Denon AVR-3808A Owner Manual

0 (0)

AV SURROUND RECEIVER

AVR-3808

Owner’s Manual Bedienungsanleitung Manuel de l’Utilisateur

 GraphicalUserInterface

English

Use this manual in combination with the operating guide displayed on the GUI screen.

GUI Menu Operation (vpage 22, 23) GUI Menu Map (vpage 24) Language (vpage 36) Remote Control Unit Operations (vpage 60)

Deutsch

Verwenden Sie dieses Handbuch zusammen mit den Bedienungsanweisungen auf dem GUIBildschirm.

GUI-Menübedienung (vSeite 22, 23) GUI-Menüplan (vSeite 24) Sprache (vpage 36) Bedienung mit der Fernbedienung (vpage 60)

Français

Utilisez ce manuel en même temps que le guide d’utilisation afﬁché sur l’écran GUI (Interface graphique).

Fonctionnement du menu de l’interface graphique GUI (vpage 22, 23) Plan du menu de l’interface graphique GUI (vpage 24) Langue (vpage 36) Fonctionnement de la télécommande (vpage 60)

Book 1

Book 2

English Deutsch Français PRESET CODE

Italiano Español Nederlands Svenska

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

ITALIANO ESPAÑOL NEDERLANDS SVENSKAENGLISH DEUTSCH FRANCAIS

SAFETY PRECAUTIONS

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning ﬂash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufﬁcient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

WARNING:

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

• DECLARATION OF CONFORMITY

We declare under our sole responsibility that this product, to which this

declaration relates, is in conformity with the following standards: EN60065, EN55013, EN55020, EN61000-3-2 and EN61000-3-3. Following the provisions of 2006/95/EC and 2004/108/EC Directive.

• ÜBEREINSTIMMUNGSERKLÄRUNG

Wir erklären unter unserer Verantwortung, daß dieses Produkt, auf das

sich diese Erklärung bezieht, den folgenden Standards entspricht: EN60065, EN55013, EN55020, EN61000-3-2 und EN61000-3-3. Entspricht den Verordnungen der Direktive 2006/95/EC und 2004/108/EC.

• DECLARATION DE CONFORMITE

Nous déclarons sous notre seule responsabilité que l’appareil, auquel se

réfère cette déclaration, est conforme aux standards suivants: EN60065, EN55013, EN55020, EN61000-3-2 et EN61000-3-3. D’après les dispositions de la Directive 2006/95/EC et 2004/108/EC.

• DICHIARAZIONE DI CONFORMITÀ

Dichiariamo con piena responsabilità che questo prodotto, al quale la

nostra dichiarazione si riferisce, è conforme alle seguenti normative: EN60065, EN55013, EN55020, EN61000-3-2 e EN61000-3-3. In conformità con le condizioni delle direttive 2006/95/EC e 2004/108/EC. QUESTO PRODOTTO E’ CONFORME AL D.M. 28/08/95 N. 548

• DECLARACIÓN DE CONFORMIDAD

Declaramos bajo nuestra exclusiva responsabilidad que este producto al

que hace referencia esta declaración, está conforme con los siguientes

estándares: EN60065, EN55013, EN55020, EN61000-3-2 y EN61000-3-3. Siguiendo las provisiones de las Directivas 2006/95/EC y 2004/108/EC.

• EENVORMIGHEIDSVERKLARING

Wij verklaren uitsluitend op onze verantwoordelijkheid dat dit produkt,

waarop deze verklaring betrekking heeft, in overeenstemming is met de

volgende normen: EN60065, EN55013, EN55020, EN61000-3-2 en EN61000-3-3. Volgens de bepalingen van de Richtlijnen 2006/95/EC en 2004/108/EC.

• ÖVERENSSTÄMMELSESINTYG

Härmed intygas helt på eget ansvar att denna produkt, vilken detta intyg

avser, uppfyller följande standarder: EN60065, EN55013, EN55020, EN61000-3-2 och EN61000-3-3. Enligt stadgarna i direktiv 2006/95/EC och 2004/108/EC.

CAUTION:

To completely disconnect this product from the mains, disconnect the plug from the wall socket outlet. The mains plug is used to completely interrupt the power supply to the unit and must be within easy access by the user.

VORSICHT:

Um dieses Gerät vollständig von der Stromversorgung abzutrennen, ziehen Sie bitte den Stecker aus der Wandsteckdose. Der Netzstecker wird verwendet, um die Stromversorgung zum Gerät völlig zu unterbrechen; er muss für den Benutzer gut und einfach zu erreichen sein.

PRECAUTION:

Pour déconnecter complètement ce produit du courant secteur, débranchez la prise de la prise murale. La prise secteur est utilisée pour couper complètement l’alimentation de l’appareil et l’utilisateur doit pouvoir y accéder facilement.

ATTENZIONE:

Per scollegare completamente questo prodotto dalla rete di alimentazione elettrica, scollegare la spina dalla relativa presa a muro. La spina di rete viene utilizzata per interrompere completamente l’alimentazione all’unità e deve essere facilmente accessibile all’utente.

PRECAUCIÓN:

Para desconectar completamente este producto de la alimentación eléctrica, desconecte el enchufe del enchufe de la pared. El enchufe de la alimentación eléctrica se utiliza para interrumpir por completo el suministro de alimentación eléctrica a la unidad y debe de encontrarse en un lugar al que el usuario tenga fácil acceso.

WAARSCHUWING:

Om de voeding van dit product volledig te onderbreken moet de stekker uit het stopcontact worden getrokken. De netstekker wordt gebruikt om de stroomtoevoer naar het toestel volledig te onderbreken en moet voor de gebruiker gemakkelijk bereikbaar zijn.

FÖRSIKTIHETSMÅTT:

Koppla loss stickproppen från eluttaget för att helt skilja produkten från nätet. Stickproppen används för att helt bryta strömförsörjningen till apparaten, och den måste vara lättillgänglig för användaren.

NOTE ON USE / HINWEISE ZUM GEBRAUCH / OBSERVATIONS RELATIVES A L’UTILISATION / NOTE SULL’USO /

NOTAS SOBRE EL USO / ALVORENS TE GEBRUIKEN / OBSERVERA ANGÅENDE ANVÄNDNINGEN

CAUTION:

• The ventilation should not be impeded by covering the ventilation openings with items, such as newspapers, tablecloths, curtains, etc.

• No naked ﬂame sources, such as lighted candles, should be placed on the unit.

• Observe and follow local regulations regarding battery disposal.

• Do not expose the unit to dripping or splashing ﬂuids.

• Do not place objects ﬁlled with liquids, such as vases, on the unit.

ACHTUNG:

• Die Belüftung sollte auf keinen Fall durch das Abdecken der Belüftungsöffnungen durch Gegenstände wie beispielsweise Zeitungen, Tischtücher, Vorhänge o. Ä. behindert werden.

• Auf dem Gerät sollten keinerlei direkte Feuerquellen wie beispielsweise angezündete Kerzen aufgestellt werden.

• Bitte beachten Sie bei der Entsorgung der Batterien die örtlich geltenden Umweltbestimmungen.

• Das Gerät sollte keiner tropfenden oder spritzenden Flüssigkeit ausgesetzt werden.

• Auf dem Gerät sollten keine mit Flüssigkeit gefüllten Behälter wie beispielsweise Vasen aufgestellt werden.

ATTENTION:

• La ventilation ne doit pas être gênée en recouvrant les ouvertures de la ventilation avec des objets tels que journaux, rideaux, tissus, etc.

• Aucune ﬂamme nue, par exemple une bougie, ne doit être placée sur l’appareil.

• Veillez à respecter les lois en vigueur lorsque vous jetez les piles usagées.

• L’appareil ne doit pas être exposé à l’eau ou à l’humidité.

• Ne pas poser d’objet contenant du liquide, par exemple un vase, sur l’appareil.

ATTENZIONE:

• Le aperture di ventilazione non devono essere ostruite coprendole con oggetti, quali giornali, tovaglie, tende e così via.

• Non posizionate sull’unità ﬁamme libere, come ad esempio candele accese.

• Prestate attenzione agli aspetti legati alla tutela dell’ambiente nello smaltimento delle batterie.

• L’apparecchiatura non deve essere esposta a gocciolii o spruzzi.

• Non posizionate sull’unità alcun oggetto contenente liquidi, come ad esempio i vasi.

PRECAUCIÓN:

• La ventilación no debe quedar obstruida por haberse cubierto las aperturas con objetos como periódicos, manteles, cortinas, etc.

• No debe colocarse sobre el aparato ninguna fuente inﬂamable sin protección, como velas encendidas.

• A la hora de deshacerse de las pilas, respete la normativa para el cuidado del medio ambiente.

• No exponer el aparato al goteo o salpicaduras cuando se utilice.

• No colocar sobre el aparato objetos llenos de líquido, como jarros.

WAARSCHUWING:

• De ventilatie mag niet worden belemmerd door de ventilatieopeningen af te dekken met bijvoorbeeld kranten, een tafelkleed, gordijnen, enz.

• Plaats geen open vlammen, bijvoorbeeld een brandende kaars, op het apparaat.

• Houd u steeds aan de milieuvoorschriften wanneer u gebruikte batterijen wegdoet.

• Stel het apparaat niet bloot aan druppels of spatten.

• Plaats geen voorwerpen gevuld met water, bijvoorbeeld een vaas, op het apparaat.

OBSERVERA:

• Ventilationen bör inte förhindras genom att täcka för ventilationsöppningarna med föremål såsom tidningar, bordsdukar, gardiner osv.

