LED Backlit Monitor

D7Q13A8

HP Z Display Z24i 24-inch IPS LED Backlit Monitor

D7P53A8

HP Z Display Z27i 27-inch IPS LED Backlit Monitor

D7P92A8

HP Z Display Z30i 30-inch IPS LED Backlit Monitor

D7P94A8

HP DreamColor LP2480zx Professional Display

GV546A8

HP DreamColor Z24x Professional Display

E9Q82A8

HP DreamColor Z27x Professional Display

D7R00A8

Monitors / Displays

QuickSpecs

HP Z840 Workstation

Supported Components

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 8

Storage / Hard Drives

Sub-Section Description/Notes

NOTES: NCQ (Native Command Queuing) not supported in Red Hat Enterprise Linux

For hard drives, 1 GB = 1 billion bytes; TB = 1 trillion bytes. Actual formatted capacity is less. Up to 12 GB of hard drive (or system disk) is reserved for the system recovery software (XP and XP Pro). Up to 3 GB of system disk is reserved for system recovery software (Vista).

SAS Hard Drives

SAS Hard Drives for HP Workstations

Factory

Configured

Option

Kit

Option

Kit Part

Number

Support

Notes

600GB* SAS 15K rpm 6Gb/s 3.5" HDD

Y Y VM647AA

300GB* SAS 15K rpm 6Gb/s 3.5" HDD

Y Y LU967AA

HP 300GB SAS 10K SFF HDD

Y Y A2Z20AA

HP 600GB SAS 10K SFF HDD

Y Y A2Z21AA

HP 1.2TB* SAS 10K SFF HDD

Y Y E2P04AA

HP 600GB* SAS 10K SFF HDD

Y Y A2Z21AA

HP 300GB* SAS 10K SFF HDD

Y Y A2Z20AA

Up to 5 3.5" SATA drives supported Up to 5 3.5" SAS drives supported

Up to 8 2.5" (SFF) SAS drives with the High Density Storage Option or Up to 8 2.5" (SFF) SATA 2.5" drives with the High Density Storage Option 8 port SAS Controller included on the system board

SATA Hard Drives

SATA Hard Drives for HP Workstations

Factory

Configured

Option Kit

Option

Kit Part

Number

Support

Notes

4TB SATA 7200 rpm 6Gb/s 3.5" HDD

Y Y K4T76AA

3.0TB* SATA 7200 rpm 6Gb/s 3.5" HDD

Y Y QF298AA

2.0TB* SATA 7200 rpm 6Gb/s 3.5" HDD

Y Y QB576AA

1TB* SATA 7200 rpm 6Gb/s 3.5" HDD

Y Y LQ037AA

500GB* SATA 7200 rpm 6Gb/s 3.5" HDD

Y Y LQ036AA

500GB* SATA 7.2K SED SFF HDD

(not available today as

After Market Option)

Up to 5 3.5" SATA drives supported Up to 5 3.5" SAS drives supported

Up to 8 2.5" (SFF) SAS drives with the High Density Storage Option or Up to 8 2.5" (SFF) SATA 2.5" drives with the High Density Storage Option

SATA Solid State Drives

SATA SSDs for HP Workstations

Factory

Configured

Option Kit

Option Kit Part

Number

Support

Notes

HP 128GB* SATA 6Gb/s SSD

Y Y A3D25AA

HP 256GB* SATA 6Gb/s SSD

Y Y A3D26AA

HP 512GB* SATA 6Gb/s SSD

Y Y D8F30AA

HP 1TB* SATA 6Gb/s SSD

Y Y F3C96AA

Samsung Enterprise 240GB* SATA SSD

Y Y F0W94AA

Samsung Enterprise 480GB* SATA SSD

Y Y F0W95AA

Intel Pro 1500 180GB* SATA SSD

Y Y F5Z70AA

QuickSpecs

HP Z840 Workstation

Supported Components

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 9

HP 256GB* SATA 6Gb/s SED Opal 1 SSD

Y Y G7U67AA

Note 1

Up to 8 SATA SSD drives supported with the High Density Storage Option

NOTE 1:

The 256GB Self-Encrypting Drive (SED) version has similar performance to the standard 256GB SSD. It is also available in Opal 1.0 and Opal 2.0 versions

PCIe Solid State Drives

PCIe SSDs for HP Workstations

Factory

Configured

Option

Kit

Option

Kit Part

Number

Support

Notes

HP Z Turbo Drive 512GB* SSD

Y Y G3G89AA

HP Z Turbo Drive 256GB* SSD

Y Y G3G88AA

*For storage drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 30GB of system disk is reserved for system recovery software.

HP 4-Bay SAS-SATA

2.5in High Density Storage Kit

Factory

Configured

Option

Kit

Option

Kit Part

Number

Support

Notes

HP 4-Bay SAS-SATA 2.5in High Density Storage Kit

Y K5J28AA

This kit converts two of the native 3.5" HDD bays to enable four SFF (2.5") HDDs or SSDs. Once the kit is installed, it enables independent, tool-free access for these SFF drives. Enterprise class SAS HDDs (15mm) are also supported. Up to two modules are supported in the Z840, which enables up to 8 SFF drives to be added to the internal section of the Z840. HDDs and SSDs are supported with up to 6Gb/s bandwidth.

Notes:

For a video installation guide, please see www.hp.com/go/sml The installation guide can also be accessed in the Maintenance and Service Guide for your workstation at www.hp.com/support/workstation_manuals

HDD Carrier

HP 4-in-1 SFF (2.5 in) HDD Carrier

Factory

Configured

Option

Kit

Option

Kit Part

Number

Support

Notes

HP 4-in-1 SFF (2.5 in) HDD Carrier*

Y B8K60AA

* For the Z440, Z640, and Z840, the carrier can be installed in any of the 5.25" ODD bays.

Notes: Additional controllers may be required to support the additional drives located in this carrier. This kit includes an additional 4 carriers which can be mounted to drives for easy external access and transfer of data between systems.

Hard Drive Controllers

Factory integrated RAID on motherboard for SATA drives

Factory

Configured

Option

Kit

Option

Kit Part

Number

Support

Notes

RAID 0 Configuration – Striped Array

Note 1

RAID 0 Data Configuration -- Boot/OS Drive + 2 Drive Striped Array

Note 2

RAID 1 Configuration – Mirrored Array

Note 3

RAID 10 Configuration - Striped/Mirrored Array

QuickSpecs

HP Z840 Workstation

Supported Components

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 10

RAID 5 Configuration - Parity Array

Note 4

HP SAS Back Panel Connector kit

Must have 4 or fewer SAS hard drives to configure this option

HP SAS Back Panel Bulkhead Connector Kit

HP SAS Back Panel Connector kit required. Internal SAS HD drives are not supported

LSI iBBU09 Battery Backup Unit

Y Y E0X19AA

LSI 9270-8i SAS 6Gb/s ROC RAID Card

Y Y E0X21AA

Integrated LSI SAS 2308 Controller with RAID 0/1/1E/10

Integrated SATA 6.0 Gb/s Controller

NOTE 1: Minimum of 2 hard drives needed. All hard drives must be identical (size/speed/type/bus/functional capabilities). Must have 2, 3 or 4 HD Drives. NOTE 2: Minimum of 3 SATA hard drives needed. All hard drives must be identical (size/speed/type/bus/functional capabilities). At least 3 HD Drives required. May have 4th and 5th HD Drives. Drives must be the same drive (size/speed/type/functional capability). NOTE 3: 2 SATA or 2 SAS hard drives required. All hard drives must be identical (size/speed/type/bus/functional capabilities). NOTE 4: Minimum of 3 SATA hard drives needed. All SATA hard drives must be identical (size/speed/type/bus/functional capabilities). Must have 3 or 4 HD Drives. 5 HD Drives not allowed.

NOTE: SATA hardware RAID is supported on Linux systems that have support for the Intel RSTe technology. The Linux kernel, with built-in software RAID, provides excellent functionality and performance. It is a good alternative to hardware-based RAID. Please visit

http://www.hp.com/support/linux_hardware_matrix for RAID capabilities with Linux.

LSI RAID Definitions: IS: Striping of 2 or more HDDs into a single logical volume IM: Mirroring of 2 HDDs into a single logical volume IME: Mirroring of 3 or more HDDs into a single logical volume

NOTE: Specific user-configured hardware SAS RAID configurations are supported on this Linux system. Please visit: http://www.hp.com/support/linux_hardware_matrix for details

Graphics

Factory

Configured

Option

Kit

Option

Kit Part

Number

Support Notes

Supported

# of cards

Mixed?

Professional 2D

NVIDIA NVS 310 512MB Graphics

A7U59AA

Note 1

NVIDIA NVS 315 1GB Graphics (for HP Workstations)

E1U66AA

Note 1

NVIDIA NVS 510 2GB Graphics

C2J98AA

Note 2

Entry 3D

NVIDIA Quadro K420 1GB Graphics

J3G86AA

NVIDIA Quadro K620 2GB Graphics

J3G87AA

AMD FirePro W2100 2GB Graphics

J3G91AA

QuickSpecs

HP Z840 Workstation

Supported Components

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 11

Mid-range 3D

AMD FirePro W5100 4GB Graphics

J3G92AA

NVIDIA Quadro K2200 4GB Graphics

J3G88AA

High End 3D

NVIDIA Quadro K4200 4GB Graphics

J3G89AA

NVIDIA Quadro K5200 8GB Graphics

J3G90AA

NVIDIA Quadro K6000 12GB Graphics

C2J96AA

AMD FirePro W7100 8GB Graphics

J3G93AA

NVIDIA Quadro M6000 12GB Graphics

L2K02AA

For configurations not listed in this specification, please contact the factory for review

NOTE 1: 3rd and 4th graphics possible by using Option Kits. NOTE 2: NVIDIA NVS 510 graphics available by using Option Kits only.

High Performance GPU Computing

Factory

Configured

Option

Kit

Option Kit Part Number

Support Notes

NVIDIA Tesla K40 Workstation Coprocessor

F4A88AA

Note 1

NOTE 1:

Up to two K40 processors are supported. Only supported with the Z840 1125W (1450W at 200V Input Voltage) Chassis. Must have add-in graphics card in addition to the K40. Supported Graphics cards are QK5200, QK6000, QK620, QK2200, QK4200, M6000.

Memory

DDR4-2133 ECC Registered DIMMs

Option Kit Part

Number

Support Notes

CTO

4GB DDR4-2133 ECC Registered RAM

J9P81AA

8GB DDR4-2133 ECC Registered RAM

J9P82AA

16GB DDR4-2133 ECC Registered RAM

J9P83AA

32GB DDR4-2133 ECC Load Reduced (LR) RAM

J9P84AA

NOTES:

For details on the supported memory configurations on the HP Z840 Workstation, please refer to the System Technical Specifications - System Board section of this document.

DIMMs should be equally distributed across all four memory channels for optimal performance.

Each processor supports up to 4 channels of DDR4 memory. To realize full performance at least 1 DIMM must be inserted into each channel.

The CPUs determine the speed at which the memory is clocked. For example, if a 1600MT/s capable CPU is used in the system, the maximum speed the memory will run at is 1600MT/s regardless of the specified speed of the memory.

MT/s = Million Transfers per second

You cannot intermix LR DIMMs with Registered DIMMs. The system will not work.

The Z840 is designed to work ONLY with DDR4 memory. The system will not work with DDR3 memory.

QuickSpecs

HP Z840 Workstation

Supported Components

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 12

Factory

Configured

Option Kit

Option Kit Part

Number

Support

Notes

HP Thin USB Powered Speakers

KK912AA

Integrated IDT 92HD94 Audio

Y N NA

Factory

Configured

Option Kit

Option Kit Part

Number

Support

Notes

HP DX115 Removable Drive Enclosure

HP DX115 Removable HDD Frame/Carrier

FZ576AA

Note 1

HP DX115 Removable HDD Carrier

NB792AA

Note 2

HP 15-in-1 Media Card Reader

F4N90AA

HP SlimTray Optical Drives

HP 9.5mm Slim SuperMulti DVD Writer

K3R64AA

HP 9.5mm Slim DVD-ROM Drive

K3R63AA

Note 3

HP 9.5mm Slim BDXL Blu-Ray Writer

K3R65AA

Note 4

Actual speeds may vary. Does not permit copying of commercially available DVD movies or other copyright protected materials. Intended for creation and storage of your original material and other lawful uses. Double Layer discs can store more data than single-layer DVD drives and players.

In order for some Blu-ray titles to play, they may require a DVI or HDMI digital connection and your display may require HDCP support. HD-DVD movies cannot be played on this workstation.

NOTE1: Z840 support is for two DX115, in both of the 5.25” ODD bays. NOTE 2: Carrier requires the workstation to have the DX115 frame installed. This part number is for the

carrier only.

NOTE 3: Not supported as a 2nd Optical Drive NOTE 4: Cannot be ordered in combination with another Blu-ray Writer drive.

Factory

Configured

Option Kit

Option Kit Part

Number

Support

Notes

HP IEEE 1394b FireWire® PCIe Card

NK653AA

HP Thunderbolt™-2 PCIe 1-port I/O Card*

F3F43AA

Factory

Configured

Option Kit

Option Kit Part

Number

Support

Notes

HP X520 10GbE Dual Port Adapter

C3N52AA

Multimedia and Audio Devices

Optical and Removable Storage

Controller Cards

Networking and Communications

QuickSpecs

HP Z840 Workstation

Supported Components

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 13

HP 10GbE SFP+ SR Transceiver

C3N53AA

Intel Ethernet I210-T1 PCIe NIC

E0X95AA

Intel 7260 802.11 a/b/g/n PCIe WLAN NIC

Integrated Intel I210AT PCIe GbE Controller

N Note 1

Integrated Intel I218LM PCIe GbE Controller

N Note 1

HP 361T PCIe Dual Port Gigabit NIC

C3N37AA

Note 1

NOTE 1: "Gigabit" or "GbE" Ethernet indicates compliance with IEEE standard 802.3ab for Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/sec. For high speed transmission, connection to a Gigabit Ethernet server and network infrastructure is required.

*Wireless access point and internet service required. Availability of public wireless access points limited.

Factory

Configured

Option Kit

Option Kit Part

Number

Support

Notes

Security Cable with Kensington Lock

PC766A

HP Chassis Intrusion Sensor

Y N

Standard on all systems

HP Z6/8 Adjustable Rail Rack Kit, Flush Mount

B8S55AA

Input Devices

Factory

Configured

Option Kit

Option Kit Part

Number

Support

Notes

HP USB Smart Card Keyboard

ED707AA

HP 2.4GHz Wireless Keyboard & Mouse

NB896AA

HP USB Optical 3-Button 2.9M OEM Mouse

ET424AA

HP SpaceExplorer 3D USB Controller

RY429AA

HP SpacePilot 3D USB Intelligent Controller

WH343AA

HP PS/2 Keyboard

QY774AA

HP PS/2 Mouse

QY775AA

HP USB Keyboard

QY776AA

HP USB Optical Mouse

QY777AA

HP USB 1000dpi Laser Mouse

QY778AA

Other Hardware

Factory

Configured

Option Kit

Option Kit Part

Number

Support

Notes

HP Internal USB Port Kit

EM165AA

Note 1

HP SAS Back Panel Connector Kit

EM164AA

HP eSATA PCI Cable Kit

GM110AA

Note 2

HP Power Cord Kit

Y N

HP Workstation Mouse Pad

Y N

Japan Only

HP Optical Bay HDD Mounting Bracket

NQ099AA

HP ENERGY STAR® Qualified Configuration

Y N

HP 4-Bay SAS-SATA 2.5in High Density

K5J28AA

Note 3

Racking and Physical Security

QuickSpecs

HP Z840 Workstation

Supported Components

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 14

Storage Kit

NOTE 1: The HP Internal USB Port kit has a single USB 2.0 type A connector. NOTE 2: No hot plug / hot swap supported with eSATA

NOTE 3: The CTO option (J8J30AV) installs two of these kits to create room for 8 2.5" bays.

Software

Factory

Configured

Option Kit

Option Kit Part

Number

Support

Notes

HP Performance Advisor

Y Note 1

HP Remote Graphics Software (RGS) 6.0

Y Note 2

MS Office Home & Business 2013

N Note 3

Cyberlink PowerDVD and Power2Go

Foxit PhantomPDF Express

NOTE 1: Available as a free download here: www.hp.com/go/performanceadvisor NOTE 2: Supports Windows 7, Windows 8.1, SLED 11, and RHEL v6.5 NOTE 3: Must be selected as a Configure to Order option. Delivered in the form of a "Drop in the Box"

CD.

Operating Systems

Support Notes

Genuine Windows® 7 Professional 64-bit

See note 1

HP Linux Installer Kit

Red Hat Enterprise Linux (RHEL) Workstation Paper License (1yr)

See note 2

Windows 8.1 Pro Downgrade to Windows 7 Professional 64-bit

Windows 8.1 Pro 64-bit

Windows 8.1 Pro Downgrade to Windows 7 Professional 64-bit (National Academic)

Windows 8.1 Simplified Chinese Edition 64-bit

Ubuntu 14.04

Windows 8.1 Emerging Markets Single-Language 64-bit OS

NOTE 1: See http://www.microsoft.com/windows/windows-7/ for support details NOTE 2: This second OS must be ordered with the HP Linux Installer Kit as the first OS.

