Epson WF-7110DTW User Guide

User’s Guide

NPD4894-03 EN

User’s Guide

Copyright and Trademarks

No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of Seiko Epson Corporation. No patent liability is assumed with respect to the use of the information contained herein. Neither is any liability assumed for damages resulting from the use of the information herein. The information contained herein is designed only for use with this Epson product. Epson is not responsible for any use of this information as applied to other products.

Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this product or third parties for damages, losses, costs, or expenses incurred by the purchaser or third parties as a result of accident, misuse, or abuse of this product or unauthorized modifications, repairs, or alterations to this product, or (excluding the U.S.) failure to strictly comply with Seiko Epson Corporation’s operating and maintenance instructions.

Seiko Epson Corporation and its affiliates shall not be liable for any damages or problems arising from the use of any options or any consumable products other than those designated as Original Epson Products or Epson Approved Products by Seiko Epson Corporation.

Seiko Epson Corporation shall not be held liable for any damage resulting from electromagnetic interference that occurs from the use of any interface cables other than those designated as Epson Approved Products by Seiko Epson Corporation.

EPSON of Seiko Epson Corporation.

Intel

PowerPC

Microsoft

Apple, Macintosh, Mac OS, and OS X are trademarks of Apple Inc., registered in the U.S. and other countries.

AirPrint is a trademark of Apple Inc.

Google Cloud Print

Adobe, Adobe Reader, Acrobat, and Photoshop are trademarks of Adobe systems Incorporated, which may be registered in certain jurisdictions.

is a registered trademark, and EPSON EXCEED YOUR V IS IO N o r E XC E ED YO U R V IS IO N i s a tr ad em a rk

is a registered trademark of Intel Corporation.

is a registered trademark of International Business Machines Corporation.

, Windows®, and Windows Vista® are registered trademarks of Microsoft Corporation.

is a registered trademark of Google Inc.

™

General Notice: Other product names used herein are for identification purposes only and may be trademarks of their respective owners. Epson disclaims any and all rights in those marks.

The contents of this manual and the specifications of this product are subject to change without notice.

User’s Guide

Contents

Introduction

Where to Find Information................... 6

Caution, Important and Note................. 6

Operating System Versions................... 7

Using Epson Connect Service................. 7

Important Instructions

Safety Instructions......................... 9

Product Advisories and Warnings............. 10

Setting up/using the product............... 10

Using the product with a wireless connection

.................................... 11

Using the LCD screen.................... 12

Handling ink cartridges................... 12

Getting to Know Your Product

Product Parts............................ 13

Guide to the Control Panel.................. 14

Icons................................ 15

Paper and Media Handling

Introduction to Using, Loading, and Storing

Media.................................. 16

Storing paper.......................... 16

Selecting Paper........................... 16

Paper type settings on the LCD screen........ 19

Paper type settings from the printer driver. . . . . 19

Loading Paper into the Paper Cassette.......... 20

Loading Envelopes into the Paper Cassette. . . . . . . 24

Loading Paper and Envelopes into the Rear Paper

Feed Slot................................ 27

Printing

Printing from Your Computer................ 30

Printer Driver and Status Monitor........... 30

Basic Operations.......................... 32

Basic printing.......................... 32

Canceling printing...................... 35

Other Options........................... 37

Printing photos the easy way............... 37

Product presets (For Windows Only). . . . . . . . . 38

2-sided printing........................ 38

Fit to page printing...................... 40

Pages per Sheet printing.................. 41

Anti-Copy Pattern printing (for Windows

Only)................................ 42

Watermark printing (For Windows Only)..... 43

Header/Footer printing (For Windows Only)

.................................... 44

Administrator Settings for Printer Driver (for

Windows Only).......................... 45

Menu List of Control Panel

System Administration Settings............... 48

Ink Cartridge and Consumable Information

Ink Cartridges............................ 51

Maintenance Box ......................... 51

Replacing Ink Cartridges

Ink Cartridge Safety Instructions, Precautions,

and Specifications......................... 52

Safety instructions....................... 52

Precautions on ink cartridge replacement. . . . . . 53

Ink Cartridge Specifications................ 54

Checking the Ink Cartridge Status............. 54

For Windows.......................... 54

For Mac OS X.......................... 55

Using the control panel................... 56

Temporary Printing with Black Ink When Color

Ink Cartridges are Expended................. 57

For Windows.......................... 57

For Mac OS X.......................... 59

Conserving Black Ink When the Cartridge Is Low

(For Windows Only)....................... 60

Replacing an ink cartridge................... 61

User’s Guide

Contents

Maintaining Your Product and Software

Checking the Print Head Nozzles.............. 65

Using the Nozzle Check utility for Windows

.................................... 65

Using the Nozzle Check utility for Mac OS X

.................................... 65

Using the control panel................... 66

Cleaning the Print Head.................... 66

Using the Head Cleaning utility for Windows

.................................... 67

Using the Head Cleaning utility for Mac OS X

.................................... 67

Using the control panel................... 68

Aligning the Print Head.................... 68

Using the Print Head Alignment utility for

Windows............................. 68

Using the Print Head Alignment utility for

Mac OS X............................. 69

Using the control panel................... 69

Making Network Service Settings.............. 70

Sharing the Product for Printing.............. 71

Cleaning the Product...................... 71

Cleaning the exterior of the product.......... 71

Cleaning the interior of the product.......... 71

Replacing Maintenance Box.................. 72

Checking the maintenance box status......... 72

Precautions on the maintenance box......... 72

Replacing a maintenance box............... 72

Transporting the Product................... 74

Checking and Installing Your Software......... 75

Checking the software installed on your

computer............................. 75

Installing the software.................... 76

Uninstalling Your Software.................. 76

For Windows.......................... 77

For Mac OS X.......................... 78

Error Indicators

Error Messages on the Control Panel........... 79

Troubleshooting for Printing

Diagnosing the Problem.................... 80

Checking product status.................. 81

Paper Jams.............................. 83

Removing jammed paper from the rear cover

.................................... 84

Removing jammed paper from inside the

product.............................. 87

Removing jammed paper from the paper

cassette............................... 88

Preventing paper jams.................... 90

Reprinting after a paper jam (for Windows

only)................................ 90

Print Quality Help......................... 91

Horizontal banding...................... 92

Vertical banding or misalignment........... 92

Incorrect or missing colors................ 92

Blurry or smeared print................... 93

Miscellaneous Printout Problems.............. 94

Incorrect or garbled characters............. 94

Incorrect margins....................... 94

Printout has a slight slant................. 95

Inverted image......................... 95

Blank pages print....................... 95

Printed side is smeared or scuffed........... 95

Printing is too slow...................... 96

Paper Does Not Feed Correctly............... 96

Paper does not feed...................... 96

Multiple pages feed...................... 97

Paper is improperly loaded................ 97

Paper is not ejected fully or is wrinkled. . . . . . . . 97

The Product Does Not Print................. 97

All lights are off........................ 97

The control panel or lights are on............ 97

An ink error is indicated after you replace the

cartridge.............................. 98

Other Problem........................... 99

Printing plain papers quietly............... 99

Rear paper feed slot is removed............. 99

Product Information

System Requirements..................... 100

For Windows......................... 100

For Mac OS X......................... 100

Technical Specifications.................... 100

Printer specifications.................... 100

Network interface specification............ 103

Mechanical........................... 103

Electrical............................. 103

Environmental........................ 104

Standards and approvals................. 104

Interface............................. 105

User’s Guide

Contents

Where To Get Help

Technical Support Web Site................. 106

Contacting Epson Support.................. 106

Before Contacting Epson................. 106

Help for Users in Europe................. 107

Index

User’s Guide

Introduction

Where to Find Information

The latest version of the following manuals are available on the Epson support website.

http://www.epson.eu/Support (Europe) http://support.epson.net/ (outside Europe)

❏ Start Here (paper):

Provides you with an introduction to the product and services.

❏ Important Safety Instructions (paper):

Provides you with instructions to ensure the safe use of this product. This manual may not be included depending on model and region.

❏ User’s Guide (PDF):

Provides you with detailed operating, safety, and troubleshooting instructions. See this guide when using this product with a computer, or when using advanced features.

❏ Network Guide (PDF):

Provides instructions on network settings for your computer, smartphone or product, and solving problems.

❏ Administrator’s Guide (PDF):

Provides the system administrator with information on security management and product settings.

Caution, Important and Note

Caution, Important, and Note in this manual are indicated as below and have the following meaning.

Caution

must be followed carefully to avoid bodily injury.

Important

must be observed to avoid damage to your equipment.

Note

contain useful tips and restrictions on product operation.

User’s Guide

Introduction

Operating System Versions

In this manual, the following abbreviations are used.

❏ Windows 8 refers to Windows 8, Windows 8 Pro, Windows 8 Enterprise.

❏ Windows 7 refers to Windows 7 Home Basic, Windows 7 Home Premium, Windows 7 Professional, and

Windows 7 Ultimate.

❏ Windows Vista refers to Windows Vista Home Basic Edition, Windows Vista Home Premium Edition, Windows

Vista Business Edition, Windows Vista Enterprise Edition, and Windows Vista Ultimate Edition.

❏ Windows XP refers to Windows XP Home Edition, Windows XP Professional x64 Edition, and Windows XP

Professional.

❏ Windows Server 2012 refers to Windows Server 2012 Essentials Edition, Server 2012 standard Edition.

❏ Windows Server 2008 refers to Windows Server 2008 Standard Edition, Windows Server 2008 Enterprise Edition,

Windows Server 2008 x64 Standard Edition, and Windows Server 2008 x64 Enterprise Edition.

❏ Windows Server 2008 R2 refers to Windows Server 2008 R2 Standard Edition and Windows Server 2008 R2

Enterprise Edition.

❏ Windows Server 2003 refers to Windows Server 2003 Standard Edition and Windows Server 2003 Enterprise

Edition, Windows Server 2003 x64 Standard Edition and Windows Server 2003 x64 Enterprise Edition.

❏ Mac OS X refers to Mac OS X 10.5.8, 10.6.x, 10.7.x, 10.8.x.

Using Epson Connect Service

Using Epson Connect and other companies’ services, you can easily print directly from your smartphone, tablet PC or laptop, anytime and practically anywhere even across the globe! For more information about the printing and other services, visit the following URL;

https://www.epsonconnect.com/ (Epson Connect portal site) http://www.epsonconnect.eu (Europe only)

User’s Guide

Introduction

Note:

You can make network service settings using a Web browser on your computer, smartphone, tablet PC, or laptop that is connected to the same network as the product. & “Making Network Service Settings” on page 70

User’s Guide

Important Instructions

Safety Instructions

Read and follow these instructions to ensure safe use of this product. Make sure you keep this guide for future reference. Also, be sure to follow all warnings and instructions marked on the product.

❏ Use only the power cord supplied with the product and do not use the cord with any other equipment. Use of other

cords with this product or the use of the supplied power cord with other equipment may result in fire or electric shock.

❏ Be sure your AC power cord meets the relevant local safety standard.

❏ Never disassemble, modify, or attempt to repair the power cord, plug, printer unit, or options by yourself, except

as specifically explained in the product’s guides.

❏ Unplug the product and refer servicing to qualified service personnel under the following conditions:

The power cord or plug is damaged; liquid has entered the product; the product has been dropped or the casing damaged; the product does not operate normally or exhibits a distinct change in performance. Do not adjust controls that are not covered by the operating instructions.

❏ Place the product near a wall outlet where the plug can be easily unplugged.

❏ Do not place or store the product outdoors, near excessive dirt or dust, water, heat sources, or in locations subject

to shocks, vibrations, high temperature or humidity.

❏ Take care not to spill liquid on the product and not to handle the product with wet hands.

❏ Keep this product at least 22 cm away from cardiac pacemakers. Radio waves from this product may adversely

affect the operation of cardiac pacemakers.

❏ If the LCD screen is damaged, contact your dealer. If the liquid crystal solution gets on your hands, wash them

thoroughly with soap and water. If the liquid crystal solution gets into your eyes, flush them immediately with water. If discomfort or vision problems remain after a thorough flushing, see a doctor immediately.

User’s Guide

Important Instructions

❏ The product is heavy and should not be lifted or carried by fewer than two persons. When lifting the product, the

two persons should assume the correct positions (see below).

Note:

The following provides safety instructions for ink cartridges. & “Replacing Ink Cartridges” on page 52

Product Advisories and Warnings

Read and follow these instructions to avoid damaging the product or your property. Make sure you keep this guide for future reference.

Setting up/using the product

❏ Do not block or cover the vents and openings in the product.

❏ Use only the type of power source indicated on the product’s label.