• Inga blottade brandkällor, såsom tända ljus, får placeras på apparaten.

• Tänk på miljöaspekterna när du bortskaffar batterier.

• Apparaten får inte utsättas för vätska.

• Placera inte föremål fyllda med vätska, t.ex. vaser, på apparaten.

• Avoid high temperatures. Allow for sufﬁcient heat dispersion when installed in a rack.

• Vermeiden Sie hohe Temperaturen. Beachten Sie, dass eine ausreichende Belüftung gewährleistet wird, wenn das Gerät auf ein Regal gestellt wird.

• Eviter des températures élevées.

Tenir compte d’une dispersion de chaleur sufﬁsante lors de

l’installation sur une étagère.

• Evitate di esporre l’unità a temperature elevate. Assicuratevi che vi sia un’adeguata dispersione del calore quando installate l’unità in un mobile per componenti audio.

• Evite altas temperaturas.

Permite la suﬁciente dispersión del calor cuando está

instalado en la consola.

• Vermijd hoge temperaturen.

Zorg er bij installatie in een audiorack voor, dat de door

het toestel geproduceerde warmte goed kan worden afgevoerd.

• Undvik höga temperaturer.

Se till att det ﬁnns möjlighet till god värmeavledning vid

montering i ett rack.

• Handle the power cord carefully.

Hold the plug when unplugging the cord.

• Gehen Sie vorsichtig mit dem Netzkabel um.

Halten Sie das Kabel am Stecker, wenn Sie den Stecker

herausziehen.

• Manipuler le cordon d’alimentation avec précaution.

Tenir la prise lors du débranchement du cordon.

• Manneggiate il cavo di alimentazione con attenzione. Tenete ferma la spina quando scollegate il cavo dalla presa.

• Maneje el cordón de energía con cuidado.

Sostenga el enchufe cuando desconecte el cordón de

energía.

• Hanteer het netsnoer voorzichtig.

Houd het snoer bij de stekker vast wanneer deze moet

worden aan- of losgekoppeld.

• Hantera nätkabeln varsamt.

Håll i kabeln när den kopplas från el-uttaget.

• Keep the unit free from moisture, water, and dust.

• Halten Sie das Gerät von Feuchtigkeit, Wasser und Staub fern.

• Protéger l’appareil contre l’humidité, l’eau et la poussière.

• Tenete l’unità lontana dall’umidità, dall’acqua e dalla polvere.

• Mantenga el equipo libre de humedad, agua y polvo.

• Laat geen vochtigheid, water of stof in het apparaat binnendringen.

• Utsätt inte apparaten för fukt, vatten och damm.

• Unplug the power cord when not using the unit for long periods of time.

• Wenn das Gerät längere Zeit nicht verwendet werden soll, trennen Sie das Netzkabel vom Netzstecker.

• Débrancher le cordon d’alimentation lorsque l’appareil n’est pas utilisé pendant de longues périodes.

• Scollegate il cavo di alimentazione quando prevedete di non utilizzare l’unità per un lungo periodo di tempo.

• Desconecte el cordón de energía cuando no utilice el equipo por mucho tiempo. Neem altijd het netsnoer uit het stopkontakt wanneer het

• apparaat gedurende een lange periode niet wordt gebruikt.

• Koppla loss nätkabeln om apparaten inte kommer att användas i lång tid.

* (For apparatuses with ventilation holes)

• Do not obstruct the ventilation holes.

• Decken Sie den Lüftungsbereich nicht ab.

• Ne pas obstruer les trous d’aération.

• Non coprite i fori di ventilazione.

• No obstruya los oriﬁcios de ventilación.

• De ventilatieopeningen mogen niet worden beblokkeerd.

• Täpp inte till ventilationsöppningarna.

• Do not let foreign objects into the unit. Lassen Sie keine fremden Gegenstände in das Gerät kommen.

•

• Ne pas laisser des objets étrangers dans l’appareil.

• Non inserite corpi estranei all’interno dell’unità.

• No deje objetos extraños dentro del equipo.

• Laat geen vreemde voorwerpen in dit apparaat vallen.

• Se till att främmande föremål inte tränger in i apparaten.

• Do not let insecticides, benzene, and thinner come in contact with the unit.

• Lassen Sie das Gerät nicht mit Insektiziden, Benzin oder Verdünnungsmitteln in Berührung kommen.

• Ne pas mettre en contact des insecticides, du benzène et un diluant avec l’appareil.

• Assicuratevi che l’unità non entri in contatto con insetticidi, benzolo o solventi.

• No permita el contacto de insecticidas, gasolina y diluyentes con el equipo.

• Voorkom dat insecticiden, benzeen of verfverdunner met dit toestel in contact komen.

• Se till att inte insektsmedel på spraybruk, bensen och thinner kommer i kontakt med apparatens hölje.

• Never disassemble or modify the unit in any way.

• Versuchen Sie niemals das Gerät auseinander zu nehmen oder zu verändern.

• Ne jamais démonter ou modiﬁer l’appareil d’une manière ou d’une autre.

• Non smontate né modiﬁcate l’unità in alcun modo.

• Nunca desarme o modiﬁque el equipo de ninguna manera.

• Dit toestel mag niet gedemonteerd of aangepast worden.

• Ta inte isär apparaten och försök inte bygga om den.

ENGLISHDEUTSCHFRANCAISITALIANOESPAÑOLNEDERLANDSSVENSKA

ITALIANO ESPAÑOL NEDERLANDS SVENSKAENGLISH DEUTSCH FRANCAIS

A NOTE ABOUT RECYCLING:

This product’s packaging materials are recyclable and can be reused. Please dispose of any materials in accordance with the local recycling regulations. When discarding the unit, comply with local rules or regulations. Batteries should never be thrown away or incinerated but disposed of in accordance with the local regulations concerning battery disposal. This product and the supplied accessories, excluding the batteries, constitute the applicable product according to the WEEE directive.

HINWEIS ZUM RECYCLING:

Das Verpackungsmaterial dieses Produktes ist zum Recyceln geeignet und kann wieder verwendet werden. Bitte entsorgen Sie alle Materialien entsprechend der örtlichen Recycling-Vorschriften. Beachten Sie bei der Entsorgung des Gerätes die örtlichen Vorschriften und Bestimmungen. Die Batterien dürfen nicht in den Hausmüll geworfen oder verbrannt werden; bitte entsorgen Sie die Batterien gemäß der örtlichen Vorschriften. Dieses Produkt und das im Lieferumfang enthaltene Zubehör (mit Ausnahme der Batterien!) entsprechen der WEEEDirektive.

UNE REMARQUE CONCERNANT LE RECYCLAGE:

Les matériaux d’emballage de ce produit sont recyclables et peuvent être réutilisés. Veuillez disposer des matériaux conformément aux lois sur le recyclage en vigueur. Lorsque vous mettez cet appareil au rebut, respectez les lois ou réglementations en vigueur. Les piles ne doivent jamais être jetées ou incinérées, mais mises au rebut conformément aux lois en vigueur sur la mise au rebut des piles. Ce produit et les accessoires inclus, à l’exception des piles, sont des produits conformes à la directive DEEE.

NOTA RELATIVA AL RICICLAGGIO:

I materiali di imballaggio di questo prodotto sono riutilizzabili e riciclabili. Smaltire i materiali conformemente alle normative locali sul riciclaggio. Per lo smaltimento dell’unità, osservare le normative o le leggi locali in vigore. Non gettare le batterie, né incenerirle, ma smaltirle conformemente alla normativa locale sui riﬁuti chimici. Questo prodotto e gli accessori inclusi nell’imballaggio sono applicabili alla direttiva RAEE, ad eccezione delle batterie.

ACERCA DEL RECICLAJE:

Los materiales de embalaje de este producto son reciclables y se pueden volver a utilizar. Disponga de estos materiales siguiendo los reglamentos de reciclaje de su localidad. Cuando se deshaga de la unidad, cumpla con las reglas o reglamentos locales. Las pilas nunca deberán tirarse ni incinerarse. Deberá disponer de ellas siguiendo los reglamentos de su localidad relacionados con los desperdicios químicos. Este producto junto con los accesorios empaquetados es el producto aplicable a la directiva RAEE excepto pilas.

EEN AANTEKENING MET BETREKKING TOT DE RECYCLING:

Het inpakmateriaal van dit product is recycleerbaar en kan opnieuw gebruikt worden. Er wordt verzocht om zich van elk afvalmateriaal te ontdoen volgens de plaatselijke voorschriften. Volg voor het wegdoen van de speler de voorschriften voor de verwijdering van wit- en bruingoed op. Batterijen mogen nooit worden weggegooid of verbrand, maar moeten volgens de plaatselijke voorschriften betreffende chemisch afval worden verwijderd. Op dit product en de meegeleverde accessoires, m.u.v. de batterijen is de richtlijn voor afgedankte elektrische en elektronische apparaten (WEEE) van toepassing.

OBSERVERA ANGÅENDE ÅTERVINNING:

Produktens emballage är återvinningsbart och kan återanvändas. Kassera det enligt lokala återvinningsbestämmelser. När du kasserar enheten ska du göra det i överensstämmelse med lokala regler och bestämmelser. Batterier får absolut inte kastas i soporna eller brännas. Kassera dem enligt lokala bestämmelser för kemiskt avfall. Denna apparat och de tillbehör som levereras med den uppfyller gällande WEEE-direktiv, med undantag av batterierna.

