Dear Customer,

We hope that your product, which has been produced in modern plants and checked under the most meticulous quality control procedures, will provide you an e

Therefore, read this entire user manual carefully before using the product and keep it as a reference. If you handover the product to someone else, give the user manual as well.

The user manual will help you use the product in a fast and safe way.

•Read the manual before installing and operating the product.

•Make sure you read the safety instructions.

•Keep the manual in an easily accessible place as you may need it later.

•Read the other documents given with the product.

Remember that this user manual is also applicable for several other models. Dir

Explanation of symbols

Throughout this user manual the following symbols are used:

Important information or useful tips.

Warning against dangerous conditions for life and property. Warning against electric voltage.

CONTENTS

1 Your Refrigerator		3		5 Using your refrigerator	16
				Indicator panel	16
2 Important Safety
				Freezing fresh food ..........................	21
Warnings		4		Recommendations for preservation of
Intended use .....................................		4		......................................frozen food	21
General safety ..................................		4		Placing the food ..............................	21
For products with a ..........................		8		Making ice .......................................	22
water dispenser; ................................		8		Deep-freeze information ..................	22
Child safety ........................................		9		Twist Ice – matic ............................	23
Compliance with WEEE Directive and				Ice container ....................................	23
Disposing of the Waste Product: .......		9		Fan ..................................................	24
Package information ..........................		9		Crisper ............................................	24
HC warning .......................................		9		Chiller compartment ........................	24
Things to be done for energy saving		10		Description and cleaning of odour
Recommendations for the fresh food				lter: ...............................................	25
compartment...................................		10		Reversing the door .................	26
				6 Maintenance and
3 Installation	11			cleaning	27
				Protection of plastic surfaces	27
Points to be paid attention to when the
relocation of the refrigerator .............		11		7 Troubleshooting	28
Electrical connection ........................		11
.............Disposing of the packaging		12
Disposing of your old refrigerator .....		12
Placing and Installation ....................		12
Adjusting the legs ............................		13
Door Open Warning .........................		13
Changing the illumination lamp .......		13
4 Preparation	15

2 EN

1 Your Refrigerator

8 *10

7	*9

*14

7

16

6

5

13

15

11

4

4

1

2

12

3

1.Door shelf

2.Egg section

3.Bottle shelf

4.Adjustable feet

5.Fridge crisper

6.Chiller compartment

7.Glass Shelf

8.Fan

9.Temperature setting button

10.Ion Guard

11.Freezer Crisper

12.Moveing door shelf

13.Ice box / Ice-making

14.Air Filter

15.Freezer compartment

16.Fridge compartment

*optional

Figures that take place in this instruction manual are schematic and may not correspond exactly with your product. If the subject parts are not included in the product you have purchased, then it is valid for other models.

3 EN

2 Important Safety Warnings

•Keep ventilation openings, in the appliance enclosure or in the. built-in structure,

clear of obstruction

•Do not use electrical appliances inside the food appliance, unless they are of the type storage compartments of the appliance, unless they are of the type recommended by the manufacturer

•this appliance can be used by children aged from 8 years and above and persons

with reduced physical, sensory or mental capabilities or lack of experience

and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.

•children shall not play with the appliance.

•Cleaning and user maintenance shall

not be made by children without supervision

Please review the following information. Failure to observe this information may cause injuries or material damage. Otherwise, all warranty and reliability commitments will become invalid.

The service life of your product is 10 years. During this period, original spare parts will be available to operate the product properly.

Intended use

This product is intended to be used

•indoors and in closed areas such as homes;

•in closed working environments such as stores and o ces;

•in closed accommodation areas

such as farm houses, hotels, pensions.

• It should not be used outdoors.

General safety

•When you want to dispose/scrap the

product, we recommend you to consult the authorized service

in order to learn the. required information and authorized bodies.

•Consult your authorized service for all your questions and problems related to the refrigerator. Do not intervene or let someone intervene to the refrigerator without notifying the authorised services.

