Apple A1085 Schematic

Download

TABLE_5_ITEM

ANGLES

3. ALL CRYSTALS & OSCILLATOR VALUES ARE IN HERTZ.

2. ALL CAPACITANCE VALUES ARE IN MICROFARADS.

1. ALL RESISTANCE VALUES ARE IN OHMS, 0.1 WATT +/- 5%.

DATE

APPD

ENG

DATE

APPD

ECN

ZONE

REV

DO NOT SCALE DRAWING

X.XXX

X.XX

DIMENSIONS ARE IN MILLIMETERS

THIRD ANGLE PROJECTION

SIZE

APPLICABLE

NOTED AS

MATERIAL/FINISH

NONE

SCALE

DESIGNER

MFG APPD

DESIGN CK

RELEASE

QA APPD

ENG APPD

DRAFTER

METRIC

SHT

DRAWING NUMBER

TITLE

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

Apple Computer Inc.

REV.

DESCRIPTION OF CHANGE

REFERENCE DESIGNATOR(S)

BOM OPTION

TABLE_5_HEAD

QTY

DESCRIPTION

PART#

TABLE_5_ITEM

SINCLAIR Q41A

INTREPID GPIOS/SERIAL/USB INTERFACES/SSCG

BATTERY CHARGER AND CONNECTOR

MARVELL GIGABIT ETHERNET PHY

SERIAL DEBUG (JOLLY ROGER, PWR/NMI/RESET)

STUFF

EXT_TMDS

ATI_MEMIO_LO

ATI_MEMIO_HI

INTREPID_USB

NEC_USB

1_5V_MAXBUS

D3_HOT D3_COLD

FIREWIRE A/B CONNECTORS, PORT POWER LIMITER

5V_HD_LOGIC 3V_HD_LOGIC

NO_4XVCORE

INT_TMDS

NO_SSCG

SPIDEY - KBD,TPAD,HALL EFFECT,PWR BUTTON

DUAL-CHANNEL LVDS

CONTENTS

PAGE

INTREPID AGP 4X/PCI

INTREPID MEMORY INTERFACE / BOOT ROM

MPC7450 DATA

TITLE PAGE AND CONTENTS

CPU PLL AND CONFIGURATION STRAPS

200PIN DDR MEMORY SODIMM CONNECTORS

INTREPID ENET/FW/UATA/EIDE INTERFACES

BBANG NO_BBANG

4 5

11 12

SSCG

DDR MEMORY MUXES

INTREPID MAXBUS AND BOOT STRAPS

GPU_SS

NO STUFF

GPU_SWITCH SERIAL_DEBUG VCORE_OFFSET 1_8V_MAXBUS

BOM OPTIONS

SYSTEM BLOCK DIAGRAM

SIL1162 TMDS TRANSMITTER

PAGE

26 27

22 23

COMPONENT LOCATIONS

SIGNAL NAMES

FUNCTIONAL TEST POINTS

SIGNAL CONSTRAINTS (2 OF 3) - DIGITAL/DIFF

1.5V/ 1.8V / 2.5V SYSTEM POWER SUPPLIES

CPU CORE VOLTAGE POWER SUPPLY

3.3V / 5V SYSTEM POWER SUPPLIES

12.8V SYSTEM POWER SUPPLY / PMU POWER SUPPLY

PMU (POWER MANAGEMENT UNIT)

INTERNAL CONNECTORS - DVD,

LMU, LIGHT SENSOR, BOOTBANGER, SLEEP LED

36 37 38

M10 ANALOG, POWER, GND

SIGNAL CONSTRAINTS (3 OF 3) - POWER NETS

43-44

41-42

FAN CONTROLLER, MODEM, SOUND

VIDEO CONNECTORS - INVERTER, DVI, S-VIDEO

CARDSLOT, HARD DRIVE, LEFT USB/BLUETOOTH

USB 2.0

SIGNAL CONSTRAINTS (1 OF 3) - DIGITAL/CLK

REVISION HISTORY (1 OF 1)

M10 LVDS/TMDS/VGA/GPIO & GPU VCORE

M10 AGP & CLOCKS

CARDBUS CONTROLLER (PCI1510)

INTREPID DECOUPLING

INTREPID POWER RAILS

FIREWIRE A/B PHY

MPC7450 MAXBUS INTERFACE

PCB NOTES AND HOLES

POWER BLOCK DIAGRAM

CONTENTS

12/18/2003

PCB1820-1615

PCBF,MLB,Q41A

ENGINEERING RELEASED

051-6598

30806001

12/19/03

SCHEM,MLB,Q41A

SCH1

051-6598

SCHEM,MLB,Q41A

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

USB PORT E

2 DATA PAIRS

RIGHT USB

Connector

Modem Board

CPU PLL

Config

MEMORY BUS

I2S I2C

AGP BUS

USB PORT A

P.15

P.14P.14

USB 2.0

J12

J3 (SHARE WITH BLUETOOTH)

J3 (SHARE WITH LEFT USB)

U44

J20/J23

U11/U12/U13/U14

J16

J17

U43

J21

U26

J10

CARDBUS

J15

U39

U36

J19

J25

U48/J2/J4

J14

J11

J13

U28

J22

J24

U49

J18

3.3V/5V

16/32 BITS

33MHZ

I2C

INTRPEID

PMU

167MHZ

1.8V

MAXBUS

32BIT ADDRESS

NOT USED

BACKUP BATTERY

LEFT USB

BlueTooth

I2C

I2S

EIDE

1394 OHCI

3.3V

8BIT TX/RX

@ 200MHz

@ 400MHZ

2 DATA PAIRS

PHY

FW - B

Connector

FW - A

125MHZ

8BIT RX

8BIT TX

3.3V

10/100/1000

Ethernet

PHY

32BITS

Connector

Serial Debug

SCCA

P.15

P.14

Circuit

Fan

Connector

TUBA (SOUND)

Connector

SUTRO (PWR)

Connector Connector

Power Supply

& Charger

SERIAL 5V

Connector

P.18

Connector

RGB

COMPOSITE

LCD Panel

Connector

LVDS

EDID (I2C)

S-Video

Connector

(DDC TOO)

2.5V

167MHZ 64BITS

P.15

P.14

P.15

P.13

P.10

P.9

P.12

P.5-6

P.7

PCI BUS

32BITS

3.3V

Controller

CardBus

Connector

CH. B

(INTERNAL MEM)

MEMORY

CH. D

MEMORY

(INTERNAL MEM)

CH. A

(INTERNAL MEM)

MEMORY

CH. C

MEMORY

(INTERNAL MEM)

USB PORT D

USB PORT B

MAXBUS

10/100/1000

2:1 DDR MUXES

SO-DIMM Connector

DDR SDRAM DIMM 0 DDR SDRAM DIMM 1

DDR MEMORY

UATA 100 EIDE

VIA/PMU

BOOTROM

FireWire

Inverter

USB PORT F

USB PORT C

Keyboard

TI PCI1510

OPTICAL DRIVE

TRACKPAD

PMU

LMU

I2C

Connector

Battery

SMBUS

3.3V

LED

SLEEP

LMU

U17

1M X 8

P.10

KB LED

LIGHT SENSOR

CONTROLLER

U52

U42

CPU

APOLLO

64BIT DATA

P.15

ETHERNET FIREWIRE

P.14

(MPC7457)

800 MB/S

100MHZ

P.11

G/MII

Ethernet

CARDSLOT

Connector

USB 2.0

BOOT ROM

P.14

Connector

DVI-I

TMDS

S-VIDEO

64MB

Connector

SYSTEM BLOCK DIAGRAM

AIRPOPT

33MHZ

1.5V/3.3V

66MHZ

ULTRA ATA/100

PCI

INTREPID

4X AGP

P.13

33MHZ

32BITS

Connector

UIDE

4 DATA PAIRS

P.28

P.30

P.29

P.25

P.26

P.32

P.31

P.32

P.24

P.32-36

P.26

P.24

P.27

P.25

P.18-21

P.22

P.22 P.22 P.22

P.25

P.33

P.25

P.26

P.28

ATI M11

051-6598

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

+1.2V/+1.0V

WHEN IT’S CONNECTED TO GND

POWER SYSTEM ARCHITECTURE

GPU_VCORE

HOWEVER, 5V SHOULD TURN ON ~2.23MS AFTER

DDR POWER

RUN/SS

HOLDS BOTH RUN/SS AT GND

REGULATOR

+PBUS

AND PREVENTS +PBUS AND +24V_PBUS FROM DROPPING BELOW 6V

BACKUP BATTERY CIRCUIT CHARGES OFF +PBUS

12.8V CHARGES BACKUP BATTERY

+PBUS

AC: 12.8V

+PBUS (12.8V)

PG 31

PG 30

1.9 MS

2.6 MS

+1_8V_MAIN

+1_5V_MAIN

~???MS

~11MS

2.6 MS

~13.5MS

1625 NOT RUNNING

NO AC: BATTERY VOLTAGE

RUN: RUNNING

SLEEP: RUNNING

SHUTDOWN: RUNNING

BATTERY VOLTAGE

STARTS ~4.25MSEC AFTER DCDC_EN_L BECOMES LOW

INTERNAL ZENER CLAMP TO 6V

TURNS ON AT >1V

RUN/SS - 5V

<100UA ALLOWED

MAIN 3V/5V

(LTC3707)

DC/DC

TURNS ON AT >1V

VCC

DCDC_EN_L

DCDC_EN_L WILL PULL ON1/ON2 LOW IN SHUTDOWN

+5V_MAIN

+1.8V_MAIN

VCC

1_5V_2_5V_OK

+BATT

+24V_PBUS

NO INRUSH PROTECTION

WHEN ONLY BATTERY IS CONNECTED

TURNS ON OUTPUT @ 2.4V

RUN: RUNNING

SLEEP: RUNNING

SHUTDOWN: STOPPED

RUN/SS - 3V

SLEEP: RUNNING

RUN: RUNNING

SHUTDOWN: STOPPED

24V IS OUTPUT ONLY FROM

CHARGER INPUT

BATTERY

BACKUP

BACKUP BATTERY

1V20_REF

U21

FEED-IN PATH

& BOOST OUTPUT

3S 3P PRISMATIC CELLS

POWER BLOCK DIAGRAM

(UNTIL DRAINED)

ADAPTER

LIMITER

INRUSH

>~13.44V TURNS-ON <~13.44V SHUTS-OFF

BUCK

BATTERY

CHARGER

(MAX1772)

+3V_PMU

LDO

+3V_PMU

14V_PBUS

+5V_MAIN

WHEN ONLY BATTERY IS CONNECTED

NO INRUSH PROTECTION

WHEN IT’S OPEN

TURNS CONTROL TO RUN/SS

INVERTER

BACKLIGHT

DC/DC

(MAX1715)

PGOOD

3V_5V_OK

PGOOD

ON1/ON2

+4_6V_BU

+5V_MAIN

+1.5V_MAIN

AGP I/O

MAXBUS BROADCOM

DC/DC

(MAX1717)

+5V_MAIN

SHDN

VCC

SLEEP

DCDC_EN

MAXBUS

SEQUENCING

+5V_MAIN

RUN: RUNNING

VCC

D3_COLD

SLEEP

DCDC_EN

DCDC_EN_L OR PMU_POWERUP_L

+5V_MAIN TURNS ON

1_5V_2_5V_OK WILL NOT PULL LOW UNTIL

INTERNAL 1.2UA CURRENT SOURCE

RUN/SS

D3_HOT

1_5V_2_5V_OK

DCDC_EN_L

SEQUENCING

GPU_VCORE

~5.88MS TO START SWITCHER

1M & 0.1UF @14V, IT TAKES

CPU_VCORE

(+1.4V/+1.5V)

DCDC_EN_L

DCDC_EN

+5V_MAIN

+3V_MAIN

+5V_SLEEP

+3V_SLEEP

2.4V - ??? MS

3V_5V_OK

SLEEP_L_LS5

SLEEP

+2_5V_MAIN

+2_5V_SLEEP

+1_5V_SLEEP

1_5V_2_5V_OK

(MAX1715 OUTPUT)

1_5V_2_5V_OK

(AT LTC1778 RUN/SS)

GPU_VCORE

(D3HOT)

GPU_VCORE

(D3COLD)

SLEEP

RUN

SHUT-DOWN

RUN

PG 31

PG 32

PG 31

PG 33

PG 32

DC/DC

(LTC1778)

SHUTDOWN: STOPPED

PG 20

SHUTDOWN: STOPPED

SLEEP: STOPPED

RUN: RUNNING

PG 35

PG 34

SLEEP: STOPPED

RUN: RUNNING

SHUTDOWN: STOPPED

MAIN 2.5V/1.5V

+5V_MAIN

INTREPID CORE

+2.5V_MAIN

MAP31 DDR I/O

RC CHARGING AT INT_VCC (5V)

TURNS ON AS LOW AS 0.8V/TYP 1.5V

EXT_VCC

AFTER PMU IS UP AND RUNNING

BECOMES ’1’; MUCH LESS THAN THE

SLEEP: D3HOT/D3COLD

+PBUS (12.8V)

SHUT-DOWN

(LTC1625)

STARTS 2.0MSEC AFTER DCDC_EN_L BECOMES LOW

(LTC3411)

PG 35

DC/DC

+3.3V_MAIN

STBYMD

<100UA ALLOWED

RC AT 1M*0.047UF @ 24V

RC AT 1M*0.1UF @ 24V

MAP31 DDR CORE

051-6598

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

I/O AREA

CONDUCTIVE MOUNTS

SPEAKER CLIPS

BOARD HOLES

CHASSIS MOUNTS

INVERTER

PREPREG (3MIL)

LAMINATE (4MIL)

PREPREG (3MIL)

LAMINATE (4MIL)

PCB SPECS

SIGNAL TRACE SPACING: 4 MILS

SIGNAL TRACE WIDTH: 4 MILS

SIGNAL (1/3 OZ + COPPER PLATING)

PREPREG (3MIL)

GROUND (1/2 OZ)

LAMINATE (4MIL)

SIGNAL (1/2 OZ)

PREPREG (3MIL)

LAMINATE (4MIL)

LAMINATE (3MIL)

PREPREG (2MIL)

CUT POWER PLANE(1 OZ)

GROUND (1/2 OZ)

SIGNAL (1/2 OZ)

SIGNAL (1/3 OZ + COPPER PLATING)

GROUND (1/2 OZ)

SIGNAL (1/2 OZ)

20R10 TH VIA OR VIA IN PAD

SIGNAL (1/2 OZ)

BOARD STACK-UP AND CONSTRUCTION

DIELECTRIC: FR-4

THICKNESS : 1.2 MM / 0.047 IN

1/2 OZ CU THICKNESS: 0.7 MILS

1.0 OZ CU THICKNESS: 1.4 MILS

IMPEDANCE : 50 OHMS +/- 10%

SEE PCB CAD FILES FOR MORE SPECIFIC INFO.

BOARD INFORMATION

ASICS HEATSINK MOUNTS

GROUND VIAS

LAYER COUNT: 12

PREPREG THICKNESS: 2-3 MILS

ZT11

255R158

OMIT

ZT75

HOLE-VIA-20R10

ZT61

HOLE-VIA-20R10

ZT63

HOLE-VIA-20R10

ZT51

HOLE-VIA-20R10

ZT54

HOLE-VIA-20R10

ZT42

HOLE-VIA-20R10

ZT64

HOLE-VIA-20R10

ZT76

HOLE-VIA-20R10

ZT59

HOLE-VIA-20R10

ZT62

HOLE-VIA-20R10

ZT22

HOLE-VIA-20R10

ZT3

HOLE-VIA-20R10

ZT25

HOLE-VIA-20R10

ZT32

HOLE-VIA-20R10

ZT31

HOLE-VIA-20R10

ZT26

HOLE-VIA-20R10

ZT23

HOLE-VIA-20R10

ZT19

HOLE-VIA-20R10

ZT15

HOLE-VIA-20R10

ZT17

HOLE-VIA-20R10

ZT13

HOLE-VIA-20R10

ZT12

HOLE-VIA-20R10

ZT21

HOLE-VIA-20R10

ZT14

HOLE-VIA-20R10

ZT18

HOLE-VIA-20R10

ZT20

HOLE-VIA-20R10

ZT4

235R126

OMIT

ZT83

OMIT

146R126

ZT5

OMIT

146R126

SH1

OG-503040

SHLD-SM

CHGND1

SP6

SPKR_CLIP_P84

SP1

SPKR_CLIP_P84

SP3

SPKR_CLIP_P84

SP5

SPKR_CLIP_P84

SP2

SPKR_CLIP_P84

BS1

STDOFF-217ODX150IDX35H-TH

SP4

SPKR_CLIP_P84

ZT6

OMIT

235R126

ZT16

OMIT

235R126

CHGND6

CHGND2

ZT10

OMIT

255R158

CHGND5

ZT77

HOLE-VIA-20R10

ZT30

HOLE-VIA-20R10

ZT28

HOLE-VIA-20R10

ZT37

HOLE-VIA-20R10

ZT39

HOLE-VIA-20R10

ZT40

HOLE-VIA-20R10

ZT27

HOLE-VIA-20R10

ZT36

HOLE-VIA-20R10

ZT38

HOLE-VIA-20R10

ZT2

OMIT

255R158

ZT24

HOLE-VIA-20R10

ZT81

HOLE-VIA-20R10

ZT34

HOLE-VIA-20R10

ZT33

HOLE-VIA-20R10

ZT43

HOLE-VIA-20R10

ZT46

HOLE-VIA-20R10

ZT50

HOLE-VIA-20R10

ZT35

HOLE-VIA-20R10

ZT44

HOLE-VIA-20R10

ZT66

HOLE-VIA-20R10

ZT67

HOLE-VIA-20R10

ZT53

HOLE-VIA-20R10

ZT52

HOLE-VIA-20R10

ZT70

HOLE-VIA-20R10

ZT71

HOLE-VIA-20R10

ZT78

HOLE-VIA-20R10

ZT69

HOLE-VIA-20R10

ZT65

HOLE-VIA-20R10

ZT45

HOLE-VIA-20R10

ZT47

HOLE-VIA-20R10

ZT49

HOLE-VIA-20R10

ZT56

HOLE-VIA-20R10

ZT48

HOLE-VIA-20R10

ZT72

HOLE-VIA-20R10

ZT55

HOLE-VIA-20R10

ZT29

HOLE-VIA-20R10

ZT82

HOLE-VIA-20R10

ZT74

HOLE-VIA-20R10

ZT79

HOLE-VIA-20R10

ZT68

HOLE-VIA-20R10

ZT60

HOLE-VIA-20R10

ZT58

HOLE-VIA-20R10

ZT41

HOLE-VIA-20R10

ZT7

HOLE-VIA-20R10

ZT9

HOLE-VIA-20R10

ZT8

HOLE-VIA-20R10

ZT1

HOLE-VIA-20R10

ZT57

HOLE-VIA-20R10

ZT80

HOLE-VIA-20R10

ZT73

HOLE-VIA-20R10

051-6598

QACK*

TEA*

A10

MCP*

A23

A28 A29

TRST*

PMON_OUT*

SHD1* HIT*

SHD0*

ARTRY*

AACK*

CI*

WT*

GBL*

TBST*

TS*

BG*

BR*

GND

VDD

A1 A2

A11

A8 A9

A12

A22

A21

A20

A19

A18

A17

A16

A15

A14

A13

A32

A31

A30

A27

A24 A25

AP1

AP4

AP2 AP3

AP0

A35

A34

A33

TT0

TT4

TSIZ1 TSIZ2

TSIZ0

TT1 TT2 TT3

DTI3

DTI2

TDI TDO TMS TCK

A26

BMODE0*

PMON_IN*

BMODE1*

DTI1

DTI0

LSSD_MODE*

TA*

L2_TSTCLK

L1_TSTCLK

EXT_QUAL

CHKS*

DX*

SRW0*

IARTRY0*

SRW1*

(1 OF 3)

HRESET*

SRESET*

TBEN

QREQ*

CKSTP_IN*

CKSTP_OUT*

SYSCLK

INT* SMI*

PLL_CFG1

CLK_OUT

OVDD

PLL_CFG0

PLL_CFG3

DRDY*

DBG*

PLL_CFG2

PLL_CFG4

BVSEL

AVDD

OVDDSENSE

PG EN

VIN

ADJ

VOUT

GND

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

CPU_VCORE DECOUPLING NETWORK

470OHM FOR BOOT BANGER

MPC7447 MAXBUS

MPC7447 PULL-UPS

CPU_OVDD DECOUPLING NETWORK

PLCAE SHORT CLOSE TO CENTER OF CPU

MORE 0805 10UF CAPS ON VCORE

POWER SUPPLY PAGE (PG 33)

IN FORMER L3 AREA

PLACE BELOW CPU

NC NC

CPU INTERNAL PLL FILTERING

470OHM FOR BOOT BANGER

TO UXX PIN 5 AND 6

PLACE RXXX AND RXXX CLOSE

VOUT = 0.59*(1+R1/R2)

R87

10K

1/16W

402

R139

1/16W

402

10K

R107

402

1/16W

10K

R59

1/16W

470

402

R97

1/16W

402

10K

R85

1/16W

200

402

NO_BBANG

R160

1/16W

10K

402

R57

1/16W

402

R58

1/16W

402

10K

R129

10K

1/16W

402

C39

10V 402

CERM

20%

0.1uF

C203

CERM

0.1uF

20% 10V

402

C73

10V 402

CERM

20%

0.1uF

C74

20% CERM

402

10V

0.1uF

C194

20%

402

10V CERM

0.1uF

C40

402

CERM

0.1uF

10V

20%

C191

20% CERM

10V 402

0.1uF

C152

CERM

20% 10V

402

0.1uF

C138

0.1uF

10V CERM

20%

402

C113

0.1uF

402

CERM

10V

20%

C104

0.1uF

402

10V CERM

20%

C115

402

20% 10V CERM

0.1uF

C38

20% CERM

402

10V

0.1uF

C224

0.1uF

20% CERM

10V 402

C48

0.1uF

20% CERM

402

10V

C90

0.1uF

20% 10V

402

CERM

C72

10V 402

CERM

20%

0.1uF

C107

CERM

20% 10V

402

0.1uF

R206

1/16W

5% MF

402

470

C114

20% CERM

10V 402

0.1uF

C154

10V CERM 402

20%

0.1uF

C91

10V

20% CERM

402

0.1uF

C168

CERM

0.1uF

20% 10V

402

C223

402

10V CERM

20%

0.1uF

C112

CERM

0.1uF

402

10V

20%

R241

402

1/16W

470

R60

1/16W

402

10K

R61

1/16W

402

470

R148

402

1/16W

10K

R98

402

1/16W

C25

10uF

20%

6.3V CERM 805

C346

6.3V

20% CERM

805

10uF

C342

CERM

20%

6.3V

10uF

805

20%

805

6.3V CERM

10uF

R120

402

1/16W

10K

R109

402

10K

1/16W

R106

402

1/16W

NO STUFF

C340

805

10V

20%

2.2uF

CERM

C12

10V 805

CERM

20%

2.2uF

R73

1/16W

402

10K

R72

402

1/16W

10K

R702

1/16W

1_5V_MAXBUS

603

R693

1_8V_MAXBUS

603

1/16W

+1_5V_SLEEP

+1_8V_SLEEP

R86

402

470

1/16W MF

BBANG

R128

470

402

1/16W

C103

402

10V CERM

20%

0.1uF

C149

402

20% CERM

10V

0.1uF

C151

0.1uF

10V 402

CERM

20%

C202

0.1uF

10V CERM

20%

402

C111

402

10V CERM

20%

0.1uF

C110

10V 402

CERM

20%

0.1uF

C275

0.1uF

10V 402

CERM

20%

C257

10V

20%

402

0.1uF

CERM

C273

0.1uF

402

CERM

20% 10V

C41

0.1uF

20% CERM

402

10V

C272

10V CERM 402

0.1uF

20%

C46

10V CERM 402

20%

0.1uF

R65

10K

1/16W

402

R130

1/16W

402

10K

R79

1/16W

402

10K

R108

5% MF

10K

402

1/16W

C190

402

10V CERM

20%

0.1uF

C150

402

10V CERM

20%

0.1uF

C201

20%

0.1uF

402

10V CERM

C193

402

0.1uF

10V CERM

20%

C153

CERM

0.1uF

402

10V

20%

C344

20% CERM

10uF

6.3V 805

C189

20% CERM

10V 402

0.1uF

C105

402

CERM

20%

0.1uF

10V

C192

10V 402

20%

0.1uF

CERM

C47

0.1UF

20% 10V CERM 402

C188

0.1UF

20% 10V CERM 402

C169

0.1UF

20% 10V CERM 402

C170

0.1UF

20% 10V CERM 402

C155

0.1UF

20% 10V CERM 402

C139

0.1UF

20% 10V CERM 402

C92

0.1UF

20% 10V CERM 402

C106

0.1UF

20% 10V CERM 402

C195

20%

6.3V CERM 805

10UF

C347

10UF

20%

6.3V CERM 805

C258

805

CERM

6.3V

20%

10UF

C345

10UF

20%

6.3V CERM 805

C156

10UF

20%

6.3V CERM 805

C341

CERM

10UF

20%

6.3V 805

C225

6.3V CERM 805

20%

10UF

C343

10UF

20%

6.3V CERM 805

XW31

OMIT

K10

J13

J11

J9J7H12

H10

M12

M10

L13

L11

L9L7K14

K12

F11

A10

E10

B10

P4 G5

G18

E18

L5K2J5H3F2D5C12

V14

V10

V7V4U16

U12

U2C2T9T6R16

R13

P11

P8P2N6

G17

E17

V15

V11

U17

U13

D13

T10

R17

R14

P12

P9P3N7

M13D6M11

M9M7M4

L12

L10

K13

K11

K9K3K7

J12

J10

H13

H11

A11

D10

A12

B7D2

C10

D11

F10

B11

G10

B12

C11

D12

E11

U43

1.XX-1.33GHZ

APOLLO7-1.2V-1.05V

BGA

CRITICAL

3 5

CRITICAL

FAN2558

SOT23-6

C283

603

6.3V

2.2UF

20%

CERM1

C909

402

CERM

6.3V

10%

1UF

R280

1/16W

402

R275

402

1/16W

47K

R276

1/10W

603

R282

63.4K

1% 1/16W MF 402

R283

52.3K

1% 1/16W MF 402

+3V_SLEEP

C137

402

10V

20% CERM

0.1uF

C136

20%

2.2uF

10V CERM 805

051-6598

CPU_AVDD_ADJ

CPU_AVDD_VOUT

VCORE_SHDN_L

CPU_AVDD_VIN CPU_AVDD_PG

CPU_SRWX_L

CPU_PULLUP

CPU_BUS_VSEL

CPU_PLL_CFG<0>

CPU_QREQ_L

CPU_SMI_L

MPIC_CPU_INT_L

CPU_AVDD

CPU_VCORE_SLEEP

CPU_SRESET_L CPU_HRESET_L

CPU_TEA_L

CPU_PULLDOWN

CPU_PULLUP

CPU_L1TSTCLK CPU_L2TSTCLK

JTAG_CPU_TRST_L CPU_LSSD_MODE

CPU_CLKOUT_SPN

CPU_EMODE1_L

CPU_PULLDOWN

SYSCLK_CPU

CPU_TA_L

CPU_QACK_L

CPU_ADDR<7>

CPU_AACK_L

CPU_CI_L

CPU_GBL_L CPU_WT_L

CPU_TSIZ<1> CPU_TSIZ<2>

CPU_TSIZ<0>

CPU_TT<4> CPU_TBST_L

CPU_TT<2> CPU_TT<3>

CPU_TT<1>

CPU_TT<0>

CPU_ADDR<30> CPU_ADDR<31>

CPU_ADDR<29>

CPU_ADDR<28>

CPU_ADDR<27>

CPU_ADDR<26>

CPU_ADDR<25>

CPU_ADDR<23> CPU_ADDR<24>

CPU_ADDR<22>

CPU_ADDR<20>

CPU_ADDR<19>

CPU_ADDR<17>

CPU_ADDR<15>

CPU_ADDR<13> CPU_ADDR<14>

CPU_ADDR<12>

CPU_ADDR<10> CPU_ADDR<11>

CPU_ADDR<8> CPU_ADDR<9>

CPU_ADDR<5> CPU_ADDR<6>

CPU_ADDR<4>

CPU_ADDR<3>

CPU_TS_L

CPU_BG_L

CPU_BR_L

CPU_SHD1_L CPU_HIT_L

CPU_SHD0_L

CPU_ARTRY_L

JTAG_CPU_TCK

JTAG_CPU_TDO_TP

CPU_EMODE0_L

CPU_PMONIN_L

CPU_ADDR<21>

CPU_ADDR<16>

CPU_PULLDOWN

CPU_CHKS_L

CPU_ADDR<0>

CPU_ADDR<2>

CPU_PLL_CFG<2>

CPU_ADDR<18>

CPU_CHKSTP_OUT_L

CPU_MCP_L

CPU_TBEN

JTAG_CPU_TMS

JTAG_CPU_TDI

CPU_DTI<2>

CPU_DTI<1>

CPU_DTI<0>

CPU_EDTI

CPU_DRDY_L

CPU_PLL_CFG<3>

CPU_DBG_L

CPU_PLL_CFG<1>

CPU_PLL_CFG<4>

CPU_ADDR<1>

CPU_VCORE_SLEEP

ADT7460_VCORE_MON

JTAG_CPU_TRST_L

JTAG_CPU_TCK

CPU_L1TSTCLK

MPIC_CPU_INT_L

JTAG_CPU_TDI

JTAG_CPU_TMS

CPU_SMI_L

CPU_HRESET_L

CPU_SRWX_L

CPU_L2TSTCLK

CPU_PULLDOWN

CPU_EDTI

CPU_PULLUP

CPU_PMONIN_L

CPU_CHKSTP_OUT_L

CPU_LSSD_MODE

CPU_SHD0_L

CPU_TBEN

CPU_SHD1_L

CPU_CHKS_L

MAXBUS_SLEEP

CPU_EMODE1_L

CPU_MCP_L

CPU_SRESET_L

MAXBUS_SLEEP

D22

D4 D5 D6 D7 D8 D9 D10 D11 D12 D13 D14 D15 D16 D17 D18 D19 D20 D21

D28

D27

D23 D24 D25 D26

D29

D32

D31

D30

D33 D34 D35 D36 D37 D38 D39 D40 D41 D42 D43 D44

D48

D47

D45 D46

D49

D51

D50

D52 D53 D54 D55

D58

D57

D56

D59

DP6

DP5

DP4

DP3

DP2

DP1

DP0

DP7

D63

D62

D61

D60

(2 OF 3)

VDD

N/C_1

N/C_4

N/C_8

N/C_13

N/C_17

N/C_20

N/C_22 N/C_23

N/C_31

N/C_39

N/C_30

N/C_33

N/C_35 N/C_36

N/C_38

N/C_29

N/C_28

N/C_27

N/C_25

N/C_24

N/C_21

N/C_19

N/C_18

N/C_16

N/C_15

N/C_14

N/C_12

N/C_11

N/C_10

N/C_9

N/C_7

N/C_6

N/C_5

N/C_3

N/C_2

(3 OF 3)

N/C_26

N/C_32

N/C_34

N/C_37

SENSEVDD

GND

TEMP_CATHODE

TEMP_ANODE

SENSEGND

HPR*

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

SEE PAGE 22

BOOT BANGER - LMU PERORMS THIS FUNCTION IF NEEDED

MPC7447/BBANG

NC NC NC NC

NC NC NC NC NC NC NC NC NC NC NC NC NC NC NC NC NC

NC NC

W13

V13

P14

U15

V17

T17

T18

T16

W18

T15

W17

U18

W19

U19

T19

V19

R18

V18

R19

P17

W16

V16

W10

U10

P10

R10

T11

W11

U11

R11

T14

N10

N11

V12

W12

T12

R12

W14

U14

P13

T13

W15

R15

U43

1.XX-1.33GHZ

APOLLO7-1.2V-1.05V

BGA

P18

P16

N17

N15

M18

M16

M14

H19

H17

H14

G16

G11

F19

F17

F12

E16

E13

C13

B19

B17

A18

A16

A13

N19

N18

G13

N12

G12

N13

B15

A15

G14

F14

E14

D14

L19

K19

J19

L18

K18

J18

L17

K17

J17

L16

C14

K16

J16

H16

D19

C19

D18

C18

D17

C17

D16

B14

C16

L15

K15

J15

H15

G15

F15

E15

D15

C15

A14

P19

P15

N16

N14

M19

M17

M15

L14

J14

H18

G19

F18

F16

F13

E19

E12

B18

B16

B13

A19

A17

U43

1.XX-1.33GHZ

APOLLO7-1.2V-1.05V

BGA

051-6598

CPU_VCORE_SLEEP

CPU_THERM_DM

CPU_DATA<63>

CPU_DATA<0>

CPU_DATA<62>

CPU_DATA<61>

CPU_DATA<60>

CPU_DATA<59>

CPU_DATA<58>

CPU_DATA<57>

CPU_DATA<56>

CPU_DATA<55>

CPU_DATA<54>

CPU_DATA<53>

CPU_DATA<52>

CPU_DATA<51>

CPU_DATA<50>

CPU_DATA<49>

CPU_DATA<48>

CPU_DATA<47>

CPU_DATA<46>

CPU_DATA<45>

CPU_DATA<44>

CPU_DATA<43>

CPU_DATA<42>

CPU_DATA<41>

CPU_DATA<40>

CPU_DATA<39>

CPU_DATA<38>

CPU_DATA<37>

CPU_DATA<36>

CPU_DATA<35>

CPU_DATA<34>

CPU_DATA<33>

CPU_DATA<32>

CPU_DATA<31>

CPU_DATA<30>

CPU_DATA<29>

CPU_DATA<28>

CPU_DATA<27>

CPU_DATA<26>

CPU_DATA<25>

CPU_DATA<24>

CPU_DATA<23>

CPU_DATA<22>

CPU_DATA<21>

CPU_DATA<20>

CPU_DATA<19>

CPU_DATA<18>

CPU_DATA<17>

CPU_DATA<16>

CPU_DATA<15>

CPU_DATA<14>

CPU_DATA<13>

CPU_DATA<12>

CPU_DATA<11>

CPU_DATA<10>

CPU_DATA<9>

CPU_DATA<8>

CPU_DATA<7>

CPU_DATA<6>

CPU_DATA<5>

CPU_DATA<4>

CPU_DATA<3>

CPU_DATA<2>

CPU_DATA<1>

CPU_THERM_DP

39 38 34

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

R01D

TRANSISTOR ON CPU_PLL_CFG<4> IS MET.

PLL DISABLE 1 X

STATE ENCODING CPU_PLL_STOP_OC CPU_VCORE_HI_OC

R01B R00C

1417

1167

1083

1000

9.0X

11.0X

1500

R10B

MAXBUS VSEL

1.5V INTERFACE

BUSTYPE SELECT

APOLLO ONLY SUPPORTS MAXBUS

(PROCESSOR)

CPU_BUS_VSEL

SIGNAL

(PROCESSOR)

CPU_EMODE0_L

CPU_HRESET_L

CPU_HRESET_INV

CPU_HRESET_L

TIED

HIGH

LOW

1.8V INTERFACE

1.5V INTERFACE

2.5V INTERFACE

60X BUS MODE

APPLICATION

MAX BUS MODE

DESKTOP HAD PROBLEM USING

1.8V INTERFACE

933

267 400 533

867

800

733

667

0 1011 0B 0 1001 09

5.0X

5.5X

333 500 667

9.5X

8.0X

7.5X

7.0X

6.5X

6.0X

4.0X

3.0X

2.0X

1.0X

0.0X

APOLLO 7

PULLUP TO ENSURE THAT Vgs OF PASS

R10E R00ER10A R00D

LOW SPEED 0 0

R10D R01E

CPU FREQUENCY CONFIGURATION

(MHZ)

PLL OFF

133MHZ

(Bus-to-Core)

MULTIPLIER

0 1111 0F

CPU_PLL_CFG

(AT BUS FREQUENCY)

CORE FREQUENCY

167MHZ

PLL BYPASS 0 0011 03

0 0100 04 0 1000 08 0 1010 0A

0 1101 0D 0 0101 05 0 0010 02

0 1100 0C

0 0001 01

1000 1067

1 0110 16

32004000

3733466728.0X

24.0X

1 1010 1A

0 0000 00

1 1000 18 1 1001 19

1833

1667 1750

1917

1467

1333 1400

1533

1 1100 1C 1 0001 11 1 1101 1D

1 0101 15 0 1110 0E

1 0000 10 1 0010 12 1 0011 13

1 1011 1B 1 1111 1F

1 0100 14

1667

1600

2667

2400

2267

1800

1733

2133

2000

18672333 2500 2667

2083

2000

3333

3000

2833

2250

2167

3500 2800

16.0X

15.0X

14.0X

10.0X

10.5X

12.0X

11.5X

12.5X

13.0X

13.5X

17.0X

18.0X

20.0X

21.0X

1 0111 17

1200

1133

0 0110 06

1583 1267

0 0111 07

1 1110 1E

CPU CONFIGURATION

4 0123 E ABCD HEX

R10E, R01E, OR PULLUP STUFFED

STUFF PASS TRANSISTOR ONLY IF

HIGH SPEED 0 1

CPU PLL CONFIG CIRCUITRY

R00B R10C

INVERTED HRESET_L

R00A R01C

NEED TO CHARACTERIZE

INVERTER TO INVERT HRESET_L

CPU CONFIGURATION

1250 1333

833 917

8.5X

+5V_SLEEP NOW REQUIRED FOR PLL_STOP_L

R01A

R23

MF 402

5% 1/16W

R16

NO STUFF

402

1/16W

10K

5% MF

402

R10

1/16W

10K

402

R11

10K

1/16W

5% MF

402

R12

402

10K

1/16W

402

1/16W

47K

R48

1/16W 402

10K

5% MF

R33

402

82K

1/16W

R18

5% 1/16W MF 402

R17

NO STUFF

1/16W MF 402

10K

5% 1/16W MF 402

2N7002DW

SOT-363

2N7002DW

SOT-363

SC70-5

SN74AUC1G04

1_5V_MAXBUS

CRITICAL

R27

NO STUFF

402

1/16W

2N7002DW

SOT-363

NO STUFF

2N7002DW

SOT-363

+5V_SLEEP

1 2

1/16W

402

1_5V_MAXBUS

1 2

R149

1/16W

402

1/16W

402

1_8V_MAXBUS

2N7002

2N3904

R47

249K

402

1/16W

R19

NO STUFF

5% 1/16W MF 402

+3V_SLEEP

R20

1/16W

NO STUFF

402

R21

MF 402

NO STUFF

1/16W

R22

1/16W

NO STUFF

402

R24

1/16W

402

NO STUFF

R25

1/16W MF

402

NO STUFF

R26

5% 1/16W MF 402

NO STUFF

R14

402

1/16W

R13

402

NO STUFF

1/16W

R15

NO STUFF

402

1/16W

051-6598

CPU_PLL_CFG<0> CPU_PLL_CFG<1>

CPU_PLL_FS10

CPU_PLL_FS00

MAXBUS_SLEEP

CPU_VCORE_HI_OC

CPU_PLL_FS01

CPU_PLL_CFG<2> CPU_PLL_CFG<3>

CPU_PLL_STOP_BASE

CPU_PLL_CFGEXT CPU_PLL_CFG<4>

CPU_PLL_STOP_OC

PLL_STOP_L

CPU_PLL_STOP_OC

CPU_BUS_VSEL

MAXBUS_SLEEP

CPU_HRESET_INV

CPU_HRESET_L

CPU_HRESET_L CPU_EMODE0_L

PLL_STOP_L

5 5

(PLL6)

VSSA_7

(PLL6)

VDD15A_7

D_42

D_41

D_40

D_39

D_38

D_44

D_43

D_45 D_46 D_47 D_48

D_52

D_51

D_50

D_49

D_53

D_55

D_54

D_56 D_57 D_58

D_60

D_59

D_62

D_61

D_63

DBG

DRDY

DTI_0

TEA

DTI_2

DTI_1

D_1

D_0

D_2

D_6

D_5

D_4

D_3

D_7

D_11

D_10

D_9

D_8

D_12

D_14

D_13

D_15 D_16 D_17

D_22

D_21

D_20

D_19

D_18

D_23 D_24 D_25 D_26 D_27

D_32

D_31

D_30

D_29

D_28

D_34

D_33

D_35 D_36 D_37

(1 OF 9)

MAXBUS

INTERFACE

A_0 A_1 A_2 A_3 A_4 A_5

A_9

A_6 A_7 A_8

A_10

A_14

A_13

A_12

A_11

A_20

A_16 A_17 A_18 A_19

A_15

A_27

A_22

A_21

A_30

A_29

A_28

A_26

A_25

A_24

A_23

TT_2

TT_1

TT_0

A_31

TBST TSIZ_0 TSIZ_1 TSIZ_2

CI GBL

TT_4

AACK

QREQ

ARTRY

TT_3

HIT

ANALYZER_CLK

SUSPENDACK

SUSPENDREQ

QACK

STOPCPUCLK

CPU_FB_OUT

CPU_FB_IN

CPU_CLK

TBEN

ACS_REF

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

PCI1 Source Clock

1: PLL4

BIT 40 TO 47

InternalSpreadEn

BIT 48 TO 55

0: PLL5

0: Inactive

1: Active low

Spare

1: Active

INTREPID BOOT STRAPS

MODE A (2.5X) IS FOR STATIC OPERATION

100: 83.20MHZ

011: 99.84MHZ (1.5X)

010: 133.12MHZ (2.0X)

PCI0 Source Clock

0: PLL5 (NO SPREAD)

BIT1

000: 166.4MHZ (2.5X) 001: 149.76MHZ

1: PLL4

0: PLL5 (NO SPREAD)

NO BUS KEEPER - PU

INPUT

IT CANNOT BE CHANGED BY SOFTWARE

IF A STRAP IS NOT LISTED, THEN

CHANGED BY SOFTWARE:

THE FOLLOWING STRAP BITS CAN BE

6/ D33 - ANALYZERCLK_EN_H - IMMEDIATE EFFECT

5/ D42 - PLL4MODESEL_NXT<2> - SLEEP/WAKE CYCLE REQUIRED

4/ D43 - PLL4MODESEL_NXT<1> - SLEEP/WAKE CYCLE REQUIRED

3/ D44 - PLL4MODESEL_NXT<0> - SLEEP/WAKE CYCLE REQUIRED

2/ D46 - SELPCI1SPREADCLK - SLEEP/WAKE CYCLE REQUIRED

1/ D47 - SELAGPSPREADCLK - SLEEP/WAKE CYCLE REQUIRED

Intrepid MaxBus

NO BUS KEEPER - PU

Spare

BIT 32 TO 39

Spare

ExtPLL_SDwn_Pol

0: Active high

1: Active low

DDR_TPDEn_Pol

0: Inactive

AnalyzerClk_En_h

0: Inactive

Spare

TI 1394b workaround

1: TI PHY workaround

0: Normal 1394b

1: Active

BUF_REF_CLK_OUTEnable_h

INTREPID OUTPUTS HIGH BY DEFAULT

1: Active

SelPLL4ExtSrc

1: External source

PLL4MODESEL_NXT[2:0]

MaxBus output impedance 111: 28.6 ohm 011: 33.3 ohm

110: 66.6 ohm

000: 200 ohm

100: 200 ohm

010: 100 ohm

101: 40 ohm 001: 50 ohm

BIT2 BIT0

BIT0BIT1BIT2

Vin = Intrepid Vcore (1.5V) Vout = MaxBus rail (1.8V)

NO BUS KEEPER

NO BUS KEEPER - PU INPUT - PU

NO BUS KEEPER - PU

INPUT - PD

INPUT - PU

NO BUS KEEPER - ?

NO BUS KEEPER - ? NO BUS KEEPER - ? NO BUS KEEPER - ?

SHORT = 1" SHORTER THAN MATCHED LENGTH

LONG = 1" LONGER THAN MATCHED LENGTH

INTREPID BOOT STRAPS

BIT 56 TO 63

0: Max Bus (G4)

1: 60x bus (G3)

Processor Bus Mode

0: REQ/GNT

1: GPIOs

0: REQ/GNT

1: GPIOs

0: REQ/GNT

1: GPIOs

Spare

PCI1_REQ0_L / PCI1_GNT0_L

PCI1_REQ2_L / PCI1_GNT2_L

PCI1_REQ1_L / PCI1_GNT1_L

FireWire PHY interface

1: B-mode interface

0: Legacy interface

MAXBUS PULL-UPS

FB BUFFER HAS 50 OHM OUTPUT IMPEDANCE

MODE C (2.0X) IS FOR CLOCK SLEW OPERATION

Spare

1: TDI output

0: TDI input (JTAG)

DDR_TPDModeEnable_h

R137

402

1/16W

C308

402

CERM

6.3V

20%

0.22UF

R227

4.7

1/16W

402

R144

402

1/16W

RP24

10K

1/16W

SM1

2 1

R167

402

1/16W

R197

1/16W

402

511

R178

NO STUFF

1/16W

402

10K

R179

10K

402

1/16W

NO STUFF

R651

NO STUFF

10K

402

1/16W

R166

NO STUFF

1/16W

402

10K

R153

10K

402

1/16W

R123

NO STUFF

1/16W

402

10K

R135

NO STUFF

10K

402

1/16W

R674

1/16W

402

10K

R143

10K

402

1/16W

R673

5% MF

402

1/16W

10K

R664

1/16W

402

10K

R657

NO STUFF

10K

402

1/16W

R639

402

10K

1/16W

R643

10K

402

1/16W

R642

10K

402

1/16W

NO STUFF

R136

10K

402

1/16W

R165

402

1/16W

10K

NO_SSCG

R177

NO_SSCG

10K

402

1/16W

5% MF

R152

402

1/16W

NO_SSCG

10K

R184

1/16W

402

NO STUFF

10K

R134

402

1/16W

10K

SSCG

R164

NO STUFF

10K

402

1/16W

R142

10K

402

1/16W

NO STUFF

R122

10K

402

1/16W

NO STUFF

R666

5% MF

402

10K

SSCG

1/16W

R658

10K

1/16W

SSCG

402

R675

SSCG

10K

402

1/16W

R683

5% MF

402

10K

1/16W

R644

402

1/16W

10K

NO_SSCG

R665

1/16W

402

10K

R652

10K

402

1/16W

R640

10K

402

1/16W

R176

10K

402

1/16W

NO STUFF

R141

1/16W

402

10K

NO STUFF

R183

10K

402

1/16W

R162

10K

402

1/16W

NO STUFF

R151

1/16W

402

10K

NO STUFF

R163

10K

402

1/16W

R121

1/16W

402

10K

SSCG

R676

10K

402

1/16W

R684

NO STUFF

1/16W

402

10K

R653

1/16W

402

10K

R667

10K

402

1/16W

R659

1/16W

402

10K

R668

402

1/16W

NO STUFF

10K

R641

NO_SSCG

5% MF

402

10K

1/16W

R133

10K

402

1/16W

SSCG

R645

1/16W

NO_SSCG

10K

402

R182

1/16W

402

10K

NO STUFF

R174

10K

402

1/16W

R150

1/16W

402

10K

NO STUFF

R131

10K

402

1/16W

NO STUFF

R132

1/16W

402

10K

NO STUFF

R175

NO STUFF

10K

402

1/16W

R161

NO STUFF

10K

402

1/16W

R140

1/16W

402

10K

NO STUFF

R685

10K

402

1/16W

R660

10K

402

1/16W

R678

NO STUFF

1/16W

402

10K

R647

1/16W

402

10K

R646

10K

402

1/16W

R677

1/16W

402

10K

R669

10K

402

1/16W

R654

1/16W

402

10K

D28

H25

H26

J25

D27

B28

G25

E25

D26

H24

G24

B27

E28

A28

A31

E27

AK9 AM8

AH9

A32

G27

B31

A29

D11

E12

G20

B20

G19

E19

D19

A20

J19

B19

H19

A19

A18

D18

B18

E18

B17

A17

G18

D17

H18

J18

A16

E17

B16

A15

H17

B15

G17

E16

D16

A13

A14

D15

J16

E15

H11

G16

A12

B14

D14

H15

B13

G15

B12

E14

H14

E11

G14

A11

D13

B11

G13

E13

D12

A10

J13

B10

G12

D10

B30

D29

K25

G28

A30H16

J24

J15

G26

E29 E26

E23

A25

D23

A26

B26

G23

A21

D20

E24

B21

E20

A22

H21

B22

H20

A23

D21

A24

E21

A27

G21

J21

E22

B23

B24

D22

G22

H22

B25

J22

D25

D24

H23

H13

B29

U45

INTREPID-REV2.1

BGA

CRITICAL

R225

402

1/16W

NO STUFF

R215

1/16W

402

R208

402

1/16W

R207

NO STUFF

1/16W

402

R226

402

1/16W

R196

NO STUFF

402

1/16W

RP24

1/16W

10K

SM1

RP23

10K

1/16W

SM1

RP23

SM1

1/16W

10K

RP23

SM1

10K

1/16W

RP21

1/16W

10K

SM1

RP21

SM1

10K

1/16W

RP21

SM1

10K

1/16W

RP21

10K

1/16W

SM1

RP24

1/16W

10K

SM1

RP23

SM1

10K

1/16W

051-6598

448

INT_CPUFB_OUT_SHORT

INT_CPUFB_OUT

SYSCLK_CPU

SYSCLK_CPU_UF

INT_CPUFB_IN

CPU_QREQ_L

MAXBUS_SLEEP

CPU_BG_L

CPU_DBG_L

CPU_TEA_L

CPU_AACK_L

CPU_HIT_L

CPU_DRDY_L

CPU_ARTRY_L

CPU_BR_L

CPU_TS_L

CPU_TA_L

CPU_DATA<56> CPU_DATA<57> CPU_DATA<58>

MAXBUS_SLEEP

CPU_DATA<59> CPU_DATA<60> CPU_DATA<61> CPU_DATA<62> CPU_DATA<63>

INT_CPUFB_LONG

INT_CPUFB_IN_NORM

INT_CPUFB_OUT_NORM

INT_CPUFB_IN

CPU_DATA<32>

CPU_DATA<48> CPU_DATA<49> CPU_DATA<50> CPU_DATA<51>

CPU_DATA<53>

CPU_DATA<40> CPU_DATA<41>

CPU_DATA<55>

CPU_DATA<33> CPU_DATA<34> CPU_DATA<35> CPU_DATA<36> CPU_DATA<37>

CPU_DATA<39>

MAXBUS_SLEEP

+1_5V_INTREPID_PLL

CPU_TEA_L

CPU_TA_L

CPU_DTI<2>

CPU_DTI<1>

CPU_DTI<0>

CPU_DRDY_L

CPU_DBG_L

CPU_DATA<63>

CPU_DATA<61> CPU_DATA<62>

CPU_DATA<60>

CPU_DATA<58> CPU_DATA<59>

CPU_DATA<57>

CPU_DATA<56>

CPU_DATA<55>

CPU_DATA<53> CPU_DATA<54>

CPU_DATA<52>

CPU_DATA<51>

CPU_DATA<48>

CPU_DATA<50>

CPU_DATA<49>

CPU_DATA<47>

CPU_DATA<46>

CPU_DATA<44> CPU_DATA<45>

CPU_DATA<43>

CPU_DATA<41> CPU_DATA<42>

CPU_DATA<40>

CPU_DATA<39>

CPU_DATA<38>

CPU_DATA<37>

CPU_DATA<36>

CPU_DATA<35>

CPU_DATA<34>

CPU_DATA<33>

CPU_DATA<32>

CPU_DATA<30> CPU_DATA<31>

CPU_DATA<29>

CPU_DATA<28>

CPU_DATA<27>

CPU_DATA<25> CPU_DATA<26>

CPU_DATA<24>

CPU_DATA<23>

CPU_DATA<22>

CPU_DATA<20> CPU_DATA<21>

CPU_DATA<19>

CPU_DATA<17> CPU_DATA<18>

CPU_DATA<16>

CPU_DATA<15>

CPU_DATA<14>

CPU_DATA<12> CPU_DATA<13>

CPU_DATA<11>

CPU_DATA<10>

CPU_DATA<7>

CPU_DATA<9>

CPU_DATA<8>

CPU_DATA<6>

CPU_DATA<5>

CPU_DATA<2>

CPU_DATA<4>

CPU_DATA<3>

CPU_DATA<0> CPU_DATA<1>

CPU_BR_L CPU_BG_L

CPU_TS_L

CPU_ADDR<1>

CPU_ADDR<0>

CPU_ADDR<2> CPU_ADDR<3> CPU_ADDR<4> CPU_ADDR<5> CPU_ADDR<6> CPU_ADDR<7> CPU_ADDR<8> CPU_ADDR<9> CPU_ADDR<10>

CPU_ADDR<12>

CPU_ADDR<11>

CPU_ADDR<14>

CPU_ADDR<13>

CPU_ADDR<15> CPU_ADDR<16> CPU_ADDR<17>

CPU_ADDR<19>

CPU_ADDR<18>

CPU_ADDR<20>

CPU_ADDR<22>

CPU_ADDR<21>

CPU_ADDR<24>

CPU_ADDR<23>

CPU_ADDR<25>

CPU_ADDR<28>

CPU_ADDR<30>

CPU_TBST_L CPU_TSIZ<0>

CPU_TSIZ<2>

CPU_TSIZ<1>

CPU_TT<1>

CPU_TT<0>

CPU_TT<2>

CPU_TT<4>

CPU_TT<3>

CPU_WT_L

CPU_AACK_L

CPU_HIT_L

CPU_ARTRY_L

CPU_QREQ_L

CPU_QACK_L INT_SUSPEND_REQ_L INT_SUSPEND_ACK_L

INT_CPUFB_OUT SYSCLK_LA_TP

CPU_CLK_EN

CPU_TBEN

INTREPID_ACS_REF

+1_5V_INTREPID_PLL7

CPU_GBL_L

CPU_DATA<44>

CPU_DATA<42>

CPU_DATA<38>

CPU_ADDR<29>

CPU_ADDR<31>

CPU_CI_L

MAXBUS_SLEEP

CPU_DATA<52>

CPU_DATA<54>

MAXBUS_SLEEP

CPU_DATA<46>

CPU_DATA<45>

CPU_DATA<47>

CPU_ADDR<27>

CPU_ADDR<26>

CPU_DATA<43>

A0 A1

A2 A3 A4 A5

A10 A11 A12 A13 A14 A15 A16

A20

A17 A18 A19

CE OE WE WP PWD

GND

DQ0 DQ1

DQ6

DQ5

DQ2 DQ3 DQ4

DQ7

VPP VCC

FEPR-1MX8

(2 OF 9)

DDR_VREF_1

DDR_VREF_0

DDR_DATA_0 DDR_DATA_1 DDR_DATA_2 DDR_DATA_3 DDR_DATA_4 DDR_DATA_5 DDR_DATA_6 DDR_DATA_7 DDR_DATA_8 DDR_DATA_9 DDR_DATA_10 DDR_DATA_11 DDR_DATA_12 DDR_DATA_13 DDR_DATA_14 DDR_DATA_15 DDR_DATA_16 DDR_DATA_17 DDR_DATA_18 DDR_DATA_19 DDR_DATA_20 DDR_DATA_21

DDR_DATA_25 DDR_DATA_26 DDR_DATA_27 DDR_DATA_28 DDR_DATA_29 DDR_DATA_30

DDR_DATA_33 DDR_DATA_34 DDR_DATA_35 DDR_DATA_36 DDR_DATA_37 DDR_DATA_38 DDR_DATA_39 DDR_DATA_40 DDR_DATA_41 DDR_DATA_42 DDR_DATA_43 DDR_DATA_44 DDR_DATA_45 DDR_DATA_46 DDR_DATA_47 DDR_DATA_48 DDR_DATA_49 DDR_DATA_50 DDR_DATA_51 DDR_DATA_52 DDR_DATA_53 DDR_DATA_54 DDR_DATA_55 DDR_DATA_56 DDR_DATA_57 DDR_DATA_58 DDR_DATA_59 DDR_DATA_60 DDR_DATA_61 DDR_DATA_62 DDR_DATA_63

DDR_DATA_22 DDR_DATA_23 DDR_DATA_24

DDR_DATA_31 DDR_DATA_32

DDR_BA_0 DDR_BA_1

DDRCS_3

DDRCS_2

DDRCS_1

DDRCS_0

DDR_DQS_7

DDR_DQS_6

DDR_DQS_5

DDR_DQS_4

DDR_DQS_3

DDR_DQS_2

DDR_DQS_1

DDR_DQS_0

DDR_DM_7

DDR_DM_6

DDR_DM_5

DDR_DM_4

DDR_DM_3

DDR_DM_2

DDR_DM_1

DDR_DM_0

DDRRAS DDRCAS

DDRWE DDRCKE0 DDRCKE1 DDRCKE2 DDRCKE3

DDR_MCLK_0_P DDR_MCLK_0_N DDR_MCLK_1_P DDR_MCLK_1_N DDR_MCLK_2_P DDR_MCLK_2_N DDR_MCLK_3_P DDR_MCLK_3_N DDR_MCLK_4_P DDR_MCLK_4_N DDR_MCLK_5_P DDR_MCLK_5_N

DDR_REF

DDR_SELHI_0 DDR_SELHI_1 DDR_SELLO_0 DDR_SELLO_1

MEMORY

DDR

INTERFACE

DDR_A_10 DDR_A_11 DDR_A_12

DDR_A_9

DDR_A_8

DDR_A_7

DDR_A_6

DDR_A_5

DDR_A_4

DDR_A_3

DDR_A_2

DDR_A_1

DDR_A_0

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

CRITICAL BOM OPTION

TABLE_5_HEAD

PART#

DESCRIPTION

QTY

REFERENCE DESIGNATOR(S)

TABLE_5_ITEM

OVERRIDE ROM MODULE

PULL-DOWN RESISTORS TO ENSURE CKE STAYS LOW AFTER INTREPID

2.5V I/O SHUTS OFF

1MB BOOT ROM

INTERCEPTS ROM CHIP SELECT

MEM_VREF

’2’ & ’3’ GO TO SLOT B

’0’ & ’1’ GO TO SLOT A

’2’ & ’3’ GO TO SLOT B

’0’ & ’1’ GO TO SLOT A

’1’S ARE SAME POLARITY (ACTIVE-HI)

’0’S ARE SAME POLARITY (ACTIVE-LO)