❏ Avoid using outlets on the same circuit as photocopiers or air control systems that regularly switch on and off.

❏ Avoid electrical outlets controlled by wall switches or automatic timers.

❏ Keep the entire computer system away from potential sources of electromagnetic interference, such as

loudspeakers or the base units of cordless telephones.

❏ The power-supply cords should be placed to avoid abrasions, cuts, fraying, crimping, and kinking. Do not place

objects on top of the power-supply cords and do not allow the power-supply cords to be stepped on or run over. Be particularly careful to keep all the power-supply cords straight at the ends and the points where they enter and leave the transformer.

User’s Guide

Important Instructions

❏ If you use an extension cord with the product, make sure that the total ampere rating of the devices plugged into

the extension cord does not exceed the cord’s ampere rating. Also, make sure that the total ampere rating of all devices plugged into the wall outlet does not exceed the wall outlet’s ampere rating.

❏ If you plan to use the product in Germany, the building installation must be protected by a 10 or 16 amp circuit

breaker to provide adequate short-circuit protection and over-current protection for the product.

❏ When connecting the product to a computer or other device with a cable, ensure the correct orientation of the

connectors. Each connector has only one correct orientation. Inserting a connector in the wrong orientation may damage both devices connected by the cable.

❏ Place the product on a flat, stable surface that extends beyond the base of the product in all directions. The product

will not operate properly if it is tilted at an angle.

❏ When storing or transporting the product, avoid tilting it, placing it vertically, or turning it upside down;

otherwise ink may leak.

❏ Allow spaces behind the product for the cables, and space above the product so that you can fully raise the printer

cover.

❏ Leave enough space in front of the product for the paper to be fully ejected.

❏ Avoid places subject to rapid changes in temperature and humidity. Also, keep the product away from direct

sunlight, strong light, or heat sources.

❏ Do not insert objects through the slots in the product.

❏ Do not put your hand inside the product or touch the ink cartridges during printing.

❏ Do not touch the white flat cable inside the product.

❏ Do not use aerosol products that contain flammable gases inside or around the product. Doing so may cause

fire.

❏ Do not move the ink cartridge holder by hand; otherwise, you may damage the product.

❏ Always turn the product off using the P button. Do not unplug the product or turn off the power at the outlet until

the LCD screen has turned off completely.

❏ Before transporting the product, make sure that the print head is in the home (far right) position and the ink

cartridges are in place.

❏ If you are not going to use the product for a long period, be sure to unplug the power cord from the electrical

outlet.

Using the product with a wireless connection

❏ Do not use this product inside medical facilities or near medical equipment. Radio waves from this product may

adversely affect the operation of electrical medical equipment.

❏ Do not use this product near automatically controlled devices such as automatic doors or fire alarms. Radio waves

from this product may adversely affect these devices, and could lead to accidents due to malfunction.

User’s Guide

Important Instructions

Using the LCD screen

❏ The LCD screen may contain a few small bright or dark spots, and because of its features it may have an uneven

brightness. These are normal and do not indicate that it is damaged in any way.

❏ Only use a dry, soft cloth to clean the LCD screen or touchscreen. Do not use liquid or chemical cleaners.

❏ The exterior cover of the LCD screen could break if it receives a heavy impact. Contact your dealer if the panel

surface chips or cracks, and do not touch or attempt to remove the broken pieces.

Handling ink cartridges

We will provide ink-related safety instructions and product advice/warnings in the linked section (before “Replacing Ink Cartridges” section).

& “Replacing Ink Cartridges” on page 52

User’s Guide

Getting to Know Your Product

Product Parts

a. Edge guides

b. Rear paper feed slot

c. Control panel

d. Output tray

e. Output tray extension

f. Stopper

g. Edge guides

h. Paper cassette

i. Paper cassette cover

a. Printer cover

b. Paper cassette 1

c. Paper cassette 2

User’s Guide

d. Print head (under the ink cartridge holder)

e. Ink cartridge holder

f. Ink cartridge cover

Getting to Know Your Product

a. Maintenance box

b. Rear cover 1

c. Rear cover 2

d. AC inlet

e. LAN port

f. USB connector

Guide to the Control Panel

Buttons/Lights Function

Turns the product on or off. The power light turns on when the product is on. Flashes when the product is printing, replacing an ink cartridge, charging ink, or cleaning the print head.

Press this to select the size and type of paper you loaded in the cassette.

User’s Guide

Getting to Know Your Product

Buttons/Lights Function

Error The orange light on the left turns on or flashes when an error occurs.

Data

d - LCD screen displays menus.

The blue light on the right flashes while the product is processing data. It stays on when there are print jobs waiting to be processed.

l, u, r, d, OK Press l, u, r, d to select menus. Press OK to confirm your selection and go to next screen.

Cancels/returns to the previous menu.

Stops the current operation.

Icons

The following icons are displayed on the control panel depending on the product’s status.

Icons Description

Indicates that there is no Ethernet connection.

Indicates that an Ethernet connection has been established.

Indicates that a Wi-Fi network error has occur red or the product is searching for a connection.

Indicates that a Wi-Fi connection has been established. The number of bars indicates the connection's signal strength.

Indicates that an Ad Hoc connection has been established.

Indicates that a Wi-Fi Direct mode connection has been established.

Indicates that Simple AP mode connection has been established.

Indicates that one of the Eco Mode functions is on.

User’s Guide

Paper and Media Handling

Introduction to Using, Loading, and Storing Media

You can achieve good results with most types of plain paper. However, coated papers provide superior prints because they absorb less ink.

Epson provides special papers that are formulated for the ink used in Epson ink jet products, and recommends these papers to ensure high-quality results.

When loading special paper distributed by Epson, read the instruction sheets packed with the paper first and keep the following points in mind.

Note:

❏ Load the paper into the paper cassette printable side down. The printable side is usually whiter or glossier. See the

instruction sheets packed with the paper for more information. Some types of paper have cut corners to help identify the correct loading direction.

❏ If the paper is curled, flatten it or curl it slightly in the opposite direction before loading. Printing on curled paper may

cause ink to smear on your prints.

Storing paper

Return unused paper to the original package as soon as you finish printing. When handling special media, Epson recommends storing your prints in a resealable plastic bag. Keep unused paper and prints away from high temperature, humidity, and direct sunlight.

Selecting Paper

The following table shows supported paper types. The loading capacity, paper source, and availability of borderless printing vary by paper as shown below.

User’s Guide

Media Type Size

Paper and Media Handling

Loading capacity (sheets or height)

paper

cassette 1

paper

cassette 2

rear paper

feed slot

Borderless

printing

2-sided

printing

Plain paper

Thick paper

Legal

Letter

27.5 mm

-1-✓

-1--

1-✓

User defined 1 1 1 - ✓

A3 - - 1 - -

B4 - - 1 - -

Legal - - 1 - -

Letter - - 1 - -

A4 - - 1 - -

B5 - - 1 - -

A5 - - 1 - -

A6 - - 1 - -

User defined - - 1 - -

Envelope #10 10 - 1 - -

DL 10 - 1 - -

C6 10 - 1 - -

C4 10 - 1 - -

Epson Bright

200

1-✓ White Ink Jet Paper

Epson Photo

A3+ 80 - 1 - Quality Ink Jet Paper

A3 80 - 1 - -

A4 80 - 1 - -

User’s Guide

Media Type Size

Paper and Media Handling

Loading capacity (sheets or height)

paper

cassette 1

paper

cassette 2

rear paper

feed slot

Borderless

printing

2-sided

printing

Epson Matte Paper Heavyweight

Epson Premium Glossy Photo Paper

Epson Premium Semigloss Photo Paper

A3+ 20 - 1 ✓ -

A3 20 - 1 ✓ -

A4 20 - 1 ✓ -

A3+ 20 - 1 ✓ -

A3 20 - 1 ✓ -

A4 20 - 1 ✓ -

10 × 15 cm (4 × 6

20 - 1 ✓ -

in.)

13 × 18 cm (5 × 7

20 - 1 ✓ -

in.)

16:9 wide size

20 - 1 ✓ -

(102 × 181 mm)

A3+ 20 - 1 ✓ -

A3 20 - 1 ✓ -

A4 20 - 1 ✓ -

10 × 15 cm (4 × 6

20 - 1 ✓ -

in.)

Epson Ultra

A4 20 - 1 ✓ - Glossy Photo Paper

10 × 15 cm (4 × 6

20 - 1 ✓ -

in.)

13 × 18 cm (5 × 7

20 - 1 ✓ -

in.)

Epson Photo

A4 20 - 1 ✓ - Paper, Glossy

× 15 cm (4 × 6

20 - 1 ✓ -

in.)

13 × 18 cm (5 × 7

20 - 1 ✓ -

in.)

*1Paper cassette 2 may not be available depending on the product.

*2Plain paper is defined as paper with a weight of 64 g/m

(17 lb) to 90 g/m2 (24 lb). This includes preprinted paper, letterhead, colored paper, and recycled paper. Make sure you are using long-grain paper. If you are not sure what type of paper you are using, consult the paper packaging or the manufacturer to check the paper specifications.

*3The loading capacity for manual 2-sided printing is 30 sheets.

*4Thick paper is defined as paper with a weight of 91 g/m

(25 lb) to 256 g/m2 (68 lb).

User’s Guide

Paper and Media Handling

Note:

The availability of paper varies by location.

Paper type settings on the LCD screen

The product automatically adjusts itself for the type of paper you select in your print settings. That is why the paper type setting is so important. It tells your product what kind of paper you are using and adjusts the ink coverage accordingly. The table below lists the settings you should choose for your paper.

For this paper LCD paper type

Plain paper

Preprinted paper

Letterhead

Colored paper

Recycled paper

Thick paper Thick-Paper

Epson Bright White Ink Jet Paper

Epson Ultra Glossy Photo Paper Ultra Glossy

Epson Premium Glossy Photo Paper Prem. Glossy

Epson Premium Semigloss Photo Paper Prem. Semigloss

Epson Photo Paper, Glossy Glossy

Epson Matte Paper – Heavyweight Matte

Epson Photo Quality Ink Jet Paper Matte

Envelopes Envelope

plain papers

Preprinted

Letterhead

Color

Recycled

plain papers

*1You can perform 2-sided printing with this paper.

Paper type settings from the printer driver

For this paper Printer driver paper type

Plain paper plain papers

Epson Bright White Ink Jet Paper plain papers

Preprinted paper Preprinted

Letterhead Letterhead

User’s Guide

Paper and Media Handling

For this paper Printer driver paper type

Colored paper Color

Recycled paper Recycled

Epson Ultra Glossy Photo Paper Epson Ultra Glossy

Epson Premium Glossy Photo Paper Epson Premium Glossy

Epson Premium Semigloss Photo Paper Epson Premium Semigloss

Epson Photo Paper, Glossy Photo Paper Glossy

Epson Matte Paper – Heavyweight Epson Matte

Thick paper Thick-Paper

Epson Photo Quality Ink Jet Paper Epson Matte

Envelopes Envelope

Note:

The availability of special media varies by location. For the latest information on media available in your area, contact Epson support. & “Technical Support Web Site” on page 106

Loading Paper into the Paper Cassette

Follow these steps to load paper:

Pull the paper cassette all the way out.

Remove the cover.

User’s Guide

Paper and Media Handling

Pinch and slide the edge guides to the sides of the paper cassette.

Note:

When using paper larger than A4, extend the paper cassette to the symbol on the cassette.

Slide the edge guide to adjust to the paper size you will use.

User’s Guide

Paper and Media Handling

Load paper toward the edge guide with printable side face down, and check that the paper is not sticking out

from the end of the cassette.

Note:

❏ Paper cassette 2 supports paper B5 or larger only.

❏ Fan and align the edges of the paper before loading.

User’s Guide

Slide the edge guides to the edges of the paper.

Paper and Media Handling

Note:

For plain paper, do not load paper above the H arrow mark inside the edge guide. For Epson special media, make sure the number of sheets is less than the limit specified for the media.

& “Selecting Paper” on page 16

Put the paper cassette cover back on.

User’s Guide

Paper and Media Handling

Keep the cassette flat and slowly and carefully reinsert it all the way into the product.

Note:

When you insert the paper cassette, the screen for making paper size and paper type settings is automatically displayed. Make sure the paper settings match the paper you have loaded.

Slide out the output tray and raise the stopper.

Note:

❏ If you want to print on commercially available pre-punched paper, see “Loading Paper and Envelopes into the Rear

Paper Feed Slot” on page 27.

❏ Leave enough space in front of the product for the paper to be fully ejected.

❏ Do not remove or insert the paper cassette while the product is operating.

