FUSION® MS-RA210

Quick Start Manual

ENGLISH

Getting Started

WARNING

See the Important Safety and Product Information guide in the product box for product warnings and other important information.

Getting the Owner's Manual

You can get the latest owner's manual and translations of manuals from www.fusionentertainment.com/marine/products/stereo-units/ms-ra210/support /downloads.

Stereo Controls

Button Function

Dial • Turn to adjust the volume.

◦ When adjusting the volume, press to switch between zones. ◦ When adjusting the volume, press and hold for at least one second to

adjust the subwoofer levels.

• Turn to move through the menus or adjust a setting.

• When in a menu, press to select the highlighted option.

• On a screen with tabs, press and hold for at least one second to open the other tab, such as the PRESETS tab.

• Press to turn on the stereo.

• Press to mute and un-mute the audio.

• Press and hold to turn off the stereo.

Button Function

• Press to open the menu.

• Press to return to the previous screen from the menu.

• Press and hold to exit the menu.

• Press to change the source.

• Press to skip to the beginning of the track or to the previous track, when using an applicable source.

• Press and hold to rewind the track, when using an applicable source.

• AM, FM, or SiriusXM (in Live Mode) source: ◦ Press to tune to the previous station or preset. ◦ Press and hold for faster tuning (manual mode only).

• SiriusXM (in Replay Mode) source: ◦ Press to skip to the previous track. ◦ Press and hold to rewind the current track.

• DAB source: ◦ Press to return to the previous DAB station in the ensemble. When you

reach the beginning of the current ensemble, the stereo automatically changes to the last available station in the previous ensemble.

◦ Press and hold to change the ensemble.

2 Quick Start Manual

Button Function

• Press to pause or resume media playback.

• AM/FM: ◦ Press to cycle through the tuning modes (auto, manual, and presets). ◦ Press and hold to save the selected station as a preset.

• SiriusXM source: ◦ Press and hold to switch between Replay Mode and Live Mode. ◦ In Live Mode, press to cycle through the tuning modes (manual, category,

and presets).

◦ In Replay Mode, press to pause and play.

• DAB source: press to scan for DAB stations.

• Press to skip to the next track, when using an applicable source.

• Press and hold to fast-forward the track, when using an applicable source.

• AM, FM, or SiriusXM (in Live Mode) source: ◦ Press to tune to the next station or preset. ◦ Press and hold for faster tuning (manual mode only).

• SiriusXM (in Replay Mode) source: ◦ Press to skip to the next track, if applicable. ◦ Press and hold to fast-forward the current track, if applicable.

• DAB source: ◦ Press to advance to the next DAB station in the ensemble. When you

reach the end of the current ensemble, the stereo automatically changes to the first available station in the next ensemble.

◦ Press and hold to change the ensemble.

Stereo Screen

The information displayed on the screen varies depending on the source selected. This example shows the device playing a track on a device connected using Bluetooth® wireless technology.

Source

Album art (if available from a compatible source)

Track details

Elapsed time, track duration, and the current track number out of the total number of tracks in the playlist (if available)

Selecting a Source

Select .

Turn the dial to highlight a source.

Press the dial to select the source.

Adjusting the Volume

Turn the dial to adjust the volume.

If necessary, press the dial to switch between zones. TIP: To control all zones at the same time, press the dial repeatedly to select

GLOBAL.

Quick Start Manual

Media Player Connection

CAUTION

Always disconnect your media player from the stereo when not in use and do not leave it in your vessel. This helps reduce the risk of theft and damage from extreme temperatures.

Do not remove the media player or use your stereo in a distracting manner while operating the vessel. Check and obey all marine laws in association with use.

The stereo accepts a variety of media players, including smartphones and other mobile devices. You can connect a compatible media player using a Bluetooth wireless connection or a USB connection to the USB port.

USB Device Compatibility

You can use a USB flash drive or the USB cable included with your media player to connect a media player or mobile device to the USB port.

The stereo is compatible with iAP2 Apple® devices such as the iPhone® Xs Max, iPhone Xs, iPhone XR, iPhone X, iPhone 8 Plus, iPhone 8, iPhone 7 Plus, iPhone 7, iPhone SE, iPhone 6s Plus, iPhone 6s, iPhone 6 Plus, iPhone 6, iPhone 5s, and iPod touch® (6th generation).

