QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Overview
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 1
Front right
1.
WLAN antennas (2)
11.
Microphone/ headphones combo jack
2.
WWAN antennas (2)
12.
Display Port 1.2
3.
Internal microphone (2)
13.
USB-C Basic port
4.
Webcam LED (select models)
14.
USB-C port
5.
Webcam (select models)
15.
Fingerprint reader (select models)
6.
SIM card slot
16.
Touchpad buttons (4)
7.
Power connector
17.
Indicator LEDs: Wireless Light, Power Light, AC Adapter/Battery Light, Storage Usage Light
8.
Docking connector
18.
NFC (select models)
9.
Ethernet port
19.
Pointstick
10.
USB 3.1 GEN 1 port
20
Power button
HP EliteBook 725 G4 Notebook PC
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Overview
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 2
Left
1.
Security lock slot
3.
USB 3.1 GEN 1 Charging port
2.
VGA port
4.
Smart Card Reader
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Overview
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 3
HP EliteBook 745 G4 Notebook PC
Front right
1.
WLAN antennas (2)
13.
SD card slot
2.
WWAN antennas (2) (select models)
14.
Microphone/ headphones combo jack
3.
Internal microphones (2)
15.
Display Port 1.2
4.
Webcam LED (select models)
16.
USB-C Basic port
5.
Webcam (select models)
17.
Fingerprint reader (select models)
6.
Wireless on/off button
18.
Touchpad
7.
Speaker mute button
19.
Touchpad buttons (4)
8.
SIM card slot
20.
Indicator LEDs: Wireless Light, Power Light, AC Adapter/Battery Light, Storage Usage Light
9.
Power connector
21.
NFC (select models)
10.
Docking connector
22.
Pointstick
11.
Ethernet port
23.
Power button
12.
USB 3.1 GEN 1 port
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Overview
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 4
1.
Security lock slot
3.
USB 3.1 GEN 1 Charging port
2.
VGA port
4.
Smart Card Reader
Left
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Overview
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 5
1.
WLAN antennas (2)
13.
SD card slot
2.
WWAN antennas (2) (select models)
14.
Microphone/ headphones combo jack
3.
Internal microphones (2)
15.
Display Port 1.2
4.
Webcam LED (select models)
16.
USB-C Basic port
5.
Webcam (select models)
17.
Fingerprint reader (select models) Touchpad
6.
Wireless on/off button
18.
7.
Speaker mute button
19.
Touchpad buttons (4)
8.
SIM card slot
20.
Indicator LEDs: Wireless Light, Power Light, AC Adapter/Battery Light, Storage Usage Light
9.
Power connector
21.
NFC (select models)
10.
Docking connector
22.
Pointstick
11.
Ethernet port
23.
Power button
12.
USB 3.1 GEN 1 port
24.
10-key Numeric Keypad
HP EliteBook 755 G4 Notebook PC
Front right
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Overview
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 6
1.
Security lock slot
3.
USB 3.1 GEN 1 Charging port
2.
VGA port
4.
Smart Card Reader
Left
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Overview
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 7
AT A GLANCE
Stylish, lightweight magnesium and aluminum chassis No dongles are needed with built-in VGA, drop-jaw RJ-45 Ethernet port, 2 USB 3.1 GEN 1 , 1 USB Type-C
Basic,and 1 DisplayPort 1.2 for high resolution support
Design allows memory, storage, wireless modules, and battery to be customer serviceable and upgradeable Accelerated Processing Unit and graphics from AMD Optimize your audio experience for remote collaboration with optional HD webcam, dual-microphone array,
premium speakers, and Audio by Bang & Olufsen
Featuring HP Premium Keyboard with Pointstick and 10-key numeric keypad available on HP EliteBook 755 Passed MIL-SPEC 810G testing, plus an additional 120,000 hours of reliability testing through HP's Total Test
Process1
Optional back-lit keyboard keeps you productive in all settings with HP DuraKeys to protect keys from fading Enhanced security features including TPM 2.0, SmartCard Reader, Self-Encrypting storage drives, and optional
Fingerprint reader
LED-backlit displays:
o HP EliteBook 725: 31.75 cm (12.5") diagonal Non-Touch o HP EliteBook 745: 35.6 cm (14") diagonal Touch and Non-Touch o HP EliteBook 755: 39.6 cm (15.6") diagonal Touch and Non-Touch
Experience new vibrant color provided by AMD Vivid Color Technology Regain up to 50% battery life in just 30 minutes of charging with an HP fast charging battery. HP WorkWise is office intelligence rolled into one smartphone app to provide PC security, real-time PC
performance information, and simplified printer driver installation for HP PC users.
Flexible wireless connectivity options including mobile broadband Easily dock with the HP UltraSlim Docking Station Choice of hard drives up to 1 TB and solid state drives up to 512 GB Memory up to 16 GB Preinstall Windows 10, or FreeDOS 2.0 DDR4 memory up to 16 GB
TM
1. MIL STD 810G testing is pending and is not intended to demonstrate fitness for U.S. Department of Defense contract requirements or for military use. Test results are not a guarantee of future performance under these test conditions. Damage under the MIL STD test conditions or any accidental damage requires an optional HP Accidental Damage Protection Care Pack.
NOTE: See important legal disclosures for all listed specs in their respective features sections.
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Features
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 8
Windows 10 Pro 641 Windows 10 Home 64
1
Windows 10 Home Single Language 641 Windows 10 Pro (National Academic only) 1 Windows 7 Professional 64 (available through downgrade rights from Windows 10 Pro)2 Windows 7 Professional 64 (available through downgrade rights from Windows 10 Pro 64) National Academic only2 FreeDOS 2.0
Windows 10 Enterprise 641 Windows 7 Enterprise 64
1,3
Windows 7 Professional 64
1
HP EliteBook 725 AMD PRO A8 -9600B (1.6 GHz, up to 3.0 GHz, 2 MB Cache, 4 Cores) with AMD Radeon™ R5 Graphics1 AMD PRO A10-8730B (1.8 GHz, up to 3.2 GHz, 2 MB Cache, 4 Cores) with AMD Radeon™ R5 Graphics1 AMD PRO A12-8830B (2.1 GHz, up to 3.4 GHz, 2 MB Cache, 4 Cores) with AMD Radeon™ R7 Graphics1 AMD PRO A12-9800B (2.1 GHz, up to 3.4 GHz, 2 MB Cache, 4 Cores) with AMD Radeon™ R7 Graphics1
HP EliteBook 745 AMD PRO A8 -9600B (1.6 GHz, up to 3.0 GHz, 2MB Cache, 4 Cores) with AMD Radeon™ R5 Graphics1 AMD PRO A10-8730B (1.8 GHz, up to 3.2 GHz, 2MB Cache, 4 Cores) with AMD Radeon™ R5 Graphics1 AMD PRO A12-8830B (2.1 GHz, up to 3.4 GHz, 2MB Cache, 4 Cores) with AMD Radeon™ R7 Graphics1 AMD PRO A12-9800B (2.1 GHz, up to 3.4 GHz, 2MB Cache, 4 Cores) with AMD Radeon™ R7 Graphics1
PRODUCT NAMES
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
OPERATING SYSTEM
Preinstalled
Web supported
NOTE: Your product does not support Windows 8 or Windows 7
In accordance with Microsoft’s support policy, HP does not support the Windows® 8 or Windows 7 operating system on
products configured with Intel 7th generation and forward processors or provide any Windows® 8 or Windows 7 drivers on http://www.support.hp.com.
1. Not all features are available in all editions or versions of Windows. Systems may require upgraded and/or separately
purchased hardware, drivers, software or BIOS update to take full advantage of Windows functionality. Windows 10 is automatically updated, which is always enabled. ISP fees may apply and additional requirements may apply over time for updates. See http://www.windows.com.
2. This system is preinstalled with Windows 7 Pro software and also comes with a license and media for Windows 10 Pro
software. You may only use one version of the Windows software at a time. Switching between versions will require you to uninstall one version and install the other version. You must back up all data (files, photos, etc.) before uninstalling and installing operating systems to avoid loss of your data.
ACCELERATED PROCESSING UNIT
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Features
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 9
HP EliteBook 755 AMD PRO A8 -9600B (1.6 GHz, up to 3.0 GHz, 2MB Cache, 4 Cores) with AMD Radeon™ R5 Graphics1 AMD PRO A10-8730B (1.8 GHz, up to 3.2 GHz, 2MB Cache, 4 Cores) with AMD Radeon™ R5 Graphics1 AMD PRO A12-8830B (2.1 GHz, up to 3.4 GHz, 2MB Cache, 4 Cores) with AMD Radeon™ R7 Graphics1 AMD PRO A12-9800B (2.1 GHz, up to 3.4 GHz, 2MB Cache, 4 Cores) with AMD Radeon™ R7 Graphics1
1. Multicore is designed to improve performance of certain software products. Not all customers or software applications
will necessarily benefit from use of this technology. Performance and clock frequency will vary depending on application
workload and your hardware and software configurations. AMD’s numbering is not a measurement of clock speed.
NOTE: Processor speed denotes maximum performance mode; processors will run at lower speeds in battery optimization mode.
Integrated Graphics AMD PRO A8 -9600B with AMD Radeon™ R5 Graphics AMD PRO A10-8730B with AMD Radeon™ R5 Graphics AMD PRO A12-8830B with AMD Radeon™ R7 Graphics AMD PRO A12-9800B with AMD Radeon™ R7 Graphics
AMD UMA Graphics - with shared video memory Support dual-display ports through optional docking station
1
1. Sold separately or as an optional feature.
HP EliteBook 725 Internal Non-Touch
31.75 cm (12.5") diagonal LED backlight HD SVA Anti-glare (1366 x 768) 1
31.75 cm (12.5") diagonal LED backlight HD SVA Anti-glare (1366 x 768) with camera1
31.75 cm (12.5") diagonal LED backlight FHD UWVA Anti-glare (1920 x 1080)1
31.75 cm (12.5") diagonal LED backlight FHD UWVA Anti-glare (1920 x 1080) with camera
1
Touch
31.75 cm (12.5") diagonal LED backlight FHD UWVA Touch (1920 x 1080)1
HP EliteBook 745 Internal Non-Touch
35.6 cm (14") diagonal LED backlight HD SVA Anti-glare (1366 x 768)1
35.6 cm (14") diagonal LED backlight HD SVA Anti-glare (1366 x 768) with camera1
35.6 cm (14") diagonal LED backlight FHD SVA Anti-glare (1920 x 1080) 1
35.6 cm (14") diagonal LED backlight FHD SVA Anti-glare (1920 x 1080) with camera1
35.6 cm (14") diagonal LED backlight QHD UWVA Anti-glare (2560 x 1440)1
35.6 cm (14") diagonal LED backlight QHD UWVA Anti-glare (2560 x 1440) camera
1
GRAPHICS
DISPLAY
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Features
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 10
Touch
35.6 cm (14") diagonal LED backlight FHD SVA with camera, Corning® Gorilla® Glass 4 Touch (1920 x 1080)1
HP EliteBook 755 Internal Non-Touch
39.6 cm (15.6") diagonal LED backlight HD SVA Anti-glare (1366 x 768) 1
39.6 cm (15.6") diagonal LED backlight HD SVA Anti-glare (1366 x 768) with Camera1
39.6 cm (15.6") diagonal LED backlight FHD SVA Anti-glare (1920 x 1080) 1
39.6 cm (15.6") diagonal LED backlight FHD SVA Anti-glare (1920 x 1080) with Camera1 Touch
39.6 cm (15.6") diagonal LED backlight FHD SVA with camera, Corning® Gorilla® Glass 4 Touch (1920 x 1080)1
External Up to 32-bit per pixel color depth
VGA Port supports resolutions up to 1900 x 1200 external resolution @60 Hz
DisplayPort Supports resolutions up to 4096 x 2160 @ 60Hz
NOTE: Resolutions are dependent upon monitor capability, and resolution and color depth settings.
