Epson EMP-7300 User Manual

Important Information About Your
EMP-7300

Please read the following important information about your
EMP-7300 projector.

Important Safety Information

Warning:

switched on as the bright light can damage your eyes. Never let
children look into the lens when it is on.

Warning:

lamp and filter covers. Dangerous electrical voltages inside
the projector can cause severe injury. Except as specifically
directed in this Owner’s Manual, do not attempt to service
this product yourself. Refer all servicing to qualified service
personnel.

Warning:

and optional parts out of the reach of children. Children
covering their heads with bags may result in death by
suffocation. Be particularly careful around small children.

Caution:

bulb with your bare hands. The invisible residue left by the oil
on your hands may be shorten the bulb life. Use a cloth or
gloves to handle the new bulb.

Never look into the projector lens when the lamp is

Never open any covers on the projector except the

Keep the plastic bags for the projector, accessories

When you replace the lamp, never touch the new

EMP-7300

Q

operation panel

speaker

Power

Resize

Menu

Mute

Operation Panel

n

c

y

.

S

g

n

i

k

c

a

r

T

S

.

y

c

n

Volume

UICK

foot adjuster lever

Button Function

Power Starts or stops projection.
Source Switches to Computer 1 , Computer 2, or

Menu Displays or hides the menu.

BlankSource

T

r

a

c

k

i

n

g

Up, down arrows
(Sync+/Sync-)

Left, right
arrows(tracking-/
tracking+)

Enter key Registers a menu selection.
Resize Switches the display dot mode and resize

Mute Cuts off audio.
– Volume + Adjusts the volume.

S

operation indicator

TART

speaker

front foot

Video.

Synchronizes the computer’s graphic signal.
Use these buttons to adjust an overall image
that is fuzzy or streaked, or to select menu
items during menu opera- tions.

Matches the projector’s internal clock to
various computer graphic signals (tracking
adjustment).
Use these buttons to adjust an image with
vertical fuzzy lines, or to change numeric
settings during menu opera- tions.

mode (for VGA, SVGA, and SXGA input).

remoto
control
reciver

zoom ring
focus ring

EMP-7300

Source

Menu

Effects

3

2

1

Blank

Resize

Custom

Freeze

Mute

- Volume +

Power

Remote control

4

5

Q

UICK

Button Function

Menu Displays or hides the menu.
Source Switches to Computer 1 , Computer 2*, or

Pointer button Use the pointer button to navigate the menus

Effects buttons Use to display special effects in conjunction

Top multi-pur­pose button

Bottom multi-pur­pose button

Blank Clears the screen of special effects and

Resize Switches the display dot mode and resize

Custom Use to assign functions to the Effects keys

Freeze Keeps the current computer or video image

Mute Cuts off audio.
– Volume + Adjusts the volume.
Power Starts or stops the projector.

S

TART

Video.

or use the remote as a mouse pointer when
the projector is con- nected to the computer
with all cables in the ELP Link II
communications kit.

with the ELP Link II software.
Acts as a right mouse click, registers a menu

selection, and selects other custom
functions.

Acts as a left mouse click, registers a menu
selection, and selects other custom
functions.

switches to a black, a blue or user logo
display.

mode (for VGA, SVGA and SXGA input).

using the ELP Link II software.

on the screen.

Connecting to
a PC laptop computer

Computer cable

Connecting to
a Macintosh PowerBook

MAC
desktop
adapter

Computer cable

Video
cable
adapter

®

DATA/VIDEO PROJECTOR

Owner’s Manual

All rights reserved. No part of this publication may be reproduced, stored in a
retrieval system, or transmitted in any form or by any means, electronic,
mechanical, photocopying, recording, or otherwise, without the prior written
permission of SEIKO EPSON CORPORATION. No patent liability is
assumed with respect to the use of the information contained herein. Neither
is any liability assumed for damages resulting from the use of the information
contained herein.

Neither SEIKO EPSON CORPORATION nor its affiliates shall be liable to
the purchaser of this product or third parties for damages, losses, costs, or
expenses incurred by purchaser or third parties as a result of: accident, misuse,
or abuse of this product or unauthorized modifications, repairs, or alterations
to this product, or (excluding the U.S.) failure to strictly comply with SEIKO
EPSON CORPORATION’s operating and maintenance instructions.

SEIKO EPSON CORPORATION shall not be liable against any damages or
problems arising from the use of any options or any consumable products
other than those designated as Original EPSON Products or EPSON
Approved Products by SEIKO EPSON CORPORATION.

EPSON is a registered trademark and PowerLite is a trademark of SEIKO
EPSON CORPORATION.

General Notice: The following trademarks and registered trademarks are the

property of their respective owners and are used in this publication for
identification purposes only.

• EPSON/Seiko Epson Corp.

• Macintosh, Macintosh OS System 7, PowerBook, Quadra, Centris, Power
Mac/Apple Computer Corp.

• IBM/International Business Machines, Inc.

• Windows 3.x, Windows 95/Microsoft Corp.

Other product names used herein are also for identification purposes only and
may be trademarks of their respective owners. EPSON disclaims any and all
rights in those marks.

■

■

■

■

■

■

■

■

■

■

■

■

■

■

Contents

Contents iii
Introduction vii

Getting the Most Out of Your Projector ................................ix

Remote control ..........................................................................ix

Sleep mode.................................................................................ix

Control Panel.............................................................................ix

Optional Accessories....................................................................x

About This Manual................................................................ xi

Safety Instructions ................................................................ xii

Where to Get Help.............................................................. xiv

World Wide Web site.................................................................xv

■

■

Installation 1

Unpacking the Projector.........................................................2

Additional Items......................................................................... 3

Setting Up the Projector.........................................................4

Connecting to a Computer.....................................................7

Connecting to a PC desktop computer ....................................... 8

Connecting to a PC laptop computer........................................ 12

Connecting to a Macintosh desktop computer .......................... 16

Connecting to a Macintosh PowerBook.................................... 20

Connecting to a Video Source .................................................. 24

Connecting to an External Speaker or PA System..................26

Connecting to a Workstation ................................................28

■ ■ ■ ■ ■

iii

Using the Projector 29

Turning the Equipment On and Off .....................................31

Turning the Projector On and Off ............................................ 31

Sleep Mode .............................................................................. 32

Focusing and Positioning the Screen Image ..........................33

Resize Button........................................................................... 35

Controlling the Projector......................................................36

Using the Remote Control ....................................................... 37

Using the Control Panel........................................................... 39

Projector Status Indicators....................................................41

Operation Indicator.................................................................. 41

Lamp Indicator......................................................................... 42

Temperature Indicator.............................................................. 42

Using the Projector Menus 43

Accessing the Main Menu.....................................................44

Changing a Menu Setting.....................................................44

Menu Options......................................................................47

Video Menu (Image source = Computer) ................................. 47

Video Menu (Image source = Video)........................................ 50

Audio Menu............................................................................. 51

Options Menu.......................................................................... 52

Custom Menu .......................................................................... 54

About Menu............................................................................. 57

RESET ALL Menu................................................................... 57

■ ■ ■ ■

Using the ELP Link III Software 59

Installing the Software ..........................................................60

Connecting Needed Cables ...................................................... 60

Installing the Software from Windows 3.x................................. 60

Installing the Software from Windows 95.................................. 61

Installing the Software from Windows NT ................................ 63

Installing the Software from Macintosh OS System (from ver. 7)...
63

Launching the Software ........................................................64

Contents

iv

■

Using the Software ...............................................................64

Customizing the Remote Control Effects Buttons .................... 64

Function Description and Usage...........................................65

Assigning Functions.................................................................. 66

Setting Effect Options .............................................................. 67

Saving and Recalling Effects Key Button Assignments............... 70

Changing the COM Port Assignment....................................... 70

Controlling Projector Features.................................................. 71

Displaying the Projector Set Window........................................ 71

Using the Quick Change Toolbar............................................. 72

Changing Projector Settings .................................................73

Computer Tab.......................................................................... 73

Video Tab ............................................................................... 74

Sound Tab .............................................................................. 75

Option Tab ............................................................................. 76

Custom Tab ............................................................................ 78

Changing the Test Pattern........................................................ 79

Setting the Image Color Property ............................................. 80

Maintenance 81

Cleaning the Lens.................................................................82

Cleaning the Projector Case..................................................82

Cleaning the Air Filter ..........................................................83

Replacing the Lamp..............................................................84

Troubleshooting 87

Problems with the Projector..................................................88

Problems with the Image or Sound.......................................90

Technical Specifications 93

Supported Monitor Displays .................................................95

Monitor and Computer In 1/2 connector pin assignments ...97

Glossary 99
Index 101

■ ■ ■ ■ ■

v

■ ■ ■ ■

vi

Contents

■

■

■

■

■

■

■

Introduction

T

he compact, lightweight EPSON EMP-7300 Projector
allows you to project XGA full-color images and video onto a
large screen for presentations. The projector can connect
simultaneously to three image sources: two PC or Apple®
Macintosh® computer image sources plus on video source
such as a video tape deck, camcorder, or digital camera. Audio
can also be connected for each image source.

Images are displayed in XGA compatible full color
(16,670,000 colors) at a resolution of 1024 x 768 pixels. The
projector produces bright images that can be easily seen in
rooms with enough light to take notes. Audio can be
produced from the projector’s 3+3W speakers, which employ
a built-in 3D sound® for output that is rich and powerful. An
external speaker can also be connected when further
amplification is required.

■

■

■

■

■

■

■

■

■

A totally new AVTSS™ (Automatic Video Tracking and
Synchronization Sensing, patent pending) provides automatic
set-up of image from a computer with a touch of the AUTO
button for quick and easy projection of beautiful images every
time.

