Canon MF249DW, MF247DW, MF23BN User Manual

Getting Started

IMPORTANT

For Mac OS users, please refer to P.13

Mise en route

Introducción

Introdução

FT6-1695 (000)

IMPORTANT

IMPORTANTE

You can access http://canon.com/oip-manual to read the User’s Guide that describes all functions of this machine.

Si vous utilisez Mac OS, reportez-vous à la P.29

Para usuarios de Mac OS, consulte la pág.45

Para usuários de Mac OS, por favor consulte a pág.61

Installing the Machine

Installation Requirements

●

MF249dw

14 1/2

3 7/8

(99 mm)

4 1/4

(106 mm)

(128 mm)

1 3/4

(45 mm)

15 3/8"

(390 mm)

●

MF247dw

(128 mm)

1 1/2

(39 mm)

15 3/8

(390 mm)

(369 mm)

14 1/4

(362 mm)

12 1/8

(308 mm)

14 1/4

(360 mm)

10 5/8"

(270 mm)

14 1/4

(360 mm)

●

MF236n

1 1/2

15 3/8

(128 mm)

(39 mm)

(390 mm)

14 1/4

(362 mm)

10 5/8

(270 mm)

14 1/4

(360 mm)

Remove all the tape.

Installing the Machine

Contents

About the Manuals .......................................................................8

Navigating the Menu and Text Input Method ....................8

Connecting the Power Cord and Turning ON

the Power .........................................................................................8

Specifying the Initial Settings ...................................................9

Choosing the Method to Connect the Machine ................9

Choosing the Method to Connect:

Via Wireless LAN or Other Method ..........................................9

Connecting via a Wired LAN ................................................... 10

Connecting via a USB Cable ...................................................10

Table des matières

A propos des manuels ..............................................................24

Navigation dans le menu et méthode de saisie

du texte .......................................................................................... 24

Branchement du cordon d’alimentation et mise sous

tension............................................................................................ 24

Con guration des réglages initiaux ....................................25

Choix de la méthode de connexion de la machine .......25

Choix de la méthode de connexion de la machine:

Méthode via réseau sans  l ou autre ................................... 25

Connexion via un réseau  laire ............................................. 26

Connexion via un câbleUSB................................................... 26

Connecting via a Wireless LAN

(MF249dw/MF247dw Only) .................................................... 10

Setting Wireless LAN

(MF249dw/MF247dw Only) .................................................... 11

Setting a Paper Size and Type ................................................ 13

Specifying Initial Fax Settings and Connecting a

Telephone Cable ........................................................................ 13

Perform Useful Tasks ................................................................. 14

Clearing Paper Jams ..................................................................15

Replacing Toner Cartridge ...................................................... 16

* For Mac OS users, please refer to P.13

Connexion via un réseau sans  l

(MF249dw/MF247dw uniquement) ....................................26

Con guration du réseau sans  l

(MF249dw/MF247dw uniquement) ....................................27

Réglage du format et du type de papier............................ 29

Con guration des réglages de fax initiaux et

connexion d’un câble téléphonique ..................................29

Procédures utiles ........................................................................30

Résolution des bourrages papier .........................................31

Remplacement de la cartouche d’encre ............................32

* Si vous utilisez Mac OS, reportez-vous à la P.29

Contenido

Acerca de los manuales ............................................................ 40

Navegación por el menú y método de introducción

de texto .......................................................................................... 40

Conexión del cable de alimentación y encendido del

interruptor de alimentación ................................................... 40

Especi cación de la con guración inicial .......................... 41

Selección del método de conexión del equipo ............... 41

Selección del método de conexión: a través de red

LAN inalámbrica u otro método ........................................... 41

Conexión mediante una red LAN cableada ...................... 42

Conexión con un cable USB.................................................... 42

Índice

Sobre os manuais .......................................................................56

Navegação pelo menu e pelo método de entrada de

texto ................................................................................................ 56

Como conectar o cabo de alimentação e ligar a

máquina ......................................................................................... 56

Especi cação das con gurações iniciais ............................ 57

Escolha do método de conexão da máquina ................... 57

Escolher o Método para Conectar:

Através de LAN sem  o ou outro método .........................57

Conexão via LAN com  o ......................................................... 58

Conexão via cabo USB .............................................................. 58

Conexión mediante una red LAN inalámbrica

(MF249dw/MF247dw únicamente) ..................................... 42

Con guración de la red LAN inalámbrica

(MF249dw/MF247dw únicamente) ..................................... 43

Ajuste del tamaño y el tipo del papel ................................. 45

Especi cación de la con guración inicial de fax y

conexión del cable del teléfono ........................................... 45

Tareas útiles .................................................................................. 46

Eliminación de atascos de papel ..........................................47

Sustitución del cartucho de tóner ........................................ 48

* Para usuarios de Mac OS, consulte la pág.45

Conexão via LAN sem  o

(somente MF249dw/MF247dw) ............................................ 58

Con guração da LAN sem  o

(somente MF249dw/MF247dw) ............................................ 59

Con guração do tamanho e do tipo de papel ................ 61

Especi cação das con gurações iniciais do fax e

conexão do cabo telefônico .................................................. 61

Tarefas úteis .................................................................................. 62

Eliminação de obstruções de papel..................................... 63

Substituição do cartucho de toner ...................................... 64

* Para usuários de Mac OS, por favor consulte a pág.61

About the Manuals



Getting Started (This manual):

Read this manual  rst. This manual describes the installation of the machine, the settings, and a caution. Be sure to read this manual before using the machine.

Navigating the Menu and Text Input Method

Canon-1

ApplyA/a/12



MF Driver Installation Guide (Visit

the website):

This manual describes software installation.

You can access http://canon.com/oip-manual to read the User’s Guide that describes all functions of this machine.



User’s Guide (Visit the website):

You can access http://canon.com/oip-manual to read the User’s Guide that describes all functions of this machine.

<A/a/12>Back

◀▶

Navigating the Menu

Item selection

Tap an item to select it. Press

to return to the previous

screen.

Text Input Method

Changing entry mode

Tap <A/a/12> to change the entry mode. You can also press the entry mode.

Entry mode Available text

Uppercase alphabetic letters and

<A>

symbols Lowercase alphabetic letters and

<a>

symbols

<12> Numbers

Entering text, symbols, and numbers

Enter with the numeric keys or

Moving the cursor (Entering a space)

Tap <◀> or <▶> to move the cursor. To enter a space, move the cursor to the end of the text, and tap <▶>.

