Refrigerator-Freezer type I |
|
RCNA340K30ZX |
|
||
|
|
|
Please read this user manual first!
Dear Customer,
We hope that your product, which has been produced in modern plants and checked under the most meticulous quality control procedures, will provide you an effective service.
Therefore, read this entire user manual carefully before using the product and keep it as a reference. If you handover the product to someone else, give the user manual as well.
The user manual will help you use the product in a fast and safe way.
Read the manual before installing and operating the product.
Make sure you read the safety instructions.
Keep the manual in an easily accessible place as you may need it later.
Read the other documents given with the product.
Remember that this user manual is also applicable for several other models. Differences between models will be identified in the manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
C A B
Important information or useful tips.
Warning against dangerous conditions for life and property.
Warning against electric voltage.
CONTENTS
1 |
Your refrigerator |
34 |
|
|
|
|
|
2 |
Important Safety Warnings |
45 |
|
5 |
|
|
|
Intended use......................................... |
4 |
||
General safety....................................... |
4 |
||
For products with a water dispenser...... |
6 |
||
Child safety............................................ |
6 |
||
Compliance with the WEEE Regulation and Disposing of the Waste Product….. 6
Package information.............................. |
7 |
HCA warning.......................................... |
7 |
Things to be done for energy saving….. 7
3 Installation |
89 |
Points to be paid attention to when the |
|
relocation of the refrigerator.................... |
8 |
Before you start the refrigerator,............ 8
Electrical connection............................ |
9 |
Disposing of the packaging.................. |
9 |
Disposing of your old refrigerator......... |
9 |
Placing and Installation........................ |
9 |
Changing the illumination lamp ............ |
9 |
Adjusting the legs................................ |
9 |
2
4 |
Preparation |
112 |
5 |
Using your refrigerator |
123 |
Thermostat setting button................... |
12 |
|
Moisture controlled vegetable bin …… 12 |
||
Defrost………………............................ 13 |
||
Freezing fresh food............................... |
14 |
|
Icematic and ice storage container …. 15 |
||
Recommendations for preservation |
|
|
of frozen food.................................... |
15 |
|
Recommendations for the fresh food |
|
|
compartment...................................... |
15 |
|
Reversing the doors.......................... |
16 |
|
6 |
Maintenance and cleaning |
17 |
Avoiding bad odours…………………. |
17 |
|
Protection of plastic surfaces .............. |
17 |
|
7 |
Troubleshooting |
1820 |
EN
1 Your refrigerator
1. |
Setting knob and interior light |
10. |
Compartments for frozen foods keeping |
2. |
Fresh Food fan |
11. |
Adjustable front feet |
3. |
Wine bottles support |
12. |
Dairy Compartment |
4. |
Adjustable Cabinet shelves |
13. |
Shelf for jars |
5. |
Controlled vegetable bin cover |
14. |
Shelf for bottles |
6. |
Controlled vegetable bin |
15. |
Freezer fan |
7.Icebank tray
8.Ice tray support & ice tray
9.Compartment for quickly freezing
C Figures that take place in this instruction manual are schematic and may not correspond exactly with your product. If the subject parts are not included in the product you have purchased, then it is valid for other models.
3 EN
2 Important Safety Warnings
Please review the following information. Failure to observe this information may cause injuries or material damage. Otherwise, all warranty and reliability commitments will become invalid.
The service life of your product is 10 years. During this period, original spare parts will be available to operate the product properly.
Intended use
This product is intended to be used
indoors and in closed areas such as homes;
in closed working environments such as stores and offices;
in closed accommodation areas such as farm houses, hotels, pensions.
It should not be used outdoors.
General safety
When you want to dispose/scrap the product, we recommend you to consult the authorized service in
order to learn the required information and authorized bodies.
Consult your authorized service for all your questions and problems related to the refrigerator. Do not intervene or let someone intervene to the refrigerator without notifying the authorised services.
For products with a freezer compartment; Do not eat cone ice cream and ice cubes immediately after you take them out of the freezer compartment! (This may cause frostbite in your mouth.)
For products with a freezer compartment; Do not put bottled and canned liquid beverages in the freezer compartment. Otherwise, these may burst.