The projector can be controlled using a hand-held remote
control unit, with menus being provided for image source
switching and image adjustment. The remote control can also
be used as a wireless mouse to control mouse operations on
the computer screen during presentations. The ELP LINK

■ ■ ■ ■ ■

vii

III™ software that comes with the projector provides a
number of add-on features that are designed to make
presentations more effective.

The projector also features a new patented AIrR™ (Advanced
Image real-time Resizer) chip which supports XGA computer
output, as well as VGA and SXGA output. Whichever type of
computer output is used, the result is a full-size video image
of outstanding clarity.

The EMP-7300 Projector supports IBM-compatible PCs and
laptops, as well as Apple® Macintosh®, Power Macintosh and
PowerBook computers. The video source can be NTSC, PAL
or SECAM in composite video, S-Video format.

■ ■ ■ ■

viii

Introduction

■

Getting the Most Out of Your Projector

The projector comes with a full set of features that allow you
to control the settings for the image display, video and audio.
To get the most out of your projector read this section for a
quick summary of the important features.

Remote control

The buttons on the remote control allow you to turn the
projector on and off, an provide direct access to auto set-up,
blank, freeze, volume, mute and image source switching.
Remote control buttons can also be used for custom functions
and to access the projector’s menu system. The remote
control can even be used instead of your computer’s mouse to
control your computer.

Sleep mode

The sleep mode conserves electricity by automatically turning
off the lamp if the projector does not receive video input
signal for specified period (default is 30 minutes). In the sleep
mode, the projector remains on but the lamp is turned off,
conserving electricity, cooling the projector and extending the
life of the lamp.

Use the Power button to turn the projector on and off.

Control Panel

The control panel buttons on the projector duplicate the
remote control buttons and let you perform additional
functions, such as adjusting the tracking and sync for
computer images.

Getting the Most Out of Your Projector

■ ■ ■ ■ ■

ix

Optional Accessories

To enhance your use of the projector, EPSON provides the
following accessories:

• An ELP communication cable set, a computer cable and a

Mac adapter set to connect to another computer.
ELP Communication Cable Set ELPKC04
Computer Cable ELPKC02
Mac Adapter Set ELPAP01

• Replacement lamp

Spare Lamp ELPLP05

• Carrying cases designed especially for the projector and its

cables.
Hard Travel Case ELPKS09
Soft Travel Case ELPKS10

The following accessories are EPSON recommended.
A 13W3 computer cable and a 5BNC computer cable

designed especially to connect to the workstation.
For more details, call the After Sales Service Center.
(13W3 Computer Cable) MS8158CA, MS8128CA
(5BNC Computer Cable) MS8102CA

■ ■ ■ ■

Introduction

x

You can purchase these accessories from your EMP-7300
dealer.

■

About This Manual

Chapter 1, “Installation”, gives step-by-step instructions on
how to set-up the projector and connect it to your computer,
video source, or other external speaker or PA system. Read
the installation procedures that apply to your environment.

Chapter 2, “Using the Projector”, tells you how to switch the
projector on/off and control simple projector settings.

Chapter 3, “Using the Menus”, describes how to use the
menus to adjust the color and image settings, change the
display of the projected image and modify audio settings such
as bass and treble.

Chapter 4, “Using ELP Link III”, describes how to use the
ELP Link III software which supports the presentation
function and controls the projector with the computer you
connected.

Chapter 5, “Maintenance”, describes how to maintain the
projector.

Chapter 6, “Troubleshooting”, tells you how to interpret the
projector’s indicator lights and gives helpful information for
avoiding errors, optimizing image quality and solving
problems.

Chapter 7, “Technical Specifications,” lists the technical
specifications for your EMP-7300 projector.

About This Manual

■ ■ ■ ■ ■

xi

Safety Instructions

Always follow these safety instructions when setting up and
using the projector:

1. Do not place the projector on an unstable trolley, stand or

table.

2. Do not use the projector near water or sources of heat.

3. Use attachments only as recommended.

4. Use the type of power source indicated on the projector.

If you are not sure of the type of power available, consult
your dealer or local electricity company.

5. Place the projector near a wall outlet where the plug can

be easily unplugged. Placez l’imprimante près d’une prise

de contacte où la fiche peut être débranchée facilement.

6. Insert the projector’s three-pin earthed plug into a

properly earthed socket. If you have a two-pin socket,
contact an electrician to replace it. Do not handle the plug
with wet hands.

7. Always take the following precautions when handling the

plug. Failure to do so may result in sparks or fire.

■ ■ ■ ■

xii

• Ensure the plug is free of dust before inserting it into a
socket.

• Ensure that the plug is inserted into the socket securely.

8. Do not overload wall sockets, extension leads or multi­way plug boards as this may cause fire or electric shock.

9. Do not place the projector where the cord can be stepped
on as this may result in fraying or damage to the lead or
the plug.

10.Unplug the projector from the wall socket before
cleaning. Use a damp cloth for cleaning. Do not use liquid
or aerosol cleaners.

Introduction

■

11.Do not block the slots and openings in the projector case.
They provide ventilation and prevent the projector from
overheating. Do not place the projector on a sofa, rug or
other soft surface or in a built-in installation unless proper
ventilation is provided.

12.Never push objects of any kind through cabinet slots.
Never allow liquid of any kind to spill into the projector.

13.Except as specifically instructed in this Owner’s Manual,
do not attempt to service this product yourself. Opening
or removing covers may expose you to dangerous voltages
and other hazards. Refer all servicing to qualified service
personnel.

14.Unplug the projector during thunder storms or if it is not
going to be used for an extended period. Do not place the
projector or remote control on top of heat-emitting
equipment or heated objects such as a car, etc.

15.Do not place the projector and remote control on top of
heat-producing equipment or in a heated place, such as a
car.

16.In the following situations unplug the projector from the
wall outlet and refer servicing to qualified service
personnel:

• If the power cable or plug becomes damaged or frayed.

• If liquid has been spilled into it or it has been exposed

to rain or water.

• If it does not operate normally when the operating

instructions are followed or if it exhibits a clear change
in performance indicating the need for servicing.

• If it has been dropped or the cabinet has been damaged.

Safety Instructions

■ ■ ■ ■ ■

xiii

Where to Get Help

SEIKO EPSON CORPORATION provides local customer
support and service through a nationwide network of
authorized EPSON dealers and Service Centres.

• Fax-on-Demand access to EPSON’s technical information

library

• Literature on current and new products

• The location of your nearest Authorized EPSON Reseller

or Customer Care Center

• Technical information on installation, configuration, and

operation of EPSON products

• Customer relations

For inquiries please contact the appropriate representative
listed in the section entitled “After sales service contact
addresses” at the end of this manual.

When you call for technical assistance, be ready to identify
your system and its configuration.

If you need help with any software program you are using,
please refer to the documentation that came with the
programs for technical support.

■ ■ ■ ■

xiv

Introduction

■

World Wide Web site

If you are connected to the Internet and have a Web browser,
you can access EPSON’s World Wide Web site at http://
www. epson. com. EPSON’s home page links users to What’s
New, EPSON Products, EPSON Connection, Corporate Info
and EPSON Contacts. Link to the EPSON Connection for
the latest drivers and FAQ’s (Frequently Asked Questions)
and the EPSON Chart area. To get in touch with EPSON
around the world, EPSON Contacts includes Contact
Information for local EPSON subsidiaries.

Where to Get Help

■ ■ ■ ■ ■

xv

■ ■ ■ ■

xvi

Introduction

■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■

■

1

Installation

This chapter tells you how to unpack and set up your

projector and connect it to other equipment. The projector
must be connected to a computer or a video source such as a
video tape deck, camcorder, digital camera or laser disk player.
For example, you may want to connect the projector to both
your computer and a video source, or set up the projector for
one or more of the following:

• Connect the mouse cable to use the remote control as a

wireless mouse.

• Provide audio for one or both image sources. The audio

source can be the computer, video source, or another
device such as a stereo.

• Connect to an external speaker or PA system to amplify the

audio.

■ ■ ■ ■ ■

1

Unpacking the Projector

When you unpack the projector, make sure you have all these
components:

• Projector

• Remote control

• 2 AA batteries

• Power cord

• Computer cable

• Audio cable

• Video/ audio cable

• MAC Desktop adapter

• MAC Monitor adapter

• Main cable

• PS/2 mouse cable

• Serial mouse cable

• MAC mouse cable

■ ■ ■ ■

2

• PC serial cable

• MAC serial cable

• ELP Link III (software)
Windows 3.1/95 diskette for IBM-PC
Windows NT diskette for IBM-PC
Macintosh diskette for Macintosh

All of the above items may not be required for your particular
computer system

Save all packaging materials in case you need to ship the
projector in the future. It should always be transported in its
original packaging or the equivalent.

Installation

■

Additional Items

The following items may also be required, depending upon
how you plan to use the projector.

• S-Video cable for S-Video signal input

A separate cable is required for each video source.

• Macintosh PowerBook output cable

This cable is normally provided with PowerBook models with
video output capabilities. Contact your Macintosh dealer if
you need to purchase one.

• Special connector, cable or components for connecting the

mouse cable to your computer

These items should be available from your computer dealer.
Note that the mouse cable cannot be used with a computer
that does not have a mouse connector.

♦

Note:

The hole on the right side of the projector accepts the
connection of the Kensington MicroSaver anti-theft device,
which can be purchased at your local computer dealer.