	• For products with a	.
	freezer compartment;
	Do not eat cone ice
	cream and ice cubes
	immediately after you
	take them out of the
	freezer compartment!
	(This may cause frostbite
	in your mouth.)

•For products with a freezer compartment; Do not put bottled and canned liquid beverages in the freezer compartment.

Otherwise, these may burst.

•Do not touch frozen food by hand; they may stick to your hand.

4 EN

•Unplug your refrigerator before cleaning or defrosting.

•Vapor and vaporized cleaning materials should never be used in cleaning and defrosting processes of your refrigerator. In such cases, the vapor may get in contact with the electrical parts and cause short circuit or electric shock.

•Never use the parts on your refrigerator such as the door as a means of support or step.

•Do not use electrical devices inside the refrigerator.

•Do not damage the parts, where the refrigerant is circulating, with drilling or cutting tools. The refrigerant that might blow out when the gas channels of the evaporator, pipe extensions or surface coatings are punctured causes skin irritations and eye injuries.

•Do not cover or block the ventilation holes on your refrigerator with any material.

•Electrical devices must be repaired by only authorised persons. Repairs performed by incompetent persons create a risk for the user.

•In case of any failure or during a maintenance or repair work, disconnect your refrigerator’s mains supply by either turning off the relevant fuse

or unplugging your appliance.

•Do not pull by the cable when pulling off the plug.

•Ensure highly alcoholic beverages are stored securely with the lid fastened and placed upright.

•Never store spray cans containing

flammable and explosive substances in the refrigerator.

•Do not use mechanical devices or other means to accelerate the defrosting process, other than those

5 EN

recommended by the manufacturer.

•This product is not intended to be used by persons with physical, sensory or mental disorders or unlearned or inexperienced people (including children) unless they are attended by a person who will

be responsible for their safety or who will instruct them accordingly for use of the product

•Do not operate a damaged refrigerator. Consult with the service agent if you have any concerns.

•Electrical safety of your refrigerator shall be guaranteed only if the earth system in your house complies with standards.

•Exposing the product to rain, snow, sun and wind is dangerous with respect to electrical safety.

•Contact authorized service when there is a power cable damage to avoid danger.

•Never plug the refrigerator into the wall outlet during installation. Otherwise, risk of death or serious injury may arise.

•This refrigerator is intended for only storing food items. It must not be used for any other purpose.

•Label of technical specifications is located on the left wall inside the refrigerator.

•Never connect your refrigerator to electricitysaving systems; they may damage the refrigerator.

•If there is a blue light on the refrigerator, do not look at the blue light with optical tools.

•For manually controlled refrigerators, wait for at least 5 minutes to start the refrigerator after power failure.

•This operation manual should be handed in to the new owner of the product when it is given to others.

6 EN

•Avoid causing damage on power cable when transporting the refrigerator. Bending cable may cause fire. Never place heavy objects on power cable. Do not touch the plug with wet hands when plugging the product.

•Do not plug the refrigerator if the wall outlet is loose.

•Water should not be sprayed on inner or outer parts of the product for safety purposes.

•Do not spray substances containing inflammable gases such as propane gas near the refrigerator to avoid fire and explosion risk.

•Never place containers filled with water on top of the refrigerator; in the event of spillages, this may cause electric shock or fire.

•Do not overload the refrigerator with food. If overloaded, the food

items may fall down and hurt you and damage

refrigerator when you
open the door.	7

•Never place objects on top of the refrigerator; otherwise, these objects may fall down when you open or close the refrigerator’s door.

•As they require a precise temperature, vaccines, heat-sensitive medicine and scientific materials and etc. should not be kept in the refrigerator.

•If not to be used for a long time, refrigerator should be unplugged. A possible problem in power cable may cause fire.

•The plug’s tip should be cleaned regularly with a dry cloth; otherwise, it may cause fire.

•Refrigerator may move if adjustable legs are not properly secured on the floor. Properly securing adjustable legs on the floor can prevent the refrigerator to move.

