Reliable Control Valve Solutions
Achieve greater success by partnering with Emerson
Reliable
Control
Valve
Solutions
n the day-to-day operation of your plant you have a long list of concerns, like
meeting production schedules, maintaining product quality, and improving the
I
efficiency of plant utilities, to name just a few. The last thing you should have to worry
about is the performance of your plant’s control valves. The answer to that concern is
Emerson.
Emerson wants to be your partner.
With Emerson, you’ll have the support of a global company with extensive international
engineering, research, sales, marketing, manufacturing, and service operations. Which
means you’ll have access to leading control valve and instrument technologies that
offer new levels of performance and reliability. Regardless of your industry. Regardless
of your location.
If you can’t count on your control valves, you can’t count on your process! That’s why
operations like yours have chosen Fisher
The Fisher digital valve provides you with real-time predictive intelligence,
not just numbers and graphs. So you will know there’s a problem and can
take action before your process is impacted! The Fisher digital valve is a
core component of Emerson’s PlantWeb
PlantWeb digital plant architecture uses open communication standards to link
intelligent field devices (like the Fisher digital valve), automation systems, and
applications in a plantwide network. Operations can run production with greater
confidence in automation as they tune the process for optimal throughput, quality,
and availability while reducing the overall cost of operations.
®
final control capabilities.
™
digital plant architecture.
2
Whatever your control valve challenge, we can get it done!
Technology Leader
All products bearing the Fisher logo have one thing in
common: differentiating technologies. Technologies
that are the result of industry expertise, research,
creativity and a 130-plus year tradition of answering
control valve needs.
We know the process industries well. We are familiar
with your people and facilities. In fact, millions of
dollars of research are invested annually in solving the
control valve issues that are important to you.
When we say a Fisher product will do the job for your
application, we mean it. We design and manufacture
Fisher control valves and instruments according to
industry codes and standards and prove our products
in our own research and engineering facilities. Nothing
is based on chance.
When you own a Fisher product, you can feel
confident that it will operate reliably and will deliver
the performance you expect.
Backed By Research
We operate flow loops that can duplicate actual
dynamic flow conditions encountered in the
processing industries. These research findings
are utilized in the development and refinement
of Fisher control valves. Our global capabilities
for validating control valve performance are
unmatched in the industry. Fisher research and
engineering capabilities extend worldwide with
engineers and labs in North America, Europe, and
Asia. We can help you schedule a visit to our labs.
The Right Materials
Understanding materials allows
us to know their application
limits in various processes, which
benefits you. Emerson has a fullyequipped materials lab that helps
ensure that Fisher products deliver
excellent performance.
3
Industries
Delivering Results
Served
uring the last 130-plus years, the industries that use control valves have grown
in number, in capacity, and in sophistication. We have played a part in their
D
growth by developing control valves to meet ever-changing requirements. Below are
some examples of how we serve customers around the world.
Hydrocarbon
Upstream - The Long Lake Oil Sands Extraction Project in Alberta, Canada, specified
Fisher valves with Fisher FIELDVUE
efficiency and economics of oil sands processing.
™
digital valve controllers to help improve the
Refining - The Schwechat refinery, located in Vienna, Austria, specified over 8,000
Fisher control valves to help process nine million metric tons of crude oil per year.
Offshore/Marine - BP Angola specified Fisher products to automate the floating
production, storage, and offloading vessel that will develop the Greater Plutonio
Deepwater offshore oil fields of Angola, Africa.
Liquefied Natural Gas - Twenty-five Fisher optimized antisurge control valves will
provide reliable surge protection for five critical compressor trains in an LNG facility
in Brunei.
Chemical
Nantong Cellulose Fibers Co., Ltd. specified Fisher digital valves for its acetic acid unit
located in the Jiangsu province of China.
Power
ENELPOWER specified 69 Fisher digital valves for ENEL Production’s Sulcis power plant
on the island of Sardinia near Italy.
Taiwan Power Company specified over 600 Fisher digital valves as key balance of plant
and containment vessel control devices within a 2,700 megawatt nuclear power plant
to be constructed near Taipai.
4
Pulp and Paper
Caraustar’s paperboard mill in Connecticut, United
States, is using Fisher products to achieve full
automation of its 525-tons-per-day mill.
Food and Beverage
A Danish food processor, Aarhus United, specified
Fisher digital valves to help produce a wide range of
specialty vegetable oils.
Industries Served
Metals and Mining
BHP Billiton’s nickel/cobalt mine in Ravensthorpe,
Australia, specified Emerson’s products for digital
automation and control of minerals processing.
Life Sciences
Celltrion, Inc. specified Fisher and Baumann™ control
valves with Fisher FIELDVUE digital valve controllers
for its biopharmaceutical manufacturing facility in
South Korea.