Unpacking the Projector

■ ■ ■ ■ ■

3

Setting Up the Projector

1. Place the projector on a sturdy, level surface within five

feet of the computer or video source.

♦

Caution:

Do not hold the projector by the lens. This can damage

the lens.

2. Place the projector the correct distance from the screen.

The distance between the projector and the screen
determines the actual image size. Use the general
guidelines below to determine the correct distance.

The distance above is a standard. Adjust to the correct
distance as referring to the guidelines.

■ ■ ■ ■

4

Installation

■

Screen size Horizontal distance from projector to screen

300 inches (610x460cm)488.2 inches (12.4 m) ~ 657.5 inches (16.7 m)
200 inches (410x300cm) 322.8 inches (8.2 m) ~ 437.0 inches (11.1 m)
100 inches (200x150cm) 161.4 inches (4.1 m) ~ 216.5 inches (5.5 m)
80 inches (160x120cm) 126.0 inches (3.2 m) ~ 173.2 inches (4.4 m)
60 inches (120x90cm) 94.5 inches (2.4 m) ~ 129.9 inches (3.3 m)
40 inches (81x61cm) 63.0 inches (1.6 m) ~ 86.6 inches (2.2 m)
30 inches (61x46cm) 47.2 inches (1.2 m) ~ 63.0 inches (1.6 m)
23 inches (47x35cm) 47.2 inches (1.2 m)

3. Turn the projector so that the lens is at right angles to the

screen. If the projector is not angled correctly the screen
image will be crooked.

4. Connect one end of the power cable to the projector’s

power connector. Connect the other end to an earthed
electrical socket.
The projector should be in sleep mode, indicated by an
orange power indicator.

♦

Warning:

Never look into the lens when the projector is on.
There is a risk that the projector might come on suddenly even
though it is not in use. The light from the lamp can damage your
eyes. It is especially important that children should not be
allowed to look into the lens.

Setting Up the Projector

■ ■ ■ ■ ■

5

5. To insert the batteries in the remote control device, slide

off the battery compartment cover as shown below.

6. Insert the two AA batteries included with the projector.

Make sure the polarity of the batteries is correct.

7. Replace the battery compartment cover.

■ ■ ■ ■

6

Installation

■

When replacing batteries, take the following precautions:

• Do not recharge used batteries or expose batteries to fire or

water.

• Replace batteries as soon as they run out. If the batteries

leak, wipe away the fluid with a soft cloth. If battery fluid
gets onto your hands wash them immediately.

• Remove the batteries if you will not be using the projector

for a long period.

Connecting to a Computer

You can connect the projector to a computer capable of
SVGA, VGA, SXGA, and XGA output. Resizing is supported
for VGA, SVGA and SXGA output. Below a list may be found
of the types of computers supported by this projector.

• IBM desktop PC or compatible

• IBM laptop or compatible

• Apple Macintosh desktop computer, including Macintosh

Quadra®, Macintosh Centris®, and Power Macintosh

• Any Apple PowerBook with video-out capability, including

all 160, 165, 180 and 500 series PowerBooks

See the section that applies to your computer.

Connecting to a Computer

■ ■ ■ ■ ■

7

Connecting to a PC desktop computer

Before beginning, make sure that the projector and computer
are both turned off.

1. Connect the video cable.

Monitor cable

Computer cable

■ ■ ■ ■

♦

8

Note:

manual for the location of the ports needed to connect your EMP

-7300 projector.

Installation

Computer configurations vary. See your computer

a. Connect either end of the computer cable to the

projector’s Computer 1 port. The Computer 2 port is
used when connecting a second computer.

b. Disconnect the monitor cable from the computer and

connect it to the other end of the computer cable.

■

c. If necessary, connect the monitor cable of the

computer monitor to the projector’s Computer out.

d. Tighten the screws on all connectors.

2. Connect the main cable. The main cable connects the

mouse cable (needed to use the remote control as a
mouse) and serial cable (needed to use the ELP Link III
software and the Effects buttons on the remote control)
from your computer to the projector.

serial cable

main cable

mouse cable

Connecting to a Computer

■ ■ ■ ■ ■

9

a. Connect the small end of the main cable to the

projector’s Mouse/Com 1 port. The Mouse/Com 2
port is used when you are connecting a second
computer.

b. Connect the PS/2 mouse cable (9-pin) to the mouse

terminal on the large end of the main cable.

c. Disconnect the computer’s mouse cable from the

mouse port on the back of your computer and connect
the mouse connector (6-pin) of the PS/2 mouse
cable to the mouse port.

d. If your system uses a serial mouse, use the serial mouse

cable instead of the PS/2 mouse cable.

e. If you are planning to use the ELP Link III software,

connect either end of a PC serial cable to the PC serial
terminal on the large end of the main cable.

■ ■ ■ ■

10

♦

Installation

Note:

that you will not be able to use the ELP Link III software

if your system does not have two serial ports.

f. Connect the other end of the PC serial cable to the

serial port on the back of your computer.

g. Tighten all connector screws to ensure secure

connections.

■

3. Connect the audio cable if needed.

Audio cable

a. Connect one end of the audio cable to the Audio 1

jack on the projector. (Use the Audio 2 jack if you are
connecting a second computer).

b. Connect the other end of the audio cable to the audio

out port on a sound card in the computer.

Connecting to a Computer

■ ■ ■ ■ ■

11

Connecting to a PC laptop computer

Before beginning, make sure that the projector and computer
are both turned off.

1. Connect the video cable.

Computer cable

■ ■ ■ ■

12

♦

Installation

Note:

Laptop configurations vary. See your computer manual
for the location of the ports needed to connect your EMP-7300
projector.

a. Connect either end of the computer cable to the

projectors Computer 1 port. The Computer 2 port is
used when connecting a second computer.

b. Connect the other end of the computer cable to the

laptop’s video (monitor) port.

c. Tighten the screws on all connectors to make sure they

are fastened securely.

■

2. Connect the main cable. The main cable connects the

mouse cable (needed to use the remote control as a
mouse) and serial cable (needed to use the ELP Link III
software and the Effects buttons on the remote control) to
the projector.

serial cable

mouse cable

main cable

a. Connect the small end of the main cable to the

projector’s Mouse/Com 1 port. The Mouse/Com 2
port is used when you are connecting a second
computer.

b. Connect the PS/2 mouse cable (9-pin) to the mouse

terminal on the large end of the main cable.

c. Disconnect the computer’s mouse cable from the

mouse port on the back of the computer and connect
the mouse connector of the PS/2 mouse cable (6-pin)
to the mouse port on the back of your laptop.

d. If your system uses a serial mouse, use the serial mouse

cable instead of the PS/2 mouse cable.

Connecting to a Computer

■ ■ ■ ■ ■

13

e. If you are planning to use the ELP Link III software,

connect either end of a PC serial cable to the PC
SERIAL terminal on the large end of the main cable.

f. Connect the other end of the PC serial cable to the

serial port on the back of your laptop.

♦

Note:

That you will not be able to use the ELP Link III software
if your system does not have two serial ports.

g. Tighten all connector screws to ensure secure

connections.

h. Configure your laptop to work with an external

mouse.

■ ■ ■ ■

14

Installation

■

3. Connect the audio cable.

Audio cable

a. Connect one end of the audio cable to the Audio 1

jack on the projector. (Use the Audio 2 jack if you are
connecting a second computer).

b. Connect the other end of the audio cable to your

laptop.

Connecting to a Computer

■ ■ ■ ■ ■

15

Connecting to a Macintosh desktop
computer

Before beginning, make sure that the projector and computer
are both turned off.

1. Connect the video cables.

Video
cable
adapter

MAC monitor

MAC
desktop
adapter

Monitor cable

Computer cable

adapter

■ ■ ■ ■

16

♦

Installation

Note:

Macintosh computer configurations vary. See your
computer manual for the location of the ports needed to connect
your EMP-7300 projector.

a. Connect either end of the computer cable to the

projector’s Computer 1 port. The Computer 2 port is
used when connecting a second computer.

b. Set the DIP switches of the Mac desktop adapter in

accordance with the resolutions you want to use (i.e.
16” mode).

c. Connect either end of the computer cable to the small

terminal of the desktop adapter.

d. Disconnect the monitor cable from the computer and

connect it to the large terminal (D-sub 15 pin) of the
desktop adapter.

■

e. Tighten fixed screws for the desktop adapter.
f. If necessary, attach the Mac monitor adapter to the

monitor cable and connect the cable with the adapter
to the projector’s Computer out.

Connecting to a Computer

■ ■ ■ ■ ■

17

2. Connect the main cable. The main cable connects the

mouse cable (needed to use the remote control as a
mouse) and serial cable (needed to use the ELP Link III
software) from your Macintosh to the projector.

MAC serial
cable

MAC mouse cable

Main cable

a. Connect the small end of the main cable to the

projector’s Mouse/Com 1 port. The Mouse/Com 2
port is used when you are connecting a second
computer.

b. Connect the MAC mouse cable (9-pin) to the mouse

terminal on the other end of the main cable.

c. Disconnect the mouse cable from the Mouse port of

the Macintosh and connect the mouse connector of
the MAC mouse cable to it.

d. If you are planning to use the ELP Link III software,

connect either end of a MAC serial cable to the MAC
serial terminal at the large end of the main cable.
Connect the other end of the MAC serial cable to the
printer port or modem port on the back of your
Macintosh.

■ ■ ■ ■

18

Installation

■

3. Connect the audio cable.

Audio cable

a. Connect one end of the audio cable to the Audio 1

jack on the projector. (Use the Audio 2 jack if you are
connecting a second computer.)

b. Connect the other end of the audio cable to your

computer.