Number of Displays supported with Docking
Supports 3 independent displays if used with optional HP Ultraslim Docking Station.
2
1. HD content required to view HD images.
2. Sold separately or as an optional feature.
Primary Storage SATA, 2.5" Hard Drives1
500 GB 7200 rpm Hard Drive 500 GB 7200 rpm SED Hard Drive (Opal 2) 500 GB 7200 rpm SED Hard Drive (FIPS-140-2) 1 TB 5400 rpm
M.2 (NGFF) 2280 Solid State Drives 128 GB SATA-3 SS Value Solid State Drive 256 GB PCIe NVMe TLC Solid State Drive 256 GB SATA-3 SED MLC Solid State Drive (Opal 2) 512 GB PCIe NVMe TLC Solid State Drive 512 GB PCIe NVMe M Solid State Drive
HP 3D DriveGuard (Windows and Hard Drives only)
The hard drive is mounted directly to the notebook frame, reducing the transmission of shock to the hard drive
STORAGE AND DRIVES
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Features
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 11
1. For storage drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 30 GB (for Windows
10) is reserved for system recovery software.
Standard
DDR4 PC4 – 1866 (Transfer rates up to 1866 MT/s) Two SODIMM slots supporting dual-channel memory Both slots are customer accessible / upgradeable
Supports the following configurations 4096 MB Total System Memory (4096 MB x 1) 8192 MB Total System Memory (4096 MB x 2) 8192 MB Total System Memory (8192 MB x 1) 16384 MB Total System Memory (8192 MB x 2)
Maximum Up to 16 GB
Dual-channel
Maximized dual-channel performance requires SODIMMs of the same size and speed in both memory slots.
NOTE: Improved system performance when memory is added in pairs (dual channel). Due to the non-industry standard nature of some third-party memory modules, we recommend HP branded memory to ensure compatibility. If you mix memory speeds, the system will perform at the lower memory speed.
Broadband Wireless (WWAN)
HP lt4120 Qualcomm® Snapdragon™ X5 LTE Mobile Broadband Module
1,2
HP lt4132 LTE/HSPA+ 4G Mobile Broadband Module
1,2
HP hs3210 WW HSP with GPS Mobile Broadband
1,2
Wireless LAN (WLAN) Via MiniCard
Realtek RTL8723BE-VB 802.11 b/g/n (1x1) Wi-Fi + Bluetooth® 4.0 Combo3 Intel® Dual Band AC 3168 802.11 a/b/g/n/ac (1x1) Wi-Fi + Bluetooth® 4.2 Combo3 Intel® Dual Band AC 7265 802.11 a/b/g/n/ac (2x2) Wi-Fi + Bluetooth® 4.2 Combo3(non-vPro)
Near Field Communication (NFC)1
HP Module with NXP NFC Controller NPC100
1. Sold separately or as an optional feature.
2. WWAN module is optional, requires separately purchased service contract. Check with service provider for coverage and availability in your area. Connection speeds will vary due to location, environment, network conditions, and other factors. 4G LTE not available on all products, in all regions.
3. Wireless access point and Internet service is required and is not included. Availability of public wireless access points limited. The specifications for the 802.11ac WLAN are draft specifications and are not final. If the final specifications differ from the draft specifications, it may affect the ability of the notebook to
MEMORY
NETWORKING/COMMUNICATIONS
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Features
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 12
communicate with other 802.11ac WLAN devices.
Communications Broadcom 5762 10/100/1000 Ethernet NIC with DASH Support
NOTE: The term "10/100/1000" or "Gigabit" Ethernet indicates compatibility with IEEE standard 802.3ab for Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed transmission, connection to a Gigabit Ethernet server and network infrastructure is required.
Support for Miracast Support for HP Sure Connect
Audio
Audio by Bang & Olufsen Digital Microphones (Dual Array) 2 Premium Stereo Speakers
Webcam1
Optional2 720p webcam
1. Internet access required.
2. Sold separately or as an optional feature.
HP Premium Keyboard
Spill-resistant with drain using a thin layer of Mylar film under the keyboard DuraKeys & Backlit Dual Point
Pointing Devices
Glass Touchpad On/Off button Taps enabled as default Gestures enabled by default - 2 Finger Scrolling, 2 Finger Zoom (Pinch)
Buttons and Function Keys HP EliteBook 725
Function Keys F1 - Sleep F2 - Blank F3 - Backlit Toggle F4 - Display Switching F5 - Brightness Down F6 - Brightness Up F7 - Audio Mute F8 - Volume Down
AUDIO/MULTIMEDIA
KEYBOARDS/POINTING DEVICES/BUTTONS & FUNCTION KEYS
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Features
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 13
F9 - Volume Up F10 - Mic Mute F11 - Wireless F12 - numlk
Hidden Function Keys
Fn+R - Break Fn+S - Sys Rq Fn+C - Scroll Lock
HP EliteBook 745
Function Keys
F1 - Sleep F2 - Blank F3 - Backlit Toggle F4 - Display Switching F5 - Brightness Down F6 - Brightness Up F7 - Blank F8 - Volume Down F9 - Volume Up F10 - Mic Mute F11 - Blank F12 – numlk
Hidden Function Keys
Fn+R - Break Fn+S - Sys Rq Fn+C - Scroll Lock Fn+Up – PG UP Fn+Down – PG Down Fn+Left - Home Fn+ Right - End
HP EliteBook 755 Function Keys
F1 - Sleep F2 - Blank F3 - Backlit Toggle F4 - Display Switching F5 - Brightness Down F6 - Brightness Up F7 - Blank F8 - Volume Down F9 - Volume Up F10 - Mic Mute F11 - Blank F12 - Blank
Hidden Function Keys
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Features
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 14
Fn+R - Break Fn+S - Sys Rq Fn+C - Scroll Lock
BIOS
HP BIOSphere1 HP Sure Start with Runtime Intrusion Detection2 HP DriveLock | HP Automatic DriveLock BIOS Update via Network Master Boot Record Security Power On Authentication Secure Erase
3
Absolute Persistence Module4 Pre-boot Authentication
Communication / Connectivity
HP Mobile Connect Pro (Windows 10 only)
5
Native Miracast Support6 HP LAN-WLAN Protection HP MAC Address Manager
HP Value Add Software
HP 3D DriveGuard (Requires Windows) HP ePrint Driver + JetAdvantage7 HP Hotkey Support - CMIT HP Recovery Manager HP Jumpstart HP Support Assistant HP Noise Cancellation Software
Microsoft Products
Buy Office Bing Search Skype8
Manageability
HP Driver Packs9 HP SoftPaq Download Manager (SDM) HP System Software Manager (SSM)9
SOFTWARE AND SECURITY
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Features
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 15
HP BIOS Config Utility (BCU)9 HP Client Catalog9 HP Management Integration Kit for Microsoft SCCM
9
HP WorkWise LANDESK Management10
For more information on HP Client Management Solutions refer to: http://www.hp.com/go/clientmanagement.
Client Security Software
HP Client Security Suite Gen3
HP Security Manager (including Credential Manager and Password Manager) HP Drive Lock HP Fingerprint Sensor HP Password Manager Absolute Persistence Module Power On Authentication HP Device Access Manager
Microsoft Defender (Windows 10 only)
Security
Trusted Platform Module (TPM) 1.2 (Infineon SLB9670). Common Criteria EAL4+ Certified. Upgradable to TPM 2.0. Convertible to FIPS 140-2 Certified mode. (TPM 2.0 is not available for Win 7 32-
bit.)
11
HP Fingerprint Reader (On select models) Integrated Smart Card Reader Security lock slot (Lock sold separately) For more information on HP Client Security Software Suite, refer to http://www.hp.com/go/clientsecurity.
1. Available only on business PCs with HP BIOS.
2. Available on HP EliteBook products equipped with AMD® 7th generation processors.
3. For the methods outlined in the National Institute of Standards and Technology Special Publication 800-
88.
4. Absolute agent is shipped turned off, and will be activated when customers activate a purchased subscription. Subscriptions can be purchased for terms ranging multiple years. Service is limited, check with Absolute for availability outside the U.S. The Absolute Recovery Guarantee is a limited warranty. Certain conditions apply. For full details visit: http://www.absolute.com/company/legal/agreements/ computrace­agreement. Data Delete is an optional service provided by Absolute Software. If utilized, the Recovery Guarantee is null and void. In order to use the Data Delete service, customers must first sign a Pre­Authorization Agreement and either obtain a PIN or purchase one or more RSA SecurID tokens from Absolute Software.
5. HP Mobile Connect Pro is only available on preconfigured devices with WWAN. For geographic availability refer to www.hp.com/go/mobileconnect
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Features
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 16
6. Miracast is a wireless technology your PC can use to project your screen to TVs, projectors, and streaming media
players that also support Miracast. You can use Miracast to share what you’re doing on your PC and present a slide
show. For more information: http://windows.microsoft.com/en-us/windows-8/project-wireless-screen-miracast
7. Requires an Internet connection to HP web-enabled printer and HP ePrint account registration (for a list of eligible printers, supported documents and image types and other HP ePrint details, see www.hp.com/go/eprintcenter). Requires optional broadband module. Broadband use requires separately purchased service contract. Check with service provider for coverage and availability in your area. Separately purchased data plans or usage fees may apply. Print times and connection speeds may vary.
8. Skype is not offered in China.
9. Not preinstalled, however available for download at http://www.hp.com/go/clientmanagement
10. Subscription required.
11. This product ships with TPM 1.2 with option to upgrade to TPM 2.0. Upgrade utility is available via HP Customer Support
Power Supply1
HP 45W Smart AC Adapter HP 45W 2-prong DC jack AC Adapter HP 65W Smart AC Adapter (Supports HP Fast Charging) HP 65W Smart AC Adapter EM (Supports HP Fast Charging)
1. Availability may vary by country.
Power cord is configurable; either 3.2 feet or 6 feet (1.0 or 1.8 meter) Total length including external AC adapter is 9.2 feet or 12 feet (2.86 or 3.66 meter)
Primary Battery HP EliteBook 725
HP 3-cell Long Life Li-Ion (44 WHr) HP 3-cell Long Life Li-Ion (49 WHr) (Supports HP Fast Charging)
HP EliteBook 745 and 755 HP 3-cell Long Life Li-Ion (46 WHr)
HP 3-cell Long Life Li-Ion (51 WHr) (Supports HP Fast Charging)
Battery Life1
Platform
Other HW Details
Battery
Battery life
HP EliteBook 725 G4
HDD
3-cell (49WHr)
Up to 8 hrs 15 mins
HP EliteBook 725 G4
SSD
3-cell (49WHr)
Up to 9 hrs 45 mins
HP EliteBook 745 G4
HDD
3-cell (51WHr)
Up to 9 hrs 15 mins
HP EliteBook 745 G4
SSD
3-cell (51WHr)
Up to 11 hrs 00 mins
HP EliteBook 755 G4
HDD
3-cell (51WHr)
Up to 9 hrs 00 mins
POWER
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Features
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 17
HP EliteBook 755 G4
SSD
3-cell (51WHr)
Up to 10 hrs 30 mins
1. Windows 10/MM14 battery life will vary depending on various factors including product model, configuration, loaded applications, features, use, wireless functionality, and power management settings. The maximum capacity of the battery will naturally decrease with time and usage. See www.bapco.com for additional details.