III

ENGLISH

Contents

Getting Started Accessories ······················································································2

Cautions on Handling ·····································································3 Cautions on Installation ································································· 3 About the Remote Control Unit ···················································· 3

Inserting the Batteries ····································································3 Operating Range of the Remote Control Unit ································3

Part Names and Functions ·····························································4

Front Panel ·····················································································4 Display ···························································································4 Rear Panel ······················································································5 Remote Control Unit ······································································ 6

Connections Preparations ···················································································· 7

Cables Used for Connections ························································7 Video Conversion Function ·····························································8

Speaker Connections ·····································································9

Speaker Installation ········································································9 Speaker Connections ······························································· 9, 10

Connecting Equipment with HDMI connectors ························· 11 Connecting the Monitor ······························································· 12 Connecting the Playback Components ······································12

DVD Player ··················································································· 12 Record Player ···············································································13 CD Player ····················································································· 13 iPod® ···························································································· 13 TV/CABLE Tuner ··········································································· 14 Satellite Receiver ········································································· 14

Connecting the Recording Components ···································· 15

Digital Video Recorder ··································································15 Video Cassette Recorder ····························································· 15 CD Recorder / MD Recorder / Tape Deck ····································· 16

Connections to Other Devices ····················································· 16

Components Equipped with a DENON LINK connector ·············· 16 Video Camera / Game Console ···················································· 17 Component with Multi-channel Output connectors ····················· 17 External Power Ampliﬁer ······························································ 17 USB Port ······················································································18 Antenna terminals ······································································· 19 Network Audio ············································································· 20 Multi-Zone ····················································································21 External Controller ·······································································21

Connecting the Power Cord·························································22 Once Connections are Completed ··············································22

GUI Menu Operations Example of the Display of the GUI Mark at a Title····················· 22

Example of Display of Default Values ········································· 22 Examples of GUI Screen Displays ··············································· 23

Example: Browse Menu (Top Menu)············································ 23 Example: Menus with Illustrations (Auto Setup) ··························23 Cursor Position Display ································································ 23

Operations ·····················································································23 GUI Menu Map ··············································································24

Auto Setup Preparations ·················································································· 25

Auto Setup ····················································································26

a Auto Setup ·············································································· 26 Error Messages ·······································································27 s

Option ····················································································· 27

Parameter Check ·····································································27

Manual Setup Speaker Setup···············································································28

Speaker Conﬁguration ·····························································28

Subwoofer Mode ····································································28

Distance ··················································································28

Channel Level··········································································29

Crossover Frequency ······························································29

Surround Speaker ···································································29

HDMI Setup ··················································································· 30

i/p Scaler ·················································································30

Resolution ···············································································30

Progressive Mode ··································································· 30

Aspect ····················································································· 30

Color Space ············································································· 30

RGB Range ·············································································30

Auto Lip Sync ·········································································· 30

Audio ······················································································· 30

Audio Setup ··················································································30

EXT. IN Setup ··········································································

2ch Direct/Stereo ····································································

Downmix Option ·····································································

Auto Surround Mode ······························································

Manual EQ ·············································································· 31

Network Setup ··············································································32

Network Setup ········································································ 32

Other ······················································································· 33

Network Information ······························································· 33

Zone Setup ···················································································· 33

ZONE2 ··············································································33, 34

ZONE3 ··············································································33, 34

Option Setup ·················································································34

Amp Assign ·············································································

Volume Control ·······································································

30 31 31 31

34 34

Source Delete ·········································································

GUI ····················································································

Quick Select Name ·································································

Trigger Out 1 ··········································································· 35

Trigger Out 2 ··········································································· 35

Remote ID ···············································································35

2Way Remote ·········································································35

Dimmer ···················································································35

Setup Lock ··············································································36

Maintenance Mode ································································· 36

Firmware Update ···································································· 36

A4 Add New Feature

Language ······················································································· 36

Source Select Input Source Selection ·································································37

Settings Related to Playing Input Sources ·································37

Play ·························································································

Auto Preset ·············································································

Preset Skip ··············································································

Preset Name ···········································································

Input Mode ·············································································38

Rename ···················································································38

Other ······················································································· 38

Playback Mode (iPod) ······························································39

Assign ····················································································· 39

Playback Mode ········································································40

Surround Modes Standard Playback ········································································40

Surround Playback of 2-channel Sources ·····································40 Playing Multi-channel Sources (Dolby Digital, DTS, etc.) ·············40

DSP Simulation Playback·····························································41 Stereo Playback ············································································41 Direct Playback ·············································································41

Playback in the PURE DIRECT Mode ···········································41

Parameter Audio······························································································42

Surround Parameters ························································42, 43

Tone ························································································43

Room EQ ················································································44

RESTORER ··············································································44

Night Mode ·············································································44

Audio Delay ············································································· 44

Picture Adjust ················································································ 45

Contrast ··················································································45

Brightness ··············································································· 45

Chroma Level ·········································································· 45

Hue ·························································································45

···································································· 36

34, 35

37 37 37 38



ENGLISH

e r y

Getting Started

Information Status ····························································································45

MAIN ZONE ············································································45

ZONE2/3 ·················································································45

Audio Input Signal ········································································45 HDMI Information ········································································· 46

Connections Setup Playback Remote Control Multi-Zone Information Troubleshooting Speciﬁcations

Signal Information ···································································46

Monitor ···················································································46

Auto Surround ·············································································· Quick Select ·················································································· Preset Station ···············································································

Playback Preparations ·················································································· 47

Turning the Power On ··································································47 Operations During Playback ·························································47

Playing Video and Audio Equipment ···········································47

Basic Operation ············································································47

Listening to FM/AM Broadcasts ·················································48

Basic Operation ············································································48 Presetting Radio Stations (Preset Memory) ·································48 Listening to Preset Stations ·························································49 RDS (Radio Data System) ····························································49 RDS Search ··················································································49 PTY Search ···················································································50 TP Search ·····················································································50 RT (Radio Text) ·············································································· 51

iPod® Playback ············································································· 51

Basic Operation ············································································51 Listening to Music ·······································································52 Viewing Still Pictures or Videos on the iPod ·································52

Playing Network Audio or USB Memory Devices ······················ 53

Basic Operation ············································································54 Listening to Internet Radio ·····················································54, 55 Presetting Internet Radio Stations ··············································· 55 Registering Internet Radio Stations as Your Favorites ·················· 55 Playing Files Stored on a Computer ·············································55 Playing Files Stored on USB Memory Devices ···························· 56 Operating the AVR-3808 Using a Browser (Web control) ······56, 57

Convenient Functions ··································································59

Channel Level ···············································································59 Fader Function ·············································································59 Quick Select Function ··································································59 Personal Memory Plus Function ·················································· 59 Last Function Memory ·································································59 Backup Memory ···········································································59 Resetting the Microprocessor ······················································59

46 46

Remote Control Unit Operations

Main Remote Control Unit···························································60

Operating DENON Audio Components ········································60 Presetting ·····················································································60 Operating Preset Components ············································60 ~ 62 Setting the Remote ID ································································· 63 Learning Function ·········································································63 System Call Function ····································································64 Punch Through Function ······························································· 64 Setting the Time the Backlight Stays Lit ·······································65 Adjusting the Backlight’s Brightness ············································65 Resetting the Main Remote Control Unit ····································· 65

Sub Remote Control Unit Operations ··································66, 67

Switching Zones ···········································································68 Setting the Zone for Which the Sub Remote Control Unit is Used (ZONE SELECT LOCK mode) ·······················································68 Setting the Remote ID ································································· 68 Resetting the Settings ··································································68

Amp Assign / Multi-Zone Connections and Operations Multi-Zone Settings with the Amp Assign Function ·········69 ~ 71

Multi-Zone Settings and Operations with Zone Pre-out Output ···71 Multi-Zone Operations ································································· 72

Turning the Power On and Off······················································72 Selecting the Input Source ···························································72 Adjusting the Volume ···································································72 Turning off the Sound Temporarily ················································72

Other Information ································································73 ~ 82

Getting Started

Thank you for purchasing this DENON product. To ensure proper operation, please read these owner’s manual carefully before using the product. After reading them, be sure to keep them for future reference.

Accessories

Check that the following parts are supplied with the product.

q Owner’s manual ...................................................................... 1

w Service station list ...................................................................1

e Power cord (Cord length: Approx. 1.5 m) ................................. 1

r Main remote control (RC-1068) ............................................... 1

t LR6/AA batteries (for RC-1068) ................................................ 2

y Sub remote control (RC-1070) ................................................. 1

u R03/AAA batteries (for RC-1070) .............................................2

i FM indoor antenna ..................................................................1

o AM loop antenna ..................................................................... 1

Q0 Setup microphone (Cord length: Approx. 7.6 m) ...................... 1

Other Operations and Functions Other Operations ·········································································· 58

Playing Super Audio CD ······························································· 58 Recording on an External Device (REC OUT mode) ··············· 58, 59



Troubleshooting ···································································83 ~ 85

Speciﬁcations ··············································································· 86

List of preset codes ··········································· End of this manual

Cautions on Handling

• Before turning the power switch on

Check once again that all connections are correct and that there are

no problems with the connection cables.

•

Power is supplied to some of the circuitry even when the unit is set to the standby mode. When traveling or leaving home for long periods of time, be sure to unplug the power cord from the power outlet.

• About condensation

If there is a major difference in temperature between the inside of

the unit and the surroundings, condensation (dew) may form on the operating parts inside the unit, causing the unit not to operate properly.

If this happens, let the unit sit for an hour or two with the power

turned off and wait until there is little difference in temperature before using the unit.