Connecting to a Computer

■ ■ ■ ■ ■

19

Connecting to a Macintosh PowerBook

Remember that you can only use a PowerBook model that
have video-out capability. See page 7 for more information.

Before beginning, make sure that the projector and
PowerBook are both turned off.

1. Connect the video cable.

MAC
desktop
adapter

Computer cable

Video
cable
adapter

■ ■ ■ ■

20

♦

Installation

Note:

PowerBook configurations vary. See your computer
manual for the location of the ports needed to connect your EMP

-7300 projector.

a. Connect the other end of the computer cable to the

projector’s Computer 1 port. The Computer 2 port is
used when connecting a second computer.

b. Set the DIP switches of the MAC desktop adapter in

accordance with the resolutions you want to use (i.e.
16” mode).

c. Connect an adapter (which came with the computer or

your own) such as a converter for a D-Sub 15 terminal
to the video output port of your PowerBook.

■

d. Connect the big connector (D-Sub15) of the MAC

desktop adapter to the video output port converted in
step c.

e. Connect either end of the computer cable to the small

connector (D-Sub 15 Mini) of the MAC desktop
adapter which you connected in the previous steps.

f. Tighten the fixed screws for the MAC desktop adapter

and the converter.

Connecting to a Computer

■ ■ ■ ■ ■

21

2. Connect the main cable. The main cable connects the

mouse cable (needed to use the remote control as a
mouse) and serial cable (needed to use the ELP Link III
software) to the projector.

MAC serial
cable

MAC mouse cable

Main cable

a. Connect the small end of the main cable to the

projector’s Mouse/Com 1 port. The Mouse/Com 2
port is used when connecting a second computer.

b. Connect the MAC mouse cable (9-pin) to the

MOUSE terminal on the large end of the main cable.

c. Disconnect the mouse from the computer port, and

connect the MAC mouse cable (4-pin) to this port.

d. If you are planning to use the ELP Link III software,

connect either end of a MAC serial cable to the MAC
SERIAL terminal on the large end of the main cable.
Connect the other end of the MAC serial cable to the
Printer port or Modem port on the back of your
PowerBook.

e. Tighten the screws on all connectors to make sure they

are fastened securely.

■ ■ ■ ■

22

Installation

■

3. Connect the audio cable.

Audio cable

a. Connect one end of the audio cable to the Audio 1

jack on the projector. (Use the Audio 2 jack if you are
connecting a second computer.)

b. Connect the other end of the audio cable to your

computer.

Connecting to a Computer

■ ■ ■ ■ ■

23

Connecting to a Video Source

You can use this connection procedure to connect a video
tape deck, a camcorder, a laser disc player or any other
compatible video image source to the projector. The
projector can receive composite video or S-Video signals. If
your video source has a one-pin RCA video jack you have
composite video. If your video source has a four-pin video
jack you have S-Video. If your video source has a three-pin
video jack, you have G Sync-Video.

♦

Note:

The projector is not compatible with a cable TV-style F
connector.

You can connect to both an S-Video and a composite video
source at the same time. However, the projector automatically
selects the S-Video source. To display composite video you
must disconnect the S-Video source.

The projector supports NTSC, PAL and SECAM video
formats. By default, it automatically detects and identifies the
video format. However, you can set it to detect a single
broadcast format. (See “Video menu” in Chapter 3.) Note
that the projector will then be able to detect only one type of
video signal.

The type of cable you need to connect the video source to the
projector depends on whether you have composite video, S­Video or G Sync-Video. For composite video, use the video/
audio cable supplied with the projector. For S-Video, use the
S-Video cable and audio cable supplied with your video device
or obtain one from your computer dealer. For G Sync-Video,
use the BNC type cable came with your video source.

■ ■ ■ ■

24

Installation

■

To connect a video source to the projector:

1. Switch off the projector and video source if they are on.

2. If your composite video uses an RCA-type composite

video connector, you will need the audio/video cable
supplied with the EMP-7300. If your video uses a S-Video
or BNC type connector, you will need to provide YOUR
OWN S-Video or BNC type cable, or use the S-Video or
BNC type cable that came with your video source.

3. For composite video, connect the yellow RCA plug at one

end of the video/audio cable to the projector’s Video
jack. Connect the other yellow RCA plug to the video-out
jack on the video source.

A/V cable

4. Connect the other plugs on the audio/visual cable to the

Audio jacks of the projector: insert the white plug into the
L jack and the red plug into the R jack. Connect the plug
at the other end of the audio/visual cable to the audio
output jacks of the video source.

Connecting to a Computer

■ ■ ■ ■ ■

25

5. For S-Video, insert one end of the S-Video cable into the

projector’s S-Video jack. Insert the other end in the S­Video Out jack on your S-Video source.

S-Video cable

6. For G Sync-Video (BNC typy), insert the end of the G

Sync-Video cable into the projector’s R/R-Y, G/Y and
B/B-Y jack. Insert the other end in the jack on your G
Sync-Video source.

Connecting to an External Speaker or

■ ■ ■ ■

PA System

Though the projector’s internal speakers are enough for most
small-size or medium-size rooms, an external speaker can be
connected to achieve the best results for large room
presentations.

A commercially available RCA-to-3.5 mm stereo mini audio
cable or 3.5 mm stereo mini audio cable is required to
connect the projector’s 3.5 mm stereo mini jack to an external
speaker or a PA system. These items can be obtained from
your computer dealer.

1. Check to ensure that both the projector and all sources are

turned off.

Installation

26

■

2. Connect the cable’s 3.5 mm stereo mini-plug to the

projector’s Audio Out jack.

RCA/3.5 mm cable

3. Connect the other end of the cable to the external speaker

or PA system.Ensure you to connect the red RCA plug to
the right channel and the white RCA plug to the left
channel.

Connecting to an External Speaker or PA System

■ ■ ■ ■ ■

27

Connecting to a Workstation

You can not use any kind of workstations. Before connecting,
make sure the type of your workstation. If you are not sure of
the type of workstation, consult your dealer or local
workstation company.

The following workstations are available:

• If your workstation output is 13W3, use a

13W3(male)↔HD D-Sub15(male) cable.

(Epson recommended, MS8158CA (1.8m) 6ft,

MS8128CA (0.9m) 3ft)

• If your workstation output is 5BNC, use a

5BNC(male)↔HD D-Sub15(male) cable

(Epson recommended, MS8102CA (1.8m) 6ft)

* You need to turn the Computer2/5BNC switch on the back of the projector to

5BNC.

■ ■ ■ ■

28

♦

Installation

Note:

If your computer contains the workstation function, refer
the section of "Connecting to a Computer" to connect.

■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■

■

2

Using the Projector

This chapter provides the following information about using

your projector:

• Turning equipment on and off

• Adjusting the screen image

• Controlling the projector

• Checking the status of the projector

■ ■ ■ ■ ■

29

The illustration below identifies the parts of your projector.

operation indicator

operation panel

speaker

remoto
control
reciver

zoom ring

focus ring

speaker

front foot

foot adjuster lever

■ ■ ■ ■

Using the Projector

30

■

Turning the Equipment On and Off

Always turn on the projector and its attached equipment in
the following order.

1. Video source

2. Audio source (if different than computer or video source)

3. Projector

4. External speaker or PA system

5. Computer

Turning the Projector On and Off

1. Remove the projector lens cap.

2. Press the Power button on the remote control or control

panel. The green power indicator comes on.

If computer or video equipment is attached, the computer or
video signal is projected.

Allow about 30 seconds for full illumination.

♦

Warning:

Never look into the lens when the lamp is on. This can
damage your eyes. It is especially important that children are not
allowed to look into the lens.

Turning the Equipment On and Off

■ ■ ■ ■ ■

31

Reverse the order shown above to turn off the projector and
other equipment. After you press the Power button to turn
off the projector, the fan will remain on and the operation
indicator will flash orange for about one minute as the
projector cools.

operation indicator

The indicator stops blinking (and remains lit in orange) when
the cooling operation is complete.

■ ■ ■ ■

♦

Note:

on while the power indicator is flashing green. Before pressing
the Power button again, wait until the lamp has cooled and the
operation indicator is orange.

Sleep Mode

Sleep mode conserves electricity by automatically turning off
the lamp after the projector has not been used for 30 minutes.
In sleep mode, the projector’s operation indicator is orange
and only a minimum amount of the projector’s circuitry
remains on. This conserves electricity, cools the projector, and
extends the life of the lamp. When the projector is in sleep
mode, you can press the Power button to start projecting
images, or you can unplug the projector’s power cord.

Using the Projector

32

The projector is designed so that it cannot be turned back

■

Focusing and Positioning the Screen

After an image appears on the screen, check to see if it is in
focus and whether it fits properly on the screen.

zoom ring

focus ring

• To adjust the focus of the image, rotate the focus ring,

which is the outer ring on the projector’s lens.

• To adjust the size of the image, rotate the inner zoom ring.

Rotate the zoom ring clockwise to make the image larger,
and counterclockwise to make it smaller.

Focusing and Positioning the Screen Image

■ ■ ■ ■ ■

33

If you need to raise or lower the image on the screen, extend
or retract the two feet at the bottom of the projector as
follows.

1. Stand behind the projector and support the front of it

while you lift the foot adjuster lever located above the feet.
This unlocks the feet so they can move up and down
freely. Do not let the projec-tor drop.

■ ■ ■ ■

♦

Using the Projector

34

Caution:

Do not hold the projector by the lens as you may

damage it.

2. While lifting the foot adjuster lever, raise or lower the

projector until the screen image is positioned correctly.