System Standby Time2 TBD
Power Conservation
Hibernation Standby ACPI compliance
HP EliteBook 725 G4 Weight1 Non-Touch
Starting at 2.78 lbs (1.26 kg) (3-cell battery (49WHr), UMA, no FPR, 1 SODIMM, WLAN, M.2 SSD, no camera, no WWAN, FHD Panel)
Touch Starting at 3.05 lbs (1.38 kg) (3-cell battery (49WHr), UMA, no FPR, 1 SODIMM, WLAN, M.2 SSD, no camera, no WWAN, FHD Touch)
Dimensions2 (w x d x h) Non-Touch
12.2 x 8.6 x 0.74 in 31 x 21.89 x 1.89 cm
Touch
12.2 x 8.6 x 0.80 in 31 x 21.89 x 2.02 cm
HP EliteBook 745 G4 Notebook PC Weight1 Non-Touch
Starting at 3.27 lbs (1.48 kg) (3-cell battery (51WHr), UMA, no FPR, 1 SODIMM, WLAN, M.2 SSD, no camera, no WWAN, QHD screen) Touch Starting at 3.75 lbs (1.70 kg) (3-cell battery (51WHr), UMA, no FPR, 1 SODIMM, WLAN, M.2 SSD, no camera, no WWAN, FHD Touch screen)
1. Weight varies by configuration and components.
2. Height varies depending upon where on the notebook the measurement is made.
WEIGHTS & DIMENSIONS
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Features
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 18
Dimensions2 (w x d x h) Non-Touch
13.3 x 9.3 x 0.74 in
33.8 x 23.7 x 1.89 cm
Touch
13.3 x 9.3 x 0.80 in
33.8 x 23.7 x 2.02 cm
HP EliteBook 755 G4 Notebook PC Weight1 Non-Touch
Starting at 4.06 lbs (1.84 kg) (3-cell battery (51WHr), UMA, no FPR, 1 SODIMM, WLAN, M.2 SSD, no camera, no WWAN, FHD Panel) Touch Starting at 4.54 lbs (2.06 kg) (3-cell battery (51WHr), UMA, no FPR, 1 SODIMM, WLAN, M.2 SSD, no camera, no WWAN, FHD Touch)
Dimensions2 (w x d x h) Non-Touch
15.1 x 10.10 x 0.76 in
38.36 x 25.77 x 1.94 cm
Touch
15.1 x 10.10 x 0.82 in
38.36 x 25.77 x 2.08 cm
1. Weight varies by configuration and components.
2. Height varies depending upon where on the notebook the measurement is made.
Ports
1 USB 3.1 GEN 1 Charging Port 1 USB 3.1 GEN 1 Port 1 USB Basic Type-C Basic Port (Up to 5 Gbps data transfer and 15W power) 1 Display Port 1 RJ-45 / Ethernet 1 Docking connector 1 Headphone/Microphone Combo 1 AC Port
NOTE: Cables are not included.
Slots External Micro SIM Slot(3FF) 15 x 12 mm SD Media Reader Slot Supports SD, SDHC, SDXC
PORTS/SLOTS
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Features
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 19
HP Services offers 3-year and 1-year limited warranties and 90 day software support depending on country. Batteries have a default one year limited warranty. On-site service and extended coverage is also available. HP Care Pack Services are optional extended service contracts that go beyond the standard limited warranties. To choose the right level of service for your HP product, use the HP Care Pack Services Lookup Tool at: http://www.hp.com/go/cpc.
1. Sold separately or as an optional feature.
2. Service levels and response times for HP Care Packs may vary depending on your geographic location. Service starts on
date of hardware purchase. Restrictions and limitations apply. HP services are governed by the applicable HP terms and conditions of service provided or indicated to Customer at the time of purchase. Customer may have additional statutory rights according to applicable local laws, and such rights are not in any way affected by the HP terms and conditions of service or the HP Limited Warranty provided with your HP Product. To choose the right level of service for your HP product, use the HP Care Pack Services Lookup Tool at: http://www.hp.com/go/cpc.
SERVICE AND SUPPORT
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 20
Stand-Alone Power Requirements (AC Power)
Nominal Operating Voltage
19.5 V
Average Operating Power
Windows 10 (64-bit)
Integrated graphics
12.9 W
Max Operating Power
Discrete < 90W UMA < 65W
Temperature
Operating
32° to 95° F (0° to 35° C) (not writing optical)
41° to 95° F (5° to 35° C) (writing optical)
Non-operating
-4° to 140° F (-20° to 60° C)
Relative Humidity
10% to 90%, non-condensing
5% to 95%, 101.6° F (38.7° C) maximum wet bulb temperature
Shock
Operating
40 G, 2 ms, half-sine
Non-operating
200 G, 2 ms, half-sine
Random Vibration
Operating
0.75 grms
Non-operating
1.50 grms
Altitude (unpressurized)
Operating
-50 to 10,000 ft (-15.24 to 3,048 m)
Non-operating
-50 to 15,000 ft (-15.24 to 12,192 m)
Planned Industry Standard
Certifications
UL
Yes
CSA
Yes
FCC Compliance
Yes
ENERGY STAR®
Select models*
EPEAT®
Registered Gold in United States**
ICES
Yes
SYSTEM UNIT
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 21
Australia / NZ RCM Compliance
Yes
CCC
Yes
Japan VCCI Compliance
Yes
KC
Yes
BSMI
Yes
CE Marking Compliance
Yes
CIT
Yes
EAC
Yes
Saudi Arabian Compliance (SASO)
Yes
SABS
Yes
UKRSERTCOMPUTER
Yes
* Configurations of the HP EliteBook 725, 745 and 755 G4 that are ENERGY STAR qualified are identified as HP EliteBook 725 G 4, HP EliteBook 745 G4 or HP EliteBook 755 G4 ENERGY STAR on HP websites and on www.energystar.gov. ** EPEAT registration varies by country. See www.epeat.net for registration status by country. EPEAT status listed above applies to U.S. For accessibility information on HP products, please visit: http://www.hp.com/accessibility.
31.75 cm (12.5”) diagonal LED backlight HD Slim eDP SVA Anti­glare non-touch (1366 x 768)
Outline Dimensions
(W x H x D)
291.0 x 181.9 X 3.0 mm (max)
Active Area
276.62 mm x 155.52 mm
Weight
250g max
Diagonal Size
31.75 cm (12.5)
Surface Treatment
AG
Contrast Ratio
300:1 (typ)
Refresh Rate
60Hz
Response time
16ms typ.
Displays
Note: All specifications represent the typical specifications provided by HP's component manufacturers; actual performance may
vary either higher or lower.
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 22
Pixel Per Inch (PPI)
125
Brightness
220nits
Pixel Resolution Format
1366 x 768 (HD)
Configuration
RGB
Interface
eDP 1.2
LCD Mode
TN
Viewing Angle
SVA 45/45/25/35
31.75 cm (12.5”)
diagonal LED backlight FHD UltraSlim eDP UWVA Anti-glare non-touch (1920 x 1080)
Outline Dimensions
(W x H x D)
282.7 x 179.82 x 2.3 (mm) max
Active Area
276.48 x 155.52 mm
Weight
170g max
Diagonal Size
31.75 cm (12.5)
Surface Treatment
AG
Contrast Ratio
600:1 (typ)
Refresh Rate
60Hz
Response time
25ms typ.
Pixel Per Inch (PPI)
176
Brightness
300nits
Pixel Resolution Format
1920 x 1080 (FHD)
Configuration
RGB
Interface
eDP 1.3 + PSR
LCD Mode
IPS/FFS/VA
Viewing Angle
UWVA 85/85/85/85
31.75 cm (12.5”)
diagonal LED backlight FHD UltraSlim eDP UWVA (1920 x 1080) Touch
Outline Dimensions
(W x H x D)
282.7 x 179.82 x 2.3 (mm) max
Active Area
276.48 x 155.52 mm
Weight
170g max
Diagonal Size
31.75 cm (12.5”)
Touch Enabled
Yes
TSP Type
Capacitive
Surface Treatment
Anti-smudge/fingerprint coating
Contrast Ratio
600:1 (typ)
Refresh Rate
60Hz
Response time
25ms typ.
Pixel Per Inch (PPI)
176
Brightness
300nits
Pixel Resolution Format
1920 x 1080 (FHD)
Configuration
RGB
Interface
eDP 1.3 + PSR
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 23
LCD Mode
IPS/FFS/VA
Viewing Angle
UWVA 85/85/85/85
35.56 cm (14”) diagonal
LED backlight HD Slim eDP SVA Anti-glare non­touch (1366 x 768)
Outline Dimensions
(W x H x D)
320.9 x 205.6 (max) x 3.0mm max
Active Area
309.4 x 173.95 (mm)
Weight
290 g max
Diagonal Size
35.56 cm (14)
Surface Treatment
Anti-Glare (AG)
Contrast Ratio
300:1 (typ)
Refresh Rate
60Hz
Response time
16ms typ.
Pixel Per Inch (PPI)
112
Brightness
220nits
Pixel Resolution Format
1366 x 768 (HD)
Configuration
RGB
Interface
eDP 1.2
LCD Mode
TN
Viewing Angle
SVA 45/45/25/35
35.56 cm (14”) diagonal LED backlight FHD Slim eDP SVA Anti-glare non­touch (1920 x 1080)
Outline Dimensions
(W x H x D)
320.9 x 205.6 (max) x 3.0(max) mm
Active Area
309.40 x 173.95 (mm)
Weight
270 g max
Diagonal Size
14
Surface Treatment
Anti-Glare (AG)
Contrast Ratio
300:1 (typ)
Refresh Rate
60Hz
Response time
16ms typ.
Pixel Per Inch (PPI)
157
Brightness
300nits
Pixel Resolution Format
1920 x 1080 (FHD)
Configuration
RGB
Interface
eDP 1.2
LCD Mode
TN
Viewing Angle
SVA 45/45/25/35
Outline Dimensions (W x H x D)
320.9 x 205.6 (mm) max x 2.6 (mm) max
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 24
35.56 cm (14”) diagonal
LED backlight QHD UltraSlim eDP UWVA Anti­glare non-touch (2560 x 1440)
Active Area
309.50 x 174.10 (mm)
Weight
270g max
Diagonal Size
35.56 cm (14”)
Surface Treatment
Anti-Glare (AG)
Contrast Ratio
600:1 (typ.)
Refresh Rate
60Hz
Response time
30 ms typ.
Pixel Per Inch (PPI)
210
Brightness
340 nits
Pixel Resolution Format
2560x1440 (QHD)
Configuration
RGB
Interface
eDP 1.3 + PSR
LCD Mode
IPS/FFS/VA
Viewing Angle
UWVA 85/85/85/85
35.56 cm (14”) diagonal
LED backlight FHD Slim eDP SVA (1920 x 1080) Touch
Outline Dimensions
(W x H x D)
320.9 x 205.6 (mm) max x 3.0 (mm) max
Active Area
309.40 x 173.95 (mm)
Weight
270 g max
Diagonal Size
14
Surface Treatment
Anti-smudge/fingerprint coating
Touch Enabled
Yes
TSP Type
Capacitive
Contrast Ratio
300:1 (typ)
Refresh Rate
60 Hz
Response time
16ms typ.
Pixel Per Inch (PPI)
157
Brightness
300nits
Pixel Resolution Format
1920 x 1080 (FHD)
Configuration
RGB
Interface
eDP 1.2
LCD Mode
TN
Viewing Angle
SVA 45/45/25/35
39.6 cm (15.6”) diagonal
LED backlight HD Slim
Outline Dimensions
(W x H x D)
360.0 x 224.3 x 3.2 (mm) max
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 25
eDP SVA Anti-glare non­touch (1366 x 768)
Active Area
344.2 x 193.5 (mm)
Weight
370g max
Diagonal Size
39.6 cm (15.6”)
Surface Treatment
Anti-Glare (AG)
Contrast Ratio
300:1 (typ)
Refresh Rate
60Hz
Response time
16ms typ.
Pixel Per Inch (PPI)
101
Brightness
220 nit typ
Pixel Resolution Format
1366 x 768 (HD)
Configuration
RGB
Interface
eDP 1.2
LCD Mode
TN
Viewing Angle
SVA 45/45/25/35
39.6 cm (15.6”) diagonal
LED backlight FHD Slim eDP SVA Anti-glare non­touch (1920 x 1080)
Outline Dimensions
(W x H x D)
360.0 x 224.3 x 3.2 (mm) max
Active Area
344.2 x 193.5 (mm)
Weight
360 g max.
