AT&T AT3101 User Manual

User’s manual

AT3101 Expansion DECT 6.0

cordless handset

For use with the AT&T AT3111-2 telephone system with caller ID/call waiting

Congratulations

on purchasing your

new AT&T product.

Before using this AT&T product, please

read the Important safety instructions

on pages 18-21 of this manual.

Please thoroughly read the user’s

manual for all the feature operations

and troubleshooting information necessary to

install and operate your new AT&T product.

For complete instructions, please refer to the manual provided with your AT3111-2

telephone

Model #: AT3101

Type:

Serial #:

Purchase date:

Expansion DECT 6.0 digital cordless handset

Place of purchase:

The ENERGY STAR® program (www.energystar.gov) recognizes and encourages the use of products that save energy and help protect our environment. We are proud to mark this product with the ENERGY STAR® label indicating it meets the latest energy efficiency guidelines.

You must install and charge the battery before using the telephone.

CAUTION: To reduce t he risk of fire or injury to per sons or damage to the telephone, read and follow these instructions careful ly :

• Use only the supplied rechargeable battery or replacement battery (model: BT8001) or equivalent.

• Do not dispose of the battery in a fire. Like other ba tteries of this type, it could explod e i f burned. Check with local codes for sp ecial disposal in struction s.

• Do not open or mut ilate the battery. Rele ased electrolyte is corrosive and may cause dam age to the eyes or skin. It may b e toxic if swallowed.

• Exerc ise care in handling ba tter ies in order not to create a short circuit. Do not allow conductive mater ials such as rin gs, bracelets, or keys to touch the battery. The battery or conductor may overhe at and cause harm.

• Charge the battery provided wi th or identifie d for use with this product only in accordance wit h the instructions and limitat ions specifie d i n t his manual.

• Observe proper pol arity orientation betwee n t he battery and battery charger.

• Do not disassemble your telephone. There are n o user-servi ceable parts inside. Refer to qua lified servi ce pe rsonnel for servi cing.

STOP!

See page 3

for easy instructions.

Getting started

Parts checklist

Your new AT&T AT3101 expansion handset includes:

Cordless telephone handset

User’s manual

AT3101 Expansion DECT 6.0 cordless handset

For use with the AT&T AT3111-2 telephone system with caller ID/call waiting

User's manual

Handset battery

Power adapter for handset charger

Table of contents

Getting started

Parts checklist .......................1

Charger installation ..............2

Battery installation and .

charging...............................3

Adding your new

handset ................................4

Replacing a handset ............5

Handset layout .......................6

Belt clip & headset ...............7

Battery compartment cover

Charger for cordless handset

Appendix

Troubleshooting .....................8

Important safety

instructions .....................18

FCC Part 68 and ACTA ....22

FCC Part 15 ...........................25

Limited warranty .................27

Technical specifications ..31

Belt clip

Getting started

Charger installation

Install the charger as shown below. Make sure that the electrical outlet is not controlled by a wall switch.

1. Plug the small end of the smaller power adapter into the jack on the underside of the charger, then route the cord through the slot as shown.

NOTES:

1. Use only the power adapter supplied with this product or equivalent.

2. This power unit is intended to be correctly oriented in a vertical or floor mount position. The prongs are not designed to hold the plug in place if it is plugged into a ceiling or an under-the-table/cabinet outlet.

2. Plug the large end of the smaller power adapter into an electrical outlet .

Getting started

HB9wwwwW,wwwwwwww

EBBHC9WWwww,wwww,ww

HB9wwwwW,wwwwwwww

EBBHC9WWwww,wwww,ww

HB9wwwwW,wwwwwwww

EBBHC9WWwww,wwww,ww

Battery installation & charging

The battery may have enough charge for short calls. For optimal performance, 16 hours. You can keep the battery charged by returning the handset to the telephone base after each use. When the battery power is fully depleted, a full recharge takes about 16 hours. When fully charged, the handset battery provides approximately eight hours of talk time and four days of standby time.

we recommend that you charge the handset for

1. Align the two holes of the battery plug with the socket pins in the handset battery compartment, matching the red and black wires to the color-coded label.

2. Place the battery in the compartment with the wires in the lower right corner.

3. Position the battery compartment cover and slide it towards the unit until it clicks into place.

4. Charge the handset by placing the handset face up in the telephone base or in the charger. The CHARGE light will be on when charging.

IMPORTANT INFORMATION

1. Use only the supplied rechargeable battery or replacement battery (model BT8001).

2. See the Troubleshooting section on pages 8-17 for charging issues.

Getting started

NOT REGISTERED

PRESS FIND HNDST

4 SEC ON BASE

PL E ASE W A IT . . .

