Your Gateway Plasma TV
user'sguide
Setting up
Troubleshooting
Contents
1 Introducing Your Gateway Plasma TV or Plasma Monitor . . . . . . . . 1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Important Safeguards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Turning on the main power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Front panel controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Back panel connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Audio and video connections (plasma TV only) . . . . . . . . . . . . . . . . . . . . . . . . 14
RGB and DVI connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2 Connecting Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Understanding video connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Connecting your DVD player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Using component video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Using S-Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Using composite video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Connecting your HDTV set-top box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Using component video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Using RGB video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Connecting your VCR or video camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Using S-Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Using composite video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Using coaxial (RF) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Connecting off-air TV or cable TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Connecting external amplified speakers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Connecting an external receiver or amplifier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Connecting a subwoofer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Connecting a computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Using DVI video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Using RGB video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Connecting an external monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
3 Adjusting Your Plasma TV Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Using the OSD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
OSD menus and options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
i
4 Maintenance and Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
Cleaning and maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Cleaning the screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Cleaning the exterior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Avoiding image burn-in . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
Telephone support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
A Signal Frequency Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
TV, AV1, and AV2 inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
Component 1 and Component 2 inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
RGB and DVI inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
B Safety, Regulatory, and Legal Information. . . . . . . . . . . . . . . . . . . . . . . 55
Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
ii
Introducing Your
Gateway Plasma TV
or Plasma Monitor
This chapter provides basic information about your
Gateway Plasma TV or Plasma Monitor.
Read this chapter to learn about:
■ Features
■ Warnings and safeguards
■ Package contents
■ Controls and connections
If you have purchased the plasma monitor, not all options
are available.
The illustrations in this guide show the plasma TV unless
otherwise noted.
1
1
Chapter 1: Introducing Your Gateway Plasma TV or Plasma Monitor
Features
Plasma monitor
■ A bright, flicker-free image
■ Accurate color processing
■ Digital zoom modes get rid of “black bars” around the display image
■ A built-in Digital Visual Interface (DVI) to eliminate the need for
digital-to-analog conversion
■ 1280 × 1024 SXGA support for computer input.
Plasma TV
■ A bright, flicker-free image
■ Automatic detection and conversion of film content for correct display
with minimal motion artifacts (noise)
■ Accurate color processing
■ Two high-definition component video input sources that automatically
synchronize the display to match the incoming source
■ Picture-in-picture (PIP) and picture-on-picture (POP) modes that let you
watch two programs simultaneously
■ HDTV signal compatibility using an external HDTV decoder with RGB or
component video outputs
■ Digital zoom modes get rid of “black bars” around the display image
■ A built-in BBE
■ A built-in SRS
®
sound processor that maximizes the sound quality
®
sound processor that simulates “surround” effects using
only two speakers
■ Selectable fixed/variable audio outputs
■ Built-in internal amplifier and speakers
■ Connections for adding a separate, powered subwoofer
■ A built-in Digital Visual Interface (DVI) to eliminate the need for
digital-to-analog conversion
■ 1280 × 1024 SXGA support for computer input.
■ 720p and 1080i support for HDTV signals
2
www.gateway.com
Important Safeguards
Warning Risk of electric shock - Do not open
To reduce the risk of electric shock, do no remove the back
cover. There are no user-serviceable parts inside.
Removing the back cover voids the warranty.
Have your plasma TV or plasma monitor repaired by
qualified service personnel only.
Warnings and precautions
■ Do not place your hands, face, or objects close to the ventilation openings
of your plasma TV or monitor. The top of your plasma TV or monitor gets
very hot from exhaust air that is released through the ventilation openings.
Burns or personal injuries may occur if you are too close to your plasma TV
or monitor. Damage may occur if you place any object near the top of your
plasma TV or monitor.
■ Disconnect all cables before moving your plasma TV or monitor. Moving
your plasma TV or monitor with its cables attached may damage the cables
and cause fire or electric shock danger.
Important Safeguards
■ Do not expose your plasma TV or monitor to rain or moisture.
■ Keep your plasma TV or monitor away from excessive dust, high
temperatures, moisture, or direct sunlight.
■ Use your plasma TV or monitor in a well-ventilated area and do not cover
the ventilation openings.
■ Do not modify your plasma TV or monitor, or use an unshielded power
cord or video input source cable or you may experience excessive
interference.
■ Disconnect your plasma TV or monitor and unplug the power cord when
not used for a long period of time.
www.gateway.com
3
Chapter 1: Introducing Your Gateway Plasma TV or Plasma Monitor
■ If the picture displayed is in any way abnormal, turn off your plasma TV
or monitor, then disconnect it from the electrical outlet. Make sure that
your video input source cable is connected correctly, then reconnect your
plasma TV or monitor to the electrical outlet.
■ Disconnect your plasma TV or monitor from the electrical outlet before
cleaning or performing maintenance. Do not use liquid or aerosol cleaners.
Use only a slightly damp cloth for cleaning.
■ Do not place your plasma TV or monitor on an unstable cart, stand, or
table. Your plasma TV or monitor may fall, causing serious damage.
■ Do not place your plasma TV or monitor on a bed, sofa, rug, or other
similar surfaces.
■ Never place your plasma TV or monitor near or over a radiator or heat
source.
■ Do not install your plasma TV or monitor in an enclosed area unless correct
ventilation is provided.
■ Your plasma TV or monitor should be operated from the type of power
source indicated on the label. If the type of available power is unknown,
consult your electrician or local power company.
■ Your plasma TV or monitor is equipped with a 3-pin grounded plug. The
plug will only fit into a grounded power outlet. This is a safety feature. If
you cannot plug the power cord into the outlet, contact your electrician.
Do not alter the plug because this will defeat the safety feature.
■ Do not rest objects on the power cord and avoid placing the power cord
near high traffic areas.
■ Do not overload wall outlets and extension cords because this can result
in a risk of fire or electric shock.
4
www.gateway.com
Important Safeguards
■ Unplug your plasma TV or monitor and contact qualified service personnel
if:
■ The power cord or plug is damaged or frayed.
■ Liquid has been spilled into your plasma TV or monitor.
■ Your plasma TV or monitor has been exposed to water or moisture.
■ Your plasma TV or monitor does not operate normally when the
operating instructions are followed. Adjust only those controls that
are covered by the operating instructions. Incorrect adjustment of
other controls may result in damage which often requires extensive
work by a qualified technician to restore your plasma TV or monitor
to normal operation.