Diagonal Size
39.6 cm (15.6)
Surface Treatment
Anti-Glare (AG)
Contrast Ratio
400:1 (typ)
Refresh Rate
60Hz
Response time
16ms typ.
Pixel Per Inch (PPI)
142
Brightness
300nits
Pixel Resolution Format
1920 x 1080 (FHD)
Configuration
RGB
Interface
eDP 1.2
LCD Mode
TN
Viewing Angle
SVA 45/45/25/35
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 26
39.6 cm (15.6”) diagonal
LED backlight FHD Slim eDP SVA (1920 x 1080) Touch
Outline Dimensions
(W x H x D)
360.0 x 224.3 x 3.2 (mm) max
Active Area
344.2 x 193.5 (mm)
Weight
360 g max.
Diagonal Size
39.6 cm (15.6”)
Surface Treatment
Anti-smudge/fingerprint coating
Contrast Ratio
400:1 (typical)
Touch Enabled
Yes
TSP Type
Capacitive
Refresh Rate
60Hz
Response time
16ms typ.
Pixel Per Inch (PPI)
142
Brightness
300nits
Pixel Resolution Format
1920 x 1080 (FHD)
Configuration
RGB
Interface
eDP 1.2
LCD Mode
TN
Viewing Angle
SVA 45/45/25/35
HP lt4120 Qualcomm® Snapdragon™ X5 LTE Mobile Broadband Module
Technology/Operating bands
LTE: 2100 (Band 1), 1900 (Band 2), 1800 (Band 3), 1700/2100 (Band 4), 850 (Band 5), 2600 (Band 7), 900 (Band 8), 700 (Band 12 lower), 700 (Band 13 upper), 700 (Band 17 lower), 800 (Band 20), 700 (Band 28). HSPA+: 2100 (Band 1), 1900 (Band 2), 1700/2100 (Band 4), 850 (Band 5), 900 (Band 8) MHz EV-DO: 850 (BC0), 1900 (BC1) MHz (Only work with Verizon network) E-GPRS: 1900 (Band 2), 1800 (Band 3), 850 (Band 5), 900 (Band 8) MHz
Wireless protocol standards
3GPP Release 10 LTE Specification CAT.4, 20MHz BW WCDMA R99, 3GPP Release 5, 6, 7 and 8 UMTS Specification 1xEVDO Release 0, A and B. E-GPRS: Class B, Multi-slot class 12, coding schemes CS1 - CS4 and MSC1 - MSC9
GPS
Standalone, A-GPS (MS-A, MS-B and XTRA)
GPS bands
1575.42 MHz ± 1.023 MHz, GLONASS 1596-1607MHz
Maximum data rates
LTE: 150 Mbps (Download), 50 Mbps (Upload)
NETWORKING*
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 27
DC-HSPA+: 42 Mbps (Download), 5.76 Mbps (Upload) HSPA+: 21Mbps (Download), 5.76 Mbps (Upload) CDMA 1xRTT: 153.6 kbps (Download), 153.6 kbps (Upload) EVDO Rel.A: 3.1 Mbps (Download), 1.8 Mbps (Upload) EVDO Rel.B: 14.7 Mbps (Download), 5.4Mbps (Upload) EDGE: 236.8 kbps (Download), 236.8 kbps (Upload)
GPRS: 85.6 kbps(Download), 85.6 kbps (Upload)
Maximum output power
LTE: 23 dBm HSPA+: 23.5 dBm 1xRTT/EVDO: 24dBm E-GPRS 1900/1800: 26 dBm E-GPRS 900/850: 27 dBm GPRS 1900/1800: 29.5 dBm GPRS 900/850: 32.5 dBm
Maximum power consumption
LTE: 1,200 mA (peak); 900 mA (average) HSPA+: 1,100 mA (peak); 800 mA (average) 1xRTT/EVDO: 1,000 mA (peak); 700 mA (average) E-GPRS: 2,800 mA (peak); 500 mA (average)
Form Factor
M.2, 3042-S3 Key B
Weight
6.2 g
Dimensions
(Length x Width x Thickness)
42 x 30 x 2.3 mm
* Mobile Broadband is an optional feature. Connection requires wireless data service contract, network support, and is not available in all areas. Contact service provider to determine the coverage area and availability. Connection speeds will vary due to location, environment, network conditions, and other factors. 4G LTE not available on all products or in all countries.
HP lt4132 LTE/HSPA+ 4G Mobile Broadband Module
Technology/Operating bands
LTE: 2100 (Band 1), 1900 (Band 2), 1800 (Band 3) MHz, 850 (Band 5), 2600 (Band 7), 900 (Band 8) MHz, 800 (Band 20), 700 (Band 28) MHz. HSPA+: 2100 (Band 1), 1900 (Band 2), 850 (Band 5), 900 (Band 8) MHz E-GPRS: 1900 (Band 2), 1800 (Band 3), 850 (Band 5), 900 (Band 8) MHz
Wireless protocol standards
3GPP Release 10 LTE Specification CAT.4, 20MHz BW WCDMA R99, 3GPP Release 5, 6, 7 and 8 UMTS Specification E-GPRS: Class B, Multi-slot class 12, coding schemes CS1 - CS4 and MSC1 - MSC9
GPS
Standalone, A-GPS (MS-B and LTO)
GPS bands
1575.42 MHz ± 1.023 MHz, GLONASS 1596-1607MHz
Maximum data rates
LTE: 150 Mbps (Download), 50 Mbps (Upload) DC-HSPA+: 42 Mbps (Download), 5.76 Mbps (Upload) HSPA+: 21Mbps (Download), 5.76 Mbps (Upload) EDGE: 236.8 kbps (Download), 236.8 kbps (Upload)
GPRS: 85.6 kbps(Download), 85.6 kbps (Upload)
Maximum output power
LTE: 23 dBm HSPA+: 23.5 dBm
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 28
E-GPRS 1900/1800: 26 dBm E-GPRS 900/850: 27 dBm GPRS 1900/1800: 29.5 dBm GPRS 900/850: 32.5 dBm
Maximum power consumption
LTE: 1,200 mA (peak); 900 mA (average) HSPA+: 1,100 mA (peak); 800 mA (average) E-GPRS: 2,600 mA (peak); 500 mA (average)
Form Factor
M.2, 3042-S3 Key B
Weight
6 g
Dimensions
(Length x Width x Thickness)
42 x 30 x 2.3 mm
* Mobile Broadband is an optional feature. Connection requires wireless data service contract, network support, and is not available in all areas. Contact service provider to determine the coverage area and availability. Connection speeds will vary due to location, environment, network conditions, and other factors. 4G LTE not available on all products or in all countries.
HP hs3210 WW HSP with GPS Mobile Broadband
Technology/Operating bands
HSPA+: 2100 (Band1), 1900 (Band 2), 850 (Band 5), 900 (Band 8) MHz E-GPRS: 1900 (Band 2), 1800 (Band 3), 850 MHz (Band 5), 900 (Band 8) MHz
Wireless protocol standards
WCDMA R99, 3GPP Release 5, 6 and 7 UMTS Specification E-GPRS: Class B, Multi-slot class 33, coding schemes CS1 - CS4 and MSC1 - MSC9
Maximum data rates
HSPA+: 21.6 Mbps (Download), 5.76 Mbps (Upload)
E-GPRS: 296 kbps (Download), 236.8 kbps (Upload) GPRS: 107 kbps (Download), 85.6 kbps (Upload)
Maximum output power
HSPA+: 24 dBm E-GPRS 1800/1900: 26 dBm
E-GPRS 850/900: 27 dBm GPRS 1800/1900: 30 dBm GPRS 850/900: 33 dBm
Maximum power consumption
HSPA+: 1,100 mA (peak); 800 mA (average) E-GPRS: 2,800 mA (peak); 700 mA (average)
Form Factor
M.2, 2242-S3 Key B
Weight
6 g
Dimensions (Length x Width x Thickness)
1.65 x 8.66 x 0.09 in (42 x 22 x 2.38 mm)
* Mobile Broadband is an optional feature. Connection requires wireless data service contract, network support, and is not available in all areas. Contact service provider to determine the coverage area and availability. Connection speeds will vary due to location, environment, network conditions, and other factors.
Note: Wireless access point and Internet service required. Availability of public wireless access points limited. The specifications for the 802.11ac WLAN are draft specifications and are not final. If the final specifications differ from the draft specific ations, it may affect the ability of the notebook to communicate with other 802.11ac WLAN devices.
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 29
Wireless LAN Standards
IEEE 802.11a
IEEE 802.11b IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac
IEEE 802.11ac Wave 2 MU-MIMO
Interoperability
Wi-Fi certified
Frequency Band
802.11b/g/n
2.402 – 2.482 GHz
Note:
The FCC has declared as of January 1, 2015 products that utilize passive scanning on channel 12/13 and are capable of transmitting must fully comply with requirements of 15.247 or otherwise disable those channels.
802.11a/n
4.9 – 4.95 GHz (Japan) 5.15 – 5.25 GHz 5.25 – 5.35 GHz 5.47 – 5.725 GHz 5.825 – 5.850 GHz
Note: Indonesia no support this band)
Data Rates
802.11b: 1, 2, 5.5, 11 Mbps 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz) 802.11ac : MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz,
and 80MHz)
Intel® Dual Band Wireless-AC 8265 802.11 a/b/g/n/ac (2x2) WiFi and Bluetooth® 4.2 combo
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 30
Modulation
Direct Sequence Spread Spectrum BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM
Security1
IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g
mode only
AES-CCMP: 128 bit in hardware 802.1x authentication WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES. WPA2 certification IEEE 802.11i Cisco Certified Extensions, all versions through CCX4 and CCX
Lite
WAPI
Network Architecture Models
Ad-hoc (Peer to Peer) Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power2
802.11b : +16dBm minimum 802.11g : +14dBm minimum 802.11a : +14dBm minimum 802.11n HT20(2.4GHz) : +14dBm minimum 802.11n HT40(2.4GHz) : +12dBm minimum 802.11n HT20(5GHz) : +14dBm minimum 802.11n HT40(5GHz) : +12dBm minimum
Power Consumption
Transmit: 2.0 W (max)
Receive: 1.6 W (max)
Idle mode (PSP): 180 mW (WLAN Associated)
Idle mode: 50 mW (WLAN unassociated)
Connect Standby: 10 mW (WLAN+BT)
Radio disabled: 5 mW
Power Management
ACPI and PCI Express compliant power management
802.11 compliant power saving mode
Receiver Sensitivity3
802.11b, 1Mbps : -94dBm maximum
802.11b, 11Mbps : -86dBm maximum
802.11g, 6Mbps : -88dBm maximum
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 31
802.11g, 54Mbps : -74dBm maximum
802.11a, 6Mbps : -88dBm maximum
802.11a, 54Mbps : -74dBm maximum
802.11n, MCS07 : -69dBm maximum
802.11n, MCS15 : -66dBm maximum
802.11ac, 1SS, MCS-0 : -86dBm maximum
802.11ac, 1SS, MCS-9 : -61dBm maximum
802.11ac, 2SS, MCS-0 : -83dBm maximum
802.11ac, 2SS, MCS-9 : -58dBm maximum
Antenna type
High efficiency antenna with spatial diversity, mounted in the display enclosure
Two embedded dual band 2.4/5 GHz antennas are provided to the card to support WLAN MIMO communications and Bluetooth communications
Form Factor
PCI-Express M.2 MiniCard
Dimensions
Type 2230 : 2.3 x 22.0 x 30.0 mm
Or Type 1630 : 2.3 x 16.0 x 30.0 mm
Weight
Type 2230 : 2.8g
Or
Type 1630 : 2g
Operating Voltage
3.3v +/- 9%
Temperature
Operating Non-operating
14° to 158° F (–10° to 70° C) –40° to 176° F (–40° to 80° C)
Humidity
Operating Non-operating
10% to 90% (non-condensing) 5% to 95% (non-condensing)
Altitude
Operating Non-operating
0 to 10,000 ft (3,048 m) 0 to 50,000 ft (15,240 m)
LED Activity
LED Amber – Radio OFF; LED White – Radio ON
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 32
1. Check latest software/driver release for updates on supported security features.
2. Maximum output power may vary by country according to local regulations.
3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation)
and a packet error rate of 10% for 802.11a/g (OFDM modulation).
