USER’S GUIDE

1770, 1970, 2080, 2090 SERIES

QuickSteamer

ug120-4071_1770_908.indd 1 10/14/08 1:05:58 PM

We’re glad you purchased a BISSELL QuickSteamer lightweight deep cleaner.

Everything we know about floor care went into the design and construction

of this complete, high-tech home cleaning system.

Your QuickSteamer is well made, and we back it with a limited one-year

warranty. We also stand behind it with a knowledgeable, dedicated

Consumer Services department, so, should you ever have a problem, you’ll

receive fast, considerate assistance.

My great-grandfather invented the floor sweeper in 1876. Today, BISSELL is

a global leader in the design, manufacture, and service of high quality

homecare products like your QuickSteamer.

Thanks again, from all of us at BISSELL.

Mark J. Bissell

President and Chief Executive Officer

Thanks for buying a BISSELL QuickSteamer

www.bissell.com 800.237.7691

ug120-4071_1770_908.indd 2 10/14/08 1:05:59 PM

www.bissell.com 800.237.7691

IMPORTANT SAFETY INSTRUCTIONS

When using an electrical

appliance, basic precau-

tions should be observed, including the following:

Read all instructions before using your QUICKSTEAMER

WARNING:

To reduce the risk

of fire, electric shock, or injury:

■

Do not immerse.

■

Use only on surfaces moistened by cleaning process.

■

Always connect to a properly grounded outlet.

See Grounding Instructions.

■

Unplug from outlet when not in use and before

conducting maintenance or troubleshooting.

■

Do not leave machine when it is plugged in.

■

Do not service machine when it is plugged in.

■

Do not use with damaged cord or plug.

■

If appliance is not working as it should, has been

dropped, damaged, left outdoors, or dropped into water, have it repaired at an authorized Service Center.

■

Do not expose to rain. Store indoors.

■

Do not pull or carry by cord, use cord as a handle, close

door on cord, pull cord around sharp corners or edges, run appliance over cord, or expose cord to heated surfaces.

■

Do not carry the appliance while in use.

■

Do not unplug by pulling on cord. Unplug by grasping

the plug, not the cord.

■

Do not handle plug or appliance with wet hands.

■

Do not put any object into appliance openings, use with

blocked opening, or restrict air flow.

■

Do not expose hair, loose clothing, fingers or body

parts to openings or moving parts.

■

Do not pick up hot or burning objects.

■

Do not pick up flammable or combustible materials

(lighter fluid, gasoline, kerosene, etc.) or use in the presence of explosive liquids or vapor.

■

Do not use appliance in an enclosed space filled

with vapors given off by oil base paint, paint thinner, some moth proofing substances, flammable dust, or other explosive or toxic vapors.

■

Do not pick up toxic material (chlorine bleach, ammonia,

drain cleaner, gasoline, etc.).

■

Do not modify the 3-prong grounded plug.

■

Do not allow to be used as a toy.

■

Do not use for any purpose other than described in

this User’s Guide.

■

Use only manufacturer’s recommended attachments.

■

Use only cleaning products formulated by

BISSELL for use in this appliance to prevent internal component damage. See the Cleaning Fluid section of this guide.

■

Keep openings free of dust, lint, hair, etc.

■

Keep appliance on a level surface.

■

Turn off all controls before unplugging.

■

Be extra careful when cleaning stairs.

■

Close attention is necessary when used by

or near children.

WARNING: The Power Cord on this product contains lead, a chemical known to the State of California to cause birth defects or other reproductive harm.

WASH HANDS AFTER HANDLING.

SAVE THESE INSTRUCTIONS.

THIS MODEL IS FOR HOUSEHOLD USE ONLY. Commercial use of this unit voids the manufacturer’s warranty.

GROUNDING INSTRUCTIONS

This appliance must be connected to a grounded wiring system. If it should malfunction or break down, grounding provides a safe path of least resistance for electrical current, reducing the risk of electrical shock. The cord for this appliance has an equipment-grounding conductor and a grounding plug. It must only be plugged into an outlet that is properly installed and grounded in accordance with all

local codes and ordinances.

WARNING:

Improper

connection of the equipment-grounding conductor can result in a risk of electrical shock. Check with a qualified electrician or service person if you aren’t sure if the outlet is properly grounded. DO NOT MODIFY THE PLUG. If it will not fit the outlet, have a proper outlet installed by a qualified electrician. This appliance is designed for use on a nominal 120-volt circuit, and has a grounding attachment plug that looks like the plug in the drawing above. Make certain that the appliance is connected to an outlet having the same configuration as the plug. No plug adapter should be used with this appliance.

Grounded

Outlets

Grounding Pin

ug120-4071_1770_908.indd 3 10/14/08 1:05:59 PM

Cleaning fluid

Keep plenty of genuine BISSELL Fiber Cleansing Formula™ on hand so you can clean and protect whenever it fits your schedule. Always use genuine BISSELL deep cleaning formulas. Non-BISSELL cleaning solutions may harm the machine and will void the warranty.

www.bissell.com 800.237.7691

Spray Trigger

Solution Tank

Large Easy Rolling Wheels

Power Switch

Detent Lever

Quick Release Cord Wrap™

Power Cord

Lower Cord Wrap

Handle Assembly

Upper Body

Lower Body

Vent Cover (Containing Foam Filter)

Collection Tank

Collection Tank Latch

Removable Nozzle

Product View

48 oz. BISSELL Fiber Cleansing Formula™ with Scotchgard

™

Protector

item # 0710

48 oz. BISSELL Multi- Allergen Removal

™

Formula™ with Scotchgard

™

Protector

item # 0720

48 oz. BISSELL Pet Odor and Soil Removal

™

Formula with Scotchgard

™

Protector

item # 0730

48 oz. BISSELL Natural Orange Extract Formula with Scotchgard

™

Protector

item # 0740

32 oz. BISSELL Hard Floor Solutions

™

Formula

item # 0484

22 oz. BISSELL Tough Stain PreCleaner

™

item # 0400

48 oz. BISSELL Lavender Essence Formula with Scotchgard

™

Protector

item # 0750

43 oz. BISSELL 3X Concentrated Fiber Cleansing Formula with Scotchgard™ Protector

# 0716

WARNING:

To reduce the risk of fire and electric shock due to internal component damage, use only BISSELL cleaning fluids intended for use with the deep cleaner. Non-BISSELL cleaning solutions may harm the machine and void the warranty.

ug120-4071_1770_908.indd 4 10/14/08 1:06:03 PM
