Crestron MC2E
2-Series Compact Control System with Ethernet
Operations Guide
This document was prepared and written by the Technical Documentation department at:
Crestron Electronics, Inc.
15 Volvo Drive
Rockleigh, NJ 07647
1-888-CRESTRON
All brand names, product names and trademarks are the property of their respective owners. ©2007 Crestron Electronics, Inc.
Crestron MC2E |
2-Series Compact Control System |
Contents
2-Series Compact Control System with Ethernet: MC2E |
1 |
Introduction ............................................................................................................................... |
1 |
Features and Functions................................................................................................ |
1 |
Specifications .............................................................................................................. |
3 |
Physical Description.................................................................................................... |
4 |
Industry Compliance ................................................................................................... |
8 |
Setup .......................................................................................................................................... |
9 |
Network Wiring........................................................................................................... |
9 |
Identity Code ............................................................................................................... |
9 |
Installation................................................................................................................. |
10 |
Hardware Hookup ..................................................................................................... |
12 |
Power Supply ............................................................................................................ |
12 |
Programming Software............................................................................................................ |
13 |
Earliest Version Software Requirements for the PC ................................................. |
13 |
Programming with Crestron SystemBuilder.............................................................. |
14 |
Programming with D3 Pro......................................................................................... |
14 |
Programming with SIMPL Windows ........................................................................ |
14 |
Uploading and Upgrading........................................................................................................ |
15 |
Establishing Communication..................................................................................... |
15 |
Programs and Firmware ............................................................................................ |
16 |
Operation ................................................................................................................................. |
17 |
Problem Solving ...................................................................................................................... |
18 |
Troubleshooting......................................................................................................... |
18 |
Check Network Wiring.............................................................................................. |
21 |
Reference Documents................................................................................................ |
22 |
Further Inquiries ........................................................................................................ |
22 |
Future Updates .......................................................................................................... |
22 |
Software License Agreement................................................................................................... |
23 |
Return and Warranty Policies .................................................................................................. |
25 |
Merchandise Returns / Repair Service ...................................................................... |
25 |
CRESTRON Limited Warranty................................................................................. |
25 |
Operations Guide – DOC. 6142A |
Contents • i |
Crestron MC2E |
2-Series Compact Control System |
2-Series Compact Control System with Ethernet: MC2E
Introduction
Features and Functions
•2-Series engine
•Dual bus architecture
•32-bit Freescale Coldfire® processor
•36 MB of Internal Memory*
•Cresnet® port – master/slave selectable
•10/100 Ethernet with SSL encryption
•Crestron e-Control®2 enabled
•RoomView® enabled
•Two Com ports (RS-232/422/485)
•Four IR/serial ports
•Four Versiport I/O ports
•Four low-voltage relay ports
•IR wireless compatible using CNXRMIRD (not included)
•Static and dynamic IP addressing
•Built-in web server
•POP3 email server for sending email
•External power supply included
•Single-space EIA rack-mountable
*For more information on internal memory, refer to “2-Series Memory & Directory Structure” in the latest version of the Crestron 2-Series Control System Reference Guide (Doc. 6256), which is available from the Crestron website (http://www.crestron.com/manuals).
2-Series Engine
At the heart of the MC2E is the powerful 32-bit Freescale ColdFire® processor. Crestron's exclusive enhanced real-time operating system makes the MC2E the fastest, most reliable control system available.
Operations Guide – DOC. 6142A |
2-Series Compact Control System: MC2E • 1 |
2-Series Compact Control System |
Crestron MC2E |
Cresnet®
Cresnet is the communications backbone for many Crestron touchpanels, keypads, lighting controls and other devices. The Cresnet bus is a simple, yet flexible 4-wire network that provides rock-solid bidirectional communication for numerous Cresnet devices.
Cresnet Slave Mode
Selectable Cresnet Slave Mode enables the MC2E to be configured as a Cresnet slave device, effectively transforming it into a Cresnet expansion module. Such flexibility can offer a cost-effective solution for system expansion, providing a host of additional control ports in a single module.
