Page 1

Confidential

EPSON

Receipt Printer

TM-T88III series

Specification

STANDARD Rev. No. B Notes

Copied Date , , Copied by

SEIKO EPSON CORPORATION

MATSUMOTO MINAMI PLANT 2070 KOTOBUKI KOAKA, MATSUMOTO-SHI, NAGANO, 399-8702 JAPAN PHONE(0263)86-5353 FAX(0263)86-9923

Page 2

Confidential

REVISION SHEET

Sheet 1 of 4 The table below indicates which pages in this specification have been revised. Before reading this specification, be sure you have the correct version of each page.

Revisions Design Section Sheet Rev. No.

Rev. Document WRT CHK APL Sheet Rev. Sheet Rev. Sheet Rev.

A Enactment

Nakayama -- Omura

B 17 B 42 B

B Change

B 18 B 43 B

III

B 19 B 44 B

B 20 B 45 B

B 21 B 46 B

B 22 B 47 B 23 B 48 B 24 B 49 B 25 B 50 B 1 B 26 B 51 B 2 B 27 B 52 B 3 B 28 B 53 B 4 B 29 B 54 B 5 B 30 B 55 B 6 B 31 B 56 B 7 B 32 B 57 B 8 B 33 B 58 B 9 B 34 B 59 B 10 B 35 B 60 B 11 B 36 B 61 B 12 B 37 B 62 B 13 B 38 B 63 B 14 B 39 B 64 B 15 B 40 B 65 B 16 B 41 B 66 B

Front Part

Cover

Rev.

Sheet

Confidentiality

Agreement

General

Features

Table of

Contents Contents Appendix

Total

TITLE

TM-T88III series

Specification

(STANDARD)

1 4 1 1 4 152 20 183

Page 3

Confidential

REVISION SHEET

Sheet 2 of 4 The table below indicates which pages in this specification have been revised. Before reading this specification, be sure you have the correct version of each page.

Revisions Design Section Sheet Rev. No.

Rev. Document WRT CHK APL Sheet Rev. Sheet Rev. Sheet Rev.

A Enactment

67 B 92 B 117 B

B Change

68 B 93 B 118 B 69 B 94 B 119 B

70 B 95 B 120 B 71 B 96 B 121 B 72 B 97 B 122 B 73 B 98 B 123 B 74 B 99 B 124 B 75 B 100 B 125 B 76 B 101 B 126 B 77 B 102 B 127 B 78 B 103 B 128 B 79 B 104 B 129 B 80 B 105 B 130 B 81 B 106 B 131 B 82 B 107 B 132 B 83 B 108 B 133 B 84 B 109 B 134 B 85 B 110 B 135 B 86 B 111 B 136 B 87 B 112 B 137 B 88 B 113 B 138 B 89 B 114 B 139 B 90 B 115 B 140 B 91 B 116 B 141 B

Front Part

Cover

Rev.

Sheet

Confidentiality

Agreement

General

Features

Table of

Contents Contents Appendix

Total

TITLE

TM-T88III series

Specification

(STANDARD)

1 4 1 1 4 152 20 183

Page 4

Confidential

REVISION SHEET

Sheet 3 of 4 The table below indicates which pages in this specification have been revised. Before reading this specification, be sure you have the correct version of each page.

Revisions Design Section Sheet Rev. No.

Rev. Document WRT CHK APL Sheet Rev. Sheet Rev. Sheet Rev.

A Enactment

142 B App.1 B

B Change 143 B App.2 B

144 B App.3 B 145 B App.4 B 146 B App.5 B 147 B App.6 B 148 B App.7 B 149 B App.8 B 150 B App.9 B 151 B App.10 B 152 B App.11 B App.12 B App.13 B App.14 B App.15 B App.16 B App.17 B App.18 B App.19 B App.20 B

Front Part

Cover

Rev.

Sheet

Confidentiality

Agreement

General

Features

Table of

Contents Contents Appendix

Total

TITLE

TM-T88III series

Specification

(

STANDARD)

1 4 1 1 4 152 20 183

Page 5

Confidential

REVISION SHEET

Sheet 4 of 4

REV. SHEET CHANGED CONTENTS

All All pages are revised, due to addition of the multilingual support.

II GENERAL FEATURES

The following models are available … (added)

III - VI Table of Contents (changed)

1 – 3 1.1 Printing Specifications

1.2 Character Specifications Description for Kanji and Thai characters support (added)

25 2.1.4 Other interfaces (added) 31 Kanji command list (added)

42 - 50 3.2.11 Page 20 through 3.2.17 Page 26 (added)

3.2.11 → 3.2.18, 3.2.12 → 3.2.19

66 5.1 Standard Accessories

User’s manual (Languages: .. Simplified Chinese, Traditional Chinese) (added)

77 ESC !

[Details] • Emphasized mode is … (added)

86 ESC -

[Details] • This command does not … (added)

106 ESC t

[Range] [Description] [Default] Thai model (added)

123 GS I

[Range] [Description] n=69 (added)

145 -

152

6.4 Kanji Control Commands (added)

App.1 Table A.1 Kanji font (added)

App.20 APPENDIX K, Multilingual support (changed)

TITLE

TM-T88IIIIIIIIIIII series

Specification

(STANDARD)

Page 6

Confidential

TITLE

SHEET REVISION

NO.

SHEETNEXT

TM-T88III series

Specification

(STANDARD)

EPSON

CONFIDENTIALITY AGREEMENT

BY USING THIS DOCUMENT, YOU AGREE TO ABIDE BY THE TERMS OF THIS AGREEMENT. PLEASE RETURN THIS DOCUMENT IMMEDIATELY IF YOU DO NOT AGREE TO THESE TERMS.

1. This document contains confidential, proprietary information of Seiko Epson Corporation or its affiliates. You must keep such information confidential. If the user is a business entity or organization, you must limit disclosure to those of your employees, agents, and contractors who have a need to know and who are also bound by obligations of confidentiality.

2. On the earlier of (a) termination of your relationship with Seiko Epson, or (b) Seiko Epson's request, you must stop using the confidential information. You must then return or destroy the information, as directed by Seiko Epson.

3. If a court, arbitrator, government agency, or the like orders you to disclose any confidential information, you must immediately notify Seiko Epson. You agree to give Seiko Epson reasonable cooperation and assistance in the negotiation.

4. You may use confidential information only for the purpose of operating or servicing the products to which the document relates, unless you obtain the prior written consent of Seiko Epson for some other use.

5. Seiko Epson warrants that it has the right to disclose the confidential information. SEIKO EPSON MAKES NO OTHER WARRANTIES CONCERNING THE CONFIDENTIAL INFORMATION OR ANY OTHER INFORMATION IN THE DOCUMENT, INCLUDING (WITHOUT LIMITATION) ANY WARRANTY OF TITLE OR NON-INFRINGEMENT. Seiko Epson has no liability for loss or damage arising from or relating to your use of or reliance on the information in the document.

6. You may not reproduce, store, or transmit the confidential information in any form or by any means (electronic, mechanical, photocopying, recording, or otherwise) without the prior written permission of Seiko Epson.

7. Your obligations under this Agreement are in addition to any other legal obligations. Seiko Epson does not waive any right under this Agreement by failing to exercise it. The laws of Japan apply to this Agreement.

Cautions

1. This document shall apply only to the product(s) identified herein.

2. No part of this document may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of Seiko Epson Corporation.

3. The contents of this document are subject to change without notice. Please contact us for the latest information.

4. While every precaution has been taken in the preparation of this document, Seiko Epson Corporation assumes no responsibility for errors or omissions.

5. Neither is any liability assumed for damages resulting from the use of the information contained herein.

6. Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this product or third parties for damages, losses, costs, or expenses incurred by the purchaser or third parties as a result of: accident, misuse, or abuse of this product or unauthorized modifications, repairs, or alterations to this product, or (excluding the U. S.) failure to strictly comply with Seiko Epson Corporation's operating and maintenance instructions.

7. Seiko Epson Corporation shall not be liable against any damages or problems arising from the use of any options or any consumable products other than those designated as Original EPSON Products or EPSON Approved Products by Seiko Epson Corporation.

Trademarks

EPSON® and ESC/POS® are registered trademarks of Seiko Epson Corporation. General Notice: Other product and company names used herein are for identification purposes only and may

be trademarks of their respective companies.

III

Page 7

Confidential

TITLE

SHEET REVISION

NO.

SHEETNEXT

TM-T88III series

Specification

(STANDARD)

EPSON

GENERAL FEATURES

This specification applies the following models of the TM-T88III series printer: TM-T88III (with serial i nterface (*1))

TM-T88IIIP (with parallel interface)

The following models are available for each product above.

1) Alphanumeric (ANK) model

2) Multilingual model (*)

3) Japanese model

(*): The multilingual character model supports printing with one of the following characters:

➀ Simplified Chinese ➁ Traditional Chinese ➂ Thai ➃ Korean

The printer has the following features:

1) Printing

• High speed printing: approximately 35.5 lps (4.23 mm {1/6"} feed) maximum. [lps: lines per second]

• Low-noise thermal printing.

• High reliability due to a stable mechanism.

2) Application Software

• Command protocol is based on the ESC/POS

standard.

• Various Layouts are possible by using page mode.

• Characters can be scaled up to 64 times as large as the standard size. Smoothing is also possible.

• Bar code printing is possible by using a bar code command. Bar codes can be printed both in the

vertical direction (fence bar code) and in the horizontal direction (ladder bar code) (*2).

• Repeated operation and copy printing are possible by using macro definitions.

• Character font size (12 × 24 font or 9 × 17 font) can be selected using a command.

3) Printer Handling

• Easy paper roll setting.

• Equipped with an autocutter.

• The printer allows easy maintenance for tasks such as head cleaning.

• Three different print densities can be selected by DIP switches.

• The built-in interface provides control capability for two drawers.

NOTES) *1: An RS-485 serial interface is a factory option. *2: The ladder bar code is effective only in the page mode.

IIIII

Page 8

Confidential

TITLE

SHEET REVISION

NO.

SHEETNEXT

TM-T88III series

Specification

(STANDARD)

EPSON

Table of Contents

1. GENERAL SPECIFICATIONS

1.1 Printing Specifications..................................................................................................................1

1.2 Character Specifications ..............................................................................................................2

1.3 Autocutter..................................................................................................................................... 3

1.4 Paper Roll Supply Device............................................................................................................. 4

1.5 Paper Specification ...................................................................................................................... 4

1.6 Printable Area............................................................................................................................... 5

1.7 Printing and Cutting Positions ...................................................................................................... 6

1.8 Internal Buffer...............................................................................................................................6

1.9 Electrical Characteristics.............................................................................................................. 7

1.10 EMI and Safety Standards Applied.............................................................................................7

1.11 Reliability....................................................................................................................................8

1.12 Environmental Conditions .......................................................................................................... 8

1.13 Installation.................................................................................................................................. 9

2. CONFIGURATION

2.1 Interface ..................................................................................................................................... 10

2.1.1 RS-232 serial interface ....................................................................................................... 10

2.1.2 IEEE 1284 Bidirectional Parallel Interface .......................................................................... 15

2.1.3 RS-485 Serial Interface....................................................................................................... 21

2.1.4 Other Interfaces.................................................................................................................. 25

2.2 Connectors................................................................................................................................. 26

2.2.1 Interface Connectors........................................................................................................... 26

2.2.2 Power Supply Connector .................................................................................................... 26

2.2.3 Drawer Kick-out Connector (Modular Connector)............................................................... 27

3. FUNCTIONS

3.1 List of commands....................................................................................................................... 29

3.2 Character Code Tables.............................................................................................................. 32

3.2.1 Page 0 (PC437: USA, Standard Europe) (International Character Set: U.S.A.)................. 32

3.2.2 Page 1 (Katakana)..............................................................................................................33

3.2.3 Page 2 (PC850: Multilingual) .............................................................................................. 34

3.2.4 Page 3 (PC860: Portuguese).............................................................................................. 35

3.2.5 Page 4 (PC863: Canadian-French) .................................................................................... 36

3.2.6 Page 5 (PC865: Nordic)...................................................................................................... 37

3.2.7 Page 16 (WPC1252)........................................................................................................... 38

3.2.8 Page 17 (PC866: Cyrillic#2)................................................................................................ 39

3.2.9 Page 18 (PC852: Latin2) .................................................................................................... 40

3.2.10 Page 19 (PC858).............................................................................................................. 41

3.2.11 Page 20 (Thai character code 42) .................................................................................... 42

3.2.12 Page 21 (Thai character code 11) .................................................................................... 43

3.2.13 Page 22 (Thai character code 13) .................................................................................... 44

3.2.14 Page 23 (Thai character code 14) .................................................................................... 45

3.2.15 Page 24 (Thai character code 16) .................................................................................... 46

3.2.16 Page 25 (Thai character code 17) .................................................................................... 47

3.2.17 Page 26 (Thai character code 18) .................................................................................... 48

3.2.18 Page 255 (Space Page).................................................................................................... 49

3.2.19 International Character Set...............................................................................................50

3.3 Switches and Buttons................................................................................................................. 51

3.3.1 Power Button.......................................................................................................................51

3.3.2 Panel Buttons...................................................................................................................... 51

3.3.3 DIP Switches....................................................................................................................... 52

IIIIV

Page 9

Confidential

TITLE

SHEET REVISION

NO.

SHEETNEXT

TM-T88III series

Specification

(STANDARD)

EPSON

3.4 Panel LED Indicators.................................................................................................................. 55

3.5 Self-test...................................................................................................................................... 56

3.6 Hexadecimal Dumping............................................................................................................... 57

3.7 Error Processing.........................................................................................................................58

3.7.1 Error Types.........................................................................................................................58

3.7.2 Printer Operation When an Error Occurs ........................................................................... 59

3.7.3 Data Receive Error (only in the serial interface specification) ............................................ 59

3.8 Paper Sensors............................................................................................................................ 59

3.9 Cover Open Button..................................................................................................................... 60

3.10 Cover Open Sensor.................................................................................................................. 60

3.11 Print Buffer-full Printing ............................................................................................................60

3.12 Page Mode............................................................................................................................... 61

3.12.1 General Description .......................................................................................................... 61

3.12.2 Setting Values in Standard and Page Modes ................................................................... 61

3.12.3 Formatting of Print Data in the Printable Area .................................................................. 62

4. CASE SPECIFICATIONS

4.1 External Dimensions and Mass.................................................................................................. 65

4.2 Color...........................................................................................................................................65

4.3 External Appearance.................................................................................................................. 65

5. OPTIONS AND CONSUMABLES

5.1 Standard Accessories ................................................................................................................66

5.2 Options....................................................................................................................................... 66

5.3 Consumables .............................................................................................................................66

6. COMMANDS

6.1 Command Notation .................................................................................................................... 67

6.2 Explanation of Terms ................................................................................................................. 67

6.3 Control Commands .................................................................................................................... 69

HT................................................................................................................................................ 69

LF................................................................................................................................................. 69

FF................................................................................................................................................. 70

CR................................................................................................................................................ 70

CAN .............................................................................................................................................70

DLE EOT n................................................................................................................................... 71

DLE ENQ n .................................................................................................................................. 74

DLE DC4 n m t............................................................................................................................. 75

ESC FF........................................................................................................................................ 76

ESC SP n..................................................................................................................................... 76

ESC ! n......................................................................................................................................... 77

ESC $ nL nH................................................................................................................................78

ESC % n ......................................................................................................................................79

ESC & y c1 c2 [x1 d1...d(y

x1)]...[xk d1...d(y × xk)] .................................................................. 80

ESC ∗ m nL nH d1...dk ................................................................................................................ 83

ESC - n ........................................................................................................................................86

ESC 2........................................................................................................................................... 86

ESC 3 n........................................................................................................................................ 87

ESC = n........................................................................................................................................ 88

ESC ? n........................................................................................................................................ 88

ESC @......................................................................................................................................... 89

ESC D n1...nk NUL...................................................................................................................... 90

ESC E n ....................................................................................................................................... 91

ESC G n....................................................................................................................................... 91

IVV

Page 10

Confidential

TITLE

SHEET REVISION

NO.

