Fisher & Paykel OR90L User Manual
Freestanding cooker
OR90L double oven models
Installation instructions
and User guide
GB IE
Contents
1
Safety and warnings
Installation instructions
Introducing your cooker
Using your gas cooktop
Cooktop troubleshooting
Using your main multifunction oven for the first time
Clock and timer
Using your main oven
Cooking functions
Automatic cooking
Using your compact multifunction oven for the first time
Using your compact oven
Cooking functions
Using the dish-warming shelf
Care and cleaning
Warranty and service
12
22
23
27
28
29
30
31
33
34
35
35
38
39
49
2
Important!
SAVE THESE INSTRUCTIONS
The models shown in this User Guide may not be available in all markets and are
subject to change at any time. For current details about model and specification
availability in your country, please visit our local website listed on the back cover
or contact your local Fisher & Paykel dealer.
2
Safety and warnings
Installation
Electrical Shock Hazard
Always disconnect the cooker from the
mains electricity supply before
carrying out any maintenance
operations or repairs.
Failure to do so may result in death or
electrical shock.
Cut Hazard
Take care - panel edges are sharp.
WARNING!
WARNING!
Failure to use caution could result in
injury or cuts.
Important safety precautions
General
To avoid hazard, follow these instructions
carefully before installing or using this product.
Please make this information available to the
person installing the product as it could reduce
your installation costs.
Installation must comply with your local
building and electricity regulations.
Failure to install the cooker correctly could
invalidate any warranty or liability claims.
Safety and warnings
Some appliances have a protective film. Remove
this film before using the cooker.
After unpacking the appliance, check to to
ensure it is not damaged and the door closes
correctly. If in doubt, do not use it and consult
your Authorised Dealer or a professionally
qualified technician.
Electrical
This cooker is to be installed and connected
to the electricity supply only by an authorised
person.
If the installation requires alterations to the
domestic electrical system call a qualified
3
electrician. He should also check that the
electrical system is suitable for the electricity
drawn by the cooker.
The appliance must be connected to the mains,
checking that the voltage corresponds to the
value given in the rating plate and that the
electrical cable sections can withstand the load
specified on the plate.
A suitable disconnection switch must be
incorporated in the permanent wiring, mounted
and positioned to comply with the local wiring
rules and regulations. The switch must be of an
approved type installed in the fixed wiring and
provide a 3 mm air gap contact separation in all
poles in accordance with the local wiring rules.
4
Safety and warnings
Electrical
The switch must always be accessible.
The power supply cable must not touch any hot
parts and must be positioned so that it does not
exceed 75
O
C at any point and cannot become
entrapped in the oven door.
To connect the cooker to the mains, do not use
adapters, reducers or branching devices as they
can cause overheating and burning.
This cooker must be connected to a suitable
double pole control unit adjacent to the cooker.
No diversity can be applied to this control unit.
The cooker must be earthed.
Gas
This cooker is supplied for use with natural gas
only, and cannot be used on any other gas
without modification. See ‘Gas installation’ for
modification to other gas types.
This cooker can only be installed in a room
with adequate ventilation. See the ‘Ventilation
requirements’ in the installation instructions .
Safety and warnings
General
Do not leave packing elements (plastic bags,
polystyrene foam, nails, packing straps etc)
around within easy access of children, as these
may cause serious injuries.
Read the instructions carefully before installing
and using the appliance.
The manufacturer declines all liability for injury
to persons or damage to property caused by the
incorrect use or improper use of the appliance.
If you should decide to dispose of this cooker,
we recommended that it be made inoperative in
an appropriate manner in accordance to health
and environmental protection regulations. In
5
particular, ensure that all potentially hazardous
parts are made harmless, especially in regard to
children who could play with unused appliances.
Various components of the appliance are
recyclable. Dispose of them in accordance with
the regulations in force in your country. If the
appliance is to be scrapped, remove the power
cord.
6
Safety and warnings
Operation
Your freestanding cooker has been carefully designed to operate safely during normal cooking
procedures. Please keep the following guidelines in mind when you are using it:
WARNING!
