Denon AVR-3311-CI Service Manual

e

SERVICE MANUAL

MODEL JP E3 E2 EK KA E1 E1K E1C

Ver. 5

Please refer to the MODIFICATION NOTICE.

AVR-3311CI

AVR-3311

P

s

AV SURROUND RECEIVER

P P

For purposes of improvement, specications and design are subject to change without notice.

•

Please use this service manual with referring to the operating instructions without fail.

•

Some illustrations using in this service manual are slightly different from the actual set.

•

e

D&M Holdings Inc.

S0156-1V05DM/DG1010

WARNING: Violators will be prosecuted to the maximum extent possible.

SAFETY PRECAUTIONS

The following check should be performed for the continued protection of the customer and service technician.

LEAKAGE CURRENT CHECK

Before returning the unit to the customer, make sure you make either (1) a leakage current check or (2) a line to chassis resistance check. if the leakage current exceeds 0.5 milliamps, or if the resistance from chassis to either side of the power cord is less than 460 kohms, the unit is defective. Be sure to test for leakage current with the AC plug in both polarities, in addition, in each power ON, OFF and STANDBY mode, if applicable.

CAUTION

Please heed the points listed below during servicing and inspection.

◎Heed the cautions!

Spots requiring particular attention when servicing, such as the cabinet, parts, chassis,etc., have cautions indicated on labels. be sure to heed these causions and the cautions indicated in the handling instructions.

◎Caution concerning electric shock!

(1) An AC voltage is impressed on this set, so touching

internal metal parts when the set is energized could cause electric shock. Take care to avoid electric shock, by for example using an isolating transformer and gloves when servicing while the set is energized, unplugging the power cord when replacing parts, etc.

(2) Tere are high voltage parts inside. Handle with extra

care when the set is energized.

◎ Caution concerning disassembly and

assembly!

Through great care is taken when manufacturing parts from sheet metal, there may in some rare cases be burrs on the edges of parts which could cause injury if ngers are moved across them. Use gloves to protect your hands.

◎Only use designated parts!

The set's parts have specific safety properties (fire resistance, voltage resistance, etc.). For replacement parts, be su re t o use part s whic h have the same poroperties. In particular, for the important safety parts that are marked z on wiring diagrams and parts lists, be sure to use the designated parts.

◎ Be sure to mount parts and arrange the wires

as they were originally!

For safety seasons, some parts use tape, tubes or other insulating materials, and some parts are mounted away from the surface of printed circuit boards. Care is also taken with the positions of the wores omsode amd clamps are used to keep wires away from heating and high voltage parts, so be sure to set everything back as it was originally.

◎Inspect for safety after servicing!

Check that all screws , parts and wi res removed or disconnected for servicing have been put back in their original positions, inspect that no parts around the area that has been serviced have been negatively affected, conduct an inslat ion ch eck on the exter nal metal connectors and between the blades of the power plug, and otherwise check that safety is ensured.

(Insulation check procedure) Unplug the power cord from the power outlet, disconnect the antenna, plugs, etc., and turn the power switch on. Using a 500V insulation resistance tester, check that the inplug and the externally exposed metal parts (antenna terminal, headphones terminal, input terminal, etc.) is 1MΩ or greater. If it is less, the set must be inspected and repaired.

CAUTION

Concerning important safety

parts

Many of the electric and structural parts used in the set have special safety properties. In most cases these properties are difficult to distinguish by sight, and using replacement parts with higher ratings (rated power and withstand voltage) does not necessarily guarantee that safety performance will be poreserved. Parts with safety properties are indicated as shown below on the wiring diagrams and parts lists is this service manual. Be sure to replace them with parts with the designated part number.

(1) Schematic diagrams ......Indicated by the z mark.

(2) Parts lists ......Indicated by the z mark.

Using parts other than the designated parts could result in electric shock, res or other dangerous situations.

2

NOTE FOR SCHEMATIC DIAGRAM

NOTE FOR PARTS LIST

WARNING:

Parts marked with this symbol z have critical characteristics. Use ONLY replacement parts recommended by the manufacture

CAUTION:

Before returning the unit to the customer, make sure you make either (1) a leakage current check or (2) a line to chassis resistance check. If the leakage current exceeds 0.5 milliamps, or if the resistance from chassis to either side of the power cord is less than 460 kohms, the unit is defective.

WARNING:

DO NOT return the unit to the customer until the problem is located and corrected.

NOTICE:

ALL RESISTANCE VALUES IN OHM. k=1,000 OHM / M=1,000,000 OHM ALL CAPACITANCE VALUES IN MICRO FARAD. P=MICRO-MICRO FARAD EACH VOLTAGE AND CURRENT ARE MEASURED AT NO SIGNAL INPUT CONDITION. CIRCUIT AND PARTS ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE.

r.

NOTE FOR PARTS LIST

1.

Parts for which "nsp" is indicated on this table cannot be supplied.

2.

When ordering of part, clearly indicate "1" and "I" (i) to avoid mis-supplying.

3.

Ordering part without stating its part number can not be supplied.

4.

Part indicated with the mark "★" is not illustrated in the exploded view.

5.

Not including General-purpose Carbon Film Resistor in the P.W.Board parts list. (Refer to the Schematic Diagram for those parts.)

6.

Not including General-purpose Carbon Chip Resistor in the P.W.Board parts list. (Refer to the Schematic Diagram for those parts.)

WARNING:

● Resistors

Ex.: RN

* Resistance

Capacitors

●

Ex.: CE

* Capacity (electrolyte only)

* Capacity (except electrolyte)

･ When the dielectric strength is indicated in AC,"AC" is included after the dieelectric strength value.

Parts marked with this symbol z have critical characteristics. Use ONLY replacement parts recommended by the manufacturer.

Type

RD : Carbon RC : Composition RS : Metal oxide film RW: winding RN : Metal film RK : Metal mixture

2

Indicates number of zeros after effective number. 2-digit effective number.

1-digit effective number.

: Units: ohm

Type

CE : Aluminum foil

electrolytic

CA : Aluminium solid

electrolytic

CS : Tantalum electrolytic CQ: Film CK : Ceramic CC : Ceramic CP : Oil CM: Mica CF : Metallized CH : Metallized

2

Indicates number of zeros after effective number.

･ Units:μF.

･ Units:pF

2-digit effective number.

2

14K

Shape and performance

2-digit effective number, decimal point indicated by R.

04W

Shape and performance

Indicates number of zeros after efective number. (More than 2) 2-digit effective number.

2E

Power

2B : 1/8 W 2E : 1/4 W 2H : 1/2 W 3A : 1 W 3D : 2 W 3F : 3 W 3H : 5 W

1800ohm=1.8kohm1 8

1.2ohm1 R 2

1H

Dielectric strength

0J : 6.3 V 1A : 10 V 1C : 16 V 1E : 25 V 1V : 35 V 1H : 50 V 2A : 100 V 2B : 125 V 2C : 160 V 2D : 200 V 2E : 250 V 2H : 500 V 2J : 630 V

2200μF2 2

2200pF=0.0022μF2 2

182

Resistance

F : ±1% G : ±2% J : ±5% K : ±10% M : ±20%

3R2

CapacityMAllowable

G

Allowable error

P : Pulse-resistant type NL : Low noise type NB : Non-burning type FR : Fuse-resistor F : Lead wire forming

error

F : ±1% G : ±2% J : ±5% K : ±10% M : ±20% Z : ±80%

: - 20%

P : +100% C : ±0.25pF D : ±0.5pF = : Others

FR

Others

BP

Others

HS : High stability type BP : Non-polar type HR : Ripple-resistant type DL : For change and discharge HF : For assuring high requency U : UL part C : CSA part W : UL-CSA part F : Lead wire forming

2

･ Units:μF.

1

･ Units:pF

2.2μF2 R

1-digit effective number.

2-digit effective number, decimal point indicated by R

220pF2 2

Indicates number of zeros after effective numver. (0 or 1)

2-digit effective number.

3

TECHNICAL SPECIFICATIONS

n Audio Section

• Power ampliﬁer Rated output :

Front : 125 W + 125 W (8 Ω, 20 Hz – 20 kHz with 0.05 % T.H.D.) 165 W + 165 W (6 Ω, 1 kHz with 0.7 % T.H.D.)

Center : 125 W (8 Ω, 20 Hz – 20 kHz with 0.05 % T.H.D.) 165 W (6 Ω, 1 kHz with 0.7 % T.H.D.)

Surround : 125 W + 125 W (8 Ω, 20 Hz – 20 kHz with 0.05 % T.H.D.) 165 W + 165 W (6 Ω, 1 kHz with 0.7 % T.H.D.)

Surround back / Front height / Front wide : 125 W + 125 W (8 Ω, 20 Hz – 20 kHz with 0.05 % T.H.D.) 165 W + 165 W (6 Ω, 1 kHz with 0.7 % T.H.D.)

Dynamic power : 130 W x 2ch (8 Ω) 190 W x 2ch (4 Ω)

Output connectors : 6 – 16 Ω

• Analog

Input sensitivity/Input impedance : Frequency response: 10 Hz – 100 kHz — +1, –3 dB (DIRECT mode) S/N: 102 dB (IHF–A weighted, DIRECT mode) Distortion: 0.005 % (20 Hz ~ 20 kHz) (DIRECT mode) Rated output: 1.2 V

• Digital D/A output:

Total harmonic distortion — 0.008 % (1 kHz, at 0 dB)

Rated output — 2 V (at 0 dB playback)

S/N ratio — 102 dB Dynamic range — 100 dB

Digital input: Format — Digital audio interface

• Phono equalizer (PHONO input — REC OUT)

Input sensitivity:

2.5 mV

RIAA deviation: ±1 dB (20 Hz to 20 kHz) S/N: 74 dB (A weighting, with 5 mV input) Rated output: 150 mV Distortion factor: 0.03 % (1 kHz, 3 V)

n Video Section

• Standard video connectors Input/output level and impedance : Frequency response : 5 Hz – 10 MHz — +1, –3 dB

• Color component video connector Input/output level and impedance :

PB / CB signal — 0.7 Vp-p, 75 Ω PR / CR signal — 0.7 Vp-p, 75 Ω

Frequency response : 5 Hz – 60 MHz — +0, –3 dB (when “Video

Convert” set to “OFF”)

DIMENSION

200 mV/47 kΩ

1 Vp-p, 75 Ω

Y (brightness) signal — 1 Vp-p, 75 Ω

s

n HD Radio section (for E3)

[FM](Note: μV at 75 Ω, 0 dBf = 1 x 10

–15

W)

Receiving Range :

87.5 MHz – 107.9 MHz [AM]530 kHz – 1710 kHz

[FM]

Usable Sensitivity :

1.5 μV (14.8 dBf) [AM]20 μV

[FM]

S/N (IHF-A) :

MONO 78 dB [AM]

[FM]

STEREO 68 dB HD 85 dB 85 dB

Total harmonic Distortion (at 1 kHz) :

MONO 0.1 % [AM]

[FM]

STEREO 0.2 % HD 0.02 % 0.02 %

n Tuner section (for E2, E1C)

[FM](Note: μV at 75 Ω, 0 dBf = 1 x 10

–15

W)

Receiving Range :

87.5 MHz – 108.0 MHz [AM]522 kHz – 1611 kHz

[FM]

Usable Sensitivity :

1.2 μV (12.8 dBf) [AM]18 μV

[FM]

50 dB Quieting Sensitivity :

MONO 2.0 μV (17.3 dBf)

[FM]

STEREO 42 μV (34.5 dBf)

S/N (IHF-A) :

MONO 72 dB

[FM]

STEREO 67 dB

Total harmonic Distortion (at 1 kHz) :

MONO 0.3 %

[FM]

STEREO 0.7 %

n General

Power supply : AC 120 V, 60 Hz (for E3)

AC 230 V, 50 Hz (for E2) AC 220 V, 50 Hz (for E1C)

Power consumption :

670 W

0.1 W (Standby)

2.2 W (CEC standby)

Maximum external dimensions :

434 (W) x 171 (H) x 381 (D) mm (17-3/32” x 6-47/64” x 15”) Weight : 12.2 kg (26 lbs 14.3 oz)

n Remote Control Unit (RC-1146)

Batteries : R6/AA Type (two batteries) Maximum external dimensions :

53 (W) x 224 (H) x 28 (D) mm (2-3/32” x 8-13/16” x 1-7/64”) Weight : 160 g (5.6 oz, including batteries)

n Remote Control Unit (RC-1148)

Batteries : R03/AAA Type (two batteries) Maximum external dimensions :

49 (W) x 220 (H) x 24.5 (D) mm (1-59/64” x 8-21/32” x 31/32”)

Maximum external dimensions :

114 g (Approx 4 oz, including batteries)

266

44.2

34.5

21.4

214.5

338.9

380.8

54.7

85

35.5

171

155

344 434

16

20.5

4

CAUTION IN SERVICING

Before the Digital P.W.B. are replaced

If you cannot specify the cause of the digital PWB defect, carry out "Initializing" → "Update to latest rmware". The defect may be cleared.

See the following for the method of initializing the μcom.

・

Initializing AV SURROUND RECEIVER

AV SURROUND RECEIVER initialization should be performed when the μcom, peripheral parts of μcom, and Digital P.W.B. are replaced.

1. Turn off the power using ON/STANDBY button.

2. Press ON/STANDBY button while simultaneously pressing STANDARD and DSP SIMULATION buttons.

3. Check that the entire display is ashing with an interval of about 1 second, and release your ngers from the 2 buttons and the microprocessor will be initialized.

Note: •If step 3 does not work, start over from step 1.

All user settings will be lost and this factory setting will be recovered when this initialization mode.

•

So make sure to memorize your setting for restoring after the initialization.

2,31,2

Service Jigs

When you repair the printing board, you can use the following JIG (Extension cable kit). Please order to Denon Ofcial Service Distributor in your region if necessary.

8U-110084S : EXTENSION UNIT KIT : 1 Set (Refer to 21 page)

5

DISASSEMBLY

s

• Disassembleinorderofthearrowofthegureoffollowingow.

• Inthecaseofthere-assembling,assembleitinorderofthereverseofthefollowingow.

• Inthecaseofthere-assembling,observe"attentionofassembling"it.

• Ifwirebundlesareuntiedormovedtoperformadjustmentorpartsreplacementetc.,besuretorearrangethemneatly astheywereoriginallybundledorplacedafterward. Otherwise,incorrectarrangementcanbeacauseofnoisegeneration.

CABINET TOP

FRONT PANEL ASSY

Referto "DISASSEMBLY

1. FRONT PANEL ASSY"

and"EXPLODED VIEW"

PCBFRONT

(Ref.No.ofEXPLODEDVIEW:P1)

PCBFUNCTION

(Ref.No.ofEXPLODEDVIEW:P2)

PCBCNT

(Ref.No.ofEXPLODEDVIEW:P3)

PCBV.AUX_HP

(Ref.No.ofEXPLODEDVIEW:P4)

PCBUSB

(Ref.No.ofEXPLODEDVIEW:P5)

PCBMIC

(Ref.No.ofEXPLODEDVIEW:P6)

PCBFRONTHDMI

(Ref.No.ofEXPLODEDVIEW:P29)

HEAT SINK ASSY

Referto "DISASSEMBLY

2. HEAT SINK ASSY"

and"EXPLODED VIEW"

PCBGUIDE_TOP

(Ref.No.ofEXPLODEDVIEW:P7)

PCBGUIDE_L

(Ref.No.ofEXPLODEDVIEW:P8)

PCB7CH-AMPASSY

(Ref.No.ofEXPLODEDVIEW:P10)

PCB REG CNT/PCB REG

Referto "DISASSEMBLY

3. PCB REG CNT/PCB REG"

and"EXPLODED VIEW"

PCBREG

(Ref.No.ofEXPLODEDVIEW:P11)

PCBREG_CNT

(Ref.No.ofEXPLODEDVIEW:P12)

HDMI UNIT ASSY

Referto "DISASSEMBLY

4. HDMI UNIT ASSY"

and"EXPLODED VIEW"

PCBPREOUT

(Ref.No.ofEXPLODEDVIEW:P13)

PCBSIDE_CNT

(Ref.No.ofEXPLODEDVIEW:P14)

PCBAUDIO

(Ref.No.ofEXPLODEDVIEW:P15)

PCBVIDEOASSY

(Ref.No.ofEXPLODEDVIEW:P16)

PCBHDMI

(Ref.No.ofEXPLODEDVIEW:P17)

PCBRS232

(Ref.No.ofEXPLODEDVIEW:P18)

PCBSIRIUS

(Ref.No.ofEXPLODEDVIEW:P19)

PCBSPK

(Ref.No.ofEXPLODEDVIEW:P20)

PCBSMPS

(Ref.No.ofEXPLODEDVIEW:P21)

PCBF_WIDE

(Ref.No.ofEXPLODEDVIEW:P22)

PCBFRONT_CNT

(Ref.No.ofEXPLODEDVIEW:P23)

TRANS MAIN

Referto "DISASSEMBLY

5. TRANS MAIN"

and"EXPLODED VIEW"

TRANSMAIN

(Ref.No.ofEXPLODEDVIEW:44)

6

About the photos used for descriptions in the DISASSEMBLY" section.

• Thedirectionfromwhichthephotographsusedhereinwerephotographedisindicatedat"Directionofphotograph:***" attheleftoftherespectivephotographs.

• Refertothetablebelowforadescriptionofthedirectioninwhichthephotosweretaken.

• Photographsforwhichnodirectionisindicatedweretakenfromabovetheproduct.

The viewpoint of each photograph (Photografy direction)

［View from above］

Direction of photograph: C

Direction of photograph: B

Front side

Direction of photograph: D

Direction of photograph: A

7

1. FRONT PANEL ASSY

Proceeding :

(1) Removethescrews.

View from bottom

CABINET TOP

FRONT PANEL ASSY

→

(2) Cutthewireclampband,thendisconnecttheconnectorwiresandFFCcable.Removethescrews.

STYLE PIN : Loose

cut

FFC cable

N4201

CP100

STYLE PIN : Loose

FFC cable

Pleasereferto"EXPLODEDVIEW"forthedisassemblymethodofeachPCBincludedinFRONTPANELASSY.

8

2. HEAT SINK ASSY

Proceeding :

CABINET TOP

(1) Removethescrews.

View from bottom

HEAT SINK ASSY

→

(2) Cutwireclampband,thenremovethescrews.Disconnecttheconnectorwires.

Direction of photograph: C

cut

STYLE PIN : Loose

Direction of photograph: D

CP100

9

(3) Removethescrews.

Direction of photograph: A

(4) Cutthewireclampbands,thendisconnecttheconnectorwiresandFFCcable.Removethescrews,SUPPORTER

P.C.andtheHDMIBRACKET.

STYLE PIN : Loose

N4905

FFC cable FFC cable

(5) Disconnecttheconnectorwires.

cut

N4201

HEATSINK ASSY

CUSHION BRACKET

SUPPORTER P.C.

HDMI BRACKET

CP401 CP402

STYLE PIN : Loose

PCB 7CH AMP

CP405CP403

Pleasereferto"EXPLODEDVIEW"forthedisassemblymethodofeachP.W.BincludedinHEATSINKASSY.

10

3. PCB REG CNT/PCB REG

Proceeding :

(1) Removethescrews.

(2) Disconnecttheconnectorwiresandconnectorboard.

CABINET TOP

HEAT SINK ASSY

→

PCB REG

PCB REG CNT/PCB REG

→

Direction of photograph: C

PCB REG

CP102CP104

PCB REG CNT

N2004

CP13A

Board to board

11

4. HDMI UNIT ASSY

Proceeding :

(1) Removethescrews,thenremovetheBACKPANELandtheHDMIBRACKET.

Direction of photograph: A

(2) Cutwireclampband,thendisconnecttheconnectorwiresandtheFFCcables.Removethescrewsandthe SUPPORTERP.C..

RemovethePCBSIRIUSandthePCBRS232fromthePCBSIDECNT(Boardtoboard).

CABINET TOP

STYLE PIN : Loose

HDMI UNIT ASSY

→

HDMI UNIT ASSY

PCB SIRIUS

PCB 232C

cut

CUSHION BRACKET

SUPPORTER P.C.

BACK PANEL

FFC cableN4201

HDMI BRACKET

12

(3) Cutthewireclampband,thendisconnecttheconnectorwires.Removethescrew.

Direction of photograph: C

CP13A

(4) Removethescrewsanddisconnecttheconnector.

cut

HDMI UNIT ASSY

N2004

CP402CP401

N4905

CP403

STYLE PIN : Loose

CP102

CP405

CP104N4610 CP1

13

(5) Disconnecttheconnectorwire,thenremovethescrewsandtheSUPPORTERP.C..

SUPPORTER P.C.

CX102

(6) RemovetheLICENCELABEL,thenremovethescrewsandSUPPORTERP.C..

RemovetheHDMIUNITASSYfromthemainunit.

SUPPORTER P.C.

View from bottom

Pleasereferto"EXPLODEDVIEW"forthedisassemblymethodofeachP.W.BincludedinHDMIUNITASSY.

LICENCE LABEL

5. TRANS MAIN

Proceeding :

Pleasereferto"EXPLODEDVIEW"forthedisassemblymethodofeachP.W.BincludedinTRANSMAIN.

CABINET TOP

HDMI UNIT ASSY

→

14

TRANS MAIN

→

SPECIAL MODE

PURE

DIRECT/

Special mode setting button

 PresstheON/STANDBYbuttontoturnonwhilepressingbothbuttonsAandBatthesametime.

b

Mode Button A Button B Contents

Versiondisplay (μcom/DSPErrorDisplay)

Displayingtheprotectionhistorymode STATUS MENU

IInitializationmode (RemovesettingsforInstallerSetup.)

Initializationmode (IncludessettingsforInstallerSetup)

Modeforswitchingtunerfrequencystep STANDARD

Modeforpreventingremotecontrol acceptance

Panellockmode

Panellockmode (RemoveMastervolume)

Cancellationofpanellockmode

InstallerSetupmode MENU

Diagnosticmode

STATUS RETURN

STANDARD

CURSORUP

STATUS ENTER

DSP

SIMULATION

DIRECT/

STEREO

DIRECT/

STEREO

CURSOR

LEFT

SIMULATION

CURSOR

DOWN

DIRECT/

STEREO

DIRECT/ STEREO

PURE

DIRECT

ENTER Panellockmodeiscancelled.

CURSOR

LEFT

ENTER

DSP

SerialNo.andrmwareversionssuchasMain,Sub,DSPare displayedintheFLmanager.Errorsaredisplayedwhenthey occur.(Referto16page)

Displayingtheprotectionhistory (Referto19page)

Backupdatainitializationiscarriedout. (RemovesettingsforInstallerSetup)

Backupdatainitializationiscarriedout. (IncludessettingsforInstallerSetup)

---E2modelonly--ChangetunerfrequencysteptoFM:200kHz/AM:10kHzSTEP

Operationsusingremotecontrolarerejected. (Modecancellation:Turnoffpowerandexecutethesame buttonoperationsaswhenperformingsetup.)

Operationsusingmainunitpanelbuttonsormastervolumeare rejected.

Operationsusingmainunitpanelbuttonsarerejected.

AccessRemoteMaintenancemodeviatheinternet.Installer SetupisdisplayedonGUI/OptionMenu.

RefertoAVR_RemoteMaintenance_.pdfofSDI.

※

ThismodeisusedforconrmingtheVideoandAudio(signal) paths.(Troubleshooting) Conrmingtheoperationofunitcanbeeasilydoneafterrepair.

d

NOTE:

If"S"isdisplayedontheuorescentdisplay,theunitissettothespecialdeveloper'smodeandRS-232C communicationsarenotpossible. Pressandholdinthe"STATUS"and"i"buttonsforover3secondswiththepowerturnedontoturnthe"S" displayoff.RS-232Ccommunicationsarenowenabled.



ENTER

STATUS

STANDARD

DIRECT

STEREO

DSP

SIMULATION

ZONE2

MENU

CURSOR

RETURN

ON/OFF

15

1. µcom/DSP Version display mode

1.1. Operation specications

µcom/DSP version display mode:

Whenstartedup,theversioninformationisdisplayed.

Starting up:

Withthe"RETURN"and"STATUS"buttonspressed,pressthe"ON/STANDBY"buttontoturnthepoweron. Now,pressthe"STATUS"buttontothedisplaythe2nditeminformationontheFLDisplay.

1.2. Display Order

Errorinformation(Referto1.3.Errordisplay)→qModeldestinationinformation→wFirmwarePackageVersion→

Mainµ-com/ROMversion→rMain1stBootLoader→tSubµ-com/SubFBL→yDSPversion→uAudioPLD

e

→iOSDFPGACong→oOSDProgram→Q0OSDfontdata→Q1Ethernet(DM860)1stBootLoader,HardwareID →Q2Ethernet(DM860)2ndBootLoader,RhapsodyFlag→Q3Ethernet(DM860)IMAGE→Q4Ethernet(DM860)MAC ADDRESSinformation→Q5HDRADIOSDK/HDRADIOBBP→Q6iPodVersion→Q7MultEQProAPP(Displayedwhen AudysseyProiscomplete)→Q8MultEQProICL(DisplayedwhenAudysseyProiscomplete

Modeldestinationinformation:

q

Upper

Lower

FirmwarePackageVersion:

w

Upper

Lower

A V R 3 3 1 1 E 3

S / N . * * * * * * * * * *

F i r m . P a c k a g e

V e r . : * * * *

Mainµ-com&ROMversion:

e

Upper

Lower

Main1stBootLoader:

r

Upper

Lower

Subµ-com&SubFBL:

t

Upper

Lower

DSPROM:

y

Upper

Lower

AudioPLD:

u

Upper

Lower

M a i n : * * . * *

M a i n R O M : * * . * *

M a i n F B L : * * . * *

S u b : * * . * *

S u b F B L : * * . * *

D S P : * * . * *

A u d i o P L D : * * . * *

OSDFPGACong:

i

Upper

Lower

O S D C o n f i g :

* * * * * * * * * * * *

16

OSDProgram:

o

Upper

Lower

OSDfontdata:

Q0

Upper

Lower

Ethernet(DM860)1stBootLoader,HardwareID:

Q1

Upper

Lower

Ethernet(DM860)2ndBootLoader,RhapsodyFlag:

Q2

Upper

Lower

Ethernet(DM860)IMAGE:

Q3

Upper

Lower

O S D P R G :

* * * * * * * * * * * *

O S D D A T :

* * * * * * * * * * * *

* E t h e r n e t F B L

* * * * * * * * - A A

* E t h e r n e t S B L

* * * * * * * * * * * * * - B B

* E t h e r n e t I M G

* * * * * * * * * * * * *

Ethernet(DM860)MACADDRESSinformation:

Q4

Upper

Lower

HDRADIOSDK/HDRADIOBBP(AVR-3311CIE3only):

Q5

Upper

Lower

iPodVersion:

Q6

Upper

Lower

MultEQProAPP(DisplayedwhenAudysseyProiscomplete):

Q7

Upper

Lower

MultEQProICL(DisplayedwhenAudysseyProiscomplete):

Q8

Upper

Lower

* E t h e r n e t M A C

* * * * * * - * * * * * *

* H D S D K : * * . * *

* H D B B P : C 0 0 0 2 . 0 0 0

i P o d D o c k : * * . * *

* M u l t E Q P r o A P P

* * . * * . * * . * * * *

* M u l t E Q P r o I C L

* * . * * . * * . * * * *

17

1.3. Error display

Seethefollowingtableforeach"Errorinformation"displayanditscontents(status). Displayorderisq,w,e,r,t.