• Cautions on using mobile phones

Using a mobile phone near this unit may result in noise. If so, move

the mobile phone away from this unit when it is in use.

• Moving the unit

Turn off the power and unplug the power cord from the power

outlet.

Next, disconnect the connection cables to other system units before

moving the unit.

•

Note that the illustrations in these instructions may differ from the actual unit for explanation purposes.

About the Remote Control Unit

In addition to the AVR-3808, the included main remote control unit (RC-1068) can also be used to operate the equipment listed below.

q DENON system components w Non-DENON system components

• By setting the preset memory (vpage 60 ~ 62)

• By using the learn function (vpage 63)

Inserting the Batteries

q Lift the clasp and remove the rear lid.

(RC-1068) (RC-1070)

w Load the two batteries properly as indicated by the marks in the

battery compartment.

(RC-1068) (RC-1070)

R03/AAA

LR6/AA

ENGLISH

NOTE

• Replace the batteries with new ones if the set does not operate even when the remote control unit is operated close to the unit.

• The supplied batteries are only for verifying operation.

• When inserting the batteries, be sure to do so in the proper direction, following the “q” and “w” marks in the battery compartment.

• To prevent damage or leakage of battery ﬂuid:

• Do not use a new battery together with an old one.

• Do not use two different types of batteries.

• Do not attempt to charge dry batteries.

• Do not short-circuit, disassemble, heat or dispose of batteries in

ﬂames.

• If the battery ﬂuid should leak, carefully wipe the ﬂuid off the inside of the battery compartment and insert new batteries.

• Remove the batteries from the remote control unit if it will not be in use for long periods.

• When replacing the batteries, have the new batteries ready and insert them as quickly as possible.

Operating Range of the Remote Control Unit

Point the remote control unit at the remote sensor when operating it.

Getting Started

Connections Setup Playback Remote Control Multi-Zone Information Troubleshooting

Cautions on Installation

Note: For proper heat dispersal, do not install this unit in a conﬁned space, such as a bookcase or similar enclosure.

b Note

Wall

e Put the rear cover back on.

(RC-1070)

30°

Approx. 7 m

(RC-1068)

NOTE

The set may function improperly or the remote control unit may not operate if the remote control sensor is exposed to direct sunlight, strong artiﬁcial light from an inverter type ﬂuorescent lamp or infrared light.



Speciﬁcations

ENGLISH

w e

to i u y

q r

Q3Q2Q1Q0

yQ6Q7 uo

iQ4 Q0

Q1Q2Q3Q5

wq e r

W3W4W5W7W8W9E0E1E2E3 W6

Q4 Q5 Q6 Q8 W1W0Q7 W2Q9

Getting Started

Part Names and Functions

For buttons not explained here, see the page indicated in parentheses ( ).

Connections Setup Playback Remote Control Multi-Zone Information Troubleshooting

Front Panel

E0 DIRECT/STEREO button·····························(41) E1 PURE DIRECT button ·································· (41)

Display

E2 DSP SIMULATION button ·························· (41) E3 STANDARD button ·····································(40)

GWith the door openH

q Power operation button

(ON/STANDBY) ··········································· (47)

w Power indicator ··········································· (47)

Speciﬁcations

e Power switch (hON jOFF) ·····················(47) r QUICK SELECT buttons / indicators ········· (59) t MASTER VOLUME control knob ················ (47) y Master volume indicator u Display i Remote control sensor ································· (3) o SOURCE SELECT knob······························· (37) Q0 SOURCE button ·········································· (37)

Q1 TUNING PRESET button ···························· (49) Q2 ZONE2/3 / REC SELECT button ··········(58, 72) Q3 VIDEO SELECT button ·······························(38) Q4 Headphones jack (PHONES) ······················ (47) Q5 ZONE2 ON/OFF button ······························ (72) Q6 ZONE3 ON/OFF button ······························ (72) Q7 INPUT MODE button ·································· (38) Q8 MENU button ·············································· (23) Q9 Cursor buttons (uio p) ·························· (23) W0 CH SEL / ENTER button ······················· (23, 59) W1 RETURN button ·········································· (23) W2 V.AUX INPUT connectors ··························· (17) W3 SETUP MIC jack ·········································· (25) W4 ROOM EQ button ········································ (44) W5 DIMMER button ·········································· (35) W6 USB port ······················································ (18) W7 STATUS button ··········································· (45) W8 AUDIO DELAY button ································· (44) W9 RESTORER button ······································(44)

q Input signal indicators w Input signal channel indicators

These light when digital signals are input.

e Information display

The input source name, surround mode, setting

values and other information are displayed here.

r Output signal channel indicators t Surround speaker indicators

These light according to the settings of the

surround A and B speakers.

y Master volume indicator u AUDYSSEY MULTEQ XT indicator

This lights when the room equalizer is selected.

i Recording output source indicator

This lights when the REC OUT mode is

selected.

o NIGHT indicator

This lights when the night mode is selected.

Q0 Multi-zone indicators

These light when the power for the respective

zone is turned on.

Q1 RESTORER indicator

This lights when the RESTORER mode is

selected.

Q2 AL24 indicator

This lights when AL24 Processing Plus is

activated (vpage 75).

Q3 D.LINK indicator

This lights when playing using DENON LINK

connections.

Q4 Input mode indicators Q5 HDMI indicator

This lights when playing using HDMI

connections.

Q6 Decoder indicators

These light when the respective decoders are

operating.

Q7 Tuner reception mode indicators

These light according to the reception conditions

when the input source is set to “TUNER”.

• AUTO

These light when in the auto tuning mode.

• RDS

This lights when receiving RDS broadcasts.

• STEREO

In the FM mode, these light when receiving analog stereo broadcasts.

• TUNED

Lights when the broadcast is properly tuned in.



Q6 Q7 Q7Q8 Q6 Q9

Q1Q2 Q0

oQ3Q4

q w e iu

Q6 Q7 Q7Q8 Q6 Q9

Rear Panel

ENGLISH

Getting Started

Connections Setup Playback Remote Control Multi-Zone Information Troubleshooting

q RS-232C connector ····································· (21) w REMOTE CONTROL jacks···························(21) e TRIGGER OUT jacks ···································(21) r FM/AM antenna terminals

(TUNER ANTENNA) ···································· (19)

t DOCK CONTROL jack ································· (13) y Speaker terminals (SPEAKERS) ··················(9) u AC OUTLET ·················································(22)

i AC inlet (AC IN) ··········································· (22) o Digital audio connectors

(OPTICAL / COAXIAL) ·························· (12, 14)

Q0 ETHERNET connector ································· (20) Q1 USB port ······················································ (18) Q2 DENON LINK connector ····························· (16) Q3 COMPONENT VIDEO connectors ·············· (12) Q4 HDMI connectors ·········································(11)

Q5 VIDEO / S-VIDEO connectors ···················· (12) Q6 Analog audio connectors (AUDIO) ············ (12) Q7 PRE OUT connectors ····························· (17, 21) Q8 EXT. IN connectors ····································· (17) Q9 SIGNAL GND terminal ······························· (13)

Speciﬁcations



ENGLISH

t y u

Q6 Q7

t y

Getting Started

Connections Setup Playback Remote Control Multi-Zone Information Troubleshooting

Remote Control Unit

n Main remote control unit (RC-1068) n Sub remote control unit (RC-1070)

t System buttons ···································· (61, 62) y Audio delay button (A. DL) ························(44) u Tuner system buttons ································(48) i Input mode button (INPUT) ······················· (38) o MENU button ·············································· (23) Q0 Cursor buttons (uio p) ························· (23) Q1 Parameter / Search button

(PARA / SRCH) ······································ (42, 49)

Q2 HOME button ·············································· (60) Q3 Channel buttons (CH) ································· (48) Q4 Input source select / Number buttons ···(37, 48) Q5 Remote control signal transmitter ·············· (3) Q6 Device select indicators (DEV1 / DEV2) ···(60) Q7 ZONE3 select indicators (Z3) ····················· (72) Q8 RESTORER button (RSTR) ·························· (44) Q9 Night button (NGT) ···································· (44) W0 Test tone button (TEST) ····························· (29) W1 Surround speaker select button (SPKR) ··· (29) W2 POWER buttons ·········································· (47) W3 Channel select (CH SEL) /

ENTER button ······································· (23, 59)

W4 Return button (RTN) ··································· (23) W5 Master volume control buttons (VOL) ······ (47) W6 Muting button (MUTE) ··························(47, 72) W7 Main remote control unit setup button

(RC SETUP) ·················································(60)

q ZONE indicators·········································· (68) w Advanced setup button ······························ (68) e Input source select buttons ······················· (37) r CHANNEL buttons ······································ (48) t SHIFT button ··············································· (48) y MENU button ·············································· (23) u Cursor buttons (uio p) ························· (23) i SEARCH button ··········································(49) o REPEAT button ············································ (52) Q0 RANDOM button ········································(52) Q1 Remote control signal transmitter ·············· (3) Q2 ZONE SELECT button ································· (68) Q3 Zone power on/off buttons

(ZONE ON / ZONE OFF) ····························· (72)

Q4 Master volume control buttons

(VOLUME) ············································ (66, 67)

Q5 Muting button (MUTE) ··························(47, 72) Q6 ENTER button ············································· (23) Q7 RETURN button ·········································· (23) Q8 System buttons ······························ (48, 66, 67) Q9 ALL MUSIC/FAVORITES

(DIRECT PLAY) button ······························· (66)

W0 USB (DIRECT PLAY) button························(66)

NOTE

The AUX-1, AUX-2, AUX-3, SAT TU, DTU, DVR-2 and OPTION buttons cannot be used.

