Epson EMP-730, EMP 720 User Manual

About The Manuals and Notations Used

Types of Manual

The documentation for your EPSON projector is divided into the following three manuals. The manuals cover the following topics.

Safety Instructions/World-Wide Warranty Terms

This manual contains information on using the projector safely, and also includes worldwide warranty terms and a troubleshooting check sheet.

Be sure to read this manual thoroughly before using the projector.

User's Guide (this manual)

This User’s Guide contains information on installing the projector, basic operation, using the configuration menus, troubleshooting and maintenance.

Quick Reference Guide

Contains an overview of the most commonly-used projector functions for easy reference. You should keep this Quick Reference Guide near the projector at all times and refer to it before starting presentations and while using the projector in order to check details of operation.

Notations Used in This User’s Guide

General Information

Caution :

Tip :

Procedure

Indicates procedures which may result in damage or injury if sufficient care is not taken.

Indicates additional information and points which may be useful to know regarding a topic.

Indicates that an explanation of the underlined word or words in front of this symbol appears in the glossary of terms. Refer to the "Glossary" in the "Appendices". (p.83)

Indicates operating methods and the order of operations. The procedure indicated should be carried out in the order of the numbers.

Meaning of "unit" and "projector"

When "unit" or "projector" appears in the text of this User’s Guide, it may refer to items which are accessories or optional equipment in addition to the main projector unit itself.

Unpacking the Projector

When you unpack the projector, make sure that you have all these components. If any of the components are missing or incorrect, please contact the place of purchase.

Power

p u e

g a P

ode w o

d e g

Color M a P

S-Video/Video

puter

Freeze

Com

A/V Mute

E-Zoom

Enter

ESC

Auto

Projector

(with lens cover)

Computer cable

(mini D-Sub 15-pin/mini DSub 15-pin 1.8 m (6 ft.)) For connecting the projector to a computer

Soft carrying case

(with shoulder strap and handle) For carrying the projector

Remote control

(including a CR2025 lithium battery)

RCA video cable

(1.8 m (6 ft.)) For connecting the projector to a video component

Powe r cable

(1.8 m (6 ft.)) For connecting the projector to a wall outlet

USB cable

(1.8 m (6 ft.)) For connecting the projector to a computer with a USB port so that the wireless mouse function can be used

Documentation

Safety Instructions/

World-Wide Warranty Terms User's Guide (this manual) Quick Reference Guide

Features of the Projector

Automatic keystone correction function

The vertical angle of the projector is detected, so that any vertical keystone distortion in the projected images can be automatically corrected. (p.34)

Automatic setup function

When projecting computer images, the signals from the connected computer are detected automatically and adjusted so that the optimum images are projected. Even if several people are giving presentations using the same projector, the optimum picture quality can be obtained simply by disconnecting and reconnecting the computers. Each individual setting can also be adjusted manually. (p.37)

Color mode function

The optimum images can be projected simply by selecting the image quality from the following six preset settings according to the projection environment being used. No other troublesome colour adjustments are necessary. (p.40, 47, 49)

• sRGB • Normal • Meeting

• Presentation • Theatre • Game

Compact and lightweight

The projector has a compact body with a footprint the size of a B5 page (19 (D) x 27.6 (W) x 7 (H) cm (7.5 (D) x 10.9 (w) x 2.8 (H))) and is light in weight (approximately 1.9 kg. (4.2 lbs)), making it easy to carry.

Brilliant, attractive images

Despite its compact size, the projector can display images at high resolutions with a high degree of luminance, providing beautifully clear images even in bright environments.

Easy to Operate

The accessory remote control can be used for operations such as pausing projection (see "Freeze" on p.43) and zooming in on important areas of an image (see "E-Zoom" on p.45). In addition, the remote control can be used to move the pointer around on the computer screen during projection (see "Wireless Mouse Function" on p.21). If using the wireless mouse function, you can use the remote control to scroll back and forth through pages when projecting a PowerPoint presentation.

projector

Jan

Feb

JunM

Jul

Unpacking the Projector.................................................................... 1

Features of the Projector................................................................... 2

Before Using the Projector

Part Names and Functions ............................................................... 8

Front/Top................................................................................................ 8

Control Panel..........................................................................................9

Rear ......................................................................................................10

Base......................................................................................................10

Remote Control.................................................................................... 11

Before Using the Remote Control ................................................... 12

Using the Remote Control and Remote Operating Range ...................12

Installation ....................................................................................... 14

Setting Up the Projector.......................................................................14

Screen Size and Projection Distance....................................................15

Connecting to a Computer .............................................................. 16

Eligible Computers ..............................................................................16

Projecting Images from the Computer.................................................17

Playing Sound from the Computer ...................................................... 20

Using the Remote Control to Operate the Mouse Pointer

(Wireless Mouse Function) ................................................................ 21

Connecting to a Video Source ........................................................ 23

Projecting Composite Video Images....................................................23

Projecting S-Video Images...................................................................24

Projecting Component Video Images .................................................. 24

Projecting RGB Video Images.............................................................25

Playing Sound from the Video Equipment ..........................................26

Basic Operations

Turning On the Projector ................................................................. 28

Connecting the Power Cable................................................................28

Turning On the Power and Projecting Images .....................................29

Turning Off the Projector ................................................................. 31

Adjusting the Screen Image............................................................ 33

Adjusting the Image Size ..................................................................... 33

Adjusting the Image Angle and

Automatic Keystone Correction Function.......................................... 34

Manually Correcting Keystone Distortion ...........................................36

Adjusting the Image Quality ............................................................ 37

Focusing the Screen Image.................................................................. 37

Adjusting Computer Images ................................................................ 37

Selecting the Colour Mode .................................................................. 40

Advanced Operations

Functions for Enhancing Projection ................................................ 42

A/V Mute ............................................................................................. 42

Freeze...................................................................................................43

Wide-screen Projection of Component Video and Video Images

(Changing the Aspect Ratio) ............................................................. 44

E-Zoom ................................................................................................ 45

Using the Configuration Menu Functions ........................................ 46

List of Functions .................................................................................. 46

Using the Configuration Menus...........................................................56

Troubleshooting

Using the Help ................................................................................ 60

When Having Some Trouble............................................................ 61

Power Indicator....................................................................................61

(Warning) Indicator...................................................................... 62

When the Indicators Provide No Help ............................................. 64

Appendices

Maintenance ................................................................................... 72

Cleaning............................................................................................... 72

Replacing Consumables....................................................................... 74

Saving a User's Logo ...................................................................... 80

Optional Accessories ...................................................................... 82

Glossary.......................................................................................... 83

List of ESC/VP21 Commands ......................................................... 86

Command List...................................................................................... 86

USB Connection Setup ........................................................................ 87

List of Supported Monitor Displays ................................................. 88

Specifications .................................................................................. 89

Appearance..................................................................................... 91

Index ............................................................................................... 92

the Projector

Before Using

Basic Operations

Advanced Operations

Troubleshooting

Appendices

Before Using the Projector

This chapter describes the procedures for setting up the projector before use.

Part Names and Functions .................................................8

• Front/Top ................................................................................................ 8

• Control Panel.......................................................................................... 9

• Rear....................................................................................................... 10

• Base ....................................................................................................... 10

• Remote Control.................................................................................... 11

Before Using the Remote Control ....................................12

• Using the Remote Control and Remote Operating Range............... 12

Installation .........................................................................14

• Setting Up the Projector...................................................................... 14

• Screen Size and Projection Distance .................................................. 15

Connecting to a Computer ...............................................16

• Eligible Computers.............................................................................. 16

• Projecting Images from the Computer.............................................. 17

• If the Monitor Port is a Mini D-Sub 15-pin Port .............................................. 17

• If the Monitor Port is a 5BNC Port...................................................................18

• If the Monitor Port is a 13w3 Port ....................................................................19

• Playing Sound from the Computer .................................................... 20

• Using the Remote Control to Operate the Mouse Pointer

(Wireless Mouse Function)................................................................. 21

Connecting to a Video Source .........................................23

• Projecting Composite Video Images .................................................. 23

• Projecting S-Video Images.................................................................. 24

• Projecting Component Video Images................................................. 24

• Projecting RGB Video Images............................................................ 25

• Playing Sound from the Video Equipment........................................ 26

Part Names and Functions

Front/Top

••••

Zoom ring (p.33)

Adjusts the image size.

•••• Focus ring (p.37)

Adjusts the image focus.

•••• Air exhaust vent

••••

(Warning) indicator (p.62)

Flashes or lights in different colours to indicate problems with the projector or that the projection lamp needs to be replaced.

••••

Power indicator (p.61)

Flashes or lights in different colours to indicate the operating status of the projector.

••••

Control panel (p.9)

••••

Security lock ( ) (p.84)

••••

Front adjustable foot (p.34)

Extend and retract to adjust the projection angle.

••••

Lens cover

Attach when not using the projector to prevent the lens from becoming dirty or damaged.

••••

Remote control lightreceiving area (p.12)

Receives signals from the remote control.

••••

Front adjustable foot (p.34)

Extend and retract to adjust the projection angle.

••••

Air filter (air intake vent) (p.73, 79)

Prevents dust and other foreign particles from being drawn into the projector. When replacing the lamp, replace the air filter also.

••••

Foot adjust button (p.35)

Another foot adjust button is located on the right side. Press both foot adjust buttons when extending and retracting the front adjustable feet.

Control Panel

•••• [Power] button (p.29, 31)

Turns the projector power on and off.

••••

[Source] button (p.30)

Switches the input source between the Computer/Component Video port, SVideo port and Video port each time the button is pressed. When pressed while a help menu is being displayed, it accepts the menu item that is currently selected. (p.60)

•••• [Help] button (p.60)

Displays the online help menu to assist you if you have a problem.

••••

[Keystone] button (p.36)

Press to manually correct keystone distortion in images. When pressed while a help menu is being displayed, it selects items in the menu. (p.60)

Part Names and Functions

Rear

••••

Video port (p.23)

Inputs composite video the projector from other video sources. Use the RCA video cable for this connection.

•••• S-Video port (p.24)

Inputs S-Video projector from other video sources.

••••

Power inlet (p.28)

Connects the power cable.

signals to

signals to the

•••• Audio-In port (p.20, 26)

Inputs audio signals. Connect using a stereo mini jack.

••••

Remote control lightreceiving area (p.12)

Receives signals from the remote control.

•••• Speaker

•••• Computer/Component Video

port (p.17, 24, 25)

Inputs analogue video signals from

a computer and component video

signals from other video sources.

Base

••••

Lamp cover (p.76)

Open this cover when replacing the lamp inside the projector.

•••• Remote control holder

(p.12)

Store the accessory remote control in here when not using it.

••••

Suspension bracket fixing points (3 points) (p.14, 82)

Install the optional ceiling mount here when suspending the projector from the ceiling.

•••• USB port (p.21)

Connects the projector to a computer via the USB cable.

Remote Control

•••• [Page down]/[Page up]

buttons (p.21)

When using the remote control as a wireless mouse, press these buttons to scroll back and forth through p ages when projecting a PowerPoint presentation.

•••• Input select buttons

(p.30)

[Computer]: Switches the signal source to the images being input from the Computer/Component Video port. [S-Video/Video]: Switches the signal source being input from the S-Video port and the Video port.

•••• [Menu] button (p.56)

Displays or hides the configuration menus.

•••• [E-Zoom] button ( )

(p.45)

Reduces the part of images that have been enlarged using the [ ] button.

••••

[ ][ ][ ][ ] buttons (p.22, 56, 60)

When using the remote control as a wireless mouse, these buttons move the pointer in the direction corresponding to the button that was pressed. When a configuration menu or help menu is displayed, these buttons select menu items and setting values.

••••

[Auto] button (p.37)

Use this button to automatically adjust computer images to the optimum images when automatic setup has been set to "OFF".

•••• Remote control light-

emitting area (p.13)

Outputs remote control signals.

Page upPage down

Power

Computer

S-Video/Video

Color Mode

A/V Mute

Freeze

E-Zoom

Enter

ESCAuto

••••

[ESC] button (p.22, 57)

Stops the current function. Displays the previous screen or menu while viewing a configuration menu. Acts as a mouse right-click when using the remote control as a wireless mouse.

••••

[Power] button (p.29, 31)

Turns the projector power on and off.

••••

[Color Mode] button (p.40)

Selects the colour mode. The colour mode changes in the order of Normal, Meeting, Presentation, Theatre, Game and

each time the

sRGB button is pressed.

••••

[A/V Mute] button (p.42)

Momentarily turns off the audio and video.

•••• [Freeze] button (p.43)

Keeps the current computer or video image on the screen.

••••

[E-Zoom] button ( ) (p.45)

Enlarges the p art of images without changing the size of the projection area.

••••

[Enter] button (p.22, 56, 60)

Accepts a menu item or displays the next screen or menu while viewing a configuration menu or help menu. Acts as a mouse left-click when using the remote control as a wireless mouse.

Before Using the Remote Control

Using the Remote Control and Remote Operating Range

When using the remote control for the first time, pull out the insulating tape that is protruding from the battery holder. When the insulating tape is pulled out, the remote control can then be used.

Using the Remote Control

The remote control is used in the following way.

Procedure

Point the remote control light-emitting area toward one of the remote control light-receiving areas on the projector and operate the remote control buttons.