Wireless LAN Standards
IEEE 802.11a
IEEE 802.11b IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac
Interoperability
Wi-Fi certified
Frequency Band
802.11b/g/n
2.402 – 2.482 GHz
Note:
The FCC has declared as of January 1, 2015 products that utilize passive scanning on channel 12/13 and are capable of transmitting must fully comply with requirements of 15.247 or otherwise disable those channels.
802.11a/n
4.9 – 4.95 GHz (Japan) 5.15 – 5.25 GHz 5.25 – 5.35 GHz 5.47 – 5.725 GHz 5.825 – 5.850 GHz
Note: Indonesia only supports 5.725 - 5.825 GHz (CH149 - CH161)
Data Rates
802.11b: 1, 2, 5.5, 11 Mbps 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz) 802.11ac : MCS0 ~ MCS7, (1SS) (20MHz, 40MHz, and
80MHz)
Intel® Dual Band Wireless-AC 3168 802.11 a/b/g/n/ac (1x1) WiFi and Bluetooth® 4.2 combo
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 33
Modulation
Direct Sequence Spread Spectrum BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM
Security1
IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g
mode only
AES-CCMP: 128 bit in hardware 802.1x authentication WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES. WPA2 certification IEEE 802.11i Cisco Certified Extensions, all versions through CCX4 and CCX
Lite
WAPI
Network Architecture Models
Ad-hoc (Peer to Peer) Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power2
802.11b : +16dBm minimum 802.11g : +14dBm minimum 802.11a : +14dBm minimum 802.11n HT20(2.4GHz) : +14dBm minimum 802.11n HT40(2.4GHz) : +12dBm minimum 802.11n HT20(5GHz) : +14dBm minimum 802.11n HT40(5GHz) : +12dBm minimum 802.11ac 80MHz(5GHz) : +11dBm minimum
Power Consumption
Transmit: 2.0 W (max)
Receive: 1.6 W (max)
Idle mode (PSP): 180 mW (WLAN Associated)
Idle mode: 50 mW (WLAN unassociated)
Connect Standby: 10 mW (WLAN+BT)
Radio disabled: 5 mW
Power Management
ACPI and PCI Express compliant power management
802.11 compliant power saving mode
Receiver Sensitivity3
802.11b, 1Mbps : -94dBm maximum
802.11b, 11Mbps : -86dBm maximum
802.11g, 6Mbps : -88dBm maximum
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 34
802.11g, 54Mbps : -74dBm maximum
802.11a, 6Mbps : -88dBm maximum
802.11a, 54Mbps : -74dBm maximum
802.11n, MCS07 : -69dBm maximum
802.11n, MCS15 : -66dBm maximum
802.11ac, 1SS, MCS-0 : -86dBm maximum
802.11ac, 1SS, MCS-9 : -61dBm maximum
802.11ac, 2SS, MCS-0 : -83dBm maximum
802.11ac, 2SS, MCS-9 : -58dBm maximum
Antenna type
High efficiency antenna with spatial diversity, mounted in the display enclosure
Two embedded dual band 2.4/5 GHz antennas are provided to the card to support WLAN MIMO communications and Bluetooth communications
Form Factor
PCI-Express M.2 MiniCard
Dimensions
Type 2230 : 2.3 x 22.0 x 30.0 mm
Or Type 1630 : 2.3 x 16.0 x 30.0 mm
Weight
Type 2230 : 2.8g
Or
Type 1630 : 2g
Operating Voltage
3.3v +/- 9%
Temperature
Operating Non-operating
14° to 158° F (–10° to 70° C) –40° to 176° F (–40° to 80° C)
Humidity
Operating Non-operating
10% to 90% (non-condensing) 5% to 95% (non-condensing)
Altitude
Operating Non-operating
0 to 10,000 ft (3,048 m) 0 to 50,000 ft (15,240 m)
LED Activity
LED Amber – Radio OFF; LED White – Radio ON
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 35
1. Check latest software/driver release for updates on supported security features.
2. Maximum output power may vary by country according to local regulations.
3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet error rate of 10% for 802.11a/g (OFDM modulation).
HP Integrated Module with Bluetooth 4.0/4.1/4.2 Wireless Technology
Bluetooth Specification
4.0/4.1/4.2 Compliant
Frequency Band
2402 to 2480 MHz
Number of Available Channels
Legacy : 0~79 (1 MHz/CH)
BLE : 0~39 (2 MHz/CH)
Data Rates and Throughput
Legacy : 3 Mbps data rate; throughput up to 2.17 Mbps
BLE : 1 Mbps data rate; throughput up to 0.2 Mbps
Legacy : Synchronous Connection Oriented links up to 3, 64 kbps, voice channels
Legacy : Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5) or 864 kbps symmetric (3-EV5)
Transmit Power
The Bluetooth component shall operate as a Class II Bluetooth device with a maximum transmit power of + 4 dBm for BR and EDR.
Receiver Sensitivity
Legacy
Modulation
0.01% BER
0.001% BER
GFSK
-80 dBm
-70 dBm
π/4-DQPSK
-80 dBm
-70 dBm
8DPSK
-80 dBm
-70 dBm
Power Consumption
Peak (Tx) 330 mW Peak (Rx) 230 mW Selective Suspend 17 mW
Range
Legacy Up to 33 ft (10 m)
BLE Up to 99 ft (30 m)
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 36
Electrical Interface
USB 2.0 compliant
Bluetooth Software Supported
Link Topology
Microsoft Windows Bluetooth Software
Electrical Interface
Bluetooth Software Supported
Security
Point to Point, Multipoint Pico Nets up to 7 slaves
Full support of Bluetooth Security Provisions
Power Management
Certifications
Microsoft Windows ACPI, and USB Bus Support
Self-configurable to optimize power conservation in all operating modes, including Standby, Hold, Park, and Sniff
Security
All necessary regulatory approvals for supported countries, including:
Certifications
Bluetooth Profiles Supported
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
Power Management
Certifications
ETS 300 328, ETS 300 826
Low Voltage Directive IEC950
Certifications
Bluetooth Profiles Supported
UL, CSA, and CE Mark
Serial Port Profile (SPP)1 Service Discovery Application Profile (SDAP) Dial-Up Networking (DUN)
1,2
Generic Object Exchange Profile (GOEP)
1,2
Object Push Profile (OPP)
1,2
Hard Copy Cable Replacement (HCRP)
1,2
Personal Area Networking Profile (PAN)
1,2
Human Interface Device Profile (HID)
1,2
Hands Free Profile (HFP) Advanced Audio Distribution Profile (A2DP)
Audio Video Remote Control Profile (AVRCP)
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 37
Bluetooth V4.1/V4.2 support feature
V4.1: ESR5/6/7 compliant
V4.2: ESR8 compliant, LE Secure Connection – Basic.
STORAGE AND DRIVES
500 GB 7200rpm Self Encrypting Drive (FIPS­140-2) (Opal 2)
Drive Weight
0.21 lbs (95 g)
Capacity
500 GB
Height
0.28 in (7 mm)
Width
2.75 in (69.85 mm)
Interface
ATA-8, SATA 3.0
Transfer Rate
Synchronous (maximum)
600 MB/s
Seek Time (typical reads, including settling)
Single Track
1.5 ms
Average
12 ms
Maximum
21 ms
Cache
32 MB
Rotational Speed
7200 rpm
Logical Blocks
976,773,168
Operating Temperature
32° to 140° F (0° to 60° C) [top cover temp]
Features
ATA Security; TCG Opal 2.x, FIPS, S.M.A.R.T., NCQ, Ultra DMA ,
500 GB 7200rpm Hard Drive
Drive Weight
0.20 lbs (92 g) ~ 0.21 lbs (95 g)
Capacity
500 GB
Height
0.28 in (7 mm)
Width
2.75 in (69.85 mm)
Interface
ATA-8, SATA 3.0
Transfer Rate
Synchronous (maximum)
600 MB/s
Seek Time (typical reads, including settling)
Single Track
1.5 ms ~ 2 ms
Average
11 ms ~ 13 ms
Maximum
18 ms ~ 22 ms
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 38
Cache
32 MB
Rotational Speed
7200 rpm
Logical Blocks
976,773,168
Operating Temperature
32° to 140° F (0° to 60° C) [case temp]
Features
ATA Security, S.M.A.R.T., NCQ, Ultra DMA
500 GB 7200rpm Self­Encrypting Drive (Opal 2)
Drive Weight
0.21 lbs (95 g)
Capacity
500 GB
Height
0.28 in (7 mm)
Width
2.75 in (69.85 mm)
Interface
ATA-8, SATA 3.0
Transfer Rate
Synchronous (maximum)
600 MB/s
Seek Time (typical reads, including settling)
Single Track
1.5ms
Average
12ms
Maximum
21 ms
Cache
32 MB
Rotational Speed
7200rpm
Logical Blocks
976,773,168
Operating Temperature
32° to 140° F (0° to 60° C) [top cover temp]
Features
ATA Security; TCG Opal 2.x, S.M.A.R.T., NCQ, Ultra DMA
1 TB 5400rpm Hard Drive
Drive Weight
0.21 lbs (94 g)- 0.21 lbs ( 95 g)
Capacity
1TB
Height
0.28 in (7 mm)
Width
2.75 in (69.85 mm)
Interface
ATA-8, SATA 3.0
Transfer Rate
Synchronous (maximum)
600 MB/s
Seek Time (typical reads, including settling)
Single Track
2ms
Average
12ms-13ms
Maximum
18ms- 22ms
Cache
Up to 32 MB
Rotational Speed
5400rpm
Logical Blocks
1,953,525,168
Operating Temperature
32° to 140° F (0° to 60° C) [case temp]
Features
ATA Security, S.M.A.R.T., NCQ, Ultra DMA
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 39
128 GB SATA-3 Value Solid State Drive
Drive Weight
0.01 lb (6 g) ~ 0.02 lb (10 g)
Capacity
128 GB
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Interface
ATA-8, SATA 3.0
Performance Maximum Sequential Read
Maximum Sequential Write
Up To 535 MB/s
Up To 515 MB/s
Logical Blocks
250,069,680
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Features
DIPM; TRIM; DEVSLP
256 GB PCIe Gen3x4 NVMe TLC Solid State Drive
Drive Weight
M.2 2280
Capacity
256 GB
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Interface
PCIe NVMe Gen3X4
Performance Maximum Sequential Read
Maximum Sequential Write
Up to 2600 MB/s
Up to 900 MB/s
Logical Blocks
500,118,192
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Features
ATA Security (Option); TRIM; L1.2
512 GB PCIe Gen3x4 NVMe TLC Solid State Drive
Drive Weight
M.2 2280
Capacity
512 GB
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Interface
PCIe NVMe Gen3X4
Performance Maximum Sequential Read
Maximum Sequential Write
Up to 2600 MB/s
Up to 1400 MB/s
Logical Blocks
1,000,215,216
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Features
ATA Security (Option); TRIM; L1.2
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 40
256 GB SATA-3 TLC Self­Encrypting Solid State Drive (Opal 2)
Drive Weight
M.2 2280
Capacity
256 GB
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Interface
ATA-8, SATA 3.0
Performance Maximum Sequential Read
Maximum Sequential Write
Up to 530 MB/s
Up to 515 MB/s
Logical Blocks
500,118,192
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Features
ATA Security; TCG Opal 2.0; DIPM; TRIM; DEVSLP
POWER
HP 45W Smart AC Adapter
Dimensions (H x W x D)
9.5 x 4.0 x 2.65 cm)
Weight
unit: 200g +/- 10g
Input
90 to 265 VAC
Input Efficiency
87.74% at 115Vac and 88.4% at 230Vac
Input frequency range
47 to 63 Hz
Input AC current
Max. 1.4 A at 90 Vac
Output
Output power
45W
DC output
19.5V
Hold-up time
5 ms at 115 Vac input
Output current limit
<8.0A
AC Connector (Ac Inlet)
C6 (3pin/with grounded, with Smart ID DC connector)
Environmental Design
Operating temperature
32° to 95° F (0° to 35° C)
Non-operating (storage) temperature
-4° to 185° F (-20° to 85° C)
Altitude
0 to 16,400 ft (0 to 5,000 m)
Humidity
20% to 95%
Storage Humidity
10% to 95%
EMI and Safety Certifications
*CE Mark - full compliance with LVD and EMC directives * Worldwide safety standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE. * MTBF - over 200,000 hours at 25°C ambient condition.