3. Release the lever to lock the feet in their new position.

4. To fine-tune the height of the projector, turn the feet

clockwise to raise the height or anti-clockwise to lower it.

■

Resize Button

The Resize button allows you to select the projection screen
mode for certain types of image input signals from a
computer.

With computer images up to XGA (1024 x 768 pixels) size
(for example a 640 x 480-pixels VGA image), and with video
images as well, you can either select to display the area in the
centre of the projected image (Window display) or to display
of the entire projected image (Resize display).

With images larger than XGA (1024 x 768 pixels) size (for
example a 1280 x 1024 pixels SXGA image or a 1152 x 870
Macintosh 21” image), you can either select to display a
portion of the projected image (Window display) or to display
the entire projected image (Resize display).

The Resize button cannot be used with XGA (1024 x 768
pixels).

Focusing and Positioning the Screen Image

■ ■ ■ ■ ■

35

Controlling the Projector

Normally you control the projector using the remote control.
The buttons on the remote control allow you to do the
following:

• Switch power on and off.

• Auto-set-up of the computer image screen.

• Switch between input images (Computer 1, Computer 2,

video-computer).

• Access menu for adjustment of image, audio, video, and

display settings.

• Control resizing.

• Control display freeze.

• Control display blanking.

• Adjust and mute audio output.

• Control custom functions.

• Move the pointer.

■ ■ ■ ■

Using the Projector

36

■

Using the Remote Control

Source

Menu

pointer button

Effects

3

4

2

1

5

bottom

top
multi-purpose
button

Resize

Freeze

Blank

Custom

Mute

- Volume +

Power

multi-purpose
button

Remote control

When using the remote control, always point it towards the
remote control receivers located at the front and at the back
of the projector.

To be able to use the remote control as a cordless mouse
connect the projector to your computer with the cables came
with the ELP Link III Kit.

To use the remote control, always point it towards the remote
control receivers located at the front of the projector.

You can use the remote control up to 10 metres (33 feet)
from the projector.

♦

Note:

The projector may not respond to remote control
commands in these conditions: ambient light is too bright; a
certain type of fluorescent light is present; a strong light source
(such as direct sunlight) shines into the infrared receiver; or
other equipment emitting infrared energy is present (such as a
radiant room heater). Remove these conditions to use the remote
control or control the projector from a computer.

Controlling the Projector

■ ■ ■ ■ ■

37

In addition to the remote control, you can also control the
projector by using the buttons on the projector’s operation
panel located on top of the projector.

This table summarizes the functions on the remote control.

Button Function

Menu Displays or hides the menu.
Source Switches to Computer 1 , Computer 2*, or Video.
Pointer button Use the pointer button to navigate the menus or use

the remote as a mouse pointer when the projector is
con- nected to the computer with all cables in the ELP
Link III communications kit.

Effects buttons Use to display special effects in conjunction with the

ELP Link III software.

Top multi-pur­pose button

Bottom multi-pur­pose button

Blank Clears the screen of special effects and switches to a

Resize Switches the display dot mode and resize mode (for

Custom Use to assign functions to the Effects keys using the

Freeze Keeps the current computer or video image on the

Mute Cuts off audio.
– Volume + Adjusts the volume.
Power Starts or stops the projector.

* When the computer 2/5 BNC switch on the back of the projector is turned to 5

BNC, the source is switch to 5 BNC.

Acts as a right mouse click, registers a menu selection,
and selects other custom functions.

Acts as a left mouse click, registers a menu selection,
and selects other custom functions.

black, a blue or user logo display.

VGA, SVGA and SXGA input).

ELP Link III software.

screen.

■ ■ ■ ■

Using the Projector

38

■

Using the Control Panel

Power

Menu

Mute

Resize

g

n

i

k

c

a

r

T

y

S

S

y

Volume

BlankSource

n

c

.

T

r

a

c

k

i

n

g

.

c

n

Enter button

Operation Panel

You can use the control panel to control the printer instead of
the remote control. However, you can program and access the
custom features only when you are using the remote control.

Controlling the Projector

■ ■ ■ ■ ■

39

The following table summarizes the functions on the control
panel.

Button Function

Power Starts or stops projection.
Source Switches to Computer 1 , Computer 2*, or Video.
Menu Displays or hides the menu.
Up, down arrows

(Sync+/Sync-)

Synchronizes the computer’s graphic signal.
Use these buttons to adjust an overall image that is
fuzzy or streaked, or to select menu items during menu
opera- tions.

Left, right
arrows(tracking-/
tracking+)

Matches the projector’s internal clock to various
computer graphic signals (tracking adjustment).
Use these buttons to adjust an image with vertical
fuzzy lines, or to change numeric settings during menu

opera- tions.
Enter key Registers a menu selection.
Resize Switches the display dot mode and resize mode (for

VGA, SVGA, and SXGA input).
Mute Cuts off audio.
– Volume + Adjusts the volume.

* When the computer 2/5 BNC switch on the back of the projector is turned to 5

BNC, the source is switch to 5 BNC.

■ ■ ■ ■

Using the Projector

40

■

Projector Status Indicators

The power and lamp indicators at the top of the projector tell
you the projector’s operating status.

Temperature Indicator

Lamp Indicator

Operation Indicator

♦

Caution:

A red indicator warns you if a serious problem occurs.
See Chapter 6, “Troubleshooting,” for what to do if a warning
light comes on.

Operation Indicator

Displays machine condition.

Color Status Meaning

Orange Lit Sleep mode.
Green Flashing Projection lamp is warming up for 30 sec..

Green Lit The projector is projecting and providing

Orange Flashing Projection lamp is off, the projector is

- Off The projector has internal projector prob-

After that, the indicator will turn to lit to
start projecting.

the maximum of brightness.

cooling down for one minute. While
cooling, operations can not work.

lem and turned off.

Projector Status Indicators

■ ■ ■ ■ ■

41

Lamp Indicator

Displays lamp condition.
This indicator is off when the projector is in a normal

condition.

Color Status Meaning

- Off The projector is in a normal condition.
Orange and

Red

Red Lit Projection lamp has reached the end of its

Red Flashing The projector has lamp or other problems

Flashing Projection lamp is reaching the end of its

life and should be replaced with a new
one.

life and will not longer project images.
Replace the projection lamp with a new
one.

around the lamp. Contact your nearest
service provider.

Temperature Indicator

Displays the internal temperature condition.
This indicator is off when the projector is in a normal

condition.

Color Status Meaning

- Off The projector is in a normal condition.
Orange Flashing The projector is in a hot condition.
Red Lit The projector is too hot and turned off.

■ ■ ■ ■

Using the Projector

42

Red Flashing The projector has a cooling fan or

temperature sensor problem. Contact
your nearest service provider.

■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■

■

3

Using the Projector Menus

• The seven projector menus enable you to control your

projector.

• The Computer menu controls the computer image, such as

brightness and contrast, when the computer is the image
source.

• The Video menu controls the video image, such as

brightness and color saturation, when the image source is
video, such as a VCR.

• The Audio menu controls audio features, such as the

volume level, tone setting, and 3D sound.

• The Options menu enables you to set various projector

options.

• The Custom menu assigns functions to the remote

control’s Custom button.

• The About Menu displays lamp hours, frequency and etc..

• The Reset All menu returns all settings to their factory

defaults.

■ ■ ■ ■ ■

43

Accessing the Main Menu

The projector menus can be accessed using either the
projector control panel or remote control.

To display the Main menu, press the Menu button. The Main
menu appears:

Press the Menu button again to hide the menu.

Changing a Menu Setting

To change a menu setting:

1. Press the Menu button on the control panel or remote

control to display the Main menu.

■ ■ ■ ■

Using the Projector Menus

44

■

2. Press the up or down arrows (control panel) or press the

top or bottom of the pointer button (remote) to scroll
through the menu choices.

Menu

Mute

Power

BlankSource

Resize

n

c

y

.

S

S

y

n

Volume

T

r

a

c

k

up and down

i

n

g

.

c

buttons

g

n

i

k

c

a

r

T

pointer button

Source

Menu

Effects

3

4

2

1

Resize

Freeze

5

Blank

Custom

Mute

- Volume +

Power

Changing a Menu Setting

■ ■ ■ ■ ■

45

3. Press either the Enter button (control panel) or the top or

bottom multi-purpose button (remote) to display a
submenu.

Power

Source

Menu

BlankSource

Resize

Menu

g

n

i

k

c

a

r

T

Mute

Enter button

S

S

n

y

y

n

Volume

c

.

T

r

a

c

k

i

n

g

.

c

top

multi-purpose

button

bottom

Effects

3

4

2

1

Resize

Freeze

5

Blank

Custom

Mute

- Volume +

Power

multi-purpose

button

A sub-menu such as the following appears.

■ ■ ■ ■

♦

Note:

source is Computer or Video.

Using the Projector Menus

46

Sub-menus differ, depending on if the current image

■

4. Press the up or down arrows (control panel) or the top or

bottom of the pointer button (remote) to scroll through
the menu choices.

5. Press either the left or right arrow buttons (control panel)

or the right or left sides of the pointer button (remote) to
change the setting.

6. When you are finished changing settings, press the Menu

button again to hide the menu, or press Enter to go back
to the Main menu. The changes are saved automatically.

Menu Options

The following menus are described in this section:

• Video menu (Image source = Computer)

• Video menu (Image source = Video)

• Audio menu

• Options menu

• Custom menu

• About menu

• Reset All menu

Video Menu (Image source = Computer)

The Video menu enables you make adjustments to the
projected image. The following options are available when the
image source is Computer.

