HP LaserJet M118, LaserJet M119 Reference Guide [vi]

LaserJet Pro M118-M119 LaserJet Pro M203-M205 LaserJet Ultra M206
www.hp.com/support/ljM118 www.hp.com/support/ljM203
www.register.hp.com
G3Q46-90960
© Copyright 2018 HP Development Company, L.P.
www.hp.com
2.1 2.2
2.3 2.4
3.1
3.2
HP Smart
HP Smart
2
LaserJet Pro M118-M119 LaserJet Pro M203-M205
English.........................3
Bahasa Indonesia ........6
한국어 .........................9
LaserJet Ultra M206 Reference Guide
Need Help? - FAQ
For frequently asked questions, go to
www.hp.com/support/ljM203FAQ or scan the
QR code.
Control panel view
ไทย ............................ 12
繁體中文.................. 15
Tiếng Việt ................. 18
Wireless
1
2
3
4
1
2
3
4
5
6
Attention
Ready
Supplies
Resume
Cancel
button and LED (wireless model s only)
LED
LED
LED
button
button
5
6
3
Control panel light patterns
Lights Description Solution
Ready No action to take.
Toner cartridge or imaging drum is at end of life Replace with new toner cartridge or imaging drum.
Fatal error Power cycle. If error still appears, call HP customer service.
Processing No action to take.
Toner cartridge or imaging drum is very low Replace with new toner cartridge or imaging drum.
Initialization/Cleaning/Cooling down No action to take.
Toner cartridge of imaging drum is in error/missing/ incompatible/protected/unauthorized
Error/Manual Feed/Manual Duplex/Out of paper/ Door open/Jam
Take out and reinsert toner cartridge or imaging drum; if error still appears,
callHP customer service.
Manual Feed/Manual Duplex - Press Resume button when ready.
Out of paper - Insert paper.
Door open - Secure all doors.
Error/Jam - Refer to User Guide.
Mobile printing
Wireless setup using the mobile HP Smart app (wireless models only)
1. Remove the USB cable from the printer.
2. Press and hold the Wireless the Wireless button. Printer will restore network default automatically and restart.
3. Go to 123.hp.com to install the HP smart app on your mobile device.
4. Run the HP Smart app. Follow the onscreen instructions to select the name of your printer (e.g.,“HP-setup-XXX”) and connect it to your wireless network. For more information, scan FAQ QR code.
5. After the printer connects to the wireless network successfully, the Wireless light stops blinking and stays on.
button on the printer control panel. When the Ready LED and the Attention LED start blinking simultaneously, release
Use the HP Smart app to set up, print, and more.
1. Scan the QR code or go to 123.hp.com.
2. Install the HP Smart app.
3. Run the HP Smart app and follow the onscreen instructions to connect,
setup, print, and more.
Download and install the software
NOTE: Do not connect the USB cable until you are prompted to do so.
Method 1: Download HP Easy Start
(Windows and Mac OS)
1. Go to 123.hp.com/laserjet, and click Download.
2. Follow the onscreen instructions and then prompts to save the le to the computer.
3. Launch the software le from the folder where the le was saved.
4. Follow the onscreen instructions to install the software.
5. When prompted to select a connection type, select the appropriate option for the type of connection.
Learn more about mobile printing
For further information about these and other operating systems (Chrome/Google Cloud Print),
goto www.hp.com/go/LaserJetMobilePrinting orscan the QR code.
Method 2: Download from printer support website
(Windows and Mac OS)
1. Go to www.hp.com/support/ljM118 or www.hp.com/support/ljM203.
2. Select Software and Drivers.
3. Download the software for your printer model and operating system.
4. Launch the software le from the folder where the le was saved.
5. Follow the onscreen instructions to install the software.
6. When prompted to select a connection type, select the appropriate option for the type of connection.
4
Wi-Fi Direct printing (optional)
Wi-Fi Direct allows Wi-Fi capable devices, such as smart phones, tablets, or computers, to connect directly to the printer wirelessly without using a wireless router or access point. Place the device close to the printer to ensure successful connection and printing.
NOTE: The following steps temporarily disconnect your remote device from the Internet. If you are printing web-based content such as emails, web pages,
orcloud-based documents, open them before proceeding.
1. Make sure the printer is turned on and in a ready state, and paper is loaded in the main input tray.
2. On the remote device, open the Wi-Fi menu, and then tap the printer with DIRECT in the name (Example: DIRECT-72-HP xxx) from the list of available networks.
3. When prompted for a password, type 12345678. This is the default password to log in.
4. Open the item you want to print, and then tap Print from the app or action menu.
5. Select your printer from the list of available printers, and then tap Print.
6. Reconnect to your local Wi-Fi network after the print job completes.
Troubleshooting
Wireless connection troubleshooting
NOTE: Both 2.4 GHz and 5 GHz bands are supported.