Condition State State

 Sub-μcomNG NoresponsefromSub-μcom

q

 DIRNG NoresponsefromDIR

w

WhenDSPboot,executingDSPresetmakesnochangetoDSP1FLAG0 port"H".

NochangetoDSPFLAG0port"H"beforeissuingDSPcommand.

WhenDSPdataread,executingWRITE="L"makesnochangetoACK="H".

WhenDSPdataread,executingREQ="L"makesnochangetoACK="L".

 DSPNG

e

 EEPROMNG ErrorappearedinEEPROMchecksum.(***isablockaddressnumber.)

r

 BothSUB/DSP

t

/EEPROMOK

WhenDSPdatawrite,executingWRITE="H"makesnochangetoACK="H".

WhenDSPdatawrite,executingREQ="L"makesnochangetoACK="L".

WhenDSPspecialcodeboot,executingDSPresetmakesnochangeto DSPFLAG0port"H".

NochangetoDSPFLAG0port"H"beforeissuingDSPspecialread command.

NochangetoDSPFLAG0port"H"beforeDSPversionread.

S U B E R R O R 0 1

D I R E R R O R 0 1

D S P E R R O R 0 1

D S P E R R O R 0 2

D S P E R R O R 0 3

D S P E R R O R 0 4

D S P E R R O R 0 5

D S P E R R O R 0 6

D S P E R R O R 1 1

D S P E R R O R 1 2

D S P E R R O R 1 3

E 2 P R O M E R R * * *

(Noerrordisplay,versiondisplayonly)

18

2. Errors checking mode (Displaying the protection history)

2.1. Operation specications

Error mode (Displaying the protection history):

Whenstartedup,theerrorinformationisdisplayed.

Starting up:

●All model commonness

Withthe"STATUS"and"MENU"buttonspressed,pressthe"ON/STANDBY"buttontoturnthepoweron.Theerror (protectionhistorydisplay)modeisset. Now,pressthe"STATUS"buttontoturnontheFLdisplay.

2.2. About the display on the FL display

Whenthe"STATUS"buttonispressedaftersettingtheerror(protectionhistorydisplay)mode,ahistoryliketheone shownbelowisdisplayed,dependingontheconditions.

(1) Normally(whentherehasbeennoprotectionincident)

Upper

Lower

(2) ForASO(whenthelastprotectionincidentwasASOprotection)

Upper

Lower

Cause: Thelinebetweenspeakerterminalsisshorted,orusespeakershavingimpedancelessthanthatspecied. Supplementary information: Astheexcesscurrentisdetectedafteroperationofthespeakerrelay,theshorted

Turningonthepowerwithoutcorrectingtheabnormalitywillcausetheprotectionfunctiontoworkabout5seconds laterandthepowersupplywillbeshutoff.

(3) ForDC(whenthelastprotectionincidentwasDCprotection)

Upper

Lower

Cause: DCoutputofthepoweramplierisabnormal.

Turningonthepowerwithoutcorrectingtheabnormalitywillcausetheprotectionfunctiontoworkabout5seconds laterandthepowersupplywillbeshutoff.

(4) ForTHERMAL(whenthelastprotectionincidentwasTHERMALprotection)

P R O T E C T H I S T O R Y

: N O P R O T E C T

P R O T E C T H I S T O R Y

: A S O

speakerterminalandtheconnectedspeakercanbeidentied.

P R O T E C T H I S T O R Y

: D C

Upper

Lower

Cause: Thetemperatureoftheheatsinkisexcessive.

Turningonthepowerwithoutcorrectingtheabnormalitywillcausetheprotectionfunctiontoworkabout5seconds laterandthepowersupplywillbeshutoff.

 Additionalcausesofprotectioncanbeduetolooseconnections,associatedcomponents,Microprocessor,etc.

z

Whenthe"STATUS"buttonispressedagainaftertheaboveprotectionhistoryisdisplayed,thenormaldisplayreappears.

P R O T E C T H I S T O R Y

: T H E R M A L

19

2.3. Clearing the protection history

Therearetwowaystocleartheprotectionhistory,asdescribedbelow.

(1)

Startuptheerror(protectiondisplay)mode,displaytheerror,thenpressandholdinthe"ENTER"buttonfor3seconds.

Upper

Lower

Upper

Lower

Upper

Lower

(2) Initialize.(Referto"InitializingAVSURROUNDRECEIVER"5page.)

Ifyouwanttosaveabackup,usethemethodin2.3.(1)above.

b

P R O T E C T H I S T O R Y

: T H E R M A L

 Pressandholdinthe"ENTER"buttonfor3seconds.

P R O T E C T H I S T O R Y

C L E A R

 Theaboveisdisplayedandtheprotectionhistoryiscleared.

P R O T E C T H I S T O R Y

: N O P R O T E C T

Warning indication by the POWER LED

Ifthepoweristurnedoffwhenaprotectionincidenthasbeendetected,thePOWERLED(red)ashesasawarning accordingtotheconditionsinwhichtheprotectionincidentoccurred.

(1) ASO/DCPROTECTION:Flashesincyclesof0.5seconds(0.25secondslit,0.25secondsoff) (2) THERMALPROTECTION:Flashesincyclesof2seconds(1secondlit,1secondoff)

20

3.DIAGNOSTICMODE(Video/Audio(signal)pathconrmationmode)

d

This mode is used for conrming the Video and Audio (signal) paths. (Troubleshooting) Conrming the operation of unit can be easily done after repair. Backup data will not be lost.

3.1.Startingdiagnosticmode

Press the "CURSOR LEFT" and "ENTER" botton while simulltaneously pressing those two bottons of this unit. Q1, Q2 and Q3 are lit in FL display.

3.2. Cancelingdiagnosticmode

Turn off the power by pressing the ON/Standby botton.

3.3. Operation

When you perform remote operation in accordance with the instructions in "Details of how to operate remote controller" *a) in the table below using the remote control unit (RC-1146). You will nd using another remote control unit with the macro functions very useful. To use the macro functions, program a macro function to output a remote control code in accordance with the steps in *b) in the table below.

3.4. Videosystemconrmationitems

g.XX : Refer to the block diagram of the g.XXth.

Conrmation item Setting and display

Analog Video (signal) Path Video Convert (IP Scaler) : OFF , All Sources

All ZONE : ON Display:

V 0 1 D V D

1

g.1

Analog Video Convert (signal) Path Video Convert(IP Scaler) : ON , All Sources

Display:

V 0 2 D V D

2

g.2

HDMI (signal) Path Video Convert(IP Scaler) : OFF, All Sources

All ZONE:ON Display:

V 0 1 D V D

3

g.3

Details of how to operate remote controller *a)

1.Press [AMP]

2.Press [ZONE SELECT] , Select "ZONE2"

3.Press [ZONE OFF]

4.Press [ZONE SELECT], Select "ZONE3"

5.Press [ZONE OFF]

6.Press [ZONE SELECT], Select "MAIN"

7.Press [1/./]

8.Press [ZONE SELECT], Select "ZONE2"

9.Press [ZONE ON]

10.Press [ZONE SELECT], Select "ZONE3"

11.Press [ZONE ON]

12.Press [ZONE SELECT], Select "MAIN"

13.Press [DVD]

1.Press [AMP]

2.Press [ZONE SELECT] , Select "ZONE2"

3.Press [ZONE OFF]

4.Press [ZONE SELECT], Select "ZONE3"

5.Press [ZONE OFF]

6.Press [ZONE SELECT], Select "MAIN"

7.Press [2/ABC]

8.Press [DVD]

1.Press [AMP]

2.Press [ZONE SELECT] , Select "ZONE2"

3.Press [ZONE OFF]

4.Press [ZONE SELECT], Select "ZONE3"

5.Press [ZONE OFF]

6.Press [ZONE SELECT], Select "MAIN"

7.Press [1/./]

8.Press [ZONE SELECT], Select "ZONE2"

9.Press [ZONE ON]

10.Press [ZONE SELECT], Select "ZONE3"

11.Press [ZONE ON]

12.Press [ZONE SELECT], Select "MAIN"

13.Press [DVD]

Output sequence of remote control codes

It is useful to form a macro program. *b)

※

ZONE2 POWER OFF ·Input : CVBS / Output : CVBS

q

·Input : CVBS / Output : CVBS RECOUT (DVR)

·Input : CVBS / Output : CVBS ZONE2

ZONE3 POWER OFF

w

KEY 1/CODE1 (Main Zone)

e

Initialization & Video Convert All OFF

ZONE2 POWER ON

r

ZONE3 POWER ON

t

DVD (Main Zone)

y

ZONE2 POWER OFF ·Input : CVBS / Through : V.Decoder and V.Encoder / Output : CVBS

q

ZONE3 POWER OFF

w

KEY 2/ABC (Main Zone)

e

Initialization & Video Convert All ON & IP Scaler "Analog & HDMI"

DVD (Main Zone)

r

ZONE2 POWER OFF ·Input : HDMI / Output : HDMI

q

ZONE3 POWER OFF

w

KEY1/CODE1 (Main Zone)

e

Initialization & Video Convert All OFF

ZONE2 POWER ON

r

ZONE3 POWER ON

t

DVD (Main Zone)

y

·Input : Component / Output : Component

·Input : Component / Output Component ZONE (※As the input source, you can switch from DVD to other ones.)

· Input : CVBS / Through : V.Decoder and V.Encoder / Output : Component

·Input : Component / Through V.Decoder and V.Encoder / Output : CVBS

· Input : Component / Through V.Decoder and V.Encoder / Output : Component

(※As the input source, you can switch from DVD to other ones.)

Contents of conrmation Remarks

Conrm the input pass one by one. Because it becomes only the input of the highest input becomes Convert/IP Scaler (signal) Path if it inputs it at the same time. (HDMI input > Component input > S-VIDEO input > CVBS input) Do not connect anything with HDMI Monito OUT. Because the Convert pass is used with Analog to HDMI when connecting it.

21

Conrmation item Setting and display

Analog or HDMI to HDMI (signal) Path

4

Video Convert(IP Scaler) : ON, All Sources IP Scaler : Analog & HDMI , All Sources Resolution : "AUTO", All Sources Display:

V 0 2 D V D

g.4

OSD FUNCTION Video Convert(IP Scaler) : ON, All Sources

IP Scaler : Analog & HDMI , All Sources Resolution : "AUTO", All Sources Menu : ON All ZONE :ON Display:

V 0 2 D V D

5

g.5

CEC FUNCTION (Control Monitor : HDMI Monitor1)

6

HDMI Control : ON Control Monitor Monitor1 (When checking the HDMI Monitor Out1) Display:

V 0 3 D V D

g.6

HDMI Audio (signal) Path (Audio : AMP)

8

Audio : AMP(When checking the audio output from AMP) Display:

V 0 5 D V D

g.8

HDMI Audio (signal) Path (Audio : TV)

9

Audio : TV(When checking the audio output from TV) Display:

V 0 6 D V D

g.9

Details of how to operate remote controller *a)

1.Press [AMP]

2.Press [ZONE SELECT] , Select "ZONE2"

3.Press [ZONE OFF]

4.Press [ZONE SELECT], Select "ZONE3"

5.Press [ZONE OFF]

6.Press [ZONE SELECT], Select "MAIN"

7.Press [2/ABC]

8.Press [DVD]

1.Press [AMP]

2.Press [ZONE SELECT] , Select "ZONE2"

3.Press [ZONE OFF]

4.Press [ZONE SELECT], Select "ZONE3"

5.Press [ZONE OFF]

6.Press [ZONE SELECT], Select "MAIN"

7.Press [2/ABC]

8.Press [ZONE SELECT], Select "ZONE2"

9.Press [ZONE ON]

10.Press [ZONE SELECT], Select "ZONE3"

11.Press [ZONE ON]

12.Press [ZONE SELECT], Select "MAIN"

13.Press [DVD]

14.Press [AMP]

15.Press [MENU]

16.Press [ZONE SELECT], Select "ZONE2"

17.Press [MENU]

1.Press [AMP]

2.Press [ZONE SELECT] , Select "ZONE2"

3.Press [ZONE OFF]

4.Press [ZONE SELECT], Select "ZONE3"

5.Press [ZONE OFF]

6.Press [ZONE SELECT], Select "MAIN"

7.Press [3/DEF]

8.Press [DVD]

1.Press [AMP]

2.Press [ZONE SELECT] , Select "ZONE2"

3.Press [ZONE OFF]

4.Press [ZONE SELECT], Select "ZONE3"

5.Press [ZONE OFF]

6.Press [ZONE SELECT], Select "MAIN"

7.Press [5/JKL]

8.Press [DVD]

1.Press [AMP]

2.Press [ZONE SELECT] , Select "ZONE2"

3.Press [ZONE OFF]

4.Press [ZONE SELECT], Select "ZONE3"

5.Press [ZONE OFF]

6.Press [ZONE SELECT], Select "MAIN"

7.Press [6/MNO]

8.Press [DVD]

Output sequence of remote control codes

It is useful to form a macro program. *b)

※

ZONE2 POWER OFF ·Input CVBS / Through : IP Scaler / Output : HDMI

q

·Input S-VIDEO / Through : IP Scaler / Output : HDMI

·Input Component / Through : IP Scaler / Outpu : HDMI

ZONE3 POWER OFF

w

KEY 2/ABC (Main Zone)

e

Initialization & Video Convert All ON & IP Scaler "Analog & HDMI"

DVD (Main Zone)

r

ZONE2 POWER OFF ·OSD Display / Output : CVBS

q

ZONE3 POWER OFF

w

KEY 2/ABC (Main Zone)

e

Initialization &VideoConvert All ON & IP Scaler"Analog&HDMI"

ZONE2 POWER ON

r

ZONE3 POWER ON

t

DVD (Main Zone)

y

GUI MENU (Main Zone)

u

ZONE2 MENU

i

ZONE2 POWER OFF · When the power supply of a TV is put in the standby mode, make sure

q

ZONE3 POWER OFF

w

KEY 3/DEF (Main Zone)

e

Initialization & CEC Control ON & Select Control Monitor 1

DVD (Main Zone)

r

ZONE2 POWER OFF ·Input : HDMI (Signal of PCM, DolbyDigital or DTS) / Output : Speakers

q

ZONE3 POWER OFF

w

KEY 5/JKL (Main Zone)

e

Initialization & Select Audio AMP

DVD (Main Zone)

r

ZONE2 POWER OFF · Input : HDMI (Signal of PCM or DolbyDigital or DTS) / Output : HDMI

q

ZONE3 POWER OFF

w

KEY 6/MNO (Main Zone)

e

Initialization & Audio Select TV

DVD (Main Zone)

r

·Input HDMI / Through : IP Scaler / Outpu : HDMI (※As the input source, you can switch from DVD to other ones.)

·OSD Display / Output : CVBS ZONE2

·OSD Display / Output : Component

·OSD Display / Output : HDMI (※As the input source, you can switch from DVD to other ones.)

that the power supply of this unit is also put in the standby mode.

(※As the input source, you can switch from DVD to other ones.)

·Input : HDMI (Signal of HD Audio) / Output : Speakers (※As the input source, you can switch from DVD to other ones.)

(Audio output from connected TV)

(※As the input source, you can switch from DVD to other ones.)

Contents of conrmation Remarks

Conrm the input pass one by one. Because it becomes only the input of the highest input becomes Convert/IP Scaler (signal) Path if it inputs it at the same time. (HDMI input > Component input > S-VIDEO input > CVBS input)

Connect HDMI Monitor OUT / Output : OSD from HDMI No connect HDMI Monitor OUT / Output : OSD from Component No output other terminal.

AVR2311/3311 are nothing ZONE2 OSD

※

22

3.5. Audiosystemconrmationitems

g.XX : Refer to the block diagram of the g.XXth.

Conrmation item Setting and display

Analog (signal) Path Input Mode : Fixed ANALOG

SURROUND mode : DIRECT Amp assign : NORMAL Display:

1

A 0 1 D V D

g.10

DIGITAL (signal) Path (MAIN)

Input Mode : Fixed DIGITAL Amp assign : NORMAL Display:

A 0 2 D V D

2

g.11

DIGITAL (signal) Path (ZONE2)

Input Mode : Fixed DIGITAL Amp assign : ZONE2 ZONE2 Function : Source Display:

A 0 3 D V D

3

g.12

DIGITAL (signal) Path (ZONE3)

Input Mode : Fixed DIGITAL Amp assign : ZONE3 ZONE3 Function : Source Display:

A 0 4 D V D

4

g.13

HDMI (signal) Path Input Mode : Fixed HDMI

Amp assign : NORMAL Display:

A 0 5 D V D

5

g.14

Details of how to operate remote controller

1.Press [AMP]

2.Press [ZONE SELECT] , Select "ZONE2"

3.Press [ZONE OFF]

4.Press [ZONE SELECT], Select "ZONE3"

5.Press [ZONE OFF]

6.Press [ZONE SELECT], Select "MAIN"

7.Press [7/PQRS]

8.Press [DVD]

1.Press [AMP]

2.Press [ZONE SELECT] , Select "ZONE2"

3.Press [ZONE OFF]

4.Press [ZONE SELECT], Select "ZONE3"

5.Press [ZONE OFF]

6.Press [ZONE SELECT], Select "MAIN"

7.Press [8/TUV]

8.Press [DVD]

1.Press [AMP]

2.Press [ZONE SELECT] , Select "ZONE2"

3.Press [ZONE OFF]

4.Press [ZONE SELECT], Select "ZONE3"

5.Press [ZONE OFF]

6.Press [ZONE SELECT], Select "MAIN"

7.Press [9/WXYZ]

8.Press [ZONE SELECT], Select "ZONE2"

9.Press [ZONE ON]

10.Press [ZONE SELECT], Select "MAIN"

11.Press [DVD]

1.Press [AMP]

2.Press [ZONE SELECT] , Select "ZONE2"

3.Press [ZONE OFF]

4.Press [ZONE SELECT], Select "ZONE3"

5.Press [ZONE OFF]

6.Press [ZONE SELECT], Select "MAIN"

7.Press [0/_*]

8.Press [ZONE SELECT], Select "ZONE3"

9.Press [ZONE ON]

10.Press [ZONE SELECT], Select "MAIN"

11.Press [DVD]

1.Press [AMP]

2.Press [ZONE SELECT] , Select "ZONE2"

3.Press [ZONE OFF]

4.Press [ZONE SELECT], Select "ZONE3"

5.Press [ZONE OFF]

6.Press [ZONE SELECT], Select "MAIN"

7.Press [MULTEQ]

8.Press [DVD]

Output sequence of remote control codes

It is useful to form a macro program.

※

ZONE2 POWER OFF ·Input : Analog / Output : Speakers (Front L/R)

q

·Input : Analog / Output : Pre OUT(Front L/R)

(※As the input source, you can switch from DVD to other ones.)

ZONE3 POWER OFF

w

KEY 7/PQRS (Main Zone)

e

Initialization & Amp assign NORMAL& Input Mode Fixed ANALOG & SURROUND mode DIRECT

DVD (Main Zone)

r

ZONE2 POWER OFF ·Input : Digital / Output : Speakers (Front L/R)

q

·Input : Digital / Output : Pre OUT(Front L/R)

(※As the input source, you can switch from DVD to other ones.)

ZONE3 POWER OFF

w

KEY 8/TUV (Main Zone)

e

Initialization & Amp assign NORMAL& Input Mode Fixed DIGITAL

DVD (Main Zone)

r

ZONE2 POWER OFF ·Input : Digital / Output : Speakers (SURR BACK L/R)

q

·Input : Digital / Output : Pre OUT(ZONE2 L/R)

(※As the input source, you can switch from DVD to other ones.)

ZONE3 POWER OFF

w

KEY9/WXYZ (Main Zone)

e

Initialization & Amp assign ZONE2 & Input Mode Fixed DIGITAL

ZONE2 POWER ON

r

DVD (Main Zone)

t

ZONE2 POWER OFF ·Input : Digital / Output : Speakers (SURR BACK L/R)

q

·Input : Digital / Output : Pre OUT(ZONE3 L/R)

(※As the input source, you can switch from DVD to other ones.)

ZONE3 POWER OFF

w

KEY 0/CODE2 (Main Zone)

e

Initialization & Amp assign ZONE3 & Input Mode Fixed DIGITAL

ZONE3 POWER ON

r

DVD (Main Zone)

t

ZONE2 POWER OFF ·Input : HDMI / Output : Speakers (Front L/R)

q

·Input : HDMI / Output : Pre OUT(Front L/R)

(※As the input source, you can switch from DVD to other ones.)

ZONE3 POWER OFF

w

MULTEQ Select

e

Initialization &Amp assign NORMAL & Input Mode Fixed HDMI

DVD (Main Zone)

r

Contents of conrmation Remarks

only AV3311/991

only AVR3311

23

Conrmation item Setting and display

A/D (signal) Path (Main Zone)

6

g.15

Amp Assign (signal) Path (Amp Assign : ZONE2)

7

g.16

Amp Assign (signal) Path (Amp Assign : ZONE3)

8

g.17

Amp Assign (signal) Path (Amp Assign : ZONE2/ZONE3-MONO)

9

g.18

Amp assign : NORMAL SURROUND mode : Multi ch STEREO Vol -20dB Speaker Cong : SSSSY (Front/Center/Surround/SourroundBack : Small, SW : Yes) Display:

A 0 6 D V D

Amp assign : ZONE2 ZONE2 Function : Source Zone2 Vol -20dB Display:

A 0 7 D V D

Amp assign : ZONE3 SURROUND mode : Multi ch STEREO Zone3 Vol -20dB Display:

A 0 8 D V D

Amp assign : ZONE2/ZONE3-MONO SURROUND mode : Multi ch STEREO ZONE2 Vol -20dB ZONE3 Vol -20dB Display:

A 0 9 D V D

Details of how to operate remote controller

1.Press [AMP]

2.Press [ZONE SELECT] , Select "ZONE2"

3.Press [ZONE OFF]

4.Press [ZONE SELECT], Select "ZONE3"

5.Press [ZONE OFF]

6.Press [ZONE SELECT], Select "MAIN"

7.Press [DYN EQ/VOL]

8.Press [DVD]

1.Press [AMP]

2.Press [ZONE SELECT] , Select "ZONE2"

3.Press [ZONE OFF]

4.Press [ZONE SELECT], Select "ZONE3"

5.Press [ZONE OFF]

6.Press [ZONE SELECT], Select "MAIN"

7.Press [A-DSX]

8.Press [ZONE SELECT], Select "ZONE2"

9.Press [ZONE ON]

10.Press [ZONE SELECT], Select "MAIN"

11.Press [DVD]

1.Press [AMP]

2.Press [ZONE SELECT] , Select "ZONE2"

3.Press [ZONE OFF]

4.Press [ZONE SELECT], Select "ZONE3"

5.Press [ZONE OFF]

6.Press [ZONE SELECT], Select "MAIN"

7.Press [RESTORER]

8.Press [ZONE SELECT], Select "ZONE3"

9.Press [ZONE ON]

10.Press [ZONE SELECT], Select "MAIN"

11.Press [DVD]

1.Press [AMP]

2.Press [ZONE SELECT] , Select "ZONE2"

3.Press [ZONE OFF]

4.Press [ZONE SELECT], Select "ZONE3"

5.Press [ZONE OFF]

6.Press [ZONE SELECT], Select "MAIN"

7.Press [STANDARD]

8.Press [ZONE SELECT], Select "ZONE2"

9.Press [ZONE ON]

10.Press [ZONE SELECT], Select "ZONE3"

11.Press [ZONE ON]

12.Press [ZONE SELECT], Select "MAIN"

13.Press [DVD]

Output sequence of remote control codes

It is useful to form a macro program.

※

ZONE2 POWER OFF ·Input : Analog / Output : Speakers (Front L/R)

q

·Input : Analog / Output : Pre OUT(Front L/R), SW(20Hz) (※As the input source, you can switch from DVD to other ones.)

ZONE3 POWER OFF

w

DYNAMIC EQ/VOLUME

e

Initialization &Amp assign NORMAL & SURROUND mode : Multi ch STEREO & Volume -20dB

DVD (Main Zone)

r

ZONE2 POWER OFF ·Input : Analog / Output : Speakers (SURR BACK L/R)

q

·Input : Analog / Output : Pre OUT (ZONE2 L/R) (※As the input source, you can switch from DVD to other ones.)

ZONE3 POWER OFF

w

Audyssey DSX ON/OFF

e

Initialization & Amp assign ZONE2 & SURROUND mode : Multi ch STEREO & ZONE2 Volume -20dB

ZONE2 POWER ON

r

DVD (Main Zone)

t

ZONE2 POWER OFF ·Input : Analog / Output : Speakers (SURR BACK L/R)

q

·Input : Analog / Output : Pre OUT (ZONE3 L/R) (※As the input source, you can switch from DVD to other ones.)

ZONE3 POWER OFF

w

AUDIO RESTORER

e

Initialization & Amp assign ZONE3 & SURROUND mode : Multi ch STEREO & ZONE3 Volume -20dB

ZONE3 POWER ON

r

DVD (Main Zone)

t

ZONE2 POWER OFF ·Input : Analog / Output : Speakers (SURR BACK L/R)

q

·Input : Analog / Output : Pre OUT (ZONE2 L/R)

·Input : Analog / Output : Pre OUT (ZONE3 L/R)

ZONE3 POWER OFF

w

STANDARD

e

Initialization & Amp assign ZONE2/ZONE3MONO & SURROUND mode : Multi ch STEREO & ZONE2 Volume -20dB & ZONE3 Volume -20dB

ZONE2 POWER ON

r

ZONE3 POWER ON

t

DVD (Main Zone)

y

(※As the input source, you can switch from DVD to other ones.)

Contents of conrmation Remarks

only AVR3311

24

Conrmation item Setting and display

Amp Assign (signal) Path (Amp Assign : 2CH)

10

Amp assign : 2CH SURROUND mode : DIRECT Vol -20dB Display:

A 1 0 D V D

g.19

Amp Assign (signal) Path (Amp Assign : BiAMP)

11

Amp assign : BiAMP SURROUND mode : Multi ch STEREO Vol -20dB Display:

A 1 1 D V D

g.20

Amp Assign (signal) Path (Amp Assign : Front-B)

12

Amp assign : Front-B SURROUND mode : Multi ch STEREO Vol -20dB Display:

A 1 2 D V D

g.21

Front Height (signal) Path Amp assign : Front Height ( As AVR2311&AVR

891) Amp assign : NORMAL (As AVR3311&AVR991) SURROUND mode : Multi ch STEREO Vol -20dB Surround Parameter-Speaker : F.Height Display:

14

A 1 4 D V D

g.23

Front Wide (signal) Path Amp assign : NORMAL

SURROUND mode : Multi ch STEREO Vol -20dB Surround Parameter-Speaker : F.Wide

15

Display:

A 1 5 D V D

g.24

Details of how to operate remote controller

1.Press [AMP]

2.Press [ZONE SELECT] , Select "ZONE2"

3.Press [ZONE OFF]

4.Press [ZONE SELECT], Select "ZONE3"

5.Press [ZONE OFF]

6.Press [ZONE SELECT], Select "MAIN"

7.Press [D/ST]

8.Press [DVD]

1.Press [AMP]

2.Press [ZONE SELECT] , Select "ZONE2"

3.Press [ZONE OFF]

4.Press [ZONE SELECT], Select "ZONE3"

5.Press [ZONE OFF]

6.Press [ZONE SELECT], Select "MAIN"

7.Press [SIMULATION]

8.Press [DVD]

1.Press [AMP]

2.Press [ZONE SELECT] , Select "ZONE2"

3.Press [ZONE OFF]

4.Press [ZONE SELECT], Select "ZONE3"

5.Press [ZONE OFF]

6.Press [ZONE SELECT], Select "MAIN"

7.Press [PURE]

8.Press [DVD]

1.Press [AMP]

2.Press [ZONE SELECT] , Select "ZONE2"

3.Press [ZONE OFF]

4.Press [ZONE SELECT], Select "ZONE3"

5.Press [ZONE OFF]

6.Press [ZONE SELECT], Select "MAIN"

7.Press [+10/MEMORY]

8.Press [DVD]

1.Press [AMP]

2.Press [ZONE SELECT] , Select "ZONE2"

3.Press [ZONE OFF]

4.Press [ZONE SELECT], Select "ZONE3"

5.Press [ZONE OFF]

6.Press [ZONE SELECT], Select "MAIN"

7.Press [SLEEP]

8.Press [DVD]

Output sequence of remote control codes

It is useful to form a macro program.

