Congratulations on purchasing your Brother Fax machine.
Please set up your machine as follows — refer to the Owner’s Manual for further
information.
<Installation - Chapter 2>
1. Check the Packing List
2. Install the Drum Unit
3. Install the Phone Line and Power Cord
4. Attach Wire Extensions and Document/Paper Trays
5. Loading Paper
6. Connect External Telephone (Only if you are sharing one line for both telephone
and fax)
<Initial Setup - Chapter 4>
7. Set Date and Time
8. Set Station ID
<Setup Receive - Chapter 5>
9. Select an Answer mode
<Setting Up the Machine and Computer to Work Together - Chapter 12>
(For MFC-9060 Only)
This machine has been designed to be simple to use, with LCD screen
prompts to guide you through functions. However, you can use your
machine to its fullest potential by taking a few minutes to read this
manual.
Additionally, your machine has a Help Key. Press Help (FAX-8060P) or
Copy/Help (MFC-9060) to print a list of basic operational steps and
functions.
Finding Information
All chapter headings and subheadings are listed in the Table of Contents.
You will also be able to find information about a specific feature or
function by checking the Index at the back of this manual. Also,
throughout this manual, you’ll see special symbols alerting you to
important information, cross-references, and warnings. Illustrations of
some screen displays also help you choose the correct key-presses.
2
CHAPTER ONE
Symbols Used in This Manual
Note or additional information.
The machine may be damaged or may not work
correctly if this is not observed.
Warnings detail precautions you must take to avoid
possible personal injury.
About Fax Machines
If you’re a first-time fax machine user, fax operation may seem a little
mysterious. You’ll soon get used to the unusual fax tones on your phone
line, and be able to send and receive faxes easily .
Fax Tones and Handshake
When someone is sending a fax, the fax machine sends fax calling tones,
(CNG tones)—soft, intermittent beeps at 4-second intervals. You’ll hear
them when you dial and press Start, and they continue for about 40
seconds after dialling. During that time, the sending machine must begin
the “handshake” with the receiving machine. Each time you use
automatic procedures to send a fax, you are sending CNG tones over the
phone line. You’ll soon learn to listen for these soft beeps each time you
answer a phone on your fax line, so you can know if you are receiving a
fax message.
The receiving fax responds with fax receiving tones—loud, chirping
sounds. A receiving fax chirps for about 40 seconds over the phone line,
and the screen displays RECEIVE. If your fax machine is set to the Fax
Only Mode, it will answer every call automatically with fax receiving
tones. Even if the other party hangs up, your fax machine continues to
send the “chirps” for about 40 seconds, and the screen continues to
display RECEIVE. To cancel the receiving mode, press Stop.
INTRODUCTION
When your fax machine is in Fax/Tel (F/T) Mode, it answers with a
short beep. After this beep, the fax machine listens for CNG tones, and
then responds with receiving tones.
The fax “handshake” is the time in which the sending machine’s CNG
tones and the receiving machines “chirps” overlap. This must be for at
least 2 to 4 seconds, so the fax machines can understand how each is
sending and receiving the fax. The handshake cannot begin until the call
is answered, and the CNG tones only last for about 40 seconds after the
number is dialled. Therefore, it’s important for the receiving machine to
answer the call in as few rings as possible.
When you have an external telephone answering device (T AD) on your fax
line, your TAD will determine the number of rings before the call is
answered. Pay special attention to the directions in the Installation chapter
for connecting a TAD (or answering machine) to your fax machine.
ECM (Error Correction Mode)
3
The Error Correction Mode (ECM) is a way for the fax machine to check
the integrity of a fax transmission while it is in progress. ECM
transmissions are possible only between machines that both have the
ECM feature. If they do, you may send and receive fax messages that are
continuously checked for their integrity.
Sufficient memory must be available in your machine for this feature to
work.
4
CHAPTER ONE
F AX-8060P Contr ol Panel Overview
5432161151413
6
1
Liquid Crystal Display
Displays messages to help you set up
and operate your machine.
2
Menu
Lets you access the function and
programming mode.
3
Tel (Telephone)
This key is used to have a telephone
conversation having picked up the
external handset in F/T pseudo-ringing
etc.
4
Shift
This key is used to access the “9”
through “16” One Touch keys.
8
7
9101112
5
One Touch Dial Keys
These 8 keys give you access to 16
previously stored phone numbers.
6
R (Recall)
Use this key to gain access to an outside
line and/or to recall the operator or
transfer a call to another extension when
it is connected to a PABX.
7
Search/Speed Dial
Lets you look up numbers stored in the
dialling memory. Also, lets you dial
stored phone numbers by pressing # and
two-digit number.