Verify that the printer is within the range of the wireless network. For most networks, the printer must be within 30 m (100 ft) of the wireless access point (wireless router). A USB cable might be required for temporary connection between the printer and the computer. To ensure that the wireless setup information synchronizes correctly, do not connect the USB cable until prompted to do so.
Follow these steps to restore the network settings:
1. Remove the USB cable from the printer.
2. Press and hold the Wireless the Wireless button. Printer will restore network default automatically and restart.
3. When the Ready
LED is on, continue to install the software.
button on the printer control panel. When the Ready LED and the Attention LED start blinking simultaneously, release
If your router supports Wi-Fi Protected Setup (WPS) mode, try to connect through this mode:
1. Press the WPS
2. Within two minutes, press and hold the Wireless control panel for at least three seconds, and then release the button.
3. The Wireless Wait while the printer automatically establishes the network connection.
4. This process takes up to two minutes. When the network connection is established, the Wireless install the software.
button on your router.
button on the printer
LED and the Ready LED start blinking simultaneously.
LED stops blinking and remains on. Continue to
Wireless printing
For more information about wireless printing and wireless setup, go to
www.hp.com/go/wirelessprinting.
User guide and additional support resources
The user guide includes printer usage and troubleshooting information. It is available on the web: Go to www.hp.com/support/ljM118 or
www.hp.com/support/ljM203.
Check the Wireless LED status from the printer control panel:
1. If the Wireless established.
a. Press the Wireless button on the printer control panel. b. After the Wireless
When the network connection is established, the Wireless blinking and remains on.
2. If the Wireless LED is on, it means that the wireless connection is established.
a. Check the network name (SSID) info on the Conguration Report/Network
Summary: Press and hold the Resume blinking. After you release the Resume Network Summary prints. Verify the network name (SSID) on the report.
b. Make sure the computer is connected to the same wireless network to which
you are connecting the printer.
c. Continue to install the software.
3. If the Wireless LED is blinking, it means that the wireless connection is not established.
a. Restart the printer and the router. b. Manually connect the printer to your wireless network. Use Wi-Fi Protected
Setup (WPS) to connect the printer if the router supports WPS, or continue to the next step.
c. Uninstall and reinstall the HP software.
Check for rmware updates
1. Go to www.hp.com/support/ljM118 or www.hp.com/support/ljM203.
2. Select a printer or category from the list, and then click Drivers.
3. Select the operating system, and click the Next button.
4. Select Firmware, and click the Download button.
LED is o, it means that the wireless connection is not
LED starts blinking, continue to install the software.
LED stops
button until the Ready LED starts
button, the Conguration Report/
5
English ......................3
Bahasa Indonesia .....6
한국어 ......................9
LaserJet Pro M118-M119 LaserJet Pro M203-M205
ไทย ..........................12
繁體中文 ................15
Tiếng Việt ...............18
Butuh Bantuan? - FAQ
Untuk pertanyaan umum, kunjungi
www.hp.com/support/ljM203FAQ atau pindai
kode QR.
Tampilan panel kontrol
LaserJet Ultra M206 Panduan Referensi
Tombol nirkabel
1
2
3
4
1
LED Peringatan
2
LED Siap
3
LED Persediaan
4
Tombol Resume (Lanjutkan kembali)
5
Tombol Batal
6
dan LED (hanya model nirkabel)
5
6
6
Panel kontrol pola lampu
Lampu Keterangan Solusi
Siap Tidak perlu dilakukan tindakan.
Kartrid toner atau drum olahgambar hampir habis masa pakainya
Kesalahan fatal Siklus daya. Jika kesalahan masih ada, hubungi layanan pelanggan HP.
Memproses Tidak perlu dilakukan tindakan.
Kartrid toner atau drum olahgambar sangat rendah Ganti dengan kartrid toner atau drum olahgambar yang baru.
Inisialisasi/Pembersihan/Pendinginan Tidak perlu dilakukan tindakan.
Kartrid toner pada drum olahgambar bermasalah/ hilang/tidak kompatibel/diproteksi/palsu
Masalah/Pengisian Manual/Dupleks Manual/Kertas habis/Pintu terbuka/Macet
Ganti dengan kartrid toner atau drum olahgambar yang baru.
Keluarkan dan masukkan kembali kartrid toner atau drum olahgambar;
jikamasalah masih ada, hubungi layanan pelanggan HP.
Pengisian Manual/Dupleks Manual - Tekan tombol Resume
(Lanjutkankembali) bila sudah siap.
Kertas habis - Masukkan kertas.
Pintu terbuka - Tutup semua pintu.
Masalah/Macet - Lihat Panduan Pengguna.
Pencetakan mobile
Penyiapan nirkabel menggunakan aplikasi seluler HP Smart (hanya model nirkabel)
1. Lepaskan kabel USB dari printer.
2. Tekan dan tahan tombol Nirkabel Nirkabel . Printer akan memulihkan jaringan standar secara otomatis dan melakukan start ulang.
