Epson WF-6090DW User Guide

User's Guide

NPD5258-02 EN

User's Guide

Copyright

No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of Seiko Epson Corporation. No patent liability is assumed with respect to the use of the information contained herein. Neither is any liability assumed for damages resulting from the use of the information herein. information contained herein is designed only for use with this Epson product. Epson is not responsible for any use of this information as applied to other products.

Neither Seiko Epson Corporation nor its aliates shall be liable to the purchaser of this product or third parties for damages, losses, costs, or expenses incurred by the purchaser or third parties as a result of accident, misuse, or abuse of this product or unauthorized modications, repairs, or alterations to this product, or (excluding the U.S.) failure to strictly comply with Seiko Epson Corporation's operating and maintenance instructions.

Seiko Epson Corporation and its aliates shall not be liable for any damages or problems arising from the use of any options or any consumable products other than those designated as Original Epson Products or Epson Approved Products by Seiko Epson Corporation.

e

Seiko Epson Corporation shall not be held liable for any damage resulting from electromagnetic interference that occurs from the use of any interface cables other than those designated as Epson Approved Products by Seiko Epson Corporation.

contents of this manual and the

e

specications

of this product are subject to change without notice.

User's Guide

Trademarks

❏ EPSON® is a registered trademark, and EPSON EXCEED YOUR VISION or EXCEED YOUR VISION is a

trademark of Seiko Epson Corporation.

❏

Microso

❏ Apple, Macintosh, Mac OS, OS X, Bonjour, Safari, iPad, iPhone, iPod touch, and iTunes are trademarks of Apple

Inc., registered in the U.S. and other countries. AirPrint and the AirPrint logo are trademarks of Apple Inc.

❏ Google Cloud Print™, Chrome™, Chrome OS™, and Android™ are trademarks of Google Inc.

❏ Adobe, Adobe Reader, Acrobat, and Photoshop are trademarks of Adobe systems Incorporated, which may be

registered in certain jurisdictions.

❏ Monotype is a trademark of Monotype Imaging, Inc. registered in the United States Patent and Trademark

Oce and may be registered in certain jurisdictions.

❏ Albertus, Arial, and Times New Roman are trademarks of e Monotype Corporation.

❏ ITC Avant Garde, ITC Bookman, ITC Zapf-Chancery, and ITC Zapf Dingbats are trademarks of International

Typeface Corporation registered in the United States Patent and Trademark Oce and may be registered in certain jurisdictions.

❏ Clarendon, Helvetica, New Century Schoolbook, Palatino, Times and Univers are registered trademarks of

Heidelberger Druckmaschinen AG, which may be registered in certain jurisdictions, exclusively licensed through Linotype Library GmbH, a wholly owned subsidiary of Heidelberger Druckmaschinen AG.

❏ Wingdings is a registered trademark of

❏ Antique Olive is a registered trademark of Marcel Olive and may be registered in certain jurisdictions.

❏ Marigold is a trademark of AlphaOmega Typography.

, Windows®, and Windows Vista® are registered trademarks of

Microso

Corporation in the United States and other countries.

Microso

Corporation.

❏ Coronet is a registered trademark of Ludlow Type Foundry.

❏ PCL is the registered trademark of Hewlett-Packard Company.

❏ Getopt

Redistribution and use in source and binary forms, with or without modication, are permitted provided that the following conditions are met:

1. Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.

2. Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution.

4. Neither the name of the University nor the names of its contributors may be used to endorse or promote products derived from this soware without specic prior written permission.

THIS SOFTWARE IS PROVIDED BY THE REGENTS AND CONTRIBUTORS ''AS IS'' AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE REGENTS OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

User's Guide

Trademarks

❏ Arcfour

is code illustrates a sample implementation of the Arcfour algorithm.

Redistribution and use in source and binary forms, with or without modication, are permitted provided that this copyright notice and disclaimer are retained.

THIS SOFTWARE IS PROVIDED BY KALLE KAUKONEN AND CONTRIBUTORS ''AS IS'' AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL KALLE KAUKONEN OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

❏ microSDHC Logo is a trademark of SD-3C, LLC.

Note: microSDHC is built into the product and cannot be removed.

❏ Intel® is a registered trademark of Intel Corporation.

❏ General Notice: Other product names used herein are for

of their respective owners. Epson disclaims any and all rights in those marks.

identication

purposes only and may be trademarks

User's Guide

Contents

Trademarks

About This Manual

Introduction of Manuals..................... 8

Marks and Symbols.........................8

Descriptions Used in this Manual...............8

Operating System References..................9

Important Instructions

Safety Instructions.........................10

Printer Advisories and Warnings.............. 11

Advisories and Warnings for Setting Up/

Using the Printer........................11

Advisories and Warnings for Using the

Printer with a Wireless Connection...........12

Advisories and Warnings for Using the LCD

Screen................................12

Protecting Your Personal Information...........12

Administrator Settings

Locking the Printer Settings Using an

Administrator's Password....................13

Unlocking the Printer Settings................ 13

Printer Basics

Part Names and Functions...................14

Control Panel............................ 17

Buttons and Lights.......................17

Icons Displayed on the LCD Screen...........18

Menu Options............................18

Menu................................ 18

Loading Paper

Paper Handling Precautions..................26

Available Paper and Capacities................27

List of Paper Types.......................29

Loading Paper in the Paper Cassette............30

Loading Paper in the Rear Paper Feed...........32

Loading Paper in the Front Paper Feed Slot. . . . . . . 34

Printing

Printing from a Computer...................36

Printing Basics - Windows.................36

Printing Basics - Mac OS X.................37

Printing on 2-Sides.......................40

Printing Several Pages on One Sheet..........42

Printing to Fit the Paper Size................43

Printing Multiple Files Together (for

Windows Only).........................44

Printing One Image on Multiple Sheets to

Create a Poster (for Windows Only).......... 45

Printing Using Advanced Features........... 51

Printing Using a PostScript Printer Driver........53

Printing Using a PostScript Printer Driver -

Windows..............................53

Printing Using a PostScript Printer Driver -

Mac OS X.............................55

Setting Items for the PostScript Printer Driver. . . 58

Printing from Smart Devices................. 58

Using Epson iPrint.......................58

Using AirPrint..........................61

Canceling Printing.........................61

Canceling Printing - Printer Button...........61

Canceling Printing - Windows.............. 62

Canceling Printing - Mac OS X..............62

Replacing Ink Cartridges and Other Consumables

Checking the Status of the Remaining Ink and

the Maintenance Box.......................63

Checking the Status of the Remaining Ink

and the Maintenance Box - Control Panel. . . . . . 63

Checking the Status of the Remaining Ink

and the Maintenance Box - Windows......... 63

Checking the Status of the Remaining Ink

and the Maintenance Box - Mac OS X.........63

Ink Cartridge Codes........................64

Ink Cartridge Handling Precautions............64

Replacing Ink Cartridges.................... 65

Maintenance Box Code..................... 67

Maintenance Box Handling Precautions.........67

Replacing a Maintenance Box.................67

Maintenance Rollers Codes.................. 69

Replacing Maintenance Rollers in Paper

Cassette 1............................... 69

User's Guide

Contents

Replacing Maintenance Rollers in Paper

Cassette 2 to 3............................73

Temporarily Printing with Black Ink............76

Temporarily Printing with Black Ink - Windows. 77 Temporarily Printing with Black Ink -

Mac OS X.............................78

Conserving Black Ink when the Black Ink Is

Low (for Windows Only)....................78

Improving Print Quality

Checking and Cleaning the Print Head..........80

Checking and Cleaning the Print Head -

Control Panel.......................... 80

Checking and Cleaning the Print Head -

Windows..............................81

Checking and Cleaning the Print Head -

Mac OS X.............................81

Aligning the Print Head.....................82

Improving Horizontal Streaks.................83

Cleaning the Paper Path.....................83

Applications and Network Service Information

Epson Connect Service......................85

We b

Running Web Cong on a Web Browser. . . . . . . 85

Running Web Cong on Windows........... 86

Running Web Cong on Mac OS X...........86

Necessary Applications......................87

Windows Printer Driver...................87

Mac OS X Printer Driver..................88

E-Web Print (for Windows Only)............89

EPSON Soware Updater..................89

EpsonNet

Uninstalling Applications....................90

Uninstalling Applications - Windows......... 90

Uninstalling Applications - Mac OS X.........91

Installing Applications......................92

Installing a PostScript Printer Driver..........92

Installing the Epson Universal Printer Driver

(for Windows Only)......................95

Updating Applications and Firmware...........95

..............................85

Cong

........................90

Cong

Solving Problems

Checking the Printer Status.................. 97

Checking Messages on the LCD Screen........97

Checking the Printer Status - Windows........98

Checking Printer Status - Mac OS X..........98

Removing Jammed Paper....................98

Removing Jammed Paper from the Front

Cover (A)............................. 99

Removing Jammed Paper from the Rear

Paper Feed (B1)........................100

Removing Jammed Paper from the Front

Paper Feed Slot (B2).....................100

Removing Jammed Paper from the Paper

Cassette (C1/C2/C3).................... 101

Removing Jammed Paper from Rear Cover 1

(D1) and Rear Cover 2 (D2)...............102

Removing Jammed Paper from the Rear

Cover (E).............................103

Paper Does Not Feed Correctly...............104

Power and Control Panel Problems............105

Power Does Not Turn On.................105

Power Does Not Turn O.................105

LCD Screen Gets Dark...................105

Printer Does Not Print.....................105

Printout Problems........................106

Print Quality Is Poor.................... 106

e Position, Size, or Margins of the Printout

Are Incorrect..........................107

Paper Is Smeared or Scued...............108

Printed Characters Are Incorrect or Garbled. . . 108

e Printed Image Is Inverted..............108

e Printout Problem Could Not be Cleared. . . 109

Other Printing Problems................... 109

Printing Is Too Slow.....................109

Printing Slows Down Dramatically During

Continuous Printing.....................109

PostScript Printer Driver Problems............110

Printer Does Not Print While Using

PostScript Printer Driver................. 110

Printer Does Not Print Correctly While

Using PostScript Printer Driver.............110

Print Quality Is Poor While Using PostScript

Printer Driver......................... 110

Printing Is Too Slow While Using PostScript

Printer Driver......................... 110

Other Problems..........................110

Slight Electric Shock when Touching the

Printer...............................110

Operation Sounds Are Loud...............111

Forgot Your Password....................111

Application Is Blocked by a Firewall (for

Windows Only)........................111

User's Guide

Contents

Appendix

Technical Specications....................112

Printer Interface

Wi-Fi Specications.....................113

Ethernet Specications...................113

Security Protocol.......................113

Supported

Dimensions...........................114

Electrical Specications..................114

Environmental

System Requirements....................115

Font Information.........................116

Available Fonts for PostScript..............116

Available Fonts for PCL..................117

List of Symbol Sets......................119

Regulatory Information....................124

Standards and Approvals................. 124

German Blue Angel.....................125

Restrictions on Copying..................125

Saving Power............................125

Saving Power - Control Panel..............125

Transporting the Printer....................126

Installing the Optional Units.................127

Optional Paper Cassette Unit Code..........127

Installing the Optional Paper Cassette Units. . . 127

Where to Get Help........................132

Technical Support Web Site................132

Contacting Epson Support................133

Specications

ird

....................112

...................113

Party Services.............114

Specications

..............115

User's Guide

About This Manual

Introduction of Manuals

e latest versions of the following manuals are available from the Epson support website.

http://www.epson.eu/Support (Europe)

http://support.epson.net/ (outside Europe)

❏ Important Safety Instructions (paper manual)

Provides you with instructions to ensure the safe use of this printer. is manual may not be included depending on model and region.

❏ Start Here (paper manual)

Provides you with information on setting up the printer and installing the

soware.

❏ User's Guide (PDF manual)

is manual. Provides overall information and instructions on using the printer, and on solving problems.

❏ Network Guide (PDF manual)

Provides information on network settings and solving problems when using the printer on a network.

❏ Administrator's Guide (PDF manual)

Provides network administrators with information on management and printer settings.

As well as the manuals above, check the various types of help information available from the Epson applications.

Marks and Symbols

Caution:

Instructions that must be followed carefully to avoid bodily injury.

Important:

Instructions that must be observed to avoid damage to your equipment.

Note:

Provides complementary and reference information.

Related Information

Links to related sections.

Descriptions Used in this Manual

❏ Screenshots of the printer driver screens are from Windows 8.1 or Mac OS X v10.10.x. e content displayed on

the screens varies depending on the model and situation.

User's Guide

About This Manual

❏ Illustrations of the printer used in this manual are examples only. Although there may be slight dierences

depending on the model, the method of operation is the same.

❏ Some of the menu items on the LCD screen vary depending on the model and settings.

Operating System References

Windows

In this manual, terms such as "Windows 8.1", "Windows 8", "Windows 7", "Windows Vista", "Windows XP", "Windows Server 2012 R2", "Windows Server 2012", "Windows Server 2008 R2", "Windows Server 2008", "Windows Server 2003 R2", and "Windows Server 2003" refer to the following operating systems. Additionally, "Windows" is used to refer to all versions.

❏ Microso

❏

Microso

❏ Microso

Mac OS X

In this manual, "Mac OS X v10.10.x" refers to OS X Yosemite, "Mac OS X v10.9.x" refers to OS X Mavericks, and "Mac OS X v10.8.x" refers to OS X Mountain Lion. Additionally, "Mac OS X" is used to refer to "Mac OS X v10.10.x", "Mac OS X v10.9.x", "Mac OS X v10.8.x", "Mac OS X v10.7.x", and "Mac OS X v10.6.8".