Semiconductor
Industry-leading semiconductor manufacturers around
the world rely on Baumann and Fisher control valves
in their cleanroom HVAC systems. Baumann patented
low-flow, corrosion-resistant lined valves are specified
for precise Ph control in their water tower systems.
5
SlidingStem
Control
Valves
e have the broadest
Products That Deliver
W
control valves available anywhere
in a variety of construction
materials, flow characteristics, and
end connections. Complementary
actuators and accessories are
also available. Popular sliding-
stem valve product lines include:
Fisher easy-e™ globe valves and
Baumann valves.
range of sliding-stem
Universal -
Fisher easy-e valve line popularized
the concept of one valve body with
interchangeable trim. Can be used
effectively, plantwide, in a number of
applications.
High Pressure, High Flow -
Built-to-last design with rugged cage
guiding and hardened trim materials.
Fisher ENVIRO-SEAL
packing systems in the valve provide
a tight stem seal for fugitive
emissions control.
6
™
and HIGH-SEAL
Steam Conditioning -
Enhanced pressure reduction
capabilities as well as highly efficient
and accurate steam conditioning
performance in a single valve.
Provides the ultimate
combination of performance
and maintainability.
Sliding-Stem Control Valves
Chemical and General Service -
Unmatched innovation, technology,
and reliability. Compact size, anticorrosion finish, certified emission
control packing and integrated digital
technology.
Environmental Requirements -
Fisher ENVIRO-SEAL valve packing
systems are designed to control
emissions below 100 ppmv. Provide
extended service life.
Utility and Low Flow Service -
Compact, low-weight Baumann
control valves help ensure reduced
installation and maintenance costs.
Designs include patented low
flow technology and exceptional
deadband and hysteresis
characteristics.
Sweet or Sour Oil and Gas
Applications - Special deep-bore
hammer nut for increased safety.
Fisher Micro-Form valve plug is sour
gas compatible. Fisher easy-Drive
electric actuator was designed
to protect the environment from
methane gas venting.
Sanitary -
Designed to satisfy the stringent
demands of the pharmaceutical and
biotechnology industries. Includes
FDA, USP CLVI, and 3A Sanitary
Standards, Inc. certifications.
High-Pressure Gas Service -
Innovative Fisher FloPro selectable
flow rate feature. Designed for high-
™
pressure separators, scrubbers, and
other gas processing equipment.
7
Rotary
Control
Valves
Meeting Control Needs
hen capacity and
W
requirements, the Fisher line of
rotary valves is the answer. Popular
rotary valve products include ball,
eccentric disc, eccentric plug, and
butterfly valves with such familiar
tradenames as Vee-Ball
Control-Disk.
performance are the
™
and
™
Proven Performance -
Fisher Vee-Ball control valves feature
the Fisher-pioneered V-notch ball
for nonclogging, high capacity flow
control. Designed for gas, steam,
liquids and fibrous slurries
where reducing process
variability is a must.
Hard-to-Handle Fluids -
Fisher V500 and CV500 control
valves offer low operating torque and
combine the ruggedness of a globe
valve with the efficiency of a rotary
valve. Well suited to erosive,
coking and other hard-tohandle fluids.
8
High Performance -
Fisher 8580 control valves are
reliable, high performance butterfly
valves suitable for throttling
applications that require extremely
low leakage rates.
Rotary Control Valves
Wide Control Range -
Fisher Control-Disk valves have
a wide control range and offer
excellent throttling performance
to control closer to target set
point, regardless of process
disturbances.
Tight Shutoff -
Fisher POSI-SEAL™ valves survive in
extreme pressure and temperature
conditions. Exceptional shutoff rates
with birdirectional soft seal ring.
Special Fisher NOVEX and
Phoenix III metal seals offer
added shutoff capabilities.
Pipeline Control -
Designed from the ground up with
features for optimized pressure, flow,
and process control. Used in gas and oil
flow streams. Special Fisher
or Hydrodome attenuators reduce
noise and cavitation effects that cause
pipeline vibration.
Aerodome
Automated On-Off Performance -
Fisher A81 rotary valves with FieldQ™
rack-and-pinion actuators offer
automated on-off, quarter-turn
performance and feature either a soft
or metal seal for enhanced
shutoff.
9
Field
Instruments
and Valve
Accessories
Controlling Valves and the Process
wide selection of Fisher
A
digital, pneumatic and
electronic instruments control
valve position and variables such
as level, pressure, or temperature.
Popular Fisher products include:
FIELDVUE digital valve controllers,
FIELDVUE digital level transmitters,
ValveLink™ software, and pressure
and temperature controllers.