Deleting characters

Delete with

. Pressing and holding

deletes all characters.

to change

<Apply> #Clear Numeric keys

Setting con rmation

Tap the item. However, when <Apply> appears, tap <Apply>.

Entry mode:

(space) - . * # ! “ , ; : ^ ` _ = / | ‘

? $ @ % & + \ ˜ ( ) [ ] { } < >

Entry mode:

<A>

ABC abc 2

DEF def 3

GHI ghi 4

JKL jkl 5

MNO mno 6

PQRS pqrs 7

TUV tuv 8

WXYZ wxyz 9

(Not available) 0

<a>

@ . - _ / 1

Entry mode:

<12>

(Not available)

Connecting the Power Cord and Turning ON the Power

OFF

Do not connect the USB cable at this time. Connect it when installing software.

Specifying the Initial Settings

Follow the instructions on the screen, set the language, region, time zone, and date and time. For details on navigating the menu and how to input the numbers, see “Navigating the Menu and Text Input Method” ( P.8).

Language Chinese (Simplified) Chinese (Traditional)

English

French German

1/2

Current Time Set.

08/08 2014 10:00 AM

(0:00-12:59)

Apply

Choosing the Method to Connect the Machine

●

Connecting via a Wired LAN

You can connect the machine to a wired router. Use the LAN cables to connect the machine to the wired router (access point).

Connect the computer to the router by cable or wirelessly. Make sure that there is an available port in the router to connect

the machine and the computer.

Have a LAN Cable of Category 5 twisted-pair cable or higher ready.

●

Connecting via a USB cable

You can connect the machine to the computer using a USB cable.

Make sure that the USB cable you use has the following

mark.

Check if your router has a button

Select from the following two methods depending on the router (access point) that you are using.

●

There is a button. You can easily setup if your router (access point) has a button, and if the mark is on the router.

●

There is no button. If there is no button on your router (access point), manually select your SSID and complete the settings.

NOTE

• If you are looking to install your new device via a Wireless Network connection, you can  nd a video and written guides with step-by-step instruction to assist you through the process from the following URL: http://www.usa.canon.com/WirelessHelp Viewing these guides will ensure a smooth setup of the device into your existing wireless environment.

●

Direct Connection (MF249dw/MF247dw Only)

Connect a mobile device to the machine wirelessly and directly without routing through a wireless LAN router (or access point).

User’s Guide “Can Be Used Conveniently with a Mobile

Device” ▶ “Make Direct Connection (Access Point Mode)”

Choosing the Method to Connect: Via Wireless LAN or Other Method

●

MF249dw/MF247dw

Do you want to use the wireless LAN to connect to the network? The settings can be configured later.

Yes No

Current Time Set.

Must rechg. battery for 24 hours to save time settings. After turning main power

1/3

●

Connecting via a Wireless LAN (MF249dw/MF247dw Only)

You can connect the machine to a wireless router*. Since it is wirelessly connected, no LAN cables are needed.

* A wireless router (access point) that supports IEEE802.11b/g/n is

required.

Connect the computer to the router by cable or wirelessly.

There is a button.

Yes

●

MF236n

Current Time Set.

Must rechg. battery for 24 hours to save time settings. After turning main power

Start from step 4 of ”Push Button Mode” (P.11).

There is no button.

Start from step 4 of ”Setting the Access Point

Manually” (P.11).

Connect to the computer via a wired LAN

Proceed to “Connecting via a Wired LAN” (P.10).

Connect to the computer via a USB cable

Proceed to “Connecting via a USB Cable” (P.10).

Connect to the computer via a wireless LAN later

Proceed to “Connecting via a Wireless LAN

(MF249dw/MF247dw Only)” (P.10).

Connect to the computer via a wired LAN

Proceed to “Connecting via a Wired

1/3

LAN” (P.10).

Connect to the computer via a USB cable

Proceed to“Connecting via a USB

Cable” (P.10).

Connecting via a Wired LAN

Connecting via a USB Cable

Checking Before the Setup

Internet

Are the computer and the router (or hub) properly connected using a LAN cable?

For more information, see the instruction manual for the network device you are using, or contact the networking device manufacturer.

Have the network settings on the computer been completed?

If the computer is not properly con gured, you may not be able to use the wired LAN connection even after completing the following settings.

NOTE

• You cannot connect both the wired LAN and wireless LAN at the same time. In addition, the machine is set to the “Wired LAN” by default.

• When you connect to a network environment that is not security protected, your personal information could be disclosed to third parties. Please use caution.

• If you connect through a LAN in the o ce, contact your network administrator.

Router

hub

LAN cable

Install the Driver and Software

Install the driver and software on the provided DVD-ROM.

See “For details on the installation procedures:” (P.13).

Proceed to “Setting a Paper Size and Type” (P.13).

NOTE

• If you connected the USB cable before installing,  rst remove the USB cable and then re-install.

Connecting via a USB Cable

Follow the MF Driver Installation Guide to connect the USB cable.

Connecting via a Wired LAN

Connect the LAN cable.

The IP address will be automatically con gured in 2 minutes. If you want to set the IP address manually, see the following items.

User’s Guide “Network” ▶ “Connecting to a Network” ▶

“Setting IP Addresses”

Install the driver and software using the provided

DVD-ROM.

See “For details on the installation procedures:” (P.13).

Proceed to “Setting a Paper Size and Type” (P.13).

Connecting via a Wireless LAN (MF249dw/MF247dw Only)

Checking Before the Setup

Wireless LAN Router

Internet

Is the computer connected to the router (access point) correctly by a LAN cable or wireless LAN?

For more information, see the instruction manual for the network device you are using, or contact the networking device manufacturer.

Have the network settings on the computer been completed?

If the computer is not properly con gured, you may not be able to use the wireless LAN connection even after completing the following settings.

NOTE

• You cannot connect both the wired LAN and wireless LAN at the same time. In addition, the machine is set to the “Wired LAN” by default.

• When you connect to an unsecured network environment, your personal information could be disclosed to third parties. Please use caution.

• If you connect through a LAN in the o ce, contact your network administrator.

Checking the Router

Select the connection method to the wireless LAN. Select from the following two methods depending on the router (access point) that you are using.

●

There is a button.

This machine supports WPS (Wi-Fi Protected Setup). You can easily set up if your router (access point) has a button, and if the mark is on the router.