Remote control light-receiving area (front)

Remote control light-emitting area

Page upPage down

Power

Computer

Color Mode

S-Video/Video

Freeze

A/V Mute

E-Zoom

Enter

ESCAuto

Page upPage down

Power

Computer

Color Mode

S-Video/Video

Freeze

A/V Mute

E-Zoom

Enter

ESCAuto

Remote control light-receiving area (back)

Tip :

• Do not allow sunlight or light from fluorescent lamps to shine directly onto the projector's remote control light-receiving areas, otherwise it may interfere with the reception of signals from the remote control.

• If delays in the responsiveness of the remote control occur or if it does not operate after it has been used for some time, it probably means that the battery is getting flat. If this happens, replace the battery with a new one. (p.74)

• When not using the remote control, place it into the remote control holder at the back of the projector so that it does not get lost.

Remote Operating Range

Use the remote control within the ranges indicated below. If the distance or angle between the remote control and the remote control light-receiving area is outside the normal operating range, the remote control may not work.

Operating distance Operating angle

Approx. 6 m (20 ft.)

Approx. 30º horizontally

Approx. 15º vertically

Approx. 30º horizontally

Approx. 30º

Approx. 15º vertically

Approx. 15º

When suspended from the ceiling

Remote control light-receiving area

Approx. 30º

Page upPage down

Power

Color Mode

S-Video/VideoComputer

Freeze

A/V Mute

E-Zoom

Enter

ESCAuto

Approx. 30º

Remote control light-emitting area

Approx. 30º

Page upPage down

Power

Computer

Color Mode

S-Video/Video

Freeze

A/V Mute

E-Zoom

Enter

ESCAuto

Approx. 15º

Within approx. 6 m (20ft.)

Approx. 15º

Installation

Setting Up the Projector

The projector supports the following four different projection methods, allowing you to choose the best method for displaying your images.

Caution :

Before setting up the projector, be sure to first read the separate Safety Instructions/ World-Wide Warranty Terms.

• Front projection • Rear projection using a translucent

screen

• Front/ceiling projection • Rear/ceiling projection using a

translucent screen

* A special method of installation is required in order to suspend the projector from

the ceiling. Please contact the place of purchase if you would like to use this installation method. The optional ceiling mount is required when installing the projector to the ceiling. (p.82)

Tip :

When using rear/ceiling projection using a translucent screen, set the "Ceiling" or "Rear Proj." command in the "Advanced" menu to match the installation method. (p.53)

Screen Size and Projection Distance

The distance between the projector and the screen determines the actual image size.

Recommended distance

While referring to the table below, position the projector so that the images are projected onto the screen at the optimum size. The values should be used as a guide for setting up the projector. The actual

values will vary depending on projection conditions and the zoom setting.

4:3 Screen size

(cm (in.))

30" (61 × 46 (24.0 × 18.1)) 1.0−1.1 (3.2–3.7) 4.6 (1.8)

40" (81 × 61 (31.9 × 24.0)) 1.3−1.5 (4.3–5.0) 6.1 (2.4)

60" (120 × 90 (47.2 × 35.4) 2.0−2.3 (6.5–7.5) 9.1 (3.6)

80" (160 × 120 (63.0 × 47.2)) 2.7−3.1 (8.7–10.1) 12.2 (4.8)

100" (200 × 150 (78.7 × 59.1)) 3.3−3.9 (11.0–12.7) 15.2 (6.0)

200" (410 × 300 (161.4 × 118.1)) 6.7−7.8 (22.1–25.6) 30.5 (12.0)

300" (610 × 460 (240.2 × 181.1)) 10.1−11.7 (33.2–38.5) 45.7 (18.0)

Projection distance

1.0–11.7 m (3.2–38.5 ft.)

(m (ft.))

of screen (cm (in.))

Distance from center

of lens to bottom edge

Screen

90º

Centre of lens

* When installing against a wall, leave a space of about 20 cm (7.9 in.) between the

projector and the wall.

Tip :

• The projector's lens allows a zoom ratio of up to about 1.16. The image size at the maximum zoom setting is about 1.16 times bigger than the image size at the minimum zoom setting.

• The image size will be reduced when keystone correction is carried out.

Connecting to a Computer

Caution :

When connecting the projector to a computer, be sure to check the following.

• Turn off the power for both the projector and the computer before connecting them. If the power for either device is on at the time of connection, damage may result.

• Check the shapes of the cable connectors and the device ports before making the connections. If you try to force a connector to fit a device port with a different shape or number of terminals, damage to the connector or port may result.

Eligible Computers

The projector cannot be connected to some types of computer, or projection of images may not be possible even if actual connection is possible. Make sure that the computer you intend to use satisfies the conditions given below.

• Condition 1: The computer must have an image signal output port.

Check that the computer has a port such as an "RGB port", "monitor port" or "CRT port" which can output image signals. If the computer has a built-in monitor, or if using a laptop computer, it may not be possible to connect the computer to the projector, or alternatively you may need to purchase a separate external output port. Refer to the documentation for your computer under a heading such as "Connecting an external monitor" or similar for further details.

• Condition 2: The display resolution and frequency of the computer must be

listed in the "List of Supported Monitor Displays". See "Appendices: List of Supported Monitor Displays"(p.88).

Some computers allow you to change the output resolution, so if necessary, change the resolution to one that matches a setting in the "List of Supported Monitor Displays", while referring to the documentation provided with the computer.

Tip :

• You may need to purchase a separate adapter depending on the shape of the computer's port. Refer to the documentation provided with the computer for further details.

• If the computer and projector are too far away from each other for the accessory computer cable to reach, use the optional VGA-HD15 PC cable. See "Appendices: Optional Accessories" (p.82)

Projecting Images from the Computer

The shape and specifications of the computer's monitor port will determine what type of cable should be used. Check the following to see which type of port your computer has.

If the Monitor Port is a Mini D-Sub 15-pin Port

Use the accessory computer cable to connect the Computer/Component Video port at the rear of the projector to the monitor port of the computer.

To monitor port

Computer cable

(accessory)

To Computer/ Component Video port

Tip :

• Change the "Input Signal" setting in the "Video" menu to "RGB" after making the connections. (p.47)

• If more than one external component is connected to the projector, use the [Source] button on the projector's control panel or the [Computer] button on the remote control to select the Computer port as the input source. (p.30)

• Do not bind the power cable and the computer cable together, otherwise image interference or errors in operation may result.

Connecting to a Computer

If the Monitor Port is a 5BNC Por t

Use the optional VGA-HD15 PC cable to connect the Computer/Component Video port at the rear of the projector to the monitor port of the computer. See "Appendices: Optional Accessories" (p.82)

To monitor port

To Computer/

VGA-HD15 PC cable

(optional)

Component Video port

Tip :

• Change the "Input Signal" setting in the "Video" menu to "RGB" after making the connections. (p.47)

• Do not bind the power cable and the computer cable together, otherwise image interference or errors in operation may result.

If the Monitor Port is a 13w3 Port

Some workstation-type computers have a 13w3 monitor port. Use a commercially-available 13w3 ⇔ D-Sub 15-pin cable to connect the Computer/Component Video port at the rear of the projector to the monitor port of the computer.

To monitor port

To Computer/

13w3 cable

(commercially-available)

Component Video port

Tip :

• Change the "Input Signal" setting in the "Video" menu to "RGB" after making the connections. (p.47)

• Do not bind the power cable and the computer cable together, otherwise image interference or errors in operation may result.

• Some workstations may require a special cable. Consult the workstation manufacturer for further details.

Connecting to a Computer

Playing Sound from the Computer

The projector has a single built-in speaker with a maximum output of 1 W. If the computer that is connected to the projector has an audio output port, you can output sound from the computer through the projector's speaker by connecting the computer's audio output port and the Audio-In port (stereo mini jack) on the rear of the projector using a stereo mini jack audio cable (commercially-available). It is recommended that you use an audio cable with a

3.5 mm diameter stereo mini jack.

To audio output port

Stereo mini jack audio cable

To Audio-In port

(commercially-available)

Use the following procedure to adjust the volume of the sound output.

Procedure

Press the [Menu] button on the

remote control, and then select "Volume" from the "Audio" menu.

Video

Audio

Setting User's Logo Advanced About Reset All

For details on this operation, refer to "Using the Configuration Menus". (p.56)

: Select: Return : Adjust

Use the [ ] and [ ] buttons to

adjust the volume.

The volume is increased or reduced each time a button is pressed.

After making the adjustment, press the [Menu] button to exit

the configuration menu.

Video

Audio

Setting User's Logo Advanced About Reset All

: Select: Return : Adjust

Volume

Tone:: Reset

Volume

Tone:: Reset

Execute

Using the Remote Control to Operate the Mouse Pointer (Wireless Mouse Function)

You can use the remote control as a wireless mouse to control the mouse pointer on the computer screen. To do this, you must use the accessory USB connect the USB port of the computer to the USB port at the rear of the projector.

Computer Mouse used Applicable cable

Windows 98/2000/Me/ XP Home Edition/ XP Professional

Macintosh (OS 8.6 - 9.2/X/10.1)

USB mouse USB cable (accessory)

cable to

To USB port

USB cable

(accessory)

To USB port

* When using the remote control as a wireless mouse, the [Page down] and [Page

up] buttons on the remote control can be used to scroll back and forth through pages when projecting a PowerPoint presentation.

Tip :

• The USB cable can only be connected to computers with a standard USB interface. If using a computer which is running Windows, the computer must have had a full version of Windows 98/2000/Me/XP Home Edition/XP Professional installed. If the computer is running a version of Windows 98/2000/Me/XP Home Edition/XP Professional that has been upgraded from an earlier version of Windows, correct operation cannot be guaranteed.

• It may not be possible to use the mouse function under some versions of both the Windows and Macintosh operating systems.

• Some computer settings may have to be changed in order for the mouse function to be used. Consult the documentation for the computer for further details.

Connecting to a Computer

Once the connection has been made, the mouse pointer can be operated as follows.

Moving the mouse pointer

Press the [ ], [ ], [ ] or [ ] button to move the mouse pointer in the direction of the button pressed.

Page upPage down

Power

Computer

Color Mode

S-Video/Video

Freeze

A/V Mute

E-Zoom

Left click

Press the [Enter] button. If you press the [Enter] button twice in rapid succession, it has the effect of a double-click.

Page upPage down

Power

Computer

Color Mode

S-Video/Video

Freeze

A/V Mute

E-Zoom

Enter

ESCAuto

Right click

Press the [ESC] button.

Drag and drop

While holding down the [Enter] button,

Enter

ESCAuto

press the [ ], [ ], [ ] or [ ] button to drag items. Release the [Enter] button to drop the items being dragged at the desired position.

Computer

Page upPage down

S-Video/Video

A/V Mute

E-Zoom

Enter

Power

Color Mode

Freeze

ESCAuto

Computer

Page upPage down

S-Video/Video

A/V Mute

E-Zoom

Enter

Power

Color Mode

Freeze

ESCAuto

Tip :

• If the mouse button settings have been reversed at the computer, the operation of the remote control buttons will also be reversed.

• The wireless mouse function cannot be used while a configuration menu or help menu is being displayed or while the E-Zoom function is being used.

Connecting to a Video Source

Caution :

When connecting the projector to other video sources, take the following precautions.

• Turn off the power for both the projector and the video source before connecting them. If the power for either device is on at the time of connection, damage may result.

Projecting Composite Video Images

Use the accessory RCA video cable to connect the video source to the Video port at the rear of the projector.

To video output port (yellow)

To Video port

RCA video cable

(accessory)

Tip :

If more than one external component is connected to the projector, use the [Source] button on the projector's control panel or the [S-Video/Video] button on the remote control to select the Video port as the input source. (p.30)

Connecting to a Video Source

Projecting S-Video Images

Use a S-Video cable (commercially-available) to connect the video source to the S-Video port at the rear of the projector.

To video output port

S-Video cable

(commercially-available)

Tip :

Projecting Component Video Images

Use the optional component video cable to connect the video source to the Computer/Component Video port at the rear of the projector. See "Appendices: Optional Accessories" (p.82)

To video output port

Component video cable

(optional)

Tip :

• Change the "Input Signal" setting in the "Video" menu to "YCbCr " or "YPbPr " after making the connections. (p.49)

• If more than one external component is connected to the projector, use the [Source] button on the projector's control panel or the [Computer] button on the remote control to set the input source to "YCbCr " or "YPbPr ", depending on the type of signal being input. (p.30)

To S-Video port

To Computer/ Component Video port

Projecting RGB Video Images

RGB video is used when RGB signals that have copy protection added are input and projected. Use the accessory computer cable to connect the video source to the Computer/Component Video port on the rear of the projector.

To RGB output port

Computer cable

(accessory)

To Computer/ Component Video port

Tip :

• Change the "Input Signal" setting in the "Video" menu to "RGB" after making the connections. (p.47)

• For a RGB connection, a commercially available adapter or converter cable might be required.

Connecting to a Video Source

Playing Sound from the Video Equipment

The projector has a single built-in speaker with a maximum output of 1 W. You can output sound from the video equipment through the projector's speaker by connecting the video equipment's audio output port and the Audio-In port (stereo mini jack) at the rear of the projector using a stereo mini jack audio cable (commercially-available). It is recommended that you use an audio cable with a 3.5 mm diameter stereo mini jack.

To audio output port

Stereo mini jack audio cable

To Audio-In port

(commercially-available)

Use the following procedure to adjust the volume of the sound output.