■ Your plasma TV or monitor has been dropped or the cabinet has been
damaged.
Avoid image burn-in
■ Displaying the same stationary images over an extended period of time,
such as a black bar, stock ticker, video game, or a shopping channel logo,
can leave a permanent ghost image (burn-in). Avoid burn-in by mixing
your viewing patterns. Do not show the same stationary image for more
than 15% of your total viewing time in any one week.
Your warranty does NOT cover screen burn-in.
www.gateway.com
5
Chapter 1: Introducing Your Gateway Plasma TV or Plasma Monitor
Package contents
Along with your plasma TV or monitor, the packaging box contains the
following items:
Remote control
Two AA batteries
Power cord
6
www.gateway.com
User guide
Remote control
user guide
Package contents
www.gateway.com
7
Chapter 1: Introducing Your Gateway Plasma TV or Plasma Monitor
Accessories
You can purchase these optional accessories for your plasma TV or monitor:
■ Wall mount kit. The wall mount kit contains all of the required hardware
for mounting your plasma TV or monitor on the wall. (Gateway
recommends you use a qualified installer.) For more information, see the
Wall Mount Installation Guide at support.gateway.com
■ Cable kits. Gateway cable kits consist of high-quality gold cables of various
lengths, including:
■ DVI-D video cable
■ RCA audio cable
■ RCA component video cable
■ RCA composite video cable
■ S-Video cable
■ VGA video cable
Contact Gateway for these and other accessories.
.
8
www.gateway.com
Turning on the main power
To turn on the main power:
1 Connect the power cord to the power cord connector on the back of your
plasma TV or monitor, then plug the other end of the power cord into a
correctly grounded electrical outlet or surge protector.
Turning on the main power
2 Press the MAIN POWER switch on the back of your plasma TV or monitor.
The Status LED on the front turns yellow and your plasma TV or monitor
is ready to turn on.
www.gateway.com
9
Chapter 1: Introducing Your Gateway Plasma TV or Plasma Monitor
3 Press the POWER button on the front of your plasma TV or monitor. The
Status LED on the front turns green.
Warning If you will be away for an extended period of time, turn off
your plasma TV or monitor with the MAIN POWER switch
instead of using the remote control or front POWER button.
Plasma TV
For added protection during a lightning storm or when it
is left unattended or unused for long periods of time,
unplug your plasma TV from the wall outlet and disconnect
the antenna or cable system.
Plasma monitor
High voltages can enter your computer and monitor
through both the power cord and the modem connection.
Protect your computer and monitor by using a surge
protector. If you have a telephone modem, use a surge
protector that has a modem jack. If you have a cable
modem, use a surge protector that has an antenna/cable
TV jack. During an electrical storm, unplug both the surge
protector and the modem.
10
www.gateway.com
Front panel controls
Front panel controls
Adjust +/-
Menu +/-Volu me an d
Input
www.gateway.com
Remote
Control
Sensor
Status
LED
Power
11
Chapter 1: Introducing Your Gateway Plasma TV or Plasma Monitor
Button Description
Volume and Adjustment +/– Increases or decreases the volume.
OSD active: Adjusts on-screen display (OSD) options. For more
information, see “Using the OSD” on page 36.
Menu +/– Opens and closes the OSD.
OSD active: Selects on-screen display (OSD) options. For more
information, see “Using the OSD” on page 36.
Input Switches between available input sources.
Remote control sensor Receives signals from the remote control. Do not block.
■
Status LED
Power Turns your plasma TV or monitor on and off after the MAIN POWER
Not lit - No AC power detected. The MAIN POWER switch is off
or the power cord is not connected.
■
Solid Yellow - The MAIN POWER switch is on and your plasma TV
or monitor is off.
■
Solid Green - Your plasma TV or monitor is on.
switch is turned on. When you turn your plasma TV or monitor on
or off, wait three seconds before pressing this button again.
12
www.gateway.com
Back panel connections
Back panel connections
Audio and video
connections
(Plasma TV only)
Connector Description
Audio and video connections See “Audio and video connections (plasma TV only)” on
RGB and DVI connections See “RGB and DVI connections” on page 15.
RGB and DVI
connections
page 14.
www.gateway.com
13
Chapter 1: Introducing Your Gateway Plasma TV or Plasma Monitor
Audio and video connections
(plasma TV only)
DVI
Antenna
Subwoofer
External Speaker
Switch
Connector
Antenna Connects to a VHF/UHF antenna or cable TV.
DVI Audio In Connects to the audio on a DVI device, such as a computer or set-top box.
Video 1/Audio In Connects to a composite audio/video device, such as a VCR.
Audio In
RGB
Audio In
Description
Video 1/
Audio In
S-Video/
Audio In
Component Video 1/
Audio In Audio Out
Component Video 2/
Audio In
Component Video 1/
Audio In
Audio Out Connects to an audio device, such as a receiver.
External Speaker
Switch
Subwoofer Connects to an external subwoofer.
RGB Audio In Connects to the audio on an RGB device, such as a computer or set-top box.
S-Video/Audio In Connects to an S-Video device, such as a satellite dish receiver or digital
Component Video 2/
Audio In
14
Connects to a component audio/video device, such as a DVD player.
Connects to the speaker switch jack on switchable external speakers or an
external receiver or amplifier.
cable box.
Connects to a component video device, such as a HDTV set-top box.
www.gateway.com
RGB and DVI connections
Back panel connections
RGB In
Connector
RGB In Connects to an RGB video device, such as a computer
RGB Out Connects to an external RGB monitor.
DVI In Connects to a DVI video device, such as a computer or
RS-232 Connects to a computer to display the computer image
RGB Out DVI In
Description
or set-top box.
set-top box.
on the plasma TV or monitor using customized software
(typically used by business, education, or government).
For more information see the
Technical Reference
at support.gateway.com.
RS-232 Serial Connection
RS-232
www.gateway.com
15
Chapter 1: Introducing Your Gateway Plasma TV or Plasma Monitor
16
www.gateway.com
Connecting
Components
Read this chapter to learn how to connect:
■ DVD players (plasma TV only)
■ HDTV decoder set-top boxes (plasma TV only)
■ VCRs (plasma TV only)
■ Off-air TV and cable TV (plasma TV only)
■ External audio devices (plasma TV only)
■ Computers
If you purchased the plasma monitor, go to “Connecting
a computer” on page 31.