Explosion Hazard
Do not store flammable materials such
as gasoline near the cooktop.
Do not store flammable material in the
ovens or in the storage compartment.
Do not spray aerosols near the cooktop
during use.
Failure to do so may result in death or
serious injury.
WARNING!
Electrical Shock Hazard
Switch the cooker off at the wall before
replacing fuses or the oven lamp.
Failure to do so may result in death or
electrical shock.
Safety and warnings
WARNING!
7
Hot Surface Hazard
Accessible parts will become hot when
this cooker is in use.
To avoid burns and scalds keep children
away.
Do not touch hot surfaces inside the
ovens.
Use oven mitts or other protection
when handling hot surfaces such as
oven shelves or dishes.
Take care when opening the oven doors.
Let hot air or steam escape before
removing or replacing food.
Do not touch the cooktop components,
burners, trivets/pan supports or the
base when hot.
Before cleaning, turn the cooker off and
make sure it is cool.
Failure to do so could result in burns
and scalds.
8
Safety and warnings
Important safety precautions
Never leave the appliance unattended
when in use. Boilover causes smoking and
greasy spillovers that may ignite. NEVER try
to extinguish a fire with water. Switch the
appliance off at the wall and then cover the
flame with a lid or fire blanket.
Isolating switch: make sure this cooker is
connected to a circuit which incorporates an
isolating switch providing full disconnection
from the power supply.
Household appliances are not intended to
be played with by children. Children of less
than 8 years old must be kept away from the
appliance unless continuously supervised. This
appliance can be used by children aged from
8 years and above, and persons with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge, if they have been
given supervision or instruction concerning
the use of the appliance in a safe way and they
understand the hazards involved.
Cleaning and user maintenance shall not be
done by children without supervision.
Safe food handling: leave food in the oven for
as short a time as possible before and after
cooking. This is to avoid contamination by
organisms which may cause food poisoning.
Safety and warnings
Take particular care during warmer weather.
Do not place aluminium foil, dishes, trays, water
or ice on the oven floor during cooking as this
will irreversibly damage the enamel.
Do not line the walls with aluminium foil.
Do not stand on the doors, or place heavy
objects on them.
Do not use harsh abrasive cleaners or sharp
metal scrapers to clean the oven door glass since
they scratch the surface, which may result in
shattering of the glass.
Do not use a steam cleaner to clean any part of
the cooker.
Do not use an asbestos mat or decorative covers
9
between the flame and the saucepan as this
may cause serious damage to your cooktop. Do
not place aluminium foil or plastic dishes on the
cooktop burners.
Do not let large saucepans or frying pans
overlap the bench as this can deflect heat onto
your benchtop and damage the surface.
Do not let large saucepans, frying pans or
woks push any other pans aside. This could
make them unstable or deflect heat onto your
benchtop and damage the surface.
Saucepan handles may be hot to touch. Ensure
saucepan handles do not overhang other gas
burners that are on. Keep handles out of reach
of children.
10
Safety and warnings
Do not hang towels, dishcloths or other items
on the cooker or oven door handle as this is a
potential a fire hazard.
If the electrical supply cord is damaged, it must
only be replaced by an authorised person.
Do not touch the cooker with wet hands or feet.
Do not operate whilst in bare feet.
This cooker is not to be used as a space heater.
The use of a gas cooking appliance results in
the production of heat and moisture in the
room in which it is installed. Ensure the kitchen
is well ventilated. Keep natural ventilation
holes open or install a mechanical ventilation
device (mechanical extractor hood). Prolonged
intensive use of the appliance may call for
additional ventilation, for example opening
of a window, or more effective ventilation, for
example increasing the level of mechanical
ventilation where present.
Do not operate the cooker by means of an
external timer or separate remote-control
system.
Do not modify this appliance as it may become
dangerous to use. The manufacturer declines all
responsibility for any inconvenience or damage
to persons or property arising from the nonobservance of this condition.
Safety and warnings
The manufacturer declines all liability for
damage to property cause by the incorrect or
improper use of the appliance.