※

ZONE2 POWER OFF ·Input : Analog / Output : Speakers (SURR BACK L/R)

q

·Input : Analog / Output : Pre OUT (Front L/R)

(※As the input source, you can switch from DVD to other ones.)

ZONE3 POWER OFF

w

DIRECT/STEREO

e

Initialization &Amp assign 2CH & SURROUND mode : DIRECT & Volume

-20dB DVD (Main Zone)

r

ZONE2 POWER OFF ·Input : Analog / Output : Speakers (SURR BACK L/R)

q

·Input : Analog / Output : Pre OUT (SB L/R) (※As the input source, you can switch from DVD to other ones.)

ZONE3 POWER OFF

w

DSP SIMULATION

e

Initialization & Amp assign BiAMP & SURROUND mode : Multi ch STEREO & Volume -20dB

DVD (Main Zone)

r

ZONE2 POWER OFF ·Input : Analog / Output : Speakers (SURR BACK L/R)

q

·Input : Analog / Output : Pre OUT (SB L/R) (※As the input source, you can switch from DVD to other ones.)

ZONE3 POWER OFF

w

PURE DIRECT

e

Initialization & Amp assign Front-B & SURROUND mode Multi ch STEREO & olume -20dB

DVD (Main Zone)

r

ZONE2 POWER OFF ·Input : Analog / Output : Speakers (F.HEIGHT L/R)

q

(※As the input source, you can switch from DVD to other ones.)

ZONE3 POWER OFF

w

MEMORY/+10 (Main Zone)

e

As AVR2311&AVR891

Initialization & Amp assign Front Height & SURROUND mode:Multi ch STEREO & Volume -20dB

As AVR3311&AVR991

Initialization & Amp assign NORMAL & SURROUND mode:Multi ch STEREO & Volume -20dB & Surround ParameterSpeaker : F.Height

DVD (Main Zone)

r

ZONE2 POWER OFF ·Input : Analog / Output : Speakers (F.WIDE L/R)

q

(※As the input source, you can switch from DVD to other ones.)

ZONE3 POWER OFF

w

SLEEP MODE

e

Initialization &Amp assign NORMAL & SURROUND mode:Multi ch STEREO & Volume -20dB Surround Parameter-Speaker : F.Wide

DVD (Main Zone)

r

Contents of conrmation Remarks

AVR2311/891and AVR3311/991, operate differently

only AVR3311/991

25

BLOCKDIAGRAM

g.1

TO DIGITAL AUDIO

d

SPDIF/I2S/DSD SPDIF/I2S/DSD

HDMI IN

JAPAN D-JACK

D TERMINAL JAPAN MODEL ONLY

COMPONENT IN

ETHERNET

iPOD

S(Y/C) IN

CVBS IN

SAT/CBL

V.AUX

HDMI1

HDMI2

HDMI3

HDMI4

HDMI5

HDMI6

FRONT HDMI

IN1

IN2

DVR

HDP DVD

DVR

BUS SW FPGA XC35S400A-4FGG320C

2311/891/991

3311

TMDS SW ADV3002

LINE1,2 &3

HDMI Rx VIDEO DECODER ADV7840

24

IP SCALER ABT2015

75 75 51 51 51 75

I/P SCALER

DDRII 512 400MHz 8MBit*16Bit*4Bank

OSD

DDRII 512 400MHz 8MBit*16Bit*4Bank

TO DIGITAL AUDIO

FROM DIGITAL AUDIO

FROM RX DIGITAL AUDIO

COMPONENT & CVBS SELECT

AVDM-2000

LINE1,2 &3

Y Cb Cr

COMP1-Y COMP1-Cb COMP1-Cr

COMP2-Y COMP2-Cb COMP2-Cr

DET.

INPUT SELECT

TC4052

75

2.2K

75

Y/C MIX

75

COMP1-Y COMP2-Y

UP-Y

COMP1-Cb COMP2-Cb

UP-Cb

COMP1-Cr COMP2-Cr

UP-Cr

MAIN Y/C

2V

DET.

Y C

3311 ONLY

INPUT SELECT

TC4052

3311 ONLY

2.2K

Y/C MIX

75

ZONE2 Y/C

2V

DET.

75

1K

75

DET.

75

1K

75

HDMI TRANSMITTER ADV7511

HDMI Tx AUDIO BUS SW TC74VHC244FT

ENCODER ADV7392

Cb Cr

Y

+5V

HDMI BUS BUFFER

TR SW

0dB

TC4052BF

3311 ONLY

HDMI OUT1

HDMI OUT2

JAPAN ONLY

D VIDEO OUT

75

Y

COMPONENT

Cb

OUT

Cr

CVBS MAIN OUT

CVBS Z2 MONI. OUT

75

CVBS REC OUT

26

g.2

TO DIGITAL AUDIO

SPDIF/I2S/DSD SPDIF/I2S/DSD

HDMI IN

JAPAN D-JACK

D TERMINAL JAPAN MODEL ONLY

COMPONENT IN

ETHERNET

iPOD

S(Y/C) IN

DVR

HDP

CVBS IN

DVD

SAT/CBL

DVR

V.AUX

HDMI1

HDMI2

HDMI3

HDMI4

HDMI5

HDMI6

FRONT HDMI

IN1

IN2

BUS SW FPGA XC35S400A-4FGG320C

2311/891/991

3311

TMDS SW ADV3002

LINE1,2 &3

HDMI Rx VIDEO DECODER ADV7840

24

IP SCALER ABT2015

75 75 51 51 51

DDRII 512 400MHz

75

8MBit*16Bit*4Bank

I/P SCALER

OSD

DDRII 512 400MHz 8MBit*16Bit*4Bank

TO DIGITAL AUDIO

FROM DIGITAL AUDIO

FROM RX DIGITAL AUDIO

COMPONENT & CVBS SELECT

AVDM-2000

LINE1,2 &3

Y Cb

Cr

Y Cb

Cr

COMP1-Y COMP1-Cb COMP1-Cr

COMP2-Y COMP2-Cb COMP2-Cr

DET.

INPUT SELECT

TC4052

2.2K

75

Y/C MIX

75

COMP1-Y COMP2-Y

UP-Y

COMP1-Cb COMP2-Cb

UP-Cb

COMP1-Cr COMP2-Cr

UP-Cr

MAIN Y/C

2V

DET.

Y C

Y

C

3311 ONLY

INPUT SELECT

TC4052

3311 ONLY

2.2K

Y/C MIX

75

ZONE2 Y/C

2V

DET.

75

1K

75

DET.

75

1K

75

HDMI TRANSMITTER ADV7511

HDMI Tx AUDIO BUS SW TC74VHC244FT

ENCODER ADV7392

Cb Cr

Y

+5V

HDMI BUS BUFFER

TR SW

0dB

TC4052BF

3311 ONLY

HDMI OUT1

HDMI OUT2

JAPAN ONLY

D VIDEO OUT

75

Y

COMPONENT

Cb

OUT

Cr

CVBS MAIN OUT

CVBS Z2 MONI. OUT

75

CVBS REC OUT

27

g.3

TO DIGITAL AUDIO

SPDIF/I2S/DSD SPDIF/I2S/DSD

HDMI IN

JAPAN D-JACK

D TERMINAL JAPAN MODEL ONLY

COMPONENT IN

ETHERNET

iPOD

S(Y/C) IN

HDP

CVBS IN

DVD

SAT/CBL

V.AUX

HDMI1

HDMI2

HDMI3

HDMI4

HDMI5

HDMI6

FRONT HDMI

IN1

IN2

DVR

BUS SW FPGA XC35S400A-4FGG320C

2311/891/991

3311

TMDS SW ADV3002

LINE1,2 &3

HDMI Rx VIDEO DECODER ADV7840

24

IP SCALER ABT2015

75 75 51 51 51

DDRII 512 400MHz

75

8MBit*16Bit*4Bank

I/P SCALER

OSD

DDRII 512 400MHz 8MBit*16Bit*4Bank

TO DIGITAL AUDIO

FROM DIGITAL AUDIO

FROM RX DIGITAL AUDIO

COMPONENT & CVBS SELECT

AVDM-2000

LINE1,2 &3

Y Cb Cr

COMP1-Y COMP1-Cb COMP1-Cr

COMP2-Y COMP2-Cb COMP2-Cr

DET.

INPUT SELECT

TC4052

75

2.2K

75

Y/C MIX

75

COMP1-Y COMP2-Y

UP-Y

COMP1-Cb COMP2-Cb

UP-Cb

COMP1-Cr COMP2-Cr

UP-Cr

MAIN Y/C

2V

DET.

Y C

3311 ONLY

INPUT SELECT

TC4052

3311 ONLY

2.2K

Y/C MIX

75

ZONE2 Y/C

2V

DET.

75

1K

75

DET.

75

1K

75

HDMI TRANSMITTER ADV7511

HDMI Tx AUDIO BUS SW TC74VHC244FT

ENCODER ADV7392

Cb Cr

Y

+5V

HDMI BUS BUFFER

TR SW

0dB

TC4052BF

3311 ONLY

HDMI OUT1

HDMI OUT2

JAPAN ONLY

D VIDEO OUT

75

Y

COMPONENT

Cb

OUT

Cr

CVBS MAIN OUT

CVBS Z2 MONI. OUT

75

CVBS REC OUT

28

g.4

TO DIGITAL AUDIO

SPDIF/I2S/DSD SPDIF/I2S/DSD

HDMI IN

JAPAN D-JACK

D TERMINAL JAPAN MODEL ONLY

COMPONENT IN

ETHERNET

iPOD

S(Y/C) IN

DVR

HDP

CVBS IN

DVD

SAT/CBL

DVR

V.AUX

HDMI1

HDMI2

HDMI3

HDMI4

HDMI5

HDMI6

FRONT HDMI

IN1

IN2

BUS SW FPGA XC35S400A-4FGG320C

2311/891/991

3311

TMDS SW ADV3002

LINE1,2 &3

HDMI Rx VIDEO DECODER ADV7840

24

IP SCALER ABT2015

75 75 51 51 51

DDRII 512 400MHz

75

8MBit*16Bit*4Bank

I/P SCALER

OSD

DDRII 512 400MHz 8MBit*16Bit*4Bank

TO DIGITAL AUDIO

FROM DIGITAL AUDIO

FROM RX DIGITAL AUDIO

COMPONENT & CVBS SELECT

AVDM-2000

LINE1,2 &3

Y Cb

Cr

Y Cb

Cr

COMP1-Y COMP1-Cb COMP1-Cr

COMP2-Y COMP2-Cb COMP2-Cr

DET.

INPUT SELECT

TC4052

2.2K

75

Y/C MIX

75

COMP1-Y COMP2-Y

UP-Y

COMP1-Cb COMP2-Cb

UP-Cb

COMP1-Cr COMP2-Cr

UP-Cr

MAIN Y/C

2V

DET.

Y C

Y

C

3311 ONLY

INPUT SELECT

TC4052

3311 ONLY

2.2K

Y/C MIX

75

ZONE2 Y/C

2V

DET.

75

1K

75

DET.

75

1K

75

HDMI TRANSMITTER ADV7511

HDMI Tx AUDIO BUS SW TC74VHC244FT

ENCODER ADV7392

Cb Cr

Y

+5V

HDMI BUS BUFFER

TR SW

0dB

TC4052BF

3311 ONLY

HDMI OUT1

HDMI OUT2

JAPAN ONLY

D VIDEO OUT

75

Y

COMPONENT

Cb

OUT

Cr

CVBS MAIN OUT

CVBS Z2 MONI. OUT

75

CVBS REC OUT

29

g.5

TO DIGITAL AUDIO

SPDIF/I2S/DSD SPDIF/I2S/DSD

HDMI IN

JAPAN D-JACK

D TERMINAL JAPAN MODEL ONLY

COMPONENT IN

ETHERNET

iPOD

S(Y/C) IN

DVR

HDP

CVBS IN

DVD

SAT/CBL

DVR

V.AUX

HDMI1

HDMI2

HDMI3

HDMI4

HDMI5

HDMI6

FRONT HDMI

IN1

IN2

BUS SW FPGA XC35S400A-4FGG320C

2311/891/991

3311

TMDS SW ADV3002

LINE1,2 &3

HDMI Rx VIDEO DECODER ADV7840

24

IP SCALER ABT2015

75 75 51 51 51

DDRII 512 400MHz

75

8MBit*16Bit*4Bank

I/P SCALER

OSD

DDRII 512 400MHz 8MBit*16Bit*4Bank

TO DIGITAL AUDIO

FROM DIGITAL AUDIO

FROM RX DIGITAL AUDIO

COMPONENT & CVBS SELECT

AVDM-2000

LINE1,2 &3

Y Cb Cr

COMP1-Y COMP1-Cb COMP1-Cr

COMP2-Y COMP2-Cb COMP2-Cr

DET.

INPUT SELECT

TC4052

75

2.2K

75

Y/C MIX

75

COMP1-Y COMP2-Y

UP-Y

COMP1-Cb COMP2-Cb

UP-Cb

COMP1-Cr COMP2-Cr

UP-Cr

MAIN Y/C

2V

DET.

Y C

Y

C

3311 ONLY

INPUT SELECT

TC4052

3311 ONLY

2.2K

Y/C MIX

75

ZONE2 Y/C

2V

DET.

75

1K

75

DET.

75

1K

75

HDMI TRANSMITTER ADV7511

HDMI Tx AUDIO BUS SW TC74VHC244FT

ENCODER ADV7392

Cb Cr

Y

+5V

HDMI BUS BUFFER

TR SW

0dB

TC4052BF

3311 ONLY

HDMI OUT1

HDMI OUT2

JAPAN ONLY

D VIDEO OUT

75

Y

COMPONENT

Cb

OUT

Cr

CVBS MAIN OUT

CVBS Z2 MONI. OUT

75

CVBS REC OUT

30

g.6

TO DIGITAL AUDIO

SPDIF/I2S/DSD SPDIF/I2S/DSD

HDMI IN

JAPAN D-JACK

D TERMINAL JAPAN MODEL ONLY

COMPONENT IN

ETHERNET

iPOD

S(Y/C) IN

DVR

HDP

CVBS IN

DVD

SAT/CBL

DVR

V.AUX

HDMI1

HDMI2

HDMI3

HDMI4

HDMI5

HDMI6

FRONT HDMI

IN1

IN2

BUS SW FPGA

2311/891/991

3311

TMDS SW ADV3002

LINE1,2 &3

HDMI Rx VIDEO DECODER ADV7840

XC35S400A-4FGG320C

IP SCALER ABT2015

75 75 51 51 51 75

24

I/P SCALER

DDRII 512 400MHz 8MBit*16Bit*4Bank

OSD

DDRII 512 400MHz 8MBit*16Bit*4Bank

TO DIGITAL AUDIO

FROM DIGITAL AUDIO

FROM RX DIGITAL AUDIO

HDMI TRANSMITTER ADV7511

HDMI Tx AUDIO BUS SW TC74VHC244FT

ENCODER ADV7392

Cb Cr

Y

HDMI BUS BUFFER

TC4052BF

COMPONENT & CVBS SELECT

AVDM-2000

LINE1,2 &3

Y Cb

Cr

Y Cb

Cr

COMP1-Y COMP1-Cb COMP1-Cr

COMP2-Y COMP2-Cb COMP2-Cr

DET.

INPUT SELECT

TC4052

2.2K

75

Y/C MIX

75

COMP1-Y COMP2-Y

UP-Y

COMP1-Cb COMP2-Cb

UP-Cb

COMP1-Cr COMP2-Cr

UP-Cr

MAIN Y/C

2V

DET.

Y C

Y

C

3311 ONLY

INPUT SELECT

TC4052

3311 ONLY

2.2K

Y/C MIX

75

ZONE2 Y/C

2V

DET.

75

1K

75

DET.

75

1K

75

+5V

TR SW

0dB

75

3311 ONLY

CEC

SUB uCOM

JAPAN ONLY

75

HDMI OUT1

HDMI OUT2

D VIDEO OUT

Y

COMPONENT

Cb

OUT

Cr

CVBS MAIN OUT

CVBS Z2 MONI. OUT

CVBS REC OUT

31

g.8

DIRECT

VOLUME AND INPUT SELECTOR R2A15220FP

R-CH Audio Selction

ATT

HEADPHONE OUT

ANALOG INPUT

FRONT INPUT

SIRIUS

MIC(Mini Jack)

iPod Dock

HD Radio

HD-RADIO

AVR2311/3311 NA

AM/FM TUNER

AVR2311 EU/3311 EU AVR891/991

HDMI IN

ETHERNET

USB FRONT

DIGITAL IN

AVR3311/991=PHONO+6INPUT

AVR2311/891 = 6INPUT

AVR3311/991 NA Series

AVR2311/891/3311/991

HDMI1

HDMI2

HDMI3

HDMI4

HDMI5

HDMI6

AVR2311/891/991

FRONT HDMI

AVR3311

AVR3311/991

AVR2311/891

OPT1

OPT2

HDMI RECEIVER ADV7840

HDMI SWITCHER ADV3002

TMDS BUFFER

ETHERNET PHY LAN8700

USB CONTROLLER TCC8600

I2S/SPDIF/DSD

NETWORK CONTROLLER DM860

DAC AK4424ET

TO DSP

ZONE2

ZONE3

SPDIF

AUDIO PLD EPM240T100C5N

DSP ADSP21367

SDRAM

FLASH

SPDIF

CLOCK JITTER REDUCER CS2100

DIR2 LC89058

ADC AK5358B

I2S

DIR1 LC89058

I2S

ZONE2 DAC AK4424ET

AVR3311

HPF

MONO MIX

HPF

MONO MIX

HPF

SPDIF/I2S/DSD

I2S

MONO MIX

AVR891/991(Bypass)

AVR3311

HDMI TRANSMITTER ADV7511

MAIN ZONE DAC AK4358VQ (PCM ONLY)

ZONE2 VOLUME NJW1194

AVR2311/3311

ZONE3 VOLUME NJW1194

HDMI SWITCHER

PI3HDMI1310A

+

-

+

-

+

-

+

-

+

-

+

-

+

-

+

-

RELAY BLOCK

ARC SPDIF

FL

FR

C

SL

AVR2311/891 FL/SBL/Z2L/FL-H

SR

AVR3311/991 FL/SBL/Z2L/Z3L/FL-H

SBL

SBR

AVR2311/891 FR/SBR/Z2R/FR-H

AVR3311/991

FL

FR/SBR/Z2R/Z3R/FR-H

FR

C

SL

SBL

AVR2311(EU),AVR3311=7.2CH

SBR

SW1

AVR2311(NA/N/C)/891/991=0.2CH

SW2

Z2L

Z2R

Z3L

Z3R

AVR3311

HDMI OUT1

HDMI OUT2

AVR3311(EU/N/C)

SPK OUT

PRE-OUT

REC OUT

HDMI OUT

DIGITAL OUT

COAX1

COAX2

TC74HCU04AF

SPDIF

DIR3 LC89058

ZONE3 DAC AK4424ET

AVR3311

32

g.9

DIRECT

VOLUME AND INPUT SELECTOR R2A15220FP

R-CH Audio Selction

ATT

HEADPHONE OUT

ANALOG INPUT

FRONT INPUT

SIRIUS

MIC(Mini Jack)

iPod Dock

HD Radio

HD-RADIO

AVR2311/3311 NA

AM/FM TUNER

AVR2311 EU/3311 EU AVR891/991

HDMI IN

ETHERNET

USB FRONT

DIGITAL IN

AVR3311/991=PHONO+6INPUT

AVR2311/891 = 6INPUT

AVR3311/991 NA Series

AVR2311/891/3311/991

HDMI1

HDMI2

HDMI3

HDMI4

HDMI5

HDMI6

AVR2311/891/991

FRONT HDMI

AVR3311

AVR3311/991

AVR2311/891

OPT1

OPT2

HDMI RECEIVER ADV7840

HDMI SWITCHER ADV3002

TMDS BUFFER

ETHERNET PHY LAN8700

USB CONTROLLER TCC8600

I2S/SPDIF/DSD

NETWORK CONTROLLER DM860

DAC AK4424ET

TO DSP

ZONE2

ZONE3

SPDIF

AUDIO PLD EPM240T100C5N

DSP ADSP21367

SDRAM

FLASH

SPDIF

CLOCK JITTER REDUCER CS2100

DIR2 LC89058

ADC AK5358B

I2S

DIR1 LC89058

I2S

ZONE2 DAC AK4424ET

AVR3311

HPF

MONO MIX

HPF

MONO MIX

HPF

SPDIF/I2S/DSD

I2S

MONO MIX

AVR891/991(Bypass)

AVR3311

HDMI TRANSMITTER ADV7511

MAIN ZONE DAC AK4358VQ (PCM ONLY)

ZONE2 VOLUME NJW1194

AVR2311/3311

ZONE3 VOLUME NJW1194

HDMI SWITCHER

PI3HDMI1310A

+

-

+

-

+

-

+

-

+

-

+

-

+

-

+

-

RELAY BLOCK

ARC SPDIF

FL

FR

C

SL

AVR2311/891 FL/SBL/Z2L/FL-H

SR

AVR3311/991 FL/SBL/Z2L/Z3L/FL-H

SBL

SBR

AVR2311/891 FR/SBR/Z2R/FR-H

AVR3311/991

FL

FR/SBR/Z2R/Z3R/FR-H

FR

C

SL

SBL

AVR2311(EU),AVR3311=7.2CH

SBR

SW1

AVR2311(NA/N/C)/891/991=0.2CH

SW2

Z2L

Z2R

Z3L

Z3R

AVR3311

HDMI OUT1

HDMI OUT2

AVR3311(EU/N/C)

SPK OUT

PRE-OUT

REC OUT

HDMI OUT

DIGITAL OUT

COAX1

COAX2

TC74HCU04AF

SPDIF

DIR3 LC89058

ZONE3 DAC AK4424ET

AVR3311

33

g.10

DIRECT

VOLUME AND INPUT SELECTOR R2A15220FP

R-CH Audio Selction

ATT

HEADPHONE OUT

ANALOG INPUT

FRONT INPUT

SIRIUS

MIC(Mini Jack)

iPod Dock

HD Radio

HD-RADIO

AVR2311/3311 NA

AM/FM TUNER

AVR2311 EU/3311 EU AVR891/991

HDMI IN

ETHERNET

USB FRONT

DIGITAL IN

AVR3311/991=PHONO+6INPUT

AVR2311/891 = 6INPUT

AVR3311/991 NA Series

AVR2311/891/3311/991

HDMI1

HDMI2

HDMI3

HDMI4

HDMI5

HDMI6

AVR2311/891/991

FRONT HDMI

AVR3311

AVR3311/991

AVR2311/891

OPT1

OPT2

HDMI RECEIVER ADV7840

HDMI SWITCHER ADV3002

TMDS BUFFER

ETHERNET PHY LAN8700

USB CONTROLLER TCC8600

I2S/SPDIF/DSD

NETWORK CONTROLLER DM860

DAC AK4424ET

TO DSP

ZONE2

ZONE3

SPDIF

AUDIO PLD EPM240T100C5N

DSP ADSP21367

SDRAM

FLASH

SPDIF

CLOCK JITTER REDUCER CS2100

DIR2 LC89058

ADC AK5358B

I2S

DIR1 LC89058

I2S

ZONE2 DAC AK4424ET

AVR3311

HPF

MONO MIX

HPF

MONO MIX

HPF

SPDIF/I2S/DSD

I2S

MONO MIX

AVR891/991(Bypass)

AVR3311

HDMI TRANSMITTER ADV7511

MAIN ZONE DAC AK4358VQ (PCM ONLY)

ZONE2 VOLUME NJW1194

AVR2311/3311

ZONE3 VOLUME NJW1194

HDMI SWITCHER

PI3HDMI1310A

+

-

+

-

+

-

+

-

+

-

+

-

+

-

+

-

RELAY BLOCK

ARC SPDIF

FL

FR

C

SL

AVR2311/891 FL/SBL/Z2L/FL-H

SR

AVR3311/991 FL/SBL/Z2L/Z3L/FL-H

SBL

SBR

AVR2311/891 FR/SBR/Z2R/FR-H

AVR3311/991

FL

FR/SBR/Z2R/Z3R/FR-H

FR

C

SL

SBL

AVR2311(EU),AVR3311=7.2CH

SBR

SW1

AVR2311(NA/N/C)/891/991=0.2CH

SW2

Z2L

Z2R

Z3L

Z3R

AVR3311

HDMI OUT1

HDMI OUT2

AVR3311(EU/N/C)

SPK OUT

PRE-OUT

REC OUT

HDMI OUT

DIGITAL OUT

COAX1

COAX2

TC74HCU04AF

SPDIF

DIR3 LC89058

ZONE3 DAC AK4424ET

AVR3311

34

g.11

DIRECT

VOLUME AND INPUT SELECTOR R2A15220FP

R-CH Audio Selction

ATT

HEADPHONE OUT

ANALOG INPUT

FRONT INPUT

SIRIUS

MIC(Mini Jack)

iPod Dock

HD Radio

HD-RADIO

AVR2311/3311 NA

AM/FM TUNER

AVR2311 EU/3311 EU AVR891/991

HDMI IN

ETHERNET

USB FRONT

DIGITAL IN

AVR3311/991=PHONO+6INPUT

AVR2311/891 = 6INPUT

AVR3311/991 NA Series

AVR2311/891/3311/991

HDMI1

HDMI2

HDMI3

HDMI4

HDMI5

HDMI6

AVR2311/891/991

FRONT HDMI

AVR3311

AVR3311/991

AVR2311/891

OPT1

OPT2

HDMI RECEIVER ADV7840

HDMI SWITCHER ADV3002

TMDS BUFFER

ETHERNET PHY LAN8700

USB CONTROLLER TCC8600

I2S/SPDIF/DSD

NETWORK CONTROLLER DM860

DAC AK4424ET

TO DSP

ZONE2

ZONE3

SPDIF

AUDIO PLD EPM240T100C5N

DSP ADSP21367

SDRAM

FLASH

SPDIF

CLOCK JITTER REDUCER CS2100

DIR2 LC89058

ADC AK5358B

I2S

DIR1 LC89058

I2S

ZONE2 DAC AK4424ET

AVR3311

HPF

MONO MIX

HPF

MONO MIX

HPF

SPDIF/I2S/DSD

I2S

MONO MIX

AVR891/991(Bypass)

AVR3311

HDMI TRANSMITTER ADV7511

MAIN ZONE DAC AK4358VQ (PCM ONLY)