INTRODUCTION
5
8
Redial/Pause
Re-dials the last number called. Also
inserts a pause in autodial numbers.
9
Dial Pad
Dials phone and fax numbers and can be
used as a keyboard for entering
information into the machine.
10
Fax Keys:
Mode
Select how the fax machine will handle
incoming calls.
Broadcast
Use this key when you want to send a
fax to several different locations
(maximum 96 locations at once).
Resolution
Sets the resolution when you send a fax.
11
Stop
Stops a fax, cancels an operation or
exits from function mode.
12
Start
Starts sending a fax.
13
Copy Keys:
Photo/Text
Lets you identify the type of document
you want to copy: a photograph or text.
Enlarge/Reduce
Lets you select an enlargement or
reduction ratio: 100%, 120%, 125%,
150%, 200%, 50%, 75%, 87%, 93%,
Selecting AUTO automatically reduces
the original to the selected paper size.
Copy
Makes a copy.
14
Help
Prints a quick reference Help List.
15
Set/Verify
Stores a function setting into the
machine. When the machine is idle, you
can also use this key to print the
Transmission Verification Report for
your last transmission.
16
(Left Arr ow)
(Right Arr ow)
Volume
Moves the LCD cursor to the left or
right in Function mode so you can make
selections. Also, adjusts speaker and
ring volume.
6
CHAPTER ONE
MFC-9060 Control P anel Overview
5432161151413
6
1
Liquid Crystal Display
Displays messages to help you set up
and operate your machine.
2
Menu
Lets you access the function and
programming mode.
3
Tel (Telephone)
This key is used to have a telephone
conversation having picked up the
external handset in F/T pseudo-ringing
etc.
8
7
9101112
4
Scanner Key:
Scan
Lets you scan the next original into your
computer and select the type of
destination: word processing, graphics
or E-mail application.
5
One Touch Dial Keys
These 8 keys give you access to 8
previously stored phone numbers.
6
R (Recall)
Use this key to gain access to an outside
line and/or to recall the operator or
transfer a call to another extension when
it is connected to a PABX.
INTRODUCTION
7
7
Search/Speed Dial
Lets you look up numbers stored in the
dialling memory. Also, lets you dial
stored phone numbers by pressing # and
two-digit number.
8
Redial/Pause
Re-dials the last number called. Also
inserts a pause in autodial numbers.
9
Dial Pad
Dials phone and fax numbers and can be
used as a keyboard for entering
information into the machine.
10
Fax Keys:
Mode
Select how the fax machine will handle
incoming calls.
Broadcast
Use this key when you want to send a
fax to several different locations
(maximum 88 locations at once).
Resolution
Sets the resolution when you send a fax.
13
Copy Keys:
Photo/Text
Lets you identify the type of document
you want to copy: a photograph or text.
Enlarge/Reduce
Lets you select an enlargement or
reduction ratio: 100%, 120%, 125%,
150%, 200%, 50%, 75%, 87%, 93%,
Selecting AUTO automatically reduces
the original to the selected paper size.
Copy/Help
Makes a copy. If the ADF is empty, a
quick reference Help List will be
printed.
14
Printer Key:
Job Cancel
Clears data from the printer memory.
15
Set/Verify
Stores a function setting into the
machine. When the machine is idle, you
can also use this key to print the
Transmission Verification Report for
your last transmission.
11
Stop
Stops a fax, cancels an operation or
exits from function mode.
12
Start
Starts sending a fax.
16
(Left Arr ow)
(Right Arr ow)
Volume
Moves the LCD cursor to the left or
right in function mode so you can make
selections. Also, adjusts speaker and
ring volume.
Whenever you transport the machine, use the packing materials that
came with your machine and pack the machine correctly.
Floppy Disk*
Wire Extensions
CD-ROM
(For MFC-9060 Only)
(Both wire extensions
are same size)
Multi-purpose
Sheet Feeder
Drum Unit Assembly
(with free Starter
Toner Cartridge)
Owner’s Manual
Dust Cover
10
CHAPTER TWO
Choosing a Location
Place your fax machine on a flat, stable surface, such as a desk. Select a
place that is free of vibration and shocks. Locate the machine near a
telephone wall socket and a standard earthed electrical socket, grounded
power outlet.