Procedure

Press the [Menu] button on the

remote control, and then select "Volume" from the "Audio" menu.

Video

Audio

Setting User's Logo Advanced About Reset All

For details on this operation, refer to "Using the Configuration Menus". (p.56)

: Select: Return : Adjust

Use the [ ] and [ ] buttons to

adjust the volume.

The volume is increased or reduced each time a button is pressed.

After making the adjustment, press the [Menu] button to exit

the configuration menu.

Video

Audio

Setting User's Logo Advanced About Reset All

: Select: Return : Adjust

Volume

Tone:: Reset

Volume

Tone:: Reset

Execute

Basic Operations

This chapter describes basic operations such as turning projection on and off and adjusting the projected images.

Turning On the Projector ..................................................28

• Connecting the Power Cable............................................................... 28

• Turning On the Power and Projecting Images.................................. 29

Turning Off the Projector ..................................................31

Adjusting the Screen Image .............................................33

• Adjusting the Image Size..................................................................... 33

• Adjusting the Image Angle and

Automatic Keystone Correction Function....................................... 34

• Manually Correcting Keystone Distortion ........................................ 36

Adjusting the Image Quality .............................................37

• Focusing the Screen Image.................................................................. 37

• Adjusting Computer Images............................................................... 37

• Automatic Setup................................................................................................ 37

• Adjusting the Tracking...................................................................................... 38

• Adjusting the Sync............................................................................................ 39

• Selecting the Colour Mode.................................................................. 40

Turning On the Projector

Turn on the power to start projecting images.

Caution :

Be sure to read the separate Safety Instructions/World-Wide Warranty Terms before projecting images.

Connecting the Power Cable

Procedure

Check that the power is turned off for the projector and all

components connected to the projector.

Connect the computer or other video source to the projector.

(p.17, 23)

Remove the lens cover.

Place your finger under the top of the lens cover and pull to remove the cover.

Connect the accessory power cable

to the projector.

Check that the power cable connector is facing the same way as the power inlet on the projector, and then insert the power cable connector securely into the projector.

Connect the other end of the power

cable to an earthed electrical outlet.

Wait until the Power indicator lights orange.

Tip :

The projector's control panel and remote control buttons cannot be operated while the Power indicator is flashing orange.

Lit orange

Turning On the Power and Projecting Images

Procedure

Check that the Power indicator has

stopped flashing and is lit orange.

Turn on the power for all equipment connected to the projector.

Lit orangeLit orange

For a video source, press the [Play] button at the video source to start playback if necessary.

Press the [Power] button on either

the projector's control panel or the remote control to turn on the power for the projector.

The Power indicator flashes green. After a short period it stops flashing and lights steadily, and projection starts. Wait until the Power indicator lights green

Changes from flashing to lit green

Page upPage down

Power

Computer

Color Mode

S-Video/Video

A/V Mute

E-Zoom

Enter

Freeze

ESCAuto

(it normally takes about 40 seconds to change).

Remote control

Tip :

The projector's control panel and remote control buttons cannot be operated while the Power indicator is flashing green. Depending on the settings, the message "No-Signal." may appear. See "Setting" - "NoSignal Msg." (p.51)

Turning On the Projector

If more than one signal source has

been connected, use the projector's control panel or the remote control buttons to select the port which the signal source that you would like to use is connected to, while referring to the following table.

Por t

Computer/ Component Video

S-Video

Vid eo Vid eo

The image source changes each time [Source] is pressed.

Button to press

Projector Remote control

[Computer]

[S-Video/Video]

Projector Remote control

Page upPage down

Power

Computer

Color Mode

S-Video/Video

Freeze

A/V Mute

E-Zoom

Enter

Display at top-right of

screen

Computer * YCbCr YPbPr

S-Video

* The items selected using the "Input Signal" command in the "Video" menu

will appear.

Tip :

• If only one signal source has been connected, the signals from that source will be projected without needing to press one of the buttons from the previous table.

• If the "No-Signal." message does not disappear, check the connections again.

• If a laptop computer or a computer with an LCD screen has been connected to the projector, the images may not be projected straight away. After making the connections, check that the computer has been set up to output signals externally. The following table shows examples of how to toggle output settings. For details, refer to the section of the documentation provided with your computer under a heading such as "External output", "Connecting an external monitor" or similar.

NEC Panasonic Toshiba IBM Sony Fujitsu Macintosh

[Fn]+[F3] [Fn]+[F3] [Fn]+[F5] [Fn]+[F7] [Fn]+[F7] [Fn]+[F10]

After startup, change

the Control Panel

adjustments so that

Mirroring is active

• If the same still picture is projected for a long period of time, the projected image may become burned in on the computer screen. You should avoid leaving the same image displayed for long periods.

Turning Off the Projector

Follow the procedure below to turn off the power of the projector.

Procedure

Turn off the power for the signal sources that are connected to

the projector.

Check that the power for all connected components has been turned off.

Press the [Power] button on either

the projector's control panel or the

Projector

Remote control

remote control.

The following confirmation message will appear.

Power OFF?

Please press key again to power off .

If you do not want to turn off the power, press any button except the [Power] button. If you do not press any button, the message will disappear automatically after seven seconds. (The power will not turn off at this time.)

Press the [Power] button once

more.

Stops flashing and lights orange

The lamp will switch off. The Power indicator will flash orange and cooldown will start. The cool-down period lasts for about 45 seconds. (This varies depending on factors such as the ambient air temperature.)

Tip :

The projector's control panel and remote control buttons cannot be operated while the Power indicator is flashing orange. Wait until it lights steadily.

Computer

Page upPage down

S-Video/Video

A/V Mute

E-Zoom

Power

Color Mode

Freeze

Check that the cool-down is complete.

When cool-down is complete, the Power indicator lights orange.

Turning Off the Projector

Unplug the power cable from the electrical outlet.

Caution :

Do not disconnect the power cable from the outlet while the Power indicator is still flashing orange, otherwise it may result in errors in projector operation and reduce the lamp unit operating life.

Retract the front adjustable feet if

they are extended.

Gently push down on the projector while simultaneously pressing the two foot adjust buttons.

Foot adjust buttons

Attach the lens cover.

Attach the lens cover to the lens when not using the projector, in order to stop the lens from getting dusty or dirty.

Lens cover

Adjusting the Screen Image

You can correct and adjust the screen image in order to obtain the best possible picture.

Adjusting the Image Size

The size of the projected image is basically determined by the distance from the projector to the screen. (p.15) The following procedures explain how to adjust the screen image once the projector itself has been set up.

Tip :

The E-Zoom function lets you enlarge parts of the image. (p.45)

Procedure

Turn the zoom ring on the projector to adjust the image.

The image can be enlarged in this way to 1.16 times the normal size.

If you would like to enlarge the image further, move the projector further away from the screen. (p.15)

Turn to "T" to reduce the size

Turn to "W" to increase the size

Zoom ring

Adjusting the Screen Image

Adjusting the Image Angle and Automatic Keystone Correction Function

The projector should be set up so that it is as perpendicular to the screen as possible.

Seen from the side Seen from above

Centre of

lens

If it is not possible to set up the projector so that it is perpendicular to the screen, it can be set up at a slight vertical angle instead. You can extend or retract the front adjustable feet to adjust the projection angle within a maximum range of 11º.

When the projector is tilted, it will cause keystone distortion to appear in the image. The projector is equipped with automatic keystone correction function that can automatically correct this keystone distortion as long as the vertical angle of tilt is within a range of approximately 15º*. Automatic keystone correction is carried out approximately one minute after the projector's power has been turned on and the projector has been positioned.

Approx. 15º above Approx. 15º below

15º

* This value applies when the zoom ring is turned to the maximum "T" setting.

If the zoom ring is turned to the "W" setting, the available angle of tilt for automatic adjustment will become smaller.

Tip :

• Automatic keystone correction is not carried out when the "Rear" or "Ceiling" commands in the "Advanced" menu are set to "ON".

• If you would like to make further adjustments after automatic keystone correction has been carried out, you can use the [keystone] button on the projector's control panel. (p.36)

Procedure

While pressing the two foot adjust buttons at either side, lift up the front of the projector so that the front adjustable feet can extend.

Extend the front adjustable feet until the desired angle is obtained, and then release the foot adjust buttons. To retract the front adjustable feet, gently push down on the projector while pressing the two foot adjust buttons.

Tip :

• If the projector is tilted horizontally, turn the bases of the front adjustable feet to adjust the angle.

Foot adjust buttons (side)

Front adjustable foot

Extend Retract

• When keystone correction is carried out, the projected image will become smaller.

• If the images become uneven in appearance after keystone correction is carried out, decrease the sharpness setting. (p.47, 48)

• If automatic keystone correction is not required, set "Auto Keystone" in the "Setting" menu to "OFF". (p.51)

Adjusting the Screen Image

Manually Correcting Keystone Distortion

The projector is provided with an automatic keystone correction function which detects the vertical angle of the projector and carries out keystone correction automatically. If further correction adjustment is required after automatic keystone correction has been carried out, use the [Keystone] buttons on the projector's control panel to make the adjustment.

Procedure

If the bottom of the image is elongated

Projector Projector

If the top of the

image is elongated

Tip :

• When keystone correction is carried out, the projected image will become smaller.

• If the images become uneven in appearance after keystone correction is carried out, decrease the sharpness setting. (p.47, 48)

• Keystone correction can also be carried out using the configuration menu. (p.50, 51)

• If the value displayed in the gauge on the screen stops changing when keystone correction is being carried out, it indicates that the limit for keystone correction has been exceeded. Check that the projector has not been set up at an angle which exceeds the proper limit.

Adjusting the Image Quality

The quality of the screen images can be adjusted as follows.

Focusing the Screen Image

Procedure

Turn the focus ring to adjust the image focus.

Turn the focus ring of the projector until the projected images are in proper focus.

Focus ring

Tip :

• If the surface of the lens is dirty or misted over as a result of condensation, it may not be possible to adjust the focus correctly. If this happens, clean or de-mist the lens. (p.66, 72)

• If the projector is positioned outside the normal projecting range of 1.0–11.7 m (3.2–

38.5 ft.), it may not be possible to obtain the correct focus. If you have trouble obtaining the correct focus, check the projection distance.

Adjusting Computer Images

Automatic Setup

Automatic setup detects the status of the signals coming from the connected computer, and automatically adjusts these signals so that the optimum images can be obtained. It involves adjustment of the following three items: Tracking

Tip :

• If "Auto Setup" in the "Video" menu is set to "OFF" (the default setting for this item is "ON"), automatic setup is not carried out. If you press the [Auto] button on the remote control while computer signals are being projected, adjustment will then be carried out.

, Position and Sync .

Remote control

Enter

ESCAuto

Adjusting the Image Quality

• If you press the [Auto] button while the E-Zoom or Freeze function is being used or while a configuration menu or help menu is being displayed, the function will be cancelled when you press the [Auto] button, and then the adjustment will be carried out.

• Sometimes the signals may not be adjusted correctly depending on the type of signals being output by the computer. In such cases, use the configuration menu commands to adjust the tracking and sync settings manually. (p.38, 39)

Adjusting the Tracking

If vertical stripes appear in the projected images, and this cannot be fixed using automatic setup, you will need to adjust the tracking

manually using the following

procedure.

Procedure

Press the [Menu] button on the

remote control, and then select "Tracking" from the "Video" menu.

For details on this operation, refer to "Using the Configuration Menus".

Video

Audio Setting User's Logo Advanced About Reset All

Position

0000

Tracking

Sync . 0

Brightness 0

Contrast

Sharpness 0 Color Mode Input Signal

RGB

Auto Setup

ON OFF

Reset

Adjust

[Normal ]

Select

YUV( YCbCr YPbPr)

Execute

(p.56)

: Select: Return : Adjust

Press the [ ] and [ ] buttons

to set the tracking value.

The tracking value increases or decreases each time a button is pressed.

After making the adjustment, press the [Menu] button to exit

the configuration menu.

Video

Audio Setting User's Logo Advanced About Reset All

Position

Tracking

Sync . Brightness Contrast Sharpness Color Mode Input Signal

Auto Setup Reset

: Select: Return

: Adjust

Adjust

1000

Select [Normal ]

RGB

YUV( YCbCr YPbPr)

ON OFF

Execute

Tip :

The image will flash when continuous tracking adjustment is carried out, but this is normal.

Adjusting the Sync

If flickering, fuzziness or interference appear in images that are input from the computer, and this cannot be fixed using automatic setup, you will need to adjust the sync

manually

using the following procedure.

Procedure

Press the [Menu] button on the

remote control, and then select "Sync." from the "Video" menu.

For details on this operation, refer to "Using the Configuration Menus".

Video

Audio Setting User's Logo Advanced About Reset All

Position Tracking

Sync . 0

Brightness 0 Contrast Sharpness 0 Color Mode Select Input Signal

Auto Setup Reset

: : :

0000

RGB

ON OFF

Adjust

YUV( YCbCr YPbPr)

Execute

[Normal ]

(p.56)

: Select: Return

: Adjust

Press the [ ] and [ ] buttons

to set the sync value.

The sync value increases or decreases each time a button is pressed.

After making the adjustment, press the [Menu] button to exit

the configuration menu.