QuickSpecs

HP Z840 Workstation

System Technical Specifications

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 15

System Board

System Board Form Factor

Custom Form Factor, 13" x 14.25" (330.20mm x 361.95mm)

Processor Socket

Dual LGA2011-3

CPU Bus Speed

QPI: Up to 9.6GT/sec, dual link implementation

Chipset

Intel® C612 Chipset

Super I/O Controller

Nuvoton NPCD379H

Memory Expansion Slots

16 slots (8 slots per CPU)

Memory Type Supported

DDR4 R-DIMM (Registered), ECC: 4GB, 8GB, and 16GB DDR4 LR-DIMM (Load Reduced), ECC: 32GB (64GB and 128GB added after initial release)

Memory Modes

NUMA (Non-Uniform Memory Architecture), Memory Node Interleave

Memory Speed Supported

1600MT/s, 1866MT/s, and 2133MT/s

Single Processor

CPU 0

Bottom Slots

Top Slots

Capacity

Notes

DIMM1

DIMM2

DIMM3

DIMM4

DIMM5

DIMM6

DIMM7

DIMM8

Rating

4 GB

4 GB Fair

8 GB

4 GB 8 GB

4 GB

Good

Fair

12 GB

4 GB 4 GB

4 GB

Better

16 GB

4 GB 8 GB

4 GB

4 GB 8 GB

Best

Good

32 GB

4 GB 8 GB

16 GB

4GB

4 GB 8 GB

4 GB

4 GB 8 GB

4 GB

4 GB 8 GB

16 GB

Best Best

Good

48 GB

8 GB

4 GB

8 GB

4 GB

8 GB

4 GB

8 GB

Best

64 GB

8 GB

16 GB

8 GB 8 GB

16 GB

8 GB 8 GB 8 GB

16 GB

8 GB 8 GB

16 GB

Best Best

96 GB

16 GB

8 GB

16 GB

8 GB

16 GB

8 GB

16 GB

Best

128 GB

16 GB 32 GB

16 GB

16 GB 32 GB

16 GB

16 GB 32 GB

16 GB

16 GB 32 GB

Best Best

256 GB

~ 32 GB

64 GB

32 GB

32 GB 64 GB

32 GB

32 GB 64 GB

32 GB

32 GB 64 GB

Best Best

512 GB

~ ~ 64 GB

128 GB

64 GB

128 GB

64 GB

128 GB

64 GB

128 GB

Best Best

1 TB

128 GB

Best

Slot Load Order

1 5 3 7 8 4 6 2

QuickSpecs

HP Z840 Workstation

System Technical Specifications

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 16

Dual Processor

CPU 0

CPU 1

Bottom Slots

Top Slots

Bottom Slots

Top Slots

Capacity

Notes

DIMM1

DIMM2

DIMM3

DIMM4

DIMM5

DIMM6

DIMM7

DIMM8

DIMM1

DIMM2

DIMM3

DIMM4

DIMM5

DIMM6

DIMM7

DIMM8

Rating

8 GB

4 GB 4 GB Fair

16 GB

4 GB 8 GB

4 GB 4 GB

8 GB

4 GB Good

Fair

32 GB

4 GB 8 GB

16 GB

4 GB

4 GB 8 GB

16 GB

4 GB

4 GB 8 GB

Best

Good

Fair

64 GB

4 GB 8 GB

4 GB 4 GB 8 GB

4 GB 4 GB 4 GB 8 GB

4 GB 4 GB 8 GB

4 GB 8 GB

4 GB 4 GB 8 GB

4 GB 4 GB 4 GB 8 GB

4 GB 4 GB 8 GB

Best Best

96 GB

8 GB

4 GB

8 GB

4 GB

8 GB

4 GB

8 GB

4 GB

8 GB

4 GB

8 GB

4 GB

8 GB

Best

128 GB

8 GB 16 GB 32 GB

8 GB

16 GB

8 GB

16 GB

8 GB

8 GB 16 GB 32 GB

8 GB

16 GB

8 GB

16 GB

8 GB

8 GB 16 GB 32 GB

Best

Best Good

192 GB

~ 16 GB

16 GB

8 GB 16 GB

16 GB 16 GB

8 GB 8 GB 16 GB 16 GB

8 GB 16 GB

16 GB 16 GB

8 GB 16 GB

16 GB 16 GB

8 GB 8 GB 16 GB 16 GB

8 GB 16 GB

16 GB 16 GB

Best

Better

256 GB

16 GB 32 GB

16 GB

16 GB 32 GB

16 GB

16 GB 16 GB

32 GB

16 GB

16 GB 32 GB

16 GB

16 GB 32 GB

16 GB

16 GB 16 GB

32 GB

16 GB

16 GB 32 GB

Best

512 GB

~ 32 GB

64 GB

32 GB

32 GB 64 GB

32 GB

32 GB 32 GB

64 GB

32 GB

32 GB 64 GB

32 GB

32 GB 64 GB

32 GB

32 GB 32 GB

64 GB

32 GB

32 GB 64 GB

Best

1 TB

~ ~

64 GB

128

64 GB

128

64 GB

128

64 GB

128

64 GB

128

64 GB

128

64 GB

128

64 GB

128

Best

2 TB

128

Best

Slot Load

Order

1 9 5

15 7 11 3 2

10 6 14

16 8 12 4

QuickSpecs

HP Z840 Workstation

System Technical Specifications

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 17

Memory Loading Order:

Load Order for Single Processor Configuration

Load Order for Dual Processor Configuration

Maximum Memory

Supports up to 256GB using RDIMMs Supports up to 1024GB using LRDIMMs Supports up to 2048GB using LRDIMMs

Memory Configuration (Supported)

 Not all memory configurations possible are represented. Not all memory

configurations shown are available as CTO. Please check Ordering Guide for supported configurations.

 Only ECC DIMMs are supported.  RDIMM (Registered) and LR DIMM (Load Reduction) memory cannot be mixed. All

memory installed in the system must be either RDIMM or LR DIMM.

 Do not install memory modules into memory slots if corresponding processor is not

installed.

 Dual processor configurations with memory modules installed for only one

processor is not supported.

Notes

Please refer to the table above for details on how supported memory configurations are installed in your system.

* For 32 bit operating systems, there is a memory limit of 4GB.

~ Although technically possible, these configurations are not available to order at this time.

The Z840 will support up to 512GB at initial release.

The Z840 will support up to 1024GB when 64GB DIMM support is added following initial Z840 release.

The Z840 will support up to 2048GB when 128GB DIMM support is added following initial Z840 release.

PCI Express Connectors

Two PCIe Gen3 x16 with latch One PCIe Gen3 x16 with latch.

 Enabled only with optional 2nd CPU is installed.

QuickSpecs

HP Z840 Workstation

System Technical Specifications

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 18

One PCIe Gen3 x8 open-ended connector.

 Enabled only with optional 2nd CPU is installed.

One PCIe x8 open-ended connector.

 Enabled for One PCIe Gen2 x4 slot with 1 CPU  Enabled for One PCIe Gen3 x8 with optional 2nd CPU installed

One PCIe Gen3 x4 open-ended connector. One PCIe Gen2 x1 open-ended connector

Supported Drive Interfaces

SATA

2 SATA @6Gb/s, supports RAID 0,1 and NCQ. 4 sSATA @6Gb/s, Supports RAID 0,1,5,10 and NCQ. Factory integrated RAID is Microsoft Windows only.

External SATA (eSATA)* Supported on all SATA and sSATA ports configurable with optional eSATA* After-Market Option cable kit) * hot plug / hot swap not supported with eSATA

Serial Attached SCSI

Integrated 8-channel SAS 6.0Gb/sec controller with HW RAID 0, 1, 10

Integrated RAID

SATA: RAID 0, 1 (Supports one RAID) SATA: RAID 0, 1, 5, 10 (Supports up to 2 RAIDs) SAS: HW RAID 0, 1, 10 (Supports up to 2 RAIDs)

Integrated Graphics

None

Network Controller

Integrated Intel I218LM

Memory Integrated 3KB receive buffer and 3KB transmit buffer Data rates supported: 10/100/1000 Mb/s Compliance IEEE 802.1as, 802.1p, 802.1Q, 802.3, 802.3ab,

802.3az, 802.3i 802.3u, 802.3x, 802.3z Bus architecture PCIe 1.0 x1 and SMBus Power requirement 0.5 watts Boot ROM support Network transfer rates: 10BASE-T (half-duplex) 10 Mb/s 10BASE-T (full-duplex) 20 Mb/s 100BASE-TX (half-duplex) 100 Mb/s 100BASE-TX (full-duplex) 200 Mb/s 1000BASE-T (full-duplex) 2000 Mb/s Management capabilities: WOL, auto MDI crossover, PXE, Multiport teaming, RSS, Advanced cable diagnostics

AMT 9.1 support, vPro compliant

Integrated I210AT

Adjustable FIFO packet buffer memory up to 24KB Tx, 16KB Rx Data rates supported 10/100/1000 Mb/s Compliance IEEE 802.1as, 802.1q, 802.1Q, 802.3, 802.3ab,

802.3ap, 802.3az, 802.3u, 802.3x, 802.3z

QuickSpecs

HP Z840 Workstation

System Technical Specifications

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 19

Bus architecture PCIe 1.0 x1 and SMBus Boot ROM support Network transfer rates: 10BASE-T (half-duplex) 10 Mb/s 10BASE-T (full-duplex) 20 Mb/s 100BASE-TX (half-duplex) 100 Mb/s 100BASE-TX (full-duplex) 200 Mb/s 1000BASE-T (full-duplex) 2000 Mb/s Management capabilities: WOL, auto MDI crossover, PXE, Multiport teaming, RSS, Advanced cable diagnostics PCI-X Connectors

None

PCI Card Guide

Yes

Wake on LAN

Yes, both ports

Integrated Trusted Platform Module

Infineon TPM 1.2 Certified (TPM2.0 Certified, Hardware Enabled; Not Available at Initial Release)

IEEE 1394 Connector(s)

Front

None

Rear

None

Internal

None

USB Connector(s)

Front

4 USB 3.0

Rear

4 USB 3.0 2 USB 2.0

Internal

1 USB 3.0 available with a single 20-pin shrouded connector.This header supports a USB Media Card reader.

2 USB 2.0 port available with one 2x5 header. This header supports an HP Internal USB Port Kit (EM165AA) to provide a single USB Type-A connector. This port kit uses one half of the 2x5 header. Third party adapters are also available.

HD Integrated Audio

Realtek ALC221

Flash ROM

Yes

CPU Fan Header

One header (blind mate) for CPU fans and memory fans

Chassis Fan Header

One Chassis Fan Header Front PCI Fan Header

2 Front PCI Fan Headers

Front Control Panel/Speaker Header

Yes CMOS Battery Holder - Lithium

Yes

Power Supply Headers

Yes

Power Switch, Power LED & Hard Drive LED Header

Front power switch, front power and hard drive LED. Rear power switch and rear power LED. Drive LED header on system board.

Clear Password Jumper

Yes

Serial Port

Yes, on rear panel

Parallel Port

Keyboard/Mouse

Yes

Power Supply

850W 88% Efficient, Custom PSU

1125W/1275W*/1450W*

QuickSpecs

HP Z840 Workstation

System Technical Specifications

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 20

(Wide-Ranging, Active PFC)

90% Efficient, Custom PSU

(Wide-Ranging, Active PFC)

Operating Voltage Range

90-269 VAC

Rated Voltage Range

100-127 VAC 200-240 VAC

118 VAC

Rated Voltage Range

100 VAC 115-127 VAC 200-240 VAC

Rated Line Frequency

50-60 Hz

400 Hz

Rated Line Frequency

50-60 Hz

Operating Line Frequency Range

47-66 Hz

393-407 Hz

Operating Line Frequency Range

47-66 Hz

Rated Input Current

11A @ 100-127 VAC

5.5A @ 200-240 VAC

11A @ 118 VAC

Rated Input Current

11A @ 100–127 VAC

5.5A @ 200–240 VAC

Heat Dissipation (Configuration and software dependent)

Typical = 2142 btu/hr (540kg-cal/hr)

Max = 3335 btu/hr (840 kg-cal/hr)

Typical = 2773 btu/hr (699 kg-cal/hr)

Max-1 = 3878 btu/hr (977 kg-cal/hr) Max-2 = 5002 btu/hr (1260 kg-cal/hr) Max-3 = 5624 btu/hr (1417 kg-cal/hr)

Power Supply Fan

(2) 80x25 mm variable speed

ENERGY STAR Qualified (Configuration dependent)

Yes

Power Supply Efficiency

88% Efficient

The Z840 850W power supply efficiency

report can be found at this link:

http://www.plugloadsolutions.com/psu_repor

ts/HEWLETT%20PACKARD_719798-

001_850W_ECOS%203882_Report.pdf

90% Efficient

The Z840 1125W (1450W at 200V Input

Voltage) power supply efficiency report can

be found at this link:

http://www.plugloadsolutions.com/psu_rep

orts/HEWLETT%20PACKARD_719799-

001_1125W_ECOS%203883_Report.pdf

FEMP Standby Power Compliant @115V (<2W in S5 - Power Off)

Yes

EuP Compliant @ 230V (<0.5 W in S5 - Power Off)

Yes

CECP Compliant @ 220V (<4W in S3 - Suspend to RAM)

Yes; Configuration dependent

Power Consumption in sleep mode (as defined by ENERGY STAR) Suspend to RAM (S3) (Instantly Available PC)

<23W

<30W

Built-in Self-Test LED

Yes

Surge Tolerant Full Ranging Power Supply (withstands power surges up to 2000V)

Yes

*Input voltage restriction

The 1125W Power Supply can also supply 1450W of output power when the input voltage is

QuickSpecs

HP Z840 Workstation

System Technical Specifications

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 21

greater than 180V under all conditions.

AUX IN (audio)

Clear CMOS Button

Yes

Multibay Header

Integrated Gigabit Ethernet

Yes, dual port.

Access Panel Solenoid Lock Header

Access Panel Intrusion Sensor Header

Yes, as part of Front UI (Control Panel) cable header Memory Fan Connector

Yes, blind-mate

Example Configuration #1

Processor Info

1x Intel Xeon E5-2609v3 (Six-Core) 85W

Memory Info

16GB DDR4-2133 (2x8GB) 1CPU RegRAM

Graphics Info

1x NVIDIA Quadro K620

Disks/Optical/Floppy

1x 500GB SATA 7200/1x DVD-ROM SATA

Power Supply

850W 88% Custom PSU

Other

Energy Consumption

115 VAC

230 VAC

100 VAC

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

Windows Idle (S0)

103.41 W

102.23 W

103.92 W

Windows Busy Typ (S0)

183.75 W

181.88 W

189.37 W

Windows Busy Max (S0)

204.93 W

201.28 W

206.74 W

Sleep (S3)

3.711 W

3.587 W

3.785 W

3.711 W

3.587 W

3.785 W

Off (S5)

1.053 W

0.992 W

1.159 W

1.053 W

0.992 W

1.159 W

Zero Power Mode (ErP)

0.182 W

0.298 W

0.172 W

Heat Dissipation** (Btu/hr)

115 VAC

230 VAC

100 VAC

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

Windows Idle (S0)

352.83 btu/hr

348.81 btu/hr

354.58 btu/hr

Windows Busy Typ (S0)

626.96 btu/hr

620.57 btu/hr

646.13 btu/hr

Windows Busy Max (S0)

699.22 btu/hr

686.77 btu/hr

705.40 btu/hr

Sleep (S3)

12.66

btu/hr

12.24

btu/hr

12.91

btu/hr

12.66

btu/hr

12.24

btu/hr

12.91

btu/hr

Off (S5)

3.59 btu/hr

3.38 btu/hr

3.95 btu/hr

3.59 btu/hr

3.38 btu/hr

3.95 btu/hr

Zero Power Mode (ErP)

0.621 btu/hr

1.018 btu/hr

0.586 btu/hr

Example Configuration #2

(ENERGY STAR QUALIFIED)

Processor Info

2x Intel Xeon E5-2640v3 (Eight-Core) 90W

Memory Info

32GB DDR4-2133 (8x4GB) 2CPU RegRAM

Graphics Info

1x NVIDIA Quadro K2200

Disks/Optical/Floppy

3x 500GB SATA 7200/1x DVD-ROM SATA

Power Supply

1125W (1450W at 200V Input Voltage) 90% Custom PSU

Other

Energy Consumption

115 VAC

230 VAC

100 VAC

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

Windows Idle (S0)

1242.17 W

141.01 W

142.47 W

SYSTEM CONFIGURATION

QuickSpecs

HP Z840 Workstation

System Technical Specifications

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 22

Windows Busy Typ (S0)

324.18 W

320.33 W

323.91 W

Windows Busy Max (S0)

398.27 W

396.25 W

398.75 W

Sleep (S3)

6.08 W

6.03 W

6.13 W

6.08 W

6.03 W

6.13 W

Off (S5)

1.04 W

0.99 W

1.10 W

1.04 W

0.99 W

1.10 W

Zero Power Mode (ErP)

0.181 W

0.308 W

0.172 W

Heat Dissipation** (Btu/hr)

115 VAC

230 VAC

100 VAC

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

Windows Idle (S0)

485.08 btu/hr

481.13 btu/hr

486.11 btu/hr

Windows Busy Typ (S0)

1106.10 btu/hr

1092.97 btu/hr

1105.18 btu/hr

Windows Busy Max (S0)