SHEETNEXT

TM-T88III series

Specification

(STANDARD)

EPSON

ESC J n........................................................................................................................................ 92

ESC L........................................................................................................................................... 93

ESC M n....................................................................................................................................... 94

ESC R n.......................................................................................................................................94

ESC S .......................................................................................................................................... 95

ESC T n .......................................................................................................................................96

ESC V n ....................................................................................................................................... 97

ESC W xL xH yL yH dxL dxH dyL dyH........................................................................................ 98

ESC \ nL nH...............................................................................................................................100

ESC a n...................................................................................................................................... 101

ESC c 3 n................................................................................................................................... 102

ESC c 4 n................................................................................................................................... 103

ESC c 5 n................................................................................................................................... 104

ESC d n...................................................................................................................................... 104

ESC p m t1 t2............................................................................................................................. 105

ESC t n....................................................................................................................................... 106

ESC { n ......................................................................................................................................107

FS g 1 m a1 a2 a3 a4 nL nH d1...dk..........................................................................................108

FS g 2 m a1 a2 a3 a4 nL nH...................................................................................................... 109

FS p n m ....................................................................................................................................111

FS q n [xL xH yL yH d1...dk]1...[xL xH yL yH d1...dk]n.............................................................. 112

GS ! n.........................................................................................................................................115

GS $ nL nH................................................................................................................................117

GS ∗ x y d1...d(x

y × 8) ........................................................................................................... 118

GS ( A pL pH n m....................................................................................................................... 119

GS / m........................................................................................................................................120

GS :............................................................................................................................................121

GS B n ....................................................................................................................................... 122

GS H n.......................................................................................................................................122

GS I n.........................................................................................................................................123

GS L nL nH................................................................................................................................125

GS P x y..................................................................................................................................... 126

➀GS V m ➁GS V m n..............................................................................................................127

GS W nL nH...............................................................................................................................128

GS \ nL nH................................................................................................................................. 130

GS ^ r t m................................................................................................................................... 131

GS a n........................................................................................................................................132

GS b n........................................................................................................................................135

GS f n.........................................................................................................................................135

GS h n........................................................................................................................................136

➀ GS k m d1...dk NUL ➁GS k m n d1...dn.............................................................................. 136

GS r n......................................................................................................................................... 141

GS v 0 m xL xH yL yH d1....dk................................................................................................... 143

GS w n.......................................................................................................................................144

6.4 Kanji Control Commands ......................................................................................................... 145

FS ! n .........................................................................................................................................145

FS &...........................................................................................................................................146

FS - n.........................................................................................................................................147

FS . ............................................................................................................................................148

FS 2 c1 c2 d1...dk...................................................................................................................... 148

FS C n........................................................................................................................................150

FS S n1 n2................................................................................................................................. 151

FS W n....................................................................................................................................... 152

VVI

Page 11

Confidential

TITLE

SHEET REVISION

NO.

SHEETNEXT

TM-T88III series

Specification

(STANDARD)

EPSON

APPENDIX A: MISCELLANEOUS NOTES ................................................................................App.1

APPENDIX B: PAPER ROLL SETUP.........................................................................................App.4

APPENDIX C: ADJUSTING THE PAPER ROLL NEAR-END SENSOR LOCATION.................App.5

APPENDIX D: RECOVERY FROM THE AUTO CUTTER ERROR............................................App.7

APPENDIX E: PRINT HEAD CLEANING ...................................................................................App.8

APPENDIX F: NOTES ON USING THE DRAWER KICK-OUT CONNECTOR.........................App.9

APPENDIX G: TRANSMISSION STATUS IDENTIFICATION..................................................App.10

APPENDIX H: CONFIGURING THE SPACE PAGE ................................................................App.11

APPENDIX I: EXAMPLE PRINTING IN PAGE MODE............................................................App.13

APPENDIX J: CODE128 BAR CODE ......................................................................................App.16

APPENDIX K: COMPARISON TABLE BETWEEN TM-T88III AND TM-T88II ........................App.20

Page 12

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

2 1

TM-T88III series

Specification

(STANDARD)

1. GENERAL SPECIFICATIONS

1.1 Printing Specifications

1) Printing method: Thermal line printing

2) Dot density: 180 dpi × 180 dpi [dpi: dots per 25.4 mm {1"}]

3) Printing direction: Unidirectional with friction feed

4) Printing width: 72 mm {2.83"}, 512 dot positions

5) Characters per line (default): Font A: 42 Font B: 56 Kanji: 21

6) Character spacing (default): Font A: 0.28 mm {0.01"} (2 dots) Font B: 0.28 mm {0.01"} (2 dots) Programmable by control command.

7) Printing speed: High speed mode: Approximately 150 mm/s maximum {Approximately 5.9"/s maximum}

47.2 lps maximum (computed value for 3.18 mm {1/8"} feed)

35.5 lps maximum (4.23 mm {1/6"} feed) (at 24V, 28°C {82.4°F}, Density level 1. Speeds are switched

automatically depending on the voltage applied to the printer and head temperature conditions.)

Low power consumption mode: Approximately 16.5 lps (4.23 mm {1/6"} feed) Approximately 70 mm/s {approximately 2.76"/s}

When a ladder bar code is printed: Approximately 42 mm/s {approximately 1.7"/s}

[lps: lines per second]

NOTES: • There may be variations in printing after switching the mode of the printing speed. To

prevent this for logo printing with ESC ∗∗∗∗ command, using a downloaded bit image is recommended. Change in printing speed does not occur during down loaded bit image printing.

• Printing speed may be slower depending on the data transmission speed and the

combination of control commands.

• Low transmission speed may cause intermittent printing. It is recommended to transmit

data to the printer as quickly as possible.

• High speed mode or low power consumption mode is selected by a DIP switch. (Refer to

Table 3.3.4 and 3.3.7).

Page 13

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

3 2

TM-T88III series

Specification

(STANDARD)

8) Paper feed speed: Approximately 150 mm/s {approximately 5.9"/s}

(continuous paper feeding)

9) Line spacing (default): 4.23 mm {1/6"}

Programmable by control command.

1.2 Character Specifications

1) Number of characters: Alphanumeric characters: 95

Extended graphics: 128 × 11 pages (including one space page)

International characters: 37

Japanese model: JIS (JIS X0208-1990): Level 1: 3489 Level 2: 3390

Multilingual character m odel supports printing with one of the following

character sets:

➀ Simplified Chinese (GB2312)

7580 (Using the GB5199 of the Chinese national standard font)

➁ Traditional Chinese (Big 5)

13494

➂ Thai characters (3-pass printing font)

128 characters × 7 pages (133 character types)

➃ Korean Kanji (KS C5601)

8366

2) Character structure: Font A: 12 × 24 (including 2-dot spacing in horizontal)

Font B: 9 × 17 (including 2-dot spacing in horizontal) Kanji: 24 × 24 Thai font: 12 × 72, 9 × 51

Font A is selected as the default

Page 14

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

4 3

TM-T88III series

Specification

(STANDARD)

3) Character size: Refer to Table 1.2.1.

Table 1.2.1 Character Size

Standard Double-height Double-width

Double-width/ Double-height

W×H (mm)

cpl

W×H (mm)

cpl

W×H (mm)

cpl

W×H (mm)

cpl

Font A 12×24 1.41×3.39

1.41×6.77

2.82×3.39

2.82×6.77

Font B 9×17 0.99×2.40

0.99×4.80

1.98×2.40

1.98×4.80

Kanji 24 × 24 3.39×3.39

3.39×6.67

6.77×3.39

6.77×6.77

Thai FontA

1.14×10.16

1.41×20.32

2.82×10.16

2.82×20.32

Thai FontB

0.99×7.20

0.99×14.40

1.98×7.20

1.98×14.40

Space between characters is not included. Characters can be scaled up to 64 times as large as the standard sizes. cpl = characters per line

4) Supporting character on each model type: Refer to Table 1.2.2

Table 1.2.2 Supporting Character on Each Model Type

Product Specifications Supported Characters

ANK model --Multilingual model

(Simplified Chinese)

Simplified Chinese characters

Multilingual model (Traditional Chinese)

Traditional Chinese characters

Multilingual model (Thai)

Thai characters

Multilingual model (Korean)

Korean characters

Japanese model

• Alphanumeric

• Extended graphics

• International characters

Japanese characters

(ANK = alphanumeric)

Page 15

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

5 4

TM-T88III series

Specification

(STANDARD)

1.3 Autocutter

Partial cut: Cutting with one point left uncut NOTE: To prevent dot displacement, after cutting, paper must be fed approximately 1 mm {14/360"}

or more before printing.

1.4 Paper Roll Supply Dev ice

1) Supply method: Drop-in paper roll

2) Near-end sensor:

a) Detection method: Microswitch b) Paper roll spool diameter: Inside: 12 mm {0.47"}

Outside: 18 mm {0.71"} c) Near-end adjustment: Can be adjusted by changing the position of the adjusting screw. Fixed position #1 (approximately 23 mm {0.9"})

#2 (approximately 27 mm {1.06"})

NOTE: You can use a command to stop printing upon detection of a paper near-end.

1.5 Paper Specification

1) Paper type: Specified thermal paper

2) Form: Paper roll

3) Paper width: 79.5 ± 0.5 mm {3.13 ± 0.02"}

4) Paper roll size: Roll diameter: Maximum 83 mm {3.26"} Take-up paper roll width: 80 +0.5/–1.0 mm {3.15+0.02/–0.04"}

5) Specified paper: Specified thermal roll paper: NTP080-80 [Original paper: TF50KS-E Nippon Paper Industries Co., Ltd.]

Packaged roll paper: [Original paper: PD160R (Oji Paper Mfg. Co., Ltd.)]

In Japan: Nakagawa Manufacturing Co., Ltd. In U.S.A.: Nakagawa Mfg. (USA) Inc. In Europe: Nakagawa Mfg. (Europe) GmbH In Southeast Asia: N.A.K. Mfg. (Malaysia) SDN BHD

The following paper can be used instead of the specified paper above: Original paper: PD190R (Oji Paper Mfg. Co., Ltd.)

P350(F380), P310, P300 (Kanzaki Specialty Papers, Inc. (U.S.A.)) AF50KS-E (Jujo Thermal Oy (Finland))

6) Paper roll spool diameter: Inside: 12 mm {0.47"} Outside: 18 mm {0.71"}

NOTE: Paper must not be pasted to the paper roll spool.

Page 16

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

6 5

TM-T88III series

Specification

(STANDARD)

1.6 Printable Area

1) Paper roll The printable area of a paper with width of 79.5 ± 0.5 mm {3.13 ± 0.02"} is 72.2 ± 0.2 m m { 2.84 ±

0.008"} (512 dots) and the space on the right and left sides are approximately

3.7 ±2 mm {0.15 ± 0.079"}.

Figure 1.6.1 Paper Roll Printable Area

Approximately 0.07mm (0.0028")

1 256

257 512

Figure 1.6.2 Shifting of the Print Position

NOTE: The print position within the printable area of the thermal elements for dots 257 to 512 is

shifted approximately 0.07 mm {0.003"} in the paper feed direction from the position for dots 1 to 256. Be sure not to print a ladder bar code across both printable areas, as this can cause variations in printing which are difficult to read. However, when the ladder bar code is printed with level 2 of print density, the difference is only approximately 0.04 ∼ 0.05 mm {0.0015∼0.0019"}.

a = 79.5 ± 0.5 mm {3.13 ± 0.02"} b = 0.141 ± 0.05 mm {0.056 ± .002"} c = 72.2 ± 0.2 mm {2.84 ± .008"} d = 3.7 ± 0.2 mm {0.15 ± 0.079"} e = 3.7 ± 0.2 mm {0.15 ± 0.079"} [All the numeric values are typical.]

Page 17

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

7 6

TM-T88III series

Specification

(STANDARD)

1.7 Printing and Cutting Positi ons

Paper feed direction

[ Units: mm (All the numeric values are typical.) ]

Center of the print dotline

Auto-cutter blade position

Manual-cutter position

14.8

26.3

Figure 1.7.1 Printing and Cutting Positions

NOTE: Numeric values used here are typical values; the values may vary slightly as a result of

paper slack or variations in the paper. Take the notice into account when setting the cutting position of the auto-cutter.

1.8 Internal Buffer

1) Receive buffer selectable as 45 bytes or 4 KB using the DIP switch.

2) User-defined buffer (both for user-defined characters and user-defined bit images): 12 KB

3) Macro buffer: 2 KB

4) NV (Non-volatile) bit image buffer: 256 KB

5) NV user memory: 1 KB

Approx. 29

Approx. 15

Page 18

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

8 7

TM-T88III series

Specification

(STANDARD)

1.9 Electrical Characteristics

1) Supply voltage: +24 VDC ± 7%

2) Current consumption (at 24V, room temperature):

High speed mode:

Mean: Approximately 1.8 A (Character font A α-N, capital letters, 36-charac ter rolling pattern, 42 columns printing) Peak: Approximately 7.7 A

Low power consumption mode:

Mean: Approximately 1.2 A (Character font A α-N, capital letters, 36-charac ter rolling pattern, 42 columns printing) Peak: Approximately 6.6 A

Standby:

Mean: Approximately 0.2 A

NOTE: Maximum 1 A for drawer kick-out driving.

1.10 EMI and Safety Standards Applied

EMC is measured using SEIKO EPSON’s AC adapter

1) Europe CE marking:

Directive: 89/336/EEC EN55022 Class B EN55024 IEC61000-4-2 IEC61000-4-3 IEC61000-4-4 IEC61000-4-5 IEC61000-4-6 IEC61000-4-11

Safety Standard: EN60950

2) North America EMI: FCC/ICES-003 Class A

Safety standards: UL1950/CSA C22.2 No.950

3) Japan EMI: VCCI Class A

4) Oceania EMC: AS/NZS 3548

Conditions of Acceptability

1) This component has been judged on the basis of the required spacing in the Standard for Information Technology equipment, Including Electric al Business Equipment, UL 1950 and CSA C22.2 No. 950, Sub-clause 2.9, which would cover the component itself if submitted for Listing.

