ASUS M2N32 WS User Manual

Motherboard

M2N32 WS

Professional

ii

E2560

First Edition V1
May 2006

Copyright © 2006 ASUSTeK COMPUTER INC. All Rights Reserved.

No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK COMPUTER INC. (“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the

product is defaced or missing.

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be registered trademarks or

copyrights of their respective companies, and are used only for identication or explanation and to the
owners’ benet, without intent to infringe.

iii

Contents

Notices ........................................................................................................ vii

Safety information .................................................................................... viii

About this guide ......................................................................................... ix

M2N32 WS Professional specications summary ................................... xi

Chapter 1: Product introduction

1.1 Welcome! ...................................................................................... 1-1

1.2 Package contents .........................................................................

1-1

1.3 Special features ............................................................................

1-2

1.3.1 Product highlights ...........................................................

1-2

1.3.2 ASUS Special features ...................................................

1-5

Chapter 2: Hardware information

2.1 Before you proceed ..................................................................... 2-1

2.2 Motherboard overview .................................................................

2-2

2.2.1 Placement direction ........................................................

2-2

2.2.2 Screw holes ....................................................................

2-2

2.2.3 ASUS Stack Cool 2 .........................................................

2-3

2.2.5 Motherboard layout .........................................................

2-4

2.2.4 Layout contents ...............................................................

2-5

2.3 Central Processing Unit (CPU) ...................................................

2-7

2.3.1 Installing the CPU ...........................................................

2-7

2.3.2 Installing the heatsink and fan ........................................

2-9

2.4 System memory .........................................................................

2-12

2.4.1 Overview .......................................................................

2-12

2.4.2 Memory congurations ..................................................

2-13

2.4.3 Installing a DIMM ..........................................................

2-15

2.4.4 Removing a DIMM ........................................................

2-15

2.5 Expansion slots ..........................................................................

2-16

2.5.1 Installing an expansion card .........................................

2-16

2.5.2 Conguring an expansion card .....................................

2-16

2.5.3 Interrupt assignments ...................................................

2-17

2.5.4 PCI slot .........................................................................

2-18

2.5.5 PCI-X slots ....................................................................

2-18

2.5.6 PCI Express x1 slots .....................................................

2-18

2.5.7 Two PCI Express x16 slots ...........................................

2-18

iv

Contents

2.6 Jumper ........................................................................................ 2-25

2.7 Connectors .................................................................................

2-27

2.7.1 Rear panel connectors ..................................................

2-27

2.7.2 Internal connectors .......................................................

2-29

Chapter 3: Powering up

3.1 Starting up for the rst time ........................................................ 3-1

3.2 Powering off the computer ..........................................................

3-2

3.2.1 Using the OS shut down function ....................................

3-2

3.2.2 Using the dual function power switch ..............................

3-2

Chapter 4: BIOS setup

4.1 Managing and updating your BIOS ............................................ 4-1

4.1.1 ASUS Update utility ........................................................

4-1

4.1.2 Creating a bootable oppy disk .......................................

4-4

4.1.3 ASUS EZ Flash 2 utility ...................................................

4-5

4.1.4 Updating the BIOS ..........................................................

4-6

4.1.5 Saving the current BIOS le ............................................

4-8

4.1.6 ASUS CrashFree BIOS 3 utility ......................................

4-9

4.2 BIOS setup program ..................................................................

4-10

4.2.1 BIOS menu screen .........................................................

4-11

4.2.2 Menu bar ........................................................................

4-11

4.2.3 Legend bar ....................................................................

4-12

4.2.4 Menu items ...................................................................

4-12

4.2.5 Sub-menu items ............................................................

4-12

4.2.6 Conguration elds .......................................................

4-12

4.2.7 Pop-up window .............................................................

4-13

4.2.8 General help .................................................................

4-13

4.3 Main menu ..................................................................................

4-14

4.3.1 System Time ................................................................

4-14

4.3.2 System Date .................................................................

4-14

4.3.3 Language ......................................................................

4-14

4.3.4 Legacy Diskette A ........................................................

4-14

4.3.5 Primary IDE Master/Slave .............................................

4-15

4.3.6

First, Second, Third, Fourth, Fifth,

and Sixth SATA Master ..................................................................4-17

v

Contents

4.3.7 HDD SMART Monitoring ............................................... 4-18

4.3.8 Installed Memory ...........................................................

4-18

4.3.9 Usable Memory ............................................................. 4-18

4.4 Advanced menu .........................................................................

4-19

4.4.1 JumperFree Conguration ............................................

4-19

4.4.2 AI NET2 ........................................................................

4-22

4.4.3

PEG Link Mode ............................................................. 4-23

4.4.4 CPU Conguration ........................................................

4-23

4.4.5 Chipset ..........................................................................

4-27

4.4.6 PCIPnP .........................................................................

4-29

4.4.7 Onboard Device Conguration ......................................

4-30

4.5 Power menu ................................................................................

4-34

4.5.1 ACPI Suspend Type .....................................................

4-34

4.5.2 ACPI APIC Support ......................................................

4-34

4.5.3 APM Conguration ........................................................

4-35

4.5.4 Hardware Monitor .........................................................

4-37

4.6 Boot menu ..................................................................................

4-38

4.6.1 Boot Device Priority ......................................................

4-38

4.6.2 Removable Drives .........................................................

4-39

4.6.3 Hard Disk Drives ...........................................................

4-39

4.6.4 CDROM Drives .............................................................

4-39

4.6.5 Boot Settings Conguration .........................................

4-40

4.6.6 Security .........................................................................

4-41

4.7 Tools menu .................................................................................

4-43

4.7.1 ASUS Music Alarm ........................................................

4-43

4.7.2 ASUS O.C. Prole .........................................................

4-45

4.7.3 ASUS EZ Flash 2 ..........................................................

4-47

4.8 Exit menu ....................................................................................

4-48

vi

Contents

Chapter 5: Software support

5.1 Installing an operating system ................................................... 5-1

5.2 Support CD information ..............................................................

5-1

5.2.1 Running the support CD .................................................

5-1

5.2.2 Drivers menu ...................................................................

5-2

5.2.3 Utilities menu ..................................................................

5-3

5.2.4 Make Disk menu .............................................................

5-5

5.2.5 Manuals menu ................................................................

5-6

5.2.6 ASUS Contact information ..............................................

5-7

5.2.7 Other information ............................................................

5-7

vii

Notices

Federal Communications Commission Statement

This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:

•

This device may not cause harmful interference, and

•

This device must accept any interference received including interference that
may cause undesired operation.

This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with manufacturer’s
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:

•

Reorient or relocate the receiving antenna.

•

Increase the separation between the equipment and receiver.

•

Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.

•

Consult the dealer or an experienced radio/TV technician for help.

Canadian Department of Communications Statement

This digital apparatus does not exceed the Class B limits for radio noise emissions
from digital apparatus set out in the Radio Interference Regulations of the
Canadian Department of Communications.

This class B digital apparatus complies with Canadian ICES-003.

The use of shielded cables for connection of the monitor to the graphics card is

required to assure compliance with FCC regulations. Changes or modications

to this unit not expressly approved by the party responsible for compliance
could void the user’s authority to operate this equipment.

viii

Safety information

Electrical safety

•

To prevent electrical shock hazard, disconnect the power cable from the

electrical outlet before relocating the system.

•

When adding or removing devices to or from the system, ensure that the
power cables for the devices are unplugged before the signal cables are
connected. If possible, disconnect all power cables from the existing system
before you add a device.

•

Before connecting or removing signal cables from the motherboard, ensure
that all power cables are unplugged.

•

Seek professional assistance before using an adpater or extension cord.
These devices could interrupt the grounding circuit.

•

Make sure that your power supply is set to the correct voltage in your area.
If you are not sure about the voltage of the electrical outlet you are using,
contact your local power company.

•

If the power supply is broken, do not try to x it by yourself. Contact a
qualied service technician or your retailer.

Operation safety

•

Before installing the motherboard and adding devices on it, carefully read all
the manuals that came with the package.

•

Before using the product, make sure all cables are correctly connected and the
power cables are not damaged. If you detect any damage, contact your dealer
immediately.

•

To avoid short circuits, keep paper clips, screws, and staples away from
connectors, slots, sockets and circuitry.

•

Avoid dust, humidity, and temperature extremes. Do not place the product in
any area where it may become wet.

•

Place the product on a stable surface.

•

If you encounter technical problems with the product, contact a qualied

service technician or your retailer.

ix

About this guide

This user guide contains the information you need when installing and conguring

the motherboard.

How this guide is organized

This guide contains the following parts:

• Chapter 1: Product introduction

This chapter describes the features of the motherboard and the new
technology it supports.

• Chapter 2: Hardware information

This chapter lists the hardware setup procedures that you have to perform
when installing system components. It includes description of the switches,
jumpers, and connectors on the motherboard.

• Chapter 3: Powering up

This chapter describes the power up sequence and ways of shutting down
the system.

• Chapter 4: BIOS setup

This chapter tells how to change system settings through the BIOS Setup
menus. Detailed descriptions of the BIOS parameters are also provided.

• Chapter 5: Software support

This chapter describes the contents of the support CD that comes with the
motherboard package.

Where to nd more information

Refer to the following sources for additional information and for product and
software updates.

1. ASUS websites

The ASUS website provides updated information on ASUS hardware and
software products. Refer to the ASUS contact information.

2. Optional documentation

Your product package may include optional documentation, such as warranty

yers, that may have been added by your dealer. These documents are not

part of the standard package.

x

Conventions used in this guide

To make sure that you perform certain tasks properly, take note of the following
symbols used throughout this manual.

Typography

Bold text Indicates a menu or an item to select.

Italics

Used to emphasize a word or a phrase.

<Key> Keys enclosed in the less-than and greater-than sign

means that you must press the enclosed key.

Example: <Enter> means that you must press the
Enter or Return key.

<Key1+Key2+Key3> If you must press two or more keys simultaneously, the

key names are linked with a plus sign (+).

Example: <Ctrl+Alt+D>

Command Means that you must type the command exactly

as shown, then supply the required item or value
enclosed in brackets.

Example: At the DOS prompt, type the command line:

awdash M2N32-WS.ROM

DANGER/WARNING: Information to prevent injury to yourself

when trying to complete a task.

CAUTION: Information to prevent damage to the components

when trying to complete a task.

NOTE: Tips and additional information to help you complete a

task.

IMPORTANT: Instructions that you MUST follow to complete a

task.

xi

M2N32 WS Professional

specications summary

(continued on the next page)

CPU Socket AM2 for AMD Athlon™64 FX/Athlon™ 64 X2/

Athlon™ 64/Sempron™ processor
Supports AMD Cool ‘n’ Quiet™ Technology
AMD64 architecture enables simultaneous 32-bit and
64-bit computing

Chipset NVIDIA® nForce® 590 SLI™ MCP(NVIDIA® LinkBoost™

Technology, NVIDIA® Tritium Technology certied)
North bridge: NVIDIA® C51XE
South bridge: NVIDIA® MCP55PXE
PCI-X bridge: NEC uPD720404

System bus 2000 / 1600 MT/s

Memory Dual-channel memory architecture

- 4 x 240-pin DIMM sockets support unbufferred
ECC/non-ECC DDR2 800/667/533 MHz memory
modules

- Supports up to 8 GB system memory

Expansion slots 2 x PCI Express™ x16 slots with NVIDIA® SLI™ support

at full x16, x16 speed
2 x PCI-E x1 slots
2 x PCI-X slots
1 x PCI 2.2 slot

Scalable Link Interface
(SLI™)

Supports two identical NVIDIA® SLI™-ready graphics
cards, both at x16 mode

Storage NVIDIA® nForce® 590 SLI™ MCP supports:

- 1 x IDE connector for up to two Ultra DMA
133/100 devices

- 6 x Serial ATA 3.0 Gb/s connectors support six
Serial ATA devices

- RAID 0, RAID1, RAID 0+1, RAID 5, and JBOD
congurations spanning across Serial ATA drives
via the onboard NVIDIA® MediaShield™ RAID
controller
Marvell® 88SE614x Serial ATA controller supports:

- 3 x Internal Serial ATA 3.0 Gb/s

- 1 x External Serial ATA 3.0 Gb/s on the rear panel

- 1 x IDE connector for up to two Ultra DMA 100
devices

LAN 2 x Marvell® 88E1116 PHY

Firewall function
Supports Teaming functions

xii

M2N32 WS Professional

specications summary

High Denition Audio SoundMAX® ADI AD1988B 8-channel CODEC

Supports Jack-Sensing, Enumeration, Multi-Streaming,
and Jack-Retasking Technology
Optical and Coaxial S/PDIF Out interfaces

IEEE 1394 T1 1394 controller supports:

- 2 x IEEE 1394a connectors (at mid-board)

USB Supports up to 10 USB 2.0/1.1 ports

ASUS special features
Performance

Intelligent overclocking tools:

- AI NOS™ (Non-delay Overclocking System)

- AI Overclocking (intelligent CPU frequency tuner)

- AI Clock Skew

- ASUS PEG Link (automatic performance tuning for

single/dual graphics cards) ASUS BIOS Prole:
overclocking conguration-sharing tool

- ASUS C.P.R. (CPU Parameter Recall) -

- ASUS AI Booster

- Adjustable FSB/DDR2 ratio. Fixed PCI/PCIe
frequencies.

- Hyper Path 3
Precision Tweaker:

- vDIMM: 25-step DRAM voltage control

- vCore: Adjustable CPU voltage at 0.0125 V
increment

- Stepless Frequency Selection(SFS) allows FSB
tuning from 200 MHz up to 400 MHz at 1 MHz
increment

- PCI Express x16 frequency allows PCI Express x16

frequency tuning from 100 MHz to 200 MHz at 1
MHz increment

ASUS special features
Thermal

ASUS 8-Phase Power Design
Stack Cool 2
Q-Fan 2
ASUS Heat-pipe Thermal solution

ASUS special features
Life

Multi-language BIOS
SATA on the Go
AI Nap
AI Gear
My Logo™ 3

ASUS special features
Others

CrashFree BIOS 3
EZ Flash 2
ASUS AI NET 2
Q-Connector
ASUS AI Quiet

(continued on the next page)

xiii

M2N32 WS Professional

specications summary

Rear panel 1 x PS/2 keyboard port (purple)

1 x PS/2 mouse port (green)
1 x Parallel port
1 x External Serial ATA 3.0 Gb/s
1 x Optical S/PDIF Out port
1 x Coaxial S/PDIF Out port
2 x LAN (RJ-45) ports
4 x USB 2.0/1.1 ports
8-channel audio ports

Internal connectors 3 x USB 2.0 connectors support six additional USB 2.0

ports
1 x Floppy disk drive connector
2 x IDE connectors for two devices
9 x Serial ATA connectors
1 x CPU / 4 x Chassis / 1 x Power fan connectors
2 x IEEE 1394a connectors
1 x Parallel connector
1 x TPM connector
Chassis intrusion connector
Front panel audio connector
CD audio in connector
24-pin ATX power connector
8-pin ATX 2.0/1.1 power connector
System panel connector

BIOS features 8 Mb AWARD BIOS, PnP, DMI 2.0, WfM2.0, SM BIOS 2.3

Manageability WOL by PME, WOR by PME, PXE, AI NET 2, Chassis

Intrusion

Power requirements ATX power supply (with 24-pin and 4-pin 12 V plugs)

ATX 12 V 2.0 compliant

Support CD contents Device drivers

BIOS ash utility under DOS
ASUS AI Booster
ASUS PC Probe II
ASUS Update
NVIDIA® RAID

Form factor ATX form factor: 12 in x 9.6 in (30.5 cm x 24.5 cm)

*Specications are subject to change without notice.

xiv

1

Product

introduction

This chapter describes the motherboard
features and the new technologies
it supports.

ASUS M2N32 WS Professional

Chapter summary

1

1.1 Welcome! ...................................................................................... 1-1

1.2 Package contents .........................................................................

1-1

1.3 Special features ............................................................................

1-2

ASUS M2N32 WS Professional 1-1

1.1 Welcome!

Thank you for buying an ASUS® M2N32 WS Professional motherboard!

The motherboard delivers a host of new features and latest technologies, making it
another standout in the long line of ASUS quality motherboards!

