Illustrated Parts Manual
Lawn Tractor — LTX 1040
CUB CADET LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019
Printed In USA |
Form No. 769-04587 |
|
(July 29, 2009) |
Steering & Front Axle Assembly
|
1 |
2 |
|
3 |
4 |
|
5
6
8
7
|
|
|
|
|
9 |
|
|
|
|
|
|
|
|
10 |
|
|
|
|
|
11 |
|
|
|
14 |
|
|
|
|
|
12 |
|
|
|
|
|
|
|
|
|
|
|
|
15 |
|
|
|
|
|
|
13 |
|
|
|
|
|
|
|
|
|
14 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
8 |
|
|
|
16 |
19 |
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
18 |
|
21 |
20 |
33 |
|
35 |
|
|
|
17 |
|
22 |
|
34 |
|||
|
|
19 |
|
23 |
|
|
|||
|
18 |
|
|
24 |
25 |
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
27 |
|
|
|
|
|
21 |
20 |
24 |
|
|
|
|
||
|
26 |
|
|
|
|
||||
|
|
|
30 |
|
|
|
|||
|
|
|
|
|
|
|
|
||
|
22 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
25 |
|
|
|
|
|
|
|
|
|
31 |
|
|
|
23 |
28 |
32 |
|
|
|
|
|
|
|
|
|
|||
33 |
|
|
|
29 |
|
|
|
||
|
|
|
|
|
|
|
|
||
|
|
32 |
|
|
|
|
|
|
34
35
2
|
|
Steering & Front Axle Assembly |
|
|
|
|
|
Ref. |
Part Number |
Description |
|
|
|
|
|
|
|
|
|
1 |
731-04532B |
Steering Wheel Cover |
|
2 |
710-04484 |
Hex Washer Screw, 5⁄16-18 x .750 |
|
3 |
936-3004 |
Flat Washer, .406 x .875 x .105 |
|
4 |
631-04008A |
Steering Wheel |
|
5 |
738-04262 |
Steering Wheel Shaft |
|
6 |
710-0514 |
Hex Screw, 3⁄8-16 x 1.00 |
|
7 |
741-04237A |
Hex Flange Bearing |
|
8 |
712-04065 |
Flange Lock Nut, 3⁄8-16 |
|
9 |
783-06043-0637 |
Steering Support Bracket |
|
10 |
717-1550F |
Steering Gear |
|
11 |
736-3084 |
Flat Washer, .51 x 1.12 x .06 |
|
12 |
717-1554 |
Steering Gear |
|
13 |
712-0459 |
Flange Lock Nut, 7⁄16-20 |
|
14 |
738-04363 |
Shoulder Spacer, .385 x 1.25 x .3025 |
|
15 |
710-04095 |
Hex Screw, 3⁄8-16 x 1.00 |
|
16 |
711-04998 |
LH Drag Link |
|
17 |
711-04999 |
RH Drag Link |
|
18 |
712-3004A |
Flange Lock Nut, 5⁄16-18 |
|
19 |
912-0240 |
Jam Nut, 7⁄16-20 |
|
20 |
923-0448A |
Lock Joint |
|
21 |
712-04063 |
Flange Lock Nut, 5⁄16-18 |
|
22 |
748-04065-0637 |
Steering Block |
|
23 |
710-3180 |
Hex Screw, 5⁄16-18 x 1.75 |
|
24 |
912-0214 |
Hex Lock Nut, 3⁄8-24 |
|
25 |
748-04068 |
Spacer, .71 x .125 x .56 |
|
26 |
712-3083 |
Hex Lock Nut, 1⁄2-13 |
|
27 |
719-04413 |
Axle Pivot Bar |
|
28 |
750-05041 |
Spacer, .510 x 1.00 x 1.5075 |
|
29 |
710-04824 |
Hex Screw, 1⁄2-13 x 2.5 |
|
30 |
638-04021-0637 |
RH Axle Assembly |
|
31 |
638-04027-0637 |