Avoid placing your machine where it may be knocked. Do not place near
heaters, air conditioners, water, chemicals or refrigerators. Do not expose
the machine to direct sunlight, excessive heat, moisture or dust. Do not
connect your machine to electrical outlets controlled by wall switches or
automatic timers as disruption of power can wipe out information in the
unit’s memory. Do not connect your machine to electrical outlets on the
same circuit as large appliances or other equipment that might disrupt the
power supply . Avoid interference sources, such as speakers or the base
units of cordless phones. Ensure the airflow from the fan on the right
hand side of the machine is not impeded.
CAUTION
Caution
INSTALLATION
We recommend that this product be used with a surge protection
1
device to protect the product against damage caused by a lightning
strike.
Never touch telephone wires or terminals that are not insulated
2
unless the telephone line has been disconnected at the network
interface.
Avoid using a telephone (other than a cordless type) during an
3
electrical storm. There may be a remote risk of electric shock from
lightning.
Do not use the telephone to report a gas leak in the vicinity of the
4
leak.
11
Assembly
Install the Drum Unit Assembly
(with Toner Cartridge)
1
Unpack the drum unit assembly, including the toner cartridge, and
gently rock it from side to side five or six times.
To prevent damage to the drum, do not expose it
to light for longer than a few minutes.
Do NOT remove the starter sheet – this will be
ejected while the machine is warming up.
12
Top Cover
CHAPTER TWO
Open the top cover of the machine.
2
Do NOT remo ve starter sheet.
Holding the drum unit by its handles, insert it in the machine.
3
Close the top cover.
4
Setting Up the Machine
INSTALLATION
13
Follow the instructions below to connect power cord, and telephone line.
(Example for the U.K.)
Connect the power cord.
1
EXT.
LINE
14
CHAPTER TWO
IMPORTANT:
If you need to remove the moulded mains plug in order to
fit an appropriate type, you must discard the moulded plug
immediately having cut it off, in order that it is not
inadvertently inserted into a live socket, thus presenting a
shock hazard. The wires in the mains lead of this
appliance are coloured in accordance with the following
code.
As the wires in the mains lead of this apparatus may not
correspond with the coloured markings identifying the
terminals in your plug, proceed as follows:
The wire which is coloured green-and-yellow must be
connected to the terminal in the plug which is marked by
the letter “E” or by the safety earth symbol
green or green-and-yellow.
The wire which is coloured blue must be connected to the
terminal which is marked with the letter “N” or coloured
black.
The wire which is coloured brown must be connected to
the terminal which is marked with the letter “L” or
coloured red.
Green-and-yellow : Earth
Blue: Neutral
Brown: Live
or coloured
The PC interface is a SELV (Safety Extra Low Voltage) por t
as defined in EN41003. It must only be connected with a
SELV circuit; only the MFL Pro for Fax cable kit (available
in an option pack), satisfies this requirement.
NOTICE:
■ This machine must be fitted with an earthed plug.
■ Since the machine is earthed via the mains plug, you can protect
yourself from potentially hazardous electrical conditions on the
telephone network by keeping the power to your machine on when
you connect it to a telephone line. Similarly, you can protect yourself
when you want to move your machine, by disconnecting the
telephone line first, and then the power cord.
■ Do not touch the rollers at the paper exit.
Connect one end of the telephone line cord to the socket marked
2
LINE on the left side of the machine. Connect the other end to the
modular wall socket.
INSTALLATION
Attach the wire extensions to the Multi-purpose Sheet Feeder, and to
3
the document guide base.
15
Attach the document and paper trays to the machine, and pull out
4
their extensions.
Loading Paper
Open the Multi-purpose Sheet Feeder cover.
1
16
CHAPTER TWO
Fan the paper well. Load the paper, making sure that the printing
2
surface is towards the fax unit and the paper level is stacked below
the triangle mark. The feeder can hold up to 200 sheets of paper.
Adjust the guides to fit the paper width.
3
Acceptable Paper
Size: A4 (210 mm x 297 mm)
Weight: 60 g/m
Thickness : 0.08 – 0.20 mm
2
– 158 g/m
2
INSTALLATION
Manual Feed Slot
The Multi-purpose Sheet Feeder also has a Manual Feed Slot. You can
load paper sheet-by-sheet into this slot. You do not have to remove paper
from the Multi-purpose Sheet Feeder.
1
Multi-purpose
Sheet Feeder
2
Manual Feed Slot
Multi-Line Connections (PABXs)
17
Most offices use a central telephone system, or PABX. The machine will
work with most PABX or key systems that allow a two-wire analogue
connection. However, we recommend that you have a separate telephone
line for your machine. You can then leave the machine in Fax Only Mode
to receive faxes any time of day or night.
If you are installing the machine to w ork with a P ABX:
It is not guaranteed that the unit will operate correctly under all
1
circumstances with a PABX. Any cases of difficulty should be
reported first to the company that handles your PABX.
