EN Operating instructions
Cordless Hammer Drill
FR Mode d’emploi
Perceuse à percussion sans fi l
SP Manual de instrucciones
Taladro de impacto inalámbrico
TC-ID 18 Li
7
Art.-Nr.: 4513961 I.-Nr.: 21022
Anl_TC_ID_18_Li_SPK7_USA.indb 1Anl_TC_ID_18_Li_SPK7_USA.indb 1 22.04.2022 11:04:0922.04.2022 11:04:09
1
1
2 3
6
4
5
7
2
1
7
Anl_TC_ID_18_Li_SPK7_USA.indb 2Anl_TC_ID_18_Li_SPK7_USA.indb 2 22.04.2022 11:04:1022.04.2022 11:04:10
3
7
- 2 -
4 5
2
7
6
1.
8
2.
8
7
6
5
9
1
4
3
B
Anl_TC_ID_18_Li_SPK7_USA.indb 3Anl_TC_ID_18_Li_SPK7_USA.indb 3 22.04.2022 11:04:1422.04.2022 11:04:14
A
- 3 -
9
10
8
10
12
4536
104°F
(+40°C)
50°F
(+10°C)
- 4 -
Anl_TC_ID_18_Li_SPK7_USA.indb 4Anl_TC_ID_18_Li_SPK7_USA.indb 4 22.04.2022 11:04:1722.04.2022 11:04:17
EN
DANGER!
When using the equipment, a number of safety
precautions must be observed to avoid injuries
and damage. Please read the complete operating
instructions and safety information with due care.
Keep these operating instructions in a safe place
so that the information is available at all times. If
you give the equipment to any other person, hand
over these operating instructions and the safety
information as well. We cannot accept any liability
for damage or accidents which arise due to
failure to follow these instructions and the safety
information.
1. Safety information
DANGER!
Read all the safety information and
instructions. Failure to adhere to the safety
information and instructions set out below
may result in electric shock, fi re and/or serious
injury. Keep all the safety information and
instructions in a safe place for future use.
General safety information for power tools
The term “power tool“ used in the safety
regulations refers to power tools operated from
the mains power supply (with a power cable) and
to battery operated power tools (without a power
cable).
1) Work area safety
a) Keep work area clean and well lit.
Cluttered and dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
fl ammable liquids, gases or dust. Power
tools create sparks which may ignite the dust
or fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can
cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet.
Never modify the plug in any way. Do
not use any adapter plugs with earthed
(grounded) power tools. Unmodifi ed plugs
and matching outlets will reduce risk of
electric shock.
b) Avoid body contact with earthed or
grounded surfaces such as pipes,
radiators, ranges and refrigerators. There
is an increased risk of electric shock if your
body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the cord. Never use the
cord for carrying, pulling or unplugging
the power tool. Keep cord away from
heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the
risk of electric shock.
e) When operating a power tool outdoors,
use an extension cord suitable for
outdoor use. Use of a cord suitable for
outdoor use reduces the risk of electric
shock.
f) If operating a power tool in a damp
location is unavoidable, use a ground
fault circuit interruptor (GFCI) protected
supply. Use of an GFCI reduces the risk of
electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and
use common sense when operating a
power tool. Do not use a power tool while
you are tired or under the infl uence of
drugs, alcohol or medication. A moment of
inattention while operating power tools may
result in serious personal injury.
b) Use personal protective equipment.
Always wear eye protection. Protective
equipment such as dust mask, non-skid
safety shoes, hard hat, or hearing protection
used for appropriate conditions will reduce
personal injuries.
c) Prevent unintentional starting. Ensure
the switch is in the Off -position before
connecting to power source and/or
BATTERY pack, picking up or carrying the
tool. Carrying power tools with your fi nger on
the switch or energizing power tools that have
the switch on invites accidents.
d) Remove any adjusting key or wrench
before turning the power tool on. A wrench
or a key left attached to a rotating part of the
power tool may result in personal injury.
e) Do not overreach. Keep proper footing
and balance at all times. This enables
better control of the power tool in unexpected
situations.
f) Dress properly. Do not wear loose
clothing or jewellery. Keep your hair,
clothing and gloves away from moving
parts. Loose clothes, jewelery or long hair
- 5 -
Anl_TC_ID_18_Li_SPK7_USA.indb 5Anl_TC_ID_18_Li_SPK7_USA.indb 5 22.04.2022 11:04:1722.04.2022 11:04:17
EN
can be caught in moving parts.
g) If devices are provided for the connection
of dust extraction and collection facilities,
ensure these are connected and properly
used. Use of these devices can reduce dust
related hazards.
h) Do not let familiarity gained from frequent
use of tools allow you to become
complacent and ignore tool safety
principles. A careless action can cause
severe injury within a fraction of a second.