LH Axle Assembly |
|
32 |
714-0162 |
Cotter Pin, 5⁄32 x 1.25 |
|
33 |
N/A |
Wheel Assembly (Plastic Flange) |
|
— |
634-04405-0499 |
Rim Assembly |
|
— |
734-1731-0901 |
Tire |
|
— |
734-0255 |
Tubeless Air Valve |
|
— |
741-0990B |
Flange w/ Fitting Bearing |
|
— |
741-0516B |
Flange w/o Fitting Bearing |
|
34 |
736-04228A |
Flat Washer, .781 x 1.590 |
|
35 |
731-05674 |
Bumper Cap |
|
|
|
|
|
3
Hood & Dash Assembly
1
3
11 |
12 |
13 |
15 |
|
|
|
|
|
16 |
|
|
|
|
|
|
|
|
19 |
|
17 |
|
18 |
23 |
35 |
|
21 |
|
|
|
|
|
|
|
|
36
20
22
|
31 |
32 |
25 |
|
|
|
5 |
|
|
|
26
27
38 37
41
40
39
2
6 |
7 |
8 |
|
|
5 |
5 |
10
24 4
|
|
|
|
9 |
|
|
29 |
30 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
33 |
|
|
|
|
|
34 |
|
|
|
|
|
38 |
42 |
California Models |
||
|
|
|
|
|
||
|
|
|
|
|
48 |
|
|
|
|
|
47 |
49 |
|
|
43 |
|
|
|
||
44 |
|
|
|
|
|
|
46
45
50
51
14
4
Ref. |
Part Number |
Description |
|
|
|
|
|
|
1 |
931-06634 |
Hood |
2 |
731-06543 |
LH Hood Scoop |
3 |
731-06542 |
RH Hood Scoop |
4 |
931-04322 |
Grill |
— |
777X43335 |
Reflective Label, LH |
— |
777X43334 |
Reflective Label, RH |
5 |
710-0895 |
Hex Washer Screw, 1⁄4-15 x .750 |
6 |
936-3020 |
Flat Washer, .271 x .630 x .065 |
7 |
936-0222 |
Lock Washer, 1⁄4 |
8 |
931-06559 |
Lens, LH |
9 |
931-06558 |
Lens, RH |
10 |
925-0963 |
Lamp, 12V |
— |
925-1649 |
Headlight Socket |
11 |
925-2054A |
Key |
12 |
925-04227B |
Key Switch |
13 |
925-04022B |
Indicator Meter |
14 |
951-10590 |
Canister Vent Filter |
15 |
710-1017 |
Screw, 1⁄4-14 x .625 |
16 |
731-06593 |
Throttle Knob |
17 |
712-0142 |
Hex Nut, #8-32 |
18 |
710-3217 |
Screw, #8-32 x .375 |
19 |
731-05447A |
Parking Brake/Cruise Control Lever |
20 |
747-05009 |
Control Rod |
21 |
714-04040 |
Bow-Tie Cotter Pin |
22 |
732-04580 |
Extension Spring, .500 x 2.733 |
23 |
931-06666 |
Dash Panel |
24 |
735-0271A |
Bumper |
25 |
710-04484 |
Hex Washer Screw, 5⁄16-18 x .750 |
|
|
|
|
|
Hood & Dash Assembly |
|
|
|
|
|
|
Ref. |
Part Number |
Description |
|
|
|
|
|
|
26 |
710-0599 |
Hex Washer Screw, 1⁄4-20 x .500 |
27 |
710-1611B |
Screw, 5⁄16-18 x .750 |
28 |
710-1652 |
Hex Washer Screw, 1⁄4-20 x .625 |
29 |
747-1196 |
Bent Lever Rod |
30 |
710-0895 |
Hex Washer Screw, 1⁄4-15 x .750 |
31 |
783-06099-0637 |
Dash Support, RH |
32 |
783-06098-0637 |
Dash Support, LH |
33 |
783-06114-0637 |
Hood Pivot Bracket |
34 |
738-04091A |