CNTL

ADDR

CKE

PINS ARE SWAPABLE FOR RPAKS

CLOCKS

INT - DDR/BOOTROM

SERIES RESISTORS FOR CLOCK/CONTROL SIGNALS

R387

402

1/16W

10K

R238

402

1/16W

R199

402

1/16W

R198

402

1/16W

10K

C245

402

CERM

10V

20%

0.1UF

R191

1/16W

402

10K

11 3130

3923

U17

OMIT

3.3V

TSOP

C460

10V CERM 805

20%

2.2UF

C470

20% 10V CERM 402

0.1UF

C479

20% 10V CERM 402

0.1UF

R386

402

1/16W

10K

+3V_MAIN

T22

Y22

T32

N30

AE29

AB32

AA22

W35 W36

V33 V32

W32 W33

Y30 W30

Y35 Y36

Y32 Y33

L32

N29

P32

V30

AB30

AD32

AH31

AJ31

L33

N32

T33

T35

AC35

AD33

AH33

AJ33

AG35

AG33

AJ36

K35

K36

J36

K33

AJ35

K32

J35

J33

J32

M30

N33

L36

M33

M35

L35

AJ32

M36

N35

R32

R33

R35

R36

P36

P35

R30

P33

AK36

T36

U35

U36

T30

V35

U32

U33

V36

AB33

AA32

AK35

AC36

AB35

AB36

AA33

AA35

AA36

AD35

AD36

AE33

AE35

AK31

AE36

AF36

AF35

AE32

AG31

AG32

AH32

AH36

AG36

AH35

AK33

AK32

M29

L30

H36

D36

G32

E36

E35

F35

F36

G36

D35

H33

G33

G35

H35

K30

L29

AL33

AL35

AN36

AN34

AL36

AM36

AM35

AN35

H32

U45

INTREPID-REV2.1

CRITICAL

BGA

R338

10K

1/16W

402

R357

1/16W

402

RP33

SM1

1/16W

RP33

1/16W

SM1

RP34

SM1

1/16W

RP34

1/16W

SM1

RP33

1/16W

SM1

RP34

1/16W

SM1

R250

1/16W

402

RP33

1/16W

SM1

RP34

1/16W

SM1

RP36

1/16W

SM1

RP35

1/16W

SM1

RP36

1/16W

SM1

RP36

SM1

1/16W

RP36

SM1

1/16W

RP35

1/16W

SM1

RP35

SM1

1/16W

RP35

SM1

1/16W

RP31

1/16W

SM1

RP25

1/16W

SM1

RP25

1/16W

SM1

RP25

SM1

1/16W

RP25

1/16W

SM1

RP30

SM1

1/16W

RP30

SM1

1/16W

RP31

SM1

1/16W

RP30

SM1

1/16W

RP31

SM1

1/16W

RP31

SM1

1/16W

RP26

SM1

1/16W

RP30

1/16W

SM1

RP26

1/16W

SM1

RP26

1/16W

SM1

RP26

1/16W

SM1

+3V_MAIN

R500

402

1/16W

10K

R439

10K

1/16W

402

R409

402

1/16W

10K

9 44

051-6598

341S1464

BOOTROM,PROTO,Q41A

CRITICAL

U17

RAM_CKE<1>

RAM_CKE<2>

RAM_CKE<3>

+2_5V_INTREPID

MEM_RAS_L RAM_RAS_L

RAM_WE_LMEM_WE_L

MEM_CAS_L RAM_CAS_L

RAM_BA<1>MEM_BA<1>

RAM_BA<0>MEM_BA<0>

RAM_ADDR<11>MEM_ADDR<11>

RAM_ADDR<9>MEM_ADDR<9>

RAM_ADDR<12>MEM_ADDR<12>

RAM_ADDR<10>MEM_ADDR<10>

RAM_ADDR<8>MEM_ADDR<8>

RAM_ADDR<7>MEM_ADDR<7>

RAM_ADDR<5>MEM_ADDR<5>

RAM_ADDR<3>MEM_ADDR<3>

RAM_ADDR<1>MEM_ADDR<1>

RAM_ADDR<6>MEM_ADDR<6>

RAM_ADDR<4>MEM_ADDR<4>

RAM_ADDR<2>MEM_ADDR<2>

RAM_ADDR<0>MEM_ADDR<0>

RAM_CKE<3>MEM_CKE<3>

RAM_CKE<1>MEM_CKE<1>

RAM_CS_L<3>MEM_CS_L<3>

RAM_CKE<2>MEM_CKE<2>

RAM_CKE<0>MEM_CKE<0>

RAM_CS_L<2>MEM_CS_L<2>

RAM_CS_L<1>MEM_CS_L<1>

SYSCLK_DDRCLK_B0_L

SYSCLK_DDRCLK_B0_L_UF

SYSCLK_DDRCLK_B1_L

SYSCLK_DDRCLK_B1_L_UF

SYSCLK_DDRCLK_A0_L

SYSCLK_DDRCLK_A0_L_UF

RAM_CS_L<0>MEM_CS_L<0>

SYSCLK_DDRCLK_B0

SYSCLK_DDRCLK_B0_UF

SYSCLK_DDRCLK_B1

SYSCLK_DDRCLK_B1_UF

SYSCLK_DDRCLK_A1_L

SYSCLK_DDRCLK_A1_L_UF

SYSCLK_DDRCLK_A0

SYSCLK_DDRCLK_A0_UF

SYSCLK_DDRCLK_A1

SYSCLK_DDRCLK_A1_UF

INT_MEM_VREF

MEM_ADDR<12>

MEM_ADDR<11>

MEM_ADDR<10>

MEM_ADDR<9>

MEM_ADDR<8>

MEM_ADDR<7>

MEM_ADDR<6>

MEM_ADDR<5>

MEM_ADDR<4>

MEM_ADDR<3>

MEM_ADDR<2>

MEM_ADDR<1>

MEM_ADDR<0>

MEM_MUXSEL_L<1>

MEM_MUXSEL_H<1>

MEM_MUXSEL_H<0>

MEM_CKE<3>

MEM_CKE<2>

MEM_CKE<1>

MEM_CKE<0>

MEM_WE_L

MEM_CAS_L

MEM_RAS_L

MEM_DQM<7>

MEM_DQM<6>

MEM_DQM<5>

MEM_DQM<4>

MEM_DQM<3>

MEM_DQM<1>

MEM_DQM<0>

MEM_DQM<2>

MEM_DQS<7>

MEM_DQS<6>

MEM_DQS<5>

MEM_DQS<4>

MEM_DQS<3>

MEM_DQS<2>

MEM_DQS<1>

MEM_DQS<0>

MEM_CS_L<2>

MEM_CS_L<1>

MEM_CS_L<0>

MEM_CS_L<3>

MEM_BA<1>

MEM_BA<0>

MEM_DATA<54>

MEM_DATA<31>

MEM_DATA<29>

MEM_DATA<25>

MEM_DATA<24>

MEM_DATA<15>

MEM_DATA<63>

MEM_DATA<62>

MEM_DATA<61>

MEM_DATA<60>

MEM_DATA<59>

MEM_DATA<58>

MEM_DATA<57>

MEM_DATA<56>

MEM_DATA<55>

MEM_DATA<53>

MEM_DATA<52>

MEM_DATA<51>

MEM_DATA<50>

MEM_DATA<49>

MEM_DATA<48>

MEM_DATA<47>

MEM_DATA<46>

MEM_DATA<45>

MEM_DATA<44>

MEM_DATA<43>

MEM_DATA<42>

MEM_DATA<41>

MEM_DATA<40>

MEM_DATA<39>

MEM_DATA<38>

MEM_DATA<37>

MEM_DATA<36>

MEM_DATA<35>

MEM_DATA<34>

MEM_DATA<33>

MEM_DATA<32>

MEM_DATA<30>

MEM_DATA<28>

MEM_DATA<27>

MEM_DATA<26>

MEM_DATA<23>

MEM_DATA<22>

MEM_DATA<21>

MEM_DATA<20>

MEM_DATA<19>

MEM_DATA<18>

MEM_DATA<17>

MEM_DATA<16>

MEM_DATA<14>

MEM_DATA<13>

MEM_DATA<12>

MEM_DATA<11>

MEM_DATA<10>

MEM_DATA<9>

MEM_DATA<8>

MEM_DATA<7>

MEM_DATA<6>

MEM_DATA<5>

MEM_DATA<4>

MEM_DATA<3>

MEM_DATA<2>

MEM_DATA<1>

MEM_DATA<0>

MEM_MUXSEL_L<0>

INT_DDRCLK5_N_TP

SYSCLK_DDRCLK_A1_L_UF

SYSCLK_DDRCLK_A1_UF

SYSCLK_DDRCLK_A0_UF SYSCLK_DDRCLK_A0_L_UF

SYSCLK_DDRCLK_B1_L_UF

SYSCLK_DDRCLK_B1_UF

SYSCLK_DDRCLK_B0_L_UF

SYSCLK_DDRCLK_B0_UF

INT_DDRCLK5_P_TP

INT_DDRCLK2_P_TP INT_DDRCLK2_N_TP

INT_MEM_VREF

INT_MEM_REF_H

PCI_AD<31>

PCI_AD<30>

PCI_AD<29>

PCI_AD<28>

PCI_AD<27>

PCI_AD<26>

PCI_AD<25>

PCI_AD<24>

PCI_AD<9>

PCI_AD<8>

PCI_AD<7>

PCI_AD<6>

PCI_AD<5>

PCI_AD<4>

PCI_AD<3>

PCI_AD<20>

PCI_AD<2>

PCI_AD<19>

PCI_AD<18>

PCI_AD<17>

PCI_AD<16>

PCI_AD<15>

PCI_AD<14>

PCI_AD<13>

PCI_AD<12>

PCI_AD<11>

PCI_AD<10>

PCI_AD<1>

PCI_AD<0>

ROM_OE_L ROM_RW_L

INT_RESET_L

ROM_CS_L

ROM_ONBOARD_CS_L

ROM_WP_L

RAM_CKE<0>

36 36

11 36

36 36

11 36

36 36

9 9

GND

DA10

SEL

DH19

DH18

DH17

DH16

DH15

DH14

DH13

DH12

DH11

DH10

DH9

DH8

DH7

DH6

DH5

DH4

DH3

DH2

DH1

DH0

DA19

DA18

DA17

DA16

DA15

DA14

DA13

DA12

DA11DB0*

DA9

DA8

DA7

DA6

DA5

DA4

DA3

DA2

DA1

DA0

DB19*

DB18*

DB17*

DB16*

DB15*

DB14*

DB13*

DB12*

DB11*

DB10*

DB9*

DB8*

DB7*

DB6*

DB5*

DB4*

DB3*

DB2*

DB1*

VDD

GND

DA10

SEL

DH19

DH18

DH17

DH16

DH15

DH14

DH13

DH12

DH11

DH10

DH9

DH8

DH7

DH6

DH5

DH4

DH3

DH2

DH1

DH0

DA19

DA18

DA17

DA16

DA15

DA14

DA13

DA12

DA11DB0*

DA9

DA8

DA7

DA6

DA5

DA4

DA3

DA2

DA1

DA0

DB19*

DB18*

DB17*

DB16*

DB15*

DB14*

DB13*

DB12*

DB11*

DB10*

DB9*

DB8*

DB7*

DB6*

DB5*

DB4*

DB3*

DB2*

DB1*

VDD

GND

DA10

SEL

DH19

DH18

DH17

DH16

DH15

DH14

DH13

DH12

DH11

DH10

DH9

DH8

DH7

DH6

DH5

DH4

DH3

DH2

DH1

DH0

DA19

DA18

DA17

DA16

DA15

DA14

DA13

DA12

DA11DB0*

DA9

DA8

DA7

DA6

DA5

DA4

DA3

DA2

DA1

DA0

DB19*

DB18*

DB17*

DB16*

DB15*

DB14*

DB13*

DB12*

DB11*

DB10*

DB9*

DB8*

DB7*

DB6*

DB5*

DB4*

DB3*

DB2*

DB1*

VDD

GND

DA10

SEL

DH19

DH18

DH17

DH16

DH15

DH14

DH13

DH12

DH11

DH10

DH9

DH8

DH7

DH6

DH5

DH4

DH3

DH2

DH1

DH0

DA19

DA18

DA17

DA16

DA15

DA14

DA13

DA12

DA11DB0*

DA9

DA8

DA7

DA6

DA5

DA4

DA3

DA2

DA1

DA0

DB19*

DB18*

DB17*

DB16*

DB15*

DB14*

DB13*

DB12*

DB11*

DB10*

DB9*

DB8*

DB7*

DB6*

DB5*

DB4*

DB3*

DB2*

DB1*

VDD

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

MEM_MUXSEL_H<1> AND MEM_MUXSEL_L<1> ARE ACTIVE HIGH

ADDED 0 OHM RESISTORS IN CASE POLARITY IS WRONG

SEL = LOW; HOST = B PORT; A PORT = 100OHM TO GND SEL = HIGH; HOST = A PORT; B PORT = 100OHM TO GND

16BIT 2:1 DDR MUXES

BIT 48..63BIT 32..47

BIT 16..31

BIT 0..15

MEM_MUXSEL_H<0> AND MEM_MUXSEL_L<0> ARE ACTIVE LOW

C742

402

CERM

10V

20%

0.1UF

C748

20% 10V CERM 402

0.1UF

C753

402

CERM

10V

20%

0.1UF

C737

402

CERM

10V

20%

0.1UF

C738

20% 10V CERM 402

0.1UF

C736

402

CERM

10V

20%

0.1UF

C752

402

CERM

10V

20%

0.1UF

C747

20% 10V CERM 402

0.1UF

C741

402

CERM

10V

20%

0.1UF

C743

402

CERM

10V

20%

0.1UF

C727

402

CERM

10V

20%

0.1UF

C735

402

CERM

10V

20%

0.1UF

F8F3E8

H6H5G9G2D9D2C6

B10

D10

F10

H10

K10

A10

C10

E10

G10

J10

U13

CBTV4020

BGA

CRITICAL

F8F3E8

H6H5G9G2D9D2C6

B10

D10

F10

H10

K10

A10

C10

E10

G10

J10

U12

CBTV4020

BGA

CRITICAL

F8F3E8

H6H5G9G2D9D2C6

B10

D10

F10

H10

K10

A10

C10

E10

G10

J10

U10

CRITICAL

BGA

CBTV4020

F8F3E8

H6H5G9G2D9D2C6

B10

D10

F10

H10

K10

A10

C10

E10

G10

J10

CRITICAL

BGA

CBTV4020

R242

NO STUFF

402

1/16W

R252

NO STUFF

1/16W

402

R243

1/16W

402

R239

402

1/16W

051-6598

10 44

+2_5V_INTREPID+2_5V_INTREPID

+2_5V_INTREPID

RAM_DATA_A<57>

MEM_DQM<7>

RAM_DATA_A<56>

RAM_DATA_A<48>

RAM_DATA_A<50> RAM_DATA_A<51>

RAM_DATA_A<49>

RAM_DATA_A<53>

RAM_DATA_A<52>

RAM_DATA_A<54> RAM_DATA_A<55> RAM_DQS_A<6> RAM_DQM_A<6>

RAM_MUXSEL_H

MEM_DATA<63>

MEM_DQS<7>

MEM_DATA<62>

MEM_DATA<60> MEM_DATA<61>

MEM_DATA<57> MEM_DATA<58> MEM_DATA<59>

MEM_DATA<56>

MEM_DQM<6>

MEM_DATA<55>

MEM_DATA<54>

MEM_DQS<6>

MEM_DATA<52> MEM_DATA<53>

MEM_DATA<50>

MEM_DATA<49>

MEM_DATA<51>

RAM_DQM_A<7>

MEM_DATA<48>

RAM_DQS_A<7>

RAM_DATA_A<62> RAM_DATA_A<63>

RAM_DATA_A<60> RAM_DATA_A<61>

RAM_DATA_A<59>

RAM_DATA_A<58>

RAM_DATA_B<59> RAM_DATA_B<60> RAM_DATA_B<61> RAM_DATA_B<62> RAM_DATA_B<63> RAM_DQS_B<7> RAM_DQM_B<7>

RAM_DATA_B<53> RAM_DATA_B<54> RAM_DATA_B<55>

RAM_DATA_B<51> RAM_DATA_B<52>

RAM_DQS_B<6> RAM_DQM_B<6> RAM_DATA_B<56> RAM_DATA_B<57> RAM_DATA_B<58>

RAM_DATA_B<50>

RAM_DATA_B<49>

RAM_DATA_B<48>RAM_DATA_A<41>

MEM_DQM<5>

RAM_DATA_A<40>

RAM_DATA_A<32>

RAM_DATA_A<34> RAM_DATA_A<35>

RAM_DATA_A<33>

RAM_DATA_A<37>

RAM_DATA_A<36>

RAM_DATA_A<38> RAM_DATA_A<39> RAM_DQS_A<4> RAM_DQM_A<4>

RAM_MUXSEL_H

MEM_DATA<47>

MEM_DQS<5>

MEM_DATA<46>

MEM_DATA<44> MEM_DATA<45>

MEM_DATA<41> MEM_DATA<42> MEM_DATA<43>

MEM_DATA<40>

MEM_DQM<4>

MEM_DATA<39>

MEM_DATA<38>

MEM_DQS<4>

MEM_DATA<36> MEM_DATA<37>

MEM_DATA<34>

MEM_DATA<33>

MEM_DATA<35>

RAM_DQM_A<5>

MEM_DATA<32>

RAM_DQS_A<5>

RAM_DATA_A<46> RAM_DATA_A<47>

RAM_DATA_A<44> RAM_DATA_A<45>

RAM_DATA_A<43>

RAM_DATA_A<42>

RAM_DATA_B<43> RAM_DATA_B<44> RAM_DATA_B<45> RAM_DATA_B<46> RAM_DATA_B<47> RAM_DQS_B<5> RAM_DQM_B<5>

RAM_DATA_B<37> RAM_DATA_B<38> RAM_DATA_B<39>

RAM_DATA_B<35> RAM_DATA_B<36>

RAM_DQS_B<4> RAM_DQM_B<4> RAM_DATA_B<40> RAM_DATA_B<41> RAM_DATA_B<42>

RAM_DATA_B<34>

RAM_DATA_B<33>

RAM_DATA_B<32>

RAM_DATA_A<25>

MEM_DQM<3>

RAM_DATA_A<24>

RAM_DATA_A<16>

RAM_DATA_A<18> RAM_DATA_A<19>

RAM_DATA_A<17>

RAM_DATA_A<21>

RAM_DATA_A<20>

RAM_DATA_A<22> RAM_DATA_A<23> RAM_DQS_A<2> RAM_DQM_A<2>

RAM_MUXSEL_L

MEM_DATA<31>

MEM_DQS<3>

MEM_DATA<30>

MEM_DATA<28> MEM_DATA<29>

MEM_DATA<25> MEM_DATA<26> MEM_DATA<27>

MEM_DATA<24>

MEM_DQM<2>

MEM_DATA<23>

MEM_DATA<22>

MEM_DQS<2>

MEM_DATA<20> MEM_DATA<21>

MEM_DATA<18>

MEM_DATA<17>

MEM_DATA<19>

RAM_DQM_A<3>

MEM_DATA<16>

RAM_DQS_A<3>

RAM_DATA_A<30> RAM_DATA_A<31>

RAM_DATA_A<28> RAM_DATA_A<29>

RAM_DATA_A<27>

RAM_DATA_A<26>

RAM_DATA_B<27> RAM_DATA_B<28> RAM_DATA_B<29> RAM_DATA_B<30> RAM_DATA_B<31> RAM_DQS_B<3> RAM_DQM_B<3>

RAM_DATA_B<21> RAM_DATA_B<22> RAM_DATA_B<23>

RAM_DATA_B<19> RAM_DATA_B<20>

RAM_DQS_B<2> RAM_DQM_B<2> RAM_DATA_B<24> RAM_DATA_B<25> RAM_DATA_B<26>

RAM_DATA_B<18>

RAM_DATA_B<17>

RAM_DATA_B<16>

RAM_DATA_A<9>

MEM_DQM<1>

RAM_DATA_A<8>

RAM_DATA_A<0>

RAM_DATA_A<2> RAM_DATA_A<3>

RAM_DATA_A<1>

RAM_DATA_A<5>

RAM_DATA_A<4>

RAM_DATA_A<6> RAM_DATA_A<7> RAM_DQS_A<0> RAM_DQM_A<0>

RAM_MUXSEL_L

MEM_DATA<15>

MEM_DQS<1>

MEM_DATA<14>

MEM_DATA<12> MEM_DATA<13>

MEM_DATA<9> MEM_DATA<10> MEM_DATA<11>

MEM_DATA<8>

MEM_DQM<0>

MEM_DATA<7>

MEM_DATA<6>

MEM_DQS<0>

MEM_DATA<4>

MEM_DATA<5>

MEM_DATA<2>

MEM_DATA<1>

MEM_DATA<3>

RAM_DQM_A<1>

MEM_DATA<0>

RAM_DQS_A<1>

RAM_DATA_A<14> RAM_DATA_A<15>

RAM_DATA_A<12> RAM_DATA_A<13>

RAM_DATA_A<11>

RAM_DATA_A<10>

RAM_DATA_B<11> RAM_DATA_B<12> RAM_DATA_B<13> RAM_DATA_B<14> RAM_DATA_B<15> RAM_DQS_B<1> RAM_DQM_B<1>

RAM_DATA_B<5> RAM_DATA_B<6> RAM_DATA_B<7>

RAM_DATA_B<3> RAM_DATA_B<4>

RAM_DQS_B<0> RAM_DQM_B<0> RAM_DATA_B<8> RAM_DATA_B<9> RAM_DATA_B<10>

RAM_DATA_B<2>

RAM_DATA_B<1>

RAM_DATA_B<0>

RAM_MUXSEL_L

MEM_MUXSEL_L<1>

RAM_MUXSEL_H

MEM_MUXSEL_H<1>

RAM_MUXSEL_L

MEM_MUXSEL_L<0>

RAM_MUXSEL_H

MEM_MUXSEL_H<0>

38 38

16 16

15 15

10 10

36 36

9 9

11 11

DQ58

RFU18

KEY

VDD6 VSS6 VSS8

VDD5

DQ15

DQ13

DQ14

VSS5

DM1

VDD3

VSS3

DQ7

DQ12

DQ6

DM0

DQ4 DQ5

VSS1

VREF1

VDD1

SA1 SA2

RFU19

SA0

VDD32

DQ63

DQ62

VSS32

DQ61

VDD30

DQ60

DQ55

DM7

VSS30

DQ54

DM6

VDD28

DQ53

DQ52

VDD25

CK1*

CK1

VSS28

DQ47

DQ46

VDD23

VSS25

DM5

DQ45

DQ44

DM4

DQ39

VSS23

DQ38

DQ37

RFU17

DQ36

VSS21

VDD21

VDD19

RAS*

BA1

CAS*

S1*

A6 A4 A2 A0

VSS19

A11

VDD17

RFU15

CKE0

VDD15

VSS17

RFU11 VSS16

RFU9

VDD14

RFU3

VSS14

RFU5 RFU7

RFU1

VDD12

VSS12

DM3

DQ31

DQ30

DQ29

VSS10

VDD10

DQ28

DQ23

DM2

DQ20

VDD8

DQ21

DQ22

VDDSPD

SCL

SDA

VDD31

VSS31

DQ59

DQS7

DQ51

VDD29

DQ56

VSS29

DQ57

DQ48

DQS6

VDD27

DQ49

DQ50

DQ43

VSS26

VDD26

VDD24

VSS27

DQ41 DQS5 VSS24

VDD22

DQ42

DQ34 VSS22 DQ35

DQS4

DQ40

VDD20

RFU16

DQ32

VSS20

DQ33

S0*

VDD18

BA0

A10_AP

WE*

A5 A3

VSS18

CKE1 RFU14

RFU13 VDD16

VDD13

VSS15

RFU10

RFU8

RFU12

RFU0

RFU4

VSS13

RFU2

RFU6

VSS11 DQ26 DQ27

DQS3

VDD11

DQ19 DQ24 VDD9

VSS9

DQ25

DQ18

DQ16

VDD7

DQ17

DQS2

DQ11 VDD4

VSS7

CK0*

CK0

DQS1 VSS4 DQ10

VDD2 DQ9

DQ2

DQS0

DQ8

DQ3

VSS2

VDD0

DQ0 DQ1

VSS0

VREF0

A12

DQ58

RFU18

KEY

VREF0

VDD0

DQ0 DQ1

VSS0

DQS0

VSS2

DQ3 DQ8

DQ2

VDD2

VSS4

DQS1

DQ10

DQ9

DQ11

CK0 CK0* VSS7

VDD4

DQ16

DQ18

VDD7

DQ17

DQS2

VSS9

DQ25

VDD9

DQ24

DQ19

DQS3

VDD11

DQ27

DQ26

VSS11

RFU0

VDD13

RFU4

VSS13

RFU2

RFU6

RFU13

RFU12

RFU8

RFU10 VSS15

CKE1

RFU14

VDD16

VSS18

BA0

VDD18

S0*

WE*

A10_AP

DQ33

VSS20

DQ32

VDD20

RFU16

DQS4 DQ34

VSS22

DQ35 DQ40

VDD22

DQ41 DQS5

VSS24

DQ42 DQ43

DQ48

VSS26

VDD26

VDD24

VSS27

VSS29

DQ50

DQ49

DQS6

VDD27

DQS7

DQ51

VDD29

DQ56

DQ57

SDA

VDD31

VSS31

DQ59

VDDSPD

SCL

RFU19

VDD32

VSS28

CK1

DQ52

VDD28 DM6 DQ54 VSS30

DM7

DQ55 DQ60 VDD30 DQ61

DQ53

SA1 SA2

SA0

DQ63

DQ62

VSS32

VSS25

DM5

DQ45

VDD23

VDD21

VSS21 DQ36

RFU17

DQ44

DM4

DQ39

VSS23

DQ38

DQ37

RAS* CAS* S1*

DQ46 DQ47

CK1*

VDD25

RFU7

RFU5

VDD14

VSS17 VDD15

CKE0 RFU15

VDD17

A11 A8

RFU11 VSS16

RFU9

VSS19

BA1

VDD19

VDD12

VSS12

DQ31

DQ30

DM3

DQ22

DQ21 VDD8

DQ20

DQ29

VSS10

VDD10

DQ28

DQ23

DM2

VSS6 VSS8

RFU1

VSS14

RFU3

VREF1

DQ5

DQ4

DM0 DQ6

DQ12

DQ7

VSS3

VSS1

VDD1

VDD3

DM1 VSS5 DQ14

DQ13

DQ15 VDD5 VDD6

A12

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

FOR RETURN CURRENT

DDR BYPASS CAPS

SLOT "B"

SLOT "A"

ADDR=0XA2(WR)/0XA3(RD)

ADDR=0XA0(WR)/0XA1(RD)

CUSTOMER SLOT

SLOT "B"

REVERSED

STANDARD SLOT "A"

FACTORY SLOT

DDR SODIMM CONNS

NC NC

NCNC

DDR VREF

ONE 0.1UF PER SLOT

NC NC

119

4039

2827

186185

174

173

162161

159

150149

138137

126125

104103

8887

7675

6463

197

4645

3433

192191

180

179

168167

157

156155

144143

132131

114113

9493

8281

7069

193 195

198

196

194

122121

8483

8079

7877

7473

200199

124123

9897

8685

7271

118

202

201

183

169

147

133

190

188

182

178

189

187

181

177

176

172

166

164

175

171

165

163

154

152

146

142

153

151

145

141

140

136

130

128

139

135

129

127

184

170

148

134

95 96

158 160

120

116

117

101 102

105 106 107 108 109 110

100

115

111 112

J19

CRITICAL

F-RT-SM

AS0A42-D2S

C602

CERM

6.3V

20%

805

10UF

C601

805

CERM

6.3V

20%

10UF

119

40 39

28 27

186 185

174

173

162 161

159

150 149

138 137

126 125

104 103

88 87

76 75

64 63

4 3

2 1

197

46 45

34 33

192 191

180

179

168 167

157

156 155

144 143

132 131

114 113

94 93

82 81

70 69

193 195

198

196

194

122 121

84 83

80 79

78 77

74 73

200 199

124 123

98 97

86 85

72 71

118

202

201

183

169

147

133

190

188

182

178

189

187

181

177

176

172

166

164

175

171

165

163

154

152

146

142

153

151

145

141

140

136

130

128

139

135

129

127

184

170

148

134

9596

158 160

120

116

117

101102

105106 107108 109110

100

115

111112

J22

AS0A42-D2R

F-RT-SM

CRITICAL

C530

CERM

6.3V

20%

805

10UF

C589

805

CERM

6.3V

20%

10UF

R449

402

1/16W

R440

1% 1/16W MF 402

C542

20% 10V CERM 402

0.1UF

C482

20% 10V CERM 402

0.1UF

+2_5V_MAIN+2_5V_MAIN

+2_5V_MAIN +2_5V_MAIN

+2_5V_MAIN

+3V_MAIN

C573

402

CERM

10V

20%

0.1UF

C526

402

CERM

10V

20%

0.1UF

C525

20% 10V CERM 402

0.1UF

+3V_MAIN

C490

402

CERM

10V

20%

0.1UF

C527

20% 10V CERM 402

0.1UF

C481

402

CERM

10V

20%

0.1UF

C523

20% 10V CERM 402

0.1UF

C549

402

CERM

10V

20%

0.1UF

C524

20% 10V CERM 402

0.1UF

C595

20% 10V CERM 402

0.1UF

C522

20% 10V CERM 402

0.1UF

C597

402

CERM

10V

20%

0.1UF

C489

402

CERM

10V

20%

0.1UF

+3V_MAIN

C594

20% 10V CERM 402

0.1UF

C596

20% 10V CERM 402

0.1UF

C548

402

CERM

10V

20%

0.1UF

C565

20% 10V CERM 402

0.1UF

C550

402

CERM

10V

20%

0.1UF

C551

402

CERM

10V

20%

0.1UF

C761

20% 10V CERM 402

0.1UF

4411

051-6598

RAM_DATA_B<19> RAM_DATA_B<24>

RAM_DATA_B<18>

RAM_DQS_B<2>

RAM_DATA_B<17>

RAM_DATA_B<16>

SYSCLK_DDRCLK_B0_L

SYSCLK_DDRCLK_B0

RAM_DATA_B<11>

RAM_DATA_B<10>

RAM_ADDR<12>

RAM_DATA_B<35>

RAM_DATA_B<34>

RAM_DQS_B<4>

RAM_DATA_B<33>

RAM_DATA_B<32>

RAM_WE_L

RAM_CS_L<2>

RAM_BA<0>

RAM_ADDR<10>

RAM_ADDR<1>

RAM_ADDR<3>

RAM_ADDR<5>

RAM_ADDR<7>

RAM_ADDR<9>

RAM_CKE<3>

RAM_DATA_B<27>

RAM_DATA_B<26>

RAM_DQS_B<3>

RAM_DATA_B<25>

RAM_DQS_B<5>

RAM_DATA_B<41>

RAM_DATA_B<40>

DDR_VREF

RAM_DATA_A<21>

RAM_DATA_A<61>

RAM_DATA_A<62>

RAM_DQM_A<7>

RAM_DATA_A<60>

RAM_DATA_A<55>

RAM_DQM_A<6> RAM_DATA_A<54>

RAM_DATA_A<53>

RAM_DATA_A<52>

SYSCLK_DDRCLK_A1

SYSCLK_DDRCLK_A1_L

RAM_DATA_A<47>

RAM_DATA_A<46>

RAM_DQM_A<5>

RAM_DATA_A<45>

RAM_DATA_A<39> RAM_DATA_A<44>

RAM_DATA_A<38>

RAM_DQM_A<4>

RAM_DATA_A<36> RAM_DATA_A<37>

RAM_CS_L<1>

RAM_RAS_L RAM_CAS_L

RAM_BA<1>

RAM_ADDR<0>

RAM_ADDR<4> RAM_ADDR<2>

RAM_ADDR<6>

RAM_ADDR<8>

RAM_ADDR<11>

RAM_CKE<0>

RAM_DATA_A<30>

RAM_DQM_A<3>

RAM_DATA_A<29>

RAM_DATA_A<28>

RAM_DATA_A<23>

RAM_DATA_A<22>

RAM_DATA_A<20>

RAM_DATA_A<15>

RAM_DATA_A<14>

RAM_DQM_A<1>

RAM_DATA_A<13>

RAM_DATA_A<7>

RAM_DATA_A<12>

RAM_DATA_A<6>

RAM_DQM_A<0>

RAM_DATA_A<5>

RAM_DATA_A<4>

DDR_VREF

INT_I2C_CLK0

INT_I2C_DATA0

RAM_DATA_A<59>

RAM_DATA_A<58>

RAM_DQS_A<7>

RAM_DATA_A<57>

RAM_DATA_A<56>

RAM_DATA_A<51>

RAM_DQS_A<6> RAM_DATA_A<50>

RAM_DATA_A<49>

RAM_DATA_A<48>

RAM_DATA_A<43>

RAM_DQS_A<5>

RAM_DATA_A<42>

RAM_DATA_A<41>

RAM_DATA_A<35> RAM_DATA_A<40>

RAM_DQS_A<4> RAM_DATA_A<34>

RAM_DATA_A<32> RAM_DATA_A<33>

RAM_CS_L<0>

RAM_BA<0> RAM_WE_L

RAM_ADDR<10>

RAM_ADDR<1>

RAM_ADDR<5> RAM_ADDR<3>

RAM_ADDR<7>

RAM_ADDR<9>

RAM_ADDR<12>

RAM_CKE<1>

RAM_DATA_A<27>

RAM_DATA_A<26>

RAM_DQS_A<3>

RAM_DATA_A<24>

RAM_DATA_A<25>

RAM_DATA_A<19>

RAM_DATA_A<18>

RAM_DQS_A<2>

RAM_DATA_A<17>

RAM_DATA_A<16>

SYSCLK_DDRCLK_A0 SYSCLK_DDRCLK_A0_L

RAM_DATA_A<11>

RAM_DQS_A<1>

RAM_DATA_A<10>

RAM_DATA_A<9>

RAM_DATA_A<3> RAM_DATA_A<8>

RAM_DATA_A<2>

RAM_DQS_A<0>

RAM_DATA_A<1>

RAM_DATA_A<0>

DDR_VREF

RAM_DATA_A<63>

RAM_DQM_A<2>

RAM_DATA_A<31>

DDR_VREF

RAM_DATA_B<0> RAM_DATA_B<1>

RAM_DQS_B<0>

RAM_DATA_B<2>

RAM_DATA_B<3> RAM_DATA_B<8>

RAM_DATA_B<9>

RAM_DQS_B<1>

RAM_DATA_B<42> RAM_DATA_B<43>

RAM_DATA_B<48> RAM_DATA_B<49>

RAM_DATA_B<50>

RAM_DQS_B<6>

RAM_DATA_B<56>

RAM_DATA_B<51>

RAM_DQS_B<7>

RAM_DATA_B<57>

RAM_DATA_B<58> RAM_DATA_B<59>

INT_I2C_DATA0

INT_I2C_CLK0

RAM_DATA_B<62>

RAM_DQM_B<7>

RAM_DATA_B<61>

RAM_DATA_B<63>

RAM_DATA_B<60>

RAM_DATA_B<55>

RAM_DQM_B<6> RAM_DATA_B<54>

RAM_DATA_B<53>

RAM_DATA_B<52>

SYSCLK_DDRCLK_B1

SYSCLK_DDRCLK_B1_L

RAM_DATA_B<45> RAM_DQM_B<5>

RAM_DATA_B<44>

RAM_DATA_B<39>

RAM_DATA_B<46> RAM_DATA_B<47>

RAM_DATA_B<38>

RAM_DQM_B<4>

RAM_DATA_B<37>

RAM_DATA_B<36>

RAM_CAS_L

RAM_RAS_L

RAM_CS_L<3>

RAM_ADDR<4>

RAM_ADDR<0>

RAM_ADDR<6>

RAM_ADDR<8>

RAM_ADDR<11>

RAM_ADDR<2>

RAM_BA<1>

RAM_CKE<2>

RAM_DATA_B<31>

RAM_DQM_B<3>

RAM_DATA_B<30>

RAM_DATA_B<29>

RAM_DATA_B<28>

RAM_DATA_B<23>

RAM_DQM_B<2> RAM_DATA_B<22>

RAM_DATA_B<21>

RAM_DATA_B<20>

RAM_DATA_B<15>

RAM_DATA_B<14>

RAM_DATA_B<13> RAM_DQM_B<1>

RAM_DATA_B<12>

RAM_DATA_B<7>

RAM_DATA_B<6>

RAM_DQM_B<0>

RAM_DATA_B<5>

RAM_DATA_B<4>

DDR_VREF

(PLL4)

VDD15A_6

(PLL4) VSSA_6

ROM_WE

ROM_OE

PCI_STOP PCI_DEVSEL

PCI_CBE_3

PCI_CBE_2

PCI_CBE_1

PCI_CBE_0

ROM_CS

PCI_CLK_IN

PCI_CLK_OUT

PCI_CLK2

PCI_CLK1

PCI_CLK0

PCI_FRAME

PCI_PAR

PCI_TRDY PCI_IRDY

PCI_REQ_2

PCI_REQ_1

PCI_REQ_0

PCI_GNT_0 PCI_GNT_1 PCI_GNT_2

PCI/ROM

INTERFACE

PCIAD_31

PCIAD_30

PCIAD_28

PCIAD_27

PCIAD_26

PCIAD_25

PCIAD_29

PCIAD_19

PCIAD_18

PCIAD_17

PCIAD_16

PCIAD_15

PCIAD_23 PCIAD_24

PCIAD_20 PCIAD_21 PCIAD_22

PCIAD_14

(7 OF 9)

PCIAD_11

PCIAD_10

PCIAD_12 PCIAD_13

PCIAD_9

PCIAD_6

PCIAD_5

PCIAD_7 PCIAD_8

PCIAD_4

PCIAD_3

PCIAD_1 PCIAD_2

PCIAD_0

ROM_OVRLY_EN

VSSA_5 (PLL5)

(PLL5)

VDD15A_5

STP_AGP AGPPVT AGPVREF0 AGPVREF1

AGP_BUSY AGP_CLK AGP_FB_IN AGP_FB_OUT

AGPAD0

AGPREQ AGPGNT

AGP_SBA3

AGP_SBA2

AGP_SBA1

AGP_SBA0

AGPCBE_3

AGPFRAME

AGPTRDY AGPIRDY AGPSTOP

AGPDEVSEL

AGPPAR

AGPAD31

AGPAD30

AGPCBE_0 AGPCBE_1 AGPCBE_2

AGP_ST2

AGP_AD_STB0_P AGP_AD_STB0_N AGP_AD_STB1_P AGP_AD_STB1_N

AGPPIPE

AGPRBF

AGP_ST1

AGP_SBA7

AGP_SB_STB_P AGP_SB_STB_N

AGP_ST0

AGP_WBF

AGP

INTERFACES

AGP_SBA6

AGP_SBA5

AGP_SBA4

AGPAD29

AGPAD28

AGPAD27

AGPAD26

AGPAD25

AGPAD24

AGPAD23

AGPAD22

AGPAD21

AGPAD20

AGPAD19

AGPAD18

AGPAD17

AGPAD16

AGPAD15

AGPAD14

AGPAD13

AGPAD12

AGPAD11

AGPAD10

AGPAD9

AGPAD8

AGPAD7

AGPAD6

AGPAD5

AGPAD4

AGPAD3

AGPAD2

AGPAD1

(3 OF 9)

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

PCI FEEDBACK CLOCK MATCHES LONGEST PCI CLOCK ROUTE

VIN = 1.5V (CORE)

VOUT = 3.3V

PCI PULL-UPS

NOTE: Designs using AGP slot should

use 52-ohm a resistor here.

Vout = AGPIO (1.5V)

Vin = Vcore (1.5V)

AGP PULL-UPS/PULL DOWNS

INTREPID AGP/PCI

Need divider for 3.3V slot!

OUTPUT IMPEDANCE IS ABOUT 20OHM

AGP I/O REFERENCE

(PLACE CLOSE TO INTREPID AGP BALLS)

SIMPLY PROVIDING REFERENCE TO CHIP BECAUSE SINGLE AGP PWR PLANE AND CLOSE PROXIMITY OF CHIPS

SERIES RESISTORS FOR BOOTROM CONTROL SIGNALS

PLACE CLOSE TO INTREPID SIDE

AGP_FB_CLK IS ROUTED THE SAME LENGTH AS CLK66M_GPU_AGP

USB2 AND CBUS REQ REMAINS ON +3V_MAIN BECAUSE THESE CHIPS ARE POWERED IN SLEEP

R146

1/16W

4.7

402

R217

402

1/16W

R209

1% 1/16W MF 402

60.4

RP22

SM1

10K

1/16W

RP20

SM1

1/16W

10K

RP19

SM1

1/16W

10K

RP19

SM1

1/16W

10K

R112

402

4.7

1/16W

C83

0.22UF

402

20%

6.3V CERM

J10

J11

AN9

AK17

AR7

AM9

AT15

AR15

AT17

AR16

AR17

AT14

AH16

AN17

AN18

AT16

AN16

AM17

AM18 AJ19

AT18

AH18

AR18

AJ15

AM16

AK16

AR14

AR9

AK13

AH13

AN11

AT8

AN10

AM15

AN15

AJ8

AK14

AT13

AN14

AH15

AK15

AR13

AM11

AT12

AJ11

AR12

AK12

AM13

AN13

AT10

AT11

AK11

AN12

AM12

AR11

AT9

AR10

AR8

AM10

U45

INTREPID-REV2.1

BGA

CRITICAL

R192

402

1/16W

R147

402

1/16W

R171

1/16W

402

R186

5% 1/16W MF 402

+3V_SLEEP

RP18

SM1

1/16W

10K

RP17

SM1

1/16W

10K

RP17

SM1

1/16W

10K

RP17

10K

1/16W

SM1

RP18

SM1

1/16W

10K

RP17

SM1

10K

1/16W

RP18

1/16W

10K

SM1

RP18

1/16W

10K

SM1

R77

402

1/16W

R82

402

1/16W

R103

402

1/16W

R169

402

1/16W

R157

NEC_USB

1/16W

402

+3V_MAIN

R187

10K

1/16W

402

R230

10K

1/16W

402

R193

402

1/16W

10K

R170

10K

1/16W

402

R194

402

1/16W

10K

R216

10K

1/16W

402

R185

4.99K

1/16W

402

R180

4.99K

1/16W

402

C247

0.22UF

6.3V 402

CERM

20%

RP20

10K

1/16W

SM1

RP22

10K

1/16W

SM1

RP20

1/16W

10K

SM1

RP19

SM1

10K

1/16W

RP19

10K

1/16W

SM1

RP20

10K

1/16W

SM1

RP22

10K

1/16W

SM1

RP22

10K

1/16W

SM1

V13

V14

AN19

AK30

AR30

AT30

AN29

AH25 AG25

AN30

AM30

AT31

AR31

AN31

AM31

AR32

AT32

AK25

AK27

AK28

AT19

AK21 AK22

AK20 AK19

AB21

AB20

AR29

AM28

AT33

AK24

AJ24

AJ29

AT29

AT28

AM29

AN28

AM27

AL25

AN24

AT23

AM20

AT22

AM21

AN21

AR21

AN20

AT21

AN27

AR28

AR20

AT27

AR27

AM26

AN26

AM25

AT26

AR26

AL24

AN25

AM24

AT20

AR25

AT25

AR24

AM23

AT24

AR23

AN23

AM22

AN22

AR22

AM19

AR19

U45

INTREPID-REV2.1

BGA

CRITICAL

C160

0.22UF

CERM

6.3V

20%

402

051-6598

12 44

CBUS_PCI_REQ_L

USB2_PCI_REQ_L

AIRPORT_PCI_REQ_L

INT_ROM_RW_L

ROM_RW_L

INT_ROM_OE_L

ROM_OE_L

INT_ROM_CS_L

ROM_CS_L

INT_AGP_VREF

+1_5V_AGP

INT_AGP_FB_OUT

INT_AGP_FB_IN

CLK66M_AGP_15V_TP

AGP_SB_STB_L

AGP_AD_STB_L<1>

AGP_SB_STB

+1_5V_AGP

AGP_AD_STB<0>

AGP_STOP_L

AGP_WBF_L

AGP_IRDY_L

AGP_AD_STB_L<0>

AGP_AD_STB<1>

AGP_PIPE_L

AGP_RBF_L

AGP_TRDY_L

AGP_DEVSEL_L

AGP_REQ_L

AGP_FRAME_L

+3V_GPU

STOP_AGP_L

AGP_GNT_L

AGP_BUSY_L

+1_5V_INTREPID_PLL

AGP_WBF_L

AGP_RBF_L

AGP_PIPE_L

AGP_AD_STB_L<0>

AGP_AD_STB<0>

AGP_AD_STB_L<1>

AGP_AD_STB<1>

AGP_ST<1> AGP_ST<2>

AGP_ST<0>

AGP_SB_STB_L

AGP_SB_STB

AGP_SBA<7>

AGP_SBA<6>

AGP_SBA<5>

AGP_SBA<4>

AGP_SBA<3>

AGP_SBA<2>

AGP_SBA<0>

AGP_DEVSEL_L

AGP_STOP_L

AGP_IRDY_L

AGP_TRDY_L

AGP_FRAME_L

AGP_PAR

AGP_CBE<3>

AGP_CBE<2>

AGP_CBE<1>

AGP_CBE<0>

AGP_AD<7>

AGP_AD<31>

AGP_AD<30>

AGP_AD<29>

AGP_AD<28>

AGP_AD<27>

AGP_AD<26>

AGP_AD<25>

AGP_AD<24>

AGP_AD<23>

AGP_AD<22>

AGP_AD<21>

AGP_AD<20>

AGP_AD<19>

AGP_AD<18>

AGP_AD<17>

AGP_AD<16>

AGP_AD<15>

AGP_AD<14>

AGP_AD<13>

AGP_AD<12>

AGP_AD<11>

AGP_AD<10>

AGP_AD<9>

AGP_AD<8>

AGP_AD<6>

AGP_AD<5>

AGP_AD<4>

AGP_AD<3>

AGP_AD<2>

AGP_AD<1>

AGP_AD<0>

INT_AGP_VREF

AGP_BUSY_L

STOP_AGP_L

AGP_GNT_L

AGP_REQ_L

AGP_SBA<1>

+1_5V_INTREPID_PLL5

INT_AGPPVT

+1_5V_AGP

PCI_FRAME_L

PCI_DEVSEL_L

PCI_IRDY_L

PCI_TRDY_L

PCI_STOP_L

+1_5V_INTREPID_PLL

PCI_AD<0>

PCI_AD<3>

PCI_AD<1> PCI_AD<2>

PCI_AD<4> PCI_AD<5> PCI_AD<6>

PCI_AD<8>

PCI_AD<7>

PCI_AD<10> PCI_AD<11>

PCI_AD<9>

PCI_AD<13>

PCI_AD<12>

PCI_AD<16>

PCI_AD<14> PCI_AD<15>

PCI_AD<18>

PCI_AD<17>

PCI_AD<20> PCI_AD<21>

PCI_AD<19>

PCI_AD<22> PCI_AD<23> PCI_AD<24> PCI_AD<25> PCI_AD<26> PCI_AD<27> PCI_AD<28> PCI_AD<29>

PCI_AD<31>

PCI_AD<30>

+1_5V_INTREPID_PLL6

AIRPORT_PCI_REQ_L CBUS_PCI_REQ_L USB2_PCI_REQ_L

USB2_PCI_GNT_L

AIRPORT_PCI_GNT_L CBUS_PCI_GNT_L

PCI_PAR

PCI_IRDY_L

PCI_FRAME_L PCI_TRDY_L

PCI_STOP_L PCI_DEVSEL_L

PCI_CBE<0> PCI_CBE<1> PCI_CBE<2> PCI_CBE<3>

INT_ROM_OE_L

INT_ROM_CS_L

INT_ROM_RW_L

CLK33M_AIRPORT_UF

CLK33M_AIRPORT

CLK33M_CBUS

INT_PCI_FB_OUT INT_PCI_FB_IN

CLK33M_USB2_UF

CLK33M_USB2

CLK66M_GPU_AGP_UF

CLK66M_GPU_AGP

CLK33M_CBUS_UF

CS_CE2

CS_CE1

CS_IORD CS_IOWR

ATA_CS1

ATA_CS0

IDE

IDEINTRQ

IDECHRDY

IDECS0

IDECS1

IDEDMACK IDEDMARQ

IDERD

IDEWR

IDERST

IDEA9

IDEA8

IDEA7

IDEA6

IDEA5

IDEA4

IDEA3

IDEA2

IDEA1

IDEA0

IDEDD15

IDEDD14

IDEDD13

IDEDD12

IDEDD11

IDEDD10

IDEDD9

IDEDD8

IDEDD7

IDEDD6

IDEDD5

IDEDD4

IDEDD3

IDEDD2

IDEDD1

IDEDD0

CARDSLOT

CS_WAIT

CS_OE CS_WE

ATA_INTRQ

ATA_DMARQ

ATA_CHRDY

ATA_DMACK

ATA_RD

ATA_WR

ATA_RST

ATA_VREF

UATA100

ATA_A1 ATA_A2

ATA_A0

ATA_D12

ATA_D11

ATA_D15

ATA_D14

ATA_D13

ATA_D10

ATA_D9

ATA_D3

ATA_D2

ATA_D1

ATA_D0

ATA_D4

ATA_D8

ATA_D7

ATA_D6

ATA_D5

(5 OF 9)

IICDATA_1

IICCLK_1

IICCLK_0 IICDATA_0

TST_PLLEN

TST_MONOUT

TST_MONIN

TEI

TRSTN

TMS

TCK

TDO

TDI

TEST

MDC

GBE_REFCLK

MDIO

COL

CRS

GTX_CLK

RXD_6

RXD_4 RXD_5

RXD_3

RXD_7

RXD_2

RXD_1

RX_ER

RX_DV

RX_CLK

RXD_0

FW_PINT

FW_LINKON

FWR_LCLK

TX_ER

TX_EN

TX_CLK

TXD_0

RESET

PURESET

PHY_LPS PHY_CTL0 PHY_CTL1 PHY_LREQ FWR_PCLK

(4 OF 9)

MISC

TXD_3

TXD_2

TXD_1

TXD_4 TXD_5 TXD_6 TXD_7

GB ETHERNET

FIREWIRE

PHY_DATA0 PHY_DATA1 PHY_DATA2 PHY_DATA3

PHY_DATA5

PHY_DATA7

PHY_DATA4

PHY_DATA6

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

CS_WAIT IS AN INPUT

PMU

U3 - PG 24

J12 - PG 24

CLOCK SLEW SSCG

U56 - PG 15

ADDR LSB INDICATES READ (’1’) OR WRITE (’0’) MODES

AC-WR AD-RD

58-WR

ATPG NORMAL

0(I)

J9 - PG 25

U36 - PG 23

U37 - PG 23

J23 - PG 12

J20 - PG 12

TEST PULL-UPS/DOWNS

I2C PULL-UPS

ENET_TXD SERIES TERMINATION

INT - ENET/FW/UATA

EIDE/I2C

NOT USING CARDSLOT INTERFACE

UDMA - DEVICEDMARDY/DSTROBE

UDMA - HOSTDMARDY/HSTROBE

UDMA - STOP

FUNCTIONAL TEST WITH

FUNCTIONAL TEST IDDQ

FUNCTIONAL TEST WITHOUT

VIEW PLLS (HARDWARE)

TEST TRI-STATE

NORMAL OPERATION VIEW PLLS (SOFTWARE)

DESCRIPTION

JTAG MODE

ANALYZER_CLK

BYPASS

SYNC/MEM DATA

(OUTPUT)

PLL OUTPUTS

SELECTED

PLL OUTPUTS

POSTSCALAR BYPASS

ATPG IDDQ

X(I)

MEMWE

TST_PLLEN_H

JTG_TDI_H

(I/O)

1(I)

0(I)

TPDENABLE

DDR_

(OUTPUT)

0(I)

(INPUT)

(OUTPUT)

TESTSEL5

JTG_TDO_H

(OUTPUT)

SHUTDOWN

HWPLL_

(I/O)

TST_TEI_H

X 0 0

EXTPLL

1(I)

0(I)

1(I) 1(I)

0(I)

1(I) 1(I) 1(I)

0(I)

0(I) 1 1 1

JTG_RSTN_L

0 0

N/A

(SLEEP)

N/A N/A N/A N/A

N/A

DASH MODEM

N/A

I2C-2

(SLEEP)

N/A

I2C-1

N/A

(MAIN)

N/A N/A N/A

N/A

SNAPPER SOUND

FAN CONTROLLER

N/A

BOOTBANG E2PROM

N/A

RAM - REVERSED

I2C-0

N/A N/A N/A

RAM - STANDARD

(MAIN)

LMU

BUS

AF-RD

AE-WR

A3-RD

A2-WR

A0-WR

85-RD

84-WR

ADDR

A1-RD

59-RD 6B-RD

6A-WR D0-WR

D1-RD

R629

402

1/16W

RP16

10K

1/16W

SM1

R621

10K

402

1/16W

R52

402

1/16W

10K

RP15

1/16W

SM1

RP14

1/16W

SM1

RP14

1/16W

SM1

RP14

1/16W

SM1

RP14

1/16W

SM1

RP15

1/16W

SM1

RP15

1/16W

SM1

RP15

1/16W

SM1

+3V_MAIN

R117

10K

1/16W

402

+3V_MAIN

R626

402

1/16W

RP12

SM1

1/16W

2.2K

RP12

SM1

1/16W

2.2K

RP12

SM1

1/16W

2.2K

RP12

1/16W

SM1

2.2K

RP16

1/16W

10K

SM1

RP16

SM1

10K

1/16W

RP16

1/16W

10K

SM1

R154

1/16W MF 402

AM2

AJ4

AL2

AA7

AH7

AG8

AE5

AE4

AG2

AD5

AH1

AF2

AG1

AF1

AJ2

AJ1

AG4

AD7

AH2

AF4

AD4

AC5

AM1

AB7

AK4

AG7

AF7

AH5

AK2

AL1

AH4

AG5

AK1

AE7

AF5

AE1 AE2

AC4

AD2

AB5

AB4

AD1

AA1

Y15

AA2

AA8

AC2

AC1

AB2

AA4

AA5

AB1

U45

BGA

CRITICAL

INTREPID-REV2.1

R51

402

1/16W

R92

402

1/16W

E10

G10

H10

AR6

AK10

AM7

AN6

AR5

AH10

AT5

AK8

AP5

J12

B5 B6

AM3

AN1

AK5

AN2

H12

L13

U14 E6 C5

U45

BGA

INTREPID-REV2.1

CRITICAL

R145

1/16W

402

R34

402

1/16W

R624

402

1/16W

R630

402

1/16W

R124

402

1/16W

051-6598

13 44

CSLOT_ADDR3_SPN CSLOT_ADDR4_SPN CSLOT_ADDR5_SPN CSLOT_ADDR6_SPN CSLOT_ADDR7_SPN CSLOT_ADDR8_SPN CSLOT_ADDR9_SPN

CSLOT_CE1_L_SPN CSLOT_CE2_L_SPN CSLOT_IORD_L_SPN CSLOT_IOWR_L_SPN CSLOT_OE_L_SPN CSLOT_WE_L_SPN CSLOT_IOWAIT_L_PU

UIDE_INTRQ

HD_INTRQ

UIDE_DMARQ

HD_DMARQ

EIDE_RST_L

EIDE_RD_L

EIDE_WR_L

EIDE_DMARQ

EIDE_DMACK_L

EIDE_INT

EIDE_CS1_L

EIDE_CS0_L

EIDE_DATA<0> EIDE_DATA<1> EIDE_DATA<2> EIDE_DATA<3>

EIDE_DATA<5>

EIDE_DATA<4>

EIDE_DATA<7>

EIDE_DATA<6>

EIDE_DATA<8>

EIDE_DATA<10>

EIDE_DATA<9>

EIDE_DATA<12>

EIDE_ADDR<2>

EIDE_IOCHRDY

EIDE_ADDR<1>

EIDE_ADDR<0>

EIDE_DATA<14> EIDE_DATA<15>

EIDE_DATA<13>

EIDE_DATA<11>

UIDE_DATA<0> UIDE_DATA<1> UIDE_DATA<2> UIDE_DATA<3> UIDE_DATA<4>

UIDE_DATA<6> UIDE_DATA<7> UIDE_DATA<8> UIDE_DATA<9> UIDE_DATA<10> UIDE_DATA<11> UIDE_DATA<12> UIDE_DATA<13> UIDE_DATA<14> UIDE_DATA<15>

UIDE_DATA<5>

UIDE_ADDR<0> UIDE_ADDR<1> UIDE_ADDR<2>

UIDE_RST_L UIDE_DIOW_L UIDE_DIOR_L

UIDE_DMACK_L

UIDE_IOCHRDY UIDE_CS0_L UIDE_CS1_L

UIDE_REF

FW_PHY_LREQ

CLKFW_PHY_LCLK

ENET_PHY_TX_EN

ENET_PHY_TX_ER

CLKFW_LINK_PCLK

FW_LINK_LREQ

FW_LINK_CNTL<0> FW_LINK_CNTL<1>

FW_PHY_LPS

FW_LINK_DATA<7>

FW_LINK_DATA<6>

FW_LINK_DATA<5>

FW_LINK_DATA<4>

FW_LINK_DATA<2>

FW_LINK_DATA<0>

FW_LINK_DATA<3>

FW_LINK_DATA<1>

ENET_LINK_TXD<7>

ENET_LINK_TXD<5> ENET_LINK_TXD<6>

ENET_LINK_TXD<4>

ENET_LINK_TXD<3>

ENET_LINK_TXD<2>

ENET_LINK_TXD<0> ENET_LINK_TXD<1>

ENET_LINK_TX_EN

CLKENET_LINK_TX

ENET_LINK_TX_ER

FW_LKON FW_PINT

CLKFW_LINK_LCLK

CLKENET_LINK_RX ENET_RX_DV ENET_RX_ER

ENET_LINK_RXD<0> ENET_LINK_RXD<1>

ENET_LINK_RXD<3>

ENET_LINK_RXD<2>

ENET_LINK_RXD<4> ENET_LINK_RXD<5> ENET_LINK_RXD<6> ENET_LINK_RXD<7> CLKENET_LINK_GBE_REF

ENET_CRS ENET_COL ENET_MDIO ENET_MDC

INT_TST_MONIN_PD

INT_TST_PLLEN_PD

INT_TST_MONOUT_TP

INT_I2C_CLK0 INT_I2C_DATA0

INT_I2C_DATA1

INT_I2C_CLK1

INT_JTAG_TEI

JTAG_ASIC_TRST_L

JTAG_ASIC_TMS

JTAG_ASIC_TCK

JTAG_ASIC_TDO

JTAG_ENET_TDO

INT_RESET_L

INT_PU_RESET_L

CLKENET_LINK_GTX

CLKENET_PHY_GTX

ENET_PHY_TXD<1>

ENET_LINK_TXD<1>

ENET_PHY_TXD<0>

ENET_LINK_TXD<0>

ENET_PHY_TXD<3>

ENET_LINK_TXD<3>

ENET_PHY_TXD<4>

ENET_LINK_TXD<4>

ENET_PHY_TXD<2>

ENET_LINK_TXD<2>

ENET_PHY_TXD<5>

ENET_LINK_TXD<5>

ENET_PHY_TXD<7>

ENET_LINK_TXD<7>

ENET_PHY_TXD<6>

ENET_LINK_TXD<6>

INT_I2C_DATA0

INT_I2C_CLK0

INT_I2C_DATA1

INT_I2C_CLK1

INT_JTAG_TEI

JTAG_ASIC_TRST_L

INT_TST_MONIN_PD

INT_TST_PLLEN_PD

JTAG_ASIC_TDO

JTAG_ENET_TDO

JTAG_ASIC_TMS

JTAG_ASIC_TCK

37 37

27 13

(PLL9)

(PLL7)

(PLL3)

(PLL2)

(PLL1)

VSSA_8

VSSA4

VSSA3

VSSA2

VSSA1

(PLL9)

(PLL7)

(PLL3)

(PLL2)

(PLL1)

VDD15A_8

VDD15A_4

VDD15A_3

VDD15A_2

VDD15A_1

CPU_INT PCIPME

EXTINT12 EXTINT13 EXTINT14 EXTINT15 EXTINT16 EXTINT17

GPIO16

GPIO15

GPIO12

GPIO11

GPIO9

GPIO6

GPIO5

GPIO4

GPIO3

GPIO2

GPIO1

GPIO0

VSSU_2

VDDU33_2

VDDU33_1

(6 OF 9)

SCCRTSA

SCCTXDA

SCCDTRA

SCCRXDA SCCGPIOA SCCTRXCA

SCCTXDB

SCCGPIOB SCCTRXCB

SCCRXDB

SCCRTSB

PURPOSE

GENERAL

I/O’S

EXTINT8

EXTINT7

EXTINT6

EXTINT0

INTERRUPTS

EXTINT11

EXTINT4 EXTINT5

EXTINT10

EXTINT9

EXTINT3

EXTINT2

EXTINT1

AUD_DTO

AUD_DTI AUD_SYNC

MOD_DTO

AUD_BITCLK AUD_CLKOUT

IICCLK_2

MOD_SYNC

MOD_DTI

MOD_CLKOUT

IICDATA_2

MOD_BITCLK

IIC

AUDIO/I2S

CLOCKS

XTAL_OUT

PROCSLEEPREQ PENDPROCINT

XTAL_IN

SS_REF_CLK_IN

BUF_REF_CLK_OUT

STOPXTAL

WATCHDOG

PCI_

VSSU_1

PCI_

USB_VD0_P USB_VD0_N

USB_VD1_P USB_VD1_N

USB_VD2_N

USB_VD2_P

USB_PWRFLT0

USB_PRTPWR0

USB_VD3_N

USB_VD3_P

USB

USB_PRTPWR1 USB_PWRFLT1

USB_VD4_N

USB_VD4_P

USB_VD5_N

USB_VD5_P

USB_PRTPWR2 USB_PWRFLT2

ADJ

BYP GND

OUT

SHDN

CPU0

VDDA

VDD0

VDD1

VDDC

VDDQ

VSS1

VSS0

VSSA

VSSC

VSSQ

LOCK ODSEL

PD*

SDATA

SCLK

FSEL

CLKIN

RESET*

ADDRSEL

REFERENCE DESIGNATOR(S)

BOM OPTION

TABLE_5_HEAD

QTY

DESCRIPTION

PART#

PART NUMBER

ALTERNATE FOR

PART NUMBER

BOM OPTION

REF DES

COMMENTS:

TABLE_ALT_HEAD

TABLE_ALT_ITEM

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

TABLE_5_ITEM

PORT B - UNUSED

CBUS_IREQ_L

PORT D - UNUSED

PORT C - LEFT USB

PORT F - MODEM

PORT E - BLUETOOTH

PORT A - RIGHT USB 1

INTERNAL 250K PULL-UP

OUTPUT IMPEDANCE ~18-20OHM

PLACE R68 CLOSE TO INTREPID SIDE

OPEN-DRAIN OUTPUT

VCORE_A/B SEL

VGATE/LOCK INTERRUPT

USB PORT ASSIGNMENTS

VIA

SCK

ACK*

MOSI

REQ*

MISO

POWERBOOK SPARE

FAN PWM

INTERNAL 250K PULL-UP

JTG_TDO_H

MOD_DTI_B_H

MOD_CLKOUT_B_H

MOD_BITCLK_B_H

SIGNAL NAME

4 3 2

MOD_SYNC_B_H

MOD_DTO_B_H

HWPLL_

TESTMUXSEL

OTHERWISE A LOT OF OVERSHOOT/UNDERSHOOT

USB POWER FAULT SIGNALS

CONTRAST PWM

BRIGHTNESS PWM

INT - USB/GPIOS/I2S

INTERNAL 250K PULL-DOWN

CRYSTAL LOAD CAPACITANCE IS 16PF

+3V_MAIN

C97

10UF

CERM 805

20%

6.3V

R111

1/16W

402

100K

+3V_MAIN

C85

0.1UF

CERM

20% 10V

402

C84

0.01UF

20% CERM

16V 402

R50

402

1/16W

R67

402

5% MF

1/16W

R91

402

5% MF

1/16W

RP8

1/16W

SM1

RP8

1/16W

SM1

RP8

1/16W

SM1

RP8

SM1

1/16W

R90

402

1/16W

V15

AT7

AH29

AK18

AJ16

AJ13

AA15

AG29

P8 N8

K5 L5

M7 M8

H2 H1

G2 G1

L8 L7

AN7

AR4

AF9

AM5

AT4

AG10

AG11

AL5

AN3

AP4

AG9

AF10

AT6

AN8

AJ18

AJ17

AJ12

AA16

AJ7

R2 T4

AH8

AL4

C32

D31

G30

E31

A33

B33

D34

C33

E30

B32

E34

F33

D30

U15

R4 R7

U45

INTREPID-REV2.1

BGA

CRITICAL

+3V_SLEEP

R614

INTREPID_USB

402

1/16W

R115

402

1/16W MF

15K

R609

INTREPID_USB

1/16W

402

R89

1/16W

402

INTREPID_USB

R80

402

1/16W

INTREPID_USB

C198

0.22UF

CERM

6.3V

20%

402

R155

402

4.7

1/16W

C148

0.22UF

CERM

6.3V

20%

402

R125

1/16W

4.7

402

C182

0.22UF

CERM

6.3V

20%

402

R156

4.7

1/16W

402

C353

0.22UF

CERM

6.3V

20%

402

R114

402

1/16W

15K

C200

0.22UF

CERM

6.3V

20%

402

R244

1/16W

402

4.7

R168

1/16W

4.7

402

18.432M

CRITICAL

8X4.5MM-SM

2 1

R622

1/16W

10M

402

NO STUFF

C140

22PF

402

CERM

5% 50V

C15

402

CERM

50V

22PF

R49

1/16W

NO STUFF

402

5% MF

U.FL-R_SMT

F-ST-SM

NO STUFF

CRITICAL

R28

402

NO STUFF

1/16W MF

R632

402

1/16W

C433

1UF

603

CERM

10V

20%

R277

402

68.1K

1/16W

R278

402

15.8K

1/16W

C419

10UF

805

20%

6.3V CERM

R291

603

1/16W

NO STUFF

R264

1/16W

603

+2_5V_MAIN

+1_8V_MAIN

LT1962-ADJ

MSOP

CRITICAL

C424

CERM

0.01UF

402

20% 16V

402

1/16W

10K

R113

402

10K

1/16W

R29

402

5% 1/16W MF

R102

402

5% 1/16W MF

RP48

10K

1/16W

SM1

RP7

10K

1/16W

SM1

RP46

10K

1/16W

SM1

RP46

10K

1/16W

SM1

RP47

1/16W

SM1

10K

RP47

SM1

10K

1/16W

RP7

1/16W

SM1

10K

RP47

SM1

1/16W

10K

RP48

1/16W

SM1

10K

RP6

10K

SM1

1/16W

RP29

SM1

1/16W

10K

RP29

1/16W

SM1

10K

RP51

1/16W

SM1

10K

RP47

SM1

1/16W

10K

RP46

1/16W

10K

SM1

RP51

10K

SM1

1/16W

RP51

10K

1/16W

SM1

RP29

10K

SM1

1/16W

RP1

1/16W

SM1

10K

RP6

10K

SM1

1/16W

RP48

SM1

10K

1/16W

RP6

10K

SM1

1/16W

RP48

10K

SM1

1/16W

RP29

1/16W

10K

SM1

RP24

1/16W

10K

SM1

RP7

1/16W

10K

SM1

RP6

1/16W

10K

SM1

R100

SSCG

1/16W

402

RP46

10K

1/16W

SM1

RP1

10K

1/16W

SM1

RP1

SM1

1/16W

10K

RP1

SM1

1/16W

10K

R636

402

1/16W

SSCG

R638

1/16W

10K

402

C691

0.1UF

SSCG

20% 10V CERM 402

C692

1UF

603

20% 10V CERM

SSCG

C698

CERM

0.1UF

402

10V

20%

SSCG

L22

SSCG

SM-1

400-OHM-EMI

+3V_MAIN

L18

400-OHM-EMI

SM-1

SSCG

C686

0.1UF

SSCG

402

CERM

10V

20%

+2_5V_MAIN

R281

402

SSCG

1/16W

R656

402

10K

5% 1/16W MF

NO STUFF

R682

10K

402

1/16W

NO STUFF

RP51

10K

1/16W

SM1

U42

CRITICAL

TSSOP

SSCG

CY28512D

R634

SSCG

402

1/16W

R625

402

10K

SSCG

1/16W

5% MF

R631

402

1/16W

NO STUFF

+3V_SLEEP

RP56

1/16W

SM1

RP56

1/16W

SM1

RP56

MOD_BITCLK

SM1

1/16W

RP56

SM1

1/16W

R701

NEC_USB

10K

1/16W MF 402

R708

NEC_USB

402

1/16W

10K

R699

NEC_USB

402

1/16W

10K

R707

NEC_USB

10K

1/16W MF 402

R698

1/16W

402

R720

402

1/16W

10K

R285

402

1/16W

NO STUFF

R604

1/16W

402

R608

402

1/16W

INT_GPIO0

FERR-EMI-100-OHM

ALT FOR SIWARD

197S0035197S0004

051-6598

14 44

R100

RES,METAL FILM,10 K OHM,5,1/16W,0402,SM

NO_SSCG

116S1104

CG_FSEL

SYSTEM_CLK_EN

CG_SYSCLK_EN

JTAG_ASIC_TDO

CG_SYSCLK_EN

INT_EXTINT12_PU

CLK18M_INT_XIN

CG_FSEL

CG_ADDRSEL

SND_HW_RESET_L

INT_MOD_DTO_UF

INT_MOD_BITCLK_UF INT_MOD_CLKOUT_UF

SND_SYNC

INT_MOD_SYNC_UF

FW_PHY_PD_INT

CG_RESET_L

COMM_SHUTDOWN

INT_MOD_BITCLK_UF

INT_MOD_DTI_UF

INT_GPIO9_PU

INT_EXTINT10_PU

INT_EXTINT16_PU

INT_EXTINT11_PU

INT_EXTINT13_PU

INT_EXTINT3_PU

INT_MOD_DTO_UF

PMU_INT_NMI

PMU_INT_L

INT_GPIO12_PU

PMU_REQ_L

CBUS_INT_L

INT_MOD_CLKOUT_UF

INT_GPIO15_PU

INT_GPIO1_PU

INT_EXTINT14_PU

USB_OC_CD_L

COMM_RING_DET_L

INT_EXTINT8_PU

USB2_PCI_INT_L

USB_PWREN_AB_L

USB_PWREN_CD_L

USB_OC_EF_L

USB_OC_AB_L

USB_PWREN_EF_L

AIRPORT_PCI_INT_L

MAIN_RESET_L

INT_REF_CLK_IN

INT_GPIO1_PU

USB_DBP

INT_EXTINT8_PU

CG_LOCK

+1_5V_INTREPID_PLL

SND_SCLK

INT_SND_SYNC

INT_SND_TO_AUDIO

INT_SND_SCLK

INT_SND_CLKOUT

SND_CLKOUT

MOD_SYNC

MOD_CLKOUT

MOD_DTO

USB_OC_EF_L

INT_MOD_DTI

INT_AUDIO_TO_SND

USB_OC_CD_L

USB_DFM

USB_PWREN_EF_L

USB_DBM

USB_DCP

SND_TO_AUDIO

+1_5V_INTREPID_PLL4

+1_5V_INTREPID_PLL8

CLK18M_INT_XOUT

CLK18M_XTAL_IN

INT_EXTINT12_PU INT_EXTINT13_PU INT_EXTINT14_PU

INT_EXTINT16_PU USB2_PCI_INT_L

SND_HP_SENSE_L

MPIC_CPU_INT_L

PMU_PME_L

INT_ENET_RST_L

INT_GPIO15_PU

SND_AMP_MUTE_L

USB_DFP

USB_DEM

USB_DEP

USB_PWREN_CD_L

USB_DDM

USB_DDP

USB_PWREN_AB_L

USB_DCM

USB_DAP USB_DAM

PMU_TO_INT

PMU_CLK

COMM_RXD

COMM_TRXC

INT_REF_CLK_IN

INT_REF_CLK_OUT

INT_WATCHDOG_L

SYSTEM_CLK_EN

INT_PEND_PROC_INT

INT_PROC_SLEEP_REQ_L

INT_EXTINT11_PU

PMU_INT_NMI

ENET_ENERGY_DET AIRPORT_PCI_INT_L CBUS_INT_L

SND_LIN_SENSE_L

INT_EXTINT3_PU

PMU_INT_L

INT_GPIO9_PU

SND_HW_RESET_L

INT_GPIO12_PU

PMU_REQ_L

PMU_ACK_L

PMU_FROM_INT

COMM_DTR_L

COMM_GPIO_L

COMM_RTS_L

COMM_TXD_L

+1_5V_INTREPID_PLL1

+1_5V_INTREPID_PLL3

+1_5V_INTREPID_PLL2

+3V_INTREPID_USB

LT1962_INT_ADJ

LT1962_INT_BYP

INT_EXTINT10_PU

VCORE_VGATE

CG_CLKOUT

INT_REF_CLK_OUT

INT_I2C_DATA1

LTC1962_INT_VIN

+3V_CG_PLL_MAIN

INT_I2C_DATA2

INT_I2C_CLK2

USB_OC_AB_L

MODEM_USB_DP

MODEM_USB_DM

BT_USB_DP

USB_DEP

BT_USB_DM

USB_DEM

USB_DFP

USB_DFM

USB_DDP

USB_DDM

USB_D1P

USB_D1MUSB_DCM

USB_DBP

USB_D2P

USB_D2M

USB_DCP

USB_DBM

USB_DAM

USB_DAP

AGP_INT_L

COMM_RING_DET_L

COMM_RESET_L

SND_HP_MUTE_L

FW_PHY_PD_INT

FW_PHY_PD

+2_5V_CG_MAIN

INT_I2C_CLK1

CLK18M_INT_EXT

39 30 26

37 37

24 14

26 14

POWER/GROUND

VSS

(8 OF 9)

VDD2.5

VSS

VDD1.8/CPUVIO

GROUND

POWER

(9 OF 9)

VDD1.5

AGP_IO_VDD

VDD3.3

AGP_IO_VSS

VSS

VDD3.3

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

Intrepid Power

M34

M32

M31

M28

M24

M21

M20

M18

M17

M14

L24

J34

J31

J3G7F6

F34

F31F3F28

F25

F22

F19

F16

F13

F10D4D33C7C36

C34

C31

C28

C25

C22

C19

C16

C13

C10

B35

AT34

AT3

AR35

AR2

AP9

AP6

AP36

AP34

AP33

AP30

AP3

AP27

AP24

AP21

AP18

AP15

AP12

AP1

AN4

AN33

U16

U10

T27

T24

T23

T14

T11

R34

R31

R29

R26

R24

R23

R21

R19

R18

R16

R14

P29

P22

P17

P12

N25

N15

AE31

AC28

AC27

AC25

AB34

E33

Y29

Y27

W34

AB31

W31

W25

V29

V25

U28

U25

T34

T31

T29

T28

AB27

T25

R27

R25

P28

P25

N36

N34

N31

N28

K34

AB25

K31

G34

G31

C35

AP35

AK34

AH34

AH30

AF28

AE34

AA29

AA25

F12

C30

C27

C24

C21

C18

P19

P16

N23

N21

N18

C15

M23

M22

M19

M16

M15

F27

F24

F21

F18

F15

C12

U45

BGA

INTREPID-REV2.1

AE21

AE19

AE18

AE16

AE14

AD6

AL9

AL6

AL34

AL31

AL27

AD34

AL21

AL18

AL15

AL12

AK7

AK3

AH27

AH23

AH21

AD31

AH20

AG6

AG34

AG30

Y25

Y24

Y23

Y19

Y16

AG3

Y14

Y12

Y11

W26

W23

W14

W11

V34

V31

AG24

V24

V21

V18

V17

V12

V10

U29

U27

U22

AG23

U19

AG21

AE28

AE22

AD3

AD28

G3F9F7

F30

B34

D32

AR3

AC13

AP7

AP2

W13

W12

U12

T18

AC12

T12

R22

P14

P13

N24

AP16

AB6

AP13

AP10

AN5

AM4

AL7

AL3

AL16

AL13

AL10

AK6

AB3

AH6

AH3

AF25

AE6

AE3

AE17

AE15

AD21

AC14

AA12

AA11

AD13

AC23

AC19

AC17

AB19

AB17

AB15

Y18

Y13

W24

W16

V22

V20

V19

V16

U24

U18

AB13

U17

T13

R20

R17

P21

P20

P18

P15

AD22

AD15

AA24

AA21

AA6

AA34

AA31

AA3

AA27

AA20

A34

AD25

AD23

AD12

AC26

AC22

AC20

AC18

AC16A3AC15

AC11

AB29

AB28

AB24

AB18

AB16

AB14

AB12

AB11

AL19

AJ23

AJ21

AH28

AH22

AH19

AF22

AR34

AE23

AR33

AP31

AP28

AP25

AP22

AP19

AN32

AL30

AL28

AL22

AE20

AD20

U45

BGA

INTREPID-REV2.1

+1_5V_MAIN

+3V_MAIN

+2_5V_MAIN

R287

1/10W

805

R399

5% 1/10W FF 805

NO STUFF

+2_5V_SLEEP

15 44

051-6598

+1_5V_AGP

MAXBUS_SLEEP

+2_5V_INTREPID

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

INTREPID 3.3V DECOUPLING

INTREPID CORE DECOUPLING

INTREPID AGP I/O DECOUPLING

21 Balls 4 X 10UF (0805) 24 X 0.22UF (0402)

INTREPID MAXBUS DECOUPLING

INTREPID DDR DECOUPLING

72 X 0.22UF (0402)

32 X 0.22UF (0402)

44 Balls 51 X 0.22UF (0402)

4 X 10UF (0805)

57 Balls 4 X 10UF (0805)

30 Balls 4 X 10UF (0805) 4 X 10UF (0805)

24 Balls

Intrepid Decoupling

29 X 0.22UF (0402)

C240

402

CERM

6.3V

20%

0.22uF

C239

402

CERM

6.3V

20%

0.22uF

C174

0.22uF

20%

6.3V CERM 402

C206

402

CERM

6.3V

20%

0.22uF

C348

10uF

20%

6.3V CERM

805

C204

805

CERM

6.3V

20%

10uF

C350

0.22uF

20%

6.3V CERM 402

C259

0.22uF

20%

6.3V CERM 402

C312

0.22uF

20%

6.3V CERM 402

C237

0.22uF

20%

6.3V CERM 402

C176

0.22uF

20%

6.3V CERM 402

C238

0.22uF

20%

6.3V CERM 402

C288

0.22uF

20%

6.3V CERM 402

C95

0.22uF

20%

6.3V CERM 402

C313

0.22uF

20%

6.3V CERM 402

C117

0.22uF

20%

6.3V CERM 402

C94

0.22uF

20%

6.3V CERM 402

C241

0.22uF

20%

6.3V CERM 402

C226

402

CERM

6.3V

20%

0.22uF

C175

402

CERM

6.3V

20%

0.22uF

C171

0.22uF

20%

6.3V CERM 402

C173

402

CERM

6.3V

20%

0.22uF

C196

805

CERM

6.3V

20%

10uF

C236

10uF

20%

6.3V CERM

805

C320

0.22uF

20%

6.3V CERM 402

C370

0.22uF

20%

6.3V CERM 402

C392

0.22uF

20%

6.3V CERM 402

C294

402

CERM

6.3V

20%

0.22uF

C322

0.22uF

20%

6.3V CERM 402

C384

402

CERM

6.3V

20%

0.22uF

C390

0.22uF

20%

6.3V CERM 402

C352

0.22uF

20%

6.3V CERM 402

C369

402

CERM

6.3V

20%

0.22uF

C480

0.22uF

20%

6.3V CERM 402

C317

0.22uF

20%

6.3V CERM 402

C291

0.22uF

20%

6.3V CERM 402

C335

402

CERM

6.3V

20%

0.22uF

C403

0.22uF

20%

6.3V CERM 402

C410

402

CERM

6.3V

20%

0.22uF

C310

0.22uF

20%

6.3V CERM 402

C391

402

CERM

6.3V

20%

0.22uF

C295

0.22uF

20%

6.3V CERM 402

C399

402

CERM

6.3V

20%

0.22uF

C292

402

CERM

6.3V

20%

0.22uF

C318

0.22uF

20%

6.3V CERM 402

C407

402

CERM

6.3V

20%

0.22uF

C367

0.22uF

20%

6.3V CERM 402

C321

402

CERM

6.3V

20%

0.22uF

C417

10uF

20%

6.3V CERM

805

C423

805

CERM

6.3V

20%

10uF

C422

805

CERM

6.3V

20%

10uF

C418

10uF

20%

6.3V CERM

805

C389

0.22uF

20%

6.3V CERM 402

C354

0.22uF

20%

6.3V CERM 402

C401

0.22uF

20%

6.3V CERM 402

C387

0.22uF

20%

6.3V CERM 402

C289

0.22uF

20%

6.3V CERM 402

C397

0.22uF

20%

6.3V CERM 402

C386

0.22uF

20%

6.3V CERM 402

C402

0.22uF

20%

6.3V CERM 402

C400

402

CERM

6.3V

20%

0.22uF

C290

402

CERM

6.3V

20%

0.22uF

C404

402

CERM

6.3V

20%

0.22uF

C337

0.22uF

20%

6.3V CERM 402

C298

0.22uF

20%

6.3V CERM 402

C393

0.22uF

20%

6.3V CERM 402

C325

20%

0.22uF

6.3V CERM 402

C267

0.22uF

20%

6.3V CERM 402

C229

0.22uF

20%

6.3V CERM 402

C355

0.22uF

20%

6.3V CERM 402

C217

0.22uF

20%

6.3V CERM 402

C357

0.22uF

20%

6.3V CERM 402

C378

0.22uF

20%

6.3V CERM 402

C250

0.22uF

20%

6.3V CERM 402

C268

0.22uF

20%

6.3V CERM 402

C297

402

CERM

6.3V

20%

0.22uF

C265

0.22uF

20%

6.3V CERM 402

C249

402

CERM

6.3V

20%

0.22uF

C230

402

CERM

6.3V

20%

0.22uF

C266

0.22uF

20%

6.3V CERM 402

C356

402

CERM

6.3V

20%

0.22uF

C228

0.22uF

20%

6.3V CERM 402

C251

402

CERM

6.3V

20%

0.22uF

C231

10uF

20%

6.3V CERM

805

C394

805

CERM

6.3V

20%

10uF

C371

805

CERM

6.3V

20%

10uF

C281

10uF

20%

6.3V CERM

805

C215

402

CERM

6.3V

20%

0.22uF

C142

402

CERM

6.3V

20%

0.22uF

C162

402

CERM

6.3V

20%

0.22uF

C208

402

CERM

6.3V

20%

0.22uF

C161

402

CERM

6.3V

20%

0.22uF

C197

402

CERM

6.3V

20%

0.22uF

C181

402

CERM

6.3V

20%

0.22uF

C159

402

CERM

6.3V

20%

0.22uF

C213

402

CERM

6.3V

20%

0.22uF

C227

402

CERM

6.3V

20%

0.22uF

C242

402

CERM

6.3V

20%

0.22uF

C177

402

CERM

6.3V

20%

0.22uF

C180

402

CERM

6.3V

20%

0.22uF

C179

402

CERM

6.3V

20%

0.22uF

C263

402

CERM

6.3V

20%

0.22uF

C262

402

CERM

6.3V

20%

0.22uF

C243

0.22uF

20%

6.3V CERM 402

C178

402

CERM

6.3V

20%

0.22uF

C211

402

CERM

6.3V

20%

0.22uF

C212

0.22uF

20%

6.3V CERM 402

C246

0.22uF

20%

6.3V CERM 402

C147

0.22uF

20%

6.3V CERM 402

C244

402

CERM

6.3V

20%

0.22uF

C144

402

CERM

6.3V

20%

0.22uF

C101

805

CERM

6.3V

20%

10uF

C315

10uF

20%

6.3V CERM

805

C128

10uF

20%

6.3V CERM

805

C157

805

CERM

6.3V

20%

10uF

C143

402

CERM

6.3V

20%

0.22uF

C31

402

CERM

6.3V

20%

0.22uF

C21

402

CERM

6.3V

20%

0.22uF

C42

402

CERM

6.3V

20%

0.22uF

C53

402

CERM

6.3V

20%

0.22uF

C351

0.22uF

20%

6.3V CERM 402

C199

402

CERM

6.3V

20%

0.22uF

C52

402

CERM

6.3V

20%

0.22uF

C277

0.22uF

20%

6.3V CERM 402

C96

0.22uF

20%

6.3V CERM 402

C76

0.22uF

20%

6.3V CERM 402

C145

0.22uF

20%

6.3V CERM 402

C60

402

CERM

6.3V

20%

0.22uF

C45

0.22uF

20%

6.3V CERM 402

C30

0.22uF

20%

6.3V CERM 402

C109

0.22uF

20%

6.3V CERM 402

C98

0.22uF

20%

6.3V CERM 402

C126

0.22uF

20%

6.3V CERM 402

C261

402

CERM

6.3V

20%

0.22uF

C35

402

CERM

6.3V

20%

0.22uF

C125

0.22uF

20%

6.3V CERM 402

C141

0.22uF

20%

6.3V CERM 402

C32

0.22uF

20%

6.3V CERM 402

C146

0.22uF

20%

6.3V CERM 402

C43

402

CERM

6.3V

20%

0.22uF

C184

0.22uF

20%

6.3V CERM 402

C55

0.22uF

20%

6.3V CERM 402

C120

0.22uF

20%

6.3V CERM 402

C108

402

CERM

6.3V

20%

0.22uF

C23

402

CERM

6.3V

20%

0.22uF

C163

0.22uF

20%

6.3V CERM 402

C59

0.22uF

20%

6.3V CERM 402

C51

0.22uF

20%

6.3V CERM 402

C122

402

CERM

6.3V

20%

0.22uF

C375

0.22uF

20%

6.3V CERM 402

C395

805

CERM

6.3V

20%

10uF

C164

10uF

20%

6.3V CERM

805

C33

402

CERM

6.3V

20%

0.22uF

C16

0.22uF

20%

6.3V CERM 402

C34

402

CERM

6.3V

20%

0.22uF

10uF

20%

6.3V CERM

805

C10

805

CERM

6.3V

20%

10uF

C75

0.22uF

20%

6.3V CERM 402

C44

0.22uF

20%

6.3V CERM 402

C61

0.22uF

20%

6.3V CERM 402

C20

0.22uF

20%

6.3V CERM 402

C22

0.22uF

20%

6.3V CERM 402

C58

0.22uF

20%

6.3V CERM 402

C210

0.22uF

20%

6.3V CERM 402

C248

402

CERM

6.3V

20%

0.22uF

C124

402

CERM

6.3V

20%

0.22uF

C396

0.22uF

20%

6.3V CERM 402

C99

0.22uF

20%

6.3V CERM 402

C17

0.22uF

20%

6.3V CERM 402

C36

0.22uF

20%

6.3V CERM 402

C18

402

CERM

6.3V

20%

0.22uF

C296

402

CERM

6.3V

20%

0.22uF

C183

402

CERM

6.3V

20%

0.22uF

C214

0.22uF

20%

6.3V CERM 402

C280

0.22uF

20%

6.3V CERM 402

C278

0.22uF

20%

6.3V CERM 402

C279

402

CERM

6.3V

20%

0.22uF

C264

0.22uF

20%

6.3V CERM 402

C121

0.22uF

20%

6.3V CERM 402

C123

0.22uF

20%

6.3V CERM 402

C19

0.22uF

20%

6.3V CERM 402

C57

0.22uF

20%

6.3V CERM 402

C26

0.22uF

20%

6.3V CERM 402

C28

402

CERM

6.3V

20%

0.22uF

C50

0.22uF

20%

6.3V CERM 402

C54

0.22uF

20%

6.3V CERM 402

C27

0.22uF

20%

6.3V CERM 402

C56

0.22uF

20%

6.3V CERM 402

C24

0.22uF

20%

6.3V CERM 402

C29

402

CERM

6.3V

20%

0.22uF

C366

0.22uF

20%

6.3V CERM 402

C365

0.22uF

20%

6.3V CERM 402

C376

402

CERM

6.3V

20%

0.22uF

C385

0.22uF

20%

6.3V CERM 402

C405

402

CERM

6.3V

20%

0.22uF

C406

402

CERM

6.3V

20%

0.22uF

C398

402

CERM

6.3V

20%

0.22uF

C309

402

CERM

6.3V

20%

0.22uF

C336

0.22uF

20%

6.3V CERM 402

C319

0.22uF

20%

6.3V CERM 402

C293

402

CERM

6.3V

20%

0.22uF

C388

402

CERM

6.3V

20%

0.22uF

C334

402

CERM

6.3V

20%

0.22uF

C368

402

CERM

6.3V

20%

0.22uF

C316

0.22uF

20%

6.3V CERM 402

C216

402

CERM

6.3V

20%

0.22uF

C377

402

CERM

6.3V

20%

0.22uF

C323

402

CERM

6.3V

20%

0.22uF

C324

0.22uF

20%

6.3V CERM 402

C158

0.22uF

20%

6.3V CERM 402

C286

0.22uF

20%

6.3V CERM 402

C314

0.22uF

20%

6.3V CERM 402

C260

0.22uF

20%

6.3V CERM 402

C349

0.22uF

20%

6.3V CERM 402

C119

402

CERM

6.3V

20%

0.22uF

C287

402

CERM

6.3V

20%

0.22uF

C118

402

CERM

6.3V

20%

0.22uF

C207

402

CERM

6.3V

20%

0.22uF

C172

402

CERM

6.3V

20%

0.22uF

C205

0.22uF

20%

6.3V CERM 402

C209

0.22uF

20%

6.3V CERM 402

C127

0.22uF

20%

6.3V CERM 402

C100

0.22uF

20%

6.3V CERM 402

C185

0.22uF

20%

6.3V CERM 402

+1_5V_MAIN

+3V_MAIN

C49

0.22uF

20%

6.3V CERM 402

16 44

051-6598

+2_5V_INTREPID

+1_5V_AGP

MAXBUS_SLEEP

C/BE3*

C/BE2*

C/BE1*

C/BE0*

VR_EN* VR_PORT

VCCCB

VCCP

GND

VCC

GRST

MFUNC4 MFUNC5 MFUNC6

MFUNC3

MFUNC0

SUSPEND

MFUNC1 MFUNC2

PCLK

SPKROUT

GNT

TRDY

STOP

FRAME

PRST REQ

DEVSEL

PERR

IDSEL

SERR

IRDY

AD31

PAR

AD30

AD29

AD28

AD27

AD20 AD21

AD18 AD19

AD26

AD25

AD24

AD23

AD22

AD17

AD10 AD11

AD9

AD8

AD16

AD15

AD14

AD13

AD12

AD7

AD0

AD2 AD3 AD4 AD5 AD6

AD1

D14/RSVD

D13/CAD6

D12/CAD4

D11/CAD2

D10/CAD31

D15/CAD8

D9/CAD30

D8/CAD28

D7/CAD7

D6/CAD5

D5/CAD3

D4/CAD1

D3/CAD0

D2/RSVD

D1/CAD29

D0/CAD27

A22/CTRDY*

A20/CSTOP*

A23/CFRAME*

A21/CDEVSEL*

A19/CBLOCK*

A15/CIRDY*

A14/CPERR*

A12/CC/BE2*

A8/CC/BE1*

A25/CAD19

A24/CAD17

A18/RSVD

A17/CAD16

A16/CCLK

A13/CPAR

A11/CAD12

A10/CAD9

A9/CAD14

A7/CAD18

A6/CAD20

A5/CAD21

CE2/CAD10*

INPACK/CREQ*

WAIT/CSERR*

A4/CAD22

A3/CAD23

A2/CAD24

A1/CAD25

A0/CAD26

VPPD1

VPPD0

VCCD0* VCCD1*

IORD*/CAD13 IOWR*/CAD15

OE*/CAD11

WE*/CGNT*

CD2*/CCD2*

CD1*/CCD1*

CE1*/CC/BE0*

RDY/IREQ*/CINT*

VS1*/CVS1 VS2*/CVS2

REG*/CC/BE3*

RESET/CRST*

BVD1/CSTSCHG/STSCHG*/RI*

BVD2/SPKR*/CAUDIO

WP/IOIS16*/CCLKRUN*

RI_OUT/PME

CLK_48_RSVD/NC

TPS2211

AVPP

AVCC2

AVCC1

AVCC0

GND

SHTDWN

VCCD0 VCCD1 VPPD0 VPPD1

V_5_2

V_5_1

V_3_2

V_3_1

V_12

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

PC CARD/CARDBUS CONNECTOR

TI REFERENCE SCHEMATIC DID NOT HAVE BULK ON +VCC_CBUS_SW

INTEGRATED PULL-UP

CLAMP FOR PC-CARD CLAMP FOR PCI

NC NC

CARDBUS

TO MINIMIZE INDUCTANCE!

MAKE SURE VCC AND VPP ARE WIDE PLANE/TRACES

0.1UF ARE USED TO INCREASE ESD DISCHARGES OF UP TO 10KV

PCI1510 PULL-UPS

THIS PROPERLY SHUTS DOWN CARDBUS POWER FOR PSUEDO-D3COLD

+3V_MAIN

+5V_MAIN

+3V_MAIN

C467

402

CERM

10V

20%

0.1UF

R757

402

10K

1/16W

R756

1/16W

10K

402

R753

402

10K

1/16W

RP39

25V

1/32W

10K

+3V_MAIN

83 82

80879

78 77

76 75

74 73

72 71

68 67

66 65

64 63

62 61

58 57

56 55

54 53

52 51

50549

48 47

46 45

44 43

42 41

38 37

36 35

34 33

32 31

28 27

26 25

24 23

22 21

18 17

16 15

14 13

12 11

CRITICAL

QT500806-L111

M-ST-SM1

C813

CERM 805

6.3V

20%

10UF

D13

M11

L12

N13

B11

N11

N7M1E1D5

C13

N10

G10

L10

N12

M10

K10

C11

F12

L11

M13

K8H4

F13

A11

H12

J10

J13

K12

K11

H11

J12

K13

J11

M12

H10

G13

H13

L13

F11

E11

A12

B12

D10

B10

A10

C12

D11

E10

A13

E13

F10

B13

C10

D12

E12

G12

G11

U26

CRITICAL

BGA

PCI1510GGU

+2_5V_MAIN

R762

402

1/16W

10K

C783

805

CERM

10V

20%

2.2UF

C776

805

CERM

10V

20%

2.2UF

R766

1/16W

402

R348

1/16W 402

R373

NO STUFF

1/16W

10K

402

C789

6.3V 402

CERM

20%

0.22UF

U19

CRITICAL

SSOI

C791

6.3V 402

20% CERM

0.22UF

C797

6.3V 402

20% CERM

0.22UF

C790

6.3V

20% CERM

402

0.22UF

C796

6.3V 402

20% CERM

0.22UF

C798

6.3V

20% CERM

402

0.22UF

R750

402

1/16W

C795

6.3V

20% CERM

402

0.22UF

C773

402

10V

20%

CERM

0.1UF

R767

1/16W

402

R764

402

1/16W

NO STUFF

051-6598

CBUS_VCCD0_L

+VCC_CBUS_SW

CBUS_MFUNC6_PD

MAIN_RESET_L

TPS2211_SHDN_L_PU

CBUS_PCI_SERR_L

CBUS_SUSPEND_PU

CBUS_PCI_PERR_L

MAIN_RESET_L

CBUS_VCCD1_L

CBUS_VPPD0

CBUS_VPPD1

+VPP_CBUS_SW

PCI_AD<19>

PCI_AD<26>

CBUS_PCI_IDSEL

PCI_AD<27> PCI_AD<28> PCI_AD<29>

PCI_AD<3>

PCI_AD<30> PCI_AD<31>

PCI_AD<4> PCI_AD<5> PCI_AD<6> PCI_AD<7> PCI_AD<8> PCI_AD<9>

PCI_AD<25>

PCI_AD<24>

PCI_AD<23>

PCI_AD<22>

PCI_AD<21>

PCI_AD<20>

PCI_AD<2>

PCI_AD<18>

PCI_AD<17>

PCI_AD<16>

PCI_AD<15>

PCI_AD<14>

PCI_AD<13>

PCI_AD<12>

PCI_AD<11>

PCI_AD<10>

PCI_CBE<0> PCI_CBE<1> PCI_CBE<2> PCI_CBE<3>

PCI_AD<1>

PCI_AD<0>

CLK33M_CBUS

PCI_STOP_L PCI_TRDY_L PCI_DEVSEL_L

CBUS_PCI_REQ_L CBUS_PCI_GNT_L

CBUS_INT_L

CBUS_SUSPEND_PU

CBUS_MFUNC6_PD

CBUS_MFUNC5_PD

CBUS_MFUNC4_PD

CBUS_MFUNC3_PD

CBUS_MFUNC2_PD

CBUS_MFUNC1_PD

PCI_PAR PCI_IRDY_L

PCI_FRAME_L

CBUS_PCI_SERR_L

CBUS_PCI_PERR_L

CBUS_ADDR<16>

CBUS_VS2

CBUS_VS1

CBUS_DATA<15>

CBUS_ADDR<0> CBUS_ADDR<1> CBUS_ADDR<2> CBUS_ADDR<3> CBUS_ADDR<4> CBUS_ADDR<5> CBUS_ADDR<6> CBUS_ADDR<7> CBUS_ADDR<8> CBUS_ADDR<9> CBUS_ADDR<10> CBUS_ADDR<11> CBUS_ADDR<12> CBUS_ADDR<13> CBUS_ADDR<14> CBUS_ADDR<15> CBUS_ADDR_16_UF CBUS_ADDR<17> CBUS_ADDR<18> CBUS_ADDR<19> CBUS_ADDR<20> CBUS_ADDR<21> CBUS_ADDR<22> CBUS_ADDR<23> CBUS_ADDR<24> CBUS_ADDR<25>

CBUS_DATA<0> CBUS_DATA<1> CBUS_DATA<2> CBUS_DATA<3> CBUS_DATA<4> CBUS_DATA<5> CBUS_DATA<6> CBUS_DATA<7> CBUS_DATA<8> CBUS_DATA<9> CBUS_DATA<10> CBUS_DATA<11> CBUS_DATA<12> CBUS_DATA<13> CBUS_DATA<14>

CBUS_WAIT_L

CBUS_INPACK_L

CBUS_CE2_L

CBUS_WP_L

CBUS_BVD2_L

CBUS_REG_L

CBUS_RESET_L

CBUS_READY

CBUS_WE_L

CBUS_CE1_L

CBUS_OE_L

CBUS_IOWR_L

CBUS_IORD_L

CBUS_DET_2_L

CBUS_DET_1_L

CBUS_BVD1_L

CBUS_MFUNC5_PD

CBUS_MFUNC4_PD

CBUS_MFUNC1_PD CBUS_MFUNC2_PD CBUS_MFUNC3_PD

PCI1510_VR_EN_L

CBUS_DATA<3> CBUS_DATA<4> CBUS_DATA<5> CBUS_DATA<6>

CBUS_DATA<7> CBUS_CE1_L CBUS_ADDR<10> CBUS_OE_L

CBUS_ADDR<11> CBUS_ADDR<9>

CBUS_ADDR<13>

CBUS_ADDR<14> CBUS_WE_L CBUS_READY +VCC_CBUS_SW

+VPP_CBUS_SW CBUS_ADDR<16> CBUS_ADDR<15> CBUS_ADDR<12>

CBUS_ADDR<7>

CBUS_ADDR<5> CBUS_ADDR<4>

CBUS_ADDR<3> CBUS_ADDR<2> CBUS_ADDR<1> CBUS_ADDR<0>

CBUS_DATA<0> CBUS_DATA<1> CBUS_DATA<2> CBUS_WP_L

CBUS_ADDR<8>

CBUS_ADDR<25>

CBUS_DET_1_L CBUS_DATA<11> CBUS_DATA<12> CBUS_DATA<13>

CBUS_DATA<14> CBUS_DATA<15> CBUS_CE2_L CBUS_VS1

CBUS_IORD_L CBUS_IOWR_L CBUS_ADDR<17> CBUS_ADDR<18>

CBUS_ADDR<19> CBUS_ADDR<20> CBUS_ADDR<21> +VCC_CBUS_SW

+VPP_CBUS_SW CBUS_ADDR<22> CBUS_ADDR<23> CBUS_ADDR<24>

CBUS_VS2 CBUS_RESET_L CBUS_WAIT_L

CBUS_INPACK_L CBUS_REG_L CBUS_BVD2_L CBUS_BVD1_L

CBUS_DATA<8> CBUS_DATA<9> CBUS_DATA<10> CBUS_DET_2_L

CBUS_PCI_RESET_L

IO_RESET_L

CBUS_ADDR<6>

12 24 26 37 39

GND

OUT

VCC

OSC

XIN/CLKIN

SSCLK

VSS

FRSEL

XOUT

VDD

MVREF

VSS

(1 OF 6)

RAGE_MOBILITY

AGP_BUSYB

AD_STBB1

AD_STBB0

AD_STB0

AGPREF

AD_STB1

AD30

AD31

AD29 AD28 AD27 AD26 AD25 AD24

AD17

AD14

AD15

AD23 AD22

AD19

AD20

AD21

AD16

AD18

AD6 AD5 AD4

AD13

AD11

AD12

AD10 AD9 AD8 AD7

AD3

CBEB1

CBEB2

CBEB3

AD0

AD1

AD2

CBEB0 PCICLK

FRAMEB

PAR

IRDYB TRDYB

RSTB

INTAB

GNTB

REQB

DEVSELB

STOPB

MEMVMODE1

MEMVMODE0

TEST_YCLK TEST_MLCK

D+ D-

VREFG

MEMTEST PLLTEST

WBF

ST0 ST1 ST2

SBA5

SBA6

SBA3

SBA4

SBA7

SBA2

STP_AGPB

RBFB

SB_STB

SBA1 SBA0

SUS_STAT

AGPTEST

AGP8X_DETB

RSTB_MSK

DBI_LO DBI_HI

SB_STBS

RAGE_MOBILITY

(6 OF 6)

VSS

VDDCI

(2 OF 6)

RAGE_MOBILITY

VSS VSS

VSSVSS

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

CRITICAL BOM OPTION

TABLE_5_HEAD

PART#

DESCRIPTION

QTY

REFERENCE DESIGNATOR(S)

TABLE_5_ITEM

(PULL-UP to GPU_MEM_IO)

MAIN_RESET_L IS TOGGLED FOR SLEEP

(PLACE C1002 CLOSE TO AGPREF PIN)

M10 AGP INTERFACE

MEMVMODE1=1.8V

MEMVMODE0=GND

FOR 1.8 VDDR1

MEMVMODE1=GND

MEMVMODE0=1.8V

FOR 2.5 VDDR1

PLACE VERF VOLTAGE DIVIDER CLOSE TO ATI M10 VREF PIN

SPREAD SPECTRUM SUPPORT

S0=1;S1=M => -1.5% DOWN-SPREAD

27M OSC

CLOSE TO ATI PIN AJ29)

(PLACE THE OSCILLATOR AND R189 AND R195

(PLACE R200 CLOSE TO OSC)

R53

402

1/16W

R54

10K

1/16W

402

60-OHM-EMI

C64

16V 402

CERM

20%

0.01uF

C68

0.01uF

16V

20% CERM

402

C67

10uF

805

6.3V

20% CERM

C65

0.01uF

402

20% CERM

16V

C66

0.01uF

20% CERM

402

16V

C69

0.01uF

20% CERM

402

16V

R159

5% MF

402

1/16W

20K

R172

402

1/16W

20K

R118

45.3

1% 1/16W MF 402

R158

5% MF

1/16W

402

R127

402

10K

1/16W

R104

4.7K

ATI_MEMIO_HI

402

1/16W

R70

ATI_MEMIO_HI

402

1/16W

4.7K

R43

1/16W MF 402

R44

1/16W MF

402

R45

402

1/16W

R46

402

1/16W

C11

402

CERM

20% 10V

0.1uF

C37

CERM 805

10uF

6.3V

20%

CRITICAL

27.0000M

SM-1

R188

NO STUFF

1/16W

402

100K

C78

4.7uF

6.3V

20% CERM

805

C77

20% 10V

0.1uF

CERM

402

FERR-EMI-100-OHM

+3V_SLEEP

R173

NO STUFF

402

5% MF

1/16W

FERR-EMI-100-OHM

GPU_SS

+3V_SLEEP

3 4

U47

GPU_SS

CY25811

SOI

CRITICAL

C71

20%

GPU_SS

402

10V CERM

0.1uF

C70

GPU_SS

6.3V

20% CERM

805

10uF

R181

402

5% 1/16W

GPU_SS

R38

402

5% MF

1/16W

NO STUFF

R37

1/16W

402

NO STUFF

R189

1/16W

402

287

R195

1% MF

402

1/16W

162

R119

402

1/16W

R138

47K

5% 1/16W MF 402

R126

47K

402

1/16W

C62

0.1uF

20% 10V

402

CERM

R105

5% MF

402

ATI_MEMIO_LO

4.7K

1/16W

R55

1/16W

ATI_MEMIO_LO

5% MF

402

4.7K

R200

1/16W

402

GPU_SS

R201

1/16W 402

GPU_SS

C63

20% 16V

402

CERM

0.01uF

AE27

A22

B22

A23

B23

AC4

AB2

A10

C11

A15

C16

C26

B29

G27

G29

D19

A18

A19

B18

C19

AK3

T28

E8 J6

AJ28

AG29

T27

AE29

AF28

AF30

AC28 AB29 AC27 AC30 AD27 AD30 AE28 AD29

AD28

AC29

AD24

AH30

AF29

AE30

AC22

AG30

R28

B7 C8

T30

AH29

AF27

U27

T29

Y25 Y27

AC11

AC10

W28 U29 R30 N27

K29

K30

AG28

U25

Y29

W29

M28

N29

N28 N30 M30 M27 M29 L28

AB30 AB27

L30

AA29 AB28 AA30 AA27

Y30

AA28

W30 W27 V30 V28

L27

V29 V27 U30 U28 R27 R29 P28 P30 P27 P29

L29 K28

U44

OMIT

M11-CSP64

64MB

BGA

R19

R18

R17

R16

T16

U16

V16

W16

T14

T13

T12

T15

R15

P15

N15

M15

B19

A21

P25

F18

AE15

U44

OMIT

M11-CSP64

64MB

BGA

G30

B27

A27

D23

C23

D22

C20

D20

C21

D21

C22

A25

B25

A26

B26

AE4

AE3

AD4

AD3

AB4

AB3

AA4

AA3

AD2

AD1

AC2

AC1

AA2

AA1

A11

B11

A12

B12

C10

D10

C12

D12

C13

D13

A13

B13

A14

B14

A16

B16

A17

B17

C14

D14

C15

D15

C17

D17

C18

D18

C24

D24

C25

D25

C27

D27

C28

D28

B28

A28

A29

A30

C29

C30

D29

D30

E27

E28

F27

F28

H27

H28

J27

J28

E29

E30

F29

F30

H29

H30

J29

J30

AC3

AB1

B10

D11

B15

D16

D26

B30

G28

U44

OMIT

M11-CSP64

64MB

BGA

18 44

051-6598

338S0158 M11_CSP128CRITICAL

U44

IC,ATI,M11-CSP128,GRPHCTLR,667BGA

M11_CSP64

CRITICAL

U44

IC,ATI,M11-CSP64,GRPHSCTLR,667BGA

338S0154

+3V_ATI_SS

ATI_CLK27M_IN

ATI_CLK27M_OSC_SS

ATI_SSCLK_UF

CY25811_S0

CY25811_S1

ATI_SSCLK_IN

ATI_CLK27M_OSC_SS

ATI_CLK27M_OSC

ATI_OSC_OE

+1_8V_GPU

+3V_GPU

GPU_VCORE

+1_5V_AGP

MAIN_RESET_L

+3V_GPU

+1_5V_AGP

+3V_GPU

+3V_ATI_OSC_SLEEP

+GPU_MEM

AGP_SB_STB_L

ATI_DBI_LO_PU ATI_DBI_HI_PU

ATI_RSTB_MSK

AGP8X_DET_PU

GPU_AGP_TEST

AGP_SUS_STAT_L_PU

AGP_SB_STB

AGP_STP_L

AGP_RBF_L

AGP_SBA<0>

AGP_SBA<1>

AGP_SBA<2>

AGP_SBA<3>

AGP_SBA<4>

AGP_SBA<5>

AGP_SBA<7> AGP_SBA<6>

AGP_ST<2>

AGP_ST<1>

AGP_ST<0>

AGP_WBF_L

ATI_MEMTEST

AGP_ATI_VREFG AGP_ATI_VREF

GPU_THERM_DM_TP

GPU_THERM_DP_TP

+GPU_MEM

ATI_MEMVMODE1

ATI_MEMVMODE0

AGP_ATI_RESET_L

AGP_INT_L

AGP_REQ_L AGP_GNT_L

AGP_PAR

AGP_STOP_L AGP_DEVSEL_L

AGP_IRDY_L AGP_TRDY_L

AGP_FRAME_L

AGP_CBE<0>

CLK66M_GPU_AGP

AGP_CBE<2> AGP_CBE<1>

AGP_AD<0>

AGP_CBE<3>

AGP_AD<1>

AGP_AD<3> AGP_AD<2>

AGP_AD<4>

AGP_AD<5>

AGP_AD<6>

AGP_AD<7>

AGP_AD<8>

AGP_AD<10> AGP_AD<9>

AGP_AD<11>

AGP_AD<12>

AGP_AD<13>

AGP_AD<15> AGP_AD<14>

AGP_AD<16>

AGP_AD<17>

AGP_AD<18>

AGP_AD<19>

AGP_AD<20>

AGP_AD<21>

AGP_AD<23> AGP_AD<22>

AGP_AD<26> AGP_AD<25> AGP_AD<24>

AGP_AD<27>

AGP_AD<28>

AGP_AD<29>

AGP_AD<30>

AGP_AD<31>

INT_AGP_VREF

AGP_AD_STB_L<1> AGP_BUSY_L

AGP_AD_STB<1>

AGP_AD_STB<0>

AGP_AD_STB_L<0>

GPU_VCORE_VDDCI

B00ST

EXT VCC VCC

INT

VIN

SGND PGND

RUN/SS

VFB

ITH

ION

PGOOD

VRNG FCB

ZV_LCDDATA11 ZV_LCDDATA12

VSS

(3 OF 6)

RAGE_MOBILITY

ZV_LCDDATA0 ZV_LCDDATA1

ROMCSB

SSIN

TESTEN

XTALOUT

SSOUT

TXCLK_LP

TXCLK_LN

TXOUT_L3P

XTALIN

TXCP

TX0P TX1M

TXCM

TX2M

TX1P

TX2P

TX0M

GPIO13 GPIO14

GPIO9

GPIO11

GPIO10

GPIO12

GPIO8

TXOUT_U1N

TXOUT_U0N TXOUT_U0P

TXOUT_U1P TXOUT_U2N

TXCLK_UP

TXOUT_U3N

TXOUT_L1P

TXOUT_L1N

TXOUT_L0P

TXOUT_L0N

TXOUT_U2P

TXCLK_UN

TXOUT_U3P

TXOUT_L2N TXOUT_L2P TXOUT_L3N

GPIO4

GPIO3

GPIO2

GPIO6 GPIO7

GPIO5

GPIO1

GPIO0

ZV_LCDCNTL3

ZV_LCDCNTL2

ZV_LCDDATA19

ZV_LCDDATA18

ZV_LCDDATA17

ZV_LCDDATA23

ZV_LCDDATA22

ZV_LCDCNTL1

ZV_LCDCNTL0

ZV_LCDDATA20 ZV_LCDDATA21

AUXWIN

COMP_B

DIGON

C_R

ZV_LCDDATA16

ZV_LCDDATA10

ZV_LCDDATA9

ZV_LCDDATA8

ZV_LCDDATA7

ZV_LCDDATA13 ZV_LCDDATA14 ZV_LCDDATA15

ZV_LCDDATA6

ZV_LCDDATA2 ZV_LCDDATA3 ZV_LCDDATA4 ZV_LCDDATA5

VSYNC

V2SYNC

HSYNC

H2SYNC

RSET

R2SET

Y_G

R G

GPIO15 GPIO16

BLON

DDC2DATA

DDC2CLK

DDC1DATA

DDC1CLK

DDC3DATA

DDC3CLK

HPD1

VDD15

VSS

RAGE_MOBILITY

(5 OF 6)

VDDC

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

GPU VCORE - 1.2V

(GPIO0)

(GPIO2)

(GPIO6)

1.2V = 0.8V * (1 + R332 / (R331//R333))

(NO ICT TEST)

1.0V = 0.8V * (1 + R332 / R333)

WHEN VCORE_CNTL HIGH => 1.2V

WHEN VCORE_CNTL LOW => 1.0V

(NO ICT TEST)

(500mA)

(NO ICT TEST)

(PUT ALL CAPs BELOW ATI ASIC)

(GPIO3)

(GPIO1)

M10 CORE PWR/LVDS/TMDS

NC NC

(GPIO4) (GPIO5)

CMF LINE SHOULD BE ROUTED AS 4MIL SURFACE

GPU VCORE SUPPLY

(NO ICT TEST)

M10 Power Shut down Sequencing

(NO ICT TEST)

TRACE SO THAT IT MAY BE CUT BETWEEN CAPS

TERMINATION NETWORK SHOULD BE CONNECTED AS SHOWN

TMDS TERMINATION

C252

CERM

0.22uF

20%

402

6.3V

C167

CERM

6.3V

20%

805

10uF

C219

10uF

20%

6.3V CERM 805

C270

CERM 402

20%

6.3V

0.22uF

C301

20% CERM

402

6.3V

0.22uF

C307

402

0.22uF

CERM

20%

6.3V

C329

20%

6.3V 402

CERM

0.22uF

C332

0.22uF

6.3V

20% CERM

402

C186

6.3V 402

CERM

20%

0.22uF

C220

0.22uF

6.3V 402

CERM

20%

C253

20%

0.22uF

402

CERM

6.3V

C271

6.3V

20% CERM

402

0.22uF

C302

402

CERM

6.3V

20%

0.22uF

C311

0.22uF

6.3V 402

CERM

20%

C330

0.22uF

6.3V 402

CERM

20%

C333

6.3V

0.22uF

402

20% CERM

C187

0.22uF

20% CERM

402

6.3V

C221

402

CERM

20%

6.3V

0.22uF

C254

402

6.3V

20% CERM

0.22uF

C282

0.22uF

20% CERM

402

6.3V 2

C303

402

6.3V CERM

20%

0.22uF

C326

0.22uF

CERM

20%

402

6.3V

C331

0.22uF

20%

402

CERM

6.3V

C338

0.22uF

402

CERM

20%

6.3V

C708

1210

22uF

10V

20% CERM

C719

SMD

6.3V

20%

330UF

POLY

D24

SMB

B340LB

C514

25V

0.1uF

20%

CERM

603

R416

1/16W

603

2.2

C494

20%

0.1uF

25V

CERM

603

R430

5% 1/16W MF

603

R339

1/16W 402

576K

C473

1206

10V

20% CERM

4.7UF4.7uF

+5V_MAIN

R388

1/16W

NO STUFF

402

R451

402

1/16W

GPU_PWRMSR

18.2K

R351

402

1/16W

20K

C515

20% 10V

CERM

402

0.1uF

GPU_PWRMSR

R410

402

1/16W

10K

GPU_PWRMSR

XW2

OMIT

15 14

1149

U16

SSOP

LTC1778

CRITICAL

R311

402

1/16W

C451

5% CERM

402

220pF

25V

C766

25V

20%

CERM

4.7UF

1206

+PBUS

R389

1/16W

402

C483

10V 402

20% CERM

0.1uF

C448

402

CERM

50V

10%

470pF

R340

20K

1/16W

402

R341

NO STUFF

63.4K

402

1/16W

R332

402

1/16W

R223

10K

5% MF

402

1/16W

NO STUFF

Q51

SI7860DP

SO-8-PWRPK

CRITICAL

C762

1206

CERM

25V

20%

4.7UF

C720

20%

6.3V SMD

330UF

POLY

C721

6.3V SMD

20%

330UF

POLY

R390

1/16W

402

R316

100K

5% MF

402

1/16W

R306

402

1/16W

100K

6 1

DP1

BAS16TW

SOT-363

2N3904

R294

10K

1/16W

402

DP1

SOT-363

BAS16TW

DP1

SOT-363

BAS16TW

+5V_MAIN

R247

10K

1/16W

402

R253

402

1/16W

10K

R245

402

1/16W

R249

MF 402

1% 1/16W

R246

1/16W 402

R240

402

1/16W

R248

402

1/16W

R254

1/16W

402

R257

402

499

1/16W MF

R256

1/16W

715

402

R260

402

1/16W MF

10K

R261

1/16W MF

402

10K

NO STUFF

R262

1/16W

NO STUFF

10K

MF 402

R265

402

1/16W

10K

NO STUFF

R266

NO STUFF

402

10K

1/16W

R269

10K

MF 402

NO STUFF

1/16W

R270

1/16W

10K

MF 402

NO STUFF

R271

NO STUFF

1/16W 402

5% MF

10K

R272

10K

402

1/16W

NO STUFF

R258

402

10K

5% 1/16W

R259

402

1/16W

5% MF

10K

NO STUFF

R273

1/16W

NO STUFF

10K

402

R274

402

1/16W

NO STUFF

10K

R263

5% 1/16W

10K

MF 402

NO STUFF

2 1

R229

1/16W

402

C328

10uF

6.3V

20% CERM

805

C305

0.01uF

20% 16V CERM 402

C299

0.01uF

16V CERM

20%

402

C256

16V

20% CERM

402

0.01uF

C222

0.01uF

402

CERM

20% 16V

C306

20%

0.01uF

16V 402

CERM

C300

16V CERM

20%

402

0.01uF

C269

0.01uF

CERM

16V

20%

402

C232

402

CERM

20% 16V

0.01uF

R352

402

1/16W

4.99K

R228

1/16W

10K

402

EXT_TMDS

Q48

SO-8-PWRPK

SI7892DP

CRITICAL

L24

FERR-220-OHM

0805

R236

100K

402

1/16W

R203

33K

1/16W

402

Q77

SI3446DV

TSOP

C166

402

X7R

25V

10%

1000pF

DP6

SOT-363

BAS16TW

DP6

BAS16TW

SOT-363

DP6

SOT-363

BAS16TW

+2_5V_SLEEP

XW21

XW20

XW22

XW24

XW23

R221

1/16W 5%

402

Q80

2N7002DW

SOT-363

Q80

2N7002DW

SOT-363

R307

100K

1/16W MF 402

+5V_MAIN

C882

402

CERM

50V

10%

0.0022UF

NO STUFF

MBR0540

R711

10K

5% 1/16W MF 402

R804

402

1/16W

1.82K

GPU_PWRMSR

C902

402

CERM

10V

20%

0.1UF

GPU_PWRMSR

R234

402

1/16W

10K

INT_TMDS

L30

2.1UH-11A

CRITICAL

AK7

AJ7

AH7

AG7

AK6

AJ6

AH6

AH11

AG11

AK10

AJ10

AG6

AH10

AG10

AK9

AJ9

AH9

AG9

AK8

AJ8

AH8

AG8

AK5

AJ5

AG5

AH5

AK4

AJ4

AK23

AJ30

AJ29

AG27

B21

A20

A24

B20

B24

AG25

AG22

AH22

AG20

AH20

AG19

AH19

AG18

AH18

AJ20

AK20

AJ18

AK18

AJ17

AK17

AJ16

AK16

AK12

AJ12

AG21

AH21

AJ19

AK19

AK15

AJ15

AK14

AJ14

AK13

AJ13

AH24

AJ25AJ26

AK25

AE5

AJ24

AK28

AG26

AF11

AG24

AF3

AG3

AH1

AF4

AJ1

AH2

AH3

AK1

AE1

AE2

AF1

AG1

AF2

AG2

AK2

AJ2

AK27

AE13

AH26 AH25

AE12 AF12

AH28 AH27

AK22

AK24

AF13

AK26

AJ27

U44

OMIT

M11-CSP64

64MB

BGA

G16

G15

AD23

G14

AD22

AD21

AD20

AD19

AD18

AD17

AD16

AD15

AD14

AD13

G13

AD12

AD11

AD10

AD9

AD8

AD7

AC24

AC23

AC8

AC7

G12

AB24

AB7

AA24

AA7

Y24

W24

V24

G11

U24

T24

R24

P24

N24

G10

M24

L24

K24

J24

H24

H23

G24

G23

G22

G21

G20

G19

G18

G17

AD26

AF5

V25

W25

N25

M25

F25

AE24

F24

AH4

F23

AE18

AC25

AE17

AF15

W26

AF14

AE14

F14

F13

AG4

AE11

F11

AE10

F10

AE6

AD6

AC6

AF25

AJ3

AB25

R25

G25

F17

AB6

F12

U44

OMIT

M11-CSP64

64MB

BGA

4419

051-6598

1778_TG

HIGH_VCORE

HIGH_VCORE_DIV

1778_BG

1778_SHDN_L

1778_ITH

GPU_VCORE_CNTL

1778_VFB

1778_VCC

1778_BST_RC

1778_GND

+GPU_VDD15_NECK

1778_VRNG

1778_FCB

1778_VIN

VCORE_CNTL_RC

+1_5V_AGP_NECK

1778_SHDN_L_D3COLD

SLEEP_L_LS5

DCDC_EN

GPU_VCORE_SEQ

GPU_VCORE_SEQ_L

GPU_VCORE_PWR_SEQ

+1_5V_AGP

1778_ITH_RC

GPU_CORE_OK

1778_GND

1778_VFB

+1_5V_AGP

+2_5V_SLEEP_NECK1

+GPU_VDD15_UF

GPU_VCORE

ATI_X1CLK_SKEW<1>

ATI_BUS_CFG<0>

ATI_BUS_CFG<2>

+3V_GPU

ATI_AGP_FBSKEW<1>

ATI_BUS_CFG<1>

+1_5V_AGP

GPU_CORE_OK

ATI_AGP_FBSKEW<0>

+GPU_VDD15_UF

+1_8V_PVDD_NECK

+1_8V_ATI_PVDD

GPU_VCORE_NECK

+3V_GPU

1778_ION

+3V_GPU

+1_8V_GPU

+3V_GPU

GPU_VCORE_CNTL_L

GPU_VCORE

ATI_X1CLK_SKEW<0>

GPU_VCORE_SW

1778_BST

GPU_DVOD<10>

GPU_DVOD<1>

GPU_DVOD<0>

ATI_TESTEN

ATI_CLK27M_IN

ATI_TMDS_CLKP

ATI_TMDS_CLKN

ATI_TMDS_DP<2>

ATI_TMDS_DN<2>

ATI_TMDS_DP<1>

ATI_TMDS_DN<0>

ATI_TMDS_DN<1>

ATI_TMDS_DP<0>

ATI_GPIO13_SPN HPD_PWR_SNS_EN

ATI_GPIO11_SPN ATI_GPIO12_SPN

ATI_GPIO10_SPN

ATI_GPIO8_PD

ATI_GPIO9_SPN

ATI_GPIO7_SPN

ATI_BUS_CFG<2>

ATI_BUS_CFG<1>

ATI_BUS_CFG<0>

ATI_X1CLK_SKEW<1>

ATI_AGP_FBSKEW<1>

ATI_AGP_FBSKEW<0>

ATI_X1CLK_SKEW<0>

GPU_DVO_CLKP

GPU_DVOD_DE

GPU_DVO_HSYNC

GPU_DVO_VSYNC

ZV_LCDDATA20_PU

GPU_DVOD<11>

GPU_DVOD<9>

GPU_DVOD<8>

GPU_DVOD<6> GPU_DVOD<7>

GPU_DVOD<5>

GPU_DVOD<4>

GPU_DVOD<3>

GPU_DVOD<2>

CLKLVDS_LN

LVDS_L3P_TP

CLKLVDS_LP

LVDS_L3N_TP

LVDS_L2P

LVDS_L1P LVDS_L2N

LVDS_L1N

LVDS_L0P

LVDS_L0N

CLKLVDS_UN CLKLVDS_UP

LVDS_U3P_TP

LVDS_U2P LVDS_U3N_TP

LVDS_U1P

LVDS_U1N

LVDS_U2N

LVDS_U0P

LVDS_U0N

GPU_AUXWIN

FP_PWR_EN

GPU_C GPU_COMP

ATI_R2SET

ATI_RSET

GPU_Y

ATI_HSYNC

ATI_VSYNC

GPU_B

GPU_R

GPU_G

GPU_VCORE_CNTL_L ATI_SSCLK_IN

INV_ON_PWM

LVDS_DDC_DATA LVDS_DDC_CLK

GPU_DVI_DDC_DATA GPU_DVI_DDC_CLK

SI_DDC_DATA SI_DDC_CLK

GPU_HPD

+1_5V_GPU_VDD15

GPU_VCORE

21 38

20 18

18 12

PAD

THRML

GND

SDA/DK0

SCL/DK1

AGND

PD* EDGE/HTPLG

DE HSYNC VSYNC IDCK+ IDCK-

D11

D10

D2 D3 D4 D5 D6 D7 D8 D9

GND

AVCC

PVCC2

PVCC1

VCC

AVCC

VCC

EXT_SWING

VREF

TX1+

TX2-

TX1TX2+

TX0+ TX0-

TXC-

TXC+

MSEN

PGND

AGND

PGND

AGND

CTL3/A2 ISEL/RST*

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

SIL1162 DVI TRANSMITTER

RP58

1/16W

SM1

EXT_TMDS

1234

314337

SIL1162

TSSOP

EXT_TMDS

CRITICAL

R88

10K

5% MF

402

1/16W

NO STUFF

R224

402

1% 1/16W

4.99K

EXT_TMDS

RP58

1/16W

SM1

EXT_TMDS

R222

330

402

1/16W MF

EXT_TMDS

R212

402

1/16W

EXT_TMDS

10K

R99

NO STUFF

10K

5% 1/16W MF 402

R66

5% MF

402

10K

NO STUFF

1/16W

L14

SM-1

400-OHM-EMI

EXT_TMDS

L13

400-OHM-EMI

SM-1

EXT_TMDS

L15

400-OHM-EMI

SM-1

EXT_TMDS

C14

10UF

20%

6.3V CERM 805

EXT_TMDS

C130

10UF

20%

6.3V CERM 805

EXT_TMDS

C132

100PF

5% 50V CERM 402

EXT_TMDS

RP59

1/16W

SM1

EXT_TMDS

C165

100PF

5% 50V CERM 402

EXT_TMDS

C129

10UF

20%

6.3V CERM 805

EXT_TMDS

C131

100PF

5% 50V CERM 402

EXT_TMDS

C133

100PF

CERM 402

EXT_TMDS

5% 50V

C233

100PF

5% 50V CERM 402

EXT_TMDS

C218

100PF

5% 50V CERM 402

EXT_TMDS

C255

10UF

20%

6.3V CERM 805

EXT_TMDS

RP59

SM1

1/16W

EXT_TMDS

+3V_SLEEP

R41

603

1/16W

RP57

SM1

1/16W

INT_TMDS

RP27

1/16W

SM1

INT_TMDS

RP57

INT_TMDS

1/16W

SM1

RP32

INT_TMDS

1/16W

SM1

RP27

1/16W

SM1

INT_TMDS

RP32

1/16W

SM1

INT_TMDS

RP60

1/16W

SM1

EXT_TMDS

RP28

1/16W

SM1

INT_TMDS

RP28

1/16W

SM1

INT_TMDS

C79

470PF

10% 50V

402

CERM

C87

470PF

10% 50V

402

CERM

RP60

1/16W

SM1

EXT_TMDS

R204

402

1/16W

49.9

R214

402

1/16W

49.9

RP61

1/16W

SM1

EXT_TMDS

R220

402

1/16W

49.9

C102

470PF

10% 50V CERM 402

C82

470PF

10% 50V

CERM

402

R210

402

1/16W

49.9

R219

402

1/16W

49.9

C89

470PF

10% 50V CERM 402

RP61

1/16W

SM1

EXT_TMDS

C81

470PF

10% 50V

CERM

402

R211

402

1/16W

49.9

R218

402

1/16W

49.9

C88

470PF

10% 50V CERM 402

C80

10% 50V

402

CERM

470PF

R205

402

1/16W

49.9

R202

MF 402

1/16W

10K

EXT_TMDS

C284

0.1UF

20% CERM

402

EXT_TMDS

10V

R231

402

1/16W

EXT_TMDS

R232

402

1/16W

EXT_TMDS

R110

MF 402

EXT_TMDS

5% 1/16W

10K

R237

1/16W

402

EXT_TMDS

R235

402

1/16W

NO STUFF

R233

1/16W 402

10K

5% MF

NO STUFF

20 44

051-6598

SI_DDC_DATA

SI_DDC_CLK

SI_RST

SI_PD SI_EDGE

TMDS_DP<1>

+3V_GPU_SI

TMDS_DN<2>

TMDS_DP<2> TMDS_DN<2>

TMDS_DP<1> TMDS_DN<1>

TMDS_DP<0>

TMDS_CLKP

TMDS_DN<0>

TMDS_CLKN

+3V_GPU_SI

+3V_SI_PLLVCC

SI_TMDS_CLKP

SI_TMDS_DP<1>

SI_TMDS_DP<0> SI_TMDS_DN<0>

SI_TMDS_DP<2> SI_TMDS_DN<2>

GPU_DVOD<0>

GPU_DVOD<2>

GPU_DVOD<1>

GPU_DVOD<3>

GPU_DVOD<10>

GPU_DVOD<9>

GPU_DVOD_DE

GPU_DVOD<11>

GPU_DVO_CLKP

TMDS_CLKN

SI_TMDS_CLKN

TMDS_CLKP

SI_TMDS_CLKP

TMDS_DP<0>

SI_TMDS_DP<0>

SI_TMDS_DP<1>

TMDS_DN<0>

SI_TMDS_DN<0>

TMDS_DP<2>

SI_TMDS_DP<2>

TMDS_DN<1>

SI_TMDS_DN<1>

TMDS_CLKN

TMDS_CLKP

ATI_TMDS_CLKP

TMDS_DN<0>

ATI_TMDS_DN<0>

TMDS_DP<0>

ATI_TMDS_DP<0>

TMDS_DP<1>

ATI_TMDS_DP<1>

TMDS_DP<2>

ATI_TMDS_DP<2>

TMDS_DN<1>

ATI_TMDS_DN<1>

TMDS_DN<2>

ATI_TMDS_DN<2>

MAIN_RESET_L

GPU_DVO_HSYNC

GPU_DVOD<5>

GPU_DVOD<8>

GPU_DVOD<7>

EXT_SWING

+1_8V_GPU

SI_VREF

+3V_SI_AVCC

SI_MSEN

SI_A2

+3V_SI_VCC

SI_VREF

GPU_DVOD<6>

GPU_DVO_VSYNC

SI_TMDS_DN<2>

ATI_TMDS_CLKN

TMDS_CLK_CMF

TMDS_D0_CMF

TMDS_D1_CMF

TMDS_D2_CMF

GPU_DVOD<4>

SI_TMDS_DN<1>

SI_TMDS_CLKN

39 30 26

39 39

37 37

22 22

20 20

20 19

CONT

NOISE

VIN

VOUT

GND

CONT

NOISE

VIN

VOUT

GND

VDDR4

VDDR3

TXVSSR1 TXVSSR2 TXVSSR3

TXVDDR2

TXVDDR1

TXVDDR0

TXVDDR3

MPVDD

TPVDD

LPVDD

LVDDR_18 LVDDR_18

VDDM

LVSSR3

LVSSR2

LVSSR1

LVSSR0

MPVSS

TPVSS

LPVSS

VDDP

VDDRH1

VDDRH0

A2VDDQ

AVDD0 AVDD1

PVDD

A2VDD1

A2VDD0

VDDR1

VSSRH1

VSSRH0

A2VSSN1

A2VSSN0

A2VSSQ AVSSN0 AVSSN1

AVSSQ

PVSS

RAGE_MOBILITY

(4 OF 6)