Digital Valve Controller -
The Fisher FIELDVUE digital valve
controller family has powerful
diagnostic capabilities. Patented
modular design and minor loop
feedback.
10
Digital Valve Controller -
Non-contact, linkage-less travel
feedback and local user interface
with LCD and four pushbuttons for
menu navigation. Powerful FIELDVUE
diagnostic capabilities.
Valve Diagnostics Software -
ValveLink software is the
configuration, calibration, and
diagnostic tool used with FIELDVUE
Instrumentation. It uses predictive
intelligence to improve the
availability and performance of
control valves.
Field Instruments and Valve Accessories
Wireless Position Monitor -
Volume Booster -
Wireless Position Monitor -
Rugged, reliable, easy-to-use
measurement device that monitors
equipment position with a percent of
span plus on/off indication.
Electro-Pneumatic Transducer -
Special free-flow design resists
plugging. Approved for use with
natural gas as the supply medium.
Digital Level Transmitter -
Provides installation flexibility.
Built-to-last design. HART
F
OUNDATION
bringing digital advantages to liquid
level control.
™
fieldbus certified,
®
and
Liquid Level Controller -
Designed for controlling level on
gas separators and scrubbers. Sour
gas service ready. Low bleed relays
conserve energy and reduce impact
on the environment.
Pressure Controller -
Offers long-lasting dependability.
Simply constructed. Can reduce
steady-state air/gas consumption
to as little as 1/10th that of other
products.
Volume Booster -
Used in conjuction with a positioner
on a throttling control valve to
increase stroking speed. Connectors
and piping can be installed for
diagnostic testing.
11
Severe
III trim contains a multitude
Meeting Your Needs
Service
Solutions
or decades, we have been
F
providing solutions for
severe service control valve
applications in the power and
hydrocarbon industries. Special
control problems—either
anticipated or existing—that
involve extremes in temperature,
pressure, corrosion, erosion,
noise, flashing or cavitation, have
a Fisher valve solution.
Cavitating Liquid -
Cavitrol™ III trim contains a multitude
of specially shaped holes that reduce
flow turbulence. The holes are
radially aligned to flow from one
restriction to another. Both features
dissipate the fluid pressure and
prevent cavitation.
12
Outgassing -
Dirty Service Trim for Outgassing
(DST-G) is used in services where
the fluid has dissolved gases that
are released from solution due to a
reduction in pressure. DST-G trim
allows large 6.35 mm (¼-inch)
particulate to pass.
Drilled Hole Noise Trim -
Whisper Trim™ III is a drilled hole
trim available in a variety of control
valve sizes and styles. It delivers
excellent noise reduction. The design
architecture even allows for flexibility
of size, pressure class, materials,
rangeability, and attenuation.
Severe Service Solutions
DST trim uses a series of
trim offers state-of-
Cavitating Dirty Flow -
NotchFlo™ DST trim uses a series of
flow restrictions and expansions to
control the pressure drop of the fluid.
The notched plug allows up to 12 mm
(½-inch) particulate to flow through
the trim without plugging.
Stacked Disk Noise Trim -
WhisperFlo™ trim offers state-of-
the-art noise attenuation in vapor,
gas, or steam applications involving
high pressure drops. It is a laser cut,
stacked-disk cage assembly that is
available in globe and angle bodies
for the most severe applications.
Cavitating Dirty Flow, Customized -
Dirty Service Trim (DST) provides
cavitation-control for applications
with entrained particulate. It uses a
combined axial and radial flow path
that features large openings allowing
particulate up to 19 mm (¾-inch) in
diameter to pass through the valve.
Slotted Noise Trim -
Whisper Trim I offers proven
attenuation of aerodynamic noise
in vapor, gas, or steam applications
involving low to medium pressure
drops. It offers economical,
dependable noise attenuation. It
offers great application flexibility.
Large Pressure Drops -
Each of the Cavitrol IV trim stages
has a successively large flow area.
The results is very efficient operation
because more than 90 percent of
the overall pressure drop is taken in
the initial stages where there is little
danger of cavity formation.
Diffusers -
The 6010 inline diffuser places
back pressure on the control valve,
thereby reducing the turbulence and
pressure drop across the valve, which
are main contributors in damaging
noise and vibration.
13
Capabilities
Global Reach, Local Service
That Serve
You
ne thing all control valve buyers have in common
is a desire to know as much as possible about their
O
prospective purchase and the company that manufactures it.
Fisher valve operations started in 1880 in Marshalltown, Iowa,
United States. Since then, Fisher valve operations have grown
to employ more than 3,700 people worldwide. We’re the
largest control valve and regulator manufacturer in the world.