Shoulder Screw, 5⁄16-18 x .43 x .29 |
35 |
735-04076 |
Net |
36 |
726-3046 |
Ratchet Clip |
37 |
751-0603A |
Fuel Cap |
38 |
735-04170 |
Fuel Tank Gasket |
39 |
747-05040A |
Fuel Tank Support Rod |
40 |
710-1652 |
Hex Washer Screw, 1⁄4-20 x .625 |
41 |
751-10879 |
Fuel Tank |
42 |
951-10947 |
Fuel Cap |
43 |
751-10906 |
Fuel Tank |
44 |
751-10441 |
Rollover Valve |
— |
735-04081 |
Rubber Grommet |
45 |
747-05040A |
Fuel Tank Support Rod |
46 |
710-0642 |
Hex Washer Screw, 1⁄4-20 x .750 |
47 |
951-10589 |
Carbon Canister |
48 |
951-10610 |
Canister Adapter Bracket |
49 |
710-04484 |
Hex Washer Screw, 5⁄16-18 x .750 |
50751-10749-30 Fuel Hose, 3⁄16 White
51751-10750-28 Fuel Hose, 7⁄32 Yellow
5
Seat, Fender & Deck Lift
1
|
|
2 |
|
3 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
4 |
|
11 |
|
5 |
|
|
|
15 |
|
|
|
8 |
|
||
|
54 |
|
|
|
||
|
|
6 |
|
|
||
|
|
|
|
|
|
|
|
|
|
|
7 |
|
|
|
|
16 |
|
|
7 |
|
|
|
|
|
9 |
|
|
|
|
|
12 |
|
|
|
|
|
|
|
|
10 |
17 |
|
|
13 |
|
|
|
|
|
|
|
|
|
|
|
14 |
|
|
|
|
|
|
|
|
|
40 |
|
|
|
39 |
|
|
|
|
|
|
24 |
|
41 |
|
42 |
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
23 |
|
|
46 |
|
|
|
|
|
45 |
43 |
|
31 |
|
|
|
|
32 |
|||
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
44 |
|
33 |
|
|
|
|
34 |
|
|
|
|
49 |
|
|
|
|
48 |
53 |
|
35 |
|
36 |
|
47 |
|
|
|
|
37 |
|
|
|
|
|
|
38 |
|
|
|
|
|
|
|
|
|
|
50 |
|
|
|
25 |
|
|
|
51 |
|
|
|
|
|
|
|
|
27 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
26 |
18
19
20
21
22
29 30 28
6
Ref. |
Part Number |
Description |
|
|
|
|
|
|
1 |
757-04085 |
Medium Back Seat |
2 |
783-06049-0637 |
Seat Mounting Bracket |
3 |
783-06050 |
Seat Adjustment Lever |
4 |
732-04563 |
Compression Spring, .68 x 1.065 x .055 |
5 |
938-0296 |
Shoulder Screw, 5⁄16-18 x .437 x .268 |
6 |
710-04482 |
Hex Flange Bolt, 3⁄8-16 x .875 |
7 |
710-04484 |
Hex Washer Screw, 5⁄16-18 x .750 |
8 |
732-04561 |
Compression Spring, 1.71 x 3.735 x .238 |
9 |
712-3004A |
Flange Lock Nut, 5⁄16-18 |
10 |
783-06088-0637 |
Seat Pivot Bracket |
11 |
731-06754 |
Fender Cover. RH |
12 |
710-04484 |
Hex Washer Screw, 5⁄16-18 x .750 |
13 |
710-0895 |
Hex Washer Screw, 1⁄4-15 x .750 |
14 |
783-06039-0637 |
Manual PTO Lift Bracket |
15 |
731-05515B |
Fender Cover, LH |
16 |
783-06235-4021 |
Fender |
17 |
710-0599 |
Hex Washer Screw, 1⁄4-20 x .500 |
18 |
710-0528 |
Screw, 5⁄16-18 x 1.25 |
19 |
750-3310 |