VDD1DI VDD2DI

VSS1DI VSS2DI

LVDDR_25 LVDDR_25

DVOVMODE

VDDR1

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

(20mA)

LVDS PLL - 1.8V

(40mA)

(1800mA)

MEMORY PLL - 1.8V

2.5V

(140mA)

MEMORY I/O

(350mA)

(Total PVDD = 66mA)

3.3V IO SUPPLY

AGP 4X I/O - 1.5V

(Max Current varies, depends on usage)

GPU POWER SOURCES - 1.5V, 1.8V, 2.5V & 3.3V

(AVDD+VDDDI=75mA)

2.5V

1.8V

1.5V

M10 SHUT DOWN POWER SEQUENCING

(100mA MAX)

(2mA)

GPU PLL - 1.8V

(20mA)

(AVDD+VDDDI=75mA)

M10 POWER

(21mA)

3.3V

(1200mA)

LVDS/TMDS - 1.8V

LVDS - 2.5V

(180mA)

MEMORY CORE - 2.5V

C853

10V 402

CERM

0.1uF

20%

C848

0.1uF

CERM

20% 10V

402

C722

10uF

20%

6.3V 805

CERM

C858

10V

20% CERM

402

0.1uF

C855

10V CERM 402

20%

0.1uF

C850

CERM

0.1uF

402

10V

20%

C875

CERM 402

10V

20%

0.1uF

C851

0.1uF

CERM 402

10V

20%

C876

10V

0.1uF

402

CERM

20%

C872

6.3V

20%

10uF

805

CERM

C873

0.1uF

20% 10V

402

CERM

C871

10uF

20%

805

CERM

6.3V

C543

0.1uF

CERM 402

10V

20%

C671

16V 402

CERM

20%

0.01uF

C857

20% 10V

402

CERM

0.1uF

C852

0.1uF

CERM 402

10V

20%

C847

10V

0.1uF

402

CERM

20%

C874

0.1uF

CERM

20%

402

10V

C446

0.1uF

10V 402

CERM

20%

C420

CERM

10V 402

20%

0.1uF

C447

16V CERM

20%

402

0.01uF

C421

16V

20% CERM

402

0.01uF

C381

20%

402

CERM

10V

0.1uF

C382

402

20% 16V

0.01uF

CERM

C860

20% 10V

402

CERM

0.1uF

C856

10V

0.1uF

CERM 402

20%

C861

0.1uF

CERM 402

10V

20%

C862

20% 16V

0.01uF

CERM 402

C715

10uF

6.3V

20% CERM

805

C672

0.1uF

CERM 402

10V

20%

C701

0.01uF

16V 402

CERM

20%

C866

0.1uF

402

10V

20% CERM

C450

16V CERM

20%

0.01uF

402

C426

402

16V CERM

20%

0.01uF

C425

CERM

10V

20%

0.1uF

402

C383

CERM

0.1uF

402

10V

20%

C408

402

20% 16V CERM

0.01uF

C704

0.1uF

CERM 402

20% 10V

C864

20%

0.1uF

CERM

10V 402

C869

16V

20%

0.01uF

402

CERM

C435

0.1uF

CERM 402

10V

20%

C436

CERM 402

20% 16V

0.01uF

C870

402

CERM

20% 16V

0.01uF

C437

402

20%

0.01uF

CERM

16V

C868

16V CERM

20%

402

0.01uF

C434

402

0.01uF

16V

20% CERM

C859

402

20% 10V CERM

0.1uF

C854

20% 10V

402

CERM

0.1uF

C849

0.1uF

10V CERM 402

20%

C725

CERM 402

10V

20%

0.1uF

C863

0.1uF

402

20% 10V CERM

C364

16V 402

20% CERM

0.01uF

C363

0.01uF

402

20% CERM

16V

C361

0.01uF

16V

20% CERM

402

C372

16V CERM

20%

0.01uF

402

C373

CERM 402

20% 16V

0.01uF

C362

CERM 402

20% 16V

0.01uF

+1_5V_SLEEP

R722

1/10W 805

+2_5V_SLEEP

R728

1/4W 1210

ATI_MEMIO_HI

+3V_SLEEP

R299

805

1/10W

+1_8V_SLEEP

R729

ATI_MEMIO_LO

1/4W 1210

C867

0.01uF

CERM 402

20% 16V

C428

CERM

16V 402

20%

0.01uF

C429

402

CERM

20%

0.01uF

16V

R284

805

1/10W

+1_8V_SLEEP

+2_5V_SLEEP

C379

16V CERM 402

20%

0.01uF

C716

402

0.01uF

16V

20% CERM

C339

CERM

20%

6.3V 805

10uF

C358

10uF

805

6.3V

20% CERM

C374

402

CERM

0.01uF

16V

20%

C360

20%

805

CERM

6.3V

10uF

C359

CERM

10uF

805

6.3V

20%

C415

6.3V

20%

10uF

805

CERM

C409

6.3V

10uF

805

20% CERM

C411

CERM

20%

805

10uF

6.3V

C412

10uF

805

6.3V

20% CERM

C865

10V

0.1uF

402

CERM

20%

C438

10uF

20%

805

CERM

6.3V

C413

10uF

6.3V CERM 805

20%

C414

20% 10V

402

0.1uF

CERM

L58

FERR-220-OHM

0402

L55

FERR-220-OHM

0402

L56

0402

FERR-220-OHM

L57

0402

FERR-220-OHM

L65

0402

FERR-220-OHM

L66

0402

FERR-220-OHM

L61

FERR-220-OHM

0402

L62

0402

FERR-220-OHM

L60

FERR-220-OHM

0402

C380

10uF

6.3V CERM 805

20%

L63

0805

FERR-220-OHM

L64

FERR-10-OHM-500MA

L67

0805

FERR-220-OHM

2 1

L68

FERR-10-OHM-500MA

L59

FERR-10-OHM-500MA

DP7

SOT-363

BAS16TW

DP7

SOT-363

BAS16TW

DP7

SOT-363

BAS16TW

XW30

OMIT

XW27

OMIT

+2_5V_SLEEP_NECK2

XW28

OMIT

+1_8V_SLEEP_NECK

XW29

OMIT

+1_5V_SLEEP_NECK

+2_5V_SLEEP

+1_8V_SLEEP

+1_5V_SLEEP

+3V_SLEEP

C878

402

CERM

16V

0.01uF

20%

C877

CERM

20%

805

6.3V

10uF

U54

CRITICAL

ATI_TPVDD_BYP

SOT-25A

MM1571J

INT_TMDS

C879

1UF

10%

6.3V CERM 603

INT_TMDS

C880

CERM 402

16V

10%

0.01UF

INT_TMDS

C881

805

CERM

6.3V

20%

10UF

INT_TMDS

L69

0402

FERR-220-OHM

INT_TMDS

U55

CRITICAL

SOT-25A

MM1571J

C889

1UF

10%

6.3V CERM 603

R721

5% 1/10W FF 805

2 1

L16

FERR-10-OHM-500MA

EXT_TMDS

C304

10uF

CERM 805

6.3V

20%

C327

402

10V

20%

0.1uF

CERM

C647

402

10V

20%

0.1uF

CERM

R255

EXT_TMDS

402

1/16W

R251

INT_TMDS

1/16W MF

402

R268

603

5% MF

1/16W

INT_TMDS

R279

603

1/16W

EXT_TMDS

F20

AF19

AG23

F19

AE8

AF7

AE7

AF6

AE25

AD25

AF10

AF9

AE9

AF8

AF26

AE26

E25

E24

E23

E22

E21

E17

E16

E15

E14

E11

E10

H26

J26

J25

H25

F22

F21

F16

F15

AA6

G26

AD5

AC5

AB5

AA5

N26

M26

L26

K26

AA25

K27

Y28

T25

AC26

AB26

AA26

Y26

V26

U26

T26

R26

P26

L25

K25

F26

E26

E20

E19

E18

E13

E12

AF20

AH23

AH15

AH14

AH13

AG15

AG14

AG13

AG12

AJ11AK11

AK30AK29

A6A7

AF18

AH17

AG17

AH16

AF17

AG16

AF16

AE16

AJ21AK21

AH12

AF22

AE23

AE22

AF24

AF23

AJ22

AE20

AE19

AJ23

AF21

AE21

U44

OMIT

M11-CSP64

64MB

BGA

051-6598

21 44

+1_8V_ATI_PVDD

+1_8V_GPU_TP_PLL

GPU_CORE_OK

+1_8V_ATI_TPVDD

+3V_SLEEP_NECK

+2_5V_GPU

+3V_GPU

+2_5V_GPU

+1_8V_GPU

+1_8V_GPU_VDDDI

+1_8V_GPU

+GPU_MCLK

+GPU_MEM

+1_8V_ATI_PVDD

+1_8V_GPU

+1_8V_GPU_AVDDQ

+1_8V_GPU

+1_5V_AGP

+1_8V_GPU

+1_5V_AGP

+GPU_MEM

+2_5V_GPU

+3V_GPU

+1_8V_GPU

+GPU_MEM

+2_5V_GPU

ATI_PVDD_BYP

+1_8V_ATI_PVDD

+2_5V_GPU

GPU_CORE_OK

+2_5V_GPU_A2VDD

+1_8V_DVO_F

+1_8V_GPU_PNLIO

+1_8V_GPU_TP_PLL

+1_8V_GPU_MEMPLL

+1_8V_GPU_PNLPLL

+GPU_MEMCORE

+3V_GPU_FLT

+GPU_MCLK

+1_8V_GPU_AVDDQ

+2_5V_GPU_A2VDD

+1_8V_GPU_PLL

+1_8V_GPU_AVDD

GPU_MEM_IO_FLT

+1_8V_GPU_VDDDI

+2_5V_GPU_PNLIO

+1_5V_AGP_GPU

+GPU_MEM

SYM_VER-1

MINIDIN

LCFILTER

SYM_VER-1

SYM_VER-1 SYM_VER-1

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

NOTE: Pulldown for DVI_HPD provided by DVI power switch interface

BECAUSE OF BOARD REAL ESTATE

LCD INTERFACE

EXTERNAL VIDEO (DVI) INTERFACE

VGA VSYNC BUFFERS

ANALOG FILTERING

PLACE CLOSE TO CONNECTOR

TMDS FILTERING

PLACE CLOSE TO CONNECTOR

graphics controller

Place GND shorts at

LCD POWER SWITCHES

Panel has 2K pull-ups

SIGNAL IS TRISTATED INITIALLY

NEED PULL-DOWN BECAUSE THIS

GPIO.

when system is running. HPD normally driven to

3.3V. When power key on remote device pressed, HPD will be driven to 5V.

Power key detect path

COMPARATOR ENABLED BY NV17MAP

PLACE NEAR 3, 11 & 19

(TMDS_DP<5>)

(LVDS DDC POWER)

will turn off, as will remote

As host rails rise, TP0610 device path into DDC_CLK.

Isolation will be disabled as well.

on, driving SOFT_PWR_ON_L low.

will be low, TP0610 will turn

NV17M DURING SHUTDOWN. WHEN

Power key detect path when

is pressed, 5V will be driven

power key on remote device

system is shutdown or asleep..

into DDC_CLK. Since host rails

DDC_CLK is isolated from

3V LEVEL SHIFTERS

(TMDS_DN<3>) (TMDS_DP<4>) (TMDS_DP<3>)

Isolation required for DVI power switch

pullup.

on when DVI monitor powered DDC clock

Pulldown prevents

has active, self-

3904 from turning

VIDEO CONNECTORS

INVERTER EXPECTS ACTIVE HIGH SIGNAL

LVDS INTERFACE

100K pull-ups are for no-panel case (development)

DVI POWER SWITCH

INVERTER INTERFACE

SHARES LOGIC WITH KB RESET SIGNALS (PG 28)

DVI DDC CURRENT LIMIT

PLACE NEAR C5A & C5B

(TMDS_DN<5>) (TMDS_DN<4>)

(55mA requirement per DVI spec)

S-VIDEO/COMP OUT INTERFACE

(+5V_DDC SLEEP)

NOTE: DVI_HPD SHARES Q68 WITH ALS

+5V_MAIN

R317

100K

1/16W

402

C739

0.001UF

20% CERM

50V 402

CHGND2

C749

0.001UF

CERM

20% 50V

402

C746

0.001UF

20% 50V CERM 402

C440

10UF

805

CERM

20%

6.3V

L33

FERR-1K-OHM-EMI

L31

SM-1

400-OHM-EMI

+PBUS

+3V_PMU

C552

0.1UF

20% 10V

CERM

402

3 2

SC70-6

FDG6324L

SC70-6

FDG6324L

C685

402

0.25% 50V CERM

3.3PF

C676

402

3.3PF

CERM

50V

0.25%

C684

3.3PF

50V CERM

0.25%

402

R671

10K

5% 1/16W MF 402

R662

402

1/16W

10K

Q38

2N7002DW

SOT-363

+3V_SLEEP

Q38

SOT-363

2N7002DW

R694

402

100K

1/16W MF

C669

402

100pF

5% 50V CERM

R655

4.7K

5% 1/16W MF 402

R661

4.7K

1/16W

402

C706

402

100pF

5% 50V CERM

C710

0.01UF

CERM

50V

20%

603

CHGND1

L23

SM-1

400-OHM-EMI

Q35

2N7002DW

SOT-363

0.5AMP-13.2V

D21

MBR0530

CERM

50V

402

100pF

Q44

2N3904

R700

1/16W

402

20K

C696

0.1UF

20% 10V CERM 402

R680

68.1K

1/16W

402

U46

CRITICAL

LMC7211

R663

402

1/16W

10K

R681

402

1/16W

100K

R686

402

10K

1/16W

Q41

2N7002DW

SOT-363

R696

100K

402

1/16W

Q42

2N3904

R691

1/16W

402

10K

R688

330

402

1/16W

Q40

TP0610

C712

603

20% 50V

CERM

0.01UF

CHGND1

L26

FERR-10-OHM-500MA

L25

3.3UH

0603

L29

3.3UH

0603

C717

CERM

50V

20%

603

0.01UF

L27

3.3UH

0603

L28

FERR-10-OHM-500MA

+3V_SLEEP

+5V_SLEEP

XW12

XW13

R706

402

1/16W

5% 1/16W MF 402

R670

1/16W

402

100

R649

100

402

1/16W

R650

100

402

1/16W

SM-2MT

CRITICAL

L32

SM-1

400-OHM-EMI

L21

CRITICAL

165-OHM

4 3 2 1

1110

J15

CRITICAL

RT-TH

MH1177

CHGND4

C416

0.001uF

20% 50V

CERM

402

R320

100K

1/16W

402

C452

402

CERM

50V

20%

0.001uF

CHGND4

+3V_SLEEP

R342

402

1/16W

100K

CRITICAL

G-501973

F-RT-SM

CHGND4

2 1

C500

0.001uF

402

CERM

50V

20%

CHGND4

C474

0.001uF

402

CERM

50V

20%

FERR-250-OHM

+3V_MAIN

C484

603

50V

CERM

2200pF

3 6

5 2 1

Q11

TSOP

SI3443DV

R391

100K

1/16W

402

R400

100K

5% 1/16W MF 402

2N7002

U24

74LVC32

TSSOP

2 1

R690

680

402

1/16W

CHGND5

CHGND2

C744

20% 50V

CERM

603

0.01uF

C5B C5A

J14

F-RT-TH

CRITICAL

QH1112

R724

402

1/16W

R705

402

1/16W

68K

+PBUS

Q45

TP0610

R703

5% 1/16W MF 402

330

C703

47UF

CERM 1210

20%

6.3V

Q41

SOT-363

2N7002DW

R704

402

1/16W

100K

R213

402

1/16W

100K

C449

0.001uF

20% 50V

CERM

402

NO STUFF

C702

CERM

50V

10%

560PF

402

C718

402

CERM

50V

10%

560PF

C714

402

560PF

10% 50V

CERM

C707

402

CERM

50V

10%

560PF

C724

402

560PF

10% 50V

CERM

C713

402

CERM

50V

10%

560PF

FL2

SM-220MHZ

CRITICAL

FL1

SM-220MHZ

CRITICAL

FL3

CRITICAL

SM-220MHZ

L72

CRITICAL

90-OHM-300MA

2012H

L73

TMDS_CONN_DN<1>

CRITICAL

90-OHM-300MA

2012H

L74

CRITICAL

TMDS_CONN_DN<2>

TMDS_CONN_DP<2>

90-OHM-300MA

2012H

U57

CRITICAL

74AHC1G32

VGA_VSYNC_BUF

U56

CRITICAL

VGA_HSYNC_BUF

74AHC1G32

R718

402

1/16W

R714

402

1/16W

+3V_MAIN

051-6598

22 44

DVI_DDC_DATA_UF

ATI_VSYNC

TV_GND1

TV_C

+5V_DDC_SLEEP_UF

+5V_DDC_SLEEP

TMDS_CONN_DP<0>

TMDS_CONN_DN<0>

VGA_VSYNC

DVI_HPD_DIV

LVDS_DDC_CLK LVDS_DDC_DATA

HPD_ON_RC

+12_8V_INV

+5V_INV_SW

+5V_INV_UF_SW

DVI_DDC_CLK_UF

VGA_R

DVI_HPD_UF

VGA_G

TMDS_CONN_CLKP

TMDS_CONN_CLKN

VGA_B

VGA_HSYNC

TMDS_CONN_DN<2> TMDS_CONN_DN<1> TMDS_CONN_DP<2> TMDS_CONN_DP<1>

CLKLVDS_UP

CLKLVDS_UN

LVDS_U2P

LVDS_U2N

LVDS_U1P

LVDS_U1N

LVDS_U0P

LVDS_L1N LVDS_L1P

LVDS_L2N LVDS_L2P

CLKLVDS_LP

CLKLVDS_LN

LVDS_U0N

LVDS_L0N LVDS_L0P

BRIGHT_PWM_UF

INV_ON_PWM

FP_PWR_EN_L

FP_PWR_EN

BRIGHT_PWM

DDC_CLK_ISO

DVI_DDC_CLK

DVI_DDC_DATA

DVI_HPD

GPU_DVI_DDC_CLK

DVI_TURN_ON_BASE

DVI_TRUN_ON_ILIM

+5V_DDC_SLEEP

DVI_TURN_ON

DVI_DDC_CLK_UF

HPD_4V_REF

DVI_HPD_UF

COMP_DISABLE

SOFT_PWR_ON_L

HPD_BASE

COMP_ENABLE

HPD_PWR_SW

HPD_ON

HPD_PWR_SNS_EN

+3V_LCD

+3V_LCD_SW

LCD_PWREN_L

LCD_DIGON_L

FP_PWR_EN

TV_Y

GPU_Y

TV_COMP

TV_GND2

GPU_C

GPU_COMP

GPU_TV_GND1

GPU_TV_GND2

TMDS_CONN_DP<1>

TMDS_DP<1>

TMDS_DN<1>

TMDS_DP<2>

TMDS_DN<2>

TMDS_CONN_DN<0>

TMDS_CONN_DP<0>

TMDS_DP<0>

TMDS_DN<0>

TMDS_CONN_CLKP

TMDS_CONN_CLKN

TMDS_CLKN

TMDS_CLKP

VGA_BGPU_B

GPU_G

GPU_R

VGA_G

VGA_R

VGA_HSYNC

ATI_HSYNC

VGA_VSYNC

GPU_DVI_DDC_DATA

GPU_HPD

37 37

22 22

22 20

22 19

PC4/OCMP2_B/AIN4 PC3/ICAP2_B/AIN3

PC1/OCMP1_B/AIN1

PC2/MCO/AIN2

PC5/EXTCLK_A/AIN5

PC0/ICAP1_B/AINO

PB3/OCMP2_A PB2/ICAP2_A PB1/OCMP1_A PB0/ICAP1_A

PB6/SCK

PB7/SS*

PB5/MISO PB4/MOSI

PA6/SDAI

PA7/TDO

PA5/RDI

PA4/SCLI

PA1/ICCDATA

PA0/ICCCLK

PA2

PA3

VDD

RESET*

OSC2

OSC1

TEST

VSS

VCC

VSS

SDA SCL

WC*

GND

LED3

LED1 LED2

SET

V+

V-

TABLE_5_ITEM

CRITICAL BOM OPTION

TABLE_5_HEAD

PART#

DESCRIPTION

QTY

REFERENCE DESIGNATOR(S)

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

PART NUMBER

ALTERNATE FOR

PART NUMBER

BOM OPTION

REF DES

COMMENTS:

TABLE_ALT_HEAD

TABLE_ALT_ITEM

LOAD CAPACITANCE = 16PF

PULL-UP FOR I2C (IN-CIRCUIT PROGRAMMING)

INPUTS ARE 3V TOLERANT

KEYBOARD PULLUPS

3/ BBANG_JTAG_TCK (REGULAR OUTPUT)

2/ PMU_HRESET_L (3V INPUT INTO LMU)

BOOT BANGING SIGNAL DEFINITION

4/ JTAG_CPU_TMS (OPEN COLLECTOR OUTPUT - 470OHM PULLUP ON MLB) 5/ JTAG_CPU_TDI (OPEN COLLECTOR OUTPUT - 470OHM PULLUP ON MLB) 6/ JTAG_CPU_TRST_L (OPEN COLLECTOR OUTPUT - 470OHM PULLUP ON MLB)

1/ BBANG_HRESET_L (OPEN COLLECTOR OUTPUT - 10K PULLUP ON MLB)

MLB - ALS SENSOR

SHDN_L

(PMU_PWM)

NC NC

LMU/BOOTBANGER/SPIDEY

LMU PULL-DOWNS

BOOT BANGER E2PROM

SLEEP LED

XOUT

NOTE: KEEP L39 CLOSE TO C781

KB LED DRIVER

LMU

XIN

SPIDEY FLEX

C663

0.1UF

20% 10V

402

CERM

C648

27PF

CERM

50V

402

C637

0.1UF

20% 10V

402

CERM

CRITICAL

8.000M

8X4.5MM-SM

C654

27PF

50V

CERM

402

F2 E2 F3 E3 F4 D3

A2 A1 B1 B2 C3 D2 E1 F1

E4 F5 F6 E6 C6 D4 A6 A5

E5 D6 D5

U52

ST72264G2H1

BGA

OMIT

256KX8

RP53

SM1

1/16W

10K

RP53

SM1

10K

1/16W

RP52

1/16W

10K

SM1

RP52

10K

1/16W

SM1

RP53

SM1

10K

1/16W

RP53

SM1

10K

1/16W

5 6

U32

CRITICAL

BBANG

16KX8_M24128B

SOI

R533

BBANG

402

1/16W

10K

C638

0.1UF

CERM 402

10V

20%

BBANG

R532

BBANG

402

1/16W

10K

+3V_PMU

R771

100K

1/16W

402

RP43

25V

1/32W

10K

RP42

10K

1/32W

25V

U35

SOT23-6

MAX1916

CRITICAL

SN74AUC1G08

SC70-5

BBANG

NO_BBANG

1/16W

402

+3V_MAIN

U40

SOT23-6

MAX4236EUTT

CRITICAL

+3V_MAIN

R619

1/16W

402

R617

402

1/16W

120K

C675

0.22UF

20%

CERM

402

6.3V

R615

15K

1/16W

402

R618

402

1/16W

C673

0.1UF

402

CERM

10V

20%

R606

402

1/16W

R605

402

5.1M

1/16W

C670

16V 402

CERM

20%

0.01UF

2 1

PD1

BS520

CRITICAL

R40

10K

1/16W

402

BBANG

R62

BBANG

402

1/16W

10K

SN74AUC1G08

SC70-5

BBANG

R550

5% 1/16W MF 402

R39

10K

1/16W

402

BBANG

+3V_SLEEP

R552

402

1/16W

2.2K

C655

0.1UF

402

CERM

10V

20%

C636

0.1UF

20% 10V CERM 402

RP52

10K

5% 1/16W SM1

+3V_MAIN

R772

1/16W

5% MF

402

100

+5V_MAIN

R773

2.2K

1/16W

402

Q74

2N3906

R777

1/16W

402

4.7K

R776

5% 1/16W MF 402

10K

L52

SM-1

400-OHM-EMI

C828

603

CERM

50V

10%

470pF

Q75

2N7002DW

SOT-363

Q75

2N7002DW

SOT-363

R534

402

5% 1/16W MF

10K

J24

40FLH-SM1-TB

F-RT-SM

CRITICAL

+3V_MAIN

Q73

2N3906

2 1

R770

200

1/16W

402

+3V_MAIN

2 1

R582

402

1/16W

200

Q33

2N3906

2 1

L46

SM-1

400-OHM-EMI

C814

0.001UF

50V CERM

20%

402

+5V_SLEEP

L47

400-OHM-EMI

SM-1

2 1

L49

SM-1

400-OHM-EMI

C816

0.001UF

402

20% 50V CERM

+3V_PMU

2 1

R587

1/16W

402

C660

0.001UF

50V CERM

20%

402

1 2

L11

SM-1

400-OHM-EMI

C656

0.001UF

402

20%

CERM

50V

L48

400-OHM-EMI

SM-1

C815

0.001UF

50V CERM

20%

402

R568

402

1/16W

R598

402

1/16W

100K

+3V_PMU

Q35

SOT-363

2N7002DW

+3V_MAIN

R581

402

1/16W

17.4K

IC,LMU,P84341S1194 CRITICAL

U52

23 44

051-6598

ALT FOR SIWARD

197S0040197S0008

ST7_OSC1

IO_RESET_L

KBD_LED_SET

KBD_LED_EN

KBD_LED1_OUT KBD_LED2_OUT

ST7_KBD_LED_OUT

ST7_SLEEP_LED_H

SLEEP_LED_SW_L

PMU_SLEEP_LED_L

PMU_SLEEP_LED

ST7_XTAL_IN

ST7_OSC2

SLEEP_LED

SLEEP_LED_UF

SLEEP_LED_L SLEEP_LED_I

EEPROM_ADDR

INT_I2C_CLK0

INT_I2C_DATA0

ST7_ICP_SEL_PD

ST7_PB6_PD

ST7_SENSOR4_SCK_PD

ST7_SENSOR5_SCK_PU

ST7_SENSOR4_SDA_PD

ST7_SENSOR5_SDA_PU

ST7_RESET_L

ST7_ICP_SEL_PD

INT_I2C_DATA0

ST7_SENSOR4_SCK_PD

INT_I2C_CLK0

ST7_SENSOR4_SDA_PD

ST7_PB6_PD

SLEEP

BBANG_HRESET_L

SUTRO_ALS_GAIN_SW

PMU_CPU_HRESET_L BBANG_JTAG_TCK ST7_KBD_LED_OUT MLB_ALS_GAIN_SW

PMU_LID_CLOSED_L

JTAG_CPU_TMS

ST7_SLEEP_LED_H

MLB_ALS_OUT

SUTRO_ALS_OUT

MLB_ALS_OUT

MLB_ALS_OUT_FB

MLB_ALS_OP_IN

MLB_ALS_OP_COMP

MLB_ALS_GAIN_SW

GAIN_SETTING2

MLB_PHOTODIODE

NUMLOCK_LED_L

NUMLOCK_LED

SOFT_PWR_ON_L

CAPSLOCK_LED_L

CAPSLOCK_LED

PMU_LID_CLOSED_L

TPAD_RXD

TPAD_TXD

KBD_ID

KBD_X<5>

KBD_X<3>

KBD_X<4>

KBD_X<2>

KBD_X<9>

KBD_X<6> KBD_X<7> KBD_X<8>

KBD_X<0>

KBD_X<1>

KBD_OPTION_L

KBD_COMMAND_L

KBD_FUNCTION_L KBD_CONTROL_L KBD_SHIFT_L

MAXBUS_SLEEP

BBANG_TCK_EN

BBANG_JTAG_TCK

JTAG_CPU_TCK

BBANG_HRESET_L

CPU_HRESET_L

PMU_CPU_HRESET_L

KBD_X<6>

KBD_X<4> KBD_NUMLOCK_LED

KBD_X<3> KBD_X<2> KBD_X<1>

KBD_Y<1> KBD_Y<0> KBD_X<9>

KBD_Y<2>

KBD_Y<3>

KBD_Y<5>

KBD_Y<6>

KBD_Y<7>

KBD_ID

KBD_CAPSLOCK_LED

KBD_FUNCTION_L

KBD_COMMAND_L

KBD_OPTION_L

KBD_SHIFT_L

KBD_X<0>

PWR_BUTTON_L

KBD_LED1_OUT

LID_CLOSED_L

TPAD_F_RXD

TPAD_F_TXD

KBD_LED2_OUT

MAXBUS_SLEEP

EEPROM_WP_PD

ST7_SENSOR5_SDA_PU

ST7_SENSOR5_SCK_PU

JTAG_CPU_TRST_L

JTAG_CPU_TDI

+3V_HALL_EFFECT

KBD_X<5>

KBD_X<8>

+5V_TPAD_SLEEP

KBD_CONTROL_L

KBD_Y<4>

KBD_X<7>

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

WIRELESS INTERFACE

HARD DRIVE INTERFACE (UATA100)

PLACE PULLUP RESISTORS CLOSE TO INTREPID

OPTICAL DRIVE INTERFACE (EIDE)

IOCHRDY - UATA100 REQUIRES PULL-UP TO 3.3V

PLACE SERIES R CLOSE TO INTERPID

NC NC

PLACE TERMINATORS NEAR INTREPID

EIDE SERIES TERMINATION

BLUETOOTH/LEFT-SIDE USB

ANY SEQUENCING REQUIREMENT BETWEEN

+5V_HD_SLEEP AND +3V_SLEEP?

INTERNAL I/O CONNECTORS

R63

10K

1/16W

402

R74

402

1/16W

5% MF

402

5% MF

1/16W

10K

R68

402

1/16W

R35

402

1/16W

R613

1/16W

402

R75

1/16W

5% MF

402

+5V_SLEEP

R411

NO STUFF

10K

5% 1/16W MF 402

R442

402

1/16W

10K

R458

402

1/16W

10K

49 48 47 46 45 44 43 42 41 40

39 38 37 36 35 34 33 32 31 30

29 28 27 2625

J10

M-ST-SM1

CRITICAL

R452

NO STUFF

1/16W

402

100K

R441

402

1/16W

20K

R36

402

1/16W

10K

R32

1/16W

402

R76

1/16W

402

R81

1/16W

402

R612

10K

402

1/16W MF

R30

1/16W

402

R116

1/16W

402

R95

1/16W

402

R31

402

1/16W

R69

402

1/16W

+3V_SLEEP

R94

1/16W

10K

402

R93

1/16W

402

C86

10PF

402

5% 50V CERM

+3V_SLEEP

RP2

SM1

1/16W

RP9

1/16W

SM1

RP9

1/16W

SM1

RP9

1/16W

SM1

RP2

1/16W

SM1

RP2

1/16W

SM1

RP9

1/16W

SM1

RP2

1/16W

SM1

RP3

1/16W

SM1

RP4

1/16W

SM1

RP3

1/16W

SM1

RP3

1/16W

SM1

RP4

1/16W

SM1

RP5

1/16W

SM1

RP4

1/16W

SM1

RP5

1/16W

SM1

RP5

1/16W

SM1

RP4

1/16W

SM1

RP3

1/16W

SM1

RP5

1/16W

SM1

RP50

SM1

1/16W

RP13

SM1

1/16W

RP13

SM1

1/16W

RP50

1/16W

SM1

RP49

SM1

1/16W

RP10

SM1

1/16W

RP13

SM1

1/16W

RP10

SM1

1/16W

RP50

SM1

1/16W

RP13

SM1

1/16W

RP49

SM1

1/16W

RP50

SM1

1/16W

RP10

1/16W

SM1

RP49

SM1

1/16W

RP10

SM1

1/16W

RP11

SM1

1/16W

RP11

SM1

1/16W

RP49

SM1

1/16W

RP11

SM1

1/16W

RP11

SM1

1/16W

R745

1/16W

402

+3V_MAIN+5V_MAIN

R64

15K

5% 1/16W MF 402

R71

402

1/16W

15K

49 48 47 46 45 44 43 42 41 40

39 38 37 36 35 34 33 32 31 30

29 28 27 2625

J13

M-ST-SM1

CRITICAL

54550-1490

F-RT-SM

CRITICAL

R730

402

1/16W

10K

+3V_SLEEP

R602

3V_HD_LOGIC

402

1/16W

R601

402

1/16W

5V_HD_LOGIC

83 82

80879

78 77

76 75

74 73

72 71

68 67

66 65

64 63

62 61

58 57

56 55

54 53

52 51

48 47

46 45

44 43

42 41

38 37

36 35

34 33

32 31

28 27

26 25

24 23

22 21

18 17

16 15

14 13

12 11

J20

F-ST-SM1

QT510806-L111

CRITICAL

R603

20K

5% MF

1/16W

402

R101

1/16W

10K

402

051-6598

4424

EIDE_OPTICAL_DATA<10>

BT_USB_DM

HD_ADDR<1>

PCI_AD<9>

PCI_AD<29>

PCI_AD<31>

MAIN_RESET_L

CLK33M_AIRPORT

AIRPORT_PCI_INT_L

PCI_AD<30>

EIDE_RST_L

EIDE_OPTICAL_RST_L

EIDE_INT

EIDE_OPTICAL_INT

EIDE_WR_L

EIDE_OPTICAL_WR_L

EIDE_IOCHRDY

EIDE_OPTICAL_IOCHRDY

EIDE_RD_L

EIDE_OPTICAL_RD_L

EIDE_CS1_L

EIDE_OPTICAL_CS1_L

EIDE_DMACK_L

EIDE_OPTICAL_DMAACK_L

EIDE_DMARQ

EIDE_OPTICAL_DMA_RQ

EIDE_DATA<7>

EIDE_OPTICAL_ADDR<0>

EIDE_ADDR<0>

EIDE_OPTICAL_ADDR<1>

EIDE_ADDR<1>

EIDE_OPTICAL_DATA<5>

EIDE_DATA<5>

EIDE_OPTICAL_ADDR<2>

EIDE_ADDR<2>

EIDE_OPTICAL_CS0_L

EIDE_CS0_L

EIDE_OPTICAL_DATA<7>

EIDE_OPTICAL_DATA<3>

EIDE_DATA<3>

EIDE_OPTICAL_DATA<4>

EIDE_DATA<4>

EIDE_OPTICAL_DATA<6>

EIDE_DATA<6>

EIDE_OPTICAL_DATA<1>

EIDE_DATA<1>

EIDE_OPTICAL_DATA<15>

EIDE_DATA<15>

EIDE_OPTICAL_DATA<0>

EIDE_DATA<0>

EIDE_OPTICAL_DATA<2>

EIDE_DATA<2>

EIDE_OPTICAL_DATA<11>

EIDE_DATA<11>

EIDE_OPTICAL_DATA<14>

EIDE_DATA<14>

EIDE_OPTICAL_DATA<13>

EIDE_DATA<13>

EIDE_OPTICAL_DATA<12>

EIDE_DATA<12>

EIDE_DATA<10>

EIDE_OPTICAL_DATA<9>

EIDE_DATA<9>

EIDE_OPTICAL_DATA<8>

EIDE_DATA<8>

AIRPORT_CLKRUN_L

BT_USB_DP

SUTRO_ALS_OUT NEC_LEFT_USB_OVERCURRENT SUTRO_ALS_GAIN_SW

LEFT_USB_DM

HD_INTRQ

HD_DIOW_L

HD_CS1_L

HD_ADDR<2>

HD_IOCHRDY

HD_DATA<11>

HD_DATA<9>

HD_DATA<8>

HD_DATA<10>

HD_DATA<12> HD_DATA<13>

HD_DATA<14> HD_DATA<15>

HD_DMARQ

HD_DATA<1> HD_DATA<0>

HD_DATA<3> HD_DATA<2>

HD_DATA<5>

HD_CS1_LUIDE_CS1_L

HD_IOCHRDY

UIDE_RST_L

UIDE_DMACK_L

PCI_IRDY_L

UIDE_DATA<7>

PCI_AD<3>

ROM_ONBOARD_CS_L

PCI_AD<5>

PCI_AD<1> ROM_CS_L

PCI_AD<14>

PCI_CBE<1>

PCI_AD<12> PCI_AD<10> ROM_RW_L PCI_AD<8> PCI_AD<7>

PCI_AD<19>

PCI_AD<21>

PCI_AD<23>

PCI_AD<17>

PCI_CBE<2>

AIRPORT_PCI_REQ_L

PCI_AD<27> PCI_AD<25>

PCI_CBE<3>

EIDE_OPTICAL_CS0_L

EIDE_OPTICAL_ADDR<1>

EIDE_OPTICAL_IOCHRDY

EIDE_OPTICAL_WR_L

EIDE_OPTICAL_DATA<0>

EIDE_OPTICAL_DATA<1>

EIDE_OPTICAL_DATA<2>

EIDE_OPTICAL_DATA<3>

EIDE_OPTICAL_ADDR<0>

HD_DMACK_L

HD_DIOW_L

UIDE_DIOW_L

HD_RESET_L

HD_DIOR_L

UIDE_DIOR_L

UIDE_IOCHRDY

UIDE_ADDR<2>

UIDE_DATA<13>

UIDE_ADDR<1>

UIDE_DATA<15>

UIDE_DATA<12>

UIDE_ADDR<0>

UIDE_DATA<10>

UIDE_DATA<8>

UIDE_DATA<4>

UIDE_CS0_L

UIDE_DATA<14>

UIDE_DATA<9>

UIDE_DATA<6>

UIDE_DATA<3>

UIDE_DATA<2>

UIDE_DATA<11>

UIDE_DATA<1>

UIDE_DATA<0>

UIDE_DATA<5>

HD_DATA<3>

HD_DATA<7>

HD_DATA<2>

HD_DATA<8>

HD_DATA<4>

HD_ADDR<0>

HD_DATA<10>

HD_DATA<13>

HD_ADDR<1>

HD_ADDR<2>

HD_DATA<15>

HD_DATA<12>

HD_DATA<6>

HD_DATA<9>

HD_DATA<14>

HD_CS0_L

HD_DATA<5>

HD_DATA<0>

HD_DATA<1>

HD_DATA<11>

PCI_AD<18>

HD_RESET_L

HD_DATA<7> HD_DATA<6>

HD_DIOR_L

HD_DMACK_L

HD_ADDR<0> HD_CS0_L

HD_DATA<4>

+5V_HD_SLEEP

+HD_LOGIC_SLEEP

EIDE_OPTICAL_DATA<11>

EIDE_OPTICAL_CS1_L

EIDE_OPTICAL_ADDR<2>

EIDE_OPTICAL_DATA<10>

EIDE_OPTICAL_DATA<9>

EIDE_OPTICAL_DATA<8>

LEFT_USB_DP

NEC_LEFT_USB_PWREN

EIDE_OPTICAL_RST_L

EIDE_OPTICAL_DATA<7> EIDE_OPTICAL_DATA<6> EIDE_OPTICAL_DATA<5> EIDE_OPTICAL_DATA<4>

EIDE_OPTICAL_INT

EIDE_OPTICAL_DMAACK_L

EIDE_OPTICAL_RD_L

EIDE_OPTICAL_DMA_RQ

EIDE_OPTICAL_DATA<15>

EIDE_OPTICAL_DATA<14>

EIDE_OPTICAL_DATA<13>

EIDE_OPTICAL_DATA<12>

AIRPORT_PCI_GNT_L

AIRPORT_PME_L_TP

PCI_AD<28> PCI_AD<26> PCI_AD<24>

AIRPORT_IDSEL

PCI_AD<22> PCI_AD<20>

PCI_PAR PCI_AD<18> PCI_AD<16>

PCI_FRAME_L

PCI_TRDY_L PCI_STOP_L

PCI_DEVSEL_L

PCI_AD<15> PCI_AD<13> PCI_AD<11>

PCI_CBE<0>

ROM_OE_L

PCI_AD<6>

PCI_AD<4> PCI_AD<2> PCI_AD<0>

RF_DISABLE_L_SPN

39 39

37 37

13 24

24 13

24 24

GND

PWM1/

PWM2/

ADR SELECT/

TACH4/

ADR ENABLE#

PWM3/

THERM#

TACH3

TACH2

SMBALERT#

TACH1

XTO

+2.5V/

VCC

SMBALERT# SDA SCL

D1+ D1-

D2+ D2-

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

SOUND BOARD (SOUSAPHONE)

KEEP STUFFING RESISTORS CLOSE TO ADT7460 CONTROLLER

LEFT FAN (CPU)

PLACE CLOSE

TO CONNECTOR

SUPPORTS BOTH THE LAST DASH AND Q52 SOFT MODEM

RIGHT FAN (GPU)

SERIAL DEBUG INTERFACE

DEBUG POWER BUTTON

FAN/MODEM/SOUND/SLEEP LED/DEBUG

PLACE CLOSE

TO CONNECTOR

MODEM

DEBUG JUMPERS

ALTERNATE2

ALTERNATE1

MAIN2

MAIN1

PLACE CLOSE TO CPU

PLACE IN BETWEEN 3/5/1.5/2.5V PWR SUPPLY

PLACE CAPS AS CLOSE TO THERMISTORS AS POSSIBLE

PLACE UNDERNEATH UPPER RAM

AUDIO - SNAPPER

FAN CONTROLLER

SND - INTREPID

THERM ISOLATION

FAN INTERFACE

PLACE CLOSE TO BATTERY CHARGER/VCORE

PLACE XW9 CLOSE TO 5V SWITCHER (U27)

CAPS FOR EMI EXPERIMENTATION ONLY

KEEP STUFFING RESISTORS CLOSE TO ADT7460 CONTROLLER

C711

CERM

10V

0.1UF

20%

402

R623

1/16W MF

402

10K

+3V_MAIN

+5V_SLEEP

Q39

2N3904

+5V_SLEEP

Q66

2N3904

R679

1/16W

402

10K

SM-2MT

CRITICAL

SM-2MT

CRITICAL

+5V_MAIN +3V_MAIN

C469

805

CERM

6.3V

20%

10UF

C478

CERM

10V 402

20%

0.1UF

NO STUFF

R405

10K

1/16W

402

C767

CERM 805

6.3V

20%

10UF

C513

0.1UF

NO STUFF

20% 10V CERM 402

Q62

NO STUFF

2N3904

Q47

2N3904

NO STUFF

R719

5% MF

1/16W

402

R725

402

1/16W

R713

402

1/16W

R716

1/16W

402

R723

402

1/16W

NO STUFF

R726

1/16W

402

NO STUFF

R710

NO STUFF

1/16W

402

R717

NO STUFF

1/16W

402

+5V_MAIN

9 8 7 65

J16

SERIAL_DEBUG

CRITICAL

M-ST-5087

R527

NO STUFF

603

1/16W

1615

1413

1211

CRITICAL

QT510166-L010

F-ST-SM1

R537

NO STUFF

603

1/16W

R553

NO STUFF

603

1/16W

3 6

521

Q36

TSOP

SI3446DV

3 6

521

Q37

TSOP

SI3446DV

C135

CERM

10V

20%

1206

4.7UF

C134

4.7UF

1206

20% 10V CERM

J12

CRITICAL

QT510306-L111

F-ST-SM1

+5V_MAIN

+3V_MAIN

XW9

Q26

2N7002DW

SOT-363

Q26

SOT-363

2N7002DW

RP44

100K

5% SM1

1/16W

+5V_MAIN

RP44

SM1

100K

1/16W

Q31

SOT-363

2N7002DW

Q31

SOT-363

2N7002DW

RP44

SM1

1/16W

100K

RP44

100K

SM1

1/16W

CRITICAL

ADT7460

QSOP

R42

10K

402

1/16W

Q78

SOT-363

2N7002DW

Q78

2N7002DW

SOT-363

+5V_SLEEP

R293

402

1/16W

10K

R295

402

1/16W

10K

+3V_MAIN

+5V_SLEEP

R689

100K

1/16W 402

R695

402

1/16W

10K

R692

402

10K

1/16W

C895

402

CERM

NO STUFF

0.01UF

20% 16V

C899

402

CERM

16V

20%

0.01UF

NO STUFF

C896

20%

0.01UF

16V CERM 402

NO STUFF

C897

402

NO STUFF

20% CERM

16V

0.01UF

C898

0.01UF

20% 16V CERM 402

NO STUFF

L82

0402

FERR-220-OHM

L77

FERR-220-OHM

0402

L80

FERR-220-OHM

0402

L81

FERR-220-OHM

0402

INT_AUDIO_TO_SND_F

L76

0402

FERR-220-OHM

L78

FERR-220-OHM

0402

C900

0.01UF

CERM 402

16V

20%

NO STUFF

L79

FERR-220-OHM

0402

C901

402

CERM

16V

20%

0.01UF

NO STUFF

Q87

2N7002DW

SOT-363

Q87

SOT-363

2N7002DW

R811

5% MF

402

1/16W

100K

R812

402

100K

1/16W

+3V_MAIN

R813

402

100K

1/16W

C903

0.1UF

402

CERM

10V

20%

C904

1UF

603

10V

20% CERM

R814

402

1/16W

C681

0.001UF

20% 50V CERM 402

C668

0.001UF

20% 50V CERM 402

C678

0.001UF

20% 50V CERM 402

NO STUFF

C651

0.001UF

20% 50V CERM 402

NO STUFF

C690

NO STUFF

402

CERM

50V

20%

0.001UF

C846

NO STUFF

402

CERM

50V

20%

0.001UF

C905

NO STUFF

0.001UF

20% 50V CERM 402

C688

NO STUFF

20% 50V

0.001UF

402

CERM

R628

NO STUFF

1/16W

402

R620

402

1/16W

NO STUFF

4425

051-6598

THERM1_DP

CPU_THERM_DP

CPU_THERM_DM

THERM1_DM

THERM1_DP

THERM1_A_DP

THERM1_A_DM

SND_SYNC

SND_SYNC_F

SND_TO_AUDIO_F

THERM1_DM

THERM2_DM

THERM1_DP

MODEM_USB_DM

SND_HW_RESET_L_F

SND_AMP_MUTE_F

INT_I2C_DATA2

SND_LIN_SENSE_L

MOD_DTO

INT_I2C_DATA2

SND_SCLK_F

THERM2_DP

ADT7460_THERM

THERM_INV

THERM_L_OC

+3V_PMU_AVCC

THERM1_A_DM

THERM1_A_DP

SND_CLKOUT_F

SUPPLY_M_DM

THERM2_A_DP

THERM2_A_DM

CPU_M_DP

CPU_M_DM

SUPPLY_M_DP

SLEEP_LED

SLEEP

SND_HP_SENSE_L

INT_AUDIO_TO_SND_F

INT_I2C_CLK2

THERM2_A_DM

THERM2_DM

THERM2_A_DP

THERM2_DP

SUPPLY_M_DM

THERM2_DM

SUPPLY_M_DP

THERM2_DP

CPU_M_DM

THERM1_DM

CPU_M_DP

FANL_PWM

INT_I2C_CLK1

INT_I2C_DATA1

ADT7460_VCORE_MON

ADT7460_ADR_EN_L

PMU_RESET_BUTTON_L

PMU_NMI_BUTTON_L

COMM_RESET_L

INT_MOD_DTI

MOD_SYNC

MODEM_USB_DP

MOD_CLKOUT

COMM_SHUTDOWN

MOD_BITCLK

SND_AMP_MUTE_L

PWR_BUTTON_L

COMM_DTR_L COMM_RTS_L

COMM_RXD

COMM_TXD_L COMM_TRXC

COMM_GPIO_L

AMP_CONTROL

SND_HP_MUTE_L

AMP_CONTROL

SND_AMP_MUTE

SND_HP_MUTE_INV

SND_HP_MUTE

COMM_RING_DET_L

FANR_PWM

FANR_TACH

FANR_GND

SND_CLKOUT

SND_HW_RESET_L_F

SND_SCLK

SND_SCLK_F

SND_HW_RESET_L

SND_AMP_MUTE

SND_TO_AUDIO

SND_SYNC_F

SND_HP_MUTE_INV

SND_TO_AUDIO_F

SND_CLKOUT_F

INT_PU_RESET_L

FANL_PWM

FANL_TACH

FANL_GND

INT_I2C_CLK2

ADT7460_THERM

ADT7460_VCC

ADT7460_FAN1_PWM

FANL_TACH

ADT7460_FAN2_PWM

FANR_TACH

THERM1_DP

INT_AUDIO_TO_SND

SND_AGND

SND_AMP_MUTE_F

39 35

37 37

39 25

37 37

39 25

25 25

14 25

14 14

25 25

14 25

AVDD

VDD

VDD_PCI

AD3 AD4 AD5

AD2

AD0 AD1

VSS

AD6 AD7

AD17

AD16

AD15

AD8 AD9 AD10 AD11 AD12 AD13 AD14

AD27

AD26

AD25

AD18 AD19 AD20 AD21 AD22 AD23 AD24

AD28 AD29 AD30 AD31

CBE0 CBE1 CBE2 CBE3

PAR

PERR

GNT

DEVSEL

IDSEL

FRAME IRDY TRDY STOP

REQ

SERR

CRUN

SMI

VBBRST

VCCRST

INTA INTB INTC PCLK

PME

LEGC

XT2

DM1 DP1

DM2 DP2

DM3 DP3

RSDM4

RSDM2

RSDP2

RSDM3

RSDP3

RSDP1

XT1/SCLK

RSDM1

DM4 DP4

DM5 DP5

RREF

OCI1 OCI2

OCI4

OCI3

OCI5

RSDP4

RSDM5

RSDP5

PPON1

NC1 NC2

SMC

TEB

NTEST1

PPON2 PPON3 PPON4 PPON5

AVSS(R)

AVSS

SRCLK SRDTA SRMOD

NANDTEST

AMC

TEST

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

PART NUMBER

ALTERNATE FOR

PART NUMBER

BOM OPTION

REF DES

COMMENTS:

TABLE_ALT_HEAD

TABLE_ALT_ITEM

Y7 LOAD CAPACITANCE IS 16PF

HAS DEDICATED PULL-UP

LEFT PORT

NEED PULL-UP RESISTORS IN CASE USB 1.0 IS USED FOR PORT POWER

Tie to GND at ball N11

RIGHT PORT

Low/Full/High Speed (External)

IPD

INTREPID USB CONSTRAINTS

IPD

SERR_L AND PERR_L

FOR BOTH CBUS AND USB2

SUTRO CONNECTOR

PLACE NEAR J12

BUBBA CONNECTOR

Low/Full/High Speed (External)

IPD

OUT OUT

OUT

OUT OUT

OD OD OD OD

(PCI_AD<27>)

USB 2.0

(NEC_USB_DAM) (NEC_USB_DAP)

(NEC_USB_DBM) (NEC_USB_DBP)

facilitate NAND-tree testing

Series Rpaks required to

PLACE NEAR J3

R784

402

1/16W

NEC_USB

+3V_MAIN

R796

NEC_USB

5% MF

603

1/16W

R794

NEC_USB

402

1/16W

9.09K

NEC_AVSS_F

L54

FERR-EMI-100-OHM

NEC_USB

C649

5% 50V CERM

NEC_USB

402

27PF

NEC_USB

30.0000M

CRITICAL

8X4.5MM-SM

C657

402

NEC_USB

CERM

50V

27PF

R590

NEC_USB

402

1/16W

100

N2B2A2

B14

H14

N14

P10

F11

J11

D12

H12

L12

M11

B13

N13

C8M4H3

L13

N8E2A3

A12

A13

P12

G12

D13

F13

H13

J13

C14

E14

G14

J12

K13

E13

F12

H11

K14

M14

P11

C10

C11

A11

C12

J4 B9

A10

B10

B11

B12

M10

C13

E12

G13

J14

L14

D14

F14

G11

K12

M13

N11

M12

P13

N12

N10

U39

RSDP5_TP

RSDM5_TP

RSDP4_TP

RSDM4_TP

RSDP3_TP

NEC_USB

NEC_UPD720101_USB2

FBGA

CRITICAL

R795

NEC_USB

402

R792

402

NEC_USB

R791

NEC_USB

402

R790

NEC_USB

402

+3V_MAIN

R600

1/16W

15K

402

NEC_USB

C665

0.1uF

20% 10V CERM 402

NEC_USB

R591

1/16W

15K

402

NEC_USB

C661

NEC_USB

0.1uF

20%

402

CERM

10V

RP45

SM1

1/16W

10K

NEC_USB

RP45

SM1

10K

5% 1/16W

NEC_USB

RP45

NEC_USB

1/16W

10K

SM1

RP45

SM1

1/16W

10K

NEC_USB

RP54

1/16W

SM1

NEC_USB

RP55

1/16W

SM1

NEC_USB

R84

402

1/16W

NEC_USB

R78

INTREPID_USB

1/16W

402

R96

1/16W

402

INTREPID_USB

R83

NEC_USB

1/16W

402

R545

NEC_USB

1/16W

402

R554

INTREPID_USB

402

1/16W

R530

402

1/16W

INTREPID_USB

R540

402

1/16W

NEC_USB

R586

NEC_USB

1/16W

10K

402

RP52

SM1

1/16W

10K

+3V_MAIN

R783

NEC_USB

402

1/16W

10K

R789

NEC_USB

1.5K

5% 1/16W MF 402

R793

402

1/16W

1.5K

NEC_USB

R531

402

10K

5% 1/16W MF

INTREPID_USB

R56

10K

5% MF

INTREPID_USB

402

1/16W

R286

1/16W

603

NEC_USB

C841

NEC_USB

20% 10V CERM 402

0.1uF

C836

0.1uF

20% 10V CERM

NEC_USB

402

C843

NEC_USB

CERM

10V

20%

402

0.1uF

C838

NEC_USB

402

CERM

10V

20%

0.1uF

C834

NEC_USB

20% 10V CERM 402

0.1uF

C829

NEC_USB

20% 10V CERM 402

0.1uF

C840

NEC_USB

402

CERM

10V

20%

0.1uF

C842

NEC_USB

20% 10V CERM 402

0.1uF

C837

0.1uF

20% 10V CERM 402

NEC_USB

C830

0.1uF

NEC_USB

CERM

10V

20%

402

C833

NEC_USB

20% 10V CERM 402

0.1uF

C845

10uF

20%

6.3V CERM 805

NEC_USB

R551

4.7K

NEC_USB

1/16W

402

C667

10uF

20%

6.3V CERM 805

NEC_USB

C844

0.1uF

20% 10V CERM 402

NEC_USB

C839

0.1uF

402

CERM

10V

20%

NEC_USB

051-6598

4426

ALT FOR SIWARD

NEC_USB

197S0038197S0608

5 MIL SPACING

USB_D1

USB_D1P

NEC_OCI<1>

NEC_LEFT_USB_OVERCURRENT

NEC_OCI<2>

NEC_RIGHT_USB_OVERCURRENT

NEC_USB_RSDM2

NEC_USB_RSDM1

CLK33M_USB2

NEC_CRUN_L

NEC_IO_RESET_L NEC_PME_L NEC_MAIN_RESET_L

MAIN_RESET_L

PMU_PME_L

IO_RESET_L

NEC_PME_L NEC_MAIN_RESET_L

NEC_IO_RESET_L

NEC_PCI_INTC_L

NEC_PPON5_TP

NEC_LEGC

NEC_PCI_INTB_L

NEC_PCI_INTA_LUSB2_PCI_INT_L

NEC_PCI_INTC_L

NEC_PCI_INTB_L

NEC_PCI_INTA_L

PCI_AD<27>

NEC_OCI<1> NEC_OCI<2>

NEC_NANDTESTOUT_TP

NEC_SMI_L_TP

NEC_PCI_SERR_L

NEC_PCI_PERR_L

USB2_PCI_GNT_L

USB2_PCI_REQ_L

PCI_DEVSEL_L

PCI_STOP_L

PCI_TRDY_L

PCI_IRDY_L

PCI_FRAME_L

PCI_PAR

PCI_CBE<3>

PCI_CBE<2>

PCI_CBE<1>

PCI_CBE<0>

PCI_AD<31>

PCI_AD<30>

PCI_AD<28> PCI_AD<29>

PCI_AD<25> PCI_AD<26>

PCI_AD<24>

PCI_AD<23>

PCI_AD<20>

PCI_AD<22>

PCI_AD<21>

PCI_AD<19>

PCI_AD<18>

PCI_AD<17>

PCI_AD<16>

PCI_AD<15>

PCI_AD<14>

PCI_AD<13>

PCI_AD<12>

PCI_AD<11>

PCI_AD<10>

PCI_AD<9>

PCI_AD<8>

PCI_AD<7>

PCI_AD<6>

PCI_AD<5>

PCI_AD<2> PCI_AD<3> PCI_AD<4>

PCI_AD<0> PCI_AD<1>

NEC_IDSEL

NEC_XT1

NEC_AVDD

NEC_XT2

NEC_AMC_TP

NEC_PPON3_TP

NEC_USB_DAM LEFT_USB_DM

LEFT_USB_DPNEC_USB_DAP

RIGHT_USB_DM

NEC_USB_DBM

NEC_USB_DBP

NEC_PCI_SERR_L

NEC_PCI_PERR_L

NEC_USB_DAP

NEC_USB_RSDP1

NEC_USB_DAM

NEC_USB_DBM

NEC_USB_DBP

NEC_USB_RSDP2

5 MIL SPACING

USB_DC

USB_DCP

5 MIL SPACING

USB_DC

USB_DCM

USB_DAP

USB_DA

5 MIL SPACING

USB_DAM

USB_DA

5 MIL SPACING

USB_D2

USB_D2P

5 MIL SPACING

USB_D2

USB_D2M

USB_D1P

USB_D1

USB_D1M

5 MIL SPACING

USB_D1M

+3V_NEC_VDD

NEC_AVSS_F

+3V_NEC_VDD

RIGHT_USB_DP

NEC_PPON4_TP

RSDM3_TP

NTEST1_TP

TEB_TP

TEST_TP

SRCLK_TP

SRMOD_TP

NEC_NANDTESTEN_TP

SMC_TP

NEC_NC1_TP NEC_NC2_TP

NEC_LEFT_USB_PWREN

NEC_RIGHT_USB_PWREN

NEC_OCI<5>

NEC_OCI<4>

NEC_OCI<3>

NEC_RREF

NEC_XT2_R

39 30

37 37

26 24

26 32

26 14

26 24

24 26

32 26

VFB

MODE

RUN

VIN

GND

TX_EN

TXD7

TXD6

TXD5

TXD4

TX_ER

GTX_CLK

125CLK

RX_CLK

TXD0

TXD3

TXD2

TXD1

TX_CLK

VDDOX

VDDOH

VDDO

DVDD

CTRL10

MDC

CRS COL

RX_ER

RX_DV

RXD7

RXD1 RXD2 RXD3 RXD4 RXD5 RXD6

RXD0

MDI1MDI2+ MDI2MDI3+

MDI1+

MDI0-

MDI0+

AVDD

VSSC

XTAL2

HSDAC-

HSDAC+

S_CLK-

S_CLK+

XTAL1

S_OUT-

S_OUT+

S_IN-

S_IN+

COMA

RESET

INT+

INT-/

MDIO

LED_LINK1000

LED_LINK100

GND

SEL_2.5V

SEL_OSC

TRST

RSET

TDO

TDI

TCK TMS

CONFIG5 CONFIG6

CONFIG4

CONFIG0 CONFIG1 CONFIG2 CONFIG3

LED_TX

LED_RX

LED_DUPLEX

LED_LINK10

MDI3-

PART NUMBER

ALTERNATE FOR

PART NUMBER

BOM OPTION

REF DES

COMMENTS:

TABLE_ALT_HEAD

TABLE_ALT_ITEM

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

TABLE_ALT_ITEM

PUT CRYSTAL CIRCUIT CLOSE TO PHY

ASLEEP ON BATTERY (SAVES POWER)

PLACES PHY IN "COMA" MODE WHEN

SEL_BDT

001

PLACE CLOSE TO

Short shielded RJ-45

R2EQV = R2A||R2B

R2A

R2B

VOUT = 0.8V*(1+R2EQV/R1)

MARVELL 88E1111

Ethernet routing priority:

MDI pairs and all RJ45 pairs

1. Decoupling caps

3. RX SERIES TERMINATION - LOCATE NEAR PHY

2. TX SERIES TERMINATION - LOCATE NEAR LINK

Sandwich each RJ54 pair between chassis grounds

Must maintain 50-ohms trace impedance on all

All differential signals should be close,

via count, and short if possible

parallel, matched lengths, with minimum

10/100/1000 ETHERNET

PLACE RESISTORS CLOSE TO PHY

NC NC

PLACE ALL SERIES RES CLOSE TO PHY

(000) (111) (110) (111) (101)

(000)

SEE CONFIG TABLES

(BELOW)

(000)

Y3’S LOAD CAPACITANCE IS 20PF

PLACE CAPS (IN ORDER) ON PINS 5, 21/26, 48/52, 66/72, 88, 96

PLACE CAPS (IN ORDER) ON PINS 1, 6, 10/15, 57/62, 67/71, 85

PLACE CAPS (IN ORDER) ON PINS 32/35, 36/40, 45 & 78

CONFIG DEFINITIONS

101

110

100

010

011

000

111

BIT[2:0]

LED_LINK10

LED_DUPLEX LED_RX LED_TX VSS

VDDO

LED_LINK100 LED_LINK1000

PHYADR[0] PHYADR[3]

BIT[0]

ANEG[1] DIS_125 MODE[0]

75/50 OHM

MODE[3]

BIT[1]

INT_POL

ENA_XC

ANEG[2]

MODE[1]

CONFIG INPUTS

DIS_SLEEP

PHYADR[4]

PHYADR[1]

BIT[2]

PHYADR[2] ENA_PAUSE

ANEG[0]

ANEG[3]

