CONVENIENCE
AND ACCURACY
BRINGING CONVENIENCE
AND ACCURACY TO FAST
FOOD OUTLETS, HOSPITALITY
AND RETAIL
A special version of the world’s leading receipt printer
has been developed to produce repositionable labels
which stick to almost any material. The TM-T88IV
ReStick prints individual receipt labels which can
be conveniently repositioned without damaging
the surface.
Helping to improve customer service, this unique
thermal printer will reduce errors in order processing
and avoid mistakes when labelling customised
goods and individual offers.
With its durable and proven construction and design,
this innovative product prints and cuts linerless
thermal paper roll on demand, at high speed, and
with outstanding reliability.
The liner-free label solution that works
Epson’s TM-T88IV ReStick label printer is ideal for quick
service, fast food and take-away restaurants needing to
improve order accuracy, reduce food costs, speed work
flow and increase customer satisfaction. Based on new
technology, the TM-T88IV ReStick printer prints
repositionable liner-free labels that can be used for
customer bag labels, exception labels in the food
preparation area and product labels, all without any liners
to dispose of. And it is available in two versions: one for
58 mm labels/receipts and one for 80 mm labels/receipts.
The features you need
Fast and reliable, the TM-T88IV ReStick label printer prints
both text and barcodes at a crisp resolution of 203 x 203 dpi.
It features variable length label output, two different paper
widths, autocutter, small footprint and more. And because
the TM-T88IV ReStick can print both liner-free labels and
receipts, the same printer can be used throughout the
restaurant minimising service, supplies and training costs.
Cost-effective liner-free label printing
Epson’s liner-free label printing solution, using adhesive
label paper, is significantly less expensive than using a
standard label printer. There is no need to peel off and
dispose of a paper liner, reducing both cost and waste.
KEY FEATURES
Easy integration
Epson’s TM-T88IV ReStick label printer can be easily
integrated into your current systems. It is compatible with
Epson’s actual TM-T88 printers, so almost no software
changes or application development is required. Just install
the driver and it’s ready to go. And with Epson’s exclusive
family of interfaces, the TM-T88IV is compatible with all
current best-of-breed and component-based systems.
TYPICAL LINER-FREE LABEL APPLICATIONS
Epson’s liner-free ReStick label printer is a cost-effective
solution for a wide range of label applications used in the fast
food, hospitality and convenience industries including:
• Exception labels
• Bag tag labels
• Product labels
• Pizza Box labels
• Sandwich wrap labels
• Specialty cup labels
• Take-away order labels
• Freshness dating labels
• Delivery receipt labels
• Refrigerator coupons
• Prepared food labels
• Ingredient labels
• Bakery labels
• Special pricing labels
• Nutritional information labels
• Prints on both receipt and liner-free
label paper
• High-speed printing for graphics,
barcodes and text
• High quality and reliability
• High resolution 203 dpi print head
• Fully TM-T88IV compatible
• Uses repositionable adhesive
liner-free labels
• Easy drop-in paper loading
• Several bar codes and 2D codes
(PDF417, QR) included
• Various interface boards (Epson
UIB series) can be used
• Maintenance counter function
supported
• Buzzer included as standard
• OPOS ADK and Windows® printer
drivers available
• Page mode layouts Epson
ESC/POS Command System
• Vertical and horizontal mounting
options available
PRODUCT SPECIFICATIONS
Printing method Thermal line printing
Printing speed
Characters per line
Paper Recommended liner-free label For 80 mm paper width model; Part number: 1520526
Internal buffer
Electrical characteristics Supply voltage: DC+24 V ± 7%
Current consumption
when using the
liner-free label
Current consumption
when using thermal roll
paper
Interface Various interface boards (Epson UB series) can be used
Reliability MTBF 360,000 hours
Using the recommended
liner-free label
Using thermal roll paper Life Mechanism 15,000,000 print lines
Dimensions and Mass H x W x D 148 x 145 x 195 mm
Standard accessories • Roll paper × 1 roll
Options • Wall hanging bracket WH-10
When using the recommended
liner-free label
Normal: 150 mm/s
Approximately 40 lps
Page mode printing: 150 mm/s
Bit-image / Raster bit-image printing: 150 mm/s
When using thermal roll paper Normal: 177 mm/s
Approximately 47.2 lps
Page mode printing: 177 mm/s
Bit-image / Raster bit-image printing: 177 mm/s
Dot density 203 dpi × 203 dpi
Printing direction Unidirectional with friction feed
Paper width 80 mm or 58 mm (The paper width setting cannot be changed
after the shipment from the factory)
Printing width for 80 mm paper
72 mm, 576 dot positions
width model
Printing width for 58 mm paper
52.5 mm, 420 dot positions
width model
Print density When the DIP switch is set to the recommended liner-free
label mode, the print density will be automatically set to the
recommended value
For 80 mm paper width model Font A 44 or 48
Font B 57 or 64
Font C 52 or 57
For 58 mm paper width model Font A 42 or 35
Font B 46 or 46
Font C 35 or 42
For 58 mm paper width model; Part number: 1520527
Thermal roll paper The chromogenic side must face outside
Paper must not be pasted to the roll paper spool
Roll paper diameter 83 mm maximum
Roll paper spool Inside: 12 mm, Outside: 18 mm
Width: Same with the paper width or 1 mm less
Receive buffer Selectable as 45 bytes or 4 KB using the DIP switch
User-defined buffer Macro buffer: 2 KB
NV graphics memory 256 KB
NV user memory 1 KB
High speed mode
Character printing
High speed mode
Character printing
Mean: Approximately 1.6 A
Peak: Approximately 5.5 A
Mean: Approximately 1.4 A
Peak: Approximately 5.2 A
Standby Mean: Approximately 0.1 A
Maximum 1 A for drawer kick-out driving
Life Mechanism 10,000,000 print lines
Thermal head 100 million pulses, 60 km
Autocutter 600,000 cuts
MCBF 48,000,000 lines
Thermal head 100 million pulses, 100 km
Autocutter 1,500,000 cuts
MCBF 52,000,000 lines
mass Approximately 1.8 kg
Color Epson standard color (ECW, EDG)
• User’s Manual (Language: English)
• Power switch cover
• External power supply PS-180
• Connector cover
• Power supply box OT-BX88