ZONE2 VOLUME NJW1194

AVR2311/3311

ZONE3 VOLUME NJW1194

HDMI SWITCHER

PI3HDMI1310A

+

-

+

-

+

-

+

-

+

-

+

-

+

-

+

-

RELAY BLOCK

ARC SPDIF

FL

FR

C

SL

AVR2311/891 FL/SBL/Z2L/FL-H

SR

AVR3311/991 FL/SBL/Z2L/Z3L/FL-H

SBL

SBR

AVR2311/891 FR/SBR/Z2R/FR-H

AVR3311/991

FL

FR/SBR/Z2R/Z3R/FR-H

FR

C

SL

SBL

AVR2311(EU),AVR3311=7.2CH

SBR

SW1

AVR2311(NA/N/C)/891/991=0.2CH

SW2

Z2L

Z2R

Z3L

Z3R

AVR3311

HDMI OUT1

HDMI OUT2

AVR3311(EU/N/C)

SPK OUT

PRE-OUT

REC OUT

HDMI OUT

DIGITAL OUT

COAX1

COAX2

TC74HCU04AF

SPDIF

DIR3 LC89058

ZONE3 DAC AK4424ET

AVR3311

35

g.12

DIRECT

VOLUME AND INPUT SELECTOR R2A15220FP

R-CH Audio Selction

ATT

HEADPHONE OUT

ANALOG INPUT

FRONT INPUT

SIRIUS

MIC(Mini Jack)

iPod Dock

HD Radio

HD-RADIO

AVR2311/3311 NA

AM/FM TUNER

AVR2311 EU/3311 EU AVR891/991

HDMI IN

ETHERNET

USB FRONT

DIGITAL IN

AVR3311/991=PHONO+6INPUT

AVR2311/891 = 6INPUT

AVR3311/991 NA Series

AVR2311/891/3311/991

HDMI1

HDMI2

HDMI3

HDMI4

HDMI5

HDMI6

AVR2311/891/991

FRONT HDMI

AVR3311

AVR3311/991

AVR2311/891

OPT1

OPT2

HDMI RECEIVER ADV7840

HDMI SWITCHER ADV3002

TMDS BUFFER

ETHERNET PHY LAN8700

USB CONTROLLER TCC8600

I2S/SPDIF/DSD

NETWORK CONTROLLER DM860

DAC AK4424ET

TO DSP

ZONE2

ZONE3

SPDIF

AUDIO PLD EPM240T100C5N

DSP ADSP21367

SDRAM

FLASH

SPDIF

CLOCK JITTER REDUCER CS2100

DIR2 LC89058

ADC AK5358B

I2S

DIR1 LC89058

I2S

ZONE2 DAC AK4424ET

AVR3311

HPF

MONO MIX

HPF

MONO MIX

HPF

SPDIF/I2S/DSD

I2S

MONO MIX

AVR891/991(Bypass)

AVR3311

HDMI TRANSMITTER ADV7511

MAIN ZONE DAC AK4358VQ (PCM ONLY)

ZONE2 VOLUME NJW1194

AVR2311/3311

ZONE3 VOLUME NJW1194

HDMI SWITCHER

PI3HDMI1310A

+

-

+

-

+

-

+

-

+

-

+

-

+

-

+

-

RELAY BLOCK

ARC SPDIF

FL

FR

C

SL

AVR2311/891 FL/SBL/Z2L/FL-H

SR

AVR3311/991 FL/SBL/Z2L/Z3L/FL-H

SBL

SBR

AVR2311/891 FR/SBR/Z2R/FR-H

AVR3311/991

FL

FR/SBR/Z2R/Z3R/FR-H

FR

C

SL

SBL

AVR2311(EU),AVR3311=7.2CH

SBR

SW1

AVR2311(NA/N/C)/891/991=0.2CH

SW2

Z2L

Z2R

Z3L

Z3R

AVR3311

HDMI OUT1

HDMI OUT2

AVR3311(EU/N/C)

SPK OUT

PRE-OUT

REC OUT

HDMI OUT

DIGITAL OUT

COAX1

COAX2

TC74HCU04AF

SPDIF

DIR3 LC89058

ZONE3 DAC AK4424ET

AVR3311

36

g.13

DIRECT

VOLUME AND INPUT SELECTOR R2A15220FP

R-CH Audio Selction

ATT

HEADPHONE OUT

ANALOG INPUT

FRONT INPUT

SIRIUS

MIC(Mini Jack)

iPod Dock

HD Radio

HD-RADIO

AVR2311/3311 NA

AM/FM TUNER

AVR2311 EU/3311 EU AVR891/991

HDMI IN

ETHERNET

USB FRONT

DIGITAL IN

AVR3311/991=PHONO+6INPUT

AVR2311/891 = 6INPUT

AVR3311/991 NA Series

AVR2311/891/3311/991

HDMI1

HDMI2

HDMI3

HDMI4

HDMI5

HDMI6

AVR2311/891/991

FRONT HDMI

AVR3311

AVR3311/991

AVR2311/891

OPT1

OPT2

HDMI RECEIVER ADV7840

HDMI SWITCHER ADV3002

TMDS BUFFER

ETHERNET PHY LAN8700

USB CONTROLLER TCC8600

I2S/SPDIF/DSD

NETWORK CONTROLLER DM860

DAC AK4424ET

TO DSP

ZONE2

ZONE3

SPDIF

AUDIO PLD EPM240T100C5N

DSP ADSP21367

SDRAM

FLASH

SPDIF

CLOCK JITTER REDUCER CS2100

DIR2 LC89058

ADC AK5358B

I2S

DIR1 LC89058

I2S

ZONE2 DAC AK4424ET

AVR3311

HPF

MONO MIX

HPF

MONO MIX

HPF

SPDIF/I2S/DSD

I2S

MONO MIX

AVR891/991(Bypass)

AVR3311

HDMI TRANSMITTER ADV7511

MAIN ZONE DAC AK4358VQ (PCM ONLY)

ZONE2 VOLUME NJW1194

AVR2311/3311

ZONE3 VOLUME NJW1194

HDMI SWITCHER

PI3HDMI1310A

+

-

+

-

+

-

+

-

+

-

+

-

+

-

+

-

RELAY BLOCK

ARC SPDIF

FL

FR

C

SL

AVR2311/891 FL/SBL/Z2L/FL-H

SR

AVR3311/991 FL/SBL/Z2L/Z3L/FL-H

SBL

SBR

AVR2311/891 FR/SBR/Z2R/FR-H

AVR3311/991

FL

FR/SBR/Z2R/Z3R/FR-H

FR

C

SL

SBL

AVR2311(EU),AVR3311=7.2CH

SBR

SW1

AVR2311(NA/N/C)/891/991=0.2CH

SW2

Z2L

Z2R

Z3L

Z3R

AVR3311

HDMI OUT1

HDMI OUT2

AVR3311(EU/N/C)

SPK OUT

PRE-OUT

REC OUT

HDMI OUT

DIGITAL OUT

COAX1

COAX2

TC74HCU04AF

SPDIF

DIR3 LC89058

ZONE3 DAC AK4424ET

AVR3311

37

g.14

VOLUME AND INPUT SELECTOR R2A15220FP

DIRECT

R-CH Audio Selction

ATT

HEADPHONE OUT

ANALOG INPUT

FRONT INPUT

SIRIUS

MIC(Mini Jack)

iPod Dock

HD Radio

HD-RADIO

AVR2311/3311 NA

AM/FM TUNER

AVR2311 EU/3311 EU AVR891/991

HDMI IN

ETHERNET

USB FRONT

DIGITAL IN

AVR3311/991=PHONO+6INPUT

AVR2311/891 = 6INPUT

AVR3311/991 NA Series

AVR2311/891/3311/991

HDMI1

HDMI2

HDMI3

HDMI4

HDMI5

HDMI6

AVR2311/891/991

FRONT HDMI

AVR3311

AVR3311/991

AVR2311/891

OPT1

OPT2

HDMI RECEIVER ADV7840

HDMI SWITCHER ADV3002

TMDS BUFFER

ETHERNET PHY LAN8700

USB CONTROLLER TCC8600

I2S/SPDIF/DSD

NETWORK CONTROLLER DM860

DAC AK4424ET

TO DSP

ZONE2

ZONE3

SPDIF

AUDIO PLD EPM240T100C5N

SPDIF

DSP ADSP21367

SDRAM

FLASH

SPDIF

CLOCK JITTER REDUCER CS2100

DIR2 LC89058

ADC AK5358B

I2S

DIR1 LC89058

I2S

ZONE2 DAC AK4424ET

AVR3311

HPF

MONO MIX

HPF

MONO MIX

HPF

SPDIF/I2S/DSD

I2S

MONO MIX

AVR891/991(Bypass)

AVR3311

HDMI TRANSMITTER ADV7511

MAIN ZONE DAC AK4358VQ (PCM ONLY)

ZONE2 VOLUME NJW1194

AVR2311/3311

ZONE3 VOLUME NJW1194

HDMI SWITCHER

PI3HDMI1310A

+

-

+

-

+

-

+

-

+

-

+

-

+

-

+

-

RELAY BLOCK

ARC SPDIF

FL

FR

C

SL

AVR2311/891 FL/SBL/Z2L/FL-H

SR

AVR3311/991 FL/SBL/Z2L/Z3L/FL-H

SBL

SBR

AVR2311/891 FR/SBR/Z2R/FR-H

AVR3311/991

FL

FR/SBR/Z2R/Z3R/FR-H

FR

C

SL

SBL

AVR2311(EU),AVR3311=7.2CH

SBR

SW1

AVR2311(NA/N/C)/891/991=0.2CH

SW2

Z2L

Z2R

Z3L

Z3R

AVR3311

HDMI OUT1

HDMI OUT2

AVR3311(EU/N/C)

SPK OUT

PRE-OUT

REC OUT

HDMI OUT

DIGITAL OUT

COAX1

COAX2

TC74HCU04AF

SPDIF

DIR3 LC89058

ZONE3 DAC AK4424ET

AVR3311

38

g.15

DIRECT

VOLUME AND INPUT SELECTOR R2A15220FP

R-CH Audio Selction

ATT

HEADPHONE OUT

ANALOG INPUT

FRONT INPUT

SIRIUS

MIC(Mini Jack)

iPod Dock

HD Radio

HD-RADIO

AVR2311/3311 NA

AM/FM TUNER

AVR2311 EU/3311 EU AVR891/991

HDMI IN

ETHERNET

USB FRONT

DIGITAL IN

AVR3311/991=PHONO+6INPUT

AVR2311/891 = 6INPUT

AVR3311/991 NA Series

AVR2311/891/3311/991

HDMI1

HDMI2

HDMI3

HDMI4

HDMI5

HDMI6

AVR2311/891/991

FRONT HDMI

AVR3311

AVR3311/991

AVR2311/891

OPT1

OPT2

HDMI RECEIVER ADV7840

HDMI SWITCHER ADV3002

TMDS BUFFER

ETHERNET PHY LAN8700

USB CONTROLLER TCC8600

I2S/SPDIF/DSD

NETWORK CONTROLLER DM860

DAC AK4424ET

TO DSP

ZONE2

ZONE3

SPDIF

AUDIO PLD EPM240T100C5N

SPDIF

SDRAM

DSP ADSP21367

FLASH

DIR2 LC89058

ADC AK5358B

I2S

DIR1 LC89058

SPDIF

CLOCK JITTER REDUCER CS2100

I2S

ZONE2 DAC AK4424ET

AVR3311

HPF

MONO MIX

HPF

MONO MIX

HPF

SPDIF/I2S/DSD

I2S

MONO MIX

AVR891/991(Bypass)

AVR3311

HDMI TRANSMITTER ADV7511

MAIN ZONE DAC AK4358VQ (PCM ONLY)

ZONE2 VOLUME NJW1194

AVR2311/3311

ZONE3 VOLUME NJW1194

HDMI SWITCHER

PI3HDMI1310A

+

-

+

-

+

-

+

-

+

-

+

-

+

-

+

-

RELAY BLOCK

ARC SPDIF

FL

FR

C

SL

AVR2311/891 FL/SBL/Z2L/FL-H

SR

AVR3311/991 FL/SBL/Z2L/Z3L/FL-H

SBL

SBR

AVR2311/891 FR/SBR/Z2R/FR-H

AVR3311/991

FL

FR/SBR/Z2R/Z3R/FR-H

FR

C

SL

SBL

AVR2311(EU),AVR3311=7.2CH

SBR

SW1

AVR2311(NA/N/C)/891/991=0.2CH

SW2

Z2L

Z2R

Z3L

Z3R

AVR3311

HDMI OUT1

HDMI OUT2

AVR3311(EU/N/C)

SPK OUT

PRE-OUT

REC OUT

HDMI OUT

DIGITAL OUT

COAX1

COAX2

TC74HCU04AF

SPDIF

DIR3 LC89058

ZONE3 DAC AK4424ET

AVR3311

39

g.16

DIRECT

VOLUME AND INPUT SELECTOR R2A15220FP

R-CH Audio Selction

ATT

HEADPHONE OUT

ANALOG INPUT

FRONT INPUT

SIRIUS

MIC(Mini Jack)

iPod Dock

HD Radio

HD-RADIO

AVR2311/3311 NA

AM/FM TUNER

AVR2311 EU/3311 EU AVR891/991

HDMI IN

ETHERNET

USB FRONT

DIGITAL IN

AVR3311/991=PHONO+6INPUT

AVR2311/891 = 6INPUT

AVR3311/991 NA Series

AVR2311/891/3311/991

HDMI1

HDMI2

HDMI3

HDMI4

HDMI5

HDMI6

AVR2311/891/991

FRONT HDMI

AVR3311

AVR3311/991

AVR2311/891

OPT1

OPT2

HDMI RECEIVER ADV7840

HDMI SWITCHER ADV3002

TMDS BUFFER

ETHERNET PHY LAN8700

USB CONTROLLER TCC8600

I2S/SPDIF/DSD

NETWORK CONTROLLER DM860

DAC AK4424ET

TO DSP

ZONE2

ZONE3

SPDIF

AUDIO PLD EPM240T100C5N

DSP ADSP21367

SDRAM

FLASH

SPDIF

CLOCK JITTER REDUCER CS2100

DIR2 LC89058

ADC AK5358B

I2S

DIR1 LC89058

I2S

ZONE2 DAC AK4424ET

AVR3311

HPF

MONO MIX

HPF

MONO MIX

HPF

SPDIF/I2S/DSD

I2S

MONO MIX

AVR891/991(Bypass)

AVR3311

HDMI TRANSMITTER ADV7511

MAIN ZONE DAC AK4358VQ (PCM ONLY)

ZONE2 VOLUME NJW1194

AVR2311/3311

ZONE3 VOLUME NJW1194

HDMI SWITCHER

PI3HDMI1310A

+

-

+

-

+

-

+

-

+

-

+

-

+

-

+

-

RELAY BLOCK

ARC SPDIF

FL

FR

C

SL

AVR2311/891 FL/SBL/Z2L/FL-H

SR

AVR3311/991 FL/SBL/Z2L/Z3L/FL-H

SBL

SBR

AVR2311/891 FR/SBR/Z2R/FR-H

AVR3311/991

FL

FR/SBR/Z2R/Z3R/FR-H

FR

C

SL

SBL

AVR2311(EU),AVR3311=7.2CH

SBR

SW1

AVR2311(NA/N/C)/891/991=0.2CH

SW2

Z2L

Z2R

Z3L

Z3R

AVR3311

HDMI OUT1

HDMI OUT2

AVR3311(EU/N/C)

SPK OUT

PRE-OUT

REC OUT

HDMI OUT

DIGITAL OUT

COAX1

COAX2

TC74HCU04AF

SPDIF

DIR3 LC89058

ZONE3 DAC AK4424ET

AVR3311

40

g.17

DIRECT

VOLUME AND INPUT SELECTOR R2A15220FP

R-CH Audio Selction

ATT

HEADPHONE OUT

ANALOG INPUT

FRONT INPUT

SIRIUS

MIC(Mini Jack)

iPod Dock

HD Radio

HD-RADIO

AVR2311/3311 NA

AM/FM TUNER

AVR2311 EU/3311 EU AVR891/991

HDMI IN

ETHERNET

USB FRONT

DIGITAL IN

AVR3311/991=PHONO+6INPUT

AVR2311/891 = 6INPUT

AVR3311/991 NA Series

AVR2311/891/3311/991

HDMI1

HDMI2

HDMI3

HDMI4

HDMI5

HDMI6

AVR2311/891/991

FRONT HDMI

AVR3311

AVR3311/991

AVR2311/891

OPT1

OPT2

HDMI RECEIVER ADV7840

HDMI SWITCHER ADV3002

TMDS BUFFER

ETHERNET PHY LAN8700

USB CONTROLLER TCC8600

I2S/SPDIF/DSD

NETWORK CONTROLLER DM860

DAC AK4424ET

TO DSP

ZONE2

ZONE3

SPDIF

AUDIO PLD EPM240T100C5N

SPDIF

SDRAM

DSP ADSP21367

FLASH

DIR2 LC89058

ADC AK5358B

I2S

DIR1 LC89058

SPDIF

CLOCK JITTER REDUCER CS2100

I2S

ZONE2 DAC AK4424ET

AVR3311

HPF

MONO MIX

HPF

MONO MIX

HPF

SPDIF/I2S/DSD

I2S

MONO MIX

AVR891/991(Bypass)

AVR3311

HDMI TRANSMITTER ADV7511

MAIN ZONE DAC AK4358VQ (PCM ONLY)

ZONE2 VOLUME NJW1194

AVR2311/3311

ZONE3 VOLUME NJW1194

HDMI SWITCHER

PI3HDMI1310A

+

-

+

-

+

-

+

-

+

-

+

-

+

-

+

-

RELAY BLOCK

ARC SPDIF

FL

FR

C

SL

AVR2311/891 FL/SBL/Z2L/FL-H

SR

AVR3311/991 FL/SBL/Z2L/Z3L/FL-H

SBL

SBR

AVR2311/891 FR/SBR/Z2R/FR-H

AVR3311/991

FL

FR/SBR/Z2R/Z3R/FR-H

FR

C

SL

SBL

AVR2311(EU),AVR3311=7.2CH

SBR

SW1

AVR2311(NA/N/C)/891/991=0.2CH

SW2

Z2L

Z2R

Z3L

Z3R

AVR3311

HDMI OUT1

HDMI OUT2

AVR3311(EU/N/C)

SPK OUT

PRE-OUT

REC OUT

HDMI OUT

DIGITAL OUT

COAX1

COAX2

TC74HCU04AF

SPDIF

DIR3 LC89058

ZONE3 DAC AK4424ET

AVR3311

41

g.18

DIRECT

VOLUME AND INPUT SELECTOR R2A15220FP

R-CH Audio Selction

ATT

HEADPHONE OUT

ANALOG INPUT

FRONT INPUT

SIRIUS

MIC(Mini Jack)

iPod Dock

HD Radio

HD-RADIO

AVR2311/3311 NA

AM/FM TUNER

AVR2311 EU/3311 EU AVR891/991

HDMI IN

ETHERNET

USB FRONT

DIGITAL IN

AVR3311/991=PHONO+6INPUT

AVR2311/891 = 6INPUT

AVR3311/991 NA Series

AVR2311/891/3311/991

HDMI1

HDMI2

HDMI3

HDMI4

HDMI5

HDMI6

AVR2311/891/991

FRONT HDMI

AVR3311

AVR3311/991

AVR2311/891

OPT1

OPT2

HDMI RECEIVER ADV7840

HDMI SWITCHER ADV3002

TMDS BUFFER

ETHERNET PHY LAN8700

USB CONTROLLER TCC8600

I2S/SPDIF/DSD

NETWORK CONTROLLER DM860

DAC AK4424ET

TO DSP

ZONE2

ZONE3

SPDIF

AUDIO PLD EPM240T100C5N

DSP ADSP21367

SDRAM

FLASH

SPDIF

CLOCK JITTER REDUCER CS2100

DIR2 LC89058

ADC AK5358B

I2S

DIR1 LC89058

I2S

ZONE2 DAC AK4424ET

AVR3311

HPF

MONO MIX

HPF

MONO MIX

HPF

SPDIF/I2S/DSD

I2S

MONO MIX

AVR891/991(Bypass)

AVR3311

HDMI TRANSMITTER ADV7511

MAIN ZONE DAC AK4358VQ (PCM ONLY)

ZONE2 VOLUME NJW1194

AVR2311/3311

ZONE3 VOLUME NJW1194

HDMI SWITCHER

PI3HDMI1310A

+

-

+

-

+

-

+

-

+

-

+

-

+

-

+

-

RELAY BLOCK

ARC SPDIF

FL

FR

C

SL

AVR2311/891 FL/SBL/Z2L/FL-H

SR

AVR3311/991 FL/SBL/Z2L/Z3L/FL-H

SBL

SBR

AVR2311/891 FR/SBR/Z2R/FR-H

AVR3311/991

FL

FR/SBR/Z2R/Z3R/FR-H

FR

C

SL

SBL

AVR2311(EU),AVR3311=7.2CH

SBR

SW1

AVR2311(NA/N/C)/891/991=0.2CH

SW2

Z2L

Z2R

Z3L

Z3R

AVR3311

HDMI OUT1

HDMI OUT2

AVR3311(EU/N/C)

SPK OUT

PRE-OUT

REC OUT

HDMI OUT

DIGITAL OUT

COAX1

COAX2

TC74HCU04AF

SPDIF

DIR3 LC89058

ZONE3 DAC AK4424ET

AVR3311

42

g.19,20,21

DIRECT

VOLUME AND INPUT SELECTOR R2A15220FP

R-CH Audio Selction

ATT

HEADPHONE OUT

ANALOG INPUT

FRONT INPUT

SIRIUS

MIC(Mini Jack)

iPod Dock

HD Radio

HD-RADIO

AVR2311/3311 NA

AM/FM TUNER

AVR2311 EU/3311 EU AVR891/991

HDMI IN

ETHERNET

USB FRONT

DIGITAL IN

AVR3311/991=PHONO+6INPUT

AVR2311/891 = 6INPUT

AVR3311/991 NA Series

AVR2311/891/3311/991

HDMI1

HDMI2

HDMI3

HDMI4

HDMI5

HDMI6

AVR2311/891/991

FRONT HDMI

AVR3311

AVR3311/991

AVR2311/891

OPT1

OPT2

HDMI RECEIVER ADV7840

HDMI SWITCHER ADV3002

TMDS BUFFER

ETHERNET PHY LAN8700

USB CONTROLLER TCC8600

I2S/SPDIF/DSD

NETWORK CONTROLLER DM860

DAC AK4424ET

TO DSP

ZONE2

ZONE3

SPDIF

AUDIO PLD EPM240T100C5N

SPDIF

SDRAM

DSP ADSP21367

FLASH

DIR2 LC89058

ADC AK5358B

I2S

DIR1 LC89058

SPDIF

CLOCK JITTER REDUCER CS2100

I2S

ZONE2 DAC AK4424ET

AVR3311

HPF

MONO MIX

HPF

MONO MIX

HPF

SPDIF/I2S/DSD

I2S

MONO MIX

AVR891/991(Bypass)

AVR3311

HDMI TRANSMITTER ADV7511

MAIN ZONE DAC AK4358VQ (PCM ONLY)

ZONE2 VOLUME NJW1194

AVR2311/3311

ZONE3 VOLUME NJW1194

HDMI SWITCHER

PI3HDMI1310A

+

-

+

-

+

-

+

-

+

-

+

-

+

-

+

-

RELAY BLOCK

ARC SPDIF

FL

FR

C

SL

AVR2311/891 FL/SBL/Z2L/FL-H

SR

AVR3311/991 FL/SBL/Z2L/Z3L/FL-H

SBL

SBR

AVR2311/891 FR/SBR/Z2R/FR-H

AVR3311/991

FL

FR/SBR/Z2R/Z3R/FR-H

FR

C

SL

SBL

AVR2311(EU),AVR3311=7.2CH

SBR

SW1

AVR2311(NA/N/C)/891/991=0.2CH

SW2

Z2L

Z2R

Z3L

Z3R

AVR3311

HDMI OUT1

HDMI OUT2

AVR3311(EU/N/C)

SPK OUT

PRE-OUT

REC OUT

HDMI OUT

DIGITAL OUT

COAX1

COAX2

TC74HCU04AF

SPDIF

DIR3 LC89058

ZONE3 DAC AK4424ET

AVR3311

43

g.23,24

DIRECT

VOLUME AND INPUT SELECTOR R2A15220FP

R-CH Audio Selction

ATT

HEADPHONE OUT

ANALOG INPUT

FRONT INPUT

SIRIUS

MIC(Mini Jack)

iPod Dock

HD Radio

HD-RADIO

AVR2311/3311 NA

AM/FM TUNER

AVR2311 EU/3311 EU AVR891/991

HDMI IN

ETHERNET

USB FRONT

DIGITAL IN

AVR3311/991=PHONO+6INPUT

AVR2311/891 = 6INPUT

AVR3311/991 NA Series

AVR2311/891/3311/991

HDMI1

HDMI2

HDMI3

HDMI4

HDMI5

HDMI6

AVR2311/891/991

FRONT HDMI

AVR3311

AVR3311/991

AVR2311/891

OPT1

OPT2

HDMI RECEIVER ADV7840

HDMI SWITCHER ADV3002

TMDS BUFFER

ETHERNET PHY LAN8700

USB CONTROLLER TCC8600

I2S/SPDIF/DSD

NETWORK CONTROLLER DM860

DAC AK4424ET

TO DSP

ZONE2

ZONE3

SPDIF

AUDIO PLD EPM240T100C5N

DSP ADSP21367

SDRAM

FLASH

SPDIF

CLOCK JITTER REDUCER CS2100

DIR2 LC89058

ADC AK5358B

I2S

DIR1 LC89058

I2S

ZONE2 DAC AK4424ET

AVR3311

HPF

MONO MIX

HPF

MONO MIX

HPF

SPDIF/I2S/DSD

I2S

MONO MIX

AVR891/991(Bypass)

AVR3311

HDMI TRANSMITTER ADV7511

MAIN ZONE DAC AK4358VQ (PCM ONLY)

ZONE2 VOLUME NJW1194

AVR2311/3311

ZONE3 VOLUME NJW1194

HDMI SWITCHER

PI3HDMI1310A

+

-

+

-

+

-

+

-

+

-

+

-

+

-

+

-

RELAY BLOCK

ARC SPDIF

FL

FR

C

SL

AVR2311/891 FL/SBL/Z2L/FL-H

SR

AVR3311/991 FL/SBL/Z2L/Z3L/FL-H

SBL

SBR

AVR2311/891 FR/SBR/Z2R/FR-H

AVR3311/991

FL

FR/SBR/Z2R/Z3R/FR-H

FR

C

SL

SBL

AVR2311(EU),AVR3311=7.2CH

SBR

SW1

AVR2311(NA/N/C)/891/991=0.2CH

SW2

Z2L

Z2R

Z3L

Z3R

AVR3311

HDMI OUT1

HDMI OUT2

AVR3311(EU/N/C)

SPK OUT

PRE-OUT

REC OUT

HDMI OUT

DIGITAL OUT

COAX1

COAX2

TC74HCU04AF

SPDIF

DIR3 LC89058

ZONE3 DAC AK4424ET

AVR3311

44

S5(-VKK)

5.2V

DV3.3V

NET3.3V

FL AC (F2)

A.V-5.0V

A.V+5.0V

MAIN -B

3

4 1

2

VCC

DV1.0V

NET1.2V

DA1.2V

CEC1.8V

NET1.8V

DV1.8V

CEC3.3V

DA3.3V

ABT2015

ADSP21367

ADV7840

DM860(AVR3311)

TCC8600(AVR2311)

DV 5V

FL AC (F1)

DA+5.0V

A-8.0V (Pre)

A+8.0V (Pre)

MAIN +B

CPU POWER

AVR2311

AVR3311

MAIN PWR ON

S4(VIDEO)

S1(AMP +B)

CEC3.3V

DV 5V

VE 1.8V ADV7392

VH

A.V+3.3V

SCPU+5V

CEC+5V

USB+5V

REMOTE POWER

SWM3.3V

M3.3V

BU7628*4,BU4052*2,AVDM2000

AVDM2000

BU7628*4,BU4052*2

AC CORD

S6(FILAMENT)

S2(+8V,-8V)

PQ018DNA

PQ012ENB

PQ018ENA

PQ033DNA

NJM2388F

PQ120

NJM7908

NJM7805

AVDD 1.8V ADV7840

GUI 1.2V XC3S400A

VE 3.3V ADV7392

TC74VHCT125,PI3HDMI1310

SCPU+3.3V

BFNK0563F5RAND330QP

MUTE3.3V

REMOTE3.3V

SWM5V

AZ4580*15,R2A15220,NJW1194*2

AK5358/AK4424*2(AVR3311)

AZ4580*15,R2A15220,NJW1194*2

NJM7905

NJM7805

PQ120

NJM7808

PQ033DNA

TC74VHCT244,ADV7511,PI3HDMI1310,ADV7392

ADSP21367,W9864G,EN29LV160BB

SAA7121,LAN8700,DM860

TC74VHC08,MC14094BD*4

R5F64169DFD,EN29LV160BB

2388F09 : TUNER(AVR23/3311 E2/E1C/K/891/991/EA) +9.0V

D1.0V

DV POWER3

D1.2V1

NET POWER

ABT2015,ADV7511,K4T51163QG*2

ADV7840,ADV3002,AD8195

CS2100,EPM240T,LC89057*3,TC74VHCU04

M25P40,TC74VHCT125*3,XC3S400A,ABT2015

MAIN TRANS

ILX3232D,TC74VHCT125VF

TC74VHCT08,MC14094BD

TRIGGER +12V

VCC DIAGRAM

D1.8V

D5V POWER

D1.2V2

DA POWER

D3.3V1

D5V POWER

D3.3V2

D5V POWER

45

Personal notes: Personal notes:

46

JIG FOR SERVICING

When you repair the printing board, you can use the following JIG (Extension cable kit). Please order to DENON Ofcial Service. Distributor in your region if necessary.