3. Kunjungi 123.hp.com untuk menginstal aplikasi HP Smart di perangkat seluler Anda.
4. Jalankan aplikasi HP Smart. Ikuti petunjuk di layar untuk memilih nama printer (mis., “penyiapan HP-XXX”) dan sambungkan printer ke jaringan nirkabel. Untuk informasi lebih lanjut, pindai kode QR pada Pertanyaan Umum.
5. Setelah printer berhasil tersambung ke jaringan nirkabel, Lampu nirkabel berhenti berkedip dan terus menyala.
pada panel kontrol printer. Bila LED Siap dan LED Peringatan mulai berkedip bersamaan, lepas tombol
Gunakan aplikasi HP Smart untuk mengongurasi, mencetak, dan lainnya.
1. Pindai kode QR atau kunjungi 123.hp.com.
2. Instal aplikasi HP Smart.
3. Jalankan aplikasi HP Smart dan ikuti petunjuk di layar untuk
menyambungkan, mengongurasi, mencetak, dan lainnya.
Selengkapnya tentang pencetakan seluler
Untuk informasi lebih lanjut tentang hal ini dan sistem operasi lainnya (Chrome/Google Cloud Print), kunjungi
www.hp.com/go/LaserJetMobilePrinting atau
pindai kode QR.
Mendownload dan menginstal perangkat lunak
CATATA N: Jangan sambungkan kabel USB hingga diminta untuk melakukannya.
Metode 1: Download HP Easy Start
(Windows dan Mac OS)
1. Kunjungi 123.hp.com/laserjet, dan klik Download.
2. Ikuti petunjuk di layar dan perintah untuk menyimpan le di komputer.
3. Jalankan le perangkat lunak dari folder tempat menyimpan le.
4. Ikuti petunjuk di layar untuk menginstal perangkat lunak.
5. Bila diminta untuk memilih jenis sambungan, gunakan pilihan yang tepat untuk jenis sambungan.
1. Kunjungi www.hp.com/support/ljM118 atau www.hp.com/support/ljM203.
2. Pilih Software and Drivers (Perangkat lunak dan Driver).
3. Download perangkat lunak untuk model printer dan sistem operasi Anda.
4. Jalankan le perangkat lunak dari folder tempat menyimpan le.
5. Ikuti petunjuk di layar untuk menginstal perangkat lunak.
6. Bila diminta untuk memilih jenis sambungan, gunakan pilihan yang tepat untuk jenis sambungan.
7
Metode 2: Download dari situs web dukungan
printer (Windowsdan Mac OS)
Pencetakan Wi-Fi Direct (opsional)
Wi-Fi Direct memungkinkan perangkat yang mendukung Wi-Fi, misalnya smartphone, tablet, atau komputer, untuk terhubung langsung ke printer tanpa menggunakan router atau jalur akses nirkabel. Tempatkan perangkat dekat ke printer untuk memastikan koneksi dan pencetakan yang lancar.
CATATA N: Langkah-langkah berikut secara temporer memutuskan sambungan perangkat jarak jauh Anda dari internet. Jika Anda mencetak konten berbasis
web seperti email, halaman web, atau dokumen berbasis cloud, buka konten tersebut sebelum melanjutkan.
1. Pastikan printer dinyalakan dan dalam status siap, dan kertas dimuat dalam baki masukan utama.
2. Pada perangkat jarak jauh, buka menu Wi-Fi, lalu ketuk printer dengan DIRECT pada namanya (Contoh: DIRECT-72-HP xxx) dari daftar jaringan yang tersedia.
3. Bila diminta kata sandi, ketikkan 12345678. Ini adalah kata sandi standar untuk login.
4. Buka item yang ingin Anda cetak, lalu ketuk Print (Cetak) dari aplikasi atau menu tindakan.
5. Pilih printer dari daftar printer yang tersedia, lalu ketuk Print (Cetak).
6. Sambungkan kembali ke jaringan Wi-Fi lokal setelah tugas cetak selesai.
Mengatasi masalah
Pemecahan masalah koneksi nirkabel
CATATA N: Kedua pita 2,4 GHz dan 5 GHz didukung.
Pastikan printer telah berada dalam jangkauan jaringan nirkabel. Untuk sebagian besar jaringan, printer harus berada dalam jarak 30 m (100 kaki) dari jalur akses nirkabel (router nirkabel). Kabel USB mungkin diperlukan untuk membuat sambungan sementara antara printer dan komputer. Untuk memastikan
bahwa informasi kongurasi nirkabel telah disinkronisasi dengan benar, jangan sambungkan kabel USB hingga Anda diminta untuk melakukannya.
