Bakemax BMDSD01 BMTSD05 Installation Manual

Slush Machine

BMDSD01 BMTSD05

1 . Exterior layout

 BMDSD01
 BMTSD05

2. Setup

 Installation

Contents

 Operation
 Cleaning and maintenance

3. How to Operate

4. Troubleshooting

5. General Specifications

6. Circuit Diagram

7. Parts List

1. Exterior layout

BMDSD01

BMTSD05

2. Set Up

Installation Instructions

Transportation and unpacking

1. Do not slant the machine over 45°

2. Unpack the product with care to ensure no damage.

3. Do not move the machine while it is full.

Location

1. This machine is designed for indoor use only.

2. Locate on a flat, solid and level surface.

3. Do not install.

a. in direct sunlight or adjacent to heat sources such as stove tops or ovens.
b. where the machine is subject to excessive moisture.
c. where the machine may come in contact with gas, oil or electrical leakage.

4. The machine can be leveled by screw adjusting the rubber legs if necessary.

Electrical Requirements

1. The machine is designed for use with 220volts { ± 10%).

2. Do not use this machine with a double adaptor or extension cord.

3. Where multiple machines are on a single circuit ensure the total power

requirement does not exceed the circuit capacity.

4. Ensure the machine is properly earthed.