Do not touch frozen food by hand; they may stick to your hand.
Unplug your refrigerator before cleaning or defrosting.
Vapor and vaporized cleaning materials should never be used in cleaning and defrosting processes of your refrigerator. In such cases, the vapor may get in contact with the electrical parts and cause short circuit or electric shock.
Never use the parts on your refrigerator such as the door as a means of support or step.
Do not use electrical devices inside the refrigerator.
Do not damage the parts, where the refrigerant is circulating, with
drilling or cutting tools. The refrigerant that might blow out when the gas channels of the evaporator, pipe extensions or surface coatings are punctured causes skin irritations and eye injuries.
Do not cover or block the ventilation holes on your refrigerator with any material.
Electrical devices must be repaired by only authorised persons. Repairs performed by incompetent persons create a risk for the user.
4 EN
In case of any failure or during a maintenance or repair work,
disconnect your refrigerator’s mains supply by either turning off the relevant fuse or unplugging your appliance.
Do not pull by the cable when pulling off the plug.
Never store spray cans containing flammable and explosive substances in the refrigerator.
Do not use mechanical devices or other means to accelerate the
defrosting process, other than those recommended by the manufacturer.
This product is not intended to be used by persons with physical, sensory or mental disorders or unlearned or inexperienced people (including children) unless they are attended by a person who will be responsible for their safety or who will instruct them accordingly for use of the product.
Do not operate a damaged refrigerator. Consult with the service agent if you have any concerns.
Electrical safety of your refrigerator shall be guaranteed only if the earth system in your house complies with standards.
Exposing the product to rain, snow, sun and wind is dangerous with respect to electrical safety.
Contact authorized service when there is a power cable damage to avoid danger.
Never plug the refrigerator into the wall outlet during installation. Otherwise, risk of death or serious injury may arise.
5
This refrigerator is intended for only storing food items. It must not be used for any other purpose.
Label of technical specifications is located on the left wall inside the refrigerator.
Never connect your refrigerator to electricity-saving systems; they may damage the refrigerator.
If there is a blue light on the refrigerator, do not look at the blue light with optical tools.
For manually controlled refrigerators, wait for at least 5 minutes to start the refrigerator after power failure.
This operation manual should be handed in to the new owner of the product when it is given to others.
Avoid causing damage on power cable when transporting the refrigerator. Bending cable may cause fire. Never place heavy objects on power cable.
Do not touch the plug with wet hands when plugging the product.
Do not plug the refrigerator if the wall outlet is loose.
Water should not be sprayed on inner or outer parts of the product for safety purposes.
EN
Do not spray substances containing inflammable gases such as propane gas near the refrigerator to avoid fire and explosion risk.
Never place containers filled with water on top of the refrigerator; in the event of spillages, this may cause electric shock or fire.
Do not overload the refrigerator with food. If overloaded, the food items may fall down and hurt you and damage refrigerator when you open the door.
Never place objects on top of the refrigerator; otherwise, these objects may fall down when you open or close the refrigerator's door.
As they require a precise temperature, vaccines, heat-sensitive medicine and scientific materials
and etc. should not be kept in the refrigerator.
If not to be used for a long time, refrigerator should be unplugged. A possible problem in power cable may cause fire.
The plug's tip should be cleaned regularly with a dry cloth; otherwise, it may cause fire.
Refrigerator may move if adjustable legs are not properly secured on the floor. Properly securing adjustable legs on the floor can prevent the refrigerator to move.
When carrying the refrigerator, do not hold it from door handle. Otherwise, it may be snapped.
When you have to place your product next to another refrigerator or freezer, the distance between devices should be at least 8cm. Otherwise, adjacent side walls may be humidified.
For products with a water dispenser;
Pressure of water mains should be minimum 1 bar. Pressure of water mains should be maximum 8 bars.
Use only potable water.
Child safety
If the door has a lock, the key should be kept away from reach of children.
Children must be supervised to prevent them from tampering with the product.
Compliance with the WEEE Regulation and Disposing of the Waste Product
The symbol
on the product or on packaging indicates that this product may not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling of this product, please contact your local city office, you household waste disposal service or the shop where you purchased the product.
6 EN