Ethernet
Crestron pioneered the IP-based control system to harness the vast possibilities of Ethernet and the Internet for remote control, monitoring, programming and diagnostics. The MC2E is designed to deliver the world's most advanced IP control solution with full-duplex 10/100 Ethernet, built-in Web server and email client and support for both static and dynamic IP addressing.
Crestron e-Control®2
Crestron's award-winning e-Control 2 XPanel solutions offer the most flexible range of IP control possibilities available. Using a Windows® computer or CE/PocketPC™ PDA device, e-Control 2 provides an amazing control GUI that looks and behaves just like a Crestron Isys® touchpanel.
Crestron RoomView®
Every Ethernet-enabled 2-Series control system works directly with Crestron's exclusive RoomView Help Desk software for the industry's most comprehensive facility-wide asset management solution.
SNMP
Built-in SNMP support enables network management of Crestron control systems using third-party SNMP software. As an alternative or supplement to RoomView, SNMP allows full control and monitoring from the IT Help Desk or NOC in a format that is familiar to IT personnel.
SSL
All Ethernet-enabled 2-Series control systems support SSL (Secure Sockets Layer), the industry standard for protecting sensitive network communications.
IR Wireless Option
When equipped with an optional CNXRMIRD IR receiver, the MC2E provides a low-cost wireless control solution using any of Crestron’s IR wireless touchpanels or a third-party universal IR remote.
2 • 2-Series Compact Control System: MC2E |
Operations Guide – DOC. 6142A |
Crestron MC2E |
2-Series Compact Control System |
Specifications
Specifications for the MC2E are listed in the following table.
MC2E Specifications
|
SPECIFICATION |
|
DETAILS |
||
|
|
|
|
|
|
|
Processor |
|
|
|
|
|
CPU |
|
32-bit Freescale Coldfire Microprocessor |
||
|
Memory |
|
|
|
|
|
SDRAM |
|
|
32 MB |
|
|
|
|
|
||
|
NVRAM |
|
|
256 kB |
|
|
Flash |
|
|
4 MB |
|
|
Operating System |
|
Real-time preemptive multi- |
||
|
|
|
|
threaded/multitasking kernel; FAT32 file |
|
|
|
|
|
system with long names; supports SIMPL™ |
|
|
|
|
|
Windows® and SIMPL+ |
|
|
Ethernet |
|
|
10/100BaseT, auto-negotiating, full/half |
|
|
|
|
|
duplex, static IP or DHCP/DNS, SSL, |
|
|
|
|
|
TCP/IP, UDP/IP, CIP, SMTP, SNMP, built- |
|
|
|
|
|
in Web server and e-mail client; supports |
|
|
|
|
|
Crestron e-Control 2 Xpanel and |
|
|
|
|
|
RoomView applications |
|
|
Power Requirements |
|
12 Watts (0.5 Amp) @ 24 Volts DC |
||
|
|
|
|
(PW-2410RU power supply included) |
|
|
Available Cresnet Power |
|
13 Watts using PW-2410RU (included) or |
||
|
|
|
|
38 Watts using PW-2420RU (sold |
|
|
|
|
|
separately) |
|
|
Cresnet Power Usage |
|
12 Watts (0.5 Amp @ 24 Volts DC) with no |
||
|
|
|
|
power supply connected to the 24VDC |
|
|
|
|
|
connector |
|
|
Environmental |
|
|
|
|
|
Temperature |
|
|
41º to 113ºF (5º to 45ºC) |
|
|
Humidity |
|
|
10% to 90% RH (non-condensing) |
|
|
Enclosure |
|
|
|
|
|
Chassis |
|
Steel, black matte powder coat finish |
||
|
Faceplate |
|
Extruded aluminum, black matte powder |
||
|
|
|
|
coat finish with polycarbonate label overlay |
|
|
Mounting |
|
Freestanding or 1U 19 inch rack mountable |
||
|
|
|
|
(adhesive feet and rack ears included) |
|
|
Dimensions |
|
|
|
|
|
Height |
|
|
1.70 in (4.32 cm) without feet; |
|
|
|
|
|
1.80 in (4.58 cm) with feet |
|
|
Width |
|
|
17.03 in (43.25 cm) without ears; |
|
|
|
|
|
