Bosch B5512-C-930, B5512E-DC1 Specsheet

Intrusion Alarm Systems | B5512 Control Panels

B5512 Control Panels

www.boschsecurity.com

u Supports up to 48 points using a combination of

hardwired or wireless points for installation
flexibility and up to 4 areas with perimeter and
interior control

The B5512 Control Panel integrates intrusion and
residential fire, providing one simple user interface for
both systems. The B5512 provides up to 48
individually identified points that can be split into 4
areas. The control panel includes a built-in Ethernet
port for IP network communications, and is
compatible with modules that send events to selected
public switched telephone network (PSTN), IP
network, or cellular network destinations through four
programmable route groups.
With the B5512, you can monitor doors, windows, and
motion within areas like showrooms or those that hold
inventory. Each user can have a personalized
passcode, a wireless keyfob, and a credential to
control the system.

u On-board Ethernet port for Conettix IP alarm

communication and remote programming,
compatible with modern IP networks including IPv6/
IPv4, Auto-IP, and Universal Plug and Play

u Installer-friendly features including on-board USB

for easy on-site RPS programming, plus plug-in
PSTN and Cellular communication modules for
simple installation and future proof upgrades

u Notifications with email and text messaging, and the

Remote Security Control app for Android and iOS
mobile devices

u Programmable keypad shortcuts, situation sensitive

on-screen help, and a bilingual user interface make
system operation simple and easy

Use programmable authority levels with restricted
privileges to provide service, security, and cleaning
personnel with full or limited access. Use the three
programmable outputs (expandable up to 43) to turn
on lights or lock and unlock doors. Users can:

• Turn on the system to secure the stockroom while
you conduct daily business.

• Perform tests to ensure your system is working
properly.

• Set your system to alarm immediately if a door opens.

• Activate the Watch feature so a tone sounds
whenever a customer enters.

• Set a schedule for your system to automatically turn
on at closing time.

• Use wireless security options to customize your
system.

| B5512 Control Panels

2

Central monitoring stations provide 24-hour system
monitoring with access to vital services. Professional
security personnel can test the system, monitor
system activity, and alert the police, fire department,
or other emergency response teams if necessary.

Functions

Programmable outputs

• 500 mA not to exceed 1.3 A total current for a
burglary system, or not to exceed 1.0 A total current
for household fire applications

• 800 mA auxiliary power at 12 VDC

• Four alarm-output patterns

• Programmable bell test

• Three programmable outputs; one high current using
a relay, and two trigger outputs

• Output A contact rating is 3 Amps

System response

• High-performance micro-controller provides industry
leading system response

• 20 custom point indexes

• Selectable point response time

• Selectable EOL resistor configuration, single or dual

• Cross point capability

• Fire alarm verification

• Dangerous gas indicator includes carbon monoxide
(NFPA 720)

• Watch mode

• Scheduled events (SKEDs) perform several functions,
such as turn on (arm) the system, turn off (disarm)
the system, bypass and unbypass points, and control
relays

User interface

• Supervision of up to 8 keypads

• Custom keypad text is fully programmable through
RPS

• Full function menu including custom functions

• Authority by area and 32 character name for each
user

• 14 custom authority levels control user’s authority to
change, add, or delete passcodes to disarm or bypass
areas; and to start system tests

• Programmable primary and secondary language by
user and keypad; select from English, Spanish,
French, and Portuguese

Area configurations

Area programming offers a wide selection of different
system configurations. Make area arming conditional
on other areas (master or associate), if desired. You
can configure any area for perimeter and interior
arming, not requiring a separate area for this function.
Link multiple areas to a shared area which is
automatically controlled (hallway or lobby). For higher
security applications, the Area Re-Arm feature
guarantees that areas are always rearmed, and are
disarmed for no longer than a specific, configurable,
amount of time (for example, service time).

Custom functions

For added convenience, the installer can program
custom functions that allow customers to complete
complex tasks with one simple action. For example, a
custom function can bypass a group of points and arm
the system, allowing the user to perform these
functions with one easy command. Users can activate
custom functions with a keypad, keyfob, token, or
card, or the control panel can activate a function in
reaction to a faulted point, or automatically through a
scheduled event (SKED).

Passcode security

• Two-man rule. Requires two people with two unique
passcodes to be present at the time of opening.

• Early ambush. Allows users to verify that the facility is
safe by requiring two passcodes. The control panel
sends a duress event if the user does not enter the
passcode a second time after inspecting the
premises.

• Dual authentication. Requires two forms of
identification before processing certain system
commands, including turning off the system and
opening doors. A standard system user must have a
passcode, a credential (token or card), and
appropriate command authority permissions assigned
in the door and keypad’s assigned area.