♦

Note:

The computer must be connected and operating, and the
image source on the projector must be set to Computer for you to
access these menu options.

Menu Options

■ ■ ■ ■ ■

47

Menu item Description

Brightness Lightens or darkens the overall image. Increase

brightness to make the image lighter, or decrease it to
make the image darker.

Contrast Adjusts the relative difference between light and dark

areas. Increase contrast to make light areas lighter
and dark areas darker, or decrease it to lessen the
difference between the light areas and dark areas of
the image.

Sync Synchronizes with the tracking signal sent from the

computer. Adjust this setting whenever the overall
image is fuzzy or to remove streaks from the image.

Tracking Matches the projector’s internal clock to various

computer graphic signals. Adjust this setting to remove
vertical fuzzy lines from the image.

Color Adjusts the color balance of the input source.

Select this item and then press a Click button or the
<Enter> button to enter the color adjustment mode.
While in the color adjustment mode, use the pointing
button or the <Up> and <Down> button to select a
color. Next, use the pointing button or <Left> and
<Right> buttons to adjust the selected color.
Increasing a color’s setting makes that color more
intense on the screen, while a lower setting makes the
color less intense.
After you are finished, press a Click button or the
<Enter> button to return to the Computer Menu.

■ ■ ■ ■

Position Select this item and then press a Click button or the

Using the Projector Menus

48

<Enter> button to enter the screen position adjustment
mode. While in the screen position adjustment mode,
use the pointing button or the <Up>, <Down>, <Left>
and <Right> buttons to move the screen position in the
corresponding direction. After you are finished, press a
Click button or the <Enter> button to return to the
Computer Menu.

■

Menu item Description

Auto Pressing AUTO automatically adjusts the computer

input signal to the current projector settings. Press the
AUTO button while the image fills the entire screen of
your computer, like a Windows screen. Certain
computer input signals may not be totally compatible
with AUTO button settings. In such cases, use the
menus to make additional adjustments.

Reset Returns all Computer Menu items to their factory

defaults. Select this item and then press a Click button
or the <Enter> button to display the confirmation
screen.
Next, select Yes and then press a Click button or the
<Enter> button to reset the Computer Menu items. If
you change your mind, select No and then press a
Click button or the <Enter> button to clear the
confirmation screen without changing any settings.

Menu Options

■ ■ ■ ■ ■

49

Video Menu (Image source = Video)

The Video menu enables you make adjustments to the
projected image. The following options are available when the
image source is Video.

♦

Note:

The video source (such as a VCR or camcorder) must be
connected and operating, and the image source on the projector
must be set to Video for you to access these menu options.

Menu item Description

Brightness Lightens or darkens the overall image. Increase

brightness to make the image lighter, or decrease it to
make the image darker.

Contrast Adjusts the relative difference between light and dark

areas. Increase contrast to make light areas lighter
and dark areas darker, or decrease it to lessen the
difference between the light areas and dark areas of
the image.

Sharpness Adjusts screen sharpness.

Increase sharpness to make screen images more
sharp, or decrease it to make the images less sharp.

Saturation Adjusts color density. Increase color density to make

colors darker and more opaque, or decrease it to make
colors lighter and less opaque.

Tint (NTSC only) Adjust the red-green balance of the screen. Increase

tint to add more green, or decrease it to add more red.

Auto Specifies the video signal system. Normally this signal

system setting should be left at AUTO for automatic
detection of the video signal system. If automatic
selection is not possible for some reason, use this
menu to manually specify NTSC, NTSC 4.43, PAL,
MPAL, NPAL, PAL (60Hz) or SECAM.

■ ■ ■ ■

Using the Projector Menus

50

■

Menu item Description

Reset Returns all Video Menu items to their factory defaults.

Audio Menu

The Audio menu enables you make adjustments related to
audio.

Menu item Description

Volume Adjusts the volume level for the speakers and audio-

Treble Adjusts the treble tone.
Bass Adjusts the bass tone.
3D Sound Adjusts sound effects from 1 to 6 value. Increasing

Select this item and then press a Click button or the
<Enter> button to display the confirmation screen.
Next, select Yes and then press a Click button or the
<Enter> button to reset the Video Menu items. If you
change your mind, select No and then press a Click
button or the <Enter> button to clear the confirmation
screen without changing any settings.

out terminal. Increase the audio volume to raise the
volume, or decrease it to lower the volume.

number, the sound effects gets enhanced.

Reset Returns all Audio menu items to their initial factory

defaults. Select this item and then press the Enter
button (control panel) or either multi-purpose button
(remote) to display the confirmation screen.
Next, select Yes and then press the Enter button
(control panel) or a multi-purpose button (remote) to
reset the Audio menu.
If you change your mind, select No and then press a
multi- purpose button (remote) or the Enter button
(control panel) to clear the confirmation screen without
changing any settings.

Menu Options

■ ■ ■ ■ ■

51

Options Menu

The Options menu enables you to adjust basic settings that
normally do not need changing.

Menu item Description

Prompt Temporarily displays a prompt on the projector screen

Color Temp. Adjusts the whiteness of the screen. The H setting

Rear Proj. Mirrors the projected images horizontally (left-right).

to identify which source (computer or video) is
providing the image.

provides a cold white, M standard white, L a warm
white, and U sets sub-brightness R, B.
Selecting the User item and pressing a Click button or
the <Enter> button displays a screen for more precise
color temperature setting. Use the pointing button or
the <Up> and <Down> buttons to select the color you
want to adjust, and then use the pointing button of the
<Left> and <Right> buttons to change the selected
value. A high color temperature value enhances the
selected color within the overall image, while a lower
value weakens the color. Press a Click button or the
<Enter> button to clear the setting screen and return to
the Option Menu.

Selecting ON turns mirroring on, while OFF turns it off
(for a normal image). Turn this option on when
projecting from behind onto a transparent screen being
viewed from the opposite side.

■ ■ ■ ■

Ceiling Mirrors the projected images vertically (top-bottom)

Blank Selects what should be projected when the projector’s

Using the Projector Menus

52

and horizontally (left-right). Selecting ON turns
mirroring on, while OFF turns it off (for a normal
image). Turn this option on when hanging the projector
upside-down from the ceiling.

Blank button is pressed to blank the screen. You can
select either a black screen, a blue screen or a user
logo. A user logo can be created using the ELP Link III
software that comes with the projector.

■

Menu item Description

View Change Specifies the view change to use when the input

source is changed.
OFF: No visual effects, simply cut to new source.
Diagonal: Original source screen shrinks from upper

left to lower right, and new source screen
expands from upper left to lower right.

Left

→ Right: Original source screen shrinks from left

to right, and new source screen expands
from left to right.

Fade: Original source screen shrinks from outside in,

and new source screen expands from
inside out.

Language Selects the menu language in the sequence:

Japanese, English, German, French, Italian, Spanish
and Portuguese.

Mouse /COM Locks and unlocks the Mouse/Com port.

Select 1 to assign the wireless mouse control to the
computer connected to the Mouse/Com 1 port. The
wireless mouse controls the computer connected to
Mouse/Com 1 only if the input source is switched to
Computer 2.

Select 2 to assign the wireless mouse control to the
computer connected to the Mouse/Com 2 port.

Selecting 1

→2 tells the projector to automatically

switch wireless mouse control whenever the input
source computer is changed.

BNC Specifies input image signal mode. User can select

either RGB or R-Y,Y,B-Y.

Reset Returns all Option Menu items to their factory defaults.

Select this item and then press a Click button or the
<Enter> button to display the confirmation screen.
Next, select Yes and then press a Click button or the
<Enter> button to reset the Option Menu items. If you
change your mind, select No and then press a Clock
button of the <Enter> button to clear the confirmation
screen without changing any settings.

Menu Options

■ ■ ■ ■ ■

53

Custom Menu

The Custom menu allows you to select special features such as
zoom, preview, or strobe effects. Unlike the other menus,
which use the Enter button to select a menu option, the
Custom menu requires that you use the Custom button to
select a Custom menu option.

The Custom button is located on the lower part of the remote
control.

To open the Custom menu, press the top multi-purpose
button or select CUSTOM from the Main menu. ZOOM is
highlighted and the words PRESENT SET are displayed after
it. Refer to the table below for a description of the various
zoom functions.

To change PREVIEW or STROBE settings, select the
function you want, then press the top multi-purpose button.

The Custom menu functions are:

Menu item Function Description

Zoom Press the bottom multi-purpose button

then check if the value next to the Zoom
menu is New Set or Present Set. If the
value is New Set, press the bottom multi­purpose button to toggle the value.

■ ■ ■ ■

Using the Projector Menus

54

Press the Custom button to access the
Zoom function. An indicator appears in
the lower right of the screen while the
zoom function is on. Zoom remains on
until you press the Custom button again.

The following remote control functions are
available while the zoom function is on:

Zoom In Each press of the remote control’s bottom

multi-purpose button zooms in on the
center of the displayed image, enlarging it
+0.25 times.

■

Menu item Function Description

Zoom Out Each press of the remote control’s top

multi-purpose button zooms out on the
center of the displayed image, reducing it
+0.25 times.

Zoom Screen
Shift

Press the pointer button to zoom in on a
portion of the enlarged display. You can
move the image up, down, left, right, and
diagonally to closely view any part of the
display.

Preview Press the bottom multi-purpose button

then check if the value next to the Preview
menu is New Set or Present Set. If the
value is New Set, press the bottom multi­purpose button to toggle the value.

Press the Custom button to turn on the
Preview function. The preview function
remains on until you press the Custom
button again, select an input source with
the pointer button, or press the remote
control’s bottom multi-purpose button.