If you are not sure whether or not your router supports WPS,

please see the manual included in the product, or contact the product manufacturer.

●

There is no button.

If there is no button on your router (access point), you may manually select SSID and complete the settings. In this case, you need to remember SSID and network key of your router (access point). See “1 Check SSID or Network Key for a Wireless LAN Router/Access Point.” (P.11) to learn how to  nd out your SSID and network key.

To set up with the WPS PIN code method/To set up manually:

User’s Guide “Connecting to a Wireless LAN”

Setting Wireless LAN (MF249dw/MF247dw Only)

Push Button Mode

Tap <Menu> in the Home Screen.

Tap <Network Settings>.

Tap <Wireless LAN Settings>.

If a screen appears asking whether to enable the wireless LAN, tap <Yes>.

Tap <WPS Push Button Mode>.

Wireless LAN Settings SSID Settings

WPS Push Button Mode

WPS PIN Code Mode Power Save Mode Wireless LAN Information

Tap <Yes>.

Press and hold* the button until the lamp lights or

blinks.

You should press the WPS button within 2 minutes after you tap <Yes> in step 6.

* The time that you should hold the button may vary depending

on the router you are using.

Wait approximately 2 minutes after the connection.

IP address is set during this period of time.

When an error message appears:

Tap <Close> to close the screen, check whether or not the network key is correct, and then retry the settings. If the access point cannot be detected even after retrying, see the following.

User’s Guide “When an Error Message Appears”

When checking the network connection:

You can check if the machine is properly connected to the network by using a computer that is connected to the network.

User’s Guide “Viewing Network Settings”

To set IP address manually:

User’s Guide “Connecting to a Wireless LAN”

Setting the Access Point Manually

Check SSID or Network Key for a Wireless LAN

Router/Access Point.

• Check the label on the Wireless LAN router.

• You can check the SSID or the network key using “Canon

MF / LBP Wireless Setup Assistant,” which is included in the DVD-ROM supplied with the machine.

Read the message that is displayed, and tap <OK>.

SampleABCD WEP 01234567890123456789ABCDEF SampleEFGHIJ WPA-PSK 543210EDCBA SampleK WPA2-PSK 1234ABCD

If the information of the wireless LAN router is not displayed, click the [Refresh] button. If the information is not displayed when you click the [Refresh] button, check if the computer settings for a wireless LAN router (access point) are complete.

Tap <Wireless LAN Settings>.

If a screen appears asking whether to enable the wireless LAN, tap <Yes>.

Read the message that is displayed, and tap <OK>.

Tap <SSID Settings>.

Tap <Select Access Point>.

SSID Settings

Select Access Point

Enter Manually

Select a wireless LAN router.

If multiple matched SSIDs are displayed, select the ID that is listed  rst (the one with the strongest signal).

Enter the network key that you have written

down.

Enter the network key using the numeric keys, and tap <Apply>.

WEP Key (5-26 Char.)

XXXXXXX

ApplyA/a/12

Write down the name of SSID and network key

displayed in step 1. When multiple access points are displayed, write all SSIDs that are displayed.

SSID

It is sometimes written as name of network, or name of access point. If there are multiple SSIDs, please write down all.

Network Key

It is sometimes written as PIN, WEP key, WPA/WPA2 passphrase, PSK or preshared key.

Tap <Menu> in the Home Screen.

Tap <Network Settings>.

Tap <Yes>.

After the <Connected.> screen is displayed, wait

until the Wi-Fi indicator stops blinking and turns on.

Wait approximately 2 minutes after the

connection.

IP address is set during this period of time.

When an error message appears:

Tap <Close> to close the screen, check whether or not the network key is correct, and then retry the settings.

If the access point cannot be detected even after retrying, see the following.

User’s Guide “When an Error Message Appears”

To set IP address manually:

User’s Guide “Connecting to a Wireless LAN”

Setting a Paper Size and Type

Following the instructions on the screen, set the paper size and type.

For details on the installation procedures:

Install the driver and software using the provided DVDROM.

Home

Paper Set.

Paper Save

Home Set.

Scan PC1

2/4

Paper Settings MP Tray Drawer 1 Select Frequently Used Pape...

Specifying Initial Fax Settings and Connecting a Telephone Cable

Specify the initial fax settings.

Home

Copy

Scan

Follow the “Fax Setup Guide” to specify a fax number, a unit name, and a receive mode. For more details on the receive mode, see the User’s Guide.

User’s Guide “Faxing” ▶ “Con guring Initial Settings for Fax

Functions” ▶ “Deciding Which Fax Receive Mode to Use”

How to use a user name

When you send a document, the sender information that you registered is printed on the recipient’s paper.

Fax

Addr. Book

1/4

Perform Fax Setup?

Set Up Now

Set Up Later

You can also download the driver from the Canon website.

For details on the installation procedures, see the MF Driver Installation Guide.

For Mac OS users:

The DVD-ROM supplied with this machine may not include the printer driver for Mac OS. This is di erent depending on when you purchase the machine. Please  nd and download the appropriate driver on our Canon homepage. For further information on installation or using the driver, see the manual for the driver.

Connect a telephone cable.

Telephone line connector

Telephone

When <Connect Telephone Line> appears on the display, connect the telephone cable by referring to the illustration.

Exit the Fax Setup Guide, and then restart the

machine.

Do you want to end Fax Setup Guide?

Yes No

Turn OFF the machine and wait for at least 10 seconds before turning it ON again. The telephone line types are not detected automatically. See the User’s Guide and set a telephone line manually.

User’s Guide “Setting Menu List” ▶ “Fax Settings” ▶

“Basic Settings” ▶ “Select Line Type”

Perform Useful Tasks

You can use various functions in this machine. Following functions are the overview of the main functions that you can use routinely.

Copy

Enlarged/Reduced Copies

You can enlarge or reduce standard size documents to copy on standard size paper or specify the copy ratio in percentage.

2-Sided Copying*

You can copy 1-sided documents on both sides of paper.

Collating

You can sort copies into sets arranged in page order.

Reduced Layout

You can reduce the amount of paper by printing multiple documents onto one sheet.

2 on 1 4 on 1

Copying ID Card

You can make a copy of a 2-sided card onto one side of paper.

Receiving

●

Receiving in the memory You can store the received documents in the memory. You can print the stored documents at any time, and if you do not need them, you can delete them.