MODE[2] DIS_FC

CONFIG<6>

CONFIG<3>

CONFIG<5>

CONFIG<4>

CONFIG<0> CONFIG<1> CONFIG<2>

PLACE CAPS AT TRANSFORMER PINS 1, 4, 7 & 10

ETHERNET CONNECTOR

R372

49.9

1/16W

402

R381

1/16W 402

49.9

R346

1/16W

49.9

402

R355

402

1/16W

49.9

C555

33pF

50V

CERM

402

C491

33pF

402

50V

CERM

R353

1/16W

402

CHGND1

8X4.5MM-SM

CRITICAL

25.0000M

R345

402

1/16W

10K

CHGND1

C457

10% 3KV CERM 1808

100pF

R413

49.9

1% MF

402

1/16W

R404

1/16W

49.9

402

R428

402

1/16W

49.9

R406

49.9

1% 1/16W MF 402

CRITICAL

XFR-ENET-1000BT

C454

0.01UF

20% 16V CERM 402

C493

0.01UF

402

CERM

16V

20%

C505

0.01UF

402

CERM

16V

20%

C520

0.1UF

402

CERM

10V

20%

C506

20% 10V CERM 402

0.1UF

C466

0.1UF

20% 10V CERM 402

C488

0.1UF

402

CERM

10V

20%

R393

49.9

402

NO STUFF

1/16W

R403

49.9

1/16W

402

NO STUFF

R370

402

1/16W

R335

402

1/16W

10K

R735

402

1/16W

R733

402

1/16W

R382

5% 1/16W MF 402

R347

402

1/16W

R344

1/16W

402

R354

1/16W

1.5K

402

R380

4.99K

402

1/16W

C755

10V

20%

2.2uF

CERM

805

R343

402

1/16W

C504

0.01UF

402

20% CERM

16V

C497

0.1UF

CERM

20% 10V

402

C476

0.01UF

16V CERM

20%

402

C487

0.1UF

402

10V

20% CERM

C754

10uF

6.3V

20%

805

CERM

C501

0.1UF

CERM

20% 10V

402

C503

0.01UF

402

20% CERM

16V

C453

0.1UF

CERM

20% 10V

402

C472

0.01UF

16V CERM

20%

402

C464

0.1UF

402

10V

20% CERM

C496

10uF

CERM 805

20%

6.3V

L34

FERR-EMI-600-OHM

+2_5V_MAIN

U14

CRITICAL

LTC3405

SOT23-6

CRITICAL

SM1

3.3uH

R334

665K

1/16W MF 402

C471

50V

CERM

402

22pF

R361

49.9K

402

1/16W

R362

182K

402

1/16W

R333

NO STUFF

1/16W

402

C502

0.01UF

16V CERM

20%

402

C517

0.1UF

402

10V

20% CERM

C511

0.01UF

402

20% CERM

16V

C492

0.1UF

CERM

20% 10V

402

C475

0.01UF

402

20% CERM

16V

C465

0.1UF

CERM

20% 10V

402

R319

402

1/16W

3 1

1N914

SOT23

+3V_MAIN

C486

6.3V 805

CERM

20%

10uF

C442

20%

CERM

805

6.3V

10uF

Q15

2N7002DW

SOT-363

Q15

SOT-363

2N7002DW

56 13

24 43

U49

88E1111

BCC

CRITICAL

R435

NO STUFF

1/16W

402

20K

R427

402

1/16W

J17

RJ45

RT-TH

CRITICAL

R371

402

1/16W

10K

C477

0.01UF

20% 16V CERM 402

R465

5% 1/16W MF 603

CHGND1

R438

805

1/10W

NO STUFF

R633

402

1/16W

10K

+3V_MAIN

197S0603 197S0037

ALT FOR SIWARD

ALTERNATE

27 44

051-6598

197S0037

ALTERNATE

197S0703 Y3

JTAG_ASIC_TDI

ENET_HSDACM

ENET_VSSC

ENET_HSDACP

+2_5V_MARVELL_AVDD

ENET_COMA

RJ45_DN<0>

LTC3405_SW

ENET_CTAP_CHGND

+1_0V_MARVELL

RJ45_DN<3>

RJ45_DP<3>

RJ45_DN<1>

RJ45_DN<2>

RJ45_DP<2>

RJ45_DP<0>

RJ45_DP<1>

LED_LINK10

LED_LINK100

LED_RX_SPN

ENET_RST_L

ENET_ENERGY_DET

ENET_MDIO

ENET_MDC

ENET_RX_ER

ENET_CRS ENET_COL

ENET_RX_DV

ENET_PHY_TXD<3> ENET_PHY_TXD<4> ENET_PHY_TXD<5> ENET_PHY_TXD<6> ENET_PHY_TXD<7>

ENET_PHY_TX_EN ENET_PHY_TX_ER

CLKENET_PHY_GTX

ENET_PHY_TXD<1> ENET_PHY_TXD<2>

ENET_PHY_TXD<0>

ENET_LINK_RXD<7>

ENET_LINK_RXD<6>

ENET_LINK_RXD<5>

ENET_LINK_RXD<4>

ENET_LINK_RXD<3>

ENET_LINK_RXD<2>

ENET_LINK_RXD<1>

ENET_LINK_RXD<0>

JTAG_ASIC_TRST_L

JTAG_ASIC_TMS

JTAG_ASIC_TCK

JTAG_ENET_TDO

MDI_M<3>

MDI_P<3>

MDI_M<2>

MDI_P<2>

MDI_M<1>

MDI_M<0>

AC_IN

SLEEP_L_LS5

CLKENET_PHY_TX

CLKENET_PHY_GBE_REF

CLKENET_PHY_RX

JTAG_ASIC_TDI

MDI_P<1>

MDI_P<0>

MDI0_PD MDI1_PD MDI2_PD MDI3_PD

3405_MODE

3405_VFB

RJ45_C3_PD

CLKENET_LINK_TX

CLKENET_LINK_RX

CLKENET_LINK_GBE_REF

ENET_RSET

RJ45_C0_PD

RJ45_C1_PD

RJ45_C2_PD

INT_ENET_RST_L

IO_RESET_L

+2_5V_MARVELL

CLK25M_ENET_XOUT

CLK25M_ENET_XIN

CLK25M_XTAL_IN

GND

OUT

VCC

OSC

SYM_VER2

GND

OUTIN

BYP ADJ

ADJ

BYP GND

OUT

SHDN

(SYM_VER1)

VREG_PD

PAD

THRML

AGND

TESTM

D5 D6

RESETZ

DGND

PLL VDD

1.8

3.3

DVDD

PLLGND

PLL

3.3

VDD

D3 D4

D1 D2

BMODE

PC2

PC1

CPS

PC0

LREQ

LPS

LCLK

3.3

AVDD DVDD

1.8

TPA1+ TPA1-

PCLK

TPA0-

TPA0+

TPA2+ TPA2-

C/LKON

CTL0 CTL1

CNA

PINT

TPBIAS0 TPBIAS1

TPBIAS2

TPB2-

TPB2+

TPB1-

TPB1+

TPB0-

TPB0+

DS0 DS1

ON/OFF

GND

VOUT

VIN

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

PART NUMBER

ALTERNATE FOR

PART NUMBER

BOM OPTION

REF DES

COMMENTS:

TABLE_ALT_HEAD

TABLE_ALT_ITEM

1MA(MAX) BUS HOLDER EACH

PHY PIN 64

RX0

(RXD-FWB)

1 -> A-ONLY PORT

165MA MAX LOAD

PLACE NEAR PHY

FIREWIRE

FW_TPA0P

FW_TPA0N

FW_TPA1N

FW_TPB0P

FW_TPB1P

FW_TPB0N

FW_TPA1P

FW_TPB1N

(TXD-FWB)

(TXD-FWA)

(RXD-FWB) (RXD-FWB)

(RXD-FWA) (RXD-FWA)

(TXD-FWB)

(TXD-FWA)

CAPACITOR IN CONJUCTION WITH INTERNAL PULLUP PROVIDES RESET PULSE WHEN PHY FIRST RECEIVES POWER

PWR CLASS = 100

MAY REQUIRE UP TO 3W)

(MAY PROVIDE POWER, OR

PHY PIN 28

PHY PINS 72,76

PHY PIN 25

DSX STRAP OPTIONS

0 -> BILINGUAL PORT

PLACE NEAR PHY

PHY PINS 4,14

SPEC SAID TO USE 10K

TX0

(RXD-FWA)

(RXD-FWB)

(TXD-FWA)

(TXD-FWB)

PHY PIN 38

PHY PIN 61

PHY PIN 21 PHY PIN 40

(PC0 IS MSB, PC2 IS LSB)

SN0201029PFP

VOUT = 1.22*(1+R2/R1)+ IADJ*R2

PHY PIN 50

VOUT = 1.22*(1+R2/R1)+ IADJ*R2

IADJ = 30NA AT 25C

R445

1/16W

402

C538

CERM

20%

6.3V 402

0.22UF

RP38

1/16W

SM1

RP37

1/16W

SM1

R485

402

1/16W

R484

1/16W

402

C808

402

20% 10V CERM

0.1UF

C540

CERM

10V

20%

402

0.1UF

C650

16V

0.01UF

402

CERM

20%

3 1

98.304MHZ

CRITICAL

SM-A

R446

5% MF

402

1/16W

R761

402

100K

NO STUFF

1/16W

R758

402

1/16W

R760

402

1/16W

100

C640

402

CERM

6.3V

20%

0.22UF

C627

603

CERM

20% 10V

1UF

C629

CERM

20% 10V

1UF

603

C591

603

20% 10V

1UF

CERM

C570

603

20%

1UF

CERM

10V

R555

603

1/16W

R557

603

1/16W

R494

603

1/16W

R470

1/16W

603

3 4

U36

CRITICAL

SOT-23-1

LTC1761ES5-BYP

C641

2.2UF

805

CERM

10V

20%

R574

402

16.2K

1/16W

R575

1/16W

1% MF

402

27.4K

R577

16.2K

402

1/16W

R576

27.4K

402

1% 1/16W MF

C642

20% 10V

CERM

805

2.2UF

R547

1/16W

603

C810

CERM 603

20% 10V

1UF

C628

603

CERM

20% 10V

1UF

R556

3.3

5% 1/16W MF 603

R759

603

1/16W

3.3

C546

805

CERM

10V

20%

2.2UF

C777

805

CERM

10V

20%

2.2UF

R447

5% 1/16W

402

SM-1

400-OHM-EMI

U37

LT1962-ADJ

CRITICAL

MSOP

R564

1/16W

603

C634

CERM 402

10V

20%

0.1UF

R516

402

1/16W

56.2

R509

1% 1/16W MF 402

56.2

C605

603

CERM

20% 10V

1UF

R495

402

1/16W

56.2

R510

56.2

402

1/16W

R496

1% MF

402

1/16W

4.99K

C587

402

CERM

25V

220PF

C571

603

10V

20% CERM

1UF

R486

56.2

1/16W

402

R478

MF 402

1% 1/16W

56.2

R522

1/16W

56.2

1% MF

402

R525

402

1/16W

4.99K

C614

402

CERM

25V

220PF

R524

1% 1/16W MF 402

56.2

R546

402

1/16W

D14

SDM20E40C

SC-59

+5V_SLEEP

R775

402

1/16W

706918

716537

7672643814

6357514439

6261504340

U29

PQFP

CRITICAL

TSB81BA3A

C804

CERM

10V

20%

402

0.1UF

C653

10UF

805

CERM

6.3V

20%

C561

10V 402

CERM

20%

0.1UF

R471

402

1/16W

C539

10V 402

20% CERM

0.1UF

C586

805

CERM

6.3V

20%

10UF

C646

16V

0.01UF

402

20% CERM

C645

10UF

20%

6.3V 805

CERM

C577

20% 10V CERM 402

0.1UF

C818

100UF

SMD-3

10V

20%

POLY

L51

220uH

SM-3

CRITICAL

D20

MBR0540

U34

CRITICAL

LM2594

C635

10UF

N20P20%

2320

CERM

50V

R781

402K

1% MF

402

1/16W

C541

CERM

10V

20%

402

0.1UF

R469

1/16W

402

C778

402

20% 10V CERM

0.1UF

R563

402

6.34K

1/16W

R459

10K

5% 1/16W MF 402

R437

1/16W

402

R436

402

1/16W

5% MF

R444

402

1/16W

R740

470

402

1/16W

R464

1/16W MF 402

051-6598

197S0011 197S0052

SIWARD ALT FOR FW OSC

+3V_FW

FW_INPUT_PD

FW_LINK_DATA<7>

FW_PLL_ADJ

FW_OSC_EN

FW_LINK_CNTL<1>

FW_PHY_CNTL<1>

CLKFW_LINK_PCLK

CLKFW_PHY_PCLK

FW_LINK_CNTL<0>

FW_PHY_CNTL<0>

+3V_FW

FWB_TPB1

+1_95V_FW_PLLVDD

+1_95V_FW_DVDD

FW_OSC

FWB_TPB0

FW_CORE_ADJ

+1_95V_FW_DVDD

FW_LINK_DATA<6>

FW_LINK_DATA<5>

FW_LINK_DATA<4>

FW_LINK_DATA<3>

FW_LINK_DATA<2>

FW_LINK_DATA<1>

FW_LINK_DATA<0>

+FW_PWR_OR

FWPLL_BYP

+3V_FW_UF

+FW_PWR_OR

LM2594_IN

+1_95V_FW_DVDD_TX0

FW_VREG_PD

FW_TESTM

FW_PHY_RESET_L

FW_PHY_DATA<7>

FW_PHY_DATA<6>

FW_PHY_DATA<5>

+1_95V_FW_PLL500VDD

+1_95V_FW_PLL400VDD

FW_PHY_DATA<3>

FW_PHY_DATA<2>

FW_PHY_DATA<1>

FW_PHY_DATA<4>

FW_BMODE

FW_CPS

FW_PHY_DATA<0>

FW_PC_PD

FW_PHY_PD

FW_PC_PU

FW_PHY_LREQ

FW_PHY_LPS

CLKFW_PHY_LCLK

+3V_FW_AVDD_PORT1

+3V_FW_AVDD

+1_95V_FW_DVDD_RX0

+3V_FW_AVDD_PORT2

FW_TPA1N

FW_TPA1P

CLKFW_PHY_PCLK

FW_TPA0P FW_TPA0N

FW_LKON

FW_PHY_CNTL<1>

FW_PHY_CNTL<0>

FW_PINT

FW_BIAS0 FW_BIAS1

FW_R0 FW_R1

FW_TPB1P

FW_TPB0N

FW_TPB0P

FW_PORT1_SEL

+3V_FW_AVDD_PORT0

+1_95V_FW_DVDD_PORT1

FW_CORE_BYP

+1_95V_FW_PLLVDD

+1_95V_FW_DVDD

FW_TPB1N

FW_XI

FW_TPB2_PD

37 37

36 36

37 37

13 28

SYM_VER-1

VP VGND

TPI#

TPO

TPI

TPO#

SYM_VER-2

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

TPA*

OUTPUT

BREF SHOULD BE HARD CONNECTED TO

FIREWIRE A

514S0059

LTC4210_ON

BREF

ENABLES PORT POWER WHEN MACHINE IS

PORT 0

CLEAR OUT ALL PLANES UNDER TRANSFORMERS

(TPI0R)

AND CONNECTION DETECTION CURRENTS

(PULL-DOWN RESISTOR)

OFF

0 0

1 1

AC_IN

+3V_PMU+3V_PMU

OFF

+4_6V_BU

2.99V

POWER_UP

DCDC_EN

SLEEP

(BATT)

RUN

SHUTDOWN

RUN

(AC)

SLEEP

STATE

PMU_POWER_UP_L

514-0057

PORT 1

LOGIC GROUND FOR SPEED SIGNALING

PER 1394B V1.33

THEM (TO AVOID GROUND OFFSET ISSUE)

IS PLUGGED TO BETA-ONLY DEVICE, THERE’S NO DC PATH BETWEEN

FIREWIRE PORTS

(AC)

RUNNING OR WHEN ASLEEP ON AC

SO WHEN A BILINGUAL DEVICE

AREF NEEDS TO BE ISOLATED FROM ALL LOCAL GROUNDS PER 1394B SPEC

TPA TPA(R)

TPB*

TPB(R)

TPB

VG SC

PORT POWER SWITCH

INPUT

AREF

FIREWIRE B - BILINGUAL

CLEAR OUT ALL PLANES UNDER TRANSFORMERS

R472

1/16W

402

C588

16V

20%

0.01UF

CERM

402

C606

0.01UF

402

CERM

16V

20%

2 1

1.5A-24V

3 2 1

8 7 6 5

Q67

NDS9407

SOI

CRITICAL

Q58

SOT-363

2N7002DW

D29

SMB

B340B

CRITICAL

J26

1394B-Q41

F-RT-SM

CRITICAL

L71

2012H

90-OHM-300MA

CRITICAL

L70

CRITICAL

90-OHM-300MA

2012H

L40

FERR-250-OHM

L50

FERR-250-OHM

2 1

1.5AMP-33V

C556

0.1UF

805

CERM

50V

20%

DP5

SOT-363

BAS16TW

R737

470K

402

1/16W

4 3

DP5

SOT-363

BAS16TW

DP5

BAS16TW

SOT-363

C607

NO STUFF

16V

0.01UF

CERM

20%

402

CHGND1

R453

1/10W 805

5% FF

987

J23

F-RT-TH

CRITICAL

1394A

C805

0.01UF

CERM 402

20% 16V

C807

0.01UF 16V 402

CERM

20%

C803

0.01UF

16V 402

20% CERM

L43

CRITICAL

260-OHM-330MA

SM1

L44

SM1

CRITICAL

260-OHM-330MA

R779

1/10W

805

CHGND6

C528

NO STUFF

20% 16V CERM 402

0.01UF

+3V_PMU

R736

1/16W

402

100K

2 1

R741

402

1/16W

10K

CHGND1

R752

470K

5% 1/16W MF 402

R743

1/16W MF 402

330K

C781

0.01UF

16V 402

20% CERM

+PBUS

D26

SOT-363

BAV99DW

D26

BAV99DW

SOT-363

D28

BAV99DW

SOT-363

D28

SOT-363

BAV99DW

D15

SOT-363

BAV99DW

D15

BAV99DW

SOT-363

D12

BAV99DW

SOT-363

D12

BAV99DW

SOT-363

CHGND6

Q25

SOT-363

2N7002DW

1N5227B

SOT23

C786

0.001UF

20% 50V CERM 402

C784

402

CERM

10V

20%

0.1UF

C774

402

CERM

16V

20%

0.01UF

C792

0.01UF

402

16V

20% CERM

L39

400-OHM-EMI

SM-1

R751

402

1/16W

10K

051-6598

29 44

+FW_VP0

FW_TPB1N

+FW_FUSE

FW_TPO0R

+FW_PWR_OR

+3V_FW_ESD

+FW_SW

FW_PWR_GATE

+FW_VP1

FW_TPO1P

FW_TPO1N

FW_TPI1N

POWER_UP

RUN_OR_AC

PMU_POWER_UP_L

AC_IN_FW_CNTL

AC_IN

DCDC_EN

FW_PWREN_L

FW_TPI1P

FW_TPA1P

FW_TPA1N

FW_TPB1P

FW_VGND1

+FW_PWR_PORTA

+3V_FW

FW_VGND0

+3V_FW_ESD

+3V_FW_ESD_ILIM

FW_TPB0N

FW_TPB0P

FW_TPB0P_CONN

FW_TPB0N_CONN

FW_TPA0N_CONN

FW_TPA0P_CONN

FW_TPA0P

FW_TPA0N

P86_XCOUT

AVSS

VSS

XIN RESET

VREF

CNVSS

BYTE XOUT

AVCC

P50_WRL_WR

P51_WRH_BHE

P52_RD

P65_CLK1 P66_RXD1 P67_TXD1

P74_TA2OUT_W

P75_TA2IN_W

P60_CTS0_RTS0

P57_RDY_CLKOUT

P56_ALE

P55_HOLD

P54_HLDA

P53_BCLK

P61_CLK0 P62_RXD0 P63_TXD0

P70_TXD2_SDA_TA0OUT

P72_CLK2_TA1OUT_V

P73_CTS2_RTS2_TA1IN_V

P100_AN0

P90_TB0IN_CLK3 P91_TB1IN_SIN3

P92_TB2IN_SOUT3

P93_DA0_TB3IN P94_DA1_TB4IN

P95_ANEX0_CLK4

P96_ANEX1_SOUT4

P97_ADTRG_SIN4

P87_XCIN

P85_NMI

P84_INT2

P83_INT1

P82_INT0

P81_TA4IN_U

P80_TA4OUT_U

P77_TA3IN

P76_TA3OUT

P107_AN7_KI3

P106_AN6_KI2

P105_AN5_KI1

P104_AN4_KI0

P103_AN3

P102_AN2

P101_AN1

P64_CTS1_RTS1_CTS0_CLKS1

P71_RXD2_SCL_TA0IN_TB5IN

VCC

P01_D1

P00_D0

P02_D2 P03_D3 P04_D4 P05_D5 P06_D6 P07_D7

P10_D8

P11_D9 P12_D10 P13_D11

P21_A1_D1_D0

P22_A2_D2_D1

P23_A3_D3_D2

P24_A4_D4_D3

P25_A5_D5_D4

P14_D12

P17_D15_INT5

P15_D13_INT3 P16_D14_INT4

P20_A0_D0

P27_A7_D7_D6

P26_A6_D6_D5

P30_A8_D7

P31_A9 P32_A10 P33_A11 P34_A12 P35_A13 P36_A14 P37_A15

P45_CS1 P46_CS2 P47_CS3

P44_CS0

P43_A19

P40_A16 P41_A17 P42_A18

RSET*

MR*

GND

VCC

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

TABLE_ALT_ITEM

TABLE_5_ITEM

REFERENCE DESIGNATOR(S)

BOM OPTION

TABLE_5_HEAD

QTY

DESCRIPTION

PART#

TABLE_ALT_ITEM

PART NUMBER

ALTERNATE FOR

PART NUMBER

BOM OPTION

REF DES

COMMENTS:

TABLE_ALT_HEAD

Y6’S LOAD CAPACITANCE IS 12PF

Q11 ADAPTER DETECTION SCHEME

Keep crystal subcircuit close to PMU.

Y7’S LOAD CAPACITANCE IS 12.5PF

UNDERVOLTAGE RESET CIRCUIT

RANGE

SYSTEM STATUS

HOOPER

ADAPTER

Q11 (65W)

2.558V-

0.589V-

50MV OF HYSTERSIS

PMU KEYBOARD RESET CIRCUIT

PMU

Keep crystal subcircuit close to PMU.

(CHARGE_I)

NC NC

both are off during PMU reset.

will act as our pulldown since

to +3V_MAIN or +3V_SLEEP, which

CPU_VCORE_HI_OC/PMU_AP should have a pulldown for coming out of reset. MLB will have a pull-up

(PMU_AP)

RECOGNIZES AS A29

RECOGNIZES AS Q11 FULL FUNCTIONS

LIMITED FUNCTIONS

RECOGNIZES AS HOOPER

NO BATTERY CHARGING

FULL FUNCTIONS

LIMITED FUNCTIONS

ID VOLT

2.31V

1.65V-

3.28V

PIN VOLT

2.066V

2.007V-

2.661V

0.663V

3.19V-

A29 (45W)

AIRLINE

CASE

2.31V-

2.97V

0.33V-

0.99V

2.97V-

3.30V

A29 DETECT CIRCUIT

R785

5% 1/16W MF 402

R786

10M

402

1/16W

NO STUFF

R593

1/16W

402

R572

1/16W

402

R595

10M

402

NO STUFF

1/16W

R594

1/16W

402

R765

1/16W MF 402

R518

402

1/16W

2.2K

R778

4.7

402

1/16W

R513

2.2K

5% MF

402

1/16W

C812

20% 10V

CERM

0.1UF

402

C664

CERM

50V

402

12PF

C835

402

10V

20%

CERM

0.1UF

C574

CERM

20% 10V

402

0.1UF

C832

12PF

402

CERM

50V

C831

402

5% 50V CERM

12PF

C666

50V

CERM

402

12PF

C827

402

10V

20%

CERM

0.1UF

CRITICAL

10.0000M

8X4.5MM-SM

SM-1

32.768K

CRITICAL

11 13

6212

6014

100

U33

CRITICAL

FLAS

M16C62

OMIT

C643

10UF

CERM

20%

6.3V 805

R573

402

10K

5% MF

1/16W

R584

402

10K

5% MF

1/16W

+5V_SLEEP

+3V_MAIN

R596

402

5% MF

1/16W

10K

R597

1/16W

402

100K

R788

470K

1/16W

402

R592

470K

402

1/16W

R501

402

100K

1% 1/16W MF

+3V_PMU

R569

10K

402

5% MF

1/16W

R535

10K

1/16W

402

R585

1/16W

402

100K

R583

5% MF

1/16W

10K

402

R544

402

1/16W

100K

R562

100K

402

1/16W

R505

402

1/16W

470K

R504

1/16W

402

10K

R492

10K

1/16W

402

+3V_PMU

R782

1/16W

402

R787

10K

402

1/16W

RP40

1/16W

100K

SM1

RP40

100K

1/16W

SM1

RP40

100K

1/16W

SM1

RP41

1/16W

10K

SM1

RP41

1/16W

10K

SM1

RP41

SM1

10K

1/16W

RP41

SM1

1/16W

10K

R769

7.15K

402

1/16W

R768

7.15K

402

1/16W

R536

100K

1/16W

402

U24

TSSOP

74LVC32

U24

TSSOP

74LVC32

+3V_PMU

U24

TSSOP

74LVC32

U51

SOT143

MAX6804

CRITICAL

RP40

100K

1/16W

SM1

R502

1/16W

100K

402

R503

402

1% 1/16W MF

402K

+3V_SLEEP

U27

CRITICAL

LMC7211

R475

127K

402

1/16W

R491

52.3K

1% 1/16W MF 402

+3V_PMU

R476

4.7M

402

1/16W

C558

20% 10V CERM 402

0.1UF

R517

100K

1/16W

402

Q22

2N7002

+3V_PMU

30 44

051-6598

ALT CRYSTAL SIZE

197S0704 Y6197S0041

U33

IC,PMU,V81B

341S1008

ALT FOR SIWARD

197S0041197S0604

A29_DETECT

PMU_AC_DET

2_34V_REF

PMU_PME_L

POWER_VALID

PMU_LID_CLOSED_L

+4_85V_RAW

ADAPTER_DET

A29_DET_L

PMU_KB_RESET_L

PMU_KB_RESET_IN2

PMU_KB_RESET_IN1

KBD_OPTION_L

KBD_SHIFT_L

KBD_CONTROL_L

SOFT_PWR_ON_L

PMU_I2C_CLK

PMU_I2C_DATA

PMU_SMB_DATA

PMU_SMB_CLK

PMU_KB_RESET_L

+3V_PMU_RESET

PMU_NMI_L

PMU_NMI_BUTTON_L

PMU_BATT1_DET_L_PU

PMU_BATT_DET_L

PMU_POWERUP_OK

PMU_OOPS

TPAD_RXD

TPAD_TXD

PMU_RESET_BUTTON_L

PMU_EPM

+3V_PMU_AVCC

CAPSLOCK_LED_L

PMU_CAPSLOCK_LED_L

NUMLOCK_LED_L

PMU_NUMLOCK_LED_L

CLK32K_PMU_XIN

CLK32K_PMU_XOUT_UF

PMU_AC_IN

AC_IN

PMU_BATT0_DET_L

PMU_BATT_DET_L

CLK32K_PMU_XOUT

+3V_PMU_AVCC PMU_CNVSS

PMU_BYTE

CPU_VCORE_HI_OC INT_RESET_L MAIN_RESET_L

PMU_INT_NMI

INT_PU_RESET_L PMU_CPU_HRESET_L

PMU_FROM_INT PMU_TO_INT

PMU_ACK_L PMU_CLK

PMU_REQ_L PMU_LID_CLOSED_L PMU_RESET_BUTTON_L PMU_NMI_BUTTON_L

TPAD_RXD TPAD_TXD SYSTEM_CLK_EN CPU_CLK_EN PMU_CHARGE_V PMU_CHRG_BATT_0

PMU_SLEEP_LED_L

CPU_SMI_L POWER_VALID PMU_PME_L INT_PEND_PROC_INT PMU_NMI_L

PMU_BATT1_DET_L_PU

INT_PROC_SLEEP_REQ_L PMU_POWERUP_OK

THERM_L_OC

PMU_OOPS

PMU_I2C_CLK PMU_I2C_DATA PMU_SMB_CLK PMU_SMB_DATA

KBD_Y<1>

KBD_Y<0>

KBD_Y<2>

KBD_Y<4>

KBD_Y<3>

KBD_Y<7>

KBD_Y<6>

KBD_Y<5>

PMU_POWER_UP_L

CHARGE_LED_L

COMM_RING_DET_L

SOFT_PWR_ON_L

KBD_X<0>

INT_WATCHDOG_L

KBD_X<2>

KBD_X<1>

KBD_X<5>

KBD_X<4>

KBD_X<3>

KBD_X<7>

KBD_X<6>

KBD_X<9>

KBD_X<8>

IO_RESET_L

KBD_CONTROL_L

KBD_COMMAND_L

KBD_FUNCTION_L

KBD_OPTION_L

KBD_SHIFT_L

KBD_ID

PMU_INT_L

CPU_PLL_STOP_OC

INT_SUSPEND_ACK_L

SLEEP

INT_SUSPEND_REQ_L

CHARGE_LED_L

SOFT_PWR_ON_L

PMU_POWER_UP_L

SLEEP

INT_SUSPEND_REQ_L

PMU_CNVSS

PMU_BYTE

IO_RESET_L

INT_RESET_L

MAIN_RESET_L

INT_PU_RESET_L

PMU_AC_DET

PMU_EPM

CLK10M_PMU_XIN

PMU_RESET_L

CLK10M_PMU_XOUT_UF

CLK10M_PMU_XOUT

CSIP CSIN

BATT

PGND

DLO

DHI

BST

DLOV

LDO

CELLS

GND

CSSNCSSP

REF

CCS

CCI

CCV

IINP

ICHG

ICTL

VCTL

RFIN

ACOK

ACIN

DCIN

CLS

GATE

S3 D4

D3 D2

GATE

S3 D4

D3 D2

GATE

S3D4

D3 D2

GND

OUT

RS-

V+

RS+

NC2

NC1

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

IF A29 ADAPTER USED,

DC INRUSH LIMITER

V = CELLS X (4.096 + (0.4096 * V / V ))

RC TIME IS 480K*10UF @ +3V_PMU

(BATT_IN_PD)

CONNECTOR

BATTERY

REF = 4.096V

NC NC

WHEN AC IS IN, P-CHANNEL FETS ARE QUICKLY (DIODE) TURNED OFF

GREATER THAN 13.5V DETECT

PMU SELECTS BETWEEN TWO VOLTAGES

SWITCHER VOLTAGE CONTROL

(GND)

(+3V_PMU)

BATTERY CHARGER

REFIN

VCTL

I = (0.2048/R ) * (V / V )

BATT

CHG

For 4.20V cells, VCTL = 0.245 REFIN

ICTL

REFIN

_62

SWITCHER CURRENT CONTROL

ADJUST CURRENT SETTING

IF ADAPTER IS OVER 18V,

ROUTE LTC1625_ITH CAREFULLY

OD OUTPUT LOW - WHEN AC GREATER THAN 18V

CHARGE THROTTLED BY LOW BATTERY VOLTAGE

CHARGE DISABLED BY PMU OR INPUT VOLTAGE <18V

For 4.15V cells, VCTL = 0.123 REFIN

PLACE CLOSE TO DC INPUT

DC POWER INPUT

(POWER JACK, ETC. ON SEPARATE BOARD)

WHEN AC IS NOT PLUGGED, P-CHANNEL FETS ARE ON

ADJUST CURRENT SETTING

BATTERY SWITCH-OVER CIRCUIT

1MSEC INTEGRATION TIME

U23 SENSE VOLTAGE DROP ACROSS R460

PLACE R358 CLOSE TO LTC1625

PLACE U23 NEXT TO R460

14 10

27 26

19 18

U31

MAX1772

QSOP

CRITICAL

C652

20% 10V CERM 603

1UF

R490

47K

402

1/16W

R512

402

10K

1/16W

3 2 1

8 7 6 5

Q24

SOI

SI4435DY

CRITICAL

+PBUS

SM-2

5AMP-125V

SM-2

R497

402

1/16W

R542

1/16W

402

+24V_PBUS

R571

1/8W

1206

+BATT

C572

50V

20% CERM

0.01UF

603

3 2 1

8 7 6 5

Q13

SOI

SI4435DY

R374

470K

1/16W MF 402

R549

1/16W

402

100K

C458

20% 50V

CERM

805

0.1UF

R414

330K

1/16W

402

C468

20%

CERM

16V

0.01UF

402

R394

1/16W

402

+3V_PMU

R396

20K

402

1% 1/16W MF

R364

402

1/16W

102K

R395

102K

402

1/16W

R365

1/16W

57.6K

402

R375

402

1/16W

10K

3 2 1

8 7 6 5

Q16

SI4435DY

SOI

Q21

SOT-363

2N7002DW

R489

158K

1/16W 402

D10

SOT23

1N914

R746

47K

1/16W

402

R744

10K

402

1/16W

C547

1812

50V CERM

20%

2.2UF

C562

1812

50V CERM

20%

2.2UF

C563

1812

50V

20% CERM

2.2UF

C557

1812

50V

20% CERM

2.2UF

C564

1812

50V

20% CERM

2.2UF

R543

1/16W

603

Q27

SOT-363

2N7002DW

Q27

2N7002DW

SOT-363

C624

CERM

20% 25V

603

0.1UF

R561

100K

1/16W

402

C593

6.3V CERM

805

20%

10UF

Q29

2N7002DW

SOT-363

R363

10K

1/16W MF 402

R383

470K

1/16W MF 402

Q10

2N7002DW

SOT-363

Q10

2N7002DW

SOT-363

Q21

SOT-363

2N7002DW

R548

402

1/16W

10K

Q29

SOT-363

2N7002DW

Q30

SOT-363

2N7002DW

R578

402

1/16W

100K

Q30

SOT-363

2N7002DW

+3V_PMU

C608

50V 805

20%

CERM

0.1UF

R454

1/16W

603

0.1%

2.21K

R734

0.1%

603

82.5K

1/16W

2 1

R358

1/16W

402

150

U15

CRITICAL

LMC7211

5 2

DP4

BAS16TW

SOT-363

DP4

SOT-363

BAS16TW

C619

1206

4.7UF

CERM

25V

20%

R559

100K

402

1/16W

C631

1206

4.7UF

20% 25V

CERM

C633

1206

4.7UF

CERM

25V

20%

C632

1206

4.7UF

20% 25V CERM

R473

4.12K

1/16W

402

R487

10K

402

1/16W

J18

87438-0833

M-RT-SM

CRITICAL

+BATT

L53

FERR-50-OHM

L10

FERR-EMI-100-OHM

L12

FERR-50-OHM

J25

87438-0833

M-RT-SM

CRITICAL

FERR-EMI-100-OHM

321

8765

Q64

CRITICAL

SO-8

IRF7811W

U23

CRITICAL

TSSOP

MAX4172

R460

0.025

2512

R466

10K

1/16W

402

R747

42.2K

0.1%

1/16W

603

R739

0.1%

51.1K

1/16W 603

Q20

2N7002DW

SOT-363

R738

0.1%

1/16W

603

42.2K

R488

4.7

402

1/16W

R742

1/16W

402

C771

20% 10V

CERM

402

0.1UF

C772

20% 10V CERM 402

0.1UF

+3V_PMU

6 1

DP4

SOT-363

BAS16TW

Q20

2N7002DW

SOT-363

C775

10V

20% CERM

603

1UF

+24V_PBUS

R498

4.7

402

1/16W

+24V_PBUS

R749

6.34K

1/16W

402

C592

20% 50V

CERM

805

0.1UF

U50

CRITICAL

LMC7111 SOT23-5

Q65

SOT-363

2N7002DW

Q65

SOT-363

2N7002DW

R748

100K

1/16W

402

+3V_PMU

C578

50V

CERM

20%

1206

0.47UF

D30

MBRS140T3

C757

NO STUFF

0.1UF

20% 50V CERM 805

Q76

TO-252

SUD45P03

CRITICAL

C883

603-1

X7R

50V

10%

0.1UF

C906

0.0022UF

10% CERM

402

50V

NO STUFF

C579

CERM

50V

20%

1206

0.47UF

C630

CERM

10V

20%

603

1UF

R754

1/16W

402

100K

R755

402

1/16W

12.7K

C600

1UF

20% 50V

1210

CERM1

L42

10uH

SM1

CRITICAL

R763

0.05

2512

R511

603

1/16W

C616

20% 16V CERM 402

0.01UF

C817

CERM

20% 25V

603

0.1UF

C802

0.1UF

603

CERM

25V

20%

+3V_PMU

R567

1/16W

402

27.4K

R560

4.12K

1/16W

402

R558

402

1/16W

10K

R565

48.7K

402

1/16W

R580

5.23K

402

1/16W

C622

20% 16V

CERM

402

0.01UF

R566

1/16W

402

321

8765

Q63

IRF7805

CRITICAL

U38

CRITICAL

LMC7211

+3V_PMU

R526

402

1/16W

R588

1/16W

100K

402

R599

100K

402

1/16W

R579

1/16W MF 402

499K

R570

1/16W MF 402

100K

C658

CERM

16V

0.047uF

10%

402

C615

0.1UF

20% 10V CERM 402

SOT23

1N914

C621

20% 10V CERM 402

0.1UF

C617

1206

4.7UF

CERM

25V

20%

C618

1206

4.7UF

CERM

25V

20%

C824

20%

SM1

25V ELEC

33UF

XW19

R774

603

1/16W

4.7

R474

5% 1/16W

402

47K

R499

68K

5% 1/16W

402

051-6598

4431

1772_CSIP 1772_CSIN

1772_DLO

+ADAPTER_SW

BATT_14V_GATE

BATT_24PBUS_EN

ADAPTER_I_REG

AC_GTR_18V

A29_CURRENT_ADJ

BATT_14PBUS_EN

1772_ACIN

+BATT_24V_FUSE

BCKFD_PROT_EN_L

LTC1625_ITH

A29_CLS_ADJ

A29_DETECT

MAX4172_OUT

A29_DETECT

CURRENT_THRESHOLD

1772_ACOK_L

OVER_18V_ADJ

BCKFD_PROT_GATE

AC_IN

PMU_SMB_DATA

PMU_SMB_CLK

1772_CCI

1772_DLOV

1772_CSSN

1772_CSSP

1772_CCS

1772_CELLS

1772_LDO

1772_DHI

1772_CCV

1772_CCV_RC

1772_ICHG

BATT_LOW_L

CHARGE_DISABLE

PMU_CHRG_BATT_0

1772_VCTL

BATTV_HIGH

BATTV_LOW

PMU_CHARGE_V

1V65_REF

BATT_DIV

BATT_LOW

+BATT_RSNS

CHARGE_LED_L

AC_IN_L

AC_IN

AC_ENABLE_L

1772_DCIN

AC_IN_L

AC_IN_L_RC

BATT_CLK BATT_DATA

+BATT_POS

PMU_BATT_DET_L

BATT_NEG

1772_REF

1772_CLS

1625_COMP

AC_ENABLE_GATE

IAC_RC_COMP

IAC_FB

1772_ICTL

1772_LX

1772_IINP

BATT_24V_GATE

+ADAPTER

AC_DIV

1V20_REF

+BATT_VSNS

1772_ACOK_L

ADAPTER_DET

1772_GND

1772_BST_ESR

1772_BST

+ADAPTER_SENSE

+BATT_24V_FUSE

+BATT_14V_FUSE

VTAP

IN OUT SENSE

GND

FDBK

ERR

LP2951

SHUT

PLUS5VTAP

LP2951

ERR

FDBK

GND

SENSE

OUTIN

BOOST

SGND PGND

VIN

SYNC RUN/SS

VPROG

ITH FCB

INTVCC

VOSENSE

LTC1625

EXTVCC

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

PBUS HOLD-UP CAPS

+PBUS IS BOTH AN INPUT AND OUTPUT TO BUBBA

12.8V REGULATOR

1625 IS SHUT-OFF

WHEN +24V_PBUS IS BELOW ~13.44V,

KEEP VIN/TK LOOP SHORT

(+4_6V_BU)

BACKUP BATTERY / USB CONNECTOR

24V IS AN OUTPUT FROM BUBBA

PMU SUPPLY

12.8V PBUS SUPPLY

BOOTSTRAP SYSTEM FROM

3V_PMU_SENSE

CONNECT LTC1625 TK PIN AT TOP-SIDE FET

ADAPTER OR BATTERY

R412

1/16W

603

+PBUS

R379

1/16W

4.99K

402

321

8765

Q59

CRITICAL

IRF7805

2 1

L37

8.0UH-6.8A

SM1

CRITICAL

+24V_PBUS

3 1

1N914

SOT23

C794

33UF

SM1

25V

20% ELEC

C750

SM-1

35V

20%

ELEC

22uF

C820

20% ELEC

35V SM-1

22uF

C821

20%

SM-1

35V ELEC

22uF

C799

20%

ELEC SM-1

35V

22uF

C819

22uF

20% 35V

SM-1

ELEC

C765

33UF

SM1

25V

20%

ELEC

C822

33UF

20%

ELEC

SM1

25V

C769

33UF

ELEC

20%

SM1

25V

C793

33UF

SM1

25V

20%

ELEC

C758

33UF

20% ELEC

25V SM1

C495

CERM

0.1UF

20% 10V

402

+3V_PMU

U25

SOI-3.3V

CRITICAL

R468

1/16W 603

C584

10UF

6.3V

20%

805

CERM

C553

0.1UF

10V 402

20% CERM

R483

1/16W 603

C568

2.2UF

20% CERM

10V 805

R521

294K

402

1% MF

1/16W

C613

603

50V

470pF

10% CERM

R541

1/16W

100K

1% MF

402

U30

SOI

CRITICAL

C599

0.1UF

402

10V

CERM

20%

C625

0.1UF

CERM

50V

20%

805

D17

MBR0540

D19

MBR0540

R508

1210

1/4W

390

+PBUS

R359

158K

1% 1/16W MF 402

R360

402

1/16W

16.2K

U21

LMC7211

CRITICAL

+3V_PMU

C537

0.1UF

402

CERM

10V

20%

R443

1/16W

402

102K

R433

1/16W

10K

402

R432

402

1% MF

1/16W

Q14

CRITICAL

SC70-6

FDG6324L

3 2

Q14

CRITICAL

SC70-6

FDG6324L

+5V_MAIN

R426

1/16W

402

470K

+24V_PBUS

MBR0520LT

+5V_MAIN

D11

MBR0520LT

+BATT

+5V_MAIN

R401

2.2

5% 1/16W MF 603

C461

4.7UF

1206

10V CERM

20%

R402

5% 1/16W MF 402

NO STUFF

R392

5% 1/16W MF 402

XW4

OMIT

J11

54550-1490

F-RT-SM

CRITICAL

C554

0.0047UF

402

CERM

25V

10%

NO STUFF

321

8765

Q60

SO-8

CRITICAL

IRF7811W

D27

MBRS140T3

D18

SOT23

1N914

C626

50V

2.2UF

20%

CERM 1812

C604

2.2UF

50V CERM 1812

20%

C585

2.2UF

50V CERM 1812

20%

C569

2.2UF

1812

CERM

50V

20%

C787

2.2UF

20%

50V CERM 1812

C801

2.2UF

50V CERM 1812

20%

C509

805

CERM

20% 25V

0.22UF

C536

20% 25V

CERM

4.7UF

1206

C535

CERM

25V

20%

4.7UF

1206

MBR0540

16 15 13

639

U18

CRITICAL

SSOP

C485

CERM

25V 603

4700pF

C462

603

10% 50V CERM

470pF

C510

0.1UF

805

CERM

20% 50V

C463

25V

CERM

603

4700pF

C644

2.2UF

20%

50V CERM 1812

051-6598

32 44

NEC_RIGHT_USB_OVERCURRENT

+ADAPTER_OR_BATT

1625_SGND

+ADAPTER_ILIM

1625_BG

1625_INTVCC

1625_BST_ESR

1625_VSW

1625_TG

1625_ENABLE

1625_VIN

1625_VFB

1625_BST

1625_DIV

+3V_PMU_ESR

+4_85V_ESR

+ADAPTER

+4_85V_RAW

FB_4_85V_BU

1625_EXTVCC

1V20_REF

1625_ENABLE_L

COMP_RC

1625_COMP

1625_RUNSS

1625_FCB

+4_6V_BU

3V_PMU_VTAP

RIGHT_USB_DP

NEC_RIGHT_USB_PWREN

RIGHT_USB_DM

SGND PGND

STBYMD

FCB FREQSET

SNS1-

PGOOD

VOSNS2

VOUT

3.3

VCCVCC

EXT INT VIN

TG2

SW2

SNS2-

BG2

SNS2+

BOOST2

ITH2 RUN/

SS2SS1

SNS1+

BG1

SW1

BOOST1

TG1

VOSNS1 ITH1 RUN/

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

+5V_SLEEP LOADS

VOLTAGE

PMU_POWER_UP_L DCDC_EN

DCDC_EN_L

SLEEP LEVEL SHIFTER (3V -> 5V)

1) OPTICAL DRIVE

2) DVI

1 (2.99V)

3) TRACKPAD

5) FIREWIRE PHY

4) FANS

+3V_PMU

+4_6V_BU

+3V_PMU

0 1

+3V_PMU

0 0 1

Sleep Shutdown

Run

State

POWERDOWN DELAY IS AROUND 4MS-15.6MS

3V START TO TURN ON ~25MS AFTER DCDC_EN_L

5V START TO TURN ON ~12.5MS AFTER DCDC_EN_L

DIODE WILL ENSURE DCDC_EN_L IS QUICKLY DISCHARGED DURING SHUT-DOWN

3.3V/5V MAIN SUPPLY

3) MAP31 - 3V RAIL (IF USING D3COLD)

BECAUSE Q21 IS PLACED AT OUTPUT OF +3V_MAIN SWITCHER

2) INTREPID - IIC AND PCI PULL-UPS

4) GRAPHIC CHIP SPREAD SPECTRUM CHIP

THIS SIGNAL IS OPEN COLLECTOR TO GND WHEN POWER IS NOT GOOD

3.3V/5V REGULATOR

+3V_SLEEP LOADS

1) CPU PLL Config Control

6) DVI LEVEL SHIFTERS & PULL-UPS & HPD

THERE’S NO 10UF INPUT CAP

5) LVDS DDC PULL-UPS

8) BOOT BANGER

11) PMU - IIC Pull-ups

12) PCI PULL-UPS

10) WIRELESS (IF POWERING OFF IN SLEEP)

9) HARD DRIVE (IF USING 3V LOGIC)

7) SOUND BOARD

ADDED FOR M10 POWER SEQUENCING

220PF IS USED TO QUIET NOISE ON PGOOD ONCE INTERNAL OPEN DRAIN IS DISENGAGED

SLEEP

DCDC_EN TRUTH TABLE

1627

1726

1825

1923

U28

CRITICAL

SSOP

LTC3707

R378

1/16W MF 402

R506

5% MF

1/16W

470K

402

Q23

SOT-363

2N7002DW

C623

402

16V

20% CERM

0.01UF

Q25

2N7002DW

SOT-363

R528

402

1/16W

100K

R515

1/4W

0.005

1206

Q23

SOT-363

2N7002DW

+5V_SLEEP

C825

20% 10V

SMD-3

100uF

POLY

C545

0.22UF

20% 25V

CERM

805

C662

20% 16V

402

0.01UF

CERM

+5V_MAIN

3 6

5 2 1

Q32

TSOP

SI3443DV

C694

SMD-3

10V

20%

100uF

POLY

3 6

5 2 1

Q43

SI3443DV

TSOP

C700

402

10V

20%

CERM

0.1UF

C697

CERM

20%

6.3V 805

10UF

R589

402

100K

1/16W

R697

100K

1/16W

402

R457

603

1/16W

2.2

R350

402

1/16W

100K

SOT-363

2N7002DW

C456

CERM

20% 16V

402

0.01UF

R367

402

1/16W

100K

+5V_MAIN

R377

402

1/16W

100K

SOT-363

2N7002DW

+3V_SLEEP

+3V_MAIN

C532

CERM

20% 50V

402

0.001uF

3 6

5 2 1

Q28

TSOP

SI3443DV

C639

50V

CERM

603

2200pF

R368

402

1/16W

100K

R538

1/16W

100K

402

R463

113K

402

1/16W

MBR0540

D13

MBR0540

R482

603

1/16W

2.2

3 1

D16

SOT23

1N914

R523

1/16W

402

C609

CERM

20% 16V

402

0.01UF

C659

CERM

20%

6.3V 805

10UF

R462

402

1/16W

21.5K

C534

402

CERM

220PF

25V

D22

MBRS140T3

D34

MBRS140T3

Q79

2N7002DW

SOT-363

NO STUFF

Q79

SOT-363

NO STUFF

2N7002DW

R298

402

1/16W

100K

R296

402

1/16W

100K

SLEEP_NET

+5V_MAIN

C566

402

180pF

CERM

50V

NO STUFF

R300

NO STUFF

100K

1/16W MF 402

L38

IHLP-5050

CRITICAL

4.7UH

L41

IHLP-5050

4.7UH

CRITICAL

R308

NO STUFF

402

100K

5% 1/16W MF

R309

NO STUFF

470K

5% 1/16W MF 402

R310

NO STUFF

100K

5% 1/16W MF 402

+3V_SLEEP

+5V_MAIN

C567

1206

10V

20% CERM

4.7UF

Q81

NO STUFF

2N7002DW

SOT-363

Q81

2N7002DW

SOT-363

NO STUFF

321

8765

Q71

SOI

CRITICAL

SI4888DY

C612

402

CERM

20% 10V

0.1UF

C533

CERM

402

16V

10%

0.047UF

C598

CERM 805

0.22UF

20% 25V

C590

NO STUFF

180pF

402

CERM

50V

321

8765

Q72

SI4888DY

CRITICAL

SOI

R507

63.4K

402

1/16W

R514

1% 1/16W MF 402

20K

C560

20% 16V

CERM

402

0.01UF

R456

1/16W

402

R477

402

1/16W

47K

R467

402

1/16W

20K

C611

10%

0.0022UF

CERM

50V 402

C610

50V

100PF

CERM

402

R519

12.7K

402

1% 1/16W MF

C583

10%

0.0022UF

CERM

50V 402

3 2 1

8 7 6 5

Q61

SOI

CRITICAL

SI4888DY

C576

CERM 402

5% 50V

100PF

R481

1% MF

402

1/16W

15K

+5V_MAIN

C826

20%

1210

CERM

10V

22UF

C811

20%

1210

CERM

10V

22UF

3 2 1

8 7 6 5

Q52

CRITICAL

SI4888DY

SOI

C760

10V CERM

20%

1210

22UF

C759

1210

22UF

10V

CERM

20%

C756

CASE-D4

330UF

6.3V

20%

TANT

XW8

C516

CERM

50V

1812

2.2UF

20%

C508

20% 50V

2.2UF

CERM 1812

C763

50V

CERM

20%

1812

2.2UF

C770

2.2UF

CERM

20% 50V

1812

C785

20% CERM

50V 1812

2.2UF

C779

20% CERM

50V 1812

2.2UF

C800

CERM

20% 50V

1812

2.2UF

C806

20% CERM

50V 1812

2.2UF

R369

402

1/16W

C823

6.3V SMD

330UF

20%

330UF

POLY

R539

1/16W

402

R529

1/16W

402

R731

1/4W

0.005

1206

+24V_PBUS

C620

0.001uF

CERM

20% 50V

402

R431

5% MF

402

1/16W

R520

5% 1/16W MF 402

+5V_MAIN

+3V_MAIN

33 44

051-6598

5V_SNSP

3707_STBY

DCDC_EN_L

3V_BG

3V_SW

3V_BOOST

SLEEP_L_LS5_NET

SLEEP_NET_INV

5V_TG

3707_INTVCC

3707_FSET

3V_5V_OK

5V_ITH

3V_RSNS

5V_RUNSS

SLEEP

PMU_POWER_UP_L

DCDC_EN_L

+4_6V_BU

3V_SNSP

3V_ITH

3V_ITH_RC

5V_HD_PWREN

5V_ITH_RC

SLEEP

5V_BOOST_ESR

3V_RUNSS

3V_VOSNS

3V_TG

3V_SNSM

3V_BOOST_ESR

LTC3707_START_RC

SLEEP_LS5

3707_FCB

SLEEP_LS5

SLEEP_L_LS5

SLEEP_L_LS5_EN_L

SLEEP

+3V_SLP_OK_L

+3V_SLP_ON

5V_SLEEP_PWREN

SLEEP_LS5_EN_L

5V_VOSNS

5V_BG

5V_SNSM

DCDC_EN

3V_SLEEP_PWREN_L

+5V_HD_SLEEP

5V_SW

5V_BOOST

5V_RSNS

3707_SGND

D0 D1 D2 D3 D4

SKP/SDN

VCC VDD

V+

ILIM

FBS

GNDS A/B

REF

TON CC

BST

LX DL

GND

VGATE

TIME

SYM_VER-2

GND

SEL

B3 A4

A2 B2

A1 B1

VCC

TABLE_5_ITEM

CRITICAL BOM OPTION

TABLE_5_HEAD

PART#

DESCRIPTION

QTY

REFERENCE DESIGNATOR(S)

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

1.30V -> 1.10V

SEL = 1; Y1=B1

SEL = 0; Y1=A1

When A/B_ is high (fast): D4-D0 read as-is When A/B_ is low (slow): <=1K-ohm -> 0

If all pull-ups are >=100K and all

pull-downs are <=1K, V = V .

>=100K-ohm -> 1

1.175V -> 1.025V

D<4..0>

<= 1K PU

1.45

1.50

1.150

1.125

NO CPU NO CPU

1.65

D4=0

DAC

D2 D0

Lo/Slow

>= 100K PU

<= 1K PD

>= 100K PD

1 0 0

Hi/Fast

1 1 0

1.025

0.950

0.9251.30

1.35

1.100

1.075

1.050

1.000

0.975

1.60

1.40

1.55

1.70

1.275

1.75

1.95

2.00

1.85

1.250

1.225

1.200

1.1751.80

1.90

D4=1

OUTPUT VOLTAGE

1111

1 1

1 11

0 0

110

0 0

1 0 1

1 0

<D0>

Keep trace fat and short!!

ROUTE AS DIFFERENTIAL PAIR

CLOSEST TO CPU

PIN OF 1000uF CAP

VCORE SUPPLY

TO PINS 15 & 13!!

MAX1717 VID CAN TAKE 3.3V TO 5.5V INPUTS

(approx. 7ms delay)

CPU core follows CPU I/O voltage

(VCORE_GNDSNS)

(VCORE_SNS)

Keep trace fat and short!!

Connect MAX1717 GND pin 13

VCORE_VPLUS

VREF = 2.0V, HENCE VOFFSET = 2.0V * (R1/(R1+R2)) AND VCORE = VDAC + VOFFSET.

VCORE POWER SEQUENCING

PLACE THIS SHORT AT

to GND at bottom-side FET

Keep trace fat (40-100 mils) and short!!

PLACE C423 CLOSE

Keep trace fat and short!!

GROUND SENSE VOLTAGE DIVIDER

FMAX CONNECTOR

NC (RFU)

A/B_ =

FOR V-STEP:

NOTE: R310 (R2) NO STUFFED FOR NO OFFSET CASE

This allows for an offset to the ground sense to adjust the output voltage.