Loading Envelopes into the Paper Cassette

Follow these steps to load envelopes:

User’s Guide

Pull the paper cassette 1 all the way out.

Remove the cover.

Paper and Media Handling

Pinch and slide the edge guides to the sides of the paper cassette.

Load envelopes lengthwise with the flap facing up and to the right.

Note:

Make sure the number of envelopes does not exceed the limit.

& “Selecting Paper” on page 16

User’s Guide

Paper and Media Handling

Slide the edge guides to the edges of the envelopes and check that the envelopes are not sticking out from the end

of the cassette.

Note:

Even if you do not feel a click, slide the edge guides to the edges of the envelopes.

Put the paper cassette cover back on.

Keep the cassette flat and slowly and carefully reinsert it all the way into the product.

Note:

When you insert the paper cassette, the screen for making paper size and paper type settings is automatically displayed. Make sure the paper settings match the paper you have loaded.

User’s Guide

Slide out the output tray and raise the stopper.

Note:

❏ The thickness of envelopes and their ability to fold vary widely. If the total thickness of the stack of envelopes

exceeds 10mm, press down on the envelopes to flatten them before loading. If print quality declines when a stack of envelopes is loaded, load one envelope at a time.

Paper and Media Handling

❏ Do not use envelopes that are curled or folded.

❏ Flatten the envelope and the flaps before loading.

❏ Flatten the leading edge of the envelope before loading.

❏ Avoid using envelopes that are too thin, as they may curl during printing.

❏ Align the edges of the envelopes before loading.

Loading Paper and Envelopes into the Rear Paper Feed Slot

Follow the steps below to load paper and envelopes into the rear paper feed slot:

Note:

❏ Send your job before loading paper into the rear paper feed slot.

❏ Load paper in the rear paper feed slot when the product is not operating.

User’s Guide

Slide out the output tray, and raise the stopper.

Open the rear paper feed slot.

Paper and Media Handling

While holding only one sheet of paper with the printable side face-up at the center of the rear paper feed slot,

slide the edge guides until they are flush with the edges of the paper.

Note:

The printable side is often whiter or brighter than the other side.

Insert the paper into the rear paper feed slot. The paper is automatically fed.

User’s Guide

Note:

❏ When loading envelopes, load the short edge first with the flap facing down.

❏ Do not use envelopes that are curled or folded.

❏ Flatten the envelope and the flaps before loading.

Paper and Media Handling

❏ Flatten the leading edge of the envelope before loading.

❏ Avoid using envelopes that are too thin, as they may curl during printing.

Note for paper with binding holes:

❏ You can use pre-punched paper with binding holes on one of the long edges. Do not load the paper with the

binding holes along the top or the bottom.

❏ Available sizes are A3, B4, A4, B5, A5, A6, Letter and Legal.

❏ Automatic 2-sided printing is not available.

❏ Make sure you adjust the print position of your file to avoid printing over the binder holes.

User’s Guide

Printing

Printing from Your Computer

Printer Driver and Status Monitor

The printer driver lets you choose from a wide variety of settings to get the best printing results. The status monitor and the printer utilities help you check the product and keep it in top operating condition.

Note for Windows users:

❏ Your printer driver automatically finds and installs the latest version of the printer driver from Epson’s Web site. Click

the Software Update button in your printer driver’s Maintenance window, and then follow the on-screen instructions. If the button does not appear in the Maintenance window, point at All Programs or Programs in the Windows Start menu, and check in the EPSON folder.* * For Windows 8: If the button does not appear in the Maintenance window, right-click on the Start screen, or swipe from the bottom or top edge of the Start screen and select All apps, then select Software Update from EPSON category.

❏ If you want to change the language of the driver, select the language you want to use from the Language setting in your

printer driver’s Maintenance window. Depending on the location, this function may not be available.

Accessing the printer driver for Windows

You can access the printer driver from most Windows applications, the desktop or the taskbar.

To make settings that apply only to the application you are using, access the printer driver from that application.

To make settings that apply to all of your Windows applications, access the printer driver from the desktop or the taskbar.

Refer to the following sections to access the printer driver.

Note:

Screen shots of the printer driver windows in this User’s Guide are from Windows 7.

From Windows applications

Click Print or Print Setup on the File menu.

In the window that appears, click Printer, Setup, Options, Preferences, or Properties. (Depending on your

application, you may need to click one or a combination of these buttons.)

From the desktop

❏ Windows 8 and Server 2012

Select Desktop, Settings charm, and Control Panel. Then select Devices and Printers from the Hardware and Sound category. Right-click on the product, or press and hold the product and select Printing preferences.

User’s Guide

Printing

❏ Windows 7 and Server 2008 R2:

Click the start button, select Devices and Printers. Then right-click the product and select Printing preferences.

❏ Windows Vista and Server 2008:

Click the start button, select Control Panel, and then select Printer from the Hardware and Sound category. Then select the product and then click Select printing preferences.

❏ Windows XP and Server 2003:

Click Start, Control Panel, (Printers and Other Hardware,) then Printers and Faxes. Select the product, then click Printing Preferences on the File menu.

From the shortcut icon on the taskbar

Right-click the product icon on the taskbar, then select Printer Settings.

To add a shortcut icon to the Windows taskbar, first access the printer driver from the desktop as described above. Next, click the Maintenance tab, and then the Monitoring Preferences button. In the Monitoring Preferences window, select the Register the shortcut icon to the task bar check box.

Getting information through online help

In the printer driver window, try one of the following procedures.

❏ Right-click the item, then click Help.

❏ Click the

button at the top right of the window, then click the item (for Windows XP only).

Accessing the printer driver for Mac OS X

The table below describes how to access the printer driver dialog.

Dialog Box How to Access It

Page Setup

Epson Printer Utility 4

Click Page Setup on the File menu of your application.

Note:

Depending on your application, the Page Setup menu may not appear in the File menu.

Click Print on the File menu of your application.

For Mac OS X 10.8 or 10.7, click System Preferences on the Apple menu and then click Pr int & Scan. Select your product from the Printers list box, click Options & Supplies, Utility, and then click Open Printer Utility.

For Mac OS X 10.6, click System Preferences on the Apple menu and then click Print & Fax. Select your product from the Printers list box, click Options & Supplies, Utility, and then click Open Printer Utility.

For Mac OS X 10.5, click System Preferences on the Apple menu and then click Print & Fax. Select your product from the Printers list box, click Open Print Queue and then click Utility button.

User’s Guide

Printing

Basic Operations

Basic printing

Follow the steps below to print from your computer. If you cannot change some of the printer driver settings, they may have been locked by the administrator. Contact your administrator or a power user for assistance.

Note:

❏ The screen shots in this manual may vary depending on the model.

❏ Before you print, load paper properly.

& “Loading Paper into the Paper Cassette” on page 20 & “Loading Envelopes into the Paper Cassette” on page 24 & “Loading Paper and Envelopes into the Rear Paper Feed Slot” on page 27

❏ Refer to the section below for the printable area.

& “Printable area” on page 102

❏ After completing the settings, print one test copy and examine the results before printing an entire job.

Basic product settings for Windows

Open the file you want to print.

Access the printer settings.

& “Accessing the printer driver for Windows” on page 30

User’s Guide

Printing

Click the Main tab.

Select the appropriate Paper Source setting.

Select the appropriate Document Size setting. You can also define a custom paper size. For details, see the online

help.

Check Borderless to print borderless photos.

& “Selecting Paper” on page 16

If you want to control the amount of the image that extends beyond the edges of the paper, click the Settings button, select Auto Expand as the Method of Enlargement, and then adjust the Amount of Enlargement slider.

Select Portrait (tall) or Landscape (wide) to change the orientation of your print.

Note: Select Landscape when printing on envelopes.

Select the appropriate Paper Type setting.

& “Paper type settings from the printer driver” on page 19

Note:

Print quality is automatically adjusted for the selected Paper Type.

Select the appropriate Quality setting.

Note:

If you are printing high-density data on plain paper, letterhead, or preprinted paper, select Standard-Vivid to make your printout vivid.

Click OK to close the printer settings window.

Note:

To make changes to advanced settings, refer to the relevant section.

Print your file.

Basic product settings for Mac OS X

Note:

❏ Screen shots of the printer driver windows in this manual are from Mac OS X 10.7.

❏ When printing envelopes, use the application to rotate the data 180 degrees.

User’s Guide

Open the file you want to print.

Access the Print dialog box.

& “Accessing the printer driver for Mac OS X” on page 31

Printing

Note:

If the simplified dialog box is displayed, click the Show Details button (for Mac OS X 10.8 or 10.7) or the d button (for Mac OS X 10.6 or 10.5.8) to extend this dialog box.

Select the product you are using as the Printer setting.

Note: Depending on your application, you may not be able to select some of the items in this dialog box. If so, click Page Setup on the File menu of your application, and then make suitable settings.

Select the appropriate Paper Size setting.

Note: Select XXX ( Borderless) as the Paper Size if you want to print borderless photos.

& “Selecting Paper” on page 16

Select the appropriate Orientation setting.

Note:

Select landscape orientation when printing envelopes.

User’s Guide

Select Print Settings from the pop-up menu.

Printing

Select the appropriate Paper Source setting.

Select the appropriate Media Type setting.

& “Paper type settings from the printer driver” on page 19

Select the appropriate Print Quality setting.

Note:

If you are printing high-density data on plain paper, letterhead, or preprinted paper, select Standard-Vivid to make your printout vivid.

Select the appropriate Expansion setting during borderless printing to control the amount of the image that

extends beyond the edges of the paper.

Click Print to start printing.

Canceling printing

If you need to cancel printing, follow the instructions in the appropriate section below.

Using the product button

Press y to cancel a print job in progress.

User’s Guide

Printing

For Windows

Note:

You cannot cancel a print job that has been completely sent to the product. In this case, cancel the print job by using the product.

Access the EPSON Status Monitor 3.

& “For Windows” on page 81

Click the Print Queue button. The Windows Spooler appears.

Right-click on the job you want to cancel and then select Cancel.

For Mac OS X

Follow the steps below to cancel a print job.

Note:

If you have sent a print job from a Mac OS X 10.6 or 10.5.8 through the network, you may not be able to cancel printing from the computer. Press y on the product’s control panel to cancel a print job. To solve this problem, see the online Network Guide.

Click your product icon in the Dock.

In the Document Name list, select the document which is printing.

Click the Delete button to cancel the print job.

User’s Guide

For Mac OS X 10.8: Click the

Printing

button to cancel the print job.

Other Options

Printing photos the easy way

Epson Easy Photo Print lets you lay out and print digital images on various types of paper. The step-by-step instructions in the window let you preview the printed images and get the effects you want without having to make any difficult settings.

Using the Quick Print function, you can perform one-click printing with the settings you make.

Starting Epson Easy Photo Print

Note:

You can download Epson Easy Photo Print from the following Epson website.

http://support.epson.net/ http://www.epson.eu/Support (Europe)

For Windows

❏ Double-click the Epson Easy Photo Print icon on the desktop.

User’s Guide

Printing

❏ For Windows 8:

Enter "Epson Easy Photo Print" at the search charm, and select the software.

For Windows 7 and Vista: Click the start button, point to All Programs, click Epson Software, and then click Easy Photo Print.

For Windows XP: Click Start, point to All Programs, point to Epson Software, then click Easy Photo Print.

For Mac OS X

Double-click the Applications fo lder on your Mac OS X h ard dri ve, then double-click in turn on the Epson Software and Easy Photo Print folders and finally double-click the Easy Photo Print icon.

Product presets (For Windows Only)

Printer driver presets make printing a snap. You can also create presets of your own.

Product settings for Windows

Access the printer settings.

& “Accessing the printer driver for Windows” on page 30

Select a Printing Presets in the Main tab. Product settings are automatically set to the values displayed in the

pop-up window.

2-sided printing

Use the printer driver to print on both sides of the paper.

User’s Guide

Printing

Note:

❏ This feature may not be available at some settings.

❏ The loading capacity differs during 2-sided printing.

& “Selecting Paper” on page 16

❏ Only use papers that are suitable for 2-sided printing. Otherwise, the printout quality may deteriorate.

& “Selecting Paper” on page 16

❏ Manual 2-sided printing may not be available when the product is accessed over a network or is used as a shared

printer.

❏ If the ink runs low during automatic 2-sided printing, the product stops printing and the ink needs to be replaced. When

ink replacement is complete, the product starts printing again, but there may be some missing parts in your print. If this happens, print again the page that has missing parts.

❏ Depending on the paper and the amount of ink used to print text and images, ink may bleed through to the other side of

the paper.

❏ The surface of the paper may be smeared during 2-sided printing.

