Current Service Notes for HP OmniBooks. 13 June 2000

Product Service note Category Time Required Bios Description Date

Ob 800

800-01 Fix on fail
800-02a Fix on fail 40 minutes 1.02 Suspend/Resume Issues and BIOS 1.02 01/29/1997
800-03 Fix on fail Flash Card Incompatability 11/04/1996
800-04 Fix on fail STANDOFF-HEX Replacement 12/03/1996
800-05 Fix on fail 30 minutes Mouse Tracking Problem 11/21/1996
800-06 Update 1.01 Bios and Driver Upgrade 12/20/1996
800-07 For information External Monitor Connections 01/14/1997
800-08 Fix on fail 30 minutes Mouse Tracking Problem 12/20/1996
800-09 Fix on fail 15 minutes Support Plate Insulator 01/02/1997
800-10 Fix on fail 30 minutes Mouse Behavior 01/29/1997
800-11 Fix on fail 5 minutes 16 MB RAM Module Problems 01/30/1997
800-12a For information HDD Breather Hole Covered 06/17/1997
800-13 Fix on fail 5 minutes Position of HDD Insulator 04/07/1997
800-14 Fix on fail 5 minutes Spacer –link added to Logic Board 04/05/1997
800-15 For information Display Labeling Procedure 06/02/1997
800-16 Fix on fail Toshiba 2.1GB HDD Problems 06/09/1997
800-17 For information 2.1 GB HDD Information 10/21/1997
800-18 Fix on fail 5 minutes HDD Insulator Quality Upgrade 01/08/1998
800-19 Fix on fail 5 minutes 2.01 New Bios Release 2.01.00 01/29/1998

CPU Insulator 09/12/1996

Ob 900

900-01 For information

2.13 Docking Trays 04/30/1999
900-02 For information Module Bay Adapter Modified 05/26/1999
900-03 For information 5 minutes 2.24 Bios Update to 2.24.00 06/08/1999
900-04 Fix on fail 10 minutes PCMCIA Flex Cables Stiffened 06/11/1999
900-05 Fix on fail 10 minutes Keys popping off during keyboard removal 06/14/1999
900-06 For information 12.1 inch IBM / Mitsubishi Parts 06/03/1999
900-07a For information Motherboard Revision 09/13/1999
900-08 Fix on fail 5 minutes FDD detection failure during Hot Plug or Cold Boot 07/07/1999
900-09 For information FDD Handling : Electrostatic and Pressure Damage 07/20/1999
900-10 Fix on fail 30 minutes LCD Panel Flex Connectors coming loose. 07/29/1999
900-11 Update 5 minutes 2.24 Burr on HDD Connector and Shorting Problems 09/07/1999
900-12 Fix on fail 30 minutes Display Cover Latch Redesigned to Protect LCD 09/24/1999
900-13 Fix on fail 10 minutes Corrupt Screen fonts on Windows 95 Desktop 10/29/1999

- 1 -

Current Service Notes for HP OmniBooks. 13 June 2000

Product Service note Category Time Required Bios Description Date

Ob 900
cont …

900-14 Fix on fail 60 minutes
900-15 For information

2.13 Operation of DVD Mod / MPEG-2 PC Card/Player 01/26/2000
900-16 For information A new HP nameplate hs been introduced 04/05/2000
900-17 For information Update OB900 Service Manual re: LCD displays 05/23/2000
900-18 Fix on fail 10 minutes 3.10 – 7.11 New BIOS Required 04/26/2000

HDD Protective Bracket added under palm rest 11/11/1999

Ob 2000

Ob 2100

2000-03 Fix on fail

Replacement of Logic PCA 10/01/1997
2000-04 For information 2.1GB HDD Information 10/21/1997
2000-05 For information Recovery CD Available 10/28/1997
2000-06 For information BIOS and Software History 12/01/1997
2000-07 For information Correction to Service Manual 12/02/1997
2000-08 For information OB3000 AC Adapter Incompatible 12/22/1997
2000-09 For information Refurbished OB2000 SKU added 02/01/1998
2000-10 For information New OmniBook 2000 SKU added 02/01/1998
2000-11 Fix on fail 15 minutes Support Bracket for OFF Button 02/27/1998
2000-12b For information 15 minutes Port Replicator Optional Lever 03/20/1998
2000-13 For information Revised 20x / 24x CD-ROM 10/03/1998
2000-14 For information 3.16 System.Config.Util. reports incorrect HD size 08/26/1999
2000-15 For information Clarification of Service Manual re : motherboards 12/09/1999