2) This unit is intended to be supplied by a SELV circuit only.

3) The terminals and connectors have not been evaluated for field wiring.

Page 19

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

9 8

TM-T88III series

Specification

(STANDARD)

1.11 Reliability

1) Life: Mechanism: 15,000,000 lines Thermal head: 100 million pulses, 100 km Auto cutter: 1,500,000 cuts (End of life is defined to have reached the end of its life when it reaches

the beginning of the Wearout Period.)

2) MTBF: 360,000 hours (Failure is defined as Random Failure occurring at the time of the

Random Failure Period.)

3) MCBF: 52,000,000 lines (This is an average failure interval based on failures r elating to wearout

and random failures up to the life of 15 million lines.)

1.12 Environmental Conditions

1) Temperature: Operating: 5 to 45°C {41 to 113°F} Storage: -10 to 50°C {14 to 122°F} (except for paper)

2) Humidity: Operating: 10 to 90% RH Storage: 10 to 90% RH (except for paper)

Ambient temperature

[˚C]

[% RH]

Relative humidity

Operating environment range

34 ˚C, 90 %

40 ˚C, 65 %

45 ˚C, 50 %

10 0

0 10 20 30 40 50

Figure 1.12.1 Operating Temperature and Humidity Range

NOTE: If the printer is not used for a long time with paper installed, some part of the printing may be

light due to the deformation of the paper. If the printer is not used for a long time with paper installed, be sure to feed paper approximately 30 mm {1.18"} before printing.

Page 20

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

10 9

TM-T88III series

Specification

(STANDARD)

3) Vibration resistance: When Packed: Frequency: 5 to 55 Hz

Acceleration: Approximately 19.6 m/s

{2 G} Sweep: 10 minutes (half cycle) Duration: 1 hour Directions: x, y, and z

No external or internal damage should be f ound after the vibr ation test,

and the unit should operate normally.

4) Impact resistance: When Packed: Package: EPSON standard package Height: 60 cm {23.6"} Directions: 1 corner, 3 edges, and 6 surfaces

No external or internal damage should be found after the

drop test, and the unit should operate normally.

When unpacked: Height: 5 cm {1.97"}

Directions: Lift one edge and release it (for all 4 edges).

W hen the printer is not printing, no external or internal dam age should

be found after the drop test.

5) Acoustic noise(Operating): When using autocutter: Approximately 55 dB (Bystander position) When not using autocutter: Approximately 45 dB (Bystander position)

1.13 Installation

The TM-T88III series printer must be installed horizontally. (Vibration during paper cutting and using a drawer should be c onsidered. T ake m easures to prevent

the printer from moving. Affixing tapes are provided as an option.) An optional hanging bracket can attach the printer to a wall. (Following the proc edures describes in

the installation manual, install the wall mount and change the location of the paper roll near - end sens or , then install the paper roll stopper and other parts.)

Page 21

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

11 10

TM-T88III series

Specification

(STANDARD)

2. CONFIGURATION

2.1 Interface

2.1.1 RS-232 serial interface

2.1.1.1 Specifications

Data transmission: Serial Synchronization: Asynchronous Handshaking: DTR/DSR or XON/XOFF control Signal levels: MARK = -3 to -15 V: Logic "1"/ OFF

SPACE = +3 to +15 V: Logic "0"/ ON Baud rate: 4800, 9600, 19200, 38400 bps

[bps: bits per second] Data word length: 7 or 8 bits Parity Settings: None, even, odd Stop bits: 1 or more Connector (printer side): Female DSUB-25 pin connector

NOTES: • The data word length, baud rate, and parity depend on the DIP switch settings. (Refer to

Section 3.3.3.)

• The stop bit for the printer side is fixed to 1.

2.1.1.2 Switching between online and offline

The printer does not have an online/offline switch. The printer goes offline:

1) Between when the power is turned on (including reset using the interface) and when the printer is ready to receive data.

2) During the self-test.

3) When the cover is open.

4) During paper feeding using the paper feed button.

5) W hen the printer stops printing due to a paper-end (in cases when an empty paper supply is detected by either paper roll end detector or the paper roll near-end detector with a printing halt feature by ESC c 4).

6) During macro executing standby status.

7) When a temporary abnormality occurs in the power supply voltage.

8) When an error has occurred.

Page 22

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

12 11

TM-T88III series

Specification

(STANDARD)

2.1.1.3 Interface connector terminal assignments and signal functions

Interface connector terminal assignments and signal functions are described in Table 2.1.1.

Table 2.1.1 TM-T88III Printer Status and Signals

Pin number

Signal name

Signal direction

Function

1 FG — Frame ground 2 TXD Output Transmit data 3 RXD Input Receive data 4 RTS Output Same as DTR signal 6 DSR Input This signal indicates whether the host computer can receive data.

SPACE indicates that the host computer can receive data, and MARK indicates that the host computer cannot receive data.

When DTR/DSR control is selected, the printer transmits data after confirming this signal (except when transmitting data by DLE EOT, and GS a).

When XON/XOFF control is selected, the printer does not check this signal.

Changing the DIP switch setting enables this signal to be used as a reset signal for the printer (refer to Section 3.3.3).

The printer is reset when the signal remains MARK for 1 ms or more. (refer to Section 2.1.1.7)

7 SG — Signal ground

20 DTR Output 1) When DTR/DSR control is selected, this signal indicates whether the

printer is busy. SPACE indicates that the printer is ready to receive data, and MARK indicates that the printer is busy. The busy condition can be changed by using DIP SW 2-1 as follows (refer to Section 3.3.3):

DIP SW 2-1 status

Printer status ON OFF

1. During the period from when the power is turned on (including resetting using the interface) to when the printer is ready to receive data.

BUSY BUSY

2. During the self-test. BUSY BUSY

3. When the cover is open. — BUSY

4. During paper feeding using the paper feed button.

— BUSY

5. When the printer stops printing due to a paper-end.

— BUSY

6. During macro executing standby status. — BUSY

7. When a temporary abnormality occurs in the power supply voltage.

— BUSY

Offline

8. When an error has occurred. — BUSY

9. When the receive buffer becomes full.(*1) BUSY BUSY

Page 23

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

13 12

TM-T88III series

Specification

(STANDARD)

Table 2.1.1 TM-T88III Printer Status and Signals (Continued)

Pin number

Signal name

Signal direction

Function

2) When XON/XOFF control is selected: The signal indicates whether the printer is correctly connected and

is ready to receive data. SPACE indicates that the printer is ready to receive data. The signal is always SPACE except in the following cases:

• During the period from when the power is turned on to when the printer is ready to receive data

• During the self-test

25 INIT Input Changing the DIP switch setting enables this signal to be used as a

reset signal for the printer. The printer is reset when the signal remains SPACE for 1 ms or more.

*1 • Definition of “receive buffer full”

• When the receive buffer capacity is specified to 4 KB (DIP SW1-2 is Off):

• If the DIP SW2- 5 is off, when the rem aining space in the rec eive buffer drops to 128 bytes,

the printer status becomes “buffer full” and it remains “buffer full” until the space in the receive buffer increases to 256 bytes.

• If the DIP SW2- 5 is on, when the remaining spac e in the receive buffer drops to 128 bytes, the printer status becomes “buffer full” and it remains “buffer full” until the space in the receive buffer increases to 138 bytes.

• When the receive buffer capacity is specified to 45 bytes (DIP SW1-2 is On):

• Regardless of the DIP SW2-5 setting, when the rem aining space in the r eceive buff er dr ops

to 16 bytes, the printer status becomes “buffer f ull” and it remains “buffer f ull” until the spac e in the receive buffer increases to 26 bytes.

• The printer ignores the data received when the remaining space in the receive buffer is 0 bytes.

2.1.1.4 XON/XOFF transmit timing

When XO N/X OF F c ontr ol is s elec ted, the printer tr ansmits XON or XOF F s ignals as follows. Transmit timing differs depending on the DIP SW2-1 setting.

Table 2.1.2 XON/XOFF Transmit Timing

DIP SW 2-1 status

Printer status

ON OFF XON transmission

① When the printer goes online after turning on the power (or

reset using interface)

Transmit Transmit

② When the receive buffer is released from the buffer full state

Transmit Transmit

③ When the printer switches from offline to online

— Transmit

④ When the printer recovers from an error using the

DLE ENQ 1 or DLE ENQ 2 commands

— Transmit

⑤ When the receive buffer becomes full

Transmit Transmit

XOFF Transmission

⑥ When the printer switches from online to offline

— Transmit NOTES: • The XON code is <11>H and the XOFF code is <13>H.

• In case

③, XON is not transmitted when the receive buffer is full.

• In case

⑥, XOFF is not transmitted when the receive buffer is full.

Page 24

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

14 13

TM-T88III series

Specification

(STANDARD)

2.1.1.5 Serial interface connection example

Host side Printer side (DTE ex.8251)

TXD ....................................RXD

DSR....................................DTR

CTS ....................................RTS

RXD....................................TXD

DTR....................................DSR

FG.......................................FG

SG ......................................SG

NOTES: • Set the handshaking so that the transmit data can be received.

• Transmit data to the printer after turning on the power and initializing the printer.

2.1.1.6 Notes on setting DIP switch 2-1 to ON

1) The printer mechanism stops but does not becom e busy when: an error has occ urred, the c over is open, printing stops due to a paper-end, or paper is fed using the paper feed button.

2) W hen setting DIP switch 2-1 to ON to enable handshaking with the printer, be sure to chec k the printer status using the GS a command and the ASB function. In this setting, the default value of n for GS a is 2. The printer autom atically transmits the printer s tatus, depending on online/offline changes.

3) When using DLE EOT, DLE ENQ, and DLE DC4 be sure that the receive buff er does not becom e full.

• When using a host that cannot transmit data when the printer is busy: If an error has occurred, DLE EOT, DLE ENQ , and DLE DC4 cannot be us ed when the printer

is busy due to a receive buffer-full state.

• When using a host that can transmit data when the printer is busy: W hen the receive buffer becomes full while transmitting bit-im age data, DLE EOT, DLE ENQ

or DLE DC4 used while sending the bit-image data is processed as bit-im age data. The data transmitted when the receive buffer is full may be lost.

Example: Check the printer status using GS r after transmitting each line of data and use

the 4 KB receive buffer. Transmit one line of data so that the receive buffer does not become full.

2.1.1.7 Notes on Resetting the Printer Using the Interface

The printer can be reset using interface pins 6 and 25 by changing the DIP switch setting (refer to Section 3.3.3, DIP switch 2).

Table 2.1.3 Reset Switching

Signal Line DIP Switch Reset Condition Pin 6 (DSR) DSW 2-7: ON MARK level input

Pin 25 (INIT) DSW 2-8: ON SPACE or TTL-HIGH level input

Page 25

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

15 14

TM-T88III series

Specification

(STANDARD)

To reset the printer, the following requirements must be satisfied.

• DC characteristics:

Table 2.1.4 Reset DC Characteristics

Pin 6 (DSR) Pin 25 (INIT) Reset active voltage VA -15 to -3 V +2 to +15 V

Reset negative voltage VN +3 to +15 V -15 to + 0.8 V Reset active current IA -5.3 mA (maximum) 1 mA (maximum) Reset negative current IN -5.0 mA (maximum) -2 mA (maximum) Input impedance RIN

3 kΩ (minimum)

• AC characteristics: Minimum reset pulse width: T

RS 1 ms (minimum)

• When using pin 6 (DSR) (DIP switch 2-7 is ON):

TRS

Figure 2.1.1 Minimum Reset Pulse Width (pin 6)

• When using pin 25 (INIT) (DIP switch 2-8 is ON):

TRS

Figure 2.1.2 Minimum Reset Pulse Width (pin 25)

NOTES: • When a signal that does not satisfy the requirements above is input, printer operation is

not guaranteed. When a signal is input to pin 25 (INIT) at the TTL level, the requirements above must also be satisfied. Although a signal is input to pin 6 (DSR) at the TTL level, according to the DC characteristics described above, the operation is not guaranteed and pin 6 cannot be controlled.

• When pin 6 (DSR) and pin 25 (INIT) are open, the printer is operating.

SPACE

MARK

TRS

SPACE (H)

MARK (L)

TRS

Page 26

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

16 15

TM-T88III series

Specification

(STANDARD)

2.1.2 IEEE 1284 Bidirectional Parallel I nt erf ace

2.1.2.1 Compatibility Mode

(Data Transmission from Host to Printer: Centronics compatible)

1) Outline Compatibility mode supports the compatibility with Centronics parallel interface.

2) Specifications Data transmission: 8-bit Parallel Synchronization: Externally supplied nStrobe signals Handshaking: nAck and Busy signals Signal levels: TTL compatible Connector: ADS-B36BLFDR176 (Honda) or equivalent (IEEE 1284 Type B)

3) Switching between online and offline The printer is not equipped with any online/offline switch. T he printer is placed into offline s tatus

in either of the followings:

1) W hen the power is turned on or until the printer becom es ready for data transm ission after it is initialized by the reset signal (nInit) from the interface.

2) During the self-test.

3) When the cover is open.

4) During paper feeding using the paper feed button.

5) When the printer stops printing due to a paper-end (in cases when em pty paper s upply is detected by either the paper roll end detector or the paper roll near-end detector with a printing halt due to paper shortage enabled by ESC c 4).

6) During macro executing standby status.

7) When a temporary abnormality occurs in the power supply voltage.

8) When an error has occurred.

2.1.2.2 Reverse Mode (Data Transmission from Printer to Host)

The STATUS data transmission from the printer to the host is proceeded in the Nibble or Byte mode.

• Description This mode allows data transmission from the asynchronous printer under the control of the host. Data transmissions in the Nibble Mode are made via the existing control lines in units of f our bits

(Nibble). In the Byte Mode, data transmissions are proceeded by making the eight-bits data lines bidirectional. The both modes fail to be proc eeded concurrently with the Compatibility Mode, thereby causing half duplex transmission.