Before you start installing the motherboard, and hardware devices on it, check the
items in your package with the list below.

If any of the above items is damaged or missing, contact your retailer.

1.2 Package contents

Check your motherboard package for the following items.

Motherboard ASUS M2N32 WS Professional

I/O modules 1 x 2-port IEEE 1394a module
1 x 2-port USB 2.0 module

Cables 9 x Serial ATA cables
5 x Serial ATA power cables for up to nine devices
1 x Ultra DMA 133/100/66 cable
1 x Floppy disk drive cable

Accessories I/O shield
ASUS SLI™ Bridge
ASUS Q-Connector Kit (USB, 1394, System panel)

Application CD ASUS motherboard support CD
InterVideo® Media Launcher

Documentation User guide

1-2 Chapter 1: Product introduction

1.3 Special features

1.3.1 Product highlights

Latest processor technology

The motherboard comes with a 940-pin AM2 socket that supports AMD Athlon™
64 X2/Athlon™ 64/Athlon™ FX/Sempron™ processor. With an integrated low­latency high-bandwidth memory controller and a highly scalable HyperTransport™
technology-based system bus, the motherboard provides a powerful platform for

your diverse computing needs, increased ofce productivity, and enhanced digital

media experience. See page 2-7 for details.

NVIDIA® Scalable Link Interface (SLI™)

The NVIDIA® Scalable Link Interface (SLI™) technology allows two graphics
processing units (GPUs) in a single system. This technology takes advantage of
the PCI Express™ bus architecture and features intelligent hardware and software
solutions that allows multiple GPUs to work together and achieve exceptional
graphics performance.

64-bit CPU support

The motherboard supports 64-bit computing, which is the next generation
technology to replace the current 32-bit architecture. The 64-bit architecture
delivers advanced system performance, faster memory access, and increased

productivity. This motherboard provides excellent compatibility and exibility by

support either 64-bit or 32-bit architecture. See page 2-7 for details.

DDR2 memory support

The motherboard supports DDR2 memory that features data transfer rates of

800/667/533 MHz to meet the higher bandwidth requirements of the latest

3D graphics, multimedia, and Internet applications. The dual-channel DDR2
architecture doubles the bandwidth of your system memory to boost system
performance, eliminating bottlenecks with peak bandwidths of up to 10.7 GB/s.
See pages 2-12 to 2-13 for details.

PCI-X® interface

The motherboard supports PCI-X, the new and improved version of the previous
PCI standard. PCI-X offers faster data transfers and enhanced system reliability
with ECC automatic single-bit error recovery and double-bit error detection. PCI-X,
which is backward-compatible with PCI-based hardware and software, enables
users to keep pace with upcoming advances in high-bandwidth, business-critical

applications such as Fiber Channel, RAID, InniBrand™ Architecture, and iSCSI.

See pages 2-18 and 2-26 for details.

ASUS M2N32 WS Professional 1-3

PCI Express™ interface

The motherboard fully supports PCI Express, the latest I/O interconnect technology
that speeds up the PCI bus. PCI Express features point-to-point serial
interconnections between devices and allows higher clockspeeds by carrying data
in packets. This high speed interface is software compatible with existing PCI

specications. See page 2-18 for details.

Serial ATA I/II technology and SATA-On-The-Go

The motherboard fully supports the Serial ATA II 3.0 Gb/s technology through the
Serial ATA interfaces and the NVIDIA® nForce® 590 SLI™ chipset. The Serial

ATA 3 Gb/s specication provides twice the bandwidth of the current Serial

ATA products with a host of new features, including Power Management (PM)

Implementation Algorithm. Serial ATA allows for thinner, more exible cables with

lower pin count and reduced voltage required. Leveraging these Serial ATA 3.0
Gb/s features is the SATA-On-The-Go. Supported by the Marvell® 88SE614x Serial
ATA controller, four Serial ATA 3.0 Gb/s connectors (three at mid-board and one on
the rear panel) provide smart setup, and hot-plug function. See pages 2-28, 2-31,
and 2-32 for details.

IEEE 1394a support

The IEEE 1394a interface provides high-speed and exible PC connectivity to

a wide range of peripherals and devices compliant to the IEEE 1394a standard.
The IEEE 1394a interface allows up to 400 Mbps transfer rates through simple,
low-cost, high-bandwidth asynchronous (real-time) data interfacing between
computers, peripherals, and consumer electronic devices such as camcorders,
VCRs, printers, TVs, and digital cameras. See page 2-33 for details.

S/PDIF digital sound ready

The motherboard supports the S/PDIF technology through the S/PDIF interfaces
on the rear panel. The S/PDIF technology turns your computer into a high-end
entertainment system with digital connectivity to powerful audio and speaker
systems. See page 2-27 for details.

USB 2.0 technology

The motherboard implements the Universal Serial Bus (USB) 2.0 specication,

dramatically increasing the connection speed from the 12 Mbps bandwidth on USB

1.1 to a fast 480 Mbps on USB 2.0. USB 2.0 is backward compatible with USB 1.1.
See pages 2-28 and 2-33 for details.

1-4 Chapter 1: Product introduction

Dual Gigabit LAN solution

The motherboard comes with dual Gigabit LAN controllers to provide the total
solution for your networking needs. These network controllers use the PCI Express
segment to provide faster data bandwidth for your wired or wireless Internet, LAN,

and le sharing requirements. See page 2-27 for details.

AMD Cool ‘n’ Quiet Technology

The motherboard supports the AMD Cool ‘n’ Quiet Technology, which monitors
system operation and automatically adjusts CPU voltage and frequency for a cool
and quiet operating environment. See page 4-26 for details.

ASUS M2N32 WS Professional 1-5

1.3.2 ASUS Special features

AI Gear

AI Gear allows users to choose from four modes to adjust CPU, FSB speed and

Vcore voltage, minimizing noise and power consumption. Users can choose the

mode that best suits their needs. See page 4-20 for details

AI Nap

With AI Nap, the system can continue running at minimum power and noise
when the user is temporarily away. To wake the system and return to the OS
environment, simply click the mouse or press a key.

Advanced Thermal Design

ASUS Stack Cool 2

ASUS Stack Cool 2 is a fan-less and zero-noise cooling solution that lowers

the temperature of critical heat generating components. The motherboard
uses a special design on the printed circuit board (PCB) to dissipate heat that
critical components generate. See page 2-3 for details.

8-Phase Power Design

The ASUS 8-Phase Power Design prolongs CPU lifespan and keeps the
system stable by preventing high power stress to the CPU and power supply

module. The design ensures high efciency operation to generate less heat

compared with conventional power solutions, thus achieving cool system
environment and making this motherboard ideal for overclocking.

Fanless Design and Heat-pipe

The ASUS fanless design allows multi-directional heat ow from major

thermal sources in the motherboard to lower overall system temperature,
resulting in quieter operation and longer system life. ASUS has devoted
special efforts to address the thermal issues across the motherboard, and
most notably in the following areas: CPU, power, VGA, Northbridge and
Southbridge. The heat pipe, heatsink, and strategic board layout were tailor

made to dissipate heat in the most efcient manner.

1-6 Chapter 1: Product introduction

ASUS CrashFree BIOS 3

The ASUS CrashFree BIOS 3 allows users to restore corrupted BIOS data from a

USB ash disk containing the BIOS le. This utility saves users the cost and hassle

of buying a replacement BIOS chip. See page 4-9 for details.

ASUS EZ Flash 2

EZ Flash 2 is a user-friendly BIOS update utility. Simply press the predened

hotkey to launch the utility and update the BIOS without entering the OS. Update

your BIOS easily without preparing a bootable diskette or using an OS-based ash

utility. See pages 4-5 and 4-47 for details.

ASUS MyLogo 3

ASUS My Logo 3 is the new feature present in the motherboard that allows you

to personalize and add style to your system with customizable and animated boot

logos.

PEG Link Mode for two graphics cards

This feature enhances your PCI Express graphics card performance. It allows the
motherboard to automatically adjust the PCI Express graphics link mode to the

correct frequency based on the system conguration. Four additional settings are

available for overclocking the PEG Link Mode. See page 4-23 for details.

Precision Tweaker

This feature allows you to ne tune the CPU/memory voltage and gradually
increase the memory Front Side Bus (FSB) and PCI Express frequency at 1MHz

increment to achieve maximum system performance.

ASUS Multi-language BIOS

The multi-language BIOS allows you to select the language of your choice from the

available options. The localized BIOS menus allow easier and faster conguration.

See page 4-14 for details.

C.P.R. (CPU Parameter Recall)

The C.P.R. feature of the motherboard BIOS allows automatic re-setting to the
BIOS default settings in case the system hangs due to overclocking. When the
system hangs due to overclocking, C.P.R. eliminates the need to open the system
chassis and clear the RTC data. Simply shut down and reboot the system, and the
BIOS automatically restores the CPU default setting for each parameter.

ASUS M2N32 WS Professional 1-7

Q-Connector

The ASUS Q-Connector allows you to connect or disconnect chassis front panel
cables in one easy step with one complete module. This unique adapter eliminates
the trouble of plugging in one cable at a time, making connection quick and

accurate.

ASUS O.C. Prole

The motherboard features the ASUS BIOS Prole that allows users to conveniently

store or load multiple BIOS settings. The BIOS settings can be stored in the

CMOS or a separate le, giving users freedom to share and distribute their favorite

settings.

AI NOS™ (Non-Delay Overclocking System)

ASUS Non-delay Overclocking System™ (NOS) is a technology that auto-detects
the CPU loading and dynamically overclocks the CPU speed only when needed.
See page 4-20 for details.

1-8 Chapter 1: Product introduction

2

Hardware

information

This chapter lists the hardware setup
procedures that you have to perform
when installing system components. It
includes description of the jumpers and
connectors on the motherboard.

ASUS M2N32 WS Professional

Chapter summary

2

2.1 Before you proceed ..................................................................... 2-1

2.2 Motherboard overview .................................................................

2-2

2.3 Central Processing Unit (CPU) ...................................................

2-7

2.4 System memory .........................................................................

2-12

2.5 Expansion slots ..........................................................................

2-16

2.6 Jumper ........................................................................................

2-25

2.7 Connectors .................................................................................

2-27

ASUS M2N32 WS Professional 2-1

Onboard LED

The motherboard comes with a standby power LED. The green LED lights up
to indicate that the system is ON, in sleep mode, or in soft-off mode. This is a
reminder that you should shut down the system and unplug the power cable
before removing or plugging in any motherboard component. The illustration
below shows the location of the onboard LED.

2.1 Before you proceed

Take note of the following precautions before you install motherboard components
or change any motherboard settings.

• Unplug the power cord from the wall socket before touching any
component.

• Use a grounded wrist strap or touch a safely grounded object or to
a metal object, such as the power supply case, before handling
components to avoid damaging them due to static electricity.

• Hold components by the edges to avoid touching the ICs on them.

• Whenever you uninstall any component, place it on a grounded
antistatic pad or in the bag that came with the component.

• Before you install or remove any component, ensure
that the ATX power supply is switched off or the power cord is detached
from the power supply. Failure to do so may cause severe damage to the
motherboard, peripherals, and/or components.

M2N32 WS PRO

®

M2N32 WS PRO Onboard LED

SB_PWR

ON

Standby

Power

OFF

Powered

Off

2-2 Chapter 2: Hardware information

2.2 Motherboard overview

Before you install the motherboard, study the conguration of your chassis to
ensure that the motherboard ts into it.

2.2.1 Placement direction

When installing the motherboard, make sure that you place it into the chassis in
the correct orientation. The edge with external ports goes to the rear part of the
chassis as indicated in the image below.

2.2.2 Screw holes

Place nine (9) screws into the holes indicated by circles to secure the motherboard
to the chassis.

Place this side towards

the rear of the chassis

Make sure to unplug the power cord before installing or removing the
motherboard. Failure to do so can cause you physical injury and damage
motherboard components.

Do not overtighten the screws! Doing so can damage the motherboard.

M2N32 WS PRO

®

ASUS M2N32 WS Professional 2-3

2.2.3 ASUS Stack Cool 2

The motherboard comes with the ASUS Stack Cool 2 cooling solution that lowers
the temperature of critical heat generating components by 20ºC. The motherboard
uses a special design on the printed circuit board (PCB) to dissipate heat that
critical components generate.

2-4 Chapter 2: Hardware information

2.2.5 Motherboard layout

PANEL

M2N32 WS PRO

®

AAFP

CHASSIS

24.5cm (9.6in)

30.5cm (12.0in)

CPU_FAN

DDR2 DIMM_A2 (64 bit,240-pin module)

DDR2 DIMM_A1 (64 bit,240-pin module)

DDR2 DIMM_B1 (64 bit,240-pin module)

DDR2 DIMM_B2 (64 bit,240-pin module)

IE1394_1

FLOPPY

Super

I/O

8Mb

BIOS

TSB43AB22A

CD

AD1988B

PCIEX16_1

PCIEX1_1

PCI1

CLRTC

USB78USB56

ATX12V

SB_PWR

EATXPWR

PRI_IDE

CR2032 3V
Lithium Cell

CMOS Power

PRI_EIDE

COM1

LAN1_USB12

PS/2KBMS

T: Mouse
B: Keyboard

PARALLEL PORT

SPDIF_O1

SPDIF_O2

LAN2_USB34

EXT_SATA4

AUDIO

PCIEX16_2

PCIEX1_2

PCIX_1

PCIX_2

USB910
USB910_WFGBT

TPM

Socket AM2

PCIX_SPEED

IE1394_2

CHA_FAN3
CHA_FAN1

SPS_FAN1

EXT_SATA1

EXT_SATA3

EXT_SATA2

SATA5
SATA3
SATA1

SATA6
SATA4
SATA2

CHA_FAN4 CHA_FAN2

Marvell

88E1116

Marvell

88E1116

Marvell

88SE614x

nVIDIA

®

C51XE

NEC

uPD720404

nVIDIA

®

MCP55PXE

ASUS M2N32 WS Professional 2-5

2.2.4 Layout contents

Slots Page

1. DDR2 DIMM slots 2-12

2. PCI slots

2-18

3. PCI Express x16 slots

2-18

4. PCI Express x1 slot

2-18

5. PCI-X slots

2-18

Jumper Page

1. Clear RTC RAM (3-pin CLRTC) 2-25

2. PCI-X Speed setting (6-pin PCIX_SPEED)

2-26

Rear panel connectors Page

1. PS/2 mouse port (green) 2-27

2. Parallel port

2-27

3. LAN 1 (RJ-45) port

2-27

4. LAN 2 (RJ-45) port

2-27

5. Rear Speaker Out port (black)

2-27

6. Center/Subwoofer port (orange)

2-27

7. Line In port (light blue)

2-27

8. Line Out port (lime)

2-27

9. Microphone port (pink)

2-28

10. Side Speaker Out port (gray)

2-28

11. USB 2.0 ports 1 and 2

2-28

12. USB 2.0 ports 3 and 4

2-28

13. External SATA port

2-28

14. Optical S/PDIF Out port

2-28

15. Coaxial S/PDIF Out port

2-28

16. PS/2 keyboard port (purple)

2-28

2-6 Chapter 2: Hardware information

Internal connectors Page

1. Floppy disk drive connector (34-1 pin FLOPPY) 2-29

2. NVIDIA

®

IDE connector (40-1 pin PRI_IDE) 2-29

3. Marvell

®

IDE connector (40-1 pin PRI_EIDE) 2-30

4. NVIDIA

®

nForceNVIDIA® 590 SLI Southbridge Serial ATA
connectors (7-pin SATA1 [red], SATA2 [red], SATA3 [red],
SATA4 [red], SATA5 [red], SATA6 [red])

2-31

5. Marvell

®

88SE614x Serial ATA connector (7-pin EXT_

SATA1, EXT_SATA2, EXT_SATA3)

2-32

6. USB connectors (10-1 pin USB56, USB78, USB910)

2-33

7. IEEE 1394a port connectors (10-1 pin IE1394_1, 10-1 pin
IE1394_2)

2-33

8. CPU, chassis, power, and Power Fan connectors
(4-pin CPU_FAN, 3-pin CHA_FAN1, 3-pin CHA_FAN2,
3-pin CHA_FAN3, 3-pin CHA_FAN4, 3-pin SPS_FAN1)

2-34

9. Chassis intrusion connector (4-1 pin CHASSIS)

2-35

10. ATX power connectors (24-pin EATXPWR, 8-pin ATX12V)

2-35

11. Front panel audio connector (10-1 pin AAFP)

2-36

12. Internal audio connector (4-pin CD [black])

2-37

13. Serial port connector (10-1 pin COM1)

2-37

14. TPM connector (20-1 pin TPM)

2-38

15. System panel connector (20-pin PANEL)

•

System power LED (2-pin PLED)

•

Hard disk drive activity LED (2-pin IDE_LED)

•

System warning speaker (4-pin SPEAKER)

•

ATX power button/soft-off button (2-pin PWR)

•

Reset button (2-pin RESET)

2-39

ASUS M2N32 WS Professional 2-7

2.3.1 Installing the CPU

To install a CPU:

1. Locate the CPU socket on the motherboard.

Make sure that the socket lever is lifted up to a 90º angle; otherwise, the CPU
will not t in completely.