Ikuti langkah-langkah ini untuk memulihkan pengaturan jaringan:
1. Lepaskan kabel USB dari printer.
2. Tekan dan tahan tombol Nirkabel Nirkabel . Printer akan memulihkan jaringan standar secara otomatis dan melakukan start ulang.
3. Bila LED Siap
menyala, lanjutkan dengan menginstal perangkat lunak.
pada panel kontrol printer. Bila LED Siap dan LED Peringatan mulai berkedip bersamaan, lepas tombol
Jika router mendukung mode WPS (Wi-Fi Protected Setup), coba sambungkan melalui mode ini:
1. Tekan tombol WPS
2. Dalam dua menit, tekan dan tahan tombol Nirkabel printer selama minimum tiga detik, lalu lepas tombol tersebut.
3. LED Nirkabel sementara printer menetapkan sambungan jaringan secara otomatis.
4. Proses ini berlangsung hingga 2 menit. Setelah sambungan jaringan ditetapkan, LED Nirkabel Lanjutkan dengan menginstal perangkat lunak.
pada router.
pada panel kontrol
dan LED Siap mulai berkedip secara bersamaan. Tunggu
akan berhenti berkedip dan tetap menyala.
Pencetakan nirkabel
Untuk informasi lebih lanjut tentang
pencetakan dan kongurasi nirkabel, kunjungi
www.hp.com/go/wirelessprinting.
Panduan pengguna dan informasi berguna untuk dukungan tambahan
Panduan pengguna mencakup informasi tentang penggunaan dan cara mengatasi masalah printer. Informasi ini tersedia di web: Kunjungi
www.hp.com/support/ljM118 atau www.hp.com/support/ljM203.
Periksa status LED Nirkabel dari panel kontrol printer:
1. Jika LED Nirkabel
a. Tekan tombol Nirkabel di panel kontrol printer. b. Setelah LED Nirkabel
lunak. Setelah sambungan jaringan ditetapkan, LED Nirkabel berkedip dan tetap menyala.
2. Jika LED Nirkabel menyala, ini berarti sambungan nirkabel telah ditetapkan.
a. Periksa informasi nama jaringan (SSID) pada Laporan Kongurasi/Ringkasan
Jaringan: Tekan dan tahan tombol Resume (Lanjutkan kembali) Siap
Laporan Kongurasi/Ringkasan Jaringan akan dicetak. Verikasikan nama
jaringan (SSID) pada laporan.
b. Pastikan komputer telah tersambung ke jaringan nirkabel yang sama seperti
yang digunakan untuk menyambungkan printer.
c. Lanjutkan dengan menginstal perangkat lunak.
3. Jika LED Nirkabel berkedip, ini berarti sambungan nirkabel tidak ditetapkan.
a. Hidupkan ulang printer dan router. b. Sambungkan printer secara manual ke jaringan nirkabel. Gunakan WPS
(Wi-Fi Protected Setup) untuk menyambungkan printer jika router mendukung WPS, atau lanjutkan ke langkah berikutnya.
c. Hapus kemudian instal ulang perangkat lunak HP.
Memeriksa pembaruan rmware
1. Kunjungi www.hp.com/support/ljM118 atau www.hp.com/support/ljM203.
2. Pilih printer atau kategori dari daftar, lalu klik Drivers (Driver).
3. Pilih sistem operasi, lalu klik tombol Next (Berikutnya).
4. Pilih Firmware, lalu klik tombol Download.
mati, berarti sambungan nirkabel tidak ditetapkan.
mulai berkedip, lanjutkan untuk menginstal perangkat
akan berhenti
hingga LED
mulai berkedip. Setelah tombol Resume (Lanjutkan kembali) dilepas,
8
LaserJet Pro M118-M119 LaserJet Pro M203-M205
English.........................3
Bahasa Indonesia ........6
한국어 .........................9
LaserJet Ultra M206 설명서
도움말 정보? - FAQ
자주 묻는 질문은
www.hp.com/support/ljM203FAQ에서 확인하거나
QR 코드를 스캔하십시오.
제어판 보기
ไทย ............................ 12
繁體中文.................. 15
Tiếng Việt ................. 18
1
2
3
4
1
2
3
4
5
6
LED
주의
LED
준비
소모품
다시 시작
취소
버튼
LED
버튼
버튼 및 LED(무선 모델만 해당)
무선
5
6
9
제어판 표시등 패턴
표시등 설명 해결 방법
모바일 인쇄
준비
토너 카트리지 또는 이미지 드럼의 수명이 끝났음
치명적 오류
처리 중
토너 카트리지 또는 이미징 드럼 매우 부족
초기화/세척/냉각 취해야 할 조치 없음.
이미징 드럼의 토너 카트리지가 오류/누락/ 호환되지 않음/보호됨/허가되지 않음
오류/수동 공급/수동 양면 인쇄/용지 부족/도어 열림/용지 걸림
취해야 할 조치 없음.