Wi n d o w s® 8.1 operating system

Wi n d o w s® 8 operating system

Wi n d o w s® 7 operating system

Wi n d o w s Vist a® operating system

Wi n d o w s® XP operating system

Wi n d o w s® XP Professional x64 Edition operating system

Wi n d o w s Se r ver® 2012 R2 operating system

Wi n d o w s Se r ver® 2012 operating system

Wi n d o w s Se r ver® 2008 R2 operating system

Wi n d o w s Se r ver® 2008 operating system

Wi n d o w s Se r ver® 2003 R2 operating system

Wi n d o w s Se r ver® 2003 operating system

User's Guide

Important Instructions

Safety Instructions

Read and follow these instructions to ensure safe use of this printer. Make sure you keep this manual for future reference. Also, be sure to follow all warnings and instructions marked on the printer.

❏ Use only the power cord supplied with the printer and do not use the cord with any other equipment. Use of

other cords with this printer or the use of the supplied power cord with other equipment may result in re or electric shock.

❏ Be sure your AC power cord meets the relevant local safety standard.

❏ Never disassemble, modify, or attempt to repair the power cord, plug, printer unit, or options by yourself, except

as specically explained in the printer's manuals.

❏ Unplug the printer and refer servicing to qualied service personnel under the following conditions:

e power cord or plug is damaged; liquid has entered the printer; the printer has been dropped or the casing damaged; the printer does not operate normally or exhibits a distinct change in performance. Do not adjust controls that are not covered by the operating instructions.

❏ Place the printer near a wall outlet where the plug can be easily unplugged.

❏ Do not place or store the printer outdoors, near excessive dirt or dust, water, heat sources, or in locations

subject to shocks, vibrations, high temperature or humidity.

❏ Take care not to spill liquid on the printer and not to handle the printer with wet hands.

❏ Keep the printer at least 22 cm away from cardiac pacemakers. Radio waves from this printer may adversely

aect the operation of cardiac pacemakers.

❏ If the LCD screen is damaged, contact your dealer. If the liquid crystal solution gets on your hands, wash them

thoroughly with soap and water. If the liquid crystal solution gets into your eyes, ush them immediately with water. If discomfort or vision problems remain

❏ e printer is heavy and should not be lied or carried by less than two people. When liing the printer, two or

more people should assume the correct positions as shown below.

a thorough

aer

ushing,

see a doctor immediately.

User's Guide

Important Instructions

❏ Be careful when you handle used ink cartridges, as there may be some ink around the ink supply port.

❏ If ink gets on your skin, wash the area thoroughly with soap and water.

❏ If ink gets into your eyes, ush them immediately with water. If discomfort or vision problems continue aer

a thorough ushing, see a doctor immediately.

❏ If ink gets into your mouth, see a doctor right away.

❏ Do not disassemble the ink cartridge and the maintenance box; otherwise ink may get into your eyes or on your

skin.

❏ Do not shake ink cartridges too vigorously; otherwise ink may leak from the cartridge.

❏ Keep ink cartridges and maintenance box out of the reach of children.

Printer Advisories and Warnings

Read and follow these instructions to avoid damaging the printer or your property. Make sure you keep this manual for future reference.

Advisories and Warnings for Setting Up/Using the Printer

❏ Do not block or cover the vents and openings in the printer.

❏ Use only the type of power source indicated on the printer's label.

❏ Avoid using outlets on the same circuit as photocopiers or air control systems that regularly switch on and

❏ Avoid electrical outlets controlled by wall switches or automatic timers.

❏ Keep the entire computer system away from potential sources of electromagnetic interference, such as

loudspeakers or the base units of cordless telephones.

❏ e power-supply cords should be placed to avoid abrasions, cuts, fraying, crimping, and kinking. Do not place

objects on top of the power-supply cords and do not allow the power-supply cords to be stepped on or run over. Be particularly careful to keep all the power-supply cords straight at the ends and the points where they enter and leave the transformer.

❏ If you use an extension cord with the printer, make sure that the total ampere rating of the devices plugged into

the extension cord does not exceed the cord's ampere rating. Also, make sure that the total ampere rating of all devices plugged into the wall outlet does not exceed the wall outlet's ampere rating.

❏ If you plan to use the printer in Germany, the building installation must be protected by a 10 or 16 amp circuit

breaker to provide adequate short-circuit protection and over-current protection for the printer.

❏ When connecting the printer to a computer or other device with a cable, ensure the correct orientation of the

connectors. Each connector has only one correct orientation. Inserting a connector in the wrong orientation may damage both devices connected by the cable.

o.

❏ Place the printer on a at, stable surface that extends beyond the base of the printer in all directions. e printer

will not operate properly if it is tilted at an angle.

❏ When storing or transporting the printer, avoid tilting it, placing it vertically, or turning it upside down;

otherwise ink may leak.

❏ Leave enough space in front of the printer for the paper to be fully ejected.

❏ Avoid places subject to rapid changes in temperature and humidity. Also, keep the printer away from direct

sunlight, strong light, or heat sources.

❏ Do not insert objects through the slots in the printer.

User's Guide

Important Instructions

❏ Do not put your hand inside the printer during printing.

❏ Do not touch the white

❏ Do not use aerosol products that contain ammable gases inside or around the printer. Doing so may cause re.

❏ Do not move the print head by hand; otherwise, you may damage the printer.

❏ Always turn the printer o using the

until the

❏ Before transporting the printer, make sure that the print head is in the home (far right) position and the ink

cartridges are in place.

❏ If you are not going to use the printer for a long period, be sure to unplug the power cord from the electrical

outlet.

light stops ashing.

cable inside the printer.

at

button. Do not unplug the printer or turn o the power at the outlet

Advisories and Warnings for Using the Printer with a Wireless Connection

❏ Radio waves from this printer may negatively aect the operation of medical electronic equipment, causing

them to malfunction. When using this printer inside medical facilities or near medical equipment, follow directions from the authorized personnel representing the medical facilities, and follow all posted warnings and directions on the medical equipment.

❏ Radio waves from this printer may negatively aect the operation of automatically controlled devices such as

automatic doors or automatically controlled devices, follow all posted warnings and directions on these devices.

alarms, and could lead to accidents due to malfunction. When using this printer near

re

Advisories and Warnings for Using the LCD Screen

❏ e LCD screen may contain a few small bright or dark spots, and because of its features it may have an uneven

brightness. ese are normal and do not indicate that it is damaged in any way.

❏ Only use a dry,

❏ e exterior cover of the LCD screen could break if it receives a heavy impact. Contact your dealer if the

screen's surface chips or cracks, and do not touch or attempt to remove the broken pieces.

cloth for cleaning. Do not use liquid or chemical cleaners.

so

Protecting Your Personal Information

When you give the printer to someone else or dispose of it, erase all the personal information stored in the printer's memory by selecting Menu > System Administration > Restore Default Settings > Clear All Data and Settings on the control panel.

User's Guide

Administrator Settings

Locking the Printer Settings Using an Administrator's Password

You can set an administrator's password to lock the printer settings so that they cannot be changed by other users. You can lock the following settings.

System Administration

You cannot change settings without entering the password. is password is also required when you make settings using Web Cong or EpsonNet Cong.

Important:

Do not forget the password. If you forget the password, contact Epson support.

Enter Menu from the home screen.

2. Select Admin Settings > Admin Password.

3. Select Register, and then enter a password.

4. Enter the password again.

5. Select Lock Setting, and then enable it.

Unlocking the Printer Settings

1. Enter Menu from the home screen.

2. Select Admin Settings.

Enter the administrator's password.

4. Select Lock Setting, and then disable it.

User's Guide

Printer Basics

Part Names and Functions

Edge guides Feeds the paper straight into the printer. Slide to the

edges of the paper.

Front paper feed slot (B2) Load one sheet of paper at a time by hand.

Paper cassette 1 (C1) Loads paper.

Paper cassette 2 to 3 (C2 to C3) Optional paper cassette units. Loads paper.

User's Guide

Printer Basics

Edge guides Feeds the paper straight into the printer. Slide to the

edges of the paper.

Paper support Supports loaded paper.

Rear paper feed (B1) Loads paper.

Feeder guard Prevents foreign substance from entering the printer.

Usually keep this guard closed.

Output tray Holds the ejected paper.

Edge guides Feeds the paper straight into the printer. Slide to the

edges of the paper.

Paper cassette Loads paper.

User's Guide

Printer Basics

Control panel Operates the printer.

Print head Fires ink.

Front cover (A) Open when replacing an ink cartridge and removing

jammed paper inside the printer.

NFC tag Pass a smart device over this tag to print from the smart

device directly.

Rear cover 2 (D2) Remove when replacing maintenance rollers or

removing jammed paper.

AC inlet Connects the power cord.

User's Guide

Rear cover 1 (D1) Open when replacing the maintenance rollers or

Rear cover (E) Covers for the optional paper cassette units. Open

Service USB port USB port for future use.

USB port Connects a USB cable.

LAN port Connects a LAN cable.

Control Panel

Printer Basics

removing jammed paper.

when replacing the maintenance rollers or removing jammed paper.

Do not remove the sticker.

Buttons and Lights

Error Flashes or turns on when an error occurs.

Turns the printer on or o.

Unplug the power cord when the power light is o.

Displays the Paper Setup screen. You can select the paper size and paper type settings for each paper source.

Data Flashes while the printer is processing data.

Turns on when there are queued jobs.

- Displays menus and messages.

Returns to the previous screen.

l, u, r, d

, OK Press l, u, r, and d to select menus. Press OK to conrm your selection or run the selected

feature.

When entering characters, press

Stops the current operation.

When entering characters, press this button to change the character type.

l, u, r

, and d to select characters.

User's Guide

Printer Basics

Icons Displayed on the LCD Screen

e following icons are displayed on the LCD screen depending on the printer's status.

Turns on while the printer is connected to a wired (Ethernet) network.

Turns on when the wired (Ethernet) network is disabled and an Ethernet cable is not connected.

Turns on while the printer is connected to a wireless (Wi-Fi) network. The number of bars indicates the signal strength of the connection. The more bars there are, the stronger the connection.

Indicates a problem with the printer's wireless (Wi-Fi) network connection, or that the printer is searching for a wireless (Wi-Fi) network connection.

Indicates that the printer is connected to a wireless (Wi-Fi) network in Ad Hoc mode.

Indicates that the printer is connected to a wireless (Wi-Fi) network in Wi-Fi Direct mode.

Indicates that the printer is connected to a wireless (Wi-Fi) network in Simple AP mode.

Turns on when Eco Mode is enabled.

Menu Options

Specify the length of time in seconds that must elapse before ending USB communication with a computer after the printer receives a print job from a PostScript printer driver or PCL printer driver. If the job ending is not clearly dened from a PostScript printer driver or PCL printer driver, it can cause endless USB communication. When this occurs, the printer ends communication after the not want to end communication.

Feeds paper from the rear paper feed on a priority basis.

Feeds paper from the paper source set as A4 size when there is no paper source set as Letter, or feeds from the paper source set as Letter size when there is no paper source set as A4.

are multiple paper sources available, paper is fed from the paper source with paper settings that match the print job.

type settings in Paper Setup and the print settings do not match.

specied

time has elapsed. Enter 0 (zero) if you do

Auto Error Solver Select an action to perform when a 2-sided printing error or a memory full

error occurs.

❏ 2-sided printing error

Enabled: If a 2-sided job is sent when there is no paper available that supports 2-sided printing, the printer displays an error message, and then automatically prints on only one side of the paper.

Disabled: The printer displays an error message and cancels printing.

❏ Memory full error

Enabled: If the printer's memory becomes full while printing, the printer displays an error message, and then prints only the part of the data that the printer could process.

Disabled: The printer displays an error message and cancels printing.

PC Connection via USB

Paper Feed Assist Mode

Select whether the printer allows an access from USB connected computer. Disable this function to restrict printing and scanning that was not sent through a network connection.

Prevents multiple sheets of paper from feeding through paper cassette 1 at the same time, but the printing speed is slower.

User's Guide

Printer Basics

Menu Settings and Explanations

Common Settings Sleep Timer Select the time period before the printer enters sleep mode (energy saving

mode) when no operations are performed.

The LCD screen turns black when the set time passes.

Power O Timer You can adjust the time before power management is applied. Any increase

will aect the product’s energy eciency. Please consider the environment before making any change.

LCD Contrast Adjust the brightness of the LCD screen.

Date/Time Settings Date/Time Enter the current date and time.

Daylight Saving Tim e

Time Dierence Enter the time dierence between your local time and

Language Select the display language.

Scroll Speed Select the scroll speed of the LCD screen.

Network Settings Network Status Displays or prints the network settings and connection status.

Wi-Fi Setup Wi-Fi Setup Wizard See the Network Guide for more details.

Push Button Setup (WPS)

PIN Code Setup (WPS)

Wi-Fi Auto Connect

Disable Wi-Fi You may be able to resolve network problems by

Wi-Fi Direct Setup See the Network Guide for more details.

Select to set summer time.

UTC (Coordinated Universal Time).

disabling the Wi-Fi settings or making the Wi-Fi settings again. See the Network Guide for more details.