Manufacturing
To meet local product and delivery needs, Fisher
manufacturing plants are located in each world area. Each
manufacturing site is tied directly to Fisher product design
centers via the latest communication links, helping ensure that manufacturing
operations utilize the most up-to-date product information. This means that each
Fisher
product meets design specifications and performs as intended, regardless of
where its individual or component parts were manufactured.
14
Application Assistance
Control valves are an investment, so you want to speak with someone one-on-one
who knows about you and your business. The Emerson sales network has extensive
application experience and can recommend the most suitable products for your
application. Because of the technical nature of the Fisher product line, most of
the Emerson network are graduate engineers with substantial factory training. At
Emerson, we’ve built our reputation not just on our quality Fisher
on our people and their dedication to service. Wherever you are, there’s an Emerson
salesperson to discuss your control needs.
Sizing and Specification
Fisher Specification Manager software is available through your local salesperson. The
software offers a powerful set of tools for quickly producing an ISA specification sheet,
improving noise prediction calculations and exporting dimensional data for Fisher and
Baumann control valves. You’ll find it easy to learn and use.
Serving You for the Life of Your Plant
For nearly 40 years, Emerson has been a provider of trusted expertise for reliabilitycentered control valve maintenance. A network of service centers, manufacturing sites,
and sales representatives puts experienced professionals where and when they are
needed. Highly skilled technicians provide cost effective maintenance, valve reliability,
and increased process availability through flexible, local service.
products, but also
OEM Replacement Parts
The Emerson manufacturing network supports Fisher
parts needs in any emergency. The integrated sales
channel and business partner networks offer a local
point of customer contact with delivery of process
control application knowledge and complimentary
capabilities. Flexible deployment of highly skilled,
factory-trained Emerson technicians strategically
located near customer process plants provide repair
capabilities for all types of control valves and associated
field instruments. Emerson’s comprehensive quick
ship programs, along with a supporting distribution
network of process control products and spare parts,
guarantee immediate response to customer needs.
Capabilities that Serve You
Diagnostic Services
When precision is critical to keep your process in
peak performance, you need your valves to perform
to industry and factory specifications. Emerson’s
skilled, certified field technicians carefully analyze
control valves using diagnostic services to identify
maintenance priorities and develop a proactive plan
detailing when devices should be repaired or replaced
with next generation technologies. After diagnostic
service, technicians produce a clear report indicating
asset health, areas of potential risks, and a prioritized
recommend action plan.
Training
Today, the need for training is more critical than
ever to achieve and maintain cost-effective process
operations. So whether it’s at your site, our site, or the
website, we work hard to ensure you know how to get
the best from your Fisher products through a selection
of valve and instrument training courses.
Documentation
Engineering requirements behind Fisher products
necessitate a great many product bulletins,
instruction manuals, and sales brochures.
These documents are available from sales
locations. Or you can view them in PDF format at
www.EmersonProcess.com/Fisher/Documentation.
15
This mark indicates a core
component of Emerson’s
PlantWeb digital plant
architecture.
http://www.Facebook.com/FisherValves
http://www.Twitter.com/FisherValves
Emerson Process Management
Marshalltown, Iowa 50158 USA
Sorocaba, 18087 Brazil
Chatham, Kent ME4 4QZ UK
Dubai, United Arab Emirates
Singapore 128461 Singapore
www.EmersonProcess.com/Fisher
http://www.YouTube.com/user/FisherControlValve
http://www.LinkedIn.com/groups/Fisher-3941826
© 2005, 2012 Fisher Controls International LLC. All rights reserved.
Fisher, PlantWeb, FIELDVUE, easy-e, Baumann, ENVIRO-SEAL, easy-Drive, Vee-Ball, Control-Disk,
POSI-SEAL, FieldQ, ValveLink, Wizard, Cavitrol, Whisper Trim, NotchFlo, and WhisperFlo are marks
owned by one of the companies in the Emerson Process Management business unit of Emerson Electric
Co. Emerson Process Management, Emerson, and the Emerson logo are trademarks and service marks
of Emerson Electric Co. All other marks are the property of their respective owners.
The contents of this publication are presented for informational purposes only, and while every
effort has been made to ensure their accuracy they are not to be construed as warranties or
guarantees, express or implied, regarding the products or services described herein or their use
or applicability. All sales are governed by our terms and conditions, which are available upon
request. We reserve the right to modify or improve the designs or specifications of such products
at any time without notice. Neither Emerson, Emerson Process Management, nor any of their
affiliated entities assumes responsibility for the selection, use, or maintenance of any product.
Responsibility for proper selection, use, and maintenance of any product remains solely with the
purchaser and end user.
D351199X012 / MY39 (H:) / Feb12
Loading...