새 토너 카트리지 또는 이미징 드럼으로 교체합니다.
전원 껐다 켜기. 계속해서 오류가 나타나면, HP 고객 서비스센터에 문의하십시오.
취해야 할 조치 없음.
새 토너 카트리지 또는 이미징 드럼으로 교체합니다.
토너 카트리지 또는 이미징 드럼을 꺼냈다가 다시 끼워 넣고, 계속해서 오류가 나타나면 HP 고객 서비스센터에 문의하십시오.
수동 공급/수동 양면 인쇄 - 준비가 되면 다시 시작 버튼을 누릅니다.
용지 부족 - 용지를 넣습니다.
도어 열림 - 모든 도어를 고정합니다.
오류/용지 걸림 - 사용 설명서를 참조합니다.
모바일 HP 스마트 앱을 사용한 무선 설치(무선 모드만 해당)
1. USB 케이블을 프린터에서 분리합니다.
2. 프린터 제어판에 있는 무선 자동으로 네트워크 기본값을 복구하여 다시 시작합니다.
3. 123.hp.com로 이동하여 모바일 장치에 HP 스마트 앱을 설치합니다.
4. HP 스마트 앱을 실행합니다. 화면의 안내에 따라 프린터의 이름(예, “HP-setup-XXX”)을 선택한 다음 무선 네트워크에 연결합니다. 자세한 내용은 FAQ QR 코드를 스캔하십시오.
5. 프린터를 무선 네트워크에 연결하면, 무선 표시등의 깜빡임이 중지되고 켜진 상태가 됩니다.
HP 스마트 앱을 사용하여 연결, 설정 및 인쇄 등을 실시합니다.
1. QR 코드를 스캔하거나 123.hp.com으로 이동합니다.
2. HP 스마트 앱을 설치합니다.
3. HP 스마트 앱을 실행하여 화면에 표시되는 안내에 따라 연결, 설정 및
인쇄 등을 실시합니다.
버튼을 길게 누릅니다. 준비 LED주의 LED가 동시에 깜박이면 무선 버튼을 해제합니다. 프린터가
모바일 인쇄에 대해 자세히 알아보기
이들 운영 체제 및 기타 운영 체제(Chrome/ Google Cloud Print)에 대한 추가 정보는
www.hp.com/go/LaserJetMobilePrinting으로
이동하거나 QR 코드를 스캔하십시오.
소프트웨어 다운로드 및 설치
참고: 알림이 표시되기 전까지는 USB 케이블을 연결하지 마십시오.
방법 1: HP Easy Start 다운로드(WindowsMac OS)
1. 123.hp.com/laserjet으로 이동한 다음 다운로드를 클릭합니다.
2. 화면의 안내와 알림에 따라 컴퓨터에 파일을 저장합니다.
3. 파일이 저장된 폴더에서 소프트웨어 파일을 실행합니다.
4. 화면의 지시에 따라 소프트웨어를 설치합니다.
5. 연결 유형을 선택하라는 메시지가 표시되면, 연결 유형에 적합한 옵션을 선택합니다.
방법 2: 프린터 지원 웹사이트에서 다운로드
(WindowsMac OS)
1. www.hp.com/support/ljM118 또는 www.hp.com/support/ljM203으로 이동합니다.
2. 소프트웨어 및 드라이버를 선택합니다.
3. 해당 프린터 모델 및 운영 체제용 소프트웨어를 다운로드합니다.
4. 파일이 저장된 폴더에서 소프트웨어 파일을 실행합니다.
5. 화면의 지시에 따라 소프트웨어를 설치합니다.
6. 연결 유형을 선택하라는 메시지가 표시되면, 연결 유형에 적합한 옵션을 선택합니다.
10
Wi-Fi Direct 인쇄(옵션)
Wi-Fi Direct를 통해 스마트폰, 태블릿, 컴퓨터와 같은 Wi-Fi 케이블 장치를 무선 라우터나 액세스 지점을 사용하지 않고 무선으로 프린터에 직접 연결할 수 있습니다. 장치를 연결 및 인쇄할 수 있도록 프린터와 가까운 위치에 둡니다.
참고: 다음 단계에서는 원격 장치를 일시적으로 인터넷에서 분리합니다. 이메일, 웹 페이지 또는 클라우드 기반 문서와 같은 웹 기반 콘텐츠를 인쇄하는
경우에는 계속하기 전에 해당 콘텐츠를 엽니다.
1. 프린터가 준비 상태로 켜져 있는지 확인한 다음 용지를 주 입력 용지함에 넣습니다.
2. 원격 장치에서 Wi-Fi 메뉴를 연 다음 사용 가능한 네트워크의 이름 (예: DIRECT-72-HP xxx) 에서 프린터의 DIRECT를 누릅니다.
3. 암호를 입력하라는 메시지가 표시되면, 12345678을 입력합니다. 이 암호는 로그인하기 위한 기본 암호입니다.