4) Power tool use and care
a) Do not force the power tool. Use the
correct power tool for your application.
The correct power tool will do the job
better and safer at the rate for which it was
designed.
b) Do not use the power tool if the switch
does not turn it on and off . Any power tool
that cannot be controlled with the switch is
dangerous and must be repaired.
c) Disconnect the plug from the power
source and/or remove the battery pack,
if detachable, from the power tool before
making any adjustments, changing
accessories, or storing power tools. Such
preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach
of children and do not allow persons
unfamiliar with the power tool or these
instructions to operate the power tool.
Power tools are dangerous in the hands of
untrained users.
e) Maintain power tools and accessories.
Check for misalignment or binding of
moving parts, breakage of parts and
any other condition that may aff ect the
power tool’s operation. If damaged, have
the power tool repaired before use. Many
accidents are caused by poorly maintained
power tools.
f) Keep cutting tools sharp and clean.
Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are
easier to control.
g) Use the power tool, accessories and
tool bits etc., in accordance with
these instructions and in the manner
intended for the particular type of power
tool, taking into account the working
conditions and the work to be performed.
Use of the power tool for operations diff erent
from intended could result in a hazardous
situation.
h) Keep handles and grasping surfaces
dry, clean and free from oil and grease.
Slippery handles and grasping surfaces do
not allow for safe handling and control of the
tool in unexpected situations.
5) Battery tool use and care
a) Recharge only with the charger specifi ed
by the manufacturer. A charger that is
suitable for one type of battery pack may
create a risk of fi re when used with another
battery pack.
b) Use power tools only with specifi cally
designated battery packs. Use of any other
battery packs may create a risk of injury and
fi re.
c) When battery pack is not in use, keep it
away from other metal objects, like paper
clips, coins, keys, nails, screws or other
small metal objects that can make a
connection from one terminal to another.
Shorting the battery terminals together may
cause burns or a fi re.
d) Under abusive conditions, liquid may be
ejected from the battery; avoid contact.
If contact accidentally occurs, fl ush with
water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from the
battery may cause irritation or burns.
e) Do not use a BATTERY pack or tool that
is damaged or modifi ed. Damaged or
modifi ed batteries may exhibit unpredictable
behavior resulting in fi re, EXPLOSION or risk
of injury.
f) Do not expose a BATTERY pack or tool to
fi re or excessive temperature. Exposure to
fi re or temperature above 266°F (130°C) may
cause explosion.
g) Follow all charging instructions and do
not charge the BATTERY pack or tool
outside the temperature range specifi ed
in the instructions. Charging improperly or
at temperatures outside the specifi ed range
may damage the BATTERY and increase the
risk of fi re.
6) Service
a) Have your power tool serviced by a
qualifi ed repair person using only
identical replacement parts. This will
ensure that the safety of the power tool is
maintained.
b) Never service damaged BATTERY packs.
Service of BATTERY packs should only be
- 6 -
Anl_TC_ID_18_Li_SPK7_USA.indb 6Anl_TC_ID_18_Li_SPK7_USA.indb 6 22.04.2022 11:04:1722.04.2022 11:04:17
EN
performed by the manufacturer or authorized
service providers.
Additional safety instructions
We pay a great deal of attention to the design
of every battery pack to ensure that we supply
you with batteries which feature maximum
power density, durability and safety. The battery
cells have a wide range of safety devices.
Each individual cell is initially formatted and its
electrical characteristic curves are recorded.
These data are then used exclusively to be able
to assemble the best possible battery packs.
Despite all the safety precautions, caution
must always be exercised when handling
batteries. The following points must be
obeyed at all times to ensure safe use.
Safe use can only be guaranteed if
undamaged cells are used. Incorrect
handling can cause cell damage.
Caution! Analyses confi rm that incorrect use and
poor care are the main causes of the damage
caused by high performance batteries.