2. Unlock the socket by pressing the
lever sideways, then lift it up to a
90º angle.

2.3 Central Processing Unit (CPU)

The motherboard comes with a 940-pin AM2 socket designed for the AMD
Athlon™ 64 X2/Athlon™ 64 FX/Athlon™ 64/Sempron™ processor.

Socket lever

The AM2 socket has a different pinout from the 939-pin socket designed for the
AMD Opteron™ processor. Make sure you use a CPU is designed for the AM2

socket. The CPU ts in only one correct orientation. DO NOT force the CPU into

the socket to prevent bending the connectors on the socket and damaging the
CPU!

M2N32 WS PRO

®

M2N32 WS PRO CPU Socket AM2

2-8 Chapter 2: Hardware information

3. Position the CPU above the socket
such that the CPU corner with the
gold triangle matches the socket
corner with a small triangle.

4. Carefully insert the CPU into the

socket until it ts in place.

5. When the CPU is in place, push
down the socket lever to secure the
CPU. The lever clicks on the side tab
to indicate that it is locked.

6. Install a CPU heatsink and fan
following the instructions that came
with the heatsink package.

Gold triangle

Small triangle

ASUS M2N32 WS Professional 2-9

2.3.2 Installing the heatsink and fan

The AMD Athlon™ 64FX/Athlon™ 64/Athlon™ 64 X2/Sempron™ processor
requires a specially designed heatsink and fan assembly to ensure optimum
thermal condition and performance.

To install the CPU heatsink and fan:

1. Place the heatsink on top of the installed CPU, making sure that the heatsink

ts properly on the retention module base.

Retention module base

CPU heatsink

CPU fan

Retention bracket lock

Retention bracket

Your boxed CPU heatsink and fan assembly should come with installation
instructions for the CPU, heatsink, and the retention mechanism. If the
instructions in this section do not match the CPU documentation, follow the
latter.

•

The retention module base is already installed on the motherboard
upon purchase.

•

You do not have to remove the retention module base when
installing the CPU or installing other motherboard components.

•

If you purchased a separate CPU heatsink and fan assembly, make
sure that a Thermal Interface Material is properly applied to the CPU
heatsink or CPU before you install the heatsink and fan assembly.

Make sure that you use only AMD-certied heatsink and fan assembly.

2-10 Chapter 2: Hardware information

2. Attach one end of the retention bracket
to the retention module base.

3. Align the other end of the retention
bracket (near the retention bracket
lock) to the retention module base.
A clicking sound denotes that the
retention bracket is in place.

4. Push down the retention bracket lock
on the retention mechanism to secure
the heatsink and fan to the module
base.

Make sure that the fan and

heatsink assembly perfectly ts

the retention mechanism module
base, otherwise you cannot snap
the retention bracket in place.

ASUS M2N32 WS Professional 2-11

5. When the fan and heatsink assembly is in place, connect the CPU fan cable
to the connector on the motherboard labeled CPU_FAN.

Do not forget to connect the CPU fan connector! Hardware monitoring errors
can occur if you fail to plug this connector.

M2N32 WS PRO

®

M2N32 WS PRO CPU fan connector

CPU_FAN

GND
CPU FAN PWR
CPU FAN IN
CPU FAN PWM

2-12 Chapter 2: Hardware information

2.4 System memory

2.4.1 Overview

The motherboard comes with four Double Data Rate 2 (DDR2) Dual Inline Memory
Modules (DIMM) sockets.

A DDR2 module has the same physical dimensions as a DDR DIMM but has a
240-pin footprint compared to the 184-pin DDR DIMM. DDR2 DIMMs are notched
differently to prevent installation on a DDR DIMM socket.

The gure illustrates the location of the DDR2 DIMM sockets:

Channel Sockets

Channel 1 DIMM_A1 and DIMM_B1

Channel 2 DIMM_A2 and DIMM_B2

M2N32 WS PRO

®

M2N32 WS PRO 240-pin DDR2 DIMM sockets

DIMM_B1

DIMM_A1

DIMM_B2

DIMM_A2

ASUS M2N32 WS Professional 2-13

2.4.2 Memory congurations

You may install 256 MB, 512 MB, and 1 GB unbuffered ECC/non-ECC DDR2
DIMMs into the DIMM sockets.

Important notice on installing Windows® XP 32-bit version

If you install Windows® XP 32-bit version Operating System (OS), the limitation
of this OS version is that it may reserve a certain amount of memory space for
system devices. We recommend that you install less than 3 GB system memory
if you would like to work under Windows® XP 32-bit version OS. The excess
memory installation will not cause any usage problem, but it will not give users

the benet of manipulating this excess memory space.

Visit the ASUS FAQ site for further
explanation:
http://support.asus.com/faq/faq.
aspx?SLanguage=en-us
Under General Search, make the
selections as shown, then click Search.
Click the article titled “4GB memory installed but less memory size
detected.”

You also may check the URLs below for third party comments on this issue:
http://dlsvr01.asus.com/pub/ASUS/mb/4GB_Rev1.pdf
http://www.intel.com/support/motherboards/server/sb/cs-016594.htm

• For dual-channel conguration, the total size of memory module(s) installed

per channel must be the same (DIMM_A1 + DIMM_B1 = DIMM_A2 +
DIMM_B2).

• Always install DIMMs with the same CAS latency. For optimum
compatibility, we recommend that you obtain memory modules from
the same vendor. Visit the ASUS website (www.asus.com) for the latest

Qualied Vendors List.

• When using only one DDR2 DIMM module, install it into slot DIMM_A1
only.

• For single-channel memory conguration, start installing the DDR2 DIMMs

from slot DIMM_A1 or DIMM_B1.

• For dual-channel memory conguration, install the DIMMs in slots
DIMM_B1 and DIMM_A1 (yellow slots); install another pair of DIMMs in

slots DIMM_B2 and DIMM_A2 (black slots).

2-14 Chapter 2: Hardware information

SIZE Type Vendor Module Chip

Vendor

Chip
Component

256Mbytes Unbuffer Micron MT8HTF3264AG-53EB3 Micron MT4CB11Z9BQT

Unbuffer Samsung M378T3253FG0-CD5 Samsung K4T56083QF-GCD5

Unbuffer

KINGSTON KVR533D2N4/256GID

Hynix

HY5PS121621 FP-C4
528A

Unbuffer

KINGSTON KVR533D2N4/256

Hynix

HY5PS121621 FP-C4
526A

Unbuffer Adata M2OHY2F4G2150A1B0Z Hynix HY5PS12821
Unbuffer Transcend TS32MLQ64V5M ELPIDA E5116AF-5C-E

Unbuffer Corsair VS256MB533D2 Corsair

32M16CED
EL1100549

512Mbytes Unbuffer Adata M2OHT2G3H3110A1B0Z Hynix HY5PS12821

Unbuffer Corsair CM2X-512-4300 Corsair
Unbuffer PQI MEAB-328LA0102-05D1 PQI PQB2648Y38
Unbuffer Corsair

VS512MB533D2

Corsair MIII00533 32M8CEC
Unbuffer GEIL GX25124300X
Unbuffer Elpida EBE51ED8ABFA-5C-E Elpida 　
Unbuffer Elpida EBE51UD8ABFA-5C-E Elpida E5108AB-5C-E
Unbuffer Hynix HYMP564U648-C4 AA Hynix HY5PS12821F-C4
Unbuffer Hynix HYMP564U728-C4 Hynix HY5PS12821F-C4
Unbuffer Kingston KVR533D2N4/512GID SEC K4T51083QC
Unbuffer Micron MT16HTF6464AG-53EB2 Micron MT4DB11Z9BQT
Unbuffer Samsung M378T6553BG0-CD5 Samsung K4T51083QB-GCD5
Unbuffer Samsung M391T6453FG0-CD5 Samsung K4T51083QB-GCD5
Unbuffer Samsung M391T6553BG0-CD5 Samsung K4T56083QF-GCD5
Unbuffer

PQI MEAB322HA1601 PQI

PQB2328S38

Unbuffer Transcend TS64MLQ64V5J Samsung K4T51083QB-GCD5

1024Mbytes ECC Hynix HYMP512U648-C4 Hynix HY5PS12821F-C4

Unbuffer Transcend TS128MLQ64V5J SEC K4T51083QC

Unbuffer Micron MT16HTF12864AY-53EA1 Micron 4MAII D9CRZ
2048Mbytes Unbuffer Kinston KVR533D2N4/2G Elpida E1108AA-5C-E

SIZE Type Vendor Module Chip

Vendor

Chip
Component

256Mbytes Unbuffer Hynix HYMP532U64AP6-Y5 AA Hynix HY5PS121621AFP-Y5

Unbuffer

Micron MT8HTF3264AY-667B5 4SB42D9CZM
Unbuffer Samsung M378T3253FZ0-CE6 Samsung K4T56083QF-ZCE6
Unbuffer

Apacer 78.81G9F.9M2 Apacer

AM4B5716MIJS7E­0609D

512Mbytes ECC Adata M2OEL5G3H3160B1C0Z Elpdia E5108AE-GE-E

Unbuffer Hynix HYMP564U64AP8-Y4 Hynix HY5PS12821AFP-Y4
Unbuffer Hynix HYMP564U64AP8-Y5 Hynix HY5PS12821AFP-Y5
Unbuffer Kingmax KLCC28F-A8EB5 E5108AE-6E-E
Unbuffer Micron MT16HTF6464AY-667B3 Micron 4SB41D9CZM
Unbuffer Micron MT16HTF6464AY-667B4 Micron 4VB41D9CZM
Unbuffer Samsung M378T3253FZ0-CE6 Samsung K4T56083QF-ZCE6
Unbuffer Samsung M378T6453FZ0-CE6 Samsung K4T56083QF-ZCE6
Unbuffer Samsung M378T6553CZ0-CE6 SEC K4T51083QC
Unbuffer Corsair

VS512MB667D2

Corsair MIII0053032M8ECE

1024Mbytes ECC Hynix HYMP512U72AP8-Y4 Hynix HY5PS12821AFP-Y4

ECC Hynix HYMP512U72AP8-Y5 Hynix HY5PS12821AFP-Y5
Unbuffer Micron MT16HTF12864AY-667A3 Micron 4ZA32D9DQT
Unbuffer Micron MT16HTF12864AY-66EA3 Micron 5EAIIZ9FNM
Unbuffer Samsung M378T2953CZ0-CE6 Samsung K4T51083QC

SIZE Type Vendor Module Chip

Vendor

Chip
Component

256Mbytes Unbuffer Samsung M378T3253FZ3-CE7 Samsung K4T56083QF-ZCE7
512Mbytes Unbuffer Hynix HYMP564U64AP8-S6 Hynix HY5PS12821AFP-S6

Qualied Vendors Lists (QVL)

DDR2-800

DDR2-667

DDR2-533

ASUS M2N32 WS Professional 2-15

2.4.3 Installing a DIMM

Unplug the power supply before adding or removing DIMMs or other
system components. Failure to do so can cause severe damage to both the
motherboard and the components.

To install a DIMM:

1. Unlock a DIMM socket by
pressing the retaining clips
outward.

2. Align a DIMM on the socket
such that the notch on the DIMM
matches the break on the socket.

3. Firmly insert the DIMM into the
socket until the retaining clips
snap back in place and the
DIMM is properly seated.

2.4.4 Removing a DIMM

To remove a DIMM:

1. Simultaneously press the retaining
clips outward to unlock the DIMM.

2. Remove the DIMM from the socket.

• A DDR2 DIMM is keyed with a notch so that it ts in only one direction. Do

not force a DIMM into a socket to avoid damaging the DIMM.

• The DDR2 DIMM sockets do not support DDR DIMMs. DO not install DDR
DIMMs to the DDR2 DIMM sockets.

Support the DIMM lightly with

your ngers when pressing the

retaining clips. The DIMM might

get damaged when it ips out

with extra force.

1

2

1

DDR2 DIMM notch

Unlocked retaining clip

DDR2 DIMM notch

1

2

3

2-16 Chapter 2: Hardware information

2.5 Expansion slots

In the future, you may need to install expansion cards. The following sub-sections
describe the slots and the expansion cards that they support.

2.5.1 Installing an expansion card

To install an expansion card:

1. Before installing the expansion card, read the documentation that came with
it and make the necessary hardware settings for the card.

2. Remove the system unit cover (if your motherboard is already installed in a
chassis).

3. Remove the bracket opposite the slot that you intend to use. Keep the screw
for later use.

4. Align the card connector with the slot and press rmly until the card is

completely seated on the slot.

5. Secure the card to the chassis with the screw you removed earlier.

6. Replace the system cover.

2.5.2 Conguring an expansion card

After installing the expansion card, congure the it by adjusting the software

settings.

1. Turn on the system and change the necessary BIOS settings, if any. See
Chapter 4 for information on BIOS setup.

2. Assign an IRQ to the card. Refer to the tables on the next page.

3. Install the software drivers for the expansion card.

Make sure to unplug the power cord before adding or removing expansion
cards. Failure to do so may cause you physical injury and damage motherboard
components.

When using PCI cards on shared slots, ensure that the drivers support “Share

IRQ” or that the cards do not need IRQ assignments; otherwise, conicts will

arise between the two PCI groups, making the system unstable and the card
inoperable.

ASUS M2N32 WS Professional 2-17

2.5.3 Interrupt assignments

Standard interrupt assignments

* These IRQs are usually available for ISA or PCI devices.

IRQ Priority Standard function

0 1 System Timer

1 2

Keyboard Controller

2 – Redirect to IRQ#9

4 12 Communications Port (COM1)*

5 13 IRQ Holder for PCI Steering*

6 14 Floppy Disk Controller

7 15 Printer Port (LPT1)*

8 3 System CMOS/Real Time Clock

9 4 IRQ Holder for PCI Steering*

10 5 IRQ Holder for PCI Steering*

11 6 IRQ Holder for PCI Steering*

12 7 PS/2 Compatible Mouse Port*

13 8 Numeric Data Processor

14 9 Primary IDE Channel

15 10 Secondary IDE Channel

2-18 Chapter 2: Hardware information

2.5.4 PCI slot

The PCI slot supports cards such as a LAN card, SCSI card, USB card, and other

cards that comply with PCI specications. Refer to the gure below for the location

of the slot.

2.5.7 Two PCI Express x16 slots

This motherboard supports two SLI-ready PCI Express x16 graphic cards that

comply with the PCI Express specications. Refer to the gure below for the

location of the slot.

2.5.5 Two PCI-X slots

The PCI-X slots support cards such as a LAN card, SCSI card, USB card, and

other cards that comply with PCI-X 1.0 specications. Refer to the gure below for

the location of the slots.

2.5.6 Two PCI Express x1 slots

This motherboard supports PCI Express x1 network cards, SCSI cards and other

cards that comply with the PCI Express specications. Refer to the gure below for

the location of the slot.

PCI Express x1 slot

Primary PCI Express x16 slot (blue)

PCI-X slots

Secondary PCI Express x16 slot (black)

PCI Express x1 slot

PCI slot

ASUS M2N32 WS Professional 2-19

• In Single Card mode, you may use either the blue or black slot for PCI
Express x16 graphics cards.

• In SLI mode, the PCI Express x16 slots work at the full bandwidth of PCI
Express x16 on each slot for a combined bandwidth of x32.