●

Remote Receiving If an external telephone is connected, you can switch to the fax receiving mode immediately by dialing the ID number for fax receiving using the dial buttons of the telephone during a phone call.

Enlarged/Reduced Printing

2-Sided Printing*

Reduced Layout

You can reduce the amount of paper by printing multiple documents onto one sheet.

Scan

Saving the Documents Using the Operation Panel of the Machine

Documents

Data

Saving the Documents Using Operations from a Computer

●

Scanning with the MF Scan Utility

Documents

Data

●

Scanning from an Application

●

Scanning with the WIA Driver

E-mailing Scanned Documents

You can send scanned documents to your e-mail application.

Documents Data E-mail

Fax

Sending a Document Directly from a Computer (PC Fax)

In addition to the normal sending and receiving faxes, you can use the PC fax.

Sending

You can register fax destinations in the address book. You can specify the destinations using various methods, enabling you to send documents quickly and easily.

• Destination search

• One-touch buttons

• Coded dialing

• Destination Group

• Specifying from the sending history

• Sequential broadcast

2 on 1 4 on 1

Booklet Printing*

Poster Printing

Watermark Printing

Displaying a Preview before Printing

Selecting a “Pro le”

Network Settings

This machine comes equipped with a network interface that you can construct a network environment easily. You can print a document, use the PC fax, and use the network scan from all computers which are connected with the machine. The machine supports to increase work e ciency as a shared machine in the o ce.

Sending Scanned Documents to a File Server

You can send scanned documents to a  le server.

Documents Data File server

Remote UI

You can understand the condition of the machine from the computers on the network. You can access the machine and manage jobs or specify various settings via network.

* MF249dw/MF247dw Only

Clearing Paper Jams

If the following screen appears, a paper jam has occurred in the feeder or inside the machine. Follow the procedure displayed on the screen to remove the jammed document or paper. This manual indicates only areas where paper jams occur. For details on each function, see the User’s Guide.

Paper jammed. Press [Next] to display the steps.

Previous Next

Feeder

●

MF249dw

MF247dw/MF236n

Inside the machine Manual Feed Slot

Paper drawer

Rear cover

(MF249dw/MF247dw only)

Replacing Toner Cartridge

Toner cartridges are consumables. When the toner becomes nearly empty or has run out completely in the middle of a job run, a message appears on the screen, or the following problems may occur. Take the appropriate action accordingly.

When a Message Appears

When the toner becomes nearly empty in the middle of a job run, a message appears on the screen.

Message

When white streaks appear on the output, or the output is partially faded:

When white streaks appear on the output or the output is partially faded, the toner cartridge has almost reached the end of its life, even if no message appears on the screen. When the print quality becomes unacceptable, see the following to  x the problem.

When the message is

displayed on the screen

When the toner cartridge needs a replacement soon.

When the toner cartridge has reached the end of its life.

Description and Solutions

Shake the toner cartridge to evenly distribute the toner inside the cartridge.

User’s Guide “Before Replacing the Toner Cartridge”

We recommend that the toner cartridge be replaced before printing highvolume documents.

User’s Guide “How to Replace Toner Cartridges”

If this message does not disappear, replace the toner cartridge. You can continue printing, but the print quality cannot be guaranteed.

User’s Guide “Replacing Toner Cartridges”

When White Streaks Appear on the Output or the Output Is Partially Faded

When the toner nearly runs out, white streaks appear on the output, or the output is partially faded.

No message appears on the screen, if the toner nearly runs out. Replace the toner cartridge when white streaks appear on the output, or the output is partially faded.

When this problem occurs:

Follow the steps in the procedure below before replacing the toner cartridge. The machine continues printing until the toner runs out

completely.

User’s Guide “Before Replacing the Toner Cartridge”

When the print quality is still unacceptable:

If the problem persists after you have followed the steps in the procedure below, replace the toner cartridge.

User’s Guide “How to Replace Toner Cartridges”

Appendix

Important Safety Instructions

This chapter describes important safety instructions for the prevention of injury to users of this machine and others, and damage to propert y. Read this chapter bef ore using the machine, and follow the instructions to use the machine properly. Do not perf orm any operations not described in this manual. Canon will not be responsible for any damages resulting from operations not described in this manual, improper use, or repair or changes not perf ormed by Canon or a third part y authorized by Canon. Improper operation or use of this machine could result in personal injury and/or damage requiring extensive repair that may not be covered un der your Limited Warranty.

WARNING

Indicates a warning concerning operations that may lead to death or injury to persons if not performed correctly. To use the machine safely, always pay attention to these warnings.

CAUTION

Indicates a caution concerning operations that may lead to injury to persons if not performed correctly. To use the machine safely, always pay attention to these cautions.

IMPORTAN

Indicates operational requirements and restrictions. Be sure to read these items carefully to operate the machine correctly and avoid damage to the machine or property.

Installation

To use this machine safely and in a trouble-free way, carefully read the following precautions and install the machine in an appropriate location.

WARNING

Do not install in a location that may result in a  re or electrical shock

•

A location where the ventilation slots are blocked (too close to walls, beds, sofas, rugs, or similar objects)

•

A damp or dusty location

•

A location exposed to direct sunlight or outdoors

•

A location subject to high temperatures

•

A location exposed to open  ames

•

Near alcohol, paint thinners or other  ammable substances

Other warnings

•

Do not connect unapproved cables to this machine. Doing so may result in a  re or electrical shock.

•

Do not place necklaces and other metal objects or containers  lled with liquid on the machine. If foreign substances come in contact with electrical parts inside the machine, it may result in a  re or electrical shock.

•

If any foreign substance falls into this machine, unplug the power plug f rom the AC power outlet and contact your local authorized Canon dealer.

Do not install in the following locations

The machine may drop or fall, resulting in injur y.

•

An unstable location

•

A location exposed to vibrations

CAUTION

Do not install in the following locations

Doing so may result in damage to the machine.

•

A location subject to temperature and humidity extremes, whether low or high

•

A location subject to dramatic changes in temperature or humidity

•

A location near equipment that generates magnetic or electromagnetic waves

•

A laboratory or location where chemical reactions occur

•

A location exposed to corrosive or toxic gases

•

A location that may warp from the weight of the machine or where the machine is liable to sink (a carpet, etc.)