•When carrying the refrigerator, do not hold it from door handle. Otherwise, it may be snapped.

EN

•When you have to place your product next to another refrigerator or freezer, the distance between devices should be at least 8cm. Otherwise, adjacent side walls may be humidified.

•The product shall never be used while the compartment which is located at the top or back of your product and in which electronic boards are available (electronic board box cover) (1) is open.

1

1

8

For products with a water dispenser;

•Pressure for cold water inlet shall be maximum 90 psi (6.2 bar). If your water pressure exceeds 80 psi (5.5 bar), use a pressure limiting valve in your mains system. If you do not know how to check your water pressure, ask for the help of a professional plumber.

•If there is risk of water hammer effect in your installation, always use a water hammer prevention equipment in your installation. Consult Professional

plumbers is you are not sure that there is no water hammer effect in your installation.

•Do not install on the hot water inlet. Take precautions against of the risk of freezing of the hoses. Water temperature operating interval shall be 33°F (0.6°C) minimum

and 100°F (38°C)

maximum.

EN

•Use only potable water.

Child safety

•If the door has a lock, the key should be kept away from reach of children.

•Children must be supervised to prevent them from tampering

with the product.

Compliance with WEEE Directive and Disposing of the Waste Product:

This product complies

with EU WEEE Directive (2012/19/EU). This product

bears a classification symbol for waste electrical and electronic equipment

(WEEE).

This product has been manufactured with high quality parts and materials which can be reused and are suitable for recycling. Therefore, do not dispose the product with normal domestic waste at the end of its service life. Take it to a collection point for the recycling of electrical and electronic equipment. Please consult your local authorities

to learn the nearest collection point. Help protect the environment and natural resources by recycling used products. For children’s safety, cut the power cable and break the locking mechanism of the door, if any, so

that it will be non-functional before disposing of the product.

Package information

Packaging materials of the product are manufactured from recyclable materials in accordance with our National Environment Regulations. Do not dispose of the packaging materials together with the domestic or other wastes. Take them to the packaging material collection points designated by the local authorities.

Do not forget...

Any recycled substance is an indispensable matter for nature and our national asset wealth.

If you want to contribute to the re-evaluation of the packaging materials, you can consult to your environmentalist organizations or the municipalities where you are located.

HC warning

If your product's cooling system contains R600a:

This gas is flammable. Therefore, pay attention to not damaging the cooling system and piping during usage and transportation. In the event of damage, keep your product away from potential fire sources that can cause the product catch a fire and ventilate the room in which the unit is placed.

Ignore this warning if your product's cooling system contains R134a.

Type of gas used in the product is stated in the type label which is on the left wall inside the refrigerator.

Never throw the product in fire for disposal.

9 EN

Recommendations for the fresh food compartment

*May not be available in all models

Do not allow the food to touch the temperature sensor in fresh food compartment. To allow the fresh food compartment keep its ideal storage temperature, sensor must not be hindered by food.

Do not place hot foods in the product.

Things to be done for energy saving

•Do not leave the doors of your refrigerator open for a long time.

•Do not put hot food or drinks in your refrigerator.

•Do not overload your refrigerator so that the air circulation inside of it is not prevented.

•Do not install your refrigerator under direct sunlight or near heat emitting appliances such as ovens, dishwashers or radiators. Keep your refrigerator at least 30cm away from

•heat emitting sources and at least 5cm from electrical ovens.

•Pay attention to keep your food in closed containers.

For products with a freezer compartment; You can store maximum amount of food items in the freezer when you remove the shelf or drawer of the freezer. Energy consumption value stated for your refrigerator has been determined by removing freezer shelf or drawer and under maximum load. There

is no harm to use a shelf or drawer

•according to the shapes and size of food to be frozen.

Thawing frozen food in fridge compartment will both provide energy saving and preserve the food quality.