• Due to NVIDIA nForce4 SLI x16 chipset limitation, if you install a Dual-GPU
graphics card on the blue x16 slot, it runs at x8 speed for one of the two
GPUs.

• Due to NVIDIA nForce4 SLI x16 chipset limitations, this motherboard does
not support two dual-GPU graphics cards (total 4 GPUs) running in SLI
mode.

• Connect a rear chassis fan to the chassis (CHA_FAN1 or CHA_FAN2)

connector when using two graphics cards for better thermal environment.
See page 2-33 for details.

• In single card mode, you may use either the blue or black slot for PCI

Express x16 cards.

• In NVIDIA

®

SLI™ mode, the PCI Express x16 slots work at the full

bandwidth of PCI Express x16 for a combined bandwidth of x32.

• We recommend that you provide sufcient power when running NVIDIA

®

SLI™ mode. See page 2-31 for details.

2-20 Chapter 2: Hardware information

Qualied graphics cards

Model
Type: PCI

Connect
Interface

OS Environment Status Chipset

ATI GC-R92SEPCI-C3
Rev.1.1 (BIOS: V8.011.006)

PCI1 WinXP Pro Pass ATI Radeon 9200SE

Gecube R7000PCI-A3
Rev. 1.1 (BIOS: V008.004)

PCI1 Win2000 Pro (CHT) Pass ATI Radeon 7000

Gecube R9250PCI-D3
Rev. 1.0 (BIOS: V008.011)

PCI1 Win2003 R2 Standard

(CHS)

Pass ATI Radeon 9250

Matrox G200 MMS
Rev. A (BIOS: V3.3 b34)

PCI1 Win2000 Pro (CHT) Pass Matrox G200

Matrox PH-P256
Rev. A (BIOS: V1.1.017)

PCI1 Win2003 R2 Standard

(ENG)

Pass Matrox Parhelia-256

Powercolor Radeon 7000
Rev.V1.0
(BIOS: V008.004.008)

PCI1 Pass ATI Radeon 7000

Model

ASUS EAX300
Rev: V1.00
(BIOS: V5b60.8.15.117.0)

PCIEX16_2 WinXP Pro Pass ATI Radeon X300

ASUS EAX300SE
Rev: V1.00
(BIOS: V5b60.8.15.117.0)

PCIEX16_1 WinXP Pro. Pass ATI Radeon X300SE

ASUS EAX300SE-HM128
Rev: V1.00
(BIOS: V008.015.128.000)

PCIEX16_1 Win2000 Pro Pass ATI Radeon X300SE

(Hyper Memory)

ASUS EAX300SE-X
Rev: V1.00
(BIOS: V008.015.117.000)

PCIEX16_1 Win2003 R2 Standard

(CHS)

Pass ATI Radeon X300SE

ASUS EAX550 128M
(BIOS: V5B60.8.15.139.
AS05)

PCIEX16_2 WinXP Home (JPN) Pass ATI Radeon X550

ASUS EAX550GE 256M
(BIOS: V5B60.8.15.139.AS01)

PCIEX16_2 Win2000 Pro Pass ATI Radeon X550

ASUS EAX600XT Rev. V1.02
(BIOS: V113-AA20306-100
AS)

PCIEX16_1 WinXP-64 Pro. Pass ATI Radeon X600XT

ASUS EAX700
(BIOS: V5E4D.9.7.1.3. A901)

PCIEX16_2 WinXP Home (JPN) Pass ATI Radeon X700

ASUS EAX700-X 128M
Rev. V1.00a
(BIOS: V009.008.001.004)

PCIEX16_1 WinXP Pro.(CHT) Pass ATI Radeon X700LE

ASUS EAX700LE 128M
(BIOS: V5E4D.9.8.1.4. AS13)

PCIEX16_2 WinXP-64 Pro. Pass ATI Radeon X700LE

Albatron PC6200
(BIOS: V5.43.02.27)

PCIEX16_2 WinXP-64 Pro Pass nVidia GeForce 6200

ASUS EAX700PRO
Rev. V1.00
(BIOS: V113-AA.30602-100)

PCIEX16_2 Win2003 R2 Enterprise

(CHT)

Pass ATI Radeon

X700PRO

ASUS EN6800GT Rev. V1.02
(BIOS: V5.40.02.26.AS05)

PCIEX16_1 Win2003 R2 Standard nVidia GeForce

6800GT

ASUS EN6800 Rev. V1.00
(BIOS: V5.41.02.17.AS01)

PCIEX16_1
PCIEX16_2

WinXP Pro. Pass nVidia GeForce 6800

ASUS EAX800XL Rev. V1.00
(BIOS: V554D.9.7.1.AS02)

PCIEX16_2 WinXP Pro. Pass ATI Radeon X800XL

Type: PCI

Type: PCIEX16

(continued on the next page)

ASUS M2N32 WS Professional 2-21

Model
Type: PCI

Connect
Interface

OS

Environment

Status Chipset

ASUS EAX1300
(BIOS: V113.AA77100.102)

PCIEX16_1 Win2003-64

R2 Standard

Pass ATI Radeon X1300

ASUS EAX1800XT 512MB
(BIOS: V7100.9.12.4.2.AS01)

PCIEX16_1 WinXP Pro. Pass ATI Radeon X1800XT

ASUS EAX1600XT Silent
256MB V.1.00
(BIOS: 71C0.9.12.4.2)

PCIEX16_2 Win2000 Pro Pass ATI Radeon X1600XT

ASUS EAX1900CrossFire
(BIOS: 7249.9.12.5.2AS05)

PCIEX16_1 WinXP Pro. Pass ATI Radeon X1900CF

ASUS EN5750/128 Rev. 1.01
(BIOS: V04.32.20.38.00)

PCIEX16_1 WinXP-64 Pro. Pass nVidia GeForce PCX5750

ASUS EN5900 Rev. 1.01
(BIOS: V04.35.20.45)

PCIEX16_1 WinXP Pro. Pass nVidia GeForce PCX5900

ASUS EN6200GE
Rev V1.00A
(BIOS: V5.43.02.27.AS07)

PCIEX16_2 Win2003-64

R2 Standard

Pass nVidia GeForce 6200

ASUS EN6500 128M
Rev V1.02
(BIOS: V5.44.02.45.0)

PCIEX16_1 Win2000 Pro Pass nVidia GeForce 6500

ASUS EN6800LE
Rev. V1.00
(BIOS: V5.41.02.34.AS01)

PCIEX16_2 Win2003 R2

Enterprise
(ENG)

Pass nVidia GeForce 6800LE

ASUS EN7600GT Silent/256M
(Bios: V5.73.22.15.01)

PCIEX16_2 Win2003-64

R2 Standard

Pass nVIDIA GeForce 7600GT

ASUS EN7900GTX 512MX16
(Bios: V5.71.22.12.01)

PCIEX16_1 (SLI)
PCIEX16_2 (SLI)

WinXP Pro. Pass nVIDIA GeForce 7900GTX

ATI Radeon X850 CrossFire
(BIOS: V009.010.001.015)

PCIEX16_1 Win2003 R2

Enterprise
(ENG)

Pass ATI Radeon X850

Elsa Falcox X85 XT 256B3
DTV Rev: PN: 109 A47401-10
(BIOS: 009.007.001.004)

PCIEX16_1 Win2003-64

R2 Standard

Pass ATI Radeon X850 XT

ASUS EAX850XT 256MB
Rev. PN: 109-A47401-10
(BIOS: V009.007.001.004)

PCIEX16_2 WinXP Pro. ATI Radeon X850XT

Leadtek WinFast PX7300GS
128MX16
Rev. (BIOS:5.72.22.34.68)

PCIEX16_1 WinXP Pro. Pass nVidia GeForce 7300GS

Leadtek WinFast PX7800GTX
TDH 256MB
Rev. (BIOS: V5.70.02.11.68)

PCIEX16_1 Win2003 R2

Enterprise

Pass nVidia GeForce 7800GTX

Leadtek Quadro FX1400
128M (BIOS:V5.41.02.43.03)

PCIEX16_1 Win2000 Pro Pass nVidia Quadro FX1400

Matrox Parhelia APVe 128M
Rev. A (BIOS: V1.3-11)

PCIEX16_2 WinXP Pro. Pass Matrox Parhelia LX

ASUS EN7800GTX 256MB
(BIOS: V5.70.02.11.01)

PCIEX16_1 Win2000 Pro nVidia GeForce 7800GTX

Leadtek WinFast PX6800GT
TD256M
Rev. C1 (BIOS: V5.40.02.32)

PCIEX16_1
PCIEX16_2

WinXP Pro.
(CHT)

Pass nVidia GeForce 6800GT

Elsa Gladiac PCX 935
Rev. W01-46W53
(BIOS: V4.35.20.45.E0)

PCIEX16_2 Win2003-64

R2 Enterprise

Pass nVidia GeForce PCX5900

Type: PCIEX16

(continued on the next page)

Qualied graphics cards

2-22 Chapter 2: Hardware information

Model
Type: PCI

Connect

Interface

OS Environment Status Chipset

Elsa Gladiac 660GT 128MB3
Rev: 2B
(BIOS: V5.43.02.46.E1)

PCIEX16_1
PCIEX16_2

WinXP Pro.(CHT) Pass nVidia GeForce 6600GT

Elsa Gladiac 780GTX 256B3
(BIOS: V5.70.02.11.E1)

PCIEX16_1
PCIEX16_2

WinXP Pro.(CHT) Pass nVidia GeForce 7800GTX

Gecube RADEON X550
256M
(BIOS:V008.015.028.000)

PCIEX16_1 WinXP Pro. Pass ATI Radeon X550

Gecube RADEON
X1300PRO
(BIOS: V133.A671B1.102)

PCIEX16_1 Win2003 R2

Standard (CHS)

Pass ATI Radeon X1300RPO

Gigabyte GV-3D1-XL
(BIOS: V5.43.02.46)

PCIEX16_1 WinXP Pro Pass nVidia GeForce 6600

(Dual GPU)

Gigabyte GV-NX66T128D
(BIOS: V5.43.02.16)

PCIEX16_1 Win2003 R2

Enterprise (CHT)

Pass nVidia GeForce 6600GT

Gigabyte GV-NX68T256D-B
Rev: B
(BIOS: V5.40.02.36.09)

PCIEX16_1 Win2000 Pro

(CHT)

Pass nVidia GeForce 6800

GIGABYTE-GV­NX79T256DBRH-256MX16
(BIOS5.71.22.12.02)

PCIEX16_1 WinXP-64 Pro. Pass nVIDIA GeForce 7900 GT

Gigabyte GV-RX70P128D
Rev: 1.1
(BIOS: V009.004.001.032)

PCIEX16_1 Win2003-64 R2

Standard

Pass ATI Radeon X700PRO

MSI NX7300GS-TD256E
Rev.V200
(BIOS: V5.72.22.34.00)

PCIEX16_1 Win2003 R2

Enterprise

Pass nVidia GeForce 7300GS

MSI RX600XT-TD128
Rev.V2.00 (BIOS: V8.015)

PCIEX16_2 WinXP Pro. Pass ATI Radeon X600XT

MSI RX700PRO-TD128E
Rev.V2.00
(BIOS: V009.004.001.032)

PCIEX16_1 WinXP-64 Pro. Pass ATI Radeon X700PRO

PowerColor Radeon
X1800XT
(BIOS: V133.A52001.102)

PCIEX16_2 Win2003 R2

Enterprise

Pass ATI Radeon X1800XT

Gigabyte GV-NX62TC256D8
(BIOS: V5.44.02.32)

PCIEX16_1 Win2003 R2

Standard

Pass nVidia GeForce 6200TC

Leadtek WinFast PX6200 TD
Rev. A1
(BIOS: V5.43.02.36.68)

PCIEX16_1 WinXP Home

(JPN)

nVidia GeForce 6200

Xiai S18Pro-DV256
(BIOS: V88.c0.00.12)

PCIEX16_1 Win2003-64 R2

Standard

Pass S3 GammaChrome S18 Pro

MSI NX6600GT-TD128E
Rev.V200
(BIOS: V5.43.02.16)

PCIEX16_1 WinXP Pro. Pass nVidia GeForce 6600GT

Type: PCIEX16

(continued on the next page)

Qualied graphics cards

ASUS M2N32 WS Professional 2-23

SATA RAID controllers

Model
Type: PCI

Connect

Interface

OS Environment Status Chipset

Promise FastTrak S150 SX4­M (BIOS: V2.0.00.21)

PCI1

WinXP Pro. Pass Promise PDC20621

Promise FastTrak TX2200
(BIOS: V2.00.0.23)

PCI1 Win2003 R2

Standard (CHS)

Pass Promise PDC20571

Promise FastTrak TX4200
(BIOS: V2.00.0.23)

PCI1 WinXP Pro. Pass Promise PDC40519

Type: PCI

Qualied RAID cards

SCSI Disk controllers

Model
Type: PCI

Connect
Interface

OS Environment Status Chipset

Adaptec ASC-39320D
Rev.B (BIOS: V4.00.0)

PCI1 WinXP Pro. Pass AIC-7902W

Model
Type: PCI

Connect
Interface

OS Environment Status Chipset

ASUS PXL-S30
Rev.1.04 (BIOS:V5.07.03)

PCIX_2 Win2003 R2

Standard

Pass LSI LS153C1030

Type: PCI

Type: PCI-X

(continued on the next page)

Model
Type: PCI

Connect
Interface

OS Environment Status Chipset

ASUS EN6600 128M
Rev V1.00A
(BIOS: V5.43.02.61)

PCIEX16_1 WinXP Pro. (CHT) Pass nVidia GeForce 6600

GIGABYTE
GV-RX19X512VBRH
(Bios:113A52021-104)

PCIEX16_2 WinXP-64 Pro. Pass ATI Radeon X1900XTX

Leadtek WinFast PX6200TC
64M
Rev. A (BIOS: V5.44.02.18)

PCIEX16_1
PCIEX16_2

Win2000 Pro
Win2003-64 R2
Enterprise

Pass nVidia GeForce 6200

(with Turbo cache)

Leadtek WinFast PX6600GT
TDH Rev. A
(BIOS: V5.43.02.16)

PCIEX16_1 Win2000 Pro Pass nVidia GeForce 6600GT

Elsa Gladiac 660LE 256MB
Rev: 3C
(BIOS: V5.43.02.69.E2)

PCIEX16_2 WinXP Pro. (CHT) Pass nVidia GeForce 6600LE

ASUS EN6200TC128/T/16M
Rev V1.01
(BIOS: V5.44.02.11)

PCIEX16_2 Win2003 R2

Standard (CHS)

Pass nVidia GeForce 6200

(with Turbo cache)

ASUS EN6600 256M
Rev. V1.00A
(BIOS: V5.43.02.16.AS11)

PCIEX16_1 WinXP Pro. (CHT) Pass nVidia GeForce 6600

ASUS EN7800GT 256MB
Rev: V1.00
(BIOS: V5.70.02.13.AS01)

PCIEX16_2 Win2003-64 R2

Standard

Pass nVidia GeForce 7800GT

ATI FireMV2200
(BIOS: V113.A25915.100)

PCIEX16_1 Win2003-64 R2

Standard

Pass ATI FireMV 2200

3Dlabs Wildcat Realizm

500 256M
Rev. 08 (BIOS: V3.37)

PCIEX16_1 Win2003 R2

Standard (CHS)

Pass 3Dlabs Wildcat Realizm P25

Type: PCIEX16

Qualied graphics cards (Work station level)

2-24 Chapter 2: Hardware information

SCSI RAID controllers

Model
Type: PCI

Connect
Interface

OS Environment Status Chipset

Intel SRCU42L
(BIOS: V2.34.05-Ro43)

PCIX_2 WinXP Pro. Pass GC80303

Model
Type: PCI

Connect
Interface

OS Environment Status Chipset

Mylex AcceleRAID 170
Rev.A (BIOS: V6.01-30)

PCI1 Win2003 R2

Standard

Pass GC80960RM100

Model
Type: PCI

Connect
Interface

OS Environment Status Chipset

Intel SRCU42E Ultra320
(BIOS: H420)

PCIEX16_2 WinXP Pro. Pass Intel 80332

Type: PCI-X

Type: PCI

Type: PCIEX8

Model
Type: PCI

Connect
Interface

OS Environment Status Chipset

3Com 3C996B-T PCIX_2 Win2000 Pro. Pass Broadcom BCM5701KHB

ASUS PXI-G45 PCIX_2 Win2000 Pro. Pass Intel RC82545EM

Type: PCI-X

1000 BaseTx Ethernet Adapters

ASUS M2N32 WS Professional 2-25

2.6 Jumper

Clear RTC RAM (CLRTC)

This jumper allows you to clear the Real Time Clock (RTC) RAM in
CMOS. You can clear the CMOS memory of date, time, and system setup
parameters by erasing the CMOS RTC RAM data. The onboard button
cell battery powers the RAM data in CMOS, which include system setup
information such as system passwords.