Note for Windows:

❏ Four types of 2-sided printing are available: automatic standard, automatic folded booklet, manual standard and

manual folded booklet.

❏ Manual 2-sided printing is available only when EPSON Status Monitor 3 is enabled. To enable the status monitor,

access the printer driver and click the Maintenance tab followed by the Extended Settings button. In the Extended Settings window, check the Enable EPSON Status Monitor 3 check box.

❏ When automatic 2-sided printing is performed, printing may be slow depending on the combination of options selected

for Select Document Type in the Print Density Adjustment window and for Quality in the Main window.

Note for Mac OS X:

❏ Mac OS X supports automatic standard 2-sided printing only.

❏ When automatic 2-sided printing is performed, printing may be slow depending on the Document Type setting in

Two-sided Printing Settings

Product settings for Windows

Access the printer settings.

& “Accessing the printer driver for Windows” on page 30

Select the appropriate 2-Sided Printing setting.

Note:

Depending on the driver version, the 2-Sided Printing setting may become available when you select the check box. When using automatic printing, make sure the Auto check box is checked.

Click Settings, and make the appropriate settings.

Note: If you want to print a folded booklet, select Booklet.

User’s Guide

Check the other settings and print.

Note:

❏ When printing automatically, and if you are printing high-density data such as photos or graphs, we

recommend making the settings in the Print Density Adjustment window.

❏ The actual binding margin may be different from the specified settings depending on your application.

Experiment with a few sheets to examine actual results before printing the entire job.

❏ Manual 2-sided printing allows you to print the even-numbered pages first. When you print odd-numbered

pages, a blank sheet of paper is output at the end of the print job.

❏ When you are printing manually, make sure that the ink is completely dry before reloading the paper.

Product settings for Mac OS X

Access the Print dialog box.

& “Accessing the printer driver for Mac OS X” on page 31

Printing

Make the appropriate settings in the Two-sided Printing Settings pane.

Check the other settings and print.

Note:

If you are printing high-density data such as photos or graphs, we recommend adjusting Print Density and Increased Ink Drying Time settings manually.

Fit to page printing

Lets you automatically enlarge or reduce the size of your document to fit the paper size selected in the printer driver.

Note:

This feature may not be available at some settings.

User’s Guide

Printing

Product settings for Windows

Access the printer settings.

& “Accessing the printer driver for Windows” on page 30

Select Reduce/Enlarge Document and Fit to Page in the More Options tab, and then select the size of the paper

you are using from Output Paper.

Note: If you want to print a reduced image with centering, select Center.

Check the other settings and print.

Product settings for Mac OS X

Access the Print dialog box.

& “Accessing the printer driver for Mac OS X” on page 31

Choose Scale to fit paper size for Destination Paper Size in the Paper Handling pane and select the desired

paper size from the pop-up menu.

Check the other settings and print.

Pages per Sheet printing

Lets you use the printer driver to print two or four pages on a single sheet of paper.

Note:

This feature may not be available at some settings.

User’s Guide

Product settings for Windows

Access the printer settings.

& “Accessing the printer driver for Windows” on page 30

Select 2-Up or 4-Up as Multi-Page in the Main tab.

Click Page Order, and make the appropriate settings.

Check the other settings and print.

Product settings for Mac OS X

Access the Print dialog box.

& “Accessing the printer driver for Mac OS X” on page 31

Printing

Select the desired number of Pages per Sheet and the Layout Direction (page order) in the Layout pane.

Check the other settings and print.

Anti-Copy Pattern printing (for Windows Only)

This function allows you to print a document as a copy-protected document. When you try to copy a copy-protected document, the string that you added as the anti-copy pattern is printed several times on the document.

Note:

This feature may not be available at some settings.

Access the printer settings.

& “Accessing the printer driver for Windows” on page 30

User’s Guide

Printing

Click Watermark Features on the More Options tab, and then select an Anti-Copy Pattern from the Anti-Copy

Pattern list.

Note:

❏ This feature is available only with the following settings selected.

Paper Type: plain papers Quality: Standard Auto 2-Sided Printing: Off Borderless: Off Color Correction: Automatic Short Grain Paper: Off

❏ If you want to create your own watermark, click Add/Delete. For more details about each setting, see the online

help.

Click Settings, and make the appropriate settings.

Note:

Anti-Copy Pattern are printed in monochrome only.

Click OK to return to the More Options window.

Click OK to close the printer settings window and print.

Watermark printing (For Windows Only)

This function allows you to print a text-based or image-based watermark on your document.

Note:

This feature may not be available at some settings.

Access the printer settings.

& “Accessing the printer driver for Windows” on page 30

User’s Guide

Printing

Click Watermark Features on the More Options tab, and then select a watermark from the Watermark list.

Note:

❏ If you want to create your own watermark, click Add/Delete. For more details about each setting, see the online

help.

❏ Saved watermarks can only be used with the printer driver in which you saved the settings. Even if multiple

printer names are set for a printer driver, the settings are only available for the printer name in which you saved the settings.

❏ When sharing the printer on a network, you cannot create a user defined watermark as a client.

Click Settings, and then make the appropriate settings.

Click OK to return to the More Options window.

Click OK to close the printer settings window and print.

Header/Footer printing (For Windows Only)

This function allows you to print user name, computer name, date, time, or collate number, at the top or bottom of each page in a document.

Access the printer settings.

& “Accessing the printer driver for Windows” on page 30

Click Watermark Features on the More Options tab, select Header/Footer, and then click Settings.

Select the necessary items from the drop-down list in the Header Footer Settings window.

Note:

If you select Collate Number, the number of copies is printed.

User’s Guide

Printing

Click OK to return to the More Options window.

Click OK to close the printer settings window and print.

Administrator Settings for Printer Driver (for Windows Only)

Administrators can lock the following printer driver settings for each user to prevent unintended changes of the settings.

❏ Anti-Copy Pattern

❏ Watermark

❏ Header/Footer

❏ Color

❏ 2-sided printing

❏ Multi-Page

Note:

You need to logon as an administrator in Windows.

Windows 8 and Server 2012:

Select Desktop, Settings, charm, Control Panel, and then select Devices and Printers from the Hardware and Sound category.

Windows 7 and Server 2008 R2: Click the start button, and then select Devices and Printers.

Windows Vista and Server 2008: Click the start button, select Control Panel, and then select Printer from the Hardware and Sound category.

Windows XP and Server 2003: Click Start, select Control Panel, and then select Printers and Faxes from the Printers and Other Hardware category.

Windows 8, 7, Server 2008, and Server 2012:

Right-click on the product, or press and hold the product, select Printer properties, Optional Settings, and then select the Driver Settings button.

Windows Vista and Server 2008: Right-click the icon for your product, click Optional Settings, and then click the Driver Settings button.

Windows XP and Server 2003: Right-click the icon for your product, click Optional Settings, and then click the Driver Settings button.

User’s Guide

Printing

Make the appropriate settings. For more details about each setting, see the online help.

Click OK.

User’s Guide

Menu List of Control Panel

The table below shows the functions and settings available from the Menu on the control panel. See the following section for details on the Wi-Fi Setup displayed on the Home screen. & “System Administration Settings” on page 48

Menu Settings Description

Ink Levels Checks the status of ink cartridges and the maintenance box.

Maintenance Print Head Nozzle Check Prints a pattern to check if the print head nozzles are clogged.

Print Head Cleaning Cleans the print head to clear clogged nozzles.

Ink Cartridge(s) Replacement

Print Head Alignment Vertical Alignment Corrects vertical gaps in a printout.

Thick Paper

Paper Guide Cleaning Perform this function to clean the inside of the product.

Remove Paper Perform this function if there are still some torn pieces of paper inside

Paper Setup Select the paper size and paper type you loaded in each paper source. This menu is displayed each

time you load paper in the paper cassette.

Print Status Sheet Configuration Status

Sheet

Supply Status Sheet Prints a sheet showing information about consumables.

Usage History Sheet Prints a sheet showing the history of the printer’s usage.

Network Status Wi-Fi/Network Status You can see the current network settings and print a network status

Wi-Fi Direct Status

Replaces the ink cartridges.

Horizontal Alignment Corrects horizontal gaps in a printout.

Select On when printing on thick paper to avoid smearing.

the product even after clearing the paper jam.

Prints a sheet showing the current printer settings.

sheet.

Epson Connect Status You can check whether your printer is registered or connected to

Epson Connect or Google Cloud Print service. Google Cloud Print Status

Admin Settings Admin Password You can change or reset the password which is specified in Lock

Lock Setting

System Administration

& “System Administration Settings” on page 48

& “Using Epson Connect Service” on page 7

Setting.

Select On to lock the control panel to prevent unintended changed

made by using the control panel.

User’s Guide

Menu List of Control Panel

System Administration Settings

The administrator can lock the control panel to prevent unintended changes from being made. To lock the control panel, select the menus as shown below, then enter the password. Menu > Admin Settings > Lock Setting > On

The password is required when entering the System Administration settings in Menu. The password set in Lock Setting is also necessary when making settings in Epson WebConfig or EpsonNet Config.

Note:

If you forget your password, contact your dealer.

Menu Settings and Description

Printer Settings Paper Source Settings A4/Letter Auto Switching Make the paper settings for A4 and

Letter. When A4 or Letter size paper is selected for printing and there is no paper source set for the selected paper size, the printout is output using an alternate paper size (Letter for A4, or A4 for Letter).

Auto Select Settings

Error Notice Paper Size

Notice

Paper Type Notice

Auto Error Solver

PC Connection via USB

Common Settings Sleep Timer Specify the length of the time until the LCD panel turns black.

Power Off Timer Specify the length of the time until the power turns off automatically.

LCD Contrast Adjusts the brightness of the LCD panel.

Date/Time Settings Date/Time Enter the current date and time.

Select On to automatically clear product errors.

Select whether to enable or disable the USB interface. If Disable is selected, the computer does not recognize the product even if it is connected using a USB cable.

You can adjust the time before power management is applied. Any increase will affect the product's energy efficiency. Please consider the environment before making any change.

Select On to feed from the paper cassette containing paper that matches your paper settings.

Select On to display an error message when the paper size and type settings made for each cassette and the print settings made in each mode do not match.

Daylight Saving Time

Time Difference Enter the time difference between UTC

Language Select the display language.

Scroll Speed Select the scroll speed of the LCD screen.

Select On to set summer time.

and the current time zone.

User’s Guide

Menu List of Control Panel

Menu Settings and Description

Wi-Fi/Network Settings Wi-Fi/Network Status You can see the current network settings and print a net-

works status sheet.

Epson Connect Services

Wi-Fi Setup Wi-Fi Setup

Wizard

Push Button Setup (WPS)

PIN Code Setup (WPS)

Wi-Fi Auto Connect

Disable Wi-Fi

Wi-Fi Direct Setup

Connection Check You can check the network connection status, and print

Advanced Setup For details on the setting items, see the online Network

& “Using Epson Connect Service” on page 7

For details on the setting items, see the online Network Guide.

Network problems may be resolved by disabling or initializing the Wi-Fi settings, and then making the settings again. For details, see the online Network Guide.

For details on the setting items, see the online Network Guide.

the report. If there is any problem with the connection, the report helps you find the solution.

Guide.

Google Cloud Print Services

Universal Print Settings These settings are available when printing data without the printer driver.

Top Offset Adjusts the top or left margin.

Left Offset

Top Offset in Back Adjusts the top or left margin for the back of the page

when performing double-sided printing.

Left Offset in Back

Check Paper Width

Dry Time Select the drying time when performing double-sided

Skip Blank Page

Eco Mode You can adjust the time before power management is applied. Any increase will affect the product’s

energy efficiency. Please consider the environment before making any change. Select On to enable all the following Eco Mode functions.

Select On to check the paper width before printing. This prevents printing beyond the edges of the paper when the paper size settings are wrong, but may reduce the printing speed.

printing.

Select On to skip blank pages automatically.

Sleep Timer Specify the length of the time until the LCD panel turns black.

Power Off Timer Specify the length of the time until the power turns off automatically.

User’s Guide

Menu List of Control Panel

Menu Settings and Description

Restore Default Settings

Resets the selected settings to their defaults.

User’s Guide

Ink Cartridge and Consumable Information

Ink Cartridges

You can use the following ink cartridges with this product:

Icon Black Cyan Magenta Yellow

Alarm Clock

27 27XL 27XXL

27 27XL

* For information on Epson’s ink cartridge yields, visit the following website.

http://www.epson.eu/pageyield

Note:

Not all cartridges are available in all regions.

Color

Cartridge life

Temperature

* Ink thaws and is usable after approximately 3 hours at 25 °C (77 °F).

Black, Cyan, Magenta, Yellow

For best results, use up ink cartridge within six months of opening the package.