Strobe Press the bottom multi-purpose button

then check if the value next to the Strobe
menu is New Set or Present Set. If the
value is New Set, press the bottom multi­purpose button to toggle the value.

Press the Custom button to turn on the
strobe function. The strobe function
remains on until you press the Custom
button again. The screen is divided into
four quadrants, each of which shows the
image from the current input source.

Menu Options

■ ■ ■ ■ ■

55

Menu item Function Description

Number of
Frames, Time

Press the top multi-purpose button while
the strobe effect is running to display a
screen specifying the number of frames
flashed and the time interval between
them. You can specify the number of
frames as 4, 9, or 16, and the time interval
from 0.1 to 1 second in 0.1 second
increments.

Press the top multi-purpose button again
to clear the setting screen.

■ ■ ■ ■

Using the Projector Menus

56

■

About Menu

The About menu displays the following information about
your projector.

H/V Freq. Displays H/V frequency of the current computer.
COMPUTER2 /

5BNC
LAMP Displays the number of hours the current projector

Switches between computer2 and 5BNC.

lamp has been used. The color of this display turns red
when the projector lamp is near the end of its normal
life. When this happens, replace the projector lamp
with a new one as soon as possible.

RESET ALL Menu

Executing this command resets the settings in all menus to
their factory defaults.

While executing this command, the OSD menu disappears
from a screen and "RESET ALL" will be flashing on the
center of the screen.

Select this item and then press a Click button or the <Enter>
button to display the confirmation screen.

Next, select Yes and then press a Click button or the <Enter>
button to reset all menu items.

If you change your mind, select No and then press a Click
button or the <Enter> button to clear the confirmation screen
without changing any settings.

Menu Options

■ ■ ■ ■ ■

57

■ ■ ■ ■

Using the Projector Menus

58

■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■

■

4

Using the ELP Link III Software

The ELP Link III software is a utility you can run from your

desktop or laptop computer to control projector features and
configure special effect buttons on the remote control.

■ ■ ■ ■ ■

59

Installing the Software

ELP Link III software can be used with the following
operating systems:

• Windows 3.1/95

• Windows NT

• Macintosh OS System (from ver.7)

Connecting Needed Cables

Before installing the software, make sure the projector is
properly connected to your computer. See Chapter 1,
“Installation,” for instructions about how to install the serial
and mouse cables needed to use the Link III software.

Installing the Software from Windows 3.x

Perform the following steps to set up the software for
Windows 3.1/95.

1. Insert the ELP Link III for Windows 3.1/95 Setup disk

into a diskette drive (A: or B: as appropriate).

■ ■ ■ ■

2. In the Windows Program Manager, click on the File

menu, then on Run. The Run dialog box appears:

Using the ELP Link III Software

60

■

3. Type A:\SETUP (or B:\SETUP as appropriate), then press

Enter or click OK. The ELP Link III introduction
appears.

4. Press C to continue.

5. To accept the default location for where the software

should be installed, press C to continue. Otherwise, enter
a new directory name and then press C.

6. The Link III software communicates with the projector

using the computer’s serial communication (COM) port.
Specify which COM port to use, then press C to continue.
(Most likely, your computer is using COM 1.)

7. A summary screen appears stating how much free hard

disk space is required to run the software and how much is
available. If sufficient disk space is available, press C.
Otherwise, press X (exit) to free up some disk space; then
restart the installation program from step 1.

8. You see a prompt to create the installation directory you

specified in step 5. Press Y (yes).

Installing the Software from Windows 95

Perform the following steps to set up the ELP Link III for
Windows 3.1/95.

1. Insert the ELP Link III for Windows 3.1/95 Setup disk

into a diskette drive (A: or B: as appropriate).

2. Click Start.

Installing the Software

■ ■ ■ ■ ■

61

3. Click the Run menu option. The Run dialog box appears:

4. Type A:\SETUP (or B:\SETUP as appropriate), then press

Enter or click OK. The ELP Link III introduction
appears.

5. Press C to continue.

6. To accept the default location for where the software

should be installed, press C to continue. Otherwise, enter
a new directory name and then press C.

7. The Link III software communicates with the projector

using the computer’s serial communication (COM) port.
Specify which COM port to use, then press C to continue.
(Most likely, your computer is using COM 1.)

■ ■ ■ ■

8. A summary screen appears stating how much free hard

disk space is required to run the software and how much is
available. If sufficient disk space is available, press C.
Otherwise, press X (exit) to free up some disk space; then
restart the installation program from step 1.

9. You see a prompt to create the installation directory you

specified in step 6. Press Y (yes).

Using the ELP Link III Software

62

■

Installing the Software from Windows NT

Perform the following steps to set up the ELP Link III for
Windows NT.

1. Insert the ELP Link III for Windows NT setup disk into a

diskette drive (A: or B: as appropriate).

2. Refer the steps for Windows 3.1 and Windows 95 to

install.

3. The Link III software communicates with the projector

using the computer’s serial communication (COM) port.
Specify which COM port to use, then press C to continue.
(Most likely, your computer is using COM 1.)

Installing the Software from Macintosh OS
System (from ver. 7)

Perform the following steps to set up the ELP Link III for the
Macintosh.

1. Insert the ELP Link III for Macintosh Setup disk into the

diskette drive.

2. Copy the ELP III folder from the floppy disk to your local

hard disk with a drag-and-drop action. To be able to use
ELP Link III, restart the system.

• When you install the ELP Link III software, make a new
folder and designate the disk drive to be used.

• Please refer to your Mac Instruction manual.

Installing the Software

■ ■ ■ ■ ■

63

Launching the Software

1. Double-click the ELP Link III program icon from the
Windows 3.x ELP Link III program group or Mac OS
ELP Link III folder, or select ELP Link III from the
Windows 95 Programs menu. The ELP Link III program
icon appears minimized at the bottom of your screen.

2. For Windows NT, refer the Windows 3.1 or Windows 95.

3. Double-click the ELP Link III program icon. The ELP
Link III main dialog box appears.

Using the Software

The ELP Link III software can be used to:

• Customize the remote control Effects buttons

• Control standard and special projector features

Customizing the Remote Control Effects
Buttons

■ ■ ■ ■

You can assign functions to the remote control Effects
buttons so you can use them to perform special operations,
such as drawing shapes on the projected image or changing
the cursor shape.

♦

Using the ELP Link III Software

64

Note:

The ELP Link III software works only when the projector

is on and connected to the computer’s serial port.

■

Function Description and Usage

The function list on the left side of the ELP Link III main
dialog box shows the functions available for assignment to an
Effects button. To assign the functions, see page 66.

The table below describes these functions and how to use
them.

♦

Note:

To use the Effects buttons, the ELP Link III software must

be running and the computer connected to the projector.

Function Description and usage

Line Draws a straight line on the screen.

Press the Effects key assigned to this effect. Then
press the bottom multi-purpose button once to define
the line start position. Move the cursor using the
remote Pointer button. Then press the bottom multi­purpose button twice to define the line end position.

Ellipse Draws an ellipse (oval) on the screen.

Press the Effects key assigned to this effect. Then
press the bottom multi-purpose button once to define
the position of one end of the ellipse. Move the cursor
using the remote Pointer button. Then press the
bottom multi-purpose button twice to define the
position of the other end of the ellipse.

Square Draws a square on the screen.

Press the Effects key assigned to this effect. Then
press the bottom multi-purpose button once to define
the position of one corner of the square. Move the
cursor using the remote Pointer button. Then press the
bottom multi-purpose button twice to define the
position of the other corner of the square.

Bar Creates a horizontal or vertical bar. You can use this

function to highlight a portion of the screen with a
horizontal or vertical bar.
Press the Effects key assigned to this effect. Move the
bar using the remote pointer button. Press the bottom
multi- purpose button to lock the bar in place.

Function Description and Usage

■ ■ ■ ■ ■

65

Function Description and usage

Stamp Leaves one or several copies of the pre-selected

image on the screen.
Press the Effects key assigned to this effect. Use the
pointer button to place the cursor where you want the
stamp to appear. Then press the assigned Effects
button to display the stamp.

Cursor Change Changes the cursor shape.

Press the assigned Effects button to change the cursor
shape.

Screen Clear Clears all Effects functions previously executed.

Press the assigned Effects button to clear the screen.

Key Macro Types a pre-defined key sequence. This is useful

when you often need to type a sequence of characters
into your computer.
Press the assigned Effects button to automatically type
the key sequence.

Assigning Functions

■ ■ ■ ■

There are three ways to assign functions to each of the five
Effects buttons on the remote control:

Using the ELP Link III Software

66

■

• Drag and drop a function from the function list to the

Effects button you want to customize.

• Click a function in the function list, click the Effects button

number you want to customize, then click Customize.

• Select the function from the function list, and then press

the Effects button on the remote control.

Setting Effect Options

Once you have assigned functions to one or more Effects
buttons, you can specify detailed options for each function.

To set detailed options, click Detail Setting. A dialog box
similar to the following appears. (The options and tabs
displayed depend on which functions are currently assigned to
the Effects buttons.)

Click the tab for the function you want to adjust, then make
any settings you wish.

To test each setting, click the Test button and then click the
left mouse button to start and stop each setting. To end the
test, click the right mouse button. (If you are using the
remote control as a mouse pointer, use the bottom and top
multi-purpose buttons, respectively.)

Function Description and Usage

■ ■ ■ ■ ■

67

To save the changes, click OK.
The table on the following page describes the available

options for each function.

Function Options

Line Width Specify the line width, from 1 to 32 points.