This Appliance is intended to be used in household and similar applications such as

-sta kichen areas in shops, o ces and other working environments;

-farm houses and by clients in hotels, motels and other residential type environment;

-bed and breakfast type environments; -cetering and similar non-retail application.

10 EN

3 Installation

B In case the information which are given in the user manual are not taken into account, manufacturer will

not assume any liability for this.

Points to be paid attention to when the relocation of the refrigerator

1.Your refrigerator should be unplugged.Before transportation of your refrigerator, it should be emptied and cleaned.

2.Before it is re-packaged, shelves, accessories, crisper, etc. inside your refrigerator should be fixed with adhesive tape and secured against impacts. Package should

be bound with a thick tape or sound ropes and the transportation rules on the package should be strictly observed.

3.Original packaging and foam materials should be kept for future transportations or moving.

Before you start the refrigerator,

Check the following before you start to use your refrigerator:

1.Clean the interior of the refrigerator as recommended in the “Maintenance and cleaning” section.

2.Connect the plug of the refrigerator to the wall socket. When the fridge door is opened, fridge internal lamp will turn on.

3.When the compressor starts to operate, a sound will be heard. The liquid and gases sealed within the refrigeration system may also give rise to noise, even if the compressor is not running and this is quite normal.

4. Front edges and both sides of the refrigerator may feel warm. This is normal. These areas are designed to be warm to avoid condensation.

Electrical connection

Connect your product to a grounded socket which is being protected by a fuse with the appropriate capacity.

Important:

The connection must be in compliance with national regulations.

•The power plug must be easily accessible after installation.

•Electrical safety of your refrigerator shall be guaranteed only if the earth system in your house complies with standards.

•The voltage stated on the label located at left inner side of your product should be equal to your network voltage.

•Extension cables and multi plugs must not be used for connection.

11 EN

B A damaged power cable must be replaced by a qualified electrician.

B Product must not be operated before it is repaired! There is the risk of

electric shock!

Disposing of the packaging

The packing materials may be dangerous for children. Keep the packing materials out of the reach of children or dispose of them by classifying them in accordance with the waste instructions stated by your local authorities. Do not throw away with regular house waste, throw away on packaging pick up spots designated by the local authorities.

The packing of your refrigerator is produced from recyclable materials.

Disposing of your old refrigerator

Dispose of your old refrigerator without giving any harm to the environment.

•You may consult your authorized dealer or waste collection center of your municipality about the disposal of your refrigerator.

Before disposing of your refrigerator, cut out the electric plug and, if there are any locks on the door, make them inoperable in order to protect children against any danger.

Placing and Installation

A If the entrance door of the room where the refrigerator will be installed is not wide enough for the refrigerator to pass through, then call the authorized service to have them remove the doors of your refrigerator and pass it sideways through the door.

1.Install your refrigerator to a place that allows ease of use.

2.Keep your refrigerator away from heat sources, humid places and direct sunlight.

3.There must be appropriate air ventilation around your refrigerator in order to achieve an efficient operation. If the refrigerator is to be placed in a recess in the wall, there must be at least 5 cm distance with the ceiling and at least 5 cm with the wall. Do not place your product on the materials such as rug or carpet.

4.Place your refrigerator on an even floor surface to prevent jolts.

12 EN

Adjusting the legs

If your refrigerator is unbalanced;

You can balance your refrigerator by turning its front legs as illustrated in the figure. The corner where the leg exists is lowered when you turn in the direction of black arrow and raised when you turn in the opposite

direction. Taking help from someone to slightly lift the refrigerator will facilitate this process.

Changing the illumination lamp

To change the Bulb/LED used for illumination of your refrigerator, call your AuthorisedService.

The lamp(s) used in this appliance is not suitable for household room

illumination. The intended purpose of this lamp is to assist the user to place foodstuffs in the refrigerator/freezer

in a safe and comfortable way.The lamps used in this appliance have to withstand extreme physical conditions such as temperatures below -20 °C.