If all incoming calls will be answered by a switchboard operator, it is
2
recommended that the Answer Mode be set to Manual. All incoming
calls should initially be regarded as telephone calls.
The unit may be used with either pulse or tone dialling.
3
18
CHAPTER TWO
Using Extension T elephones
It may be that your premises are already wired with parallel extension
telephones, or you intend to add extension telephones to your line, in
addition to your machine. While the simplest arrangement is
straightforward parallel connection, there are some reasons as to why this
arrangement will cause unsatisfactory service, the most obvious of which
is inadvertent interruption of a facsimile transmission by someone
picking up an extension telephone in order to make an outgoing call.
Additionally, remote activation may not operate reliably in such a simple
configuration.
This machine may also be set to make a delayed transmission (i.e. a
transmission at a pre-set time). This pre-set job may coincide with
someone picking up an extension handset.
Such problems can easily be eliminated however, if you arrange
modification of your extension wiring circuit, such that extension
devices are connected “downstream” of your machine, in a master/slave
configuration. In such a configuration, this machine can always detect
whether a telephone is in use, thus it will not attempt to seize the line
during that time. This is known as “telephone off-hook detection.”
The inadvisable configuration is shown in figure 1 below, and the
recommended master/slave configuration is shown in figure 2.
This new connection configuration can be arranged by your contacting
BT, Kingston upon Hull Telecommunications, your PABX maintainer or
a qualified telephone installation company as appropriate. Simply
explained, the extension telephone circuit should be terminated on a
normal modular plug (BT 431A style), which in turn should be inserted
into the modular socket of the white “T”-shaped connector provided as
part of the line cord assembly.
EXTENSION
SOCKET
INADVISABLE CONNECTION OF EXTENSION SOCKETS
EXTENSION
SOCKET
RECOMMENDED CONNECTION OF EXTENSION SOCKETS
EXTENSION
SOCKET
FAX
Fig. 1.
DISCONNECT
EXTENSION
SOCKET
FAX MACHINE MUST BE PLUGGED
Fig. 2.
MASTER
SOCKET
MASTER
SOCKET
FAX
INTO MASTER SOCKET
INCOMING
LINE
INCOMING
LINE
INSTALLATION
Connecting an External T elephone
Answering Device (TAD)
Sequence
You might choose to connect an additional answering machine. When
you have an external TAD on the same telephone line as the machine,
the TAD answers all calls. The machine “listens” for fax calling (CNG)
tones. If it hears them, the machine takes over the call and receives the
fax. If it doesn’t hear the CNG tones, the machine will not answer the
call, and messages can be left on the TAD by callers in the normal way.
The TAD must answer within a maximum of four rings. However, we
recommend two rings as the TAD setting. The machine cannot hear CNG
tones until the TAD has answered the call, and with four rings there are
only 8–10 seconds of CNG tones left for the fax “handshake.” Make
sure you carefully follow instructions in this manual for recording your
outgoing message. Do not use a “toll-saver” ring setting on the TAD.
19
It is important that the TAD is connected via the EXT socket on the
machine or on the line jack unit. Do not use a line doubler on the line
jack as this can cause answering problems.
Connections
1
(Example
for the U.K.)
2
3
4
5
You may connect an external TAD to your machine, as shown below.
TAD
Set your external TAD to two rings or less.
Record the outgoing message (see below).
Set the TAD to answer calls.
Set the Answer Mode to TAD:ANSWER MACH. by pressing
Mode.
TAD
20
CHAPTER TWO
Outgoing Message (OGM) of External T AD
Timing is important in recording this message. The message sets up the
ways to handle both manual and automatic fax reception.
We recommend the outgoing message (OGM) is no longer than 20
1
seconds.
Allow 5 seconds of silence at the beginning of your message.
2
(This allows the fax to detect the calling tone prior to OGM, so
reception can be faster.)
We recommend that you end your OGM by giving your Remote
3
Activation Code for people sending manual faxes. For example:
“After the beep, leave a message or send a fax manually by pressing
51 and Start”
Please note that some faxes that are sent manually cannot be received
automatically because some fax machines do not send a fax tone if the
call is manually dialled. In these cases you must inform callers that they
must enter the remote activation code to send a fax.
Connecting an External T elephone
You can connect a separate telephone (or telephone answering device) to
your machine, as shown below.
(Example
for the U.K.)
Whenever this external phone (or TAD) is in use, the screen displays
TELEPHONE.
External
Telephone
Extension
Telephone
Loading...
+ 156 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