Page 27

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

17 16

TM-T88III series

Specification

(STANDARD)

2.1.2.3 Interface Pin Assignments for Each Mode

Pin Source Compatibility Mode Nibble Mode Byte Mode

1 Host nStrobe HostClk HostClk 2 Host/Ptr Data0(LSB) Data0(LSB) Data0(LSB) 3 Host/Ptr Data1 Data1 Data1 4 Host/Ptr Data2 Data2 Data2 5 Host/Ptr Data3 Data3 Data3 6 Host/Ptr Data4 Data4 Data4 7 Host/Ptr Data5 Data5 Data5 8 Host/Ptr Data6 Data6 Data6

9 Host/Ptr Data7(MSB) Data7(MSB) Data7(MSB) 10 Printer nAck PtrClk PtrClk 11 Printer Busy PtrBusy/Data3, 7 PtrBusy 12 Printer PError AckDataReq/Data2, 6 AckDataReq 13 Printer Select Xflag/Data1, 5 Xflag 14 Host nAutoFd HostBusy HostBusy 15 NC ND ND 16 GND GND GND 17 FG FG FG 18 Printer Logic-H Logic-H Logic-H 19 GND GND GND 20 GND GND GND 21 GND GND GND 22 GND GND GND 23 GND GND GND 24 GND GND GND 25 GND GND GND 26 GND GND GND 27 GND GND GND 28 GND GND GND 29 GND GND GND 30 GND GND GND 31 Host nInit nInit nInit 32 Printer nFault nDataAvail/Data0, 4 nDataAvail 33 GND ND ND 34 Printer DK_STATUS ND ND 35 Printer +5V ND ND 36 Host nSelectIn 1284-Active 1284-Active

*NC: Not Connected

ND: Not Defined

Page 28

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

18 17

TM-T88III series

Specification

(STANDARD)

NOTES: 1. A prefix “n” to signal names refers to “L” active signals. To the host provided with none of

the signal lines listed above, both-way communication fails.

2. For interfacing, signal lines shall use twisted pair cables with the return sides connected to signal ground level.

3. Interfacing conditions shall be all based on the TTL level to meet the characteristics described below. In addition, both rise time and fall time of each signal shall be

0.5 µs or less.

4. Data transmission shall not ignore the signal nAck or Busy. An attempt to transmit data with either signal, nAck or Busy, ignored can cause lost data. (Data transmissions to the printer shall be made after verifying the nAck signal or while the Busy signal is at the “L” level.)

5. Interface cables shall be as minimum required short in length as possible.

2.1.2.4 Electrical Characteristics DC Characteristics (Except Logic-H, +5 V signals)

Specifications

Characteristics Symbol

Min Max

Conditions

Output HIGH voltage VOH *2.4 V 5.5 V *IOH=0.32 mA Output LOW voltage VOL -0.5 V *0.4 V *IOL=-12 mA Output HIGH current IOH 0.32 mA - VOH=2.4 V Output LOW current IOL -12 mA - VOL=0.4 V Input HIGH voltage VIH 2.0 V - Input LOW voltage VIL - 0.8 V Input HIGH current IIH - -0.32 mA VIH=2.0 V Input LOW current IIL - 12 mA VIL=0.8 V

Logic-H Signal Sender Characteristics

Specifications

Characteristics Symbol

Min Max

Conditions

Output HIGH voltage Output LOW voltage

VOH

3.0 V

5.5 V

2.0 V

While the power is OFF

+5 V Signal Sender Characteristics

Specifications

Characteristics Symbol

Min Max

Conditions

Output HIGH voltage VOH *2.4 V 5.5 V *IOH=0.32 mA Output LOW voltage VOL - - ** While the power is OFF Output HIGH current IOH - 0.32 mA VOH=2.4 V Output LOW current IOL - ** - While the power is OFF

** No guarantee is offered to VOL and IOL while the power is OFF.

Page 29

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

19 18

TM-T88III series

Specification

(STANDARD)

2.1.2.5 Data Receiving Timing (Compatibility Mode)

DATA Data n Data n+1

nStrobe

Busy Peripheral Busy

nAck

tHold

tSTB tSetup

tBUSYtReady

tNext

tnBUSYtACK tReply

Specifications

Characteristics Symbol

Min[ns] Max[ns]

Data Hold Time (host) tHold 750 -Data Setup Time tSetup 750 -STROBE Pulse Width tSTB 750 -READY Cycle Idle Time tReady 0 -BUSY Output Delay Time tBUSY 0 500 Data Processing Time tReply 0

∞

ACKNLG Pulse Width tACK 500

10µs

BUSY Release Time tnBUSY 0

∞

ACK Cycle Idle Time tNext 0 --

*The printer latches data at a nStrobe ↓ timing

Page 30

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

20 19

TM-T88III series

Specification

(STANDARD)

2.1.2.6 Notes on resetting the printer through the interface

To enable the printer reset in compatibility mode, the following signal timing shall be satisfied. However, the printer reset is ignored when the signal nSelectln (#36 pin, 1284-Ac tie high) is active in reverse mode.

• DC characteristic: TTL level

• AC characteristics: Minimum reset pulse width: TRS 50 µs (min.) Trailing edge period: tf 500 ns (max.) Leading edge period: tr 500 ns (max.)

nInit

nSelectIn

(1284-Active)

min.0

TRS

min.1ms

Page 31

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

21 20

TM-T88III series

Specification

(STANDARD)

2.1.2.7 Reception of status from the printer through the bidirectional parallel interface

In the bidirectional parallel interface spec ifications, the printer status transmiss ion is available by using the both-way communication facility in the Nibble/Byte Modes in accordance with the IEEE 1284.

In this case, different from in the RS-232 s erial interface spec ifications, the real- time interruptions from the printer to the host are disabled and thus precautions must be taken to the followings.

1) Allowable capacity of the printer internal buffer is 99 bytes (except ASB status). The status

signals exceeding this capacity will be discarded. To prevent possible loss of status, the host shall be ready for data acception (Reverse Mode).

2) When ASB is used, the host is preferably in the wait state for data acception (Rever se Idle Mode).

When this state is not available, the host shall enter the Reverse Mode to always monitor the presence of data.

3) When ASB is used, preference shall be given to the ASB status f or transmission over the other

status signals. Any accumulated ASB status signals left for transmission from the last to the newest ASB status transmission shall be transmitted together at a time as one ASB status showing the presence of change, followed by the latest ASB status.

Example: In the normal (wait) state, the ASB status is configured as follows.

First Status Second Status Third Status Fourth Status

0001 1000 0000 0000 0000 0000 0000 0000

When a sequence of operations ar e proceeded, the near end is detected and the printer cover is opened, then the printer cover is closed, the following pieces of data are accumulated.

First Status Second Status Third Status Fourth Status

①

0001 1000 0000 0000 0000 0011 0000 0000 Near end detection

②

0011 1000 0000 0000 0000 0011 0000 0000 The printer cover is opended.

③

0001 1000 0000 0000 0000 0011 0000 0000 The printer cover is closed.

When the ASB status is received following this, a total of eight (8) bytes of ASB will be transmitted as follows.

Accumulated ASB (

①+②+③)

First Status Second Status Third Status Fourth Status

Accumulated ASB (①+②+③)

0011 1000 0000 0000 0000 0011 0000 0000

First Status Second Status Third Status Fourth Status

The latest ASB (③)

0001 1000 0000 0000 0000 0011 0000 0000

Fourth Status

2.1.2.8 Notes on setting DIP switch 2-1 to ON

Refer to Section 2.1.1.6.

Page 32

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

22 21

TM-T88III series

Specification

(STANDARD)

2.1.3 RS-485 Serial Interface

(An RS-485 serial is a factory option.)

2.1.3.1 Specifications (RS-485 compatible)

Data transmission: Serial Synchronization: Asynchronous Handshaking: Depend on the DIP switch settings

(DTR/DSR or XON/XOFF control) Signal levels: 2.0 to 5.0 V: Logic 1

0.0 to 0.8 V: Logic 0 Baud rates: 4800, 9600, 19200, 38400 bps Data word lengths: 7 or 8 bits Parity settings: None, even, odd Stop bits: 1 or more Connector (printer side): Female D-SUB25 pin connector

NOTES: • The handshaking data word length, baud rate, and parity depend on the DIP switch

(Refer to Section 3.3.3)

• Data transmitted from the printer has 1 stop bit (fixed). DR1 > DR2 CS1 > CS2 indicates that:

Channel 1 is high. Channel 2 is low.

DR1 < DR2 CS1 < CS2 indicates that:

Channel 2 is high. Channel 1 is low.

CS1 CS2 Function H L Communication is available

L H Communication is not available

NOTE: • If the electric potential of CS1 is higher than that of CS2, the printer is ready for

communication (the host is ready to receive data). If the electric potential of CS1 is lower than that of CS2, the printer is not ready for communication (the host is not ready

to receive data). DR1 DR2 Function H L Communication is available

L H Communication is not available

NOTE: • If the electric potential of DR1 is higher than that of DR2, the printer is ready for

communication (the host is ready to receive data). If the electric potential of DR1 is

lower than that of DR2, the printer is not ready for communication (the host is not ready

to receive data).

Page 33

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

23 22

TM-T88III series

Specification

(STANDARD)

2.1.3.2 Switching between online and offline

The printer does not have an online/offline switch. The printer goes offline:

1) Between when the power is turned on (including reset using the interface) and when the printer is ready to receive data.

2) During the self-test.

3) When the cover is open.

4) During paper feeding using the paper feed button.

5) When the printer stops printing due to paper-end (in cases when an empty paper supply is detected by either paper roll and detector or the paper roll near-end detector with a printing halt feature set enabled due to paper shortage by ESC c 4).

6) During macro executing standby status.

7) When a temporary abnormality occurs in the power supply voltage.

8) When an error has occurred.

9) When the receive buffer becomes full. (*1)

*1 • Definition of “receive buffer full”

• When the receive buffer capacity is specified to 4 KB (DIP SW1-2 is Off):

• If the DIP SW2- 5 is off, when the rem aining space in the rec eive buffer drops to 128 bytes,

the printer status becomes “buffer full” and it remains “buffer full” until the space in the receive buffer increases to 256 bytes.

• When the receive buffer capacity is specified to 45 bytes (DIP SW1-2 is On):

• Regardless of the DIP SW2-5 setting, when the rem aining space in the r eceive buff er dr ops

to 16 bytes, the printer status becomes “buffer f ull” and it remains “buffer f ull” until the spac e in the receive buffer increases to 26 bytes.

• The printer ignores the data received when the remaining space in the receive buffer is 0 bytes.

* For notes on setting DIP switch 2-1 to ON, refer to Section 2.1.1.6.

Page 34

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

24 23

TM-T88III series

Specification

(STANDARD)

2.1.3.3 Interface pin assignments Table 2.1.5 TM-T88III Printer Status and Signals

Pin Number

Signal name

Signal direction

Function

1 FG -- Frame ground 2

SD1 SD2

Output Transmit data

4 5

RD1 RD2

Input Receive data

7 SG -- Signal ground 8

DR1 DR2

Output When DTR/DRS is selected, this signal indicates whether the host

computer is BUSY or READY.

1) DR1>DR2 indicates that the printer is READY and DR1<DR2 indicates that the printer is BUSY. The BUSY condition can be changed depending on the offline conditions set by the DIP switches (refer to Section 3.3.3). When the DTR/DSR control is selected, the printer becomes the BUSY state (DR1<DR2) under the following conditions.

DIP SW 2-1 status

Printer status

ON OFF

1. During the period from when the power is turned on (including resetting using the interface) to when the printer is ready to receive data.

BUSY BUSY

2. During the self-test. BUSY BUSY

3. When the cover is open. — BUSY

4. During paper feeding using the paper feed button.

— BUSY

5. When the printer stops printing due to a paper-end. (only when the paper roll is not present)

— BUSY

6. During macro executing standby status. — BUSY

7. When a temporary abnormality occurs in the power supply voltage.

— BUSY

Offline

8. When an error has occurred. — BUSY

9. When the receive buffer becomes full.(*1) BUSY BUSY

2) When XON/XOFF control is selected: The signal indicates whether the printer is correctly connected and is ready to receive data. SPACE indicates that the printer is ready to receive data. The signal is always DR1>DR2 (READY) indicates that the printer is ready to receive data. The signal is always DR1>DR2 except in the following cases:

• During the period from when the power is turned on to when the printer is ready to receive data

• During the self-test

Page 35

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

25 24

TM-T88III series

Specification

(STANDARD)

Table 2.1.5 TM-T88III Printer Status and Signals (Continued)

Pin Number

Signal name

Signal direction

Function

10 11

CS1 CS2

Input This signal indicates whether the host computer is BUSY or READY.

CS1>CS2 indicates that the printer is READY and CS1<CS2 indicates that the printer is BUSY.

1) When DTR>DSR is selected: The signal is checked and data is transmitted only when the host is ready to receive data (READY) (except for transmitted by DLE EOT or GS a).

2) When XON/XOFF control is selected: Transmits data regardless of the status of this signal.

*1 • Definition of “receive buffer full”

• When the receive buffer capacity is specified to 4 KB (DIP SW1-2 is Off):

• If the DIP SW2- 5 is off, when the rem aining space in the rec eive buffer drops to 128 bytes,

the printer status becomes “buffer full” and it remains “buffer full” until the space in the receive buffer increases to 256 bytes.

• When the receive buffer capacity is specified to 45 bytes (DIP SW1-2 is On):

• Regardless of the DIP SW2-5 setting, when the rem aining space in the r eceive buff er dr ops

to 16 bytes, the printer status becomes “buffer f ull” and it remains “buffer f ull” until the spac e in the receive buffer increases to 26 bytes.

• The printer ignores the data received when the remaining space in the receive buffer is 0 bytes.

Page 36

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

26 25

TM-T88III series

Specification

(STANDARD)

2.1.3.4 XON/XOFF transmit timing

Refer to Section 2.1.1.4. For the DIP switch settings of the offline status, refer to Section 2.1.1.6.

2.1.3.5 Data format when using RS-485

Transmission data (8 bits, none parity)

START

STOP

123 45678

RS-485 Communication data format

“H” indicates <Printer transmission data> SD1<SD2

<Printer reception data> RD1<RD2 “L” indicates: <Printer transmission data> SD1>SD2

<Printer reception data> RD1>RD2 The transmission data is H = 1, L = 0

NOTE: This format is used when the UART for RS-232 is connected to the RS-485 driver.

Printer Reception Data Level

DR1 DR2 Read data

H L Receiving data line is low level L H Receiving data line is high level

Printer Transmission Data Level

SD1 SD2 Send data

H L Sending data line is low level L H Sending data line is high level

2.1.4 Other Interfaces

Various interface boards (EPSON UB series) can be used.

Page 37

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

27 26

TM-T88III series

Specification

(STANDARD)

2.2 Connectors

2.2.1 Interface Connectors

Refer to Section 2.1, Interface.

2.2.2 Power Supply Connector

This connector is used to connect the printer to an external power source.

1) Pin assignments: Refer to Table 2.2.1.

Table 2.2.1 Power Supply Connector Pin Assignments

Pin Number Signal Name

1 +24 V 2 GND 3 NC

SHELL F.G.

SHELL

Figure 2.2.1 Power Supply Connector

NOTE: Be sure to ground the metal of the interface using the hole for the frame ground.