1358.90 btu/hr

1352.01 btu/hr

1360.54 btu/hr

Sleep (S3)

20.75

btu/hr

20.57

btu/hr

20.91

btu/hr

20.75

btu/hr

20.57

btu/hr

20.91

btu/hr

Off (S5)

3.55 btu/hr

3.38 btu/hr

3.76 btu/hr

3.55 btu/hr

3.38 btu/hr

3.76 btu/hr

Zero Power Mode (ErP)

0.619 btu/hr

1.051 btu/hr

0.587 btu/hr btu/hr

Example Z840 Configuration #3

Processor Info

2x Intel Xeon E5-2680v3 (12-Core) 120W

Memory Info

64GB DDR4-2133 (8x8GB) 2CPU RegRAM

Graphics Info

1x NVIDIA Quadro K4200

Disks/Optical/Floppy

2x 300GB SAS 15K/1x SuperMulti DVDRW SATA

Power Supply

1125W (1450W at 200V Input Voltage) 90% Custom PSU

Other

Energy Consumption

115 VAC

230 VAC

100 VAC

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

Windows Idle (S0)

123.26 W

121.40 W

124.07 W

Windows Busy Typ (S0)

413.33 W

393.34 W

412.26 W

Windows Busy Max (S0)

496.46 W

483.26 W

498.07 W

Sleep (S3)

7.114 W

7.086 W

7.148 W

7.114 W

7.086 W

7.148 W

Off (S5)

1.054 W

0.993 W

1.161 W

1.054 W

0.993 W

1.161 W

Zero Power Mode (ErP)

0.181 W

0.307 W

0.177 W

Heat Dissipation** (Btu/hr)

115 VAC

230 VAC

100 VAC

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

Windows Idle (S0)

420.56 btu/hr

414.22 btu/hr

423.33 btu/hr

Windows Busy Typ (S0)

1410.28 btu/hr

1342.08 btu/hr

1406.63 btu/hr

Windows Busy Max (S0)

1693.95 btu/hr

1648.88 btu/hr

1700.10 btu/hr

Sleep (S3)

24.27

btu/hr

24.17

btu/hr

24.39

btu/hr

24.27

btu/hr

24.17

btu/hr

24.39

btu/hr

Off (S5)

3.597

btu/hr

3.388

btu/hr

3.962

btu/hr

3.597

btu/hr

3.388

btu/hr

3.962

btu/hr

Zero Power Mode (ErP)

0.619 btu/hr

1.049 btu/hr

0.607 btu/hr btu/hr

Example Z840 Configuration #4

Processor Info

2x Intel Xeon E5-2697v3 (14-Core) 145W

Memory Info

64GB DDR4-2133 (16x4GB) 2CPU RegRAM

Graphics Info

2x NVIDIA Quadro K5200

Disks/Optical/Floppy

4x 300GB SAS 15K/1x SuperMulti DVDRW SATA

QuickSpecs

HP Z840 Workstation

System Technical Specifications

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 23

Power Supply

1125W (1450W at 200V Input Voltage) 90% Custom PSU

Other

Energy Consumption

115 VAC

230 VAC

100 VAC

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

Windows Idle (S0)

141.75 W

140.45 W

141.63 W

Windows Busy Typ (S0)

510.66 W

498.90 W

510.82 W

Windows Busy Max (S0)

569.34 W

559.38 W

568.48 W

Sleep (S3)

6.454 W

3.669 W

6.497 W

6.454 W

3.669 W

6.497 W

Off (S5)

1.105 W

0.987 W

1.165 W

1.105 W

0.987 W

1.165 W

Zero Power Mode (ErP)

0.180 W

0.306 W

0.178 W

Heat Dissipation** (Btu/hr)

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

Windows Idle (S0)

483.65 btu/hr

497.22 btu/hr

483.24 btu/hr

Windows Busy Typ (S0)

1742.37 btu/hr

1702.25 btu/hr

1742.91 btu/hr

Windows Busy Max (S0)

1942.29 btu/hr

1908.60 btu/hr

1939.65 btu/hr

Sleep (S3)

22.02

btu/hr

21.63

btu/hr

22.16

btu/hr

22.02

btu/hr

21.63

btu/hr

22.16

btu/hr

Off (S5)

3.77 btu/hr

3.37 btu/hr

3.97 btu/hr

3.77 btu/hr

3.37 btu/hr

3.97 btu/hr

Zero Power Mode (ErP)

0.616 btu/hr

1.046 btu/hr

0.608 btu/hr

Example Configuration #5

(ENERGY STAR QUALIFIED)

Processor Info 2x Intel Xeon 2687Wv3 (10-Core) 160W

Memory Info

512GB DDR4-2133 (16x32GB) 2CPU LR RAM

Graphics Info

2x NVIDIA Quadro K6000

Disks/Optical/Floppy

6x 300GB 10K SAS SFF/1x SuperMulti DVDRW SATA

Power Supply

1125W (1450W at 200V Input Voltage) 90% Custom PSU

Other

Energy Consumption

115 VAC

230 VAC

100 VAC

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

On-Idle (ENERGY STAR® Idle (S0))

174.56 W

173.77 W

175.26 W

ENERGY STAR® PMAX

Windows running Linpack and Viewperf

561.98 W

559.23 W

567.75 W

ENERGY STAR® "Sleep" (S3)

16.426 W

16.279 W

16.099 W

16.426 W

16.279 W

16.099 W

ENERGY STAR® "Standby" (Off) (S5)

1.047 W

0.997 W

1.144 W

1.047 W

0.997 W

1.144 W

Heat Dissipation** (Btu/hr)

115 VAC

230 VAC

100 VAC

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

LAN Enabled

LAN Disabled

On-Idle (ENERGY STAR® Idle (S0))

595.60 btu/hr

592.90 btu/hr

597.99 btu/hr

ENERGY STAR® PMAX

Windows running Linpack and Viewperf

1917.48 btu/hr

1908.09 btu/hr

1937.16 btu/hr

ENERGY STAR® "Sleep" (S3)

56.046 btu/hr

55.545 btu/hr

54.935 btu/hr

56.046 btu/hr

55.545 btu/hr

54.935 btu/hr

QuickSpecs

HP Z840 Workstation

System Technical Specifications

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 24

System Configuration (Entry level)

Processor Info

Memory Info

Graphics Info

Disks/Optical/Floppy

Declared Noise Emissions (in accordance with ISO 7779 and ISO 9296)

Sound Power (LWAd, bels)

Deskside Sound Pressure

(LpAm, decibels)

Idle

Hard drive Operating (random reads)

DVD-ROM Operating (sequential reads)

System Configuration (High-end)

Processor Info

Memory Info

Graphics Info

Disks/Optical/Floppy

Declared Noise Emissions (in accordance with ISO 7779 and ISO 9296)

Sound Power (LWAd, bels)

Deskside Sound Pressure

(LpAm, decibels)

Idle

Hard drive Operating (random reads)

DVD-ROM Operating (sequential reads)

Environmental Requirements

Temperature

Operating: 5° to 35° C (40° to 95° F) Non-operating: -40° to 60° C (-40° to 140° F)

Humidity

Operating: 8% to 85% RH, non-condensing Non-operating: 8% to 90% RH, non-condensing

Maximum Altitude

Operating: 3,000 m (10,000 feet) Non-operating: 9,100 m (30,000 feet)

Dynamic (new)

Shock Operating: ½-sine: 40g, 2-3ms (~62 cm/sec) Non-operating: ½-sine: 160 cm/s, 2-3ms (~105g) square: 422 cm/s, 20g

NOTE: Values represent individual shock events and do not indicate repetitive shock events.

DECLARED NOISE EMISSIONS (ENTRY-LEVEL AND HIGH-END CONFIGURATIONS)

ENVIRONMENTAL DATA

QuickSpecs

HP Z840 Workstation

System Technical Specifications

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 25

Vibration Operating random: 0.5g (rms), 5-300 Hz, up to 0.0025 g²/Hz Non-operating random: 2.0g (rms), 5-500 Hz, up to 0.0150 g²/Hz

NOTE: Values do not indicate continuous vibration.

Cooling

Above 1524 m (5000 ft.) altitude, maximum operating temperature is derated by 1° C (1.8° F) per 305 m (1000 ft.) elevation increase

Access Panel

Tool-less Includes system board and memory information

Optical Drive

Tool-less, no carrier or rails required

Hard Drives

Tool-less

Expansion Cards

Tool-less

Processor Socket

Tool-less

Green User Touch Points

Yes, on tool-free internal chassis components

Color-coordinated Cables and Connectors

Yes

Memory

Tool-less

System Board

Tool-less, retained by Front PCI Card Guide

Dual Color Power and HD LED on Front of Computer

Yes

Configuration Record SW

Yes

Over-Temp Warning on Screen

Yes

Restore CD/DVD Set

Restores the computer to its original factory shipping image - Can be obtained via HP Support

Dual Function Front Power Switch

Yes, causes a fail-safe power off when held for 4 seconds

Padlock Support

Cable Lock Support

Yes, Kensington Cable Lock (optional): Prevents entire system theft only. 3mm x 7mm slot at rear of system

Universal Chassis Clamp Lock Support

Solenoid Lock and Hood Sensor

Rear Port Control Cover

Serial, Parallel, USB, Audio, Network, Enable/Disable Port Control

Yes

Removable Media Write/Boot Control

Yes, prevents ability to boot from removable media on supported devices (and can disable writes to media)

Power-On Password

Yes, prevents an unauthorized person from booting up the workstation

Setup Password

Yes, prevents an unauthorized person from changing the workstation configuration

3.3V Aux Power LED on System PCA

NIC LEDs (integrated)

Yes

PHYSICAL SECURITY AND SERVICEABILITY

QuickSpecs

HP Z840 Workstation

System Technical Specifications

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 26

(Green & Amber)

CPUs and Heatsinks

A torx driver (T15) is needed to remove the CPU heatsink(s) before the CPU can be removed. CPU removal is tool-less

Power Supply Diagnostic LED

Yes

Front Power Button

Yes

Front Power LED

Yes, white (normal), red (fault)

Front Hard Drive Activity LED

Yes, white

Front ODD Activity LED

Yes

Internal Speaker

Yes

System/Emergency ROM Flash Recovery

Recovers corrupted system BIOS

Cooling Solutions

Air cooled forced convection

Power Supply Fans

2x - 80mm x 25mm

CPU Heatsink Fan

92 x 25mm 5-wire PWM for each CPU

Chassis Fan

Rear: 2x - 92mm x 25mm Front (850W config): 1x - 92mm x 25mm (upper position) Front (1125W (1450W at 200V Input Voltage) config): 2x - 92mm x 25mm

Memory Heatsink Fan

3x - 75 x 90 x 35mm memory blowers 80 x 25 mm 4-wire PW fan

HP Vision Diagnostics Offline Edition

HP Vision Diagnostics Offline Edition The diagnostics utility enables you to perform testing and to view critical computer hardware and software configuration information from various sources. This utility enables you to:

 Run diagnostics  View the hardware configuration of the system

Key features and benefits HP Vision Diagnostics simplifies the process of effectively identifying, diagnosing, and isolating the hardware issues. In addition to robust management tools, service tools can be invaluable in quickly resolving system problems. To streamline the service process and resolve problems quickly, it is necessary to have the right information available at the time that a service call is placed. The primary information requirement, which is also the one that provides the greatest Vision into potential system issues, is the configuration of the system. Vision Diagnostics helps provide higher system availability. Typical uses of the Vision Diagnostics are:

 Testing and diagnosing apparent hardware failures  Documenting system configurations for upgrade planning, standardization, inventory

tracking, disaster recovery, and maintenance

 Sending configuration information to another location for more in-depth analysis

Access Panel Key Lock

Yes, prevents removal of the access panel and all internal components including optical and floppy drives

ACPI-Ready Hardware

Advanced Configuration and Power Management Interface (ACPI).

 Allows the system to wake from a low power mode.  Controls system power consumption, making it possible to place individual cards and

peripherals in a low-power or powered-off state without affecting other elements of the

QuickSpecs

HP Z840 Workstation

System Technical Specifications

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 27

system

Trusted Platform Module Chip

Yes

Integrated Chassis Handles

Yes, front and rear

Power Supply

Tool-less, direct-connect (blind-mate)

PCIe Card Retention

Yes, rear (all), middle (full-height cards), front (full-length with extender cards)

Flash ROM

Yes. SPI ROM

Diagnostic Power Switch LED on board

Yes

Clear Password Jumper

Yes

Clear CMOS Button

Yes

CMOS Battery Holder

Yes

DIMM Connectors

Yes

BIOS 32-bit Services

Standard BIOS 32-Bit Service Directory Proposal v0.4. BIOS supports 32 and 64-bit Operating systems.

PCI 3.0 Support

Full BIOS support for PCI Express through industry standard interfaces.

ATAPI

ATAPI Removable Media Device BIOS Specification Version 1.0.

BBS

BIOS Boot Specification v1.01

WMI Support

WMI is Microsoft's implementation of Web-Based Enterprise Management (WBEM) for Windows. WMI is fully compliant with the Distributed Management Task Force (DMTF) Common Information Model (CIM) and WBEM specifications.

BIOS Boot Spec 1.01+

Provides more control over how and from what devices the workstation will boot.

BIOS Power On

Users can define a specific date and time for the system to power on.

ROM Based Computer Setup Utility (F10)

Review and customize system settings controlled by the BIOS.

System/Emergency ROM Flash Recovery with Video

Recovers system BIOS in corrupted Flash ROM.

Replicated Setup

Saves BIOS settings to diskette or USB flash drive in human readable file. Repset.exe utility can then replicate these settings on machines being deployed without entering Computer Configuration Utility (F10 setup).

SMBIOS

System Management BIOS 2.7, for system management information

Boot Control

Disables the ability to boot from removable media on supported devices.

Memory Change Alert

Alerts management console if memory is removed or changed.

Thermal Alert

Monitors the temperature state within the chassis. Three modes:

- NORMAL - normal temperature ranges.

- ALERTED - excessive temperatures are detected. Raises a flag so action can be taken to avoid shutdown or provide for a smoother system shutdown.

- SHUTDOWN - excessive temperatures are encountered. Automatically shuts down the computer without warning before hardware component damage occurs. Remote ROM Flash

Provides secure, fail-safe ROM image management from a central network console.

BIOS

QuickSpecs

HP Z840 Workstation

System Technical Specifications

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 28

ACPI (Advanced Configuration and Power Management Interface)

Allows the system to enter and wake from low power modes (sleep states). Enables an operating system to control system power consumption based on the dynamic workload. Makes it possible to place individual cards and peripherals in a low-power or powered-off state without affecting other elements of the system. Supports ACPI 4.0 for full compatibility with 64-Bit operating systems.

Ownership Tag

A user-defined string stored in non-volatile memory that is displayed in the BIOS splash screen.

Remote Wakeup/Remote Shutdown

System administrators can power on, restart, and power off a client computer from a remote location.

Instantly Available PC (Suspend to RAM - ACPI sleep state S3)

Allows for very low power consumption with quick resume time.

Remote System Installation via F12 (PXE

2.1) (Remote Boot from Server)

Allows a new or existing system to boot over the network and download software, including the operating system.

ROM revision levels

Reports the system BIOS revision level in Computer Configuration Utility (F10 Setup). Version is available through an industry standard interface (SMBIOS) so that management SW applications can use and report this information.

System board revision level

Allows management SW to read the revision level of the system board Revision level is digitally encoded into the HW and cannot be modified.

Start-up Diagnostics (Power-on Self-Test)

Assesses system health at boot time with selectable levels of testing.

Auto Setup when new hardware installed

System automatically detects addition of new hardware. Keyboard-less Operation

The system can be booted without a keyboard.

Localized ROM Setup

Common BIOS image supports System Configuration Utility (F10 Setup) menus in 12 languages with local keyboard mappings.

Asset Tag

Allows the user or MIS to set a unique tag string in non-volatile memory.

Per-slot Control

Allows I/O slot parameters (option ROM enable/disable, bus latency) to be configured individually.

Adaptive Cooling

Fan control parameters are set according to detected hardware configuration for optimal acoustics.

Pre-boot Diagnostics

Early (pre-video) critical errors are reported via beeps and blinks on the power LED.