Storage:

-20 to 40 °C (-4 to 104 °F)

1 month at 40 °C (104 °F)

Freezing:

-12 °C (10.4 °F)

Maintenance Box

Your can use the following maintenance box with this product.

Part number

Maintenance Box T6711

User’s Guide

Replacing Ink Cartridges

Ink Cartridge Safety Instructions, Precautions, and Specifications

Safety instructions

Observe the following when handling the ink cartridges:

❏ Keep ink cartridges out of the reach of children.

❏ Be careful when you handle used ink cartridges, as there may be some ink around the ink supply port.

If ink gets on your skin, wash the area thoroughly with soap and water. If ink gets into your eyes, flush them immediately with water. If discomfort or vision problems continue after a thorough flushing, see a doctor immediately. If ink gets into your mouth, spit it out immediately and see a doctor right away.

❏ Do not remove or tear the label on the cartridge; this can cause leakage.

❏ Do not remove the transparent seal from the bottom of the cartridge; otherwise, the cartridge may become

unusable.

❏ Do not disassemble or remodel the ink cartridge, otherwise you may not be able to print normally.

User’s Guide

Replacing Ink Cartridges

❏ Do not touch the green chip or the small window on the side of the cartridge. Doing so may prevent normal

operation and printing.

❏ Do not leave the product with the ink cartridges removed or do not turn off the product during cartridge

replacement. Otherwise, ink remaining in the print head nozzles will dry out and you may not be able to print.

Precautions on ink cartridge replacement

Read all of the instructions in this section before replacing the ink cartridges.

❏ Epson recommends the use of genuine Epson ink cartridges. Epson cannot guarantee the quality or reliability of

non-genuine ink. The use of non-genuine ink may cause damage that is not covered by Epson’s warranties, and under certain circumstances, may cause erratic product behavior. Information about non-genuine ink levels may not be displayed.

❏ Gently shake all ink cartridges four or five times before opening the package.

❏ Do not shake ink cartridges too vigorously; otherwise ink may leak from the cartridge.

❏ This product uses ink cartridges equipped with an IC chip that monitors information such as the amount of

remaining ink for each cartridge. This means that even if the cartridge is removed from the product before it is expended, you can still use the cartridge after reinserting it back into the product. However, when reinserting a cartridge, some ink may be consumed to guarantee product performance.

❏ To maintain optimum print head performance, some ink is consumed from some cartridges not only during

printing but also during maintenance operations such as ink cartridge replacement and print head cleaning.

❏ If you need to remove an ink cartridge temporarily, be sure to protect the ink supply area from dirt and dust. Store

the ink cartridge in the same environment as the product. When storing the cartridge, be sure that its label identifying the color of the ink cartridge is facing upward. Do not store ink cartridges upside down.

❏ The ink supply port is equipped with a valve designed to contain the release of excess ink; there is no need to supply

your own covers or plugs. However, careful handling is recommended. Do not touch the supply port of the ink cartridge or its surrounding area.

❏ For maximum ink efficiency, only remove an ink cartridge when you are ready to replace it. Ink cartridges with

low ink status may not be used when reinserted.

❏ Do not open the ink cartridge package until you are ready to install it in the product. The cartridge is vacuum

packed to maintain its reliability. If you leave a cartridge unpacked for a long time before using it, normal printing may not be possible.

❏ Install all ink cartridges; otherwise, you cannot print.

User’s Guide

Replacing Ink Cartridges

❏ When color ink is expended and black ink still remains, you can continue printing temporarily with black ink

only. For more information refer to “Temporary Printing with Black Ink When Color Ink Cartridges are

Expended” on page 57.

❏ If an ink cartridge is running low, prepare a new ink cartridge.

❏ Be careful not to break the hooks on the side of the ink cartridge when you remove it from the package.

❏ You must remove the yellow tape from the cartridge before installing it; otherwise, print quality may decline or

you may not be able to print.

❏ After bringing an ink cartridge inside from a cold storage site, allow it to warm up at room temperature for at least

three hours before using it.

❏ Store ink cartridges in a cool, dark place.

❏ Store ink cartridges with their labels facing upward. Do not store cartridges upside down.

❏ You cannot use the cartridges that came with your product for the replacement.

Ink Cartridge Specifications

❏ Epson recommends using the ink cartridge before the date printed on the package.

❏ The ink cartridges packaged with your product are partly used during initial setup. In order to produce high

quality printouts, the print head in your product will be fully charged with ink. This one-off process consumes a quantity of ink and therefore these cartridges may print fewer pages compared to subsequent ink cartridges.

❏ Quoted yields may vary depending on the images that you are printing, the paper type that you are using, the

frequency of your prints and environmental conditions such as temperature.

❏ To ensure you receive premium print quality and to help protect your print head, a variable ink safety reserve

remains in the cartridge when your product indicates to replace the cartridge. The yields quoted for you do not include this reserve.

❏ Although the ink cartridges may contain recycled materials, this does not affect product function or performance.

❏ When printing in monochrome or grayscale, color inks instead of black ink may be used depending on the paper

type or print quality settings. This is because a mixture of color inks is used to create black.

Checking the Ink Cartridge Status

For Windows

Note:

When an ink cartridge is running low, the Low Ink Reminder screen automatically appears. You can also check the ink cartridge status from this screen. If you do not want to display this screen, first access the printer driver and then click the

Maintenance tab, and then Monitoring Preferences. On the Monitoring Preferences screen, clear the See Low Ink Reminder alerts check box.

User’s Guide

Replacing Ink Cartridges

To check the ink cartridge status, do one of the following:

❏ Open the printer driver, click the Main tab, and then click the Ink Levels button.

❏ Double-click the product shortcut icon on your Windows taskbar. To add a shortcut icon to the taskbar, see the

following section: & “From the shortcut icon on the taskbar” on page 31

❏ Open the printer driver, click the Maintenance tab, then click the EPSON Status Monitor 3 button. A graphic

displays the ink cartridge status.

Note: ❏ If EPSON Status Monitor 3 does not appear, access the printer driver and click the Maintenance tab and then the

Extended Settings button. In the Extended Settings window, check the Enable EPSON Status Monitor 3 check box.

❏ Depending on current settings, the simplified status monitor may be displayed. Click the Details button to display the

window above.

❏ The ink levels displayed are an approximate indication.

For Mac OS X

You can check the ink cartridge status using EPSON Status Monitor. Follow the steps below.

Access the Epson Printer Utility 4.

& “Accessing the printer driver for Mac OS X” on page 31

User’s Guide

Replacing Ink Cartridges

Click the EPSON Status Monitor icon. The EPSON Status Monitor appears.

Note:

❏ The graphic displays the ink cartridge status when EPSON Status Monitor was first opened. To update the ink cartridge

status, click Update.

❏ The ink levels displayed are an approximate indication.

Using the control panel

Enter Menu from the Home screen.

Select Ink Levels.

Note:

❏ The ink levels displayed are an approximate indication.

❏ The status icon on the right of the LCD screen indicates the status of the maintenance box.

User’s Guide

Replacing Ink Cartridges

Temporary Printing with Black Ink When Color Ink Cartridges are Expended

When color ink is expended and black ink still remains, you can continue printing for a short time using only black ink. However, you should replace the expended ink cartridge(s) as soon as possible. See the following section to continue printing temporarily with black ink.

Note:

The actual amount of time will vary depending on the usage conditions, images printed, print settings, and frequency of use.

For Windows

Note for Windows:

This function is available only when EPSON Status Monitor 3 is enabled. To enable the status monitor, access the printer driver and click the Maintenance tab followed by the Extended Settings button. In the Extended Settings window, check the Enable EPSON Status Monitor 3 check box.

Follow the steps below to continue printing temporarily with black ink.

User’s Guide

Replacing Ink Cartridges

When EPSON Status Monitor 3 tells you to cancel your print job, click Cancel or Cancel Print to cancel your

print job.

Note:

If the error stating that a color ink cartridge is expended originates with another computer on the network, you may need to cancel the print job at the product.

Load plain paper or envelope.

Access the printer settings.

& “Accessing the printer driver for Windows” on page 30

Click the Main tab, and make suitable settings.

Select plain papers or Envelope as the Paper Type setting.

Select the Grayscale as the Color setting.

Click OK to close the printer settings window.

User’s Guide

Replacing Ink Cartridges

Print your file.

EPSON Status Monitor 3 is displayed on your computer screen again. Click Print in Black to print with black

ink.

For Mac OS X

Follow the steps below to continue printing temporarily with black ink.

If printing can not be resumed, click the product icon in the Dock. If an error message is displayed prompting

you to cancel the print job, click Delete and follow the steps below to reprint the document with black ink.

Note:

If the error stating that a color ink cartridge is expended originates with another computer on the network, you may need to cancel the print job at the product.

For Mac OS X 10.8: Click the with black ink.

button, and if an error message appears, click OK. Follow the steps bellow to reprint the document

User’s Guide

Replacing Ink Cartridges

Open System Preferences, click Print & Scan (Mac OS X 10.8 or 10.7) or Print & Fax (Mac OS X 10.6 or 10.5),

and select the product from the Printers list. Next, click Options & Supplies and then Driver.

Select On for Permit temporary black printing.

Load plain paper or envelope.

Access the Print dialog box.

& “Accessing the printer driver for Mac OS X” on page 31

Click the Show Details button (for Mac OS X 10.7) or the d button (for Mac OS X 10.6 or 10.5) to extend this

dialog box.

Select the product you are using as the Printer setting, and then make suitable settings.

Select Print Settings from the pop-up menu.

Select plain papers or Envelope as the Media Type setting.

Select the Grayscale check box.

Click Print to close the Print dialog box.

Conserving Black Ink When the Cartridge Is Low (For Windows Only)

Note for Windows:

User’s Guide

Replacing Ink Cartridges

The window below appears when black ink runs low and there is more color ink than black ink. It appears only when plain papers is selected as the paper type, and Standard is selected as the Quality.

The window gives you the option to either continue using black ink normally or conserve black ink by using a mixture of color inks to create black.

❏ Click the Yes button to use a mixture of color inks to create black. You will see the same window the next time you

print a similar job.

❏ Click the No button to continue using the remaining black ink for the job you are printing. You will see the same

window the next time you print a similar job, and again have the option to conserve black ink.

❏ Click Disable this feature to continue using the remaining black ink.

Replacing an ink cartridge

Open the printer cover.

The ink cartridge holder moves to the ink cartridge replacement position. When you replace an ink cartridge before it is expended, select the menu as shown below.

Menu > Maintenance > Ink Cartridge(s) Replacement

Important:

Do not move the ink cartridge holder by hand; otherwise, you may damage the product.

User’s Guide

Open the ink cartridge cover.

Pinch and remove the ink cartridge.

Replacing Ink Cartridges

Note:

❏ The illustration shows replacement of the black ink cartridge. Replace the cartridge appropriate to your

situation.

❏ Removed ink cartridges may have ink around the ink supply port, so be careful not to get any ink on the

surrounding area when removing the cartridges.

Gently shake new replacement cartridges four or five times and remove the replacement ink cartridge from its

package.

User’s Guide

Note:

❏ Be careful not to break the hooks on the side of the ink cartridge when you remove it from the package.

❏ Do not touch the green chip or the small window on the side of the cartridge. Doing so may prevent normal

operation and printing.

Replacing Ink Cartridges

Remove only the yellow tape.

Important:

❏ You must remove the yellow tape from the cartridge before installing it; otherwise, print quality may

decline or you may not be able to print.

❏ If you have installed an ink cartridge without removing the yellow tape, take the cartridge out of the

product, remove the yellow tape, and then reinstall it.

❏ Do not remove the transparent seal from the bottom of the cartridge; otherwise, the cartridge may become

unusable.

❏ Do not remove or tear the label on the cartridge; otherwise, ink will leak.

User’s Guide

Insert the cartridge and press it until it clicks.

Close the ink cartridge cover.

Replacing Ink Cartridges

Press OK to check on the control panel of the product if the cartridges are installed correctly.

Close the printer cover. Ink charging starts.

Note:

The P light continues to flash while the product is charging ink. Do not turn off the product during ink charging. If the ink charging is incomplete, you may not be able to print.

Ink cartridge replacement is complete. The product will return to its previous status.

User’s Guide

Maintaining Your Product and Software

Checking the Print Head Nozzles

If you find that the printout is unexpectedly faint or that dots are missing, you may be able to identify the problem by checking the print head nozzles.

You can check the print head nozzles from your computer by using the Nozzle Check utility or from the product by using the buttons.

Using the Nozzle Check utility for Windows

Follow the steps below to use the Nozzle Check utility.