Flange Spacer, .3125 x .4375 x .625 |
20 |
735-0690 |
Grommet, .4375 x .750 |
21 |
736-3078 |
Flat Washer, .344 x 1.0 x .063 |
22 |
712-04063 |
Flange Lock Nut, 5⁄16-18 |
23 |
946-04618 |
Deck Engagement Cable |
24 |
714-04040 |
Bow-Tie Cotter Pin |
25 |
714-3002 |
Cotter Pin, 3⁄16 x 1.00 |
26 |
747-04944A |
Deck Lift Rod |
27 |
936-0179 |
Flat Washer, 1⁄2 x 1.25 x .10 |
|
|
|
|
|
Seat, Fender & Deck Lift |
|
|
|
|
|
|
Ref. |
Part Number |
Description |
|
|
|
|
|
|
28 |
736-0317 |
Bell Washer |
29 |
912-0206 |
Hex Nut, 1⁄2-13 |
30 |
712-3083 |
Hex Lock Nut, 1⁄2-13 |
31 |
738-0138A |
Shoulder Screw, 5⁄16-18 x .437 x .470 |
32 |
756-04331 |
Cable Roller Pulley |
33 |
746-0968 |
Lift Cable |
34 |
712-04063 |
Flange Lock Nut, 5⁄16-18 |
35 |
714-0111 |
Cotter Pin, 3⁄32 x 1.0 |
36 |
783-04711B-0637 |
Lift Arm, LH |
37 |
738-04130 |
Shoulder Bolt, 3⁄8-16 x .625 x .175 |
38 |
712-04065 |
Flange Lock Nut, 3⁄8-16 |
39 |
720-04116 |
Grip |
40 |
732-0932 |
Extension Spring, .38 x 5.6 |
41 |
647-04151 |
PTO Handle |
42 |
738-04237A |
Shoulder Screw, #10-32 x .500 |
43 |
741-04119 |
PTO Bearing |
44 |
710-0599 |
Hex Washer Screw, 1⁄4-20 x .500 |
45 |
716-0106A |
E-Type Ring |
46 |
941-0225 |
Hex Flange Bearing |
47 |
746-0968 |
Lift Cable |
48 |
683-04223-0637 |
Lift Shift Assembly |
49 |
914-0104 |
Cotter Pin, .072 x 1.13 |
50 |
732-0874 |
Torsion Spring |
51 |
747-04962A |
Lift Handle |
52 |
720-0311 |
Handle Grip |
53 |
736-0105 |
Washer, .401 x .870 x .063 |
54 |
925-04040 |
Seat Switch |
|
|
|
7
Drive System
1
4
8
9
12
27
33
49
34
36
35
53
51 52
50
2
3
7
10 11
13 14
26
16
25 17
24
30
31
5
|
|
|
|
|
5 |
|
|
12 |
|
41 |
|
6 |
|
|
|
|
|
|
|
|
42 |
6 |
|
|
|
|
|
|
|
55 |
|
|
|
12 |
|
|
|
|
|
||
15 |
48 |
|
|
|
|
|
|
|
|
|
43 |
14 |
47 |
|
46 |
44 |
35 |
|
|
45 |
|
||
|
|
|
|
||
|
|
|
|
|
18 |
|
23 |
19 |
|
22 |
28 |
20 |
29 |
30 |
21 |
|
||
|
|
|
|
|
72 |
31 |
|
|
|
|
|
|
3 |
|
|
|
71 |
|
|
|
|
|
|
|
|
|
|
|
|
37 |
32 |
|
8 |
68 |
12 |
|
|
|
|
|
||||
|
|
|
|
22 |
39 |
|
|
|
35 |
|
|
40 |
|
64 |
65 |
55 |
70 |
|
|
|
|
58 |
|
|
||
|
38 |
|
56 |
|
|
|
||
|
|
|
|
|
|
|||
|
|
66 |
|
|
67 |
|||
|
|
|
|
|
||||
|
|
|
|
|
63 |
|||
|
|
|
57 |
|
|
|
69 |
|
|
|
|
|
|
|
|
||
|
|
|
12 |
|
|
62 |
|
|
|
|
|
|
|
|
|
|
|
|
|
54 |
55 |
59 |
|
|
|
61 |
|
|
|
12 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
60 |
|
|
|
8
Ref. |
Part Number |
Description |
|
|
|
|