Video

Audio Setting User's Logo Advanced About Reset All

: Select: Return

Position

0000

Tracking

Sync . 10

Brightness 0

Contrast

Sharpness 0 Color Mode Input Signal

Auto Setup

Reset

: Adjust

Adjust

Select

YUV( YCbCr YPbPr)

RGB

ON OFF

Execute

[Normal ]

Tip :

• If you adjust the sync without adjusting the tracking first, it will not be possible to get the best adjustment results. Incorrect tracking adjustment may not be noticeable with some types of picture. However, pictures with lots of lines and shading will tend to show incorrect tracking adjustments more clearly, so be sure to check the tracking adjustment first.

• It may also be possible to fix flickering and fuzziness by adjusting the brightness, contrast

, sharpness and keystone correction settings.

Adjusting the Image Quality

Selecting the Colour Mode

The following six preset colour modes are available for use depending on the characteristics of the images that are being projected. You can easily obtain the optimum image quality simply by selecting the colour mode that corresponds to the projected images. The brightness of the images will vary depending on which colour mode is selected.

Mode Application

sRGB

Normal Brightness is emphasised. For presentation in bright rooms.

Meeting Images are modulated using their original tints, with no colour

Presentation For presentations in dark rooms.

Theatre Movie images are optimised using natural tints.

Game Brightness is emphasised. Ideal for playing video games in

Procedure

Images conform to the sRGB colour standard. If the connected source has an sRGB mode, set both the projector and the connected signal source to sRGB.

enhancement.

bright rooms.

The color mode changes as follows each time the [Color Mode] button on the remote control is pressed.

Normal → Meeting → Presentation → Theatre → Game → sRGB ...

The current setting appears in the top-right

Remote control

Page upPage down

Powe r

Computer

Color Mode

S-Video/Video

Freeze

A/V Mute

E-Zoom

Normal

corner of the screen each time the colour mode is changed. The default setting for the colour mode is "Normal" when computer images are being input, and "Theatre" when component video

composite video and S-Video signals are being input.

Tip :

The colour mode can also be set using the "Color Mode" command in the "Video" menu. (p.47, 49)

Advanced Operations

This chapter describes functions for enhancing the projection of images, and how to use the configuration menus.

Functions for Enhancing Projection................................42

• A/V Mute .............................................................................................. 42

• Freeze .................................................................................................... 43

• Wide-screen Projection of Component Video and Video Images

(Changing the Aspect Ratio)............................................................... 44

• E-Zoom ................................................................................................. 45

Using the Configuration Menu Functions .......................46

• List of Functions................................................................................... 46

• "Video" Menu ................................................................................................... 46

• "Audio" Menu................................................................................................... 50

• "Setting" Menu..................................................................................................50

• "User's Logo" Menu..........................................................................................52

• "Advanced" Menu.............................................................................................52

• "About" Menu................................................................................................... 54

• "Reset All" Menu.............................................................................................. 55

• Using the Configuration Menus.......................................................... 56

Functions for Enhancing Projection

This section describes the various useful functions that can be used to enhance presentations.

A/V Mute

This function momentarily pauses the image and sound. For example, it can be used when you do not want to show viewers details of operations such as selecting different files while computer images are being projected. However, if you use this function when projecting moving images, the images and sound will still continue to be played back by the source, and you cannot return to the point where the mute function was activated.

Procedure

Press the [A/V Mute] button on the remote control.

The image and sound will then be paused.

Press the [A/V Mute] button on the remote control to continue normal projection.

Remote control

Freeze

A/V Mute

E-Zoom

Enter

You can use the "A/V Mute" function in the "Setting" menu to set the screen appearance when the images and sound have been paused to any one of the following three settings. (p.51)

Solid black Solid blue User's logo

Default setting

Tip :

The default user's logo is the EPSON logo. You can change the user's logo by recording and setting your own logo. (p.80)

Freeze

This function pauses only the projected images. The sound keeps playing without pausing. The image source will still be playing back the images even while projection is paused, and so it will not be possible to resume projection from the point where it was paused.

Procedure

Press the [Freeze] button on the remote control.

The images will then be paused.

To continue projecting the images, either press the [Freeze] button again or press the [ESC]

Remote control

Freeze

A/V Mute

E-Zoom

Enter

button.

Tip :

• Pressing the [Freeze] button also clears configuration menu displays and help messages.

• The freeze function still works while the E-Zoom function is being used. However, in this case the freeze function can only be cancelled by pressing the [Freeze] button.

Functions for Enhancing Projection

Wide-screen Projection of Component Video and Video Images (Changing the Aspect Ratio)

This function changes the aspect ratio of images from 4:3 to 16:9 when component video images (YCbCr and YPbPr) or video images (S-Video or composite video) are being projected. Images which have been recorded in digital video or onto DVDs can be viewed in 16:9 wide-screen format.

When images in squeeze mode are projected at 4:3

When images in squeeze

mode are projected at 16:9

Procedure

Press the [Menu] button on the

remote control, and then select "Aspect Ratio" from the "Video" menu.

For details on this operation, refer to "Using the Configuration Menus". (p.56)

Press the [ ] and [ ] buttons

to set the aspect ratio to either "4:3" or "16:9", and then press the [Enter] button.

After making the adjustment, press the [Menu] button to exit

the configuration menu.

Video

Audio

Setting

User's Logo

Advanced

About

Reset All

: Return : Select

Video

Audio

Setting

User's Logo

Advanced

About

Reset All

: Return : Select

Position

Brightness

: :

Contrast

Color 0

Tint

: :

Sharpness 0

Color Mode

Video Signal

Aspect Ratio

Reset

: Set

Position

Brightness

: :

Contrast

Color 0

: :

Tint

Sharpness 0

Color Mode

Video Signal

Aspect Ratio

Reset

: Set

4: 316: 9

4: 3 16: 9

Adjust

Select [Theatre ]

Select [Auto ]

Execute

Adjust

Select [Theatre ]

Select [Auto ]

Execute

E-Zoom

This function lets you enlarge and reduce a part of projected images such as graphs and tables.

Procedure

Press the [E-Zoom ] button on the

remote control.

A cursor (cross) indicating the centre point for the area to be enlarged will appear on the screen.

Move the cross to the area of the

image that is to be enlarged or reduced.

Press the [ ], [ ], [ ] and [ ] buttons on the remote control to move the cross.

When [ ] is pressed, the image is

enlarged with the cross as its centre. When [ ] is pressed, the enlarged picture is then reduced.

The enlargement ratio will appear at the bottom-right of the screen. You can scroll around the image by pressing the [ ], [ ], [ ] and [ ] buttons.

Remote control

E-Zoom

Enter

ESCAuto

Cross

Shows enlargement ratio

To cancel the E-Zoom, press the [ESC] button.

Tip :

The selected area can be enlarged to between 1– 4 times, in 25 steps of x0.125.

Using the Configuration Menu Functions

The configuration menus can be used to carry out a variety of settings and adjustments. The menus have a hierarchical structure, with a main menu that is divided into sub-menus, which are further divided into other sub-menus. The remote control is used to operate the menus. Refer to "Using the Configuration Menus" (p.56) for details on using the menus.

Main menu Sub-menu (Video)

Video

Audio Setting User's Logo Advanced About Reset All

Position Tracking Sync . Brightness Contrast Sharpness Color Mode Input Signal

Auto Setup Reset

Adjust

0000

: :

Select

RGB

YUV( YCbCr YPbPr)

ON OFF

Execute

[Normal ]

: Select : Enter

List of Functions

"Video" Menu

• The functions in the "Video" menu apart from "Input Signal", "Auto Setup" and "Video Signal" cannot be adjusted while no image signal is being input.

• The functions which appear in the "Video" menu will change depending on the type of input source being used for the image signal. Functions which are not available in the "Video" menu for a particular input source cannot be adjusted.

Computer (Analogue-RGB)/RGB video

Video

Audio Setting User's Logo Advanced About Reset All

: Select : Enter

Position Tracking Sync . Brightness Contrast Sharpness Color Mode Input Signal

Auto Setup Reset

: : : : :

0000

0 0

RGB

ON OFF

Adjust

Select

[Normal ]

YUV( YCbCr YPbPr)

Execute

"Video" Menu

Sub-menu Function Default

Position Moves the image display position vertically and

horizontally.

• Press the [Enter] button and make the adjustment using the display position adjustment sub-menu that appears.

Tracking

Sync. Adjusts computer images when flickering, fuzziness or

Brightness Adjusts the image brightness. Median

Contrast

Sharpness Adjusts the image sharpness. Median

Color Mode Corrects the vividness of the image colour. The settings

Input Signal Selects the input source to be used.

Auto Setup Selects whether the automatic adjustment function for

Adjusts computer images when vertical stripes appear in the images.

interference appear in the images.

• Flickering and fuzziness may also appear when the brightness, contrast are adjusted.

• You can obtain the best results if you adjust the tracking first and then adjust the sync.

Adjusts the difference between light and shade in the images.

can be saved separately for each type of source (computer or video source). You can select from six different quality settings depending on the surroundings.

• sRGB

• Normal : Brightness is emphasised. For presentation in

• Meeting: Images are modulated using their original

• Presentation: For presentations in dark rooms.

• Theatre : Movie images are optimised using natural

• Game : Brightness is emphasised. Ideal for playing

• Select "RGB" when projecting computer images or

automatically optimising images when the input source is changed is turned ON or OFF.

: Images conform to the sRGB standard.*

bright rooms.

tints, with no colour enhancement.

tints.

video games in bright rooms.

RGB video images.

, sharpness or keystone settings

Depends on connection

value (0)

Median value (0)

value (0)

Normal

Depends on connection

Using the Configuration Menu Functions

Sub-menu Function Default

Reset Resets all adjustment values for the "Video" menu

functions except for the "Input Signal" setting to their default settings.

• Press the [Enter] button to display the confirmation screen, and select "Yes".

• Select "Reset All" to return all menu settings to their default settings. (p.55)

* If set to sRGB, the colour temperature for the "Color Adjustment" command in the

"Advanced" menu will be set to 6500K.

Component (YCbCr , YPbPr ) Video (S-Video, Composite video)

Video

Audio Setting User's Logo Advanced About Reset All

: Select : Enter

Position Brightness Contrast Color Tint Sharpness Color Mode Input Signal

Aspect Ratio Reset

Adjust

: :

0 0

Select

RGB

Execute

[Theatre ]

YUV( YCbCr YPbPr)

3 16

Video

Audio Setting User's Logo Advanced About Reset All

: Select : Enter

Position Brightness Contrast Color Tint Sharpness Color Mode Video Signal

Aspect Ratio Reset

: : : : :

0 0

Adjust

[Theatre ]

Select

[Auto ]

Select

3 16

Execute

"Video" Menu

Sub-menu Function Default

Position Moves the image display position vertically and

horizontally.

• Press the [Enter] button and make the adjustment using the display position adjustment sub-menu that appears.

Brightness Adjusts the image brightness. Median

Contrast

Adjusts the difference between light and shade in the images.

Color (Not available for RGB video)

Adjusts the colour intensity for the images.

Tint (Not available for RGB video)

(Adjustment is only possible when component video NTSC signals are being input.) Adjust the image tint.

Sharpness Adjusts the image sharpness. Median

Depends on connection

value (0)

Median value (0)

Median

value (0)

Sub-menu Function Default

Color Mode Corrects the vividness of the image colour. The settings

Input Signal (Adjustment is only possible when component video

Video Signal (Adjustment is only possible when composite video/S-

Aspect Ratio

Reset Resets all adjustment values for the "Video" menu

* If set to sRGB, the colour temperature for the "Color Adjustment" command in the

"Advanced" menu will be set to 6500K

can be saved separately for each type of source (computer or video source). You can select from six different quality settings depending on the surroundings.

• sRGB

• Normal : Brightness is emphasized. For presentation in

• Meeting: Images are modulated using their original

• Presentation: For presentations in dark rooms.

• Theatre :

• Game : Brightness is emphasized. Ideal for playing

signals are being input.) Selects the input source to be used.

Video signals are being input.) Sets the video signal format.

• Press the [Enter] button, and choose the setting from the

• When set to "Auto", the video signal format is set

Sets the aspect ratio for projected images. Depends on

functions except for the "Input Signal" and "Video Signal" setting to their default settings.

Press the [Enter] button to display the confirmation screen, and select "Yes".

Select "Reset All" to return all menu settings to their default settings. (p.55)

: Images conform to the sRGB standard.*

bright rooms.

tints, with no colour enhancement.

Movie images are optimized using natural

tints. The black & white extension function operates so that differences in colour gradations (darkness and lightness of colours) are accentuated even for images that are very dark or very bright, to make them easier to view.

video games in bright rooms.

video signal format selection sub-menu which appears.

automatically.

Theatre

Depends on connection

Auto

connection

Using the Configuration Menu Functions

"Audio" Menu

Video

Audio

Setting User's Logo Advanced About Reset All

: Select : Enter

Sub-menu Function Default

Volume Adjusts the volume. Median

Tone Adjusts the tone. Median

Reset Resets all adjustment values for the "Audio" menu

Tip :

The "Audio" menu settings are saved individually for each input signal source.

Volume

Tone

Reset

Execute

functions to their default settings.

• Press the [Enter] button to display the confirmation screen, and select "Yes".

• Select "Reset All" to return all menu settings to their default settings. (p.55)

value (10)

value (0)

"Setting" Menu

Video Audio

Setting

User's Logo Advanced About Reset All

: Select : Enter

Keystone 0

Auto Keystone

No-Signal Msg. OFF Logo

Prompt ON OFF

Color Mode Prompt

A/V Mute LogoBlack Blue

Sleep Mode ON OFF Reset

ON OFF

: :

Black Blue

ON OFF

Execute

Sub-menu Function Default

Keystone Corrects vertical keystone distortion in images.