Important! This appliance is designed and
manufactured solely for the cooking of domestic
(household) food and it not suitable for any non
domestic application and therefore should not
be used in a commercial environment.
The appliance guarantee will be void if the
appliance is used with in a non domestic
environment ie a semi-commercial, commercial
or communal environment.
11
12
650 mm
5
00
m
m
A
U
T
O
450 mm
200 mm
air vent
Installation instructions
USABLE = 41 L
USABLE = 70 L
Figure 1 Cooker dimensions and capacity
The cooker must be installed by a qualified technician and in compliance with local
safety standards. This cookers has class “2/1” overheating protection so that it can be installed
next to a cabinet.
If the cooker is installed adjacent to furniture which is higher than the gas hob cooktop, a
gap of at least 200 mm must be left between the side of the cooker and the furniture.
The furniture walls adjacent to the
cooker must be made of material
resistant to heat.The veneered
synthetical material and the glue used
must be resistant to a temperature
of 90°C in order to avoid ungluing or
deformations.
The cooker may be located in a
kitchen, a kitchen/diner or bed-sitting
room but not in a room containing a
bath or shower.
Curtains must not be fitted
immediately behind appliance or
within 500 mm of the sides.
If the cooker is located on a pedestal
it is necessary to provide safety
measures to prevent falling out.
It is essential that the cooker is
positioned as stated.
Figure 2 Correct distances from cooker
Installation instructions
Fitting the adjustable feet
Important!
Using the supplied adjustable feet is MANDATORY. For safety reasons and to ensure adequate
ventilation, the cooker chassis MUST NOT sit directly on the floor, a plinth, or other support surface.
The adjustable feet must be fitted to the base of the cooker before use.
Rest the rear of the cooker on a piece of the polystyrene packaging exposing the base for the
fitting of the feet.
Fit the four legs by screwing them tight into the support base as shown.
13
Figure 3 Location of feet Figure 4 Top of feet screwed in tightly
Levelling the cooker
Level the cooker by screwing the bottom of the feet in or out, as shown.
Figure 5 Levelling the cooker
14
A
C
B
Installation instructions
Moving the cooker
Important!
Two people must always raise the cooker, as
shown, to prevent damaging the adjustable feet.
Do not lift the cooker by the door handles.
DO NOT DRAG the cooker. Lift the feet clear of the
floor.
Figure 6 Correctly raising the cooker
Backguard
Before installing the cooker, assemble the
backguard “C” .
The backguard “C” can be found packed
at the rear of the cooker.
Before assembling remove any protective
film/adhesive tape.
Remove the two spacers “A” and the
screw “B” from the rear of the cooktop.
Assemble the backguard as shown and
fix it by screwing the central screw “B”
and the spacers “A”.
Figure 8 Incorrectly raising the cookerFigure 7 Incorrectly moving the cooker
Figure 9 Assembling
the backguard
Installation instructions
Anti-Tilt Bracket
Important!
To restrain the appliance and prevent it tipping accidentally, fit a bracket to its rear
to fix it securely to the wall.
To fit the anti-tilt bracket:
1
After you have located where the cooker is to be positioned, mark on the wall the place where
the two screws of the anti-tilt bracket have to be fitted. Please follow the indications given in Fig.
10.
2
Drill two 8 mm diameter holes in the wall and insert the plastic plugs supplied.
Important!
Before drilling the holes, check that you will not damage any pipes or electrical wires.
3
Loosely attach the anti-tilt bracket with the two screws supplied.
4
Move the cooker to the wall and adjust the height of the anti-tilt bracket so that it can engage in
the slot on the cooker’s back, as shown in fig. 10.
5
Tighten the screws attaching the anti-tilt bracket.
6
Push the cooker against the wall so that the anti-tilt bracket is fully inserted in the slot on the
cooker’s back.
Existing slot in rear of cooker
15
Figure 10 Fitting a stability bracket
Anti-tilt bracket
Dotted line showing the
position of cooker when installed
Loading...