To erase the RTC RAM:

1. Turn OFF the computer and unplug the power cord.

2. Remove the onboard battery.

3. Move the jumper cap from pins 1-2 (default) to pins 2-3. Keep the cap on
pins 2-3 for about 5~10 seconds, then move the cap back to pins 1-2.

4. Reinstall the battery.

5. Plug the power cord and turn ON the computer.

6. Hold down the <Del> key during the boot process and enter BIOS setup
to re-enter data.

Except when clearing the RTC RAM, never remove the cap on CLRTC jumper
default position. Removing the cap will cause system boot failure!

• Make sure to re-enter your previous BIOS settings after you clear the
CMOS.

• You do not need to clear the RTC when the system hangs due to
overclocking. For system failure due to overclocking, use the C.P.R. (CPU
Parameter Recall) feature. Shut down and reboot the system so the BIOS
can automatically reset parameter settings to default values.

M2N32 WS PRO

®

M2N32 WS PRO Clear RTC RAM

CLRTC

Normal Clear RTC

(Default)

1 2 2 3

2-26 Chapter 2: Hardware information

2. PCI-X Speed setting (6-pin PCIX_SPEED)

This jumper allows you to set the PCI-X slots’ maximum frequency
capability.

Default setting [Auto]: a single PCI-X card installed on a PCI-X slot can

provide 133 MHz capability, and two PCI-X cards installed on both PCI-X

slots can provide 100 MHZ capability for reliability.

3~4: the slots will have 133 MHZ capability whether you install one or two
cards.

5~6: the slots will have 100 MHZ capability whether you install one or two
cards.

M2N32 WS PRO

®

M2N32 WS PRO PCIX Speed setting

PCIX_SPEED

AUTO by PCIX Card

(Default)

Force PCI-X 133MHz Force PCI-X 100MHz

1 1 1

ASUS M2N32 WS Professional 2-27

2.7 Connectors

2.7.1 Rear panel connectors

1. PS/2 mouse port (green). This port is for a PS/2 mouse.

2. Parallel port.

This 25-pin port connects a parallel printer, a scanner, or other

devices.

3. LAN 1 (RJ-45) port.

Supported by Marvell® 88E1116 Gigabit LAN controller,
this port allows Gigabit connection to a Local Area Network (LAN) through a
network hub. Refer to the table below for the LAN port LED indications.

4. LAN 2 (RJ-45) port.

Supported by the Marvell® 88E1116 Gigabit LAN
controller, this port allows Gigabit connection to a Local Area Network
(LAN) through a network hub. Refer to the table below for the LAN port LED
indications.

11

4 61

16215 14 12

3 5 7 8

910

13

5. Rear Speaker Out port (black). This port connects the rear speakers in a

4-channel, 6-channel, or 8-channel audio conguration.

6. Center/Subwoofer port (orange).

This port connects the center/subwoofer

speakers.

7. Line In port (light blue).

This port connects the tape, CD, DVD player, or

other audio sources.

8. Line Out port (lime).

This port connects a headphone or a speaker. In

4-channel, 6-channel, and 8-channel conguration, the function of this port

becomes Front Speaker Out.

Activity/Link Speed LED
Status Description Status Description

OFF No link OFF 10 Mbps connection

ORANGE Linked ORANGE 100 Mbps connection

BLINKING Data activity GREEN 1 Gbps connection

LAN port LED indications

SPEED

LED

ACT/LINK

LED

LAN port

2-28 Chapter 2: Hardware information

Refer to the audio conguration table below for the function of the audio ports in
2, 4, 6, or 8-channel conguration.

9. Microphone port (pink). This port connects a microphone.

10. Side Speaker Out port (gray).

This port connects the side speakers in an

8-channel audio conguration.

Audio 2, 4, 6, or 8-channel conguration

Port Headset

2-channel

4-channel 6-channel 8-channel

Light Blue Line In Line In Line In Line In

Lime Line Out Front Speaker Out Front Speaker Out Front Speaker Out

Pink Mic In Mic In Mic In Mic In

Gray – – – Side Speaker Out

Black – Rear Speaker Out Rear Speaker Out Rear Speaker Out

Orange – – Center/Subwoofer Center/Subwoofer

11. USB 2.0 ports 1 and 2. These two 4-pin Universal Serial Bus (USB) ports

are available for connecting USB 2.0 devices.

12. USB 2.0 ports 3 and 4.

These two 4-pin Universal Serial Bus (USB) ports

are available for connecting USB 2.0 devices.

13. External SATA port. This port connects to an external SATA box or a Serial

ATA port multiplier.

14. Optical S/PDIF Out port

. This port connects an external audio output device

via an optical S/PDIF cable.

15. Coaxial S/PDIF Out port.

This port connects an external audio output device

via an coaxial S/PDIF cable.

16. PS/2 keyboard port (purple)

. This port is for a PS/2 keyboard.

The external SATA port supports
external Serial ATA 3.0 Gb/s
devices. Longer cables support
higher power requirements to
deliver signal up to two meters
away, and enables improved hot­swap function.

ASUS M2N32 WS Professional 2-29

2.7.2 Internal connectors

1. Floppy disk drive connector (34-1 pin FLOPPY)

This connector is for the provided oppy disk drive (FDD) signal cable. Insert

one end of the cable to this connector, then connect the other end to the

signal connector at the back of the oppy disk drive.

Pin 5 on the connector is removed to prevent incorrect cable connection when
using a FDD cable with a covered Pin 5.

2. NVIDIA® IDE connector (40-1 pin PRI_IDE)

The onboard IDE connector is for the Ultra DMA (133/)100/66 signal cable.
There are three connectors on each Ultra DMA 133/100/66 signal cable:
blue, black, and gray. Connect the blue connector to the motherboard’s IDE

connector, then select one of the following modes to congure your device.

• Pin 20 on the IDE connector is removed to match the covered hole on the
Ultra DMA cable connector. This prevents incorrect insertion when you
connect the IDE cable.

• Use the 80-conductor IDE cable for Ultra DMA 100/66 IDE devices.

If any device jumper is set as “Cable-Select,” make sure all other device
jumpers have the same setting.

Drive jumper setting Mode of

device(s)

Cable connector

Single device Cable-Select or Master - Black

Two devices Cable-Select Master

Black

Slave Gray

Master Master Black or gray

Slave Slave

M2N32 WS PRO

®

M2N32 WS PRO Floppy disk drive connector

NOTE: Orient the red markings on

the floppy ribbon cable to PIN 1.

PIN 1

FLOPPY

2-30 Chapter 2: Hardware information

M2N32 WS PRO

®

M2N32 WS PRO IDE connector

NOTE: Orient the red markings

(usually zigzag) on the IDE

ribbon cable to PIN 1.

PRI_IDE

M2N32 WS PRO

®

M2N32 WS PRO IDE connectors

NOTE: Orient the red markings

(usually zigzag) on the IDE

ribbon cable to PIN 1.

PRI_EIDE

PIN 1

3. Marvell® IDE connector (40-1 pin PRI_EIDE)

This connector is for the Ultra DMA 133/100/66 signal cable. The Marvell IDE
connector supports up to 2 IDE hard disk drives for easier data storage.

ASUS M2N32 WS Professional 2-31

4. NVIDIA® nForce® 590 SLI Southbridge Serial ATA connectors (7-pin
SATA1 [red], SATA2 [red], SATA3 [red], SATA4 [red], SATA5 [red], SATA6
[red])

These connectors are for the Serial ATA signal cables for Serial ATA 3.0
Gb/s hard disk and optical disk drives. The Serial ATA 3.0 Gb/s is backward

compatible with Serial ATA 1.5 Gb/s specication.

If you installed Serial ATA hard disk drives, you can create a RAID 0, RAID

1, RAID 0+1, RAID 5, or JBOD conguration through the onboard NVIDIA®

MediaShield™ controller.

The RAID function of these connectors is set to [Disabled] by default. If you
intend to create a Serial ATA RAID set using these connectors, enable the RAID

Enabled item in the SATA Conguration sub-menu in the BIOS. See section
“4.4.7 Onboard Device Conguration” for details.

M2N32 WS PRO

®

M2N32 WS PRO SATA connectors

SATA5

GND

RSATA_TXP5

RSATA_TXN5

GND

RSATA_RXP5

RSATA_RXN5

GND

SATA3

GND

RSATA_TXP3

RSATA_TXN3

GND

RSATA_RXP3

RSATA_RXN3

GND

SATA1

GND

RSATA_TXP1

RSATA_TXN1

GND

RSATA_RXP1

RSATA_RXN1

GND

SATA6

GND

RSATA_TXP6

RSATA_TXN6

GND

RSATA_RXP6

RSATA_RXN6

GND

SATA4

GND

RSATA_TXP4

RSATA_TXN4

GND

RSATA_RXP4

RSATA_RXN4

GND

SATA2

GND

RSATA_TXP2

RSATA_TXN2

GND

RSATA_RXP2

RSATA_RXN2

GND

2-32 Chapter 2: Hardware information

5. Marvell® 88SE614x Serial ATA connectors

(7-pin EXT_SATA1, EXT_SATA2, EXT_SATA3)

These connectors are for Serial ATA signal cables. These connectors support
Serial ATA hard disk drives.

M2N32 WS PRO

®

M2N32 WS PRO EXT_SATA connectors

EXT_SATA1

GND

RSATA_TXP1

RSATA_TXN1

GND

RSATA_RXP1

RSATA_RXN1

GND

GND
RSATA_TXP3
RSATA_TXN3

GND
RSATA_RXP3
RSATA_RXN3

GND

GND

RSATA_TXP2

RSATA_TXN2

GND

RSATA_RXP2

RSATA_RXN2

GND

EXT_SATA3 EXT_SATA2

ASUS M2N32 WS Professional 2-33

6. USB connectors (10-1 pin USB56, USB78, USB910)

These connectors are for USB 2.0 ports. Connect the USB/GAME module
cable to any of these connectors, then install the module to a slot opening at
the back of the system chassis. These USB connectors comply with USB 2.0

specication that supports up to 480 Mbps connection speed.

Never connect a 1394 cable to the USB connectors. Doing so will damage the
motherboard!

M2N32 WS PRO

®

M2N32 WS PRO USB 2.0 connectors

USB56 USB78

USB910

USB+5V

USB_P10-

USB_P10+

GND

NC

USB+5V

USB_P9-

USB_P9+

GND

1

USB+5V

USB_P6-

USB_P6+

GND

NC

USB+5V

USB_P5-

USB_P5+

GND

1

USB+5V

USB_P8-

USB_P8+

GND

NC

USB+5V

USB_P7-

USB_P7+

GND

1

7. IEEE 1394a port connectors (10-1 pin IE1394_1; 10-1 pin IE1394_2)

These connectors are for IEEE 1394a ports. Connect the IEEE 1394a
module cables to any of these connectors, then install the module to a slot
opening at the back of the system chassis.

Never connect a USB cable to the IEEE 1394a connector. Doing so will damage
the motherboard!

M2N32 WS PRO

®

M2N32 WS PRO IEEE 1394a connector

IE1394_1

1

GND

+12V

TPB1-

GND

TPA1-

+12V

TPB1+

GND

TPA1+

IE1394_2

1

GND

+12V

TPB1-

GND

TPA1-

+12V

TPB1+

GND

TPA1+

2-34 Chapter 2: Hardware information

8. CPU, Chassis, and Power Fan connectors
(4-pin CPU_FAN, 3-pin CHA_FAN1, 3-pin CHA_FAN2, 3-pin CHA_FAN3,
3-pin CHA_FAN4, 3-pin SPS_FAN1)

The fan connectors support cooling fans of 350 mA ~ 2000 mA (24 W max.) or
a total of 1 A ~ 3.48 A (41.76 W max.) at +12V. Connect the fan cables to the
fan connectors on the motherboard, making sure that the black wire of each
cable matches the ground pin of the connector.

Do not forget to connect the fan cables to the fan connectors. Insufcient air
ow inside the system may damage the motherboard components. These are

not jumpers! Do not place jumper caps on the fan connectors!

M2N32 WS PRO

®

M2N32 WS PRO Fan connectors

CPU_FAN

GND
CPU FAN PWR
CPU FAN IN
CPU FAN PWM

GND

Rotation

+12V

SPS_FAN

CHA_FAN2

GND

Rotation

CHA_FANPWR

CHA_FAN1

CHA_FAN4

GND

x

+12V

CHA_FAN3

CPU_FAN

SPS_FAN1

CHA_FAN2

CHA_FAN1

CHA_FAN4

CHA_FAN3

GND

Rotation

CHA_FANPWR

GND

x

+12V

ASUS M2N32 WS Professional 2-35

10. ATX power connectors
(24-pin EATXPWR, 8-pin EATX12V)

These connectors are for ATX power supply plugs. The power supply plugs

are designed to t these connectors in only one orientation. Find the proper
orientation and push down rmly until the connectors completely t.

9. Chassis intrusion connector (4-1 pin CHASSIS)

This connector is for a chassis-mounted intrusion detection sensor or switch.
Connect one end of the chassis intrusion sensor or switch cable to this
connector. The chassis intrusion sensor or switch sends a high-level signal to
this connector when a chassis component is removed or replaced. The signal
is then generated as a chassis intrusion event.

By default, the pins labeled “Chassis Signal” and “Ground” are shorted with
a jumper cap. Remove the jumper caps only when you intend to use the
chassis intrusion detection feature.

M2N32 WS PRO

®

M2N32 WS PRO Chassis intrusion connector

CHASSIS

+5VSB_MB

Chassis Signal

GND

(Default)

M2N32 WS PRO

®

M2N32 WS PRO ATX power connectors

EATXPWR

ATX12V

+3 Volts

+3 Volts

Ground

+5 Volts

+5 Volts

Ground

Ground

Power OK

+5V Standby

+12 Volts

-5 Volts

+5 Volts

+3 Volts

-12 Volts

Ground

Ground
Ground
PSON#

Ground

+5 Volts

+12 Volts

+3 Volts

+5 Volts

Ground

GND +12V DC

GND +12V DC

GND +12V DC

GND +12V DC

2-36 Chapter 2: Hardware information

•

For a fully congured system, we recommend that you use a power supply

unit (PSU) that complies with ATX 12 V Specication 2.0 (or later version)

and provides a minimum power of 600 W.

• Do not forget to connect the 4-pin ATX +12 V power plug; otherwise, the

system will not boot.

• Use of a PSU with a higher power output is recommended when

conguring a system with more power-consuming devices. The system

may become unstable or may not boot up if the power is inadequate.

11. Front panel audio connector (10-1 pin AAFP)

This connector is for a chassis-mounted front panel audio I/O module that
supports either HD Audio or legacy AC`97 audio standard. Connect one end
of the front panel audio I/O module cable to this connector.

•

We recommend that you connect a high-denition front panel audio

module to this connector to avail of the motherboard’s high-denition audio

capability.

• By default, this connector is set to AC97. If you want to connect a legacy

AC97 front panel audio module to this connector, set the Front Panel
Support Type item in the BIOS to [HD Audio]. See section “4.4.7 Onboard

Device Conguration” for details.

M2N32 WS PRO

®

M2N32 WS PRO Analog front panel connector

AAFP

NC

MIC2

Line out_R

Line out_L

NC

NC

MICPWR

NC

AGND

SENSE2_RETUR

PORT1 L

PORT2 R

PORT2 L

SENSE1_RETUR

SENSE_SEND

PORT1 R

PRESENCE#

GND

ASUS M2N32 WS Professional 2-37

12. Internal audio connector (4-pin CD [Black])

These connectors allow you to receive stereo audio input from sound sources
such as a CD-ROM, TV tuner, or MPEG card.