• When keystone correction is carried out, the projected

Median value (0)

image will become smaller.

• If the images become uneven in appearance after keystone correction is carried out, decrease the sharpness setting.

Sub-menu Function Default

Auto Keystone

No-Signal Msg.

Prompt Sets whether the input signal name is displayed on the

Color Mode Prompt

A/V Mute Sets the screen status when the [A/V Mute] button on the

Sleep Mode Sets the energy saving operation when no signal is being

Reset Resets all adjustment values for the "Setting" menu

Sets the function for automatically correcting keystone distortion when the angle of the projector has been adjusted to ON or OFF. This function is only enabled when the "Rear Proj. " and "Ceiling" commands in the "Advanced" menu are set to "OFF". If either "Rear Proj. " or "Ceiling" is set to "ON", this menu cannot be selected.

Sets the message status and background colour at times such as when no image signal is being input. When set to "OFF", the background colour becomes black and no message is displayed.

• To change the user's logo, you need to record and set your own logo. (p.80)

screen or not when the input signal is changed.

Sets whether the colour mode prompt is displayed on the screen or not when the colour mode is changed.

remote control is pressed.

• To change the user's logo, you need to record and set your own logo.

input.

• When set to "ON", projection stops automatically and then after the cool-down projector changes to sleep mode if no operations are carried out for 30 minutes while the "No-Signal." message is being displayed. (The Power indicator lights orange.)

• Projection starts again when the [Power] button on the projector's control panel or the remote control is pressed.

functions to their default settings.

• Press the [Enter] button to display the confirmation screen, and select "Yes".

• Select "Reset All" to return all menu settings–including settings for the "Video" and "Audio" menus–to their default settings. (p.55)

period is finished, the

Blue

Black

Using the Configuration Menu Functions

"User's Logo" Menu

Video Audio Setting

User's Logo

Advanced About Reset All

: Select : Execute

Execute

Sub-menu Function Default

Execute Records a user's logo. (p.80)

• Press the [Enter] button and follow the procedure appearing on the screen.

"Advanced" Menu

EPSON logo

Video

Audio

Setting

User's Logo

Advanced

About

Reset All

: Select : Enter

Language

Startup Screen

Color Adjust ment

Rear Proj .

Ceiling ON OFF

Link 21L

Reset

Select [English]

ON OFF

Color Temp. RGB

ON OFF

: :

ON OFF

Execute

Adjust

Sub-menu Function Default

Language Sets the language for message displays.

English

• Press the [Enter] button and select the language from the selection menu that appears.

Startup Screen

Sets whether the startup screen is displayed or not.

• To change the user's logo, you need to record and set

your own logo.

Sub-menu Function Default

Color Adjustment

Rear Proj. Use when projecting images from behind a translucent

Ceiling Use when installing the projector to a ceiling. When set

Link21L Sets whether the "EMP Link21L

Reset Resets all adjustment values for the "Advanced" menu

Adjusts the colour temperature and intensity of each RGB color for each input source.

• Color Temp.: Lets you adjust bright colours within a range from reddish tinges to bluish tinges. If the colour temperature is lower, colours appear reddish and color tones appear softer. If the colour temperature is higher, colours appear bluish and colour tones appear sharper. Press the [Enter] button and make the adjustment in the colour adjustment submenu that appears.

• RGB : Sets the colour intensity for each RGB (red/green/blue) colour in the image. Press the [Enter] button, select "R" (red), "G" (green) or "B" (blue) and make the adjustment in the colour adjustment submenu that appears.

(This item cannot be selected if "sRGB" has been selected as the "Color Mode" setting in the "Video" menu.)

screen. When set to "ON", the projected images are horizontally reversed.

to "ON", the projected images are horizontally and vertically reversed.

" utility software is being used or not. After changing the setting, turn off the projector's power. After the cool-down on. The EMP Link21L software can then be used. See "Utility Software" in the Safety Instructions/World– Wide Warranty Terms.

functions except for the "Language" setting to their default settings.

• Press the [Enter] button to display the confirmation

screen, and select "Yes".

• Select "Reset All" to return all menu settings including

settings for the "Video" and "Audio" menus to their default settings. (p.55)

has finished, turn the power back

Color Tem p. : Depends on connection

OFF

Using the Configuration Menu Functions

"About" Menu

• The "About" menu shows the setting details for the current image source.

• The "Lamp" item appears as 0H for 0–10 hours, and after that, it appears in

units of 1 hour.

Computer/RGB video/ Video (S-Video, Composite video) Component video (Analogue-RGB, YCbCr

, YPbPr )

Video

Audio

Setting

User's Logo

Advanced

About

Reset All

: Select : Enter

Lamp 0H

Reset Lamp Timer

Video Source

Input Signal

Frequency

SYNC Polarity

SYNC Mode

Resolution

Refresh Rate 0.0 Hz

Computer

: RGB

H ---.--kHz

V ---.--Hz

H ------

V ------

------

0x 0

Execute

Video

Audio

Setting

User's Logo

Advanced

About

Reset All

: Select : Enter

Lamp

Reset Lamp Timer

Video Source

Video Signal

Video

Auto( )

Execute

Sub-menu Function Default

Lamp Displays the cumulative lamp operating time.

• When the lamp warning period is reached, the display characters appear in red.

Reset Lamp Timer

Initialises the lamp operating time. When this command is selected, the cumulative lamp operating time is reset to

the initial default value.

Video Source Displays the input source which is currently being

projected.

Input Signal Displays the input signal settings.

(Does not appear when the input source is composite video or S-Video.)

Video Signal Shows the video signal format.

(Does not appear when the input source is computer, component video or RGB video.)

Frequency Displays the horizontal and vertical scanning frequencies.

(Does not appear when the input source is composite video or S-Video.)

SYNC Polarity

Displays the sync polarity. (Does not appear when the input source is composite

video or S-Video.)

Sub-menu Function Default

SYNC Mode Displays the sync attributes.

(Does not appear when the input source is composite video or S-Video.)

Resolution Displays the input resolution.

(Does not appear when the input source is composite video or S-Video.)

Refresh Rate

Displays the refresh rate. (Does not appear when the input source is composite video or S-Video.)

"Reset All" Menu

Video

Audio

Setting

User's Logo

Advanced

About

Reset All

: Select : Execute

Sub-menu Function Default

Execute Resets all items in all menus to their default settings.

• Press the [Enter] button to display the confirmation screen, and select "Yes".

• Select "Reset" in an individual menu to reset only the settings for the items in each sub-menu.

• The "Input Signal", "Video Signal", "User's Logo", "Lamp" and "Language" settings will not return to their default settings.

Execute

Using the Configuration Menu Functions

Using the Configuration Menus

The configuration menus can be operated using the remote control only.

Procedure

Press the [Menu] button on the

remote control.

The main menu will be displayed.

Select a menu item.

Press the [ ] or [ ] button to move to an item to be selected.

Confirm the selection.

Press the [Enter] button to confirm the selection of a menu item. The selected sub-menu will then be displayed.

Select a sub-menu item.

Press the [ ] or [ ] button to move to an item to be selected.

The items appearing in the "Video" menu and the "About" menu will vary depending on the type of input source being projected.

Remote control

A/V Mute

E-Zoom

Enter

Video

Audio

Setting

User's Logo

Advanced

About

Reset All

Language

Startup Screen

Color Adjust ment

Rear Proj .

Ceiling : ON OFF

Link 21L

Reset

Language

Startup Screen

Color Adjust ment

Rear Proj .

Ceiling : ON OFF

Link 21L

Reset

Select [English]

: ON OFF

Color Temp. RGB Adjust

::ON OFF

: ON OFF

Execute

Select [English]

: ON OFF

Color Temp. RGB Adjust

::ON OFF

: ON OFF

Execute

Freeze

Select a setting value.

Press the [ ] and [ ] buttons to change the setting value.

Color Temp. 8000K

Color Adjust ment

For commands which have ON/OFF settings, use the [ ] and [ ] buttons to select the desired setting, and then press the [Enter] button.

Tip :

• Sub-menu items which cause another sub-menu to be displayed when they are selected have after them. If you select such menu items and press the [Enter] button, you can then change the settings in the next sub-menu which appears.

• Refer to "List of Functions" for details on the functions of each menu item. (p.46)

Select other menu items in the same way.

Repeat steps 2 to 5 to change the setting for other menu items. To return to a previous menu, press the [ESC] button.

Close the menu.

Press the [Menu] button.

Troubleshooting

This section describes how to identify problems and what to do if a problem is found.

Using the Help ...................................................................60

When Having Some Trouble .............................................61

• Power Indicator.................................................................................... 61

• (Warning) Indicator...................................................................... 62

When the Indicators Provide No Help..............................64

Using the Help

If a problem occurs with the projector, the Help function uses on-screen displays to assist you in solving the problem. It uses a series of menus in a question and answer format.

Procedure

Press the [Help] button on the

projector's control panel.

The help menu will be displayed.

Select a menu item.

If using the control panel, the [ Select ] buttons function as the up and down keys. If using the remote control, press the [ ] and [ ] buttons to select an item.

Confirm the selection.

Press the [Enter] button to confirm the selection of a menu item.

Projector

Hel p Menu

Help for the image

Help for the sound Language selection (Language)

If the suggested solution in Help doesn't solve the problem, unplug the power from the wall outlet and contact your local dealer.

: Select : Enter : Exit

Projector

Remote control

E-Zoom

Enter

ESCAuto

Remote control

Freeze

A/V Mute

E-Zoom

Enter

ESCAuto

Repeat the operations in steps 2

and 3 to proceed through the menu to more detailed items.

You can exit the help menu at any time by pressing the [Help] button.

Hel p Menu

No image appears on the screen.

The image is distorted. The image is not displayed fully on the screen. (cut of f/ too big/ too small/ partial) The color of the image is abnormal . The image is too dark. The image is trapezoidal. Return

: Select : Enter : Exit

Tip :

If the Help function does not provide a solution to the problem, refer to "When Having Some Trouble" (p.61) or "When the Indicators Provide No Help" (p.64).

When Having Some Trouble

If you are having a problem with the projector, first check the projector's indicators. The projector is provided with the following two indicators. These indicators alert you to problems with projector operation.

Power indicator

Warning indicator

The following tables show what the indicators mean and how to remedy problems that they indicate.

Power Indicator

: lit : flashing

Status Cause Remedy or Status

Orange

Green

Standby condition

Cool-down in progress

Projection in progress

Warm-up in progress

(Not abnormal) The power cable should only be disconnected when the projector is in this condition. Press the [Power] button to start projection.

(Not abnormal)

• Please wait. The cool-down seconds.

• You cannot operate the [Power] button during cool-down. Press the button again after cooldown ends.

(Not abnormal)

(Not abnormal) Please wait. Warm-up time is approximately 40 seconds.

After warm-up is complete, the flashing green indicator changes to steady green.

period lasts about 45

See

Page

p.28

p.31

p.29

When Having Some Trouble

(Warning) Indicator

: lit : flashing

Status Cause Remedy or Status

Red

(0.5-

second

intervals)

High internal temperature (overheating)

Problem with lamp

The lamp will turn off automatically and projection will stop. Wait for about 5 minutes without operating the projector. After about 5 minutes have elapsed, unplug the power cable and then check the following two points.

• Check that the air inlet and air outlet are clear, and that the projector is not positioned against a wall.

• If the air filter is dirty, it should be cleaned.

When the power cable is plugged back in, the projector will return to its previous state, so press the [Power] button on either the projector's control panel or the remote control to turn it back on. If the projector continues to overheat even after the above points have been checked, or if the indicators show a problem when the power is turned back on, stop using the projector, disconnect the power cable from the electrical outlet, and contact your dealer or the nearest address provided at "International Warranty Conditions" in Safety Instructions/ World-Wide Warranty Terms.

Disconnect the power cable from the electrical outlet and then remove the lamp and check if it is broken. If the lamp is not broken, reinstall it. Then reconnect the power cable and press the [Power] button on either the projector's control panel or the remote control to turn the power back on. If the indicators still show a problem, stop using the projector, disconnect the power cable from the electrical outlet, and contact your dealer or the nearest address provided at "International Warranty Conditions" in Safety Instructions/World-Wide Warranty Terms.

If the lamp is broken replace by a new lamp, or contact your local dealer for further advise. If replacing the lamp yourself, be careful to avoid pieces of broken glass. (Projection cannot be carried out until the lamp is replaced.)

See

Page

p.15

p.73

p.76

Check that the lamp and the lamp cover are

Red

(1-second

intervals)

Orange

Internal problem

High-speed cooling in progress

securely installed. If the lamp or lamp cover is not securely installed, the lamp will not switch on.

Stop using the projector, disconnect the power cable from the electrical outlet, and contact your dealer or the nearest address provided at "International Warranty Conditions" in Safety Instructions/World-Wide Warranty Terms.

(This is not an abnormality, but if the temperature rises too high again, projection will stop automatically.)

• Set the projector up in a place which is wellventilated, and so that the air filter and exhaust vents are clear.

• Clean the air filter.

p.76

p.15

p.73

Tip :

• If the projector is not operating properly even though the indicators are all showing normal, refer to "When the Indicators Provide No Help" on the following page.