Information about the battery
1. The battery pack supplied with your cordless
tool is not charged. The battery pack has to
be charged before you use the tool for the fi rst
time.
2. For optimum battery performance avoid low
discharge cycles. Charge the battery pack
frequently.
3. Store the battery pack in a cool place, ideally
at 59°F (15°C) and charged to at least 40%.
4. Lithium-Ion batteries are subject to a natural
ageing process. The battery pack must be
replaced at the latest when its capacity
falls to just 80% of its capacity when new.
Weakened cells in an aged battery pack are
no longer capable of meeting the high power
requirements and therefore pose a safety risk.
5. Do not throw battery packs into an open fi re.
There is a risk of explosion!
6. Do not ignite the battery pack or expose it to
fi re.
7. Do not exhaustively discharge batteries.
Exhaustive discharge will damage the battery
cells. The most common cause of deep
discharge is lengthy storage or non-use of
partly discharged batteries. Stop working as
soon as the performance of the battery falls
noticeably or the electronic protection system
triggers. Place the battery pack in storage
only after it has been fully charged.
8. Protect batteries and the tool from
overloads. Overloads will quickly result
in overheating and cell damage inside the
battery housing without this overheating
actually being apparent externally.
9. Avoid damage and shocks. Replace
batteries which have been dropped from
a height of more than one meter or which
have been exposed to violent shocks without
delay, even if the housing of the battery pack
appears to be undamaged. The battery cells
inside the battery may have suff ered serious
damage. In this respect, please also read the
waste disposal information.
10. If the battery pack suff ers overloading and
overheating, the integrated protective cutoff will switch off the equipment for safety
reasons. Caution! Do not press the ON/OFF
switch any more if the protective cut-off has
actuated. This may damage the battery.
11. Use only original battery packs. The use
of other batteries may result in injuries,
explosion and a fi re risk.
12. Protect your rechargeable battery against
moisture, rain and high humidity. Moisture,
rain and high humidity can cause dangerous
cell damage. Never charge or work with
batteries which have been exposed to
moisture, rain or high humidity – replace them
immediately.
13. If your equipment is fi tted with a detachable
battery, remove the battery for safety reasons
after you have fi nished your work.
Information on chargers and the charging
process
1. Please check the data marked on the rating
plate of the battery charger. Be sure to
connect the battery charger to a power supply
with the voltage marked on the rating plate.
Never connect it to a diff erent mains voltage.
2. Protect the battery charger and its cable from
damage and sharp edges. Have damaged
cables repaired without delay by a qualifi ed
electrician.
3. Keep the battery charger, batteries and the
cordless tool out of children‘s reach.
4. Do not use damaged battery chargers.
5. Do not use the supplied battery charger to
charge other cordless tools.
6. In heavy use the battery pack will become
warm. Allow the battery pack to cool to room
temperature before commencing with the
charging.
7. Do not over-charge batteries. Do not
- 7 -
Anl_TC_ID_18_Li_SPK7_USA.indb 7Anl_TC_ID_18_Li_SPK7_USA.indb 7 22.04.2022 11:04:1722.04.2022 11:04:17
EN
exceed the maximum charging times. These
charging times apply only to discharged
batteries. Frequent insertion of a charged
or partly charged battery pack will result in
over-charging and cell damage. Do not leave
batteries in the charger for more than 48
hours.
8. Never use or charge batteries if you
suspect that the last time they were
charged was more than 12 months
previously. There is a high probability
that the battery pack has already suff ered
dangerous damage (exhaustive discharge).
9. Charging batteries at a temperature below
50°F (10°C) will cause chemical damage to
the cell and may cause a fi re.
10. Do not use batteries which have heated
during the charging process, as the battery
cells may have suff ered dangerous damage.
11. Do not use batteries which have suff ered
curvature or deformation during the charging
process or which show other non-typical
symptoms (gassing, hissing, cracking,…)
12. Never fully discharge the battery pack
(recommended depth of discharge max.
80%) A complete discharge of the battery
pack will lead to premature ageing of the
battery cells.
13. Never charge the batteries unsupervised.
Protection from environmental infl uences
1. Wear suitable work clothes. Wear safety
goggles.
2. Protect your cordless tool and the battery
charger from moisture and rain. Moisture
and rain can cause dangerous cell damage.
3. Do not use the cordless tool or the battery
charger near vapors and infl ammable liquids.