Note: When the connection which is wrong in the JIG (EXTENSION UNIT KIT) is done it becomes cause of damage.

8U-110084S : EXTENSION UNIT KIT

• Connection of PCB HDMI JIG

-Preparation-

8U-110084S : EXTENSION UNIT KIT : 1 Set Insulation sheet (Do not supply it) : 3 sheet Ground lead (Do not supply it) : 3 pcs

-Procedures-

(1) Remove the screws.

(2) Disconnect the connector board.

Board to board

PCB HDMI

Board to board

PCB VIDEO

Board to board

PCB INPUT

47

(3) PCB HDMI is detached from the chassis, and it puts it into the state turned inside out.

Please pave an insulation sheet that is larger than PCB HDMI under PCB.

Connect the ground point of PCB to the chassis with a ground lead or the like.

b

PCB INPUT PCB VIDEO

Ground lead

PCB HDMI

Insulation sheet

(4) Connect the four extension jig cables.

PCB HDMI

Ground lead

PCB FRONT CNT

PCB SIDE CNT

PCB VIDEO

Insulation sheet

PCB HDMI

2

9

11

34 5678

1

Insulation sheet

PCB HDMI

10

48

PCB FRONT CNT

PCB HDMI

13

14

15

16

PCB SIDE CNT

12

Insulation sheet

PCB INPUT

Connection table of Board to Board

No. Pin Ref. No. PCB Ref. No. PCB

q

w

e r t y u i o Q0 Q11 Q2 Q3 Q4 Q5 Q6

11 pin CP3 SIDE CNT N4908 HDMI 25 pin CP4 SIDE CNT N4907 HDMI 19 pin CP105 FRONT CNT N4910 HDMI 17 pin CP106 FRONT CNT N4911 HDMI 13 pin CP107 FRONT CNT N4912 HDMI 19 pin CP108 FRONT CNT N4913 HDMI 17 pin CP109 FRONT CNT N4914 HDMI 33 pin CP110 FRONT CNT N4916 HDMI 19 pin CP111 FRONT CNT N2001 VIDEO 17 pin CP112 FRONT CNT N2002 VIDEO 13 pin CP113 FRONT CNT N2003 VIDEO 13 pin CP114 FRONT CNT CX3001 INPUT 33 pin CP115 FRONT CNT CN3000 INPUT 19 pin CP6 SIDE CNT CX3000 INPUT 17 pin CP7 SIDE CNT CX3002 INPUT 15 pin CP8 SIDE CNT CX3003 INPUT

49

ABOUT REPLACE THE MICROPROCESSOR WITH A NEW ONE

When replaced of the U-PRO (Microprocessor) or the Flash ROM, conrm contents of the following.

PWB Name Ref. No. Description

HDMI U5301 R5F64169DFD B SOFTWARE: Main HDMI U5101 W19B160BBT7H B SOFTWARE: Main ROM HDMI U5500 R5F3650KNFB B SOFTWARE: Sub HDMI U3202 EN29LV160BB-70TIP B SOFTWARE: DSP ROM HDMI U3000 EPM240T100C5N B SOFTWARE: Audio PLD HDMI U1603 M25P40-VMN6PB B SOFTWARE: Video Cong ROM

After replaced

A : Mask ROM (With software). No need write-in of software to the microprocessor. B : Flash ROM (With software). Usually, no need write-in of software. But, when the software was updated, you should be

write-in of the new software to the microprocessor or ash ROM. Please check the software version.

C : Empty Flash ROM (Without software). You should be write-in of the software to the microprocessor or ash ROM.

Refer to "Update procedure" or "writing procedure", when you should be write-in the software.

After

replaced

Remark

f

VERSION UPGRADE PROCEDURE OF FIRMWARE

You can update by downloading the latest rmware from the Internet.

1. Connecting to the Network

(1) System Requirement

Internet Connection by Broadband Circuit

・

Modem

・

Router

・

Ethernet cable (CAT-5 or greater recommended)

・

(2) Setting

Internet

Computer

Router

Modem

To WAN port

To LAN port

ETHERNET connector

LAN port/ Ethernet connector

2. Check for Update and Update

Check if the latest rmware exists. You can also check approximately how long it will take to complete an update. (1) Press the MENU button on the remote control to display the GUI menu. (2) Use the cursor buttons to select "Manual Setup" → "Option Setup" → "Firmware Update" → "Update Check". (3) Press the ENTER buttom.

The latest version of the rmware uploaded to the web is displayed.

・

If the latest rmware version is on the web, proceed to (4).

・

If the latest rmware is already installed, press the MENU button to close the menu.

・

(4) Use the cursor buttons to select "Update", then press the ENTER button.

During update, the power indicator lights red and the GUI screen is shut down. And a rough remaining time is

・

indicated on the display.

When updating is complete the power indicator lights green and normal status is resumed.

・

(5) Press the MENU button to close the menu.

50

--- Cautions on Firmware Update ---

In order to use these functions, you must have the correct system requirements and settings for a broadband Internet

・

connection.

Do not turn off the power until updating is completed.

・

Even with a broadband connection to the Internet, approximately about 1 hour is required for the updating procedure to be completed. Once updating starts, normal operations on the AVR-3311 cannot be performed until updating is completed. Also, setting items of the GUI menu of AVR-3311 or setting items of the image adjustment may be initialized. Make a note of the settings before updating, and set them again after updating.

3. About the error code

See the chart below for error codes, details of faults, and coping strategies when rmware updates are performed through DPMS (Denon Product Management Server).

Error Code

01

02

03

04

05

06

07

Details of Error code Display Coping strategies

Log-in to DPMS has failed.

Line, etc., is busy when logging into DPMS.

Connection to DPMS failed.

Firmware le data was requested but error message was received.

Firmware le data was requested but it timed out.

Firmware le data was requested but error message was received.

All rmware le data was requested but it timed out.

L o g i n f a i l e d

S e r v e r i s b u s y

C o n n e c t i o n f a i l

Reset and update again. Carry out the update in an environment that

0 1

has little network load.

Carry out the update in an environment that has little network load.

0 2

Check the network connection. Carry out the update in an environment

0 3

that has little network load.

Check the network connection. Carry out the update in an environment

0 4

that has little network load.

Check the network connection. Carry out the update in an environment

0 5

that has little network load.

Check the network connection. Carry out the update in an environment

0 6

that has little network load.

Check the network connection. Carry out the update in an environment

0 7

that has little network load.

Main CPU rmware le data was requested but error message was

08

received.

Main CPU rmware le data was

09

requested but it timed out.

Error (NG) message received when

0A

downloading Main CPU rmware.

Error (line congestion) message received when downloading Main

0B

CPU rmware.

Error (connection failure) message received when downloading Main

0C

CPU rmware.

C o n n e c t i o n f a i l

D o w n l o a d f a i l

51

Check the network connection. Carry out the update in an environment

0 8

that has little network load.

Check the network connection. Carry out the update in an environment

0 9

that has little network load.

Check the network connection. Carry out the update in an environment

0 A

that has little network load.

Check the network connection. Carry out the update in an environment

0 B

that has little network load.

Check the network connection. Carry out the update in an environment

0 C

that has little network load.

Error Code

0D

10

Details of Error code Display Coping strategies

Data acquisition failed (timed out) when downloading Main CPU rmware. Received Package Version is wrong.

Main CPU failed to receive rmware for rewriting sent from DM860 (when timed out).

C o n n e c t i o n f a i l

0 D

M a i n * * * m i n

U p d a t i n g f a i l 1 0

Check the network connection. Carry out the update in an environment that has little network load.

Turn the power off then back on. Updating starts automatically.

Main CPU failed to receive rmware for rewriting sent from DM860 (when

11

an error )

There was invalid data in the rmware for rewriting sent from

12

DM860 to Main CPU (when a Check Sum error).

The deletion of block data failed

13

before rewriting Main CPU.

The rewriting of block data failed

14

when rewriting Main CPU.

The data verication was invalid

15

after rewriting Main CPU.

Log-in to DPMS has failed when rewriting rmware such as Sub

36

CPU, DSP, FPGA, and PLD.

Line, etc., is busy when logging into DPMS when rewriting rmware

37

such as Sub CPU, DSP, FPGA, and PLD.

M a i n * * * m i n

U p d a t i n g f a i l 1 1

M a i n * * * m i n

U p d a t i n g f a i l 1 2

M a i n * * * m i n

E r a s e f a i l 1 3

M a i n * * * m i n

U p d a t i n g f a i l 1 4

M a i n * * * m i n

U p d a t e C h e c k N G 1 5

L o g i n f a i l e d

3 6

S e r v e r i s b u s y

3 7

Turn the power off then back on. Updating starts automatically.

Carry out the update in an environment that has little network load.

Connection to DPMS failed when rewriting rmware such as Sub

38

CPU, DSP, FPGA, and PLD.

Connection to DPMS timed out when rewriting rmware such as

39

Sub CPU, DSP, FPGA, and PLD.

Error (NG) message received when downloading rmware when

3A

rewriting Main CPU.

Error (line congestion) message received when downloading

3B

rmware when rewriting Main CPU.

Error (connection failure) message received when downloading

3C

rmware when rewriting Main CPU.

Log-in to DPMS has failed when rewriting rmware such as Sub

50

CPU, DSP, FPGA, and PLD.

Line, etc., is busy when logging into DPMS when rewriting rmware

51

such as Sub CPU, DSP, FPGA, and PLD.

C o n n e c t i o n f a i l

3 8

C o n n e c t i o n f a i l

3 9

D o w n l o a d f a i l

3 A

D o w n l o a d f a i l

3 B

D o w n l o a d f a i l

3 C

S u b * * * m i n

L o g i n f a i l e d 5 0

S u b * * * m i n

S e r v e r i s b u s y 5 1

Check the network connection. Carry out the update in an environment that has little network load.

Turn the power off then back on. Updating starts automatically. Carry out the update in an environment that has little network load.

Carry out the update in an environment that has little network load.

52

Error Code

Details of Error code Display Coping strategies

Connection to DPMS failed when rewriting rmware such as Sub

52

CPU, DSP, FPGA, and PLD.

Error message received regarding rmware data after logging in to

54

DPMS when rewriting rmware such as Sub CPU, DSP, FPGA, and PLD.

When rewriting rmware such as Sub CPU, DS

55

was made for rmware data after logging in to DPMS, but it timed out.

Failure to download rmware after logging in to DPMS when rewriting

56

rmware such as Sub CPU, DSP, FPGA, and PLD.

Firmware download error received (line congestion) after logging in to

57

DPMS when rewriting rmware such as Sub CPU, DSP, FPGA, and PLD.

Firmware download error received (connection failure) after logging in to

58

DPMS when rewriting rmware such as Sub CPU, DSP, FPGA, and PLD.

NACK received when "C" command sent to Sub CPU, DSP, FPGA, PLD

5A

etc.

P, FPGA,

and PLD, request

S u b * * * m i n

C o n n e c t i o n F a i l 5 2

S u b * * * m i n

U p d a t i n g f a i l 5 4

S u b * * * m i n

U p d a t i n g f a i l 5 5

S u b * * * m i n

D o w n l o a d f a i l 5 6

S u b * * * m i n

S e r v e r i s b u s y 5 7

S u b * * * m i n

C o n n e c t i o n F a i l 5 8

S u b * * * m i n

C o n n e c t i o n F a i l 5 A

Check the network connection. Carry out the update in an environment that has little network load.

Turn the power off then back on. Updating starts automatically. Carry out the update in an environment that has little network load.

Turn the power off then back on. Updating starts automatically.

NACK received when "L" command sent to Sub CPU, DSP, FPGA, PLD

5B

etc.

Sub CPU, DSP, FPGA, PLD etc. failed to receive rmware for

5C

rewriting sent from DM860 (when timed out).

Sub CPU, DSP, FPGA, PLD etc. failed to receive rmware for

5D

rewriting sent from DM860 (when an error).

Invalid data in rmware such as Sub CPU, DSP, FPGA, and PLD for

5E

rewriting sent from DM860 (when a Check Sum error).

Invalid data in rmware such as Sub CPU, DSP, FPGA, and PLD for

5F

rewriting sent from DM860 (invalid data received).

NACK received when "P" command sent to Sub CPU, DSP, FPGA, PLD

60

etc.

NACK received when "I" command sent to Sub CPU, DSP, FPGA, PLD

61

etc.

S u b * * * m i n

U p d a t i n g f a i l 5 B

S u b * * * m i n

U p d a t i n g f a i l 5 C

S u b * * * m i n

U p d a t i n g f a i l 5 D

S u b * * * m i n

U p d a t i n g f a i l 5 E

S u b * * * m i n

U p d a t i n g f a i l 5 F

S u b * * * m i n

U p d a t i n g f a i l 6 0

S u b * * * m i n

U p d a t e C h e c k N G 6 1

Turn the power off then back on. Updating starts automatically.

Start failure of Sub µ-com.

62

Failure to acquire serial ash data

80

and before deleting serial ash.

S u b * * * m i n

U p d a t i n g f a i l 6 2

O S D * * * m i n

U p d a t i n g f a i l 8 0

53

Turn the power off then back on. Updating starts automatically. (AVR-4810 deal with this matter from the rst and AVR-4310 deal with this matter by the update.)

Turn the power off then back on. Updating starts automatically.

Error Code

Details of Error code Display Coping strategies

Failure to delete data before

81

rewriting serial ash.

Failure to receive rmware for serial ash rewriting sent by DM860 (when

82

timed out).

Failure to receive rmware for serial ash rewriting sent by DM860 (when

83

an error).

Failure to receive rmware for serial ash rewriting sent by DM860 (when

84

a Check Sum error).

Failure to receive rmware for serial ash rewriting sent by DM860 (when

85

invalid data received).

Failure to rewrite when writing data

86

in serial ash.

Failure to acquire (Application Mode) IP address before rewriting

A0

DM860 (AutoIP).

O S D * * * m i n

U p d a t i n g f a i l 8 1

O S D * * * m i n

U p d a t i n g f a i l 8 2

O S D * * * m i n

U p d a t i n g f a i l 8 3

O S D * * * m i n

U p d a t i n g f a i l 8 4

O S D * * * m i n

U p d a t i n g f a i l 8 5

O S D * * * m i n

U p d a t i n g f a i l 8 6

E t h e r I M G * * * m i n

C o n n e c t i o n F a i l A 0

Turn the power off then back on. Updating starts automatically.

Check the network connection. Carry out the update in an environment that has little network load.

Failure to acquire (Application Mode) IP address before rewriting

A1

DM860 (when timed out).

Notication of invalid login via DPMS access when rewriting DM860

A2

related rmware (Application Mode).

Notication of line congestion via DPMS access when rewriting

A3

DM860 related rmware (Application Mode).

Notication of connection failure via DPMS access when rewriting

A4

DM860 related rmware (Application Mode).

Firmware data error message received after DPMS login when

A6

rewriting DM860 related rmware (Application Mode).

When rewriting DM860 related rmware (Application Mode),

A7

request was made for rmware data after DPMS login but it timed out.

Failure to acquire (Boot Loader Mode) IP address before rewriting

A8

DM860 (AutoIP).

E t h e r I M G * * * m i n

C o n n e c t i o n F a i l A 1

E t h e r I M G * * * m i n

L o g i n f a i l e d A 2

E t h e r I M G * * * m i n

S e r v e r i s b u s y A 3

E t h e r I M G * * * m i n

C o n n e c t i o n F a i l A 4

E t h e r I M G * * * m i n

U p d a t i n g f a i l A 6

E t h e r I M G * * * m i n

U p d a t i n g f a i l A 7

E t h e r I M G * * * m i n

C o n n e c t i o n F a i l A 8

Check the network connection. Carry out the update in an environment that has little network load.

Turn the power off then back on. Updating starts automatically. Carry out the update in an environment that has little network load.

Check the network connection. Carry out the update in an environment that has little network load.

Failure to acquire (Boot Loader Mode) IP address before rewriting

A9

DM860 (when timed out).

Notication of invalid login via DPMS access when rewriting

AA

DM860 related rmware (Boot Loader Mode).

E t h e r I M G * * * m i n

C o n n e c t i o n F a i l A 9

E t h e r I M G * * * m i n

L o g i n f a i l e d A A

54

Check the network connection. Carry out the update in an environment that has little network load.

Error Code

AB

AC

AE

AF

B0

B2

Details of Error code Display Coping strategies

Notication of line congestion via DPMS access when rewriting DM860 related rmware (Boot Loader Mode).

Notication of connection failure via DPMS access when rewriting DM860 related rmware (Boot Loader Mode).

Firmware download error message received (when download fails) when rewriting DM860 related rmware (Boot Loader Mode).

Firmware download error message received (line congestion) when rewriting DM860 related rmware (Boot Loader Mode).

Firmware download error message received (connection failure) when rewriting DM860 related rmware (Boot Loader Mode).

Error message received when rewriting DM860 related rmware.

E t h e r I M G * * * m i n

S e r v e r i s b u s y A B

E t h e r I M G * * * m i n

C o n n e c t i o n F a i l A C

E t h e r I M G * * * m i n

D o w n l o a d f a i l A E

E t h e r I M G * * * m i n

S e r v e r i s b u s y A F

E t h e r I M G * * * m i n

C o n n e c t i o n F a i l B 0

E t h e r I M G * * * m i n

U p d a t i n g f a i l B 2

Check the network connection. Carry out the update in an environment that has little network load.

Turn the power off then back on. Updating starts automatically. Carry out the update in an environment that has little network load.

55

Device display when rmware updated

Target of devide when rmware updated.

Target of device

Main

Sub

Audio PLD

DSP

OSD (FPGA/Program/Font Data)

DM860 Boot Loader

DM860 Image

Display

M a i n * * * m i n

U p d a t i n g

S u b * * * m i n

U p d a t i n g

A P L D * * * m i n

U p d a t i n g

D S P * * * m i n

U p d a t i n g

O S D * * * m i n

U p d a t i n g

E t h e r S B L * * * m i n

U p d a t i n g

E t h e r I M G * * * m i n

U p d a t i n g

Error cpde

10~15 36~3C

50~52 54~58 5A~62

50~52 54~58 5A 62 80~86

A0~A4 A6~AC AE~B0 B2

56

SURROUND MODES AND PARAMETERS

106

Symbols in the table

Delay Time Effect Lev. Room Size

LFE

z11

z10

D. Comp

S S S

S S

DRC

z9

z5

Cinema EQ.

z3

Subwoofer Mode

L/R

Front wide

L/R

Front height

L/R

Surround back

Channel output Surround Parameter

S S

z6

z7

z6

S S S

z4

D S S S

D S S

z1

D

z1

z2

D

z1

z6

D S S

z13

D

z12

z13

D

z12

S S

z8

D S S S

D S

D S S

D S S S S

z16

D

z2

z16

D

z2

z15

D

z14

S S

speakers.

z9 This item can be selected when a Dolby TrueHD signal is played.

z10 This item can be selected when a Dolby Digital or DTS signal is played.

z11 This item can be selected when a Dolby Digital or DTS signal or DVD-Audio is played.

z12 If “Audyssey DSX” is set to “ON–Height–”, sound is output from the front height speakers.

z13 If “Audyssey DSX” is set to “ON–Wide–”, sound is output from the front wide speakers.

z14 If “Surround Parameter” – “Speaker” – “S.Back” is set to “ON”, sound is output from the surround back

z15 If “Surround Parameter” – “Speaker” – “F.Height” is set to “ON”, sound is output from the front height

z3

D S S S S

D S S S

D S S S S

z16

D

z15

D

z14

z16 If “Surround Parameter” – “Speaker” – “F.Wide” is set to “ON”, sound is output from the front wide speakers.

L/R

Surround

Center

S D D D

S D

S D D D

S D S S S

L/R

Front

Surround mode

S This indicates the audio output channels or surround parameters that can be set.

D This indicates the audio output channels. The output channels depend on the settings of “Speaker Conﬁg.”.

PURE DIRECT

S D D D D

DIRECT (2channel)

DIRECT (Multi-channel)

STEREO

MULTI CH IN

DOLBY PRO LOGIC gz S D D D D S

DOLBY PRO LOGIC gx S D D D D S S

DOLBY PRO LOGIC g S D D D S S

S D D D S S

S D D D

S D D D D S S

DOLBY PRO LOGIC

DOLBY PRO LOGIC g A-DSX S D D D

DOLBY PRO LOGIC A-DSX

DTS NEO:6

S D D D

S D D D D

DTS NEO:6 A-DSX

Audyssey DSX

DOLBY DIGITAL

DOLBY DIGITAL Plus

S D D D D

DOLBY TrueHD

DTS SURROUND

DTS 96/24

S D D D D

DTS-HD

DTS Express

S D D D

MULTI CH STEREO

ROCK ARENA

JAZZ CLUB

S D D D

MATRIX

MONO MOVIE

VIDEO GAME

S D

“Mode”.

set.

VIRTUAL

z1 A signal for each channel contained in an input signal is output as audio.

z2 If “Surround Parameter” – “F.Height” is set to “ON”, sound is output from the front height speakers.

z3 Only when “Subwoofer Mode” is set to “LFE+Main”, sound is output from the subwoofer.

z4 If this surround mode is selected, only the “Height” mode setting is available for “Surround Parameter” –

z5 For HD Audio whose sampling frequency of an input signal is more than 96 kHz, this sound parameter cannot be

z6 This item can be selected when “Surround Parameter” – “Mode” is set to “Cinema”.

z7 This item can be selected when “Surround Parameter” – “Mode” is set to “Cinema” or “Pro Logic”.

z8 This item cannot be set when “Surround Parameter” – “S.Back” is set to “PLgx Music”.

57

107

Basic versionSimple version Advanced version Information

z23

RESTORER

DSX™

Audyssey

z24 z25

Dynamic

Volume™

z24

®

z21

Dynamic EQ

Audyssey Settings

XT

®

Tone

z19

mode only

NEO:6 Music

z22

S S S S

S S S S S

S S S S S S S

z20

S S S S S

PRO LOGIC g/gx Music mode only

Panorama Dimension C.Width C.Image MultEQ

Surround Parameter

Speaker Subwoofer

z18

Height Gain

z17

F.Height

S.Back

z11

AFDM

S S S S S S S S S

z3

S

S S S S S S S S S S S

S S S S S S S S S

S S S S S S S S

S S S S S S S S S

S S S S S S S

S S S

S S S S S S S

S S S S S S S S S

Surround mode

PURE DIRECT

DIRECT (2 channel)

DIRECT (Multi-channel)

STEREO

MULTI CH IN

DOLBY PRO LOGIC gz S S S S S S S

DOLBY PRO LOGIC gx S S S S S S S S S S

DOLBY PRO LOGIC g S S S S S S S S S S S

DOLBY PRO LOGIC

DOLBY PRO LOGIC g A-DSX S S S S S S S S S

DOLBY PRO LOGIC A-DSX

DTS NEO:6

DTS NEO:6 A-DSX

Audyssey DSX

DOLBY DIGITAL

DOLBY DIGITAL Plus

DOLBY TrueHD

DTS SURROUND

DTS 96/24

DTS-HD

DTS Express

MULTI CH STEREO

ROCK ARENA

JAZZ CLUB

MONO MOVIE

VIDEO GAME

MATRIX

VIRTUAL

z3 Only when “Subwoofer Mode” is set to “LFE+Main”, sound is output from the subwoofer.

z17 If “Speaker Conﬁg.” – “F.Height” is set to “None”, this item cannot be selected.

z18 This item can be selected when “Surround Parameter” – “F.Height” is set to “ON”.

z19 This item cannot be set when “Dynamic EQ” is set to “ON”.

z20 In this surround mode, bass is +6 dB, and treble is +4 dB. (Default)

z21 This item cannot be set when “MultEQ XT” is set to “OFF” or “Manual”.

z22 This item cannot be set when “Dynamic EQ” is set to “OFF”.

z23 This item can be set when the input signal is analog, PCM 48 kHz or 44.1 kHz.

z24 For HD Audio whose sampling frequency of an input signal is more than 96 kHz, this sound parameter cannot be set.

z25 This item can not be selected when “Surround Parameter” – “F.Height” is set to “ON”.

58

108

DOLBY

DIGITAL

DOLBY

DIGITAL

DOLBY

DIGITAL

DOLBY

DIGITAL EX

DOLBY

DIGITAL EX

DOLBY

DTS 96/24

DTS

(2ch)

(4/3ch)

(5.1/5/4ch)

Flag)

(With no

(With Flag)

DIGITAL Plus

TrueHD

(5.1ch)

Input signal types and formats

MTRX

DTS ES

(With Flag)

DSCRT

DTS ES

(With Flag)

DTS

EXPRESS

High

DTS-HD

Resolution

Audio

Master

DTS-HD

(2ch)

LINEAR PCM

PCM DTS-HD DTS DOLBY DOLBY DIGITAL

(multi ch)

LINEAR PCM

ANALOG

Audio

z5 F

z4 If “Speaker Conﬁg.” – “F.Height” is set to “None”, this surround mode cannot be selected.

z5 The same was when “Audyssey DSX™” setting is set to “ON”.

S S S S S S S

S S S

z5 S S S

z5 F

z5 S S F

z1z3 F D

z5 F

z1z3 S S S S S S

z5 F

z5 S F F F

z5 F

z1z3 S S

z1z3 S S S S

z5 S S S

Surround mode NOTE

DTS NEO:6 CINEMA A-DSX

DTS NEO:6 MUSIC

DTS NEO:6 CINEMA

DTS EXPRESS

DTS (–HD) + NEO:6

DTS (–HD) + PLgz z4 S S S S S S S

DTS (–HD) + PLgx MUSIC z1z3 S S S S S S S

DTS 96/24

DTS-HD MSTR

DTS-HD HI RES

DTS ES DSCRT6.1

Symbols in the table

F This indicates the default surround mode.