• If an indicator is showing a status which does not appear in the previous tables, contact your dealer or the nearest address provided at "International Warranty Conditions" in Safety Instructions/World-Wide Warranty Terms.

When the Indicators Provide No Help

If any of the following problems occur and the indicators do not offer a solution, refer to the pages given for each problem.

• No images appear (p.64, 65) • Images appear dark (p.68)

• Poor image quality (out of

focus or distorted)

• Only part of the image is displayed (Large/small)

• The image colours are not right

No images appear (Nothing at all appears)

• Was the power turned off and then straight back on again?

After the power is turned off (during cool-down [Power] buttons on the projector's control panel and the remote control will not work. Wait until cool-down has finished. You can then use the [Power] buttons. (p.31)

No images appear

• Is sleep mode active?

When sleep mode has been set to "ON", the lamp turns off automatically if no operations are carried out for 30 minutes while no image signal is being input. The Power indicator lights orange at this time. "Setting" - "Sleep Mode" (p.51)

• Have you pressed the [Power] button?

(p.29)

• Has the image brightness been adjusted correctly?

"Video" - "Brightness" (p.47, 48)

• Is A/V Mute mode active?

(p.42)

• Is the projected image completely black?

Some input images, such as screen savers, may be completely black.

• Is an image signal being input?

If "No-Signal Msg. " in the "Setting" menu has been set to "OFF", no messages will be displayed. Set it to "Black" or "Blue" for messages to be displayed. If a message is displayed, refer to the item indicated. "Setting" - "No-Signal Msg. " (p.51)

• Try resetting all of the current settings.

"Reset All" - "Execute" (p.55)

(p.65) • Images appear greenish (p.69)

(p.67)

(p.68)

• No sound can be heard (p.69)

• The remote control does

not work

• The power does not turn off (p.70)

(p.69)

), the

No images appear (Messages do appear)

• Check the mode which corresponds to the frequency of the image signals being output from the computer.

Refer to the documentation provided with your computer for details on changing the resolution and frequency of the image signals being output from the computer. (p.88)

"Not Supported." is displayed

• Are the cables connected correctly?

(p.17–25)

• Does the input signal match the connected source?

Use the [Source] button on the projector's control panel (or the [Computer] or [S-Video/Video] button on the remote control) to select the correct signal source. (p.30)

"No-Signal." is displayed

• Is the power for the computer or video source turned on?

(p.29)

• If a laptop computer or a computer with a LCD screen has been connected to the projector, it is necessary to output the image signals to the projector rather than to the screen.

Normally image signals are output to only the computer's LCD screen, so you need to change the output to an external destination. For some computer models, when the image signals are output externally, they no longer appear on the LCD screen. For details, refer to the section of the documentation provided with your computer under a heading such as "External output", "Connecting an external monitor" or similar. (p.30)

Poor image quality (out of focus or distorted)

• Has the focus been adjusted correctly?

(p.37)

• Is the lens cover still attached?

• Has the front adjustable feet been adjusted so that the

image angle is too big?

The image is fuzzy

••••

Part of the image is

••••

out of focus The whole image is

••••

out of focus

If the image angle is too big, the image will be out of focus vertically. (p.34)

• Is the projector at the correct distance?

The recommended distance from the projector to the screen is within 1.0–11.7 m (3.2–38.5 ft.). Set up the projector so that the projection distance is within this range. (p.15)

When the Indicators Provide No Help

• Is the projector beam perpendicular to the screen?

(p.34)

• Is the lens dirty?

(p.72)

• Has condensation formed on the lens?

If the projector is suddenly taken from a cold environment to a warm environment, condensation may form on the surface of the lens, and this may cause the images to appear fuzzy. Set the projector up in the room approximately one hour before it is to be used. If condensation forms on the lens, turn off the power and wait for the condensation to disappear.

• Have the "Sync.", " Tracking" and "Position" been adjusted correctly?

If the "Auto Setup" command in the "Video" menu is set to "OFF", press the [Auto] button on the remote control to adjust these settings. If the images have not been correctly adjusted after using the automatic setup function and after pressing the [Auto] button, adjust the settings manually using the respective menus. (p.37, 47)

• Are the image signal format settings correct?

If a computer, component video connected to the projector, use the "Input Signal" command in the "Video" menu to select the signal format which matches the signal connected source. (p.47, 49) If a composite video the projector, use the "Video Signal" command in the "Video" menu to select the video signal format. (p.49)

• Are the cables connected correctly?

(p.17–25)

• Has the correct resolution been selected?

Set the computer so that the signals that are output are compatible with this projector. Refer to the documentation provided with your computer for details on changing the

Image is distorted

••••

Image contains

••••

interference

settings. (p.88)

• Have the "Sync adjusted correctly?

or RGB video source is

or S-Video source is connected to

.", " Tracking" and "Position" been

• Is an extension cable being used?

If an extension cable is used, electrical interference may affect the signals. Use the accessory cables and check if this helps.

• Are the image signal format settings correct?

or S-Video source is connected to the projector, use the "Video Signal" command in the "Video" menu to select the video signal format. (p.49)

Only part of the image is displayed (Large/small)

" setting been selected

Only part of the image is displayed

Small

• Has the "Aspect Ratio correctly?

Use the "Aspect Ratio" command in the "Video" menu to set the aspect ratio to "4:3". (p.49)

• Is the E-Zoom function being used to enlarge the image?

Press the [ESC] button on the remote control to cancel EZoom. (p.45)

• Has the "Position" setting been adjusted correctly?

Use the "Position" command in the "Video" menu to adjust. (p.47, 48)

• Has the correct resolution been selected?

Set the computer so that the signals that are output are compatible with this projector. Refer to the documentation provided with your computer for details on changing the settings. (p.88)

• Change the resolution for the laptop computer or computer with a LCD screen.

Change the resolution so that the image is displayed in the whole of the projection area, or set the image signal to external output only. (p.30)

• Has the computer been set for dual display?

If dual display has been activated in the Display Properties of the connected computer's Control Panel, the projector will only display about half of the image on the computer screen. To display the whole of the image on the computer screen, turn off the dual display setting. Refer to the video driver manual for the computer's monitor for further details.

or RGB video source is

When the Indicators Provide No Help

The image colours are not right

• Has the image brightness been adjusted correctly?

"Video" - "Brightness" (p.47, 48)

• Are the cables connected correctly?

(p.17–25)

• Are the image signal format settings correct?

If the "Input Signal" command in the "Video" menu is set to "YPbPr" or "YCbCr" when a computer is connected, the projected images will appear purplish. If a computer, component video connected to the projector, use the "Input Signal" command in the "Video" menu to select the signal format which matches the signal connected source. (p.47, 49) If a composite video the projector, use the "Video Signal" command in the "Video" menu to select the video signal format. (p.49)

• Has the image contrast been adjusted correctly?

"Video" - "Contrast" (p.47, 48)

• Has the colour been adjusted correctly?

"Advanced" - "Color Adjustment" (p.53)

• Have the colour intensity and tint been adjusted correctly?

(The colours may not exactly match the colours in the image on the computer screen or LCD screen, but this is normal and is not the sign of a problem.) "Video" - "Color", "Tint" (p.48)

• Is the lamp due for replacement?

When the lamp is nearly due for replacement, the image will become darker and the colour quality will become poorer. When this happens, the lamp should be replaced with a new one. (p.76)

or RGB video source is

or S-Video source is connected to

Images appear dark

• Is the lamp due for replacement?

When the lamp is nearly due for replacement, the image will become darker and the colour quality will become poorer. When this happens, the lamp should be replaced with a new one. (p.76)

• Has the image brightness been adjusted correctly?

"Video" - "Brightness" (p.47, 48)

• Has the image contrast

"Video" - "Contrast" (p.47, 48)

been adjusted correctly?

Images appear greenish.

• Do the settings for component video input signals match the signals from the connected device?

If the "Input Signal" command in the "Video" menu is set to "RGB" when a component video signal source is connected to the projector, the images will appear greenish. Select the correct signal format for the connected source. "Video" - "Input Signal" (p.49)

No sound can be heard.

• Is the audio source connected correctly?

(p.20, 26)

• Has the volume been adjusted to the minimum setting?

(p.50)

• Is A/V Mute mode active?

The projector may be in A/V Mute mode. Press the [A/V Mute] button on the remote control to cancel the A/V Mute. (p.42)

The remote control does not work

• Is the remote control light-emitting area facing towards the remote control light-receiving area when it is operated?

The operating angle for the remote control is approximately 30º horizontally and approximately 15º vertically.

• Is the remote control too far from the projector?

The operating distance for the remote control is approximately 6 m (20 ft.). (p.13)

• Is direct sunlight or strong light from fluorescent lamps shining onto the remote control light-receiving area?

• Has the battery insulating tape been removed?

(p.12)

• Is there battery in the remote control?

(p.74)

• Is the battery dead?

• Has the battery been inserted correctly?

(p.74)

Computer

Page upPage down

S-Video/Video

A/V Mute

E-Zoom

Enter

Power

Color Mode

Freeze

ESCAuto

When the Indicators Provide No Help

The power does not turn off (after the [Power] button is pressed)

• The Power indicator remains orange.

This projector is designed so that the Power indicator remains lit even when after the power has been turned off. The Power indicator will switch off when the power cable is disconnected from the electrical outlet.

• The cooling fan does not stop.

After the [Power] button is pressed to turn off the power, the cool-down After this, the Power indicator changes to a steady orange, and you can then disconnect the power cable from the electrical outlet. * The cool-down period lasts about 45 seconds. The actual

time will vary depending on the external air temperature.

period starts.

Appendices

This chapter provides information on maintenance procedures to ensure the best level of performance for the projector for a long time.

Maintenance.......................................................................72

• Cleaning................................................................................................ 72

• Cleaning the Projector Case.............................................................................. 72

• Cleaning the Lens ............................................................................................. 72

• Cleaning the Air Filter ...................................................................................... 73

• Replacing Consumables ...................................................................... 74

• Inserting the Battery.......................................................................................... 74

• Lamp Replacement Period................................................................................75

• Replacing the Lamp..........................................................................................76

• Resetting the Lamp Operating Time................................................................. 78

• Replacing the Air Filter .................................................................................... 79

Saving a User's Logo ........................................................80

Optional Accessories........................................................82

Glossary .............................................................................83

List of ESC/VP21 Commands ...........................................86

• Command List...................................................................................... 86

• USB Connection Setup ........................................................................ 87

List of Supported Monitor Displays.................................88

Specifications ....................................................................89

Appearance ........................................................................91

Index ...................................................................................92

Maintenance

This section describes maintenance tasks such as cleaning the projector and replacing consumable parts.

Cleaning

You should clean the projector if it becomes dirty or if the quality of projected images starts to deteriorate.

Caution :

Be sure to read the separate Safety Instructions/World-Wide Warranty Terms before cleaning.

Cleaning the Projector Case

Clean the projector case by wiping it gently with a soft cloth. If the projector is particularly dirty, moisten the cloth with water containing a small amount of neutral detergent, and then firmly wring the cloth dry before using it to wipe the projector case. Then wipe the case again with a soft, dry cloth.

Caution :

Do not use volatile substances such as wax, alcohol or thinner to clean the projector case. These can cause the case to warp and make the coating finish peel off.

Cleaning the Lens

Use a commercially-available air blower, or use a lens cleaning paper to gently wipe the lens.

Caution :

Do not rub the lens with harsh materials or subject the lens to shocks, as it can easily become damaged.

Cleaning the Air Filter

If the air filter becomes clogged with dust, it can cause overheating and damage the projector. While keeping the projector horizontal, use a vacuum cleaner to clean away the dust from the air filter.

Tip :

• If the air filter is difficult to clean or if it is broken, it should be replaced. Contact your dealer for a spare air filter.

• Spare lamps are provided with a spare air filter. The air filter should also be replaced when the lamp is replaced.

Maintenance

Replacing Consumables

This section describes how to replace the remote control battery, the lamp and the air filter.

Inserting the Battery

Use the following type of battery as a replacement. 1 CR2025 lithium battery

Caution :

Be sure to read the Safety Instructions/World-Wide Warranty Terms before handling the battery.

Procedure

Remove the battery holder.

While pushing the catch of the battery holder inwards, pull the battery holder out.

Catch

Remove the old battery and insert

the new battery.

Check the position of the (+) mark inside the battery holder to ensure that that battery is inserted the correct way.

Insert the battery holder into the

remote control.

Push the battery holder in until it clicks.

Tip :

Dispose of used batteries in accordance with local waste disposal regulations.

New battery

mark

Old battery

Lamp Replacement Period

It is time to replace the lamp when:

• The message "Lamp Replace." appears on the screen for 30 seconds

when projection starts

A message will be displayed.

• When the (Warning) indicator is flashing red at 0.5-second intervals

Flashes red at 0.5-second intervals

• The projected image gets darker or starts to deteriorate.

Tip :

• The replacement warning message is set to appear after about 1400 hours of lamp use in order to maintain the brightness and quality of the projected images. If you continue to use the lamp after this period, the possibility of the lamp breaking becomes greater. When the lamp replacement message appears, replace the lamp with a new one as soon as possible, even if it is still working.

• The warning message appears after about 1400 hours of use, but the actual life of each individual lamp will vary depending on the characteristics of the lamp and on the way it has been used. Some lamps may stop operating before 1400 hours of use, so you should always have a spare lamp ready in case.

• Contact your dealer for a spare lamp.