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 41
HP 45W Smart AC Adapter (2 Prong)
Dimensions (H x W x D)
95.0x40.0x26.5mm
Weight
unit: 200g +/- 10g
Input
90 to 265 VAC
Input Efficiency
87.74% at 115Vac and 88.4% at 230Vac
Input frequency range
47 to 63 Hz
Input AC current
Max. 1.4 A at 90 Vac
Output
Output power
45W
DC output
19.5V
Hold-up time
5 ms at 115Vac input
Output current limit
<8.0A
AC Connector (Ac Inlet)
C8 (2 pin/non-grounded, with Smart ID DC connector)
Environmental Design
Operating temperature
32° to 95° F (0° to 35° C)
Non-operating (storage) temperature
-4° to 185° F (-20° to 85° C)
Altitude
0 to 16,400 ft (0 to 5,000 m)
Humidity
20% to 95%
Storage Humidity
10% to 95%
EMI and Safety Certifications
*CE Mark - full compliance with LVD and EMC directives * Worldwide safety standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE. * MTBF - over 200,000 hours at 25°C ambient condition.
HP 65W Smart AC Adapter
Dimensions
107.0x47.0x30.0mm
Weight
unit: 250g +/- 10g
Input
90 to 265 VAC
Input Efficiency
88.0 % at 115 Vac and 89.0 % at 230 Vac
Input frequency range
47 to 63 Hz
Input AC current
1.7 A at 90 Vac
Output
Output power
65W
DC output
19.5V
Hold-up time
5 ms at 115 Vac input
Output current limit
<11.0A
AC Connector (Ac Inlet)
C6 (3pin/with grounded, with Smart ID DC connector)
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 42
Environmental Design
Operating temperature
32° to 95° F (0° to 35° C)
Non-operating (storage) temperature
-4° to 185° F (-20° to 85° C)
Altitude
0 to 16,400 ft (0 to 5,000 m)
Humidity
20% to 95%
Storage Humidity
10% to 95%
Certifications
*CE Mark - full compliance with LVD and EMC directives * Worldwide safety standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE. * MTBF - over 200,000 hours at 25°C ambient condition.
HP 65W Smart AC Adapter EM
Dimensions
102.0x55.0x30.0mm
Weight
unit: 350g +/- 10g
Input
90 to 265 VAC
Input Efficiency
87.0% min at 115 VAC and 230Vac
Input frequency range
47 to 63 Hz
Input AC current
1.7 A at 90 VAC
Output
Output power
65W
DC output
19.5V
Hold-up time
5 ms at 115 Vac input
Output current limit
<11.0A
AC Connector (Ac Inlet)
C6 (3pin/with grounded, with Smart ID DC connector)
Environmental Design
Operating temperature
32° to 95° F (0° to 35° C)
Non-operating (storage) temperature
-4° to 185° F (-20° to 85° C)
Altitude
0 to 16,400 ft (0 to 5,000 m)
Humidity
20% to 95%
Storage Humidity
10% to 95%
EMI and Safety Certifications
*CE Mark - full compliance with LVD and EMC directives * Worldwide safety standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE. * MTBF - over 200,000 hours at 25°C ambient condition.
HP 3-cell Long Life Li-Ion (49 WHr)
Dimensions (H x W x L)
8.30 mm x127.5 mm x 160.25 mm
Weight
225g
Cells/Type
3 cell Lithium-Ion Polymer cell / 505295
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 43
Energy
Voltage
11.55V
Amp-hour capacity
4250mAh
Watt-hour capacity
49Wh
Temperature
Operating (Charging)
0~45 C
Operating (Discharging)
-10~60 C
Fuel Gauge LED
NA
Warranty
1000 cycles > 65% (at 23˚C)
Optional Travel Battery Available
No
HP 3-cell Long Life Li-Ion (51 WHr)
Dimensions (H x W x L)
6.8mm x 102.8mm x 198mm
Weight
235g
Cells/Type
3cell Lithium-Ion Polymer cell / 506480
Energy
Voltage
11.55V
Amp-hour capacity
4420mAh
Watt-hour capacity
51wh
Temperature
Operating (Charging)
0~45 C
Operating (Discharging)
-10~60 C
Fuel Gauge LED
NA
Warranty
1000 cycles > 65% (at 23˚C)
Optional Travel Battery Available
No
ENVIRONMENTAL
STORAGE AND DRIVES
500 GB 7200rpm Self Encrypting Drive (FIPS­140-2) (Opal 2)
Drive Weight
0.21 lbs (95 g)
Capacity
500 GB
Height
0.28 in (7 mm)
Width
2.75 in (69.85 mm)
Interface
ATA-8, SATA 3.0
Transfer Rate
Synchronous (maximum)
600 MB/s
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 44
Seek Time (typical reads, including settling)
Single Track
1.5 ms
Average
12 ms
Maximum
21 ms
Cache
32 MB
Rotational Speed
7200 rpm
Logical Blocks
976,773,168
Operating Temperature
32° to 140° F (0° to 60° C) [top cover temp]
Features
ATA Security; TCG Opal 2.x, FIPS, S.M.A.R.T., NCQ, Ultra DMA ,
500 GB 7200rpm Hard Drive
Drive Weight
0.20 lbs (92 g) ~ 0.21 lbs (95 g)
Capacity
500 GB
Height
0.28 in (7 mm)
Width
2.75 in (69.85 mm)
Interface
ATA-8, SATA 3.0
Transfer Rate
Synchronous (maximum)
600 MB/s
Seek Time (typical reads, including settling)
Single Track
1.5 ms ~ 2 ms
Average
11 ms ~ 13 ms
Maximum
18 ms ~ 22 ms
Cache
32 MB
Rotational Speed
7200 rpm
Logical Blocks
976,773,168
Operating Temperature
32° to 140° F (0° to 60° C) [case temp]
Features
ATA Security, S.M.A.R.T., NCQ, Ultra DMA
500 GB 7200rpm Self­Encrypting Drive (Opal 2)
Drive Weight
0.21 lbs (95 g)
Capacity
500 GB
Height
0.28 in (7 mm)
Width
2.75 in (69.85 mm)
Interface
ATA-8, SATA 3.0
Transfer Rate
Synchronous (maximum)
600 MB/s
Seek Time (typical reads, including settling)
Single Track
1.5ms
Average
12ms
Maximum
21 ms
Cache
32 MB
Rotational Speed
7200rpm
Logical Blocks
976,773,168
Operating Temperature
32° to 140° F (0° to 60° C) [top cover temp]
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 45
Features
ATA Security; TCG Opal 2.x, S.M.A.R.T., NCQ, Ultra DMA
1 TB 5400rpm Hard Drive
Drive Weight
0.21 lbs (94 g)- 0.21 lbs ( 95 g)
Capacity
1TB
Height
0.28 in (7 mm)
Width
2.75 in (69.85 mm)
Interface
ATA-8, SATA 3.0
Transfer Rate
Synchronous (maximum)
600 MB/s
Seek Time (typical reads, including settling)
Single Track
2ms
Average
12ms-13ms
Maximum
18ms- 22ms
Cache
Up to 32 MB
Rotational Speed
5400rpm
Logical Blocks
1,953,525,168
Operating Temperature
32° to 140° F (0° to 60° C) [case temp]
Features
ATA Security, S.M.A.R.T., NCQ, Ultra DMA
128 GB SATA-3 Value Solid State Drive
Drive Weight
0.01 lb (6 g) ~ 0.02 lb (10 g)
Capacity
128 GB
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Interface
ATA-8, SATA 3.0
Performance Maximum Sequential Read
Maximum Sequential Write
Up To 535 MB/s
Up To 515 MB/s
Logical Blocks
250,069,680
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Features
DIPM; TRIM; DEVSLP
256 GB PCIe Gen3x4 NVMe TLC Solid State Drive
Drive Weight
M.2 2280
Capacity
256 GB
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Interface
PCIe NVMe Gen3X4
Performance Maximum Sequential Read
Maximum Sequential Write
Up to 2600 MB/s
Up to 900 MB/s
Logical Blocks
500,118,192
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 46
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Features
ATA Security (Option); TRIM; L1.2
512 GB PCIe Gen3x4 NVMe TLC Solid State Drive
Drive Weight
M.2 2280
Capacity
512 GB
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Interface
PCIe NVMe Gen3X4
Performance Maximum Sequential Read
Maximum Sequential Write
Up to 2600 MB/s
Up to 1400 MB/s
Logical Blocks
1,000,215,216
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Features
ATA Security (Option); TRIM; L1.2
256 GB SATA-3 TLC Self­Encrypting Solid State Drive (Opal 2)
Drive Weight
M.2 2280
Capacity
256 GB
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Interface
ATA-8, SATA 3.0
Performance Maximum Sequential Read
Maximum Sequential Write
Up to 530 MB/s
Up to 515 MB/s
Logical Blocks
500,118,192
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Features
ATA Security; TCG Opal 2.0; DIPM; TRIM; DEVSLP
POWER
HP 45W Smart AC Adapter
Dimensions (H x W x D)
9.5 x 4.0 x 2.65 cm)
Weight
unit: 200g +/- 10g
Input
90 to 265 VAC
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 47
Input Efficiency
87.74% at 115Vac and 88.4% at 230Vac
Input frequency range
47 to 63 Hz
Input AC current
Max. 1.4 A at 90 Vac
Output
Output power
45W
DC output
19.5V
Hold-up time
5 ms at 115 Vac input
Output current limit
<8.0A
AC Connector (Ac Inlet)
C6 (3pin/with grounded, with Smart ID DC connector)
Environmental Design
Operating temperature
32° to 95° F (0° to 35° C)
Non-operating (storage) temperature
-4° to 185° F (-20° to 85° C)
Altitude
0 to 16,400 ft (0 to 5,000 m)
Humidity
20% to 95%
Storage Humidity
10% to 95%
EMI and Safety Certifications
*CE Mark - full compliance with LVD and EMC directives * Worldwide safety standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE. * MTBF - over 200,000 hours at 25°C ambient condition.
HP 45W Smart AC Adapter (2 Prong)
Dimensions (H x W x D)
95.0x40.0x26.5mm
Weight
unit: 200g +/- 10g
Input
90 to 265 VAC
Input Efficiency
87.74% at 115Vac and 88.4% at 230Vac
Input frequency range
47 to 63 Hz
Input AC current
Max. 1.4 A at 90 Vac
Output
Output power
45W
DC output
19.5V
Hold-up time
5 ms at 115Vac input
Output current limit
<8.0A
AC Connector (Ac Inlet)
C8 (2 pin/non-grounded, with Smart ID DC connector)
Environmental Design
Operating temperature
32° to 95° F (0° to 35° C)
Non-operating (storage) temperature
-4° to 185° F (-20° to 85° C)
Altitude
0 to 16,400 ft (0 to 5,000 m)
Humidity
20% to 95%
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 48
Storage Humidity
10% to 95%
EMI and Safety Certifications
*CE Mark - full compliance with LVD and EMC directives * Worldwide safety standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE. * MTBF - over 200,000 hours at 25°C ambient condition.