D This indicates the surround mode that is ﬁxed when “AFDM” is set to “ON”.

S This indicates the selectable surround mode.

DTS SURROUND

DTS (–HD) + PLgx CINEMA z2z3 S S S S S S S

DTS ES MTRX6.1

DTS SURROUND

DOLBY TrueHD

DTS NEO:6 MUSIC A-DSX

DOLBY DIGITAL+

Audyssey DSX

DOLBY SURROUND

59

DOLBY (D) (D+) (HD) +PLgx CINEMA z2z3 S S F D S S S

DOLBY (D+) (HD) +EX

DOLBY DIGITAL

DOLBY DIGITAL EX

DOLBY PRO LOGIC

DOLBY PRO LOGIC g GAME z5 S S S

DOLBY PRO LOGIC g MUSIC z5 S S S

DOLBY PRO LOGIC g CINEMA z5 S S S

DOLBY PRO LOGIC gz z4 S S S

DOLBY PRO LOGIC gx GAME z1z3 S S S

DOLBY PRO LOGIC gx MUSIC z1z3 S S S

DOLBY PRO LOGIC gx CINEMA z1z3 S S S

DOLBY (D) (D+) (HD) +PLgz z4 S S S S S S

DOLBY (D) (D+) (HD) +PLgx MUSIC z1z3 S S S S S S

z1 If “Speaker Conﬁg.” – “S.Back” is set to “None”, this surround mode cannot be selected.

z2 If “Speaker Conﬁg.” – “S.Back” is set to “1spkr” or “None”, this surround mode cannot be selected.

z3 This surround mode can be selected when “Amp Assign” is set to “Normal”.

109

Basic versionSimple version Advanced version Information

(2ch)

DOLBY

DIGITAL

(4/3ch)

DOLBY

DIGITAL

DOLBY

DIGITAL

(5.1/5/4ch)

Flag)

DOLBY

(With no

DIGITAL EX

DOLBY

(With Flag)

DIGITAL EX

DOLBY

DIGITAL Plus

DOLBY

TrueHD

DTS 96/24

DTS

(5.1ch)

Input signal types and formats

MTRX

DTS ES

DSCRT

DTS ES

DTS

EXPRESS

High

DTS-HD

Resolution

Master

DTS-HD

(2ch)

LINEAR PCM

PCM DTS-HD DTS DOLBY DOLBY DIGITAL

(multi ch)

LINEAR PCM

(With Flag)

Audio

S S S S S S

S

ANALOG

Surround mode NOTE

S S S

DOLBY PRO LOGIC g CINEMA A-DSX S S S

DOLBY PRO LOGIC g MUSIC A-DSX S S S

DOLBY PRO LOGIC g GAME A-DSX S S S

DOLBY PRO LOGIC A-DSX

DOLBY SURROUND

z5 F

Audyssey A-DSX

MULTI CH IN

MULTI CH IN + PLgx CINEMA z2z3 S

MULTI CH IN

z3 S

z3 F D (7.1)

MULTI CH IN + PLgx MUSIC z1z3 S

MULTI CH IN + PLgz z4 S

MULTI CH IN + Dolby EX

MULTI CH IN 7.1

S S S S S S S S S S S S S S S S S

Audyssey A-DSX

DIRECT

PURE DIRECT

S S S S S S S S S S S S S S S S S

S S S S S S S S S S S S

PURE DIRECT

MULTI CH STEREO

DSP SIMULATION

60

S S S S S S S S S S S S

MONO MOVIE

JAZZ CLUB

ROCK ARENA

S S S S S S S S S S S S

VIRTUAL

MATRIX

VIDEO GAME

F S F S S S S S S S S S S S S S S

STEREO

z1 If “Speaker Conﬁg.” – “S.Back” is set to “None”, this surround mode cannot be selected.

z2 If “Speaker Conﬁg.” – “S.Back” is set to “1spkr” or “None”, this surround mode cannot be selected.

z3 This surround mode can be selected when “Amp Assign” is set to “Normal”.

z4 If “Speaker Conﬁg.” – “F.Height” is set to “None”, this surround mode cannot be selected.

z5 The same was when “Audyssey DSX™” setting is set to “ON”.

ADJUSTMENT

Audio Section

Idling Current

Required measurement equipment: DC Voltmeter

1. Preparation

(1) Avoid direct blow from an air conditioner or an electric fan, and adjust the unit at normal room temperature

15 °C ~ 30 °C (59 °F ~ 86 °F).

(2) Presetting

• POWER (Power source switch) STANDBY

• SPEAKER (Speaker terminal) No load (Do not connect speaker, dummy resistor, etc.)

2. Adjustment

(1) Remove top cover and set VR401, VR402, VR403, VR404, VR405, VR406, VR407 on 7CH AMP UNIT at fully

counterclockwise (c) position.

(2) Connect DC Voltmeter to test points (FRONT-Lch: TP401, FRONT-Rch: TP402, CENTER ch: TP403, SURROUND-

Lch: TP404, SURROUND-Rch: TP405, SURROUND-BACK Lch: TP406, SURROUND-BACK Rch: TP407. (3) Connect power cord to AC Line, and turn power switch "ON". (4) Presetting.

MASTER VOLUME : "---" counterclockwise (c min.)

SPEAKER (Speaker terminal) : No load

(Do not connect speaker, dummy resistor, etc.) MODE : MCH STEREO FUNCTION : DVD

(5) Within 2 minutes after the power on, turn VR401 clockwise (x) to adjust the TEST POINT voltage to

8 mV ± 0.5 mV DC.

(6) After 10 minutes from the preset above, turn VR401 to set the voltage to 8 mV ± 0.5 mV DC. (7) Adjust the Variable Resistors of other channels in the same way.

DC Voltmeter

VR401

TP401

F Lch

VR404

7CH AMP UNIT

VR403

TP404

S Lch

TP403

C ch

VR405

TP405

S Rch

VR402

TP402

F Rch

VR406

VR407

TP406

S Back Lch

TP407

S Back Rch

61

TROUBLE SHOOTING

1. POWER

1.1. Power not turn on

Power not turn on.

When the power turned on, does the ON/STANDBY indicator on the front panel ashing green?

YES

About 10 seconds later, does the ON/STANDBY indicator on the front panel turn lighting green ?

NO

NO NO

Is the fuse blown?

NO

Is a DC 5V voltage being supplied from the SMPS B'D (CX101) to the µ-com?

YES YES

Check µ-com periphery circuitry of HDMI B'D and replace any defective parts.

YES

NO NO

Refer to 1.2.Fuse is blown.

Is a DC 5V voltage output when the cord supplying the power from the SMPS B'D to the HDMI B'D (N4610) is unplugged?

Check circuitry and parts from N4610 on the HDMI B'D to the µ-com power supply for damage and shortcircuits, and replace any defective parts.

Are there any incomplete connections in the connectors connecting between the various circuit boards?

YES

Check for damage in the SMPS B'D parts and replace any defective parts.

NO

Check "Errors checking mode". (Refer to 19 page.)

Is the fuse blown?

NO

Check voltage of N4905 (15PIN) of HDMI B'D while the ON/STANDBY indicator is ashing green.

0.6V or -0.6V

Pull out connector (CP1) of SPK BD, and check "Errors checking mode". (Refer to 19 page.)

1.2. Fuse is blown

Check for leaks or short circuits in the primary side parts, and replace any defective parts.

NO

Refer to 1.2. Fuse is blown.

Check circuitry and parts from N4905 on

0V

the HDMI B'D to the µ-com for damage and shortcircuits, and replace any defective parts.

Fuse is blown

Check for short circuits in the rectier diodes and circuitry of the secondary side rectifying circuits, and replace any defective parts.

Connect the connectors properly.

Check for short circuits in the power stabilizer unit's regulator output terminal and the ground, and replace any defective parts.

After repairing, also replace the fuse.

62

2. Analog video

MONITOR OUT (CVBS) output NG

Input CVBS

Function : SAT

To A

MONITOR OUT (Component) output NG

"Video Convert" is set to ON.

Input CVBS

Function : SAT

Input S

Function : DVR

To B

Input S

Function : DVR

To C

Input

COMPONENT

Not output

Input COMPONENT

Function : DVD

63

A

Input

CVBS

Check power supply voltage.

V+5V : N2004-4pin V-5V : N2004-1pin

OK

Check on set value of each IC. HDMI B'D L4900 :

L4901 :

Extend HDMI B'D using a jig.

Check output of selector (U2003).

Check I2C communication

waveforms. Check I2C communication waveforms.

OK

V : K2003 (Lead of terminal) V : JV154

OK

NG

REGULATOR B'D aw.

NG

HDMI B'D aw.

NG NG

Check input of selector (U2003).

V : JV82

OK

Check power supply voltage of U2003, and soldering of IC.

Check cable between main unit and player or check player.

Check cable between main unit and monitor or check monitor.

Check FRONT CONNECTOR B'D aw, and connection of FRONT CONNECTOR B'D or HDMI B'D and VIDEO B'D.

Unless specied, VIDEO B'd part.

b

64

B

Input

S

Check power supply voltage.

V+5V : N2004-4pin V-5V : N2004-1pin

OK

Check on set value of each IC. HDMI B'D L4900 :

L4901 :

L4905 : H(+5V) L4906 : L(0V)

Extend HDMI B'D using a jig.

Check output of video amplier (U2005).

S-Y : JV101 S-C : JV27

2

C communication

Check I waveforms. Check I2C communication waveforms.

OK

NG

REGULATOR B'D aw.

NG

HDMI B'D aw.

Check input of video amplier

NG

(U2005)

.

S-Y : C2009(- side) S-C : C2010(- side)

Check power supply voltage of U2005, and surrounding circuitry soldering.

Check cable between main unit and player or check player.

Check input selector(U2001).

NG

OK OK

S-Y : JV192 S-C : JV89

Check power supply voltage of U2001, and surrounding circuitry soldering.

NG

Check output of selector.

Y/C MIX : K2003 (Lead of terminal)

OK

Check cable between main unit and monitor or check monitor.

Check FRONT CONNECTOR B'D aw, and connection of FRONT CONNECTOR B'D or HDMI B'D/ VIDEO B'D.

NG

Check input of selector (U2003).

Y/C MIX : JV61

Check power supply voltage of U2003, and soldering of IC.

OK

Check power supply voltage of

NG

U2007, and surrounding circuitry soldering.

Unless specied, VIDEO B'd part.

b

65

C

CVBS/S/COMPONENT

Check input signal of VIDEO DECODER (U1100). HDMI B'D

V : L4920 S-Y : L4924 S-C : L4925 COMPONENT-Y : L4923 COMPONENT-Cb : L4922 COMPONENT-Cr : L4921

Input

Check signal detection.

NG

HDMI B'D

V_L4903 : H(+3.3V) S_L4904 : H(+3.3V)

COMPONENT_L4902

OK

: H(+3.3V)

NG

Input CVBS : to A Input S : to B Input COPONENT : to D

OK

COMPONENT OUT : NG

Check output signal from VIDEO DECODER(U2001). HDMI B'D

COMPONENT-Y : L4919 COMPONENT-Cb : L4918 COMPONENT-Cr : L4917

OK

Extend HDMI B'D using a jig.

Check output of selector (U2003).

COMPONENT-Y : JV94 COMPONENT-Cb : JV169 COMPONENT-Cr : JV107

Check FRONT CONNECTOR B'D aw, and connection of FRONT CONNECTOR B'D or HDMI B'D and VIDEO B'D.

HDMI OUT : NG

NG

HDMI B'D aw

Check input of selector (U2003).

NG

COMPONENT-Y : JV25 COMPONENT-Cb : JV184 COMPONENT-Cr : JV185

OK

To troubleshooting 3.HDMI/DVI.

Check FRONT CONNECTOR B'D

NG

aw, and connection of FRONT CONNECTOR B'D or HDMI B'D and VIDEO B'D.

OK

Check cable between main unit and monitor or check monitor.

Check soldering of U2003.

b

66

Unless specied, VIDEO B'd part.

D

Input

COMPONENT

Check of power supply voltage

V+5V : N2004-4pin V-5V : N2004-1pin

OK

Check on set value of each IC. HDMI B'D L4900 :

Check I2C communication waveforms.

L4901 :

Check I2C communication waveforms.

OK

Extend HDMI B'D using a jig.

Check output of selector (U2003).

COMPONENT-Y : JV1 COMPONENT-Cb : JV128 COMPONENT-Cr : JV31

OK

NG

REGULATOR B'D aw

NG

HDMI B'D aw

Check input of selector (U2003).

NG NG

COMPONENT-Y : JV80 COMPONENT-Cb : JV79 COMPONENT-Cr : JV175

OK

Check power supply voltage of U2003, and surrounding circuitry soldering.

Check cable between main unit and monitor or check monitor.

Check FRONT CONNECTOR B'D aw, and connection of FRONT CONNECTOR B'D or HDMI B'D and VIDEO B'D.

I2C communication waveforms

CH1：CLK

CH1：DATA

Unless specied, VIDEO B'd part.

b

67

3. HDMI/DVI.

3.1. No picture or sound is output

No picture or sound is output.

Check HDMI/DVI cable connection.

(1) Is the HDMI/DVI cable properly connected?

YES

(2) Are you using an HDMI/DVI selector, repeater or a device for

improving picture quality?

YES

(3) Are you using a certied HDMI cable (one with the HDMI stamp)?

YES

(3) Are you using an HDMI/DVI cable less than 5 meters in length?

YES

(4) Are the picture and sound output when another HDMI/DVI cable

is used?

NO

There may be a problem with the HDMI/DVI cable. Check connection.

YES

Disconnect everything and connect only the HDMI/DVI cable to check

NO

Use a certied HDMI cable (one with the HDMI stamp).

Replace the HDMI/DVI cable with one that

NO

is less than 5 meters in length (2 meters recommended) to check.

YES

The HDMI/DVI cable is defective.

Check BD/DVD player.

YES

(5) Is the BD/DVD player's HDMI output setting correct?

YES

(6) When using a DENON BD/DVD player's, is the uorescent

display tube's "HDMI" indicator lit? If using a non-DENON BD/ DVD player's, proceed to

NO

(8) Is sound output from the set's speaker terminals when the TV's

power is turned off or the connection cable between the TV and the set is disconnected?

"YES".

YES

(7)

Are the picture and sound output when the BD/DVD player's resolution is changed?

NO

(9) Are the picture and sound

output when a different BD/ DVD player's is used?

NO

YES

Check HDMI output setting, referring to the BD/DVD player's operating instructions.

YES

Set the BD/DVD player's output resolution to a resolution with which the TV is compatible.

YES

The BD/DVD player's may not be compatible with HDCP repeaters. Ask the BD/DVD player's manufacturer.

YES

The BD/DVD player's is defective.

68

Check TV

(10) Is the TV HDCP-compatible?

YES

(11) Is the TV compatible with resolutions of 1080P?

YES

(12) Is the TV's input set to HDMI?

YES

(13) Are the picture and sound output when a different TV is used?

Check set (AVR-3311)

NO

Use an HDCP-compatible TV. PC TVs cannot be used.

If the TV is not compatible with resolutions

NO

of 1080P, no picture will be output, even if the BD/DVD player's resolution is set to 1080P.

NO

Check TV's input setting, referring to the TV's operating instructions.

NO

The TV is defective.

(14) Is the set's input set to HDMI?

Is the output setting of set corresponding to the connection of

YESYES

The set does not recognize the TV. (MONITOR OUT: Set MONITOR1)

(15) Is the "H"(3V-5V) signal outputted of

U1801 (30pin)? With the TV connected,check the voltage of the IC on the side on which the TV is connected. Is communication waveform conrmed in 15pin(DDC_CLK), 16pin(DDC_ DATA)? Is 1pin/3pin/4pin/6pin/7pin/9pin/10pi n/12pin of HDMI connector (N1801) terminated by the TMDS signal of

3.3V and is the signal output?

HDMI connector(N1801)

To page 44

The set does not recognize the TV. (MONITOR OUT: Set MONITOR2)

(36) Is the "H"(3V-5V) signal outputted of

NO

The pattern and circuit from the HDMI connector (N1801) to the IC (U1802/U1803) is defective. Or HDMI output circuit is defective. (U1802/U1803 and surrounding circuitry)

NO

Check set's input setting, referring to the

TV?

U1801 (30pin)? With the TV connected,check the voltage of the IC on the side on which the TV is connected. Is communication waveform conrmed in 15pin(DDC_CLK), 16pin(DDC_ DATA)? Is 1pin/3pin/4pin/6pin/7pin/9pin/10pi n/12pin of HDMI connector (N1801) terminated by the TMDS signal of

3.3V and is the signal output?

HDMI connector(N1801)

YES

set's operating instructions.

The pattern and circuit from the HDMI connector (N1800/N1801) to the IC (U1801/U1802/U1803) is defective.

NO

Or HDMI output circuit is defective. (U1801/U1802/U1803 and surrounding circuitry)

To item (33).

69

YES

The BD/DVD player does not recognize the connection with the set.

(17)

Is the "H"(3V-5V) signal outputted of HDMI connector (K1100/K1101/K1102/K1001/K1002/

(16)

When using a DENON BD/DVD player, is the FL display's "HDMI" indicator lit? If using a non-DENON BD/ DVD player, proceed to "NO".

YES

(18) VIDEO CONVERT : Is the picture output by off setting?

(After item (23) : To be "VIDEO CONVERT:OFF" setting.)

The HDMI input circuitry is defective. (U1002 or U1100, and surrounding circuitry)

K1003 : 19pin)? With the BD/DVD player connected, Check

NO

voltage of the HDMI connector for the input on the side on which the BD/DVD player is connected. Is communication waveform conrmed in connector (K1100/K1101/K1102/K1001/K1002/ K1003)15pin(DDC_CLK)/16pin(DDC_DATA) Is 1pin/3pin/4pin/6pin/7pin/9pin/10pin/12pin of HDMI connector (K1100/K1101/K1102/K1001/ K1002/K1003) terminated by the TMDS signal of

3.3V and is the signal output?

YES

NO

The pattern and circuit from the HDMI connector (K1100/K1101/K1102/ K1001/K1002/K1003) to

HDMI

?

U2200 (ABT2015) and surrounding circuitry

NO

is defective. VIDEO CONVERT : ON To item (19).

the U1100 is defective.

To page 45

(19) Check power supply.

Is 3.3V supplied to L2200/C2230? Is 1.8V supplied to C2242? Is 1.0V supplied to both ends of R2276?

YES

(20) Check RESET.

Is RESET waveform conrmed in through hole (RESET N)? (If continued to "H" or " L", proceed to "NO".)

YES

(21) Check input signal.

Is waveform conrmed in R1642(INPUTDE/INPUTVSN/ INPUTHSN/INPUTVCLK). (If not continued to " L", proceed to "YES".)

YES

(22) Check output signal.

Is waveform conrmed in R2200(VOUTCLK0/VOUTHS/VOUTVS/ VOUTDE). (If not continued to " L", proceed to "YES".)

YES

NO

The power supply circuitry is defective.

NO

The RESET circuitry (U2201 and surrounding circuitry ) or U2200 is defective.

NO

The U1601 is defective.

NO

The U2200 is defective.

To item (32). (Keep "VIDEO CONVERT : ON" setting.)

70

Check operation of each device.

(AMP source : DVR [i/p:OFF, MONITOR OUT: MONITOR1] / Video input of player : 480P / Connect the TV.)

Check operation of U1002 (ADV3002).

(23) Check power supply.

Are 5V or 3.3V supplied to U1002 (each power supply pin)?

YES

(24) Check RESET.

Is RESET waveform conrmed in U1002 (36pin), when power is turned on? (If continued to "H" or " L", proceed to "NO".)

YES

(25) Check output signal.

Is TMDS waveform conrmed in 25pin/26pin/28pin/29pin/31pin/32 pin/34pin/35pin. Is waveform conrmed in 67pin/68pin to DDC_SCL/DDC_SDA. (If not continued to " L", proceed to "YES".)

YES

Check operation of U1100 (ADV7840).

(26) Check power supply.

Is 1.8V supplied to C1118/C1154/C1125/L1102? Is 3.3V supplied to C11181/C1208/C1201?

YES

NO

The power supply circuitry is defective.

NO

The RESET circuitry (Q1009 and surrounding circuitry) or U1002 is defective.

NO

The U1002 is defective.

NO

The power supply circuitry is defective.

(27) Check Xtal oscillator.

Is oscillation of X1101/X1103(28.6363MHz) transmitted?

YES

(28) Check RESET.

Is RESET waveform conrmed in U5500 (53pin), when power is turned on? (If continued to "H" or " L", proceed to "NO".)

YES

(29) Check output signal.

Is waveform conrmed in R1148(HRDE/HRVSYNC/HRHSYNC/ HRPCK). (If not continued to " L", proceed to "YES".)

YES

NO

The X1101/X1103 or U1100 is defective.

NO

The RESET circuitry or U1100 is defective.

NO

The U1100 is defective.

71

Check operation of U1601.

(30) Check power supply.

Is 1.2V supplied to C1632? Is 3.3V supplied to C1656?

YES

(31) Check RESET.

Is RESET waveform conrmed in N1601 (1pin), when power is turned on? (If continued to "H" or " L", proceed to "NO".)

YES

(32) Check output signal.

Is waveform conrmed in R1643(1TXDE/1TXVSYNC/1TXHSYNC/ 1TXPCK). (If not continued to " L", proceed to "YES".)

YES

Check operation of U1801.

(33) Check power supply.

Are 1.8V or 3.3V supplied to U1801 (each power supply pin)?

YES

(34) Check RESET.

Is RESET waveform conrmed in U1801 (38pin), when power is turned on? (If continued to "H" or " L", proceed to "NO".)

YES

(35) Check output signal.

Is TMDS waveform conrmed in 32pin/33pin/35pin/36pin/39pin/40 pin/42pin/43pin (U1801) ? "NO".) Is waveform conrmed in 53pin/54pin (U1801) to DDC_SCL/DDC_ SDA. (If continued to "H" or " L", proceed to "NO".)

(If continued to "H" or " L", proceed to

YES

NO

The power supply circuitry is defective.

NO

The RESET circuitry (Q1600 and surrounding circuitry) or U1601 is defective.

NO

The U1601 is defective.

NO

The power supply circuitry is defective.

NO

The RESET circuitry (Q1801 and surrounding circuitry) or U1801 is defective.

NO

The U1801 is defective.

The pattern and circuit from the HDMI connector (N1800/N1801) to the IC(U1802/U1803) is defective, or HDMI output circuitry is defective (U1802/U1803 and surrounding circuitry).

72

2.2. HDMI test point and waveforms

U4601

R4448

R4640

L4400

L4624

U1607

R5517

N4916

C9095

R3813

R3815

C3846

C9076

L4928 R3816

L4930

L4929

R3817

L4932

L4931

L4933

L4934

C9072

R3872

R3887

R3818

C3867

R3873

R3819

R3812

C3845

R3814

B9000

C3843

C3842

P

U3802

C4920

C3815

C3878

C3833

C3814

C3839

N4908

R3926

C4910

R3810

C9068

L5033

L5018

L5019

C9021

A

L5022

C9009

C9012

Q5109

Q5107

C9058

C9006

C9018

R5123

Q5106

N4907

C5116

R5118

R5318

E

R5317

Q5108

C4923

R5322

R5310

L5013 C4904

L5012

36

R5383

L5011

R5382

L5010

37

L5009 L5008

L5035

C4913

L5034

C4916

C4912

L5007

L5006

L5005

K

C4918

L5032

C4908

C4921

R5370 R5369

C4922

72

Q5100

C4925

C4927

73

4

M

D5305

R5363

R5105

R5137

R5101

1

N5100

TOP

C5101

C5100

R5100

4

R5327

U5300

R5385 R5384

1

TOP

N5300

D5311

H

R5400

11

OUTVCC

G

Z5300

Q5309

C8007

Q5308

N5301

C5300

D5302

D5306

C5301

D5303

C5308

C5309

C5307

C8003

D5307

D5308

D5310

R5321

C5306 D5304

D5309

K5300

C5303 C5302

C3832

R3870

C3866

R3871

N4904

N4906

R3844

L4939

L4940

L4941

L4942

L4935

L4936

C9090

U3804

R3820

R3854

L4938

R3845

U3805

C9080

R3855

C3850

L4937

D

C

C9083

C3849

C9087

R3826

C3861

R3839

R3849

C3874

C3875

C3841

C3844

R3811

C3823

N4905

C3827

C9061

C3818

C9001

R3861

R3827

C9024

R3821

C3858

R3846

R3836

R3860

C3853

C3837

C

C9015

2

1

C4694

C4917

Q5315

Q4648

C4919

L5024

L5025

C4907

C9027

L4981

C4905

L4982

L4983

X5301

R5313

A

R5314

R5361

R5365

R5337

L5020

R4900 R4901

L5021

R5336

R4902

L5023

R4903

N

R5350

R5345

1

144

C5310 R5335

R5326

R5334

C5305

H

U5301

R5339

R4215

R4216

C8008

109

U4202

108

R5338

R4217

R5349

R5358

R5359

C4212

R5389

R5347

R5341

R5343

Q5102

U4201

C4207

R5107

R5390

R5391

R5386

C5102

R5387

C5103

R5104

R5108

R5388

L4200

N3900

Q5101

1

7

1

TOPTOP

TOP1TOP

R3900

Q5306

R5316

C8009 R5301

D4200

D4201

D5300

R5300

D5301

R5302

R5315

R5324

Q5307

C8002

K5301

K5302

C9093

R3886

R3858

C8531 C3836

D

L4984

R5115

C4208

C9094

C9064

C8532

L4961

C4901

L4927

L4963

L4969

L4971

L4964

L4965

L4966 R3806

L4970

L4967

C3810

R3807

L4968

C3811

R3874

C3868

R3875

R3888

R3800

C3806

R3824

C3807

C3852 R3859

R3825

R3838

R3848

C3860

C3802

C3804

U3800

L4980

C8558

C3800

L4979

L4986

L5037

L4977

L4978

L4955

L4956

L4957

R3876

R3877

R3889

C3869

L4989

L5036

N4909

L4990

L4996

L4997

L4998

L4999

L5000

L5001

L4995

L4988

L4985

L4987

C5112

C8547

U5108

R5138

U4607

R5114

C8014

C5312

C5314

R5332

R5340 R5325 C5304

C8546

C4718

C8559

L4204

L4207 C4215

C4216

C4210

C4211 R4218

R4224 C3950 C3951

U3902

R4223

C3904

C3952

C3953

N3901

L4201

C3954

D4202

D4203

N4200

N4903

C9077

L4958

L4960

L4962

F

C9003

C4900

L4959

L4402

C9081

U5104

C3834 R4436 C4463

R4433

C8551

U5107

U5106

C5108

R3805

C3824

C8533

C5107

C3825

U4404

U5102

C3805

C4455

C5104

R5135 R5136

F

TOP

R3802

R5112 R5111

1

L4948

L4950

L4951

L4943

L4944

L4945

L4946

L4947

L4949

L4952

L4953

L4954

C8557

R5106

L5038

U5105

40

C4689

U4606

R5366

R5110

39

C4717 L5017 L5016

L5004

C8556

L5015

C8555

L5014 L5030

R4646

E

L5003

L5002

C8545

C4728

C4404

R4651

C8544

R4435

C4405

Q4630

C4422

R4406

R4412

R4414

R4415

R4416

R4419

C8540

U4400

R4420

R4428

R4429

R4427

R4423

C3955

R3930

R4401

R4426

C4454

R3929

R4400

C4401

R3953

R3933

U3900 R3945 C3956 R3946 C3957 R3947

R3948

R3951

R3932

C3959

R3952

R3949 R3950

C8010

C3958

R3902

J

R3912

R3904

Q3901

R3903

C2802

G

VCC

K2800

N4610

N4913N4914

N4600

C8541

L4628

C4791

C8536

L4605

C8535

L4604

R4600

C4600

C5110

C8538

C4622

C4625

C8537

C4628

C4633

L4620

L4619

C4640

R4631

R4621

C4651

U4603

R4622

C8542

G

C5501

R5503

C5500

11

N5500

C5502

R5508

X5501

C5503

C4727

R5514

R5515

Q4635

R4407

R5521

R5522

R5520

R5525

U5502

1

R4409

C4420

TOP

U4403

R5526

R4413

8

N4400 C4435 C4439

S

C4441 C4442

N4401

R4425

R4422

C4224

R4421

C4453

X4401

R4226 R4227 R3924

R3923

C4222

R3913

U4203

C4225

X3900

Q Q

C9055

C8011

L4211

R

C3929

C4716

R3917

C4722

R4241

Q3900

C2800

R3918

R3901

C4247

R2813

C2808

R2812

G

IN

VCC

OUT

U2801

U2800

N4911

L4607

C4799

L4910

L4911

L4912

L4601

L4606

L4600

C4603

R4603

C4626

C8013

C8539

C4631

L4622

C4641

L4616

C4636

U4604

L4615

C4638

R4634

U4601

R4628

C4654

R4627

C8553

R5502

U5500

R5501

C4699

R5552

R5553

R5555

R5554

R5530

R5500

R5506

S3200

R5507

R5510

C3200 R5511 R5512

R3205

R3270 R3271

R4602

C4602

C8534

208

C4630

1

C4635

R3221

C5111

R4633

G

R3223

R3275

R5518

R5517

C4653

R4625 R4626

R3274

R3224

C5512

R5381 R5380

R5397

L4400

L4401

R5396

K

R3226

R5379

R3269

R5378

R3227

R5377

C4470

R3229

R5374

R4448

R4449

C5317 R5372

R3231

C4469

R3268

R3273

L4405

R3232

52

R3272

C3240

C3253

R4234

C4465

C4738

C3260

C4743

C9020

Q4403

C4242

C4243 R4238

R3910

R3911

R3916

C4244

R4239

C3900

C3245

C4245 R4240

C4231

R2811

R2810

C2807

C9073

C4230

C3907

Q4202

Q4200

R1110

C4446

R4204

D1100 R1119

C4201

D1106 R1116

U4200

R1113

R1129

D1127

D1115

D1118

Q1100

N4201

Q1103

C2801

D1121

D1124

C4246

D1112

D1109

U2802

VCC

G

Z1

Z3

R4632

R4629

R4630 R4635

C4655

633010051009S

1

MP1

8U-310051-1

N4912

N4910

N4901

C4618

L4610

L4611

C4624

U4600

L4621

R4619

C4610

R4605

C4648

R4616

R4617

L4612

C3211

R3216

R3217

R3215

R3210

C3207

C3246

R3206

R3218

R3241

R3240

R3239

C4748

R3238

R3261 R3262 R3263

R3248

R3252

R3249

C3265

C3266

R3264

C9042

D1103

D2800 C2803

C2805

R2800

R2802

J

R1130

R1114

D1130

D1110

Q1104

Q1101

R1111

K1100

D1101 D1104

R1120

D1107

R1117

N4902

N4900

C9028

C9078

L4926

L4923

L4924

L4925

L4905

L4906

L4907

L4908

L4909

C9074

R4643

Q4628

C4649

C4650

C4683

R3823 C3851

C9048

P

R3214

R3212

R3213

R3201

N3200

TOP

1

U3200

X3201

R3237

R3236

R3235

C4251 L4209

C3902

R3914

( )

