AT&T 9357 User Manual

900 MHz Cordless

Answering System with

Caller ID/Call Waiting 9357

Please also read

Part 1 — Important

Product Information

USER’S MANUAL

Part 2

AT&T and the globe symbol are registered trademarks of AT&T Corp. licensed to Advanced American Telephones.

DRAFT 7/6/01

9357_book/wc_1ATT 7/6/01 4:10 PM Page ii

Printed in China. Issue 1AT&T 07/01

9357_book/wc_1ATT 7/6/01 4:10 PM Page iii

BEFORE YOU BEGIN . . . . . .1

About Caller Identification ............1

INSTALLATION . . . . . . . . . .2

Before You Install ...........................2

Table/Desk Installation...................4

Wall Installation..............................5

TELEPHONE OPERATION . . .6

Answer a Call .................................6

Make a Call.....................................6

End a Call .......................................6

Redial .............................................6

Flash/Call Waiting...........................6

Hold ...............................................6

Change Channel.............................6

Handset Volume .............................6

Page/Handset Locator ....................7

Handset Ringer Style/

Battery Save ................................8

Temporary Tone Dialing.................8

Headset Jack...................................8

Operating Range ............................9

Display Screen Messages................9

TELEPHONE MEMORY . . . .10

Store Memory Numbers...............10

Edit Numbers Stored

in Memory ................................11

Delete Numbers Stored

in Memory ................................12

Dial Memory Numbers.................12

CALLER ID OPERATION . . .13

About Call History .......................13

Review Call History .....................13

Delete Records from

Call History .............................. 14

Dial a Displayed Number.............14

Store a Call History Record

in Memory ................................15

Display Screen Messages............. 15

ANSWERING SYSTEM OPERATION

AT THE BASE . . . . . . . . . . . . . .16

Audible Indicators........................16

Set the Clock................................16

About Mailboxes ..........................16

About Announcements ................16

Record Your Announcement ........17

Answering System

Feature Setup............................18

Feature Summary .........................18

Listen To, Save

& Delete Messages....................19

Call Screening/Intercept ..............20

Record a Memo............................20

Message Window Display.............20

ANSWERING SYSTEM OPERATION

AT TOUCH TONE PHONE . . . . . . .21

Connect With the

Answering System ....................21

Voice Menu ..................................21

Remote Access Commands ..........21

BATTERIES . . . . . . . . . . .23

Charging the Handset

Battery Pack..............................23

Replacing the Handset

Battery Pack..............................24

IN CASE OF DIFFICULTY . . .25

CONTENTS

9357_book/wc_1ATT 7/6/01 4:10 PM Page iv

About Caller Identification (Caller ID)

This product has a Caller ID with Call Waiting feature that works with service from your local phone service provider.

Caller ID with Call Waiting lets you see who’s calling before you answer the phone, even when you’re on another call.

You may need to change your phone service to use this feature. Contact your phone service provider if:

• You have both Caller ID and Call Waiting, but as separate services (you may need combined service)

• You have only Caller ID service, or only Call Waiting service

• You don’t subscribe to any Caller ID or Call Waiting services.

You can use this product with regular Caller ID service, and you can use this product’s other features without subscribing to either Caller ID or combined Caller ID with Call Waiting service.

There are fees for Caller ID services, and they may not be available in all areas.

This product can provide information only if both you and the caller are in areas offering Caller ID service, and if both telephone companies use compatible equipment.

BEFORE YOU BEGIN

9357_book/wc_1ATT 7/6/01 4:10 PM Page 1

Before You Install

1 Choose a location for the base near an electrical outlet and a

telephone jack.

This phone requires a modular telephone jack and a standard electrical outlet (110v AC) not controlled by a wall switch.

2 Install the handset battery.

INSTALLATION

b) Align two holes in

plug with socket pins, and snap the plug into place.

d) Replace

cover by sliding it up into place.

a) Remove battery

compartment cover by pressing on the indentation and sliding downward.

c) Place battery pack

in compartment with the wires in the lower left corner,along the bottom of the battery pack.

9357_book/wc_1ATT 7/6/01 4:10 PM Page 2

INSTALLATION

3 Attach belt clip to the cordless handset (optional).

To attach

To re mov e

9357_book/wc_1ATT 7/6/01 4:10 PM Page 3

Use only the power cord supplied with this product. If you need a replacement, call 1 800 222–3111.

3 Charge the handset battery.

Place the handset in the base. Charge the battery for at least 16 hours the first time.

4 Check for dial tone.

After the batteries are charged, pick up the handset and press P; you should hear a dial tone.

5 Set the dial mode.

If you have touch tone service, the phone is ready to use as soon as the batteries are charged.

If you have dial pulse (rotary) service, you’ll need to change the dial mode.

• Press G on the handset to enter programming mode.

• Press < or > until the screen displays DIAL MODE: and the currently selected mode.

• Press s. The current setting blinks.

• Press > to select TONE or PULSE.

• Press s, to save the displayed mode.

INSTALLATION

Modular telephone jack

Standard

electrical

outlet

Table/Desk Installation

1 Connect the

telephone line cord.

2 Connect the power cord.

CL flashes in the Message Window.

9357_book/wc_1ATT 7/6/01 4:10 PM Page 4

INSTALLATION

Wall Installation

1 Connect the telephone line cord. 2 Connect the power cord.

CL flashes in the Message Window.

Use only the power cord supplied with this product. If you need a replacement, call 1 800 222–3111.

3 Mount the base on the wall.

4 Follow Steps 3–5 in “Table/Desk Installation.”

a) Align holes

on base with mounting studs on wall jack.

b) Place power

cord as shown.

c) Pull base

down on mounting studs until it locks into place.

9357_book/wc_1ATT 7/6/01 4:10 PM Page 5

TELEPHONE OPERATION

End a Call

Press O

— OR —

Place handset

in base.

Exit

programming.

Cancel a page.

Handset Volume

While on a call,

adjust volume

of what you hear.

Hold

Press to put a call on hold. Press again to release hold

— OR —

Lift the handset of an extension.

Answer a Call

Press any key except O.

Change Channel

Switch to a clearer channel

while on a call.

Enter programming while not on a call.

Redial

Press P,then

press r to

call last number dialed

(up to 32 digits).

Make a Call

Press P, then dial the number

— OR —

Dial the number (use < to backspace and correct digits), then press P to call.

Flash/ Call Waiting

Access special telephone company subscriber services.

9357_book/wc_1ATT 7/6/01 4:10 PM Page 6

TELEPHONE OPERATION

Page/Handset Locator

Press once to page the handset for up to one minute; press twice to cancel.

Flashing quickly: a call is coming in Flashing slowly: the handset is in use On steadily: the handset is charging

Lit when there are unreviewed Caller ID records

9357_book/wc_1ATT 7/6/01 4:10 PM Page 7