Avoid poorly ventilated locations

This machine generates a slight amount of ozone and other emissions during normal use. These emissions are not harmful to health. However, they may be noticeable during extended use or long production runs in poorly ventilated rooms. To maintain a comfortable working environment, it is recommended that the room where the machine operates be appropriately ventilated. Also avoid locations where people would be exposed to emissions from the machine.

Do not install in a location where condensation occurs

Water droplets (condensation) may form inside the machine when the room where the machine is installed is heated rapidly, and when the machine is moved from a cool or dry location to a hot or humid location. Using the machine under these conditions may result in paper jams, poor print quality, or damage to the machine. Let the machine adjust to the ambient temperature and humidity for at least 2 hours before use.

In altitudes of above sea level 3,0 00 m or higher

Machines with a hard disk may not operate properly when used at high altitudes of about 3,000 meters above sea level, or higher.

Leveling feet (only for produc ts with leveling feet)

Do not remove the machine’s leveling feet af ter the machine has been installed, as this may cause the machine to fall or tip over, resulting in personal injury.

Connecting the Telephone Line (Only for Products with a Fax Function)

This machine conforms to a analog telephone line standard. The machine can be connected to the public switched telephone network (PSTN) only. If you connect the machine to a digital telephone line or a dedicated telephone line, it might impede proper operation of the machine and could be the cause of damage. Make sure to con rm a t ype of telephone line before connecting the machine. Contact your optical  ber line or IP telephone line service providers if you want to connect the machine to those telephone lines.

When using wireless LAN (only for products with a wireless LAN function)

•

Install the machine at a distance of 50 meters or less from the wireless LAN router.

•

As far as possible, install in a location where communication is not blocked by intervening objects. The signal may be degraded when passing through walls or  oors.

•

Keep the machine as far as possible from digital cordless phones, microwave ovens, or other equipment that emits radio waves.

•

Do not use near medical equipment. Radio waves emitted from this machine may interfere with medical equipment, which may result in malfunctions and accidents.

Power Supply

WARNING

•

Use only a power supply that meets the speci ed voltage requirements. Failure to do so may result in a  re or electrical shock.

•

Do not use power cords other than the one provided, as this may result in a  re or electrical shock.

•

The provided power cord is intended for use with this machine. Do not connect the power cord to other devices.

•

Do not modify, pull, forcibly bend, or perform any other act that may damage the power cord. Do not place heavy objects on the power cord. Damaging the power cord may result in a  re or electrical shock.

•

Do not plug in or unplug the power plug with wet hands, as this may result in an electrical shock.

•

Do not use extension cords or multi-plug power strips with the machine. Doing so may result in a  re or electrical shock.

•

Do not wrap the power cord or tie it in a knot, as this may result in a  re or electrical shock.

•

Insert the power plug completely into the AC power outlet. Failure to do so may result in a  re or electrical shock.

•

Remove the power plug completely from the AC power outlet during a thunder storm. Failure to do so may result in a  re, electrical shock, or damage to the machine.

•

Make sure that the power supply for the machine is safe, and has a steady voltage.

•

Keep the power cord away from a heat source; failure to do this may cause the power cord coating to melt, resulting in a  re or electrical shock.

•

If excessive stress is applied to the connection part of the power cord, it may damage the power cord or the wires inside the machine may disconnect. This could result in a  re. Avoid the following situations:

– Connecting and disconnecting the power cord

frequently. – Tripping over the power cord. – The power cord is bent near the connection

part, and continuous stress is being applied to

the power outlet or the connection part. – Applying excessive force on the power plug.

CAUTION

Install this machine near the power outlet and leave su cient space around the power plug so that it can be unplugged easily in an emergency.

IMPORTAN

When connecting power

•

Do not connect the power cord to an uninterruptible power source. Doing so may result in malfunction of or damage to the machine at power failure.

•

If you plug this machine into an AC power outlet with multiple sockets, do not use the remaining sockets to connect other devices.

•

Do not connect the power cord to the auxiliary AC power outlet on a computer.

Other precautions

Electrical noise may cause this machine to malfunction or lose data.

Handling

WARNING

•

Immediately unplug the power plug from the AC power outlet and contact an authorized Canon dealer if the machine makes an unusual noise, emits an unusual smell, or emits smoke or excessive heat. Continued use may result in a  re or electrical shock.

•

Do not disassemble or modify this machine. There are high-voltage and high-temperature components inside the machine. Disassembly or modi cation may result in a  re or electrical shock.

•

Place the machine where children will not come in contact with the power cord and other cables or gears and electrical parts inside the machine. Failure to do so may result in unexpected accidents.

•

Do not use  ammable sprays near this machine. If  ammable substances come into contact with electrical parts inside this machine, it may result in a  re or electrical shock.

•

When moving this machine, be sure to turn OFF the power of this machine, and then unplug the power plug and interface cables. Failure to do so may damage the power cord or interface cables, resulting in a  re or electrical shock.

•

When plugging or unplugging a USB cable when the power plug is plugged into an AC power outlet, do not touch the metal part of the connector, as this may result in an electrical shock.

•

Use a modular cable that is shorter than 3 meters.

•

Use a USB cable that is shorter than 3 meters.

If the operating noise concerns you

Depending on the use environment and operating mode, if the operating noise is of concern, it is recommended that the machine be Installed in a place other than the o ce.

If you are using a cardiac pacemaker

This machine generates a low level magnetic  ux. If you use a cardiac pacemaker and feel abnormalities, please move away from this machine and consult your physician immediately.

CAUTION

•

Do not place heavy objects on this machine as they may fall, resulting in injury.

•

For safety, unplug the power plug if the machine will not be used for a long period of time.

•

Use caution when opening and closing covers to avoid injury to your hands.

•

Keep hands and clothing away from the rollers in the output area. If the rollers catch your hands or clothing, this may result in personal injury.

•

The inside of the machine and the output slot are very hot during and immediately after use. Avoid contact with these areas to prevent burns. Also, printed paper may be hot immediately after being output, so use caution when handling it. Failure to do so may result in burns.

Feeder (only for products with a feeder)

•

Do not press down hard on the feeder when using the platen glass to make copies of thick books. Doing so may damage the platen glass and result in personal injury.

•

Close the feeder gently to avoid catching your hands, as this may result in personal injury.

•

Close the feeder gently to avoid catching your hands in the back of the feeder, as this may result in personal injury.

Finisher (only for products with a  nisher)

•

Do not place your hands in the part of the tray where stapling is performed (near the rollers), especially pay careful attention to the sharp staples, as this may result in personal injury.