Make sure that no warnings or errors are indicated in the control panel.

Make sure that A4-size paper is loaded in the paper cassette.

Right-click the product icon on the taskbar, then select Nozzle Check.

If the product icon does not appear, refer to the following section to add the icon. & “From the shortcut icon on the taskbar” on page 31

Follow the on-screen instructions.

Using the Nozzle Check utility for Mac OS X

Follow the steps below to use the Nozzle Check utility.

Make sure that no warnings or errors are indicated in the control panel.

Make sure that A4-size paper is loaded in the paper cassette.

Access the Epson Printer Utility 4.

& “Accessing the printer driver for Mac OS X” on page 31

Click the Nozzle Check icon.

Follow the on-screen instructions.

User’s Guide

Maintaining Your Product and Software

Using the control panel

Follow the steps below to check the print head nozzles using the product control panel.

Make sure that no warnings or errors are indicated in the control panel.

Make sure that A4-size paper is loaded in the paper cassette.

Enter Menu from the Home screen.

Select Maintenance.

Select Print Head Nozzle Check, and then follow the instructions on the LCD screen to print a nozzle check

pattern.

Below are two sample nozzle check patterns.

Compare the quality of the printed check page with the sample shown below. If there are no print quality problems, such as gaps or missing segments in the test lines, the print head is fine.

If any segment of the printed lines is missing, as shown below, this could mean a clogged ink nozzle or a misaligned print head.

& “Cleaning the Print Head” on page 66 & “Aligning the Print Head” on page 68

Cleaning the Print Head

If you find that the printout is unexpectedly faint or that dots are missing, you may be able to solve these problems by cleaning the print head, which ensures that the nozzles are delivering ink properly.

You can clean the print head from your computer using the Head Cleaning utility in the printer driver or from the product by using the buttons.

User’s Guide

Maintaining Your Product and Software

Important:

Do not turn off the product during head cleaning. If the head cleaning is incomplete, you may not be able to print.

Note:

❏ Do not open the printer cover during head cleaning.

❏ Perform the nozzle check first to identify any defective color(s); this will allow you to select the appropriate color(s) for

the head cleaning function. Black ink may be used when printing color images. & “Checking the Print Head Nozzles” on page 65

❏ Because print head cleaning uses some ink from some cartridges, clean the print head only if quality declines; for

example, if the printout is blurry or the color is incorrect or missing.

❏ When ink is low you may not be able to clean the print head. When ink is expended you cannot clean the print head.

Replace the appropriate ink cartridge first.

❏ If print quality does not improve, make sure you selected the appropriate color according to the nozzle check result.

❏ If print quality has not improved after repeating this procedure about four times, turn the product off and wait for at

least six hours. Then run the nozzle check again and repeat the head cleaning if necessary. If print quality has still not improved, contact Epson support.

❏ To maintain print quality, we recommend printing a few pages on a regular basis.

Using the Head Cleaning utility for Windows

Follow the steps below to clean the print head using the Head Cleaning utility.

Make sure that no warnings or errors are indicated in the control panel.

Right-click the product icon on the taskbar, then select Head Cleaning.

If the product icon does not appear, refer to the following section to add the icon. & “From the shortcut icon on the taskbar” on page 31

Follow the on-screen instructions.

Using the Head Cleaning utility for Mac OS X

Follow the steps below to clean the print head using the Head Cleaning utility.

Make sure that no warnings or errors are indicated in the control panel.

Access the Epson Printer Utility 4.

& “Accessing the printer driver for Mac OS X” on page 31

Click the Head Cleaning icon.

Follow the on-screen instructions.

User’s Guide

Maintaining Your Product and Software

Using the control panel

Follow the steps below to clean the print head using the product control panel.

Make sure that no warnings or errors are indicated in the control panel.

Enter Menu from the Home screen.

Select Maintenance.

Select Print Head Cleaning.

Follow the instructions on the LCD screen to continue.

Select the color you want to clean, and follow the instructions on the LCD screen to start cleaning.

Note:

Select the color that shows a defect in the nozzle check result.

Aligning the Print Head

If you notice a misalignment of vertical lines or horizontal banding, you may be able to solve this problem by using the Print Head Alignment utility in your printer driver or by using the product buttons.

Refer to the appropriate section below.

Note:

Do not cancel printing while printing a test pattern with the Print Head Alignment utility.

Using the Print Head Alignment utility for Windows

Follow the steps below to align the print head using the Print Head Alignment utility.

Make sure that no warnings or errors are indicated in the control panel.

Make sure A4-size paper is loaded in the paper cassette 1.

Right-click the product icon on the taskbar, then select Print Head Alignment.

If the product icon does not appear, refer to the following section to add the icon. & “From the shortcut icon on the taskbar” on page 31

User’s Guide

Maintaining Your Product and Software

Follow the on-screen instructions to align the print head.

Using the Print Head Alignment utility for Mac OS X

Follow the steps below to align the print head using the Print Head Alignment utility.

Make sure that no warnings or errors are indicated in the control panel.

Make sure A4-size paper is loaded in the paper cassette 1.

Access the Epson Printer Utility 4.

& “Accessing the printer driver for Mac OS X” on page 31

Click the Print Head Alignment icon.

Follow the on-screen instructions to align the print head.

Using the control panel

Follow the steps below to align the print head using the product control panel.

Make sure that no warnings or errors are indicated in the control panel.

Make sure that A4-size paper is loaded in the paper cassette 1.

Enter Menu from the Home screen.

Select Maintenance.

Select Print Head Alignment.

Select Vertical Alignment or Horizontal Alignment, and then follow the on-screen instructions to print an

alignment pattern.

Note:

If your printouts look blurry or vertical ruled lines appear misaligned, select Vertical Alignment. If you see horizontal banding at regular intervals, select Horizontal Alignment.

User’s Guide

Maintaining Your Product and Software

When you selected Vertical Alignment, find the most solid pattern in each of #1 to #6 groups, then enter the

pattern number.

When you selected Horizontal Alignment, find the least separated and overlapped pattern.

Finish aligning the print head.

Making Network Service Settings

You can make network service settings such as Epson Connect, AirPrint, or Google Cloud Print using a Web browser on your computer, smartphone, tablet PC, or laptop that is connected to the same network as the product.

Enter the product’s IP address in the address bar of the Web browser and search for the product.

<Example> [IPv4] http://192.168.11.46 [IPv6] http://[fe80::226:abff:feff:37cd]/

Note:

You can check your product’s IP address on the product’s control panel or by printing a network status sheet.

Menu > System Administration > Wi-Fi/Network Settings > Wi-Fi/Network Status

When the product is found successfully, the product’s web page is displayed. Select the menu you want.

The web page also allows you to check the product’s status and update the product’s firmware.

User’s Guide

Maintaining Your Product and Software

Sharing the Product for Printing

You can setup the printer so that other computers on the network can share it. The computer connected directly to the printer acts as a server. Other computers on the network access the server and share the printer. For more details, see the computer’s help. If you want to use the printer over a network, see the Network Guide.

Cleaning the Product

Cleaning the exterior of the product

To keep your product in optimum condition, clean it thoroughly several times a year by using the following instructions.

Important:

Never use alcohol or thinner to clean the product. These chemicals can damage the product.

Note:

Close the rear paper feed slot and the output tray when you are not using the product to protect the product from dust.

Cleaning the interior of the product

If your printouts are stained with ink, follow the steps below to clean the roller inside the product.

Caution:

Be careful not to touch the parts inside the product.

Important:

❏ Be careful to keep water away from the electronic components.

❏ Do not spray the inside of the product with lubricants.

❏ Unsuitable oils can damage the mechanism. Contact your dealer or a qualified service person if lubrication is

needed.

Make sure that no warnings or errors are indicated in the control panel.

Load several sheets of A3-size plain paper in the paper cassette 1.

& “Loading Paper into the Paper Cassette” on page 20

Enter Menu from the Home screen.

User’s Guide

Maintaining Your Product and Software

Select Maintenance, Paper Guide Cleaning, and then follow the instructions on the control panel.

Note for the product with paper cassette 2:

If the stain does not clears, load paper in paper cassette 2, then try step 3 to 4.

Replacing Maintenance Box

Checking the maintenance box status

The maintenance box status is shown in the same screen of the ink cartridge status. You can check the status from the printer software or the control panel.

& “Checking the Ink Cartridge Status” on page 54

Precautions on the maintenance box

Read all of the instructions in this section before replacing the maintenance box.

❏ Epson recommends the use of a genuine Epson maintenance box. The use of a non-genuine maintenance box may

cause damage that is not covered by Epson’s warranties, and under certain circumstances, may cause erratic printer behavior. Epson cannot guarantee the quality or reliability of a non-genuine maintenance box.

❏ Do not dismantle the maintenance box.

❏ Do not touch the green chip on the side of the maintenance box.

❏ Keep out of reach of children, and do not drink the ink.

❏ Do not tilt the used maintenance box until it is placed in the plastic bag provided.

❏ Do not reuse a maintenance box which has been removed and left detached for a long period.

❏ Keep the maintenance box away from direct sunlight.

❏ In some print cycles a very small amount of surplus ink may be collected in the maintenance box. To prevent ink

leakage from the maintenance box, the product is designed to stop printing when the absorbing capacity of the maintenance box has reached its limit. Whether and how often this is required will vary according to the number of pages you print, the type of material that you print and the number of cleaning cycles that the product performs. Replace the maintenance box when your are promoted to do so. The Epson Status Monitor, your LCD, or lights on the control panel will advise you when this part needs replacing. The need for replacement of the pad does not mean that your product has ceased to operate in accordance with its specifications. The Epson warranty does not cover the cost of this replacement. It is a user-serviceable part.

Replacing a maintenance box

To replace the maintenance box, follow the steps below.

Confirm that the product is not draining the ink.

User’s Guide

Maintaining Your Product and Software

Remove the replacement maintenance box from the package.

Note:

Do not touch the green chip on the side of the box. Doing so may prevent normal operation.

Open the rear cover 1.

Put your hand on the handle of the maintenance box, and then pull the box outward.

Note:

If ink gets on your hands, wash them thoroughly with soap and water. If ink gets into your eyes, flush them immediately with water.

Put the used maintenance box in the plastic bag provided with the replacement box, and dispose of it properly.

Note:

Do not tilt the used maintenance box until after it is sealed in the plastic bag.

User’s Guide

Maintaining Your Product and Software

Insert the maintenance box into place as far as it will go.

Close the rear cover 1.

Maintenance box replacement is complete.

Transporting the Product

If you move the product some distance, you need to prepare it for transportation in its original box or one of a similar size.

Important:

❏ When storing or transporting the product, avoid tilting it, placing it vertically, or turning it upside down;

otherwise ink may leak.

❏ Leave the ink cartridges installed. Removing the cartridges can dry out the print head and may prevent the product

from printing.

Make sure the product is off.

Open the printer cover.

Make sure the print head is in the home position on the right.

User’s Guide

Maintaining Your Product and Software

Secure the ink cartridge holder to the case with tape as shown.

Close the printer cover.

Unplug its power code and disconnect all other cables from the product.

Remove all paper from the rear paper feed slot.

Close the rear paper feed slot and the output tray.

Remove all paper from the paper cassette and re-insert the cassette into the product.

Repack the product in its box, using the protective materials that came with it.

Note:

Keep the product level during transport.

Checking and Installing Your Software

Checking the software installed on your computer

To use the functions described in this User’s Guide, you need to install the following software.

❏ Epson Driver and Utilities

❏ Epson Easy Photo Print

Follow the steps below to check that the software is installed on your computer.

User’s Guide

Maintaining Your Product and Software

For Windows

Windows 8 and Server 2012: Select Desktop, Settings charm, and Control Panel.

Windows 7, Vista, and Server 2008: Click the start button and select Control Panel.

Windows XP and Server 2003: Click Start and select Control Panel.

Windows 8, Windows 7, Vista, Server 2012 and Server 2008: Select Uninstall a program from the Programs

category.

Windows XP: Double-click the Add or Remove Programs icon.

Windows Server 2003: Click the Add or Remove Programs icon.

Check the list of currently installed programs.

For Mac OS X

Double-click Macintosh HD.

Double-click the Epson Software folder in the Applications folder and check the contents.

Note:

❏ The Applications folder contains software provided by third parties.

❏ To check that the printer driver is installed, click System Preferences on the Apple menu and then click Print & Scan

(for Mac OS X 10.8 or 10.7) or Print & Fax (for Mac OS X 10.6 or 10.5.8). Then locate your product in the Printers list box.