HS X

REGISTERED

Adding your new handset

Handsets purchased separately need to be registered to the telephone base before use. When first purchased, all optional accessory handsets will show

NOT REGISTERED on the screen. The new

handset may need to be charged for five minutes before registering to the main telephone base.

To register a handset to your telephone base

1. Place the unregistered handset into the telephone base. If

SEC ON BASE

handset screen after a few seconds, remove the handset and place it in the telephone base again.

2. On the telephone base, press and hold FIND

HANDSET for about four seconds (until

the red IN USE light on the telephone base turns on) and then release the button. The handset will show

WAIT...

and it will take about 10 seconds

to complete the registration. The handset will show

HS X REGISTERED

if registration is successful.

NO TE S:

1. If the regi stration is not successfu l, the display will show NOT REGISTERED. To reset t he handset, re move the handse t from the telep hone base and place it back in. Try the registration process aga in.

2. You cann ot register a handset if any telep hone connecte d t o the same telep hone line is in use .

PRESS HNDST LOC 4

does not appear on the

PLEASE

and will beep

Getting started

Replacing a handset

When you are replacing rather than adding a handset, for your handsets to be numbered sequentially, you need to delete all the handset registrations on the telephone base.

To de-register all handsets

1. Press and hold FIND HANDSET on the telephone base for about 10 seconds (until the IN USE light turns on and starts to flash), then release the FIND HANDSET button.

2. Immediately press and release FIND HANDSET again. You must press FIND HANDSET while the IN USE light is still flashing. The IN USE light will flash for approximately seven seconds.

3. Soon the handsets will show CONNECTING... and it will take about 10 seconds to complete the de-registration process. All handsets will show NOT REGISTERED if deregistration is successful.

NOT REGISTERED

After deleting all handset registrations, you will need to individually register each handset with the telephone base (see page 4 for registration instructions).

NO TE S:

1. If the de-r egistration process is not s uccessful , you may need to re set the system and try again. To reset: pick up the handset and press the /FL ASH bu tton, then pres s the OFF/CLEA R button and plac e the handset ba ck into the tele phone base. You may also reset b y unpluggi ng the power from the telephone ba se then pluggin g

it back in.

2. You cann ot de-regist er the handset( s) if any telephone connecte d t o the telepho ne line is in use.

Getting started

HANDSET 1

Handset layout

1. Earpiece

2. MENU/SELECT

SKIP

3. Headset jack (2.5mm)

4. CID (caller ID)

PLAY

5. /FLASH

6. Dialing keys (0-9, *, #)

7. VOICEMAIL

8. REDIAL/PAUSE

9. Microphone

10. Handset display

11. VOL / (volume)

12. (directory) ERASE

13. (speakerphone)

14. OFF/CLEAR

15. #

16. INT (intercom)

17. MUTE/REMOVE

Getting started

HANDSET 1

IC:xxxxX-xxxxxxxx

FCC ID: XXxxx-xxxx-xx

IC:xxxxX-xxxxxxxx

FCC ID: XXxxx-xxxx-xx

IC:xxxxX-xxxxxxxx

FCC ID: XXxxx-xxxx-xx

IC:xxxxX-xxxxxxxx

FCC ID: XXxxx-xxxx-xx

Belt clip & optional headset

Install belt clip as shown below if desired:

Installation

Snap belt clip into notches on both sides of handset.

Pull and unlock one flap from the notch first before detaching the whole belt clip from handset.

For hands-free telephone conversations, use any industry standard 2.5mm headset (purchased separately). For best results, use a AT&T 2.5mm headset.

Plug the 2.5 mm headset into the jack on the side of the handset (beneath the small rubber flap).

Removal

NO TE : If the sound

quality of the headset is not sat isfa ctory, try unplugging it, and firmly plugging it in again.

Appendix

Troubleshooting

If you have difficulty with your telephone, please try the suggestions below.

My phone doesn’t work at all

I cannot get a dial tone

• Make sure the power cord is securely plugged in.

• Make sure that the battery connector is securely plugged into the cordless handset.

• Make sure the telephone line cord is securely and firmly plugged into the telephone base and the telephone wall jack.

• Charge the battery in the cordless handset for at least 16 hours. For optimum daily performance, return the cordless handset to its base when not in use.

• Reset the telephone base. Unplug the unit’s electrical power. Wait for approximately 15 seconds, then plug it back in. Allow up to one minute for the cordless handset and telephone base to reset.

• You may need to purchase a new battery, please refer to page 3 of this user’s manual.

• First try all the suggestions above.

• Move the cordless handset closer to the telephone base. You might have moved out of range.