(only chest and upright freezer)

Door Open Warning

*May not be available in all models

An audio warning signal will be given when the door of your product is left open for at least 1 minute. This

warning will be muted when the door is closed or any of the display buttons (if any) are pressed.

13 EN

	100 mm
	50 mm
	50 mm
50 mm	50 mm

		)
		A
		(
		m
		m
115	̊(C)	5
		7
		2
		1

1001 mm (B)

14 EN

4	Preparation
•	Your cooler/freezer should be	Electronic Temperature Control
installed at least 30 cm away from		System. For the first installation, the
heat sources such as hobs, ovens,		product should NOT be placed under
central heater and stoves and at least		low ambient temperatures. This is
5 cm away from electrical ovens and		because the freezer cannot go down
should not be located under direct		to standard operation temperature.
sunlight.		When reaching continuous operation,
• Please make sure that the interior		the product can be moved to
of your cooler/freezer is cleaned		another place. Thus, later you can
thoroughly.		place your product in the garage
• If two coolers are to be installed side		or an unheated room without the
by side, there should be at least 2 cm		concern of causing frozen food to
distance between them.		get rotten. However, it is likely that
• When you operate your cooler/freezer		above mentioned low temperatures
for the first time, please observe the		may cause the freezing of the food in
following instructions during the initial		the fridge compartment; thus, please
six hours.		consume the food items in the fridge
• Its door should not be opened		in a controlled way as needed. When
frequently.		ambient temperature goes back
• It must be operated empty without		to normal, you may change button
placing any food in it.		setting according to your need.
• Do not unplug your cooler/freezer.		• If the ambient temperature is below
If a power failure occurs out of your		0°C, the food in fridge compartment
control, please see the warnings in		will freeze. Therefore, we recommend
the “Recommended solutions for the		not using the fridge compartment
problems” section.		in such low ambient temperatures.
• The baskets/drawers that are		You may continue to use the freezer
provided with the chill compartment		compartment as usual.
must always be in use for low energy		• In some models, the instrument panel
consumption and for better storage		automatically turns off 5 minutes
conditions.		after the door has closed. It will
• Food contact with the temperature		be reactivated when the door has
sensor in the freezer compartment		opened or pressed on any key.
may increase energy consumption of		• Due to temperature change as a
the appliance. Thus any contact with		result of opening/closing the product
the sensor(s) must be avoided.		door during operation, condensation
• This product has been designed to		on the door/body shelves and the
function at ambient temperatures		glass containers is normal.
up to 43 °C (90 SDgrF). Even if the
ambient temperature falls to -15
°C, frozen food in the freezer does
not thaw thanks to its Advanced

15 EN

5 Using your refrigerator

Indicator panel (External Display) *Optional

Indicator panel allows you to set the temperature and control the other functions related to the product without opening the door of the product. Just press the inscriptions on relevant buttons for function settings.

1 2

12

11 *10

9

8

7

1. Power failure/High temperature / error warning indicator

This indicator () illuminates during power failure, high temperature failures and error warnings. During sustained power failures, the highest temperature that the freezer compartment reaches y. After checking the food located in the freezer compartment () press the alarm orning.

Please refer to "remedies advised for troubleshooting" section on your manual if you observe that this indicator is illuminated.

6	5	4		3

2. Energy saving function (display

If the product doors are kept closed for a long time energy saving function is automatically activated and energy saving symbol is illuminated. ()

When energy saving function is activated, all symbols on the display other than energy saving symbol will turn o

function is activated, if any button is pressed or the door is opened, energy saving function will be canceled and the symbols on display will return to normal.

Figures that take place in this instruction manual are schematic and may not correspond exactly with your product. If the subject parts are not included in the product you have purchased, then it is valid for other models.

16 EN

Energy saving function is activated during delivery from factory and cannot be canceled.

