Page 1
B Series Product Guide
B Series from Bosch is the most advanced control panel available for small to mid-sized applications.
B:more:innovative
B Series includes a built-in Ethernet port for IP alarm
communications. It can also send reports using cellular
or wired phone networks using plug-in communication
modules.
A modern internet appliance, B Series is the first control
panel to support both IPv6 and IPv4 networks. And with
DNS for remote programming and central station reporting,
IP communication is simple to set up from the installer
keypad menu or via Remote Programming Software (RPS).
B:more:flexible
B Series panels are as adaptable as they are powerful. The
system can be split into up to 48 points and 4 areas, each
with perimeter and interior arming. To provide ease of use,
keypads offer dual-language support and can be configured
to operate all areas or just a single area. Custom text is
remotely programmable on each keypad—choose
from English, Spanish, French or Portuguese—reducing
costly service calls. B Series provides increased protection
and cost savings with special point types for monitoring
safety, environmental, and high-security items.
B:more:efficient
B Series offers a host of features to simplify any installation.
Connect your laptop directly to the panel with the on-board
Ethernet or USB ports. Unlike other systems, you don’t need
an extra module, specialized hardware, or custom laptop
configurations—just plug it in, and it works!
Remote programming and advanced diagnostics over IP or
cellular minimizes maintenance costs by allowing you to
service systems over the panel’s cellular connection, over the
internet or enable / disable certain functions without traveling
to a facility. Perform remote firmware updates for easy
upgrades and to offer feature enhancements as they become
available.
Page 2
B:more:connected
With the Remote Security Control app, customers can
operate B Series from an iOS or Android device. Arm
or disarm the system, check system status and control
outputs over the panel’s cellular connection, over the
internet, or through a local wireless network. Receive
notifications of important system events via email or send
text messages directly to any smart phone.
B:more:aware
View premise conditions from a remote desktop or smart
phone. Bosch IP camera integration with the B Series
Control Panels allows video motion detection to activate
points on the panel, triggering camera actions such as
sending video or snapshots via email.
B:more:automated
Combine the B Series Control Panel with the Bosch Control
Gateway, to connect Z-Wave devices—such as lighting
controls, door locks, temperature sensors, and IP cameras—
for home or premise automation. Use the dashboard for
remote monitoring to stay informed while away.
B:more:compatible
B Series supports a full range of intrusion detectors including
Blue Line Gen2 with excellent catch performance and false
alarm immunity.
For applications where appearance is important, choose the
RADION wireless platform with superior range, reliability,
flexibility, and battery life. RADION allows for the most
cost effective installation and service with multiple device
enrollment options, configurations, and diagnostics.
Page 3
B Series applications
Banking/Financial
Institutions
Retail
Residential
▶ Early ambush and two-person disarm options provide flexibility
to meet the specific security requirements of the branch
▶ Use multiple areas to partition critical zones like the ATM, vault,
and office. Allow the manager to arm the branch while keeping the
ATM vestibule accessible
▶ Features the highest level of encryption built into every
control panel
▶ Monitor critical coolers and HVAC systems—reducing risk for
grocery and convenience stores
▶ Use Area Control for arming/disarming critical areas like the
pharmacy, cash office, warehouse, and overhead doors
▶ Use the Monitor Delay/Delay Response feature to check for
propped perimeter doors, roof latches and high-value areas, even
during disarmed periods
▶ Deploy an integrated solution that addresses intrusion detection,
safety, and communication needs
▶ Custom functions provide easy one-button arming configurations,
such as Go to bed or Go out to the pool
▶ Late-to-open reports can be used to monitor children arriving
home from school
▶ Use RADION wireless detectors to monitor outbuildings, such as a
pool shed or garage, or for installs where appearance is important
Education
Office Buildings
▶ Control access authorizations so each user can have a personalized
passcode, wireless keyfob, and credentials
▶ Deploy advanced detectors and sensors to protect against a wide
range of security concerns (fire, smoke, CO, break-ins, explosions,
and more)
▶ Work with central monitoring stations to provide 24-hour support
services for testing, monitoring, and emergency services response
▶ Program scheduled events to support day-of-week, date-of-month,
and holiday schedules
▶ Investigate alarms in detail using an event log with storage for up
to 250 local and reported events
▶ Use programmable authority levels with restricted privileges to
provide service, security, and cleaning personnel with full or
limited access
▶ Use flexible area configurations to protect sensitive zones from
access while allowing workers the flexibility to enter common areas
during off hours
Page 4
System Overview
B Series panels integrate intrusion and fire, providing one
simple user interface for all systems. The scalable B Series
panels are available with 16 to 48 points and support for up
to 50 users for small to mid-sized applications.
Keypad models and options
Choose from standard or ATM style LCD keypads.
Keypad Models
B915
Standard LCD Keypad
B920
Two-line Alphanumeric LCD Keypad
B921C
Capacitive Touch Keypad
System Features B5512 B4512 B3512
Number of Points 48 28 16
Number of Areas 4 2 1
Number of Wireless Points 40 20 8
Number of System Users 50 32 10
Number of Outputs 43 27 3
Custom Functions 4 2 1
Histor y Events 255 127 127
SKEDs 5 5 1
Conettix IP Alarm-over-IP Support Yes Yes Yes
CDMA Cellular Communication Yes Yes Yes
Residential Fire Approved Yes Yes Yes
Point and output expansion
Hardware and wireless expansion options include the
new B208/B308 Octo-input/output modules and RADION
wireless technology. New expansion modules can be
mounted up to 1,000 feet away from the panel for added
installation flexibility. Any combination of hardwire,
addressable and wireless expansion is possible to meet
application requirements.
B930
Five-line ATM style Alphanumeric Keypad
B942
Touch Screen Keypad (Black)
B942W
Touch Screen Keypad (White)
Touch screen
Status icons
B Series Modules
B430 Plug-in PSTN (Phone Line) Communicator
B440 Plug-in Cellular (3G) Communicator
B441 Conettix Plug-in CDMA Cellular Communicator
B450 Conettix Plug-in Communicator Interface
B520 Auxiliary Power Supply Module
B810 RADION receiver SD wireless communications
B820 SDI2 Inovonics Interface Module
B208 SDI2 Octo-input/Octo-output Modules
B308 SDI2 Octo-input/Octo-output Modules
B426 Conettix Ethernet Communication Module
B201 2-wire Powered Loop Module
Ethernet
USB
Menu
Proximity reader