4. 인쇄하려고 하는 항목을 연 다음 앱 또는 조치 메뉴에서 인쇄를 누릅니다.
5. 사용 가능한 프린터 목록에서 프린터를 선택한 다음 인쇄를 입력합니다.
6. 인쇄 작업이 완료되면 로컬 Wi-Fi 네트워크에서 분리합니다.
문제 해결
무선 연결 문제해결
참고: 2.4GHz 및 5GHz 대역이 지원됩니다.
프린터가 무선 네트워크 범위 내에 있는지 확인합니다. 대부분의 네트워크에서는 프린터가 무선 액세스 지점(무선 라우터)의 30m(100ft) 이내에 있어야 합니다. USB 케이블을 사용하여 임시로 프린터와 컴퓨터를 연결해야 할 수도 있습니다. 무선 설정 정보가 제대로 동기화되도록 알림이 표시되기 전에는 USB 케이블을 연결하지 마십시오.
네트워크 설정을 복원하려면 다음 단계를 수행하십시오.
1. USB 케이블을 프린터에서 분리합니다.
2. 프린터 제어판에 있는 무선 자동으로 네트워크 기본값을 복구하여 다시 시작합니다.
3. 준비
LED가 켜져 있으면 소프트웨어 설치를 진행합니다.
버튼을 길게 누릅니다. 준비 LED주의 LED가 동시에 깜박이면 무선 버튼을 해제합니다. 프린터가
라우터가 Wi-Fi 보호 설정(WPS) 모드를 지원하는 경우에는 다음 모드를 통해 연결해 보십시오.
1. 라우터에서 WPS
2. 2분 이내에 프린터 제어판에 있는 무선
있다가 버튼에서 손을 뗍니다.
3. 무선
4. 처리하는 데 최대 2분이 걸립니다. 네트워크 연결이 설정되면
LED 및 준비 LED가 동시에 깜박이기 시작합니다. 프린터가
자동으로 네트워크 연결을 설정하는 동안 기다립니다.
LED가 깜박임을 멈추고 계속 켜져 있는 상태를 유지합니다.
무선 소프트웨어 설치를 진행합니다.
버튼을 누릅니다.
버튼을 최소 3초간 누르고
무선 인쇄
무선 인쇄 및 무선 설정에 대한 자세한 내용은
www.hp.com/go/wirelessprinting으로 이동합니다.
사용 설명서 및 추가 지원 리소스
사용 설명서에 프린터 사용법 및 문제 해결 정보가 포함되어 있습니다. 웹에서 사용할 수 있습니다: www.hp.com/support/ljM118 또는 www.hp.com/support/ljM203으로 이동합니다.
프린터 제어판의 무선 LED 상태를 확인합니다.
1. 무선
2. 무선 LED가 켜져 있으면 무선 연결이 설정되었다는 의미입니다.
3. 무선 LED가 깜박인다면 무선 연결이 설정되지 않았다는 의미입니다.
펌웨어 업데이트 확인
1. www.hp.com/support/ljM118 또는 www.hp.com/support/ljM203으로
2. 목록에서 프린터 또는 카테고리를 선택한 다음 드라이버
3. 운영 체제를 선택하고 다음 버튼을 클릭합니다.
4. 펌웨어를 선택하고 다운로드 버튼을 클릭합니다.
LED가 꺼져 있으면 무선 연결이 설정되지 않았다는
의미입니다.
a. 프린터 제어판에서 무선 버튼을 누릅니다. b. 무선
a. 구성 보고서/네트워크 요약에서 네트워크 이름(SSID) 정보를 확인합니다.
b. 컴퓨터가 프린터를 연결할 동일한 무선 네트워크에 연결되어 있어야
c. 소프트웨어 설치를 진행합니다.
a. 프린터와 라우터를 다시 시작합니다. b. 무선 네트워크에 프린터를 수동으로 연결합니다. 라우터가 Wi-Fi 보호
c. HP 소프트웨어를 제거 및 재설치하십시오.
이동합니다.
클릭합니다.
LED가 깜박이면 소프트웨어 다운로드 및 설치를 진행합니다. 네트워크 연결이 설정되면 무선 상태를 유지합니다.
준비 LED 표시등이 깜박일 때까지 다시 시작 버튼을 길게 누릅니다. 다시 시작 보고서에서 네트워크 이름(SSID)을 확인합니다.
합니다.
설정(WPS)을 지원하는 경우에는 WPS를 사용하여 프린터를 연결하고, 그 외의 경우에는 다음 단계를 진행합니다.
버튼을 해제하면 구성 보고/네트워크 요약이 인쇄됩니다.