2
Warning Before connecting any external
components, unplug your plasma TV or
monitor. To restart your plasma TV or
monitor, see “Turning on the main power” on
page 9.
17
Chapter 2: Connecting Components
Understanding video connections
Your plasma TV has four types of standard video connections. You should use
the best connection available to get the best display. For example, if your DVD
player supports a component video connection, connect the DVD player to
your plasma TV using component video instead of composite video or S-Video.
Connection
Cable and Connector Description
Quality
Basic Coaxial (RF). The video and audio signals
are both carried in one cable (the other three
connection types only handle video, and
require separate connections for sound).
Coaxial is the only way to connect an
antenna to your plasma TV.
Good Composite. The video signal is carried
through a single “pin.” This connection
method is the one that is most commonly
found on devices.
Better S-Video. The video signal is split into two
signals, black-and-white and color. Text
displayed on-screen through this connection
will be noticeably sharper then composite or
coaxial (RF).
Best Component. The video signal is split into
three signals, two color, and one
black-and-white. Use component video to
take advantage of the superior picture
provided by signal sources as HDTV and
18
progressive
www.gateway.com
DVD.
Connecting your DVD player
Connecting your DVD player
Using component video
To connect your DVD player using component video:
1 Connect the green-colored Y jack on the back of your DVD player to the
green-colored Y1 jack on the back of your plasma TV.
2 Connect the red-colored P
the red-colored P
1/CR1 jack on the back of your plasma TV.
R
3 Connect the blue-colored P
to the blue-colored P
or CR jack on the back of your DVD player to
R
or CB jack on the back of your DVD player
B
1/CB1 jack on the back of your plasma TV.
B
4 Connect the red (R) and white (L) audio jacks on the back of your DVD
player to the R and L audio-in jacks on the back of your plasma TV.
5 Select COMPONENT1 using the INPUT button on the front of your
plasma TV.
www.gateway.com
19
Chapter 2: Connecting Components
Using S-Video
To connect your DVD player using S-Video:
20
1 Connect the S-Video jack on the back of your DVD player to the S-VIDEO
jack on the back of your plasma TV.
2 Connect the red (R) and white (L) audio jacks on the back of your DVD
player to the R and L audio-in jacks on the back of your plasma TV.
3 Select AV 2 (S) using the INPUT button on the front of your plasma TV.
www.gateway.com
Using composite video
To connect your DVD player using composite video:
Connecting your DVD player
1 Connect the yellow video jack on the back of your DVD player to the
yellow VIDEO 1 jack on the back of your plasma TV.
2 Connect the red (R) and white (L) audio jacks on the back of your DVD
player to the R and L audio-in jacks on the back of your plasma TV.
3 Select AV 1 using the INPUT button on the front of your plasma TV.
www.gateway.com
21
Chapter 2: Connecting Components
Connecting your HDTV set-top box
Using component video
To connect your HDTV decoder set-top box using component video:
22
1 Connect the green Y jack on the back of your HDTV set-top box to the
green Y2 jack on the back of your plasma TV.
2 Connect the red P
the red P
2/CR2 jack on the back of your plasma TV.
R
3 Connect the blue P
the blue P
2/CB2 jack on the back of your plasma TV.
B
or CR jack on the back of your HDTV set-top box to
R
or CB jack on the back of your HDTV set-top box to
B
4 Connect the red (R) and white (L) audio jacks on the back of your HDTV
set-top box to the R and L audio-in jacks on the back of your plasma TV.
5 Select COMPONENT1 using the INPUT button on the front of your
plasma TV.
www.gateway.com
Using RGB video
To connect your HDTV decoder set-top box using RGB video:
Connecting your HDTV set-top box
1 Connect the 15-pin D-Sub RGB jack on the back of your HDTV set-top box
to the RGB-IN jack on the back of your plasma TV.
2 Connect the red (R) and white (L) audio-out jacks on the back of your
HDTV set-top box to the R and L audio-in jacks on the back of your
plasma TV.
3 Select RGB using the INPUT button on the front of your plasma TV.
After you connect your HDTV set-top box to the RGB input jack on your
plasma TV, you may need to adjust various plasma TV picture settings to
correctly match the output from the HDTV set-top box. For more information,
see “PICTURE – RGB/DVI mode” on page 38.
www.gateway.com
23
Chapter 2: Connecting Components
Connecting your VCR or video camera
Using S-Video
To connect your VCR or video camera using S-Video:
24
- OR -
1 Connect the S-Video jack on the back of your VCR or video camera to the
S-VIDEO jack on the back of your plasma TV.
2 Connect the red (R) and white (L) audio jacks on the back of your VCR
or video camera to the R and L audio-in jacks on the back of your
plasma TV.
3 Select AV 2 (S) using the INPUT button on the front of your plasma TV.
www.gateway.com
Connecting your VCR or video camera
Using composite video
To connect your VCR or video camera using composite video:
- OR -
1 Connect the yellow video jack on the back of your VCR or video camera
to the yellow VIDEO 1 jack on the back of your plasma TV.
2 Connect the red (R) and white (L) audio jacks on the back of your VCR
or video camera to the R and L audio-in jacks on the back of your
plasma TV.
3 Select AV 1 using the INPUT button on the front of your plasma TV.
www.gateway.com
25
Chapter 2: Connecting Components
Using coaxial (RF)
To connect your VCR using coaxial (RF) audio and video:
1 Connect the “output to TV” (RF out or Antenna out) jack on the back of
your VCR to the ANT jack on the back of your plasma TV.
2 Select TV using the INPUT button on the front of your plasma TV.
If you have an off-air antenna or cable box, connect your off-air antenna or
cable TV cable to the ANT connector on the back of your VCR.
Warning If an outdoor antenna or cable system is connected to your
plasma TV, make sure that the antenna or cable system
is correctly grounded. For more information, see
“Television antenna connectors protection (for systems
fitted with TV/cable TV tuner cards)” on page 57.
26
www.gateway.com
Connecting off-air TV or cable TV
Connecting off-air TV or cable TV
To connect off-air TV or cable TV using coaxial (RF) audio and video:
- OR -
1 Connect the coaxial (RF) connector from your antenna or cable box to the
ANT connector on the back of your plasma TV.
2 Select TV using the INPUT button on the front of your plasma TV.
If you have connected a VCR to the ANT connector on the back of your
plasma TV, connect your off-air TV or cable TV cable to the ANT connector on
the back of your VCR.