2) Connector model: Printer side: Hosiden TCS7960-532010 or equivalent User side: Hosiden TCP8927-631100 or equivalent

Hosiden TCP8927-531100 or equivalent

Page 38

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

28 27

TM-T88III series

Specification

(STANDARD)

2.2.3 Drawer Kick-out Connector (Modular Connector)

The pulse specified by ESC p or DLE DC4 is output to this connector. The host can confirm the status of the input signal by using the

DLE EOT, GS a, or GS r commands.

1) Pin assignments: Refer to Table 2.2.2

Table 2.2.2 Drawer Kick-out Connector Pin Assignments

Pin Number Signal Name Direction

1 Frame GND — 2 Drawer kick-out drive signal 1 Output 3 Drawer open/close signal Input 4 +24 V — 5 Drawer kick-out drive signal 2 Output 6 Signal GND —

+24 V is output through pin 4 when the power is turned on. However, pin 4 m ust be used only for the drawer.

Figure 2.2.2 Drawer Kick-out Connector

2) Connector model: Printer side: MOLEX 52065-6615 or equivalent User side: 6-position 6-contact (RJ12 telephone jack)

3) Drawer kick-out drive signal Output signal: Output voltage: Approximately 24 V

Output current: 1 A or less

CAUTION: To avoid an overcurrent, the resistance of the drawer kick-out solenoid must be 24 Ω

or more.

Output waveform: Outputs the waveforms in Figure 2.2.3 to the points A and B in

Figure 2.2.4.

t1 (ON time) and t2 (OFF time) are specified by ESC p or DLE DC4.

t 1x 2 msec

Figure 2.2.3 Drawer Kick-out Drive Signal Output Waveform

t2 x 2 mst1 x 2 ms

Page 39

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

29 28

TM-T88III series

Specification

(STANDARD)

4) Drawer open/close signal Input signal level (connector pin 3): "L" = 0 to 0.8 V

"H" = 2 to 5 V

Drawer kick-out connector

F. G

P-GND

Printer side User side (Drawer kick-out side)

+24V

With shielded

Drawer kick-out solenoid

Drawer open/close switch

Figure 2.2.4 Drawer Circuitry

NOTES: 1. Use a shielded cable for the drawer connector cable.

2. Two driver transistors cannot be energized simultaneously.

3. The drawer drive duty must be as shown below.

ON time

(ON time + OFF time)

≤ 0.2

4. Be sure to use the printer power supply (connector pin 4) for the drawer power source.

5. The resistance of the drawer kick-out solenoid must not be less than the specified.

Otherwise, an overcurrent could damage the solenoid.

6. Do not connect telecommunication network to the drawer kick-out connector.

Page 40

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

30 29

TM-T88III series

Specification

(STANDARD)

3. FUNCTIONS

3.1 List of commands

Command classification

Command Name

Executing Setting

Standard mode

Page mode

GS P

function

Horizontal tab

{

{ {

Print and line feed

{

{ {

Print and return to standard mode (in page mode)

{

Ignored

{

Print and carriage return

{

{ {

CAN

Cancel print data in page mode

{

Ignored

{

DLE EOT

Real-time status transmission

{

{ {

DLE ENQ

Real-time request to printer

{

{ {

DLE DC4

Generate pulse at real-time

{

{ {

ESC FF

Print data in page mode

{

Ignored

{

ESC SP

Set right-side character spacing

{ { { {

ESC !

Select print mode(s)

{ { {

ESC $

Set absolute print position

{

{ { {

ESC %

Select/cancel user-defined character set

{ { {

ESC &

Define user-defined characters

{ { {

ESC ∗∗∗∗

Select bit-image mode

{

{ {

ESC -

Turn underline mode on/off

{ { {

ESC 2

Select default line spacing

{ { {

ESC 3

Set line spacing

{ { { {

ESC =

Select peripheral device

{ { {

ESC ?

Cancel user-defined characters

{ { {

ESC @

Initialize printer

{ { { {

ESC D

Set horizontal tab positions

{ { {

ESC E

Turn emphasized mode on/off

{ { {

ESC G

Turn double-strike mode on/off

{ { {

ESC J

Print and feed paper

{

{ { {

ESC L

Select page mode

{

({) Ignored

ESC M

Select character font

{ {

ESC R

Select an international character set

{ { {

ESC S

Select standard mode

{

Ignored

{

ESC T

Select print direction in page mode

{

▲

{

ESC V

Turn 90° clockwise rotation mode on/off

{ {

▲

Page 41

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

31 30

TM-T88III series

Specification

(STANDARD)

Command

classification

Command

Name

Executing Setting

Standard

mode

Page

mode

GS P

function

ESC W

Set printing area in page mode

{

▲

{ {

ESC \

Set relative print position

{

{ { {

ESC a

Select justification

{

({)

▲

ESC c 3

Select paper sensor(s) to output paper-end signals

{ { {

ESC c 4

Select paper sensor(s) to stop printing

{ { {

ESC c 5

Enable/disable panel buttons

{ { {

ESC d

Print and feed n lines

{

{ {

ESC p

General pulse

{

{ {

ESC t

Select character code table

{ { {

ESC {

Turn upside-down printing mode on/off

{

({)

▲

FS g 1

Write to NV user memory

{ {

Disabled

FS g 2

Read from NV user memory

{

{ {

FS p

Print NV bit image

{

Disabled

FS q

Define NV bit image

{

({)

Disabled

GS !

Select character size

{ { {

GS $

Set absolute vertical print position in page mode

{

Ignored

{ {

GS ∗∗∗∗

Define downloaded bit image

{ { {

GS ( A

Execute test print

{

Disabled

GS /

Print downloaded bit image

{

●

{

GS :

Start/end macro definition

{ { { {

GS B

Turn white/black reverse printing mode on/off

{ { {

GS H

Select printing position of HRI characters

{ { {

GS I

Transmit printer ID

{

{ {

GS L

Set left margin

{

({)

▲

{

GS P

Set horizontal and vertical motion units

{ { {

GS V

Select cut mode and cut paper

{

({)

{ {

GS W

Set printing area width

{

({)

▲

{

GS \

Set relative vertical print position in page mode

Ignored

{ {

GS ^

Execute macro

{

{ {

GS a

Enable/disable Automatic Status Back (ASB)

{ { { {

GS b

Turn smoothing mode on/off

{ { {

GS f

Select font for HRI characters

{ { {

Page 42

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

32 31

TM-T88III series

Specification

(STANDARD)

Command classification

Command

Name

Executing Setting

Standard mode

Page mode

GS P function

GS h

Set bar code height

{ { {

GS k

Print bar code

{

●

{

GS r

Transmit status

{

{ {

GS v 0

Print raster bit image

{

●

Disabled

GS w

Set bar code width

{ { {

Kanji command list (when the Japanese, Simplified Chinese, Traditional Chinese, or Korean model is used)

Command classification

Command

Name

Executing Setting

Standard mode

Page mode

GS P function

FS !

Set print mode(s) for Kanji characters

{ { {

FS &

Select Kanji character mode

{ { {

FS –

Turn underline mode on/off for Kanji characters

{ { {

FS .

Cancel Kanji character mode

{ { {

FS 2

Define user-defined Kanji characters

{ { {

FS C

Select Kanji character code system

{ { {

FS S

Set Kanji character spacing

{ { { {

FS W

Turn quadruple-size mode on/off for Kanji characters

{ { {

Command classification

Executing: Printer executes the command, which does not then affect the following data. Setting: Printer uses flags to make settings, and those settings affect the following data.

Standard mode

{: Enabled. ({): Enabled only when the command is set at the beginning of a line.

●: Enabled only when data is not present in the printer buffer.

Page mode

{: Enabled.

▲: Only value setting is possible.

Disabled: Parameters are processed as printable data. Ignored: All command codes including parameters are ignored and nothing is executed.

Page 43

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

33 32

TM-T88III series

Specification

(STANDARD)

3.2 Character Code Tables

3.2.1 Page 0 (PC437: USA, Standard Europe) (International Character Set: U.S.A.)

CAN

DC4

NOTE: The character code tables show only character configurations. They do not show the actual

print pattern.

Page 44

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

34 33

TM-T88III series

Specification

(STANDARD)

3.2.2 Page 1 (Katakana)

Page 45

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

35 34

TM-T88III series

Specification

(STANDARD)

3.2.3 Page 2 (PC850: Multilingual)

Page 46

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

36 35

TM-T88III series

Specification

(STANDARD)

3.2.4 Page 3 (PC860: Portuguese)

Page 47

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

37 36

TM-T88III series

Specification

(STANDARD)

3.2.5 Page 4 (PC863: Canadian-French)

Page 48

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

38 37

TM-T88III series

Specification

(STANDARD)

3.2.6 Page 5 (PC865: Nordic)

Page 49

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

39 38

TM-T88III series

Specification

(STANDARD)

3.2.7 Page 16 (WPC1252)

Page 50

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

40 39

TM-T88III series

Specification

(STANDARD)

3.2.8 Page 17 (PC866: Cyrillic#2)

Page 51

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

41 40

TM-T88III series

Specification

(STANDARD)

3.2.9 Page 18 (PC852: Latin2)

Page 52

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

42 41

TM-T88III series

Specification

(STANDARD)

3.2.10 Page 19 (PC858)

Page 53

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

43 42

TM-T88III series

Specification

(STANDARD)

3.2.11 Page 20 (Thai character code 42)

Page 54

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

44 43

TM-T88III series

Specification

(STANDARD)

3.2.12 Page 21 (Thai character code 11)

Page 55

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

45 44

TM-T88III series

Specification

(STANDARD)

3.2.13 Page 22 (Thai character code 13)

Page 56

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

46 45

TM-T88III series

Specification

(STANDARD)

3.2.14 Page 23 (Thai character code 14)

Page 57

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

47 46

TM-T88III series

Specification

(STANDARD)

3.2.15 Page 24 (Thai character code 16)

Page 58

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

48 47

TM-T88III series

Specification

(STANDARD)

3.2.16 Page 25 (Thai character code 17)

Page 59

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

49 48

TM-T88III series

Specification

(STANDARD)

3.2.17 Page 26 (Thai character code 18)

Page 60

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

50 49

TM-T88III series

Specification

(STANDARD)

3.2.18 Page 255 (Space Page)

Page 61

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

51 50

TM-T88III series

Specification

(STANDARD)

3.2.19 International Character Set

ASCII code (Hex)

Country

23 24 40 5B 5C 5D 5E 60 7B 7C 7D 7E U.S.A # $ @ [ \ ] ^ ` { | } ~ France # $ à ° ç § ^ ` é ù è ¨ Germany # $ § Ä Ö Ü ^ ` ä ö ü ß U.K. £ $ @ [ \ ] ^ ` { | } ~ Denmark I # $ @ Æ Ø Å ^ ` æ ø å ~ Sweden # ¤ É Ä Ö Å Ü é ä ö å ü Italy # $ @ ° \ é ^ ù à ò è ì Spain I Pt $ @ ¡ Ñ ¿ ^ ` ¨ ñ } ~ Japan # $ @ [ ¥ ] ^ ` { | } ~ Norway # ¤ É Æ Ø Å Ü é æ ø å ü Denmark II # $ É Æ Ø Å Ü é æ ø å ü Spain II # $ á ¡ Ñ ¿ é ` í ñ ó ú Latin America # $ á ¡ Ñ ¿ é ü í ñ ó ú Korea # $ @ [ W ] ^ ` { | } ~

Page 62

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

52 51

TM-T88III series

Specification

(STANDARD)

3.3 Switches and Buttons

3.3.1 Power Button

The power button (a rocker switch) located on the lower right fr ont of the printer turns the power on or off.

NOTE: Turn on the power only after connecting the power supply.

3.3.2 Panel Buttons

1) FEED button: Non-locking push button [Function] • If you push this button once and release it, the printer feeds paper for one line based

on the line spacing set by ESC 2 and ESC 3. However, paper feeding using the FEED button cannot be performed under the following conditions:

① The paper roll end sensor detects a paper end ② When the printer cover is open.

• If you push this button when the printer is in the macro execution standby state, the

defined macro is executed.

• During self-test printing, you can stop the self test temporarily by pressing this button

and restart it by pressing the button again.

NOTE: This button is disabled by ESC c 5.

Page 63

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

53 52

TM-T88III series

Specification

(STANDARD)

3.3.3 DIP Switches

3.3.3.1 Serial interface specification

1) DIP switch 1: 8 switches

Table 3.3.1 DIP Switch 1

SW 1 Function ON OFF

1 Data reception error Ignored Prints '?' 2 Receive buffer capacity 45 bytes 4K bytes 3 Handshaking XON/XOFF DTR/DSR 4 Word length 7 bits 8 bits 5 Parity check Yes No 6 Parity selection Even Odd 7 Transmission speed selection Refer to Table 3.3.2 8

Table 3.3.2 Transmission Speed

Transmission Speed (bps) SW 1-7 SW 1-8

38400 ON ON

4800 OFF ON 9600 ON OFF

19200 OFF OFF

bps: bits per second

Page 64

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

54 53

TM-T88III series

Specification

(STANDARD)

2) DIP switch 2: 8 switches

Table 3.3.3 DIP Switch 2

SW 2 Function ON OFF

1 Handshaking (BUSY condition) • Receive buffer full • Offline

• Receive buffer full

2 Reserved (Do not change settings) --- Fixed to OFF 3 4

Selects print density / Low power consumption mode

Refer to Table 3.3.4

5 Setting the release condition of the

receive buffer BUSY state (this function is effective when the capacity of the receive buffer is set to 4 KB.)

Releases the BUSY state when the remaining capacity of the receive buffer reaches 138 bytes.

Releases the BUSY state when the remaining capacity of the receive buffer

reaches 256 bytes. 6 Reserved (Do not change settings) --- Fixed to Off 7 I/F pin 6 reset signal (*1) Enabled Disabled 8 IF pin 25 reset signal (*2) Enabled Disabled

(*1)(*2) With the RS-485 serial interface specification (a dealer option), DIP Switches 2-7 and 2-8

are disabled.

Table 3.3.4 DIP Switch 2-3 and 2-4

Level Function SW 2-3 SW 2-4

−

Low power consumption mode ON ON 1 Print density (Normal) OFF OFF 2 ON OFF 3 Print density (Dark) OFF ON

NOTES: • Changes in DIP switch settings (excluding switches 2-7 and 2-8 interface reset signals)

are recognized only when the printer power is turned on or when the printer is reset by using the interface. If the DIP switch setting is changed after the printer power is turned on, the change does not take effect until the printer is turned on again or is reset.

• If you turn on DIP switch 2-7 or 2-8 while the printer power is turned on, the printer may be reset, depending on the signal state. DIP switches should not be changed while the printer power is on.

• If the print density is set to level 2 or 3, printing speed is inclined to be low speed.

• In low power consumption, printing speed is fixed to 70 mm/s.