Industry Standard Specification Support

Industry Standard

Revision Supported by the BIOS

UEFI Specification Revision

2.3.1 ACPI

Advanced Configuration and Power Management Interface, Version 4.0

ATA (IDE)

AT Attachment 6 with Packet Interface (ATA/ATAPI-6), Revision 3b

CD Boot

"El Torito" Bootable CD-ROM Format Specification Version 1.0

EDD

- Enhanced Disk Drive Specification Version 1.1

- BIOS Enhanced Disk Drive Specification Version 3.0

EHCI

Enhanced Host Controller Interface for Universal Serial Bus, Revision 1.0

PCI

- PCI Local Bus Specification, Revision 2.3

- PCI Power Management Specification, Revision 1.1

- PCI Firmware Specification, Revision 3.0, Draft .7

PCI Express

PCI Express Base Specification, Revision 2.0 PCI Express Base Specification, Revision 3.0

QuickSpecs

HP Z840 Workstation

System Technical Specifications

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 29

PMM

POST Memory Manager Specification, Version 1.01

SATA

Serial ATA Specification, Revision 1.0a Serial ATA 3 Gb/s: Serial ATA Specification, Revision 2.5 Serial ATA 6 Gb/s: Serial ATA Specification, Revision 3.0

SPD

PC SDRAM Serial Presence Detect (SPD) Specification, Revision 1.2B

TPM

Trusted Computing Group TPM Specification Version 1.2

UHCI

Universal Host Controller Interface Design Guide, Revision 1.1

USB

Universal Serial Bus Revision 1.1 Specification

Universal Serial Bus Revision 2.0 Specification

Universal Serial Bus Revision 3.0 Specification

SMBIOS

System Management BIOS Reference Specification, Version 2.7

External BIOS Simulator found at: http://h20464.www2.hp.com/index.html

Eco-Label Certifications & Declarations

This product has received or is in the process of being certified to the following approvals and may be labeled with one or more of these marks:

 ENERGY STAR® (energy-saving features available on selected configurations-Windows only)  US Federal Energy Management Program (FEMP)  China Energy Conservation Program  The ECO Declaration (TED)

Batteries

The battery in this product complies with EU Directive 2006/66/EC Battery size: CR2032 (coin cell) Battery type: Lithium Metal

The battery in this product does not contain:

 Mercury greater than 5ppm by weight  Cadmium greater than 10ppm by weight  Lead greater than 40ppm by weight

Restricted Material Usage

This product meets the material restrictions specified in HP's General Specification for the Environment. http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/gse.pdf

Hewlett-Packard is committed to compliance with all applicable environmental laws and regulations, including the European Union Restriction of Hazardous Substances (RoHS) Directive. HP's goal is to exceed compliance obligations by meeting the requirements of the RoHS Directive on a worldwide basis.

Low Halogen Statement

This product is low halogen except for power cords, cables and peripherals, as well as the following customer-configurable internal components: 3 ½" SAS HDDs, LSI 9260-8i SAS 6Gb/s ROC RAID Card, Creative Recon3D PCIe Audio Card, Liquid Cooling Solution and Broadcom 5761 Gigabit PCIe NIC are not Low Halogen. Service parts obtained after purchase may not be Low Halogen.

End-of-Life Management and Recycling

Hewlett-Packard offers end-of-life HP product return and recycling programs in many geographic areas. To recycle your product, please go to: http://www.hp.com/recycle or contact your nearest HP sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible manner. This product is greater than 90% recyclable by weight when properly disposed of at end of life.

Social and Environmental Responsibility

QuickSpecs

HP Z840 Workstation

System Technical Specifications

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 30

Hewlett-Packard Corporate Environmental Information

For more information about HP's commitment to the environment: Global Citizenship Report http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html

Eco-label certifications

http://www.hp.com/hpinfo/globalcitizenship/environment/productdesign/ecolabels.html

ISO 14001 certificates:

http://www.hp.com/hpinfo/globalcitizenship/environment/operations/envmanagement.html

Additional Information

 This HP product is designed to comply with the Waste Electrical and Electronic Equipment

(WEEE) Directive – 2002/96/EC.

 Plastic parts weighing over 25 grams used in the product are marked per ISO 11469 and

ISO1043.

 This product is >90% recycle-able when properly disposed of at end of life.

EPEAT Gold - ENERGY STAR qualified configurations of this product are in compliance with the IEEE 1680 (EPEAT) standard at the Gold level where HP registers workstation products. See

http://ww2.epeat.net/CompanyDetail.aspx?CompanyID=24 for registration status in your country.

Packaging

HP Workstation product packaging meets the HP General Specification for the Environment at

http://www.hp.com/hpinfo/globalcitizenship/society/gen_specifications.html

 Does not contain restricted substances listed in HP Standard 011-1 General Specification for

the Environment

 Does not contain ozone-depleting substances (ODS)  Does not contain heavy metals (lead, mercury, cadmium or hexavalent chromium) in excess of

100 ppm sum total for all heavy metals listed

 Maximizes the use of post-consumer recycled content materials in packaging materials  All packaging material is recyclable  All packaging material is designed for ease of disassembly  Reduced size and weight of packages to improve transportation fuel efficiency  Plastic packaging materials are marked according to ISO 11469 and DIN 6120 standards

formatting

Packaging Materials

Internal

Cushions and plastic bags made of low density polyethylene (LDPE).

External

Outer carton, accessories carton, and insert made of corrugated paper board.

Industry Standard Specifications

This product meets the following industry standard specifications for manageability functionality:

 DASH 1.1 (via Intel LAN on motherboard)

Intel Active Management Technology (AMT)

Intel® Active Management Technology (AMT) 9.1

An advanced set of remote management features and functionality providing IT administrators the latest and most effective tools to remotely discover, heal, and protect networked client systems regardless of the system's health or power state. AMT 9.1 includes the following advanced management functions:

 Power Management (on, off, reset, graceful shutdown, sleep and hibernate)  Support in Max Power Savings (Shutdown and Hibernate Modes)  Hardware Inventory (includes BIOS and firmware revisions)

MANAGEABILITY

QuickSpecs

HP Z840 Workstation

System Technical Specifications

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 31

 Hardware Alerting  Agent Presence  System Defense Filters  Serial Over LAN (SOL)  IDE Redirect  ME Wake-on-LAN (WOL)  DASH 1.1 compliance  IPv6 Support  Fast Call for Help - a client inside or outside the firewall may initiate a call for help via BIOS

screen, periodic connections, or alert triggered connection

 Remote Scheduled Maintenance - pre-schedule when the system connects to the IT or service

provider console for maintenance.

 Remote Alerts - automatically alert IT or service provider if issues arise  Access Monitor - Provides oversight into Intel® AMT actions to support security requirements  PC Alarm Clock  Microsoft NAP Support  Host Base set-up and configuration  Management Engine (ME) firmware roll back  Local Time Sync to UTC Remote Memory Dump Command – Creates memory dump for debug

Intel® vPro™ Technology

The HP Z840 Workstation supports Intel vPro technology when configured as outlined below:

 Intel® Xeon® processor E5-1600 v3 product family or E5-2600 v3 product family featuring

Intel® vPro™ Technology

 Intel® C610 chipset  Intel® I218LM GbE LAN

Remote Manageability Software Solutions

The HP Z840 Workstation is supported on the following remote manageability software consoles:

 LANDesk Management Suite (HP recommended solution)  Microsoft System Center Configuration Manager  HP Client Automation Enterprise

For questions or support for manageability needs, please visit http://www.hp.com/go/easydeploy

System Software Manager

For questions or support for SSM, please visit: http://www.hp.com/go/ssm

Service, Support, and Warranty

On-site Warranty and Service (Note 1): Three-years, limited warranty and service offering delivers onsite, next business-day (Note 2) service for parts and labor and includes free telephone support (Note

3) 8am - 5pm. Global coverage (Note 2) ensures that any product purchased in one country and

transferred to another, non-restricted country will remain fully covered under the original warranty and service offering.

NOTE 1: Terms and conditions may vary by country. Certain restrictions and exclusions apply. NOTE 2: On-site service may be provided pursuant to a service contract between HP and an authorized

HP third-party provider, and is not available in certain countries. Global service response times are based on commercially reasonable best effort and may vary by country. NOTE 3: Technical telephone support applies only to HP-configured, HP and HP-qualified, third-party hardware and software. Toll-free calling and 24x7 support service may not be available in some countries.

HP Care Pack Services are extended service contracts that go beyond the standard limited warranties. Service starts from date of hardware purchase. To choose the right level of service for your HP product, use the HP Care Pack Services Lookup Tool at: http://www.hp.com/go/lookuptool. Additional HP Care

QuickSpecs

HP Z840 Workstation

System Technical Specifications

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 32

Pack Services information by product is available at: http://www.hp.com/hps/carepack. Service levels and response times for HP Care Packs may vary depending on your geographic location. HP services are governed by the applicable HP terms and conditions of service provided or indicated to Customer at the time of purchase. Customer may have additional statutory rights according to applicable local laws, and such rights are not in any way affected by the HP terms and conditions of service or the HP Limited Warranty provided with your HP Product.

Product Change Notification

 Program to proactively communicate Product Change Notifications (PCNs) and Customer

Advisories by email to customers, based on a user-defined profile.

 PCNs provide advance notification of hardware and software changes to be implemented in

the factory providing time to plan for transition.

 Customer Advisories provide concise, effective problem resolution, greatly reducing the need

to call technical support.

QuickSpecs

HP Z840 Workstation

Stable & Consistent Offerings

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 33

Global Series SKUs

As part of its commitment to hardware, software, and solution innovation, HP is proud to introduce this breakthrough platform configuration stability to HP Workstation customers. HP Stable & Consistent Offerings are built on the foundation of a carefully chosen set of hardware and software designed and tested to work with all HP Z Workstation platforms through their end of life. These components and their corresponding HP Workstation platform compatibility are outlined in this section. HP Stable & Consistent Offerings are available worldwide to all HP Workstation customers-no special programs, no additional cost-no kidding. Simply select your hardware and software components when you customize your HP Workstation and be assured that you'll be able to buy that same configuration throughout the lifecycle of the product.

Processors

Product #

Offering

J6F75AV

Intel Xeon E5-2620v3 2.4 1866 6C 1stCPU

J6F73AV

Intel Xeon E5-2630v3 2.4 1866 8C 1stCPU

J6F71AV

Intel Xeon E5-2637v3 3.5 2133 4C 1stCPU

J6F94AV

Intel Xeon E5-2620v3 2.4 1866 6C 2ndCPU

J6F92AV

Intel Xeon E5-2630v3 2.4 1866 8C 2ndCPU

J6F90AV

Intel Xeon E5-2637v3 3.5 2133 4C 2ndCPU

Hard Drives

Product #

Offering

J3K71AV

500GB 7200 RPM SATA 1st HDD

J3K72AV

1TB 7200 RPM SATA 1st HDD

J3K92AV

500GB 7200 RPM SATA 2nd HDD

J3K93AV

1TB 7200 RPM SATA 2nd HDD

J3L13AV

500GB 7200 RPM SATA 3rd HDD

J3L14AV

1TB 7200 RPM SATA 3rd HDD

J3L36AV

500GB 7200 RPM SATA 4th HDD

J3L37AV

1TB 7200 RPM SATA 4th HDD

J3L54AV

500GB 7200 RPM SATA 5th HDD

J3L55AV

1TB 7200 RPM SATA 5th HDD

Graphics

Product #

Offering

J1Q20AV

NVIDIA Quadro K2200 4GB 1st GFX

J1Q24AV

AMD FirePro W2100 2GB 1st GFX

J1Q30AV

NVIDIA Quadro K620 2GB 2nd GFX

J1Q31AV

NVIDIA Quadro K2200 4GB 2nd GFX

J1Q35AV

AMD FirePro W2100 2GB 2nd GFX

J1Q38AV

NVIDIA Quadro K2200 4GB 3rd GFX

Memory

Product #

Offering

G8X58AV

8GB DDR4-2133 (1x8GB) 1CPU RegRAM

G8X61AV

16GB DDR4-2133 (2x8GB) 1CPU RegRAM

G8X63AV

32GB DDR4-2133 (4x8GB) 1CPU RegRAM

G8X64AV

64GB DDR4-2133 (8x8GB) 1CPU RegRAM

QuickSpecs

HP Z840 Workstation

Stable & Consistent Offerings

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 34

G8X74AV

32GB DDR4-2133 (4x8GB) 2CPU RegRAM

G8X77AV

64GB DDR4-2133 (8x8GB) 2CPU RegRAM

G8X78AV

128GB DDR4-2133 (16x8GB) 2CPU RegRAM

G8X65AV

64GB DDR4-2133 (4x16GB) 1CPU RegRAM

G8X66AV

128GB DDR4-2133 (8x16GB) 1CPU RegRAM

G8X79AV

128GB DDR4-2133 (8x16GB) 2CPU RegRAM

G8X80AV

256GB DDR4-2133 (16x16GB) 2CPU RegRAM

Optical and Removable Storage

Product #

Offering

F5G79AV

Slim SuperMulti DVDRW SATA 1st ODD

G8U90AV

Slim SuperMulti DVDRW SATA 2nd ODD

Input Devices

Product #

Offering

G8U76AV

HP USB Keyboard

G8U87AV

HP USB Optical Mouse

QuickSpecs

HP Z840 Workstation

Technical Specifications - Processors

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 35

Xeon E5-2603 v3 1.6 1600 6C CPU

J9V77AA

Xeon E5-2609 v3 1.9 1600 6C CPU

J9V76AA

Xeon E5-2620 v3 2.4 1866 6C CPU

J9V75AA

Xeon E5-2623 v3 3.0 1866 4C CPU

J9Q18AA

Xeon E5-2630 v3 2.4 1866 8C CPU

J9Q17AA

Xeon E5-2640 v3 2.6 1866 8C CPU

J9Q16AA

Xeon E5-2637 v3 3.5 2133 4C CPU

J9Q15AA

Xeon E5-2650 v3 2.3 2133 10C CPU

J9Q14AA

Xeon E5-2660 v3 2.6 2133 10C CPU

J9Q13AA

Xeon E5-2643 v3 3.4 2133 6C CPU

J9Q12AA

Xeon E5-2670 v3 2.3 2133 12C CPU

J9Q11AA

Xeon E5-2680 v3 2.5 2133 12C CPU

J9Q10AA

Xeon E5-2683 v3 2.0 2133 14C CPU

J9Q09AA

Xeon E5-2667 v3 3.2 2133 8C CPU

J9Q08AA

Xeon E5-2690 v3 2.6 2133 12C CPU

J9Q07AA

Xeon E5-2687Wv3 3.1 2133 10C CPU

J9Q06AA

Xeon E5-2695 v3 2.3 2133 14C CPU

J9Q05AA

Xeon E5-2697 v3 2.6 2133 14C CPU

J9Q04AA

Xeon E5-2699 v3 2.3 2133 18C CPU

J9Q03AA

PROCESSORS

QuickSpecs

HP Z840 Workstation

Technical Specifications – Storage Hard Drives

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 36

HP SAS (Serial Attached SCSI) Hard Drives for HP Workstations

600GB SAS 15K rpm 6Gb/s 3.5" HDD

Capacity

600GB

Height

1 in; 2.54 cm

Width Media Diameter

3.5 in; 8.9 cm

Physical Size

4 in; 10.17 cm

Interface

SAS

Synchronous Transfer Rate (Maximum)

6.0 Gb/s

Buffer

16 MB

Seek Time (typical reads, includes controller overhead, including settling)

Single Track

0.2 ms

Average

3.4 ms

Full Stroke

6.6 ms

Rotational Speed

15,000 rpm

Logical Blocks

1,172,123,568 - 512 byte blocks

Operating Temperature

50° to 95° F (10° to 35° C)

300GB SAS 15K rpm 6Gb/s 3.5" HDD

Capacity

300GB

Height

1 in; 2.54 cm

Width Media Diameter

3.5 in; 8.9 cm

Physical Size

4 in; 10.17 cm

Interface

SAS

Synchronous Transfer Rate (Maximum)

6Gb/s

Buffer

16MB

Seek Time (typical reads, includes controller overhead, including settling)

Single Track

0.2 ms

Average

3.4 ms

Full Stroke

6.6 ms

Rotational Speed

15,000 rpm

Operating Temperature

50° to 95° F (10° to 35° C)

600GB SAS 15K SFF HDD

Capacity

600GB

Height

5.9 in; 15 cm

Width

Media Diameter

Interface

12Gb/s SAS

Synchronous Transfer Rate (Maximum)

up to 1200 MB/s (SAS single port)

Cache

128MB

Seek Time (typical reads, includes controller overhead, including settling)

Average

2.0ms

Rotational Speed

15K rpm

HARD DRIVES

QuickSpecs

HP Z840 Workstation

Technical Specifications – Storage Hard Drives

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 37

Operating Temperature

41° to 131° F (5° to 55° C)

300GB SAS 15K SFF HDD

Capacity

300GB

Height

5.9 in; 15 cm

Width

Media Diameter

2.5 in; 6.36 cm

Interface

12Gb/s SAS

Synchronous Transfer Rate (Maximum)

up to 1200 MB/s (SAS single port)

Cache

128MB

Seek Time (typical reads, includes controller overhead, including settling)

Average

2.0ms

Rotational Speed

15K rpm

Operating Temperature

41° to 131° F (5° to 55° C)

HP 300GB SAS 10K SFF HDD

Capacity

300GB

Height

0.6 in; 1.53 cm

Width Media Diameter

2.5 in; 6.36 cm

Physical Size

2.75 in; 6.99 cm

Interface

SAS 6Gb/s

Synchronous Transfer Rate (Maximum)

Up to 600MB/s

Buffer

64MB

Cache

multi-segmentable cache buffer

Seek Time (typical reads, includes controller overhead, including settling)

Single Track

0.4 ms (max)

Average

3.6 ms

Full Stroke

7.3 ms

Rotational Speed

10,000 rpm

Logical Blocks

585,937,500

Operating Temperature

41° to 131° F (5° to 55° C)

HP 600GB SAS 10K SFF HDD

Capacity

600GB

Height

0.6 in; 1.53 cm

Width Media Diameter

2.5 in; 6.36 cm

Physical Size

2.75 in; 6.99 cm

Interface

SAS 6Gb/s

Synchronous Transfer Rate (Maximum)

Up to 600MB/s

Buffer

64MB

Cache

multi-segmentable cache buffer

Seek Time (typical reads, includes controller overhead, including settling)

Single Track

0.4 ms (max)