4. Use the battery charger and cordless tools
only in dry conditions and an ambient
temperature of 50°F to 104°F (10°C to 40°C).
5. Do not keep the battery charger in places
where the temperature is liable to reach over
104°F (40°C). In particular, do not leave the
battery charger in a car that is parked in the
sunshine.
6. Protect batteries from overheating.
Overloads, over-charging and exposure to
direct sunlight will result in overheating and
cell damage. Never charge or work with
batteries which have been overheated –
replace them immediately if possible.
7. Storage of batteries, battery chargers
and cordless tools. Store the charger and
your cordless tool only in dry places with an
ambient temperature of 50°F to 104°F (10°C
to 40°C). Store the Lithium-Ion rechargeable
battery in a cool and dry place at 50°F to 68°F
(10°C to 20°C). Protect them from humidity
and direct sunlight! Place only fully charged
batteries in storage (charged at least 40%).
8. Prevent the Lithium-Ion battery pack from
freezing. Battery packs which were stored
below 32°F (0°C) for more than 60 minutes
must be disposed of.
9. When handling batteries beware of
electrostatic charge: Electrostatic discharges
cause damage of the electronic protection
system and the battery cells. Avoid
electrostatic charging and never touch the
battery poles.
Battery Caution + Disposal
Disposal
Should your appliance need replacement after
extended use, do not dispose of it with the
household refuse, but in an environmentally safe
way.
Waste produced by electrical machine
items should not be handled like normal
household rubbish. Please recycle where
recycle facilities exist. Check with your local
authority or retailer for recycling advice.
Always dispose of your battery pack according
to federal, state, provincial and local regulations.
Contact a recycling agency in your area for recycling
locations.
CAUTION! Even discharged battery packs
contain some energy. Before disposing, use
electrical tape to cover the terminals to prevent
the battery pack from shorting, which could cause
a fi re or explosion.
WARNING! To reduce the risk of injury or
explosion, never burn or incinerate a battery
pack even if it is damaged, dead, or completely
discharged. When burned, toxic fumes and
materials are emitted into the surrounding
atmosphere.
1. Batteries vary according to device. Consult
your manual for specifi c information.
2. Install only new batteries of the same type in
your product (where applicable).
3. Failure to insert batteries in the correct
polarity, as indicated in the battery
compartment or manual, may shorten the life
of the batteries or cause batteries to leak.
4. Do not mix old and new batteries.
5. Do not mix Alkaline, Standard (Carbon-Zinc),
- 8 -
Anl_TC_ID_18_Li_SPK7_USA.indb 8Anl_TC_ID_18_Li_SPK7_USA.indb 8 22.04.2022 11:04:1722.04.2022 11:04:17
EN
or Rechargeable (Nickel Cadmium, Nickel
Metal Hydride, or Lithium-Ion) batteries.
6. Do not dispose of batteries in fi re.
7. Batteries should be recycled or disposed of
as per state, provincial and local guidelines.
When shipping or disposing of batteries and
cordless tools, always ensure that they are
packed individually in plastic bags to prevent
short circuits and fi res.
Safety information for hammer drills
1) Safety instructions for all operations
a) Wear ear protection when hammer
drilling. Exposure to noise can cause
hearing loss.
b) Use the auxiliary handle(s). Loss of control
can cause personal injury.
c) Hold the power tool by insulated gripping
surfaces, when performing an operation
where the cutting accessory or fasteners
may contact hidden wiring or its own
cord. Cutting accessory or fasteners
contacting a “live” wire may make exposed
metal parts of the power tool “live” and could
give the operator an electric shock.
Safety Instruction when using long drill bits
a) Never operate at higher speed that the
maximum speed rating of the drill bit.
At higher speeds, the bit is likely to bend if
allowed to rotate freely without contacting the
workpiece, resulting in personal injury.
b) Always start drilling at low speed and
with the bit tip in contact with the
workpiece. At higher speeds, the bit is likely
to bend if allowed to rotate freely without
contacting the workpiece, resulting in
personal injury.
c) Apply pressure only in direct line with the
bit and do not apply excessive pressure.
Bits can bend causing breakage or loss of
control, resulting in personal injury.
SAVE THESE INSTRUCTIONS
Explanation of the symbols used (see Fig. 10)
1. Danger! - Read the operating instructions to
reduce the risk of injury.
2. Caution! Wear ear-muff s. The impact of
noise can cause damage to hearing.