Epson Connect Services

Google Cloud Print Services

Connection Check Checks the status of the network connection and prints the network

connection check report. If there are any problems with the connection, see the check report to solve the problem.

Advanced Setup See the Network Guide for more details.

You can suspend or resume the Epson Connect or Google Could Print service, or cancel using the services (restore the default settings).

See the Epson Connect portal website for more details.

https://www.epsonconnect.com/

http://www.epsonconnect.eu (Europe only)

User's Guide

Menu Settings and Explanations

Printer Basics

Universal Print Settings

Security Settings Delete All

Eco Mode The following Eco mode settings are available. When these settings are disabled, the settings made in

These print settings are applied when printing from an external device without using the printer driver, or when printing from a PostScript printer driver or PCL printer driver.

Top Oset Adjust the top or left margin of the paper.

Left Oset

Top Oset in Back Adjust the top margin or left margin for the back of the page when

performing 2-sided printing.

Left Oset in Back

Check Paper Width Checks the paper width before the printer starts printing. This prevents

printing beyond the edges of the paper when the paper size setting is not correct, but the printing time may be little longer.

Dry Time Select the drying time when performing 2-sided printing.

Skip Blank Page Skips blank pages in the print data automatically.

PDL Print Conguration

Condential

Common Settings are applied.

Jobs

See the list of menus in PDL Print Conguration.

Deletes all saved condential jobs.

Sleep Timer Select the time period before the printer enters sleep mode (energy saving

mode) when no operations are performed.

The LCD screen turns black when the set time passes.

Power O Timer Select the time period before the printer turns o automatically.

Clear Internal Memory Data

Restore Default Settings

Deletes the print settings for a PostScript printer driver and a PCL printer driver.

Select Clear All to delete all of the data for a PostScript printer driver and a PCL printer driver that is saved in the printer's memory.

Resets the selected settings to their defaults.

Related Information

& “PDL Print Conguration” on page 23

PDL Print Conguration

Select Menu > System Administration > Universal Print Settings > PDL Print Conguration from the home screen.

User's Guide

Menu Settings and Explanations

Printer Basics

Common Settings

PCL Menu Font Source Resident: Select to use a preinstalled font on the printer.

Paper Size Select the paper size.

Paper Type Select the paper type.

Orientation Select the printing direction.

Quality Select the print quality.

Ink Save Mode Conserves ink by reducing the print density.

Print Order Last Page on Top: Prints from the rst page of a le.

First Page on Top: Prints from the last page of a le.

Number of Copies

Binding Margin Select the binding position.

Auto Paper Ejection

2-Sided Printing Performs 2-sided printing.

Set the number of copies.

Ejects paper automatically when printing is stopped during a print job.

Download: Select to use a font you have downloaded.

Font Number Select the default font number for the default font source. The available number

varies depending on the settings you made.

Pitch Set the default font pitch if the font is scalable and of xed-pitch. You can select from

0.44 to 99.99 cpi (characters per inch), in 0.01 increments.

This item may not appear depending on the font source or font number settings.

Height Set the default font height if the font is scalable and proportional. You can select

from 4.00 to 999.75 points, in 0.25 increments.

This item may not appear depending on the font source or font number settings.

Symbol Set Select the default symbol set. If the font that you selected in the font source and the

font number setting is not available in the new symbol set setting, the font source and the font number settings are automatically replaced with the default value, IBM- US.

Form Set the number of lines for the selected paper size and orientation. This also causes a

line spacing (VMI) change, and the new VMI value is stored in the printer. This means that later changes in the page size or orientation settings cause changes in the Form value based on the stored VMI.

CR Function Select the line feed command when printing with a driver from a specic operating

system.

LF Function

Paper Source Assign

Set the assignment for the paper source select command. When 4 selected, the commands are set as compatible with the HP LaserJet 4. When 4K is selected, the commands are set as compatible with the HP LaserJet 4000, 5000, and 8000. When

5S is selected, the commands are set as compatible with the HP LaserJet 5S.

User's Guide

Printer Basics

Menu Settings and Explanations

PS3 Menu Error Sheet Prints a sheet showing the error status when any PostScript errors occur while

printing and any errors occur while printing a PDF

Coloration Select the color mode for PostScript printing.

Binary Enable this feature when printing data that contains binary images. This settings is

only available when the printer is connected to the network.

The application may send the binary data even if the printer driver setting is set to ASCII, but you can print the data when this feature is enabled.

le.

PDF Page Size

Select the paper size when printing a PDF le. If Auto is selected, the paper size is determined based on the size of the rst page that is printed.

User's Guide

Loading Paper

Paper Handling Precautions

❏ Read the instruction sheets supplied with the paper.

❏ Fan and align the edges of the paper before loading. Do not fan or curl photo paper. Doing so may damage the

printable side.

❏ If the paper is curled, atten it or curl it slightly in the opposite direction before loading. Printing on curled

paper may cause paper jams and smears on the printout.

❏ Do not use paper that is wavy, torn, cut, folded, damp, too thick, too thin, or paper that has stickers stuck to it.

Using these types of paper causes paper jams and smears on the printout.

❏ Make sure you are using long-grain paper. If you are not sure what type of paper you are using, check the paper

packaging or contact the manufacturer to conrm the paper specications.

❏ Fan and align the edges of the envelopes before loading. When the stacked envelopes are

press them down to atten them before loading.

pued

up with air,

❏ Do not use envelopes that are curled or folded. Using these envelopes causes paper jams and smears on the

printout.

❏ Do not use envelopes with adhesive surfaces on the aps or window envelopes.

❏ Avoid using envelopes that are too thin, as they may curl during printing.

Related Information

& “Printer Specications” on page 112

User's Guide

Loading Paper

Available Paper and Capacities

Epson recommends using genuine Epson paper to ensure high-quality printouts.

Genuine Epson Paper

Note:

Genuine Epson paper is not available when printing with the Epson universal printer driver.

Media Name Size Loading Capacity (Sheets) 2-Sided

Paper Cassette 1

Paper Cassette 2 to 3

Rear Paper Feed

Front Paper Feed Slot

Printing

Epson Bright White Ink Jet Paper

Epson Ultra Glossy Photo Paper

Epson Premium Glossy Photo Paper

Epson Premium Semigloss Photo Paper

Epson Photo Paper Glossy

Epson Matte PaperHeavyweight

A4 400 400 50 1

A4, 13×18 cm (5×7 in.), 10×15 cm (4×6 in.)

A4, 13×20 cm (5×8 in.), 13×18 cm (5×7 in.), 16:9 wide size (102×181 mm), 10×15 cm (4×6 in.)

A4, 10×15 cm (4×6 in.)

A4, 13×18 cm (5×7 in.), 10×15 cm (4×6 in.)

A4 ––20––

––20––

Auto, Manual

Epson Photo Quality Ink Jet Paper

* Only use the rear paper feed to print 2-sided print jobs manually. You can load up to 30 sheets for paper with one side

already printed.

A4 ––70––

Note:

❏ e availability of paper varies by location. For the latest information on paper available in your area, contact Epson

support.

❏ When printing on genuine Epson paper at a user dened size, only Standard or Normal print quality settings are

available. Although some printer drivers allow you to select a better print quality, the printouts are printed using Standard or Normal.

User's Guide

Loading Paper

Commercially Available Paper

Media Name Size Loading Capacity (Sheets or Envelopes) 2-Sided

Paper Cassette 1

Paper Cassette 2 to 3

Rear Paper Feed

Front Paper Feed Slot

Printing

Plain paper

Copy paper

Letterhead

Recycled paper

Color paper

Preprinted paper

Plain paper

Copy paper

Letterhead

Recycled paper

Color paper

Preprinted paper

Legal, Letter, A4, B5, A5

B6, A6 , Executive

Half Letter – – 80 1

User Dened (mm)

55×127 to 105×148,

215.9×355.6 to

215.9×1200

User Dened (mm)

105×148 to 148×210

Up to the line under the symbol inside the edge guide.

Up to the line under

the symbol inside the edge guide.

--1–Manual

––801

–801

80 1 Auto,

Manual

*1*2

User Dened (mm)

148×210 to

215.9×355.6

Thick paper Letter, A4, B5,

Envelope Envelope #10,

Envelope DL, Envelope C6

Envelope C4––1––

*1 Only use the rear paper feed to print 2-sided print jobs manually.

*2 You can load up to 30 sheets for paper with one side already printed.

*3 You can load up to 5 sheets for paper with one side already printed.

––801Auto,

––10–

––10––

Related Information

“Part Names and Functions” on page 14

“Technical Support Web Site” on page 132

Manual

*1*2

User's Guide

Loading Paper

List of Paper Types

To obtain optimum printing results, select the paper type that suits the paper.

Media Name Media Type

Control Panel Printer Driver PostScript Printer

Driver

Copy paper, Plain paper

Epson Bright White Ink Jet Paper

Letterhead Letterhead Letterhead Letterhead Letterhead

Recycled paper Recycled Recycled Recycled Recycled

Color paper Color Color Color Color

Preprinted paper Preprinted Preprinted Preprinted Preprinted

Epson Ultra Glossy Photo Paper

Epson Premium Glossy Photo Paper

Epson Premium Semigloss Photo Paper

Epson Photo Paper Glossy

plain papers plain papers Plain Plain

Ultra Glossy Epson Ultra Glossy Epson Ultra Glossy -

Prem. Glossy Epson Premium

Glossy

Prem. Semigloss Epson Premium

Semigloss

Glossy Photo Paper Glossy Photo Paper Glossy -

Epson Premium Glossy

Epson Premium Semigloss

Epson Universal Printer Driver

Epson Matte PaperHeavyweight

Epson Photo Quality Ink Jet Paper

Thick paper Thick-Paper Thick-Paper Thick Thick

Envelope Envelope Envelope Envelope Envelope

Matte Epson Matte Epson Matte -

User's Guide

Loading Paper

Loading Paper in the Paper Cassette

1. Check that the printer is not operating, and then pull out the paper cassette.

2. Slide the front edge guide to its maximum position, and then slide the side edge guides to adjust to the paper size you want to use.

Load paper with the printable side facing down, and then slide the front edge guide to the edge of the paper.

User's Guide

Loading Paper

Important:

Do not load more than the maximum number of sheets specied for the paper. For plain paper, do not load

above the line indicated by the

4. Check that the paper size label matches the size of the paper loaded in the paper cassette. If it does not match, remove the holder and change the paper size indicated on the label.

symbol on the edge guide.

Insert the paper cassette all the way.

6. On the control panel, set the size and type of the paper you loaded in the paper cassette.

Note: You can also display the paper size and paper type settings screen by selecting Menu > Paper Setup.

7. Slide out the output tray.

Related Information

& “Paper Handling Precautions” on page 26 & “Available Paper and Capacities” on page 27

User's Guide

Loading Paper

Loading Paper in the Rear Paper Feed

1. Open the feeder guard and pull out the paper support.

2. Slide the edge guides.

Load paper at the center of the rear paper feed with the printable side facing up.

Important:

❏ Do not load more than the maximum number of sheets specied for the paper. For plain paper, do not load

above the line just under the

❏ Load paper short edge rst. However, when you have set the long edge as the width of the user dened size,

load paper long edge

rst.

symbol inside the edge guide.

User's Guide

❏ Envelopes

❏ Pre-punched paper

Loading Paper

Note:

You can use pre-punched paper under the following conditions. Automatic 2-sided printing is not available for prepunched paper.

❏ Loading capacity: One sheet

❏ Available size: A4, B5, A5, A6, B6, Letter, Legal

❏ Binding holes: Do not load paper with the binding holes at the top or the bottom.

Adjust the print position of your le to avoid printing over the holes.

4. Slide the edge guides to the edges of the paper.

5. On the control panel, set the size and type of the paper you loaded in the rear paper feed.

Note: You can also display the paper size and paper type settings screen by selecting Menu > Paper Setup.

User's Guide

Loading Paper

6. Slide out the output tray.

Note:

Return the remaining paper to its package. If you leave it in the printer, the paper may curl or the print quality may decline.

Related Information

& “Paper Handling Precautions” on page 26 & “Available Paper and Capacities” on page 27

Loading Paper in the Front Paper Feed Slot

You can only load one sheet of paper in the front paper feed slot. Because the front paper feed slot also serves the output tray, you cannot load paper during printing.

Important:

You can load paper with a thickness of 0.08 to 0.11 mm in the front paper feed slot. However, even if the thickness is within this range, some papers may not be fed correctly depending on their hardness.

1. Slide out the output tray.

User's Guide

Loading Paper

2. Slide the edge guides to adjust to the paper size you want to use.

3. Insert the paper with the printable side facing down until the printer partially pulls in the paper.

Important:

❏ Load paper short edge rst. However, when you have set the long edge as the width of the user dened size,

load paper long edge rst.

❏ Keep the paper straight to prevent it from being fed askew.

Note:

If the printer does not pull in the paper, load it again.

Related Information

& “Paper Handling Precautions” on page 26 & “Available Paper and Capacities” on page 27

User's Guide

Printing

Printing from a Computer

If you cannot change some of the printer driver settings, they may have been restricted by the administrator. Contact your printer administrator for assistance.

Printing Basics - Windows

Note:

❏ See the online help for explanations of the setting items. Right-click an item, and then click Help.

❏ Operations may

1. Load paper in the printer.

2. Open the le you want to print.

Select Print or Print Setup from the File menu.