Speciﬁcations

q Signal transmission indicator ···················(60) w Mode select buttons ··································(60) e Quick select / System call buttons ·····(59, 64) r Surround mode buttons ······················(40, 41)



The time for which the backlight stays on can be changed (vpage 65 “Setting the Time the Backlight Stays Lit”).

NOTE

• The M. SEL, SAT TU, DTU buttons cannot be used.

• The ZONE2 mode QUICK SELECT (1 ~ 3), A.DL,

RSTR, NGT, INPUT, SPKR, TEST and surround

mode buttons cannot be used.

• The ZONE4 mode cannot be used.

Preparations

ENGLISH

Getting Started Setup Playback Remote Control Multi-Zone Information Troubleshooting

Connections

Connections for all compatible audio and video signal formats are described in these operating instructions. Please select the types of connections suited for the equipment you are connecting. With some types of connections, certain settings must be made on the AVR-3808. For details, refer to the instructions for the respective connection items below.

NOTE

• Do not plug in the power cord until all connections have been completed.

• When making connections, also refer to the operating instructions of the other components.

• Be sure to connect the left and right channels properly (left with left, right with right).

• Do not bundle power cords together with connection cables. Doing so can result in humming or noise.

Cables Used for Connections

Select the cables according to the equipment being connected.

Audio cables Video cables

Coaxial digital connections

(Orange)

Coaxial digital (75 Ω/ohms pin-plug) cable

Optical digital connections

Optical cable

Analog connections (stereo)

(White)

(Red)

Stereo pin-plug cable

Analog connections (monaural, for subwoofer)

(Black)

Pin-plug cable

DENON LINK connections

DENON LINK cable

Component video connections

(Green)

(Blue)

(Red)

S-Video connections

Video connections

(Yellow)

Component video cable

S-Video cable

75 Ω/ohms pin-plug video cable

Audio and video cables

HDMI connections

19-pin HDMI cable

Connections

(Y) (PB/CB) (PR/CR)

Speaker connections

Audio signal: Video signal:

Output

Input

Speaker cables

Network connections

Ethernet cable

Signal direction

Input

Output

Input

Output

Speciﬁcations



ENGLISH

Getting Started Setup Playback Remote Control Multi-Zone Information Troubleshooting

Video Conversion Function

• This function automatically converts various formats of video signals input to the AVR-3808 into the format used to output the video signals from the AVR-3808 to a monitor.

• The AVR-3808’s video input/output circuitry is compatible with the following four types of video signals:

Connections

Digital video signals: HDMI Analog video signals: Component video, S-Video and Video

GFlow of video signals inside the AVR-3808H

Main zone

High picture

quality playback

HDMI connector

• When not using this function, connect a monitor output with the same type of connector as the video input connector.

• The resolution of the HDMI input-compatible monitor connected to the AVR-3808 can be checked at GUI menu “Information” – “HDMI Information” – “Monitor” (vpage 46).

NOTE

• HDMI signals cannot be converted into analog signals.

• 1080p component input video signals cannot be output to anything other than component video connectors.

• 480p/576p, 1080i and 720p component video input signals cannot be converted into S-Video or Video format.

• When a non-standard video signal from a game machine or some other source is input, the video conversion function might not operate.

Speciﬁcations

ZONE2

High picture

quality playback

Component video

connectors

S-Video connector

Video connector

Video inputs Video outputs

: When 480i/576i signals are input in the main zone

GFlow of video signals for ZONE2H

S-Video connector

Video connector Video connector

Video inputs Video outputs

Component video

connectors

S-Video connector

Video connector

Monitor

ZONE2

monitor



Speaker Connections

w q

w q w q w q w q w q w q

w q

(R)

(L) (R) (L) (R)

(L)

(L) (R)

Speaker Installation

The illustration below shows a basic example of installation of the ampliﬁer combined with 8 speakers and a monitor.

Subwoofer Center speaker

Surround back speakers

Front speakers

Place the front speakers to the sides of the monitor or screen and as ﬂush with the screen surface as possible.

The table below shows a typical speaker conﬁguration for the AVR-3808.

7.1-channels

(Surround A+B)

7.1-channels

6.1-channels

5.1-channels

3.1-channels

2.1-channels 2-channels

FRONT

CENTER

L R L R L R L R

S S S S S S S S S

S S S S S S S S S S S S S S S S S S S S S S

SURROUND ASURROUND BSURROUND

– – – – – – – – – – – – – – – – – – – – – – – –

Surround speakers

BACK

only

– – – – – – – – – – –

S S

SUBWOOFER

–

S S

ENGLISH

Getting Started Setup Playback Remote Control Multi-Zone Information Troubleshooting

Speaker Connections

Example: 7.1-channels (Surround A+B)

Front speakers Center speaker Subwoofer

Connections

Subwoofer with built-in ampliﬁer

b L : Left R : Right

S S S

When using just one surround back speaker, connect it to the left channel (SBL).

Surround speakers

Surround Back

speakers

Speciﬁcations



ENGLISH

Getting Started Setup Playback Remote Control Multi-Zone Information Troubleshooting Speciﬁcations

Connecting the Speaker Cables

Carefully check the left (L) and right (R) channels and + (red) and – (black) polarities on the speakers being connected to the AVR-3808, and be sure to interconnect the channels and polarities correctly.

Connections

Peel off about 10 mm of sheathing from

the tip of the speaker cable, then either twist the core wire tightly or terminate it.

Turn the speaker terminal

counterclockwise to loosen it.

Insert the speaker cable’s core wire to

the hilt into the speaker terminal.

Turn the speaker terminal clockwise to

tighten it.

NOTE

• Use speakers with an impedance of 6 to 16 Ω/ohms. When using surround A and B speakers simultaneously, use speakers with an impedance of 8 to 16 Ω/ohms.

• Connect the speaker cables in such a way that they do not stick out of the speaker terminals. The protection circuit may be activated if the core wires touch the rear panel or if the + and – sides touch each other (v “Protection circuit”).

• Never touch the speaker terminals while the power supply is connected. Doing so could result in electric shock.

Protection circuit

If speakers with an impedance lower than speciﬁed (for example 4 Ω/ohms speakers) are used for an extended period of time with the volume turned up high, the temperature may rise, activating the protection circuit. When the protection circuit is activated, the speaker output is shut off and the power indicator ﬂashes red. If this happens, unplug the power cord, then check the speaker cable and input cable connections. If the set is extremely hot, wait for it to cool off and improve ventilation around it. Once this is done, plug the power cord back in and turn the set’s power back on. If the protection circuit is activated again even though there are no problems in the ventilation around the set nor in the connections, the set may be damaged. Turn the power off, then contact a DENON service center.

0

065

)%.*

Connecting Equipment with HDMI connectors

With HDMI connections, the video and audio signals can be transferred with a single cable.

MonitorDVD player

b The AVR-3808 is equipped for HDMI version 1.3a. This

version is compatible with other versions, allowing connection to all components equipped with an HDMI connector.

b The AVR-3808 is compatible with 30- and 36-bit Deep

Color.

Compatible

audio format

2-channel linear PCM

Multi-channel linear PCM

Dolby Digital, DTS Bitstream DVD-Video

DSD

Dolby Digital Plus, Dolby TrueHD, DTS-HD

Details

2ch 32-192 kHz 16/20/24 bits

8ch 32-192 kHz 16/20/24 bits

2/5.1ch

2.8224 MHz 1 bit

Bitstream

In order to play the digital video and audio signals of a DVDVideo or DVD-Audio disc using HDMI/DVI connections, both the connected DVD player and monitor must be equipped for a copyright protection system called “HDCP” (Highbandwidth Digital Content Protection). HDCP is a copy protection technology consisting of data encoding and mutual identiﬁcation of the devices. The AVR-3808 is HDCP-compatible. For details on the DVD player or monitor you are using, refer to its operating instructions.

Discs

(examples)

CD, DVD-Video, DVD-Audio

DVD-Audio

SACD

HD DVD, Blu-ray Disc

ENGLISH

NOTE

• Use a CPPM-compatible DVD player to play DVD-Audio discs that are copyright-protected by CPPM.

• The AVR-3808 cannot be controlled from another device via the HDMI cable.

• The audio signals output from the HDMI connector (sampling frequency, bit rate, etc.) may be restricted by the connected device.

• Video signals are not output properly when using devices that are not HDCP-compatible.

• Video signals are not output if the input video signals do not match the monitor’s resolution. In this case, switch the DVD player’s resolution to a resolution with which the monitor is compatible.

• If the GUI menu “Manual Setup” – “HDMI Setup” – “Audio” setting (vpage 30) is set to “Amp”, the sound may be interrupted when the monitor’s power is turned off.

• Use a cable on which the HDMI logo is indicated (a certiﬁed HDMI product) for connection to the HDMI connector. Normal playback may not be possible when using a cable other than one on which the HDMI logo is indicated (a non-HDMI-certiﬁed product).

• If the monitor or DVD player does not support deep color, deep color signal transfer is not possible.

• If the monitor or DVD player does not support xvYCC, xvYCC signal transfer is not possible.

• If the monitor does not support “Auto Lipsync Correction” function, this function will not work.

• When the AVR-3808 and DVD player are connected using an HDMI cable, also connect the AVR-3808 and monitor using an HDMI cable.

• If the connected monitor or DVD player only has a DVI-D connector, use an HDMI/DVI converter cable. When using a DVI cable, no audio signals are transmitted.

