Fisher & Paykel WH80F60W1 User Guide

Installation instructions

and user guide

Washing machine

WH60F60W2, WH70F60W2

and

WH80F60W1 models

NZ AU SGP

Contents

Safety and warnings 2
Installation instructions 4
Initial preparations for washing 8
Selecting a program and operating your machine 10
Care and cleaning 19
Trouble shooting 22
Specifications 23
Manufacturers warranty 24
Customer Care 25

Important!

SAVE THESE INSTRUCTIONS

The models shown in this user guide may not be available in all markets and are
subject to change at any time. For current details about model and specification
availability in your country, please go to our website www.fisherpaykel.com or
contact your local Fisher & Paykel dealer.

Safety and warnings

General safety

Never place your machine on a carpet covered floor. A lack of airflow from below of your
machine may cause electrical parts to overheat.
Secure the drain hose into the standpipe or tub to prevent any water leakage and to allow
machine to discharge water as required. Ensure that the inlet and drain hoses are not folded,
squashed, or broken when the appliance is pushed into place after it is installed or cleaned.
There may be some water in your machine when you receive it. This is from the quality control
process and is normal. It is not harmful to your machine.
Clean the outside of the appliance with a soft cloth. Do not use abrasive detergents.
Never force open the door or use it as a step.
Your washing machine is designed to continue operation in the event of a power interruption.
The cycle will resume once the power is restored. To cancel a program, refer to the “Cancelling a
program” section.
If damaged, the power cable should be replaced with an identical one obtained from an
Authorised Service Agent. The power cable may only be replaced by a qualified technician.
This appliance is not intended for use by young children or infirmed persons without
supervision.
Young children should be supervised to ensure that they do not play with the appliance or climb
inside the drum.
Keep the packaging materials out of reach of children.

2

First use

Ensure that the cold and hot water inlet hoses have been correctly connected when installing
your machine.
To remove any residues from the manufacturing process, we recommend running the machine
through an initial Cottons 90º cycle with a half -load amount of detergent, but without adding
laundry.

Intended use

This product has been designed for home use.
The appliance may only be used for the washing and rinsing of textiles that are marked
accordingly.

3

Safety and warnings

Safety instructions

This appliance must be connected to an earthed outlet protected by a fuse of suitable capacity.
Never open the loading door or remove the filter while there is still water in the drum.
Unplug the machine when it is not in use.
Never touch the plug with wet hands.
Do not operate the machine if the power cord or plug is damaged.
For malfunctions that cannot be solved by information in the operating manual:

1 Turn off the machine.
2 Unplug the appliance at the wall socket.
3 Turn off the water taps.
4 Contact an Authorised Service Agent.

If there are children in your house...

Keep children away from the machine when it is operating.
Do not let them tamper with the machine.
Close the loading door when you leave the area where the machine is located.

Installation instructions

4

Remove the packaging

Remove the packaging reinforcement underneath the product by tiliting the machine and
pulling the extruding ribbon.

Removing the transit safety bolts

The washing machine is fitted with transit safety bolts to avoid any possible damage to the
interior during transportation.

Before using the machine it is imperative that these bolts are removed. Failure to remove these
will result in damage to the machine.

Please keep these transit safety bolts in a safe place to reuse before transporting the machine in
the future.
Never transport the machine without the transportation safety bolts properly fixed in place.
To remove the bolts:

1 Loosen all the bolts with a spanner until they rotate freely (“C”).
2 Remove the transit bolts by turning them gently.
3 Fit the bolthole covers (supplied in the bag with the operation manual) into the holes on the rear

panel (“P”).

Positioning the machine

Move the machine into position without lifting by the top panel.
Install the machine on a solid and level floor surface, preferably in a corner of the room.

5

Installation instructions

Adjusting the feet

In order for quiet and stable operation, the machine should be placed properly and levelled on
its feet.
If the machine is unstable:

1 Loosen the plastic lock nut
2 Screw or unscrew the adjustable foot until the machine stands firmly level.
3 Tighten the lock nut for stability.