19.00 in (48.26 cm) with ears |
|
|
Depth |
|
|
8.50 in (21.59 cm) |
|
|
Weight |
|
4.3 lbs (2.0 kg) |
||
|
|
|
|
|
|
|
Included Accessories |
|
|
|
|
|
PW-2410RU |
|
|
25 Watt Regulated Universal Power Supply |
|
(Continued on following page)
Operations Guide – DOC. 6142A |
2-Series Compact Control System: MC2E • 3 |
2-Series Compact Control System |
Crestron MC2E |
||
|
MC2E Specifications (Continued) |
|
|
|
|
|
|
|
SPECIFICATION |
DETAILS |
|
|
|
|
|
|
Available Accessories |
|
|
|
PW-2420RU |
50 Watt Regulated Universal Power Supply |
|
|
C2N-HBLOCK |
Cresnet Network Distribution Block |
|
|
CNSP-XX |
Custom Serial Interface Cable |
|
|
IRP2 |
IR Probe |
|
|
CNXRMIRD |
IR Receiver |
|
|
|
|
|
Physical Description
This section provides information on the connections, controls and indicators available on your MC2E.
MC2E Physical View (Front)
MC2E Physical View (Rear)
4 • 2-Series Compact Control System: MC2E |
Operations Guide – DOC. 6142A |
Crestron MC2E |
2-Series Compact Control System |
MC2E Overall Dimensions
1 2 3 4 5
19.00 in
(48.26 cm)
1.70 in
(4.32 cm)
17.03 in
(43.25 cm)
8.50 in
(21.59 cm)
|
6 |
7 |
8 |
9 |
10 |
11 |
12 |
13 |
14 |
Connectors, Controls & Indicators |
|
|
|
|
|
|
|
|
|
# |
CONNECTORS1, |
|
|
|
|
DESCRIPTION |
|
|
|
|
CONTROLS & INDICATORS |
|
|
|
|
|
|
|
|
1 |
PWR LED |
Indicates 24 Volts DC power supplied from Cresnet control network |
|||||||
|
|
or external power supply. |
|
|
|
|
|||
2 |
NET LED |
Indicates communication with Cresnet System. |
|
||||||
3 |
RESET BUTTONS |
HW-R - Initiates system hardware reset. |
|
|
|||||
|
|
SR-R - Pressing this in combination with HW-R button performs a |
|||||||
|
|
system restart without loading the program. Pressing it alone while |
|||||||
|
|
the system is running restarts the program. |
|
|
|||||
4 |
MSG LED2 |
Illuminates when a message is present in the message log. To view |
|||||||
|
|
the contents of the message log, use Crestron Toolbox™. |
|||||||
5 |
LAN LEDs |
LNK – Indicates when there is a connection to the rear panel LAN |
|||||||
|
|
port. |
|
|
|
|
|
|
|
|
|
ACT – Indicates communication (activity) at the rear panel LAN port. |
|||||||
(Continued on following page) |
|
|
|
|
|
|
|
|
|
Operations Guide – DOC. 6142A |
2-Series Compact Control System: MC2E • 5 |
2-Series Compact Control System |
Crestron MC2E |
||||
Connectors, Controls & Indicators (Continued) |
|
|
|||
|
|
|
|
|
|
# |
CONNECTORS1, |
|
DESCRIPTION |
||
|
|
CONTROLS & INDICATORS |
|
|
|
6 |
INFRARED-SERIAL |
(4) 2-pin 3.5 mm detachable terminal blocks IR/Serial output ports; |
|
OUTPUT (A – D)3, 4 |
IR output up to 1.2 MHz; |
|
A B C D |
1-way serial TTL/RS-232 (0-5 Volts) up to 115.2k baud; |
|
|
Individual signal generator per port, allowing simultaneous firing of |
|
S G S G S G S G |
all ports. |
|
IR SERIAL OUT |
|
|
7 |
|
|
|
|
|
|
|
|
IR IN |
|
|
|
|
|
|
(1) 3-pin 3.5 mm detachable terminal block; |
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
For connection of the CNXRMIRD IR Receiver (sold separately); |
|
||
|
|
|
|
|
|
|
|
|
|
T R S |
|
|
|
|
|
|
Allows IR wireless control from Crestron or third-party universal |
|
||||||
|
|
|
|
|
|
|
|
|
|
IR IN |
|
|
|
|
|
|
remotes using RC-5 IR commands. |
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
8 |
|
|
|
|
I/O (1 – 4)5, 6 |
|
(1) 5-pin 3.5 mm detachable terminal block comprising (4) digital |
|
||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