• Use a Deep Color compatible cable for connection to Deep Color compatible devices.

When connecting with an HDMI/DVI converter cable (adapter)

• HDMI video signals are theoretically compatible with the DVI format. When connecting to a monitor, etc., equipped with a DVI-D connector, connection is possible using an

HDMI/DVI converter cable, but depending on the combination of components in some cases the video signals will not be output.

• When connecting using an HDMI/DVI converter adapter, the video signals may not be output properly due to poor connections with the connected cable, etc.

Getting Started Setup Playback Remote Control Multi-Zone Information Troubleshooting

Connections

Speciﬁcations

• By default, the HDMI audio signals are output from the speakers connected to the AVR-3808.

• To output the sound from the TV, make the settings at GUI menu “Manual Setup” – “HDMI Setup” – “Audio” – “TV” (vpage 30).



ENGLISH

47*%&0

7*%&0

$0.10/&/57*%&0

: 1# 13

7*%&0

)%.*

*/ */

47*%&0

065

"6%*07*%&0

$0.10/&/57*%&0

: 1# 13

7*%&0

065 065

"6%*0

$0"9*"-

065

065065

)%.*

Getting Started Setup Playback Remote Control Multi-Zone Information Troubleshooting

Connecting the Monitor

• Connect the cables to be used (vpage 8 “Video Conversion Function”).

• With HDMI connections, the video and audio signals can be transferred with a single cable.

• To output the audio signals to the monitor with HDMI connections, set GUI menu “Manual Setup”

Connections

– “HDMI Setup” – “Audio” to “TV” (vpage 30).

Monitor

Connecting the Playback Components

Carefully check the left (L) and right (R) channels and the inputs and outputs, and be sure to interconnect correctly.

DVD Player

• Connect the cables to be used.

• With HDMI connections, the video and audio signals can be transferred with a single cable.

DVD player

NOTE

• The component video connectors may be indicated differently on your monitor. For details, see the

Speciﬁcations

monitor’s operating instructions.

• The audio signals output from the HDMI connectors are only the HDMI input signals.



• Connect an HDP (High-Deﬁnition Player) in the same way.

• When using an optical cable for the digital audio connection, make the settings at GUI menu “Source Select” – “DVD” – “Assign” – “Digital” (vpage 39).

Record Player

(/%

"6%*0

065

"6%*0

$0"9*"-

065

"4%3

CD Player

iPod

ENGLISH

Getting Started Setup Playback Remote Control Multi-Zone Information Troubleshooting

Turntable (MM cartridge)

Connect the cables to be used.

CD player

Use a DENON Control Dock for iPod (ASD-1R, sold separately) to connect the iPod to the AVR-3808. For instructions on the Control Dock for iPod settings, refer to the Control Dock for iPod’s operating instructions.

Example :

iPod

Connections

• When connecting a record player with an MC cartridge, use a commercially available MC head ampliﬁer or a step-up transformer.

• Induction humming (a booming sound) may be produced from the

• With some record players, noise may be generated when the ground

speakers if the volume is raised with no record player connected.

wire is connected. If so, disconnect the ground wire.

NOTE

The AVR-3808’s SIGNAL GND terminal is meant to reduce noise when a record player is connected. This is not a safety ground terminal.

When using an optical cable for the digital audio connection, make the settings at GUI menu “Source Select” – “CD” – “Assign” – “Digital” (vpage 39).

Speciﬁcations

• With the default settings, the iPod can be used connected to the VCR (iPod) connector.

• To assign the iPod to a connector other than VCR (iPod), make the settings at GUI menu “Source Select” – “(input source to which iPod dock assigned)” – “Assign” – “iPod dock” (vpage 39).



ENGLISH

47*%&0

065

"6%*07*%&0

$0.10/&/57*%&0

: 1# 13

7*%&0

065 065

"6%*0

065

$0"9*"-

065

47*%&0

065

"6%*07*%&0

7*%&0

065 065

015*$"-"6%*0

065

Getting Started Setup Playback Remote Control Multi-Zone Information Troubleshooting

TV/CABLE Tuner

Satellite Receiver

Connect the cables to be used.

Connections

TV tuner

Connect the cables to be used.

DBS / BS tuner

When using an optical cable for the digital audio connection, make the settings at GUI menu “Source Select” – “TV/CBL” – “Assign” – “Digital” (vpage 39).

Speciﬁcations



• When using a coaxial digital cable for the digital audio connection, make the settings at GUI menu “Source Select” – “SAT” – “Assign” – “Digital” (vpage 39).

• When using a component video cable for the video connection, make the settings at GUI menu “Source Select” – “SAT” – “Assign” – “Component” (vpage 39).

Connecting the Recording Components

47*%&0

3- 3-

*/*/065

"6%*07*%&0

*/065

015*$"-

065

"6%*07*%&0

065

47*%&0

3- 3-

*/*/065

"6%*07*%&0

065

"6%*07*%&0

065 */065

015*$"-

Carefully check the left (L) and right (R) channels and the inputs and outputs, and be sure to interconnect correctly.

ENGLISH

Getting Started Setup Playback Remote Control Multi-Zone Information Troubleshooting

Video Cassette Recorder

Connect the cables to be used.

Video cassette recorder

Digital Video Recorder

Connect the cables to be used.

Digital video recorder

or or

• Make analog connections if you wish to record analog audio signals.

• When recording via the AVR-3808, the playback device’s cable must be of the same type as the cable used to connect the AVR-3808’s DVR OUT connector. Example: TV IN → S-Video cable : DVR OUT → S-Video cable TV IN → Video cable : DVR OUT → Video cable

• When using a component video cable for the video connection, make the settings at GUI menu “Source Select” – “DVR” – “Assign” – “Component” (vpage 39).

NOTE

Do not connect the output of the component connected to the AVR-3808’s OPTICAL2 output connector to any input connector other than OPTICAL2.

• When recording via the AVR-3808, the playback device’s cable must be of the same type as the cable used to connect the AVR-3808’s VCR OUT connector. Example: TV IN → S-Video cable : VCR OUT → S-Video cable TV IN → Video cable : VCR OUT → Video cable

• When using a component video cable for the video connection, make the settings at GUI menu “Source Select” – “VCR” – “Assign” – “Component” (vpage 39).

NOTE

Do not connect the output of the component connected to the AVR-3808’s OPTICAL3 output connector to any input connector other than OPTICAL3.

Connections

Speciﬁcations



ENGLISH

3- 3-

065 */065

015*$"-

"6%*0

%&/0/-*/,

"6%*0

Getting Started Setup Playback Remote Control Multi-Zone Information Troubleshooting

CD Recorder / MD Recorder / Tape Deck

Make analog connections if you wish to record analog audio signals, or digital connections if you wish to record digital audio signals, depending on the types of connectors on the components being used.

Connections

CD recorder / MD recorder / Tape deck

Connections to Other Devices

Carefully check the left (L) and right (R) channels and the inputs and outputs, and be sure to interconnect correctly.

Components Equipped with a DENON LINK connector

Multi-channel playback is possible with DVD-Audio discs, Super Audio CD, etc.

DVD player

NOTE

Do not connect the output of the component connected to the AVR-3808’s OPTICAL3 output connector to any input connector other than OPTICAL3.

Speciﬁcations



To use with DENON LINK connections, make the settings at GUI menu “Source Select” – “Assign” – “Digital” – “DENON LINK” (vpage 39).

47*%&0

065

"6%*07*%&0

7*%&0

065 065

015*$"-"6%*0

065

46#

800'&3

$&/5&3 463306/%

#"$,

463306/%

'30/5

"6%*0

Video Camera / Game Console

46#

800'&3

$&/5&3 463306/%

#"$,

463306/%

'30/5

"6%*0

Video camera / Game console

Component with Multi-channel Output connectors

DVD player / Super Audio CD player / External decoder

ENGLISH

Getting Started Setup Playback Remote Control Multi-Zone Information Troubleshooting

External Power Ampliﬁer

Power ampliﬁer

Connections

When using just one surround back speaker, connect it to the left

• To play the analog input signals input to the EXT. IN connectors, press the INPUT MODE button on the main unit or INPUT button

channel (SBL).

on the main remote control unit and select “EXT. IN” or make the settings at GUI menu “Source Select” – “(input source)” – “Input Mode” – “Input Mode” – “EXT. IN” (vpage 38).

• The video signal can be connected in the same way as a DVD player

Speciﬁcations

(vpage 12).

• To play copyright-protected discs, connect the AVR-3808’s EXT. IN connector with the DVD player’s analog multi-channel output connector.



ENGLISH

Getting Started Setup Playback Remote Control Multi-Zone Information Troubleshooting Speciﬁcations

USB Port

n Front panel n Rear panel

USB memory device USB memory device

Connections

• In the initial status, USB memory devices can be used by connecting them to the USB port on the front panel.

• To change the port to be used, see “USB Select” on page 40.

• For instructions on playing the ﬁles on a USB memory device, see page 56.

NOTE

• Set to the USB port you want to use.

• The AVR-3808 is equipped with two USB ports, one each on the front and rear panels. It is not possible to use the set with USB memory devices connected to both the ports at the same time. Select the USB port you want to use at the GUI menu “Source Select” – “NET/USB” – “Playback Mode” – “USB Select”.

• Do not use the extension cable for connecting the USB memory device to the AVR-3808’s USB port.

Use of the extension cable may cause harmful interference.



Antenna terminals

An FM antenna cable plug can be connected directly.