4. Select your printer.

5. Select Preferences or Properties to access the printer driver window.

depending on the application. See the application's help for details.

dier

Make the following settings.

❏ Paper Source: Select the paper source in which you loaded the paper.

❏ Document Size: Select the paper size you loaded in the printer.

User's Guide

Printing

❏ Orientation: Select the orientation you set in the application.

❏ Paper Type: Select the type of paper you loaded.

❏ Color: Select Grayscale when you want to print in black or shades of gray.

Note:

❏ If you are printing high-density data on plain paper, letterhead, or preprinted paper, select Standard-Vivid as the

Quality setting to make your printout vivid.

❏ When printing on envelopes, select Landscape as the Orientation setting.

7. Click OK to close the printer driver window.

8. Click Print.

Related Information

“Available Paper and Capacities” on page 27

“Loading Paper in the Paper Cassette” on page 30

& “Loading Paper in the Rear Paper Feed” on page 32 & “Loading Paper in the Front Paper Feed Slot” on page 34 & “List of Paper Types” on page 29

Printing Basics - Mac OS X

Note:

Operations dier depending on the application. See the application's help for details.

1. Load paper in the printer.

2. Open the le you want to print.

User's Guide

Printing

3. Select Print from the File menu or another command to access the print dialog.

If necessary, click Show Details or

to expand the print window.

4. Make the following settings.

❏ Printer: Select your printer.

❏ Presets: Select when you want to use the registered settings.

❏ Paper Size: Select the paper size you loaded in the printer.

❏ Orientation: Select the orientation you set in the application.

Note:

When printing on envelopes, select landscape orientation.

User's Guide

5. Select Print Settings from the pop-up menu.

Printing

Note:

On Mac OS X v10.8.x or later, if the Print Settings menu is not displayed, the Epson printer driver has not been installed correctly.

Select System Preferences from the printer, and then add the printer again. See the following to add a printer.

http://epson.sn

menu > Printers & Scanners (or Print & Scan, Print & Fax), remove the

6. Make the following settings.

❏ Paper Source: Select the paper source in which you loaded the paper.

❏ Media Type: Select the type of paper you loaded.

❏ Grayscale: Select to print in black or shades of gray.

Note: If you are printing high-density data on plain paper, letterhead, or preprinted paper, select Normal-Vivid as the Print Quality setting to make your printout vivid.

7. Click Print.

Related Information

“Available Paper and Capacities” on page 27

“Loading Paper in the Paper Cassette” on page 30

“Loading Paper in the Rear Paper Feed” on page 32

& & “Loading Paper in the Front Paper Feed Slot” on page 34 & “List of Paper Types” on page 29

User's Guide

Printing

Printing on 2-Sides

You can use either of the following methods to print on both sides of the paper.

❏ Automatic 2-sided printing

❏ Manual 2-sided printing (for Windows only)

When the printer has nished printing the rst side, ip the paper over to print on the other side.

You can also print a booklet that can be created by folding the printout. (For Windows only)

Note:

❏ If you do not use paper that is suitable for 2-sided printing, the print quality may decline and paper jams may occur.

❏ Depending on the paper and the data, ink may bleed through to the other side of the paper.

Related Information

“Available Paper and Capacities” on page 27

Printing on 2-Sides - Windows

Note:

❏ Manual 2-sided printing is available when EPSON Status Monitor 3 is enabled. If EPSON Status Monitor 3 is disabled,

access the printer driver, click Extended Settings on the Maintenance tab, and then select Enable EPSON Status Monitor 3.

❏ Manual 2-sided printing may not be available when the printer is accessed over a network or is used as a shared printer.

1. Load paper in the printer.

2. Open the le you want to print.

3. Access the printer driver window.

4. Select Auto (Long-edge binding), Auto (Short-edge binding), Manual (Long-edge binding), or Manual (Short-edge binding) from 2-Sided Printing on the Main tab.

5. Click Settings, make the appropriate settings, and then click OK.

Note: To print a folded booklet, select Booklet.

User's Guide

Printing

6. Click Print Density, select the document type from Select Document Type, and then click OK.

printer driver automatically sets the Adjustments options for that document type.

e

Note: ❏ Printing may be slow depending on the combination of options selected for Select Document Type in the Print

Density Adjustment window and for Quality on the Main tab.

❏ For manual 2-sided printing, the Print Density Adjustment setting is not available.

7. Set the other items on the Main and More Options tabs as necessary, and then click OK.

8. Click Print.

For manual 2-sided printing, when the rst side has nished printing, a pop-up window is displayed on the computer. Follow the on-screen instructions.

Related Information

& “Loading Paper in the Paper Cassette” on page 30 & “Loading Paper in the Rear Paper Feed” on page 32 & “Loading Paper in the Front Paper Feed Slot” on page 34 & “Printing Basics - Windows” on page 36

Printing on 2-Sides - Mac OS X

1. Load paper in the printer.

2. Open the le you want to print.

Access the print dialog.

4. Select Two-sided Printing Settings from the pop-up menu.

5. Select the bindings and Document Type.

Note:

❏ Printing may be slow depending on the Document Type setting.

❏ If you are printing high-density data such as photos or graphs, select Text & Gr aphics or Tex t & P h otos as th e

Document Type setting. If scung occurs or the image bleeds through to the reverse side, adjust the print density and ink drying time by clicking the arrow mark next to Adjustments.

6. Set the other items as necessary.

7. Click Print.

Related Information

& “Loading Paper in the Paper Cassette” on page 30 & “Loading Paper in the Rear Paper Feed” on page 32 & “Loading Paper in the Front Paper Feed Slot” on page 34 & “Printing Basics - Mac OS X” on page 37

User's Guide

Printing

Printing Several Pages on One Sheet

You can print two or four pages of data on a single sheet of paper.

Printing Several Pages on One Sheet - Windows

1. Load paper in the printer.

2. Open the

3. Access the printer driver window.

4. Select 2-Up or 4-Up as the Multi-Page setting on the Main tab.

5. Click Page Order, make the appropriate settings, and then click OK to close the window.

6. Set the other items on the Main and More Options tabs as necessary, and then click OK.

7. Click Print.

Related Information

you want to print.

le

Printing Several Pages on One Sheet - Mac OS X

1. Load paper in the printer.

2. Open the le you want to print.

Access the print dialog.

4. Select Layout from the pop-up menu.

User's Guide

Printing

5. Set the number of pages in Pages per Sheet, the Layout Direction (page order), and Border.

6. Set the other items as necessary.

7. Click Print.

Related Information

Printing to Fit the Paper Size

You can print to t the paper size you loaded in the printer.

Printing to Fit the Paper Size - Windows

Load paper in the printer.

2. Open the le you want to print.

3. Access the printer driver window.

Make the following settings on the More Options tab.

❏ Document Size: Select the paper size you set in the application.

❏ Output Paper: Select the paper size you loaded in the printer.

Fit to Page is selected automatically.

Note: If you want to print a reduced image at the center of the page, select Center.

Set the other items on the Main and More Options tabs as necessary, and then click OK.

6. Click Print.

User's Guide

Printing

Related Information

Printing to Fit the Paper Size - Mac OS X

Load paper in the printer.

2. Open the le you want to print.

3. Access the print dialog.

4. Select the size of the paper you set in the application as the Paper Size setting.

5. Select Paper Handling from the pop-up menu.

6. Select Scale to t paper size.

7. Select the paper size you loaded in the printer as the Destination Paper Size setting.

8. Set the other items as necessary.

9. Click Print.

Related Information

& “Loading Paper in the Paper Cassette” on page 30 & “Loading Paper in the Rear Paper Feed” on page 32

“Loading Paper in the Front Paper Feed Slot” on page 34

“Printing Basics - Mac OS X” on page 37

Printing Multiple Files Together (for Windows Only)

Job Arranger Lite allows you to combine several les created by dierent applications and print them as a single print job. You can specify the print settings for combined les, such as layout, print order, and orientation.

Note:

To op e n a Print Project saved in Job Arranger Lite, click Job Arranger Lite on the printer driver's Maintenance tab. Next, select Open from the File menu to select the le. e extension of the saved les is "ecl".

User's Guide

Printing

1. Load paper in the printer.

2. Open the le you want to print.

3. Access the printer driver window.

4. Select Job Arranger Lite on the Main tab.

5. Click OK to close the printer driver window.

Click Print.

e Job Arranger Lite window is displayed and the print job is added to the Print Project.

7. With the Job Arranger Lite window opened, open the le that you want to combine with the current le, and then repeat steps 3 to 6.

Note:

If you close the Job Arranger Lite window, the unsaved Print Project is deleted. To print later, select Save from the File menu.

Select the Layout and Edit menus in Job Arranger Lite to edit the Print Project as necessary.

9. Select Print from the File menu.

Related Information

“Loading Paper in the Paper Cassette” on page 30

& & “Loading Paper in the Rear Paper Feed” on page 32 & “Loading Paper in the Front Paper Feed Slot” on page 34 & “Printing Basics - Windows” on page 36

Printing One Image on Multiple Sheets to Create a Poster (for Windows Only)

is feature allows you to print one image on multiple sheets of paper. You can create a larger poster by taping them together.

1. Load paper in the printer.

2. Open the

3. Access the printer driver window.

you want to print.

le

User's Guide

Printing

4. Select 2x1 Poster, 2x2 Poster, 3x3 Poster, or 4x4 Poster from Multi-Page on the Main tab.

5. Click Settings, make the appropriate settings, and then click OK.

Set the other items on the Main and More Options tabs as necessary, and then click OK.

7. Click Print.

Related Information

Making Posters Using Overlapping Alignment Marks

Here is an example of how to make a poster when 2x2 Poster is selected, and Overlapping Alignment Marks is selected in Print Cutting Guides.

User's Guide

Printing

1. Prepare Sheet 1 and Sheet 2. Cut o the margins of Sheet 1 along the vertical blue line through the center of the top and bottom cross marks.

2. Place the edge of Sheet 1 on top of Sheet 2 and align the cross marks, then temporarily tape the two sheets together from the back.

User's Guide

Printing

3. Cut the taped sheets in two along the vertical red line through the alignment markers (this time, the line to the

of the cross marks).

le

4. Tape the sheets together from the back.

5. Repeat steps 1 to 4 to tape Sheet 3 and Sheet 4 together.

User's Guide

Printing

6. Cut o the margins of Sheet 1 and Sheet 2 along the horizontal blue line through the center of the le and right side cross marks.

7. Place the edge of Sheet 1 and Sheet 2 on top of Sheet 3 and Sheet 4 and align the cross marks, and then temporarily tape them together from the back.

User's Guide

Printing

8. Cut the taped sheets in two along the horizontal red line through the alignment markers (this time, the line above the cross marks).

9. Tape the sheets together from the back.

User's Guide

Printing

10. Cut o the remaining margins along the outer guide.

Printing Using Advanced Features

is section introduces a variety of additional layout and printing features available on the printer driver.

Related Information

& “Windows Printer Driver” on page 87 & “Mac OS X Printer Driver” on page 88

Adding a Printing Preset to Print Easily

If you create your own preset of frequently used print settings on the printer driver, you can print easily by selecting the preset from the list.

User's Guide

Printing

Windows

To add your own preset, set items such as the Document Size and Paper Type on the Main or More Options tab, and then click Add/Remove Presets in Printing Presets.

Note:

To delete an added preset, click Add/Remove Presets, select the preset name you want to delete from the list, and then delete it.

Mac OS X

Access the print dialog. To add your own preset, set items such as the Paper Size and Media Type, and then save the current settings as the preset in the Presets setting.

Note:

To delete an added preset, click Presets > Show Presets, select the preset name you want to delete from the list, and then delete it.

Printing a Reduced or Enlarged Document

You can reduce or enlarge the size of a document by a specic percentage.

Windows

Set the Document Size on the More Options tab. Select Reduce/Enlarge Document, Zoom to, and then enter a percentage.

Mac OS X

Select Page Setup from the File menu. Select the settings for Format For and Paper Size, and then enter a percentage in Scale. Close the window, and then print following the basic printing instructions.

Adjusting the Print Color

You can adjust the colors used in the print job.

PhotoEnhance produces sharper images and more vivid colors by automatically adjusting the contrast, saturation, and brightness of the original image data.

Note:

❏ ese adjustments are not applied to the original data.

❏ PhotoEnhance adjusts the color by analyzing the location of the subject.

the subject by reducing, enlarging, cropping, or rotating the image, the color may change unexpectedly. If the image is out of focus, the tone may be unnatural. If the color is changed or becomes unnatural, print in a mode other than PhotoEnhance.

erefore,

if you have changed the location of

Windows

Select the method of color correction from Color Correction on the More Options tab.

If you select Automatic, the colors are automatically adjusted to match the paper type and print quality settings. If you select Custom and click Advanced, you can make your own settings.

Mac OS X

Access the print dialog. Select Color Matching from the pop-up menu, and then select EPSON Color Controls. Select Color Options from the pop-up menu, and then select one of the available options. Click the arrow next to Advanced Settings and make the appropriate settings.

User's Guide

Printing

Printing an Anti-Copy Pattern (for Windows Only)

You can print documents with invisible letters such as "Copy". ese letters appear when the document is photocopied so that the copies can be distinguished from the original. You can also add your own anti-copy pattern.

Note:

is feature is only available when the following settings are selected.