Average

3.6 ms

Full Stroke

7.3 ms

Rotational Speed

10,000 rpm

QuickSpecs

HP Z840 Workstation

Technical Specifications – Storage Hard Drives

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 38

Logical Blocks

1,172,123,568

Operating Temperature

41° to 131° F (5° to 55° C)

HP 1.2TB SAS 10K SFF HDD

Capacity

1.2TB

Height

0.6 in; 1.53 cm

Width Media Diameter

2.5 in; 6.36 cm

Physical Size

2.75 in; 6.99 cm

Interface

SAS 6Gb/s

Synchronous Transfer Rate (Maximum)

Up to 600MB/s

Buffer

64MB

Seek Time (typical reads, includes controller overhead, including settling)

Single Track

0.18ms (max)

Average

3.5ms

Full Stroke

7.17ms

Rotational Speed

10,000 rpm

Logical Blocks

2,344,225,968

Operating Temperature

41° to 131° F (5° to 55° C)

SATA Hard Drives for HP Workstations

500GB SATA 10K rpm SFF HDD

Capacity

500GB

Height

0.6 in; 1.53 cm

Width

Media Diameter

2.5 in; 6.36 cm

Physical Size

2.75 in; 6.99 cm

Interface

Serial ATA (6Gb/s)

Synchronous Transfer Rate (Maximum)

Up to 600MB/s

Buffer

64MB

Cache

Adaptive

Seek Time (typical reads, includes controller overhead, including settling)

Single Track

1.2ms (typical)

Average

3.6ms

Full Stroke

9.0ms (typical)

Rotational Speed

10K rpm

Operating Temperature

41° to 131° F (5° to 55° C)

1TB SATA 7200 rpm 6Gb/s 3.5" HDD

Capacity

1TB

Height

1 in; 2.54 cm

Width Media Diameter

3.5 in; 8.9 cm

Physical Size

4 in; 10.17 cm

Interface

Serial ATA (6Gb/s)

Synchronous Transfer Rate (Maximum)

Up to 600 MB/s

Buffer

64MB

Seek Time (typical reads, includes controller overhead, including settling)

Single Track

1.2ms (typical)

Average

11ms

Full Stroke

21ms (typical)

Rotational Speed

7,200 rpm

QuickSpecs

HP Z840 Workstation

Technical Specifications – Storage Hard Drives

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 39

Logical Blocks

1,953,525,168

Operating Temperature

41° to 131° F (5° to 55° C)

2.0TB SATA 7200 rpm 6Gb/s 3.5" HDD

Capacity

2.0TB

Height

1 in; 2.54 cm

Width

Media Diameter

3.5 in; 8.9 cm

Physical Size

4 in; 10.17 cm

Interface

Serial ATA (6.0 Gb/s), NCQ Enabled

Synchronous Transfer Rate (Maximum)

Up to 600 MB/s

Buffer

64MB

Seek Time (typical reads, includes controller overhead, including settling)

Single Track

1.0 ms

Average

11 ms

Full Stroke

18 ms

Rotational Speed

7,200 rpm

Logical Blocks

3,907,029,168

Operating Temperature

41° to 131° F (5° to 55° C)

3.0TB SATA 7200 rpm 6Gb/s 3.5" HDD

Capacity

3.0TB

Height

1 in; 2.54 cm

Width Media Diameter

3.5 in; 8.9 cm

Physical Size

4.0 in; 10.17 cm

Interface

Serial ATA (6.0Gb/s), NCQ enabled

Synchronous Transfer Rate (Maximum)

Up to 6.0 Gb/s

Buffer

64MB

Seek Time (typical reads, includes controller overhead, including settling)

Single Track

0.6 ms

Average

11 ms

Full Stroke

Not Specified

Rotational Speed

7,200 rpm

Operating Temperature

41° to 140° F (5° to 60° C)

4TB SATA 7200 rpm 6Gb/s 3.5" HDD

Capacity

4TB

Height

1 in; 2.54 cm

Width Media Diameter

2.5 in; 6.36 cm

Physical Size

2.75 in; 6.99 cm

Interface

Serial ATA (6Gb/s), NCQ enabled

Synchronous Transfer Rate (Maximum)

Up to 600MB/s

Buffer

128MB

Seek Time (typical reads, includes controller overhead, including settling)

Single Track

0.7ms

Average

8.5ms

Full Stroke

15.7ms

Rotational Speed

7,200 rpm

QuickSpecs

HP Z840 Workstation

Technical Specifications – Storage Hard Drives

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 40

Operating Temperature

41° to 131° F (5° to 55° C)

500GB SATA 7.2K SED SFF HDD

Capacity

500GB

Height

0.275 in; 0.7 cm

Width Media Diameter

2.5 in; 6.36 cm

Physical Size

2.75 in; 6.99 cm

Interface

Serial ATA (6Gb/s)

Synchronous Transfer Rate (Maximum)

Up to 600MB/s

Buffer

32MB

Seek Time (typical reads, includes controller overhead, including settling)

Single Track

1ms

Average

4.2ms

Full Stroke

25ms (typical) Rotational Speed

7,200 rpm

Operating Temperature

32° to 140° F (0° to 60° C)

HP Solid State Drives (SSDs) for Workstations

HP 128GB SATA 6Gb/s SSD

Capacity

128GB

Height

0.28 in; 0.7 cm

Width

Physical Size

2.5 in; 6.36 cm

Interface

SATA 6Gb/s

Synchronous Transfer Rate (Maximum)

Up to 500MB/s (Sequential Read)

Operating Temperature

32° to 158° F (0° to 70° C)

HP 256GB SATA 6Gb/s SSD

Capacity

256GB

Height

0.28 in; 0.7 cm

Interface

SATA 6Gb/s

Synchronous Transfer Rate (Maximum)

Up to 500MB/s (Sequential Read)

Operating Temperature

32° to 158° F (0° to 70° C)

HP 256GB SATA 6Gb/s SED Opal 1SSD

Capacity

256GB

Height

0.28 in; 0.7 cm

Width

Physical Size

2.5 in; 6.36 cm

Interface

6Gb/s SATA

Synchronous Transfer Rate (Maximum)

Up to 500MB/s (Sequential Read)

Operating Temperature

32° to 158° F (0° to 70° C)

HP 512GB SATA 6Gb/s SSD

Capacity

512GB

Height

0.28 in; 0.7 cm

Width

Physical Size

2.5 in; 6.36 cm

Interface

6Gb/s SATA

Synchronous Transfer Rate (Maximum)

Up to 500MB/s (Sequential Read)

QuickSpecs

HP Z840 Workstation

Technical Specifications – Storage Hard Drives

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 41

Operating Temperature

32° to 158° F (0° to 70° C)

HP 1TB SATA 6Gb/s SSD

Capacity

1TB

Height

0.28 in; 0.7 cm

Width

Physical Size

2.5 in; 6.36 cm

Interface

6Gb/s SATA

Synchronous Transfer Rate (Maximum)

Up to 550MB/s (Sequential Read)

Operating Temperature

32° to 158° F (0° to 70° C)

Samsung Enterprise 240GB SATA SSD

Capacity

240GB

Width

Physical Size

2.5 in; 6.36 cm

Interface

SATA 6Gb/s

Synchronous Transfer Rate (Maximum)

600 Mb/s

Samsung Enterprise 480GB SATA SSD

Capacity

480GB

Width

Physical Size

2.5 in; 6.36 cm

Interface

SATA 6Gb/s

Synchronous Transfer Rate (Maximum)

600 Mb/s

Intel Pro 1500 180GB SATA SSD

Capacity

180GB

Width

Physical Size

2.5 in; 6.36 cm

Interface

6Gb/s SATA

Synchronous Transfer Rate (Maximum)

600 Mb/s Operating Temperature

32° to 158° F (0° to 70° C)

PCIe SSDs for HP Workstations

HP Z Turbo Drive 256GB SSD

Capacity

256GB

Interface

PCI Express 2.0 x4 electrical x4 physical

Operating Temperature

32° to 158° F (0° to 70° C)

HP Z Turbo Drive 512GB SSD

Capacity

512GB

Interface

PCI Express 2.0 x4 electrical x4 physical

Operating Temperature

32° to 158° F (0° to 70° C)

HDD Carrier

HP 4-in-1 SFF (2.5in) HDD Carrier

Dimensions (L x W x H)

6.70 x 5.75 x 1.63 in

Kit Contents

Drive Carrier, Drive trays (4), Power adapter

Weight

1.77 lbs

QuickSpecs

HP Z840 Workstation

Technical Specifications - Hard Drive Controllers

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 42

LSI 9270-8i SAS 6Gb/s ROC RAID Card and iBBU9 Battery Backup Unit

PCI Bus

x8 lane PCIe 3.0 compliant

RAID Levels

RAID 0, 1, 5, and 6 RAID spans 10, 50 and 60 PCI Card Type

Low profile, single PCIe slot design with full height bracket.

PCI Voltage

+3.3V Add-in Card

PCI Power

+3.3V, +12V

Certification Level

PCI-Express 3.0

IO Bus

Eight 6Gb/s and 3Gb/s compatible SAS/SATA ports

SAS Processor

LSISAS2208 Dual-Core RAID on Chip (ROC)

Internal Connectors

Two SAS SFF8087 x4 (Mini-SAS)

External Connectors

None

Maximum Number of SCSI Devices

Up to 128 SAS and/or SATA hard drives and SSDs Note: HP Workstations do not support this many internal drives.

LED Indicators

Heartbeat LED on card

QuickSpecs

HP Z840 Workstation

Technical Specifications – Graphics

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 43

NVIDIA NVS 310 512MB Graphics

Form Factor

Low Profile:

2.7 inches (H) x 5.7 inches (L), Half-Height

Weight:

~142 grams

Graphics Controller

NVIDIA NVS 310 GPU: GF119-825

Bus Type

PCI Express x16, 2.0 compliant

Memory

Size: 512MB DDR3 Clock: 875MHz Memory Bandwidth: 14GB/s

Connectors

2 x DisplayPort

Maximum Resolution

Up to 2560 x 1600 (digital display) per display.

Image Quality Features

The following video formats are supported:

- MPEG2

- MPEG4 Part 2 Advanced Simple Profile

- H.264 SVC codec support

- Support for 3D Blu Ray

- VC1

- DivX version 3.11 and later

- MVC

A full range of video resolutions are supported including 1080p, 1080i, 720p, 480p and 480i. The NVS 310 GPU provides hardware acceleration for the computationally intensive parts of video processing, as well as provides improved video playback speeds via faster decode and transcode.

Display Output

Up to 2 displays in the following configurations:

DisplayPort output:

 Drives two DisplayPort enabled digital display at resolutions up to

2560 × 1600 at 60 Hz with reduced blanking, when connected natively using the 2 DisplayPort connectors on the NVS 310 graphics card

 Supports 2 monitors up to resolution of 1920 × 1200 at 60 Hz with

reduced blanking using DisplayPort 1.2 multi stream topology technology.

DVI-D output:

 Drives two digital display at resolutions up to 1920 × 1200 at 60

Hz with reduced blanking using DisplayPort to DVI-D single-link cable adaptors

 Drives two digital display at resolutions up to 2560× 1600 at 60 Hz

with reduced blanking using DisplayPort to DVI-D dual-link cable adaptors

HDMI output:

 NVS 310 is capable of driving two high definition (HD) panels up to

resolutions of 1920 × 1080P at 60 Hz using DisplayPort to HDMI cable adaptors

GRAPHICS

QuickSpecs

HP Z840 Workstation

Technical Specifications – Graphics

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 44

VGA display output:

 Drives two analog display at resolutions up to 1920 × 1200 at 60

Hz using DisplayPort to VGA cable adaptors

Shading Architecture

Shader Model 5.0

Supported Graphics APIs

DX11, OpenGL 4.1

Available Graphics Drivers

Windows 8 Genuine Windows 7 Professional (64-bit and 32-bit) Microsoft Windows XP Professional (64-bit and 32-bit) Red Hat Enterprise Linux(RHEL) SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit)

HP qualified drivers may be preloaded or the latest HP qualified drivers are available from the HP support Web site:

http://welcome.hp.com/country/us/en/support.html

SUSE Linux Enterprise drivers may also be obtained from: ftp://download.nvidia.com/novell or http://www.nvidia.com

NOTES:

1. The thermal solution used on this card is an active fan heatsink.

2. Factory configured NVS 310 graphics card have no cable adapters included. Adapters must be ordered separately.

3. Option kit NVS 310 includes 2 DP to DVI-D cable adapters.

NVIDIA NVS 315 512MB Graphics

Form Factor

Low Profile:

2.713 inches in height × 5.7 inches in length Weight: ~142 grams

Graphics Controller

NVIDIA NVS 315 (using GF119-825 GPU) Number of Cores: 48 CUDA cores Max. Power: 19.3W Cooling Solution: Active fan heatsink

Bus Type

PCI Express x16, 2.0 compliant

Memory

Size: 1GB DDR3 Clock: 875MHz Memory Bandwidth: 14GB/s

Connectors

DMS-59 output Cables included:

- For CTO: DMS-59 to DVI cable

- For AMO: DMS-59 to DVI cable and DMS-59 to VGA cable

Maximum Resolution

Maximum number of displays supported: 2

Maximum Resolution Support:

- DMS-59 to VGA: 2048 x 1536 @ 85Hz

- DMS-59 to DVI: 1980 x 1200 @ 60Hz

- DMS-59 to DP: 2560 x 1600 @ 60Hz

Image Quality Features

See Display Output section.

The following video formats are supported:

QuickSpecs

HP Z840 Workstation

Technical Specifications – Graphics

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 45

- MPEG2

- MPEG4 Part 2 Advanced Simple Profile

- H.264 SVC codec support

- Support for 3D Blu Ray

- VC1

- DivX version 3.11 or later

A full range of video resolutions are supported including 1080p, 1080i, 720p, 480p and 480i. The NVS 315 GPU provides hardware acceleration for the computationally intensive parts of video processing, as well as provides improved video playback speeds via faster decode and transcode.

Display Output

Up to 2 displays using one of the following DMS-59 cables:

- DMS-59 to DVI

- DMS-59 to VGA

- DMS-59 to DP

DisplayPort output:

 Drives two DisplayPort enabled digital displays at resolutions up

to 2560 × 1600 at 60 Hz with reduced blanking, when connected via the DMS-59 to DP adapter.

DVI-D output:

 Drives two digital displays at resolutions up to 1920 × 1200 at 60

Hz with reduced blanking using DMS-59 to DVI-D single-link cable adaptor

VGA display output:

 Drives two analog displays at resolutions up to 2048 × 1536 at 85

Hz using DMS-59 to VGA cable adaptor.

Shading Architecture

Shader Model 5.0

Supported Graphics APIs

DX11, OpenGL 4.3

Available Graphics Drivers

Windows 8 Microsoft Windows 7 Professional (64-bit and 32-bit) Microsoft Windows XP Professional (64-bit and 32-bit) Red Hat Enterprise Linux(RHEL) SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit)

HP qualified drivers may be preloaded or the latest HP qualified drivers are available from the HP support Web site:

http://welcome.hp.com/country/us/en/support.html

SUSE Linux Enterprise drivers may also be obtained from: ftp://download.nvidia.com/novell or http://www.nvidia.com

NOTES:

1. The thermal solution used on this card is an active fan heatsink.

2. Factory configured graphics card includes DMS-59 to DVI cable.

3. Option kit graphics card includes DMS-59 to DVI and DMS-59 to

VGA cables (one each).

QuickSpecs

HP Z840 Workstation

Technical Specifications – Graphics

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 46

NVIDIA NVS 510 2GB Graphics

Form Factor

Low Profile, 2.713 inches × 6.3 inches, single slot

Graphics Controller

NVS 510 GPU Core Clock: 797 MHz Memory Clock: 891 MHz CUDA Cores: 192

Bus Type

PCI Express x16, Generation 2.0

Memory

2GB DDR3

Connectors

Four mini-DisplayPort. Four mini-DisplayPort to DisplayPort adapters included. (DisplayPort to DVI-D, DisplayPort to VGA, DisplayPort to HDMI, and DisplayPort to Dual-Link DVI adapters available as separate accessories)

Maximum Resolution

Mini-DisplayPort connectors support ultra-high-resolution panels (up to 3840 x 2160 @ 60Hz)

NOTE: This card supports up to four displays. For Windows XP, only 2 active displays are supported.

Image Quality Features

10-bit internal display processing, including hardware support for 10-bit scan-out

Display Output

DisplayPort with Multi-Stream Technology (MST) and High Bit Rate 2 (HBR2) support.

Digital Display Support

1. DisplayPort Output

 Drives four DisplayPort enabled digital display at resolutions up to

3840 × 2160 at 60 Hz with reduced blanking, when connected natively using the 4 DisplayPort connectors on the NVS 510 graphics card.

 DisplayPort Multi-Stream Topology (MST) Technology: Supports

various combinations of display resolutions and number of displays when using DisplayPort multi stream topology technology – up to a maximum of 4 monitors at a resolution of 1920 × 1200 at 60 Hz with reduced blanking.

2. DVI-D Output

 Drives four digital displays at resolutions up to 1920 × 1200 at 60

Hz with reduced blanking using DisplayPort to DVI-D single-link cable adaptors.

 Drives four digital displays at resolutions up to 2560× 1600 at 60

Hz with reduced blanking using DisplayPort to DVI-D dual-link cable adaptors.