Direction of broadcasting station

FM antenna

75 Ω/ohms Coaxial cable

FM indoor antenna

(supplied)

AM loop antenna (supplied)

ENGLISH

Getting Started Setup Playback Remote Control Multi-Zone Information Troubleshooting

Connections

AM loop antenna assembly

Remove the vinyl tie and take out the connection line.

a. With the antenna on top of

any stable surface.

Mount

Ground

Connect to the AM antenna terminals.

Bend in the reverse direction.

b. With the antenna attached

to a wall.

Installation hole Mount on wall, etc.

AM outdoor antenna

Connection of AM antennas

1. Push the lever.

2. Insert the conductor.

NOTE

• Do not connect two FM antennas simultaneously.

• Even if an external AM antenna is used, do not disconnect the AM loop antenna.

• Make sure the AM loop antenna lead terminals do not touch metal parts of the panel.

3. Return the lever.

Speciﬁcations



ENGLISH

Getting Started Setup Playback Remote Control Multi-Zone Information Troubleshooting Speciﬁcations

Network Audio

Connections

Router

Internet

Modem

To WAN side

To LAN port To LAN port

Computer

LAN port/

Ethernet

connector

Required system n Broadband Internet connection

A broadband line connection to the Internet is required in order to use the AVR-3808’s Internet radio function and ﬁrmware update.

n Modem

This is a device that is connected to the broadband line to communicate with the Internet. Some are integrated with the router.

n Router

When using the AVR-3808, we recommend you use a router

equipped with the following functions:

• Built-in DHCP (Dynamic Host Conﬁguration Protocol) server This function automatically assigns IP addresses on the LAN.

• Built-in 100BASE-TX switch When connecting multiple devices, we recommend a switching

hub with a speed of 100 Mbps or greater.

n Ethernet cable (CAT-5 or greater recommended)

• The AVR-3808 does not come with an Ethernet cable.

• Some ﬂat type Ethernet cables are easily affected by noise. We recommend using a normal type cable.

• For the Ethernet cable, used a shielded twisted pair (STP) cable. Do not use an unshielded twisted pair (UTP) cable, as it may exceed

noise standard limits.

n Computer

A computer with the following speciﬁcations is required to use a music server:

• OS Windows® XP Service Pack2, Windows Vista

• Software (Prepare one of the following.)

· .NET Framework 1.1 and Windows Media Connect (Windows XP)

· Windows Media Player ver.11

· DLNA-compatible server software

• Internet browser Microsoft Internet Explorer 5.01 or later

• LAN port

• 300 MB or more free disk space b Free disk space is required to store music ﬁles. The following

sizes are approximate.

For connections to the Internet, contact an ISP (Internet Service Provider) or a computer shop.

NOTE

• A contract with an ISP is required to connect to the Internet. No additional contract is needed if you already have a broadband

connection to the Internet.

• The types of routers that can be used depend on the ISP. Contact an ISP or a computer shop for details.

• Depending on the server, video ﬁles may be displayed, but they cannot be played on the AVR-3808.

n Others

• If you have an Internet provider contract for a line on which network

settings are made manually, make the settings at GUI menu “Manual Setup” – “Network Setup” (vpage 32, 33).

• With the AVR-3808, it is possible to use the DHCP and Auto IP

functions to make the network settings automatically.

• When using a broadband router (DHCP function), the AVR-3808

sets the IP address, etc., automatically.

When using the AVR-3808 connected to a network with no DHCP

function, make the settings for the IP address, etc., at GUI menu “Manual Setup” – “Network Setup” (vpage 32, 33).

• The AVR-3808 is not compatible with PPPoE. A PPPoE-compatible

router is required if you have a contract for a line of the type with which the PPPoE is set.

• Depending on the ISP with which you have your contract, it may

be necessary to make proxy server settings to use the Internet radio function. If you made proxy server settings on the computer to connect to the Internet, make the proxy server settings on the AVR-3808 in the same way.

0

Format Bit rate Per minute Per hour

MP3 / WMA

MPEG-4 AAC

WAV (LPCM)

FLAC

128 kbps Approx. 1 MB Approx. 60 MB 192 kbps Approx. 1.5 MB Approx. 90 MB 256 kbps Approx. 2 MB Approx. 120 MB

392 kbps Approx. 3 MB Approx. 180 MB 1400 kbps Approx. 10 MB Approx. 600 MB 1080 kbps Approx. 7.7 MB Approx. 464 MB

Multi-Zone

"69 065

"6%*0

*/*/

7*%&0

"6%*07*%&0

ZONE2 or ZONE3 Pre-out Connections

• If another power ampliﬁer or pre-main (integrated) ampliﬁer is connected, the ZONE2 or ZONE3 pre-out (variable or ﬁxed level) connectors can be used to play a different program source in ZONE2 or ZONE3 the same time (vpage 69 ~ 72).

• When using an S-Video cable or a video cable for connection between the AVR-3808 and an input device, connect to the video connectors.

• The ZONE2 video out is only for ZONE2.

Monitor (ZONE2)

Power amplier (ZONE2 or ZONE3)

ENGLISH

Getting Started Setup Playback Remote Control Multi-Zone Information Troubleshooting

External Controller

Connections

RS-232C connector

This connector is used for an external controller.

b If you wish to control the AVR-3808 from an

external controller using the RS-232C connector, perform the operation below beforehand.

q Turn the AVR-3808’s power. w Turn off the AVR-3808’s power from the external

controller.

e Check that the AVR-3808 is in the standby mode.

• When using in combination with an RF Remote Controller (RC-7000CI, sold separately) or RF Remote Receiver (RC-7001RCI, sold separately) two-way communication with an RF Remote Controller is possible.

The AVR-3808’s status information as well as iPod and Internet audio music ﬁles can be browsed watching

the RF Remote Controller’s display. For details, refer to the operating instructions of the respective devices.

• When used in combination with an RF Remote Controller or RF Remote Receiver, make the settings at GUI menu “Manual Setup” – “Option Setup” – “2Way Remote” – “Used” (vpage 35).

Input

Infrared retransmitter

Output

Infrared sensor

Extension jack for future use.

NOTE

• For the audio output, use high quality pin-plug cords so that no induction humming or noise is produced.

• For instructions on installing and operating separately sold devices, refer to the respective devices’ operating instructions.

• To conduct multi-zone playback, see “Amp Assign / Multi-Zone Connections and Operations” (vpage 69 ~ 72).

Trigger output jacks

The power of an external device equipped with a trigger input jack can be turned on and off in association with operations on the AVR-3808. For details, see GUI menu “Manual Setup” – “Option Setup” – “Trigger Out 1” or “Trigger Out 2” (vpage

35).

• Output level: 150 mA/12 V Check the trigger input conditions of the connected device.

• If the trigger input level of the connected device is higher than 150 mA/12 V and depending on the short-circuiting conditions, the AVR-3808’s protection circuit may be activated, in which case “TRIGGER PROTECT” appears on the display. If this happens, turn off the AVR-3808’s power and disconnect the connected device.



Speciﬁcations

ENGLISH

Getting Started Playback Remote Control Multi-Zone Information Troubleshooting

Connecting the Power Cord

Wait until all connections have been completed before connecting the power cord.

Connections Setup

Power cord

(included)

Connection to the AC outlet

• This outlet supply power to external audio devices.

• The power supplied from these outlets turns on and off together with the set’s power switch.

• Audio equipment with a total power consumption of 100 W (0.43 A) can be connected.

To household

power outlet

(AC 230 V, 50 Hz)

GUI Menu Operations

With the AVR-3808, settings and operations for most functions can be performed by operating while looking at the GUI menus displayed on the monitor screen.

The GUI cannot be superimposed when xvYCC signals and component 1080p signal, computer’s resolution (e.g. VGA) are input.

Example of the Display of the GUI Mark at a Title

Items for which this mark is indicated at the title can be operated from the GUI. We recommend performing such operations from the GUI.

NOTE

• Insert the AC plugs securely. Incomplete connections could cause noise.

• Only use the AC outlet to plug in audio devices. Do not use them as power supplies for hairdryers or anything other than audio equipment.

Once Connections are Completed

Turning the Power On (vpage 47)

Speciﬁcations

Auto Setup

Optimize settings for speakers in use.

This is the GUI icon for this setting item or for the menu series to which this item belongs.

Example of Display of Default Values

In lists of selectable items or adjustable ranges, the item surrounded by a border is the default value.

[Selectable items] 7.1 (B) 7.1 5.1



SOURCE SELECT

TUNER PHONO

HDP

DVD

TV/CBL

Select input source and make playback settings

AUTO S ETUP

1 2 3 4 5

Start

RETURN

Amp As sign

Config 7.1(B)

STEP1 Speaker Det ection Please place the microphone at ear height at main li stening position.

Start Auto Setup

Enter Cancel

Assign

Input Mode Rename Other

Examples of GUI Screen Displays

Some typical examples are described below.

Example: Browse Menu (Top Menu)

Selected item

name

List of subsequent items

Cursor Position Display

n Icon

Switch the selected item

Switch to the next item

ENGLISH

Operations

The same operation is possible on the main unit or remote control unit.

Press the MENU button.

The GUI menu is displayed.

b To operate from the main remote control unit, be sure to set the

remote control unit to the AMP mode.

Press the u i p button to select the menu to be set

or operated.

b To return to the previous item, press the o or RETURN button.

Getting Started Connections Playback Remote Control Multi-Zone Information Troubleshooting

Setup

Guidance text for item at

cursor position

Example: Menus with Illustrations

(Auto Setup)

Operation guidance text

Guidance text for item at cursor

position

Operation step indicators

Illustration

Operation

button guidance

Selected item

Switch the selected item

n List

Selected item

Switch to the next item

b Switch the selected item using

ui.