❏ Paper Type: plain papers

❏ Quality: Standard

❏ Auto 2-sided printing: Disabled

❏ Color Correction: Automatic

❏ Short Grain Paper: Disabled

Click Watermark Features on the More Options tab, and then select an anti-copy pattern. Click Settings to change details such as the size and density.

Printing a Watermark (for Windows Only)

You can print a watermark such as "Condential" on your printouts. You can also add your own watermark.

Click Watermark Features on the More Options tab, and then select a watermark. Click Settings to change details such as the density and position of the watermark.

Printing a Header and Footer (for Windows Only)

You can print information such as a user name and printing date as headers or footers.

Click Watermark Features in the More Options tab, and then select Header/Footer. Click Settings and select necessary items from the drop-down list.

Setting a Password for a Print Job (for Windows Only)

You can set a password for a print job to prevent printing until the password is entered on the printer's control panel.

Select Condential Job on the More Options tab, and then enter a password.

To print the job, enter Menu from the printer's home screen, and then select Condential Job. Select the job and enter the password.

Printing Using a PostScript Printer Driver

Printing Using a PostScript Printer Driver - Windows

1. Load paper in the printer.

2. Open the le you want to print.

3. Access the PostScript printer driver window.

User's Guide

Printing

4. Select the orientation you set in the application as the Orientation on the Layout tab.

5. Make the following settings on the Paper/Quality tab.

❏ Paper Source: Select the paper source in which you loaded the paper.

❏ Media: Select the type of paper you loaded.

User's Guide

Printing

6. Click Advanced, make the following settings, and then click OK.

❏ Paper Size: Select the paper size you loaded in the printer.

❏ Color Mode: Select to print in full color or monochrome.

7. Click OK.

8. Click Print.

Printing Using a PostScript Printer Driver - Mac OS X

1. Load paper in the printer.

2. Open the le you want to print.

User's Guide

3. Access the print dialog.

Printing

4. Make the following settings.

❏ Printer: Select your printer.

❏ Paper Size: Select the paper size you loaded in the printer.

❏ Orientation: Select the orientation you set in the application.

Select Paper Feed from the pop-up menu, and then select the paper source in which you loaded the paper.

User's Guide

Printing

6. Select Printer Features from the pop-up menu, select Quality as the Feature Sets setting, and then select the type of paper you loaded as the MediaType setting.

7. Select Color as the Feature Sets setting, and then select the setting for Color Mode.

8. Click Print.

User's Guide

Printing

Setting Items for the PostScript Printer Driver

Note:

e availability of these settings varies by model.

Color Mode Select whether to print in color or in monochrome.

Ink Save Mode Conserves ink by reducing the print density.

Rotate by 180º Rotates the data 180 degrees before printing.

Printing from Smart Devices

Using Epson iPrint

Epson iPrint is an application that allows you to print photos, documents, and Web pages from a smart device such as a smartphone or tablet. You can use either local print, printing from a smart device that is connected to the same wireless network as your printer, or remote print, printing externally over the internet. To use remote print, register your printer in the Epson Connect service.

You can install Epson iPrint on your smart device from the following URL or QR code.

http://ipr.to/c

Using Epson iPrint

Start Epson iPrint from your smart device and select the item you want to use from the home screen.

User's Guide

Printing

e following screens are subject to change without notice.

Home screen displayed when the application is started.

Displays information on how to setup the printer and a FAQ.

Displays the screen where you can select the printer and make printer settings. Once you have selected the printer, you do not need to select it again from the next time.

Select what you want to print such as photos, documents, and web pages.

Displays the screen to make print settings such as paper size and paper type.

Displays photos and documents you selected.

Starts printing.

Note:

To print from the document menu using iPhone, iPad, and iPod touch running iOS, start Epson iPrint aer transferring the document you want to print using the

sharing function in iTunes.

le

Related Information

& “Epson Connect Service” on page 85

Printing by Touching Smart Devices to the NFC Tag

Even if the printer and your smart device are not connected, you can connect them automatically and print by touching the NFC antenna of a smart device running Android 4.0 or later and that supports NFC (Near Filed Communication) to the printer's NFC tag.

e location of the NFC antenna varies depending on the smart device. See the documentation provided with your smart device for more details.

User's Guide

Printing

Important:

❏ Make sure that Wi-Fi Direct Simple AP mode is running. See the Network Guide for more details.

❏ Make sure that Epson iPrint is installed on your smart device. If not, touch the NFC tag antenna of the smart

device to the printer's NFC tag and install it.

Note:

❏ If the printer does not communicate with the smart device even aer touching it to the tag, try adjusting the position of

the smart device and touch it to the tag again.

❏ If there are obstacles such as metal between the printer's NFC tag and the NFC antenna of the smart device, the printer

may not be able to communicate with the smart device.

❏ is feature uses Wi-Fi Direct Simple AP mode to connect to the printer. You can connect up to four devices to the printer

at the same time. See the Network Guide for more details.

❏ If you have changed the password for the Wi-Fi Direct Simple AP mode, you cannot use this feature. Restore the initial

password to use this feature.

1. Load paper in the printer.

2. Touch the NFC antenna of your smart device to the printer's NFC tag.

Epson iPrint starts.

3. On the Epson iPrint home screen, touch the NFC antenna of your smart device to the printer's NFC tag again.

printer and the smart device are connected.

e

4. Display the image you want to print.

5. Touch the NFC antenna of your smart device to the printer's NFC tag again.

Printing starts.

Related Information

& “Loading Paper in the Paper Cassette” on page 30 & “Loading Paper in the Rear Paper Feed” on page 32 & “Loading Paper in the Front Paper Feed Slot” on page 34

User's Guide

Printing

Using AirPrint

AirPrint allows you to wirelessly print to your AirPrint-enabled printer from your iOS device using the latest version of iOS and from your Mac OS X v10.7.x or later.

Note:

See the AirPrint page of the Apple website for more details.

1. Load paper in the printer.

2. Connect your device to the same wireless network that your printer is using.

Print from your device to your printer.

Related Information

& “Loading Paper in the Paper Cassette” on page 30 & “Loading Paper in the Rear Paper Feed” on page 32 & “Loading Paper in the Front Paper Feed Slot” on page 34 & “System Administration” on page 20

Canceling Printing

Note:

❏ In Windows, you cannot cancel a print job from the computer once it has been completely sent to the printer. In this case,

cancel the print job by using the printer's control panel.

❏ When printing several pages from Mac OS X, you cannot cancel all of the jobs by using the control panel. In this case,

cancel the print job from the computer.

❏ If you have sent a print job from Mac OS X v10.6.8 through the network, you may not be able to cancel printing from the

computer. In this case, cancel the print job by using the printer's control panel. You need to change settings in Web Cong to cancel printing from the computer. See the Network Guide for more details.

Canceling Printing - Printer Button

Press the y button to cancel the print job in progress.

User's Guide

Printing

Canceling Printing - Windows

1. Access the printer driver window.

2. Select the Maintenance tab.

Click Print Queue.

4. Right-click on the job you want to cancel and then select Cancel.

Related Information

& “Windows Printer Driver” on page 87

Canceling Printing - Mac OS X

1. Click the printer icon in the Dock.

2. Select the job you want to cancel.

3. Cancel the job.

❏ Mac OS X v10.8.x or later

Click

❏ Mac OS X v10.6.8 to v10.7.x

Click Delete.

next to the progress meter.

User's Guide

Replacing Ink Cartridges and Other Consumables

Checking the Status of the Remaining Ink and the Maintenance Box

You can check the approximate ink levels and the approximate service life of the maintenance box from the control panel or the computer.

Checking the Status of the Remaining Ink and the Maintenance Box

- Control Panel

1. Enter Menu from the home screen.

2. Select Ink Levels.

Note:

e indicator on the far right indicates the available space in the maintenance box.

Checking the Status of the Remaining Ink and the Maintenance Box

- Windows

1. Access the printer driver window.

2. Click EPSON Status Monitor 3 on the Maintenance tab, and then click Details.

Note: If EPSON Status Monitor 3 is disabled, click Extended Settings on the Maintenance tab, and then select Enable EPSON Status Monitor 3.

Related Information

& “Windows Printer Driver” on page 87

Checking the Status of the Remaining Ink and the Maintenance Box

- Mac OS X

1. Select System Preferences from the menu > Printers & Scanners (or Print & Scan, Print & Fax), and then select the printer.

2. Click Options & Supplies > Utility > Open Printer Utility.

3. Click EPSON Status Monitor.

User's Guide

Replacing Ink Cartridges and Other Consumables

Ink Cartridge Codes

Epson recommends the use of genuine Epson ink cartridges. Epson cannot guarantee the quality or reliability of non-genuine ink. e use of non-genuine ink may cause damage that is not covered by Epson’s warranties, and under certain circumstances, may cause erratic printer behavior. Information about non-genuine ink levels may not be displayed.

e following are the codes for genuine Epson ink cartridges.

Product Black Cyan Magenta Yellow

WF-6090 T9081

T9071

WF-6091 T7521 T7522 T7523 T7524

Note:

❏ Not all cartridges are available in all regions.

❏ For users in Europe, visit the following website for information on Epson's ink cartridge yields.

http://www.epson.eu/pageyield

T9082

T9072

T9083

T9073

Ink Cartridge Handling Precautions

Read the following instructions before replacing ink cartridges.

Handling precautions

❏ Store ink cartridges at normal room temperature and keep them away from direct sunlight.

❏ Epson recommends using the ink cartridge before the date printed on the package.

❏ For best results, use up ink cartridge within six months of installation.

T9084

T9074

❏ Aer bringing an ink cartridge inside from a cold storage site, allow it to warm up at room temperature for at

least three hours before using it.

❏ Do not touch the sections shown in the illustration. Doing so may prevent normal operation and printing.

❏ Install all ink cartridges; otherwise you cannot print.

❏ Do not move the print head by hand; otherwise, you may damage the printer.

❏ Do not turn o the printer during ink charging. If the ink charging is incomplete, you may not be able to print.

❏ Do not leave the printer with the ink cartridges removed; otherwise, ink remaining in the print head nozzles

may dry out and you may not be able to print.

User's Guide

Replacing Ink Cartridges and Other Consumables

❏ If you need to remove an ink cartridge temporarily, make sure you protect the ink supply area from dirt and

dust. Store the ink cartridge in the same environment as the printer. Because the ink supply port is equipped with a valve designed to contain the release of excess ink, there is no need to supply your own covers or plugs.

❏ Removed ink cartridges may have ink around the ink supply port, so be careful not to get any ink on the

surrounding area when removing the cartridges.

❏ is printer uses ink cartridges equipped with a green chip that monitors information such as the amount of

remaining ink for each cartridge. is means that even if the cartridge is removed from the printer before it is expended, you can still use the cartridge aer reinserting it back into the printer.

❏ To ensure you receive premium print quality and to help protect your print head, a variable ink safety reserve

remains in the cartridge when your printer indicates to replace the cartridge. e yields quoted for you do not include this reserve.

❏ Although the ink cartridges may contain recycled materials, this does not aect printer function or

performance.

❏

Specications

❏ Do not disassemble or remodel the ink cartridge, otherwise you may not be able to print normally.

❏ Do not drop or knock it against hard objects; otherwise, the ink may leak.

❏ You cannot use the cartridges that came with the printer for the replacement.

❏ Quoted yields may vary depending on the images that you are printing, the paper type that you are using, the

frequency of your prints and environmental conditions such as temperature.

Consumption of Ink

❏ To maintain optimum print head performance, some ink is consumed from all cartridges not only during

printing but also during maintenance operations such as print head cleaning.

❏ When printing in monochrome or grayscale, color inks instead of black ink may be used depending on the

paper type or print quality settings. is is because a mixture of color inks is used to create black.

❏ e ink in the ink cartridges supplied with your printer is partly used during initial setup. In order to produce

high quality printouts, the print head in your printer will be fully charged with ink. is one-o process consumes a quantity of ink and therefore these cartridges may print fewer pages compared to subsequent ink cartridges.

and appearance of the ink cartridge are subject to change without prior notice for improvement.

Replacing Ink Cartridges

1. Open the front cover.

User's Guide

Replacing Ink Cartridges and Other Consumables

2. Push the ink cartridge that you want to replace.

ink cartridge will pop out slightly.

e

3. Remove the ink cartridge from the printer.

4. Remove the new ink cartridge from its package.

Important:

Do not touch the sections shown in the illustration. Doing so may prevent normal operation and printing.

User's Guide

Replacing Ink Cartridges and Other Consumables

5. Shake the ink cartridge horizontally for 5 seconds, moving it back and forth about 10 cm 15 times.

6. Insert the cartridge into the printer until it clicks.

Note:

If Cartridge Check is displayed on the control panel, press the OK button to check if the cartridges are installed correctly.

7. Close the front cover.

Related Information

& “Ink Cartridge Codes” on page 64 & “Ink Cartridge Handling Precautions” on page 64

Maintenance Box Code

Epson recommends the use of a genuine Epson maintenance box.

following is the code for the genuine Epson maintenance box.

e

T6712

Maintenance Box Handling Precautions

Read the following instructions before replacing the maintenance box.

❏ Do not touch the green chip on the side of the maintenance box. Doing so may prevent normal operation and

printing.

❏ Do not remove the lm on the top of the box; otherwise ink may leak.

❏ Do not tilt the used maintenance box until aer it is sealed in the plastic bag; otherwise ink may leak.

❏ Keep the maintenance box out of direct sunlight.

❏ Do not replace the maintenance box during printing; otherwise, ink may leak.