HDMI Output

 The NVS 510 graphics board is capable of driving four high

definition (HD) panels up to resolutions of 1920 × 1080P at 60 Hz using DisplayPort to HDMI cable adaptors.

Analog Display Support

1. VGA display output

 Drives four analog displays at resolutions up to 1920 × 1200 at 60

Hz using DisplayPort to VGA cable adaptors.

QuickSpecs

HP Z840 Workstation

Technical Specifications – Graphics

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 47

Supported Graphics APIs

Full Microsoft DirectX 11, Shader Model 5.0 support Full OpenGL 4.3 support

Available Graphics Drivers

Genuine Windows 7 Professional (64-bit and 32-bit) Microsoft Windows XP Professional (64-bit and 32-bit) Red Hat Enterprise Linux(RHEL) 6 Desktop/Workstation SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit)

HP qualified drivers may be preloaded or available from the HP support Web site:

http://welcome.hp.com/country/us/en/support.html

NOTE: Heatsink cooler design is active.

Graphics Cable Adapters

Graphics Cable Adapter option choice is available starting Feb 1 2013 for the following graphics cards: NVS 310, Quadro 410, Quadro K5000, FirePro V3900, FirePro W7000

New Graphics Cards introduced after Feb 1 2013 will be eligible for choosing Graphics Cable Adapters, unless otherwise specified.

No cable choice for NVS 300, NVS 510.

Maximum number of cables allowed is 8.

NVIDIA Quadro K420 1GB Graphics

Form Factor

Low Profile:

2.713 inches × 6.3 inches, single slot

Graphics Controller

NVIDIA Quadro K420 GPU: GK107

Bus Type

PCI Express x16, 2.0 compliant

Memory

Size: 1GB DDR3 Clock: 891MHz Memory Bandwidth: 29GB/s

Connectors

One dual-link DVI-I connector One DisplayPort connector

Maximum Resolution

VGA (via adapter cable):

 2048 × 1536 × 32 bpp at 85 Hz

Dual-link DVI

 2560 × 1600 × 32 bpp at 60 Hz (reduced blanking)

Single-link DVI

 920 × 1200 × 32 bpp at 60 Hz (reduced blanking)

DisplayPort 1.2

 3840 × 2160 × 30 bpp at 60 Hz

RAMDAC

400 MHz integrated RAMDAC

Display Output

Maximum number of displays supported: 2

Shading Architecture

Shader Model 5.0

Supported Graphics APIs

DX11, OpenGL 4.4

QuickSpecs

HP Z840 Workstation

Technical Specifications – Graphics

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 48

Programming support for CUDA C, CUDA C++, DirectCompute 5.0, OpenCL, Python, and Fortran

Available Graphics Drivers

Microsoft Windows 8.1 Microsoft Windows 8 Microsoft Windows 7 Linux

1. Factory configured Quadro K420 does not include any video

adapters. Adapters must be ordered separately.

2. Option kit Quadro K420 includes one DP to DVI-D adapter.

NVIDIA Quadro K620 2GB Graphics

Form Factor

2.713” H x 6.3” L

Single Slot, Low Profile Full Height Profile bracket installed Low Profile bracket included Weight: 133 grams

Graphics Controller

NVIDIA Quadro K620 Graphics Card GM107 GPU 384 CUDA cores Max Power: 45 Watts

Bus Type

PCI Express 2.0 x16

Memory

2 GB GDDR3, 900 MHz 128-bit memory I/O path 29 GB/s memory bandwidth

Connectors

1 DL-DVI(I) output, 1 DisplayPort output Factory Configured: No video cable adapter included Option Kit: One DP-to-DVI adapter included with card

Additional DVI-to-VGA, DisplayPort-to-VGA or DisplayPort-to-DVI adapters are available as Factory Configuration or Option Kit accessories.

Maximum Resolution

DisplayPort 1.2:

- up to 4096x2160 x 30 bpp @ 60Hz

- supports High Bit Rate 2 (HBR2) and Multi-Stream Transport (MST)

Dual Link DVI(I) output:

- up to 2560 x 1600 x 32 bpp @ 60Hz

Single Link-DVI(I) output:

- up to 1920 x 1200 x 32 bpp @ 60Hz

Image Quality Features

10-bit internal display processing pipeline 10-bit scan-out support

Display Output

1 Dual-link DVI-I connector 1 Display Port connector

Shading Architecture

Full Microsoft DirectX 11.1 Shader Model 5.0

Supported Graphics APIs

OpenGL 4.4 DirectX 11.1 API support includes: CUDA C, CUDA C++, DirectCompute 5.0, OpenCL, Java, Python, and Fortran

Available Graphics Drivers

Microsoft Windows 8.1 Microsoft Windows 8 Microsoft Windows 7

QuickSpecs

HP Z840 Workstation

Technical Specifications – Graphics

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 49

Linux

HP qualified drivers may be preloaded or available from the HP support Web site:

http://welcome.hp.com/country/us/en/support.html

1. Factory configured Quadro K620 does not include a video cable

adapter. Video cable adapters must be ordered separately.

2. Quadro K620 offered as an Option Kit (AMO) includes one DP-to-

DVI video cable adapter. Additional cables must be ordered separately.

AMD FirePro W2100 2GB Graphics

Form Factor

Low Profile, half length (full-height bracket included)

Graphics Controller

AMD FirePro™ W2100 professional graphics based on Oland GPU.

GPU: 320 Stream Processors organized into 5 Compute Units GPU Frequency: 630MHz Power: 35W Cooling: Active

Bus Type

PCI Express® x8, Generation 3.0

Memory

2GB DDR3 memory Memory Bandwidth: 28.8 GB/s Memory Width:128bit

Connectors

2x Display Port 1.2 connectors

Factory Configured: No video cable adapter included Option Kit: One DP-to-DVI adapter included with card

Additional DisplayPort-to-VGA or DisplayPort-to-DVI adapters are available as Factory Configuration or Option Kit accessories.

Maximum Resolution

DisplayPort 1.2: up to 4096x2160 x 30 bpp @ 60Hz

Dual Link DVI(I) (requires adapter cable): up to 2560 x 1600 x 32 bpp @ 60Hz

Single Link-DVI(I)(requires adapter): up to 1920 x 1200 x 32 bpp @ 60Hz

VGA(requires adapter): up to 1920 x 1200 x 32 bpp @ 60Hz

Image Quality Features

Advanced support for 8-bit, 10-bit, and 16-bit per RGB color component. High bandwidth scaler for high quality up and downscaling.

Display Output

2 x DisplayPort® 1.2 Maximum number of displays: 2

Shading Architecture

Shader Model 5.0

Supported Graphics APIs

OpenCL™ 2.0, DirectX® 11.2/12 and OpenGL 4.4

Available Graphics Drivers

Windows 8.1 (64-bit and 32-bit) Windows 7 (64-bit and 32-bit) Linux

QuickSpecs

HP Z840 Workstation

Technical Specifications – Graphics

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 50

HP qualified drivers may be preloaded or available from the HP support Web site:

http://welcome.hp.com/country/us/en/support.html

NOTE: Depending on the card model, native DisplayPort™ connectors and/or certified DisplayPort™ active or passive adapters to convert your

monitor’s native input to your card’s DisplayPort™ or Mini-DisplayPort™ connector(s) may be required. See http://www.amd.com/firepro for details

AMD FirePro W5100 4GB Graphics

Form Factor

Full height, single slot (6.75” X 4.376”)

Graphics Controller

AMD FirePro W5100 graphics GPU Frequency: 930Mhz GPU: 768 Stream Processors organized into 12 Compute Units Power: <75 Watts Cooling: Active

Bus Type

PCI Express® x16, Generation 3.0

Memory

4GB GDDR5 memory Memory Bandwidth: up to 96 GB/s Memory Width: 128 bit

Connectors

4x Display Port 1.2 connectors with HBR2 and MST support.

Factory Configured: No video cable adapter included After market option kit: No video cable adapter included

Additional DisplayPort-to-VGA or DisplayPort-to-DVI adapters are available as Factory Configuration or Option Kit accessories.

Maximum Resolution

DisplayPort:

- 4096x2160 @24bpp 60Hz

Dual Link DVI:

- 2560x1600 (requires DP to DL-DVI adapter)

Single Link DVI:

- 1920x1200 (requires DP to DVI adapter)

VGA:

- 1920x1200 (requires DP to VGA adapter)

Image Quality Features

Advanced support for 8-bit, 10-bit, and 16-bit per RGB color component. High bandwidth scaler for high quality up and downscaling

Display Output

Max number of monitors supported using DisplayPort 1.2a:

- 4 direct attached monitors

- 6 using DP 1.2a with MST and HBR2 enabled monitors

Monitor chaining from a single DisplayPort (subject to a max of 6 total monitors across all outputs, requires use of DisplayPort enabled monitors supporting MST and HBR2):

- one 4096x2160 display

QuickSpecs

HP Z840 Workstation

Technical Specifications – Graphics

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 51

- two 2560x1600 displays

- four 1920x1200 displays

Shading Architecture

Shader Model 5.0

Supported Graphics APIs

OpenGL 4.4 OpenCL 1.2 and 2.0 DirectX 11.2 / 12 AMD Mantle

Available Graphics Drivers

Windows 8.1 / 8 (64-bit and 32-bit) Windows® 7 (64-bit and 32-bit) Linux

HP qualified drivers may be preloaded or available from the HP support Web site:

http://welcome.hp.com/country/us/en/support.html

Notes

1. AMD Eyefinity technology supports up to six DisplayPort™ monitors on

an enabled graphics card. Supported display quantity, type and resolution vary by model and board design; confirm specifications with manufacturer before purchase. To enable more than two displays, or multiple displays from a single output, additional hardware such as DisplayPort-ready monitors or DisplayPort 1.2 MST-enabled hubs may be required. A maximum of two active adapters is recommended for consumer systems. See www.amd.com/eyefinityfaq for full details.

NVIDIA Quadro K2200 2GB Graphics

Form Factor

4.38" H x 7.97" L Single Slot, Full Height

Weight:

240 grams

Graphics Controller

NVIDIA Quadro K2200 Graphics Card GM107 GPU 640 CUDA cores Max Power: 67.7 Watts

Bus Type

PCI Express 2.0 x16

Memory

4 GB GDDR5, 2500 MHz 128-bit memory I/O path 80 GB/s memory bandwidth

Connectors

1 DL-DVI(I) output, 2 DisplayPort outputs Factory Configured Option: No video cable adapter included Option Kit: One DP-to-DVI adapter included with card

Additional DVI-to-VGA, DisplayPort-to-VGA or DisplayPort-to-DVI adapters are available as accessories

Maximum Resolution

DisplayPort:

- up to 4096 x 2160 x 30 bpp @ 60Hz

- supports High Bit Rate 2 (HBR2) and Multi-Stream Transport (MST)

DL-DVI(I) output:

- up to 2560 x 1600 x 32 bpp @ 60Hz

Single Link-DVI(I) output:

- up to 1920 x 1200 x 32 bpp @ 60Hz

QuickSpecs

HP Z840 Workstation

Technical Specifications – Graphics

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 52

VGA (via adapter cable):

- 2048 × 1536 × 32 bpp at 85 Hz

Image Quality Features

12-bit internal display pipeline (hardware support for 12-bit scan-out on supported panels, applications and connection)

Stereoscopic 3D display support including NVIDIA® 3D Vision™ technology,

3D DLP, Interleaved, and passive stereo

Display Output

Maximum number of displays

- 3 direct attached monitors

- 4 using DP 1.2a with MST and HBR2 enabled monitors

Maximum number of DisplayPort displays possible (may require MST and/or HBR2):

- 4 1920x1200

- 4 2560x1600

- 2 4096x2160

Maximum number of monitors across all available Quadro K2200 outputs is 4. Shading Architecture

Full Microsoft DirectX 11.1 Shader Model 5.0

Supported Graphics APIs

OpenGL 4.4 DirectX 11.1 API support includes: CUDA C, CUDA C++, DirectCompute 5.0, OpenCL, Java, Python, and Fortran

Available Graphics Drivers

Microsoft Windows 8.1 Microsoft Windows 8 Microsoft Windows 7 Linux

HP qualified drivers may be preloaded or available from the HP support Web site:

http://welcome.hp.com/country/us/en/support.html

1. Quadro K2200 offered as Factory Configured Option does not

include a video cable adapter. Video cable adapters must be ordered separately.

2. Quadro K2200 offered as an Option Kit includes one DP-to-DVI

video cable adapter. Additional cables must be ordered separately.

3. A total maximum of 4 active monitors are supported across all

display output types. This may be accomplished by using daisy chained DisplayPort 1.2 displays or a DisplayPort 1.2 hub device.

4. A DisplayPort hub device may be used to connect multiple

DisplayPort monitors to a single Quadro K2200 DisplayPort output.

NVIDIA Quadro K4200 4GB Graphics

Form Factor

4.376” H x 9.5” L

Single Slot, Full Height Weight: ~461 grams (without extender)

QuickSpecs

HP Z840 Workstation

Technical Specifications – Graphics

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 53

Graphics Controller

NVIDIA Quadro K4200 Graphics Card Kepler GK104 GPU 1344 CUDA cores Max Power: 108 Watts

Bus Type

PCI Express 2.0 x16

Memory

4 GB GDDR5, 2700 MHz 256-bit memory I/O path 173 GB/s memory bandwidth

Connectors

1 DL-DVI(I) 2 DisplayPort 1.2a CTO: No video cable adapter included AMO: One DP-to-DVI adapter included with card

Additional DVI-to-VGA, DisplayPort-to-VGA or DisplayPort-to-DVI adapters are available as accessories

Maximum Resolution

DisplayPort:

- up to 3840 x 2160 x 30 bpp @ 60Hz

- supports High Bit Rate 2 (HBR2) and Multi-Stream Transport (MST)

DL-DVI(I) output:

- up to 2560 x 1600 x 32 bpp @ 60Hz

Single Link-DVI(I) output:

- up to 1920 x 1200 x 32 bpp @ 60Hz

VGA (via adapter cable):

- 2048 × 1536 × 32 bpp at 85 Hz

Image Quality Features

10-bit internal display processing (hardware support for 10-bit scanout for both windowed desktop and full screen, only available on Windows with Aero disabled and Linux)

NVIDIA® 3D Vision™ technology, 3D DLP, Interleaved, and other 3D stereo

format support

Full OpenGL quad buffered stereo support

Support for large-scale, ultra-high resolution visualization using the NVIDIA® SVS platform which includes NVIDIA® Mosaic, NVIDIA® Sync and NVIDIA® Warp/Blend technologies

Display Output

Maximum number of displays

- 3 direct attached monitors

- 4 using DP 1.2a with MST and HBR2 enabled monitors

Maximum number of DisplayPort displays possible (may require MST and/or HBR2):

- 4 1920x1200

- 4 2560x1600

- 2 3840x2160

Maximum number of monitors across all available Quadro K4200 outputs is 4.

QuickSpecs

HP Z840 Workstation

Technical Specifications – Graphics

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 54

Shading Architecture

Shader Model 5.0

Supported Graphics APIs

OpenGL 4.4 DirectX 11.1 API support includes: CUDA C, CUDA C++, DirectCompute 5.0, OpenCL, Java, Python, and Fortran

Available Graphics Drivers

Microsoft Windows 8.1 Microsoft Windows 8 Microsoft Windows 7 Linux

HP qualified drivers may be preloaded or available from the HP support Web site:

http://welcome.hp.com/country/us/en/support.html

NOTES: Quadro K4200 offered as CTO does not include a video cable adapter. Video cable adapters must be ordered separately. Quadro K4200 offered as AMO includes one DP-to-DVI video cable adapter. Additional cables must be ordered separately. A total maximum of 4 active monitors are supported across all display output types. This may be accomplished by using daisy chained DisplayPort 1.2 displays or a DisplayPort 1.2 hub device. A DisplayPort hub device may be used to connect multiple DisplayPort monitors to a single Quadro K4200 DisplayPort output.

NVIDIA Quadro K5200 8GB Graphics

Dimensions

4.376” H x 10.5” L

Dual Slot

Weight:

~880 grams (without extender)

Graphics Controller

NVIDIA Quadro K5200 GPU: GK110-850-B1 with 2304 CUDA cores Power: 150 Watts Bus Type

PCI Express 3.0 x16

Memory

Size: 8GB GDDR5 Memory bandwidth: 192GB/s Memory Width: 256-bit

Connectors

DVI-I (1), DVI-D (1), DP (2), Optional 3D Stereo bracket with 3-pin mini-DIN connector.

Factory configured option: No adapter included with card. Option Kit: No adaptor included with card.

DVI to VGA, DisplayPort to VGA, DisplayPort to DVI, and DisplayPort to Dual-Link DVI adapters available as accessories.

Maximum Resolution

DisplayPort:

- up to 4096 x 2160 x 30 bpp @ 60Hz

- supports High Bit Rate 2 (HBR2) and Multi-Stream Transport (MST)

DL-DVI(I) output:

QuickSpecs

HP Z840 Workstation

Technical Specifications – Graphics

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 55

- up to 2560 x 1600 x 32 bpp @ 60Hz

Single Link-DVI(I) output:

- up to 1920 x 1200 x 32 bpp @ 60Hz

VGA (via adapter cable):

- 2048 × 1536 × 32 bpp at 85 Hz

Image Quality Features

10-bit internal display processing (hardware support for 10-bit scanout for both windowed desktop and full screen, only available on Windows with Aero disabled and Linux).