|
|
1 |
712-0700 |
Flange Nut |
2 |
954-04208 |
V-Belt |
3 |
710-1007 |
Hex Washer Screw, 3⁄8-16 x 1.500 |
4 |
956-04002 |
Pulley |
5 |
720-04028 |
Shift Knob |
6 |
647-04035 |
Shift Lever Assembly |
7 |
756-04325 |
Idler Pulley |
8 |
710-1026 |
Hex Washer Screw, 1⁄4-20 x 1.750 |
9 |
710-04823 |
Bolt, 5⁄16-18 x 2.75 |
10 |
N/A |
Var. Speed Pulley Ass. w/ Bracket |
—956-04015A Variable Speed Pulley Assembly
— |
683-04522 |
Variable Speed Belt Guide |
— |
683-04523 |
Variable Speed Pulley Bracket |
— |
710-0627 |
Screw, 5⁄16-24 x .750 |
— |
710-0778 |
Screw, 1⁄4-20 x 1.500 |
— |
718-04261 |
Bearing Cup |
— |
736-0362 |
Flat Washer |
— |
741-0124 |
Ball Bearing |
11 |
731-06894 |
Shift Plate Bearing |
12 |
710-04484 |
Hex Washer Screw, 5⁄16-18 x .750 |
13 |
914-0209 |
Internal Cotter Pin |
14 |
747-05109 |
Shift Rod |
15 |
912-0431 |
Flange Lock Nut, 3⁄8-16 |
16 |
723-3018 |
Joint Ball |
17 |
936-0169 |
Lock Washer, 3⁄8 |
18 |
712-0241 |
Hex Nut, 3⁄8-24 |
19 |
750-04456 |
Spacer, .260 x .372 x 1.420 |
20 |
936-0140 |
Flat Washer, .385 x .62 x .063 |
21 |
747-04957A |
Foot Pedal Transmission Bypass Rod |
22 |
914-0111 |
Cotter Pin, 3⁄32 x 1.0 |
23 |
747-04959A |
Idler Adjuster Rod |
24 |
783-06027 |
Idler Bracket |
25 |
732-04612 |
Extension Spring, .70 x 12.00 |
26 |
954-0467 |
V-Belt |
27 |
718-04407 |
Pulley Hub |
28 |
736-04337 |
Shim Washer, 1.00 x .632 x .010 |
29 |
738-0372B |
Shoulder Spacer, 1.00 x .38 x .38 |
30 |
912-0240 |
Jam Nut, 7⁄16-20 |
31 |
756-04224 |
Flat Idler Pulley |
32 |
710-3011 |
Hex Screw, 3⁄8-16 x 2.25 |
33 |
918-04566 |
Transmatic Drive Assembly |
|
|
Drive System |
|
|
|
|
|
|
Ref. |
Part Number |
Description |
|
|
|
|
|
|
34 |
731-04604 |
Sleeve, .758 x .821 x 2.4375 |
35 |
712-04063 |
Flange Lock Nut, 5⁄16-18 |
36 |
732-0716D |
Extension Spring, .59 x 4.00 |
37 |
732-04616 |
Extension Spring, .97 x 6.18 |
38 |
738-04091A |
Shoulder Screw, 5⁄16-18 x .43 x .29 |
39 |
936-3008 |
Flat Washer, .344 x .750 x .120 |
40 |
747-04984 |
Brake Rod |
41 |
783-06132 |
Shift Bracket |
42 |
732-0525 |
Spring Shifter Clip |
43 |
710-0227 |
Hex Washer Screw, #8-18 x .500 |
44 |
926-0320 |
Insulator Nut Plate |
45 |
725-1644 |
Short Spring Switch |
46 |
914-0104 |
Cotter Pin, .072 x 1.13 |
47 |
710-3025 |
Hex Screw, 5⁄16-18 x .625 |
48783-04595A Shift Adjustment Bracket
49634-04639-0499 Rim Assembly, 8.0 x 7.0 x.750
— |