2100-01 For information

Recovery CD/Diagnostics 06/04/1998
2100-02 Update 5 minutes Display Hinge Covers 07/08/1998
2100-03 Fix on fail 5 minutes Improved FDD Design (F1384A) 07/08/1998
2100-04 For information OB2100 Display Cover different from OB3100 07/08/1998
2100-05 For information Caution Routing Wires 07/08/1998
2100-06 Fix on fail Changing Motherboards set correct keyboard matrix 08/10/1998
2100-07 For information No Cracked Hinge on OB2100 13 inch displays 09/15/1998
2100-08 For information To Prevent 13 inch Bezel Breakage 09/09/1998
2100-09 Update 5 minutes Data Corruption / System Hangs 10/16/1998
2100-10 Update 5 minutes Audio CD Skips / Torisan Drive 10/16/1998
2100-11 Fix on fail Euro Currency Symbol 01/21/1999
2100-12c Fix on fail 30 minutes Docked Boot Failure / PCMCIA 10/27/1999
2100-13 For information Motherboard / CPU Compatibilty 01/26/1999
2100-14 For information 4.x GB Hard Disk Drives in 3.2GB SKUs 03/29/1999

- 2 -

Current Service Notes for HP OmniBooks. 13 June 2000

Product Service note Category Time Required Bios Description Date

Ob 2100
Cont …

2100-15 Fix on fail 10 minutes
2100-16 For information
2100-17 Fix on fail 30 minutes Display Flex Cable Rev A to B for 12.1 inch DSTN 04/12/1999
2100-18 Update 5 minutes 2.03 New BIOS Version 2.03-Addresses HDD corruption 07/26/1999

Display Settings 03/29/1999

Auto Airline Adapter / Voltage from F1455A 04/15/1999

Ob 3000

Ob 3100

3000-01a Fix on fail 5 minutes

Port Replicator Fuzzy Ext. Video 03/19/1998
3000-02 Fix on fail 5 minutes I/O Door Assembly/Broken Hinge 03/09/1998
3000-03a Fix on fail 5 minutes Display Hinges 06/03/1998
3000-04a Fix on fail 30 minutes Display Latch Assembly 07/20/1998
3000-05 Fix on fail 5 minutes Display Hinge Covers 06/05/1998
3000-06 Fix on fail 5 minutes Improved FDD Design (F1384A) 06/03/1998
3000-07 For information 5 minutes RAM (Covers / Doors) Insulator 06/03/1998
3000-08 Fix on fail 30 minutes Broken Display Case Hook (Latch) 06/03/1998
3000-09 For information Caution Routing Wires 06/03/1998
3000-10 Fix on fail 45 minutes Audio Board / Motherboard Issues 06/03/1998
3000-11 For information China AC Adapter/Power cord 06/03/1998
3000-12 Fix on fail 5 minutes 20x CD-ROM Firmware Update 07/27/1998
3000-13 For information Australia Remove C-Tick Number 07/24/1998
3000-14 For information To Prevent 13 inch Bezel Breakage 09/09/1998
3000-15 Fix on fail 30 minutes Display Cover Hinge Crack 09/15/1998
3000-16 For information 5 minutes Toshiba 24x CD-ROM/Data Corrupt –Syst. Hangs. 10/16/1998
3000-17 Fix on fail 5 minutes Torisan 24x CDROM Audio Skips 10/16/1998
3000-18 For information Different screws for left side of 13 inch TFT display 05/15/2000

3100-01 For information

Recovery CD/Diagnostics 06/04/1998
3100-02 Update 5 minutes Diplay Hinge Covers 06/05/1998
3100-03 Fix on fail 5 minutes Improved FDD Design (F1384A) 06/03/1998
3100-04 Fix on fail 30 minutes Display Latch 06/03/1998
3100-05 For information Caution Routing Wires 06/03/1998
3100-06 Fix on fail Changing Motherboards set correct keyboard matrix 08/10/1998
3100-07 Fix on fail 30 minutes Crack in Display Hinge Area 09/15/1998
3100-08 For information To Prevent 13 inch Bezel Breakage 09/09/1998
3100-09 Update 5 minutes Data Corruption/System Hang & Toshiba CD-ROM 10/16/1998
3100-10 Update 5 minutes Audio CD Skips / Torisan Drive 10/16/1998

- 3 -