Easy exit control

The control panel changes from one On (armed) state
to another without turning off (disarming) the system.
For example, if you change the state from Part On
(Perimeter Arm) to All On (Master Arm), the control
panel complies and reports the change. Easy Exit
Control reduces the number of keystrokes, simplifying
system operation.

Programmable passcode-controlled menu list

Passcode-controlled shortcuts provide users only with
the options and information pertinent to them,
simplifying system operation.

Flexible control

The system provides the flexibility to choose added
convenience or high security. For example, you can
restrict to a keypad's immediate local area turning on
(arming) and turning off (disarming) the system with a
passcode, even if the user has access to other areas.
This is particularly useful for high security areas,
where a user may have access to the area, but would
prefer to only turn off (disarm) the area individually
rather than with the rest of the system.

Monitor Delay/Delayed Response

Create a special point index that delays the reaction of
a point for a specified time (up to 1 hour in minutes
and seconds). This delay provides time for the
specified condition to reset before activating any
annunciation. The system can annunciate locally and
send a report, if desired. When the system is armed,
the point can respond like a normal point – providing
dual functionality. Use this feature to ensure that

| B5512 Control Panels

3

perimeter doors have not been propped open, or to
monitor critical areas such as computer rooms and
safes, for example.

System users

The system supports up to 50 users. Each user can
have a personalized passcode, a wireless keyfob, and a
credential to control the system. You can assign
passcodes to one of 14 customized authority levels in
each area that can be restricted to operate only during
certain times. Programmable primary and secondary
language by user and keypad; select from English,
Spanish, French, and Portuguese.

Communication formats

The control panel prioritizes and sends reports to four
route groups. Network and phone communications can
use either the Modem4 or the Contact ID
communications formats. Each group has a
programmable primary and backup destination.
The control panel provides flexible communications for
most central stations with reporting capabilities such
as:

• Individual point numbers

• Opening or closing reports by user and area number

• Remote programming attempts

• Diagnostic reports

IP communication

The control panel can use on-board Ethernet (IP)
connection (the on-board Ethernet port is excluded on
“E” versions) to communicate with a Conettix D6600
or a Conettix D6100IPv6 Communications Receiver/
Gateway.
The control panel can optionally use a B426 Conettix
Ethernet Communication Module or a Conettix Plug-in
Cellular Communicator (B440/B441/B442/B443).
Using Conettix IP communication offers a secure path
that includes anti-replay/anti-substitution features and
provides enhanced security with AES 256-bit
encryption (using Cipher Block Chaining (CBC)).
The control panel supports Domain Name System
(DNS) for both remote programming and central
station communication. DNS provides ease of use,
eliminating the need to use static IP addresses as your
reporting destination, and accommodates a simple
solution for central station disaster recovery. IP Setup
is easy, eliminating the need to use complicated
internet programming tools such as ARP and Telnet.
The control panel supports both IPv6 and IPv4
networks.

Communication paths

The control panel accommodates up to four separate
phone and four separate network paths to the central
station receiver. When resetting alarms or turning a
system on and off, the user is identified by name and
number.

Personal notification

The control panel can send text messages and emails
for personal notification over Ethernet or using a
cellular communicator. You can configure up to 16
destinations using a combination of cellular phone
numbers and email addresses. The control panel sends
notifications in the user’s programmed primary
language.

Firmware updates

The system allows remote firmware updates through
Remote Programming Software (RPS) using the RPS
Firmware Update Wizard. The Firmware Update Wizard
uses the on-board USB connection or the on-board
Ethernet (IP) connection (the on-board Ethernet port
is excluded on “E” versions) to transmit firmware
updates.
The control panel can optionally receive firmware
updates from RPS using a B426 Conettix Ethernet
Communication Module or a Conettix Plug-in Cellular
Communicator (B440/B441/B442/B443). Notice!
Cellular firmware updates require more time than
Ethernet updates and carrier data rates apply.

• Control panel updates. Remotely update the control
panel firmware for easy feature enhancements
without replacing ROM chips.

• Module update support. Remotely update the
firmware on connected SDI2 modules for easy feature
enhancements without visiting each individual
module.

A wide variety of input options

Each point:

• Accommodates normally‑open (NO) and
normally‑closed (NC) devices with end‑of‑line (EOL)
resistor supervision.

• Accepts programming for fire, gas, fire supervisory, or
intrusion applications.

• Supports hardwired and wireless devices.

• Supports IP cameras by Bosch as point sources.

Security and fire detection

The control panel provides eight on-board points, and
up to 40 additional off-board points (depending on
model and expansion interfaces). You can program
individual points to monitor some types of burglar
alarms, fire alarms, and supervision devices.

Event log

The event log stores local and reported events. The
event log includes information such as time, date,
event, area, point, and user. View the event log from a
keypad or use RPS to remotely retrieve event
information. When the event log reaches a
programmed threshold of stored events, it can send an
optional report to a receiver.
The event log stores up to 255 local and reported
events.