3. Caution! Wear a breathing mask. Dust
which is injurious to health can be generated
when working on wood and other materials.
Never use the device to work on any
materials containing asbestos!
4. Caution! Wear safety goggles. Sparks
generated during working or splinters, chips
and dust emitted by the device can cause
loss of sight.
5. To avoid damaging the gearbox, the drill /
hammer drill selector switch should only be
moved when the machine is at a standstill.
6. Store the batteries only in dry rooms with an
ambient temperature of 50°F to 104°F (+10°C
to +40°C). Place only fully charged batteries
in storage (charged at least 40%).
2. Layout and items supplied
2.1 Layout
1. Quick-change drill chuck
2. Depth stop
3. Drill/hammer drill selector switch
4. Lock button
5. On/Off switch
6. Changeover switch
7. Additional handle
8. Pushlock button
9. Battery capacity indicator
10. Battery capacity indicator button
2.2 Items supplied
Please check that the article is complete as
specifi ed in the scope of delivery. If parts are
missing, please contact our service center or the
store where you made your purchase at the latest
within 5 work days after purchasing the article and
upon presentation of a valid bill of purchase.
Open the packaging and take out the
•
equipment with care.
Remove the packaging material and any
•
packaging and/or transportation braces (if
present).
Check to see if all the items are supplied.
•
Inspect the equipment and accessories for
•
transport damage.
If possible, keep the packaging until the end
•
of the guarantee period.
Danger!
The equipment and packaging material are
not toys. Do not let children play with plastic
bags, plastic sheets and small parts. There is
a risk of choking and suff ocating!
- 9 -
Anl_TC_ID_18_Li_SPK7_USA.indb 9Anl_TC_ID_18_Li_SPK7_USA.indb 9 22.04.2022 11:04:1722.04.2022 11:04:17
Cordless Hammer Drill
•
Depth stop
•
Original operating instruction with safety
•
information
Separately available accessories
18V 1.5Ah PXC Lithium-Ion battery
18V 2.0Ah PXC Lithium-Ion battery
18V 2.5Ah PXC Lithium-Ion battery
18V 3.0Ah PXC Lithium-Ion battery
18V 4.0Ah PXC Lithium-Ion battery
18V 3.0Ah PXC Plus Lithium-Ion battery
18V 4.0Ah PXC Plus Lithium-Ion battery
18V 5.2Ah PXC Plus Lithium-Ion battery
18V 4.0Ah/6.0Ah PXC Plus Lithium-Ion battery
18V 5.0Ah/8.0Ah PXC Plus Lithium-Ion battery
18V PXC Dual Port Fast Charger
18V PXC Fast Charger
Contact your local retailer for more specifi c
models of batteries and charger available in your
area. You can also explore battery + charger
options at Einhell.com.
3. Intended use
The hammer drill is designed for drilling holes
into wood, iron and non-ferrous metals, and for
hammer drilling in stone, using the appropriate
bits.
The equipment is not designed for tightening
screws of any kind.
The equipment is allowed to be used only for its
prescribed purpose. Any other use is deemed to
be a case of misuse. The user/operator and not
the manufacturer will be liable for any damage or
injuries of any kind resulting from such misuse.
Please note that our equipment has not been
designed for use in commercial, trade or
industrial applications. Our warranty will be voided
if the equipment is used in commercial, trade or
industrial businesses or for equivalent purposes.
EN
4. Technical data
Motor power supply: ............................18 V
No-load speed: .................... 0-2600 RPM (min-1)
Clockwise/counter-clockwise: ........................ yes
Clamping range
of drill chuck: ............................ max. ½'' (13 mm)
Impact Speed: ....................................41600 BPM
Drilling capacity:
Concrete : ........................................ ½'' (13 mm)
Metal: ................................................ ⅜'' (10 mm)
Wood: .................................................1'' (25 mm)
Weight (Tool only): ........................3.5 lbs (1.6 kg)
Wear ear-muff s.
The impact of noise can cause damage to
hearing.
Reduce noise generation and vibration to a
minimum!
Use only equipment that is in perfect
•
condition.
Maintain and clean the equipment regularly.
•
Adapt your way of working to the equipment.
•
Do not overload the equipment.
•
Have the equipment checked if necessary.
•
Switch off the equipment when not in use.
•
CAUTION!
