Bg Radia R-200 Specifications
R-200
radia
S E R I E S
A r c h i t e c t u r a l L o u d s p e a k e r
T H E R A D I A S E R I E S
The new Radia R-200 by BG is the most affordable model in the Radia Architectural
Series. An updated version of a classic, this in-wall dynamo can fit almost anywhere while
easily filling your listening space with amazing sound.
Driving the R-200 are two 5.25” long-throw woofers featuring the latest neodymium magnet
technology along with our patented Neo3 tweeter. This seamless two-way system takes
advantage of conventional loudspeaker design, as well as our proprietary planar technology,
offering the best of both worlds. The result? Stunning sound in a compact form that can be
easily mounted in an opening less than 20” long, 6” wide and 4” deep.
As with all Radia loudspeakers, the R-200 is hand crafted from the finest materials, such
as high-grade steel and aluminum. The speaker’s rugged, precision frame reduces wall
resonance, making it an excellent choice for professional installations, where there is zero
p l a n a r t e c h n o l o g y
tolerance for error and maximum demand for high fidelity. In addition, the R-200 is paintable
allowing your customers to match the speaker’s finish to their decor.
Compact yet powerful, the R-200 delivers a deep, spacious soundstage with lifelike imaging
and uncanny accuracy for a wide array of locations and applications around the home.
Rugged Highest quality components will provide a lifetime of trouble-free enjoyment
›
Versatile Perfectly suited for home theater front or surround, audio or multi-room audio
›
Stylish Attactive industrial design with paintable grille and frame to match any decor
›
Lifelike Horizontal dispersion creates expanded soundstage and wider “sweet spot”
›
Accurate Planar ribbon drivers provide superior clarity, resolution and fidelity of sound
›
T h e P o w e r o f C l a r i t y
A r c h i t e c t u r a l L o u d s p e a k e r
radia
S E R I E S
R-200
p l a n a r t e c h n o l o g y
T H E R A D I A S E R I E S
G E N E R A L P A R A M E T E R S :
›
S y s t e m t y p e
S y s t e m d i m e n s i o n s
(H xW x In st al le d Gr il le H )
W e i g h t
W a l l c u t - o u t s i z e
D r i v e r c o m p l e m e n t
Two-way symmetric hybrid array
19 3/4” x 7 1/8” x 3/4” ( 50.2 x 18.1 x 1.9 cm)
6.5 lbs. (3 kg)
17 7/8” x 5 7/8” (45.4 x 14.9 cm)
2 x 5.25” long-throw Neodymium manget woofers
1 x Neo3 Planar ribbon tweeter
C r o s s o v e r 2 kHz, passive
F r e q u e n c y r e s p o n s e 60 Hz -20 kHz (-6 dB, half space)
S e n s i t i v i t y 88 dB /2.83 V / 1m
R a t e d i m p e d a n c e 4 ohms
P o w e r h a n d l i n g 50 - 150 W RMS
W a r r a n t y
1
Lifetime to the original owner
The Radia R-200 is currently available through BG’s authorized network of specialty custom
retailers and integrators.
3535 Arrowhead Drive · Carson City, NV 89706 ·
1
Please see BG warranty for complete details
phone:
internet:
www.bgcorp.com ·
© Copyrigh t 2006 BG Corp. All rights res erved. Products, features and spe cications sub ject to change without notice.
775-884-1900 ·
email:
sales@bgcorp.com
toll free:
888-8PLANAR (888-875-2627)