input/output or analog input ports (referenced to GND); |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Digital Input: Rated for 0-24 Volts DC, input impedance 20 kΩ, logic |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
1 2 3 4 G |
|
|
|
|
|
|
threshold 1.24 Volts DC; |
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
I/O |
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Digital Output; 250 mA sync from maximum 24 Volts DC, catch |
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
diodes for use with “real world” loads; |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Analog Input: Rated for 0-10 Volts DC, protected to 24 Volts DC |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
maximum, input impedance 20 kΩ; |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Programmable 5 Volts, 2 kΩ pull-up resistor per pin. |
|
||
|
9 |
|
|
|
|
|
RELAY OUTPUT |
|
(1) 8-pin 3.5 mm detachable terminal block comprising (4) normally |
|
||||||||||||||
|
|
|
|
|
|
|
|
|
(1 – 4) |
|
|
|
|
|
|
open, isolated relays; |
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Rated 1 Amp, 30 Volts AC/DC, |
|
||
|
|
|
|
1 |
2 |
3 |
|
4 |
|
|
|
|
MOV arc suppression across contacts. |
|
||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||||
|
|
|
|
|
|
|
|
RELAY OUT |
|
|
|
|
|
|||||||||||
10 |
|
|
|
|
|
COM (A – B)7, 8, 9 |
|
(2) DB9 male, bidirectional RS-232/422/485 ports; |
|
|||||||||||||||
|
|
|
|
|
|
|
COM A |
|
|
|
|
|
|
|
COM B |
|
Up to 115.2k baud; |
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Hardware and software handshaking support; |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
All ports support C2N-NPA8 Network Poll Accelerator10. |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
PIN |
DIRECTION |
DESCRIPTION |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
1* |
To MC2E |
(RXD-) RS-422 Receive Data (Idles low) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
2 |
To MC2E |
(RXD) RS-232 Received Data |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
3 |
From MC2E |
(TXD) RS-232 Transmitted Data |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
4 |
From MC2E |
(TXD+) RS-422 Transmit Data (Idles high) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
5 |
Common |
RS-232 and RS-422 Signal Common |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
6 |
To MC2E |
(RXD+) RS-422 Receive Data (Idles high) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
7 |
From MC2E |
(RTS) RS-232 Request to Send |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
8 |
To MC2E |
(CTS) RS-232 Clear to Send |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
9 |
From MC2E |
(TXD-) RS-422 Transmit Data (Idles low) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
* RS-422 transmit and receive are balanced signals requiring two lines plus |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
a ground in each direction. RXD+ and TXD+ should idle high (going low at |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
start of data transmission). RXDand TXDshould idle low (going high at |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
start of data transmission). If necessary, RXD+/RXDand TXD+/TXDmay |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
be swapped to maintain correct signal levels. |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||
(Continued on following page) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||||
6 • 2-Series Compact Control System: MC2E |
Operations Guide – DOC. 6142A |