Paper drawer (only for products with a paper drawer)

•

Do not insert your hand into the machine

while the paper drawer is removed, as this may result in personal injury.

Energy Saver key (only for products with an Energy Saver key)

•

Press (Energy Saver) for safety when the machine will not be used for a long period of time, such as overnight. Also, turn OFF the main power switch, and disconnect the power cord for safety when the machine will not be used for an extended period of time, such as during consecutive holidays.

Laser Safety

This product is con rmed as a Class 1 laser product in IEC60825-1:2007 and EN60825-1:2007.

CLASS 1 LASER PRODUCT LASER KLASSE 1 APPAREIL À LASER DE CLASSE 1 APPARECCHIO LASER DI CLASSE 1 PRODUCTO LÁSER DE CLASE 1 APARELHO A LASER DE CLASSE 1 LUOKAN 1 LASER-TUOTE LASERPRODUKT KLASS 1

The laser beam can be harmful to human bodies. Since radiation emitted inside the product is completely con ned within protective housings and external covers, the laser beam cannot escape from the machine during any phase of user operation. Read the following remarks and instructions for safety.

•

Never open covers other than those instructed in the manuals for this machine.

•

If the laser beam should escape and enter your eyes, exposure may cause damage to your eyes.

CAUTION

Use of controls, adjustments, or performance of procedures other than those speci ed in this manual may result in hazardous radiation exposure

Other precautions

•

Follow the instructions on the caution label attached to this machine.

•

Do not subject the machine to strong shocks or vibration.

•

Do not forcibly open and close doors, covers, and other parts. Doing so may result in damage to the machine.

•

Do not turn the main power switch OFF or open the covers while the machine is in operation. This may result in paper jams.

Maintenance and Inspections

Clean this machine periodically. If dust accumulates, the machine may not operate properly. When cleaning, be sure to observe the following. If a problem occurs during operation, see Troubleshooting. If the problem cannot be resolved or you feel the machine requires an inspection, see When a Problem Cannot Be Solved.

WARNING

•

Before cleaning, turn OFF the power and unplug the power plug from the AC power outlet. Failure to do so may result in a  re or electrical shock.

•

Unplug the power plug periodically and clean with a dry cloth to remove dust and grime. Accumulated dust may absorb humidity in the air and may result in a  re if it comes into contact with electricity.

•

Use a damp, well wrung-out cloth to clean the machine. Dampen cleaning cloths with water only. Do not use alcohol, benzenes, paint thinners, or other  ammable substances. Do not use tissue paper or paper towels. If these substances come into contact with electrical

parts inside the machine, they may generate static electricity or result in a  re or electrical shock.

•

Check the power cord and plug periodically for rust, bent prongs, fraying, cracks, or excessive heat generation. Use of poorlymaintained power cord or plug may result in a  re or electrical shock.

CAUTION

•

The inside of the machine has hightemperature and high-voltage components. Touching these components may result in injury or burns. Do not touch any part of the machine that is not indicated in the manual.

•

When loading paper or removing jammed paper, be careful not to cut your hands with the edges of the paper.

Legal Limitations on the Usage of Your Product and the Use of Images

Using your produc t to scan, print or otherwise reproduce certain documents, and the use of such images as scanned, printed or otherwise reproduced by your product, may be prohibited by law and may result in criminal and/or civil liability. A non-exhaustive list of these documents is set forth below. This list is intended to be a guide only. If you are uncertain about the legality of using your product to scan, print or otherwise reproduce any particular document, and/or of the use of the images scanned, printed or otherwise reproduced, you should consult in advance with your legal advisor for guidance.

•

Paper Money

•

Travelers Checks

•

Money Orders

•

Food Stamps

•

Certi cates of Deposit

•

Passports

•

Postage Stamps (canceled or uncanceled)

•

Immigration Papers

•

Identifying Badges or Insignias

•

Internal Revenue Stamps (canceled or uncanceled)

•

Selective Service or Draft Papers

•

Bonds or Other Certi cates of Indebtedness

•

Checks or Drafts Issued by Governmental Agencies

•

Stock Certi cates

•

Motor Vehicle Licenses and Certi cates of Title

•

Copyrighted Works/Works of Art without Permission of Copyright Owner

Safety-Related Symbols

Power switch: “ON” position

Power switch: “OFF” position

Power switch: “STAND-BY” position

Push-push switch “ON” “OFF”

Protective earthing terminal

Dangerous voltage inside. Do not open covers other than instructed.

CAUTION: Hot surface. Do not touch.

Class II equipment

Moving parts: Keep body parts away from moving parts

[NOTE]

Some of symbols shown above may not be a xed depending on the product.

v1602 _00_ en- GB

Laser Safety Label

Consumables

WARNING

Do not dispose of used toner cartridges in open  ames. Also, do not store toner cartridges or paper in a location exposed to open  ames. This may cause the toner or paper to ignite, and result in burns or  re.

Telephone Equipment

WARNING

When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of  re, electric shock and injury to persons, including the following:

1. Do not use this product near water, for example, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet basement or near swimming pool.

2. Avoid using a telephone during an electrical storm. There may be remote risk of electric shock form lightning.

3. Do not use the telephone to report a gas leak in the vicinity of the leak.

Notice

Product Name

Safety regulations require the product’s name to be registered. In some regions where this product is sold, the following name(s) in parentheses () may be registered instead. imageCLASS MF249dw (F173702) imageCLASS MF247dw (F173702) imageCLASS MF236n (F171902)

FCC (Federal Communications Commission) Users in the U.S.A

Contains Transmitter Module FCC ID: TLZ-NM383

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC CAUTION

Changes or modi cations not expressly approved by the par ty responsible for compliance could void the user’s authority to operate the equipment.

[NOTE]

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures:

– Reorient or relocate the receiving antenna. – Increase the separation between the

equipment and receiver.

– Connect the equipment into an outlet on a

circuit di erent from that to which the receiver is connected.

– Consult the dealer or an experienced radio/TV

technician for help.