HP 65W Smart AC Adapter
Dimensions
107.0x47.0x30.0mm
Weight
unit: 250g +/- 10g
Input
90 to 265 VAC
Input Efficiency
88.0 % at 115 Vac and 89.0 % at 230 Vac
Input frequency range
47 to 63 Hz
Input AC current
1.7 A at 90 Vac
Output
Output power
65W
DC output
19.5V
Hold-up time
5 ms at 115 Vac input
Output current limit
<11.0A
AC Connector (Ac Inlet)
C6 (3pin/with grounded, with Smart ID DC connector)
Environmental Design
Operating temperature
32° to 95° F (0° to 35° C)
Non-operating (storage) temperature
-4° to 185° F (-20° to 85° C)
Altitude
0 to 16,400 ft (0 to 5,000 m)
Humidity
20% to 95%
Storage Humidity
10% to 95%
Certifications
*CE Mark - full compliance with LVD and EMC directives * Worldwide safety standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE. * MTBF - over 200,000 hours at 25°C ambient condition.
HP 65W Smart AC Adapter EM
Dimensions
102.0x55.0x30.0mm
Weight
unit: 350g +/- 10g
Input
90 to 265 VAC
Input Efficiency
87.0% min at 115 VAC and 230Vac
Input frequency range
47 to 63 Hz
Input AC current
1.7 A at 90 VAC
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 49
Output
Output power
65W
DC output
19.5V
Hold-up time
5 ms at 115 Vac input
Output current limit
<11.0A
AC Connector (Ac Inlet)
C6 (3pin/with grounded, with Smart ID DC connector)
Environmental Design
Operating temperature
32° to 95° F (0° to 35° C)
Non-operating (storage) temperature
-4° to 185° F (-20° to 85° C)
Altitude
0 to 16,400 ft (0 to 5,000 m)
Humidity
20% to 95%
Storage Humidity
10% to 95%
EMI and Safety Certifications
*CE Mark - full compliance with LVD and EMC directives * Worldwide safety standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE. * MTBF - over 200,000 hours at 25°C ambient condition.
HP 3-cell Long Life Li-Ion (49 WHr)
Dimensions (H x W x L)
8.30 mm x127.5 mm x 160.25 mm
Weight
225g
Cells/Type
3 cell Lithium-Ion Polymer cell / 505295
Energy
Voltage
11.55V
Amp-hour capacity
4250mAh
Watt-hour capacity
49Wh
Temperature
Operating (Charging)
0~45 C
Operating (Discharging)
-10~60 C
Fuel Gauge LED
NA
Warranty
1000 cycles > 65% (at 23˚C)
Optional Travel Battery Available
No
HP 3-cell Long Life Li-Ion (51 WHr)
Dimensions (H x W x L)
6.8mm x 102.8mm x 198mm
Weight
235g
Cells/Type
3cell Lithium-Ion Polymer cell / 506480
Energy
Voltage
11.55V
Amp-hour capacity
4420mAh
Watt-hour capacity
51wh
Temperature Operating (Charging)
0~45 C
Operating (Discharging)
-10~60 C
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 50
Fuel Gauge LED
NA
Warranty
1000 cycles > 65% (at 23˚C)
Optional Travel Battery Available
No
ENVIRONMENTAL
HP EliteBook 725 G4 Notebook PC
Eco-Label Certifications & declarations
This product has received or is in the process of being certified to the following approvals and may be labeled with one or more of these marks:
IT ECO declaration US ENERGY STAR® EPEAT Gold registered in the United States. See http://www.epeat.net for
registration status in your country.
System Configuration
The configuration used for the Energy Consumption and Declared Noise Emissions data for the Notebook model is based on a “Typically Configured Notebook”.
Energy Consumption (in accordance with US ENERGY STAR® test method)
115VAC, 60Hz
230VAC, 50Hz
100VAC, 50Hz
Normal Operation (Short idle)
8.12 W
8.99 W
8.23 W
Normal Operation (Long idle)
6.78 W
6.77 W
6.23 W
Sleep
0.76 W
0.77 W
0.76 W
Off
0.49 W
0.53 W
0.49 W
Note:
Energy efficiency data listed is for an ENERGY STAR® compliant product if offered within the model family. HP computers marked with the ENERGY STAR® Logo are
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 51
compliant with the applicable U.S. Environmental Protection Agency (EPA) ENERGY STAR® specifications for computers. If a model family does not offer ENERGY STAR® compliant configurations, then energy efficiency data listed is for a typically configured PC featuring a hard disk drive, a high efficiency power supply, and a Microsoft Windows® operating system.
Heat Dissipation*
115VAC, 60Hz
230VAC, 50Hz
100VAC, 50Hz
Normal Operation (Short idle)
28 BTU/hr
31 BTU/hr
28 BTU/hr
Normal Operation (Long idle)
23 BTU/hr
23 BTU/hr
21 BTU/hr
Sleep
3 BTU/hr
3 BTU/hr
3 BTU/hr
Off
2 BTU/hr
2 BTU/hr
2 BTU/hr
*NOTE: Heat dissipation is calculated based on the measured watts, assuming the service level is attained for one hour.
Declared Noise Emissions (in accordance with ISO 7779 and ISO
9296)
Sound Power
(L
WAd
, bels)
Sound Pressure
(L
pAm
, decibels)
Typically Configured – Idle
3.1
24
Fixed Disk – Random writes
3.1
25
Batteries
This battery(s) in this product comply with EU Directive 2006/66/EC
Batteries used in the product do not contain:
Mercury greater the1ppm by weight Cadmium greater than 20ppm by weight
Battery size: CR2320 (coin cell) Battery type: Lithium
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 52
Additional Information
This product is in compliance with the Restrictions of Hazardous Substances
(RoHS) directive - 2011/65/EC.
This HP product is designed to comply with the Waste Electrical and
Electronic Equipment (WEEE) Directive – 2002/96/EC.
This product is in compliance with California Proposition 65 (State of
California; Safe Drinking Water and Toxic Enforcement Act of 1986).
This product is in compliance with the IEEE 1680 (EPEAT) standard at the
gold level, see www.epeat.net
Plastics parts weighing over 25 grams used in the product are marked per
ISO11469 and ISO1043.
This product contains 0% post-consumer recycled plastic (by wt.) This product is 96.7% recycle-able when properly disposed of at end of life.
Packaging Materials
External:
PAPER/Corrugated
328 g
Internal:
PLASTIC/Expanded Polyethylene - EPE
38 g
PLASTIC/Polyethylene low density - LDPE
14 g
PLASTIC/Polypropylene - PP
3 g
The plastic packaging material contains at least 50% recycled content.
The corrugated paper packaging materials contains at least 70% recycled content.
Material Usage
This product does not contain any of the following substances in excess of regulatory limits (refer to the HP General Specification for the Environment at
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/gse.pdf):
Asbestos Certain Azo Colorants Certain Brominated Flame Retardants – may not be used as flame
retardants in plastics
Cadmium Chlorinated Hydrocarbons Chlorinated Paraffins Formaldehyde Halogenated Diphenyl Methanes Lead carbonates and sulfates Lead and Lead compounds Mercuric Oxide Batteries Nickel – finishes must not be used on the external surface designed to be
frequently handled or carried by the user.
Ozone Depleting Substances Polybrominated Biphenyls (PBBs) Polybrominated Biphenyl Ethers (PBBEs) Polybrominated Biphenyl Oxides (PBBOs) Polychlorinated Biphenyl (PCB) Polychlorinated Terphenyls (PCT) Polyvinyl Chloride (PVC) – except for wires and cables, and certain retail
packaging has been voluntarily removed from most applications.
Radioactive Substances
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 53
Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
Packaging Usage
HP follows these guidelines to decrease the environmental impact of product packaging:
Eliminate the use of heavy metals such as lead, chromium, mercury and
cadmium in packaging materials.
Eliminate the use of ozone-depleting substances (ODS) in packaging
materials.
Design packaging materials for ease of disassembly. Maximize the use of post-consumer recycled content materials in
packaging materials.
Use readily recyclable packaging materials such as paper and corrugated
materials.
Reduce size and weight of packages to improve transportation fuel
efficiency.
Plastic packaging materials are marked according to ISO 11469 and DIN
6120 standards.
End-of-life Management and Recycling
Hewlett-Packard offers end-of-life HP product return and recycling programs in many geographic areas. To recycle your product, please go to:
http://www.hp.com/go/reuse-recycle or contact your nearest HP sales office.
Products returned to HP will be recycled, recovered or disposed of in a responsible manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each product type for use by treatment facilities. This information (product disassembly instructions) is posted on the Hewlett Packard web site at:
http://www.hp.com/go/recyclers. These instructions may be used by recyclers and
other WEEE treatment facilities as well as HP OEM customers who integrate and re­sell HP equipment.
HP Inc.
Environmental Information
For more information about HP’s commitment to the environment:
Global Citizenship Report
http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html
Eco-label certifications
http://www8.hp.com/us/en/hp-information/environment/ecolabels.html
ISO 14001 certificates:
http://h20195.www2.hp.com/V2/GetDocument.aspx?docname=c04755842
and
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/cert.pdf
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 54
HP EliteBook 745 G4 Notebook PC
Eco-Label Certifications & declarations
This product has received or is in the process of being certified to the following approvals and may be labeled with one or more of these marks:
IT ECO declaration US ENERGY STAR® EPEAT <Gold> registered in the United States. See http://www.epeat.net for registration status in
your country.
System Configuration
The configuration used for the Energy Consumption and Declared Noise Emissions data for the Notebook model is based on a “Typically Configured Notebook”.
Energy Consumption (in accordance with US ENERGY STAR® test method)
115VAC, 60Hz
230VAC, 50Hz
100VAC, 50Hz
Normal Operation (Short idle)
8.78 W
9.59 W
8.76 W
Normal Operation (Long idle)
5.64 W
6.37 W
6.47 W
Sleep
0.73 W
0.74 W
0.73 W
Off
0.50 W
0.52 W
0.49 W
Note:
Energy efficiency data listed is for an ENERGY STAR® compliant product if offered within the model family. HP computers marked with the ENERGY STAR® Logo are compliant with the applicable U.S. Environmental Protection Agency (EPA) ENERGY STAR® specifications for computers. If a model family does not offer ENERGY STAR® compliant configurations, then energy efficiency data listed is for a typically configured PC featuring a hard disk drive, a high efficiency power supply, and a Microsoft Windows® operating system.
Heat Dissipation*
115VAC, 60Hz
230VAC, 50Hz
100VAC, 50Hz
Normal Operation (Short idle)
30 BTU/hr
33 BTU/hr
30 BTU/hr
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 55
Normal Operation (Long idle)
19 BTU/hr
22 BTU/hr
22 BTU/hr Sleep
2 BTU/hr
3 BTU/hr
2 BTU/hr
Off
2 BTU/hr
2 BTU/hr
2 BTU/hr
*NOTE: Heat dissipation is calculated based on the measured watts, assuming the service level is attained for one hour.
Declared Noise Emissions (in accordance with ISO 7779 and ISO
9296)
Sound Power
(L
WAd
, bels)
Sound Pressure
(L
pAm
, decibels)
Typically Configured – Idle
3.1
21
Fixed Disk – Random writes
3.4
24
Batteries
This battery(s) in this product comply with EU Directive 2006/66/EC
Batteries used in the product do not contain:
Mercury greater the1ppm by weight Cadmium greater than 20ppm by weight
Battery size: CR2032 (coin cell) Battery type: Lithium
Additional Information
This product is in compliance with the Restrictions of Hazardous Substances (RoHS) directive -
2011/65/EC.
This HP product is designed to comply with the Waste Electrical and Electronic Equipment (WEEE)
Directive – 2002/96/EC.