Warning If an outdoor antenna or cable system is connected to your
plasma TV, make sure that the antenna or cable system
is correctly grounded. For more information, see
“Television antenna connectors protection (for systems
fitted with TV/cable TV tuner cards)” on page 57.
www.gateway.com
27
Chapter 2: Connecting Components
Connecting external amplified speakers
You can connect your plasma TV to a set of external, amplified speakers using
the AUDIO OUT jacks located on the back of your plasma TV. If your speakers
have remote turn-on/off capability, connect the external speaker switch.
To connect your external amplified speakers:
28
1 Connect the red (R) and white (L) audio jacks on the back of your speakers
to the AUDIO OUT jacks on the back of your plasma TV.
2 If your external amplified speakers accept remote turn-on/off signals,
connect the external speaker switch. Not all external amplified speakers
can accept remote turn-on/off signals.
www.gateway.com
Connecting an external receiver or amplifier
Connecting an external receiver or
amplifier
You can connect an external receiver or amplifier to your plasma TV. Your
plasma TV is equipped with a external speaker switch that can automatically
send a remote turn-on/off signal to an external receiver or amplifier.
To connect your external receiver or amplifier:
1 Connect the red (R) and white (L) audio jacks on the back of your external
amplifier or receiver to the AUDIO OUT jacks on the back of your
plasma TV.
2 If your external amplifier or receiver accepts remote turn-on/off signals,
connect the external speaker switch. Not all external amplifiers or receivers
can accept remote turn-on/off signals.
www.gateway.com
29
Chapter 2: Connecting Components
Connecting a subwoofer
Your plasma TV has built-in speakers. You can enhance the bass response of
your plasma TV’s sound by connecting an external, amplified subwoofer.
To connect your subwoofer:
30
1 Connect the audio jack on the back of your subwoofer to the SUBWOOFER
jack on the back of your plasma TV.
2 If your subwoofer accepts remote turn-on/off signals, connect the external
speaker switch. Not all subwoofers can accept remote turn-on/off signals.
www.gateway.com
Connecting a computer
Using DVI video
To connect your computer using DVI video:
Connecting a computer
Plasma TV only
1 Connect the DVI connector on your computer to the DVI-In connector
on the back of your plasma TV or monitor.
2 Connect the Audio Out jack on your computer to the DVI Audio In jacks
on the back of your plasma TV.
An audio connection is not available on your plasma monitor.
3 Select DVI using the INPUT button on the front of your plasma TV or
monitor.
www.gateway.com
31
Chapter 2: Connecting Components
Using RGB video
To connect your computer using RGB video:
32
Plasma TV only
1 Connect the 15-pin D-Sub RGB connector on your computer to the RGB-IN
connector on the back of your plasma TV or monitor.
2 Connect the Audio Out jack on your computer to the RGB Audio In jacks
on the back of your plasma TV.
An audio connection is not available on your plasma monitor.
3 Select RGB using the INPUT button on the front of your plasma TV or
monitor.
www.gateway.com
Connecting a computer
Connecting an external monitor
A RGB loop-out (labeled RGB Out) lets you connect another RGB monitor. The
RGB loop-out displays the same signal as the RGB In video input source.
To connect your external monitor:
1 Connect the RGB connector on your monitor to the RGB Out connector
on the back of your plasma TV or monitor.
2 Select RGB using the INPUT button on the front of your plasma TV or
monitor.
The maximum physical display resolution of the external monitor is 640 × 480
when the aspect ratio is set to 4:3, and 852 × 480 when the ratio is set to 16:9.
If the computer’s display resolution exceeds these maximums, the external
monitor eliminates the extra dots which results in a loss of detail and picture
clarity.
www.gateway.com
33
Chapter 2: Connecting Components
34
www.gateway.com
Adjusting Your
Plasma TV
Settings
Read this chapter to learn how to adjust your plasma TV
or monitor settings from the on-screen display (OSD).
You can also use your remote control to change some
settings. For more information, see You r G a te wa y R e mo t e
Control User’s Guide.
3
35
Chapter 3: Adjusting Your Plasma TV Settings
Using the OSD
Your plasma TV or monitor features an on-screen display (OSD) that lets you
adjust and save contrast, brightness, and other settings. The TV or monitor saves
changes you make to the settings, even if you turn off the TV or monitor.
To adjust settings from the OSD:
1 Press the MENU + or – button on the front of your plasma TV or monitor.
The OSD opens.
2 Press the ADJ + or – button on the front of your plasma TV or monitor to
select the menu you want.
3 Press the MENU + or – button on the front of your plasma TV or monitor
to select a menu option.
4 Press the ADJ + or – button on the front of your plasma TV or monitor to
adjust the option setting.
5 Press the MENU + or – button on the front of your plasma TV or monitor.
The OSD closes.
36
www.gateway.com
OSD menus and options
You can use these OSD menus and options to adjust various settings for your
plasma TV or monitor.
Some menus are not available on your plasma monitor.
OSD Menu Description
Using the OSD
(Plasma TV only)
PICTURE – TV, AV1, AV2 (S), COMPONENT1,
and COMPONENT2 mode
PICTURE SOUND PIP/POP TV OTHER
INPUT SOURCE
CONTRAST
BRIGHT
COLOR
TINT
SHARPNESS
COLOR TEMPERATURE
CLOCK PHASE
SCREEN WIDTH
ZOOM
GEOMETRIC ADJUST
SELECT ITEM ADJUST VALUE
TV
100
50
50
50
50
6500D
50
16 : 9
OFF
OFF
INPUT SOURCE. Switches between available
video input sources.
CONTRAST. Adjusts the contrast of the picture.
BRIGHT. Adjusts the brightness of the picture.
You may need to readjust brightness after the
plasma TV warms up.
COLOR. Adjusts the color saturation making
colors more intense.
TINT. Adjusts the color of flesh tones.
SHARPNESS. Adjust the amount of detail
enhancement.
COLOR TEMPERATURE. Adjusts the white
balance.
CLOCK PHASE. Adjusts your plasma TV to
match the video input source.
SCREEN WIDTH. Adjusts the screen width to
4:3, 16:9, or PANORAMA viewing mode.
ZOOM. Moves or stretches the display image
when the screen width is set to 16:9.
Zoom1 moves the image upward (good for
presentations with sub-titles).
Zoom2 stretches 1.85:1 content to fill the screen.