Press the ENTER button to enter the setting.

Press the MENU button to nish.

When “Screensaver” is set to “ON”, the screensaver is activated if no operation is performed for about 3 minutes.

Speciﬁcations



ENGLISH

Getting Started Connections Playback Remote Control Multi-Zone Information Troubleshooting Speciﬁcations

GUI Menu Map

Setup

Information

(vpage 45, 46)

n Status

• MAIN ZONE

• ZONE2/3

n Audio Input Signal n HDMI Information n Auto Surround Mode n Quick Select n Preset Station

Parameter

(vpage 42 ~ 45)

n Audio

• Surround Parameters

· Mode

· Cinema EQ

· DRC

· D.COMP

· LFE

· Center Image

· Panorama

· Dimension

· Center Width

· Delay Time

· Effect

· Effect Level

· Room Size

· AFDM

· SB CH Out

· Subwoofer Att.

· Subwoofer

· Default

• Tone

· Tone Defeat

· Bass

· Treble

• Room EQ

• RESTORER

• Night Mode

• Audio Delay

n Picture Adjust

• Contrast

• Brightness

• Chroma Level

• Hue

Source Select

n TUNER (FM/AM)

• Play

• Auto Preset

• Preset Skip

• Preset Name

• Input Mode

• Rename

• Other

· Video Select

· Source Level

(vpage 37 ~ 40)

Surround Mode

(vpage 40, 41)

n STEREO n DIRECT n STANDARD n DOLBY PLIIx, DOLBY PLII or

DOLBY PL

n DTS NEO:6 n 7CH STEREO n WIDE SCREEN n SUPER STADIUM n ROCK ARENA n JAZZ CLUB n CLASSIC CONCERT n MONO MOVIE n VIDEO GAME n MATRIX n VIRTUAL

n PHONO

• Input Mode

• Rename

• Other

· Video Select

· Source Level

n CD, DVD, HDP, TV/CBL, SAT, VCR, DVR, V.AUX

Auto Setup

n Auto Setup

• STEP1: Speaker Detection

• STEP2: Measurement

• STEP3: Calculation

• STEP4: Check

• STEP5: Store

Manual Setup

n Speaker Setup (vpage 28, 29)

• Speaker Conﬁguration

• Subwoofer Mode

• Distance

• Channel Level

• Crossover Frequency

• Surround Speaker

n HDMI Setup (vpage 30)

• i/p Scaler

• Resolution

• Progressive Mode

• Aspect

• Color Space

• RGB Range

• Auto Lip Sync

• Audio

n Audio Setup (vpage 30, 31)

• EXT. IN Setup

· Surround Speaker

· Subwoofer Level

• 2ch Direct/Stereo

• Downmix Option

• Auto Surround

• Manual EQ

(vpage 25 ~ 27)

(vpage 28 ~ 36)

• Play (iPod)

• Playback Mode (iPod)

• Assign

• Input Mode

• Rename

• Other

· Video Select Video Convert (Excluding CDs)

· Source Level

n Option

• Room EQ

• Direct Mode

• Mic Select

n Network Setup (vpage 32, 33)

• Network Setup

• Other

· Power Saving

· Character

· PC Language

• Network Information

n Zone Setup (vpage 33, 34)

• ZONE2

· Bass

· Treble

· HPF

· Lch Level

· Rch Level

· Channel

· Volume Level

· Volume Limit

· Power On Level

· Mute Level

• ZONE3

· Bass

· Treble

· HPF

· Lch Level

· Rch Level

· Channel

· Volume Level

· Volume Limit

· Power On Level

· Mute Level

n NET/USB

• Play

• Playback Mode

• Input Mode

• Rename

• Other

· Video Select

· Source Level

n Parameter

• Speaker Conﬁguration Check

• Distance Check

• Channel Level Check

• Crossover Check

• EQ Check

• Restore

Option Setup (vpage 34 ~ 36)

• Amp Assign

• Volume Control

· Volume Limit

· Power On Level

· Mute Level

• Source Delete

• GUI

· Screensaver

· Wall Paper

· Format

· Text

· Master Volume

· NET/USB

· iPod

· Tuner

• Quick Select Name

• Trigger Out 1

• Trigger Out 2

• Remote ID

• 2Way Remote

• Dimmer

• Setup Lock

• Maintenance Mode

• Firmware Update

• Add New Feature

n Language (vpage 36)



Auto Setup

• Audyssey MultEQ problems in the listening environment to create the best audio experience for your home theater.

• It optimizes a large listening area where one or more listeners are seated.

Measurements are performed by placing the calibrated microphone

(DM-A405) successively at multiple positions throughout the listening area as shown in Example q. For best results, it is strongly recommended to measure 6 or more positions so that the measurements have the proper spatial weighting.

Even if the listening environment is small as shown in Example w,

measuring at multiple points throughout the listening environment results in more effective correction.

Example q Example w

( :Measuring positions)

XT automatically measures the acoustical

Preparations

Connect the included calibrated setup microphone to

the SETUP MIC jack on the main unit.

The auto setup screen appears automatically.

Sound receptor

Place the microphone at ear height on a tripod or stand

with the microphone pointing directly up towards the ceiling.

Setup

microphone

ENGLISH

Getting Started Connections Playback Remote Control Multi-Zone Information Troubleshooting

Setup

About the main listening position (*M)

The main listening position refers to the most central position where one would normally sit within the listening environment. MultEQ XT uses the measurements from this position to calculate speaker distance, level, polarity, and the optimum crossover value for the subwoofer.

To make manual adjustments to the settings, see page 28, 29.

b It is not recommended to hold it in your hand. Be sure that the

path from microphone to the speakers is not blocked by objects. Avoid placing the microphone close to a seat back or wall as sound reﬂections may give inaccurate results.

When using a subwoofer, make the following settings before starting the auto setup procedure:

• Defeat the volume and crossover controls if possible

• If this is not possible then set

•

Volume: “12 o’clock” position

•

Crossover frequency: “Maximum/Highest Frequency”

•

Low pass ﬁlter: “Off”

•

Standby mode: “Off”

NOTE

• Do not disconnect the setup microphone until the auto setup procedure is completed.

• When using headphones, unplug the headphones before starting the auto setup procedure.

Speciﬁcations



ENGLISH

Getting Started Connections Playback Remote Control Multi-Zone Information Troubleshooting Speciﬁcations

Auto Setup

Optimize settings for speakers in use.

F Menu tree F

Auto Setup

a Auto Setup s Option

Setup

Start

Start Auto Setup. The Audyssey MultEQ XT Auto Setup process automatically calculates the size, level, distance, bass management crossover frequency, and optimal settings for each speaker and subwoofer. Audyssey MultEQ XT corrects acoustical distortions within the listening area. Before starting, connect and position all your speakers. Once started, MultEQ XT will play a series of test tones through each speaker.

d Parameter

a Auto Setup

The settings are performed automatically.

GAuto setup ﬂowH

STEP1: Speaker Detection

STEP2: Measurement (2 to 8 positions)

STEP3: Calculation

STEP4: Check

STEP5: Store

Conﬁguration

The speaker system to be measured can be selected ahead of time here.

[Selectable items] 7.1 (B) 7.1 5.1

Setting the correct speaker conﬁguration can reduce the time required to measure during the auto setup procedure as the system will not have to look for speakers that are not connected.

Amp Assign

Advanced setting : changes power ampliﬁer assignment.

NOTE

The items selectable at “Conﬁguration” differ according to the “Amp Assign” settings.

STEP1 : Speaker Detection

The speaker connection and polarity are detected at the ﬁrst measurement position. The following attributes are also determined at this time: “Speaker Size”, “Speaker Distance”, “Channel Level”, “Crossover Frequency”. Once the measurements are completed, the results are displayed.

NOTE

• Loud test tone may be played during Audyssey MultEQ XT Automatic Speaker Setup. This is part of normal operation. If there is background noise in room, these test tones will increase in volume.

• Do not stand between the speakers and setup microphone or allow obstacles in the path while the measurements are being made. This will cause inaccurate readings.

• Quiet the listening environment before beginning measurements and refrain from talking. Turn off air conditioning units or other devices that emit noise if at all possible as measurements may be affected by these sounds.

• Operating the MASTER VOLUME knob on the main unit or the VOL +/– buttons on the remote control unit during the measurements will cancel the measurements.

• Do not change the speaker connections or subwoofer volume after “STEP1”.

STEP2: Measurement

After completing a measurement position, move the microphone to the next position.

Measure at least 6 positions (main listening position and at least 5 other surrounding positions). For best results it is recommend measuring 6

or more positions (with a maximum of 8 positions).

STEP3: Calculation

When “Calculate” is selected at “STEP2”, the measurements taken are analyzed automatically to determine how the speaker system interacts with the room.

The time required for this analysis depends on the number of speakers connected. The higher the number of speakers, the longer the time required for analysis.

STEP4: Check

Once the auto setup procedure is complete, a measuring result check screen appears. Select any item whose results you want to check to review the results.

Values that are different from the actual distance may be set for speakers with built-in ﬁlters (subwoofers, etc.). This is because ﬁlters add electrical delay to the signal that should be compensated.

STEP5: Store

The auto setup measurement results are stored in the AVR-3808.

NOTE

Do not turn the power off while the settings are being stored.

If an error message appears during the measurements, check “Error Messages” (vpage 27), take the advised action, then start the measurements again.