Page 65

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

55 54

TM-T88III series

Specification

(STANDARD)

3.3.3.2 Parallel interface specification Table 3.3.5 DIP Switch 1

SW Function ON OFF

1 Auto line feed Always enabled Always disabled 2 Receive buffer capacity 45 bytes 4 KB

3-8 Undefined --- ---

Table 3.3.6 DIP Switch 2

SW Function ON OFF

1 Handshaking (BUSY condition) • Receive buffer full

• Offline

• Receive buffer full

2 Reserved (Do not change settings) --- Fixed to Off. 3 Refer to Table 3.3.7 4

Selects print density / Low power consumption mode

5 Setting the release condition of the

receive buffer BUSY state (this function is effective when the capacity of the receive buffer is set to 4 KB.)

Releases the BUSY state when the remaining capacity of the receive buffer reaches 138 bytes.

Releases the BUSY state when the remaining capacity of the receive buffer

reaches 256 bytes. 6 Reserved (Do not change settings) --- Fixed to Off. 7 Reserved (Do not change settings) --- Fixed to Off. 8 I/F pin 31 reset signal

(Do not change settings)

Fixed to On ---

Table 3.3.7 DIP Switch 2-3 and 2-4

Level Function SW 2-3 SW 2-4

−

Low power consumption mode ON ON 1 Print density (Normal) OFF OFF 2 ON OFF 3 Print density (Dark) OFF ON

NOTES: • Changes in DIP switch settings (excluding switch 2-8, interface reset signal) are

recognized only when the printer power is turned on or when the printer is reset by using the interface. If the DIP switch setting is changed after the printer power is turned on, the change does not take effect until the printer is turned on again or is reset.

• If the DIP switch 2-8 is turned on while the printer power is turned on, the printer may be reset, depending on the signal state. DIP switches should not be changed while the printer power is on.

• If the print density is set to level 2 or 3, printing speed is inclined to be low speed.

• In a low power consumption, printing speed is fixed to 70 mm/s.

Page 66

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

56 55

TM-T88III series

Specification

(STANDARD)

3.4 Panel LED Indicators

1) Power (POWER) LED: Green On: Power is stable. Off: Power is not stable.

2) Paper roll end (PAPER OUT) LED: Red On: The paper roll near end is detected. Off: Paper is loaded (Normal condition) Blinking: • Self-test standby state (refer to Section 3.5.3) or macro standby state

• Macro execution standby state when the macro execution command is used.

Table 3.4.1 Standby State Indication

State PAPER LED Blinking Pattern Recovery Conditions Waiting for self-test printing to be continued or macro execution ready state.

PAPER OUT

Approximately 320 ms

Pressing the FEED button causes self-test printing to be continued or executes the macro.

NOTE: A macro can be executed r times (r specifies the number of times to execute the macro)

within the specified definition range. The macro can be executed continuously or can be executed by pressing the button. If the macro is executed by pressing the FEED button, the PAPER OUT LED blinks to indicate the macro execution ready state. (See Section 6, Commands.)

3) Error (ERROR) LED: Red

On: Off line (except during paper feeding using the FEED button and during test printing,

and the error state). (refer to Section 2.1.1.2, Switching between online and offline) Off: Normal condition Blinking: Error (refer to Section 3.7)

Figure 3.4.1 Panel Switches and Indicators

Page 67

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

57 56

TM-T88III series

Specification

(STANDARD)

3.5 Self-test

1) The printer has a self-test function that checks the following:

• Control circuit functions

• Printer mechanisms

• Print quality

• Control software version

• DIP switch settings

2) Starting the self-test To start the self-test on a paper roll, hold down the FEED button and tur n on the printer with the

cover closed, then the current printer status (*1) is printed.

(*1) • Control software version

• DIP switch settings

3) Self-test standby state After printing the current printer status, the printer prints the message "Self-test printing. Please

press FEED button." The PAPER OUT LED indicator blinks and the printer enters the test printing (*2) standby state. Press the FEED button to start test printing.

(*2) • A rolling pattern using only the built-in character set

• A partial cut after completing the test printing

4) Ending the self-test After a number of lines are printed, the printer indicates the end of the self-test by printing "***

completed ***", initializes, and goes to the standard mode (refer to Section 3.12, Page Mode).

Page 68

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

58 57

TM-T88III series

Specification

(STANDARD)

3.6 Hexadecimal Dumping

1) Hexadecimal dumping function

This function prints the data trans mitted from the host c omputer in hexadecimal numbers and in its corresponding characters.

2) Starting hexadecimal dumping

Open the cover and turn the power on while pressing the FEED button or executing GS ( A command, then close the c over. The printer first prints "Hexadecim al Dump To term inate ….." on paper roll and prints the received print data in hexadecim al numbers and in its corres ponding characters.

NOTES: 1. If no characters correspond to the data received, the printer prints ".".

2. During hexadecimal dumping, any commands other than DLE EOT, DLE ENQ,

and DLE DC4 do not function.

3. Insufficient print data to fill the last line can be printed by setting the printer offline.

3) Ending hexadecimal dumping

Hexadecimal dumping ends by turning the power of f, pressing the FEED button three times, or resetting the printer after printing has finished.

Hexadecimal Dump To terminate hexadecimal dump, press FEED button three times.

1B 21 00 1B 26 02 40 40 1B 69 . ! . .&.

1B 25 01 1B 63 34 00 1B 30 31 .%..c4..01

41 42 43 44 45 46 47 48 49 4A

ABC

DEFG

HIJ

*** completed ***

Page 69

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

59 58

TM-T88III series

Specification

(STANDARD)

3.7 Error Processing

3.7.1 Error Types

1) Errors that automatically recover

Table 3.7.1 Errors That Automatically Recover

Error Description

ERROR LED Blinking Pattern

160 ms

Recovery

Print head temperature error

The temperature of the print head is extremely high.

Recovers automatically when the print head cools.

Paper roll cover open error

Printing on the paper roll is not performed correctly due to a cover-open

Recovers automatically when cover is closed. The printer restarts printing with the line being printed when the cover was opened.

NOTE: Print head temperature error is not an abnormality.

2) Errors that have the possibility of recovery

Table 3.7.2 Errors That Can Possibly Recover

Error Description

ERROR LED Blinking Pattern

160 ms

Recovery

Autocutter error

The autocutter does not work correctly.

Approximately

2.56 s

Recovers by DLE ENQ 1 or DLE ENQ 2.

NOTE: If the paper jams, turn the printer off and remove jammed paper; then turn the printer on

again.

Page 70

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

60 59

TM-T88III series

Specification

(STANDARD)

3) Errors that are impossible to recover

Table 3.7.3 Unrecoverable Errors

Error Description

ERROR LED Blinking Pattern

160 ms

Recovery

R/W error in memory or gate array

After R/W checking, the printer does not work correctly.

Impossible to recover.

High voltage error

The power supply voltage is extremely high.

Impossible to recover.

Low voltage error

The power supply voltage is extremely low.

Impossible to recover.

CPU execution error

The CPU executes an incorrect address or I/F board is not connected.

Impossible to recover.

Internal circuit connection error

Internal circuits are not connected correctly.

pproximately 2.56 s

Impossible to recover.

NOTE: When any error shown above occurs, turn off the power as soon as possible.

3.7.2 Printer Operation When an Error Occurs

The printer executes the following operations when detecting an error.

• Stops all printer operations for the selected paper section.

• Goes BUSY (Refer to Section 3.3.3 DIP switches when DIP switch 2-1 is off).

• Blinks the ERROR LED.

3.7.3 Data Receive Error (only in the serial i nterface speci fi cati on)

If one of the following errors occurs during serial interface communication, the printer prints "?" or ignores the data, depending on the setting of DIP switch 1-1.

• Parity error

• Framing error

• Overrun error

Page 71

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

61 60

TM-T88III series

Specification

(STANDARD)

3.8 Paper Sensors

The printer has 2 paper sensors as follows:

1) Paper roll end sensor

The sensor which detects whether paper is present or not.

When the sensor detects a paper-end, the printer stops printing.

2) Paper roll near-end sensor

The sensor which detects a near-end of a paper roll.

When the paper roll diameter becom es sufficiently small, the detects a near- end of the paper roll and the PAPER OUT LED lights. If the sensor is enabled by ESC c 4, the printer stops printing.

NOTE: After installing new paper roll, close the printer cover; then the printer restarts printing.

3.9 Cover Open Button

When the cover open button (located to the right of the cover) is pr essed, the printer cover is opened. When the cover is closed, the cover open button is latched.

NOTES: 1. Be sure to use the cover open button to open the printer cover.

2. Do not open the cover during printing.

3. Do not open the cover during auto-cutting operation; otherwise the mechanism may be

damaged.

3.10 Cover Open Sensor

The cover open sensor monitors the printer cover. W hen the sensor detects a cover open during printing, the error LED blinks and the printer stops printing. The printer recovers when the cover is closed. W hen the sensor detects a cover open while the printer is in the standby status, the printer goes offline. The printer recovers when the cover is closed.

NOTE: Whether the cover is open or not does not affect the status reported by the paper roll end

sensor.

3.11 Print Buffer-full Printing

When subs equent data is received after the printer processes one line of data in the print buf fer, the printer automatically prints the processed line and feeds the paper by one line (in standard mode).

Page 72

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

62 61

TM-T88III series

Specification

(STANDARD)

3.12 Page Mode

3.12.1 General Description

The printer operates in two print modes only when the paper roll is selected as the print s heet: s tandar d mode and page mode. In standard mode, the printer prints and feeds paper each time it receives print data or paper feed comm ands. In page mode, all the received print data and paper feed commands are processed in the specified m emory, and the printer executes no operations. All the data in the memory is then printed when an ESC FF or FF command is received.

For example, when the printer receives the data "ABCDEF" <LF> in standar d mode, it prints "ABCDEF" and feeds the paper by one line. In page mode, "ABCDEF" is written to the specif ied printing area in memory, and the position in memory for the next print data is shifted by one line.

The ESC L command puts the printer into page mode, and all commands received thereafter are processed in page mode. Executing an ESC FF command prints the received data c ollectively, and executing an FF command restores the printer to standard mode after the received data is printed collectively. Executing an ESC S command restores the printer to s tandard mode without printing the received data in page mode; the received data is cleared from memory instead.

Printing

ESC L

ESC S

Standard mode

Page mode

ESC FF

Printing

Figure 3.12.1 Shifting Between Standard Mode and Page Mode

3.12.2 Setting Values in Standard and Page Modes

1) The available commands and parameters are the same for both standard and page modes. However, these values can be set independently in each mode for the ESC SP, ESC 2, ESC 3, and FS S commands. For these commands, different settings can be stored for each mode.

2) Although the m ax im um num ber of printable dots f or a bit im age when the paper roll is s elected as the print sheet is 512 in standard mode, 831 bit-image dots can be printed in the y direction (paper feed direction) in page mode. (This is possible only when the ESC W comm and has specified 831 printable-area dots in the y direction and the printing direction value of n in the ESC T command is 1 or 3.)

Page 73

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

63 62

TM-T88III series

Specification

(STANDARD)

3.12.3 Formatting of Print Data in the Printable Area

Formatting of print data in the printable area is performed as follows:

1) T he printable ar ea is set us ing ESC W. If all printing and feeding are com plete before the pr inter receives the ESC W comm and, the left side (as you face the printer ) is tak en as the origin (x0, y0) of the printable area. The printable rectangular area is defined by the length (dx dots ) extending from and including the origin (x0, y0) in the x direction (perpendicular to the paper feed dire ction), and by the length (dy dots) in the y direction (paper feed direction). (If the ESC W command is not used, the printable area remains the default value.)

2) When the printer receives print data after ESC W sets the printable area and ESC T sets the printing direction, the print data is formatted within the printable area so that point A in Figure

3.12.2 is at the beginning of the printable area as a default value. (W hen a character is printed, point A is the baseline.)

Print data containing downloaded bit images or bar codes is f ormatted so that the bottom point of

the left side of the image data (point B in Figure 3.12.3) is aligned with the baseline. However, any Human Readable Interpretation (HRI) characters are printed under the baseline.

At the points labeled Point B, if characters (such as double-height character s) higher than normal

size characters or downloaded bit image character s are received, any part of the character higher than the normal-size character is not printed.

3) If the print data (inc luding the space to the right of a charac ter) exceeds the pr intable area before the printer receives a command (e.g., LF or ESC J) that includes line feeding, a line feed is executed automatically within the printable area. The print position, therefore, moves to the beginning of the next line. The line f eed amount depends on the values set by comm ands ( such as ESC 2 and ESC 3).

4) The default value of the line spacing is set to 4.23 mm {1/6″} and corresponds to 30 dots in the vertical direction. If print data for the nex t line contains extended charac ters that are higher than double-height characters, bit images taking up two or more lines, or bar codes higher than norm al characters, the amount of line feeding may be insufficient, resulting in overlapping of the characters' higher-order dots with the previous line. To avoid this, increase the amount of line spacing. The line spacing in Figure 3.12.4 requires 27 dots or more.

Page 74

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

64 63

TM-T88III series

Specification

(STANDARD)

Example

When printing a downloaded bit image of six bytes in the vertical direction, use the following formula:

{number of vertical dots (8 × 6) - number of dots for feeding at the beginning of the printable area (21)} × vertical motion unit conversions (360/180) = 54

Therefore, 27 dots (54 pitch) are required for feeding. Use the following commands:

ESC W x

L, xH, yL, yH, dxL, dxH, dyL, dyH

ESC T n ESC 3 54 ← Set line spacing to be added. LF GS / 1 ESC 2 ← Reset the line spacing to 4.23 mm {1/6"}.

NOTE: Vertical and horizontal motion units are 1/360 in the vertical direction and 1/180 in the

horizontal direction; therefore, the position you specify varies depending on the printing direction. Setting the vertical motion unit to 1/180 using the GS P command does not change the current print position.

(x0, y0)

Development direction

Base line

24 - 3

Point A

Printing area

(dx, dy)

[Units: dots]

Figure 3.12.2 Character Data Developing Position

Page 75

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

65 64

TM-T88III series

Specification

(STANDARD)

24 - 3

nH x 256 + nL

6 x 8 = 48

User-defined

bit image

(GS* xy)

GS h n

x x 8

Bar Code

(GPS k m)

Bit image (ECS - m nL nH)

24 x 2 - 6 = 42

Point B Point B

Baseline

(HRI characters)

Point BPoint B

Double-height character

2B_4.eps

Figure 3.12.3 Print Data Developing Position

(x0, y0)

x × 8

Development direction

Base line

User-defined bit image

Base line

Point B

24 - 3

(GS * x y)

6 × 8 = 48

Printing area

[Units: dots]

(dx, dy)

Point A

24 - 3

Point B

Figure 3.12.4 Downloaded Bit Image Developing Position

(GS k m)

(ESC ∗ m nL nH)

Page 76

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

66 65

TM-T88III series

Specification

(STANDARD)

4. CASE SPECIFICATIONS

4.1 External Dimensions and Mass

Height: Approximately 148 mm {5.83"} Width: Approximately 145 mm {5.71"} Depth: Approximately 195 mm {7.68"} Mass: Approximately 1.8 kg {3.96 lb} (except for a paper roll)

4.2 Color

EPSON standard color (ECW, EDG)

4.3 External Appearance

148

145

195

Materials for the external: 94V-0

Figure 4.3.1 External Appearance

[Units: mm]

Page 77

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

67 66

TM-T88III series

Specification

(STANDARD)

5. OPTIONS AND CONSUMABLES

5.1 Standard Accessories

• Paper roll (diameter 50 mm [1.96"]) × 1 roll

• User's Manual (Languages: English, German, French, Spanish, Portuguese, Italian, Dutch,

Simplified Chinese, Traditional Chinese, Japanese)

• External power supply (for the model with the power supply unit)

Model: PS-180

PS-175 (only for North America)

5.2 Options

• Affixing tapes

Model: DF-10

• Wall hanging bracket

Model: WH-10

• RS-485 interface board (installed at the factory)

• External power supply

Model: PS-180 PS-170

5.3 Consumables

• Specified paper

Thermal roll paper: NTP080-80 [Original paper: TF50KS-E Nippon Paper Industries Co., Ltd.]