LED가 깜박임을 멈추고 계속 켜져 있는
11
English ......................3
Bahasa Indonesia .....6
한국어 ......................9
ไทย ..........................12
繁體中文 ................15
Tiếng Việt ...............18
1
2
3
4
5
6
12
131415
LaserJet Pro M118-M119 LaserJet Pro M203-M205
English.........................3
Bahasa Indonesia ........6
한국어 .........................9
LaserJet Ultra M206
參考指南
需要協助?- 常見問題解答
如需常見問題解答,請前往
www.hp.com/support/ljM203FAQ
或掃描 QR 代碼。
控制面板視圖
ไทย ............................ 12
繁體中文.................. 15
Tiếng Việt ................. 18
1
2
3
4
1
LED
注意
2
LED
就緒
3
LED
耗材
4
按鈕
繼續
5
取消
6
按鈕
按鈕和 LED (僅限無線機型)
無線
5
6
控制面板指示燈模式
指示燈 說明 解決方案
就緒 沒 有動 作 需要 執行。
碳粉匣或感光鼓的使用壽命已達終點 更 換新 的碳 粉匣 或感 光 鼓。
嚴重錯誤
處理中 沒有 動作需 要執 行。
碳粉匣或感光鼓嚴重不足 更 換新 的碳 粉匣 或感 光 鼓。
初始化/清理/降溫
碳粉匣的感光鼓狀態顯示為錯誤/遺失/不相容/ 受到保護/未獲授權
錯誤/手動送紙/手動雙面列印/紙張用完/擋門已 打開/夾紙
關閉電源再重新開啟。如果錯誤仍然存在,請致電與 HP 客戶服 務 聯繫。
沒有 動作需 要執 行。
取出碳粉匣或感光鼓,並接著重新放入,如果錯誤仍然存在,請致電與 HP 客戶服務 聯繫。
手動送紙/手動雙面列印 - 在就緒時按下 Resume (繼續) 按鈕。
紙張用完 - 放入紙張。
擋門已打開 - 關上所有擋門。
錯誤/夾紙 - 請參閱使用指南。
行動列印
無線設定,使用行動版 HP Smart 應用程式 (僅限無線機型)
1. 從印表機拔下 USB 連接線。
2. 按住印表機控制面板上的無線 路預設值,並且重新開機。
3. 前往 123.hp.com,並在您的行動裝置上安裝 HP Smart 應用程式。
4. 執行 HP Smart 應用程式。請依照螢幕上的指示,選擇印表機的名稱 (例如,「HP-setup-XXX」),並將其連接到無線網路。如需詳細資 訊,請掃描 FAQ QR 碼。
5. 印表機成功連接至無線網路之後,無線網路燈號就會停止閃爍,並開始維持恆亮。
按鈕。當就緒 LED 和注意 LED 指示燈開始一起閃爍時,放開無線 按鈕。 印表機將自動還原成網
使用 HP Smart 應用程式,進行設定、列印和其他動作。
1. 掃描 QR 碼或前往 123.hp.com。
2. 安裝 HP Smart 應用程式。
3. 執行 HP Smart 應用程式,然後依照畫面上的指示,進行連線、設 定、列印和其他動作。
下載與安裝軟體
附註:在接獲提示前,請勿連接 USB 連接線。
方法 1:下載 HP Easy Start (WindowsMac OS)
1. 前往 123.hp.com/laserjet,然後按一下 Download (下載)。
2. 請依照螢幕上的指示和提示,將檔案儲存至電腦。
3. 從儲存軟體檔案的資料夾中,啟動軟體檔案。
4. 請依照螢幕上的指示,安裝軟體。
5. 在出現選擇連線類型的提示時,選擇適合連線類型的選項。
進一步了解行動列印
如需有關這些和其他作業系統 (Chrome/ Google 雲端列印) 的更多資訊,請前往
www.hp.com/go/LaserJetMobilePrinting
或掃描 QR 碼。
方法 2:從印表機支援網站下載 (WindowsMac OS)
1. 前往 www.hp.com/support/ljM118 www.hp.com/support/ljM203。
2. 選擇軟體和驅動程式
3. 下載適用於您印表機型號和作業系統的軟體。
4. 從儲存軟體檔案的資料夾中,啟動軟體檔案。
5. 請依照螢幕上的指示,安裝軟體。
6. 在出現選擇連線類型的提示時,選擇適合連線類型的選項。
16
Wi-Fi Direct 列印 (選用)
Wi-Fi Direct 可讓具備 Wi-Fi 功能的裝置 (例如智慧型手機、平板電腦或電腦) 在沒有使用無線路由器或存取點的情況下,直接與印表機進行連線。 將裝置放在靠近印表機的地方,確保成功達成連線及列印。
附註:下面步驟會使您的遠端裝置與網際網路暫時中斷連線。若您要列印的是電子郵件、網頁等網站類型的內容,或是雲端類型的文件,請先開
啟這些內容後,再進行列印。
1. 請確定印表機電源已開啟並處於就緒狀態,而且紙張已放入主要進紙匣。
2. 在遠端裝置上,開啟 Wi-Fi 功能表,並接著從可用網路清單中,輕按名稱包含 DIRECT 的印表機 (例如:DIRECT-72-HP xxx)。
3. 在收到密碼提示時,鍵入 12345678。這是用於登入的預設密碼。
4. 打開您要列印的項目,接著從應用程式或動作功能表中輕按 Print (列印)。
5. 從可用印表機清單中選擇印表機,然後輕按 Print (列印)。