<D3>

R398

402

1/16W

100K

+5V_MAIN

R408

1/16W

402

100K

Q12

2N3904

Q17

2N3904

R267

402

1/16W

10K

XW15

C732

7343

TANT

20%

CRITICAL

220UF

2 1

XW3

C729

7343

TANT

CRITICAL

220UF

20%

+PBUS

MBR0530

C498

20% CERM

1UF

10V 603

+5V_MAIN

R349

1/16W

402

C733

7343

TANT

220UF

20%

CRITICAL

C734

7343

TANT

220UF

20%

CRITICAL

C730

7343

TANT

CRITICAL

220UF

20%

C518

0.1UF

CERM

20%

603

25V

10 11

U20

QSOP

MAX1717

CRITICAL

R415

100

1/16W

402

XW7

C521

0.001UF

20% 50V

CERM

402

R434

390K

402

5% MF

1/16W

C507

10V

20%

CERM

603

1UF

R407

402

1/16W

C512

220PF

402

25V

CERM

R397

1/16W

402

27.4K

C459

CERM

10V

20%

1UF

603

R385

402

1/16W

12.7K

C529

402

20%

0.01UF

CERM

16V

R337

402

1/16W

470K

NO STUFF

R325

402

1/16W MF

R329

402

5% 1/16W

R304

470K

5% MF

1/16W 402

R336

470K

1/16W

402

R330

MF 402

1/16W

470K

NO STUFF

R305

1/16W

NO STUFF

402

XW5

R321

1% 1/16W

3.01K

402

OMIT

R376

1/16W

162K

VCORE_OFFSET

603

5 2

DP2

BAS16TW

SOT-363

4 3

DP2

BAS16TW

SOT-363

6 1

DP2

BAS16TW

SOT-363

R301

470K

5% 1/16W

402

R448

66.5K

402

1/16W

C455

NO STUFF

402

CERM

25V

10%

0.0047uF

C768

402

0.0047uF

10% 25V

CERM

R732

2.2

1/4W 1210

NO STUFF

2 1

R429

603

1/16W

2.2

C689

10UF

20%

CERM

805

6.3V

10UF

6.3V 805

CERM

20%

C699

10UF

20%

CERM

805

6.3V

C234

10UF

6.3V 805

CERM

20%

10UF

20%

CERM

805

6.3V

C680

10UF

6.3V 805

CERM

20%

10UF

20%

CERM

805

6.3V

C274

10UF

6.3V 805

CERM

20%

C674

10UF

20%

CERM

805

6.3V

C682

10UF

20%

CERM

805

6.3V

C695

10UF

6.3V 805

CERM

20%

10UF

20%

CERM

805

6.3V

C116

10UF

6.3V 805

CERM

20%

C13

10UF

20%

CERM

805

6.3V

C693

20%

CERM

805

6.3V

10UF

C687

10UF

6.3V 805

CERM

20%

10UF

20%

CERM

805

6.3V

10UF

6.3V 805

CERM

20%

C285

10UF

20%

CERM

805

6.3V

C679

10UF

20%

6.3V 805

CERM

C764

603

CERM

50V

10%

0.0022uF

NO STUFF

C731

7343

TANT

CRITICAL

220UF

20% 2V

L36

SM1

CRITICAL

1.2UH-18.3A

D25

B540C

CRITICAL

+3V_MAIN

R324

402

1/16W

NO STUFF

R328

5% MF

402

1/16W

R314

MF 402

1/16W

470K

NO STUFF

R313

402

1/16W

470K

R303

1/16W 402

NO STUFF

R297

402

1/16W

470K

R327

NO STUFF

402

1/16W

470K

R323

402

470K

1/16W

R302

5% 1/16W

402

+3V_MAIN

R366

402

1/16W

R384

1/16W

NO STUFF

402

R322

402

5% 1/16W

10K

NO STUFF

R318

1/16W

402

C439

CERM

20%

402

0.1UF

10V

U11

QSOP

CRITICAL

PI3B3257

R326

1/16W

402

NO STUFF

C728

7343

TANT

220UF

20%

CRITICAL

C427

CRITICAL

TANT

16V CASE-D

20%

8.2UF

C431

16V

CRITICAL

20% TANT

CASE-D

8.2UF

C443

16V TANT CASE-D

20%

CRITICAL

8.2UF

C430

CASE-D

16V TANT

20%

CRITICAL

8.2UF

C432

20% 16V TANT CASE-D

CRITICAL

8.2UF

C441

TANT CASE-D

CRITICAL

20% 16V

8.2UF

C444

20% 16V TANT

CRITICAL

CASE-D

8.2UF

C445

20% 16V

CASE-D

CRITICAL

TANT

8.2UF

CRITICAL

NO STUFF

M-ST-SM-52465-1217

R315

2.05K

NO STUFF

402

1/16W

R312

NO STUFF

402

1/16W

100

R288

1/16W MF 402

NO_4XVCORE

R289

1/16W MF 402

NO_4XVCORE

R290

5% 1/16W MF 402

NO_4XVCORE

R292

1/16W

5% MF

NO_4XVCORE

402

321

Q50

SI7860DP

SO-8-PWRPK

CRITICAL

321

Q49

SO-8-PWRPK

CRITICAL

SI7860DP

C884

7343

TANT

CRITICAL

220UF

20%

C885

7343

TANT

220UF

CRITICAL

20%

Q86

SOT-363

2N7002DW

R806

402

1/16W

NO STUFF

R807

1/16W

402

AB_SEL_LOW

R805

402

100K

1/16W

R809

1/16W 402

1.5K

R808

NO STUFF

402

5% 1/16W

100K

+5V_MAIN

Q86

SOT-363

2N7002DW

R331

2512

CRITICAL

0.001

321

8765

Q54

SO-8

IRF7832

CRITICAL

321

8765

Q55

SO-8

CRITICAL

IRF7832

321

8765

Q53

IRF7832

SO-8

CRITICAL

R356

402

1/16W

100K

RESISTOR

1_32_VCORE

R321114S6343

1_30_VCORE

R321RESISTOR114S4023

051-6598

34 44

VCORE_MUX_SEL

MIN_LINE_WIDTH=10

VCORE_VID<2>

MIN_LINE_WIDTH=10

VCORE_VID<4>

VCORE_SEL_OFF_PU

VCORE_SLOW<4>

VCORE_FAST<4>

VCORE_SEL_ON

VCORE_ILIM

VCORE_GNDSNS

VCORE_GNDSNS_TEST

VCORE_GNDDIV

SOFT_PWR_ON_L

+3V_PMU_RESET

VCORE_VID<3> VCORE_VID<4>

VCORE_VID<2>

VCORE_VID<1>

VCORE_VID<0>

VCORE_GNDDIV_TEST

VCORE_GNDA

CPU_VCORE_SLEEP

VCORE_FAST<3>

VCORE_SLOW<2>

VCORE_DH

CPU_VCORE_SLEEP

VCORE_REF

MIN_LINE_WIDTH=10

VCORE_VID<3>

VCORE_GND

MIN_LINE_WIDTH=10

VCORE_VID<0>

VCORE_FAST<2>

VCORE_SLOW<3>

VCORE_FAST<2>

CPU_VCORE_SNUB

VCORE_MUX_EN

VCORE_TON

INT_GPIO1_PU

VCORE_FAST<1>

CPU_VCORE_HI_OC

VCORE_BOOST

MAXBUS_SLEEP

VCORE_BST

CPU_VCORE_HI_OC

CPU_VCORE_SEQ

CPU_VCORE_SEQ_L

CPU_VCORE_PWR_SEQ

SLEEP_L_LS5

DCDC_EN

VCORE_VGATE

VCORE_VID<2>

VCORE_FAST<3>

VCORE_FAST<4>

VCORE_FAST<1>

VCORE_VID<4>

VCORE_VID<1>

MIN_LINE_WIDTH=10

VCORE_TIME

VCORE_CC

VCORE_VCC

MAX1717_AB_SEL

VCORE_FB

VCORE_LX

VCORE_DL

CPU_VCORE_SLEEP_F

VCORE_VID<1>

VCORE_SHDN_L

VCORE_GNDSNS

VCORE_SNS

VCORE_GNDDIV

VCORE_VID<3>

VCORE_SLOW<1>

38 23

30 34

AGND

THRML

NC_28

NC_23

NC_15

BST2

OUT1

TON

PGOOD REF

DL1

LX1

DH1

VCC

BST1

ON2

ON1

ILIM2

ILIM1

OUT2

SKIP

DL2

LX2

PGND

DH2

VDD

V+

FB1

FB2

JUMPER

SGND PGND

PAD

THERM

SVIN PVIN

PGOOD

VFB

ITH SYNC/MODE

RUN/SS

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

THERE’S 100K PULL-UP ON PG 31 ALREADY

BURST MODE

2) INTREPID MEMORY I/O

4) OPTIONAL VIDEO MEMORY (M10 PRO ONLY)

3) CPU PLL Config Straps

+1_8V_SLEEP LOADS

1) MPC7450 - MAXBUS I/O - IF 1.8V INTERFACE

2) CPU JTAG & MaxBus Pull-ups

CONTINUOUS MODE

1) MAP31 - FBCORE/FBIO IF USING D3HOT

2) GIGABIT ETHERNET - AVDDL

1) INTREPID PLLS

2) AGP I/O IF USING D3HOT

2) MAXBUS I/O - IF 1.5V INTERFACE

1) AGP I/O - IF USING D3COLD

+1_5V_SLEEP LOADS

1) FBCORE/FBIO IF USING D3COLD

+2_5V_SLEEP LOADS

5) CLOCK SLEWING I/O

6) PCI1510 CORE

4) DDR MUXES

3) DDR SODIMMS - CORE/IO

+2_5V_MAIN LOADS

1.5V/1.8V/2.5V SUPPLIES

MAX1715_GND

1) INTREPID CORE

1.5V/2.5V SWITCHER

+1_8V_MAIN LOADS

DIODE PROVIDE PROVIDE QUICK SHUT-DOWN

CONNECTING 1_5V_FB TO GND, FORCES 1.8V OUTPUT

POWER DOWN DELAY 1.5MS TO 3.5MS

+1_5V_MAIN LOADS

CHANGE R424 BACK TO 10K, 1%, AND STUFF 5.11K FOR 1.5V OPERATION

1.8V SWITCHER

+2_5V_MAIN

C499

603

20% CERM

10V

1UF

2 1

R480

1/16W

402

+1_8V_SLEEP

+1_8V_MAIN

C276

805

6.3V

20%

10UF

CERM

C235

2200pF

50V

CERM

603

R190

100K

1/16W

402

C705

CERM

20%

6.3V 805

10UF

C709

603

CERM

50V

2200pF

R709

402

1/16W

100K

+2_5V_MAIN

+2_5V_SLEEP

2021

1627

1924

1726

1825

U22

CRITICAL

QSOP

MAX1715

L35

4.7UH

SM4

CRITICAL

3 2 1

8 7 6 5

Q57

IRF7805

CRITICAL

321

8765

Q69

IRF7805

CRITICAL

R423

402

1/16W

158K

R418

1/16W

402

158K

5 2

DP3

BAS16TW

SOT-363

R493

603

4.7

1/16W

R479

603

4.7

1/16W

C575

0.1UF

20% CERM

25V 603

D23

MBRS130LT3

R425

402

5.11K

1/16W

R424

10K

402

1/16W

+1_5V_MAIN

+5V_MAIN

4 3

DP3

BAS16TW

SOT-363

C580

0.1UF

603

CERM

20% 25V

C751

SMD-1

20% TANT

POSCAPS

150UF

6.3V

L45

4.7UH

SM4

CRITICAL

R420

1/16W

5% MF

402

R419

5% 1/16W MF 402

NO STUFF

+PBUS

C745

150UF

TANT

20%

SMD-1

POSCAPS

6.3V

C782

6.3V

150UF

TANT

20%

SMD-1

POSCAPS

C780

150UF

SMD-1

20%

6.3V TANT

POSCAPS

C788

20%

150UF

TANT

6.3V SMD-1

POSCAPS

C559

CRITICAL

CERM

25V

20%

4.7UF

1206

C582

CRITICAL

20% 25V CERM

4.7UF

1206

C519

CERM

25V

20%

CRITICAL

4.7UF

1206

C544

CERM

25V

20%

CRITICAL

4.7UF

1206

R421

NO STUFF

402

1/16W

R422

402

1/16W

NO STUFF

D33

MBRS130LT3

C677

20% CERM

22UF

1206

6.3V

R627

15K

402

1% MF

1/16W

C683

603

CERM

25V

1000PF

XW1

OMIT

XW6

OMIT

+1_5V_SLEEP

+1_5V_MAIN

C726

2200pF

603

CERM

50V

C723

10UF

CERM

20%

6.3V 805

C809

CERM

6.3V

10UF

20%

805

C740

10UF

20%

6.3V CERM 805

C603

2.2UF

CERM

10V

20%

805

C581

2.2UF

805

20% 10V CERM

6 1

DP3

BAS16TW

SOT-363

R450

1/16W

402

330K

C531

0.01UF

20% 16V CERM 402

Q46

TSOP

SI3446DV

Q19

2N7002

R461

100K

1/16W

402

R715

603

1/16W

R712

NO STUFF

603

1/16W

3 2 1

8 7 6 5

Q56

SO-8

CRITICAL

IRF7811W

321

8765

Q68

IRF7811W

SO-8

CRITICAL

+1_5V_MAIN

+2_5V_MAIN

XW11

OPEN

OMIT

R616

402

15.4K

1/16W

R672

402

1/16W

10K

R455

1/16W MF 402

100K

R607

1/16W MF 402

100K

R417

402

100K

1/16W

Q82

2N7002DW

SOT-363

Q82

2N7002DW

SOT-363

C886

402

X7R

25V

1000PF

10%

+5V_MAIN

C887

NO STUFF

X7R

25V

10%

1000PF

402

R610

100K

1/16W

402

NO STUFF

C888

NO STUFF

1000PF

10% 25V X7R 402

R611

NO STUFF

1/16W

100K

402

U58

CRITICAL

LTC3412

TSSOP

C890

402

5% 50V CERM

100PF

R802

100K

1/16W 402

R799

110K

1% 1/16W MF 402

R800

75K

1% MF

402

1/16W

C893

22PF

5% 50V CERM 402

R803

232K

1% 1/16W MF 402

C892

10% CERM

402

50V

470PF

R727

1/16W

5% MF

4.7M

402

R798

NO STUFF

1/16W 402

R797

1/16W

402

R801

402

1/16W

309K

7632

851

Q84

CRITICAL

SI6467BDQ

TSSOP

7632

851

Q85

CRITICAL

SI6467BDQ

TSSOP

L75

CRITICAL

1.0UH-3.5A

C894

1206

CERM

6.3V

20%

22UF

C891

22UF

20%

6.3V CERM 1206

Q83

2N7002DW

SOT-363

Q83

SOT-363

2N7002DW

R810

402

1/16W

100K

C907

0.022UF

20% 16V CERM 402

NO STUFF

C908

402

CERM

50V

10%

0.0022UF

NO STUFF

C93

6.3V

20%

1206

22UF

CERM

+1_8V_MAIN

+3V_MAIN

4435

051-6598

1_5V_LX

MAX1715_GND

1_5V_DH

2_5V_LX

3V_5V_OK

1_5V_DL

3V_5V_OK_INV

3V_5V_OK

LTC3412_RT

LTC3412_SYNC

+1_8V_MAIN_LX_F

LTC3412_PGOOD

LTC3412_VFB

LTC3412_ITH_RC

1_8V_SW

SLEEP_L_LS5_INV

1_5V_SLEEP_EN_L

1_5V_BOOST

SLEEP_L_LS5_INV

DCDC_EN_L

1_5V_SLEEP_EN_L

SLEEP_L_LS5_NET

SLEEP_L_LS5

MAX1715_FB2

MAX1715_SKIP

1_5V_FB

2_5V_BOOST

1_5V_FB

2_5V_BST1_5V_BST

2_5V_DH

MAX1715_GND

2_5V_ILIM

MAX1715_TON

MAX1715_VCC

1_5V_2_5V_OK

MAX1715_ON_RC

+1_5V_SLEEP_VIN

+1_5V_LDO

1_5V_ILIM

MAX1715_FB2

SLEEP_L_LS5_INV

SLEEP

1_8V_SLEEP_PWREN_L

2_5V_SLEEP_PWREN_L

SLEEP

LTC3412_VFB_DIV

LTC3412_RUNSS

LTC3412_ITH

LTC3412_GND

MAX1715_REF

2_5V_DL

38 38

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

TOTAL LENGTH CONTROLLED BY SPREADSHEET

NET_SPACING_TYPE

CLOCK LINE CONSTRAINTS

GROUPGROUP

TOTAL LENGTH CONTROLLED BY SPREADSHEET

SHOULD BE AT MOST 4 VIAS FOR CLK

INTREPID

CLOCKS

SIG_NAME MAX VIAS

MAX EXPOSED LENGTH

STUB_LENGTH

NET_SPACING_TYPE

PULSE PARAM

SIGNAL CONSTRAINTS - PAGE 1

PULSE_PARAM

NO_TEST

STUB_LENGTH

MAX_EXPOSED_LENGTH

MAX_VIAS

MAXBUS

DIGITAL SIGNALS

GROUP 0

GROUP 1

RAM

DDR

GROUP 6

GROUP 4/5

GROUP 2/3

GROUP 7

ADDR

CONTROL

TOTAL LENGTH CONTROLLED BY SPREADSHEET

SOUND

FIREWIRE

ETHERNET

MARVELL

CRYSTALS

THERE’S ANOTHER 280MIL LEG

MAP31

SIG_NAME

4436

051-6598

200.0000

10 MIL SPACING

SYSCLK_DDRCLK_B0_L_UF

200.0000

10 MIL SPACING

SYSCLK_CPU

200.0000

10 MIL SPACING

SND_SCLK

200.0000

10 MIL SPACING

SND_CLKOUT

200.0000

10 MIL SPACING

CLKENET_LINK_TX

250.0000

CPU_WT_L

250.0000

10 MIL SPACING

CPU_TBST_L

250.0000

CPU_CI_L

MEM_MUXSEL_L<1..0>

MEM_MUXSEL_H<1..0>

200

RAM_CKE<3..0>

MEM_CKE<3..0>

200

RAM_CS_L<3..0>

MEM_CS_L<3..0>

200

RAM_BA<1..0>

MEM_BA<1..0>

200

RAM_ADDR<12..0>

83 MHZ

MEM_ADDR<12..0>

200

167 MHZ

RAM_DATA_B<63..56>

200

167 MHZ

RAM_DATA_A<63..56>

200

167 MHZ

MEM_DATA<63..56>

200

167 MHZ

RAM_DATA_B<55..48>

200

167 MHZ

MEM_DATA<55..48>

200

167 MHZ

RAM_DATA_A<55..48>

167 MHZ

200

RAM_DQM_B<5..4>

167 MHZ

200

RAM_DQM_A<5..4>

167 MHZ

200

MEM_DQM<5..4>

167 MHZ

200

RAM_DQS_B<5..4>

167 MHZ

200

RAM_DQS_A<5..4>

167 MHZ

200

MEM_DQS<5..4>

167 MHZ

200

RAM_DATA_B<47..32>

167 MHZ

200

RAM_DATA_A<47..32>

200

167 MHZ

RAM_DQM_B<3..2>

167 MHZ

200

MEM_DATA<47..32>

200

167 MHZ

RAM_DQM_A<3..2>

200

167 MHZ

MEM_DQM<3..2>

200

167 MHZ

RAM_DQS_B<3..2>

200

167 MHZ

RAM_DQS_A<3..2>

200

167 MHZ

MEM_DQS<3..2>

200

167 MHZ

RAM_DATA_B<31..16>

200

167 MHZ

RAM_DATA_A<31..16>

200

167 MHZ

MEM_DATA<31..16>

167 MHZ

200

RAM_DATA_A<15..8>

167 MHZ

200

MEM_DATA<15..8>

167 MHZ

200

RAM_DATA_A<7..0>

167 MHZ

200

MEM_DATA<7..0>

83 MHZ

250

CPU_DATA<0..31>

RAM_MUXSEL_L

RAM_MUXSEL_H

10 MIL SPACING

NEC_XT2

10 MIL SPACING

NEC_XT1

MEM_WE_L

MEM_RAS_L

MEM_CAS_L

10 MIL SPACING

CLK25M_ENET_XOUT

10 MIL SPACING

CLK18M_INT_XOUT

10 MIL SPACING

CLK18M_INT_XIN

167 MHZ

200

RAM_DATA_B<15..8>

10 MIL SPACING

CLK25M_ENET_XIN

10 MIL SPACING

CLK18M_INT_EXT

10 MIL SPACING

CLK18M_XTAL_IN

10 MIL SPACING

CLK27M_GPU_XIN

10 MIL SPACING

CLK27M_XTAL_IN

167 MHZ

200

RAM_DATA_B<7..0>

250

CPU_DTI<0..2>

250

CPU_TSIZ<0..2>

250

83 MHZ

CPU_DATA<32..63>

250

83 MHZ

CPU_ADDR<0..31>

250.0000510 MIL SPACING

CPU_DBG_L

250

CPU_TT<0..4>

10 MIL SPACING

CLK27M_GPU_XOUT

250.0000

CPU_GBL_L

250.0000510 MIL SPACING

CPU_QACK_L

200.0000610 MIL SPACING

CLK33M_AIRPORT

200.0000

10 MIL SPACING

CLK33M_AIRPORT_UF

200.0000610 MIL SPACING

CLK33M_CBUS

200.0000

10 MIL SPACING

CLK33M_CBUS_UF

200.0000610 MIL SPACING

CLK33M_USB2

200.0000

10 MIL SPACING

CLK33M_USB2_UF

200.0000

10 MIL SPACING

CLK66M_GPU_AGP

200.0000

10 MIL SPACING

CLK66M_GPU_AGP_UF

200.0000310 MIL SPACING

CLKENET_LINK_GBE_REF

200.0000

CLKENET_LINK_GTX

200.0000310 MIL SPACING

CLKENET_LINK_RX

200.0000

CLKENET_PHY_GBE_REF

200.0000310 MIL SPACING

CLKENET_PHY_GTX

200.0000

CLKENET_PHY_RX

200.0000

CLKENET_PHY_TX

200.0000

CLKFW_LINK_LCLK

200.0000

10 MIL SPACING

CLKFW_LINK_PCLK

200.0000310 MIL SPACING

CLKFW_PHY_LCLK

200.0000

CLKFW_PHY_PCLK

250.0000

10 MIL SPACING

CPU_AACK_L

250.0000

10 MIL SPACING

CPU_ARTRY_L

250.0000

10 MIL SPACING

CPU_BG_L

250.0000

10 MIL SPACING

CPU_BR_L

250.0000

10 MIL SPACING

CPU_DRDY_L

10 MIL SPACING

CPU_DRDY_L_UF

250.0000

10 MIL SPACING

CPU_HIT_L

250.0000

10 MIL SPACING

CPU_QREQ_L

250.0000

10 MIL SPACING

CPU_TA_L

250.0000

CPU_TEA_L

10 MIL SPACING

250.0000

CPU_TS_L

200.0000

10 MIL SPACING

FW_OSC

200.0000

10 MIL SPACING

FW_XI

10 MIL SPACING

GPU_CLK27M_OUT

10 MIL SPACING

GPU_CLK27M_UF

10 MIL SPACING

GPU_DVO_CLKP

10 MIL SPACING

GPU_FBCLK0

10 MIL SPACING

GPU_FBCLK0_L

10 MIL SPACING

GPU_FBCLK1

10 MIL SPACING

GPU_FBCLK1_L

10 MIL SPACING

GPU_SSCLK_IN

10 MIL SPACING

GPU_SSCLK_UF

200.0000

10 MIL SPACING

INT_AGP_FB_IN

200.0000

10 MIL SPACING

INT_AGP_FB_OUT

200.0000

10 MIL SPACING

INT_CPUFB_IN

10 MIL SPACING

INT_CPUFB_IN_NORM

10 MIL SPACING

INT_CPUFB_LONG

10 MIL SPACING

INT_CPUFB_OUT

10 MIL SPACING

INT_CPUFB_OUT_NORM

10 MIL SPACING

INT_CPUFB_OUT_SHORT

200.0000310 MIL SPACING

INT_PCI_FB_IN

200.0000

10 MIL SPACING

INT_PCI_FB_OUT

200.0000

10 MIL SPACING

INT_REF_CLK_IN

200.0000310 MIL SPACING

INT_REF_CLK_OUT

200

MEM_DQM<0>

200

MEM_DQM<1>

200

MEM_DQM<6>

200

MEM_DQM<7>

200

MEM_DQS<0>

200

MEM_DQS<1>

200

MEM_DQS<6>

200

MEM_DQS<7>

200.0000

RAM_CAS_L

200

RAM_DQM_A<0>

200

RAM_DQM_A<1>

200

RAM_DQM_A<6>

200

RAM_DQM_A<7>

200

RAM_DQM_B<0>

200

RAM_DQM_B<1>

200

RAM_DQM_B<6>

200

RAM_DQM_B<7>

200

RAM_DQS_A<0>

200

RAM_DQS_A<1>

200

RAM_DQS_A<6>

200

RAM_DQS_A<7>

200

RAM_DQS_B<0>

200

RAM_DQS_B<1>

200

RAM_DQS_B<6>

200

RAM_DQS_B<7>

200.0000

RAM_RAS_L

200.0000

RAM_WE_L

10 MIL SPACING

SYSCLK_CPU_UF

200.0000

DDRCLK_A0

10 MIL SPACING

SYSCLK_DDRCLK_A0

200.0000

DDRCLK_A0

10 MIL SPACING

SYSCLK_DDRCLK_A0_L

200.0000

10 MIL SPACING

SYSCLK_DDRCLK_A0_L_UF

200.0000

10 MIL SPACING

SYSCLK_DDRCLK_A0_UF

200.0000

DDRCLK_A1

10 MIL SPACING

SYSCLK_DDRCLK_A1

200.0000

DDRCLK_A1

10 MIL SPACING

SYSCLK_DDRCLK_A1_L

200.0000

10 MIL SPACING

SYSCLK_DDRCLK_A1_L_UF

200.0000

10 MIL SPACING

SYSCLK_DDRCLK_A1_UF

200.0000

DDRCLK_B0

10 MIL SPACING

SYSCLK_DDRCLK_B0

200.0000

DDRCLK_B0

10 MIL SPACING

SYSCLK_DDRCLK_B0_L

200.0000

10 MIL SPACING

SYSCLK_DDRCLK_B0_UF

200.0000

DDRCLK_B1

10 MIL SPACING

SYSCLK_DDRCLK_B1

200.0000

DDRCLK_B1

10 MIL SPACING

SYSCLK_DDRCLK_B1_L

200.0000

10 MIL SPACING

SYSCLK_DDRCLK_B1_L_UF

200.0000

10 MIL SPACING

SYSCLK_DDRCLK_B1_UF

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

STUB_LENGTH

DELAY_RULE

DVO

AGP BYTES 2-3

AGP SIDEBAND

AGP CONTROL

AGP

GROUP

AGP BYTES 0-1

SIG_NAME

MAX_EXPOSED_LENGTH

MAX_VIAS

PULSE_PARAM

NO_TEST

NET_SPACING_TYPE

Digital Signals (cont’d)

PCI

ULTRA ATA-100

OPTICAL

INTREPID

EIDE

ETHERNET MII

ZDIFF = 89.3OHM (USB 1.1)/ 89.4OHM (USB 2.0)

ZSINGLE = 51.5OHM (USB 1.1)/ 46.2OHM (USB 2.0)

S = 10MIL (USB 2.0) (SEPERATION OF DIFF TRACES)

W = 4MIL(USB 1.1)/ 5MIL(USB 2.0) (TRACE WIDTH)

S = 5MIL (USB 1.1) (SEPERATION OF DIFF TRACES)

B = 12.2MIL (DIST BETW 2 GND PLANES) T = 0.7MIL (TRACE THICKNESS)

ER = 4.3 (DIELECTRIC CONSTANT)

INTERNAL LAYER (USB1.1/USB 2.0)

POWER

THERMOSTAT

SUPPLIES

USB

UPPER

LVDS

LOWER

FIREWIRE

GROUP

ETHERNET

SIG_NAME

DIFFERENTIAL_PAIR

MAX_EXPOSED_LENGTH

NET_SPACING_TYPE

MAX_VIAS

NEED TO MATCH DELAY TO 250

TOTAL UIDE+HD SKEW <500MIL

FIREWIRE MII

SIGNAL CONSTRAINTS - PAGE 2

Differential Signals

SPACING DELETED BECAUSE OF PHYSICAL CONSTRAINTS AROUND MARVELL PHY

ER = 4.3 (DIELECTRIC CONSTANT)

S = 10MIL (SEPERATION OF DIFF TRACES)

T = 0.7MIL (TRACE THICKNESS)

B = 12.2MIL (DIST BETW 2 GND PLANES)

W = 3.4MIL (TRACE WIDTH)

ZSINGLE = 53.37OHM ZDIFF = 107.17OHM

W = 4MIL (TRACE WIDTH)

INTERNAL LAYER

ER = 4.3 (DIELECTRIC CONSTANT)

B = 12.2MIL (DIST BETW 2 GND PLANES) T = 0.7MIL (TRACE THICKNESS)

