Section 1 - Product Overview
Product Overview
Package Contents
DCS-8600LH ||
Full HD Outdoor Wi-Fi Camera
USB Power Adapter
Quick Installation Guide
Magnetic Mounting Bracket
Quick Installation Card
If any of the above items are missing, please contact your reseller.
Note: Using a power supply with a dierent voltage rating than the one included with your product will cause damage and void
the warranty for this product.
1D-Link DCS-8600LH User Manual
Section 1 - Product Overview
Introduction
The D-Link DCS-8600LH Full HD Outdoor Wi-Fi Camera boasts a wide-angle lens that easily captures your entire room, wallto-wall, in high-denition 1080p. You will know what is happening day or night due to the built in night vision, motion
and sound detection features, which send notications to you via the mydlinkTM app. The rotatable head makes discrete
installations easy even on ceilings.
System Requirements
• 802.11n/g wireless network
Network Requirements
mydlink™ App Requirements
• An Internet connection
• A router connected to your broadband modem
• iPhone, iPad, Android smartphone or tablet (please refer to the mobile
app's store page to check whether your device is compatible)
• Email account (for mydlink™ service registration)
2D-Link DCS-8600LH User Manual
Section 1 - Product Overview
Hardware Overview
Front
1
2
3
4
5
1 Microphone Picks up sound near your camera.
Solid Green: Camera has successfully connected to a Wi-Fi network. Setup is
complete.
Flashing Green: Live view active.
2 Status LED
Solid Red: Booting up.
Flashing Red: Updating rmware.
Flashing Orange: Bluetooth pairing or oine.
3 IR LEDs IR LEDs encircle the camera lens.
4 Camera Lens Records video of the surrounding area.
The IR-Cut removable sensor monitors lighting conditions and switches between
5 Light Sensor
color and infrared accordingly.
3D-Link DCS-8600LH User Manual
Section 1 - Product Overview
Side
1
2
1 Speaker Provides audio playback for the two-way audio feature.
2 Power Cord Supplies power to the camera.
4D-Link DCS-8600LH User Manual
Section 1 - Product Overview
Bottom
1
2
3
1 Reset Button
Hold the recessed button down for at least 10 seconds to reset the camera to factory
default settings.
2 microSD Card Slot Where a microSD card can be inserted.
3 Mounting Thread ¼ x 20 UNF mounting thread.
5D-Link DCS-8600LH User Manual
Section 1 - Product Overview
Back
1
1 Snap Mount Indentation Where the snap mount is attached.
6D-Link DCS-8600LH User Manual
Section 2 - Installation
Installation
Safety
Please read all of the safety and operating instructions before using device:
• Do not open the device or attempt to repair it.
• Make sure that the microSD card slot cover is securely fastened before placing the camera outside.
• Do not submerge the device in liquid or attempt to clean it with liquids or solvents. To clean the device, disconnect it
from the power outlet and use a damp towel to gently wipe it down.
Before you Begin
Plan the location of your camera:
• Verify that your camera is electrically rated to operate with the power available in your location.
• Connect the camera's USB power adapter into electrical outlets that are not controlled by a wall switch. This will help you
to avoid accidentally turning o power to the device.
• Be sure to plug the device into a properly grounded electrical outlet in order to help prevent against electrical shock.
• Make sure that the device is rmly mounted and won't fall o.
7D-Link DCS-8600LH User Manual
Section 2 - Installation
Wireless Installation Considerations
The DCS-8600LH Full HD Outdoor Wi-Fi Camera lets you view video footage from virtually anywhere within the operating
range of your wireless network. Keep in mind that the number, thickness and location of walls, ceilings, or other objects that
the wireless signals must pass through may limit the range. Typical ranges vary depending on the types of materials and
background RF (radio frequency) noise in your home or business. The key to maximizing wireless range is to follow these
basic guidelines:
1. Keep the number of walls and ceilings between the camera and wireless access point to a minimum - each wall or ceiling
can reduce your camera’s range from 1 to 30 meters (3 to 90 feet). Position your devices so that the number of walls or
ceilings is minimized.
2. Be aware of the direct line between network devices. A wall that is 0.5 meters (1.5 feet) thick, at a 45-degree angle
appears to be almost 1 meter (3 feet) thick. At a 2-degree angle it looks over 14 meters (42 feet) thick! Position devices so
that the signal will travel straight through a wall or ceiling (instead of at an angle) for better reception.
3. Building materials make a dierence. A solid metal door or aluminum studs may have a negative eect on range. Try
to position access points, wireless routers, and cameras so that the signal passes through drywall or open doorways.
Materials and objects such as glass, steel, metal, walls with insulation, water (sh tanks), mirrors, le cabinets, brick, and
concrete will degrade your wireless signal.
4. Keep your product away at least 1 to 2 meters (3 to 6 feet) from electrical devices or appliances that generate RF noise.
8D-Link DCS-8600LH User Manual
Section 2 - Installation
/
1
Place the baseplate at the desired location, ensuring that it is at
least 20 cm from the ceiling. Make sure the screw is facing up and
the holes are level. Use a pencil to mark the holes.
Mounting the Camera
2/
3/
Using a 6 mm drill bit, drill two 25 mm deep holes over the pencil
marks. For a plaster, drywall, or concrete wall, insert the plastic
anchors to support the screws.
Place the baseplate over the holes. Use the supplied screws to
attach the baseplate to the wall.
9D-Link DCS-8600LH User Manual
Section 2 - Installation
4/
5/
Align the large top screw with the largest hole on the snap mount.
Slide the mount down to lock into place.
Attach the back of the camera to the mount. Adjust the angle as
desired.
6/
Connect the USB cable from the camera to the USB power supply.
Plug the USB power supply into a power outlet.
Note: The power supply and all power cords can be used both indoors and
outdoors. Therefore you can place everything outdoors if desired.
10D-Link DCS-8600LH User Manual