Zoom3 stretches 2.35:1 content to fill the screen.
GEOMETRIC ADJUST. Controls the V-SIZE,
V-CENTER, H-WIDTH, and H-POSITION of the
display image.
Only available in Component 1 and
Component 2 mode.
www.gateway.com
37
Chapter 3: Adjusting Your Plasma TV Settings
OSD Menu Description
(Plasma TV and monitor)
PICTURE – RGB/DVI mode
PICTURE SOUND PIP/POP TV OTHER
INPUT SOURCE
CONTRAST
BRIGHTNESS
COLOR TEMPERATURE
CLOCK PHASE
SCREEN WIDTH
V-SIZE
V-CENTER
H-WIDTH
H-POSITION
SELECT ITEM ADJUST VALUE
6500D
RGB
50
50
50
16:9
50
50
50
50
INPUT SOURCE. Switches between available
video input sources.
CONTRAST. Adjusts the contrast of the picture.
BRIGHTNESS. Adjusts the brightness of the
picture.
You may need to readjust brightness after the
plasma TV or monitor warms up.
COLOR TEMPERATURE. Adjusts the white
balance.
CLOCK PHASE. Adjusts your plasma TV or
monitor to match the video input source.
SCREEN WIDTH. Adjusts the screen width to
4:3 or 16:9 viewing mode.
V-SIZ E. Adjusts the vertical screen size.
V-CENTER. Adjusts the vertical screen position.
H-WIDTH. Adjusts the horizontal screen size.
H-POSITION. Adjusts the horizontal screen
position.
38
www.gateway.com
OSD Menu Description
Using the OSD
(Plasma TV only)
SOUND
PICTURE SOUND PIP/POP TV OTHER
BASS
TREBLE
BALANCE
SURROUND
BBE
BASS EXTENSION
VOLUME
INNER SPKR
AUDIO OUTPUT
SELECT ITEM ADJUST VALUE
STEREO
FIXED
50
50
50
OFF
OFF
50
ON
BASS. Adjusts the bass. The AUDIO OUTPUT
option must be set to VARIABLE to adjust this
setting.
TREBLE. Adjusts the treble. The AUDIO
OUTPUT option must be set to VARIABLE to use
this option.
BALANCE. Adjusts the balance level between
the channels. The AUDIO OUTPUT option must
be set to VARIABLE to adjust this setting.
SURROUND. Switches between STEREO,
MONO, or turns surround OFF. The AUDIO
OUTPUT option must be set to VARIABLE to use
this option.
BBE. Turns the BBE option on or off. Turn this
option on when you are listening to
live-performance programs. The AUDIO
OUTPUT option must be set to VARIABLE to use
this option.
BASS EXTENSION. Extends the level of BASS
sent to the audio out jack. The AUDIO OUTPUT
option must be set to VARIABLE and the INNER
SPKR option must be turned off to use this
option.
VOLUM E. Adjusts the volume. The AUDIO
OUTPUT option must be set to VARIABLE to use
this option.
INNER SPKR. Turns the built-in speakers on or
off. The AUDIO OUTPUT option must be set to
VARIABLE to use this option.
AUD IO OUTPUT. Changes the audio output
options for the plasma TV.
FIXED bypasses your plasma TV’s internal
sound controls.
VARIABLE lets you adjust the type of output your
plasma TV sends to the built-in speakers or the
audio output jack.
www.gateway.com
39
Chapter 3: Adjusting Your Plasma TV Settings
OSD Menu Description
(Plasma TV only)
PIP/POP
PICTURE SOUND PIP/POP TV OTHER
PIP
SOURCE
POSITION
H-LOCATION
V-LOCATION
SWAP
POP
SOURCE
SCREEN RATE
SWAP
SELECT ITEM ADJUST VALUE
FIXED
RIGHT
DISABLE
FULL
DISABLE
OFF
TV
TOP
OFF
TV
PIP. Turns PIP mode on or off. When PIP is
turned on, you can display two pictures at one
time. One picture is displayed on the full screen
and the other picture is displayed in a small
window. The picture on the full screen is the main
picture. The picture in the window is the
sub-picture.
You can use PIP mode if your video input source
is set to TV, AV, S-Video, Component 1, or
Component 2 and the video input source is 480i
or lower (such as a non-progressive DVD player).
PIP mode does not work with component video
input sources higher than 480i (such as a HDTV
set-top box or progressive DVD player), RGB, or
DVI video sources.
SOURCE. Changes the video input source of the
sub-picture when PIP is turned on.
POSITION. Moves the sub-picture within the
screen.
FIXED lets you use the H-LOCATOR and
V-LOCATOR options to place the sub-picture in
one of the four corners of the screen.
VARIABLE lets you use the H-LOCATOR and
V-LOCATOR options to move the sub-picture
anywhere within the screen.
H-LOCATION. Moves the sub-picture left or
right.
V-LOCATION. Moves the sub-picture up or
down.
SWAP. Swaps the main picture and the
sub-picture.
40
www.gateway.com
OSD Menu Description
Using the OSD
PIP/POP (continued)
POP. Turns POP mode on or off. When POP is
turned on, the screen is split into two pictures.
The picture on the left side of your screen is the
main picture. The picture on the right side of the
screen is the sub-picture.
You can use POP mode if your video input
source is set to TV, AV, S-Video, Component 1,
or Component 2 and the video input source is
480i or lower (such as a non-progressive DVD
player).
POP mode does not work with component video
input sources higher than 480i (such as a HDTV
set-top box or progressive DVD player), RGB, or
DVI video sources.
SOURCE. Changes the video input source of the
sub-picture when POP is turned on.
SCREEN RATE. Changes the aspect ratio of the
sub-picture.
SWAP. Swaps the main picture and the
sub-picture.
www.gateway.com
41
Chapter 3: Adjusting Your Plasma TV Settings
OSD Menu Description
(Plasma TV only)
TV
PICTURE SOUND PIP/POP TV OTHER
CHANNEL
CHANNEL STATUS
MTS
CCD
V-CHIP
SET PARENTAL CODE
SET RATING
CH SEARCH
TUNER SOURCE
BACKGROUND
BACKGROUND COLOR
SELECT ITEM ADJUST VALUE
NORMAL
STEREO
DISABLE
DISABLE
DISABLE
CABLE
BLUE
12
OFF
OFF
ON
CHANNEL. Changes the TV channel.