NVIDIA® 3D Vision™ technology, 3D DLP, Interleaved, and other 3D stereo format support.

Full OpenGL quad buffered stereo support.

Support for NVIDIA® Quadro® Mosaic, NVIDIA® nView® multi-display technology, NVIDIA® Enterprise Management Tools.

Support for large-scale, ultra-high resolution visualization using the NVIDIA® SVS platform which includes NVIDIA® Mosaic, NVIDIA® Sync and NVIDIA® Warp/Blend technologies.

Display Output

Maximum number of displays

- 4 direct attached monitors

- 4 using DP 1.2a with MST and HBR2 enabled monitors

Maximum number of DisplayPort displays possible (may require MST and/or HBR2):

- 4 1920x1200

- 4 2560x1600

- 2 4096x2160

Maximum number of monitors across all available Quadro K5200 outputs is 4.

Shading Architecture

Shader Model 5.0

Supported Graphics APIs

OpenGL 4.4 DirectX 11

API support for NVIDIA’s CUDA™ C, CUDA C++, DirectCompute 5.0, OpenCL,

Java, Python, Fortran

Available Graphics Drivers

Windows 8.1 Windows 8 Windows 7 Linux - Full OpenGL implementation, complete with NVIDIA and ARB extensions

HP qualified drivers may be preloaded or available from the HP support Web site:

http://welcome.hp.com/country/us/en/support.html

QuickSpecs

HP Z840 Workstation

Technical Specifications – Graphics

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 56

NOTES:

1. Factory configured Quadro K5200 does not include a video cable

adapter. Video cable adapters must be ordered separately.

2. A total maximum of 4 active monitors are supported across all

display output types. This may be accomplished by using daisy chained DisplayPort 1.2 displays (displays must support MST and HBR2).

NVIDIA Quadro K6000 12GB Graphics

Form Factor

4.376” H x 10.5” L

Dual Slot Power: 234 Watts

Weight:

~880 grams

Graphics Controller

NVIDIA Quadro K6000 Graphics Card based on the GK180 GPU Core Count: 2880 Base Clock: 797 MHz Boost Clock: 902 MHz

Bus Type

PCI Express 3.0 x16

Memory

12GB GDDR5 384-bit memory I/O path 288 GB/s memory bandwidth ECC Memory

Connectors

DVI-I (1), DVI-D (1), DP (2), Optional 3D Stereo bracket with 3-pin mini-DIN connector.

Factory configured option: No adapter included with card. Option Kit: No adaptor included with card.

DVI to VGA, DisplayPort to VGA, DisplayPort to DVI, and DisplayPort to DualLink DVI adapters available as accessories.

Image Quality Features

 DisplayPort with Multi-Stream Technology (MST) and High Bit Rate

2 (HBR2), HDMI 1.4, and HDCP support

 NVIDIA 3D Vision™ technology  NVIDIA Premium Mosaic and nView

Display Output

400 MHz integrated RAMDAC

 Maximum resolution over VGA (through DVI to VGA cable): 2048 ×

1536 × 32 bpp at 85 Hz

Dual-link internal TMDS (DVI 1.0)

 Maximum resolution over digital port (single GPU and SLI mode):

2560 × 1600 × 32 bpp at 60 Hz (reduced blanking)

Single-link internal TMDS (DVI 1.0)

 Maximum resolution over digital port (single GPU and SLI

mode):1920 × 1200 × 32 bpp at 60 Hz (reduced blanking)

QuickSpecs

HP Z840 Workstation

Technical Specifications – Graphics

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 57

DisplayPort with MST and HBR2.

 Maximum resolution: 3840 × 2160 × 36 bpp at 60Hz

HDMI

 Maximum resolution: 1920 × 1080 × 32 bpp at 60Hz

Shading Architecture

Shader Model 5.0 Full IEEE 764-2008 32-bit and 64-bit precision

Supported Graphics APIs

Full OpenGL 4.3 Full DirectX 11 CUDA API support includes: CUDA C, CUDA C++, DirectCompute 5.0, OpenCL, Java, Python, and Fortran

Available Graphics Drivers

Windows 8 Windows 7 Professional (64-bit and 32-bit) Red Hat Enterprise Linux (RHEL) 6 Desktop/Workstation SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit)

HP qualified drivers may be preloaded or available from the HP support Web site:

http://welcome.hp.com/country/us/en/support.html

Novell SUSE Linux Enterprise drivers may also be obtained from: ftp://download.nvidia.com/novell or http://www.nvidia.com

NOTES:

NVIDIA GRID VGX Pass Through feature supported on NVIDIA Quadro K6000 to enable direct mapping of GPU to Virtual Machine. No display output adapter included.

AMD FirePro W7100 8GB Graphics

Form Factor

Full height, single slot (9.5” X 4.376”)

Graphics Controller

AMD FirePro W7100 graphics GPU: 1792 Stream Processors organized into 28 Compute Units Power: <75 Watts Cooling: Active

Bus Type

PCI Express® x16, Generation 3.0

Memory

8GB GDDR5 memory Memory Bandwidth: up to 176 GB/s Memory Width: 256 bit

Connectors

4x Display Port 1.2a connectors with HBR2 and MST support.

Factory Configured: No video cable adapter included After market option kit: No video cable adapter included

QuickSpecs

HP Z840 Workstation

Technical Specifications – Graphics

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 58

Additional DisplayPort-to-VGA or DisplayPort-to-DVI adapters are available as Factory Configuration or Option Kit accessories.

Maximum Resolution

DisplayPort:

- 4096x2160 @24bpp 60Hz

Dual Link DVI:

- 2560x1600 (requires DP to DL-DVI adapter)

Single Link DVI:

- 1920x1200 (requires DP to DVI adapter)

VGA:

- 1920x1200 (requires DP to VGA adapter)

Image Quality Features

Advanced support for 8-bit, 10-bit, and 16-bit per RGB color component. High bandwidth scaler for high quality up and downscaling

Display Output

Max number of monitors supported using DisplayPort 1.2a:

- 4 direct attached monitors

- 6 using DP 1.2a with MST and HBR2 enabled monitors

Monitor chaining from a single DisplayPort (subject to a max of 6 total monitors across all outputs, requires use of DisplayPort enabled monitors supporting MST and HBR2):

- one 4096x2160 display

- two 2560x1600 displays

- four 1920x1200 displays

Shading Architecture

Shader Model 5.0

Supported Graphics APIs

OpenGL 4.4 OpenCL 1.2 and 2.0 DirectX 11.2 / 12 AMD Mantle

Available Graphics Drivers

Windows 8.1 / 8 (64-bit and 32-bit) Windows® 7 (64-bit and 32-bit) Linux

HP qualified drivers may be preloaded or available from the HP support Web site:

http://welcome.hp.com/country/us/en/support.html

Notes

1. AMD Eyefinity technology supports up to six DisplayPort™ monitors on an enabled graphics card. Supported display quantity, type and resolution vary by model and board design; confirm specifications with manufacturer before purchase. To enable more than two displays, or multiple displays from a single output, additional hardware such as DisplayPort-ready monitors or DisplayPort 1.2 MST-enabled hubs may be required. See www.amd.com/eyefinityfaq for full details.

2. OpenGL 4.4 support available with driver 14.301.xxx or later.

3. OpenCL 2.0 support planned in driver updates for early 2015.

4. For HP Z440 Workstation configurations, the HP Z4 Fan and Front Card

QuickSpecs

HP Z840 Workstation

Technical Specifications – Graphics

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 59

Guide Kit, which is available both CTO (G8T99AV) and AMO (J9P80AA), is required.

NVIDIA Quadro M6000 12GB Graphics

Form Factor

4.42” H x 10.5” L

Dual Slot Power: 250 Watts Weight: ~1030 grams

Graphics Controller

NVIDIA Quadro M6000 Graphics Card based on the GM200 GPU Core Count: 3072 Base Clock: 1026 MHz Boost Clock: 1152 MHz Idle Clock: 324 MHz

Bus Type

PCI Express 3.0 x16

Memory

12GB GDDR5 384-bit memory I/O path 317 GB/s memory bandwidth ECC Memory (disabled by default)

Connectors

DP (x4) DL-DVI(I) 3-pin mini-DIN connector SLI connector Quadro Sync connector One 8-pin auxiliary power connector

Factory configured option: No adapter included with card. Option Kit: No adaptor included with card.

DVI to VGA, DisplayPort to VGA, DisplayPort to DVI, and DisplayPort to Dual-Link DVI adapters available as accessories.

Image Quality Features

• DisplayPort with Multi-Stream Technology (MST) and High Bit Rate 2 (HBR2), HDMI 1.4, and HDCP 1.3 support

• NVIDIA 3D Vision™ technology

• NVIDIA Premium Mosaic and nView

Display Output

400 MHz integrated RAMDAC

● Maximum resolution over VGA (through DVI to VGA cable): 2048 × 1536 × 32 bpp at 85 Hz

Dual-link internal TMDS (DVI 1.0)

● Maximum resolution over digital port (single GPU and SLI mode): 2560 × 1600 × 32 bpp at 60 Hz (reduced blanking)

Single-link internal TMDS (DVI 1.0)

● Maximum resolution over digital port (single GPU and SLI mode):1920 × 1200 × 32 bpp at 60 Hz (reduced blanking)

DisplayPort 1.2 with MST and HBR2.

● Maximum pixel clock: 592 MPixel/s

QuickSpecs

HP Z840 Workstation

Technical Specifications – Graphics

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 60

● Maximum bandwidth: 17.2 Gbps

● Example maximum resolution: 4096 × 2160 × 30 bpp at 60Hz

HDMI

● Maximum resolution: 4096 × 2160 × 8 bpp at 60Hz

Shading Architecture

Shader Model 5.0

Supported Graphics APIs

Full OpenGL 4.4 Full DirectX 12 API support includes: CUDA C, CUDA C++, DirectCompute 5.0, OpenCL, Java, Python, and Fortran

Available Graphics Drivers

Windows 8.1 Windows 8 Windows 7 Professional Linux

HP qualified drivers may be preloaded or available from the HP support Web site:

http://www8.hp.com/us/en/drivers.html

Notes

1. NVIDIA GRID VGX Pass Through feature supported on NVIDIA Quadro M6000 to enable direct mapping of GPU to Virtual Machine.

2. No display output adapter included.

3. For HP Z840 Workstation configurations, the 1125W power supply option must be used.

QuickSpecs

HP Z840 Workstation

Technical Specifications – High Performance GPU Computing

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 61

NVIDIA Tesla K40 Workstation Compute Processor

Form Factor

Size: 4.376 inches by 10.5 inches Slots: Dual Slot Power Connectors: One 6-pin and one 8-pin Weight: ~826 grams

System Interface

PCI Express Gen3 ×16

Video Outputs

None.

Memory

12GB GDDR5, memory path: 384-bit memory clock: 3Ghz

Peak Memory Bandwidth

288 GB/s

Supported APIs

CUDA, OpenACC, OpenCL 1.2 API support includes: C, C++, Java, Python, and Fortran

Supported Operating Systems

Windows 8 (64-bit) Genuine Windows 7 Professional (64-bit) Red Hat Enterprise Linux (RHEL) 5, 6 Desktop/Workstation (64-bit) SUSE Linux Enterprise Desktop 11 (64-bit)

HP qualified drivers may be preloaded or available from the HP support Web site:

http://welcome.hp.com/country/us/en/support.html

Novell SUSE Linux Enterprise drivers may also be obtained from: ftp://download.nvidia.com/novell or http://www.nvidia.com

Processor Cores

GK110B GPU Base Clock: 745 MHz Boost Clock: up to 875 Mhz 2888 CUDA cores

Power Consumption

~235 Watts

Note 1: A 1125W PSU is required for any K40 configuration on the Z820

HIGH PERFORMANCE GPU COMPUTING

QuickSpecs

HP Z840 Workstation

Technical Specifications - Optical and Removable Storage

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 62

HP 9.5mm Slim SuperMulti DVD Writer

Description

9.5mm height, tray-load

Mounting Orientation

Either horizontal or vertical

Interface Type

SATA/ATAPI

Dimensions (WxHxD)

128 x 9.5 x 127mm

Supported Media Types

DVD-RAM DVD+R DVD+RW DVD+R DL DVD-R DL DVD-R DVD-RW CD-R CD-RW

Disc Capacity

DVD-ROM

8.5 GB DL or 4.7 GB standard

Full Stroke DVD

< 200 ms (seek)

Full Stroke CD

< 200 ms (seek)

Maximum Data Transfer Rates

CD ROM Read

CD-ROM, CD-R Up to 24X CD-RW Up to 24X

DVD ROM Read

DVD-RAM Up to 8X DVD+RW Up to 8X DVD-RW Up to 8X DVD+R DL Up to 8X DVD-R DL Up to 8X DVD-ROM Up to 8X DVD-ROM DL Up to 8X DVD+R Up to 8X DVD-R Up to 8X

Power

Source

SATA DC power receptacle

DC Power Requirements

5 VDC ± 5%-100 mV ripple p-p

DC Current

5 VDC -< 800 mA typical, <1600 mA maximum

Operating Environmental (all conditions noncondensing)

Temperature

41° to 122° F (5° to 50° C)

Relative Humidity

10% to 80%

Maximum Wet Bulb Temperature

84° F (29° C)

Operating Systems Supported

Windows 8.1, Windows 8 32-bit and 64-bit, Windows 7 Professional 32-bit and 64-bit, Windows Vista Business 64*, Windows Vista Business 32*, Windows Vista Home Basic 32*, Windows 2000, Windows XP Professional or Windows XP Home 32*. Red Hat Enterprise Linux(RHEL) WS4**, 5, 6 Desktop/Workstation SUSE Linux Enterprise Desktop 10 & 11

No driver is required for this device. Native support is provided by the operating system.

OPTICAL AND REMOVABLE STORAGE

QuickSpecs

HP Z840 Workstation

Technical Specifications - Optical and Removable Storage

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 63

Kit Contents

9.5mm Slim SuperMulti DVD Writer, 5.25" ODD Bay adapter/carrier, slim SATA data/power cable, installation guide

HP 9.5mm Slim DVD-ROM Drive

Description

9.5mm height, tray-load

Mounting Orientation

Either horizontal or vertical

Interface Type

SATA / ATAPI

Dimensions (WxHxD)

128 x 9.5 x 127mm

Disc Capacity

DVD-ROM

Single layer: Up to 4.7 GB Double layer: Up to 8.5 GB

Access Times

DVD-ROM Single Layer

< 110 ms (typical)

CD-ROM Mode 1

< 110 ms (typical)

Full Stroke DVD

< 230 ms (typical)

Full Stroke CD

< 220 ms (typical)

Power

Source

SATA DC power receptacle

DC Power Requirements

5 VDC ± 5%-100 mV ripple p-p

DC Current

5 VDC – <800mA typical, < 1600 mA maximum

Operating Environmental (all conditions noncondensing)

Temperature

41° to 122° F (5° to 50° C)

Relative Humidity

10% to 80%

Maximum Wet Bulb Temperature

84° F (29° C)

Operating Systems Supported

No driver is required for this device. Native support is provided by the operating system.

Kit Contents

9.5mm Slim DVD-ROM Drive, 5.25" ODD Bay adapter/carrier, slim SATA data/power cable, installation guide

HP 9.5mm Slim BDXL BluRay Writer

Description

9.5mm height, tray-load

Mounting Orientation

Either horizontal or vertical

Interface Type

SATA/ATAPI

Dimensions (WxHxD)

128 x 9.5 x 127mm

Supported Media Types

BD-ROM BD-R BD-RE DVD-RAM DVD+R DVD+RW DVD+R DL DVD-R DL

QuickSpecs

HP Z840 Workstation

Technical Specifications - Optical and Removable Storage

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 64

DVD-R DVD-RW CD-R CD-RW

Disc Capacity

DVD-ROM

8.5 GB DL or 4.7 GB standard

Blu-ray

25 GB (single-layer) 50 GB (dual-layer) 100/128 GB (BDXL)

Full Stroke DVD

< 230 ms (seek)

Full Stroke CD

< 220 ms (seek)

Blu-ray

< 230 ms (seek) (Full Stroke Blu-ray)

Startup Time

(Time to drive ready from tray loading) BD-ROM (SL/DL) 25S / 28S BD-R (SL/DL) 25S / 28S BD-RE (SL/DL) 25S / 28S DVD-ROM (SL/DL) 18S / 18S DVD-R (SL/DL) 25S / 25S DVD-RW 25S DVD+R (SL/DL) 25S / 25S DVD+RW 25S DVD-RAM 45S CD-ROM 15S

Maximum Data Transfer Rates

CD ROM Read

CD-ROM, CD-R Up to 24X CD-RW Up to 24X

DVD ROM Read

DVD-RAM Up to 8X DVD+RW Up to 8X DVD-RW Up to 8X DVD+R DL Up to 8X DVD-R DL Up to 8X DVD-ROM Up to 8X DVD-ROM DL Up to 8X DVD+R Up to 8X DVD-R Up to 8X

Blu-ray

BD-ROM Up to 6X BD-ROM DL Up to 6X BD-R Up to 6X BD-R DL Up to 6X BD-R Up to 6X BD-RE SL/DL Up to 6X

Power

Source

SATA DC power receptacle

DC Power Requirements

5 VDC ± 5%-100 mV ripple p-p

DC Current

5 VDC -900 mA typical, 2000mA maximum

Operating Environmental (all conditions noncondensing)

Temperature

41° to 122° F (5° to 50° C)

Relative Humidity

10% to 80%

Maximum Wet Bulb Temperature

84° F (29° C)

Operating Systems

Windows 8.1, Windows 8 32-bit and 64-bit, Windows 7 Professional 32-bit

QuickSpecs

HP Z840 Workstation

Technical Specifications - Optical and Removable Storage

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 65

Supported

and 64-bit, Windows Vista Business 64*, Windows Vista Business 32*, Windows Vista Home Basic 32*, Windows 2000, Windows XP Professional or Windows XP Home 32*. Red Hat Enterprise Linux(RHEL) WS4**, 5, 6 Desktop/Workstation SUSE Linux Enterprise Desktop 10 & 11

No driver is required for this device. Native support is provided by the operating system.