934-0255 |
Tubeless Air Valve |
— |
734-1730-0901 |
Tire, 20 x 8 x 8 |
50 |
731-2290A |
Hub Cap |
51 |
710-0627 |
Hex Lock Screw, 5⁄16-24 x .750 |
52 |
736-0242 |
Bell Washer, .340 x .872 x .060 |
53 |
736-0430 |
Flat Washer, .350 x 1.59 x .062 |
54 |
726-0214 |
Push Cap, 5⁄8 |
55 |
741-0495 |
Flange Bearing, .630 x .695 x .60 |
56 |
735-0662 |
Control Pad |
57 |
683-0266 |
Auto Drive Control Pedal Assembly |
58 |
683-04489 |
Transmatic Pedal Bracket Assembly |
59 |
783-05914 |
Pedal Strap Support Bracket |
60 |
712-04065 |
Flange Lock Nut, 3⁄8-16 |
61 |
938-0380 |
Shoulder Bolt, 3⁄8-16 x .500 x .270 |
62 |
741-3065B |
Hex Flange Bearing |
63 |
748-04203 |
Cruise Latch |
64 |
714-04040 |
Bow-Tie Cotter Pin |
65 |
783-06278 |
Bracket Reinforcement Plate |
66 |
711-05068 |
Clevis Pin, 5⁄16-3.985 |
67 |
647-04152 |
Brake Control Assembly |
68 |
732-04587 |
Extension Spring, .63 x 4.95 |
69 |
710-0604A |
Hex Washer Screw, 5⁄16-18 x .625 |
70 |
783-05940 |
Pedal Strap Support Bracket |
71 |
783-06103A-0637 |
Brake Pedal Bracket |
72 |
735-04136 |
Brake Pedal Pad |
9
Frame, Battery & PTO
|
1 |
|
2 |
3 |
4 |
|
|
|
5 |
|
|
14 |
6 |
|
15 |
10 |
|
|
|
|
11 |
|
7 |
12 |
8 |
|
|
|
|
|
|
9 |
13 |
|
|
16
17
18
19
20
22
21 |
6 |
10
Frame, Battery & PTO
Ref. |
Part Number |
Description |
|
|
|
|
|
|
1 |
747-04121A |
Battery Hold-Down Rod |
2 |
712-0271 |
Sems Nut, 1⁄4-20 |
3 |
710-04666 |
Hex Flange, 1⁄4-20 x .75 |
4 |
925-1707D |
Battery |
5 |
783-06089-0637 |
Seat Frame Bracket |
6 |
710-04484 |
Hex Washer Screw, 5⁄16-18 x .750 |
7 |
738-04058 |
Shoulder Spacer, .38 x 1.0 x .70 |
8 |
710-3005 |
Hex Screw, 3⁄8-16 x 1.25 |
9 |
783-0349-0637 |
Battery Tray |
10 |
712-04065 |
Flange Lock Nut, 3⁄8-16 |
11 |
725-04439 |
Solenoid |
12 |
710-0653 |
Hex Washer Screw, 1⁄4-20 x .375 |
13 |
712-04064 |
Flange Lock Nut, 1⁄4-20 |
14 |
738-04237A |
Shoulder Screw, #10-32 x .500 |
15 |
725-04363 |
Interlock Switch |
16 |
683-04469-0637 |
Lower Frame Assembly |
17 |
756-04208A |
Engine Pulley |
18 |
736-0322 |
Flat Washer, .450 x 1.250 x .164 |
19 |
936-0171 |
Lock Washer, 7⁄16 |
20 |
710-04607 |
Hex Screw, 7⁄16-20 x 2.75 |
21 |
712-04063 |
Flange Lock Nut, 5⁄16-18 |
22 |
747-05065 |
Keeper Rod |
|
|
|
11
Engine Accessories
Kohler Single |
|
Engine Shown |
1 |
For Reference |
2 |
|
Only |
||
1 |
||
15 |
||
|
|
|
8 |
|
|
|
|
|
6 |
|
4 |
|
|
|
|
3 |
|
|
10 |
|
|
|
7 |