S = 10MIL (SEPERATION OF DIFF TRACES) ZSINGLE = 51.57OHM ZDIFF = 99.8OHM

FOR FIREWIRE

TMDS

051-6598

37 44

200.0000

UIDE_RST_L

200.0000

UIDE_IOCHRDY

10 MIL SPACING

200.0000

UIDE_INTRQ

200.0000

UIDE_DMARQ

200.0000

UIDE_DMACK_L

200.0000

UIDE_DIOW_L

200.0000

UIDE_DIOR_L

10 MIL SPACING

UIDE_DATA<7>

200

200.0000

UIDE_CS1_L

200.0000

UIDE_CS0_L

TMDS_CONN_CLKP

CLKCONN_TMDS

10 MIL SPACING

TMDS_CONN_CLKN

CLKCONN_TMDS

10 MIL SPACING

TMDS_CLKP

CLKTMDS 10 MIL SPACING

TMDS_CLKN

CLKTMDS 10 MIL SPACING

MIN_DAISY_CHAIN

PCI_TRDY_L

MIN_DAISY_CHAIN

PCI_STOP_L

MIN_DAISY_CHAIN

PCI_PAR

MIN_DAISY_CHAIN

PCI_IRDY_L

MIN_DAISY_CHAIN

PCI_FRAME_L

MIN_DAISY_CHAIN

PCI_DEVSEL_L

200.0000

HD_RESET_L

200.0000

10 MIL SPACING

HD_IOCHRDY

HD_INTRQ

200.0000

HD_DMARQ

200.0000

HD_DMACK_L

200.0000

HD_DIOW_L

200.0000

HD_DIOR_L

10 MIL SPACING

200.0000

HD_CS1_L

200.0000

HD_CS0_L

GPU_DVO_VSYNC

GPU_DVO_HSYNC

EIDE_WR_L

EIDE_RST_L

EIDE_RD_L

EIDE_OPTICAL_WR_L

EIDE_OPTICAL_RST_L

EIDE_OPTICAL_RD_L

EIDE_OPTICAL_IOCHRDY

EIDE_OPTICAL_INT

EIDE_OPTICAL_DMA_RQ

EIDE_OPTICAL_DMAACK_L

EIDE_OPTICAL_CS1_L

EIDE_OPTICAL_CS0_L

EIDE_IOCHRDY

EIDE_INT

EIDE_DMARQ

EIDE_DMACK_L

EIDE_CS1_L

EIDE_CS0_L

CLKLVDS_UP

CLKLVDS_U

10 MIL SPACING

CLKLVDS_UN

CLKLVDS_U

10 MIL SPACING

CLKLVDS_LP

CLKLVDS_L

10 MIL SPACING

CLKLVDS_LN

CLKLVDS_L

10 MIL SPACING

250.0000

AGP_TRDY_L

250.0000

AGP_STOP_L

100.0000

8 MIL SPACING

AGP_SB_STB_L

100.0000

8 MIL SPACING

AGP_SB_STB

250.0000

AGP_RBF_L

250.0000

AGP_PAR

250.0000

AGP_IRDY_L

250.0000

AGP_GNT_L

250.0000

AGP_FRAME_L

250.0000

AGP_DEVSEL_L

100

8 MIL SPACING

AGP_AD_STB_L<1>

100

8 MIL SPACING

AGP_AD_STB_L<0>

100

8 MIL SPACING

AGP_AD_STB<0>

DIFF

3V_SNS

3V_SNSP

DIFF

5V_SNS

5V_SNSM

DIFF

1772_CSI

1772_CSIN

DIFF

1772_CSI

1772_CSIP

DIFF

1772_CSS

1772_CSSP

BT_USB_DM

BT_USB_D

5 MIL SPACING

BT_USB_DP

BT_USB_D

5 MIL SPACING

ENET_COL ENET_CRS

ENET_LINK_TX_EN

ENET_LINK_TX_ER

ENET_MDC

ENET_MDIO

ENET_PHY_TX_EN

ENET_PHY_TX_ER

ENET_RX_DV ENET_RX_ER

FW_LINK_LREQ

FW_PHY_LREQ

FW_PINT

MIN_LINE_WIDTH=3.4 10 MIL SPACING

FW_TPA0N

FW_TPA0

MIN_LINE_WIDTH=3.4

FW_TPA0P

FW_TPA0 10 MIL SPACING

MIN_LINE_WIDTH=3.4

FW_TPB0N

FW_TPB0 10 MIL SPACING

MIN_LINE_WIDTH=3.4

FW_TPB0P

FW_TPB0 10 MIL SPACING

MIN_LINE_WIDTH=3.4

FW_TPI1N

FW_TPI1 10 MIL SPACING

MIN_LINE_WIDTH=3.4

FW_TPI1P

FW_TPI1 10 MIL SPACING

MIN_LINE_WIDTH=3.4

FW_TPO1N

FW_TPO1 10 MIL SPACING

MIN_LINE_WIDTH=3.4

FW_TPO1P

FW_TPO1 10 MIL SPACING

MIN_LINE_WIDTH=5

LEFT_USB_DM

LEFT_USB

10 MIL SPACING

MIN_LINE_WIDTH=5

LEFT_USB_DP

LEFT_USB

10 MIL SPACING

LVDS_L0N

LVDS_L0 10 MIL SPACING

LVDS_L0P

LVDS_L0 10 MIL SPACING

LVDS_L1N

LVDS_L1 10 MIL SPACING

LVDS_L1P

LVDS_L1 10 MIL SPACING

LVDS_L2N

LVDS_L2 10 MIL SPACING

LVDS_L2P

LVDS_L2 10 MIL SPACING

LVDS_U0N

LVDS_U0 10 MIL SPACING

LVDS_U0P

LVDS_U0 10 MIL SPACING

LVDS_U1N

LVDS_U1 10 MIL SPACING

LVDS_U1P

LVDS_U1 10 MIL SPACING

LVDS_U2N

LVDS_U2 10 MIL SPACING

LVDS_U2P

LVDS_U2 10 MIL SPACING

ENET_MDI0

MDI_M<0>

MDI_M<1>

ENET_MDI1

ENET_MDI2

MDI_M<2>

MDI_M<3>

ENET_MDI3

MDI_P<0>

ENET_MDI0

MDI_P<1>

ENET_MDI1

MDI_P<2>

ENET_MDI2

MDI_P<3>

ENET_MDI3

MODEM_USB_DM

MODEM_USB_D

5 MIL SPACING

MODEM_USB_DP

MODEM_USB_D

5 MIL SPACING

MIN_LINE_WIDTH=5

NEC_USB_DAM

NEC_USB_DA

10 MIL SPACING

MIN_LINE_WIDTH=5

NEC_USB_DAP

NEC_USB_DA

10 MIL SPACING

MIN_LINE_WIDTH=5

NEC_USB_DBM

NEC_USB_DB

10 MIL SPACING

MIN_LINE_WIDTH=5

NEC_USB_DBP

NEC_USB_DB

10 MIL SPACING

MIN_LINE_WIDTH=5

NEC_USB_RSDM1

NEC_USB_RSD1

10 MIL SPACING

MIN_LINE_WIDTH=5

NEC_USB_RSDM2

NEC_USB_RSD2

10 MIL SPACING

MIN_LINE_WIDTH=5

NEC_USB_RSDP1

NEC_USB_RSD1

10 MIL SPACING

MIN_LINE_WIDTH=5

NEC_USB_RSDP2

NEC_USB_RSD2

10 MIL SPACING

MIN_LINE_WIDTH=5

RIGHT_USB_DM

RIGHT_USB

10 MIL SPACING

MIN_LINE_WIDTH=5

RIGHT_USB_DP

RIGHT_USB

10 MIL SPACING

RJ45_DP0

10 MIL SPACING

RJ45_DN<0>

RJ45_DN<1>

RJ45_DP1

10 MIL SPACING

RJ45_DP2

10 MIL SPACING

RJ45_DN<2>

RJ45_DN<3>

RJ45_DP3

10 MIL SPACING

RJ45_DP<0>

RJ45_DP0

10 MIL SPACING

RJ45_DP<1>

RJ45_DP1

10 MIL SPACING

RJ45_DP<2>

RJ45_DP2

10 MIL SPACING

RJ45_DP<3>

RJ45_DP3

10 MIL SPACING

DIFF

THERM1_ALT

THERM1_A_DM

DIFF

THERM1_ALT

THERM1_A_DP

DIFF

THERM1

THERM1_DM

DIFF

THERM1

THERM1_DP

DIFF

THERM1_MAIN

THERM1_M_DM

DIFF

THERM1_MAIN

THERM1_M_DP

DIFF

THERM2_ALT

THERM2_A_DM

DIFF

THERM2_ALT

THERM2_A_DP

DIFF

THERM2

THERM2_DM

DIFF

THERM2

THERM2_DP

DIFF

THERM2_MAIN

THERM2_M_DM

DIFF

THERM2_MAIN

THERM2_M_DP

TMDS_DN<0>

TMDS_D0 10 MIL SPACING

TMDS_DN<2>

TMDS_D2 10 MIL SPACING

TMDS_DP<0>

TMDS_D0 10 MIL SPACING

TMDS_DP<1>

TMDS_D1 10 MIL SPACING

TMDS_DP<2>

TMDS_D2 10 MIL SPACING

USB_DEM

USB_DE

5 MIL SPACING

USB_DEP

USB_DE

5 MIL SPACING

USB_DFM

USB_DF

5 MIL SPACING

USB_DFP

USB_DF

5 MIL SPACING

ENET_LINK_RXD<7..0>

ENET_PHY_TXD<7..0>

ENET_LINK_TXD<7..0>

FW_LINK_DATA<7..0>

FW_PHY_DATA<7..0>

5 FW_LINK_CNTL<1..0> FW_PHY_CNTL<1..0>

MIN_LINE_WIDTH=3.4

FW_TPI0N

FW_TPI0 10 MIL SPACING

MIN_LINE_WIDTH=3.4

FW_TPI0P

FW_TPI0 10 MIL SPACING

MIN_LINE_WIDTH=3.4

FW_TPO0N

FW_TPO0 10 MIL SPACING

MIN_LINE_WIDTH=3.4

FW_TPO0P

FW_TPO0 10 MIL SPACING

33 MHZ

EIDE_DATA<15..0>

33 MHZ

EIDE_ADDR<2..0>

33 MHZ

EIDE_OPTICAL_DATA<15..0>

33 MHZ

EIDE_OPTICAL_ADDR<2..0>

100 MHZ

UIDE_DATA<15..8>

200

100 MHZ

UIDE_DATA<6..0>

200

100 MHZ

UIDE_ADDR<2..0>

200

HD_ADDR<2..0>

100 MHZ

200

MIN_DAISY_CHAIN

33 MHz

PCI_AD<31..0>

MIN_DAISY_CHAIN

33 MHz

PCI_CBE<3..0>

100

66 MHz

AGP_AD<15..0>

100

66 MHz

AGP_AD<31..16>

66 MHz

100

AGP_CBE<3..2>

100

66 MHz

AGP_SBA<7..0>

500.0000

MIN_LINE_WIDTH=3.4

FW_TPA1N

FW_TPA1 10 MIL SPACING

500.0000

MIN_LINE_WIDTH=3.4

FW_TPA1P

FW_TPA1 10 MIL SPACING

500.0000

MIN_LINE_WIDTH=3.4

FW_TPB1N

FW_TPB1 10 MIL SPACING

500.0000

MIN_LINE_WIDTH=3.4

FW_TPB1P

FW_TPB1 10 MIL SPACING

100

66 MHz

AGP_CBE<1..0>

250

GPU_DVOD<0..11>

100 MHZ

HD_DATA<15..0>

200

DIFF

3V_SNS

3V_SNSM

285.0000

AGP_REQ_L

100

8 MIL SPACING

AGP_AD_STB<1>

DIFF

1772_CSS

1772_CSSN

TMDS_DN<1>

TMDS_D1 10 MIL SPACING

DIFF

5V_SNSP

5V_SNS

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

MIN_NECK_WIDTH

SOUND

KB LED

VIDEO

HALL EFFECT

TRACKPAD

MISC

I/O AREA

SIGNAL CONSTRAINTS - PAGE 3

LTC1778

2.5V SWITCHER

SIG_NAME

LTC1625

GROUP

14V SWITCHER

SIG_NAME

VOLTAGE MIN_LINE_WIDTH MIN_NECK_WIDTH

SIG_NAME

GROUP

VOLTAGE MIN_LINE_WIDTH

3V SWITCHER

5V SWITCHER

LTC3707

MAX1715

INVERTER TRACKPAD

I/O AREA

LVDS

CHARGER

BATTERY

ADAPTER

PMU

MAIN/SLEEP

1.5V SWITCHER

INT PLLS

LTC1962

LTC3411

MAX1717

CONTROL

CPU

DDR RAM

INTREPID

PLLS

MIN_NECK_WIDTH REDUCED FOR TESTPOINTS

FAN GND

POWER NET CONSTRAINTS

INTREPID

SSCG

USB 2.0

88E1111

ATI M10

IMIAGE

SILICON

REFERENCE

GROUP

VOLTAGE MIN_LINE_WIDTH MIN_NECK_WIDTH

CARDBUS

CHGND1

CHGND3

CHGND4

CHGND5

CHGND6

I331

+1_8V_GPU_VDDDI

I332

GPU_VCORE_VDDCI

+1_8V_GPU_PNLPLL

I333

+1_8V_GPU_AVDD

I334

+1_8V_GPU_PNLIO

I335

+2_5V_GPU_A2VDD

I336

+GPU_MCLK

I337

+1_8V_GPU_AVDDQ

I338

I339

+3V_ATI_SS

+3V_ATI_OSC_SLEEP

I340

I341

+1_8V_GPU_MEMPLL

I342

+GPU_VDD15_UF +2_5V_SLEEP_NECK1

I343

I344

GPU_VCORE_NECK

+1_5V_AGP_NECK

I345

+1_8V_PVDD_NECK

I346

+3V_SLEEP_NECK

I347

I348

+GPU_VDD15_NECK

I349

+1_8V_SLEEP_NECK

I350

+1_5V_SLEEP_NECK

I351

+2_5V_SLEEP_NECK2

I352

+2_5V_GPU

I353

+3V_SI_PLLVCC

I354

+3V_SI_VCC

I355

+3V_SI_AVCC

CHGND2

051-6598

38 44

VOLTAGE=0V

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=12

CHGND1

GND

MIN_NECK_WIDTH=6

MIN_LINE_WIDTH=25

VOLTAGE=0V

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=12

CHGND3

VOLTAGE=0V

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=12

CHGND4

VOLTAGE=0V

MIN_NECK_WIDTH=12MIN_LINE_WIDTH=25

CHGND5

MIN_NECK_WIDTH=12MIN_LINE_WIDTH=25

VOLTAGE=0V

CHGND6

MIN_NECK_WIDTH=12MIN_LINE_WIDTH=25

VOLTAGE=0V

CHGND2

MIN_LINE_WIDTH=25

VOLTAGE=0V

MIN_NECK_WIDTH=10

FW_TPO0R

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

VOLTAGE=3.3V

NEC_AVDD

MIN_LINE_WIDTH=25

VOLTAGE=3.3V

MIN_NECK_WIDTH=10

+3V_NEC_VDD

VOLTAGE=3.3V

MIN_LINE_WIDTH=15

MIN_NECK_WIDTH=8

+3V_CG_PLL_MAIN

VOLTAGE=2.5V

MIN_LINE_WIDTH=15

MIN_NECK_WIDTH=8

+2_5V_CG_MAIN

MIN_LINE_WIDTH=10

VOLTAGE=3.3V

MIN_LINE_WIDTH=10

VOLTAGE=3.3V

MIN_NECK_WIDTH=10

MIN_LINE_WIDTH=20 MIN_NECK_WIDTH=10

VOLTAGE=1.8V

+1_8V_ATI_PVDD

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

VOLTAGE=1.4V

CPU_AVDD

MIN_LINE_WIDTH=15

VOLTAGE=1.5V

MIN_NECK_WIDTH=6

+1_5V_INTREPID_PLL7

MIN_LINE_WIDTH=10

VOLTAGE=5.4V

1772_LDO

VOLTAGE=24V

MIN_LINE_WIDTH=10

+ADAPTER_ILIM

VOLTAGE=4.85V

MIN_LINE_WIDTH=10

+4_85V_ESR

MIN_LINE_WIDTH=10

VOLTAGE=3.3V

+3V_HALL_EFFECT

MIN_LINE_WIDTH=20

VOLTAGE=1.5V

VOLTAGE=1.8V

MIN_LINE_WIDTH=10

VOLTAGE=1.5V

VOLTAGE=3.3V

MIN_LINE_WIDTH=25

MIN_NECK_WIDTH=8

VOLTAGE=3.3V

MIN_LINE_WIDTH=25

MIN_NECK_WIDTH=8

VOLTAGE=3.3V

MIN_LINE_WIDTH=25

MIN_NECK_WIDTH=8

VOLTAGE=2.5V

MIN_LINE_WIDTH=10 MIN_NECK_WIDTH=10

VOLTAGE=3.3V

MIN_LINE_WIDTH=10

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

VOLTAGE=1.8V

+1_8V_GPU

MIN_LINE_WIDTH=20 MIN_NECK_WIDTH=10

VOLTAGE=2.5V

+2_5V_GPU_PNLIO

MIN_LINE_WIDTH=10

VOLTAGE=1.8V

MIN_NECK_WIDTH=10

MIN_LINE_WIDTH=25

VOLTAGE=3.3V

MIN_NECK_WIDTH=10

+3V_FW_UF

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=1.95V

+1_95V_FW_DVDD

MIN_LINE_WIDTH=25

VOLTAGE=3.3V

MIN_NECK_WIDTH=10

+3V_FW_AVDD_PORT2

MIN_NECK_WIDTH=12

VOLTAGE=0V

MIN_LINE_WIDTH=100

FW_VGND0

MIN_NECK_WIDTH=12

VOLTAGE=0V

MIN_LINE_WIDTH=100

FW_VGND1

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

VOLTAGE=1.95V

+1_95V_FW_DVDD_TX0

MIN_LINE_WIDTH=25

VOLTAGE=3.3V

MIN_NECK_WIDTH=10

+3V_FW

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=1.95V

+1_95V_FW_PLL500VDD

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=1.95V

+1_95V_FW_PLL400VDD

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

VOLTAGE=1.95V

+1_95V_FW_PLLVDD

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

VOLTAGE=1.95V

+1_95V_FW_DVDD_PORT1

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

VOLTAGE=1.95V

+1_95V_FW_DVDD_RX0

MIN_NECK_WIDTH=10

VOLTAGE=3.3V

MIN_LINE_WIDTH=25

+3V_FW_AVDD

MIN_NECK_WIDTH=10

VOLTAGE=3.3V

MIN_LINE_WIDTH=25

+3V_FW_AVDD_PORT0

MIN_NECK_WIDTH=6

VOLTAGE=3.3V

MIN_LINE_WIDTH=25

+3V_FW_AVDD_PORT1

MIN_NECK_WIDTH=12

VOLTAGE=33V

MIN_LINE_WIDTH=100

+FW_VP0

MIN_NECK_WIDTH=12

VOLTAGE=33V

MIN_LINE_WIDTH=100

+FW_PWR_OR

MIN_LINE_WIDTH=25

VOLTAGE=3.3V

MIN_NECK_WIDTH=10

LM2594_IN

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=3.3V

+3V_FW_ESD

MIN_LINE_WIDTH=25

VOLTAGE=3.3V

MIN_NECK_WIDTH=10

+3V_FW_ESD_ILIM

VOLTAGE=12.8V

MIN_LINE_WIDTH=100

MIN_NECK_WIDTH=12

+FW_FUSE

VOLTAGE=12.8V

MIN_LINE_WIDTH=100

MIN_NECK_WIDTH=12

+FW_SW

MIN_NECK_WIDTH=12

VOLTAGE=33V

MIN_LINE_WIDTH=100

+FW_VP1

MIN_NECK_WIDTH=12

VOLTAGE=33V

MIN_LINE_WIDTH=100

+FW_PWR_PORTA

VOLTAGE=2.5V

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

+2_5V_MARVELL

MIN_LINE_WIDTH=25

MIN_NECK_WIDTH=8

VOLTAGE=1.0V

LTC3405_SW

VOLTAGE=1.0V

MIN_NECK_WIDTH=8

MIN_LINE_WIDTH=25

+1_0V_MARVELL

VOLTAGE=2.5V

MIN_LINE_WIDTH=25

MIN_NECK_WIDTH=8

+2_5V_MARVELL_AVDD

MIN_LINE_WIDTH=10

VOLTAGE=1.8V

MIN_LINE_WIDTH=25

VOLTAGE=12.8V

MIN_NECK_WIDTH=10

+12_8V_INV

MIN_LINE_WIDTH=10

VOLTAGE=1.8V

MIN_LINE_WIDTH=10 MIN_NECK_WIDTH=10

VOLTAGE=2.5V

MIN_LINE_WIDTH=10

MIN_NECK_WIDTH=10

VOLTAGE=1.8V

MIN_LINE_WIDTH=15 MIN_NECK_WIDTH=10

MIN_LINE_WIDTH=20 MIN_NECK_WIDTH=10

VOLTAGE=1.5V

+1_5V_GPU_VDD15

MIN_LINE_WIDTH=20 MIN_NECK_WIDTH=10

VOLTAGE=1.5V

+1_5V_AGP_GPU

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=2.5V

+GPU_MEMCORE

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=2.5V

GPU_MEM_IO_FLT

MIN_LINE_WIDTH=10

VOLTAGE=1.8V

MIN_LINE_WIDTH=15 MIN_NECK_WIDTH=10

MIN_NECK_WIDTH=10

VOLTAGE=2.5V

MIN_LINE_WIDTH=25

GPU_MEM_IO

MIN_NECK_WIDTH=10

VOLTAGE=3.3V

MIN_LINE_WIDTH=25

+3V_GPU

VOLTAGE=1.8V

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=15

MIN_LINE_WIDTH=10

VOLTAGE=3.3V

MIN_NECK_WIDTH=10

VOLTAGE=2.5V

MIN_LINE_WIDTH=30

+GPU_MEM

MIN_LINE_WIDTH=25

VOLTAGE=3.3V

MIN_NECK_WIDTH=8

+3V_GPU_FLT

VOLTAGE=1.2V

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=30

GPU_VCORE

MIN_NECK_WIDTH=6

MIN_LINE_WIDTH=15

VOLTAGE=1.5V

+1_5V_INTREPID_PLL2

MIN_LINE_WIDTH=25

VOLTAGE=3.3V

MIN_NECK_WIDTH=10

+HD_LOGIC_SLEEP

VOLTAGE=5V

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

+5V_SOUND_SLEEP

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

VOLTAGE=0V

FANL_GND

MIN_NECK_WIDTH=10

VOLTAGE=5V

MIN_LINE_WIDTH=25

+5V_INV_SW

VOLTAGE=4.6V

MIN_LINE_WIDTH=10

+4_6V_BU

VOLTAGE=5.4V

MIN_LINE_WIDTH=10

1772_DLOV

VOLTAGE=0V

MIN_LINE_WIDTH=25

GPU_TV_GND2

VOLTAGE=0V

MIN_LINE_WIDTH=25

TV_GND1

VOLTAGE=0V

MIN_LINE_WIDTH=25

TV_GND2

MIN_LINE_WIDTH=10

VOLTAGE=0V

KBD_LED2_OUT

VOLTAGE=3.3V

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

+3V_LCD_SW

VOLTAGE=5V

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=15

+5V_DDC_SLEEP

VOLTAGE=1.8V

MIN_LINE_WIDTH=15

MIN_NECK_WIDTH=10

+1_8V_GPU_PLL

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=10

VOLTAGE=12.6V

+BATT_VSNS

VOLTAGE=4.85V

MIN_LINE_WIDTH=10

+4_85V_RAW

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=1.5V

+1_5V_SLEEP_VIN

VOLTAGE=24V

MIN_LINE_WIDTH=50 MIN_NECK_WIDTH=10

+ADAPTER_SENSE

VOLTAGE=1.2V

MIN_LINE_WIDTH=15

MIN_NECK_WIDTH=10

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=1.5V

+1_5V_AGP

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=5V

+VPP_CBUS_SW

VOLTAGE=3.3V

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

+VCC_CBUS_SW

MIN_LINE_WIDTH=10

VOLTAGE=1.25V

INT_AGP_VREF

VOLTAGE=0V

MIN_LINE_WIDTH=8

UIDE_REF

VOLTAGE=0V

MIN_LINE_WIDTH=10

INT_MEM_REF_H

MIN_LINE_WIDTH=10

VOLTAGE=1.25V

INT_MEM_VREF

VOLTAGE=1.5V

MIN_LINE_WIDTH=15

MIN_NECK_WIDTH=6

+1_5V_INTREPID_PLL6

MIN_NECK_WIDTH=6

VOLTAGE=1.5V

MIN_LINE_WIDTH=15

+1_5V_INTREPID_PLL8

MIN_LINE_WIDTH=15

VOLTAGE=1.5V

MIN_NECK_WIDTH=5

+1_5V_INTREPID_PLL5

MIN_NECK_WIDTH=5

MIN_LINE_WIDTH=15

VOLTAGE=1.5V

+1_5V_INTREPID_PLL4

MIN_NECK_WIDTH=6

MIN_LINE_WIDTH=15

VOLTAGE=1.5V

+1_5V_INTREPID_PLL3

MIN_NECK_WIDTH=6

MIN_LINE_WIDTH=15

VOLTAGE=1.5V

+1_5V_INTREPID_PLL1

MIN_LINE_WIDTH=15

VOLTAGE=1.5V

MIN_NECK_WIDTH=10

+1_5V_INTREPID_PLL

MIN_NECK_WIDTH=10

VOLTAGE=2.5V

MIN_LINE_WIDTH=25

+2_5V_INTREPID

VOLTAGE=3.3V

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

+3V_INTREPID_USB

VOLTAGE=1.25V

MIN_LINE_WIDTH=10

DDR_VREF

MIN_LINE_WIDTH=10

VOLTAGE=24V

1772_DCIN

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=12.6V

+BATT_RSNS

VOLTAGE=24V

MIN_LINE_WIDTH=10

+ADAPTER_OR_BATT

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=12.6V

+BATT_24V_FUSE

MIN_LINE_WIDTH=25

VOLTAGE=12.6V

MIN_NECK_WIDTH=10

1772_LX

MIN_LINE_WIDTH=25

VOLTAGE=0V

MIN_NECK_WIDTH=10

BATT_NEG

MIN_LINE_WIDTH=30 MIN_NECK_WIDTH=10

VOLTAGE=0V

MAX1715_GND

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=20

VOLTAGE=5V

MAX1715_VCC

MIN_LINE_WIDTH=8

MAX1715_SKIP

MIN_LINE_WIDTH=8

VOLTAGE=2.0V

MAX1715_REF

MIN_LINE_WIDTH=8

MAX1715_TON

MIN_LINE_WIDTH=8

2_5V_ILIM

MIN_LINE_WIDTH=8

1_5V_ILIM

VOLTAGE=1.5V

MIN_LINE_WIDTH=20 MIN_NECK_WIDTH=10

1_5V_DL

VOLTAGE=1.5V

MIN_LINE_WIDTH=20 MIN_NECK_WIDTH=10

1_5V_DH

VOLTAGE=5V

MIN_LINE_WIDTH=15 MIN_NECK_WIDTH=10

1_5V_BOOST

VOLTAGE=5V

MIN_LINE_WIDTH=15 MIN_NECK_WIDTH=10

1_5V_BST

VOLTAGE=2.5V

MIN_LINE_WIDTH=20 MIN_NECK_WIDTH=10

2_5V_DL

VOLTAGE=2.5V

MIN_LINE_WIDTH=20 MIN_NECK_WIDTH=10

2_5V_DH

VOLTAGE=5V

MIN_LINE_WIDTH=15 MIN_NECK_WIDTH=10

2_5V_BOOST

VOLTAGE=5V

MIN_LINE_WIDTH=15 MIN_NECK_WIDTH=10

2_5V_BST

MIN_LINE_WIDTH=8

VOLTAGE=0V

VCORE_GNDDIV

MIN_LINE_WIDTH=8

VOLTAGE=1.4V

VCORE_SNS

MIN_LINE_WIDTH=8

VOLTAGE=0V

VCORE_GNDSNS

MIN_LINE_WIDTH=30

VOLTAGE=0V

VCORE_GND

MIN_LINE_WIDTH=8

VCORE_VGATE

MIN_LINE_WIDTH=8

VCORE_TIME

MIN_LINE_WIDTH=8

VOLTAGE=1.4V

VCORE_FB

MIN_LINE_WIDTH=8

VCORE_CC

MIN_LINE_WIDTH=8

VOLTAGE=5V

VCORE_TON

MIN_LINE_WIDTH=8

VCORE_ILIM

MIN_LINE_WIDTH=8

VCORE_REF

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=15

VOLTAGE=5V

VCORE_BST

VOLTAGE=5V

MIN_LINE_WIDTH=15 MIN_NECK_WIDTH=10

VCORE_BOOST

MIN_LINE_WIDTH=20 MIN_NECK_WIDTH=10

VCORE_DL

MIN_LINE_WIDTH=20 MIN_NECK_WIDTH=10

VCORE_DH

VOLTAGE=1.4V

MIN_LINE_WIDTH=200

MIN_NECK_WIDTH=10

VCORE_LX

VOLTAGE=5V

MIN_LINE_WIDTH=20 MIN_NECK_WIDTH=10

VCORE_VCC

MIN_LINE_WIDTH=8

1778_VRNG

MIN_LINE_WIDTH=8

1778_FCB

MIN_LINE_WIDTH=8

1778_VFB

MIN_LINE_WIDTH=8

1_5V_2_5V_OK

MIN_LINE_WIDTH=8

1778_ITH_RC

MIN_LINE_WIDTH=8

1778_ITH

MIN_LINE_WIDTH=8

1778_ION

MIN_LINE_WIDTH=8

LTC3411_SHDN

MIN_LINE_WIDTH=8

LTC3411_SYNC

MIN_LINE_WIDTH=8

LTC3411_ITH

MIN_LINE_WIDTH=8

LTC3411_ITH_RC

MIN_LINE_WIDTH=8

1_8V_VFB

VOLTAGE=0V

MIN_LINE_WIDTH=10

3707_SGND

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=15

VOLTAGE=1.2V

1V20_REF

VOLTAGE=0V

MIN_LINE_WIDTH=10

1625_SGND

MIN_LINE_WIDTH=10

VOLTAGE=5V

1625_INTVCC

MIN_LINE_WIDTH=10

VOLTAGE=5V

1625_EXTVCC

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=50

VOLTAGE=1.5V

1_5V_LX

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=1.5V

+1_5V_LDO

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

VOLTAGE=1.5V

+1_5V_MAIN

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=1.5V

+1_5V_SLEEP

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

VOLTAGE=3.3V

+3V_MAIN

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

VOLTAGE=5V

+5V_MAIN

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

VOLTAGE=12.8V

+PBUS

MIN_LINE_WIDTH=10

VOLTAGE=3.3V

+3V_PMU_ESR

MIN_LINE_WIDTH=10

VOLTAGE=0V

1772_GND

MIN_NECK_WIDTH=10

VOLTAGE=12.6V

MIN_LINE_WIDTH=25

+BATT_14V_FUSE

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=16.8V

+BATT_POS

MIN_LINE_WIDTH=50

VOLTAGE=24V

MIN_NECK_WIDTH=10

+ADAPTER

MIN_LINE_WIDTH=50

VOLTAGE=24V

MIN_NECK_WIDTH=10

+ADAPTER_SW

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=10

VOLTAGE=5V

3707_INTVCC

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=3.3V

3V_RSNS

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=3.3V

3V_SW

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=5V

5V_RSNS

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=5V

5V_SW

MIN_LINE_WIDTH=25

VOLTAGE=1.4V

MIN_NECK_WIDTH=10

CPU_VCORE_SLEEP

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=50

VOLTAGE=2.5V

2_5V_LX

MIN_LINE_WIDTH=8

VOLTAGE=1.5V

1_5V_FB

MIN_LINE_WIDTH=20 MIN_NECK_WIDTH=10

VOLTAGE=14V

1778_VIN

MIN_LINE_WIDTH=20 MIN_NECK_WIDTH=10

VOLTAGE=5V

1778_VCC

MIN_LINE_WIDTH=30 MIN_NECK_WIDTH=10

VOLTAGE=0V

1778_GND

MIN_LINE_WIDTH=15 MIN_NECK_WIDTH=10

VOLTAGE=5V

1778_BST

MIN_LINE_WIDTH=20 MIN_NECK_WIDTH=10

1778_TG

MIN_LINE_WIDTH=15 MIN_NECK_WIDTH=10

VOLTAGE=5V

1778_BST_RC

MIN_LINE_WIDTH=20 MIN_NECK_WIDTH=10

1778_BG

MIN_LINE_WIDTH=50 MIN_NECK_WIDTH=10

VOLTAGE=1.2V

GPU_VCORE_SW

MIN_LINE_WIDTH=10

VOLTAGE=24V

1625_VIN

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=12.8V

1625_VSW

VOLTAGE=1.8V

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

MAXBUS_SLEEP

MIN_LINE_WIDTH=20 MIN_NECK_WIDTH=10

VOLTAGE=3.3V

LTC3411_VCC

MIN_LINE_WIDTH=30 MIN_NECK_WIDTH=10

VOLTAGE=0V

LTC3411_GND

MIN_LINE_WIDTH=30 MIN_NECK_WIDTH=10

VOLTAGE=1.8V

1_8V_SW

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=20

LTC1962_INT_VIN

MIN_LINE_WIDTH=20 MIN_NECK_WIDTH=10

LTC1962_L3_VIN

MIN_LINE_WIDTH=20 MIN_NECK_WIDTH=10

LTC1962_L3_VOUT

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=20

LTC1962_1V5_VIN

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=20

LTC1962_1V5_VOUT

VOLTAGE=3.3V

MIN_LINE_WIDTH=10

+3V_PMU_AVCC

VOLTAGE=0V

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=12

ENET_CTAP_CHGND

VOLTAGE=5V

MIN_LINE_WIDTH=10

+5V_TPAD_SLEEP

MIN_NECK_WIDTH=10

VOLTAGE=5V

MIN_LINE_WIDTH=25

+5V_INV_UF_SW

VOLTAGE=5V

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=15

+5V_DDC_SLEEP_UF

VOLTAGE=3.3V

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=12

+3V_LCD

MIN_LINE_WIDTH=25

VOLTAGE=0V

GPU_TV_GND1

MIN_LINE_WIDTH=10

VOLTAGE=0V

KBD_LED1_OUT

VOLTAGE=0V

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

FANR_GND

MIN_NECK_WIDTH=15MIN_LINE_WIDTH=25

VOLTAGE=0V

SND_AGND

VOLTAGE=5V

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

+5V_HD_SLEEP

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=5V

+5V_SLEEP

MIN_LINE_WIDTH=25

VOLTAGE=1.8V

MIN_NECK_WIDTH=6

+1_8V_MAIN

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=1.8V

+1_8V_SLEEP

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

VOLTAGE=2.5V

+2_5V_SLEEP

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=24V

+24V_PBUS

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

VOLTAGE=12.6V

+BATT

MIN_LINE_WIDTH=25

VOLTAGE=2.5V

MIN_NECK_WIDTH=10

+2_5V_MAIN

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

VOLTAGE=3.3V

+3V_PMU

MIN_LINE_WIDTH=25

MIN_NECK_WIDTH=6

VOLTAGE=3.3V

+3V_SLEEP

MIN_LINE_WIDTH=15 MIN_NECK_WIDTH=10

VOLTAGE=2.5V

MIN_LINE_WIDTH=10

VOLTAGE=2.5V

VOLTAGE=1.8V

MIN_NECK_WIDTH=10

MIN_LINE_WIDTH=15

MIN_LINE_WIDTH=10

VOLTAGE=1.8V

19 19

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

FUNCTIONAL TEST POINTS

I271

I272

I273

I274

I275

I276

I277

I278

I279

I280

I281

I282

I283

I284

I285

I286

I287

I288

I289

I290

I291

I292

I293

I294

051-6598

4439

FUNC_TEST=YES

PCI_TRDY_L

KBD_X<3>

FUNC_TEST=YES

KBD_CONTROL_L

FUNC_TEST=YES

+3V_HALL_EFFECT

FANR_GND

FUNC_TEST=YES

FANL_TACH

FUNC_TEST=YES

FANL_GND

FUNC_TEST=YES

KBD_LED2_OUT

FUNC_TEST=YES

KBD_LED1_OUT

FUNC_TEST=YES

SUTRO_ALS_OUT

FUNC_TEST=YES

SUTRO_ALS_GAIN_SW

FUNC_TEST=YES

ADAPTER_DET

FUNC_TEST=YES

BATT_CLK

FUNC_TEST=YES

BT_USB_DM

FUNC_TEST=YES

SND_AMP_MUTE

FUNC_TEST=YES

EIDE_OPTICAL_ADDR<2>

FUNC_TEST=YES

KBD_X<6>

FUNC_TEST=YES

EIDE_OPTICAL_RD_L

FUNC_TEST=YES

EIDE_OPTICAL_DATA<15>

FUNC_TEST=YES

EIDE_OPTICAL_DATA<11>

FUNC_TEST=YES

KBD_X<7>

FUNC_TEST=YES

EIDE_OPTICAL_DMAACK_L

FUNC_TEST=YES

PCI_AD<31>

FUNC_TEST=YES

PCI_AD<29>

FUNC_TEST=YES

SLEEP_LED

LVDS_U0N

FUNC_TEST=YES

CHGND4

FUNC_TEST=YES

INT_I2C_CLK2

INT_I2C_DATA2

FUNC_TEST=YES

TV_Y

FUNC_TEST=YES

TV_COMP

FUNC_TEST=YES

SND_CLKOUT

FUNC_TEST=YES

SND_HP_SENSE_L

EIDE_OPTICAL_ADDR<0>

FUNC_TEST=YES

RJ45_DN<2>

FUNC_TEST=YES

RJ45_DP<2>

FUNC_TEST=YES

COMM_RXD

FUNC_TEST=YES

COMM_RTS_L

FUNC_TEST=YES

CHARGE_LED_L

FUNC_TEST=YES

KBD_NUMLOCK_LED

FUNC_TEST=YES

LID_CLOSED_L

FUNC_TEST=YES

+BATT_POS

FUNC_TEST=YES

COMM_GPIO_L

FUNC_TEST=YES

COMM_TXD_L

AIRPORT_PCI_REQ_L

FUNC_TEST=YES

PCI_CBE<3>

FUNC_TEST=YES

PCI_CBE<1>

FUNC_TEST=YES

+24V_PBUS

FUNC_TEST=YES

+3V_PMU

FUNC_TEST=YES

+PBUS

FUNC_TEST=YES

+5V_DDC_SLEEP

FUNC_TEST=YES

+5V_INV_SW

+5V_TPAD_SLEEP

FUNC_TEST=YES

+12_8V_INV

FUNC_TEST=YES

AIRPORT_PCI_GNT_L

FUNC_TEST=YES

AIRPORT_PCI_INT_L

FUNC_TEST=YES

BATT_NEG

FUNC_TEST=YES

BBANG_HRESET_L

FUNC_TEST=YES

BRIGHT_PWM

FUNC_TEST=YES

BT_USB_DP

FUNC_TEST=YES

CBUS_DET_1_L

FUNC_TEST=YES

CBUS_DET_2_L

FUNC_TEST=YES

CLKLVDS_LN

FUNC_TEST=YES

CLKLVDS_LP

FUNC_TEST=YES

CLKLVDS_UN

FUNC_TEST=YES

CLKLVDS_UP

FUNC_TEST=YES

COMM_RESET_L

COMM_RING_DET_L

FUNC_TEST=YES

COMM_SHUTDOWN

FUNC_TEST=YES

COMM_TRXC

FUNC_TEST=YES

CPU_CHKSTP_OUT_L

FUNC_TEST=YES

CPU_HRESET_L

FUNC_TEST=YES

CPU_SRESET_L

FUNC_TEST=YES

CPU_VCORE_SLEEP

FUNC_TEST=YES

DCDC_EN

FUNC_TEST=YES

DVI_DDC_CLK_UF

FUNC_TEST=YES

DVI_DDC_DATA_UF

FUNC_TEST=YES

DVI_HPD_UF

FUNC_TEST=YES

EIDE_OPTICAL_CS0_L

FUNC_TEST=YES

EIDE_OPTICAL_CS1_L

FUNC_TEST=YES

EIDE_OPTICAL_DATA<0>

FUNC_TEST=YES

EIDE_OPTICAL_DATA<1>

FUNC_TEST=YES

EIDE_OPTICAL_DATA<2>

FUNC_TEST=YES

EIDE_OPTICAL_DATA<3>

FUNC_TEST=YES

EIDE_OPTICAL_DATA<4>

FUNC_TEST=YES

EIDE_OPTICAL_DATA<5>

FUNC_TEST=YES

EIDE_OPTICAL_DATA<6>

FUNC_TEST=YES

EIDE_OPTICAL_DATA<7>

FUNC_TEST=YES

EIDE_OPTICAL_DATA<8>

EIDE_OPTICAL_DATA<9>

FUNC_TEST=YES

EIDE_OPTICAL_DATA<10>

FUNC_TEST=YES

EIDE_OPTICAL_DATA<12>

FUNC_TEST=YES

EIDE_OPTICAL_DATA<13>

FUNC_TEST=YES

EIDE_OPTICAL_DATA<14>

FUNC_TEST=YES

EIDE_OPTICAL_DMA_RQ

FUNC_TEST=YES

EIDE_OPTICAL_IOCHRDY

FUNC_TEST=YES

EIDE_OPTICAL_RST_L

FUNC_TEST=YES

EIDE_OPTICAL_WR_L

FUNC_TEST=YES

FW_TPI1N

FUNC_TEST=YES

FW_TPI1P

FUNC_TEST=YES

FW_TPO1N

FUNC_TEST=YES

FW_TPO1P

FUNC_TEST=YES

GPU_VCORE

FUNC_TEST=YES

INT_AUDIO_TO_SND

FUNC_TEST=YES

INT_I2C_CLK0

FUNC_TEST=YES

INT_I2C_CLK1

FUNC_TEST=YES

INT_I2C_DATA0

FUNC_TEST=YES

INT_I2C_DATA1

FUNC_TEST=YES

JTAG_ASIC_TCK

FUNC_TEST=YES JTAG_ASIC_TDI

FUNC_TEST=YES

JTAG_ASIC_TDO

FUNC_TEST=YES

JTAG_ASIC_TRST_L

FUNC_TEST=YES

JTAG_CPU_TCK

FUNC_TEST=YES JTAG_CPU_TDI

FUNC_TEST=YES

JTAG_CPU_TDO_TP

FUNC_TEST=YES JTAG_CPU_TMS

FUNC_TEST=YES

JTAG_CPU_TRST_L

FUNC_TEST=YES

KBD_COMMAND_L

FUNC_TEST=YES

KBD_FUNCTION_L

FUNC_TEST=YES

KBD_ID

KBD_SHIFT_L

FUNC_TEST=YES

KBD_X<0>

FUNC_TEST=YES

KBD_X<1>

FUNC_TEST=YES

KBD_X<2>

FUNC_TEST=YES

KBD_X<4>

FUNC_TEST=YES

KBD_X<5>

KBD_X<8>

FUNC_TEST=YES

KBD_X<9>

FUNC_TEST=YES

KBD_Y<0>

FUNC_TEST=YES

KBD_Y<1>

FUNC_TEST=YES

KBD_Y<2>

FUNC_TEST=YES

KBD_Y<3>

FUNC_TEST=YES

KBD_Y<4>

FUNC_TEST=YES

KBD_Y<5>

FUNC_TEST=YES

KBD_Y<6>

FUNC_TEST=YES

KBD_Y<7>

FUNC_TEST=YES

LEFT_USB_DM

FUNC_TEST=YES

LEFT_USB_DP

FUNC_TEST=YES

LVDS_DDC_CLK

FUNC_TEST=YES LVDS_DDC_DATA

FUNC_TEST=YES

LVDS_L0N

FUNC_TEST=YES

LVDS_L0P

FUNC_TEST=YES

LVDS_L1N

FUNC_TEST=YES

LVDS_L1P

FUNC_TEST=YES

LVDS_L2N

FUNC_TEST=YES

LVDS_L2P

FUNC_TEST=YES

LVDS_U0P

FUNC_TEST=YES

LVDS_U1N

FUNC_TEST=YES

LVDS_U1P

FUNC_TEST=YES

LVDS_U2N

FUNC_TEST=YES

LVDS_U2P

FUNC_TEST=YES

MAIN_RESET_L

FUNC_TEST=YES

MODEM_USB_DM

FUNC_TEST=YES

MODEM_USB_DP

FUNC_TEST=YES

NEC_LEFT_USB_OVERCURRENT

FUNC_TEST=YES

NEC_LEFT_USB_PWREN

FUNC_TEST=YES

NEC_RIGHT_USB_OVERCURRENT

FUNC_TEST=YES

NEC_RIGHT_USB_PWREN

FUNC_TEST=YES

PCI_AD<0>

FUNC_TEST=YES

PCI_AD<1>

FUNC_TEST=YES

PCI_AD<2>

FUNC_TEST=YES

PCI_AD<3>

FUNC_TEST=YES

PCI_AD<4>

FUNC_TEST=YES

PCI_AD<5>

FUNC_TEST=YES

PCI_AD<6>

FUNC_TEST=YES

PCI_AD<7>

FUNC_TEST=YES

PCI_AD<8>

FUNC_TEST=YES

PCI_AD<9>

FUNC_TEST=YES

PCI_AD<10>

PCI_AD<11>

FUNC_TEST=YES

PCI_AD<13>

FUNC_TEST=YES

PCI_AD<14>

FUNC_TEST=YES

PCI_AD<15>

FUNC_TEST=YES

PCI_AD<16>

FUNC_TEST=YES

PCI_AD<17>

FUNC_TEST=YES

PCI_AD<18>

FUNC_TEST=YES

PCI_AD<19>

PCI_AD<20>

FUNC_TEST=YES

PCI_AD<21>

FUNC_TEST=YES

PCI_AD<22>

FUNC_TEST=YES

PCI_AD<23>

PCI_AD<25>

FUNC_TEST=YES

PCI_AD<26>

PCI_AD<27>

FUNC_TEST=YES

PCI_AD<28>

FUNC_TEST=YES

PCI_AD<30>

FUNC_TEST=YES

PCI_CBE<0>

FUNC_TEST=YES

PCI_CBE<2>

FUNC_TEST=YES

PCI_DEVSEL_L

FUNC_TEST=YES

PCI_FRAME_L

FUNC_TEST=YES

PCI_IRDY_L

PCI_PAR

FUNC_TEST=YES

PCI_STOP_L

FUNC_TEST=YES

PMU_BATT_DET_L

FUNC_TEST=YES

PMU_KB_RESET_L

FUNC_TEST=YES

RF_DISABLE_L_SPN

FUNC_TEST=YES

RIGHT_USB_DM

FUNC_TEST=YES

RIGHT_USB_DP

FUNC_TEST=YES

ROM_RW_L

FUNC_TEST=YES

SND_HW_RESET_L

SND_LIN_SENSE_L

FUNC_TEST=YES

SND_SCLK

SND_SYNC

FUNC_TEST=YES

TMDS_CONN_CLKN

FUNC_TEST=YES

TMDS_CONN_CLKP

FUNC_TEST=YES

TMDS_DN<0>

FUNC_TEST=YES

TMDS_DN<1>

FUNC_TEST=YES

TMDS_DN<2>

FUNC_TEST=YES

TMDS_DP<0>

FUNC_TEST=YES

TMDS_DP<1>

FUNC_TEST=YES

TMDS_DP<2>

FUNC_TEST=YES

TPAD_F_RXD

FUNC_TEST=YES

TV_GND1

FUNC_TEST=YES

TV_GND2

FUNC_TEST=YES

VCORE_FB

FUNC_TEST=YES

VGA_B

FUNC_TEST=YES

VGA_G

VGA_HSYNC

FUNC_TEST=YES

VGA_R

FUNC_TEST=YES

VGA_VSYNC

FUNC_TEST=YES

TV_C

SND_TO_AUDIO

FUNC_TEST=YES

PCI_AD<24>

FUNC_TEST=YES

KBD_OPTION_L

FUNC_TEST=YES

TPAD_F_TXD

FUNC_TEST=YES

EIDE_OPTICAL_INT

FUNC_TEST=YES

BATT_DATA

FUNC_TEST=YES

RJ45_DN<0>

FUNC_TEST=YES

RJ45_DP<1>

FUNC_TEST=YES

FANR_PWM

FUNC_TEST=YES KBD_CAPSLOCK_LED

FUNC_TEST=YES

FANL_PWM

FUNC_TEST=YES

RJ45_DP<0>

FUNC_TEST=YES

AIRPORT_IDSEL

FUNC_TEST=YES

CLK33M_AIRPORT

FUNC_TEST=YES

ROM_CS_L

FUNC_TEST=YES

ROM_OE_L

FUNC_TEST=YES ROM_ONBOARD_CS_L

INT_MOD_DTI

FUNC_TEST=YES

JTAG_CPU_TRST_L

FUNC_TEST=YES

PWR_BUTTON_L

FUNC_TEST=YES

COMM_DTR_L

MOD_CLKOUT

FUNC_TEST=YES

MOD_BITCLK

FUNC_TEST=YES

MOD_DTO

FUNC_TEST=YES

1778_VFB

FUNC_TEST=YES

MOD_SYNC

FUNC_TEST=YES

RJ45_DN<3>

FUNC_TEST=YES

RJ45_DP<3>

FUNC_TEST=YES

RJ45_DN<1>

VCORE_VID2

FUNC_TEST=YES

VCORE_VID4

FUNC_TEST=YES

VCORE_VID3

FUNC_TEST=YES

VCORE_VID1

FUNC_TEST=YES

FW_TPO0R

VCORE_VID0

FUNC_TEST=YES

VCORE_MUX_EN

FUNC_TEST=YES

SLEEP

FUNC_TEST=YES

+1_8V_MAIN

FUNC_TEST=YES

EIDE_OPTICAL_ADDR<1>

SRCLK_TP

FUNC_TEST=YES

SRMOD_TP

FUNC_TEST=YES

TEB_TP

FUNC_TEST=YES

TEST_TP

FUNC_TEST=YES

SND_HP_MUTE_INV

FUNC_TEST=YES

FUNC_TEST=YES JTAG_ASIC_TMS

FUNC_TEST=YES

PCI_AD<12>

FUNC_TEST=YES

AIRPORT_CLKRUN_L

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

12/15/03

** RELEASED FOR EVT **

12/18/03

12/17/03

12/16/03

21) CHANGED MAX VIA COUNT ON ALL AGP STB NETS TO 5 TO CLEAR DRCS

20) CHANGED FIREWIRE OSCILLATOR (G1) TO NEW PREFERRED SUNNY PART

19) UPDATE DIFF NET_SPACING_TYPE PROPERTY ON POWER SUPPLY SENSE AND THERMAL DIODE DIFF PAIRS

18) CHANGED R657 (EXTPLL_SDWN_POL BOOT STRAP) TO NO STUFF AND REMOVED NO STUFF FROM R153

17) FIXED MISSED CONNECTION WITH MAXBUS_SLEEP TO CPU

16) CHANGED GPU_THERM_DM TO GPU_THERM_DM_TP

15) CHANGED GPU_THERM_DP TO GPU_THERM_DP_TP

14) CHANGED CPU_TEMP_DP TO CPU_THERM_DP

13) CHANGED CPU_TEMP_DM TO CPU_THERM_DM

12) ADDED R633 AS PULLUP ON JTAG_ASIC_TDI

11) CHANGED PIN 11 OF J11 TO NC

10) CHANGED PIN 4 (DCDC_EN) ON J11 TO NEC_RIGHT_USBOVERCURRENT

9) CHANGED JTAG_ASIC_TDI TO CONNECT TO ETHERNET PHY’S TDI

1) IMPORTED Q41 PRODUCTION RELEASE SCHEMATIC

2) CHANGED CPU (U43) TO A7PM

3) CHANGED PLL CONFIG STUFFING FOR NEW CPU

4) CHANGED U44 TO M11-CSP64 SYMBOL

5) ADDED CPU AVDD LDO (U6)

6) ADDED R284 AND R604 TO ADD OPTION FOR PD_L OF U42 (CLOCK CHIP) TO BE DRIVEN BY JTAG_ASIC_TDO FROM INTREPID

7) ADDED R608 TO DISCONNECT INT_GPIO0 FROM CG_FSEL

8) CHANGED JTAG_ASIC_TDO_TP TO JTAG_ASIC_TDO AND MOVED IT TO INTREPID’S TDO

12/11/03

REVISION HISTORY

051-6598

40 44

8 7

2 1

7 6

*** Signal Cross-Reference for the entire design ***

+1_0V_MARVELL 27D2< 38B3> +1_5V_AGP 12C5< 12D1< 12D4< 15D5< 16C8<

18C6< 18D6< 19A8< 19B4<> 19D5<>

21B8< 21D6< 38C3> +1_5V_AGP_GPU 21C5< 38C3> +1_5V_AGP_NECK 19B4<> 38B3> +1_5V_GPU_VDD15 19D3< 38C3> +1_5V_INTREPID_PLL 8D6< 12D4< 12D8< 14D6<> 38D3> +1_5V_INTREPID_PLL1 14C3< 38D3> +1_5V_INTREPID_PLL2 14D3< 38D3> +1_5V_INTREPID_PLL3 14D3< 38D3> +1_5V_INTREPID_PLL4 14D3< 38D3> +1_5V_INTREPID_PLL5 12D3< 38D3> +1_5V_INTREPID_PLL6 12D6< 38D3> +1_5V_INTREPID_PLL7 8D5< 38D3> +1_5V_INTREPID_PLL8 14D3< 38D3> +1_5V_LDO 35D8< 38D6> +1_5V_MAIN 38D6> +1_5V_SLEEP 38D6> +1_5V_SLEEP_NECK 21A3<> 38B3> +1_5V_SLEEP_VIN 35D8<> 38D6> +1_8V_ATI_PVDD 19C5<> 21B6< 21B6< 21D6<> 38C3> +1_8V_ATI_TPVDD 21D2<> +1_8V_DVO_F 21B2< +1_8V_GPU 18A7< 19D8< 20A5< 21A2< 21A6<

21B1< 21B6< 21C8< 21D6< 21D8< 38C3> +1_8V_GPU_AVDD 21D5< 38C3> +1_8V_GPU_AVDDQ 21D4< 21D7< 38C3> +1_8V_GPU_MEMPLL 21B5< 38C3> +1_8V_GPU_PLL 21D5< 38C3> +1_8V_GPU_PNLIO 21A5< 38C3> +1_8V_GPU_PNLPLL 21B5< 38C3> +1_8V_GPU_TP_PLL 21B4< 21D1< +1_8V_GPU_VDDDI 21C7< 21D4< 38C3> +1_8V_MAIN 38D6> 39A2> +1_8V_MAIN_LX_F 35A4<> +1_8V_PVDD_NECK 19B5<> 38B3> +1_8V_SLEEP 38D6> +1_8V_SLEEP_NECK 21A3<> 38B3> +1_95V_FW_DVDD 28C4< 28C7<> 28D5< 38A3> +1_95V_FW_DVDD_PORT1 28D6< 38A3> +1_95V_FW_DVDD_RX0 28C5< 38A3> +1_95V_FW_DVDD_TX0 28C5< 38A3> +1_95V_FW_PLL400VDD 28D5< 38A3> +1_95V_FW_PLL500VDD 28D5< 38A3> +1_95V_FW_PLLVDD 28D5< 28D7<> 38A3> +2_5V_CG_MAIN 14C6< 38A3> +2_5V_GPU 21A7< 21B6< 21D3< 21D7< 21D8<

38B3> +2_5V_GPU_A2VDD 21D4< 21D7< 38C3> +2_5V_GPU_PNLIO 21A5< 38C3> +2_5V_INTREPID 9A8< 10D3< 10D5< 10D6< 10D8< 15D7<

16B8< 38D3> +2_5V_MAIN 38D6> +2_5V_MARVELL 27B8< 27C4<> 38B3> +2_5V_MARVELL_AVDD 27C4< 38B3> +2_5V_SLEEP 38D6> +2_5V_SLEEP_NECK1 19C4<> 38B3> +2_5V_SLEEP_NECK2 21A3<> 38B3> +3V_ATI_OSC_SLEEP 18D2< 38C3> +3V_ATI_SS 18B2< 38C3> +3V_CG_PLL_MAIN 14C6< 38A3> +3V_FW 28A3< 28D7<> 29D5< 38A3> +3V_FW_AVDD 28C6< 38A3> +3V_FW_AVDD_PORT0 28C6< 38A3> +3V_FW_AVDD_PORT1 28C6< 38A3> +3V_FW_AVDD_PORT2 28D6< 38A3> +3V_FW_ESD 29B3<> 29D2<> 38B3> +3V_FW_ESD_ILIM 29D4< 38B3> +3V_FW_UF 28D7<> 38A3> +3V_GPU 12D1< 18B8< 18C5< 18C7< 18D6<

19C4< 19C6< 19C7< 19D7< 21A6< 21B1<

38C3> +3V_GPU_FLT 21B2< 38C3> +3V_GPU_SI 20C4< 20C8< 20D8< +3V_HALL_EFFECT 23C6<> 38B6> 39C4> +3V_INTREPID_USB 14C3< 38D3> +3V_LCD 22B4<> 38B6> +3V_LCD_SW 22A4<> 38B6> +3V_MAIN 38D6> +3V_NEC_VDD 26D7< 26D7< 38A3> +3V_PMU 38D6> 39A2> +3V_PMU_AVCC 25A4< 30B6< 30D5<> 38C6> +3V_PMU_ESR 32A2< 38C6> +3V_PMU_RESET 30B7< 34A3<> +3V_SI_AVCC 20C7< 38B3> +3V_SI_PLLVCC 20C7< 38B3> +3V_SI_VCC 20C6< 38B3> +3V_SLEEP 38D6> +3V_SLEEP_NECK 21A3<> 38B3> +3V_SLP_OK_L 33B4<> +3V_SLP_ON 33A5<> +4_6V_BU 32A3<> 33B7< 38C6> +4_85V_ESR 32A4< 38C6> +4_85V_RAW 30B4< 32A4<> 38C6> +5V_DDC_SLEEP 22D3<> 22D5<> 38B6> 39A2> +5V_DDC_SLEEP_UF 22D6< 38B6> +5V_HD_SLEEP 24D1<> 33A7<> 38C6> +5V_INV_SW 22B1<> 38B6> 39D1> +5V_INV_UF_SW 22B2<> 38B6> +5V_MAIN 38D6> +5V_SLEEP 38D6> +5V_SOUND_SLEEP 38B6> +5V_TPAD_SLEEP 23C7<> 38B6> 39C4> +12_8V_INV 22B1<> 38B6> 39A2> +24V_PBUS 38D6> 39B2> +ADAPTER 31D8<> 32B7< 38D6> +ADAPTER_ILIM 32B6<> 38C6> +ADAPTER_OR_BATT 32A5<> 38C6> +ADAPTER_SENSE 31D5<> 38C6> +ADAPTER_SW 31D6<> 38C6> +BATT 38D6> +BATT_14V_FUSE 31D1<> 38C6> +BATT_24V_FUSE 31B1< 31D2<> 38C6> +BATT_POS 31A4<> 38C6> 39C3> +BATT_RSNS 31B2< 38C6> +BATT_VSNS 31A4< 38C6> +FW_FUSE 29D7<> 38A3> +FW_PWR_OR 28B8< 28D8<> 29D5<> 38A3> +FW_PWR_PORTA 29C5< 38A3> +FW_SW 29D5<> 38A3> +FW_VP0 29C2<> 38A3> +FW_VP1 29A3<> 38A3> +GPU_MCLK 21C7< 21D4< 38C3> +GPU_MEM 18A6<> 18B8< 21B4< 21B7< 21C6<

21C8< 21D2< 38C3> +GPU_MEMCORE 21C5< 38C3> +GPU_VDD15_NECK 19B5<> 38B3> +GPU_VDD15_UF 19B5<> 19D4<> 38C3> +HD_LOGIC_SLEEP 24C2<> 38C6> +PBUS 38D6> 39B2> +VCC_CBUS_SW 17B1<> 17B2<> 17D2<> 38D3> +VPP_CBUS_SW 17B1<> 17B2<> 17D2<> 38C3> 1V20_REF 31C7< 32C8< 38D1> 1V65_REF 31A5< 1_5V_2_5V_OK 35C5> 38B1> 1_5V_BOOST 35C6<> 38C1> 1_5V_BST 35C5<> 38C1> 1_5V_DH 35C5<> 38C1> 1_5V_DL 35B5<> 38C1> 1_5V_FB 35B5< 35B7< 38C1> 1_5V_ILIM 35C5<> 38C1> 1_5V_LX 35B5<> 38C1> 1_5V_SLEEP_EN_L 35C7<> 35D7<> 1_8V_SLEEP_PWREN_L 35A3<> 1_8V_SW 35A5<> 38A1> 1_8V_VFB 38A1> 2_5V_BOOST 35C4<> 38D1> 2_5V_BST 35C4<> 38D1> 2_5V_DH 35C4<> 38D1> 2_5V_DL 35B4<> 38D1> 2_5V_ILIM 35C5<> 38C1> 2_5V_LX 35B4<> 38D1> 2_5V_SLEEP_PWREN_L 35C2<> 2_34V_REF 30A4< 3V_5V_OK 33B4<> 35A8<> 35D6< 3V_5V_OK_INV 35A8<> 3V_BG 33C4<> 3V_BOOST 33C4<> 3V_BOOST_ESR 33D3<> 3V_ITH 33C4<> 3V_ITH_RC 33C3< 3V_PMU_VTAP 32B3< 3V_RSNS 33D2< 38D1> 3V_RUNSS 33C4< 3V_SLEEP_PWREN_L 33A3<>

3V_SNSM 33C4< 37A2> 3V_SNSP 33C4< 37A2> 3V_SW 33C4<> 38D1> 3V_TG 33D4<> 3V_VOSNS 33C4<> 5V_BG 33C5<> 5V_BOOST 33C5<> 5V_BOOST_ESR 33D6<> 5V_HD_PWREN 33A8<> 5V_ITH 33C5<> 5V_ITH_RC 33C6< 5V_RSNS 33D7< 38D1> 5V_RUNSS 33C5< 5V_SLEEP_PWREN 33A8<> 5V_SNSM 33C5< 37A2> 5V_SNSP 33C5< 37A2> 5V_SW 33C5<> 38D1> 5V_TG 33C5<> 5V_VOSNS 33C5<> 1625_BG 32C5<> 1625_BST 32C5< 1625_BST_ESR 32C5<> 1625_COMP 31D2< 32C6< 1625_DIV 32C8< 1625_ENABLE 32D7<> 1625_ENABLE_L 32D6<> 1625_EXTVCC 32D5<> 38D1> 1625_FCB 32C6< 1625_INTVCC 32C5<> 38D1> 1625_RUNSS 32C6< 1625_SGND 32B7<> 38D1> 1625_TG 32C5<> 1625_VFB 32B5<> 1625_VIN 32C6< 38D1> 1625_VSW 32C4<> 38D1> 1772_ACIN 31B5< 1772_ACOK_L 31B5<> 31C4<> 1772_BST 31B4<> 1772_BST_ESR 31C3< 1772_CCI 31B5<> 1772_CCS 31B5< 1772_CCV 31B5<> 1772_CCV_RC 31B5< 1772_CELLS 31B4< 1772_CLS 31A4< 1772_CSIN 31B4<> 37A2> 1772_CSIP 31B4<> 37A2> 1772_CSSN 31C5< 37A2> 1772_CSSP 31C5< 37A2> 1772_DCIN 31B5< 38C6> 1772_DHI 31B4<> 1772_DLO 31B4<> 1772_DLOV 31B4<> 38C6> 1772_GND 31A5<> 38C6> 1772_ICHG 31B5<> 1772_ICTL 31B5<> 1772_IINP 31B5< 1772_LDO 31C4<> 38C6> 1772_LX 31B4<> 38C6> 1772_REF 31B5<> 1772_VCTL 31B5< 1778_BG 19A5<> 38B1> 1778_BST 19A5<> 38B1> 1778_BST_RC 19A4<> 38B1> 1778_FCB 19A5< 38B1> 1778_GND 19A5< 19A7<> 38B1> 1778_ION 19A5< 38B1> 1778_ITH 19A5<> 38B1> 1778_ITH_RC 19A7< 38B1> 1778_SHDN_L 19A6< 1778_SHDN_L_D3COLD 19A7<> 1778_TG 19A5<> 38B1> 1778_VCC 19A5<> 38B1> 1778_VFB 19A2< 19A5< 38B1> 39A1> 1778_VIN 19A5< 38B1> 1778_VRNG 19A5< 38B1> 3405_MODE 27D5< 3405_VFB 27D4<> 3707_FCB 33C5< 3707_FSET 33C5< 3707_INTVCC 33D4<> 38D1> 3707_SGND 33B5<> 38D1> 3707_STBY 33C5<> A29_CLS_ADJ 31A5<> A29_CURRENT_ADJ 31C4<> A29_DETECT 30A2< 31A5<> 31C4<> A29_DET_L 30A3< AB_SEL_LOW 34A6<> AC_DIV 31C8< AC_ENABLE_GATE 31D6<> AC_ENABLE_L 31C6<> AC_GTR_18V 31C4<> AC_IN 27B8<> 29C7< 30B3< 31C5<> 31C7<> AC_IN_FW_CNTL 29C7<> AC_IN_L 31C2<> 31C6<> AC_IN_L_RC 31C2<> ADAPTER_DET 30A4< 31D8<> 39C2> ADAPTER_I_REG 31D3<> ADT7460_ADR_EN_L 25B3<> ADT7460_FAN1_PWM 25B3<> ADT7460_FAN2_PWM 25B3<> ADT7460_THERM 25A5<> 25B3<> ADT7460_VCC 25C4< ADT7460_VCORE_MON 5C8<> 25B4<> AGP8X_DET_PU 18C6<> AGP_AD<0> 12D2<> 18C7<> AGP_AD<15..0> 37D5> AGP_AD<1> 12C2<> 18C7<> AGP_AD<2> 12C2<> 18C7<> AGP_AD<3> 12C2<> 18C7<> AGP_AD<4> 12C2<> 18C7<> AGP_AD<5> 12C2<> 18C7<> AGP_AD<6> 12C2<> 18C7<> AGP_AD<7> 12C2<> 18C7<> AGP_AD<8> 12C2<> 18C7<> AGP_AD<9> 12C2<> 18C7<> AGP_AD<10> 12C2<> 18C7<> AGP_AD<11> 12C2<> 18C7<> AGP_AD<12> 12C2<> 18C7<> AGP_AD<13> 12C2<> 18C7<> AGP_AD<14> 12C2<> 18C7<> AGP_AD<15> 12C2<> 18C7<> AGP_AD<16> 12C2<> 18C7<> AGP_AD<31..16> 37D5> AGP_AD<17> 12C2<> 18C7<> AGP_AD<18> 12C2<> 18C7<> AGP_AD<19> 12C2<> 18C7<> AGP_AD<20> 12C2<> 18C7<> AGP_AD<21> 12C2<> 18C7<> AGP_AD<22> 12C2<> 18C7<> AGP_AD<23> 12C2<> 18C7<> AGP_AD<24> 12C2<> 18C7<> AGP_AD<25> 12C2<> 18D7<> AGP_AD<26> 12C2<> 18D7<> AGP_AD<27> 12B2<> 18D7<> AGP_AD<28> 12B2<> 18D7<> AGP_AD<29> 12B2<> 18D7<> AGP_AD<30> 12B2<> 18D7<> AGP_AD<31> 12B2<> 18D7<> AGP_AD_STB<0> 12A2<> 12B2< 18D6<> 37D5> AGP_AD_STB<1> 12A2<> 12B2< 18D6<> 37D5> AGP_AD_STB_L<0> 12A2<> 12B2< 18D6<> 37D5> AGP_AD_STB_L<1> 12A2<> 12A2< 18D6<> 37D5> AGP_ATI_RESET_L 18B7< AGP_ATI_VREF 18B7< AGP_ATI_VREFG 18B7< AGP_BUSY_L 12C4<> 12D2< 18D6> AGP_CBE<0> 12B2<> 18B7<> AGP_CBE<1..0> 37D5> AGP_CBE<1> 12B2<> 18B7<> AGP_CBE<2> 12B2<> 18B7<> AGP_CBE<3..2> 37D5> AGP_CBE<3> 12B2<> 18C7<> AGP_DEVSEL_L 12B2<> 12C2< 18B7<> 37D5> AGP_FRAME_L 12B2<> 12C2< 18B7<> 37D5> AGP_GNT_L 12C2< 12D2<> 18B7< 37D5> AGP_INT_L 14B5<> 18B7<> AGP_IRDY_L 12B2<> 12C2< 18B7<> 37D5> AGP_PAR 12B2<> 18B7> 37D5> AGP_PIPE_L 12A2<> 12B2< AGP_RBF_L 12A2<> 12C2< 18C6> 37D5> AGP_REQ_L 12C2< 12D2<> 18B7<> 37D5> AGP_SBA<0> 12B2< 18C6> AGP_SBA<7..0> 37D5> AGP_SBA<1> 12B2<> 18C6> AGP_SBA<2> 12B2<> 18C6> AGP_SBA<3> 12B2<> 18C6> AGP_SBA<4> 12B2<> 18C6>

AGP_SBA<5> 12B2<> 18C6> AGP_SBA<6> 12B2<> 18C6> AGP_SBA<7> 12B2<> 18C6<> AGP_SB_STB 12B2<> 12B2< 18C6<> 37D5> AGP_SB_STB_L 12A2<> 12A2< 18C6<> 37D5> AGP_ST<0> 12A2<> 18C6< AGP_ST<1> 12A2<> 18C6< AGP_ST<2> 12A2<> 18C6< AGP_STOP_L 12B2<> 12C2< 18B7<> 37D5> AGP_STP_L 18C6< AGP_SUS_STAT_L_PU 18C6< AGP_TRDY_L 12B2<> 12C2< 18B7<> 37D5> AGP_WBF_L 12A4<> 12B2< 18B7> AIRPORT_CLKRUN_L 24C6<> 39C1> AIRPORT_IDSEL 24C5<> 39B1> AIRPORT_PCI_GNT_L 12D7<> 24D5<> 39C4> AIRPORT_PCI_INT_L 14B5<> 14D7< 24D5<> 39C4> AIRPORT_PCI_REQ_L 12A7< 12D7<> 24D6<> 39D4> AIRPORT_PME_L_TP 24D5<> AMP_CONTROL 25C5<> 25D5<> ATI_AGP_FBSKEW<0> 19C2< 19C7<> ATI_AGP_FBSKEW<1> 19C2< 19C7<> ATI_BUS_CFG<0> 19B2< 19C7<> ATI_BUS_CFG<1> 19B2< 19C7<> ATI_BUS_CFG<2> 19B2< 19C7<> ATI_CLK27M_IN 18C1< 19B7< ATI_CLK27M_OSC 18D2< ATI_CLK27M_OSC_SS 18B2< 18D1< ATI_DBI_HI_PU 18C6<> ATI_DBI_LO_PU 18C6<> ATI_GPIO7_SPN 19C7<> ATI_GPIO8_PD 19C7<> ATI_GPIO9_SPN 19C7<> ATI_GPIO10_SPN 19C7<> ATI_GPIO11_SPN 19C7<> ATI_GPIO12_SPN 19C7<> ATI_GPIO13_SPN 19C7<> ATI_HSYNC 19D5<> 22C8< ATI_MEMTEST 18A6<> ATI_MEMVMODE0 18A7< ATI_MEMVMODE1 18A7< ATI_OSC_OE 18D3< ATI_PVDD_BYP 21D6<> ATI_R2SET 19D6<> ATI_RSET 19D6<> ATI_RSTB_MSK 18C6<> ATI_SSCLK_IN 18B1< 19B7<> ATI_SSCLK_UF 18B1<> ATI_TESTEN 19B7< ATI_TMDS_CLKN 19B7> 20B4< ATI_TMDS_CLKP 19B7> 20B4< ATI_TMDS_DN<0> 19B7> 20B4< ATI_TMDS_DN<1> 19B7> 20A4< ATI_TMDS_DN<2> 19B7> 20A4< ATI_TMDS_DP<0> 19B7> 20B4< ATI_TMDS_DP<1> 19B7> 20A4< ATI_TMDS_DP<2> 19B7> 20A4< ATI_TPVDD_BYP 21D1<> ATI_VSYNC 19D5<> 22C8< ATI_X1CLK_SKEW<0> 19C2< 19C7<> ATI_X1CLK_SKEW<1> 19B2< 19C7<> BATTV_HIGH 31B7<> BATTV_LOW 31B8<> BATT_14PBUS_EN 31C1<> BATT_14V_GATE 31C1<> BATT_24PBUS_EN 31C2<> BATT_24V_GATE 31C1<> BATT_CLK 31A4<> 39C3> BATT_DATA 31A4<> 39C3> BATT_DIV 31A5< BATT_LOW 31A6<> BATT_LOW_L 31B6<> BATT_NEG 31A4<> 38C6> 39C3> BBANG_HRESET_L 23A4< 23C4<> 39C1> BBANG_JTAG_TCK 23B3< 23C4<> BBANG_TCK_EN 23B3< BCKFD_PROT_EN_L 31C6<> BCKFD_PROT_GATE 31D6<> BRIGHT_PWM 22A1<> 39A7> BRIGHT_PWM_UF 22A2<> BT_USB_DM 14B1< 24B2<> 37B2> 39B6> BT_USB_DP 14C1< 24B2<> 37B2> 39B6> CAPSLOCK_LED 23A8< CAPSLOCK_LED_L 23B8< 30C7< CBUS_ADDR<0> 17B1<> 17B4> CBUS_ADDR<1> 17B1<> 17B4> CBUS_ADDR<2> 17B1<> 17B4> CBUS_ADDR<3> 17B1<> 17B4> CBUS_ADDR<4> 17B1<> 17B4> CBUS_ADDR<5> 17B1<> 17B4> CBUS_ADDR<6> 17B1<> 17B4> CBUS_ADDR<7> 17B1<> 17B4> CBUS_ADDR<8> 17B1<> 17B4> CBUS_ADDR<9> 17B1<> 17B4> CBUS_ADDR<10> 17B4> 17C1<> CBUS_ADDR<11> 17B1<> 17B4> CBUS_ADDR<12> 17B1<> 17B4> CBUS_ADDR<13> 17B1<> 17B4> CBUS_ADDR<14> 17B1<> 17B4> CBUS_ADDR<15> 17B1<> 17B4> CBUS_ADDR<16> 17B1<> 17B4< CBUS_ADDR<17> 17B2<> 17B4> CBUS_ADDR<18> 17B2<> 17B4> CBUS_ADDR<19> 17B2<> 17B4> CBUS_ADDR<20> 17B2<> 17B4> CBUS_ADDR<21> 17B2<> 17B4> CBUS_ADDR<22> 17A4> 17B2<> CBUS_ADDR<23> 17A4> 17B2<> CBUS_ADDR<24> 17A4> 17B2<> CBUS_ADDR<25> 17A4> 17B2<> CBUS_ADDR_16_UF 17B5<> CBUS_BVD1_L 17B2<> 17C4< CBUS_BVD2_L 17B2<> 17C4< CBUS_CE1_L 17C1<> 17C4> CBUS_CE2_L 17B4> 17C2<> CBUS_DATA<0> 17A1<> 17A4<> CBUS_DATA<1> 17A1<> 17A4<> CBUS_DATA<2> 17A1<> 17A4<> CBUS_DATA<3> 17A4<> 17C1<> CBUS_DATA<4> 17A4<> 17C1<> CBUS_DATA<5> 17A4<> 17C1<> CBUS_DATA<6> 17A4<> 17C1<> CBUS_DATA<7> 17A4<> 17C1<> CBUS_DATA<8> 17A2<> 17A4<> CBUS_DATA<9> 17A2<> 17A4<> CBUS_DATA<10> 17A2<> 17A4<> CBUS_DATA<11> 17A4<> 17C2<> CBUS_DATA<12> 17A4<> 17C2<> CBUS_DATA<13> 17A4<> 17C2<> CBUS_DATA<14> 17A4<> 17C2<> CBUS_DATA<15> 17A4<> 17C2<> CBUS_DET_1_L 17C2<> 17C4< 39B8> CBUS_DET_2_L 17A2<> 17C4< 39B8> CBUS_INPACK_L 17B2<> 17B4< CBUS_INT_L 14B5<> 14B7< 17A7<> CBUS_IORD_L 17B2<> 17C4> CBUS_IOWR_L 17B2<> 17C4> CBUS_MFUNC1_PD 17A7< 17A7<> CBUS_MFUNC2_PD 17A7< 17A7<> CBUS_MFUNC3_PD 17A7< 17A7<> CBUS_MFUNC4_PD 17A7< 17A7<> CBUS_MFUNC5_PD 17A7< 17A7<> CBUS_MFUNC6_PD 17A7<> 17A7< CBUS_OE_L 17C1<> 17C4> CBUS_PCI_GNT_L 12D7<> 17A7< CBUS_PCI_IDSEL 17B7< CBUS_PCI_PERR_L 17B7<> 17D7< CBUS_PCI_REQ_L 12A7< 12D7<> 17A7> CBUS_PCI_RESET_L 17A7< CBUS_PCI_SERR_L 17B7> 17D7< CBUS_READY 17B1<> 17C4< CBUS_REG_L 17B2<> 17C4> CBUS_RESET_L 17B2<> 17C4> CBUS_SUSPEND_PU 17A7< 17D7< CBUS_VCCD0_L 17C4<> CBUS_VCCD1_L 17C4<> CBUS_VPPD0 17C4<> CBUS_VPPD1 17C5<> CBUS_VS1 17B2<> 17C4<> CBUS_VS2 17B2<> 17C4<> CBUS_WAIT_L 17B2<> 17B4< CBUS_WE_L 17B1<> 17C4> CBUS_WP_L 17A1<> 17B4< CG_ADDRSEL 14B7< CG_CLKOUT 14B6<> CG_FSEL 14B7< 14C5< CG_LOCK 14B7<> CG_RESET_L 14B7<

CG_SYSCLK_EN 14A6< 14B7< CHARGE_DISABLE 31A7<> CHARGE_LED_L 30C6<> 30D7< 31D8<> 39D2> CHGND1 38A6> CHGND2 38A6> CHGND3 38A6> CHGND4 38A6> 39B6> CHGND5 38A6> CHGND6 38A6> CLK10M_PMU_XIN 30B6< CLK10M_PMU_XOUT 30B6< CLK10M_PMU_XOUT_UF 30B7< CLK18M_INT_EXT 14A6<> 36B1> CLK18M_INT_XIN 14A5< 36B1> CLK18M_INT_XOUT 14A5<> 36B1> CLK18M_XTAL_IN 14A5< 36B1> CLK25M_ENET_XIN 27A7< 36B1> CLK25M_ENET_XOUT 27A7<> 36B1> CLK25M_XTAL_IN 27A7< CLK27M_GPU_XIN 36B1> CLK27M_GPU_XOUT 36B1> CLK27M_XTAL_IN 36B1> CLK32K_PMU_XIN 30B3<> CLK32K_PMU_XOUT 30B3<> CLK32K_PMU_XOUT_UF 30B2<> CLK33M_AIRPORT 12D8< 24D5<> 36C1> 39B1> CLK33M_AIRPORT_UF 12C7<> 36C1> CLK33M_CBUS 12D8< 17A7< 36C1> CLK33M_CBUS_UF 12C7<> 36C1> CLK33M_USB2 12C8< 26B7< 36C1> CLK33M_USB2_UF 12C7<> 36C1> CLK66M_AGP_15V_TP 12C4> CLK66M_GPU_AGP 12C8< 18B7< 36C1> CLK66M_GPU_AGP_UF 12C7<> 36C1> CLKENET_LINK_GBE_REF 13C5< 27C8< 36B1> CLKENET_LINK_GTX 13C5<> 36A1> CLKENET_LINK_RX 13D5< 27C8< 36B1> CLKENET_LINK_TX 13D5< 27D8< 36A1> CLKENET_PHY_GBE_REF 27C7<> 36B1> CLKENET_PHY_GTX 13C6< 27C7< 36A1> CLKENET_PHY_RX 27C7<> 36B1> CLKENET_PHY_TX 27D7<> 36B1> CLKFW_LINK_LCLK 13C3<> 36A1> CLKFW_LINK_PCLK 13C3<> 28C3< 36A1> CLKFW_PHY_LCLK 13C2< 28B8< 36A1> CLKFW_PHY_PCLK 28B4> 28C3< 36A1> CLKLVDS_LN 19B5> 22A4<> 37C2> 39B7> CLKLVDS_LP 19B5> 22A4<> 37C2> 39B7> CLKLVDS_UN 19B5> 22A4<> 37C2> 39B7> CLKLVDS_UP 19B5> 22A4<> 37C2> 39A7> COMM_DTR_L 14C2> 25D1<> 39B2> COMM_GPIO_L 14C2<> 25D2<> 39C2> COMM_RESET_L 14C5<> 25C4<> 39C4> COMM_RING_DET_L 14B5<> 14C7< 25C3<> 30C6<> 39C4> COMM_RTS_L 14C2> 25D1<> 39B2> COMM_RXD 14C2<> 25D1<> 39B2> COMM_SHUTDOWN 14C5<> 25C4<> 39C4> COMM_TRXC 14C2<> 25D2<> 39C2> COMM_TXD_L 14C2<> 25D2<> 39C2> COMP_DISABLE 22C2<> COMP_ENABLE 22C1<> COMP_RC 32C6< CPU_AACK_L 5A7< 8B6<> 8C2< 36D5> CPU_ADDR<0> 5C7<> 8D6<> CPU_ADDR<0..31> 36D5> CPU_ADDR<1> 5C7<> 8D6<> CPU_ADDR<2> 5C7<> 8D6<> CPU_ADDR<3> 5C7<> 8D6<> CPU_ADDR<4> 5C7<> 8D6<> CPU_ADDR<5> 5C7<> 8C6<> CPU_ADDR<6> 5C7<> 8C6<> CPU_ADDR<7> 5C7<> 8C6<> CPU_ADDR<8> 5C7<> 8C6<> CPU_ADDR<9> 5C7<> 8C6<> CPU_ADDR<10> 5B7<> 8C6<> CPU_ADDR<11> 5B7<> 8C6<> CPU_ADDR<12> 5B7<> 8C6<> CPU_ADDR<13> 5B7<> 8C6<> CPU_ADDR<14> 5B7<> 8C6<> CPU_ADDR<15> 5B7<> 8C6<> CPU_ADDR<16> 5B7<> 8C6<> CPU_ADDR<17> 5B7<> 8C6<> CPU_ADDR<18> 5B7<> 8C6<> CPU_ADDR<19> 5B7<> 8C6<> CPU_ADDR<20> 5B7<> 8C6<> CPU_ADDR<21> 5B7<> 8C6<> CPU_ADDR<22> 5B7<> 8C6<> CPU_ADDR<23> 5B7<> 8C6<> CPU_ADDR<24> 5B7<> 8C6<> CPU_ADDR<25> 5B7<> 8C6<> CPU_ADDR<26> 5B7<> 8C6<> CPU_ADDR<27> 5B7<> 8C6<> CPU_ADDR<28> 5B7<> 8C6<> CPU_ADDR<29> 5B7<> 8C6<> CPU_ADDR<30> 5B7<> 8C6<> CPU_ADDR<31> 5B7<> 8B6<> CPU_ARTRY_L 5A7<> 8B6<> 8D2< 36D5> CPU_AVDD 5C3< 38D3> CPU_AVDD_ADJ 5C2<> CPU_AVDD_PG 5C3<> CPU_AVDD_VIN 5C3< CPU_AVDD_VOUT 5C3<> CPU_BG_L 5C7< 8C2< 8D6<> 36D5> CPU_BR_L 5C7> 8D2< 8D6< 36D5> CPU_BUS_VSEL 5C4< 7A6< CPU_CHKSTP_OUT_L 5B4<> 5C2< 39D8> CPU_CHKS_L 5A4< 5D2< CPU_CI_L 5A7> 8B6<> 36D5> CPU_CLKOUT_SPN 5C4> CPU_CLK_EN 8A6< 30C4<> CPU_DATA<0> 6D8<> 8D4<> CPU_DATA<0..31> 36D5> CPU_DATA<1> 6D8<> 8D4<> CPU_DATA<2> 6D8<> 8D4<> CPU_DATA<3> 6D8<> 8D4<> CPU_DATA<4> 6D8<> 8D4<> CPU_DATA<5> 6D8<> 8D4<> CPU_DATA<6> 6D8<> 8D4<> CPU_DATA<7> 6D8<> 8D4<> CPU_DATA<8> 6D8<> 8D4<> CPU_DATA<9> 6D8<> 8D4<> CPU_DATA<10> 6C8<> 8D4<> CPU_DATA<11> 6C8<> 8D4<> CPU_DATA<12> 6C8<> 8C4<> CPU_DATA<13> 6C8<> 8C4<> CPU_DATA<14> 6C8<> 8C4<> CPU_DATA<15> 6C8<> 8C4<> CPU_DATA<16> 6C8<> 8C4<> CPU_DATA<17> 6C8<> 8C4<> CPU_DATA<18> 6C8<> 8C4<> CPU_DATA<19> 6C8<> 8C4<> CPU_DATA<20> 6C8<> 8C4<> CPU_DATA<21> 6C8<> 8C4<> CPU_DATA<22> 6C8<> 8C4<> CPU_DATA<23> 6C8<> 8C4<> CPU_DATA<24> 6C8<> 8C4<> CPU_DATA<25> 6C8<> 8C4<> CPU_DATA<26> 6C8<> 8C4<> CPU_DATA<27> 6C8<> 8C4<> CPU_DATA<28> 6C8<> 8C4<> CPU_DATA<29> 6C8<> 8C4<> CPU_DATA<30> 6C8<> 8C4<> CPU_DATA<31> 6C8<> 8C4<> CPU_DATA<32> 6C8<> 8C4<> 8D8< CPU_DATA<32..63> 36D5> CPU_DATA<33> 6C8<> 8C4<> 8D8< CPU_DATA<34> 6C8<> 8C4<> 8D8< CPU_DATA<35> 6C8<> 8C4<> 8D8< CPU_DATA<36> 6B8<> 8C4<> 8D8< CPU_DATA<37> 6B8<> 8C4<> 8D8< CPU_DATA<38> 6B8<> 8B4<> 8D8< CPU_DATA<39> 6B8<> 8B4<> 8D8< CPU_DATA<40> 6B8<> 8B4<> 8C8< CPU_DATA<41> 6B8<> 8B4<> 8C8< CPU_DATA<42> 6B8<> 8B4<> 8C8< CPU_DATA<43> 6B8<> 8B4<> 8C8< CPU_DATA<44> 6B8<> 8B4<> 8C8< CPU_DATA<45> 6B8<> 8B4<> 8B8< CPU_DATA<46> 6B8<> 8B4<> 8B8< CPU_DATA<47> 6B8<> 8B4<> 8B8< CPU_DATA<48> 6B8<> 8A8< 8B4<> CPU_DATA<49> 6B8<> 8A8< 8B4<> CPU_DATA<50> 6B8<> 8A8< 8B4<> CPU_DATA<51> 6B8<> 8A8< 8B4<> CPU_DATA<52> 6B8<> 8A8< 8B4<> CPU_DATA<53> 6B8<> 8A8< 8B4<> CPU_DATA<54> 6B8<> 8A8< 8B4<> CPU_DATA<55> 6B8<> 8A8< 8B4<>

CPU_DATA<56> 6B8<> 8B3< 8B4<> CPU_DATA<57> 6B8<> 8B3< 8B4<> CPU_DATA<58> 6B8<> 8B3< 8B4<> CPU_DATA<59> 6B8<> 8B3< 8B4<> CPU_DATA<60> 6B8<> 8B3< 8B4<> CPU_DATA<61> 6B8<> 8B3< 8B4<> CPU_DATA<62> 6A8<> 8B3< 8B4<> CPU_DATA<63> 6A8<> 8B3< 8B4<> CPU_DBG_L 5C4< 8A4<> 8C2< 36D5> CPU_DRDY_L 5C4> 8A4< 8C2< 36D5> CPU_DRDY_L_UF 36D5> CPU_DTI<0> 5C4< 8A4<> CPU_DTI<0..2> 36D5> CPU_DTI<1> 5C4< 8A4<> CPU_DTI<2> 5C4< 8A4<> CPU_EDTI 5B2< 5C4< CPU_EMODE0_L 5A4< 7A4< CPU_EMODE1_L 5A4< 5C2< CPU_GBL_L 5A7<> 8B6<> 36D5> CPU_HIT_L 5A7> 8B6< 8D2< 36D5> CPU_HRESET_INV 7A7<> CPU_HRESET_L 5B4< 5C2< 7A5< 7A8< 23A2<> 39C8> CPU_L1TSTCLK 5B2< 5B4< CPU_L2TSTCLK 5B4< 5C2< CPU_LSSD_MODE 5B4< 5C2< CPU_MCP_L 5B4< 5D2< CPU_M_DM 25A8< 25B6< CPU_M_DP 25B6< 25B8< CPU_PLL_CFG<0> 5C4< 7D3< CPU_PLL_CFG<1> 5C4< 7D3< CPU_PLL_CFG<2> 5C4< 7D3< CPU_PLL_CFG<3> 5C4< 7D3< CPU_PLL_CFG<4> 5C4< 7D3<> CPU_PLL_CFGEXT 7D4<> CPU_PLL_FS00 7C4<> CPU_PLL_FS01 7C4< CPU_PLL_FS10 7C4< CPU_PLL_STOP_BASE 7C7< CPU_PLL_STOP_OC 7C4<> 7C8<> 30B6<> CPU_PMONIN_L 5A4< 5C2< CPU_PULLDOWN 5A2< 5A4< 5A4< 5C7<> CPU_PULLUP 5A4< 5A4< 5C2< CPU_QACK_L 5B4< 8B6<> 36D5> CPU_QREQ_L 5B4> 8B6< 8C2< 36D5> CPU_SHD0_L 5A7<> 5D2< CPU_SHD1_L 5A7<> 5D2< CPU_SMI_L 5B4< 5C2< 30C4<> CPU_SRESET_L 5B2< 5B4< 39C8> CPU_SRWX_L 5A4< 5C2< CPU_TA_L 5B4< 8A4<> 8D2< 36D5> CPU_TBEN 5B4< 5D2< 8A6<> CPU_TBST_L 5A7> 8B6<> 36D5> CPU_TEA_L 5B4< 8A4<> 8C2< 36D5> CPU_THERM_DM 6A6<> 25A6< CPU_THERM_DP 6A6<> 25A6< CPU_TSIZ<0> 5A7> 8B6<> CPU_TSIZ<0..2> 36D5> CPU_TSIZ<1> 5A7> 8B6<> CPU_TSIZ<2> 5A7> 8B6<> CPU_TS_L 5C7<> 8D2< 8D6<> 36D5> CPU_TT<0> 5A7<> 8B6<> CPU_TT<0..4> 36C5> CPU_TT<1> 5A7<> 8B6<> CPU_TT<2> 5A7<> 8B6<> CPU_TT<3> 5A7<> 8B6<> CPU_TT<4> 5A7<> 8B6<> CPU_VCORE_HI_OC 7B8< 30D4<> 34C8< 34D7< CPU_VCORE_PWR_SEQ 34D8<> CPU_VCORE_SEQ 34D8< CPU_VCORE_SEQ_L 34D8< CPU_VCORE_SLEEP 5C3< 5D8<> 6C6<> 34C1< 34D2< 38D3>

39B2> CPU_VCORE_SLEEP_F 34C2<> CPU_VCORE_SNUB 34B3< CPU_WT_L 5A7> 8B6<> 36C5> CSLOT_ADDR3_SPN 13B7> CSLOT_ADDR4_SPN 13B7> CSLOT_ADDR5_SPN 13B7> CSLOT_ADDR6_SPN 13B7> CSLOT_ADDR7_SPN 13B7> CSLOT_ADDR8_SPN 13B7> CSLOT_ADDR9_SPN 13B7> CSLOT_CE1_L_SPN 13C7> CSLOT_CE2_L_SPN 13C7> CSLOT_IORD_L_SPN 13C7> CSLOT_IOWAIT_L_PU 13C7< CSLOT_IOWR_L_SPN 13C7> CSLOT_OE_L_SPN 13C7> CSLOT_WE_L_SPN 13C7> CURRENT_THRESHOLD 31C4< CY25811_S0 18B2< CY25811_S1 18B2< DCDC_EN 19A7<> 29C7<> 33B7<> 34C8<> 39C1> DCDC_EN_L 33B6< 33B7<> 35C7<> DDC_CLK_ISO 22D4<> DDR_VREF 11D1< 11D3<> 11D5<> 11D6<> 11D8<>

38D3> DVI_DDC_CLK 22D4<> DVI_DDC_CLK_UF 22C5<> 22D3<> 39C7> DVI_DDC_DATA 22C4<> DVI_DDC_DATA_UF 22C5<> 39C7> DVI_HPD 22C4<> DVI_HPD_DIV 22C3< DVI_HPD_UF 22C3< 22C5<> 39C7> DVI_TRUN_ON_ILIM 22D2< DVI_TURN_ON 22D3<> DVI_TURN_ON_BASE 22D2< EEPROM_ADDR 23D4< EEPROM_WP_PD 23D3<> EIDE_ADDR<0> 13B7> 24B8< EIDE_ADDR<2..0> 37B5> EIDE_ADDR<1> 13B7> 24B8< EIDE_ADDR<2> 13B7> 24B8< EIDE_CS0_L 13B7> 24B8< 37B5> EIDE_CS1_L 13B7> 24B8< 37B5> EIDE_DATA<0> 13C7<> 24C8< EIDE_DATA<15..0> 37B5> EIDE_DATA<1> 13C7<> 24C8< EIDE_DATA<2> 13C7<> 24C8< EIDE_DATA<3> 13C7<> 24C8< EIDE_DATA<4> 13C7<> 24C8< EIDE_DATA<5> 13B7<> 24B8< EIDE_DATA<6> 13B7<> 24C8< EIDE_DATA<7> 13B7<> 24C8< EIDE_DATA<8> 13B7<> 24D8< EIDE_DATA<9> 13B7<> 24D8< EIDE_DATA<10> 13B7<> 24D8< EIDE_DATA<11> 13B7<> 24D8< EIDE_DATA<12> 13B7<> 24D8< EIDE_DATA<13> 13B7<> 24C8< EIDE_DATA<14> 13B7<> 24C8< EIDE_DATA<15> 13B7<> 24C8< EIDE_DMACK_L 13A7<> 24A8< 37B5> EIDE_DMARQ 13A7< 24B8< 37B5> EIDE_INT 13A7< 24A8< 37B5> EIDE_IOCHRDY 13B7< 24A8< 37B5> EIDE_OPTICAL_ADDR<0> 24A5<> 24B7< 39A4> EIDE_OPTICAL_ADDR<2..0> 37B5> EIDE_OPTICAL_ADDR<1> 24A5<> 24B7< 39A4> EIDE_OPTICAL_ADDR<2> 24A6<> 24B7< 39A4> EIDE_OPTICAL_CS0_L 24A5<> 24B7< 37B5> 39D4> EIDE_OPTICAL_CS1_L 24A6<> 24B7< 37B5> 39D4> EIDE_OPTICAL_DATA<0> 24A5<> 24C7< 39C4> EIDE_OPTICAL_DATA<15..0> 37B5> EIDE_OPTICAL_DATA<1> 24A5<> 24C7< 39C4> EIDE_OPTICAL_DATA<2> 24A5<> 24C7< 39C4> EIDE_OPTICAL_DATA<3> 24A5<> 24C7< 39C4> EIDE_OPTICAL_DATA<4> 24A5<> 24C7< 39C4> EIDE_OPTICAL_DATA<5> 24A5<> 24B7< 39C4> EIDE_OPTICAL_DATA<6> 24A5<> 24C7< 39C4> EIDE_OPTICAL_DATA<7> 24A5<> 24C7< 39B4> EIDE_OPTICAL_DATA<8> 24A6<> 24D7< 39B4> EIDE_OPTICAL_DATA<9> 24A6<> 24D7< 39B4> EIDE_OPTICAL_DATA<10> 24A6<> 24D7< 39B4> EIDE_OPTICAL_DATA<11> 24A6<> 24D7< 39B4> EIDE_OPTICAL_DATA<12> 24A6<> 24D7< 39B4> EIDE_OPTICAL_DATA<13> 24A6<> 24C7< 39B4> EIDE_OPTICAL_DATA<14> 24A6<> 24C7< 39B4> EIDE_OPTICAL_DATA<15> 24A6<> 24C7< 39B4> EIDE_OPTICAL_DMAACK_L 24A6<> 24A7< 37A5> 39A4> EIDE_OPTICAL_DMA_RQ 24A6<> 24B7< 37A5> 39A4> EIDE_OPTICAL_INT 24A5<> 24A7< 37A5> 39D4> EIDE_OPTICAL_IOCHRDY 24A5<> 24A7< 37A5> 39D4> EIDE_OPTICAL_RD_L 24A6<> 24A7< 37B5> 39A4> EIDE_OPTICAL_RST_L 24A7< 24B5<> 37A5> 39D4> EIDE_OPTICAL_WR_L 24A5<> 24A7< 37A5> 39D4> EIDE_RD_L 13A7> 24A8< 37B5> EIDE_RST_L 13B7> 24A8< 37B5>

EIDE_WR_L 13A7> 24A8< 37B5> ENET_COL 13C5< 27B7> 37A5> ENET_COMA 27B7<> ENET_CRS 13C5< 27B7> 37A5> ENET_CTAP_CHGND 27A1< 38A6> ENET_ENERGY_DET 14B5<> 27B7<> ENET_HSDACM 27A7<> ENET_HSDACP 27A7<> ENET_LINK_RXD<0> 13C5< 27C7> ENET_LINK_RXD<7..0> 37A5> ENET_LINK_RXD<1> 13C5< 27C7> ENET_LINK_RXD<2> 13C5< 27C7> ENET_LINK_RXD<3> 13C5< 27B7> ENET_LINK_RXD<4> 13C5< 27B7> ENET_LINK_RXD<5> 13C5< 27B7> ENET_LINK_RXD<6> 13C5< 27B7> ENET_LINK_RXD<7> 13C5< 27B7> ENET_LINK_TXD<0> 13B4< 13D5> ENET_LINK_TXD<7..0> 37A5> ENET_LINK_TXD<1> 13B4< 13D5> ENET_LINK_TXD<2> 13B4< 13D5> ENET_LINK_TXD<3> 13B4< 13D5> ENET_LINK_TXD<4> 13B4< 13D5> ENET_LINK_TXD<5> 13B4< 13D5> ENET_LINK_TXD<6> 13A4< 13D5> ENET_LINK_TXD<7> 13A4< 13D5> ENET_LINK_TX_EN 13D5<> 37A5> ENET_LINK_TX_ER 13D5<> 37A5> ENET_MDC 13C5> 27B7< 37A5> ENET_MDIO 13C5<> 27B7<> 37A5> ENET_PHY_TXD<0> 13B5< 27C7< ENET_PHY_TXD<7..0> 37A5> ENET_PHY_TXD<1> 13B5< 27C7< ENET_PHY_TXD<2> 13B5< 27C7< ENET_PHY_TXD<3> 13B5< 27C7< ENET_PHY_TXD<4> 13B5< 27C7< ENET_PHY_TXD<5> 13B5< 27C7< ENET_PHY_TXD<6> 13A5< 27C7< ENET_PHY_TXD<7> 13A5< 27C7< ENET_PHY_TX_EN 13D6< 27C7< 37A5> ENET_PHY_TX_ER 13D6< 27C7< 37A5> ENET_RSET 27A5< ENET_RST_L 27B7< ENET_RX_DV 13D5< 27B7> 37A5> ENET_RX_ER 13C5< 27B7> 37A5> ENET_VSSC 27A7<> EXT_SWING 20A5<> FANL_GND 25A3<> 38B6> 39B3> FANL_PWM 25A3<> 25B2<> 39B3> FANL_TACH 25A3<> 25B2< 39B3> FANR_GND 25B2<> 38B6> 39B3> FANR_PWM 25A2<> 25B1<> 39B3> FANR_TACH 25B2< 25B2<> FB_4_85V_BU 32A5< FP_PWR_EN 19C6<> 22A6< 22B3<> FP_PWR_EN_L 22B3<> FWB_TPB0 28A3< FWB_TPB1 28A4< FWPLL_BYP 28C8<> FW_BIAS0 28A5<> FW_BIAS1 28A5<> FW_BMODE 28B7< FW_CORE_ADJ 28C8< FW_CORE_BYP 28C7<> FW_CPS 28B7< FW_INPUT_PD 28A7< FW_LINK_CNTL<0> 13C3<> 28C3< FW_LINK_CNTL<1..0> 37A5> FW_LINK_CNTL<1> 13C3<> 28C3< FW_LINK_DATA<0> 13D3<> 28B8< FW_LINK_DATA<7..0> 37A5> FW_LINK_DATA<1> 13D3<> 28B8< FW_LINK_DATA<2> 13D3<> 28B8< FW_LINK_DATA<3> 13D3<> 28A8< FW_LINK_DATA<4> 13C3<> 28A8< FW_LINK_DATA<5> 13C3<> 28A8< FW_LINK_DATA<6> 13C3<> 28A8< FW_LINK_DATA<7> 13C3<> 28A8< FW_LINK_LREQ 13C3<> 37A5> FW_LKON 13C3<> 28B5<> FW_OSC 28A4< 36A1> FW_OSC_EN 28A3< FW_PC_PD 28B7< FW_PC_PU 28B7< FW_PHY_CNTL<0> 28B4<> 28C3< FW_PHY_CNTL<1..0> 37A5> FW_PHY_CNTL<1> 28B4<> 28C3< FW_PHY_DATA<0> 28B8<> FW_PHY_DATA<7..0> 37A5> FW_PHY_DATA<1> 28B8<> FW_PHY_DATA<2> 28B8<> FW_PHY_DATA<3> 28A8<> FW_PHY_DATA<4> 28A8<> FW_PHY_DATA<5> 28A8<> FW_PHY_DATA<6> 28A8<> FW_PHY_DATA<7> 28A8<> FW_PHY_LPS 13C3<> 28B8< FW_PHY_LREQ 13C2< 28B8< 37A5> FW_PHY_PD 14C5< 28B8< FW_PHY_PD_INT 14A7< 14C5<> FW_PHY_RESET_L 28A8< FW_PINT 13C3<> 28B4> 37A5> FW_PLL_ADJ 28C7< FW_PORT1_SEL 28B6< FW_PWREN_L 29C6<> FW_PWR_GATE 29D6<> FW_R0 28A5<> FW_R1 28A5<> FW_TESTM 28A7< FW_TPA0N 28B1<> 29C4<> 37D2> FW_TPA0N_CONN 29C3<> FW_TPA0P 28B1<> 29C4<> 37D2> FW_TPA0P_CONN 29C3<> FW_TPA1N 28B1<> 29A4<> 37C2> FW_TPA1P 28B1<> 29A4<> 37C2> FW_TPB0N 28B1<> 29C4<> 37D2> FW_TPB0N_CONN 29C3<> FW_TPB0P 28B1<> 29C4<> 37D2> FW_TPB0P_CONN 29C3<> FW_TPB1N 28B1<> 29A4<> 37C2> FW_TPB1P 28B1<> 29A4<> 37C2> FW_TPB2_PD 28A5<> FW_TPI0N 37C2> FW_TPI0P 37C2> FW_TPI1N 29A3<> 37C2> 39D2> FW_TPI1P 29A3<> 37C2> 39D2> FW_TPO0N 37C2> FW_TPO0P 37C2> FW_TPO0R 29C2<> 38A3> 39A3> FW_TPO1N 29A3<> 37C2> 39D2> FW_TPO1P 29A3<> 37C2> 39D2> FW_VGND0 29C2<> 38A3> FW_VGND1 29A3<> 38A3> FW_VREG_PD 28A7< FW_XI 28A5<> 36A1> GAIN_SETTING2 23C7<> GPU_AGP_TEST 18D6< GPU_AUXWIN 19C5<> GPU_B 19D6<> 22D8< GPU_C 19D6<> 22A8< GPU_CLK27M_OUT 36C1> GPU_CLK27M_UF 36C1> GPU_COMP 19C6<> 22A8< GPU_CORE_OK 19A6<> 19D4<> 21D2<> 21D7<> GPU_DVI_DDC_CLK 19C5<> 22D3<> GPU_DVI_DDC_DATA 19C5<> 22C3<> GPU_DVOD<0> 19D7<> 20B7< GPU_DVOD<0..11> 37D5> GPU_DVOD<1> 19D7<> 20B7< GPU_DVOD<2> 19D7<> 20B7< GPU_DVOD<3> 19D7<> 20B7< GPU_DVOD<4> 19D7<> 20B7< GPU_DVOD<5> 19D7<> 20A7< GPU_DVOD<6> 19D7<> 20A7< GPU_DVOD<7> 19D7<> 20A7< GPU_DVOD<8> 19D7<> 20A7< GPU_DVOD<9> 19D7<> 20A7< GPU_DVOD<10> 19D7<> 20A7< GPU_DVOD<11> 19D7<> 20A7< GPU_DVOD_DE 19C7<> 20A7< GPU_DVO_CLKP 19C7<> 20A7< 36B1> GPU_DVO_HSYNC 19C7<> 20A7< 37C5> GPU_DVO_VSYNC 19C7<> 20A7< 37C5> GPU_FBCLK0 36B1> GPU_FBCLK0_L 36B1> GPU_FBCLK1 36B1> GPU_FBCLK1_L 36B1> GPU_G 19D6<> 22D8<