Packaged roll paper: [Original paper: PD160 Oji Paper Mfg. Co., Ltd.] In Japan: Nakagawa Manufacturing Co., Ltd.

In U.S.A.: Nakagawa Mfg. (USA) Inc. In Europe: Nakagawa Mfg. (Europe) GmbH In Southeast Asia: N.A.K. Mfg. (Malaysia) SDN BHD

The following paper can be used instead of the specified paper above: Original paper: PD190 (Oji Paper Mfg. Co., Ltd.)

P350(F380), P310, P300 Kanzaki Specialty Papers, Inc. (U.S.A.) AF50KS-E Jujo Thermal Oy (Finland)

NOTE: Do not use any paper other than these specified above. Otherwise, print head reliability and

print quality are affected adversely.

Page 78

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

68 67

TM-T88III series

Specification

(STANDARD)

6. COMMANDS

6.1 Command Notation

[Name] The name of the command. [Format] The code sequence. [Range] Gives the allowable ranges for the arguments. [Description] Describes the command’s function. [Details] Describes the usage of the command in detail. [Notes] Provides important information on setting and using the printer command, if necessary. [Default] Gives the default values, if any, for the command parameters. [Reference] Lists related commands. [Example] Gives examples of how to use the command.

Hex indicates the hexadecimal equivalents. Decimal indicates the decimal equivalents. [ ]k indicates the contents of the [ ] should be repeated k times.

6.2 Explanation of Terms

(1) Receive buffer

The receive buffer is a buffer that stores, as is, the data received fr om the host (the reception data). The reception data is stored in the receive buffer temporarily, and is then processed sequentially.

(2) Print buffer

The print buffer is a buffer that stores the image data to be printed.

(3) Print buffer full

This is the state where the print buffer is f ull. If new print data is input while the print buff er is full, the data in the print buffer is printed out and a line feed is executed. This is the same operation as the LF operation.

(4) Start of line

The start of line state satisfies the following condition:

• There is no print data (including spac es and portions of data skipped due to bit im age data) currently in the print buffer.

• There is no print data (including portions of data skipped due to HT)

• The print position is not specified by the ESC $ or ESC \ command.

Page 79

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

69 68

TM-T88III series

Specification

(STANDARD)

(5) Printable area

The maximum range within which printing is possible under the printer specifications. The printable area for this printer is as follows:

① The length of the horizontal direction in standard mode:

approximately 72.2 mm {512/180"}

② The length of the horizontal direction in page mode:

approximately 72.2 mm {512/180"}

③ The length of the vertical direction in page mode: approximately 117.3 mm {1662/360"}

(6) Printing area

Printing range is set by the command. It must be printing area ≤ printable area.

(7) Ignore

The state in which all codes, including parameters, are read in and discarded, and nothing happens.

(8) Inch

A unit of length. One inch is 25.4 mm.

(9) MSB

Most Significant Bit

(10) LSB

Least Significant Bit

(11) Base line

Standard position when character data is stored in the print buffer. Normal character in standard mode and page mode:

18 dots

8 dots

Line spacing (default)

48 dots

Line spacing (default)

Base line

21 dots

10 dots

A y

Base line

9 dots

Rotated character in standard mode (only when font A is selected):

∗1

∗1. When font A (12×24 dots) is selected,

this height is for 21 dots.

When font B (9×17 dots) is selected, this

height is for 16 dots.

Page 80

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

70 69

TM-T88III series

Specification

(STANDARD)

6.3 Control Commands

[Name] Horizontal tab [Format] ASCII HT

Hex 09

Decimal 9 [Description] Moves the print position to the next horizontal tab position. [Details] • This command is ignored unless the next horizontal tab position has been set.

• If the next horizontal tab position exceeds the printing area, the printer sets the printing

position to [Printing area width + 1].

• Horizontal tab positions are set with ESC D.

• If this command is received when the printing position is at [printing area width + 1], the

printer executes print buffer-full printing of the current line and horizontal tab processing from the beginning of the next line.

• The default setting of the horizontal tab position for the paper roll is font A

(12 × 24) every 8th character (9th, 17th, 25th, ... column).

[Reference] ESC D

[Name] Print and line feed [Format] ASCII LF

Hex 0A

Decimal 10 [Description] Prints the data in the print buffer and feeds one line based on the current line spacing. [Details] This command sets the print position to the beginning of the line. [Reference] ESC 2, ESC 3, Appendix A.1

Page 81

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

71 70

TM-T88III series

Specification

(STANDARD)

[Name] Print and return to standard mode in page mode [Format] ASCII FF

Hex 0C

Decimal 12 [Description] Prints the data in the print buffer collectively and returns to standard mode. [Details] • The buffer data is deleted after being printed.

• The printing area set by ESC W is reset to the default setting.

• The printer does not execute paper cutting.

• This command sets the print position to the beginning of the line.

• This command is enabled only in page mode. [Reference] ESC FF, ESC L, ESC S

[Name] Print and carriage return [Format] ASCII CR

Hex 0D

Decimal 13 [Description] When automatic line feed is enabled, this command functions the same as LF; when automatic

line feed is disabled, this command is ignored. [Details] • Sets the print starting position to the beginning of the line.

• The automatic line feed is ignored with a serial interface model.

• This command is set according to the DIP switch 1-1 setting with a parallel interface model. [Reference] LF

CAN

[Name] Cancel print data in page mode [Format] ASCII CAN

Hex 18

Decimal 24 [Description] In page mode, deletes all the print data in the current printable area. [Details] • This command is enabled only in page mode.

• If data that existed in the previously specified printing area also exists in the currently

specified printing area, it is deleted.

[Reference] ESC L, ESC W

Page 82

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

72 71

TM-T88III series

Specification

(STANDARD)

DLE EOT n

[Name] Real-time status transmission [Format] ASCII DLE EOT n

Hex 10 04 n

Decimal 16 4 n [Range] 1 ≤ n ≤ 4 [Description] Transmits the selected printer status specified by n in real-time, according to the following

parameters:

n = 1: Transmit printer status n = 2: Transmit offline status n = 3: Transmit error status n = 4: Transmit paper roll sensor status

[Details] • The printer transmits the current status. Each status is represented by one-byte data.

• The printer transmits the status without confirming whether the host computer can receive

data.

• The printer executes this command upon receiving it.

• This command is executed even when the printer is offline, the receive buffer is full, or there

is an error status with a serial interface model.

• With a parallel interface model, this command can not be executed when the printer is busy.

This command is executed even when the printer is offline or there is an error status when DIP switch 2-1 is on with a parallel interface model.

• When Auto Status Back (ASB) is enabled using the GS a command, the status transmitted by

the DLE EOT command and the ASB status must be differentiated. (Refer to Appendix G, TRANSMISSION STATUS IDENTIFICATION)

• Even though the printer is not selected using ESC = (select peripheral device), this command

is effective.

[Notes] • The status is transmitted whenever the data sequence of <10>H<04>H<n>

(1 ≤ n ≤ 4) is received.

Example:

In ESC ∗ m n

L nH d1...dk, d1=<10>H, d2=<04>H, d3=<01>H

• This command should not be used within the data sequence of another command that

consists of 2 or more bytes.

Example:

If you attempt to transmit ESC 3 n to the printer, but DTR (DSR for the host computer) goes to MARK before n is transmitted and then DLE EOT 3 interrupts before n is received, the code <10>H for DLE EOT 3 is processed as the code for ESC 3 <10>H.

Page 83

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

73 72

TM-T88III series

Specification

(STANDARD)

n = 1: Printer status

Bit Off/On Hex Decimal Function 0 Off 00 0 Not used. Fixed to Off.

1 On 02 2 Not used. Fixed to On. 2 Off 00 0 Drawer open/close signal is LOW (connector pin 3). On 04 4 Drawer open/close signal is HIGH (connector pin 3). 3 Off 00 0 Online. On 08 8 Offline. 4 On 10 16 Not used. Fixed to On. 5,6 - - - Undefined. 7 Off 00 0 Not used. Fixed to Off.

n = 2: Offline status

Bit Off/On Hex Decimal Function 0 Off 00 0 Not used. Fixed to Off.

1 On 02 2 Not used. Fixed to On. 2 Off 00 0 Cover is closed. On 04 4 Cover is open. 3 Off 00 0 Paper is not being fed by using the FEED button. On 08 8 Paper is being fed by the FEED button. 4 On 10 16 Not used. Fixed to On. 5 Off 00 0 No paper-end stop. On 20 32 Printing is being stopped. 6 Off 00 0 No error. On 40 64 Error occurs. 7 Off 00 0 Not used. Fixed to Off.

Bit 5: Becomes on when the paper end sensor detects paper end and printing stops.

Page 84

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

74 73

TM-T88III series

Specification

(STANDARD)

n = 3: Error status

Bit Off/On Hex Decimal Function 0 Off 00 0 Not used. Fixed to Off.

1 On 02 2 Not used. Fixed to On. 2 – – – Undefined 3 Off 00 0 No autocutter error. On 08 8 Autocutter error occurs. 4 On 10 16 Not used. Fixed to On. 5 Off 00 0 No unrecoverable error. On 20 32 Unrecoverable error occurs. 6 Off 00 0 No auto-recoverable error. On 40 64 Auto recoverable error occurs. 7 Off 00 0 Not used. Fixed to Off.

Bit 3: If these errors occur due to paper jams or the like, it is possible to recover by correcting

the cause of the error and executing DLE ENQ n (1 ≤ n ≤ 2). If an error due to a circuit failure (e.g. wire break) occurs, it is impossible to recover.

Bit 6: When printing is stopped due to high print head temperature until the print head

temperature drops sufficiently or when the paper roll cover is open during printing, bit 6 is On.

n = 4: Continuous paper sensor status

Bit Off/On Hex Decimal Function 0 Off 00 0 Not used. Fixed to Off.

1 On 02 2 Not used. Fixed to On. 2, 3 Off 00 0 Paper roll near-end sensor: paper adequate. On 0C 12 Paper near-end is detected by the paper roll near-end

sensor. 4 On 10 16 Not used. Fixed to On. 5, 6 Off 00 0 Paper roll sensor: Paper present. On 60 96 Paper roll end detected by paper roll sensor. 7 Off 00 0 Not used. Fixed to Off.

[Reference] DLE ENQ, GS a, GS r, Appendix G

Page 85

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

75 74

TM-T88III series

Specification

(STANDARD)

DLE ENQ n

[Name] Real-time request to printer [Format] ASCII DLE ENQ n

Hex 10 05 n

Decimal 16 5 n [Range] 1 ≤ n ≤ 2 [Description] Responds to a request from the host computer. n specifies the requests as follows:

n Request 1 Recover from an error and restart printing from the line where the error occurred

2 Recover from an error aft clearing the receive and print buffers

[Details] • When the printer is disabled with ESC = (Select peripheral device), this command is effective.

• This command is effective only when an autocutter error occurs.

• The printer starts processing data upon receiving this command.

• This command is executed even when the printer is offline, the receive buffer is full, or there

is an error status with a serial interface model.

• With a parallel interface model, this command can not be executed when the printer is busy.

This command is executed even when the printer is offline or there is an error status when DIP switch 2-1 is on with a parallel interface model.

• DLE ENQ 2 enables the printer to recover from an error after clearing the data in the receive

buffer and the print buffer. The printer retains the settings (by ESC !, ESC 3, etc.) that were in effect when the error occurred. The printer can be initialized completely by using this command and ESC @. This command is enabled only for errors that have the possibility of recovery, except for print head temperature error.

[Notes] • The status is also transmitted whenever the data sequence of <10>H<05>H<n> (1 ≤ n ≤ 2) is

received.

Example:

In ESC ∗∗∗∗ m n

L nH dk, d1 = <10>H, d2 = <05>H, d3 = <01>H

• This command should not be contained within another command that consists of two or more

bytes.

Example:

If you attempt to transmit ESC 3 n to the printer, but DTR (DSR for the host computer) goes to MARK before n is transmitted, and DLE ENQ 2 interrupts before n is received, the code <10>H for DLE ENQ 2 is processed as the code for ESC 3 <10>H.

[Reference] DLE EOT

Page 86

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

76 75

TM-T88III series

Specification

(STANDARD)

DLE DC4 n m t

[Name] Generate pulse at real-time [Format] ASCII DLE DC4 n m t

Hex 10 14 n m t

Decimal 16 20 n m t [Range] n = 1

m = 0, 1

1 ≤ t ≤ 8 [Description] Outputs the pulse specified by t to connector pin m as follows:

m Connector pin 0 Drawer kick-out connector pin 2.

1 Drawer kick-out connector pin 5.

The pulse ON time is [t × 100 ms] and the OFF time is [t × 100 ms].

[Details] • When the printer is in an error status when this command is processed, this command is

ignored.

• When the pulse is output to the connector pin specified while ESC p or DEL DC4 is executed

while this command is processed, this command is ignored.

• The printer executes this command upon receiving it.

• With a serial interface model, this command is executed even when the printer is offline, the

receive buffer is full, or there is an error status.

• With a parallel interface model, this command cannot be executed when the printer is busy.

This command is executed even when the printer is offline or there is an error status when DIP switch 2-1 is on.

• This command is effective even when the printer is disabled with ESC = (Select peripheral

device).

[Notes] • If print data includes the same character strings as this command, the printer performs the

same operation specified by this command. The user must consider this.

• This command should not be used within the data sequence of another command that

consists of 2 or more bytes.

[Reference] ESC p

Page 87

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

77 76

TM-T88III series

Specification

(STANDARD)

ESC FF

[Name] Print data in page mode [Format] ASCII ESC FF

Hex 1B 0C

Decimal 27 12 [Description] In page mode, prints all buffered data in the printing area collectively. [Details] • This command is enabled only in page mode.

• After printing, the printer does not clear the buffered data, setting values for ESC T and ESC

W, and the position for buffering character data.