3.Quick fridge function

The button has two functions. To activate or deactivate the quick cool function press it briefly. Quick Cool indicator will turn off and the product will return to its normal settings. ( )

CUse quick cooling function when you want to quickly cool the food placed in the fridge compartment. If you want to cool large amounts of fresh food, activate this function before putting the food into

.the product

CIf you do not cancel it, quick cooling will cancel itself automatically after 1 hours or when the fridge compartment reaches to the required

.temperature

CIf you press the quick cooling button repeatedly with short intervals, the electronic circuit protection will be activated and the compressor will not

.start up immediately

CThis function is not recalled when power restores after a

.power failure

4.Fridge compartment temperature setting button

Press this button to set the temperature of the fridge compartment to 8, 7,6, 5,4,3, 2, 8... respectively. Press this button to set the fridge

compartment temperature to the desired value. ()

5.Vacation Function

In order to activate vacation function, press the this button ( ) for 3 seconds, and the vacation mode indicator () will be activated. When the vacation function is activated, “- -” is displayed on the fridge compartment temperature indicator and no active cooling is performed on the fridge compartment. It is not suitable to keep the food in the fridge compartment when this function is activated. Other compartments shall be continued to be cooled as per their set temperature.

To cancel this function press Vacation function button again.

6. Alarm off warning:

In case of power failure/high temperature alarm, after checking the food located in the freezer compartment press the alarm off button () to clear the warning.

7. Key lock

Press key lock button ( ) simultaneously for 3 seconds. Key lock symbol

( ) will light up and key lock mode will be activated. Buttons will not function if the Key lock mode is active. Press key lock button simultaneously for 3 seconds again. Key lock symbol will turn off and the key lock mode will be exited.

Press the key lock button if you want to prevent changing of the temperature setting of the refrigerator ( ).

8. Eco fuzzy

Press and hold eco fuzzy button for 1 seconds to activate eco fuzzy function. Refrigerator will start operating in

the most economic mode at least 6 hours later and the economic usage

17 EN

indicator will turn on when the function

is active ( ). Press and hold eco fuzzy function button for 3 seconds to deactivate eco fuzzy function.

This indicator is illuminated after 6 hours when eco fuzzy is activated.

9.Freezer compartment temperature setting button

Press this button to set the temperature of the freezer compartment to-16,-17,-18,-19,-20,- 22,-24,-16... respectively. Press this

button to set the freezer compartment temperature to the desired value.()

10.Icematic function (optional)

Indicates whether the icematic is on

or off. ()If On, then the icematic is not operating. To operate the icematic again press and hold the On-Off button for 3 seconds.

CWater flow from water tank will stop when this function is selected. However, ice made previously can be taken from

.the icematic

11.Quick freeze function button

Press this button to activate or deactivate the quick freezing function. When you activate the function, the freezer compartment will be cooled to

a temperature lower than the set value. ()

CUse the quick freeze function when you want to quickly freeze the food placed in fridge compartment. If you want to freeze large amounts of fresh food, activate this function before putting the food into

.the product

CIf you do not cancel it, Quick Freeze will cancel itself automatically after 24 hours or when the fridge compartment reaches to the required

.temperature

CThis function is not recalled when power restores after a

.power failure

12.Economic usage indicator

Indicates that the product is running

in energy-efficient mode. ()This indicator will be active if the Freezer Compartment temperature is set to -16 or the energy efficient cooling is being performed due to Eco-Extra function.

CEconomic usage indicator is turned off when quick cooling or quick freeze functions are

.selected

18 EN

5 Using your refrigerator

Indicator panel (Internal Display) *Optional

Indicator panels may vary according to the product model.

Audio – visual functions on the indicator panel helps you in using your product.

8								7				2								3

9

1

6

5

4

1.Freezer compartment indicator

2.Error status indicator

3.Temperature indicator

4.Vacation function button

5.Temperature setting button

6.Compartment selection button

7.Fridge Compartment Indicator

8.Economy mode indicator

9.Vacation function indicator

*optional

Figures that take place in this instruction manual are schematic and may not correspond exactly with your product. If the subject parts are not included in the product you have purchased, then it is valid for other models.

19 EN