|
|
|
|
17 |
|
|
|
|
|
|
|
9 |
6 |
16 |
13 |
14 |
|
|
11 |
|
|
12 5
Ref. |
Part Number |
Description |
|
|
|
|
|
|
1 |
726-0205 |
Hose Clamp |
2 |
751-10349 |
Fuel Hose |
3 |
751-3141-14 |
Extension Hose |
4 |
951-10517A |
Oil Drain |
5 |
710-04683 |
Hex Washer Screw, 3⁄8-16 x 1.00 |
6 |
710-0599 |
Hex Washer Screw, 1⁄4-20 x .500 |
7 |
710-1314A |
Screw, 5⁄16-18 x .750 |
8 |
721-0377A |
Exhaust Gasket |
9 |
725-0157 |
Cable Tie, 3⁄16 x .05 x 7.4 |
|
|
|
Ref. |
Part Number |
Description |
|
|
|
|
|
|
10 |
751-0564B |
Muffler Deflector |
11 |
751-10353 |
Long Muffler Deflector |
12 |
710-0227 |
Hex Washer Screw, #8-18 x .500 |
13 |
728-04000 |
Rivet, .188 x .300 |
14 |
683-04549-0637 |
Muffler Shield Assembly |
15 |
712-0271 |
Sems Nut, 1⁄4-20 |
16 |
751-11022 |
Kohler Single Muffler |
17 |
710-1652 |
Hex Washer Screw, 1⁄4-20 x .625 |
|
|
|
12
Notes
13
42” U.S. Timed Mowing Deck
36A |
|
|
36B |
|
46 |
|
46 |
|
|
|
|
|
||
|
|
|
66 |
|
|
55 |
|
57 |
|
|
|
|
||
|
56 |
|
|
|
|
|
|
58 |
|
|
57 |
60 |
59 |
|
|
|
|||
|
|
|
||
|
58 |
|
61 |
|
|
62 |
|
||
|
59 |
|
||
60 |
61 |
63 |
||
61 |
||||
|
|
34 |
||
|
|
|
62 |
63 |
|
61 |
||
64 |
||
|
||
|
65 |
64
65
35
6
18
40
6
41
42
45
1
2
30 29 28 27
33
32
36A 6
37
12
39
38
14
12
43
44
46
|
3 |
|
|
|
|
6 |
4 |
|
|
26 |
7 |
5 |
|
|
|
|
|
||
6 |
9 |
|
|
|
|
|
|
||
31 |
8 |
10 |
|
|
|
|
|
||
11 |
12 |
|
|
|
|
|
|
||
|
14 |
13 |
|
|
|
18 |
|
|
|
|
15 |
|
|
|
|
16 |
19 |
22 |
|
|
17 |
10 |
|
|
|
|
23 |
|
|
|
20 |
24 |
25 |
|
7 |
|
|||
21 |
|
|
|
|
36B |
|
|
54 |
67 |
|
|
|
6 |
50 |
51 |
|
||
|
|
|
|
|
52 |
|
|
6 |
|
48 |
53 |
|
|
49
47
14
Ref. |
Part Number |
Description |
|
|
|
|
|
|
1 |
954-0266A |
Drive Belt |
2 |
954-04167 |
Timing Belt |
3 |
710-1325 |
Hex Washer Screw, 1⁄4-20 x 1.625 |
4 |
750-04456 |
Spacer, .260 x .372 x 1.420 |
5 |
932-0428A |
Extension Spring, .50 x 4.35 |
6 |
712-04065 |
Flange Lock Nut, 3⁄8-16 |
7 |
756-04129B |
Idler Pulley |
8 |
936-3004 |
Flat Washer, .406 x .875 x .105 |
9 |
750-0807 |
Spacer, .385 x .625 x .700 |
10 |
738-04162A |
Shoulder Spacer, .8840 x .190 |
11 |
983-04524 |
Brake Assembly |
12 |
710-04484 |
Hex Washer Screw, 5⁄16-18 x .750 |
13 |
783-06176-0637 |
Idler Brace Bracket |
14 |
710-0347 |
Hex Screw, 3⁄8-16 x 1.75 |
15 |
712-0266A |
Jam Lock Nut, 3⁄8-16 |
16 |
936-0300 |
Flat Washer, .406 x .875 x .059 |
17 |
756-04280 |
Idler Pulley |
18 |
712-0229 |