L4212 L4210 C4250

R3920

C3901

R

C2804

C4726

D2801

R2801

R2803

D1128

D1119

D1116

D1113

D1125

D1122

L4916

L4920

L4921

L4922

C9025

L4915

L4913

L4914

R2018

C2016

C2013

L4917

R2013

C2018

C2011

C2015

L4918

L4904

L4900

L4901

L4902

L4903

L4919

R2011

R2012

C2020

C2012

R2006

R2017

R2008

R2009

R2016

C4675

C4781

C4787

R3857 R3856

C4746

C9062

R3822

R3837

R3847

C3859

R3203

10

C3218

C3201

C3220 C3221

157

156

C3223

C3226 C3227

R3225

R3219

R3220 R3209

R3242 R3244 R3245

R3246

105

C3254

104

C9017

1

R3247

R3233

R3234

R3265

C3014

7

C4249 R4242 R4243 C4248

C4733

C2806

R1131

R1115

D1131

Q1105

Q1102

R1112

K1101

D1102 D1105

R1121

D1108

R1118

R2003

R2007

R2002

U2001

C2243

R2014 R2015

C2007

C4691

Q2001

C2006

C2005

R2843

C4765

C4741

C4767

C2823

C2849

C2848

C2818

C2839

9

C4701

R2503

C4707

R2842

C4760

C2821

C4731

C4736

C2847

C2846

S

R3012

N3000

TOP1TOP

M L5031 L5029 L5028

D1111

TOP

N2200

C2817

C2837

N

C5322

C5321

R5353

R5362

R5364

R5113

R5356

C2819

C2834

L4403

R4445

C4467

( )

L4406

C2816

C2827

C2845

L4404 C4468

R4444

C4466

C4720

C2833

C2844

C2835

R3004

R3001

R3002

R3000

R3005

U3000

R3003

C3003

R3006

R3009

R3013

R3011

R3026

R3021

C4780

C4712

C4786

C4706

C1125

SRCfs

L1100

C1176

SRCDATA

SRC64fs

C1108

C1175

C1109

C4906

C1152

C1155

R1162

C1103

C1127

R1164

C4903

C1100

C1163

C1162

C1101

C4902

Q1004

Q1005

D1120

D1129

D1117

D1132

D1114

D1123

D1126

R1004

Q1001

K1102

R1001

DDCDATA

DDCCLK

C2526

C2524

C2525

R2512

C2244

C9031

R

U2002

C2017

U2501

R2286

R2281

R2282

R2287

R

R2283

R2285

U2500

R2284

C2213

C2219

C2217

C2215

A

1

C2221

C2223

C2225

C2227

5

R2229

L2201

C2257

C2259

R2228

1

C2258

R2276

20

L2200

C2266

C1115

C1116

C1201

C1205

R1127

R1132

C1228

C1236

C4758

C4763

C1232

C1220

C1225

C2203

C4764

C4724

C1212 C1208

R1180

C3005

C2202

R1177

C4759

R1133

R1134

X1103

IPSDA

R1172

R1159

C4751

R1158

R1105

R1101

R1123

C1111

X1102

R1165

C1112

L1102

C1148

C1151

C1154

C1118

C1119

R1126

C1114 R1167 R1168

C1102

C1110

R1122

C1836

R1862

R1104

C1106 C1107

R1855

R1102

R1860

D1802

C1104

R1861

R1103

D1804

C1105

R1868

C1835

D1806

C1834

K1002

K1001

R1005

Q1002

R1002

DDCDATA

DDCCLK

R4624

R4623

C4634

C4637

C4632 C4604

R4604

U4605

L4608

L4609

C4642

C4627

C4671 L4624 L4623

R2230

C4662

Q4624

C4667

C4679

C4729

A

C2537

C4682

19

C4749 C4744

C4623

C4639

R2505

C4708

R1683

L4617

L4618

C1667

C4702

R2504

U1606

R1678

R2227

R1671

C2255

R2245

R2226

R2275

C2256 C2254

C2242

R2251

Y

R1618

C2229

C4735

C2228

R2269 R2268 R2244 R2243 R2266 R2267

VOUTDE VOUTHS VOUTVS

R1631 R1633 R1635

C2230

A

U2200

1

INPUTHSN

R1627

INPUTDE

R1629

INPUTHSN

R2262

R2201

R2258

R2260

R2261

R2263

R2257

C4723

C2276

C4719

TOP

HRDE

10

HRHSYNC

1

R1148

C2201

N2201

R1149 R1150

R1160

R1151

R1152

R1153

R1154

R1155

R1156

R1157

U1100

C1181

R1017

R1018

R1019

C1012

C1006

C1008

C9016

K1003

R1006

Q1003

R1003

DDCDATA DDCCLK

C1659

C4629

C4601 R4601

C4652

R4644

L4603

L4602

U4602

R4639

Q4627 C1665

R1670

C4730

HRVSYNC

HSCL

C1658

U1607

R4640 C4672

Q4629

R4645

Q4626

C4681

C4715

C4680

Q4625

C4703

C4684

C4709

R4642

C4673

C4674

R1673

R1682

R4641

C9004

C1669

R1674

R1684

C4732

C1666

R1681

S1600

R1672

R1668

C1656

717

1

U1605

U1604

R1676

U1603

R1677

TOP

R1664

R1680

R1679

R1613

R1612

R1622

DONE

C1604

R1621

R1615 R1614 R1610

R1611

18

R1640

R1642

C1606

R1617

R1619

HSDA

23

R1845

R1844

R1021

R1020

D1001

TOP

C1654

R1669

C1657

C9007

N1601

N1600

R1600

R1620

R1662

V

R1657

R1659

U1601

A 1

C1605

R1643

R1639

R1616

R1637

R1638

C1001

1

TOP

N1001

C1806

C1807

C1808 C1815

C4750

C4754

C1017

R1811

C1016

U1002

Q1803

R1813

C9013

R1814

D1800

R1839

R1841

R1854

D1801

R1838

R1840

D1803

R1864

R1865

U1804

D1805

R1843

R1842

D1810

D1820

D1814

D1808

D1812

D1822

D1816

D1818

C9057

N1801

C1613

R1605

R1607

R1609

C1614

C1632

C1634

C1651

R1658

C1612

C1611

R1660

C1610

R1656

R1655

C1609

R1654

R1653

C1608

U1602

R1641

C1607

R1636

R1625

R1630

R1626

R1623

R1628

R1632

R1634

C1803

C1804

C1002

C1805

C1801

U1801

R1803

R1804

R1805

R1810

R1832

R1869 C1819

R1833

R1824

C1820

R1870

R1826

R1828

R1829

R1830

R1831

R1827

R1834

C1825

C1824

C1827

R1835

R1836

U1803

C1829

C1832

C1833

C1830

C1837

C1838

R1837

D1821

D1811

D1813

D1819

D1807

D1809

D1817

D1815

C9054

R1866

R1867

N1800

Z2

C2801

R5501

L4401

C4242

L4615

C4638

C8553

G

R5397 K

C4469

C4243

R4238

C4244

C4245

R4240

C4231

C3907

U4200

N4201

U2802

G

C4799

L4616

U5500

C5111

C4446

Q1103

L4601 L4600

R5500 R5506

R5507

R5510 R5511 R5512

C4635

C4470

R4239

L4912

C8539

C8534

C4630

R5396 R5379 R5378 R5377 R5374 C5317 R5372

L4405

L4911

C8013

R4625 R4626

R5381

R5380

R4234

C4465

Q4403

Q4202

R1129

Z1

L4910

C4631

C4602

R4633

C4653

R4628

R4602

C4230

C4603

R4627

C4699

C3253

R4204

C4654

C3245

Q4200

R1113

Q1100

D1109

R4603

R4634

R3275

R3274

R3269

R3268

R3272

C3260

C4636

R5552

C3200

R3227 R3229

R3273

C4738

U4604

R5553

R3221 R3223

R3232

C4743

D1112

S3200

R3231

C4201

L4607

R5554

R3270

R3271

R3224

C3240

C3900

D1115

C4626

C4641

R5530

R3226

R3916

R2811

R1110 D1100 R1119

D1106 R1116

D1118

D1121

33

L4622

R5555

52

C9020

R3910

R2810

C2807

D1127

1

R3911

L4606

208

32

R3205

J

D1124

L4621

R3264

D1103

D2800 C2803

D1130

L4611

R4605

C4648

R3241 R3261 R3262 R3263

C9042

N4901

C4610

R4617

Q1104

K1100

R1120 R1117

R4619

R4616

C3207

R3218

R3240

L4612

R3210

R3248 R3249 C3266

R2800

R1130

L4610

C3211

C3246

C4748

C2805

R2802

R1111 D1101 D1104 D1107

C4618

R3217

R3239

C4624

R3216

R3206

R3238

R1114

Q1101

U4600

R3215

R3252 C3265

D1110

C9074

R3214

C4726

D1116

L4926

R3213

1

D1113

C9048

TOP

R3212

Q

L4925

C4650

U3200

C2804 D2801

D1119

L4909

C4649

X3201

D1122

R3237

R3914

R3920

L4924

L4908

C3902

C3901

L4907

R3201

R3236

( )

R

L4923

L4906

R4643

P

N3200

R3235

C4251 L4209 L4212 L4210

C4250

R2803

D1128

D1125

L4905

Q4628

C4683

R3823 C3851

R3265

C2806

R2801

L4922

L4904

R3234

L4903

C4787

R3822

D1131

L4902

R3857 R3856

R3837

R3203

10

104

R3233

C4249 R4242 R4243

C4248

L4921

R3847

157

C9017

R3247

C3014

Q1105

K1101

R1121 R1118

L4901

C4675

C4781

C3859

C3201

156

C4733

L4920

L4900

C3218 C3220 C3221 C3223

R3219

105

R1131

C3254

R1112 D1102 D1105 D1108

C9062

C3226 C3227

R3225

R3244

R3245

R3246

N4900

C9078

R2011

R2017 R2016

R3220 R3209

R3242

1

7

R1115

C9025

L4919

C4746

R3012

M L5031 L5029 L5028

Q1102

N4902

R2012

C2839

C2846

S

D1111

L4918

R2006

C4741

C2849

C2847

N3000

TOP1TOP

R2009

U2001

C2823

C2818

C2837

R3002

C4467

C4466

R3003

R3009

C4906 C4903 C4902

D1117

D1114

C4767

L4403

R4445 ( )

L4406 L4404

R4444

R3006

R3013

C2007

C2821

C4468

R2843

R2842

D1120

D1123

L4917

C2005

C2848

C2817

R3026

SRCDATA

SRC64fs

R2013

C2006

C2013

C2012

C2827

SRCfs

D1129

D1126

L4916

C2816

C2844

C2835

C1125

L1100

C1127

R1164 C1162

R2018

C4731

R3021

C1155

C4691

C4701

C4707

C4736

N

C2819

C1152

D1132

L4915

C2834

C4765

C4760

R5364

R3000

C1175

R1162 C1163

K1102

16

DDCDATA

C2016

R2007

Q2001

R5113

R5362

C2845

C1176

Q1001

R1001

30

DDCCLK

L4914

C2020 R2008

R5356

C2833

R3011

C4712

C4706

Q1004

L4913

C5322

R3001

31

C9028

9

R5353

R1004

29

C2011

R2003 R2002

C2243

R2503

R3004

U3000

C4780

C2015

R2014 R2015

N2200

C5321

C4720

12

C4786

C1108 C1109 C1103 C1100

Q1005

C2018

C3003

C1101

TOP

R3005

C2017

1

13

C4724

C1212 C1208

C3005

R

U2500

A

5

1

C1225

R1134

R1180

R1167 R1168

C2258

C2266

C1220

R1133

R1105

K1001

R2276

9

C4764 C4759

14

C1148

C2244

U2002

R2281

R2282 R2283

R2285

R2284

C2217

C2213

C2219

C2215

C2221

C2223

C2225

C2227

R2229

L2201

C2257

C2259

R2228

8

7

L2200

C1201

C1232

C1228

C1236

C4758

C4763

R1177

11

C4751

R1101

R1123

C1111

X1102

13

15

R1165

C1112

L1102

C1151

C1154

C1118

C1119

C1114

C1102

C1110

R1104

C1106 C1107

R1102

C1104

R1103

C1105

R1005 R1006

Q1002

R1002

DDCDATA

DDCCLK

C1205

10

R1126

R1122

R2512

R

20

R2287

C1115 R1127

C2203

X1103

R1862

R1860 R1861

R1868

C1835 C1834

C2526

U2501

C1116 R1132

R2286

C2202

R1172

R1158

C1836 R1855

D1802 D1804 D1806

C2525

K1002

12

R1159

C2524

C9031

11

IPSDA

C2276

R1160

A

TOP

1

19

R2505

R2504

C2242

U1100

28

L4623

R2230

R2201

N2201

27

26

C1008

C2537

L4618

C2255

R2226

C2256 C2254

R2260

C1012

C4749 C4744

C4639

L4617

R2261

R2258

25

24

C1006

DDCDATA DDCCLK

3

R2257

C4729

R2262

23

22

6

C1181

R1003

C4623

R2263

C4667

R2227

U2200

INPUTHSN

INPUTDE

10

21

Q1003

C4662

R1683 C1667

U1606

R2245

R2251

1 2 3

A 1

INPUTHSN

C4723

8 9

10

C2201

R1156

R1157

C4702

Y

C2229 C2228

R1148 R1149 R1150

R1151

R1152

R1153

R1154

R1155

Q4624

C4682

R1678 R1671

R2269 R2268 R2244 R2243 R2266 R2267

C4719

R1017

C4679

C4708

R2275

VOUTDE VOUTHS

VOUTVS

4

C2230

R1627 R1629

HRDE

HRHSYNC

R1018

R1019

C9016

K1003

R1631 R1633

R1635

Q4627

C1665

R1670

R1618 C4735

C4730

7

HRVSYNC

HSCL

R1615 R1614 R1610

U1604

6

HSDA

Q4625

D1001

R1679

R1622

R1020

C4672

R4642 C4674

R1680

R1621

R1611

R1640

R1642

23

R1021

R1612

C1606

U1605

DONE

C1604

R1617

R1845

R1664

R1619

R1844

Q4629

C4680

R1673

C1666

R1669

R1613

18

R1616

R1682

R1674

R1637

R1684

R1620

R1638

C4684

R1677

R1662

R1639

R1843

C1669

U1603

R1842

D1808

N1801

R4645

R1676

C1657

C1001

18 19 20

R1681

N1001

U1002

R1841

5

C9013

R1840

Q4626

C9004

2

C1016

17

D1812

C9057

C4732

R1672

C1656

5

R1839

D1810

C4715

C4703 C4709 C4673 R4641

C1654

C4754

R1838

16

C4681

R1668

C9007

R1600

C4750

D1814

D1816

1

C1017

D1800

TOP

C1605

C1806 C1807

R1811

Q1803

R1813

15

D1818

S1600

N1600

R1814

D1820

1

34

TOP

C1808

C1815

U1804

V

R1657

R1659

U1601

A

R1864

R1865

D1822

R1643

1

R1854 D1801 D1803 D1805

14

1

C1002

C1824

7

R1626

R1867

R1834

Z2

1

TOP

C1632

R1625

R1870

C1838

R1658

R1660

R1655

R1654

R1653

C1829

R1607

C1651

C1634

R1656

R1623

C1804 C1805

35

R1810

36 384042

R1833

R1824

C1837

R1837

R1866

R1609

R1632

37 39 41

R1832

R1831

D1807

C9054

N1800

U1602

R1830

C1825

7

N1601

R1630

R1829

D1809

R1605

R1828

D1811

C1832C1833

R1628

R1827

R1826

R1641

C1803

D1813

D1815

R1636

C1801

C1820

43

C1827

U1803

R1869

C1819

C1830

D1819

C1614

U1801

R1805

44

D1817

R1803

R1835

C1613

C1612

C1611

C1610

C1609

C1608

C1607

R1634

R1804

R1836

D1821

73

Check the voltage (Red)

No.

1 1.2V 2 3.3V 3 1.8V 4 3.3V 5 +5V 6 3.3V 7 3.3V 8 1.0V

9 1.0V 10 3.3V 11 1.8V 12 3.3V 13 1.8V 14 1.8V 15 1.8V 16 +5V

Check the wave form (Blue)

No. No.

1 VOUTDE 23 RXD_1+

2 VOUTHS 24 RXD_1-

3 VOUTVS 25 RXD_0+

4 VOUTCLK0 26 RXD_0-

5 HRPCK 27 RXD_C+

6 INPUTVCLK 28 RXD_C-

7 INPUTHSN 29 DDC CLK

8 HRDE 30 DDC DATA

9 HRVSYNC 31 HPD 10 HRHSYNC 32 I2C CLK 11 INPUTDE 33 I2C DATA

12 INPUTVSN 34

13 RESETN. 35 TXC14 D2+/D2- 36 TXC+ 15 D1+/D1- 37 TX016 D0+/D0- 38 TX0+ 17 CK+/CK- 39 TX118 HPD 40 TX1+ 19 DDC_SDA 41 TX220 DDC_SCL 42 TX2+ 21 RXD_2+ 43 DDCSCL 22 RXD_2- 44 DDCSDA

1TXHSYNC/1TXVSYNC

1TXPCK/1TXDE/

74

DDC_CLK/DDC_DATA/TMDS : Check item (15),(17),(25),(35),(36)

0.9V

DDC_CLK

2.48V

DDC_DATA

INPUTDE/INPUTVSN/INPUTHSN/INPUTVCLK : Check item (21)

INPUTDE

INPUTHSN

INPUTVSN

INPUTVCLK

37.0ns

16.68ms

INPUTDE

INPUTHSN

INPUTVSN

31.76us

31.84us

75

VOUTDE/VOUTVS/VOUTHS/VOUTCLK0 : Check item (22)

VOUTDE

VOUTHS

VOUTVS

VOUTCLK0

16.68ms

37.0ns

VOUTDE

VOUTHS

VOUTVS

31.76us

31.84us

76

HRDE/HRVSYNC/HRHSYNC/HRPCK : Check item (29)

HRDE

HRHSYNC

HRVSYNC

HRPCK

37.0ns

16.68ms

HRDE

HRHSYNC

HRVSYNC

31.76us

31.84us

77

1TXDE/1TXVSYNC/1TXHSYNC/1TXPCK : Check item (32)

1TXDE

1TXHSYNC

1TXVSYNC

1TXPCK

37.0ns

16.68ms

1TXDE

1TXHSYNC

1TXVSYNC

31.76us

31.84us

78

4. AUDIO

4.1. AUDIO CHECK

AUDIO OUTPUT : NG

CHECK1

CHECK2

CHECK3

CHECK4

CHECK5

Check other factors.

INPUT SURROND MODE SOURCE ANALOG 2CH DIRECT ANALOG

OK

INPUT SURROND MODE SOURCE COAX or OPT --- Legacy(PCM or DolbyDigital or dts…)

OK

INPUT SURROND MODE SOURCE ANALOG 2CH 7ch STEREO ANALOG

OK

INPUT SURROND MODE SOURCE HDMI --- Legacy(PCM2ch or DolbyDigital or dts…)

OK

INPUT SURROND MODE SOURCE

HDMI ---

OK (Digital Audio BOLCK is OK)

NG

Check ANALOG AUDIO BLOCK.

NG

Check Digital AUDIO BLOCK.

NG

Check via AD.

NG

Check HDMI BLOCK.

HD AUDIO (PCM MULTI or DolbyTrueHD or dtsHD MA)

NG

CHECK6

Connect Setting SOURCE

HDMI OUT→other AVR HDMI IN CEC STANDBY

OK

Check Digital AUDIO BLOCK.

HD AUDIO (PCM MULTI or DolbyTrueHD or dtsHD MA)

Check HDMI BLOCK.

NG

79

4.2. Power AMP (7CH AMP B'D)

No sound is output. The protector operates.

YES

Is the power transistor open or short circuit?

2SB1647/2SD2560

NO

Is the emitter resistance of the power transistor open?

0.47Ω

NO

Is the base resistance of the power transistor open?

22Ω

NO

Is trimmer potentiometer between the base of the power transistor open?

1kΩ

NO

Is the zener diode and diode which are connected with the base of a power transistor short-circuited?

MTZJ4.7B

1SS133

NO

YES

Replace the power transistor.

YES

Replace the emitter resistance.

YES

Replace the base resistance.

YES

Replace the trimmer potentiometers.

YES

Replace the Zener diode and the diode.

YES

Is other transistor trouble?

NO

YES

Is other resistance trouble?

Turn on power, check that voltage of the section is normal and that idling electric current is owing.

Replace the transistor.

Replace the resistance.

80

4.3. Analog audio

No sound is output

Is the voltage of ±8V supplied to SIDE CNT B'D CP6 9-12 pin?

YES

Is the audio signal transmitted to AUDIO B'D CN3001?

NO

Is the serial data for electronic volume transmitted to FRONT CNT B'D P114 4,5pin?

YES

Once more, checking the connection of the connector. When can specify the trouble of the channel and function, Check signal route where it corresponds.

NO

The power supply of ±8V is repaired.

YES

The power amplier is repaired.

YES

Is the connector correctly connected with HDMI B'D?

NO

Connect the connectors properly.

YES

The HDMI B'D is repaired.

81

5. Network/USB

5.1. Cannot connect to network

Is the LAN cable properly connected?

YES

Are the AVR-3311CI's network settings correct?

YES

Checking the environment

NO

Check the LAN cable properly then turn the power back on.

Checking the settings

Set the IP address and other parameters properly. For a xed IP setting, check

NO

whether the IP address is redundant with that of other devices, and check whether the subnet mask setting is correct.

Are the router, hub and other peripherals properly connected?

YES

Are the router's settings correct?

YES

Checking the set (AVR-3311CI)

Is a voltage (5V) being supplied between N4610 3pin and 4pin?

YES

Is input voltage (3.3V) being supplied of U4601?

YES

Is output voltage (1.2V) being supplied of U4603?

NO

Connect properly to peripherals.

Check the router's operating instructions

NO

and set properly. Check whether there are connection restrictions due to the MAC address, etc.

NO

The circuit from AC inlet to N4610 is defective.

NO

The U4601 and surrounding circuitry or circuitry of 3.3v device is defective.

NO

The U4603 or U3900 and surrounding circuitry is defective.

YES

Is the version of IMG or Ethernet SBL displayed with Version check mode?

YES

The U4202 and surrounding circuitry are defective.

NO

The rmware of ethernet is defective.

82

5.2. USB device is not recognized

Checking the USB device

Are you using a USB hub?

NO

Is the USB device compatible with the set?

YES

Checking the set (AVR-3311CI)

Is the wire of N4201 properly connected?

YES

Is a voltage (5V) being supplied between pins 1 and 4 of Jack602 on the USB circuit board (USB connector)?

YES

The circuitry from U3990 on the HDMI circuit board to Jack602 on the USB circuit board is defective.

YES

You do not use the USB hub.

Only mass storage devices in FAT16 or

NO

FAT32 formats or MTPcompatible devices and iPod (Remove some models) are supported.

NO

Connect the wire properly.

NO

The Q4200 and surrounding circuitry on the HDMI cirucuit board is defective.

83

5.3. No picture or sound is output

Checking the set (AVR-3311CI):(If no picture is output)

Are video signals output from U4203 pin 27 (Y) and pin 24 (C)? You do not use the USB hub.

YES

Check the analog video circuit.

Checking the set (AVR-3311CI):(If no sound is output)

Are S/PDIF signals output to U3000 pin 21?

YES

Check the Digital audio circuit.

NO

U3900 and surrounding circuitry is defective.