❏ Do not reuse a maintenance box which has been removed and le detached for a long period. Ink inside the box

will have

solidied

and no more ink can be absorbed.

Replacing a Maintenance Box

In some print cycles a very small amount of surplus ink may be collected in the maintenance box. To prevent ink leakage from the maintenance box, the printer is designed to stop printing when the absorbing capacity of the

User's Guide

Replacing Ink Cartridges and Other Consumables

maintenance box has reached its limit. Whether and how oen this is required will vary according to the number of pages you print, the type of material that you print and the number of cleaning cycles that the printer performs. Replace the maintenance box when you are promoted to do so. e Epson Status Monitor, your LCD, or lights on the control panel will advise you when this part needs replacing. e need for replacement of the box does not mean that your printer has ceased to operate in accordance with its cover the cost of this replacement. It is a user-serviceable part.

1. Remove the new maintenance box from its package.

Important:

specications. e

Epson warranty does not

❏ Do not touch the green chip on the side of the maintenance box. Doing so may prevent normal operation

and printing.

❏ Do not remove the lm on the top of the box; otherwise ink may leak.

Note:

A transparent bag for the used maintenance box is provided with the new maintenance box.

2. Open rear cover 1.

Remove the used maintenance box.

4. Put the used maintenance box in the transparent bag that came with the new maintenance box and seal the bag shut.

User's Guide

Replacing Ink Cartridges and Other Consumables

Important:

❏ Do not remove the lm on the top of the maintenance box.

❏ Do not tilt the used maintenance box until aer it is sealed in the plastic bag; otherwise ink may leak.

5. Insert the new maintenance box all the way into the printer.

6. Close rear cover 1.

Related Information

& “Maintenance Box Code” on page 67 & “Maintenance Box Handling Precautions” on page 67

Maintenance Rollers Codes

Epson recommends the use of genuine Epson maintenance rollers.

following are the codes.

e

Maintenance rollers of paper cassette 1: S210046

Maintenance rollers of paper cassette 2 to 3: S210047

Replacing Maintenance Rollers in Paper Cassette 1

ere are two places for replacing the maintenance rollers: on the back of the printer (two rollers) and on the paper cassette (one roller).

1. Remove the new maintenance rollers from their package.

Important:

❏ e maintenance rollers for the paper cassette 1 and paper cassette 2 to 3 are dierent. Check the direction

of the arrow at the center of the maintenance rollers, and make sure the maintenance rollers are the ones for paper cassette 1. If you attach the wrong rollers, the printer may not feed the paper.

❏ Be careful not to stain the surface of the maintenance rollers. If dust collects on the surface of the

maintenance rollers, clean the rollers by using a so and dry cloth.

2. Turn o the printer by pressing the P button, and then unplug the power cord.

User's Guide

3. Pull out paper cassette 1.

Replacing Ink Cartridges and Other Consumables

4. Turn the printer around, and open rear cover 1.

5. Pull out rear cover 2.

User's Guide

Replacing Ink Cartridges and Other Consumables

6. Remove the cover inside the back of the printer.

7. Slide out the two used maintenance rollers, and remove them.

8. Insert two new maintenance rollers until they click into place.

Note:

Insert the maintenance rollers by rolling them so that you can insert them smoothly.

9. Reattach the cover inside the back of the printer.

User's Guide

Replacing Ink Cartridges and Other Consumables

10. Hold up the maintenance roller for the paper cassette by rolling it up, and then remove it.

11. Install the new maintenance roller in the paper cassette.

12. Hold down the maintenance roller

13. Insert rear cover 2, close rear cover 1, and then insert the paper cassette.

14. Turn on the printer, select Menu>Maintenance>Maintenance Roller Information>Reset Maintenance Roller Counter, and then select the paper cassette in which you replaced the maintenance rollers.

Related Information

& “Maintenance Rollers Codes” on page 69

rmly.

User's Guide

Replacing Ink Cartridges and Other Consumables

Replacing Maintenance Rollers in Paper Cassette 2 to 3

ere are two places for replacing the maintenance rollers: on the back of the printer (two rollers) and on the paper cassette (one roller).

Remove the new maintenance rollers from their package.

Important:

❏ e maintenance rollers for the paper cassette 1 and paper cassette 2 to 3 are dierent. Check the direction

of arrow on the center of the maintenance rollers, and make sure the maintenance rollers are the ones for paper cassette 2 to 3. If you attach the wrong rollers, the printer may not feed the paper.

❏ Be careful not to stain the surface of the maintenance rollers. If the dust collects on the surface of the

maintenance rollers, clean the rollers by using a

2. Turn o the printer by pressing the P button, and then unplug the power cord.

3. Pull out the paper cassette for which you want to replace the rollers.

and dry cloth.

so

User's Guide

Replacing Ink Cartridges and Other Consumables

4. Turn the printer around, and then open the printer's rear cover.

5. Remove the screws by a screwdriver and remove the cover on the rear of inside the printer.

6. Slide out two used maintenance rollers, and remove both of them.

7. Insert two new maintenance rollers until they click into place.

User's Guide

Replacing Ink Cartridges and Other Consumables

Note:

Insert the maintenance rollers by rolling them so that you can insert them smoothly.

8. Hold up the maintenance roller for the paper cassette by rolling it up, and then remove it.

9. Install the new maintenance roller in the paper cassette.

10.

Hold down the maintenance roller rmly.

11. Fasten the screws to attach the cover back on, and close the rear cover.

12. Insert the paper cassette.

13. Turn on the printer, select Menu > Maintenance > Maintenance Roller Information > Reset Maintenance Roller Counter, and then select the paper cassette in which you replaced the maintenance rollers.

User's Guide

Replacing Ink Cartridges and Other Consumables

Related Information

& “Maintenance Rollers Codes” on page 69

Temporarily Printing with Black Ink

When color ink is expended and black ink still remains, you can use the following settings to continue printing for a short time using only black ink.

❏ Type of paper: plain papers, Envelope

❏ Color: Grayscale

❏ EPSON Status Monitor 3: Enabled (for Windows only)

Because this feature is only available for approximately ve days, replace the expended ink cartridge as soon as possible.

Note:

❏ If EPSON Status Monitor 3 is disabled, access the printer driver, click Extended Settings on the Maintenance tab, and

then select Enable EPSON Status Monitor 3.

❏ e available period varies depending on the usage conditions.

User's Guide

Replacing Ink Cartridges and Other Consumables

Temporarily Printing with Black Ink - Windows

1. When the following window is displayed, cancel printing.

Note:

If you cannot cancel printing from the computer, cancel using the printer's control panel.

2. Access the printer driver window.

3. Select plain papers or Envelope as the Paper Type setting on the Main tab.

Select Grayscale.

5. Set the other items on the Main and More Options tabs as necessary, and then click OK.

6. Click Print.

7. Click Print in Black in the window displayed.

User's Guide

Replacing Ink Cartridges and Other Consumables

Related Information

Temporarily Printing with Black Ink - Mac OS X

Note: To use this feature through a network, connect with Bonjour.

1. Click the printer icon in the Dock.

Cancel the job.

Note:

If you cannot cancel printing from the computer, cancel using the printer's control panel.

Select System Preferences from the then select the printer. Click Options & Supplies > Options (or Driver).

4. Select On as the Permit temporary black printing setting.

5. Access the print dialog.

6. Select Print Settings from the pop-up menu.

7. Select plain papers or Envelope as the Media Type setting.

Select Grayscale.

9. Set the other items as necessary.

10. Click Print.

Related Information

“Canceling Printing - Mac OS X” on page 62

“Loading Paper in the Paper Cassette” on page 30

“Loading Paper in the Rear Paper Feed” on page 32

“Loading Paper in the Front Paper Feed Slot” on page 34

& “Printing Basics - Mac OS X” on page 37

menu > Printers & Scanners (or Print & Scan, Print & Fax), and

Conserving Black Ink when the Black Ink Is Low (for Windows Only)

When black ink is running low and there is enough color ink remaining, you can use a mixture of color inks to create black. You can continue printing while preparing a replacement black ink cartridge.

feature is only available when you select the following settings in the printer driver.

is

User's Guide

Replacing Ink Cartridges and Other Consumables

❏ Paper Type: plain papers

❏ Quality: Standard

❏ EPSON Status Monitor 3: Enabled

Note:

❏ If EPSON Status Monitor 3 is disabled, access the printer driver, click Extended Settings on the Maintenance tab, and

then select Enable EPSON Status Monitor 3.

❏ Composite black looks slightly dierent from pure black. In addition, the print speed is reduced.

❏ To maintain the quality of the print head, black ink is also consumed.

Options Description

Yes Select to use a mixture of color inks to create black. This window is displayed the next time

you print a similar job.

No Select to continue using the remaining black ink. This window is displayed the next time

you print a similar job.

Disable this feature Select to continue using the remaining black ink. This window is not displayed until you

replace the black ink cartridge and it runs low again.

User's Guide

Improving Print Quality

Checking and Cleaning the Print Head

If the nozzles are clogged, the printouts become faint, there is visible banding, or unexpected colors appear. When print quality has declined, use the nozzle check feature and check if the nozzles are clogged. If the nozzles are clogged, clean the print head. You can perform a nozzle check and head cleaning from the control panel or the computer.

Important:

Do not open the front cover or turn o the printer during head cleaning. If the head cleaning is incomplete, you may not be able to print.

Note:

❏ Because print head cleaning uses some ink, clean the print head only if quality declines.

❏ When ink is low, you may not be able to clean the print head. Replace the ink cartridge rst.

❏ If print quality has not improved aer repeating nozzle check and head cleaning about four times, wait for at least six

hours without printing, and then run the nozzle check again and repeat the head cleaning if necessary. We recommend to turn o the printer. If print quality has still not improved, contact Epson support.

❏ To prevent the print head from drying out, always turn the printer o by pressing the

❏ To keep the print head operating at its best, we recommend printing a few pages on a regular basis.

button.

Checking and Cleaning the Print Head - Control Panel

1. Load A4-size plain paper in the printer.

2. Enter Menu from the home screen.

3. Select Maintenance > Print Head Nozzle Check.

4. Follow the on-screen instructions to print the nozzle check pattern.

Note:

e test pattern may vary by model.

5. Compare the printed check pattern with the sample shown below.

❏ All lines are printed: e print head nozzles are not clogged. Close the nozzle check feature.

User's Guide

Improving Print Quality

❏ ere are broken lines or missing segments: e print head nozzles may be clogged. Go to the next step.

Follow the on-screen instructions to clean the print head.

7. When cleaning is nished, print the nozzle check pattern again. Repeat cleaning and printing the pattern until all lines are printed completely.

Related Information

& “Loading Paper in the Paper Cassette” on page 30 & “Loading Paper in the Rear Paper Feed” on page 32

Checking and Cleaning the Print Head - Windows

1. Load A4-size plain paper in the printer.

Access the printer driver window.

Click Nozzle Check on the Maintenance tab.

4. Follow the on-screen instructions.

Related Information

& “Loading Paper in the Paper Cassette” on page 30 & “Loading Paper in the Rear Paper Feed” on page 32 & “Windows Printer Driver” on page 87

Checking and Cleaning the Print Head - Mac OS X

1. Load A4-size plain paper in the printer.

2. Select System Preferences from the then select the printer.

menu > Printers & Scanners (or Print & Scan, Print & Fax), and

3. Click Options & Supplies > Utility > Open Printer Utility.

4. Click Nozzle Check.

Follow the on-screen instructions.

Related Information

& “Loading Paper in the Paper Cassette” on page 30

User's Guide

Improving Print Quality

& “Loading Paper in the Rear Paper Feed” on page 32

Aligning the Print Head

If you notice a misalignment of vertical lines or blurred images, align the print head.

1. Load A4-size plain paper in the printer.

Enter Menu from the home screen.

3. Select Maintenance > Print Head Alignment.

4. Select one of the alignment menus and follow the on-screen instructions to print a pattern for alignment.

❏ Ruled Line Alignment: Select this if vertical lines look misaligned.

❏ Vertical Alignment: Select this if your printouts look blurry.

❏ Horizontal Alignment: Select this if you see horizontal banding at regular intervals.

Follow the on-screen instructions to align the print head.

Note:

e alignment patterns may be slightly dierent from the actual ones, but the procedures are the same.

❏ Ruled Line Alignment: Find and enter the number for the pattern that has the least misaligned vertical line.

❏ Vertical Alignment: Find and enter the number for the most solid pattern in each group.

User's Guide

Improving Print Quality

❏ Horizontal Alignment: Find and enter the number for the least separated or overlapping pattern in each

group.

Related Information

& “Loading Paper in the Paper Cassette” on page 30 & “Loading Paper in the Rear Paper Feed” on page 32

Improving Horizontal Streaks

If your printouts contain horizontal banding or streaks aer trying Print Head Cleaning and Horizontal Alignment, nely tune the horizontal alignment.

1. Enter Menu from the home screen.

2. Select Maintenance > Improve Horizontal Streaks.

3. Follow the on-screen instructions to perform horizontal alignment.

Cleaning the Paper Path

When the printouts are smeared or scued, clean the roller inside.

Important:

Do not use tissue paper to clean the inside of the printer. e print head nozzles may be clogged with lint.

1. Make sure there is no dust or stains on the scanner glass and the document cover.

Load A4-size plain paper in the paper source that you want to clean.