Push Nut, 3⁄8 |
19 |
750-04446 |
Spacer, 3⁄8 x .68 x 1.46 |
20 |
783-05802-0637 |
Tension Bracket |
21 |
710-0520 |
Hex Screw, 3⁄8-16 x 1.50 |
22 |
710-1325 |
Hex Washer, 1⁄4-20 x 1.625 |
23 |
750-0566A |
Spacer, .260 x .375 x 1.030 |
24 |
732-0826A |
Extension Spring, .865 x 4.68 |
25 |
737-04003D |
Deck Water Nozzle |
26 |
710-0528 |
Hex Screw, 5⁄16-18 x 1.25 |
27 |
936-0119 |
Lock Washer, 5⁄16 |
28 |
917-04074 |
Deck Adjustment Gear |
29 |
914-0470 |
Cotter Pin, 1⁄8 x 1.25 |
30 |
932-0306A |
Compression Spring, .531 x 1.75 |
31 |
747-1116 |
Deck Handle Rod |
32 |
738-04316A |
Shoulder Bolt, 5⁄16-24 x .435 x 1.76 |
33 |
783-05627-063 |
Deck Lift Bracket |
34 |
710-0599 |
Hex Washer Screw, 1⁄4-20 x .500 |
35 |
731-06291A |
Belt Cover |
|
|
|
42” U.S. Timed Mowing Deck
Ref. |
Part Number |
Description |
|
|
|
|
|
|
|
|
|
36A |
918-04512A |
Spindle Assembly, Drive |
|
36B |
918-04516 |
Spindle Assembly, Driven |
|
37 |
711-1044A |
Belt Guard Pin |
|
38 |
783-06262-0637 |
Deck Engage Cable Bracket |
|
39 |
747-05055 |
Belt Keeper Rod |
|
40 |
631-04254 |
Chute Assembly |
|
41 |
734-0973 |
Deck Wheel |
|
42 |
938-0373 |
Shoulder Bolt, 3⁄8-16 x .496 x 1.525 |
|
43 |
710-3178 |
Carriage Bolt, 3⁄8-16 x .75 |
|
44 |
712-04063 |
Flange Lock Nut, 5⁄16 x 18 |
|
45 |
942-04217 |
2-in-1 Blade |
|
46 |
712-0417A |
Flange Nut, 5⁄8-18 |
|
47 |
710-3130 |
Hex Screw, 3⁄8-16 x 3.25 |
|
48 |
736-0258 |
Flat Washer, .385 x 1.0 x .135 |
|
49 |
710-3005 |
Hex Screw, 3⁄8-16 x 1.25 |
|
50 |
938-0785 |
Shoulder Spacer, 1.38 x .445 x .36 |
|
51 |
734-04155 |
Deck Wheel |
|
52 |
736-0225 |
Lock Washer, 5⁄8 |
|
53 |
912-0641 |
Hex Nut, M16-1.5 |
|
54 |
683-04492-4021 |
Deck Assembly |
|
55 |
756-04372 |
Pulley (Drive Spindle) |
|
56 |
750-04724 |
Spacer, .792 x 1.060 x 1.860 (Drive |
|
Spindle) |
|||
|
|
||
57 |
913-04040A |
Timing Pulley |
|
58 |
787-01520 |
Timing Pulley Plate |
|
59 |
710-04065 |
Screw, 1⁄4-10 x .625 |
|
60 |
936-0287 |
Flat Washer, .793 x 1.24 x .06 |
|
61 |
941-0919 |
Ball Bearing, .787 x 1.85 x .551 |
|
62 |
750-04936 |
Spacer, .792 x 1.060 x 1.860 |
|
63 |
937-3000 |
Drive Lube Fitting |
|
64 |
619-04199 |
Spindle Housing |
|
65 |
938-04292 |
Spindle Shaft (Drive Spindle) |
|
— |
938-04291 |
Spindle Shaft (Driven Spindle) |
|
66 |
736-0315 |
Flat Washer, .760 x 1.50 x .120 |
|
67 |
938-3056 |
Shoulder Bolt, 3⁄8-16 x .50 x 2.5 |
|
|
|
|
15