CHANNEL STATUS. Sets the status of the
TV channel.
NORMAL is the default.
FAV programs the channel as a favorite channel.
LOCK prevents the channel from being viewed.
You need the remote control to use this option.
For more information, see
Control User’s Guide
ERASE removes the channel from the channel
list.
MTS. Changes the sound output for
TV programs. Switch between STEREO,
MONO, or SAP (Second Audio Program) for
audio simulcasts. The TV program must support
the output option.
CCD. Activates closed captioning.
V-CHIP. Activates the Parental Guide. You need
the remote control to use this option. For more
information, see
User’s Guide
SET PARENTAL CODE. Sets a password for the
Parental Guide. You need the remote control to
use this option. For more information, see
Your Gateway Remote Control
.
Gateway Remote Control User’s Guide
SET RATING. Blocks individual programs based
on program ratings. You need the remote control
to use this option. For more information, see
Gateway Remote Control User’s Guide
CH SEARCH. When this option is turned on,
your plasma TV only displays channels that have
a signal when you change channels.
TUNER SOURCE. Sets the source for the tuner.
CABLE sets the tuner for cable or a satellite dish.
AIR sets the tuner for an antenna.
BACKGROUND. Displays a background color
when a video signal is not available.
BACKGROUND COLOR. Changes the color of
the background when the BACKGROUND option
is turned on.
Your Gateway Remote
.
Yo u r
.
Your
.
42
www.gateway.com
OSD Menu Description
Using the OSD
(Plasma TV and monitor)
OTHER
PICTURE SOUND PIP/POP TV OT HE R
OSD TIMEOUT
SET OSD TIME
OSD BRIGHTNESS
OSD BACKGROUND
OSD LANGUAGE
SLEEP
SLEEP TIME
POWER SAVE
POWER ON SEQUENCE
RESET
S/W VERSION
SELECT ITEM ADJUST VALUE
ENGLISH
1-120
1 STEP
DISABLE
G513-0611
OFF
ON
OFF
OFF
OSD TIMEOUT. Turns the OSD timer on and off.
To avoid image burn-in, we recommend that
you keep this timer turned on.
SET OSD TIME. Specifies the number of
5
seconds the OSD menu is displayed before it
8
turns off automatically. The OSD TIMEOUT
option must be turned on to use this option.
OSD BRIGHTNESS. Adjusts the brightness
level of the OSD menu.
OSD BACKGROUND. Switches the OSD menu
background to blue or transparent.
OSD LANGUAGE. Changes the language of the
OSD menu.
SLEEP. Turns the sleep timer on and off.
SLEEP TIME. Adjusts the number of minutes the
plasma TV or monitor waits before it
automatically turns off. You can specify from 1
to 120 minutes. The SLEEP option must be
turned on.
POWER SAVE. Turns power save mode on or
off. The plasma TV or monitor goes into sleep
mode when in RGB and DVI video mode. For
more information, see the documentation that
came with your computer.
POWER ON SEQUENCE. Selects the power-on
sequences.
1 STEP. Turns the plasma TV or monitor on or
off using the MAIN POWER switch.
2 STEP (factory default). Press the MAIN
POWER switch to activate the plasma TV or
monitor. This puts the plasma TV or monitor in
suspend mode. Then use the POWER button on
the front of the plasma TV or monitor to turn it
on and off. For more information, see “Turning
on the main power” on page 9.
RESET. Resets picture settings to the factory
default.
S/W VERSION. Shows the version of the
software your plasma TV or monitor is using.
www.gateway.com
43
Chapter 3: Adjusting Your Plasma TV Settings
44
www.gateway.com
Maintenance and
Troubleshooting
Read this chapter to learn how to maintain and
troubleshoot your plasma TV or monitor.
4
45
Chapter 4: Maintenance and Troubleshooting
Cleaning and maintenance
Cleaning the screen
■ Do not use substances such as glass cleaners, solvents, and thinners.
■ The screen of your plasma TV or monitor has been specially treated. Wipe
the surface gently using only a cleaning cloth or a soft, lint-free cloth.
■ If the surface is particular dirty, use a soft cloth and water to clean the
screen. Squirt a little water on the cloth (never directly on the screen), then
wipe the screen with the cloth.
Warning The screen of your plasma TV or monitor is made of
specially coated glass and can be scratched or damaged
by abrasive or ammonia-based window cleaners.
Scratches on the bezel or glass are not covered by your
warranty.
■ Do not scratch or hit the surface of the screen with your fingers or any
hard objects.
Cleaning the exterior
■ Your plasma TV or monitor is cooled by air circulated through the vents
on the case, so keep the vents free of dust. With your plasma TV or monitor
turned off and unplugged, brush the dust away from the vents with a damp
cloth. Be careful not to drip any water into the vents. Do not attempt to
clean dust from the inside of your plasma TV or monitor.
■ Do not use abrasive or solvent cleaners because they can damage the finish
on components.
■ Do not allow any excessive water or moisture to come into contact with
the surface of your plasma TV or monitor. If water or moisture gets inside
your plasma TV or monitor, operating problems and electrical and shock
hazards may result.
■ Do not scratch or hit the cabinet with your fingers or any hard objects.
■ Do not place articles made from rubber or PVC near the cabinet for any
extended periods of time.
46
www.gateway.com
Avoiding image burn-in
■ Displaying the same stationary image over an extended period of time,
such as a black bar, stock ticker, video game, or shopping channel logo,
can leave a permanent ghost image (burn-in). Avoid burn-in by mixing
your viewing patterns. Do not show the same stationary image for more
than 15% of your total viewing time in any one week.
Your warranty does NOT cover screen burn-in.
Troubleshooting
Use the following information to solve common problems.
You cannot see a picture
■ Make sure that the power cord is plugged into a grounded electrical outlet.
■ Make sure that the main power switch and power button are turned on.
■ Make sure that the selected input source is connected to a working input
source.
Troubleshooting
■ If your plasma TV or monitor is connected to your computer in RGB mode,
press any key on your keyboard to “wake” your computer.
You see a distorted picture or hear unusual sound
■ You may be getting interference from electrical appliances, cars,
motorcycles, or fluorescent lights. Try moving your plasma TV or monitor
to another location.
The color is abnormal
■ Make sure that the input source cable is connected securely and correctly
to the back of your plasma TV or monitor.
The picture has abnormal patterns
■ Make sure that the input source cable is connected securely and correctly
to the back of your plasma TV or monitor.