13 Serial port connector (10-1 pin COM1)

This connector is for a serial (COM) port. Connect the serial port module
cable to this connector, then install the module to a slot opening at the back
of the system chassis.

M2N32 WS PRO

®

M2N32 WS PRO Internal audio connector

CD

(black)

Right Audio Channel

Left Audio Channel

Ground

Ground

M2N32 WS PRO

®

M2N32 WS PRO COM port connector

PIN 1

COM1

2-38 Chapter 2: Hardware information

14. TPM connector (20-1 pin TPM)

This connector supports a Trusted Platform Module (TPM) system, which can

securely store keys, digital certicates, passwords, and data. A TPM system

also helps enhance network security, protects digital identities, and ensures
platform integrity.

The TPM module is purchased separately.

M2N32 WS PRO

®

CK_33M_TPM

LFRAMEn

LRESETn

LAD3

+3.3V

LAD0

+3.3VXGND

LPC_PD#

GND

X

X

LAD2

LAD1

GND

SERIRQ

X

X

TPM

1

M2N32 WS PRO TPM connector

ASUS M2N32 WS Professional 2-39

•

System power LED (2-pin PLED)

This 3-pin connector is for the system power LED. Connect the chassis
power LED cable to this connector. The system power LED lights up when
you turn on the system power, and blinks when the system is in sleep mode.

•

Hard disk drive activity LED (2-pin IDE_LED)

This 2-pin connector is for the HDD Activity LED. Connect the HDD Activity

LED cable to this connector. The IDE LED lights up or ashes when data is

read from or written to the HDD.

•

System warning speaker (4-pin SPEAKER)

This 4-pin connector is for the chassis-mounted system warning speaker. The
speaker allows you to hear system beeps and warnings.

•

ATX power button/soft-off button (2-pin PWR)

This connector is for the system power button. Pressing the power button
turns the system on or puts the system in sleep or soft-off mode depending
on the BIOS settings. Pressing the power switch for more than four seconds
while the system is ON turns the system OFF.

•

Reset button (2-pin RESET)

This 2-pin connector is for the chassis-mounted reset button for system
reboot without turning off the system power.

15. System panel connector (20-pin PANEL)

This connector supports several chassis-mounted functions.

M2N32 WS PRO

®

M2N32 WS PRO System panel connector

* Requires an ATX power supply.

PANEL

PLED-

PWR

+5V

Speaker

Ground

RESET

Ground

Reset

Ground

Ground

PWRSW

PLED+

IDE_LED-

IDE_LED+

IDE_LED

PLED SPEAKER

2-40 Chapter 2: Hardware information

3

Powering up

This chapter describes the power up
sequence and ways of shutting down the
system.

ASUS M2N32 WS Professional

Chapter summary

3

3.1 Starting up for the rst time ........................................................ 3-1

3.2 Powering off the computer ..........................................................

3-2

ASUS M2N32 WS Professional 3-1

3.1 Starting up for the rst time

1. After making all the connections, replace the system case cover.

2. Be sure that all switches are off.

3. Connect the power cord to the power connector at the back of the system
chassis.

4. Connect the power cord to a power outlet that is equipped with a surge
protector.

5. Turn on the devices in the following order:

a. Monitor

b. External SCSI devices (starting with the last device on the chain)

c. System power

6. After applying power, the system power LED on the system front panel case
lights up. For systems with ATX power supplies, the system LED lights up
when you press the ATX power button. If your monitor complies with “green”
standards or if it has a “power standby” feature, the monitor LED may light up
or switch between orange and green after the system LED turns on.

The system then runs the power-on self tests or POST. While the tests are

running, the BIOS beeps or additional messages appear on the screen.
If you do not see anything within 30 seconds from the time you turned on
the power, the system may have failed a power-on test. Check the jumper
settings and connections or call your retailer for assistance.

7. At power on, hold down the <Delete> key to enter the BIOS Setup. Follow the
instructions in Chapter 4.

3-2 Chapter 3: Powering up

3.2 Powering off the computer

3.2.1 Using the OS shut down function

If you are using Windows® 2000:

1. Click the Start button then click Shut Down...

2. Make sure that the Shut Down option button is selected, then click the OK
button to shut down the computer.

3. The power supply should turn off after Windows

®

shuts down.

If you are using Windows® XP:

1. Click the Start button then select Turn Off Computer.

2. Click the Turn Off button to shut down the computer.

3. The power supply should turn off after Windows

®

shuts down.

3.2.2 Using the dual function power switch

While the system is ON, pressing the power switch for less than four seconds puts
the system to sleep mode or to soft-off mode, depending on the BIOS setting.
Pressing the power switch for more than four seconds lets the system enter the
soft-off mode regardless of the BIOS setting. Refer to section “4.5 Power Menu”
in Chapter 4 for details.

4

BIOS setup

This chapter tells how to change
the system settings through the BIOS
Setup menus. Detailed descriptions
of the BIOS parameters are also
provided.

Chapter summary

4

ASUS M2N32 WS Professional

4.1 Managing and updating your BIOS ............................................ 4-1

4.2

BIOS setup program .................................................................. 4-10

4.3 Main menu .................................................................................. 4-14

4.4 Advanced menu .........................................................................

4-19

4.5 Power menu ................................................................................

4-34

4.6 Boot menu ..................................................................................

4-38

4.7 Tools menu .................................................................................

4-43

4.8 Exit menu ....................................................................................

4-48

ASUS M2N32 WS Professional 4-1

4.1 Managing and updating your BIOS

The following utilities allow you to manage and update the motherboard Basic
Input/Output System (BIOS) setup.

1.

ASUS Update (Updates the BIOS in Windows® environment.)

2.

ASUS EZ Flash 2 (Updates the BIOS in DOS using a oppy disk or the

motherboard support CD.)

3.

Award BIOS Flash Utility (Updates the BIOS in DOS mode using a bootable

oppy disk.)

4.

ASUS CrashFree BIOS 3 (Updates the BIOS using a bootable oppy disk or
the motherboard support CD when the BIOS le fails or gets corrupted.)

Refer to the corresponding sections for details on these utilities.

Save a copy of the original motherboard BIOS le to a bootable oppy disk in

case you need to restore the BIOS in the future. Copy the original motherboard
BIOS using the ASUS Update or Award BIOS Flash utilities.

Installing ASUS Update

To install ASUS Update:

1. Place the support CD in the optical drive. The Drivers menu appears.

2. Click the Utilities tab, then click Install ASUS Update VX.XX.XX. See page
5-3 for the Utilities screen menu.

3. The ASUS Update utility is copied to your system.

4.1.1 ASUS Update utility

The ASUS Update is a utility that allows you to manage, save, and update the
motherboard BIOS in Windows® environment. The ASUS Update utility allows you
to:

• Save the current BIOS le

• Download the latest BIOS le from the Internet

• Update the BIOS from an updated BIOS le

• Update the BIOS directly from the Internet, and

• View the BIOS version information.

This utility is available in the support CD that comes with the motherboard
package.

ASUS Update requires an Internet connection either through a network or an
Internet Service Provider (ISP).

4-2 Chapter 4: BIOS setup

Quit all Windows® applications before you update the BIOS using this utility.

3. Select the ASUS FTP site nearest

you to avoid network trafc, or

click Auto Select. Click Next.

Updating the BIOS through the Internet

To update the BIOS through the Internet:

1. Launch the ASUS Update utility from the Windows

®

desktop by clicking Start

> Programs > ASUS > ASUSUpdate > ASUSUpdate. The ASUS Update
main window appears.

2. Select Update BIOS from the
Internet option from the drop-down
menu, then click Next.

ASUS M2N32 WS Professional 4-3

Updating the BIOS through a BIOS le

To update the BIOS through a BIOS le:

1. Launch the ASUS Update utility from the Windows

®

desktop by clicking Start
> Programs > ASUS > ASUSUpdate > ASUSUpdate. The ASUS Update main
window appears.

2. Select Update BIOS from a le

option from the drop-down menu,
then click Next.

4. From the FTP site, select the BIOS
version that you wish to download.
Click Next.

5. Follow the screen instructions to
complete the update process.

The ASUS Update utility is
capable of updating itself through
the Internet. Always update the
utility to avail all its features.

3. Locate the BIOS le from the Open

window, then click Open.

4. Follow the screen instructions to
complete the update process.

4-4 Chapter 4: BIOS setup

4.1.2 Creating a bootable oppy disk

1. Do either one of the following to create a bootable oppy disk.

DOS environment

a. Insert a 1.44MB oppy disk into the drive.

b. At the DOS prompt, type

format

A:/S then press <Enter>.

Windows® XP environment

a. Insert a 1.44 MB oppy disk to the oppy disk drive.

b. Click

Start from the Windows® desktop, then select My Computer.

c. Select the 3 1/2 Floppy Drive icon.

d. Click File from the menu, then select

Format. A Format 3 1/2 Floppy

Disk window appears.

e. Select

Create an MS-DOS startup disk from the format options eld,

then click Start.

Windows® 2000 environment

To create a set of boot disks for Windows® 2000:

a. Insert a formatted, high density 1.44 MB oppy disk into the drive.

b. Insert the Windows

®

2000 CD to the optical drive.

c. Click

Start, then select Run.

d. From the Open eld, type

D:\bootdisk\makeboot a:

assuming that D: is your optical drive.

e. Press <Enter>, then follow screen instructions to continue.

2. Copy the original or the latest motherboard BIOS le to the bootable oppy

disk.

ASUS M2N32 WS Professional 4-5

To update the BIOS using EZ Flash 2:

1. Visit the ASUS website (www.asus.com) to download the latest BIOS le for

the motherboard.

2. Save the BIOS le to a oppy disk, then restart the system.

3. You can launch the EZ Flash 2 by two methods.

(1) Insert the oppy disk/USB ash disk that contains the BIOS le to

the oppy disk drive or the USB port.

4.1.3 ASUS EZ Flash 2 utility

The ASUS EZ Flash 2 feature allows you to update the BIOS without having to go

through the long process of booting from a oppy disk and using a DOS-based

utility. The EZ Flash utility is built-in the BIOS chip so it is accessible by pressing
<Alt> + <F2> during the Power-On Self Tests (POST).

• This function can support devices such as USB ash disk, hard disk,
or oppy disk with FAT32/16/12 format only.

• Do not shut down or reset the system while updating the BIOS to
prevent system boot failure!

ASUSTek EZ Flash 2 BIOS ROM Utility B312

Current ROM Update ROM

BOARD: M2N32WS
Professional
VER: 0122
DATE: 04/24/2006

BOARD: Unknown
VER: Unknown
DATE: Unknown

PATH: C:\M2NPVOC

[Enter] Select [S] Save [ESC]Exit
[Tab]Switch [Up/Down/Home/End] Move

WIN98E <DIR>
NETTERM <DIR>
DRIVERS <DIR>
RECYCLED <DIR>
WUTEMP <DIR>
NEWFOL~1 <DIR>
INSTALL <DIR>
TEST-REB <DIR>
MSDOWNLD.TMP <DIR>

Note

(2) Enter BIOS setup program. Go to the Tools menu to select EZ

Flash 2 and press <Enter> to enable it.

You can switch between drives by pressing <Tab> before the

correct le is found. Then press <Enter>.

4. When the correct BIOS le is found, EZ Flash 2 performs the BIOS update

process and automatically reboots the system when down.

Press <Alt> + <F2> during POST to display the following.

FLASH TYPE: Winbond W39V080A 8Mb LPC

WIN98E <DIR>

A:

C:

4-6 Chapter 4: BIOS setup

4.1.4 Updating the BIOS

The Basic Input/Output System (BIOS) can be updated using the AwardBIOS
Flash Utility. Follow these instructions to update the BIOS using this utility.

1. Download the latest BIOS le from the ASUS web site. Rename the le to
M2N32-WS.BIN and save it to a oppy disk, CD ROM or a USB ash disk in

FAT 16/12 format.

Save only the updated BIOS le in the oppy disk to avoid loading the wrong
BIOS le.

2. Copy the AwardBIOS Flash Utility (awdash.exe) from the Software folder of
the support CD to the oppy disk, CD ROM or a USB ash disk with the latest
BIOS le.

3. Boot the system in DOS mode using the bootable oppy disk, CD ROM or a
USB ash disk you created earlier.

4. Under the DOS mode,
use <X:> (X stands for
the name of the disk
assignment) to switch to

the folder of oppy disk,
CD ROM or USB ash

disk you saved the BIOS

le and Award BIOS Flash

Utility.

5. At the prompt, type

awdash then press

<Enter>. The Award BIOS
Flash Utility screen appears.

AwardBIOS Flash Utility for ASUS V1.14

(C) Phoenix Technologies Ltd. All Rights Reserved

Message: Please input File Name!

For C51XEMCP55PXE-M2N32-WS-00 DATE:04/13/2006
Flash Type - Unknown Flash

File Name to Program:

AwardBIOS Flash Utility for ASUS V1.14

(C) Phoenix Technologies Ltd. All Rights Reserved

For C51XEMCP55PXE-M2N32-WS-00 DATE:04/13/2006
Flash Type - Unknown Flash

File Name to Program: 0104.bin

Message: Do You Want To Save Bios (Y/N)

6. Type the BIOS le name in

the File Name to Program

eld, then press <Enter>.

ASUS M2N32 WS Professional 4-7

7. Press <N> when the utility prompts you to save the current BIOS le. The

following screen appears.

8. The utility veries the BIOS
le in the oppy disk, CD
ROM or a USB ash disk
and starts ashing the
BIOS le.

Do not turn off or reset the system during the ashing process!

AwardBIOS Flash Utility for ASUS V1.14

(C) Phoenix Technologies Ltd. All Rights Reserved

Warning: Don’t Turn Off Power Or Reset System!

9. The utility displays a
Flashing Complete
message indicating that
you have successfully

ashed the BIOS le.
Remove the oppy disk

then press <F1> to restart
the system.

AwardBIOS Flash Utility for ASUS V1.14

(C) Phoenix Technologies Ltd. All Rights Reserved

F1

Reset

For C51XEMCP55PXE-M2N32-WS-00 DATE:04/13/2006
Flash Type - Unknown Flash

File Name to Program: 0107.bin
Flashing Complete

Press <F1> to Continue

Write OK No Update Write Fail

For C51XEMCP55PXE-M2N32-WS-00 DATE:04/13/2006
Flash Type - Unknown Flash

File Name to Program: 0107.bin

Programming Flash Memory - OFE00 OK

Write OK No Update Write Fail

4-8 Chapter 4: BIOS setup

4. The utility saves the

current BIOS le to the
oppy disk, then returns to
the BIOS ashing process.

3. Type a lename for the
current BIOS le in the
Save current BIOS as eld,

then press <Enter>.

To save the current BIOS le using the AwardBIOS Flash Utility:

1. Follow steps 1 to 6 of the
previous section.

2. Press <Y> when the utility
prompts you to save the

current BIOS le. The

following screen appears.

4.1.5 Saving the current BIOS le

You can use the AwardBIOS Flash Utility to save the current BIOS le. You can
load the current BIOS le when the BIOS le gets corrupted during the ashing

process.

AwardBIOS Flash Utility for ASUS V1.14

(C) Phoenix Technologies Ltd. All Rights Reserved

Message:

For C51XEMCP55PXE-M2N32-WS-00 DATE:04/13/2006
Flash Type - Unknown Flash

File Name to Program: 0107.bin

Save current BIOS as:

AwardBIOS Flash Utility for ASUS V1.14

(C) Phoenix Technologies Ltd. All Rights Reserved

Message: Please Wait!

For C51XEMCP55PXE-M2N32-WS-00 DATE:04/13/2006
Flash Type - Unknown Flash

File Name to Program: 0112.bin
Checksum: D800H
Save current BIOS as: 0113.bin

AwardBIOS Flash Utility for ASUS V1.14

(C) Phoenix Technologies Ltd. All Rights Reserved

Message: Please Wait!

For C51XEMCP55PXE-M2N32-WS-00 DATE:04/13/2006
Flash Type - Unknown Flash

File Name to Program: 0107.bin
Now Backup System BIOS to

File!