This transmit ter must not be co-located or operated in conjunction with any other antenna or transmitter. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines. This equipment should be installed and operated keeping the radiator at least 20cm or more away from person’s body. Use of shielded cable is required to comply with class B limits in Subpart B of Part 15 of FCC Rules. Do not make any changes or modi cations to the equipment unless otherwise speci ed in this manual. If you make such changes or modi cations, you could be required to stop operation of the equipment. CANON U.S.A., INC One Canon Park, Melville, NY 11747, U.S.A. TEL No. 1-800-OK-CANON

Regulator y Information for Users in Canada English This device complies with Industry

Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment and meets RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment should be installed and operated keeping the radiator at least 20cm or more away from person’s body. Français [ French ] Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. Cet équipement est conforme aux limites d’exposition aux rayonnements énoncées pour un environnement non contrôlé et respecte les règles d’exposition aux fréquences radioélectriques (RF) CNR-102 de l’IC. Cet équipement doit être installé et utilisé en gardant une distance de 20 cm ou plus entre le radiateur et le corps humain.

Regulator y Information for Users in Mexico

Módulo WLAN instalado adentro de este producto AW-NM383 RCPAZAW13-2287 AzureWave AW-N M383 La operación de este equipo está sujeta a las siguientes dos condiciones:

(1) es posible que este equipo o dispositivo no

cause interferencia perjudicial y

(2) este equipo o dispositivo debe aceptar

cualquier inter ferencia, incluyendo la que pueda causar su operación no deseada.

Regulator y information for users in Brazil

Este equipamento possui um módulo de radiação restrita homologado na Anatel sob o número 0070-14-1529.

MODELO: AW-NM383

0070-14-1529

(01) 07898581340850

Este equipamento opera em caráter secundário, isto é, não tem direito à proteção contra interferência prejudicial, mesmo de estações do mesmo tipo e não pode causar interferência a sistemas operando em caráter primário.

Disclaimers

•

The information in this document is subject to change without notice.

•

CANON INC. MAKES NO WARRANTY OF ANY KIND WITH REGARD TO THIS MATERIAL, EITHER EXPRESS OR IMPLIED, EXCEPT AS PROVIDED HEREIN, INCLUDING WITHOUT LIMITATION, THEREOF, WARRANTIES AS TO MARKETABILITY, MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OF USE OR NONINFRINGEMENT. CANON INC. SHALL NOT BE LIABLE FOR ANY DIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGES OF ANY NATURE, OR LOSSES OR EXPENSES RESULTING FROM THE USE OF THIS MATERIAL.

•

The following applies in California, USA only:

The battery included with your product

contains Perchlorate Material and may require special handling.

See http://www.dtsc.ca.gov/hazardouswaste/

perchlorate/ for details.

Users in the U.S.A.

Pre-Installation Requirements for Canon Facsimile Equipment

A. Location

Supply a suitable table, cabinet, or desk for the machine. See the User’s Guide for speci c dimensions and weight.

B. Order Information

1. A single telephone line (touch-tone or rotary) should be used.

2. Order an RJ11-C telephone wall jack (USOC), which should be installed by the telephone company. If the RJ11-C wall jack is not present, telephone/facsimile operation is not possible.

3. Order a normal business line from your telephone company’s business representative. The line should be a regular voice grade line or an equivalent one. Use one line per unit.

DDD (Direct Distance Dial) line

-orIDDD (International Direct Distance Dial) line if you communicate overseas

[NOTE]

Canon recommends an individual line following industry standards, i.e., 2,500 (touch-tone) or 500 (rotary/pulse dial) telephones. A dedicated extension o a PBX (Private Branch eXchange) unit without “Call Waiting” can be used with your facsimile unit. Key telephone systems are not recommended because they send nonstandard signals to individual telephones for ringing and

special codes, which may cause a facsimile error.

C. Power Requirements

The machine should be connec ted to a standard 120 volt AC, threewire grounded outlet only. Do not connect this machine to an outlet or power line shared with other appliances that cause “electrical noise.” Air conditioners, electric typewriters, copiers, and machines of this sort generate electrical noise that often interferes with communications equipment and the sending and receiving of documents.

Connection of the Equipment

This equipment complies with Part 68 of the FCC rules and the requirements adopted by the ACTA. On the rear panel of this equipment is a label that contains, among other information, a product identi er in the format US: AAAEQ##TXXXX. If requested, this number must be provided to the telephone company. The REN is used to determine the number of devices that may be connected to a telephone line. Excessive RENs on a telephone line may result in the devices not ringing in response to an incoming call. In most, but not all areas, the sum of RENs should not exceed  ve (5.0). To be certain of the number of devices that may be connected to a line, as determined by the total RENs, contact the local telephone company. For products approved after July 23, 2001, the REN for this product is part of the product identi er that has the format US: AAAEQ##TXXXX. The digits represented by ## are the REN without a decimal point (e.g., 03 is a REN of 0.3). An FCC compliant telephone line cable and modular plug is provided with this equipment. This equipment is designed to be connected to the telephone network or premise wiring using a compatible modular jack that is Part 68 compliant. This equipment may not be used on coin service provided by the telephone company. Connection to party lines is subjected to state tari s.

In Case of Equipment Malfunction

Should any malfunction occur which cannot be corrected by the procedures described in this guide or the User ’s Guide, disconnect the equipment from the telephone line cable and disconnect the power cord. The telephone line cable should not be reconnected or the power switch turned ON until the problem is completely resolved. Users should contac t Canon Authorized Ser vice Facilities for servicing of equipment, Information regarding Authorized Service Facility locations can be obtained by calling Canon Customer Care Center (1-800-OK-CANON).

Rights of the Telephone Company

If this equipment (imageCLASS MF249dw/ MF247dw/MF236n) causes harm to the telephone network, the telephone company may temporarily disconnect service. The telephone company also retains the right to make changes in facilities and services that may a ect the operation of this equipment. When such changes are necessary, the telephone company is required to give adequate prior notice to the user. However, if advance notice is not possible, the telephone company will notif y the customer as soon as possible. Also, the customer will be advised of his/her right to  le a complaint with the FCC if he/she believes it is necessary.

WARNING

The Telephone Consumer Protection Act of 1991

makes it unlawful for any person to use a computer or other electronic device, including FAX machines, to send any message unless such message clearly contains in a margin at the top or bottom of each transmitted page or on the  rst page of the transmission, the date and time it is sent and an identi cation of the business or other entity, or other individual sending the message and the telephone number of the sending machine or such business, other entity, or individual. (The telephone number provided may not be a 900 number or any other number for which charges exceed local or long-distance transmission charges.)

[NOTE]

In order to program this information into your machine, you should complete the procedure for registering your name, unit’s telephone number, time, and date in the Getting Started.