Residual risks
Even if you use this electric power tool in
accordance with the instructions, certain
residual risks cannot be eliminated. The
following hazards may arise in connection
with the equipment‘s con-struction and
layout:
1. Lung damage if no suitable protective dust
mask is used.
2. Damage to hearing if no suitable ear
protection is applied.
3. Health damage caused by hand-arm
vibrations if the equipment is used over a
longer period or is not properly guided and
maintained.
Limit the operating time.
All stages of the operating cycle must be
considered (for example, times in which the
electric tools are switched off and times in which
the tool is switched on but operates without load).
- 10 -
Anl_TC_ID_18_Li_SPK7_USA.indb 10Anl_TC_ID_18_Li_SPK7_USA.indb 10 22.04.2022 11:04:1722.04.2022 11:04:17
EN
5. Before starting the equipment
5.1. Fitting the additional handle
(Fig. 2-3/Item 7)
The additional handle (7) enables you to achieve
better stability whilst using the hammer drill. Do
not use the tool without the additional handle.
The additional handle (7) is secured to the
hammer drill by a clamp. Turning the handle
clockwise tightens this clamp. Turning it anticlockwise will release the clamp.
The supplied additional handle (7) must
•
first be fitted. To do this, the clamp must be
opened by turning the handle until it is wide
enough for the additional handle to be slid
over the chuck (1) and on to the hammer drill.
After you have positioned the additional
•
handle (7), turn it to the most comfortable
working position for you.
Now turn the handle in the opposite direction
•
again until the additional handle is secure.
The additional handle (7) is suitable for both
•
left-handed and right-handed users.
5.2 Fitting and adjusting the depth stop (Fig.
4/Item 2)
The depth stop (2) is held in place by the
additional handle (7) by clamping. The clamp can
be released and tightened by turning the handle.
Release the clamp and fit the depth stop (2)
•
in the recess provided for it in the additional
handle.
Set the depth stop (2) to the same level as
•
the drill bit.
Pull the depth stop back by the required
•
drilling depth.
Turn the handle on the additional handle (7)
•
until it is secure.
Now drill the hole until the depth stop (2)
•
touches the workpiece.
5.3 Fitting the drill bit (Fig. 5)
Release the depth stop as described in 5.2
•
and push it towards the additional handle.
This provides free access to the chuck (1).
This hammer drill is fitted with a keyless
•
chuck (1).
Open the chuck (1). The drill bit opening must
•
be large enough to fit the drill bit into.
Select a suitable drill bit. Push the drill bit as
•
far as possible into the chuck opening.
Close the chuck (1). Check that the drill bit is
•
secure in the chuck (1).
6. Operation
6.1 On/Off switch (Fig. 7/Item 5)
Infi nitely variable speed control is possible with
the On/Off switch (5). The further you push the
switch, the higher the speed of the cordless
hammer drill.
To switch on:
Press the On/Off switch (5)
Continuous operation:
Secure the On/Off switch (5) with the locking
button (4).
To switch off :
Press the On/Off switch (5) briefl y.
6.2 Changeover switch (Fig. 7/Item 6)
Using the changeover switch (6) above the On/Off
switch (5) you can select the direction of rotation
of the cordless hammer drill and lock the cordless
hammer drill so that it cannot be switched on
accidentally. You can select between clockwise
and counter-clockwise rotation. To avoid causing
damage to the gearing, the direction of rotation
must only be changed when the equipment is at
a standstill. When the slide switch is in the middle
position, the On/Off switch is blocked.
6.3 Drill / hammer drill selector switch
(Fig. 8/Item 3)
Change switch position only when the drill is at a
standstill!
Drill
Drill / hammer drill selector switch (3) in the drill
position. (Position A)
Use for: Wood, metal, plastic
Hammer drill
Drill / hammer drill selector switch (3) in the
hammer drill position. (Position B)
Use for: Concrete, rock, masonry
Tips for working with your hammer drill
6.4 Drilling concrete and masonry
Switch the Drill/Hammer drill selector switch
•
(3) to position B (Hammer drill).
Always use carbide drill bits and a high speed
•
setting for drilling into masonry and concrete.
- 11 -
Anl_TC_ID_18_Li_SPK7_USA.indb 11Anl_TC_ID_18_Li_SPK7_USA.indb 11 22.04.2022 11:04:1822.04.2022 11:04:18
Loading...