3. Enter Menu from the home screen.

4. Select Maintenance > Paper Guide Cleaning.

5. Select the paper source, and then follow the on-screen instructions to clean the paper path.

User's Guide

Improving Print Quality

6. Repeat this procedure until the paper is not smeared with ink. If the printouts are still smeared or scued, clean the other paper sources.

Note:

If the rear paper feed has a paper feed problem and if you have a cleaning sheet that came with Epson genuine paper, you may be able to solve the paper feed problem by using the cleaning sheet instead of using A4-size plain paper. When using the cleaning sheet, load the sheet in the rear paper feed following the instructions that came with the sheet. If a paper setup screen is displayed, leave the paper settings as they are.

Related Information

& “Loading Paper in the Rear Paper Feed” on page 32

User's Guide

Applications and Network Service Information

Epson Connect Service

By using Epson Connect service available on the Internet, you can print from your smartphone, tablet PC, or laptop, anytime and practically anywhere.

e features available on the Internet are as follows.

Email Print Epson iPrint remote print Scan to Cloud Remote Print Driver

✓✓ – ✓

See the Epson Connect portal website for details.

https://www.epsonconnect.com/

http://www.epsonconnect.eu (Europe only)

Web Cong

Web Cong is an application that runs on a Web browser, such as Internet Explorer and Chrome, from a computer or smart device. You can conrm the printer status or change the network service and printer settings. To use Web Cong, connect the computer or device to the same network as the printer.

Note:

e following browsers are supported.

OS Browser

Windows XP or later

Mac OS X v10.5.8 or later

iOS

Android 2.3 or later Default browser

Internet Explorer 8 or later, Firefox

, Firefox*, Chrome

Safari

, Chrome

Chrome OS

*Use the latest version.

Default browser

Running Web Cong on a Web Browser

1. Check the printer's IP address.

Select Menu > Network Status > Wi r e d L A N/Wi- F i S ta tus from the home screen, and then check the printer's IP address.

User's Guide

Applications and Network Service Information

2. Launch a Web browser from a computer or smart device, and then enter the printer's IP address.

Format:

IPv4: http://the printer's IP address/

IPv6: http://[the printer's IP address]/

Examples:

IPv4: http://192.168.100.201/

IPv6: http://[2001:db8::1000:1]/

Note:

Using the smart device, you can also run Web Cong from the maintenance screen of Epson iPrint.

Related Information

& “Using Epson iPrint” on page 58

Running Web Cong on Windows

When connecting a computer to the printer using WSD, follow the steps below to run Web Cong.

Access the devices and printers screen in Windows.

❏ Windows 8.1/Windows 8/Windows Server 2012 R2/Windows Server 2012

Select Desktop > Settings > Control Panel > Vi ew d ev i ces a n d pri n t e rs in Hardware and Sound (or Hardware).

❏ Windows 7/Windows Server 2008 R2

Click the start button, and select Control Panel > Vi e w d e vic e s and p ri nte r s in Hardware and Sound.

❏ Windows Vista/Windows Server 2008

Click the start button, and select Control Panel > Printers in Hardware and Sound.

2. Right-click on your printer and select Properties.

Select the Web Service tab and click the URL.

Running Web Cong on Mac OS X

1. Select System Preferences from the menu > Printers & Scanners (or Print & Scan, Print & Fax), and then select the printer.

Click Options & Supplies> Show Printer Webpage.

User's Guide

Applications and Network Service Information

Necessary Applications

Windows Printer Driver

printer driver is an application that controls the printer according to the print commands from other

e applications. Making settings on the printer driver provides the best printing results. You can also check the status of the printer or keep it in top operating condition using the printer driver utility.

Note: You can change the language of the printer driver. Select the language you want to use from the Language setting on the Maintenance tab.

Accessing the printer driver from applications

To make settings that apply only to the application you are using, access from that application.

Select Print or Print Setup from the File menu. Select your printer, and then click Preferences or Properties.

Note:

Operations dier depending on the application. See the application's help for details.

Accessing the printer driver from the control panel

To make settings that apply to all of the applications, access from the control panel.

❏ Windows 8.1/Windows 8/Windows Server 2012 R2/Windows Server 2012

Select Desktop > Settings > Control Panel > Vi ew d ev i ces a n d pri n t e rs in Hardware and Sound. Right-click on your printer, or press and hold it and then select Printing preferences.

❏ Windows 7/Windows Server 2008 R2

Click the start button, and select Control Panel > Vi e w d e vic e s and p ri nte r s in Hardware and Sound. Right- click on your printer and select Printing preferences.

❏ Windows Vista/Windows Server 2008

Click the start button, and select Control Panel > Printers in Hardware and Sound. Right-click on your printer and select Select printing preferences.

❏ Windows XP/Windows Server 2003 R2/Windows Server 2003

Click the start button, and select Control Panel > Printers and Other Hardware > Printers and Faxes. Right- click on your printer and select Printing preferences.

Starting the utility

Access the printer driver window. Click the Maintenance tab.

Restricting Settings for the Windows Printer Driver

You can lock some settings of the printer driver so that other users cannot change them.

Note:

Log on to your computer as an administrator.

1. Open the Optional Settings tab in printer properties.

❏ Windows 8.1/Windows 8/Windows Server 2012

User's Guide

Applications and Network Service Information

Select Desktop > Settings > Control Panel > Vi ew d ev i ces a n d pri n t e rs in Hardware and Sound. Right- click on your printer, or press and hold it and then select Printer properties. Click the Optional Settings tab.

❏ Windows 7/Windows Server 2008 R2

Click the start button, and select Control Panel > Vi e w d e vic e s and p ri nte r s in Hardware and Sound. Right-click on your printer, and then select Printer properties. Click the Optional Settings tab.

❏ Windows Vista/Windows Server 2008

Click the start button, and select Control Panel > Printers in Hardware and Sound. Right-click on your printer, and then select Properties. Click the Optional Settings tab.

❏ Windows XP/Windows Server 2003 R2/Windows Server 2003

Click the start button, and select Control Panel > Printers and Other Hardware > Printers and Faxes. Right-click on your printer, and then select Properties. Click the Optional Settings tab.

2. Click Driver Settings.

3. Select the feature that you want to restrict.

See the online help for explanations of the setting items.

4. Click OK.

Making Operation Settings for the Windows Printer Driver

You can make settings such as enabling EPSON Status Monitor 3.

1. Access the printer driver window.

2. Click Extended Settings on the Maintenance tab.

3. Make the appropriate settings, and then click OK.

See the online help for explanations of the setting items.

Related Information

“Windows Printer Driver” on page 87

Mac OS X Printer Driver

e printer driver is an application that controls the printer according to the print commands from other applications. Making settings on the printer driver provides the best printing results. You can also check the status of the printer or keep it in top operating condition using the printer driver utility.

Accessing the printer driver from applications

Select Print from the File menu. If necessary, click Show Details (or

Note:

Operations dier depending on the application. See the application's help for details.

) to expand the print window.

User's Guide

Starting the utility

Applications and Network Service Information

Select System Preferences from the select the printer. Click Options & Supplies > Utility > Open Printer Utility.

menu > Printers & Scanners (or Print & Scan, Print & Fax), and then

Making Operation Settings for the Mac OS X Printer Driver

You can make various settings such as skipping blank pages and enabling/disabling high speed printing.

Select System Preferences from the then select the printer. Click Options & Supplies > Options (or Driver).

2. Make the appropriate settings, and then click OK.

❏ ick paper and envelopes: Prevents the ink from smearing when printing on thick paper. However, the

print speed may be slower.

❏ Skip Blank Page: Avoids printing blank pages.

❏ Quiet Mode: Prints quietly. However, the print speed may be slower.

❏ Permit temporary black printing: Prints only with black ink temporarily.

❏ High Speed Printing: Prints when the print head moves in both directions. e print speed is faster, but the

quality may decline.

❏ Wa rn i n g

Notications

: Allows the printer driver to display warning

menu > Printers & Scanners (or Print & Scan, Print & Fax), and

notications.

❏ Establish bidirectional communication: Usually, this should be set to On. Select O when acquiring the

printer information is impossible because the printer is shared with Windows computers on a network or for any other reason.

❏ Lower Cassette: Add the optional paper cassette units to the paper source.

Note:

e availability of these settings varies by model.

Related Information

& “Temporarily Printing with Black Ink” on page 76

E-Web Print (for Windows Only)

E-Web Print is an application that allows you to easily print web pages with various layouts. See the application's help for details. You can access the help from the E-Web Print menu on the E-Web Print tool bar.

Note:

Windows Server operating systems are not supported.

Starting

When you install E-Web Print, it is displayed in your browser. Click Print or Clip.

EPSON Software Updater

EPSON Soware Updater is an application that checks for new or updated soware on the internet and installs it. You can also update the printer's rmware and manual.

User's Guide

Applications and Network Service Information

Note:

Windows Server operating systems are not supported.

Starting on Windows

❏ Windows 8.1/Windows 8

Enter the application name in the search charm, and then select the displayed icon.

❏ Wi n d o w s 7/Wi n d ow s Vista / Wi ndows X P

Click the start button, and select All Programs (or Programs) > Epson Soware > EPSON Soware Updater.

Starting on Mac OS X

Select Go > Applications > Epson Soware > EPSON Soware Updater.

EpsonNet Cong

EpsonNet operations guide for EpsonNet

Starting on Windows

❏ Windows 8.1/Windows 8/Windows Server 2012 R2/Windows Server 2012

Enter the application name in the search charm, and then select the displayed icon.

❏ Except for Windows 8.1/Windows 8/Windows Server 2012 R2/Windows Server 2012

Click the start button, and select All Programs (or Programs) > EpsonNet > EpsonNet Cong V4 > EpsonNet

Cong

Starting on Mac OS X

Select Go > Applications > Epson

is an application that allows you to set the network interface addresses and protocols. See the

Cong

or the application's help for more details.

Cong

Soware

> EpsonNet > EpsonNet

Cong

V4 > EpsonNet

Cong

Uninstalling Applications

Note:

Log on to your computer as an administrator. Enter the administrator password if the computer prompts you.

Uninstalling Applications - Windows

1. Press the P button to turn o the printer.

2. Quit all running applications.

3. Open Control Panel:

❏ Windows 8.1/Windows 8/Windows Server 2012 R2/Windows Server 2012

Select Desktop > Settings > Control Panel.

❏ Except for Windows 8.1/Windows 8/Windows Server 2012 R2/Windows Server 2012

Click the start button and select Control Panel.

User's Guide

Applications and Network Service Information

4. Open Uninstall a program (or Add or Remove Programs):

❏ Windows 8.1/Windows 8/Windows 7/Windows Vista/Windows Server 2012 R2/Windows Server 2012/

Windows Server 2008 R2/Windows Server 2008

Select Uninstall a program in Programs.

❏ Windows XP/Windows Server 2003 R2/Windows Server 2003

Click Add or Remove Programs.

5. Select the application you want to uninstall.

6. Uninstall the applications:

❏ Windows 8.1/Windows 8/Windows 7/Windows Vista/Windows Server 2012 R2/Windows Server 2012/

Windows Server 2008 R2/Windows Server 2008

Click Uninstall/Change or Uninstall.

❏ Windows XP/Windows Server 2003 R2/Windows Server 2003

Click Change/Remove or Remove.

Note: If the User Account Control window is displayed, click Continue.

7. Follow the on-screen instructions.

Uninstalling Applications - Mac OS X

Download the Uninstaller using EPSON Soware Updater.

Once you have downloaded the Uninstaller, you do not need to download it again each time you uninstall the application.

2. Press the

3. To uninstall the printer driver, select System Preferences from the & Scan, Print & Fax), and then remove the printer from the enabled printers list.

4. Quit all running applications.

Select Go > Applications > Epson Soware > Uninstaller.

6. Select the application you want to uninstall, and then click Uninstall.

button to turn o the printer.

menu > Printers & Scanners (or Print

Important:

Uninstaller removes all drivers for Epson inkjet printers on the computer. If you use multiple Epson inkjet

e printers and you only want to delete some drivers, delete all of them rst, and then install the necessary printer driver again.

Note:

If you cannot nd the application you want to uninstall in the application list, you cannot uninstall using the Uninstaller. In this situation, select Go > Applications > Epson Soware, select the application you want to uninstall, and then drag it to the trash icon.

User's Guide

Applications and Network Service Information

Related Information

& “EPSON Soware Updater” on page 89

Installing Applications

If your computer is connected to a network, install the latest applications available on the website. If you are unable to download the applications from the website, install them from the

Note:

❏ Log on to your computer as an administrator. Enter the administrator password if the computer prompts you.

❏ When reinstalling an application, you need to uninstall it rst.

1. Quit all running applications.

2. When installing the printer driver, disconnect the printer and the computer temporarily.

soware

disc that came with the printer.

Note:

Do not connect the printer and the computer until you are instructed to do so.

Install the applications by following the instructions on the website below.

http://epson.sn

Related Information

& “Uninstalling Applications” on page 90

Installing a PostScript Printer Driver

Installing a PostScript Printer Driver Using USB Interface - Windows

1. Turn o all virus protection applications.

2. Insert the eppsnt.inf" le.

Note:

If your computer does not have a CD/DVD drive, download the printer driver from the Epson support website.

soware

disc that came with the printer into the computer, and download the "Driver/PostScript/

http://www.epson.eu/Support (Europe)

http://support.epson.net/ (outside Europe)

3. Connect the printer to the computer with a USB cable, and then turn on the printer.

Note: For Windows Vista/Windows XP, when the Found New Hardware screen appears, click Ask me again later.