Kit Contents

9.5mm Slim BDXL Blu-Ray Writer, 5.25" ODD Bay adapter/carrier, slim SATA data/power cable, installation guide

As Blu-ray is a new format containing new technologies, certain disc, digital connection, compatibility and/or performance issues may arise, and do not constitute defects in the product. Flawless playback on all systems is not guaranteed. In order for some Blu-ray titles to play, they may require a DVI or HDMI digital connection and your display may require HDCP support. HD-DVD movies cannot be played on this workstation.

HP DX115 Removable Drive Enclosure

Interface Type

Compatible with SAS or SATA controllers. Offers 6Gb/s performance when used with 6Gb/s HDDs.

Dimensions (WxHxD)

147.6 x 41.1 x 205 mm (5.81 x 1.62 x 8.08 in)

Weight

Frame and Carrier: 1.73 kg (3.8 lbs.) Carrier: 0.45 kg (1 lbs.)

HP 15-in-1 Media Card Reader

Description

Supports hardware ECC (Error Correction Code) function Supports hardware CRC (Cyclic Redundancy Check) function Supports MS 4-bit parallel transfer mode Supports MS-PRO 4-bit parallel transfer mode Supports MS PRO-HG Duo 4-bit parallel transfer mode Supports SD 4-bit parallel transfer mode Supports UHS-104 SD 4-bit card (version 3.0) Supports CF v6.0 with PIO mode 6 and Ultra DMA 7 mode

Interface Type

USB 3.0 High-speed interface

NOTE: If there is a USB2 connection, USB2 transfer speeds are supported.

Dimensions (WxHxD)

4.9 x 4 x 1 in (124.5 x 101.6 x 25.4 mm) Fits conveniently in the 5.25" drive bay.

Supported Media Types

CompactFlash Type I CompactFlash Type II Microdrive Secure Digital Card (SD) Secure Digital High Capacity (SDHC) SD Extended Capacity Memory Card (SDXC) SD Ultra High Speed II(SD UHSII) Memory Stick Memory Stick Select Memory Stick Duo (MS Duo) Memory Stick PRO (MS PRO) Memory Stick PRO Duo (MS PRO Duo) Memory Stick PRO-HG Duo MagicGate Memory Stick (MG)

QuickSpecs

HP Z840 Workstation

Technical Specifications - Optical and Removable Storage

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 66

MagicGate Memory Stick Duo

These additional media types are supported with a card adapter. Memory Stick Micro (M2) miniSD miniSD High Capacity Micro SD Memory Card (MicroSD) Micro SD High Capacity Memory Card (MicroSDHC)

Test Parameters/Conditions - Power applied, unit operating on system ±5%

Operating Systems Supported

Windows 8 Pro (64-bit)* Windows 8.1 (64-bit)* Windows 8 (64-bit)* Windows 7 Professional (32-bit)** Windows 7 Professional (64-bit)** Windows Vista Business 64 Windows Vista Business 32 Windows Vista Home Basic 32 Windows XP Professional Windows XP Home 32 No driver is required for this device. Native support is provided by the operating system.

Not all features are available in all editions of Windows 8. Systems may require upgraded and/or separately purchased hardware, drivers and/or software to take full advantage of Windows 8 functionality. See

http://www.microsoft.com.

Not all features are available in all editions of Windows 7. This system may require upgraded and/or separately purchased hardware to take full advantage of Windows 7 functionality. Seehttp://www.microsoft.com/windows/windows-7/ for details.

Kit Contents

Media card reader, 5.25" bracket/rails/bezel, Install Guide, IO & Security Software and Documentation CD

Approvals

USB-IF, WHQL, Compliant with USB Mass Storage Class Bulk only Transport Specification Rev. 1.0, Compliant Intel Front Panel I/O Connectivity Design Guide V. 1.3, FCC, CE, BSMI, C-Tick, VCCI, MIC, cUL, TUVT

Weight

0.35 lbs. (0.16 kg)

QuickSpecs

HP Z840 Workstation

Technical Specifications - Controller Cards

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 67

HP IEEE 1394b FireWire PCIe Card

Data Transfer Rate

Supports up to 800 Mb/s

Devices Supported

IEEE-1394 compliant devices

Bus Type

PCIe card full height PCIe slots

Ports

Two IEEE-1394b external 9-Pin connectors (Rear)

Internal Connectors

One 10-Pin header connector

System Requirements

Windows 8.1 64-bit, Windows 7 Professional 32-bit and 64-bit, SLED 11 and RHEL 6. Intel i5 series or higher processor, min 2GB of RAM, 20GB Hard Drive, CD-ROM drive, built in sound system, Available PCIe slot.

Temperature – Operating

50° to 131° F (10° to 55° C)

Temperature – Storage

-22° to 140° F (-30° to 60° C)

Relative Humidity – Operating

20% to 80%

Compliances

FCC Part 15B, cULus 60950, CE Mark EN55022B(1995)/EN55024-1998 STD, Taiwan BSMI CNS13438, Korea MIC

Operating Systems Supported

Windows 8.1 64-bit, Windows 7 Professional 32-bit and 64-bit

HP Thunderbolt-2 PCIe 1port I/O Card

Data Transfer Rate

Supports up to 20 Gb/s (20,000 Mb/s)

Devices Supported

Thunderbolt™ certified devices

Bus Type

PCIe card, full or half height PCIe slots

Ports

One Thunderbolt™ 2 external 20-Pin output connectors (Rear) One full size DisplayPort input connector (Rear)

Internal Connectors

One 5-Pin header connector

System Requirements

Genuine Windows 7 Professional 64-bit, Genuine Windows 8.1 64-bit, Intel i5 series or higher processor, 4-GB RAM, 20-GB Hard Drive, available PCIe slot.

Temperature - Operating

50° to 131° F (10° to 55° C)

Temperature - Storage

-22° to 140° F (-30° to 60° C)

Relative Humidity Operating

20% to 80%

Compliances

FCC Part 15B, cULus 60950, CE Mark EN55022B(1995)/EN55024-1998 STD, Taiwan BSMI CNS13438, Korea MIC

Operating Systems Supported

Genuine Windows 7 Professional 64-bit, Genuine Windows 8.1 64-bit.

Kit Contents

HP Thunderbolt™ 2 PCIe 1-port I/O Card, full height and half height bracket, DisplayPort to DisplayPort cable, internal header cables (2), user documentation and warranty card.

CONTROLLER CARDS

QuickSpecs

HP Z840 Workstation

Technical Specifications - Networking and Communications

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 68

HP X520 10GbE Dual Port Adapter

Hardware Certifications

FCC B, UL, CE, VCCI, BSMI, CTICK, KCC

HP 10GbE SFP+ SR Transceiver

Operating Temperature

0C to 45C (32F to 113F)

Operating Humidity

0% to 85%, noncondensing

Dimensions (H x W x D)

0.47(h) x 0.54(w) x 2.19(d)inches (1.19 x 1.38 x 5.57 cm)

Intel 7260 802.11 a/b/g/n PCIe WLAN NIC

Operating Humidity

Operating 10% to 90% (non-condensing) Non-operating 5% to 95% (non-condensing)

Dimensions (H x W x D)

Native HMC: 26.8 x 30.0 x 2.4 mm Carrier Card Assembly 3.3 x 4.7 in (84 x 119 mm)

Kit Contents

PCIe x1 card with full height bracket, rf antenna, antenna cable, separate low profile bracket, software CD and warranty.

NOTES:

1. WLAN supplier's client utility is required for Cisco Compatible Extensions support with

Microsoft Windows XP. WLAN may also be compatible with certain third-party software supplicants. WLAN supplier IHV extensions required for Cisco Compatible Extensions support for Microsoft Windows Vista.

2. Check latest software/driver release for updates on supported security features.

3. Maximum output power may vary by country according to local regulations.

4. In Power Save Polling mode and on battery power.

5. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CCK modulation)

and a packet error rate of 10% for

6. 802.11a/g (OFDM modulation).

Integrated Intel I210AT PCIe GbE Controller

Connector

RJ-45 (motherboard integration)

Controller

Intel I210 GbE platform LAN connect networking controller

Memory

Programmable FIFO packet buffer memory Tx 24KB default Rx up to 16KB

Data Rates Supported

10/100/1000 Mbps

Compliance

802.1as, 802.1q, 802.1Q, 802.3, 802.3ab, 802.3ap, 802.3az, 802.3u,

802.3x, 802.3z

Bus Architecture

PCI Express 2.1 (x1) and SMBus

Data Transfer Mode

PCIe-based interface for active state operation (S0 state) and SMBus for host and management traffic (Sx low power state)

Power Requirement

Requires 3.3V only (integrated regulators)

Boot ROM Support

Yes

Network Transfer Mode

Full-duplex; Half-duplex (not supported for the 1000BASE-T transceiver)

Network Transfer Rate

10BASE-T (half-duplex) 10 Mbps 10BASE-T (full-duplex) 20 Mbps 100BASE-TX (half-duplex) 100 Mbps 100BASE-TX (full-duplex) 200 Mbps

NETWORKING AND COMMUNICATIONS

QuickSpecs

HP Z840 Workstation

Technical Specifications - Networking and Communications

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 69

1000BASE-T (full-duplex) 2000 Mbps

Management Capabilities

WOL, auto MDI crossover, PXE, Multi-port teaming, RSS, Advanced cable diagnostics

Integrated Intel I218LM PCIe GbE Controller

Connector

RJ-45 (motherboard integration)

Controller

Intel I218LM GbE platform LAN connect networking controller

Memory

3 KB FIFO packet buffer memory (both Tx and Rx)

Data Rates Supported

10/100/1000 Mbps

Compliance

802.1as, 802.1p, 802.1Q, 802.3, 802.3ab, 802.3az, 802.3i, 802.3u, 802.3x,

802.3z

Bus Architecture

PCI Express 1.1 (x1) and SMBus

Data Transfer Mode

PCIe-based interface for active state operation (S0 state) and SMBus for host and management traffic (Sx low power state)

Power Requirement

Requires 3.3V only (integrated regulators)

Boot ROM Support

Yes

Network Transfer Mode

Full-duplex; Half-duplex (not supported for the 1000BASE-T transceiver)

Network Transfer Rate

10BASE-T (half-duplex) 10 Mbps 10BASE-T (full-duplex) 20 Mbps 100BASE-TX (half-duplex) 100 Mbps 100BASE-TX (full-duplex) 200 Mbps 1000BASE-T (full-duplex) 2000 Mbps

Management Capabilities

WOL, auto MDI crossover, PXE, Multi-port teaming, RSS, Advanced cable diagnostics AMT 9.1 support, vPro compliant

HP 361T PCIe Dual Port Gigabit NIC

Connector

Two RJ-45

Controller

Intel® Ethernet I350 Controller

Data Rates Supported

10/100/1000 Mbps, Half- and full-duplex

Compliance

802.3, 802.3u, 802.3x, 802.3ab, 802.3ad, 802.1p, 802.1Q, 802.3az, IEEE 1588 PCIe v2.0 standard RoHS (6 of 6) FCC (U.S. only) Class B DOC (Canada) Class B CE EN 55024, EN55022 Class B VCCI Class II UL 1950 CSA 950 EN 60950 CE ACPI 1.1a Microsoft WHQL (Windows Hardware Quality Labs)

Data Path Width

Four lane (x4) PCI Express compatible with x4, x8, and x16 PCI Express slots

Power Requirement

4.1W idle without EEE link partner

3.2W idle with EEE link partner

4.2W maximum

Network Transfer Rate

10BASE-T (half-duplex) 10 Mb/s 10BASE-T (full-duplex) 20 Mb/s 100BASE-TX (half-duplex) 100 Mb/s

QuickSpecs

HP Z840 Workstation

Technical Specifications - Networking and Communications

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 70

100BASE-TX (full-duplex) 200 Mb/s 1000BASE-T (full-duplex) 2000 Mb/s Operating Temperature

32° to 131° F (0° to 55° C )

Operating Humidity

10% to 95% non-condensing

Dimensions (H x W x D)

5.3 x 2.5 in (13.50cm x 6.4 cm) (without brackets)

Operating System Driver Support

Windows 7 Professional 32-bit and 64-bit. Red Hat Enterprise Linux(RHEL) WS4, 5, 6 Desktop/Workstation Novell SLED 10 & SLED 11

Kit Contents

HP 361T PCIe Dual Port Gigabit NIC PCA with a standard height bracket attached to it (the low profile bracket is included in the clamshell that the PCA ships in) Product Warranty statement and the Quick Install Card (QIC).

Intel X540-T2 10GbE Dual Port Adapter

Operating Temperature

32° to 131° F (0° to 55° C)

Operating Humidity

5% to 95% non-condensing

Dimensions (H x W x D)

Standard PCIe with full height bracket installed, half height bracket included.

0.7 x 2.7 x 6.0 in

Operating System Driver Support

The HP driver drop is a unified package that includes the X540-T2 driver. It is the same driver as is used for the 561T. Currently, it includes drivers for Win7-32, Win7-x64, Win8-x64, and Win81-x64.

Kit Contents

Intel X540 10Gb Ethernet Dual port adapter, Installation guide, Warranty card.

Windows Server 2012 R2, Windows Server 2012, Windows 8, Windows Server 2008 R2, Windows 7, Windows Server 2008 SP2, Windows Vista SP2, Windows Server 2003 R2, Windows Server 2003 SP2, Linux Stable Kernel version 3.x, 2.6,x, Red Hat Enterprise Linux 5, 6, SUSE Linux Enterprise Server 10, 11, FreeBSD 9, VMware ESX/ESXi. Note: Not all OS's supported on all HP Z Workstations.

QuickSpecs

HP Z840 Workstation

Summary of Changes

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 71

Date of change:

Version History:

Description of change:

August 21, 2014

Added

Style and technical specifications

October 24, 2014

From v1 to v2

Added

note to supported components: memory, Foxit PhantomPDF Express and Cyberlink Power2Go: software, Optical drives: DVD, BD-XL specs

November 1, 2014

From v2 to v3 Added

Note for Internal USB connector conversion, Overview,

Changed

Internal USB statement in Overview and System Board sections

December 1, 2014

From v3 to v4

Added

Intel X540-T2 10GbE Dual Port Adapter, HP 4-in-1 SFF (2.5in) HDD Carrier

January 1, 2015

From v4 to v5 Added

RHEL for Preinstalled OS, AMD FirePro W7100, Tesla K40 to GPU and High Performance Computing; Ubuntu 14.04 for Supported Components

Changed

Memory Load Order, High Performance Computing for K40

February 1, 2015

From v5 to v6

Added

Windows 8.1 Pro 64-bit OS, Red Hat Enterprise Linux (RHEL), HP DX115 Removable HDD Carrier, and notes, 4-Bay SAS-SATA and notes, HP 4-Bay SAS-SATA 2.5in High Density Storage Kit

Changed

Overview OS, Processors table Power Supply table, Hard Drives Notes, Optical and Removable Storage order, Power Consumption and Chassis Fan

Removed

Windows 7 Professional 64-bit (National Academic)

March 1, 2015

From v6 to v7

Added

Overview: RAID support. Supported Components, Hard Drives: New SAS SFF 15 HDD line and notes, 4TB SATA HDD

Changed

SAS, and SATAHDD Description Notes. System Board: Memory section.

April 1, 2015

From v7 to v8

Added

NVIDIA Quadro M6000 12GB Graphics, Memory notes

Changed

Memory from Supported Components, Memory Speed Supported from System Board, ACPI version updated in BIOS section.

SUMMARY OF CHANGES

QuickSpecs

HP Z840 Workstation

c04400043 — DA – 15098 — Worldwide — Version 8 — April 1, 2015

Page 72

© 2014 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. Intel, Xeon, and Thunderbolt are trademarks of Intel Corporation in the U.S. and other countries. Microsoft and Windows are U.S. registered trademarks of Microsoft Corporation. Red Hat is a registered trademark of Red Hat, Inc. in the United States and other countries. Firewire is a trademark of Apple Inc. Linux® is the registered trademark of Linus Torvalds in the U.S. and other countries.

HP Z840 Workstation User Manual [ru]

Specifications and Main Features

Frequently Asked Questions

User Manual

Overview

Supported Components

System Technical Specifications

Stable & Consistent Offerings

Technical Specifications - Processors

Technical Specifications – Storage Hard Drives

Technical Specifications - Hard Drive Controllers

Technical Specifications – Graphics

Technical Specifications – High Performance GPU Computing

Technical Specifications - Optical and Removable Storage

Technical Specifications - Controller Cards

Technical Specifications - Networking and Communications

Summary of Changes