Users in Canada

Pre-Installation Requirements for Canon Facsimile Equipment

A. Location

Supply a suitable table, cabinet, or desk for the machine. See the User’s Guide for speci c dimensions and weight.

B. Order Information

1. A single telephone line (touch-tone or rotary) should be used.

2. Order a CA11A modular jack, which should be installed by the telephone company. If the CA11A jack is not present, installation cannot occur.

3. Order a normal business line from your telephone company’s business representative. The line should be a regular voice grade line or an equivalent one. Use one line per unit.

DDD (Direct Distance Dial) line

-orIDDD (International Direct Distance Dial) line if you communicate overseas

[NOTE]

C. Power Requirements

The power outlet should be a three-prong grounded receptacle (Single or Duplex). It should be independent from copiers, heaters, air conditioners, or any electric equipment that is thermostatically controlled. The rated value is 115 volts and 15 amperes. The CA11A modular jack should be relatively close to the power outlet to facilitate installation.

[Notice]

•

The REN of this product is 1.0.

•

Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company. The equipment must also be installed using an acceptable method of connection. In some cases, the company’s inside wiring associated with a single line individual service may be extended by means of a certi ed connector assembly (telephone extension cord). The customer should be aware that compliance with the

above conditions may not prevent deterioration of service in some situations.

•

Repairs to certi ed equipment should be made by an authorized Canadian maintenance facility designated by the supplier. Any repairs or alterations made by the user to this equipment, or equipment malfunctions, may give the telecommunications company cause to request the user to disconnect the equipment.

•

Users should ensure for their own protection that the electrical ground connections of the power utility, telephone lines, and internal metallic water pipe system, if present, are connected together. This precaution may be particularly important in rural areas.

CAUTION

Users should not attempt to make such connections themselves, but should contact the appropriate electric inspection authority, or electrician, as appropriate.

[NOTE]

This equipment complies with the Canadian ICES-003 Class B limits.

English This product meets the applicable Innovation, Science and Economic Development Canada technical speci cations. The Ringer Equivalence Number (REN) indicates the maximum number of devices allowed to be connected to a telephone interface. The termination of an interface may consist of any combination of devices subject only to the requirement that the sum of the RENs of all the devices not exceed  ve. Francais [ French ] Le present produit est conforme aux speci cations techniques applicables d’Innovation, Sciences et Developpement economique Canada. L’indice d’equivalence de la sonnerie (IES) sert a indiquer le nombre maximal de dispositifs qui peuvent etre raccordes a une interface telephonique. La terminaison d’une interface peut consister en une combinaison quelconque de dispositifs, a la seule condition que la somme des IES de tous les dispositifs n’excede pas cinq.

About This Manual

Keys and Buttons Used in This Manual

The following symbols and key names are a few examples of how keys to be pressed are expressed in this manual.

•

Operation panel keys: [Key icon] Example:

•

Display: <Specify destination.>

•

Buttons and items on the computer display: [Preferences]

Illustrations and Displays Used in This Manual

Illustrations and displays used in this manual are which of imageCLASS MF249dw unless speci ed.

Tra dem ark s

Mac is a trademark of Apple Inc. Microsoft, Windows, Windows Vista, Windows Server, Internet Explorer, Excel, and PowerPoint are either registered trademarks or trademarks of Microsoft Corporation in the United States and/ or other countries. Other product and company names herein may be the trademarks of their respective owners.

Third Party Software

This Canon product (the “PRODUCT”) includes third-par ty software modules. Use and distribution of these sof tware modules, including any updates of such software modules (collectively,the “SOFTWARE”) are subject to

license conditions below.

(1) You agree that you will comply with any

applicable export control laws, restrictions or regulations of the countries involved in the event that the PRODUCT including the SOFTWARE is shipped, transferred or exported into any country.

(2) Rights holders of the SOFT WARE retain in all

respects the title, ownership and intellectual property rights in and to the SOFTWARE. Except as expressly provided herein, no license or right, expressed or implied, is hereby conveyed or granted by rights holders of the SOFTWARE to you for any intellectual property of rights holders of the SOFTWARE.

(3) You may use the SOFTWARE solely for use

with the PRODUCT.

(4) You may not assign, sublicense, market,

distribute, or transfer the SOFTWARE to any third part y without prior writ ten consent of rights holders of the SOFTWARE.

(5) Notwithstanding the foregoing, you may

transfer the SOFTWARE only when (a) you assign to a transferee all of your rights to the PRODUCT and all rights and obligations under the conditions governing the SOFTWARE and PRODUCT and (b) such transferee agrees in writing to be bound by all these conditions.

(6) You may not decrypt, decompile, reverse

engineer, disassemble or otherwise reduce the code of the SOFTWARE to human readable form.

(7) You may not modify, adapt, translate, rent,

lease or loan the SOFTWARE or create derivative works based on the SOFTWARE.

(8) You are not entitled to remove or make

separate copies of the SOFT WARE from the PRODUCT.

(9) The human-readable portion (the source

code) of the SOFTWARE is not licensed to

you. Notwithstanding (1) through (9) above, the PRODUCT includes third-party software modules accompanying the other license conditions, and these software modules are subject to the other license conditions.Please refer to the other license conditions of third-party software modules described in Appendix of Manual for the corresponding the PRODUCT. This Manual is available at http://canon.com/oip-manual. By using the PRODUCT, you shall be deemed to have agreed to all applicable license conditions. If you do not agree to these license conditions, please contac t your service representative.

ACCEPTANCE

THE TERMS OF THIS THIRD PARTY SOFTWARE STATED HERE OR IN RELATED WARRANTY PROVISIONS SHALL BE DEEMED ACCEPTED UPON YOUR USE OF THE PRODUCT FOR ONE OR MORE OF ITS NORMAL PURPOSES, IF THERE HAS BEEN NO OTHER PRIOR EXPRESS ACCEPTANCE. THE TERMS OF THIS THIRD PARTY SOFTWARE GOVERN THE THIRD PARTY SOFT WARE AS DELIVERED WITH THE PRODUCT AND ALL UPDATED VERSIONS OF THE THIRD PARTY SOFTWARE PROVIDED UNDER MAINTENANCE AGREEMENTS OR OTHER SERVICE ARRANGEMENTS FOR THE PRODUCT WITH CANON USA OR CANON CANADA OR THEIR RESPECTIVE AUTHORIZED SERVICE ORGANIZATIONS.

+ 50 hidden pages