84

CLOCK FLOW & WAVE FORM IN DIGITAL BLOCK

Wave form

1

CH1: D-DATA

(2)

(1)

2

CH1: DATA

CH2: fs

CH3: 64fs

3

CH1: DATA

CH2: fs

CH3: 64fs

CH4: 256fs

(3)

85

(

/

LAEVEL DIAGRAM

R2A15220FP

LEVEL DIAGRAM

FRONT ch

ANALOG

ATT

H/POUT

LINE IN

EXT IN

200mV

+20dB

+10dB

　0dB

-10dB

-20dB

-30dB

LINE IN

-12dB

＋

ZONE2

AVR2311

ZONE3

AVR3311 ONLY

TO

3311 ONLY

TO

AD IN=50mV

AK5358B

A/D

0dBFS=1.06Vrms

-10dBFS

-20dBFS

-27dBFS

-30dBFS

-40dBFS

PLD

P

DS

0dBFS=1.77Vrms

-20dBFS=177mVrms

-20dBFS(DIG.IN)

-27dBFS(A/D IN)

SW NO

-32dBFS(DIG.IN)

-39dBFS(A/D IN)

AK4358VQ

-10dBFS

79mVrm

-30dBFS

-40dBFS

+30dB

PK OUT

S

+20dB

+10dB

H/POUT

200mVrms PR

E OUT

-10dB

-20dB

-30dB

SPEAKER

OUT

PRE OUT

RECOUT1

RECOUT2

＋

GAIN

D/A

－

Config2(L/S/S/N)

+5dB

L.P.F GAIN=+5d

+5dB

B

FULL S

C

A

LE LEV

OLBY L

D

E

L

138mVrm

7

34

V

=3

r

IMIT LE

3

mVr

8

0

7mVrm

.

mV

5

ms

m

s

m

r

VEL=2.43Vr

m

h

BFS

(5.1c

d

a

s

GAIN setting of MASTER VOL 00dB. ･SW:YES (DIGITAL) 　　-2dB -3dB -1dB =-6dB ･SW:YES (ANALOG) 　　-2dB -3dB +6dB =+1dB ･SW:NONE (DIGITAL)　　-2dB -3dB +12dB -1dB =+6dB ･SW:NONE (ANALOG) 　　-2dB -3dB +12dB +6dB =+13dB ① ② ③ ④ ⑤ ①:Basic OFFSET of VOL=0dB( indication value) ②:FRONT-ch revision ③:OFFSET of SW NON ④:OFFSET of the AD input ⑤:Revision OFFSET of the DIGITAL input

0Hz)

-3

t 3

-6dB

+1dB

+6dB

+13dB

＋

ADJ.

Headroom:2dB

(AVR3311 ONLY)

MUTE

(AVR3311ONLY)

r

4.34V

s/

m

Ω

8

+

29dB

-

4

2

B

d

3Ω

217mVr

3

ms/

154mVrms

-40dB

86

LEVEL DIAGRAM

CENTER ch

R2A15220FP

EXT IN

200mV

+20dB

+10dB

　0dB

-10dB

-20dB

EXT IN

DD INPUT:-20dBFS CNT 1kHz

ANA INPUT:200mVrms L+R 1kHz (MODE:MULTI CH STEREO)

PLD

DSP

AK4358VQ

D/A

0dBFS=1.77Vrms

-10dBFS

-20dBFS=177mVrms

79mVrms

-30dBFS

-40dBFS

＋

－

MAX

GNA

SI

L.P.F GAIN=+1.6dB

+1.6dB

L LEV

+30dB

SP OUT

+20dB

+10dB

200mVrms

RE OUT

P

-10dB

-20dB

SPEAKER

OUT

PRE OUT

＋

GAIN ADJ.

MUTE

4.2

EL

+

9

2

B

d

m

3

m

21

Vr

mVrms

s

GAIN setting of MASTER VOL 00dB. ･DOLBY DIGITAL IN -2dB -1dB =-3dB ･ANALOG IN 　　 -2dB +6dB =+4dB ① ② ③ ①:Basic OFFSET of VOL=0dB(indication value) ②:OFFSET of the AD input ③:Revision OFFSET of the DIGITAL input

-3dB 50mVr

1

+4dB95

r

V

/

ms

8

s

m

(AVR3311 ONLY)

Ω

-30dB

-40dB

-30dB

-40dB

87

LEVEL DIAGRAM

SUBWOOFER ch

R2A15220FP

EXT IN

200mV

+20dB

+10dB

　0dB

DD INPUT:0dBFS LFE 30Hz

PL

D

DSP

AK4358VQ

D/A

AK4358VQ

0dBFS=1.77Vrms

-10dBFS

-20dBFS=177mVrms

+30dB PRE OUT

+20dB

+10dB PRE OUT

0dB

SPEAKER

OUT

PRE OUT

＋

GAIN

＋

－

S

A

N

L

I

AL LEV

G

E

L

IT

L=2.5

I

LEVE

Y

M

1

.

37m

37mVr

1

c

dB

s (5.

3

rm

V

1

rms

V

s

m

30Hz

h-

F

t

S a

)

+11dB

L

.P

+8dB

F

GAIN=+8d

.

Confi

W ch D

S

g1(S/S/S/

B

MA

C

X

Y

L

)D

B

O

ADJ.

MUTE

4

　3

　2

V

.74

4

74mVr

09

00

(AVR3311 ONLY)

rms

ms

r

mV

mVr

ms

-10dB

-20dB

-30dB

-40dB

DD INPUT:-20dBFS LFE 30Hz

ANA INPUT:200mVrms L+R 30Hz

-30dBFS=56mV

-40dBFS

15.8mVrms

+8dB

88

+18dB

-10dB

s

3

m

mVr

9

-20dB

GAIN setting of MASTER VOL 00dB. ･DOLBY DIGITAL IN -2dB +14dB -1dB =+11dB ･ANALOG IN -2dB +14dB +6dB =+18dB ① ② ③ ④ ①:Basic OFFSET of VOL=0dB(indication value) ②:SW-ch revision ③:OFFSET of the AD input ④:Revision OFFSET of the DIGITAL input

-30dB

-40dB

LEVEL DIAGRAM

SPEAKER

PRE OUT

SURROUND ch

R2A15220FP

EXT IN

+20dB

+10dB

PLD

SP

D

AK4358VQ

D/A

AK4358VQ

0dBFS=1.77Vrms

-10dBFS

＋

－

L.P.F GAIN=+5dB

+5dB

MAX SI

＋

GAIN ADJ.

MUTE

m

4.2Vr

s

E

N

AL

V

G

L

E

B

9d

+

2

/

(AVR3311 ONLY)

8Ω

OUT

+30dB

SP OUT

+20dB

+10dB

200mV

　0dB

-10dB

-20dB

-30dB

-40dB

DD INPUT:-20dBFS SURR 1kHz

ANA INPUT:200mVrms L+R 1kHz (MODE:MULTI CH STEREO)

-20dBFS=177mVrms

125mVrms

-30dBFS=56mVrms

-40dBFS

+5dB

2

18mV

m

98

V +4dB

GAIN setting of MASTER VOL 00dB. ･DOLBY DIGITAL IN -2dB -1dB =-3dB ･ANALOG IN 　　 -2dB +6dB =+4dB ① ② ③ ①:Basic OFFSET of VOL=0dB(indication value) ②:OFFSET of the AD input ③:Revision OFFSET of the DIGITAL input

-3dB

154mV

ms

r

200mVrms

O

E

R

U

P

-10dB

-20dB

-30dB

-40dB

T

89

LEVEL DIAGRAM

SURR.BACK ch

R2A15220FP

200mV

+20dB

+10dB

　0dB

-10dB

EXT IN

DD INPUT:-20dBFS SL+SR 1kHz (SB:MTRX ON, DD EX MODE)

ANA INPUT:200mVrms L+R 1kHz (MODE:MULTI CH STEREO)

PL

D

DSP

AK4358VQ

D/A

AK4358VQ

0dBFS=1.77Vrms +1.6dB

-10dBFS

-20dBFS=177mVrms

-30dBFS=56mVrms +1.6dB

＋

GAIN

＋

－

(AVR2311/3311 ONLY)

from

ZONE2

from

ZONE3

(AVR3311 ONLY)

A

L L

E

V

E

mV

50

1

V

7m

6

0dB

+7dB

L

F GAIN=+1.6dB

.P.

+1.6dB

X SIGNA

M

ADJ.

MUTE

4.2Vrms/8Ω

B

9d

+

2

15

0

ms

mVr

SPEAKER

OUT

(AVR3311 ONLY)

PRE OUT

+30dB

SP OUT

+20dB

+10dB

200mVrms PRE OUT

-10dB

-20dB

-30dB

-40dB

-40dBFS

90

GAIN setting of MASTER VOL 00dB. ･DOLBY DIGITAL IN -2dB +3dB -1dB =0dB ･ANALOG IN 　　 -2dB +3dB +6dB =+7dB ① ② ③ ④ ①:Basic OFFSET of VOL=0dB(indication value) ②:SB-ch revision ③:OFFSET of the AD input ④:Revision OFFSET of the DIGITAL input

-20dB

-30dB

-40dB

/

R2A15220FP

LINE IN

＋

AVR2311/3311, ONLY

AVR3311 ONLY

MAIN

LEVEL DIAGRAM

ZONE2/3

TO

from F-ch

from

DA SB-ch

from

EXT.IN SB-ch

SB-ch FRONT/ZONE ASIGN 0dB

＋

SPEAKER

OUT

ZONE2 NJW1194

MONO

HPF

D/A

MONO

TONE

MUTE

PREOUT

ZONE3 NJW1194

MONO

HPF

D/A

MONO

TONE

MUTE

PREOUT

200mV

+20dB

+10dB

　0dB

-10dB

-20dB

-30dB

-40dB

LINE IN/EXT IN

0dBFS

2.0Vrms

0dBFS

-10dBFS

-20dBFS(DIG.IN)

-20dBFS

-30dBFS

-40dBFS

AK4424ET

MAX SIGNAL LEVEL 2.00Vrms

-2.0dB

+30dB

SP OUT

8Ω

4.48Vrms

+20dB

B

9d

+2

+10dB

　0dB PREOUT 159mVrms

-10dB

-20dB

-30dB

-40dB

91

PRINTED WIRING BOARDS

7CH-AMP (COMPONENT SIDE)

MTG

ZD402

R432

R421

C435

D402

D403

Q407

Q412

R413

FL

R441

Q401

R401

R703

C411

C407

B

R410

R402

R433

R439

J401

J415

BKT400

D406

D405

R443

TP401

J403

J416

R414

C415

J426

C414

C E

R552

R419

J518

J418

R550

J417

R430

C408

R436

R427

R437

VR401

IN OP FIADJICT

DC DET4 DC DET3

R536

ASO DET

RADI THERMAL

TR THERMAL

R420

J435

Q402

CN404

J584

R408

J408

R422

R404

J406

J585

R412

J409

J420

J419

BAR CODE

C402

R415

B C E

D401

R403 R405

C517

C515

R411

C412

C416

C406

C409

C404

J421

J410

R424

C410

R438

R717

R434

R429

R418

J404

J411

R428

J405

MTZ5.1A

J422

J412

ZD403

R435

J424

R425

ZD401

Q408

Q411

R440

R710

R442

R409

J413

R416

D404

J423

J433

J425

BE

C

VR404

R535

J453

R431

J440

J457

B

Q438

R538

C514

J434

J445

R545

C456

R533

R541

C464

C454

R720

R568

C457

J447

C452 D419

J436

ZD412

R554

R564

R548

R559

J438

C458

J450

R555

J437

R565

R558

Q444

R572

Q447

J432

MTZ5.1A

J439

D421

J454

R557

R542

R566

C460

R567

R534

C516

J402

J446

C449

C ECE B

ZD410

R546

D422

J451

ZD411

J449

R560

J448

R539

Q448

D420

181716151413121110987654321

G401

CLAMP 401

D435

WIRE BONDING

R659

J558

J546

J547

J556

C494

EC

J590

D436

TP406

R630

R646

R635

CP405

J548

SBL NC SBR

WIRE BONDING

R696

J591

VR407

Q474

J564

J482

J563

R679

R647

R674

B E

R681

R664

J575

R686

J565

C508

R667

R671

J576

C497

C

631010096006S

WIRE BONDING

R687

G402

C504

R670

R678

C506

R723

C512

J566

C502

J568

J577

R683

R694

C500 D437

MTZ5.1A

Q480

R688

R697

R677

J562

R662

ZD419

C505

ZD421

R693

J580

R684 J567

E B

WIRE BONDING

Q483

WIRE

BONDING

J569

D438

D440

J481

J581

C

J578

R675

ZD420

J579

R691

R695

G402

R663

D439

R668

R713

R701

Q484

Q473

R672

SBR

R699

R700

C519

R660

R661

R709

R692

C507

C503

R698

B C

J571

A

Pb

Q479

D441

D442

R669

J574

J572

C511

R673

J557

J573

R493

R702

TP407

Q417

R551

C419

100/100

B

C

D

E

J582

R690

R689

C510

E

FR

SBR

SBL

AGND

SR

AGND

C

FL

AGND

SL

CP401

R514

R562

R549

Q426

R492

VR403

J561

R507

J428

B

J471

J506

R502

R523

C444

R495

D413

R499

J460

R498

J472

C433

C E

C440

R489

R524

C448

R525

R719

C436

R491

J407

J473

C438

J462

C441

ZD409

R522

R511

R521

R505

R515

C442

R516

J458

ZD407

MTZ5.1A

J430

J476

R512

E

J463

Q435

D415

D416

J455 J465

J483

SL

R716

R570

Q443

D424

J427

R509

D423

R540

R571

TP404

R573

C451

Q437

R543

R531

R706

C459

C455

B

R532

R569

R563

J441

J534

R544

J535

J442

J444

J443

C463

J452

R561

C462

C

E

AGND

Q432

R506

C

R529

R496

R503

J477

J429

ZD408

J475

R519

B

C

R712

R527

Q436

C467

Q425

R488

R705

D414

AGND

Q431

D417

R497

R528

R530

J490

J583

R490

J537

J468

J467

C443

R520

C447

C439

C446

R526

B E

C

J478

D418

J474

J469

TP403

R517

J470

R600

R609

R610

VR405

R577

R581

Q450

R578

J486

J487

J508

R593

J497

R518

R588

B

C472

J499

C468

R608

ZD415

R598

J431

R591

R607

R602

C473

J502

D425

D427

C474

J489

R597

J559

J491

D428

R601

Q456

R615

Q459

ZD413 MTZ5.1A

J456

J507

C

SR

J484

J503

C476

C470

R595

R611

R721

J560

R576

R585

J488

J511

R584

C480

J498

C465

C E E B

Q449

J485

ZD414

J501

R605

R715

R613

R582

Q460

R574

R589

R707

J492

C475

D426

C471

B E

7CH AMP B'D

7020-06941-000-0S

Q455

D430

R465

J479

R583

R614

D429

TP405

R616

C483

R575

R606

R612

J570

J493

J494

C479

C478

C

J539

J504

J500

J495

R592

J496

R603

SR SL C FR FL

Q414

CP402

R604

VR402

R448

J464

J461

R463

R471

J512

J588

R458

J523

R451

J513

J524

C424

R480

C428

C422

R481

R482

R718

R445

D407

R447

C513

J514

J587

R455

R454

C425

C432

J525

C417

E E B

CB

C420

J516

R467

R478

C426

R473

ZD406

R479

J528

J510

MTZ5.1A

J515

R468

R472

ZD404

J517

Q423

J459

C

Q420

R486

R461

R462

R459

D410

J529

R452

Q424

J526

D408

D409

ZD405

J527

R476

R711

R484

R485

C499

Q413

R444

R456

R704

R446

R477

C427

C423

R483

B E

FR

Q419

R453

J519

C431

C

J505

C430

J520

R487

D411

TP402

R457

D412

J521

CP403

J530

WIRE BONDING

J544

J522

+HIGHB +HIGHB +HIGHB

-HIGHB

-HIGHB HIGHGND HIGHGND HIGHGND PREGND

R474

J509

R638

J532

R475

CLAMP 400

WIRE

BONDING

R653

J589

VR406

Q462

R621

J533

J538

R636

J549

R631

B E

R643

R624

J480

J550

C481

C

G400

R652

C492

G400

C488

R628

R619

R654

R722

R620

G401

C486

J540

R627

C496

SBL

ZD416

MTZ5.1A

J542

R508

J551

R640

WIRE BONDING

R644

C490

R650 R645

R634

C484 D431

J541

C489

ZD418

R651

J554

R641

E

WIRE BONDING

Q468

WIRE BONDING

Q471

WIRE BONDING

J536

J543

D434

J466

J555

C

C/SBDIP

R714

R656

R658

R625

Q472

Q461

R617

J552

R629

R708

R632

D432

C491

D433

ZD417

J553

C487

R648

B

R657

R618

R649

R655

Q467

J531

R626

C518

J545

C495

7CH-AMP (FOIL SIDE)

Pb

F

123456789101112131415161718

A

WIRE

C501

D455

C509

D456

WIRE

C493

WIRE

C485

D454

D453

C429

D446

C421

D445

R586

C477

R587

C469

D452

D451

J592

R733 R734

D457

D458

R449

R464

C437

D447

C445

D448

R501

R500

C461

D450

C453

D449

Q405

R407 C403

C413

D444

D443

C405

B

C

R732

R731

D

R676

R682

R730

R685

Q478

C498

R633

R639

R729

R642

Q466

Q463Q475

C482

R460

R466

R725

R469

Q418

C418

Q415

R590

R596

R728

R599

Q454

C466

Q451

R510

Q430 R513

R504

R726

Q427

C434

R553

R556

R547

R727

Q442

Q439

C450

R417

R423

R724

R426

Q406

Q403

C401

E

B

C

B

C

R666

B

E

C

B

CE

E

C

B

鉛フリー半田

半田付けには、鉛フリー半田 (Sn-Ag-Cu) を使用してください。

Lead-free Solder

When soldering, use the Lead-free Solder (Sn-Ag-Cu).

R623

C

E

B

C

B

R450

E

C

E

B

C

B

R580

E

EC

C

B

C

B

R494

E

EBC

C

B

C

B

R537

C

E

B

CE

B

C

B

R406

E

BC

F

92

SMPS (COMPONENT SIDE)

121110987654321

BKT102

MTG

BKT100

CX100

LIVE

NEUTRAL

JK100

R100

Sec.

BONDING

470P/250V

C104

CX104

470P/250V

C105

RL101

CX106

BONDING

J164

T6.3AL/250V

F101

CX102

D112

TR102

0.01UF/250V

C117

T2AL/250V

J165

F100

J179

DGND

MAINPOWER

D5.2V

0.1UF/250V

C100

MTZJ5.6B

ZD114

CX103

J178

TH100

J180

CX105

J169

C106

BONDING

MTZJ22B

ZD106

L100

LF4ZBE273H

5600UF/6.3V

J170

C107

MTZJ22B

ZD107

MTZJ22B

ZD104

BONDING

C108

J168

5600UF/6.3V

L101

LF4ZBE273H

J151

J152

5600UF/6.3V

J154

C109

MTZJ22B

ZD117

MTZJ22B

ZD102

C101

D25SC6M

D103

J153

J158

J157

J159

BONDING

T100

5600UF/6.3V

MTZJ22B

ZD118D108

MTZJ22B

ZD100

D100

0.1UF/250V D102

D105

D104

D101

D106

A

J156

J155

R110R112IC116

R111

R107

BONDING

MTG

BKT101

C114D111

Sec.

PC123 IC100

BONDING

ST-4430A

J175

1000P/1KV

C103

IC102

BONDING

J177

100UF/400V

C102

R113

ZD108ZD109ZD110

R115

D110

MTZJ22B

ZD112

D109

J176

TR101

TOP258MG

MTZJ39B

ZD101ZD105

R105

R119

C112

TR100

MTZJ39B

ZD103

J171

R101

ZD111

2200P/250V

C115

MTZJ39B

ZD115

BAR CODE

C119

J160

J161

ZD116

ZD119

R122

IN OP FIADJICT

R104

Pb

MTZJ39B

ZD113

Pri.

SMPS B'D

7020-06942-101-0S

B

C

D

E

F

SMPS (FOIL SIDE)

Sec.

Pri.

C116

R120

C120

C121

C

C122

C123

123456789101112

A

C113

R118

D5.2V

DGND

R123

MAINPOWER

R124

CA A

R108

R109

E

C110

C111

C125

C124

B

C

R106

C118

R121

R114

R125

R144

R126

Sec.

D

E

93

鉛フリー半田

半田付けには、鉛フリー半田 (Sn-Ag-Cu) を使用してください。

F

Lead-free Solder

When soldering, use the Lead-free Solder (Sn-Ag-Cu).

SPK (COMPONENT SIDE)

CP22

1413121110987654321

A

B

JACK3

J88

J75

J80

C22

R15

J46

L6

FL_W_GND

FR_W_GND

FR_WIDE

F-WIDEV

RLGND

CN13

WIRE1

WHITE(R)

J82

FL_WIDE

WIRE2

BLACK(L)

WIRE4

RLY7

C21

J38

RLY5

RLY6

J24

L7

J87

SBL

SBR

WIRE3

CN2

J40

J23

R17

J26

J33

J27

J25

J22

J21

C25

R16

J84

C24

WIRE4

WIRE5

J50

C16

J49

J35

J39

RLY4

C19

L4

R11

C12

WIRE3

R13

IN OP FIADJICT

BKT3

R18

JACK2

J34

WIRE5

J51

R39

J58

C11

RLY3

R12

J53

J54

J52

C17

L5

Pb

C14

C1

7020-06942-201-0S

SPK B'D

BAR CODE

C8

JACK1

J55

C4

R6

R5

L2

J68

J70

L1

J57

R14

J56

CLAMP3

CN3

J73

PREGND

HIGHGND

-HIGHB

+HIGHB +HIGHB

+HIGHB

J72

J77

R7

R8

RLY2

C6 J78

C3

J79

C9

L3

C

D

CN1

J96

FL FR CEN SL SR

J63

J91

J92

J93

J94

J83

J37

J65

J81

J89

R10

J71

J97

WIRE1

J69

R20

J62

R21

R22

R23

R24

R25

J36

J44

J45

RLY1

WIRE2

BLACK(L)WHITE(R)

R26

0.1-J/5W

R27

R9

R19

J42

J66

J1

WIRE5

R38

R37

C53

LIMITLIMITLIMIT+ LIMIT+ MUTE+7V RLGND RL+B NC RELAY_WIDE RELAY_F RELAY_C RELAY_S RELAY_SB RELAY_FB RELAY_H/P RELAY_H H/PL H/PGND H/PR

R30

R33

J86

J29

J2

WIRE5

J76

R53

J85

J32

R34

R29

R32

J31

BKT1

19

18

J74

J43

CP12

2

1

D8

DZ1

C57

R31

R28

BKT2

C60

E

F

G

H

I

鉛フリー半田

半田付けには、鉛フリー半田 (Sn-Ag-Cu) を使用してください。

Lead-free Solder

When soldering, use the Lead-free Solder (Sn-Ag-Cu).

94

J

BONDING

C55

J17

J11

J6

J5

AC AC

-

J4

J12

D3SB60

J28

J13

J3

D9

+

R35

J19

J20

C54

BONDING

R36

C58

K

J18

J10

J14

J9

CP1

C61

-

J8

J15

D3SB60

AC AC

D10

J7

J16

L

+

M

SPK (FOIL SIDE)

1234567891011121314

A

C37

C29 C30 C31

C5

C2

Q20

Q21

D11

D1

Q9

Q10

Q11

Q12

Q13

Q8

Q14

Q3 Q5

Q4Q2

Q6

Q1

Q7

C34

C28

C33

C27

C32

C26

C7

D2

C40

C36

C39

C35

C38

C13

D3

C18

C10

C41

C46

C42

C45

C43

C44

C23

C15

D4

C50

C47

C51

C48

C52

C49

C20

D5

D6

D7

B

C

D

E

F

G

H

C63

C62

I

J

K

L

鉛フリー半田

半田付けには、鉛フリー半田 (Sn-Ag-Cu) を使用してください。

M

Lead-free Solder

When soldering, use the Lead-free Solder (Sn-Ag-Cu).

95

REG (COMPONENT SIDE)

FRONT_CNT (COMPONENT SIDE)

65421

13121110987659321

A

B

C

D

E

A

B

C

D

E

F

G

H

I

REG_CNT (COMPONENT SIDE)

J

7654321

A

B

C

D

鉛フリー半田

半田付けには、鉛フリー半田 (Sn-Ag-Cu) を使用してください。

Lead-free Solder

When soldering, use the Lead-free Solder (Sn-Ag-Cu).

E

F

96

REG (FOIL SIDE)

FRONT_CNT (FOIL SIDE)

12345

12345678910111213

A

B

C

D

E

A

B

C

D

E

F

G

H

I

REG_CNT (FOIL SIDE)

J

1234567

A

B

C

D

97

E

鉛フリー半田

半田付けには、鉛フリー半田 (Sn-Ag-Cu) を使用してください。

F

Lead-free Solder

When soldering, use the Lead-free Solder (Sn-Ag-Cu).

SIDE_CNT (COMPONENT SIDE)

SIDE_CNT (FOIL SIDE)

181716151413121110

123456789

A

B

C

D

E

F

G

H

I

D

E

F

G

H

I

USB (COMPONENT SIDE) MIC (COMPONENT SIDE)

321

A

B

C

USB (FOIL SIDE) MIC (FOIL SIDE)

321

A

B

C

鉛フリー半田

半田付けには、鉛フリー半田 (Sn-Ag-Cu) を使用してください。

Lead-free Solder

When soldering, use the Lead-free Solder (Sn-Ag-Cu).

4321

A

B

C

4321

A

B

C

98

FRONT (COMPONENT SIDE)

181716151413121110987654321

A

B

C

D

E

V.AUX (COMPONENT SIDE)

F

G

H

FUNCTION_CNT (COMPONENT SIDE)

4321

A

13121110987654321

A

B

99

C

B

C

鉛フリー半田

半田付けには、鉛フリー半田 (Sn-Ag-Cu) を使用してください。

Lead-free Solder

When soldering, use the Lead-free Solder (Sn-Ag-Cu).

FRONT (FOIL SIDE)

123456789101112131415161718

A

B

C

D

E

V.AUX (FOIL SIDE)

F

G

H

FUNCTION_CNT (FOIL SIDE)

1234

A

12345678910111213

B

A

100

C

B

C

鉛フリー半田

半田付けには、鉛フリー半田 (Sn-Ag-Cu) を使用してください。

Lead-free Solder

When soldering, use the Lead-free Solder (Sn-Ag-Cu).

Denon AVR-3311-CI Service Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

AVR-3311CI

NOTE FOR SCHEMATIC DIAGRAM

NOTE FOR PARTS LIST

TECHNICAL SPECIFICATIONS

CAUTION IN SERVICING

DISASSEMBLY

1. FRONT PANEL ASSY

2. HEAT SINK ASSY

3. PCB REG CNT/PCB REG

4. HDMI UNIT ASSY

5. TRANS MAIN

SPECIAL MODE

2. Errors checking mode (Displaying the protection history)

JIG FOR SERVICING

ABOUT REPLACE THE MICROPROCESSOR WITH A NEW ONE

VERSION UPGRADE PROCEDURE OF FIRMWARE

SURROUND MODES AND PARAMETERS

ADJUSTMENT

TROUBLE SHOOTING

1. POWER

2. Analog video

3. HDMI/DVI.

4. AUDIO

5. Network/USB

CLOCK FLOW & WAVE FORM IN DIGITAL BLOCK

LAEVEL DIAGRAM

PRINTED WIRING BOARDS