[Reference] FF, ESC L, ESC S

ESC SP n

[Name] Set right-side character spacing [Format] ASCII ESC SP n

Hex 1B 20 n

Decimal 27 32 n [Range] 0 ≤ n ≤ 255 [Description] Sets the character spacing for the right side of the character to [n × horizontal or vertical motion

units]. [Details] • The right-side character spacing for double-width mode is twice the normal value. When

characters are enlarged, the right-side character spacing is n times normal value.

• This command does not affect the setting of Kanji characters.

• This command sets values independently in each mode (standard and page modes).

• The horizontal and vertical motion unit are specified by GS P. Changing the horizontal or

vertical motion unit does not affect the current right-side spacing.

• The GS P command can change the horizontal (and vertical) motion unit. However, the value

cannot be less than the minimum horizontal movement amount, and it must be in even units of the minimum horizontal movement amount.

• In standard mode, the horizontal motion unit is used.

• In page mode, the horizontal or vertical motion unit differs in page mode, depending on

starting position of the printable area as follows:

① When the starting position is set to the upper left or lower right of the printable area

using ESC T, the horizontal motion unit (x) is used.

② When the starting position is set to the upper right or lower left of the printable area

using ESC T, the vertical motion unit (y) is used.

• The maximum right-side spacing is 35.983 mm {255/180"}. Any setting exceeding the

maximum is converted to the maximum automatically. [Default] n = 0 [Reference] GS P

Page 88

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

78 77

TM-T88III series

Specification

(STANDARD)

ESC ! n

[Name] Select print mode(s) [Format] ASCII ESC ! n

Hex 1B 21 n

Decimal 27 33 n [Range] 0 ≤ n ≤ 255 [Description] Selects print mode(s) using n as follows:

Bit Off/On Hex Decimal Function 0 Off 00 0

Character font A (12 × 24).

On 01 1

Character font B (9 × 17). 1 - - - Undefined. 2 - - - Undefined. 3 Off 00 0 Emphasized mode not selected. On 08 8 Emphasized mode selected. 4 Off 00 0 Double-height mode not selected. On 10 16 Double-height mode selected. 5 Off 00 0 Double-width mode not selected. On 20 32 Double-width mode selected. 6 - - - Undefined. 7 Off 00 0 Underline mode not selected. On 80 128 Underline mode selected.

[Details] • When both double-height and double-width modes are selected, quadruple size characters

are printed.

• The printer can underline all characters, but can not underline the space set by HT or 90° clockwise rotated characters.

• The thickness of the underline is that selected by ESC −−−−, regardless of the character size.

• When some characters in a line are double or more height, all the characters on the line are aligned at the baseline.

• ESC E can also turn on or off emphasized mode. However, the setting of the last received command is effective.

• ESC −−−− can also turn on or off underline mode. However, the setting of the last received command is effective.

• GS ! can also select character size. However, the setting of the last received command is effective.

• Emphasized mode is effective for alphanumeric and Kanji. All print modes except emphasized mode is effective only for alphanumeric.

[Default] n = 0 [Reference] ESC -, ESC E, GS !

Page 89

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

79 78

TM-T88III series

Specification

(STANDARD)

ESC $ nL nH

[Name] Set absolute print position [Format] ASCII ESC $ n

L nH

Hex 1B 24 n

L nH

Decimal 27 36 n

L nH

[Range] 0 ≤ n

L ≤ 255

0 ≤ n

H ≤ 255

[Description] Sets the distance from the beginning of the line to the position at which subsequent characters

are to be printed.

• The distance from the beginning of the line to the print position is [(n

L + nH × 256) × (vertical or horizontal motion unit)].

[Details] • Settings outside the specified printable area are ignored.

• The horizontal and vertical motion unit are specified by GS P.

• The GS P command can change the horizontal (and vertical) motion unit. However, the value cannot be less than the minimum horizontal movement amount, and it must be in even units of the minimum horizontal movement amount.

• In standard mode, the horizontal motion unit (x) is used.

• In page mode, horizontal or vertical motion unit differs depending on the starting position of the printable area as follows:

1 W hen the starting position is set to the upper left or lower right of the printable ar ea using

ESC T, the horizontal motion unit (x) is used.

2 W hen the starting position is set to the upper right or lower left of the printable ar ea using

ESC T, the vertical motion unit (y) is used.

[Reference] ESC \, GS $, GS \, GS P

Page 90

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

80 79

TM-T88III series

Specification

(STANDARD)

ESC % n

[Name] Select/cancel user-defined character set [Format] ASCII ESC % n

Hex 1B 25 n

Decimal 27 37 n [Range] 0 ≤ n ≤ 255 [Description] Selects or cancels the user-defined character set.

• When the LSB of n is 0, the user-defined character set is canceled.

• When the LSB of n is 1, the user-defined character set is selected. [Details] • When the user-defined character set is canceled, the internal character set is automatically

selected.

• n is available only for the least significant bit. [Default] n = 0 [Reference] ESC &, ESC ?

Page 91

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

81 80

TM-T88III series

Specification

(STANDARD)

ESC & y c1 c2 [x1 d1...d(y

××××

x1)]...[xk d1...d(y

××××

xk)]

[Name] Define user-defined characters [Format] ASCII ESC & y c1 c2 [x1 d1...d(y

x1)]...[xk d1...d(y × xk)]

Hex 1B 26 y c1 c2 [x1 d1...d(y

x1)]...[xk d1...d(y × xk)]

Decimal 27 38 y c1 c2 [x1 d1...d(y

x1)]...[xk d1...d(y × xk)]

[Range] y = 3

32 ≤ c1 ≤ c2 ≤ 126

0 ≤ x ≤ 12 (when font A (12 × 24) is selected)

0 ≤ x ≤ 9 (when font B (9 × 17) is selected)

0 ≤ d1 ... d(y × xk) ≤ 255 [Description] Defines user-defined characters.

• y specifies the number of bytes in the vertical direction.

• c1 specifies the beginning character code for the definition, and c2 specifies the final code.

• x specifies the number of dots in the horizontal direction. [Details] • The allowable character code range is from ASCII code <20>H to <7E>H (95 characters).

• It is possible to define multiple characters for consecutive character codes.

If only one character is desired, use c1 = c2.

• d is the dot data for the characters. The dot pattern is in the horizontal direction from the left

side. Any remaining dots on the right side are blank.

• The data to define a user-defined character is (y × x) bytes.

• Set a corresponding bit to 1 to print a dot or 0 to not print a dot.

• This command can define different user-defined character patterns by each fonts. To select

a font, use ESC !

• A user-defined character and a downloaded bit image cannot be defined simultaneously.

When this command is executed, the downloaded bit image is cleared.

• The user-defined character definition is cleared when:

① ESC @ is executed. ② FS q is executed. ③ GS ∗

∗∗

∗ is executed.

④ ESC ? is executed. ⑤ The printer is reset or the power is turned off.

• When the user-defined characters are defined in font B (9 × 17), only the most significant bit

of the 3rd byte of data in vertical direction is effective.

Page 92

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

82 81

TM-T88III series

Specification

(STANDARD)

[Default] The internal character set [Reference] ESC %, ESC ? [Example]

• When font A (12 × 24) is selected.

MSB

LSB

d4 d7 d34

d2 d5 d35

d3 d6 d36

24 dots

12 dots

d1= <0F>H d4 = <30>H d7 = <40>H . . . .

d2 = <03>H d5 = <80>H d8 = <40>H . . . .

d3 = <00>H d6 = <00>H d9 = <20>H . . . .

Page 93

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

83 82

TM-T88III series

Specification

(STANDARD)

• When font B (9 × 17) is selected.

LSB

MSB

d4 d1

17 dots

9 dots

d26d5

d27d6

d1 = <1F>H d4 = <08>H d7 = <10>H... d2 = <FF>H d5 = <08>H d8 = <04>H... d3 = <80>H d6 = <00>H d9 = <00> H...

d25

Page 94

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

84 83

TM-T88III series

Specification

(STANDARD)

ESC ∗∗∗∗ m nL nH d1...dk

[Name] Select bit-image mode [Format] ASCII ESC

∗ m nL nH d1...dk

Hex 1B 2A

m nL nH d1...dk

Decimal 27 42

m nL nH d1...dk

[Range]

m = 0, 1, 32, 33

≤ nL ≤ 255

≤ nH ≤ 3

≤ d ≤ 255

[Description] Selects a bit-image mode using

m for the number of dots specified by nL and nH, as follows:

Vertical Direction Horizontal Direction

Mode

Number of Dots

Dot Density Dot

Density

Number of Data (K)

0 8-dot single-density 8 60 dpi 90 dpi

nL + nH × 256

1 8-dot double-density 8 60 dpi 180 dpi

nL + nH × 256

32 24-dot single-density 24 180 dpi 90 dpi

(

nL + nH × 256) ×3

33 24-dot double-density 24 180 dpi 180 dpi

(

nL + nH × 256) ×3

[dpi: dots per 25.4 mm {1"}]

[Details]

• If the values of m is out of the specified range, nL and data following are processed as normal

data.

• The nL and nH indicate the number of dots of the bit image in the horizontal direction. The

number of dots is calculated by

nL + nH × 256.

• If the bit-image data input exceeds the number of dots to be printed on a line, the excess data

is ignored.

• d indicates the bit-image data. Set a corresponding bit to 1 to print a dot or to 0 to not print a

dot.

• If the width of the printing area set by GS L and GS W less than the width required by the

data sent with the

ESC ∗∗∗∗ command, the following will be performed on the line in question

(but the printing cannot exceed the maximum printable area):

① The width of the printing area is extended to the right to accommodate the amount of

data.

② If step ① does not provide sufficient width for the data, the left margin is reduced to

accommodate the data.

Page 95

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

85 84

TM-T88III series

Specification

(STANDARD)

• After printing a bit image, the printer returns to normal data processing mode.

• This command is not affected by print modes (emphasized, double-strike, underline,

character size or white/black reverse printing), except upside-down printing mode.

• Refer to Figure 3.12.3 for the bit image development position in page mode.

• The relationship between the image data and the dots to be printed is as follows:

• When 8-dot bit image is selected:

MSB

LSB

d2 d3

Print data

Bit-image data

d1 d2 d3

Bit-image data

Print data

1 dot

Single density Double density

Page 96

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

86 85

TM-T88III series

Specification

(STANDARD)

• When 24-dot bit image is selected:

MSB

LSB

d4 d7

d2 d5 d8

d3 d6 d

Print data

Bit-image data

d1 d2 d3

Bit-image data

Print data

1 dot

d4 d5 d6 d7 d8 d9

Single density

Double density

Page 97

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

87 86

TM-T88III series

Specification

(STANDARD)

ESC - n

[Name] Turn underline mode on/off [Format] ASCII ESC

- n

Hex 1B 2D n

Decimal 27 45 n [Range] 0 ≤ n ≤ 2, 48 ≤ n ≤ 50 [Description] Turns underline mode on or off, based on the following values of

n Function

0, 48 Turns off underline mode 1, 49 Turns on underline mode (1-dot thick) 2, 50 Turns on underline mode (2-dots thick)

[Details] • The printer can underline all characters (including right-side character spacing), but cannot

underline the space set by

HT.

• The printer cannot underline 90° clockwise rotated characters and white/black inverted

characters.

• When underline mode id turned off by setting the value of n to 0 or 48, the following data is

not underlined, and the underline thickness set before the mode is turned off does not change. The default underline thickness is 1 dot.

• Changing the character size does not affect the current underline thickness.

• Underline mode can also be turned on or off by using ESC !. Note, however, that the last

received command is effective.

• This command does not affect Kanji printing.

[Default]

n = 0

[Reference] ESC !

ESC 2

[Name] Select default line spacing [Format] ASCII ESC 2

Hex 1B 32

Decimal 27 50 [Description] Selects approximately 4.23 mm {1/6"} spacing. [Details]

• The line spacing can be set independently in standard mode and in page mode.

[Reference]

ESC 3

Page 98

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

88 87

TM-T88III series

Specification

(STANDARD)

ESC 3 n

[Name] Set line spacing [Format] ASCII ESC 3

Hex 1B 33 n

Decimal 27 51 n [Range] 0 ≤ n ≤ 255 [Description] Sets the line spacing to [

n × vertical or horizontal motion unit].

[Details]

• The line spacing can be set independently in standard mode and in page mode.

• The horizontal and vertical motion unit are specified by GS P. Changing the horizontal or

vertical motion unit does not affect the current line spacing.

• The GS P command can change the horizontal (and vertical) motion unit. However, the value

cannot be less than the minimum vertical movement amount, and it must be in even units of the minimum vertical movement amount.

• In standard mode, the vertical motion unit (y) is used.

• In page mode, this command functions as follows, depending on the starting position of the

printable area:

① When the starting position is set to the upper left or lower right of the printable area using

ESC T, the vertical motion unit (y) is used.

② When the starting position is set to the upper right or lower left of the print able area

using

ESC T, the horizontal motion unit (x) is used.

• The maximum paper feed amount is 1016 mm {40"}. Even if a paper feed amount of more

than 1016 mm {40"} is set, the printer feeds the paper only 1016 mm {40"}. [Default] Line spacing equivalent to approximately 4.23mm {1/6"}. [Reference]

ESC 2, GS P

Page 99

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

89 88

TM-T88III series

Specification

(STANDARD)

ESC = n

[Name] Set peripheral device [Format] ASCII ESC =

Hex 1B 3D n

Decimal 27 61 n [Range] 1 ≤ n ≤ 255 [Description] Selects device to which host computer sends data, using

n as follows:

Bit Off/On Hex Decimal Function 0 Off 00 0 Printer disabled.

On 01 1 Printer enabled 1-7 - - - Undefined.

[Details] • When the printer is disabled, it ignores all data except for error-recovery commands (DLE

EOT, DLE ENQ, DLE DC4

) until it is enabled by this command.

[Default]

n = 1

ESC ? n

[Name] Cancel user-defined characters [Format] ASCII ESC ?

Hex 1B 3F n

Decimal 27 63 n [Range] 32 ≤ n ≤ 126 [Description] Cancels user-defined characters. [Details]

• This command cancels the pattern defined for the character code specified by n. After the

user-defined characters is canceled, the corresponding pattern for the internal character is printed.

• This command deletes the pattern defined for the specified code in the font selected by

ESC !.

• If a user-defined character has not been defined for the specified character code, the printer

ignores this command.

[Reference]

ESC &, ESC %

Page 100

Confidential

EPSON

TITLE

SHEET REVISION

NO.

SHEETNEXT

90 89

TM-T88III series

Specification

(STANDARD)

ESC @

[Name] Initialize printer [Format] ASCII ESC @

Hex 1B 40

Decimal 27 64 [Description] Clears the data in the print buffer and resets the printer mode to the mode that was in effect

when the power was turned on. [Details]

• The DIP switch settings are not checked again.

• The data in the receive buffer is not cleared.

• The macro definition is not cleared.

• The NV bit image data is not cleared.

• The data of the NV user memory is not cleared.