Make sure that the oppy disk, CD ROM or a USB ash disk has enough
disk space to save the le.

ASUS M2N32 WS Professional 4-9

4.1.6 ASUS CrashFree BIOS 3 utility

The ASUS CrashFree BIOS 3 is an auto recovery tool that allows you to restore

the BIOS le when it fails or gets corrupted during the updating process. You can
update a corrupted BIOS le using the motherboard support CD or the oppy disk
that contains the updated BIOS le.

Prepare the motherboard support CD or the oppy disk containing the updated

motherboard BIOS before using this utility.

Recovering the BIOS from the support CD

To recover the BIOS from the support CD:

1. Turn on the system.

2. Insert the motherboard support CD to the optical drive.

3. The utility displays the following message and automatically checks the CD

for the BIOS le.

4. Restart the system after the utility completes the updating process.

• Only the USB ash disk with FAT 32/16/12 format and single partition can
support ASUS CrashFree BIOS 3. The device size should be smaller than

8GB.

• DO NOT shut down or reset the system while updating the BIOS! Doing so
can cause system boot failure!

Award BootBlock BIOS v1.0
Copyright (c) 2000, Award Software, Inc.

BIOS ROM checksum error
Detecting IDE ATAPI device...
Found CDROM, try to Boot from it... Pass

When found, the utility reads the BIOS le and starts ashing the corrupted

BIOS le.

Award BootBlock BIOS v1.0
Copyright (c) 2000, Award Software, Inc.

BIOS ROM checksum error
Detecting IDE ATAPI device...

Recovering the BIOS from the USB ash disk

To recover the BIOS from the USB ash disk:

1. Insert the USB ash disk that contains BIOS le to the USB port.

2. Turn on the system.

3. The utility will automatically checks the devices for the BIOS le When found,
the utility reads the BIOS le and starts ashing the corrupted BIOS le.

4. Restart the system after the utility completes the updating process.

4-10 Chapter 4: BIOS setup

4.2 BIOS setup program

This motherboard supports a programmable Low-Pin Count (LPC) chip that you
can update using the provided utility described in section “4.1 Managing and
updating your BIOS.”

Use the BIOS Setup program when you are installing a motherboard, reconguring
your system, or prompted to“Run Setup.” This section explains how to congure

your system using this utility.

Even if you are not prompted to use the Setup program, you can change the

conguration of your computer in the future. For example, you can enable the

security password feature or change the power management settings. This

requires you to recongure your system using the BIOS Setup program so that the
computer can recognize these changes and record them in the CMOS RAM of the

LPC chip.

The LPC chip on the motherboard stores the Setup utility. When you start up the
computer, the system provides you with the opportunity to run this program. Press

<Del> during the Power-On Self-Test (POST) to enter the Setup utility; otherwise,

POST continues with its test routines.

If you wish to enter Setup after POST, restart the system by pressing
<Ctrl+Alt+Delete>, or by pressing the reset button on the system chassis. You can
also restart by turning the system off and then back on. Do this last option only if

the rst two failed.

The Setup program is designed to make it as easy to use as possible. Being a
menu-driven program, it lets you scroll through the various sub-menus and make
your selections from the available options using the navigation keys.

• The default BIOS settings for this motherboard apply for most conditions
to ensure optimum performance. If the system becomes unstable after
changing any BIOS settings, load the default settings to ensure system
compatibility and stability. Select the Load Default Settings item under the
Exit Menu. See section “4.8 Exit Menu.”

• The BIOS setup screens shown in this section are for reference purposes
only, and may not exactly match what you see on your screen.

• Visit the ASUS website (www.asus.com) to download the latest BIOS le for

this motherboard.

ASUS M2N32 WS Professional 4-11

4.2.1 BIOS menu screen

Select Menu

Item Specic Help

Change the day, month,
year and century.

Legend bar

General helpMenu bar

Sub-menu items

Conguration eldsMenu items

Phoenix-Award BIOS CMOS Setup Utility

Main Advanced Power Boot Tools Exit

F1:Help ↑↓ : Select Item -/+: Change Value F5: Setup Defaults
ESC: Exit →←: Select Menu Enter: Select SubMenu F10: Save and Exit

System Time 15 : 30 : 36
System Date Thu, Apr 6 2006
Language [English]

Legacy Diskette A: [1.44M, 3.5 in.]

Primary IDE Master [ST321122A]
Primary IDE Slave [ASUS CDS520/A]
SATA 1 [None]
SATA 2 [None]
SATA 3 [None]
SATA 4 [None]
SATA 5 [None]
SATA 6 [None]

HDD SMART Monitoring [Disabled]

Installed Memory 512MB
Usable Memory 511MB

4.2.2 Menu bar

The menu bar on top of the screen has the following main items:

Main For changing the basic system conguration

Advanced For changing the advanced system settings

Power For changing the advanced power management (APM)

conguration

Boot For changing the system boot conguration

Tools For changing the system tools conguration

Exit For selecting the exit options and loading default

settings

To select an item on the menu bar, press the right or left arrow key on the keyboard
until the desired item is highlighted.

• The BIOS setup screens shown in this chapter are for reference purposes
only, and may not exactly match what you see on your screen.

• Visit the ASUS website (www.asus.com) to download the latest BIOS
information.

4-12 Chapter 4: BIOS setup

4.2.4 Menu items

The highlighted item on the menu bar displays the specic items for that menu.

For example, selecting Main shows the Main menu items.

The other items (Advanced, Power, Boot, and Exit) on the menu bar have their
respective menu items.

4.2.5 Sub-menu items

A solid triangle before each item on any menu screen means that the item has a
sub-menu. To display the sub-menu, select the item and press <Enter>.

4.2.6 Conguration elds

These elds show the values for the menu items. If an item is user-congurable,
you can change the value of the eld opposite the item. You cannot select an item
that is not user-congurable.

A congurable eld is enclosed in brackets, and is highlighted when selected. To
change the value of a eld, select it then press <Enter> to display a list of options.

Refer to “4.2.7 Pop-up window.”

4.2.3 Legend bar

At the bottom of the Setup screen is a legend bar. The keys in the legend bar allow
you to navigate through the various setup menus. The following table lists the keys
found in the legend bar with their corresponding functions.

Navigation Key Function
<F1> Displays the General Help screen
<F5> Loads setup default values
<Esc> Exits the BIOS setup or returns to the main menu from a

sub-menu
Left or Right arrow Selects the menu item to the left or right

Up or Down arrow Moves the highlight up or down between elds
Page Down or – (minus) Scrolls backward through the values for the highlighted eld
Page Up or + (plus) Scrolls forward through the values for the highlighted eld
<Enter> Brings up a selection menu for the highlighted eld

<F10> Saves changes and exit

ASUS M2N32 WS Professional 4-13

4.2.7 Pop-up window

Select a menu item then press <Enter> to display a pop-up window with the

conguration options for that item.

F1:Help ↑↓ : Select Item -/+: Change Value F5: Setup Defaults
ESC: Exit →←: Select Menu Enter: Select SubMenu F10: Save and Exit

Phoenix-Award BIOS CMOS Setup Utility

Main Advanced Power Boot Tools Exit

Select Menu

Item Specic Help

Species the capacity and
physical size of diskette
drive A.

System Time 15 : 30 : 36
System Date Thu, Apr 6 2006
Language [English]

Legacy Diskette A: [1.44M, 3.5 in.]

Primary IDE Master [ST321122A]
Primary IDE Slave [ASUS CDS520/A]
SATA 1
SATA 2
SATA 3
SATA 4
SATA 5
SATA 6

HDD SMART Monitoring [Disabled]

Installed Memory 512MB

Usable Memory 512MB

4.2.8 General help

At the top right corner of the menu screen is a brief description of the selected
item.

Legacy Diskette A:

Disabled ..... [ ]

720K , 3.5 in. ..... [ ]

1.44M, 3.5 in. ..... [ ]

↑↓ :Move ENTER:Accept ESC:Abort

Pop-up menu

4-14 Chapter 4: BIOS setup

F1:Help ↑↓ : Select Item -/+: Change Value F5: Setup Defaults
ESC: Exit →←: Select Menu Enter: Select SubMenu F10: Save and Exit

Phoenix-Award BIOS CMOS Setup Utility

Main Advanced Power Boot Tools Exit

Select Menu

Item Specic Help

Change the day, month,
year and century.

System Time 15 : 30 : 36
System Date Thu, Apr 6 2006
Language [English]

Legacy Diskette A: [1.44M, 3.5 in.]

Primary IDE Master [ST321122A]
Primary IDE Slave [ASUS CDS520/A]
SATA 1 [None]
SATA 2 [None]
SATA 3 [None]
SATA 4 [None]
SATA 5 [None]
SATA 6 [None]

HDD SMART Monitoring [Disabled]

Installed Memory 512MB
Usable Memory 511MB

4.3 Main menu

When you enter the BIOS Setup program, the Main menu screen appears, giving
you an overview of the basic system information.

Refer to section “4.2.1 BIOS menu screen” for information on the menu screen
items and how to navigate through them.

4.3.1 System Time [xx:xx:xx]

Allows you to set the system time.

4.3.2 System Date [Day xx/xx/xxxx]

Allows you to set the system date.

4.3.3 Language [English]

Allows you to choose the BIOS language version from the options. Conguration

options: [English] [French] [Deutsch] [Chines (Trad.)] [Chinese (Simp.)] [Japanese]

4.3.4 Legacy Diskette A [1.44M, 3.5 in.]

Sets the type of oppy drive installed.
Conguration options: [None] [720K , 3.5 in.] [1.44M, 3.5 in.]

ASUS M2N32 WS Professional 4-15

4.3.5 Primary IDE Master/Slave

While entering Setup, the BIOS automatically detects the presence of IDE devices.
There is a separate sub-menu for each IDE device. Select a device item then
press <Enter> to display the IDE device information.

The BIOS automatically detects the values opposite the dimmed items
(Capacity, Cylinder, Head, Sector and Transfer Mode). These values are not

user-congurable. These items show N/A if no IDE device is installed in the

system.

PIO Mode [Auto]

Sets the PIO mode for the IDE device.

Conguration options: [Auto] [Mode 0] [Mode 1] [Mode 2] [Mode 3] [Mode 4]

UDMA Mode [Auto]

Disables or sets the UDMA mode. Conguration options: [Disabled] [Auto]

Primary IDE Master/Slave [Auto]

Select [Auto] to automatically detect an IDE hard disk drive. If automatic detection

is successful, the BIOS automatically lls in the correct values for the remaining
elds on this sub-menu. If the hard disk was already formatted on a previous

system, the setup BIOS may detect incorrect parameters. Select [Manual] to
manually enter the IDE hard disk drive parameters. If no drive is installed select

[None]. Conguration options: [None] [Auto] [Manual]

F1:Help ↑↓ : Select Item -/+: Change Value F5: Setup Defaults
ESC: Exit →←: Select Menu Enter: Select SubMenu F10: Save and Exit

Phoenix-Award BIOS CMOS Setup Utility

Main

Select Menu

Item Specic Help

Set a PIO mode for IDE
device. Mode0 through 4
for successive increase in
performance.

Primary IDE Master

PIO Mode [Auto]
UDMA Mode [Auto]

Primary IDE Master [Auto]
Access Mode [Auto]

Capacity 82 GB

Cylinder 39420
Head 16
Sector 255
Transfer Mode UDMA 5

4-16 Chapter 4: BIOS setup

Capacity

Displays the auto-detected hard disk capacity. This item is not congurable.

Cylinder

Shows the number of the hard disk cylinders. This item is not congurable.

Head

Shows the number of the hard disk read/write heads. This item is not congurable.

Sector

Shows the number of sectors per track. This item is not congurable.

Transfer Mode

Shows the Transfer mode. This item is not congurable.

Access Mode [Auto]

The default [Auto] allows automatic detection of an IDE hard disk drive.
Select [CHS] for this item if you set the IDE Primary Master/Slave to [Manual].

Conguration options: [CHS] [LBA] [Large] [Auto]

Before attempting to congure a hard disk drive, make sure you have the
correct conguration information supplied by the drive manufacturer. Incorrect
settings may cause the system to fail to recognize the installed hard disk.

After entering the IDE hard disk drive information into BIOS, use a disk utility,
such as FDISK, to partition and format new IDE hard disk drives. This is
necessary so that you can write or read data from the hard disk. Make sure to
set the partition of the Primary IDE hard disk drives to active.

ASUS M2N32 WS Professional 4-17

4.3.6 SATA 1-6

While entering Setup, the BIOS automatically detects the presence of Serial ATA
devices. There is a separate sub-menu for each SATA device. Select a device item
then press <Enter> to display the SATA device information.

The BIOS automatically detects the values opposite the dimmed items (Capacity,
Cylinder, Head, Landing Zone and Sector). These values are not user-

congurable. These items show 0 if no SATA device is installed in the system.

Extended Drive [Auto]

Selects the type of xed disk connected to the system.
Conguration options: [None] [Auto]

Access Mode [Auto]

Sets the sector addressing mode. Conguration options: [Large] [Auto]

F1:Help ↑↓ : Select Item -/+: Change Value F5: Setup Defaults
ESC: Exit →←: Select Menu Enter: Select SubMenu F10: Save and Exit

Phoenix-Award BIOS CMOS Setup Utility

Main

Select Menu

Item Specic Help

Selects the type of xed
disk connected to the
system.

SATA 1

Extended IDE Drive [Auto]
Access Mode [Auto]

Capacity 0 MB

Cylinder 0
Head 0
Landing Zone 0
Sector 0

Before attempting to congure a hard disk drive, make sure you have the
correct conguration information supplied by the drive manufacturer. Incorrect
settings may cause the system to fail to recognize the installed hard disk.

Capacity

Displays the auto-detected hard disk capacity. This item is not congurable.

Cylinder

Shows the number of the hard disk cylinders. This item is not congurable.

4-18 Chapter 4: BIOS setup

Head

Shows the number of the hard disk read/write heads. This item is not congurable.

Landing Zone

Shows the number of landing zone per track. This item is not congurable.

Sector

Shows the number of sectors per track. This item is not congurable.

After entering the IDE hard disk drive information into BIOS, use a disk utility,
such as FDISK, to partition and format new IDE hard disk drives. This is
necessary so that you can write or read data from the hard disk. Make sure to
set the partition of the Primary IDE hard disk drives to active.

4.3.7 HDD SMART Monitoring [Disabled]

Allows you to enable or disable the HDD Self-Monitoring Analysis and Reporting

Technology (SMART) feature. Conguration options: [Disabled] [Enabled]

4.3.8 Installed Memory [xxx MB]

Shows the size of installed memory.

4.3.9 Usable Memory [XXX MB]

Shows the size of usable memory.

ASUS M2N32 WS Professional 4-19

Phoenix-Award BIOS CMOS Setup Utility

Main Advanced Power Boot Tools Exit

Select Menu

Item Specic Help

Adjust system frequency/
voltage.

JumperFree Conguration
AI NET2
PEG Link Mode

CPU Conguration
Chipset
PCIPnP
Onboard Device Conguration

4.4 Advanced menu

The Advanced menu items allow you to change the settings for the CPU and other
system devices.

Take caution when changing the settings of the Advanced menu items. Incorrect

eld values can cause the system to malfunction.

F1:Help ↑↓ : Select Item -/+: Change Value F5: Setup Defaults
ESC: Exit →←: Select Menu Enter: Select SubMenu F10: Save and Exit

4.4.1 JumperFree Conguration

F1:Help ↑↓ : Select Item -/+: Change Value F5: Setup Defaults
ESC: Exit →←: Select Menu Enter: Select Sub-menu F10: Save and Exit

Select Menu

Item Specic Help

Press [Enter] to select
overclock prole.

JumperFree Conguration

AI Tuning [Auto]

x Overclock Options Disabled
x N.O.S. Option Disabled
x CPU Frequency [200.0]
x PCIE X16_1 Clock [Auto]
x PCIE X16_2 Clock [Auto]
x DDR2 Voltage Control [Auto]
x CPU Multiplier [Auto]
x CPU Voltage [Auto]

Advanced Voltage Control

Phoenix-Award BIOS CMOS Setup Utility

Advanced

AI Tuning [Auto]

Allows selection of CPU overclocking options to achieve desired CPU internal

frequency. Selct either one of the preset overclocking conguration options:

Manual Allows you to individually set overclocking parameters.