Maintenance

Replacing the Lamp

Caution :

• If the lamp stops working and needs to be replaced, there is the danger that the lamp may break when handled. If replacing the lamp of a projector that has been installed to the ceiling, you should always assume that the lamp is broken and remove the lamp cover very carefully.

• Wait until the lamp has cooled down sufficiently before opening the lamp cover. It takes a further one hour after the cool-down enough.

period has finished for the lamp to be cool

Procedure

Turn off the projector power, wait

for the cool-down period to end, and then disconnect the power cable.

The cool-down period lasts for about 45 seconds. The actual time will vary depending on the external air temperature.

Wait until the lamp has cooled

down, and then remove the lamp cover from the base of the projector.

It takes approximately one hour for the lamp to cool down by itself after the cooldown period has finished. While pressing the two hooks, pull the lamp cover up to remove it.

Loosen the two lamp fixing screws.

Use the screwdriver that is supplied with the spare lamp or a Phillips screwdriver to loosen the two lamp fixing screws that are securing the lamp to the projector.

Take out the lamp.

Hold the lamp by the two recesses on the side to lift it up and out from the projector.

Install the new lamp.

Hold the lamp so that it faces the correct way to fit into the projector, and then insert the lamp until it clicks into place and tighten the two fixing screws.

Install the lamp cover.

Insert the two cover tabs into the projector, and then press the other side of the lamp cover until it clicks into place.

Tip :

• Install the lamp securely. If the lamp cover is removed, the lamp turns off automatically as a safety precaution. Moreover, the lamp will not turn on if the lamp or the lamp cover is not installed correctly.

• Spare lamps are provided with a spare air filter. The air filter should also be replaced when the lamp is replaced. (p.79)

• Dispose of used lamps properly in accordance with your local regulations.

Maintenance

Resetting the Lamp Operating Time

The projector has a built-in counter which keeps track of the lamp operating time. When the cumulative operating time reaches a certain point, it causes the replacement warning message to be displayed. Therefore, the counter needs to be reset after the lamp has been replaced with a new one. You can do this using the projector menu.

Tip :

Do not reset the lamp operating time except after the lamp has been replaced, otherwise the lamp replacement period will not be indicated correctly.

Procedure

Connect the power cable, turn on

the projector's power, and then press the [Menu] button on the remote control.

The main menu will be displayed.

Select "Reset Lamp Timer" from the

"About" menu and then press the [Enter] button.

Select "Yes" and then press the

[Enter] button.

The lamp operating time will then be reset.

Remote Control

A/V Mute

Lamp 1400H

Reset Lamp Timer

Video Source

Input Signal RGB

Frequency

SYNC Polarity

SYNC Mode

Resolution

Refresh Rate 0.0 Hz

Computer

: :

H ---.--kHz

V ---.--Hz

: :

H -----V ------

------

: :

0x 0

Reset Lamp Timer

Execute?

YES

Freez e

E-Zoom

Enter

Execute

Replacing the Air Filter

Procedure

Turn off the projector power, wait

for the cool-down and then disconnect the power cable.

The cool-down period lasts for about 45 seconds. The actual time will vary depending on the external air temperature.

Put your finger into the recess in

the air filter hook, and lift up the air filter to remove it.

Install the new air filter.

First insert the tabs, and then press down on the opposite side until it clicks into place.

period to end,

Tip :

Dispose of used air filters properly in accordance with your local regulations.

Saving a User's Logo

You can record the image that is currently being projected as a user's logo.

Tip :

When a user's logo is recorded, the previous user's logo will be erased.

Procedure

Project the image that you would like to use as a user's logo,

and then press the [Menu] button on the remote control.

Select the "User's Logo" menu, and

then press the [Enter] button.

Tip :

If keystone correction or E-Zoom have been carried out, they will be canceled when the "User's Logo" menu is selected.

Select "Yes" in the sub-menu, and

then press the [Enter] button.

The image to be recorded and a

selection marquee box will be displayed. Move the marquee box to select the part of the image to use.

Press the [ ], [ ], [ ] and [ ] buttons on the remote control to select the part of the image to use as the user's logo, and then press the [Enter] button.

Video Audio Setting

User's Logo

Advanced About Reset All

: Select : Execute

User's Logo

Do you use the present image as a

user's logo?

YES

: Select: Return : Execute

: Move: Return : Set

Execute

Select "Yes" at the confirmation

screen, and then press the [Enter] button.

User's Logo

Do you use this image?

YES

: Select: Return : Execute

Select the zoom rate in the Zoom

rate setting screen, and then press the [Enter] button.

Select "Yes" at the confirmation

screen, and then press the [Enter] button.

The image will then be saved. Once the image has been saved, the message "Saving the user's logo is completed." will

Set the zoom rate.

Zoom rate:

Do you save the user's logo?

If you save it, the previous user's

logo will be over written.

User's Logo

100% 200% 300%

: Select: Return : Execute

User's Logo

YES

be displayed.

: Select: Return : Execute

Tip :

• Saving the user's logo may take a few moments (about 15 seconds). Do not use the projector or any other sources which are connected to the projector while the user's logo is being saved, otherwise it may result in errors in projector operation.

• User's logos can be saved at up to 480 x 360 dots in size.

• If the image resolution is not XGA size will be changed.

• Once a user's logo has been saved, the logo setting cannot be returned to the factory default.

, or if a video image is being projected, the display

Optional Accessories

The following optional accessories are available for purchase if required. This list of optional accessories is current as of April 2002. Details of accessories are subject to change without notice.

Soft carry case ELPKS16

Use this case if you need to carry the projector by hand.

Spare lamp ELPLP18

Use as a replacement for spent lamps.

50" portable screen ELPSC06

A compact screen which can be carried easily.

60" screen ELPSC07 80" screen ELPSC08

A portable roll-type screen.

VGA-HD15 PC cable ELPKC02 (1.8 m (6 ft.) - for mini D-Sub 15-pin/mini D-Sub 15-pin)

Use to connect the projector to a computer.

VGA-HD15 PC cable ELPKC09 (3 m (9.8 ft.) - for mini D-Sub 15-pin/mini D-Sub 15-pin)

VGA-HD15 PC cable ELPKC10 (20 m (65.6 ft.) - for mini D-Sub 15-pin/mini D-Sub 15-pin)

Use this extension cable if the accessory computer cable is too short.

VGA-HD15/BNC PC Cable ELPKC11 (1.8 m (6 ft.) - for mini D-Sub 15-pin/5BNC)

Use in order to connect the projector to a computer with a 5BNC port.

Component video cable ELPKC19 (3 m (9.8 ft.) - for mini D-Sub 15-pin/RCA x 3)

Use to connect a component video

Ceiling mount * ELPMB10

Use when installing the projector to a ceiling.

Ceiling plate * ELPFC03 Pipe 370 (370 mm (14.57 inches)/silver)* ELPFP04 Pipe 570 (570 mm (22.44 inches)/silver)* ELPFP05 Pipe 770 (770 mm (30.31 inches)/silver)* ELPFP06

Use when installing the projector to a high ceiling or a ceiling with veneer panels.

Image presentation camera ELPDC02 ELPDC03 ELPDC04

Use when projecting books, OHP films and slides.

* A special method of installation is required in order to suspend the projector

from the ceiling. Please contact the place of purchase if you would like to use this installation method.

source.

Glossary

Following is an explanation of some of the terms used in this guide which may be unfamiliar or which were not explained in the text of this guide itself. Further information can be obtained by referring to other commerciallyavailable publications.

5BNC A port used to input analogue video signals.

Aspect ratio The ratio between an image's length and its height. HDTV images have

Colour temperature

Component video

Composite video

Contrast The relative brightness of the light and dark areas of an image can be

Cool-down The cooling process for the projector's lamp unit continues even after

Dolby Digital

EMP Link21L

HDTV An abbreviation for High-Definition Television. It refers to high-

an aspect ratio of 16:9 and appear elongated. The aspect ratio for standard images is 4:3.

The temperature of an object which is emitting light. If the colour temperature is high, the colours tend to take on a bluish tinge. If the colour temperature is lower, the colours tend to take on a reddish tinge.

Video signals which have the video brightness signals and colour signals separated, in order to provide better image quality. In high-definition TV (HDTV), it refers to images which consist of three independent signals: Y (luminance signal), and Pb and Pr (colour difference signals).

Video signals which have the video brightness signals and colour signals mixed together. The type of signals commonly used by household video equipment (NTSC, PAL and SECAM formats). The signals consist of the carrier signal Y (luminance signal) and the chroma (colour) signal which are contained in the colour bar signal.

increased or decreased in order to make text and graphics stand out more clearly, or to make them appear softer. Adjusting this particular property of an image is called "contrast adjustment".

the [Power] button on the projector's control panel or the remote control has been pressed to turn off the lamp. After the lamp turns off, the cooling fan continues operating, but all button operations are disabled. The length of time that this is happening is called the "cool-down period". The cool-down period lasts for about 45 seconds. The actual time will vary depending on the external air temperature.

A sound format developed by Dolby Laboratories. Normal stereo is a 2-channel format which uses two speakers. Dolby Digital is a 6channel (5.1-channel) system which adds to this a centre speaker two rear speakers and a sub-woofer.

A utility software program that allows the projector to be connected to a computer so that the computer can be used to control the projector. For details on acquiring the software and for instructions on using the software and compatible projector models, please contact one of the service offices provided in the catalog.

definition systems which satisfy the following conditions.

• Vertical resolution of 750p or 1125i or greater (p = progressive scanning , i = interlaced scanning )

• Screen aspect ratio

• Dolby Digital

of 16:9

audio reception and playback (or output)

Glossary

Interlaced scanning

Progressive scanning

Refresh rate The light-emitting element of a display maintains the same luminosity

Resize display

Security lock

sRGB An international standard for colour intervals that was formulated so

SVGA

S-Video

SXGA A type of video signal with a resolution of 1280 (horizontal) x 1024

Sync. (Synchronization)

Tr a c k i n g

USB An abbreviation for Universal Serial Bus. USB is an interface for

A method of image scanning whereby the image data is divided into fine horizontal lines which are displayed in sequence starting from left to right and then from the top to the bottom of the screen. The evennumbered lines and odd-numbered lines are displayed alternately.

A method of image scanning whereby the image data from a single image is scanned sequentially from top to bottom to create a single image.

and colour for an extremely short time. Because of this, the image must be scanned many times per second in order to refresh the light-emitting element. The number of refresh operations per second is called the "refresh rate", and is expressed in hertz (Hz).

This function is use to project computer images that have a resolution or more than or less than the projector's panel resolution to be projected so that they fill the whole of the projection area.

A device consisting of a projector case with a hole in it that a commercially-available theft-prevention cable can be passed through in order to secure the device to a table or pillar. This projector is compatible with the Microsaver Security System manufactured by Kensington.

that colours which are reproduced by video equipment can be handled easily by computer operating systems (OS) and the Internet.

A type of video signal with a resolution of 800 (horizontal) x 600 (vertical) dots which is used by IBM PC/AT-compatible computers.

A video signal which has the luminance component and colour component separated in order to provide better image quality. It refers to images which consist of two independent signals: Y (luminance signal), and C (colour signal).

(vertical) dots which is used by IBM PC/AT-compatible computers.

The signals output from computers have a specific frequency. If the projector frequency does not match this frequency, the resulting images will not be of a good quality. The process of matching the phases of these signals (the relative position of the crests and troughs in the signal) is called "synchronisation". If the signals are not synchronized, problems such as flickering, blurriness and horizontal interference can occur.

The signals output from computers have a specific frequency. If the projector frequency does not match this frequency, the resulting images will not be of a good quality. The process of matching the frequency of these signals (the number of crests in the signal) is called "tracking". If tracking is not carried out correctly, wide vertical stripes will appear in the projected images.

connecting personal computers to peripheral devices which only support relatively low data transmission speeds.

UXGA

VGA A type of video signal with a resolution of 640 (horizontal) x 480

XGA A type of video signal with a resolution of 1024 (horizontal) x 768

YCbCr The carrier signal which is contained in the colour bar signal used in

YPbPr

A type of video signal with a resolution of 1600 (horizontal) x 1200 (vertical) dots which is used by IBM PC/AT-compatible computers.

(vertical) dots which is used by IBM PC/AT-compatible computers.

modern TV transmissions. The name comes from the Y (luminance) signal and the CbCr (chroma (colour)) signals.

The carrier signal which is contained in the colour bar signal used in high-definition TV (HDTV) transmissions. The name comes from the Y (luminance) signal and the PbPr (colour difference) signals.

List of ESC/VP21 Commands

Command List

When a power ON command is sent to the projector, the power for the projector turns on. When the projector is in a command ready state, it returns the "3Ah" (:) code. Furthermore, when command processing is complete, the projector also returns a ":" code. The ":" code status can be used to determine whether the projector is ready or busy. If command processing terminates with an error, an error message is output and then the ":" code is sent.

Item Command

Power ON/OFF

Signal selection

A/V Mute ON/OFF

A/V Mute Selection

OFF

Computer/Component Video (RGB)

Computer/Component Video (YCbCr)

Computer/Component Video (YPbPr)

Vid eo

S-Video

OFF

Black

Blue

User's Logo

PWR ON

PWR OFF

SOURCE 11

SOURCE 14

SOURCE 15

SOURCE 41

SOURCE 42

MUTE ON

MUTE OFF

MSEL 00

MSEL 01

MSEL 02

USB Connection Setup

In order to control the projector using ESC/VP21 commands, the projector must be connected to a computer by means of a USB cable. The following preparation needs to be carried out before communication via a USB connection can be carried out.