Note:

Do not use any tools to loosen or tighten the lock nuts, as they can be damaged.

Connecting to the water supply

Important:

Hot water should not exceed 65ºC.
Cold water should not exceed 35ºC

Temperatures above these may cause the machine to fault or result in damage to the machine.
If you have an uncontrolled water heating source (eg. Wet back or solar heating system) you
should fit a Safe Valve. This will ensure the hot water temperature remains within safe limits.

Water supply requirements

Inlet water pressure: Max. 1Mpa (150 psi) Min. 34Pa (5 psi)
Inlet water flow rate: Min. 3 litres/min

Installation instructions

Inlet hoses

The appliance must be connected to the water mains using new hose sets. Old hose sets should
not be reused.

Connecting the hoses:

1 Connect the straight ends of the inlet hoses to the taps. There are washers fitted to both ends.
2 Connect the elbow ends of the inlet hoses to the inlet valves on the back of the machine. The

cold inlet valve is marked in blue, while the hot inlet valve is marked in red.

Cold supply only

If you only have a cold water supply, an inlet valve cap (blanking cap) MUST be connected to the
hot inlet valve. This prevents water leaking out of the hot inlet valve. The cap is supplied in the
same bag as the inlet water hoses.

6

7

max. 100 cm

min.

40 cm

Installation instructions

Connecting to the drain

The water drain hose should be placed either at the side of a basin or tub, or connected directly
to the waster standpipe.
The elbow/guide, supplied with the machine, should be fitted to the drain hose before being
connected directly into the tub or wastewater standpipe.
The drain hose should not be sharply bent.
The drain hose needs to be kept at an elevated height of at least 40cm with a maximum height
of 100cm. If the hose is placed at the floor level, or close to the floor (less than 40 cm above the
ground), water discharge becomes more difficult and the laundry may come out wet.

The drain hose should extend a maximum of 20mm past the end of the elbow/guide.
The drain hose can be trimmed to length.
The maximum length of an extended drain hose is 3.2m.

Electrical connection

Connect the appliance to an earthed outlet protected by a fuse of suitable capacity.
Connection should comply with national regulations.
The voltage and the allowed fuse protection are specified in the “Technical Specifications”
section.

Caution!
If you are using an extension cord or a portable electrical outlet devise (eg. multi-socket outlet box), ensure
that it is positioned so that it does not come into contact with water or moisture.

Important:

A damaged power cable must be replaced by a qualified electrician. The appliance must not be
operated until it is repaired, as there is risk of electric shock.
Do not operate this machine if it has been damaged in during transport. Contact your Fisher &
Paykel Dealer or Authorised Service Agent.

Initial preparations for washing

Preparing clothes for washing

Always follow the advice on the garment care label. It will tell you about the fabric of the
garment and how it should be washed.
Sort the laundry according to type of fabric, colour, degree of soiling, and allowable water
temperature.
Check and empty pockets. Coins, safety pins etc. can damage both your machine and your
clothes.
Remove any metal attachments, or place the items in a clothing bag, pillowcase, or something
similar (eg. items such as bras, or garments with metal buttons or belt buckles). The metal
attachments may cause damage to the machine.
Close zippers, hooks and eyes. This is to make sure that these items do not snag on other clothes.
Place small items like infants’ socks and nylon stockings, etc. in a laundry bag, pillow case or
something similar. This will also save your laundry from getting lost.
Wash trousers and delicate clothes turned inside out.
Wash “machine washable” or “hand washable” labelled products with an appropriate program
only.
Do not wash colours and whites together. New, dark coloured items may release a lot of dye. It is
recommended to wash them separately.
Pre-treat heavily soiled areas with stain remover if necessary.
Use only dyes/colour changers and lime removers suitable for machine wash. Plastic and rubber
parts of the washing machine can be stained by dyes. Always follow the instructions on the
packaging.

8