Installing the software

You can download the latest software applications from the following Epson website.

http://support.epson.net/ http://www.epson.eu/Support (Europe)

Uninstalling Your Software

You may need to uninstall and then reinstall your software to solve certain problems or if you upgrade your operating system.

See the following section for information on determining what applications are installed. & “Checking the software installed on your computer” on page 75

User’s Guide

Maintaining Your Product and Software

For Windows

Note:

❏ For Windows 8, 7, Vista, Server 2012 and Server 2008, you need an administrator account and password if you log on as

a standard user.

❏ For Windows XP and Server 2003, you must log on to a Computer Administrator account.

Turn off the product.

Disconnect the product’s interface cable from your computer.

Do one of the following.

Windows 8 and server 2012: Select Desktop, Settings charm, and Control Panel.

Windows 7, Vista, and Server 2008: Click the start button and select Control Panel.

Windows XP and Server 2003: Click Start and select Control Panel.

Do one of the following.

Windows 8, Windows 7, Vista, Server 2012 and Server 2008: Select Uninstall a program from the Programs category.

Windows XP: Double-click the Add or Remove Programs icon.

Windows Server 2003: Click the Add or Remove Programs icon.

Select the software you want to uninstall such as your product’s driver and the application from the list

displayed.

Do one of the following.

Windows 8, Windows 7, Server 2012 and Server 2008: Select Uninstall/Change or Uninstall.

Windows Vista: Click Uninstall/Change or Uninstall, and then click Continue in the User Account Control

window.

Windows XP and Server 2003: Click Change/Remove or Remove.

Note:

If you chose to uninstall your product’s printer driver in step 5, select the icon for your product and then click OK.

When the confirmation window appears, click Yes or Next.

Follow the on-screen instructions.

User’s Guide

Maintaining Your Product and Software

In some cases, a message may appear to prompt you to restart your computer. If so, make sure I want to restart my computer now is selected and click Finish.

For Mac OS X

Note:

❏ To uninstall your software you need to download the Uninstaller.

Access the site at:

http://www.epson.com

Next, select the support section of your local Epson Web site.

❏ To uninstall applications, you must log on to a Computer Administrator account.

You cannot uninstall programs if you log on as a limited account user.

❏ Depending on the application, the Installer may be separated from the Uninstaller.

Quit all running applications.

Double-click the Uninstaller icon in your Mac OS X hard drive.

Select the check boxes for the software you want to uninstall, such as the printer driver and the application, from

the list displayed.

Click Uninstall.

Follow the on-screen instructions.

If you cannot find the software you want to uninstall in the Uninstaller window, double-click the Applications folder in your Mac OS X hard drive, select the application you want to uninstall, and then drag it to the Trash icon.

Note:

If you uninstall the printer driver and the name of your product remains in the Print & Scan (for Mac OS X 10.8 or 10.7) or Print & Fax (for Mac OS X 10.6 or 10.5.8) window, select the name of your product and click the - remove button.

User’s Guide

Error Indicators

Error Messages on the Control Panel

This section describes the meaning of messages displayed on the LCD screen.

Messages Solutions

Paper Jam

Printer Error Turn the product off and then back on. Make sure that no paper is

Maintenance box is nearing end of its service life. Replace maintenance box before the end its service life.

Maintenance box is at the end of its service life. You need to replace it.

A printer’s ink pad is nearing the end of its service life. Please contact Epson Support.

A printer’s ink pad is at the end of its service life. Please contact Epson Support.

Invalid IP address and subnet mask. Refer the online Network Guide.

Recovery Mode The firmware update has failed. You will need to re-attempt the

& “Paper Jams” on page 83

still in the product. If the error still appears, contact Epson Support.

& “Replacing Maintenance Box” on page 72

When the maintenance box is full, the product stops and you need to replace the maintenance box to continue printing.

Replace the maintenance box. & “Replacing Maintenance Box” on page 72

Press OK button to resume printing. The message will be displayed until the ink pad* is replaced. Contact Epson or an authorized Epson service provider to replace the ink pad before the end of its service life. It is not a user-serviceable part.

Contact Epson or an authorized Epson service provider to replace the ink pad

firmware update. Ready a USB cable and visit your local Epson website for further instructions. & “Where To Get Help” on page 106

. It is not a user-serviceable part.

* In some print cycles a very small amount of surplus ink may be collected in the ink pad. To prevent ink leakage from the pad, the

product is designed to stop printing when the pad has reached its limit. Whether and how often this is required will vary according to the number of pages you print using the borderless print option. The need for replacement of the pad does not mean that your product has ceased to operate in accordance with its specifications. The product will advise you when the pad requires replacing and this can only be performed by an authorized Epson Service provider. The Epson warranty does not cover the cost of this replacement.

User’s Guide

Troubleshooting for Printing

Diagnosing the Problem

Troubleshooting product problems is best handled in two steps: first diagnose the problem, then apply likely solutions until the problem is fixed.

The information that you need to diagnose and solve most common problems is provided by online problem solving, the control panel, or the status monitor. Refer to the appropriate section below.

If you have a specific problem relating to print quality, a printing problem not related to print quality, or a paper feeding problem, or if the product does not print at all, refer to the appropriate section.

To solve a problem, you may need to cancel printing. & “Canceling printing” on page 35

User’s Guide

Troubleshooting for Printing

Checking product status

If a problem occurs while printing, an error message will appear in the status monitor window.

When you need to replace an ink cartridge or a maintenance box, click the How To button on the window, and the status monitor will lead you step-by-step through the cartridge or the maintenance box replacement procedure.

For Windows

There are two ways to access EPSON Status Monitor 3:

❏ Double-click the product shortcut icon on your Windows taskbar. To add a shortcut icon to the taskbar, see the

following section: & “From the shortcut icon on the taskbar” on page 31

❏ Open the printer driver, click the Maintenance tab, then click the EPSON Status Monitor 3 button.

When you access EPSON Status Monitor 3, the following window appears:

Note: ❏ If EPSON Status Monitor 3 does not appear, access the printer driver and click the Maintenance tab and then the

Extended Settings button. In the Extended Settings window, check the Enable EPSON Status Monitor 3 check box.

❏ Depending on current settings, the simplified status monitor may be displayed. Click the Details button to display the

window above.

EPSON Status Monitor 3 provides the following information:

User’s Guide

Troubleshooting for Printing

❏ Current Status:

If the ink is low/expended or the maintenance box is nearly full/full, the How to button appears in the EPSON Status Monitor 3 window. Clicking How to displays ink cartridge or maintenance box replacement instructions.

❏ Ink Levels:

EPSON Status Monitor 3 provides a graphic display of the ink cartridge status.

❏ Information:

You can view information about the installed ink cartridges by clicking Information.

❏ Maintenance Box Service Life:

EPSON Status Monitor 3 provides a graphic display of the maintenance box status.

❏ Technical Support:

Click Technical Support to access the Epson technical support website.

❏ Print Queue:

You can view Windows Spooler by clicking Print Queue.

For Mac OS X

Follow these steps to access EPSON Status Monitor.

Access the Epson Printer Utility 4.

& “Accessing the printer driver for Mac OS X” on page 31

Click the EPSON Status Monitor icon. The EPSON Status Monitor appears.

User’s Guide

Troubleshooting for Printing

You can also use this utility to check the ink cartridge status before printing. EPSON Status Monitor displays the ink cartridge status at the time it was opened. To update the ink cartridge status, click Update.

When ink is low/expended or the maintenance box is nearly full/full, a How to button appears. Click How to, and EPSON Status Monitor will lead you step by step through the ink cartridge or maintenance box replacement procedure.

Paper Jams

Caution:

Never touch the buttons on the control panel while your hand is inside the product.

Note:

❏ Cancel the print job if prompted by a message from the LCD screen or the printer driver.

❏ After you have removed the jammed paper, press the button indicated in the LCD screen.

User’s Guide

Troubleshooting for Printing

Removing jammed paper from the rear cover

Turn the product around.

Note:

If you need to change the position of the product, two people are required to lift the product.

Open the rear cover 1.

Remove the jammed paper.

User’s Guide

Pull out the rear cover 2.

Carefully remove the jammed paper.

Troubleshooting for Printing

Carefully remove the jammed paper.

User’s Guide

Open the rear cover 2.

Troubleshooting for Printing

Carefully remove the jammed paper.

Reattach the rear cover 2.

User’s Guide

Troubleshooting for Printing

Close the rear cover 1.

Removing jammed paper from inside the product

Carefully remove the jammed paper.

Open the printer cover.

User’s Guide

Troubleshooting for Printing

Remove all of the paper inside, including any torn pieces.

Important:

Do not touch the flat white cable connected to the cartridge holder.

Close the printer cover.

Note:

If there are still some torn pieces of paper inside the product even after clearing the paper jam, follow the steps below to remove them. Menu > Maintenance > Remove Paper

Removing jammed paper from the paper cassette

Pull the paper cassette all the way out.

Remove the jammed paper from the cassette.

User’s Guide

Troubleshooting for Printing

Carefully remove any paper jammed inside the product.

Align the edges of the paper.

Put the paper cassette cover back on.

User’s Guide

Troubleshooting for Printing

Keep the cassette flat and slowly and carefully reinsert it all the way into the product.

Preventing paper jams

If your paper jams frequently, check the following.

❏ The paper is smooth, not curled or wrinkled.

❏ You are using high-quality paper.

❏ The printable side of the paper is face down in the paper cassette.

❏ The printable side of the paper is face up in the rear paper feed slot.

❏ The paper stack was fanned before loading.

❏ For plain paper, do not load paper above the line just under the H arrow mark inside the edge guide.

For Epson special media, make sure the number of sheets is less than the limit specified for the media. & “Selecting Paper” on page 16

❏ The edge guides are snug against the edges of the paper.

❏ The product is on a flat, stable surface that extends beyond the base in all directions. The product will not operate

properly if it is tilted.

Reprinting after a paper jam (for Windows only)

After you cancel the print job because of a paper jam, you can reprint it without reprinting pages that have already been printed.

Solve the paper jam.

& “Paper Jams” on page 83

Access the printer settings.

& “Accessing the printer driver for Windows” on page 30

Select the Print Preview check box in the Main window of your printer driver.

Make the settings that you want to use to print.

User’s Guide

Troubleshooting for Printing

Click OK to close the printer settings window, and then print your file. Print Preview window opens.

Select a page that has already been printed in the page list box on the left side, and then select Remove Page from

the Print Options menu. Repeat this step for all the pages that have already been printed.

Click Print on the Print Preview window.

Print Quality Help

If you are having print quality problems, then compare it with the illustrations below. Click the caption under the illustration that best resembles your prints.

Good sample

& “Horizontal banding” on page 92

& “Horizontal banding” on page 92 & “Vertical banding or misalignment” on

& “Vertical banding or misalignment” on

Good sample

page 92

& “Incorrect or missing colors” on page 92

& “Blurry or smeared print” on page 93

User’s Guide

Troubleshooting for Printing

Horizontal banding

❏ Make sure the printable side (the whiter or glossier side) of the paper is face up in the rear paper feed slot.

❏ Make sure the printable side (the whiter or glossier side) of the paper is face down in the paper cassette.

❏ Run the Nozzle Check utility and then clean any print heads which produced a defective nozzle check result.

& “Checking the Print Head Nozzles” on page 65

If the problem does not improve, run the Print Head Alignment utility. & “Aligning the Print Head” on page 68

❏ For best results, use up ink cartridge within six months of opening the package.

❏ Try to use genuine Epson ink cartridges.

❏ Make sure the paper type selected in the LCD menu or printer driver is appropriate for the type of paper loaded in

the product. & “Selecting Paper” on page 16

Vertical banding or misalignment

❏ Make sure the printable side (the whiter or glossier side) of the paper is face up in the rear paper feed slot.

❏ Make sure the printable side (the whiter or glossier side) of the paper is face down in the paper cassette.

❏ Run the Nozzle Check utility and then clean any print heads which produced a defective nozzle check result.

& “Checking the Print Head Nozzles” on page 65

❏ Run the Print Head Alignment utility.

& “Aligning the Print Head” on page 68

❏ For Windows, clear the High Speed check box from the More Options window in your printer driver. See the

online help for details. For Mac OS X, select Off from the High Speed Printing. To display the High Speed Printing, click through the following menus: System Preferences, Print & Scan (for Mac OS X 10.8 or 10.7) or Print & Fax (for Mac OS X

10.6 or 10.5.8), your product (in the Printers list box), Options & Supplies, and then Driver.

❏ Make sure the paper type selected in the LCD menu or printer driver is appropriate for the type of paper loaded in

the product. & “Selecting Paper” on page 16

❏ For Windows, if you have selected Standard-Vivid as Quality in your printer driver's Main tab, change it to

Standard. For Mac OS X, if you have selected Normal-Vivid as Print Quality in your printer driver's Print Settings from the pop-up menu, change it to Normal.