Grid Specify whether to have the line “snap” to

the corners of a grid by entering the size
of the sides of the box, in pixels (dots).

Color Choose a color for the line. (8 colors:

Light Blue, Red, Green, Yellow, Black,
Navy blue, Magenta, White)

Transparent Click this check box to make the

background text or image visible through
the line.

Ellipse Width Specify the line width, from 1 to 32 points.

Color Choose a color for the line. (8 colors:

Light Blue, Red, Green, Yellow, Black,
Navy blue, Magenta, White)

Transparent Click this check box to make the

background text or image visible through
the ellipse.

■ ■ ■ ■

Square Width Specify the line width, from 1 to 32 points.

Using the ELP Link III Software

68

Fill Click this check box to fill the ellipse with

color.

Color Choose a color for the line. (8 colors:

Light Blue, Red, Green, Yellow, Black,
Navy blue, Magenta, White)

Transparent Click this check box to make the

background text or image visible through
the square.

Fill Click this check box to fill the ellipse with

color.

Make oval
shape

Click this check box to round the corners
of the square.

■

Function Options

Bar Width Specify the line width, from 1 to 300

points.

Color Choose a color for the bar. (8 colors: Light

Blue, Red, Green, Yellow, Black, Navy

blue, Magenta, White)
Direction Choose Horizontal or Vertical.
Transparent Click this check box to make the

background text or image visible through

the bar.

Stamp Click on the stamp to be used.
Cursor

Click on the cursor shape to be used.

Change
Screen Clear No options available.
Key Macro Enter up to 16 characters, including combinations such

as Ctrl + A in the Registration Keys Macro field. The
Backspace and Delete keys are also recorded.
Click on the Clear button to clear the current key
assignment.
Click on the Registration button to save more than one
set of key assignments.
Note: Although you can save multiple sets of key

assignments, only one set can be active at any
time.

Function Description and Usage

■ ■ ■ ■ ■

69

Saving and Recalling Effects Key Button
Assignments

To save Effects button assignments, click Execute.
To save multiple sets of button assignments, click Registration

and specify a name for the current settings.
To recall a saved set of assignments, select its name from the

Setting menu.
To delete a set of assignments from the Registration List,

select its name and then click Delete.
To exit without saving the settings, click Exit.

Changing the COM Port Assignment

If you did not select the correct COM (communication) port
when setting up the software, or if you have changed the
COM port to which the projector is connected, you can
change the COM port setting from the ELP Link III
software.

From the Option menu, select COM Port, then choose a new
COM port from the list provided.

■ ■ ■ ■

Using the ELP Link III Software

70

■

Controlling Projector Features

You can use the ELP Link III software to control the
following features:

• Projector Controls

• Test Pattern

• Color Properties.

Displaying the Projector Set Window

1. Double-click the ELP Link III program icon from the
Windows 3.x ELP Link III program group or Mac OS
ELP Link III folder, or select ELP Link III from the
Windows 95 Programs menu. The ELP Link III program
icon appears minimized on your screen.

2. Double-click the ELP Link III program icon. The main
dialog box appears.

Function Description and Usage

■ ■ ■ ■ ■

71

3. From the Options menu, select Projector Control. The
Projector Set window appears:

Using the Quick Change Toolbar

To quickly change some basic projector settings, click one of
the toolbar buttons described below:

Input Source Switch

Resize

Blank

Freeze

Brightness+

Brightness-

Contrast+

Contrast-

Volume+

Volume-

Mute

Power

■ ■ ■ ■

* Switches to Computer 1, Computer 2(5BNC) or Video source.

When the Computer 2/5BNC switch on the back of the projector is turned to
5BNC, the source is switched to 5BNC.

Using the ELP Link III Software

72

■

Changing Projector Settings

1. Click Projector Control on the Projector Set dialog box.
The following window appears:

2. Click on the tab for the settings you want to adjust.

3. Change one or more of the following options.

Computer Tab

Option Description

[Brightness] Adjusts the screen brightness.
[Contrast] Adjusts the screen contrast.
[Sync] Adjusts image flickering.
[Tracking] Adjusts any vertical lines in the displayed images.
[Auto Set Up] Automatically adjusts the graphic signal being sent

from a computer to optimize it for projector.

Changing Projector Settings

■ ■ ■ ■ ■

73

Option Description

[Position] Adjusts screen horizontal/vertical position.
[Color] Adjusts the color density for each color (Red, Green,

[Reset] Resets all settings to their default values.
[About]
Lamp: Displays the lamp life.
Computer/BNC: Displays the current switch state either Computer2 or

H/V Frequency: Displays H/V frequency of the current computer.
[Pattern Display] Displays the test pattern you select.
[Close] Exits the Projector Control screen.
[Help] Explains functions and terminology.

Video Tab

Option Description

[Brightness] Adjusts the screen brightness.

Blue).

BNC.

■ ■ ■ ■

[Contrast] Adjusts the screen contrast.
[Sharpness] Adjusts screen sharpness.
[Saturation] Adjusts the color density.
[Tint] Adjusts the color tint (NTSC only).
[Mode] Selects the video signal system.
[Reset] Resets all settings to their default values.
[About]
Lamp: Displays the lamp life.
Computer/ BNC:Displays the current switch state either Computer2 or

Using the ELP Link III Software

74

BNC.

■

Option Description

H/V Frequency: Displays H/V frequency of the current computer.
[Pattern Display] Displays the test pattern you select.
[Close] Exits the Projector Control screen.
[Help] Explains functions and terminology.

Sound Tab

Option Description

[Volume] Adjusts the volume.
[Treble] Adjusts treble tone.
[Bass] Adjusts bass tone.
[3D sound] Adjusts sound effects from 1 to 6 value. Increasing

[Reset] Resets all settings to their default values.
[About]
Lamp: Displays the lamp life.

number, the sound effects gets enhanced.

Computer/ BNC:Displays the current switch state either Computer2 or

BNC.
H/V Frequency: Displays H/V frequency of the current computer.
[Pattern Display] Displays the test pattern you select.
[Close] Exits the Projector Control screen.
[Help] Explains functions and terminology.

Changing Projector Settings

■ ■ ■ ■ ■

75

Option Tab

Option Description

[Blank To] Selects blank states for the screen.
Black: A black screen appears.
Blue: A blue screen appears.
User's Logo: A logo screen appears.
[Source Prompt] Temporarily displays a prompt on the projector screen

[Install] Selects the type of installing.
Rear proj: Select when you want to project the image from back

Ceiling Mount: Select when you want to hang the projector from the

[BNC format] Specifies input image signal mode.
[View Change] Selects the method how to switch the screen.
Off: Turns the settings off.

to identify which source(computer or video) is

providing the image.

of the screen. Flips the image right and left.

ceiling. Flips the horizontal axis of the image, so the

projector can be turned upside down.

■ ■ ■ ■

Diagonally: The projected image disappears from left top to right

Left to Right: The projected image moves to right direction, and the

Fade In: The projected image disappears from the edge of the

[Reset] Resets all settings to the default values.
[About]
Lamp: Displays the lamp life.
Computer/ BNC:Displays the current switch state either Computer2 or

Using the ELP Link III Software

76

bottom, and the switched image appears from the left

top to right bottom.

switched image appears from left.

screen, and the switched image appears from the

edge.

BNC.

■

Option Description

H/V Frequency: Displays H/V frequency of the current computer.
[Pattern Display] Displays the test pattern currently selected.
[Close] Closes the projector control screen.
[Help] Explains functions and the terminology.

Changing Projector Settings

■ ■ ■ ■ ■

77

Custom Tab

Option Description

[Customize
Function]

Zoom: Zooms(reduces/enlarges) images.
Preview: Displays all images being output by the external

Strobe: Displays images by the number of frames and the

Frame Counts: Sets the number of frames.
Frame Time: Sets the time interval.
[Reset] Resets all settings to their default values.
[About]
Lamp: Displays the lamp life.
Computer/ BNC:Displays the current switch state either Computer2 or

H/V Frequency: Displays H/V frequency of the current computer.
[Pattern Display] Selects the test pattern you want to display.
[Close] Exits the Projector Control screen.
[Help] Explains functions and terminology.

Assigns functions, such as Zoom, to the effect buttons

of the remote control.

sources which are connected to the projector.

amount of time you specified.

BNC.

■ ■ ■ ■

Using the ELP Link III Software

78

■

Changing the Test Pattern

1. Click Test Pattern on the Projector Set dialog box. The

following window appears:

2. You can display a test pattern when setting up the

projector to verify that the projector is working properly.
Choose one of the following:

Color Image Displays a color bar test pattern.
Gray Scale Displays a gray scale test pattern.
Focus Pattern Displays a character-based focus pattern.
User File(bmp) Displays a bitmapped test pattern from

the file name specified. Either type the
name or click Ref... (refer) to browse the
hard disk for the file. The bitmap should
be 1024 x 768 pixels (dots).

3. Click Pattern Display to display the test pattern selected.

Then click Close.

Changing Projector Settings

■ ■ ■ ■ ■

79

Setting the Image Color Property

1. Click Color Property on the Projector Set dialog box. The

Color Property window appears.

2. Specify a color temperature:

H High (more blue)
M Medium (normal white)
L Low (more red)
User Create a custom color temperature by

using the slide bars to specify the
amount of red and blue.

3. Specify an image gamma:

Gamma 1 Provides a dynamic and contrastive

image.

Gamma 2 Provides an image between Gamma 1

and Gamma 3.

Gamma 3 Provides a natural image.

4. Click Pattern Display to display the test pattern selected.

■ ■ ■ ■

Using the ELP Link III Software

80