Procedure

Download the EMP Link21L utility software from the EPSON

web site.

For details on acquiring the software, please contact one of the service offices listed in the catalog.

The USB driver (USB-Com Driver) will be downloaded together

with the utility software, so install this USB driver into the computer that is to be used.

Refer to the EMP Link21L User's Guide that is downloaded together with the utility software for instructions on installing the USB driver.

Change the "Link 21L" setting in the "Advanced" menu to

"ON".

Turn off the power for the projector.

After the cool-down period has finished, turn the projector's

power back on.

Once the projector's power has turned back on, communication via a USB Connection will then be possible.

List of Supported Monitor Displays

Resolutions for

resized display

(dots)

Signal Refresh rate (Hz)

Resolution

(dots)

PC98 640×400 1024×640

EGA 640

VGA

60 640×480 1024×768

350 1024×560

VGACGA 640×400 1024×640

VGAEGA 640

VGA text

VESA 60/72/75/85,iMac

SVGA

XGA

56/60/72/75/85,iMac

43i/60/70/75/85,iMac

350 1024×560

400 1024×568

720

350 1024×498

640×480 1024×768

800×600 1024×768

1024×768 1024×768

SXGA 70/75/85 1152×864 1024×768

SXGA 60/75/85 1280

SXGA 43i/60/75/85 1280

UXGA

48i/60 1600×1200 1024×768

MAC13" 640

MAC16" 832

960 1024×768

1024 960×768

480 1024×768

624 1024×768

MAC19" 1024×768 1024×768

MAC19" 60 1024

MAC21" 1152

NTSC 640

PA L/ S EC A M 7 20

HDTV

(525i) 640×480 1024×768

768 1024×768

870 1016×768

480 1024×768

540 1024×768

HDTV(525p) 640×480 1024×768

HDTV(750p) 60 1280

HDTV(1125i) 60 1920

720 1024×576

1080 1024×576

* Connection is not possible if the equipment does not have a VGA output port.

It may be possible to project signals which are not listed in the above table. However, not all functions may be supportable with such signals.

Specifications

Product name Multimedia Projector EMP-730/720

Dimensions 276 (W) x 70 (H) x 190 (D) mm

Panel size 0.9 inches

Display method Polysilicon TFT active matrix

Drive method Full-line 12-phase block sequential writing

Resolution XGA

Focus adjustment Manual

Zoom adjustment Manual (approx. 1:1.16)

Lamp (light source)

Max. audio output

Speaker 1

Powe r supply

Operating Temperature

Storage Temperature

Weight Approx. 1.9 kg (4.2 lbs)

Connectors

* The USB connector is not guaranteed to operate correctly with all USB-

compatible devices.

(10.9 (W) x 2.8 (H) x 7.5 (D) in.) (not including feet)

786,432 pixels (1024 (W) x 768 (H) dots) x 3

UHE lamp, 150 W, Model No.: ELPLP18

1W monaural

100–120 V AC, 2.6A 200–240 V AC, 1.2A 50/60 Hz

+5º– +35ºC (41º–95ºF ) (No condensation)

-10º– +60ºC (14º–140ºF ) (No condensation)

Computer/Component Vid eo:

Audio-In: 1 Stereo mini jack

Composite Video: 1 RCA pin jack

S-Video: 1 Mini DIN 4-pin

USB: 1 USB connector (B series)

1 Mini D-Sub 15-pin (female)

Specifications

Safety

USA

UL1950 3

Edition

Canada

CSA C22.2 No.950-95 (cUL)

European Community

The Low Voltage Directive (73/23/EEC)

IEC60950 2

Edition, +Amd.1, +Amd.2, +Amd.3, +Amd.4

EMC

USA

FCC 47CFR Part15B Class B (DoC)

Canada

ICES-003 Class B

European Community

The EMC Directive (89/336/EEC)

EN55022, 1998 Class B EN55024, 1998

IEC61000-4-2, IEC61000-4-3, IEC61000-4-4, IEC61000-4-5, IEC61000-4-6, IEC61000-4-8, IEC61000-4-11, IEC61000-3-2, IEC61000-3-3

Australia/New Zealand

AS/NZS 3548:1995, A1:1997, A2:1997 Class B CISPR Pub.22:1993, A1:1995, A2:1996, Class B

Appearance

78.570

276

13.4

38.8

M3X8-3

103.5

70 15

89.9

190

124

Units: mm

Index

General Terms

13w3 port ....................................................19

5BNC port...................................................18

A/V Mute ..............................................42, 51

"About" Menu............................................. 54

"Advanced" Menu.......................................52

Air exhaust vent ............................................8

Air filter ........................................................8

Air intake vent...............................................8

Analogue-RGB .....................................46, 54

Aspect ratio.................................................44

"Audio" Menu............................................. 50

Audio-In port ..............................................10

Auto Keystone.......................................34, 51

Auto Setup ............................................37, 47

Battery holder .............................................74

Brightness .............................................47, 48

Ceiling...................................................14, 53

Cleaning the Air Filter................................73

Cleaning the Lens .......................................72

Cleaning the Projector Case........................72

Color Adjustment........................................53

Color Mode Prompt ....................................51

Color Mode .....................................40, 47, 49

Color temperature .......................................53

Color ........................................................... 48

Component video ........................................24

Composite video .........................................23

Computer/Component Video port...............10

Connecting to a Computer ..........................16

Connecting to a Video Source.....................23

Contrast .................................................47, 48

Control panel.................................................9

Cool-down.............................................31, 61

Cross............................................................45

Eligible computers ......................................16

ESC/VP21 ...................................................86

E-Zoom .......................................................45

Focus ring......................................................8

Focus ...........................................................37

Foot adjustment...........................................35

Freeze ..........................................................43

Frequency....................................................54

Front adjustable foot .....................................8

Glossary.......................................................83

HDTV..........................................................88

Help function...............................................60

Image size..............................................15, 33

Indicators.................................................8, 61

Input Signal .....................................47, 49, 54

Inserting the Battery....................................74

Keystone..........................................34, 36, 50

Lamp cover..................................................10

Lamp replacement period............................75

Lamp ...........................................................54

Language .....................................................52

Lens cover.....................................................8

Link21L ......................................................53

Main menu ..................................................46

Manually Correcting Keystone

Distortion ................................................36

Menu ...........................................................46

Mini D-Sub 15-pin port ..............................17

Mouse pointer .............................................21

No-Signal Msg............................................51

Operating distance (Remote control) ..........13

Operating range (Remote control)..............13

Operating temperature ................................89

Optional accessories ...................................82

Overheating.................................................62

Part Names and Functions ............................8

Port........................................................10, 30

Position ...........................................37, 47, 48

Power cable.............................................1, 28

Power indicator.............................................8

Power inlet ..................................................10

Projection angle ..........................................34

Projection distance......................................15

Projection ....................................................29

Prompt......................................................... 51

Remote control ................................11, 12, 21

Replacing the Air Filter...............................79

Replacing the Lamp ....................................76

"Reset All" Menu ........................................55

Reset Lamp Timer.................................54, 78

Resized display............................................88

Resolution .............................................55, 88

RGB.............................................................53

Screen size...................................................15

Security lock..................................................8

"Setting" Menu............................................50

Setting Up the Projector..............................14

Sharpness...............................................47, 48

Sleep mode ..................................................51

Speaker............................................10, 20, 26

Specifications ..............................................89

Squeeze mode..............................................44

sRGB ...............................................40, 47, 49

Startup screen..............................................52

Stereo mini jack audio cable .................20, 26

Storage temperature ....................................89

Sub-menu ....................................................46

Supported Monitor Displays .......................88

Suspension bracket fixing point ............10, 91

S-Video port ................................................10

S-Video............................................24, 48, 54

SYNC Mode................................................55

SYNC Polarity ............................................54

Sync.......................................................37, 47

RCA video cable .....................................1, 23

Rear Proj. ..............................................14, 53

Refresh Rate................................................55

Remote control light-emitting area ............. 11

Remote control light-receiving area........8, 10

Tint ..............................................................48

Tone .............................................................50

Tracking ................................................37, 47

Translucent screen.......................................14

Turning off...................................................31

Index

USB cable ...............................................1, 21

USB connection setup.................................87

USB mouse .................................................21

USB port .....................................................10

"User's Logo" Menu....................................52

User's Logo ...........................................42, 80

Using the Configuration Menu Functions... 46

"Video" Menu .............................................46

Video port.................................................... 10

Video Signal..........................................49, 54

Video Source...............................................54

Video.....................................................48, 54

Volume ........................................................50

Warning indicator..........................................8

When Having Some Trouble.......................61

Wide-screen Projection ...............................44

Wireless Mouse Function............................21

Workstation .................................................19

YCbCr .............................................30, 48, 54

YPbPr..............................................30, 48, 54

Zoom ring .....................................................8

DECLARATION of CONFORMITY

According to 47CFR, Part 2 and 15

Class B Personal Computers and Peripherals; and/or

CPU Boards and Power Supplies used with Class B

Personal Computers

We :EPSON AMERICA, INC. Located at :3840 Kilroy Airport Way

MS: 3-13 Long Beach, CA 90806

Tel :562-290-5254

Declare under sole responsibility that the product identified herein, complies with 47CFR Part 2 and 15 of the FCC rules as a Class B digital device. Each product marketed, is identical to the representative unit tested and found to be compliant with the standards. Records maintained continue to reflect the equipment being produced can be expected to be within the variation accepted, due to quantity production and testing on a statistical basis as required by 47CFR 2.909. Operation is subject to the following two conditions : (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Trade Name :EPSON

Type of Product :Projector

Model :EMP-730/720 /ELP-730/720

FCC Compliance Statement

For United States Users

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio or television reception. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause interference to radio and television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures.

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that

to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

WARNING

The connection of a non-shielded equipment interface cable to this equipment will invalidate the FCC Certification or Declaration of this device and may cause interference levels which exceed the limits established by the FCC for this equipment. It is the responsibility of the user to obtain and use a shielded equipment interface cable with this device. If this equipment has more than one interface connector, do not leave cables connected to unused interfaces. Changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment.

All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of SEIKO EPSON CORPORATION. No patent liability is assumed with respect to the use of the information contained herein. Neither is any liability assumed for damages resulting from the use of the information contained herein.

Neither SEIKO EPSON CORPORATION nor its affiliates shall be liable to the purchaser of this product or third parties for damages, losses, costs, or expenses incurred by purchaser or third parties as a result of: accident, misuse, or abuse of this product or unauthorized modifications, repairs, or alterations to this product, or (excluding the U.S.) failure to strictly comply with SEIKO EPSON CORPORATION’s operating and maintenance instructions.

SEIKO EPSON CORPORATION shall not be liable against any damages or problems arising from the use of any options or any consumable products other than those designated as Original EPSON Products or EPSON Approved Products by SEIKO EPSON CORPORATION.

EPSON is a registered trademark and PowerLite is a trademark of SEIKO EPSON CORPORATION.

General Notice: The following trademarks and registered trademarks are the property of their respective owners and are used in this publication for identification purposes only.

• EPSON/Seiko Epson Corp.

• Macintosh, PowerBook/Apple Computer Inc.

• IBM/International Business Machine Corp.

• Windows/Microsoft Corp.

Other product names used herein are also for identification purposes only and may be trademarks of their respective owners. EPSON disclaims any and all rights in those marks.

Printed on 100% recycled paper.

Printed in Japan

402529801

02.06-.9A(C05)

Epson EMP-730, EMP 720 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

About The Manuals and Notations Used

Unpacking the Projector

Features of the Projector

Contents

Before Using the Projector

Part Names and Functions

Front/Top

Control Panel

Rear

Base

Remote Control

Before Using the Remote Control

Using the Remote Control and Remote Operating Range

Installation

Setting Up the Projector

Screen Size and Projection Distance

Connecting to a Computer

Eligible Computers

Projecting Images from the Computer

Playing Sound from the Computer

Using the Remote Control to Operate the Mouse Pointer (Wireless Mouse Function)

Connecting to a Video Source

Projecting Composite Video Images

Projecting S-Video Images

Projecting Component Video Images

Projecting RGB Video Images

Playing Sound from the Video Equipment

Basic Operations

Turning On the Projector

Connecting the Power Cable

Turning On the Power and Projecting Images

Turning Off the Projector

Adjusting the Screen Image

Adjusting the Image Size

Adjusting the Image Angle and Automatic Keystone Correction Function

Manually Correcting Keystone Distortion

Adjusting the Image Quality

Focusing the Screen Image

Adjusting Computer Images

Selecting the Colour Mode

Advanced Operations

Functions for Enhancing Projection

A/V Mute

Freeze

Wide-screen Projection of Component Video and Video Images (Changing the Aspect Ratio)

E-Zoom

Using the Configuration Menu Functions

List of Functions

Using the Configuration Menus

Troubleshooting

Using the Help

When Having Some Trouble

Power indicator

(Warning) Indicator

When the Indicators Provide No Help

Appendices

Maintenance

Cleaning

Replacing Consumables

Saving a User's Logo

Optional Accessories

Glossary

List of ESC/VP21 Commands

Command List

USB Connection Setup

List of Supported Monitor Displays

Specifications

Appearance

Index