Auto

Loads the optimal settings for the system.

4-20 Chapter 4: BIOS setup

Overclock Options [Disabled]

Allows you to set the overclocking options.

Conguration options: [Disabled] [Overclock 3%] [Overclock 5%] [Overclock 8%]
[Overclock 10%]

The following item becomes user-congurable when you set AI Tuning to

[AI N.O.S.]

N.O.S. Option [Disabled]

Allows you to set the Non-delay Overclocking System mode.

Conguration options: [Disabled] [Overclock 3%] [Overclock 5%] [Overclock 8%]
[Overclock 10%]

The following items become user-congurable when you set AI Tuning to

[Manual].

CPU Frequency [XXX] (value is auto-detected)

Indicates the frequency sent by the clock generator to the system bus and PCI
bus. The bus frequency (external frequency) multiplied by the bus multiple equals
the CPU speed. The BIOS auto-detects the value of this item. The values range
from 200.0 to 400.0.

Setting a very high CPU frequency may cause the system to become unstable.

If this happens, revert to the default setting.

PCIEX16_1 Clock [Auto]

Allows you to set the clock of the PCI Express_1.

Conguration options: [Auto] [100MHz] ~ [200MHz]

PCIEX16_2 Clock [Auto]

Allows you to set the clock of the PCI Express_2.

Conguration options: [Auto] [100MHz] ~ [200MHz]

Standard Loads the standard settings for the system.

AI Overclock

Loads overclocking proles with optimal parameters for

stability when overclocking.

AI N.O.S.

The ASUS Non-delay Overclocking System feature
intelligently determines the system load and automatically
boosts the performance for the most demanding tasks.

The following item becomes user-congurable when you set AI Tuning to

[AI Overclocking].

ASUS M2N32 WS Professional 4-21

DDR2 Voltage Control [Auto]

Allows you to set the operating DDR2 voltage.

Conguration options: [Auto] [1.800V] [1.825V] [1.850V] ~ [2.500V]

CPU Multiplier [Auto]

Allows you to set the operating CPU multiplier. The conguration options may vary
depending on the type of CPU installed. Conguration options: [Auto] [5x] [6x] ~

[13x]

CPU Voltage [Auto]

Allows you to set the operating CPU voltage.

Conguration options: [Auto] [1.400v] [1.375v] ...[0.800v]

Advanced Voltage Control

F1:Help ↑↓ : Select Item -/+: Change Value F5: Setup Defaults
ESC: Exit →←: Select Menu Enter: Select Sub-menu F10: Save and Exit

Select Menu

Item Specic Help

Set NB Core/PCI-E Voltage.

Advanced Voltage Control

P_+1.2V Voltage [Auto]
P_VTTDDR_SW Voltage [0.5*+1.8V]
P_+1.5V Voltage [Auto]
Vcore Offset Voltage [+ 50mV]
P_+1.2V HT Voltage [+1.250V]
P_+1.3V HT MCP Voltage [Auto]
P_+1.5VSB Voltage [+1.500V]

Phoenix-Award BIOS CMOS Setup Utility

Advanced

P_+1.2V Voltage [Auto]

Allows you to set the P_+1.2V voltage.
Configuration options: [Auto] [+1.20V] [+1.25V] [+1.30V] [+1.35V] [+1.40V]

P_VTTDDR_SW Voltage [0.5*+1.8V]

Allows you to set the P_VTTDDR_SW voltage.
Configuration options: [Auto] [0.5*+1.8V] [0.6*+1.8V]

P_+1.5V Voltage [Auto]

Allows you to set the P_+1.5V voltage.
Configuration options: [Auto] [+1.500V] [+1.525V] [+1.550V] [+1.575V]... [+1.700V]

4-22 Chapter 4: BIOS setup

P_+1.3V HT MCP Voltage [Auto]

Allows you to set the P_+1.3V HT MCP voltage.
Configuration options: [Auto] [+1.300V] [+1.325V] [+1.350V]...[+1.500V]

P_+1.5VSB Voltage [+1.500V]

Allows you to set the P_+1.5VSB voltage.
Configuration options: [+1.500V] [+1.600V] [+1.700V]

4.4.2 AI NET2

F1:Help ↑↓ : Select Item -/+: Change Value F5: Setup Defaults
ESC: Exit →←: Select Menu Enter: Select Sub-menu F10: Save and Exit

Select Menu

Item Specic Help

Enable or Disable LAN
cable check during POST.

AI NET2

POST Check LAN Cable [Disabled]
POST Check LAN2 Cable [Disabled]

Pair Status Length

LAN1(1-2) Open N/A
LAN1(3-4) Open N/A
LAN1(5-6) Open N/A
LAN1(7-8) Open N/A

LAN2(1-2) Open N/A
LAN2(3-4) Open N/A
LAN2(5-6) Open N/A
LAN2(7-8) Open N/A

Phoenix-Award BIOS CMOS Setup Utility

Advanced

POST Check LAN Cable [Disabled]
POST Check LAN2 Cable [Disabled]

Enables or disables checking of the LAN/LAN2 cable during the Power-On

Self-Test (POST). Conguration options: [Disabled] [Enabled]

Vcore Offset Voltage [+ 50mV]

Allows you to set the Vcore offset voltage.
Configuration options: [+ 50mV] [+100mV] [+150mV] [+200mV]

P_+1.2V HT Voltage [+1.250V]

Allows you to set the P_+1.2V HT voltage.
Configuration options: [+1.250V] [+1.275V] [+1.300V]...[+1.425V]

ASUS M2N32 WS Professional 4-23

4.4.3 PEG Link Mode

Select Menu

Item Specic Help

Enhance performance on
PCIE serial graphic card.

PEG Link Mode

PEG Link Mode [Auto]

Phoenix-Award BIOS CMOS Setup Utility

Advanced

PEG Link Mode [Auto]

Allows you to enhance the performance of your PCI Express graphics card.

Conguration options: [Auto] [Disabled] [Normal] [Fast] [Faster]

Setting to [Fast] or [Faster] may cause your system to be unstable. If this
happens, revert to the default setting [Auto].

4.4.4 CPU Conguration

Select Menu

Item Specic Help

DRAM timing and control.

CPU Conguration

CPU Type AMD Athlon(tm) 64 FX-62 Dual Core
Processor

CPU Speed 2940 MHz
Cache RAM 1024K x2

DRAM Conguration

AMD Cool ‘n’ Quiet Function [Disabled]

Phoenix-Award BIOS CMOS Setup Utility

Advanced

F1:Help ↑↓ : Select Item -/+: Change Value F5: Setup Defaults
ESC: Exit →←: Select Menu Enter: Select SubMenu F10: Save and Exit

Select Menu

Item Specic Help

Setting platform Memclock
or limit value.

DRAM Conguration

Memory Clock Frequency [Auto]
Tcl [Auto]
Trcd [Auto]
Trp [Auto]
Tras [Auto]
1T/2T Memory Timing [Auto]

Advanced Memory Settings
DRAM Timing Control
Output Driver Control

Phoenix-Award BIOS CMOS Setup Utility

Advanced

DRAM Conguration

The items in the sub-menu show the DRAM-related information auto-detected by
the BIOS.

4-24 Chapter 4: BIOS setup

Memory Clock Frequency [Auto]

Sets the memory clock frequency.

Conguration options: [Auto] [DDR2 400] [DDR2 533] [DDR2 667] [RSVD] [DDR2 800]

Tcl [Auto]

Conguration options: [Auto][3] [4] [5] [6]

Trcd [Auto]

Conguration options: [Auto] [3] [4] [5] [6]

Trp [Auto]

Conguration options: [Auto] [3] [4] [5] [6]

Tras [Auto]

Conguration options: [Auto] [5] [6] [7] ~ [18]

1T/2T Memory Timing [Auto]

Sets the memory timing. Conguration options: [Auto] [1T] [2T]

Advance Memory Settings

CPU On-die Termination

Conguration options: [Auto] [300ohm] [150ohm] [75ohm]

Trc

Conguration options: [Auto] [11] [12] [13]...[25] [26]

Twr

Conguration options: [Auto] [3] [4] [5] [6]

Trrd

Conguration options: [Auto] [2] [3] [4] [5]

Trwt

Conguration options: [Auto] [2] [3] [4] [5] [6] [7] [8] [9]

Twtr

Conguration options: [Auto] [1] [2] [3]

Trtp

Conguration options: [Auto] [2/4] [3/5]

Twrrd

Conguration options: [Auto] [0] [1] [2] [3]

Twrwr

Conguration options: [Auto] [1] [2] [3]

Trdrd

Conguration options: [Auto] [2] [3] [4] [5]

Tref

Conguration options: [Auto] [Undef] [7.8 us] [3.9 us]

ASUS M2N32 WS Professional 4-25

Trfc

Conguration options: [Auto] [0] [1] [2] [3] [4]

DRAM Termination

Conguration options: [Auto] [Disabled] [75 ohms] [150 ohms] [50 ohms]

Max Async Latency

Conguration options: [Auto] [0 ns] [1 ns] [2 ns] [3 ns]...[14 ns] [15 ns]

R/W Queue Bypass

Conguration options: [Auto] [2x] [4x] [8x] [16x]

Dynamic Idle Cycle

CounterConguration options: [Auto] [Disabled] [Enabled]

Idle Cycle Limit

Conguration options: [Auto] [0 cycles] [4 cycles] [8 cycles] [16 cycles] [32 cycles]

[64 cycles] [128 cycles] [256 cycles]

DCQ Bypass Maximum

Conguration options: [Auto] [0x] [1x] [2x] [3x]...[14x] [15x]

DRAM Burst Length

Conguration options: [Auto] [64‐byte] [32‐byte]

RdPadRcvFIFO Delay

Conguration options: [Auto] [1.5] [2] [2.5] [3] [3.5]

Disable Jitter

Conguration options: [Auto] [OFF] [ON]

DRAM Bank Interleaving

Conguration options: [Disabled] [Enabled]

DRAM Timing Control

CKE Fine Delay

Conguration options: [Auto] [No delay] [1/64 MEMCLK delay] [2/64 MEMCLK

delay] [3/64 MEMCLK delay] [4/64 MEMCLK delay] [5/64 MEMCLK delay]...[30/64
MEMCLK delay] [31/64 MEMCLK delay]

CKE Setup Time

Conguration options: [Auto] [1/2 MEMCLK] [1 MEMCLK]

CS/ODT Fine Delay

Conguration options: [Auto] [No delay] [1/64 MEMCLK delay] [2/64 MEMCLK

delay] [3/64 MEMCLK delay] [4/64 MEMCLK delay] [5/64 MEMCLK delay]...[30/64
MEMCLK delay] [31/64 MEMCLK delay]

CS/ODT Setup Time

Conguration options: [Auto] [1/2 MEMCLK] [1 MEMCLK]

Address/Command Fine Delay

Conguration options: [Auto] [No delay] [1/64 MEMCLK delay] [2/64 MEMCLK

delay] [3/64 MEMCLK delay] [4/64 MEMCLK delay] [5/64 MEMCLK delay]...[30/64
MEMCLK delay] [31/64 MEMCLK delay]

4-26 Chapter 4: BIOS setup

Address/Command Setup Time

Conguration options: [Auto] [1/2 MEMCLK] [1 MEMCLK]

Read DQS Timing Control

Conguration options: [Auto] [No delay] [1/96 MEMCLK delay] [2/96 MEMCLK delay]

[3/96 MEMCLK delay] [4/96 MEMCLK delay] ...[47/96]

Write Data Timing Control

Conguration options: [Auto] [No delay] [1/96 MEMCLK delay] [2/96 MEMCLK delay]

[3/96 MEMCLK delay] [4/96 MEMCLK delay] ...[47/96]

DQS Receiver Enable Timing

Conguration options: [Auto] [0 ps] [50 ps] [100 ps] [150 ps] [200 ps] [250 ps] [300

ps] [350 ps] [400 ps]...[8550 ps] [8600 ps] [8650 ps] [8700 ps]

Output Driver Control

CKE Drive Strength

Conguration options: [Auto] [1.00x] [1.25x] [1.50x] [2.00x]

CS/ODT Drive Strength

Conguration options: [Auto] [1.00x] [1.25x] [1.50x] [2.00x]

Add/CMD Drive Strength

Conguration options: [Auto] [1.00x] [1.25x] [1.50x] [2.00x]

MEMCLK Drive Strength

Conguration options: [Auto] [0.75x] [1.00x] [1.25x] [1.50x]

Data Drive Strength

Conguration options: [Auto] [0.75x] [1.00x] [1.25x] [1.50x]

DQS Drive Strength

Conguration options: [Auto] [0.75x] [1.00x] [1.25x] [1.50x]

DRAM Drivers Weak Mode

Conguration options: [Auto] [Normal] [Weak]

AMD Cool ‘n’ Quiet Function [Disabled]

Enables or disables the AMD Cool ‘n’ Quiet technology.

Conguration options: [Auto] [Disabled]

ASUS M2N32 WS Professional 4-27

4.4.5 Chipset

F1:Help ↑↓ : Select Item -/+: Change Value F5: Setup Defaults
ESC: Exit →←: Select Menu Enter: Select Sub-menu F10: Save and Exit

Select Menu

Item Specic Help

Chipset

NB<->SB HT Frequency [Auto]
CPU<->NB HT Speed [Auto]
NB<->SB HT Speed [5xNB to SB HT Frequency]
SB<->NB HT Speed [5xSB to NB HT Frequency]
CPU<->NB HT Width [↓16 ↑16]
NB<->SB HT Width [↓16 ↑16]
CPU Spread Spectrum [Center]
PCIE Spread Spectrum [Disabled]
SATA Spread Spectrum [Disabled]
HT Spread Spectrum [Disabled]
SLI Broadcast Aperture [Auto]

Phoenix-Award BIOS CMOS Setup Utility

Advanced

NB<->SB HT Frequency [Auto]

Allows yout o set the Northbridge to Southbridge HT Frequency.

Conguration options: [Auto] [200.0] [201.0] [202.0]...[400.0]

CPU<->NB HT Speed [Auto]

Allows yout o set the CPU to Northbridge HT Speed.

Conguration options: [Auto] [1xCPU Frequency] [2xCPU Frequency] [3xCPU

Frequency] [5xCPU Frequency] [5xCPU Frequency]

NB<->SB HT Speed [5xNB to SB HT Frequency]

Allows you to set the Northbridge to Southbridge HT Speed.

Conguration options: [1xNB to SB HT Frequency] [2xNB to SB HT Frequency]

[3xNB to SB HT Frequency] [4xNB to SB HT Frequency] [5xNB to SB HT
Frequency]

SB<->NB HT Speed [5xSB to NB HT Frequency]

Allows you to set the Southbridge to Northbridge HT Speed.

Conguration options: [1xNB to SB HT Frequency] [2xNB to SB HT Frequency]

[3xNB to SB HT Frequency] [4xNB to SB HT Frequency] [5xNB to SB HT
Frequency]

CPU<->NB HT Width [↓16 ↑16]

Allows you to set the CPU to Northbridge HT width.
Conguration options: [↓8 ↑8] [↓16 ↑16]

NB<->SB HT Width [↓16 ↑16]

Allows you to set the Northbridge to Southbridge HT width.
Conguration options: [↓8 ↑8] [↓16 ↑16]

4-28 Chapter 4: BIOS setup

CPU Spread Spectrum [Center]

Enables or disables Spread Spectrum for CPU.

Conguration options: [Disabled] [Center] [Down]

PCIE Spread Spectrum [Disabled]

Enables or disables Spread Spectrum for PCI Express.

Conguration options: [Disabled] [Enabled]

SATA Spread Spectrum [Disabled]

Enables or disables Spread Spectrum for SATA.

Conguration options: [Disabled] [Enabled]

HT Spread Spectrum [Disabled]

Disables or sets the spread Spectrum for Hyper Transport.

Conguration options: [Disabled] [Center] [Down]

SLI Broadcast Aperture [Auto]

Disables or sets Broadcast Aperture for SLI.

Conguration options: [Auto] [Disabled]