This product is in compliance with California Proposition 65 (State of California; Safe Drinking Water
and Toxic Enforcement Act of 1986).
This product is in compliance with the IEEE 1680 (EPEAT) standard at the <Gold> level, see
www.epeat.net
Plastics parts weighing over 25 grams used in the product are marked per ISO11469 and ISO1043. This product contains 0% post-consumer recycled plastic (by wt.) This product is 94.6% recycle-able when properly disposed of at end of life.
Packaging Materials
External:
PAPER/Corrugated
323 g
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 56
Internal:
PLASTIC/Polyethylene Expanded - EPE
38 g
PLASTIC/Polyethylene low density - LDPE
15 g PLASTIC/Polypropylene - PP
4 g
The plastic packaging material contains at least 50% recycled content.
The corrugated paper packaging materials contains at least 70% recycled content.
Material Usage
This product does not contain any of the following substances in excess of regulatory limits (refer to the HP General Specification for the Environment at
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/gse.pdf):
Asbestos Certain Azo Colorants Certain Brominated Flame Retardants – may not be used as flame retardants in plastics Cadmium Chlorinated Hydrocarbons Chlorinated Paraffins Formaldehyde Halogenated Diphenyl Methanes Lead carbonates and sulfates Lead and Lead compounds Mercuric Oxide Batteries Nickel – finishes must not be used on the external surface designed to be frequently handled or
carried by the user.
Ozone Depleting Substances Polybrominated Biphenyls (PBBs) Polybrominated Biphenyl Ethers (PBBEs) Polybrominated Biphenyl Oxides (PBBOs) Polychlorinated Biphenyl (PCB) Polychlorinated Terphenyls (PCT) Polyvinyl Chloride (PVC) – except for wires and cables, and certain retail packaging has been
voluntarily removed from most applications.
Radioactive Substances Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
Packaging Usage
HP follows these guidelines to decrease the environmental impact of product packaging:
Eliminate the use of heavy metals such as lead, chromium, mercury and cadmium in packaging
materials.
Eliminate the use of ozone-depleting substances (ODS) in packaging materials. Design packaging materials for ease of disassembly. Maximize the use of post-consumer recycled content materials in packaging materials. Use readily recyclable packaging materials such as paper and corrugated materials. Reduce size and weight of packages to improve transportation fuel efficiency. Plastic packaging materials are marked according to ISO 11469 and DIN 6120 standards.
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 57
End-of-life Management and Recycling
Hewlett-Packard offers end-of-life HP product return and recycling programs in many geographic areas. To recycle your product, please go to: http://www.hp.com/go/reuse-recycle or contact your nearest HP sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each product type for use by treatment facilities. This information (product disassembly instructions) is posted on the Hewlett Packard web site at: http://www.hp.com/go/recyclers. These instructions may be used by recyclers and other WEEE treatment facilities as well as HP OEM customers who integrate and re-sell HP equipment.
HP Inc.
Environmental Information
For more information about HP’s commitment to the environment:
Global Citizenship Report
http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html
Eco-label certifications
http://www8.hp.com/us/en/hp-information/environment/ecolabels.html
ISO 14001 certificates:
http://h20195.www2.hp.com/V2/GetDocument.aspx?docname=c04755842
and
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/cert.pdf
HP EliteBook 755 G4 Notebook PC
Eco-Label Certifications & declarations
This product has received or is in the process of being certified to the following approvals and may be labeled with one or more of these marks:
IT ECO declaration US ENERGY STAR® EPEAT <Gold> registered in the United States. See http://www.epeat.net for registration
status in your country.
System Configuration
The configuration used for the Energy Consumption and Declared Noise Emissions data for the Notebook model is based on a “Typically Configured Notebook”.
Energy Consumption (in accordance with US ENERGY STAR® test method)
115VAC, 60Hz
230VAC, 50Hz
100VAC, 60Hz
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 58
Normal Operation (Short idle)
9.16 W
9.48 W
9.10 W
Normal Operation (Long idle)
6.02 W
6.47 W
6.08 W
Sleep
0.74 W
0.72 W
0.73 W
Off
0.52 W
0.50 W
0.52 W
Note:
Energy efficiency data listed is for an ENERGY STAR® compliant product if offered within the model family. HP computers marked with the ENERGY STAR® Logo are compliant with the applicable U.S. Environmental Protection Agency (EPA) ENERGY STAR® specifications for computers. If a model family does not offer ENERGY STAR® compliant configurations, then energy efficiency data listed is for a typically configured PC featuring a hard disk drive, a high efficiency power supply, and a Microsoft Windows® operating system.
Heat Dissipation*
115VAC, 60Hz
230VAC, 50Hz
100VAC, 60Hz
Normal Operation (Short idle)
31 BTU/hr
32 BTU/hr
31 BTU/hr
Normal Operation (Long idle)
20 BTU/hr
22 BTU/hr
21 BTU/hr
Sleep
3 BTU/hr
2 BTU/hr
2 BTU/hr
Off
2 BTU/hr
1 BTU/hr
2 BTU/hr
*NOTE: Heat dissipation is calculated based on the measured watts, assuming the service level is attained for one hour.
Declared Noise Emissions (in accordance with ISO 7779 and ISO 9296)
Sound Power
(L
WAd
, bels)
Sound Pressure
(L
pAm
, decibels)
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 59
Typically Configured – Idle
2.9
22
Fixed Disk – Random writes
3.5
28
Batteries
This battery(s) in this product comply with EU Directive 2006/66/EC
Batteries used in the product do not contain:
Mercury greater the1ppm by weight Cadmium greater than 20ppm by weight
Battery size: CR2032 (coin cell) Battery type: Lithium
Additional Information
This product is in compliance with the Restrictions of Hazardous Substances (RoHS)
directive - 2011/65/EC.
This HP product is designed to comply with the Waste Electrical and Electronic Equipment
(WEEE) Directive – 2002/96/EC.
This product is in compliance with California Proposition 65 (State of California; Safe
Drinking Water and Toxic Enforcement Act of 1986).
This product is in compliance with the IEEE 1680 (EPEAT) standard at the <Gold> level, see
www.epeat.net
Plastics parts weighing over 25 grams used in the product are marked per ISO11469 and
ISO1043.
This product contains 0% post-consumer recycled plastic (by wt.) This product is 95.2% recycle-able when properly disposed of at end of life.
Packaging Materials
External:
PAPER/Corrugated
348 g
Internal:
PLASTIC/EPE-Expanded Polyethylene
38 g PLASTIC/Polyethylene low density
15 g PLASTIC/Polypropylene – PP
5 g
The plastic packaging material contains at least 50.0% recycled content.
The corrugated paper packaging materials contains at least 70.0% recycled content.
Material Usage
This product does not contain any of the following substances in excess of regulatory limits (refer to the HP General Specification for the Environment at
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/gse.pdf):
Asbestos Certain Azo Colorants Certain Brominated Flame Retardants – may not be used as flame retardants in plastics Cadmium Chlorinated Hydrocarbons Chlorinated Paraffins Formaldehyde Halogenated Diphenyl Methanes Lead carbonates and sulfates
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 60
Lead and Lead compounds Mercuric Oxide Batteries Nickel – finishes must not be used on the external surface designed to be frequently
handled or carried by the user.
Ozone Depleting Substances Polybrominated Biphenyls (PBBs) Polybrominated Biphenyl Ethers (PBBEs) Polybrominated Biphenyl Oxides (PBBOs) Polychlorinated Biphenyl (PCB) Polychlorinated Terphenyls (PCT) Polyvinyl Chloride (PVC) – except for wires and cables, and certain retail packaging has
been voluntarily removed from most applications.
Radioactive Substances Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
Packaging Usage
HP follows these guidelines to decrease the environmental impact of product packaging:
Eliminate the use of heavy metals such as lead, chromium, mercury and cadmium in
packaging materials.
Eliminate the use of ozone-depleting substances (ODS) in packaging materials. Design packaging materials for ease of disassembly. Maximize the use of post-consumer recycled content materials in packaging materials. Use readily recyclable packaging materials such as paper and corrugated materials. Reduce size and weight of packages to improve transportation fuel efficiency. Plastic packaging materials are marked according to ISO 11469 and DIN 6120 standards.
End-of-life Management and Recycling
Hewlett-Packard offers end-of-life HP product return and recycling programs in many geographic areas. To recycle your product, please go to: http://www.hp.com/go/reuse-recycle or contact your nearest HP sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each product type for use by treatment facilities. This information (product disassembly instructions) is posted on the Hewlett Packard web site at: http://www.hp.com/go/recyclers. These instructions may be used by recyclers and other WEEE treatment facilities as well as HP OEM customers who integrate and re-sell HP equipment.
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 61
Hewlett-Packard Corporate Environmental Information
For more information about HP’s commitment to the environment:
Global Citizenship Report
http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html
Eco-label certifications
http://www8.hp.com/us/en/hp-information/environment/ecolabels.html
ISO 14001 certificates:
http://h20195.www2.hp.com/V2/GetDocument.aspx?docname=c04755842
and
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/cert.pdf
COUNTRY OF ORIGIN
China
QuickSpecs
HP EliteBook 725 G4 Notebook PC HP EliteBook 745 G4 Notebook PC HP EliteBook 755 G4 Notebook PC
Not all configuration components are available in all regions/countries.
Americas – HP EliteBook 700 G4 Series – December 2016 - c05330815
Page 62
Type
Description
Part Number
Docking
HP USB-C Travel Dock
T0K29AA#xxx
HP USB Travel Dock
T0K30AA#xxx
HP UltraSlim Docking Station
D9Y32AA#xxx
HP Elite USB-C Docking Station
X7W54AA
HP Adjustable Dual Display Stand
AW664AA
HP Display and Notebook Stand II
E8G00AA
Input/Output
HP Slim Wireless Keyboard and Mouse
T6L04AAxxx
HP USB Essential Keyboard and Mouse
H6L29AA
HP Conferencing Keyboard
K8P74AA
HP Ultrathin Wireless Mouse
L9V78AA
HP UC Speaker Phone
K7V16AA
HP UC Wired Headset
K7V17AA
HP Stereo 3.5mm Headset
T1A66AA
HP Stereo USB Headset
T1A67AA
HP UC Wireless Mono Headset
W3K08AA
HP UC Wireless Duo Headset
W3K09AA
HP USB Speaker Phone
X7N17AA
Memory
HP 4GB 2133MHz DDR4 Memory
T7B76AA
HP 8GB 2133MHz DDR4 Memory
T7B77AA
Power
HP 65W Slim AC Adapter
H6Y82AA#xxx
HP 90W Slim AC Adapter
H6Y83AA#xxx
HP 90W Slim Combo AC Adapter w/ USB
H6Y84AA#xxx
HP 45W Smart AC Adapter
H6Y88AA#xxx
HP 65W Smart AC Adapter
H6Y89AA#xxx
HP 90W Smart AC Adapter
H6Y90AA#xxx
HP Notebook Power Bank
N9F71AA#xxx
Storage
HP USB External DVDRW Drive
F2B56AA
Security
HP Combination Lock
T0Y15AA
HP Keyed Cable lock
T0Y14AA
Displays
HP EliteDisplay E232 23-inch Monitor
M1N98AA
HP EliteDisplay S231d 23-inch Notebook Docking Monitor
F3J72AA
HP Elite Display S140u 14-inch USB Portable Monitor
G8R65AA
Options and Accessories (Sold separately and availability may vary by country.)
©Copyright 2016 HP Development Company, L.P. The information contained herein is subject to change without notice. The only warranties are contained in the limited warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. AMD and Radeon are trademarks of Advanced Micro Devices, Inc. All Rights Reserved. Bluetooth is a trademark of its proprietor used by HP Inc. under license. ENERGY STAR is a registered trademark of the U.S. Environmental Protection Agency. AMD and Radeon are trademarks of Advanced Micro Devices, Inc. Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
Loading...