The stereo is compatible with Android™ devices that support MTP mode. The stereo is compatible with media players and other USB mass storage

devices, including USB flash drives. Music on USB drives must meet these conditions:

• The music files must be formatted as MP3, AAC (.m4a), or FLAC, files.

• If you connect a portable hard drive, you must connect it to an external power source. The USB port on this stereo cannot provide power for a portable hard drive.

• The USB mass storage device must be formatted using one of the following systems: ◦ Microsoft®: NTFS1, VFAT, FAT2, MSDOS

◦ Apple: HFS, HFSPLUS ◦ Linux: EXT2, EXT3, EX4

Connecting a USB Device

You can connect a USB device to the USB port on the stereo.

Locate the USB port on the back of the stereo.

Connect the USB device to the USB port.

Select the USB source.

Connecting a Compatible Bluetooth Device

You can play media from a compatible Bluetooth device using the Bluetooth wireless connection.

You can control the music playback with the media app on a Bluetooth device or using the FUSION-Link™ remote control app (page 6).

Select the BT source.

Select > DISCOVERABLE to make the stereo visible to your compatible Bluetooth device.

Enable Bluetooth on your compatible Bluetooth device.

Bring the compatible Bluetooth device within 10 m (33 ft.) of the stereo.

On your compatible Bluetooth device, search for Bluetooth devices.

On your compatible Bluetooth device, select the stereo from the list of detected devices.

On your compatible Bluetooth device, follow the on-screen instructions to pair and connect to the discovered stereo.

When pairing, your compatible Bluetooth device may ask you to confirm a code on the stereo. The stereo does not display a code, but it does connect correctly when you confirm the message on the Bluetooth device.

If your compatible Bluetooth device does not immediately connect to the stereo, repeat steps 1 through 7.

Software updates are not supported using NTFS file system.2 FAT includes most types of FAT file systems except exFAT.

4 Quick Start Manual

The DISCOVERABLE setting is disabled automatically after two minutes. NOTE: On some Bluetooth devices, adjusting the volume on the device affects

the volume level on the stereo.

Connecting to a Garmin® Watch

For more information about the watch, see the watch manual at www.garmin.com /manuals.

Following the instructions in the watch manual, install the FUSION-Link Lite

™

app from the Connect IQ™ store onto the watch.

On the stereo, select the BT source.

Select > DISCOVERABLE. The stereo remains discoverable for two minutes.

Bring the watch within 3 m (10 ft.) of the stereo.

NOTE: Stay 10 m (33 ft.) away from other ANT® devices while pairing.

Open the FUSION-Link Lite app on the watch. The first time you open the app on the watch, the watch automatically pairs

with and connects to the stereo. If you need to pair to another stereo, in the FUSION-Link Lite app, select Settings > Pair new.

Control the audio playback using the FUSION-Link Lite app on the watch.

After the devices are paired, they connect automatically when they are turned on, within range, and the app is open on the watch.

Connecting to an ARX70 Remote Control

On the stereo, select the BT source.

Select > DISCOVERABLE.

Bring the ARX70 remote control within 10 m (33 ft.) of the stereo.

NOTE: Stay 10 m (33 ft.) away from other ANT devices while pairing.

On the ARX70 remote control, press and hold until the status LED starts alternating green and red.

The remote control searches for the stereo. When the remote control pairs successfully, the status LED turns on green briefly and then turns off.

If the remote control cannot find the stereo, the status LED turns on red briefly and then turns off.

Playing Music

Setting the Tuner Region

You must select the region you are in to receive AM and FM stations properly. If you are connected to a compatible SiriusXM® tuner and antenna, and have a

subscription (USA only), you must select the region you are in to receive SiriusXM stations properly.

NOTE: SiriusXM is not available in all regions. If you are connected to a compatible DAB module and antenna (not included),

you must select the region you are in to receive DAB stations properly.

NOTE: DAB stations are not available in all regions.

Select > SETTINGS > TUNER REGION.

Select the region you are in.

Changing the Radio Station

Select an applicable source, such as FM.

Select to select a tuning mode. You can use AUTO mode to scan stations, MANUAL mode to manually tune

to a station, and PRESET mode to select the next preset station.

Select or to tune to the station. TIP: You can quickly save the selected station or channel as a preset by

holding .

Scanning for DAB Stations

Before you can scan for DAB stations, you must connect a compatible DAB module and antenna (not included) to the stereo. Because DAB signals are