■ Make sure that the video input source is within the range of your
plasma TV or monitor. Compare the video input source’s specifications
with your plasma TV or monitor specifications.
www.gateway.com
47
Chapter 4: Maintenance and Troubleshooting
The display image does not cover the entire screen
■ If your are using RGB mode, make sure that H-WIDTH and V-SIZE in the
OSD are set correctly.
■ If you are using TV, AV1, AV2, or component with 480i input, use the
SCREEN WIDTH option in the OSD to scroll through various screen modes.
You can see a picture but you cannot hear sound (plasma TV only)
■ Make sure that the volume is not turned down.
■ Make sure that the sound is not muted.
■ Make sure that your audio input source cables are connected securely and
correctly.
The monitor has pixels that are always dark
■ Your plasma TV or monitor is manufactured using an extremely high level
of precision technology. However, sometimes some pixels of your
plasma TV or monitor may not display. Pixel defects within industry
specifications are inherent to this type of product and do not constitute
a defective product.
An image remains on the screen even after you turn off your
plasma TV or monitor
■ A still image may have been displayed for an extended period of time
causing burn-in. For more information about burn-in, see page 43.
You see “noise” or “trash” on the screen (plasma TV only)
■ When your plasma TV’s digital capabilities exceed a digital broadcast
signal, the signal is up-converted (increased) to match your plasma TV’s
display capabilities. Up-converting can cause noise or trash.
Screen brightness is diminished
■ Video display devices experience degradation of brightness over the life of
the device. Normal brightness degradation is not covered by your warranty.
48
www.gateway.com
Telephone support
If this troubleshooting information does not resolve your problem or if you
have other questions relating to your plasma TV or monitor, call our Service
Center at 888-737-MyGW (6949).
Troubleshooting
For more information about Gateway, visit www.gateway.com
.
www.gateway.com
49
Chapter 4: Maintenance and Troubleshooting
50
www.gateway.com
Signal Frequency
Information
Read this appendix for signal frequency information. For
more information, see OSD menu “OTHER” on page 43.
A
51
Appendix A: Signal Frequency Information
TV, AV1, and AV2 inputs
Plasma TV only.
Horizontal (KHz) Vertical (Hz) Format
15.7 60 NTSC Video
15.6 50 PAL Video
Component 1 and Component 2
inputs
Plasma TV only.
Horizontal (KHz) Vertical (Hz) Format
15.7 60 NTSC Video
52
15.6 50 PAL Video
15.7 60 480i (SDTV)
31.5 60 480P (EDTV)
33.0 60 1080i (HDTV)
45.0 60 720P (HDTV)
www.gateway.com
RGB and DVI inputs
RGB and DVI inputs
Plasma TV and monitor.
Mode Horizontal (KHz) Vertical (Hz) Format Refresh
1 31.5 59.9 640 × 480 (VGA) 60
2 37.9 72.8 640 × 480 (VGA) 72
3 37.5 75.0 640 × 480 (VGA) 75
4 43.3 85.0 640 × 480 (VGA) 85
5 35.1 56.3 800 × 600 (SVGA) 56
6 37.9 60.3 800 × 600 (SVGA) 60
7 48.1 72.2 800 × 600 (SVGA) 72
8 46.9 75.0 800 × 600 (SVGA) 75
9 53.7 85.0 800 × 600 (SVGA) 85
10 48.4 60.0 1024 × 768 (XGA) 60
11 56.5 70.0 1024 × 768 (XGA) 70
12 60.0 75.0 1024 × 768 (XGA) 75
13 68.7 85.0 1024 × 768 (XGA) 85
14 64.0 60.0 1280 × 1024 (SXGA) 60
www.gateway.com
53
Appendix A: Signal Frequency Information
Mode Horizontal (KHz) Vertical (Hz) Format Refresh
15* 80.0 75.0 1280 × 1024 (SXGA) 75
16* 91.1 85.0 1280 × 1024 (SXGA) 85
18 31.5 70.0 720 × 400 (DOS) 70
19 31.5 50.0 640 × 480 (VGA) 50
20* 45.2 60.0 1266 × 720P (HDTV) 60
21* 33.8 60i 1920 × 1080i (HDTV) 60
22 31.5 70.0 640 × 350 (VGA) 70
23 31.4 60.0 852 × 480 (WVGA) 60
24 35.0 66.7 640 × 480 (Apple) 67
25 49.7 74.6 832 × 624 (Apple) 75
26 68.7 75.0 1152 × 870 (Apple) 75
28 47.4 60.0 1360 × 768 60
30 60.0 60.0 1280 × 960 60
31* 85.9 85.0 1280 × 960 85
* These modes not available in RGB mode with DVI output.
54
www.gateway.com
Safety,
Regulatory, and
Legal Information
Regulatory compliance
statements
United States of America
Federal Communications Commission (FCC)
Unintentional emitter per FCC Part 15
This device has been tested and found to comply with the limits for a
Cl ass B d igi tal dev ice , pu rsu ant to P art 15 o f th e FC C ru les . Th ese li mit s
are designed to provide reasonable protection against harmful
interference in a residential installation.
B
55
Safety, Regulatory, and Legal Information
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio or television
reception. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause interference to radio and television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
■
Reorient or relocate the receiving antenna
■
Increase the separation between the equipment and receiver
■
Connect the equipment to an outlet on a different circuit from that to which the receiver is
connected
■
Consult the dealer or an experienced radio/TV technician for help.
Compliance Accessories: The accessories associated with this equipment are: shielded video cable
when an external monitor is connected. These accessories are required to be used in order to
ensure compliance with FCC rules.
FCC declaration of conformity
Responsible party:
Gateway Companies, Inc.
610 Gateway Drive, North Sioux City, SD 57049
(605) 232-2000 Fax: (605) 232-2023
Product:
■
GTW-P50M203 Plasma TV
■
GTW-P50M103 Plasma Monitor
This device complies with Part 15 of the FCC Rules. Operation of this product is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired operation.
Caution Changes or modifications not expressly approved by
Gateway could void the FCC compliance and negate your
authority to operate the product.
Canada
Industry Canada (IC) Unintentional emitter per ICES-003
This digital apparatus does not exceed the Class B limits for radio noise emissions from digital
apparatus as set out in the radio interference regulations of Industry Canada.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites
applicables aux appareils numériques de Classe B prescrites dans le règlement sur le brouillage
radioélectrique édicté par Industrie Canada.