Incorrect or missing colors

❏ For Windows, clear the Grayscale setting in the Main window in your printer driver.

For Mac OS X, clear the Grayscale setting in Print Settings in the Print dialog box in your printer driver.

User’s Guide

Troubleshooting for Printing

❏ Adjust the color settings in your application or in your printer driver settings.

For Windows, check the More Options window. For Mac OS X, check the Color Options dialog box from the Print dialog box.

❏ Run the Nozzle Check utility and then clean any print heads which produced a defective nozzle check result.

& “Checking the Print Head Nozzles” on page 65

❏ I f y o u h a ve j us t r ep l ac e d a n in k ca rt ri d ge , ma k e s u re th e date on the box. If you have not used the product for a long

time, Epson recommends replacing the ink cartridges. & “Replacing an ink cartridge” on page 61

❏ Try to use genuine Epson ink cartridges and paper recommended by Epson.

Blurry or smeared print

❏ Try to use genuine Epson ink cartridges and paper recommended by Epson.

❏ Make sure the product is on a flat, stable surface that extends beyond the base in all directions. The product will not

operate properly if it is tilted.

❏ Make sure your paper is not damaged, dirty, or too old.

❏ Make sure your paper is dry and the printable side (the whiter or glossier side) is face up in the rear paper feed

slot.

❏ Make sure your paper is dry and the printable side (the whiter or glossier side) is face down in the paper cassette.

❏ If the paper is curled toward the printable side, flatten it or curl it slightly in the opposite direction.

❏ Make sure the paper type selected in the LCD menu or printer driver is appropriate for the type of paper loaded in

the product. & “Selecting Paper” on page 16

❏ Remove each sheet from the output tray as it is printed.

❏ Do not touch or allow anything to come into contact with the printed side of paper with a shiny finish. To handle

your prints, follow the instructions of the paper.

❏ Run the Nozzle Check utility and then clean any print heads which produced a defective nozzle check result.

& “Checking the Print Head Nozzles” on page 65

❏ Run the Print Head Alignment utility.

& “Aligning the Print Head” on page 68

❏ From the product’s control panel, select the menu as shown below.

Menu > Maintenance > Thick Paper > On

For Windows, select Thick paper and envelopes from Extended Settings in your printer driver’s Maintenance tab.

For Mac OS X 10.5.8, select On from the Thick paper and envelopes. To display the Thick Paper and Envelopes, click through the following menus: System Preferences, Print & Scan (for Mac OS X 10.8 or 10.7) or Print & Fax (for Mac OS X 10.6 or 10.5.8), your product (in the Printers list box, Options & Supplies, and then Driver.

User’s Guide

Troubleshooting for Printing

❏ For Windows, if your printouts are still smeared when using Thick Paper and Envelopes, follow the instructions

below.

Select Short Grain Paper from Extended Settings in your printer driver’s Maintenance tab. This setting is not available when Borderless or Anti-Copy Pattern are selected.

❏ If you are printing high-density data on plain paper using automatic 2-sided printing, lower the Print Density and

choose a longer Increase Ink Drying Time in the Print Density Adjustment window (for Windows) or in the T wo -s i d ed P r in t in g S et t i ng s (f o r Ma c O S X ) o f y o ur p r in t e r driver. The longer the Increase Ink Drying Time is, the longer it takes to print.

❏ If the paper is smeared with ink after printing, clean the interior of the product.

& “Cleaning the interior of the product” on page 71

Miscellaneous Printout Problems

Incorrect or garbled characters

❏ Clear any stalled print jobs.

& “Canceling printing” on page 35

❏ Turn off the product and computer. Make sure the product’s interface cable is securely plugged in.

❏ Uninstall the printer driver, then reinstall it.

& “Uninstalling Your Software” on page 76

❏ If you put your computer into Hibernate or Sleep mode manually while the computer is sending a print job, pages

of garbled text may be printed the next time you start your computer.

Incorrect margins

❏ Make sure that the paper is loaded into the rear paper feed slot or the paper cassette correctly.

& “Loading Paper into the Paper Cassette” on page 20 & “Loading Envelopes into the Paper Cassette” on page 24 & “Loading Paper and Envelopes into the Rear Paper Feed Slot” on page 27

❏ Check the margin settings in your application. Make sure that the margins are within the printable area of the

page. & “Printable area” on page 102

❏ Make sure the printer driver settings are appropriate for the paper size you are using.

For Windows, check the Main window. For Mac OS X, check the Page Setup dialog box or Print dialog box.

❏ If margins still appear even when printing using the borderless setting, try one of the following.

For Windows, click Extended Settings button on the printer driver’s Maintenance window, and then select Remove white borders. For Mac OS X, select On from the Remove white borders. To display the Remove white borders, click through the following menus: System Preferences, Print & Scan (for Mac OS X 10.7) or Print & Fax (for Mac OS X 10.6 or

10.5), your printer (in the Printers list box), Options & Supplies, and then Driver.

User’s Guide

Troubleshooting for Printing

❏ Uninstall the printer driver, then reinstall it.

& “Uninstalling Your Software” on page 76

Printout has a slight slant

❏ Make sure that the paper is loaded into the rear paper feed slot or the paper cassette correctly.

& “Loading Paper into the Paper Cassette” on page 20 & “Loading Envelopes into the Paper Cassette” on page 24 & “Loading Paper and Envelopes into the Rear Paper Feed Slot” on page 27

❏ If Draft is selected in Quality in the Main window in your printer driver (for Windows), or in Print Quality in Print

Settings (for Mac OS X), select another setting.

Inverted image

❏ For Windows, clear the Mirror Image check box from the More Options window of your printer driver, or turn

off the Mirror Image setting in your application. For Mac OS X, clear the Mirror Image check box in Print Settings in the Print dialog box of your printer driver, or turn off the Mirror Image setting in your application.

❏ Uninstall the printer driver, then reinstall it.

& “Uninstalling Your Software” on page 76

Blank pages print

❏ Make sure the printer driver settings are appropriate for the paper size you are using.

For Windows, check the Main window. For Mac OS X, check the Page Setup dialog box or Print dialog box.

❏ For Windows, check the Skip Blank Page setting by clicking the Extended Settings button on the Maintenance

window of the printer driver. For Mac OS X, select On from the Skip Blank Page. To display the Skip Blank Page, click through the following menus: System Preferences, Print & Scan (for Mac OS X 10.8 or 10.7) or Print & Fax (for Mac OS X 10.6 or

10.5.8), your product (in the Printers list box), Options & Supplies, and then Driver.

❏ Uninstall the printer driver, then reinstall it.

& “Uninstalling Your Software” on page 76

Printed side is smeared or scuffed

❏ If the paper is curled toward the printable side, flatten it or curl it slightly in the opposite direction.

❏ Clean the interior of the product by using the Paper Guide Cleaning function.

& “Cleaning the interior of the product” on page 71

❏ Uninstall the printer driver, then reinstall it.

& “Uninstalling Your Software” on page 76

User’s Guide

Troubleshooting for Printing

Printing is too slow

❏ Make sure the paper type selected in the LCD menu or printer driver is appropriate for the type of paper loaded in

the product. & “Selecting Paper” on page 16

❏ Choose a lower print quality in the printer driver's Main window (Windows), or in the Print Settings dialog box

from the printer driver's Print dialog box (Mac OS X).

& “Accessing the printer driver for Windows” on page 30 & “Accessing the printer driver for Mac OS X” on page 31

❏ When Increase Ink Drying Time settings is changed, the print speed may decline. Choose a shorter time for

Increase Ink Drying Time in the Print Density Adjustment window (for Windows) or in the Two-sided Printing Settings (for Mac OS X) of your printer driver.

❏ Close any unnecessary applications.

❏ If you print continuously for an extended period, the printing may be extremely slow. This is to slow down the

printing speed and prevent the product mechanism from overheating and being damaged. If this happens, you can continue to print, but we recommend stopping and leaving the product idle for at least 30 minutes with the power on. (The product does not recover with the power off.) After you restart, the product will print at normal speed.

❏ Uninstall the printer driver, then reinstall it.

& “Uninstalling Your Software” on page 76

If you try all of the methods above and cannot solve the problem, see the following.

Paper Does Not Feed Correctly

Paper does not feed

Remove the stack of paper and make sure of the following:

❏ You have inserted the paper cassette all the way into the product.

❏ The paper is not curled or creased.

❏ The paper is not too old. See the instructions that came with the paper for more information.

❏ For plain paper, do not load paper above the line just under the H arrow mark inside the edge guide.

For Epson special media, make sure the number of sheets is less than the limit specified for the media. & “Selecting Paper” on page 16

❏ Paper is not jammed inside the product. If it is, remove the jammed paper.

& “Paper Jams” on page 83

❏ The ink cartridges are not expended. If a cartridge is expended, replace it.

& “Replacing an ink cartridge” on page 61

❏ You have followed any special loading instructions that came with your paper.

User’s Guide

Troubleshooting for Printing

Multiple pages feed

❏ For plain paper, do not load paper above the line just under the H arrow mark inside the edge guide.

For Epson special media, make sure the number of sheets is less than the limit specified for the media. & “Selecting Paper” on page 16

❏ Make sure the edge guides are snug against the edges of the paper.

❏ Make sure the paper is not curled or folded. If so, flatten it or curl it slightly toward the opposite side before

❏ Remove the stack of paper and make sure that the paper is not too thin.

& “Paper” on page 101

❏ Fan the edges of the stack to separate the sheets, then reload the paper.

Paper is improperly loaded

If you have loaded the paper too far into the product, the product cannot feed the paper correctly. Turn the product off and gently remove the paper. Then turn the product on and reload the paper correctly.

Paper is not ejected fully or is wrinkled

❏ If the paper does not eject fully, press the button indicated on the control panel to eject the paper. If the paper is

jammed inside the product, remove it by referring to the following section. & “Paper Jams” on page 83

❏ If the paper is wrinkled when it comes out, it may be damp or too thin. Load a new stack of paper.

Note:

Store any unused paper in its original packaging in a dry area.

The Product Does Not Print

All lights are off

❏ Press the P button to make sure the product is on.

❏ Make sure that the power cord is securely plugged in.

❏ Make sure that your outlet works and is not controlled by a wall switch or timer.

The control panel or lights are on

❏ Turn off the product and computer. Make sure the product’s interface cable is securely plugged in.

❏ If you are using the USB interface, make sure your cable meets the USB or Hi-Speed USB standards.

User’s Guide

Troubleshooting for Printing

❏ If you are connecting the product to your computer via a USB hub, connect the product to the first-tier hub from

your computer. If the printer driver is still not recognized on your computer, try to directly connect the product to your computer without the USB hub.

❏ If you are connecting the product to your computer via a USB hub, make sure the USB hub device is recognized by

your computer.

❏ If you are trying to print a large image, your computer may not have enough memory. Try reducing the resolution

of your image or printing the image at a smaller size. You may need to install more memory in your computer.

❏ Users of Windows can clear any stalled print jobs from the Windows Spooler.

& “Canceling printing” on page 35

❏ Uninstall the printer driver, then reinstall it.

& “Uninstalling Your Software” on page 76

An ink error is indicated after you replace the cartridge

Open the printer cover.

Make sure the ink cartridge holder is at the ink cartridge replacement position.

Note:

If the ink cartridge holder is at the far right position, select the menu as shown below.

Menu > Maintenance > Ink Cartridge(s) Replacement

Open the ink cartridge cover. Remove and reinsert the ink cartridge and then continue with the ink cartridge

installation.

User’s Guide

Close the ink cartridge cover firmly.

Close the printer cover.

Troubleshooting for Printing

Product Information

System Requirements

For Windows

System PC Interface

Windows 8 (32-bit, 64-bit), Windows 7 (32-bit, 64-bit), Vista (32-bit, 64-bit), XP SP1 or higher(32-bit), or XP Professional x64 Edition, Server 2012, Server 2008 R2, Server 2008, and Server 2003

Hi-Speed USB

For Mac OS X

System PC Interface

Mac OS X 10.5.8, 10.6.x, 10.7.x, 10.8.x Hi-Speed USB

Note:

The UNIX File System (UFS) for Mac OS X is not supported.

Technical Specifications

Note:

Specifications are subject to change without notice.

Printer specifications

Paper path

Capacity

Paper cassette 1 and 2, front entry

Rear paper feed slot, top entry

27.5 mm for paper cassette 1 and 2

0.3 mm for rear paper feed slot

100

Epson WF-7110DTW User Guide

Specifications and Main Features

Frequently Asked Questions