Add a printer.

❏ Windows 8.1/Windows 8/Windows Server 2012 R2/Windows Server 2012

Select Desktop > Settings > Control Panel > Vi ew d ev i ces a n d pri n t e rs in Hardware and Sound, and then click Add a Printer.

❏ Windows 7/Windows Server 2008 R2

User's Guide

Applications and Network Service Information

Click the start button, select Control Panel > View devices and printers in Hardware and Sound, and then click Add a Printer.

❏ Windows Vista/Windows Server 2008

Click the start button, select Control Panel > Printers in Hardware and Sound, and then click Add a Printer.

❏ Windows XP/Windows Server 2003 R2/Windows Server 2003

Click the start button, select Control Panel > Printers and Other Hardware > Printers and Faxes > Add a Printer, and then click Next.

5. Add a local printer.

❏ Windows 8.1/Windows 8/Windows Server 2012 R2/Windows Server 2012

Click e printer that I want isn't listed, select Add a local printer or network printer with manual settings, and then click Next.

❏ Windows 7/Windows Vista/Windows Server 2008 R2/Windows Server 2008

Click Add a local printer.

❏ Windows XP/Windows Server 2003 R2/Windows Server 2003

Select Local printer attached to this computer, clear Automatically detect and install my Plug and Play printer, and then click Next.

Select Use an existing port, select USB001 (Virtual printer port for USB), and then click Next.

7. Click Have Disk, specify the "eppsnt.inf" website, and then click OK.

8. Select your printer, and then click Next.

9. Follow the on-screen instructions for the rest of the installation.

that is on the

le

soware

disc or that you have downloaded from the

Installing a PostScript Printer Driver Using Network Interface - Windows

Select Menu > Network Status > Wi r e d L A N/Wi- F i S ta tus on the control panel, and then conrm the IP address.

Turn o all virus protection applications.

3. Turn on the printer.

4. Insert the soware disc that came with the printer into the computer, and download the "Driver/PostScript/ eppsnt.inf " le.

Note:

If your computer does not have a CD/DVD drive, download the printer driver from the Epson support website.

http://www.epson.eu/Support (Europe)

http://support.epson.net/ (outside Europe)

5. Add a printer.

❏ Windows 8.1/Windows 8/Windows Server 2012 R2/Windows Server 2012

Select Desktop > Settings > Control Panel > Vi ew d ev i ces a n d pri n t e rs in Hardware and Sound, and then click Add a Printer.

User's Guide

Applications and Network Service Information

❏ Windows 7/Windows Server 2008 R2

Click the start button, select Control Panel > View devices and printers in Hardware and Sound, and then click Add a Printer.

❏ Windows Vista/Windows Server 2008

Click the start button, select Control Panel > Printers in Hardware and Sound, and then click Add a Printer.

❏ Windows XP/Windows Server 2003 R2/Windows Server 2003

Click the start button, select Control Panel > Printers and Other Hardware > Printers and Faxes > Add a Printer, and then click Next.

6. Add a local printer.

❏ Windows 8.1/Windows 8/Windows Server 2012 R2/Windows Server 2012

Click e printer that I want isn't listed, select Add a local printer or network printer with manual settings, and then click Next.

❏ Windows 7/Windows Vista/Windows Server 2008 R2/Windows Server 2008

Click Add a local printer.

❏ Windows XP/Windows Server 2003 R2/Windows Server 2003

Select Local printer attached to this computer, clear Automatically detect and install my Plug and Play printer, and then click Next.

Select Create a new port, select Standard TCP/IP Port, and then click Next.

Note: For Windows XP/Windows Server 2003 R2/Windows Server 2003, when the Add Standard TCP/IP Printer Port Wi z a r d screen appears, click Next.

8. Enter the printer's IP address, and then click Next.

Note: For Windows XP/Windows Server 2003 R2/Windows Server 2003, when the Add Standard TCP/IP Printer Port Wi z a r d screen appears, click Finish.

9. Click Have Disk, specify the "eppsnt.inf" le that is on the soware disc or that you have downloaded from the website, and then click OK.

10. Select your printer, and then click Next.

11. Follow the on-screen instructions for the rest of the installation.

Installing a PostScript Printer Driver - Mac OS X

Download the printer driver from the Epson Support website, and then install it.

http://www.epson.eu/Support (Europe)

http://support.epson.net/ (outside Europe)

You need the IP address of the printer while installing the printer driver. > Network Status > Wire d LAN / Wi-Fi St a t us on the control panel.

Conrm

the IP address by selecting Menu

Adding the Printer Driver (for Mac OS X Only)

1. Select System Preferences from the menu > Printers & Scanners (or Print & Scan, Print & Fax).

User's Guide

Applications and Network Service Information

2. Click +, and then select Add Other Printer or Scanner.

3. Select your printer, and then click Add.

Note:

❏ If your printer is not listed, check that it is correctly connected to the computer and that the printer is on.

❏ For a USB, IP, or Bonjour connection, set the optional paper cassette unit manually aer adding the printer driver.

Related Information

& “Setting the Optional Paper Cassette Unit in the Printer Driver - Mac OS X” on page 132

Installing the Epson Universal Printer Driver (for Windows Only)

e Epson universal printer driver is the universal PCL6 compatible print driver that has the following features:

❏ It supports the basic print functions needed for business situations.

❏ It supports multiple Epson business printers besides this printer.

❏ It supports most languages among the print drivers for this printer.

Connect the printer to the same network as the computer, and then follow the procedure below to install the printer driver.

1. Download the executable le of the driver from the Epson support website.

http://www.epson.eu/Support (Europe)

http://support.epson.net/ (outside Europe)

Note:

We recommend downloading the latest driver from the website. However you can get it from the soware disc that came with the printer. Access to "Driver\Universal".

2. Double-click the executable

3. Follow the on-screen instructions for the rest of the installation.

that you have downloaded from the website or that is in the

le

soware

disc.

Updating Applications and Firmware

You may be able to clear certain problems and improve or add functions by updating the applications and the rmware. Make sure you use the latest version of the applications and rmware.

1. Make sure that the printer and the computer are connected, and the computer is connected to the internet.

2. Start EPSON

Important:

Soware

Updater, and update the applications or the

rmware.

Do not turn o the computer or the printer while updating.

Note:

If you cannot nd the application you want to update in the list, you cannot update using the EPSON Soware Updater. Check for the latest versions of the applications from your local Epson website.

http://www.epson.com

User's Guide

Applications and Network Service Information

Related Information

& “EPSON Soware Updater” on page 89

User's Guide

Solving Problems

Checking the Printer Status

You can check error messages and the approximate ink levels on the LCD screen or the computer.

Checking Messages on the LCD Screen

If an error message is displayed on the LCD screen, follow the on-screen instructions or the solutions below to solve the problem.

Error Messages Solutions

Printer Error 0xXX

Turn the power o and on again. For details, see your documentation.

Printer Error 0xXX

For details, see your documentation.

Too many paper cassette units are installed.

Turn the power o and uninstall the extra units. See your documentation for details.

Cannot print because XX is out of order.

You can print from another paper source.

Maintenance rollers on XX are nearing the end of their service life.

Maintenance rollers on XX are at the end of their service life.

You need to replace the following ink cartridge(s).

Remove any paper or protective material in the printer and the paper cassette. If the error message is still displayed after turning the power o and on again, contact Epson support.

The printer may be damaged. Contact Epson or an authorised Epson service provider to request repairs. However, non-printing features are available.

You can install up to 2 optional paper cassette units. For other optional paper cassette units, uninstall them by following the reverse steps to installation.

Turn the power o and on again, and then reinsert the paper cassette. If the error message is still displayed, contact Epson or an authorised Epson service provider to request repairs.

The maintenance rollers need to be replaced periodically. Paper is not fed correctly from the paper cassette when it is time for replacement. Prepare new maintenance rollers.

Replace the maintenance rollers. After replacing the rollers, select Menu > Maintenance > Maintenance Roller Information > Reset Maintenance Roller Counter, and then select the paper cassette for which you replaced the maintenance rollers.

To ensure you receive premium print quality and to help protect your print head, a variable ink safety reserve remains in the cartridge when your printer indicates it is time to replace the cartridge. Replace the cartridge when a message prompts you to do so.

Memory full. Try the methods below to reduce the size of the print job.

❏ Lower the print quality and the resolution.

❏ Change the format setting.

❏ Reduce the number of images, letters or fonts used in the print job.

Invalid IP address and subnet mask.

Enter them correctly. See your documentation.

See the Network Guide.

User's Guide

Solving Problems

Error Messages Solutions

Recovery Mode The printer has started in recovery mode because the rmware update

failed. Follow the steps below to try to update the

1. Connect the computer and the printer with a USB cable. (During recovery mode, you cannot update the rmware over a network connection.)

2. Visit your local Epson website for further instructions.

Related Information

& “Contacting Epson Support” on page 133 & “Installing the Optional Units” on page 127 & “Replacing Maintenance Rollers in Paper Cassette 1” on page 69 & “Replacing Maintenance Rollers in Paper Cassette 2 to 3” on page 73 & “Replacing Ink Cartridges” on page 65 & “Updating Applications and Firmware” on page 95

rmware

again.

Checking the Printer Status - Windows

1. Access the printer driver window.

2. Click EPSON Status Monitor 3 on the Maintenance tab, and then click Details.

Note: If EPSON Status Monitor 3 is disabled, click Extended Settings on the Maintenance tab, and then select Enable EPSON Status Monitor 3.

Related Information

& “Windows Printer Driver” on page 87

Checking Printer Status - Mac OS X

1. Select System Preferences from the menu > Printers & Scanners (or Print & Scan, Print & Fax), and then select the printer.

2. Click Options & Supplies > Utility > Open Printer Utility.

3. Click EPSON Status Monitor.

Removing Jammed Paper

Follow the on-screen instructions on the printer's control panel to locate and remove the jammed paper including any torn pieces.

User's Guide

Solving Problems

Caution:

Never touch the buttons on the control panel while your hand is inside the printer. If the printer starts operating, it could cause an injury. Be careful not to touch the protruding parts to avoid injury.

Important:

Remove the jammed paper carefully. Removing the paper vigorously may cause damage to the printer.

Removing Jammed Paper from the Front Cover (A)

1. Open the front cover.

2. Remove the jammed paper.

Important:

Do not touch the parts inside the printer. Doing so may cause a malfunction.

3. Close the front cover.

User's Guide

Solving Problems

Removing Jammed Paper from the Rear Paper Feed (B1)

Remove the jammed paper.

Removing Jammed Paper from the Front Paper Feed Slot (B2)

1. Remove the output tray and pull out the paper cassette.

2. Pull the lever.

e cover comes o.

100

Epson WF-6090DW User Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Copyright

Trademarks

Contents

About This Manual

Introduction of Manuals

Marks and Symbols

Descriptions Used in this Manual

Operating System References

Important Instructions

Safety Instructions

Printer Advisories and Warnings

Advisories and Warnings for Setting Up/Using the Printer

Advisories and Warnings for Using the Printer with a Wireless Connection

Advisories and Warnings for Using the LCD Screen

Protecting Your Personal Information

Administrator Settings

Locking the Printer Settings Using an Administrator's Password

Unlocking the Printer Settings

Printer Basics

Part Names and Functions

Control Panel

Buttons and Lights

Icons Displayed on the LCD Screen

Menu Options

Menu

Loading Paper

Paper Handling Precautions

Available Paper and Capacities

List of Paper Types

Loading Paper in the Paper Cassette

Loading Paper in the Rear Paper Feed

Loading Paper in the Front Paper Feed Slot

Printing

Printing from a Computer

Printing Basics - Windows

Printing Basics - Mac OS X

Printing on 2-Sides

Printing Several Pages on One Sheet

Printing to Fit the Paper Size

Printing Multiple Files Together (for Windows Only)

Printing One Image on Multiple Sheets to Create a Poster (for Windows Only)

Printing Using Advanced Features

Printing Using a PostScript Printer Driver

Printing Using a PostScript Printer Driver - Windows

Printing Using a PostScript Printer Driver - Mac OS X

Setting Items for the PostScript Printer Driver

Printing from Smart Devices

Using Epson iPrint

Using AirPrint

Canceling Printing

Canceling Printing - Printer Button

Canceling Printing - Windows

Canceling Printing - Mac OS X

Replacing Ink Cartridges and Other Consumables

Checking the Status of the Remaining Ink and the Maintenance Box

Ink Cartridge Codes

Ink Cartridge Handling Precautions

Replacing Ink Cartridges

Maintenance Box Code

Maintenance Box Handling Precautions

Replacing a Maintenance Box

Maintenance Rollers Codes

Replacing Maintenance Rollers in Paper Cassette 1

Replacing Maintenance Rollers in Paper Cassette 2 to 3

Temporarily Printing with Black Ink

Temporarily Printing with Black Ink - Windows

Temporarily Printing with Black Ink - Mac OS X

Conserving Black Ink when the Black Ink Is Low (for Windows Only)

Improving Print Quality

Checking and Cleaning the Print Head

Checking and Cleaning the Print Head - Control Panel

Checking and Cleaning the Print Head - Windows

Checking and Cleaning the Print Head - Mac OS X

Aligning the Print Head

Improving Horizontal Streaks

Cleaning the Paper Path