6. 在列印工作完成後,重新連結到您的本機 Wi-Fi 網路。
疑難排解
無線連線設定疑難排解
附註:同時支援 2.4 GHz5 GHz 頻寬。
確認印表機位於無線網路範圍內。對多數網路而言,印表機必須是在距離無線存取點 (無線路由器) 30 公尺 (100 英呎) 以內的位置。可能需要使用 USB 纜線暫時連接印表機與電腦。為確保正確同步無線設定資訊,在出現提示前,請勿連接 USB 纜線。
按照這些步驟來還原網路設定:
1. 從印表機拔下 USB 連接線。
2. 按住印表機控制面板上的無線 路預設值,並且重新開機。
3. 當就緒
LED 亮起時,繼續執行安裝軟體。
按鈕。當就緒 LED 和注意 LED 指示燈開始一起閃爍時,放開無線 按鈕。 印表機將自動還原成網
如果您的路由器支援 Wi-Fi Protected Setup (WPS) 模式,請嘗試透過此 模式連線:
1. 按下路由器上的 WPS
2. 在兩分鐘內按住印表機控制面板上的無線 放開按鈕。
3. 無線
4. 這個過程最久費時 2 分鐘。建立網路連線後,無線
LED 燈和就緒 LED 燈會一起開始閃爍。等待印表機自動建
立網路連線。
閃爍並持續亮起。繼續執行安裝軟體。
按鈕。
按鈕至少三秒,然後
LED 燈會停止
無線列印
如需關於無線列印及無線設定的詳細資訊, 請前往 www.hp.com/go/wirelessprinting。
使用指南和其他支援資源
使用指南包含印表機使用方式及疑難排解資訊。使用指南也有提供網 路版:前往 www.hp.com/support/ljM118 www.hp.com/support/ljM203。
在印表機控制面板上檢查 Wireless (無線) LED 燈的狀態:
1. 如果無線
a. 按下印表機控制面板上的無線 按鈕。 b. 在無線
2. 如果 Wireless (無線) LED 燈亮起,表示已建立無線通訊連線。
a. 檢查 Conguration Report/Network Summary (組態報告/網路摘要) 上的網
b. 確定電腦所連線的無線網路與印表機要連線的無線網路相同。 c. 繼續執行安裝軟體。
3. 如果無線 LED 燈閃爍,表示並未建立無線通訊連線。
a. 請重新啟動印表機和路由器。 b. 手動將印表機連線至無線網路。使用 Wi-Fi Protected Setup (WPS) 連線印
c. 請解除 HP 軟體,然後再重新安裝。
查看韌體更新
1. 前往 www.hp.com/support/ljM118 www.hp.com/support/ljM203。
2. 從清單選擇印表機或類別,然後按一下 Drivers (驅動程式)。
3. 選擇作業系統,然後按一下 Next (下一步) 按鈕。
4. 選擇 Firmware (韌體),然後按一下 Download (下載) 按鈕。
LED 燈熄滅,表示並未建立無線通訊連線。
無線
路名稱 (SSID) 資訊:按住 爍。在您放開 告上的網路名稱 (SSID)
表機 (如果路由器支援 WPS),或繼續進行下一個步驟。
LED 開始閃爍之後,繼續執行安裝軟體。建立網路連線後,
LED 燈會停止閃爍並持續亮起。
繼續按鈕,直到 就緒 LED 指示燈開始閃
繼續按鈕之後,組態報告/網路摘要隨即列印。驗證報
17
English ......................3
Bahasa Indonesia .....6
한국어 ......................9
ไทย ..........................12
繁體中文 ................15
Tiếng Việt ...............18
1
2
3
4
5
6
18
19
20
© Copyright 2018 HP Development Company, L.P.
Reproduction, adaptation or translation without prior written permission is prohibited, except as allowed under the copyright laws.
The information contained herein is subject to change without notice.
The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
Trademark Credits
Windows® is a U.S. registered trademark of Microsoft Corporation.
Apple and the Apple logo are trademarks of Apple Inc., registered in the U.S. and other countries.
App Store is a service mark of Apple Inc. Android, Google Play, and the Google Play logo are trademarks of Google Inc.
Mac OS is a trademark of Apple Inc., registered in the U.S. and other countries.
AirPrint is a trademark of Apple Inc., registered in the U.S. and other countries.
www.hp.com
Loading...
