KX1563
Quick Guide
Safety Instructions
Observe the fol owing safety guidelines when connection and using your monitor:
· Be sure that your monitor is electrically rated to operate with the AC power available inyour location.
· Locate your monitor near an easily accessible electrical outlet.
· Place the monitor on a solid surface and treat it carefully. The screen can be damaged if dropped, sharply hit, or touched
· Put your monitor in a location with low humidity and a minimum of dust.
· Never use your monitor if the power cable has been damaged. Do not allow anything to rest on the power cable, and keep
· Never insert anything metallic into the monitor openings. Doing so may create the danger of electric shock.
· To avoid electric shock, never touch the inside of the monitor. Only a qualified technician should open the monitor’s case.
· Be sure to hold the plug, not the cable, when disconnecting the monitor from an electrical outlet.
· Openings in the monitor cabinet are provided for ventilation. To prevent overheating, these openings should not be
· Doing so may block the ventilation openings in the bottom of the cabinet. If you put the monitor in a bookcase or some
· Do not expose the monitor to rain or use it near water. If the monitor accidentally gets wet, unplug it and contact an
Connecting Your Monitor to a Computer
1.1-1 Connect Video Cable
a. Make sure both the monitor and computer are powered-OFF.
b. Connect the video cable to the .
2. Connect power cord
Connect the power cord to the monitor, then to a properly grounded AC outlet.
Power-ON Monitor and Computer
3.
Power-ON the monitor first, then power-ON the computer.
This sequence is very important.
4.
If the monitor still does not function properly, please refer to the troubleshooting section to diagnose the problem.
l
with a sharp or abrasive implement.
the cable away from where people could trip over it.
blocked or covered. Also, avoid using the monitor on a bed, sofa, rug, or other soft surface.
other enclosed space, be sure to provide adequate ventilation.
authorized dealer immediately. You can clean the exterior of the monitor with a damp cloth when necessary, but be sure
to unplug the monitor first. If your monitor does not operate normally-in particular, if there are any unusual sounds or smells
coming from it -unplug the monitor immediately and contact an authorized dealer or service center.
computer
English
Troubleshooting Tips
No Power - The monitor’s power indicator is off.
Make sure the monitor power cable is fully inserted in the monitor’s power port and the electrical outlet.
Test the electrical oulet by plugging in a working electrical device such as a lamp.
Try another power cable on the monitor. You can use the computer’s power cable to perform this test.
No Video - The monitor’s power indicator is on but there are no
image on the screen.
Ensure that the video connector is properly connected to the computer.
Ensure that the computer is on and functioning properly.
Turn off the monitor and check the video cable pins. Make sure no pins are bent.
LCD Monitor Quick Setup Guide
Regulations and safety notices
FCC notice
This device has been tested and found to comply with the limits for a Class B digital
device pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This device
English
generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this device does cause harmful interference to radio or television reception, which
can be determined by turning the device off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the device and receiver.
• Connect the device into an outlet on a circuit different from that to which the
• Consult the dealer or an experienced radio/television technician for help.
Notice: Shielded cables
All connections to other computing devices must be made using shielded cables to
maintain compliance with C regulations.
Notice: Peripheral devices
Only peripherals (input/output devices, terminals, printers, etc.) certified to comply with
the Class B limits may be attached to this equipment. Operation with non-certified
peripherals is likely to result in interference to radio and TV reception.
Caution
Changes or modifications not expressly approved by the manufacturer could void the
user authority, which is granted by the Federal Communications Commission, to operate
this product.
receiver is connected.
CC
E
M
Operation conditions
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference,
must accept any interference received, including interference that may cause undesired
operation.
Notice: Canadian users
&$1 ,&(6%10%%
and (2) this device
LCD Monitor Quick Setup Guide
Disposal of waste equipment by user in private household in the European Union
This symbol on the product or on its packaging indicates that this product must not be
disposed of with your other household waste. Instead, it is your responsibility to
dispose of your waste equipment by handing it over it a designated collection point
for the recycling of waste electrical and electronic equipment. The separate collection
and recycling of your waste equipment at the time of disposal will help to conserve
natural resources and ensure that it is recycled in a manner that protects human
health and the environment. For more information abut where you can drop off your
waste equipment for recycling, please contact your local city office, your household
waste disposal service or the shop where you purchased the product.
English
Regulatory Compliance
C US
R
LR60441
LCD Monitor Quick Setup Guide
SPECIFICATION
Driving system TFT Color LCD
Size
Pixel pitch 0.252mm(H)x 0.252mm(V)
LCD Panel
Brightness 200cd/m2 (Typical)
Contrast
English
Viewable angle
Response time 16 ms (Typical)
Video R,G,B Analog Interface
H-Frequency 42‐
V-Frequency 52‐
Display Colors
Dot Clock 160MHz
Max. Resolution 1366x768@60Hz
Plug & Play VESA DDCCI/DDC2B
Power consumption
@cd/m
2
ON Mode
Sleep Mode
Off
Input Connector
Input Video Signal
Maximum Screen Size
Power Source 100-240V~,50/60Hz
Environmental Considerations
Dimensions
Weight (N. W.)
Switch
External Controls:
Functions
15.6” W
100000000:1 Max (ACM)
o
(H)50o(V)(CR=10)(
90
0.26M Colors
10W(typ.)
0.
46W(typ.)
0.35W(typ.)
D-Sub
Analog:0.7Vp-p(standard), 75 OHM, Positive
Horizontal : 344 mm
Vertical : 193 mm
Operating Temp: 0
Storage Temp.: -20
Operating Humidity: 20% to 85%
377 (W) x 295 (H) x 160(D)mm
1.52 kg Unit (net)
Empowering Key and Automatic adjustment/ Exit
</ >
Power Button
MENU/ENTER
Contrast
Brightness
Focus
Clock
H.Position
V.Position
(Warm) Color
(Cool) Color
RGB Color temperature
Language
OSD position. timeout
Auto configuration (only Analog input model)
Display information
Reset
Exit
FP
52KHz
68Hz
o
C to 40oC
o
C to 60oC