56
www.gateway.com
Regulatory compliance statements
Laser safety statement
All Gateway systems equipped with CD and DVD drives comply with the appropriate safety
standards, including IEC 825. The laser devices in these components are classified as “Class 1 Laser
Products” under a US Department of Health and Human Services (DHHS) Radiation Performance
Standard. Should the unit ever need servicing, contact an authorized service location.
Warning Use of controls or adjustments or performance of
procedures other than those specified in this manual may
result in hazardous radiation exposure. To prevent
exposure to laser beams, do not try to open the enclosure
of a CD or DVD drive.
California Proposition 65 Warning
Warning This product contains chemicals, including lead, known to
the State of California to cause cancer and/or birth defects
or reproductive harm.
Television antenna connectors protection (for
systems fitted with TV/cable TV tuner cards)
External television antenna grounding
If an o uts ide ant enn a or cable system i s to be c onn ect ed t o yo ur Gateway PC , ma ke s ure tha t the
antenna or cable system is electrically grounded to provide some protection against voltage surges
and static charges.
Article 810 of the National Electrical Code, ANSI/NFPSA 70, provides information with regard to
proper grounding of the mast and supporting structure, grounding of the lead-in wire to an
antenna discharge unit, size of grounding conductors, location of antenna discharge unit,
connection to grounding electrodes, and requirements for the grounding electrode.
Lightning protection
For added protection of any Gateway product during a lightning storm or when it is left
unattended or unused for long periods of time, unplug the product from the wall outlet and
disconnect the antenna or cable system.
www.gateway.com
57
Safety, Regulatory, and Legal Information
Power lines
Do not locate the antenna near overhead light or power circuits, or where it could fall into such
power lines or circuits.
Warning When installing or realigning an outside antenna system,
extreme care should be taken to keep from touching such
power lines or circuits. Contact with them could be fatal.
7
6
5
4
3
58
1
Antenna and satellite grounding
2
Reference Grounding component
1 Electric service equipment
2 Power service grounding electrode system (NEC Art 250, Part H)
3 Ground clamps
4 Grounding conductors (NEC Section 810-21)
5 Antenna discharge unit (NEC Section 810-20)
6 Ground clamp
7 Antenna lead-in wire
www.gateway.com
Notices
Copyright © 2003 Gateway, Inc.
All Rights Reserved
14303 Gateway Place
Poway, CA 92064 USA
All Rights Reserved
This publication is protected by copyright and all rights are reserved. No part of it may be reproduced or
transmitted by any means or in any form, without prior consent in writing from Gateway.
The information in this manual has been carefully checked and is believed to be accurate. However, changes are
made periodically. These changes are incorporated in newer publication editions. Gateway may improve and/or
change products described in this publication at any time. Due to continuing system improvements, Gateway is
not responsible for inaccurate information which may appear in this manual. For the latest product updates,
consult the Gateway Web site at www.gateway.com
exemplary, incidental, or consequential damages resulting from any defect or omission in this manual, even if
advised of the possibility of such damages.
In the interest of continued product development, Gateway reserves the right to make improvements in this
manual and the products it describes at any time, without notices or obligation.
Trademark Acknowledgments
1-800-GATEWAY, ActiveCPR, ALR, AnyKey, black-and-white spot design, CrystalScan, Destination, DestiVu, EZ
Pad, EZ Point, Field Mouse, Gateway 2000, Gateway Country, gateway.net, Gateway stylized logo, Perfect
Scholar, Solo, TelePath, Vivitron, stylized “G” design, and “You’ve got a friend in the business” slogan are
registered trademarks and black-and-white spotted box logo, GATEWAY, Gateway Astro, Gateway@Work,
Gateway Connected touch pad, Gateway Connected music player, Gateway Cyber:)Ware, Gateway
Education:)Ware, Gateway Flex Case, Gateway Gaming:)Ware, Gateway GoBack, Gateway Gold, Gateway
Learning:)Ware, Gateway Magazine, Gateway Micro Server, Gateway Money:)Ware, Gateway Music:)Ware,
Gateway Networking Solutions, Gateway Online Network (O.N.) solution, Gateway Photo:)Ware, Gateway
Professional PCs, Gateway Profile, Gateway Solo, green stylized GATEWAY, green stylized Gateway logo,
Gateway Teacher:)Ware, Gateway Video:)Ware, HelpSpot, InforManager, Just click it!, Learn@Gateway, Kids
BackPack, SERVE-TO-ORDER, Server Watchdog, the Spotted G Gateway Logo and the Spotted G Logo,
SpotShop, Spotshop.com, and Your:)Ware are trademarks of Gateway, Inc. Intel, Intel Inside logo, and Pentium
are registered trademarks and MMX is a trademark of Intel Corporation. Microsoft, MS, MS-DOS, and Windows
are trademarks or registered trademarks of Microsoft Corporation. All other product names mentioned herein are
used for identification purposes only, and may be the trademarks or registered trademarks of their respective
companies.
. In no event will Gateway be liable for direct, indirect, special,
Notices
www.gateway.com
59
Safety, Regulatory, and Legal Information
60
www.gateway.com
Index
A
accessories 8
adjust
brightness
color 37
contrast 37, 38
screen width 37, 38
sound 39
TV settings 37
Adjustment button 12, 36
amplified speakers
connecting
amplifier
connecting
antenna connection 14
audio and video connection 13, 14
audio in connection 14
audio out connection 14
37, 38
28
29
B
back panel connections 13
batteries 6
brightness 37, 38
burn-in 5, 47
C
cable kits 8
cable TV
connecting coaxial (RF)
channel status 42
cleaning 46
exterior 46
screen 46
closed captioning 42
Coaxial (RF) video 18
color 37
component video 18
Component Video 1 connection 14
Component Video 2 connection 14
composite video 18
27
connection 14
computer
connecting
connecting DVI video 31
connecting RGB video 32
connecting
amplifier
cable TV 27
computer 31
DVD player 19
external amplified speakers 28
external monitor 33
external receiver 29
HDTV decoder set-top box 22
off-air TV 27
power cord 9
subwoofer 30
VCR 24
video camera 24
connections
antenna
audio and video 13, 14
audio in 14
audio out 14
back panel 13
Component Video 1 14
Component Video 2 14
composite video 14
DVI 13, 15
DVI audio in 14
DVI in 15
external speaker switch 14