GPU_HPD 19C5< 22C3<> GPU_MEM_IO 38C3> GPU_MEM_IO_FLT 21C2< 38C3> GPU_R 19D6<> 22D8< GPU_SSCLK_IN 36B1> GPU_SSCLK_UF 36C1> GPU_THERM_DM_TP 18A6<> GPU_THERM_DP_TP 18A6<> GPU_TV_GND1 22B8<> 38B6> GPU_TV_GND2 22A8<> 38B6> GPU_VCORE 18A6< 19A3<> 19B5<> 19D4< 38C3>

39B2> GPU_VCORE_CNTL 19A3<> GPU_VCORE_CNTL_L 19A3< 19B7<> GPU_VCORE_NECK 19B5<> 38B3> GPU_VCORE_PWR_SEQ 19A8<> GPU_VCORE_SEQ 19A8< GPU_VCORE_SEQ_L 19A8< GPU_VCORE_SW 19A4<> 38B1> GPU_VCORE_VDDCI 18A5< 38C3> GPU_Y 19D6<> 22B8< HD_ADDR<0> 24C2<> 24C3< HD_ADDR<2..0> 37C5> HD_ADDR<1> 24C2<> 24C3< HD_ADDR<2> 24B3< 24C1<> HD_CS0_L 24C2<> 24C3< 37B5> HD_CS1_L 24B3< 24C1<> 37B5> HD_DATA<0> 24C2<> 24D3< HD_DATA<15..0> 37C5> HD_DATA<1> 24C2<> 24D3< HD_DATA<2> 24D2<> 24D3< HD_DATA<3> 24D2<> 24D3< HD_DATA<4> 24C3< 24D2<> HD_DATA<5> 24C3< 24D2<> HD_DATA<6> 24C3< 24D2<> HD_DATA<7> 24C3< 24D2<> HD_DATA<8> 24C3< 24D1<> HD_DATA<9> 24C3< 24D1<> HD_DATA<10> 24C3< 24D1<> HD_DATA<11> 24D1<> 24D3< HD_DATA<12> 24B3< 24D1<> HD_DATA<13> 24B3< 24D1<> HD_DATA<14> 24C1<> 24C3< HD_DATA<15> 24B3< 24C1<> HD_DIOR_L 24A3< 24C2<> 37B5> HD_DIOW_L 24A3< 24C1<> 37B5> HD_DMACK_L 24A3< 24C2<> 37B5> HD_DMARQ 13C6< 24C2<> 37B5> HD_INTRQ 13C6< 24C1<> 37B5> HD_IOCHRDY 24A3< 24C1<> 37B5> HD_RESET_L 24A3< 24D2<> 37B5> HIGH_VCORE 19A2<> HIGH_VCORE_DIV 19A3< HPD_4V_REF 22C3< HPD_BASE 22C1< HPD_ON 22C2<> HPD_ON_RC 22C2< HPD_PWR_SNS_EN 19C7<> 22C3<> HPD_PWR_SW 22C2<> IAC_FB 31D4< IAC_RC_COMP 31D4< INTREPID_ACS_REF 8A6< INT_AGPPVT 12D4<> INT_AGP_FB_IN 12C4< 36C1> INT_AGP_FB_OUT 12C4<> 36C1> INT_AGP_VREF 12B4< 12D4<> 18D5< 38D3> INT_AUDIO_TO_SND 14B2< 25D8< 39C6> INT_AUDIO_TO_SND_F 25D7<> 25D7< INT_CPUFB_IN 8A6< 8B6< 36D1> INT_CPUFB_IN_NORM 8A4< 36D1> INT_CPUFB_LONG 8A4< 36D1> INT_CPUFB_OUT 8A6<> 8A6< 36D1> INT_CPUFB_OUT_NORM 8A4< 36D1> INT_CPUFB_OUT_SHORT 8A5< 36D1> INT_DDRCLK2_N_TP 9B6<> INT_DDRCLK2_P_TP 9B6<> INT_DDRCLK5_N_TP 9B6<> INT_DDRCLK5_P_TP 9B6<> INT_ENET_RST_L 14B5<> 27B8< INT_EXTINT3_PU 14B5<> 14B7< INT_EXTINT8_PU 14B5<> 14C7< INT_EXTINT10_PU 14A7< 14B5<> INT_EXTINT11_PU 14A7< 14B5<> INT_EXTINT12_PU 14A7< 14B5<> INT_EXTINT13_PU 14B5<> 14B7< INT_EXTINT14_PU 14B5<> 14C7< INT_EXTINT16_PU 14B5<> 14B7< INT_GPIO0 14C5<> INT_GPIO1_PU 14C5<> 14C7< 34C8< INT_GPIO9_PU 14A7< 14B5<> INT_GPIO12_PU 14B5<> 14B7< INT_GPIO15_PU 14B5<> 14C7< INT_I2C_CLK0 11A3<> 11A8<> 13C2< 13C3<> 23D2<

23D4<> 39B8> INT_I2C_CLK1 13C2< 13C3<> 14B7< 25B4< 39B8> INT_I2C_CLK2 14A2<> 25C4<> 25D7<> 39C6> INT_I2C_DATA0 11A3<> 11A8<> 13C2< 13C3<> 23D2<>

23D4<> 39B8> INT_I2C_DATA1 13B2< 13C3<> 14B7< 25B4<> 39B8> INT_I2C_DATA2 14A2<> 25C4<> 25C7<> 39C6> INT_JTAG_TEI 13C2< 13C5< INT_MEM_REF_H 9B6< 38D3> INT_MEM_VREF 9A7< 9B6<> 38D3> INT_MOD_BITCLK_UF 14A3<> 14A7< INT_MOD_CLKOUT_UF 14A3<> 14B7< INT_MOD_DTI 14A2< 25C3<> 39B1> INT_MOD_DTI_UF 14A7< INT_MOD_DTO_UF 14A3<> 14B7< INT_MOD_SYNC_UF 14A3<> 14A7< INT_PCI_FB_IN 12C7< 36C1> INT_PCI_FB_OUT 12C7<> 36C1> INT_PEND_PROC_INT 14A5> 30C4<> INT_PROC_SLEEP_REQ_L 14A5< 30B4<> INT_PU_RESET_L 13D3< 25D4<> 30A2< 30C4<> INT_REF_CLK_IN 14A5< 14B5< 36C1> INT_REF_CLK_OUT 14A5> 14B7< 36C1> INT_RESET_L 9B3< 13D3< 30C7< 30D4<> INT_ROM_CS_L 12A6< 12C7> INT_ROM_OE_L 12A6< 12C7> INT_ROM_RW_L 12A6< 12C7> INT_SND_CLKOUT 14A3<> INT_SND_SCLK 14A3<> INT_SND_SYNC 14B3<> INT_SND_TO_AUDIO 14B3<> INT_SUSPEND_ACK_L 8B6> 30B6<> INT_SUSPEND_REQ_L 8B6< 30B6<> 30C7< INT_TST_MONIN_PD 13C2< 13C5< INT_TST_MONOUT_TP 13C5> INT_TST_PLLEN_PD 13C5< 13D2< INT_WATCHDOG_L 14A5> 30C6<> INV_ON_PWM 19C6<> 22A3< IO_RESET_L 17A7< 23D6< 26B8< 27B8< 30C6<>

30D7< JTAG_ASIC_TCK 13C5< 13D2< 27A5< 39D8> JTAG_ASIC_TDI 27A5< 27D7< 39D8> JTAG_ASIC_TDO 13C5> 13D2< 14A7< 39D8> JTAG_ASIC_TMS 13C5< 13D2< 27A5< 39D8> JTAG_ASIC_TRST_L 13C2< 13C5< 27A5< 39D8> JTAG_CPU_TCK 5B2< 5B4< 23B2> 39C8> JTAG_CPU_TDI 5B2< 5C4< 23D4<> 39C8> JTAG_CPU_TDO_TP 5C4> 39C8> JTAG_CPU_TMS 5B2< 5B4< 23C4<> 39C8> JTAG_CPU_TRST_L 5A3< 5B4< 23D4<> 39B1> 39C8> JTAG_ENET_TDO 13C5< 13D2< 27A5> KBD_CAPSLOCK_LED 23A7<> 39B4> KBD_COMMAND_L 23A5< 23A7<> 30C6<> 39B4> KBD_CONTROL_L 23A5< 23A7<> 30A8< 30C6<> 39B4> KBD_FUNCTION_L 23A5< 23A7<> 30B6<> 39B4> KBD_ID 23A7<> 23B5< 30B6<> 39C4> KBD_LED1_OUT 23A5<> 23A7<> 38B6> 39C2> KBD_LED2_OUT 23A5<> 23A7<> 38B6> 39C2> KBD_LED_EN 23A5<> KBD_LED_SET 23A5< KBD_NUMLOCK_LED 23B7<> 39C3> KBD_OPTION_L 23A5< 23B7<> 30A8< 30B6<> 39B4> KBD_SHIFT_L 23A5< 23B7<> 30A8< 30C6<> 39B4> KBD_X<0> 23A5< 23B7<> 30C6<> 39B4> KBD_X<1> 23A5< 23B7<> 30C6<> 39B4> KBD_X<2> 23B5< 23B7<> 30C6<> 39B4> KBD_X<3> 23B5< 23B7<> 30C6<> 39A4> KBD_X<4> 23B5< 23B7<> 30C6<> 39A4> KBD_X<5> 23B5< 23B7<> 30C6<> 39A4> KBD_X<6> 23B5< 23B7<> 30C6<> 39A4> KBD_X<7> 23B5< 23B7<> 30C6<> 39A4> KBD_X<8> 23B5< 23B7<> 30C6<> 39A4> KBD_X<9> 23B5< 23B7<> 30C6<> 39D3> KBD_Y<0> 23B7<> 30D6<> 39D3> KBD_Y<1> 23B7<> 30D6<> 39D3>

KBD_Y<2> 23B7<> 30D6<> 39D3> KBD_Y<3> 23B7<> 30D6<> 39D3> KBD_Y<4> 23B7<> 30D6<> 39D3> KBD_Y<5> 23B7<> 30D6<> 39D3> KBD_Y<6> 23B7<> 30C6<> 39C3> KBD_Y<7> 23B7<> 30C6<> 39C3> LCD_DIGON_L 22A6< LCD_PWREN_L 22A5<> LED_LINK10 27B5<> LED_LINK100 27B5<> LED_RX_SPN 27B5> LEFT_USB_DM 24B2<> 26B3< 37A2> 39D1> LEFT_USB_DP 24B2<> 26A3< 37A2> 39D1> LID_CLOSED_L 23A7<> 39C4> LM2594_IN 28D8<> 38B3> LT1962_INT_ADJ 14D6< LT1962_INT_BYP 14D6<> LTC1625_ITH 31D3<> LTC1962_1V5_VIN 38A1> LTC1962_1V5_VOUT 38A1> LTC1962_INT_VIN 14D7<> 38A1> LTC1962_L3_VIN 38A1> LTC1962_L3_VOUT 38A1> LTC3405_SW 27D4<> 38B3> LTC3411_GND 38A1> LTC3411_ITH 38A1> LTC3411_ITH_RC 38A1> LTC3411_SHDN 38A1> LTC3411_SYNC 38A1> LTC3411_VCC 38B1> LTC3412_GND 35A6<> LTC3412_ITH 35A6<> LTC3412_ITH_RC 35A6< LTC3412_PGOOD 35A4<> LTC3412_RT 35A6< LTC3412_RUNSS 35A6<> LTC3412_SYNC 35A6<> LTC3412_VFB 35A6<> LTC3412_VFB_DIV 35A6< LTC3707_START_RC 33B6<> LVDS_DDC_CLK 19C5<> 22B5<> 39A7> LVDS_DDC_DATA 19C5<> 22B5<> 39A7> LVDS_L0N 19B5> 22B4<> 37C2> 39C7> LVDS_L0P 19B5> 22B4<> 37C2> 39C7> LVDS_L1N 19B5> 22B4<> 37C2> 39C7> LVDS_L1P 19B5> 22B4<> 37C2> 39C7> LVDS_L2N 19B5> 22B4<> 37C2> 39C7> LVDS_L2P 19B5> 22B4<> 37C2> 39C7> LVDS_L3N_TP 19B5> LVDS_L3P_TP 19B5> LVDS_U0N 19C5> 22A4<> 37C2> 39B7> LVDS_U0P 19C5> 22A4<> 37C2> 39B7> LVDS_U1N 19C5> 22A4<> 37C2> 39B7> LVDS_U1P 19C5> 22A4<> 37C2> 39B7> LVDS_U2N 19B5> 22A4<> 37B2> 39B7> LVDS_U2P 19B5> 22A4<> 37B2> 39B7> LVDS_U3N_TP 19B5> LVDS_U3P_TP 19B5> MAIN_RESET_L 14C7< 17A7< 17D5< 18C8< 20B8<

24D6<> 26B8< 30D4<> 30D7< 39C1> MAX1715_FB2 35B1< 35B4< MAX1715_GND 35B5<> 35C5< 38C1> MAX1715_ON_RC 35C7<> MAX1715_REF 35B5<> 38C1> MAX1715_SKIP 35C4< 38C1> MAX1715_TON 35C5< 38C1> MAX1715_VCC 35D5< 38C1> MAX1717_AB_SEL 34A7< 34C6< MAX4172_OUT 31D4<> MAXBUS_SLEEP 5A2< 5D1< 5D5< 7B7< 7D8< 8B8< 8C3<

8C8< 8D1< 8D8< 15D8< 16D8< 23B3<

23B3< 34D8< 38D3> MDI0_PD 27B4< MDI1_PD 27B4< MDI2_PD 27B4< MDI3_PD 27B3< MDI_M<0> 27B5<> 37D2> MDI_M<1> 27B5<> 37D2> MDI_M<2> 27B5<> 37D2> MDI_M<3> 27B5<> 37D2> MDI_P<0> 27B5<> 37D2> MDI_P<1> 27B5<> 37D2> MDI_P<2> 27B5<> 37D2> MDI_P<3> 27B5<> 37D2> MEM_ADDR<0> 9B5< 9D6<> MEM_ADDR<12..0> 36A5> MEM_ADDR<1> 9B5< 9D6<> MEM_ADDR<2> 9B5< 9D6<> MEM_ADDR<3> 9B5< 9D6<> MEM_ADDR<4> 9B5< 9D6<> MEM_ADDR<5> 9B5< 9D6<> MEM_ADDR<6> 9B5< 9D6<> MEM_ADDR<7> 9B5< 9D6<> MEM_ADDR<8> 9B5< 9D6<> MEM_ADDR<9> 9A5< 9D6<> MEM_ADDR<10> 9A5< 9D6<> MEM_ADDR<11> 9A5< 9D6<> MEM_ADDR<12> 9A5< 9D6<> MEM_BA<0> 9A5< 9D6<> MEM_BA<1..0> 36A5> MEM_BA<1> 9A5< 9C6<> MEM_CAS_L 9A5< 9C6<> 36A5> MEM_CKE<0> 9B6<> 9C5< MEM_CKE<3..0> 36A5> MEM_CKE<1> 9B6<> 9C5< MEM_CKE<2> 9B6<> 9C5< MEM_CKE<3> 9B6<> 9C5< MEM_CS_L<0> 9C5< 9C6<> MEM_CS_L<3..0> 36A5> MEM_CS_L<1> 9C5< 9C6<> MEM_CS_L<2> 9C5< 9C6<> MEM_CS_L<3> 9C5< 9C6<> MEM_DATA<0> 9D8<> 10C7<> MEM_DATA<7..0> 36C5> MEM_DATA<1> 9D8<> 10C7<> MEM_DATA<2> 9D8<> 10C7<> MEM_DATA<3> 9D8<> 10C7<> MEM_DATA<4> 9D8<> 10C7<> MEM_DATA<5> 9D8<> 10C7<> MEM_DATA<6> 9D8<> 10C7<> MEM_DATA<7> 9D8<> 10C7<> MEM_DATA<8> 9D8<> 10C7<> MEM_DATA<15..8> 36C5> MEM_DATA<9> 9D8<> 10C7<> MEM_DATA<10> 9D8<> 10C7<> MEM_DATA<11> 9D8<> 10C7<> MEM_DATA<12> 9D8<> 10B7<> MEM_DATA<13> 9C8<> 10B7<> MEM_DATA<14> 9C8<> 10B7<> MEM_DATA<15> 9C8<> 10B7<> MEM_DATA<16> 9C8<> 10C5<> MEM_DATA<31..16> 36C5> MEM_DATA<17> 9C8<> 10C5<> MEM_DATA<18> 9C8<> 10C5<> MEM_DATA<19> 9C8<> 10C5<> MEM_DATA<20> 9C8<> 10C5<> MEM_DATA<21> 9C8<> 10C5<> MEM_DATA<22> 9C8<> 10C5<> MEM_DATA<23> 9C8<> 10C5<> MEM_DATA<24> 9C8<> 10C5<> MEM_DATA<25> 9C8<> 10C5<> MEM_DATA<26> 9C8<> 10C5<> MEM_DATA<27> 9C8<> 10C5<> MEM_DATA<28> 9C8<> 10C5<> MEM_DATA<29> 9C8<> 10B5<> MEM_DATA<30> 9C8<> 10B5<> MEM_DATA<31> 9C8<> 10B5<> MEM_DATA<32> 9C8<> 10C3<> MEM_DATA<47..32> 36B5> MEM_DATA<33> 9C8<> 10C3<> MEM_DATA<34> 9C8<> 10C3<> MEM_DATA<35> 9C8<> 10C3<> MEM_DATA<36> 9C8<> 10C3<> MEM_DATA<37> 9C8<> 10C3<> MEM_DATA<38> 9C8<> 10C3<> MEM_DATA<39> 9B8<> 10C3<> MEM_DATA<40> 9B8<> 10C3<> MEM_DATA<41> 9B8<> 10C3<> MEM_DATA<42> 9B8<> 10C3<> MEM_DATA<43> 9B8<> 10C3<> MEM_DATA<44> 9B8<> 10C3<> MEM_DATA<45> 9B8<> 10B3<> MEM_DATA<46> 9B8<> 10B3<> MEM_DATA<47> 9B8<> 10B3<> MEM_DATA<48> 9B8<> 10C1<> MEM_DATA<55..48> 36B5> MEM_DATA<49> 9B8<> 10C1<> MEM_DATA<50> 9B8<> 10C1<>

MEM_DATA<51> 9B8<> 10C1<> MEM_DATA<52> 9B8<> 10C1<> MEM_DATA<53> 9B8<> 10C1<> MEM_DATA<54> 9B8<> 10C1<> MEM_DATA<55> 9B8<> 10C1<> MEM_DATA<56> 9B8<> 10C1<> MEM_DATA<63..56> 36A5> MEM_DATA<57> 9B8<> 10C1<> MEM_DATA<58> 9B8<> 10C1<> MEM_DATA<59> 9B8<> 10C1<> MEM_DATA<60> 9B8<> 10C1<> MEM_DATA<61> 9B8<> 10B1<> MEM_DATA<62> 9B8<> 10B1<> MEM_DATA<63> 9B8<> 10B1<> MEM_DQM<0> 9C6<> 10C7<> 36C5> MEM_DQM<1> 9C6<> 10B7<> 36C5> MEM_DQM<2> 9C6<> 10C5<> MEM_DQM<3..2> 36B5> MEM_DQM<3> 9C6<> 10B5<> MEM_DQM<4> 9C6<> 10C3<> MEM_DQM<5..4> 36B5> MEM_DQM<5> 9C6<> 10B3<> MEM_DQM<6> 9C6<> 10C1<> 36B5> MEM_DQM<7> 9C6<> 10B1<> 36A5> MEM_DQS<0> 9C6<> 10C7<> 36C5> MEM_DQS<1> 9C6<> 10B7<> 36C5> MEM_DQS<2> 9C6<> 10C5<> MEM_DQS<3..2> 36B5> MEM_DQS<3> 9C6<> 10B5<> MEM_DQS<4> 9C6<> 10C3<> MEM_DQS<5..4> 36B5> MEM_DQS<5> 9C6<> 10B3<> MEM_DQS<6> 9C6<> 10C1<> 36B5> MEM_DQS<7> 9C6<> 10B1<> 36A5> MEM_MUXSEL_H<0> 9B6<> 10A6< MEM_MUXSEL_H<1..0> 36A5> MEM_MUXSEL_H<1> 9B6<> 10A4< MEM_MUXSEL_L<0> 9B6<> 10A6< MEM_MUXSEL_L<1..0> 36A5> MEM_MUXSEL_L<1> 9B6<> 10A4< MEM_RAS_L 9A5< 9C6<> 36A5> MEM_WE_L 9A5< 9C6<> 36A5> MLB_ALS_GAIN_SW 23C4<> 23C8<> MLB_ALS_OP_COMP 23D7< MLB_ALS_OP_IN 23D7< MLB_ALS_OUT 23C4<> 23D6< MLB_ALS_OUT_FB 23D7<> MLB_PHOTODIODE 23D8<> MODEM_USB_DM 14B1< 25C3<> 37A2> 39B6> MODEM_USB_DP 14B1< 25C3<> 37A2> 39B6> MOD_BITCLK 14A2< 25C3<> 39B1> MOD_CLKOUT 14A2< 25C4<> 39A1> MOD_DTO 14A2< 25C4<> 39A1> MOD_SYNC 14A2< 25C3<> 39A1> MPIC_CPU_INT_L 5B2< 5B4< 14B5> NEC_AMC_TP 26A5< NEC_AVDD 26D6< 38A3> NEC_AVSS_F 26A5< 26B4< NEC_CRUN_L 26A7<> NEC_IDSEL 26B7< NEC_IO_RESET_L 26B7< 26B7< NEC_LEFT_USB_OVERCURRENT 24B2<> 26C1< 39D1> NEC_LEFT_USB_PWREN 24B2<> 26B5<> 39D1> NEC_LEGC 26A7< NEC_MAIN_RESET_L 26A7< 26B7< NEC_NANDTESTEN_TP 26A5< NEC_NANDTESTOUT_TP 26A4<> NEC_NC1_TP 26B5<> NEC_NC2_TP 26B5<> NEC_OCI<1> 26B5< 26C3< NEC_OCI<2> 26B5< 26C3< NEC_OCI<3> 26B5< NEC_OCI<4> 26B5< NEC_OCI<5> 26B5< NEC_PCI_INTA_L 26A7< 26B7> NEC_PCI_INTB_L 26A7< 26B7> NEC_PCI_INTC_L 26A7< 26B7> NEC_PCI_PERR_L 26B7<> 26C8< NEC_PCI_SERR_L 26B7> 26C8< NEC_PME_L 26A7> 26B7< NEC_PPON3_TP 26B5> NEC_PPON4_TP 26B5> NEC_PPON5_TP 26B5> NEC_RIGHT_USB_OVERCURRENT 26C1< 32B7<> 39C1> NEC_RIGHT_USB_PWREN 26B5<> 32A7<> 39C1> NEC_RREF 26B5<> NEC_SMI_L_TP 26A7> NEC_USB_DAM 26B4< 26C3<> 37B2> NEC_USB_DAP 26A4< 26C4<> 37B2> NEC_USB_DBM 26A4< 26C3<> 37B2> NEC_USB_DBP 26A4< 26C3<> 37B2> NEC_USB_RSDM1 26C5<> 37B2> NEC_USB_RSDM2 26C5<> 37B2> NEC_USB_RSDP1 26C5<> 37B2> NEC_USB_RSDP2 26C5<> 37B2> NEC_XT1 26D5< 36B1> NEC_XT2 26D5<> 36B1> NEC_XT2_R 26D4< NTEST1_TP 26B5< NUMLOCK_LED 23B8< NUMLOCK_LED_L 23B8< 30C7< OVER_18V_ADJ 31C3<> PCI1510_VR_EN_L 17C7< PCI_AD<0> 9C3< 12D6<> 17C7<> 24B5<> 26D7<>

39B6> PCI_AD<31..0> 37C5> PCI_AD<1> 9C3< 12D6<> 17C7<> 24B6<> 26D7<>

39A6> PCI_AD<2> 9C3< 12D6<> 17C7<> 24C5<> 26D7<>

39A6> PCI_AD<3> 9C3< 12D6<> 17C7<> 24C6<> 26C7<>

39A6> PCI_AD<4> 9C3< 12D6<> 17C7<> 24C5<> 26C7<>

39A6> PCI_AD<5> 9C3< 12D6<> 17C7<> 24C6<> 26C7<>

39A6> PCI_AD<6> 9C3< 12C6<> 17C7<> 24C5<> 26C7<>

39A6> PCI_AD<7> 9C3< 12C6<> 17C7<> 24C6<> 26C7<>

39D5> PCI_AD<8> 9C3< 12C6<> 17C7<> 24C6<> 26C7<>

39D5> PCI_AD<9> 9C3< 12C6<> 17C7<> 24C5<> 26C7<>

39D5> PCI_AD<10> 9C3< 12C6<> 17C7<> 24C6<> 26C7<>

39D5> PCI_AD<11> 9C3< 12C6<> 17C7<> 24C5<> 26C7<>

39D5> PCI_AD<12> 9C3< 12C6<> 17C7<> 24C6<> 26C7<>

39D5> PCI_AD<13> 9C3< 12C6<> 17C7<> 24C5<> 26C7<>

39C5> PCI_AD<14> 9C3< 12C6<> 17C7<> 24C6<> 26C7<>

39C5> PCI_AD<15> 9C3< 12C6<> 17C7<> 24C5<> 26C7<>

39C5> PCI_AD<16> 9C3< 12C6<> 17C7<> 24C5<> 26C7<>

39C5> PCI_AD<17> 9C3< 12C6<> 17C7<> 24C6<> 26C7<>

39C5> PCI_AD<18> 9C3< 12C6<> 17B7<> 24C5<> 24D4<

26C7<> 39C5> PCI_AD<19> 9C3< 12C6<> 17B7<> 24C6<> 26C7<>

39C5> PCI_AD<20> 9B3< 12C6<> 17B7<> 24C5<> 26C7<>

39C5> PCI_AD<21> 12C6<> 17B7<> 24C6<> 26C7<> 39C5> PCI_AD<22> 12C6<> 17B7<> 24C5<> 26C7<> 39B5> PCI_AD<23> 12C6<> 17B7<> 24C6<> 26C7<> 39B5> PCI_AD<24> 9C1<> 12C6<> 17B7<> 24C5<> 26C7<>

39B5> PCI_AD<25> 9C1<> 12C6<> 17B7<> 24C6<> 26C7<>

39B5> PCI_AD<26> 9C1<> 12C6<> 17B7<> 24C5<> 26C7<>

39B5> PCI_AD<27> 9C1<> 12C6<> 17B7<> 24D6<> 26C8<>

39B5> PCI_AD<28> 9C1<> 12C6<> 17B7<> 24C5<> 26C7<>

39B5> PCI_AD<29> 9C1<> 12C6<> 17B7<> 24D6<> 26B7<>

39B5> PCI_AD<30> 9C1<> 12C6<> 17B7<> 24D5<> 26B7<>

39B5> PCI_AD<31> 9C1<> 12C6<> 17B7<> 24D6<> 26B7<>

39A5> PCI_CBE<0> 12C7<> 17B7<> 24C5<> 26B7<> 39D4> PCI_CBE<3..0> 37C5> PCI_CBE<1> 12C7<> 17B7<> 24C6<> 26B7<> 39D4>

SIZE

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

REV.

APPLE COMPUTER INC.

SCALE

NONE

PCI_CBE<2> 12C7<> 17B7<> 24C6<> 26B7<> 39D4> PCI_CBE<3> 12C7<> 17B7<> 24C6<> 26B7<> 39D4> PCI_DEVSEL_L 12B7< 12C7<> 17A7<> 24C5<> 26B7<>

37C5> 39A5>

PCI_FRAME_L 12B7< 12C7<> 17B7<> 24C5<> 26B7<>

37C5> 39A5>

PCI_IRDY_L 12B7< 12C7<> 17B7<> 24C6<> 26B7<>

37C5> 39A5>

PCI_PAR 12C7<> 17B7<> 24C5<> 26B7<> 37C5>

39D4>

PCI_STOP_L 12A7< 12C7<> 17B7<> 24C5<> 26B7<>

37C5> 39A5>

PCI_TRDY_L 12B7< 12C7<> 17A7<> 24C5<> 26B7<>

37C5> 39A5> PLL_STOP_L 7C4<> 7C8<> PMU_ACK_L 14C2< 30C4<> PMU_AC_DET 30A4< 30B4<> PMU_AC_IN 30B4<> PMU_BATT0_DET_L 30B4<> PMU_BATT1_DET_L_PU 30B4<> 30D2< PMU_BATT_DET_L 30B3< 30D2< 31A4<> 39C3> PMU_BYTE 30B6< 30C7< PMU_CAPSLOCK_LED_L 30C6<> PMU_CHARGE_V 30C4<> 31B8<> PMU_CHRG_BATT_0 30C4<> 31A8<> PMU_CLK 14C2<> 30C4<> PMU_CNVSS 30B6< 30C7< PMU_CPU_HRESET_L 23A4< 23C4<> 30C4<> PMU_EPM 30D2< 30D4<> PMU_FROM_INT 14C2<> 30C4<> PMU_I2C_CLK 30B4<> 30C2< PMU_I2C_DATA 30B4<> 30C2< PMU_INT_L 14B5<> 14B7< 30B6<> PMU_INT_NMI 14B5<> 14B7< 30D4<> PMU_KB_RESET_IN1 30A7<> PMU_KB_RESET_IN2 30A7<> PMU_KB_RESET_L 30A6> 30B7< 39B2> PMU_LID_CLOSED_L 23A8< 23C4<> 30B2< 30C4<> PMU_NMI_BUTTON_L 25C1< 30C2< 30C4<> PMU_NMI_L 30C2< 30C4<> PMU_NUMLOCK_LED_L 30C6<> PMU_OOPS 30B2< 30B4<> PMU_PME_L 14B5<> 26B8< 30B2< 30C4<> PMU_POWERUP_OK 30B4<> 30D2< PMU_POWER_UP_L 29C7<> 30C6<> 30D7< 33B8< PMU_REQ_L 14B7< 14C2> 30C4<> PMU_RESET_BUTTON_L 25B1< 30C4<> 30D2< PMU_RESET_L 30B6<> PMU_SLEEP_LED 23C4<> PMU_SLEEP_LED_L 23C2<> 30C4<> PMU_SMB_CLK 30B4<> 30C2< 31A3< PMU_SMB_DATA 30B4<> 30C2< 31A2< PMU_TO_INT 14C2<> 30C4<> POWER_UP 29C7<> POWER_VALID 30B2< 30C4<> PWR_BUTTON_L 23A7<> 25C2< 39B2> RAM_ADDR<0> 9B4< 11B5<> 11B6<> RAM_ADDR<12..0> 36A5> RAM_ADDR<1> 9B4< 11B3<> 11B8<> RAM_ADDR<2> 9B4< 11B5<> 11B6<> RAM_ADDR<3> 9B4< 11B3<> 11B8<> RAM_ADDR<4> 9B4< 11B5<> 11B6<> RAM_ADDR<5> 9B4< 11B3<> 11B8<> RAM_ADDR<6> 9B4< 11B5<> 11B6<> RAM_ADDR<7> 9B4< 11B3<> 11B8<> RAM_ADDR<8> 9B4< 11B5<> 11B6<> RAM_ADDR<9> 9A4< 11B3<> 11B8<> RAM_ADDR<10> 9A4< 11B3<> 11B8<> RAM_ADDR<11> 9A4< 11B5<> 11B6<> RAM_ADDR<12> 9A4< 11B3<> 11B8<> RAM_BA<0> 9A4< 11B3<> 11B8<> RAM_BA<1..0> 36A5> RAM_BA<1> 9A4< 11B5<> 11B6<> RAM_CAS_L 9A4< 11B5<> 11B6<> 36A5> RAM_CKE<0> 9A3< 9C4< 11B6<> RAM_CKE<3..0> 36A5> RAM_CKE<1> 9A3< 9C4< 11B8<> RAM_CKE<2> 9A3< 9C4< 11C5<> RAM_CKE<3> 9A3< 9C4< 11C3<> RAM_CS_L<0> 9C4< 11B8<> RAM_CS_L<3..0> 36A5> RAM_CS_L<1> 9C4< 11B6<> RAM_CS_L<2> 9C4< 11B3<> RAM_CS_L<3> 9C4< 11B5<> RAM_DATA_A<0> 10C8<> 11D8<> RAM_DATA_A<7..0> 36C5> RAM_DATA_A<1> 10C8<> 11D8<> RAM_DATA_A<2> 10C8<> 11D8<> RAM_DATA_A<3> 10B8<> 11D8<> RAM_DATA_A<4> 10B8<> 11D6<> RAM_DATA_A<5> 10B8<> 11D6<> RAM_DATA_A<6> 10B8<> 11D6<> RAM_DATA_A<7> 10B8<> 11D6<> RAM_DATA_A<8> 10B8<> 11D8<> RAM_DATA_A<15..8> 36C5> RAM_DATA_A<9> 10C7<> 11D8<> RAM_DATA_A<10> 10C7<> 11D8<> RAM_DATA_A<11> 10C7<> 11D8<> RAM_DATA_A<12> 10C7<> 11D6<> RAM_DATA_A<13> 10C7<> 11D6<> RAM_DATA_A<14> 10C7<> 11D6<> RAM_DATA_A<15> 10C7<> 11D6<> RAM_DATA_A<16> 10C6<> 11D8<> RAM_DATA_A<31..16> 36B5> RAM_DATA_A<17> 10C6<> 11C8<> RAM_DATA_A<18> 10C6<> 11C8<> RAM_DATA_A<19> 10B6<> 11C8<> RAM_DATA_A<20> 10B6<> 11D6<> RAM_DATA_A<21> 10B6<> 11C6<> RAM_DATA_A<22> 10B6<> 11C6<> RAM_DATA_A<23> 10B6<> 11C6<> RAM_DATA_A<24> 10B6<> 11C8<> RAM_DATA_A<25> 10C5<> 11C8<> RAM_DATA_A<26> 10C5<> 11C8<> RAM_DATA_A<27> 10C5<> 11C8<> RAM_DATA_A<28> 10C5<> 11C6<> RAM_DATA_A<29> 10C5<> 11C6<> RAM_DATA_A<30> 10C5<> 11C6<> RAM_DATA_A<31> 10C5<> 11C6<> RAM_DATA_A<32> 10C4<> 11B8<> RAM_DATA_A<47..32> 36B5> RAM_DATA_A<33> 10C4<> 11B8<> RAM_DATA_A<34> 10C4<> 11B8<> RAM_DATA_A<35> 10C4<> 11B8<> RAM_DATA_A<36> 10B4<> 11B6<> RAM_DATA_A<37> 10B4<> 11B6<> RAM_DATA_A<38> 10B4<> 11B6<> RAM_DATA_A<39> 10B4<> 11B6<> RAM_DATA_A<40> 10B4<> 11B8<> RAM_DATA_A<41> 10D3<> 11B8<> RAM_DATA_A<42> 10C3<> 11A8<> RAM_DATA_A<43> 10C3<> 11A8<> RAM_DATA_A<44> 10C3<> 11B6<> RAM_DATA_A<45> 10C3<> 11B6<> RAM_DATA_A<46> 10C3<> 11A6<> RAM_DATA_A<47> 10C3<> 11A6<> RAM_DATA_A<48> 10C2<> 11A8<> RAM_DATA_A<55..48> 36B5> RAM_DATA_A<49> 10C2<> 11A8<> RAM_DATA_A<50> 10C2<> 11A8<> RAM_DATA_A<51> 10C2<> 11A8<> RAM_DATA_A<52> 10B2<> 11A6<> RAM_DATA_A<53> 10B2<> 11A6<> RAM_DATA_A<54> 10B2<> 11A6<> RAM_DATA_A<55> 10B2<> 11A6<> RAM_DATA_A<56> 10B2<> 11A8<> RAM_DATA_A<63..56> 36A5> RAM_DATA_A<57> 10D1<> 11A8<> RAM_DATA_A<58> 10C1<> 11A8<> RAM_DATA_A<59> 10C1<> 11A8<> RAM_DATA_A<60> 10C1<> 11A6<> RAM_DATA_A<61> 10C1<> 11A6<> RAM_DATA_A<62> 10C1<> 11A6<> RAM_DATA_A<63> 10C1<> 11A6<> RAM_DATA_B<0> 10C8<> 11D3<> RAM_DATA_B<7..0> 36C5> RAM_DATA_B<1> 10C8<> 11D3<> RAM_DATA_B<2> 10C8<> 11D3<> RAM_DATA_B<3> 10C8<> 11D3<> RAM_DATA_B<4> 10C8<> 11D5<> RAM_DATA_B<5> 10C8<> 11D5<> RAM_DATA_B<6> 10C8<> 11D5<> RAM_DATA_B<7> 10C8<> 11D5<> RAM_DATA_B<8> 10C8<> 11D3<> RAM_DATA_B<15..8> 36C5> RAM_DATA_B<9> 10C8<> 11D3<> RAM_DATA_B<10> 10C8<> 11D3<> RAM_DATA_B<11> 10C8<> 11D3<>

RAM_DATA_B<12> 10C8<> 11D5<> RAM_DATA_B<13> 10C8<> 11D5<> RAM_DATA_B<14> 10C8<> 11D5<> RAM_DATA_B<15> 10C8<> 11D5<> RAM_DATA_B<16> 10C6<> 11D3<> RAM_DATA_B<31..16> 36B5> RAM_DATA_B<17> 10C6<> 11C3<> RAM_DATA_B<18> 10C6<> 11C3<> RAM_DATA_B<19> 10C6<> 11C3<> RAM_DATA_B<20> 10C6<> 11D5<> RAM_DATA_B<21> 10C6<> 11C5<> RAM_DATA_B<22> 10C6<> 11C5<> RAM_DATA_B<23> 10C6<> 11C5<> RAM_DATA_B<24> 10C6<> 11C3<> RAM_DATA_B<25> 10C6<> 11C3<> RAM_DATA_B<26> 10C6<> 11C3<> RAM_DATA_B<27> 10C6<> 11C3<> RAM_DATA_B<28> 10C6<> 11C5<> RAM_DATA_B<29> 10C6<> 11C5<> RAM_DATA_B<30> 10C6<> 11C5<> RAM_DATA_B<31> 10C6<> 11C5<> RAM_DATA_B<32> 10D4<> 11B3<> RAM_DATA_B<47..32> 36B5> RAM_DATA_B<33> 10C4<> 11B3<> RAM_DATA_B<34> 10C4<> 11B3<> RAM_DATA_B<35> 10C4<> 11B3<> RAM_DATA_B<36> 10C4<> 11B5<> RAM_DATA_B<37> 10C4<> 11B5<> RAM_DATA_B<38> 10C4<> 11B5<> RAM_DATA_B<39> 10C4<> 11B5<> RAM_DATA_B<40> 10C4<> 11B3<> RAM_DATA_B<41> 10C4<> 11B3<> RAM_DATA_B<42> 10C4<> 11A3<> RAM_DATA_B<43> 10C4<> 11A3<> RAM_DATA_B<44> 10C4<> 11B5<> RAM_DATA_B<45> 10C4<> 11B5<> RAM_DATA_B<46> 10C4<> 11A5<> RAM_DATA_B<47> 10C4<> 11A5<> RAM_DATA_B<48> 10D2<> 11A3<> RAM_DATA_B<55..48> 36B5> RAM_DATA_B<49> 10C2<> 11A3<> RAM_DATA_B<50> 10C2<> 11A3<> RAM_DATA_B<51> 10C2<> 11A3<> RAM_DATA_B<52> 10C2<> 11A5<> RAM_DATA_B<53> 10C2<> 11A5<> RAM_DATA_B<54> 10C2<> 11A5<> RAM_DATA_B<55> 10C2<> 11A5<> RAM_DATA_B<56> 10C2<> 11A3<> RAM_DATA_B<63..56> 36A5> RAM_DATA_B<57> 10C2<> 11A3<> RAM_DATA_B<58> 10C2<> 11A3<> RAM_DATA_B<59> 10C2<> 11A3<> RAM_DATA_B<60> 10C2<> 11A5<> RAM_DATA_B<61> 10C2<> 11A5<> RAM_DATA_B<62> 10C2<> 11A5<> RAM_DATA_B<63> 10C2<> 11A5<> RAM_DQM_A<0> 10B8<> 11D6<> 36C5> RAM_DQM_A<1> 10C7<> 11D6<> 36C5> RAM_DQM_A<2> 10B6<> 11C6<> RAM_DQM_A<3..2> 36B5> RAM_DQM_A<3> 10C5<> 11C6<> RAM_DQM_A<4> 10B4<> 11B6<> RAM_DQM_A<5..4> 36B5> RAM_DQM_A<5> 10C3<> 11A6<> RAM_DQM_A<6> 10B2<> 11A6<> 36B5> RAM_DQM_A<7> 10C1<> 11A6<> 36A5> RAM_DQM_B<0> 10C8<> 11D5<> 36C5> RAM_DQM_B<1> 10C8<> 11D5<> 36C5> RAM_DQM_B<2> 10C6<> 11C5<> RAM_DQM_B<3..2> 36B5> RAM_DQM_B<3> 10C6<> 11C5<> RAM_DQM_B<4> 10C4<> 11B5<> RAM_DQM_B<5..4> 36B5> RAM_DQM_B<5> 10C4<> 11B5<> RAM_DQM_B<6> 10C2<> 11A5<> 36B5> RAM_DQM_B<7> 10C2<> 11A5<> 36A5> RAM_DQS_A<0> 10B8<> 11D8<> 36C5> RAM_DQS_A<1> 10C7<> 11D8<> 36C5> RAM_DQS_A<2> 10B6<> 11C8<> RAM_DQS_A<3..2> 36B5> RAM_DQS_A<3> 10C5<> 11C8<> RAM_DQS_A<4> 10B4<> 11B8<> RAM_DQS_A<5..4> 36B5> RAM_DQS_A<5> 10C3<> 11A8<> RAM_DQS_A<6> 10B2<> 11A8<> 36B5> RAM_DQS_A<7> 10C1<> 11A8<> 36A5> RAM_DQS_B<0> 10C8<> 11D3<> 36C5> RAM_DQS_B<1> 10C8<> 11D3<> 36C5> RAM_DQS_B<2> 10C6<> 11C3<> RAM_DQS_B<3..2> 36B5> RAM_DQS_B<3> 10C6<> 11C3<> RAM_DQS_B<4> 10C4<> 11B3<> RAM_DQS_B<5..4> 36B5> RAM_DQS_B<5> 10C4<> 11B3<> RAM_DQS_B<6> 10C2<> 11A3<> 36B5> RAM_DQS_B<7> 10C2<> 11A3<> 36A5> RAM_MUXSEL_H 10A3< 10A5< 10B1<> 10B3<> 36A5> RAM_MUXSEL_L 10A3< 10A5< 10B5<> 10B7<> 36A5> RAM_RAS_L 9A4< 11B5<> 11B6<> 36A5> RAM_WE_L 9A4< 11B3<> 11B8<> 36A5> RF_DISABLE_L_SPN 24D6<> 39C1> RIGHT_USB_DM 26A3< 32A7<> 37A2> 39D1> RIGHT_USB_DP 26A3< 32A7<> 37A2> 39D1> RJ45_C0_PD 27B2<> RJ45_C1_PD 27B2<> RJ45_C2_PD 27B2<> RJ45_C3_PD 27B2<> RJ45_DN<0> 27B2<> 37D2> 39B3> RJ45_DN<1> 27B2<> 37D2> 39B3> RJ45_DN<2> 27B2<> 37D2> 39A3> RJ45_DN<3> 27B2<> 37D2> 39A3> RJ45_DP<0> 27B2<> 37D2> 39B3> RJ45_DP<1> 27B2<> 37D2> 39B3> RJ45_DP<2> 27B2<> 37D2> 39A3> RJ45_DP<3> 27B2<> 37D2> 39A3> ROM_CS_L 9B3< 12A5< 24B6<> 39B1> ROM_OE_L 9B3< 12A5< 24C5<> 39B1> ROM_ONBOARD_CS_L 9B3< 24C6<> 39B1> ROM_RW_L 9B3< 12A5< 24C6<> 39B1> ROM_WP_L 9B3< RSDM3_TP 26C5> RSDM4_TP 26C5> RSDM5_TP 26C5> RSDP3_TP 26C5> RSDP4_TP 26C5> RSDP5_TP 26C5> RUN_OR_AC 29C6<> SI_A2 20B7< SI_DDC_CLK 19C5<> 20B7< SI_DDC_DATA 19C5<> 20B7< SI_EDGE 20B7< SI_MSEN 20B5<> SI_PD 20B7< SI_RST 20B7< SI_TMDS_CLKN 20B5<> 20C4< SI_TMDS_CLKP 20B5<> 20C4< SI_TMDS_DN<0> 20B5<> 20C4< SI_TMDS_DN<1> 20B5<> 20C4< SI_TMDS_DN<2> 20A5<> 20B4< SI_TMDS_DP<0> 20B5<> 20C4< SI_TMDS_DP<1> 20B5<> 20C4< SI_TMDS_DP<2> 20A5<> 20B4< SI_VREF 20A5< 20A7< SLEEP 23C4<> 25C6<> 30B6<> 30D7< 33A4<

33A6< 33B3< 33B8<> 35B3< 35D2< 39A1>

SLEEP_LED 23C1< 25C7<> 39B6> SLEEP_LED_I 23D1< SLEEP_LED_L 23D1< SLEEP_LED_SW_L 23C2<> SLEEP_LED_UF 23C1< SLEEP_LS5 33A5<> 33A8< SLEEP_LS5_EN_L 33A5<> SLEEP_L_LS5 19A7<> 27A8<> 33A5<> 34C8<> 35C8< SLEEP_L_LS5_EN_L 33A6<> SLEEP_L_LS5_INV 35A3< 35C2< 35C8<> SLEEP_L_LS5_NET 33B3<> 35C8<> SLEEP_NET 33A3<> SLEEP_NET_INV 33A3<> SMC_TP 26B5< SND_AGND 25C7<> 38B6> SND_AMP_MUTE 25C8< 25D6<> 39A4> SND_AMP_MUTE_F 25C7< 25D6<> SND_AMP_MUTE_L 14C5<> 25D5<> SND_CLKOUT 14B1< 25D8< 36B1> 39D6> SND_CLKOUT_F 25C7<> 25D7< SND_HP_MUTE 25C5<> SND_HP_MUTE_INV 25C5<> 25C6<> 39A4>

SND_HP_MUTE_L 14C5<> 25C4<> SND_HP_SENSE_L 14B5<> 25D6<> 39C6> SND_HW_RESET_L 14A7< 14B5<> 25C8< 39C6> SND_HW_RESET_L_F 25C6<> 25C7< SND_LIN_SENSE_L 14B5<> 25D6<> 39C6> SND_SCLK 14B1< 25C8< 36B1> 39C6> SND_SCLK_F 25C7< 25D7<> SND_SYNC 14B1< 25D8< 39D6> SND_SYNC_F 25C7<> 25D7< SND_TO_AUDIO 14B1< 25D8< 39D6> SND_TO_AUDIO_F 25D6<> 25D7< SOFT_PWR_ON_L 22D1< 23A8< 30A8< 30C6<> 30D7<

34A3<> SRCLK_TP 26A5> 39A4> SRMOD_TP 26A5< 39A4> ST7_ICP_SEL_PD 23A2< 23D6< ST7_KBD_LED_OUT 23A4< 23C4<> ST7_OSC1 23D5< ST7_OSC2 23D5<> ST7_PB6_PD 23B2< 23C4<> ST7_RESET_L 23D5<> ST7_SENSOR4_SCK_PD 23B2< 23D4<> ST7_SENSOR4_SDA_PD 23B2< 23D4<> ST7_SENSOR5_SCK_PU 23B2< 23D4<> ST7_SENSOR5_SDA_PU 23B2< 23D4<> ST7_SLEEP_LED_H 23C2<> 23C4<> ST7_XTAL_IN 23C5< STOP_AGP_L 12D2< 12D4<> SUPPLY_M_DM 25B6< 25B8< SUPPLY_M_DP 25B6< 25B8< SUTRO_ALS_GAIN_SW 23C4<> 24B2<> 39C2> SUTRO_ALS_OUT 23C4<> 24B2<> 39C2> SYSCLK_CPU 5C4< 8A6< 36D1> SYSCLK_CPU_UF 8A6<> 36D1> SYSCLK_DDRCLK_A0 9D4< 11D8<> 36D1> SYSCLK_DDRCLK_A0_L 9D4< 11D8<> 36D1> SYSCLK_DDRCLK_A0_L_UF 9B6<> 9D5< 36D1> SYSCLK_DDRCLK_A0_UF 9B6<> 9D5< 36D1> SYSCLK_DDRCLK_A1 9D4< 11A6<> 36D1> SYSCLK_DDRCLK_A1_L 9D4< 11A6<> 36D1> SYSCLK_DDRCLK_A1_L_UF 9B6<> 9D5< 36D1> SYSCLK_DDRCLK_A1_UF 9B6<> 9D5< 36D1> SYSCLK_DDRCLK_B0 9D4< 11D3<> 36D1> SYSCLK_DDRCLK_B0_L 9C4< 11D3<> 36C1> SYSCLK_DDRCLK_B0_L_UF 9B6<> 9C5< 36D1> SYSCLK_DDRCLK_B0_UF 9B6<> 9D5< 36D1> SYSCLK_DDRCLK_B1 9D4< 11A5<> 36C1> SYSCLK_DDRCLK_B1_L 9D4< 11A5<> 36C1> SYSCLK_DDRCLK_B1_L_UF 9B6<> 9D5< 36D1> SYSCLK_DDRCLK_B1_UF 9B6<> 9D5< 36D1> SYSCLK_LA_TP 8A6<> SYSTEM_CLK_EN 14A5< 14A7< 30C4<> TEB_TP 26A5< 39A4> TEST_TP 26A5< 39A4> THERM1_A_DM 25A6< 25A8< 37A2> THERM1_A_DP 25A6< 25A8< 37A2> THERM1_DM 25A5< 25A5< 25B5< 25B5<> 37A2> THERM1_DP 25A5< 25A5< 25B5< 25B5<> 37A2> THERM1_M_DM 37A2> THERM1_M_DP 37A2> THERM2_A_DM 25A6< 25A8< 37A2> THERM2_A_DP 25A6< 25A8< 37A2> THERM2_DM 25A5< 25B5< 25B5<> 37A2> THERM2_DP 25A5< 25B5< 25B5<> 37A2> THERM2_M_DM 37A2> THERM2_M_DP 37A2> THERM_INV 25A5<> THERM_L_OC 25A4<> 30B4<> TMDS_CLKN 20B3< 20C1< 20C3< 22B7<> 37B2> TMDS_CLKP 20B3< 20C2< 20C3< 22C7<> 37B2> TMDS_CLK_CMF 20C1< TMDS_CONN_CLKN 22B6<> 22C7<> 37B2> 39A8> TMDS_CONN_CLKP 22C6<> 22C7<> 37B2> 39D7> TMDS_CONN_DN<0> 22C7<> 22D6<> TMDS_CONN_DN<1> 22B7<> 22D5<> TMDS_CONN_DN<2> 22B6<> 22D5<> TMDS_CONN_DP<0> 22B7<> 22D6<> TMDS_CONN_DP<1> 22B7<> 22D5<> TMDS_CONN_DP<2> 22B6<> 22D5<> TMDS_D0_CMF 20B1< TMDS_D1_CMF 20B1< TMDS_D2_CMF 20A1< TMDS_DN<0> 20B1< 20B3< 20C3< 22C8<> 37B2>

39B8> TMDS_DN<1> 20A3< 20B1< 20C3< 22B8<> 37B2>

39A8> TMDS_DN<2> 20A1< 20A3< 20B3< 22B7<> 37B2>

39A8> TMDS_DP<0> 20B2< 20B3< 20C3< 22B8<> 37B2>

39A8> TMDS_DP<1> 20A3< 20B2< 20C3< 22B8<> 37B2>

39A8> TMDS_DP<2> 20A2< 20A3< 20B3< 22B7<> 37B2>

39A8> TPAD_F_RXD 23A7<> 39C4> TPAD_F_TXD 23A7<> 39C4> TPAD_RXD 23A8< 30C2< 30C4<> TPAD_TXD 23A8< 30B2< 30C4<> TPS2211_SHDN_L_PU 17C4< TV_C 22A6<> 39D6> TV_COMP 22A6<> 39D6> TV_GND1 22B6<> 38B6> 39A7> TV_GND2 22A6<> 38B6> 39A7> TV_Y 22A6<> 39D6> UIDE_ADDR<0> 13D7<> 24C4< UIDE_ADDR<2..0> 37C5> UIDE_ADDR<1> 13D7<> 24C4< UIDE_ADDR<2> 13D7<> 24B4< UIDE_CS0_L 13C7<> 24C4< 37C5> UIDE_CS1_L 13C7<> 24B4< 37C5> UIDE_DATA<0> 13D7<> 24D4< UIDE_DATA<6..0> 37C5> UIDE_DATA<1> 13D7<> 24D4< UIDE_DATA<2> 13D7<> 24D4< UIDE_DATA<3> 13D7<> 24D4< UIDE_DATA<4> 13D7<> 24C4< UIDE_DATA<5> 13D7<> 24C4< UIDE_DATA<6> 13D7<> 24C4< UIDE_DATA<7> 13D7<> 24C4< 37C5> UIDE_DATA<8> 13D7<> 24C4< UIDE_DATA<15..8> 37C5> UIDE_DATA<9> 13D7<> 24C4< UIDE_DATA<10> 13D7<> 24C4< UIDE_DATA<11> 13D7<> 24D4< UIDE_DATA<12> 13D7<> 24B4< UIDE_DATA<13> 13D7<> 24B4< UIDE_DATA<14> 13D7<> 24C4< UIDE_DATA<15> 13D7<> 24B4< UIDE_DIOR_L 13C7<> 24A4< 37C5> UIDE_DIOW_L 13C7<> 24A4< 37C5> UIDE_DMACK_L 13C7<> 24A4< 37C5> UIDE_DMARQ 13C7<> 37C5> UIDE_INTRQ 13C7< 37C5> UIDE_IOCHRDY 13C7< 24A4< 37C5> UIDE_REF 13C7<> 38D3> UIDE_RST_L 13C7<> 24A4< 37C5> USB2_PCI_GNT_L 12C7<> 26B7< USB2_PCI_INT_L 14B5<> 14C7< 26A8< USB2_PCI_REQ_L 12A7< 12D7<> 26B7> USB_D1M 14C1< 26A5> 26B4< USB_D1P 14C1< 26A4< 26A5> USB_D2M 14D1< 26A4< 26A5> USB_D2P 14D1< 26A4< 26A5> USB_DAM 14B2<> 14D2< 26A5> USB_DAP 14B2<> 14D2< 26A5> USB_DBM 14B2<> 14D2< USB_DBP 14B2<> 14D2< USB_DCM 14B2<> 14C2< 26A5> USB_DCP 14B2<> 14C2< 26A5> USB_DDM 14B2<> 14C2< USB_DDP 14B2<> 14C2< USB_DEM 14B2< 14B2<> 37B2> USB_DEP 14B2<> 14C2< 37B2> USB_DFM 14B2< 14B2<> 37B2> USB_DFP 14B2< 14B2<> 37B2> USB_OC_AB_L 14B2< 14C7< USB_OC_CD_L 14B2< 14C7< USB_OC_EF_L 14B2< 14D7< USB_PWREN_AB_L 14B2<> 14C7< USB_PWREN_CD_L 14B2<> 14C7< USB_PWREN_EF_L 14B2<> 14D7< VCORE_BOOST 34C4<> 38C1> VCORE_BST 34C5<> 38C1> VCORE_CC 34B6<> 38B1> VCORE_CNTL_RC 19A3<> VCORE_DH 34B5<> 38C1> VCORE_DL 34B5<> 38C1> VCORE_FAST<1> 34D3< 34D5<

VCORE_FAST<2> 34D3< 34D5< VCORE_FAST<3> 34D3< 34D5< VCORE_FAST<4> 34D3< 34D5< VCORE_FB 34B5< 38B1> 39A2> VCORE_GND 34B5<> 38B1> VCORE_GNDA 34B6<> VCORE_GNDDIV 34A4< 34B5< 38B1> VCORE_GNDDIV_TEST 34A3<> VCORE_GNDSNS 34A2<> 34A4< 38B1> VCORE_GNDSNS_TEST 34A3<> VCORE_ILIM 34C6<> 38C1> VCORE_LX 34B5<> 38C1> VCORE_MUX_EN 34D5<> 39A2> VCORE_MUX_SEL 34D5<> VCORE_REF 34B6<> 38C1> VCORE_SEL_OFF_PU 34B6<> VCORE_SEL_ON 34B6<> VCORE_SHDN_L 5C3< 34C6<> VCORE_SLOW<1> 34D6< VCORE_SLOW<2> 34D6< VCORE_SLOW<3> 34D6< VCORE_SLOW<4> 34D6< VCORE_SNS 34A1<> 38B1> VCORE_TIME 34B4<> 38B1> VCORE_TON 34B6< 38C1> VCORE_VCC 34C6< 38C1> VCORE_VGATE 14B5< 14B7< 34B4> 38B1> VCORE_VID0 39A3> VCORE_VID1 39A3> VCORE_VID2 39A3> VCORE_VID3 39A3> VCORE_VID4 39A3> VCORE_VID<0> 34A2<> 34B8< VCORE_VID<1> 34A2<> 34B8< 34D4<> VCORE_VID<2> 34A2<> 34B8< 34D4<> VCORE_VID<3> 34A2<> 34B8< 34D4<> VCORE_VID<4> 34A2<> 34B8< 34D4<> VGA_B 22C6<> 22D7< 39D7> VGA_G 22C5<> 22D7< 39D7> VGA_HSYNC 22C6<> 22C7< 39D7> VGA_HSYNC_BUF 22C8<> VGA_R 22C5<> 22D7< 39D7> VGA_VSYNC 22C5<> 22C7< 39D7> VGA_VSYNC_BUF 22C8<> ZV_LCDDATA20_PU 19C7<>

051-6598 01

4442

8 7

2 1

7 6

*** Part Cross-Reference for the entire design ***

BS1 PCB_STANDOFF 4 C1 CAP 22 C2 CAP 34 C3 CAP 34 C4 CAP 34 C5 CAP 34 C6 CAP 34 C7 CAP 34 C8 CAP 5 C9 CAP 16 C10 CAP 16 C11 CAP 18 C12 CAP 5 C13 CAP 34 C14 CAP 20 C15 CAP 14 C16 CAP 16 C17 CAP 16 C18 CAP 16 C19 CAP 16 C20 CAP 16 C21 CAP 16 C22 CAP 16 C23 CAP 16 C24 CAP 16 C25 CAP 5 C26 CAP 16 C27 CAP 16 C28 CAP 16 C29 CAP 16 C30 CAP 16 C31 CAP 16 C32 CAP 16 C33 CAP 16 C34 CAP 16 C35 CAP 16 C36 CAP 16 C37 CAP 18 C38 CAP 5 C39 CAP 5 C40 CAP 5 C41 CAP 5 C42 CAP 16 C43 CAP 16 C44 CAP 16 C45 CAP 16 C46 CAP 5 C47 CAP 5 C48 CAP 5 C49 CAP 16 C50 CAP 16 C51 CAP 16 C52 CAP 16 C53 CAP 16 C54 CAP 16 C55 CAP 16 C56 CAP 16 C57 CAP 16 C58 CAP 16 C59 CAP 16 C60 CAP 16 C61 CAP 16 C62 CAP 18 C63 CAP 18 C64 CAP 18 C65 CAP 18 C66 CAP 18 C67 CAP 18 C68 CAP 18 C69 CAP 18 C70 CAP 18 C71 CAP 18 C72 CAP 5 C73 CAP 5 C74 CAP 5 C75 CAP 16 C76 CAP 16 C77 CAP 18 C78 CAP 18 C79 CAP 20 C80 CAP 20 C81 CAP 20 C82 CAP 20 C83 CAP 12 C84 CAP 14 C85 CAP 14 C86 CAP 24 C87 CAP 20 C88 CAP 20 C89 CAP 20 C90 CAP 5 C91 CAP 5 C92 CAP 5 C93 CAP 35 C94 CAP 16 C95 CAP 16 C96 CAP 16 C97 CAP 14 C98 CAP 16 C99 CAP 16 C100 CAP 16 C101 CAP 16 C102 CAP 20 C103 CAP 5 C104 CAP 5 C105 CAP 5 C106 CAP 5 C107 CAP 5 C108 CAP 16 C109 CAP 16 C110 CAP 5 C111 CAP 5 C112 CAP 5 C113 CAP 5 C114 CAP 5 C115 CAP 5 C116 CAP 34 C117 CAP 16 C118 CAP 16 C119 CAP 16 C120 CAP 16 C121 CAP 16 C122 CAP 16 C123 CAP 16 C124 CAP 16 C125 CAP 16 C126 CAP 16 C127 CAP 16 C128 CAP 16 C129 CAP 20 C130 CAP 20 C131 CAP 20 C132 CAP 20 C133 CAP 20 C134 CAP 25 C135 CAP 25 C136 CAP 5 C137 CAP 5 C138 CAP 5 C139 CAP 5 C140 CAP 14 C141 CAP 16 C142 CAP 16 C143 CAP 16 C144 CAP 16 C145 CAP 16 C146 CAP 16 C147 CAP 16 C148 CAP 14 C149 CAP 5 C150 CAP 5 C151 CAP 5 C152 CAP 5 C153 CAP 5 C154 CAP 5 C155 CAP 5 C156 CAP 5 C157 CAP 16 C158 CAP 16 C159 CAP 16 C160 CAP 12 C161 CAP 16 C162 CAP 16 C163 CAP 16 C164 CAP 16 C165 CAP 20

C166 CAP 19 C167 CAP 19 C168 CAP 5 C169 CAP 5 C170 CAP 5 C171 CAP 16 C172 CAP 16 C173 CAP 16 C174 CAP 16 C175 CAP 16 C176 CAP 16 C177 CAP 16 C178 CAP 16 C179 CAP 16 C180 CAP 16 C181 CAP 16 C182 CAP 14 C183 CAP 16 C184 CAP 16 C185 CAP 16 C186 CAP 19 C187 CAP 19 C188 CAP 5 C189 CAP 5 C190 CAP 5 C191 CAP 5 C192 CAP 5 C193 CAP 5 C194 CAP 5 C195 CAP 5 C196 CAP 16 C197 CAP 16 C198 CAP 14 C199 CAP 16 C200 CAP 14 C201 CAP 5 C202 CAP 5 C203 CAP 5 C204 CAP 16 C205 CAP 16 C206 CAP 16 C207 CAP 16 C208 CAP 16 C209 CAP 16 C210 CAP 16 C211 CAP 16 C212 CAP 16 C213 CAP 16 C214 CAP 16 C215 CAP 16 C216 CAP 16 C217 CAP 16 C218 CAP 20 C219 CAP 19 C220 CAP 19 C221 CAP 19 C222 CAP 19 C223 CAP 5 C224 CAP 5 C225 CAP 5 C226 CAP 16 C227 CAP 16 C228 CAP 16 C229 CAP 16 C230 CAP 16 C231 CAP 16 C232 CAP 19 C233 CAP 20 C234 CAP 34 C235 CAP 35 C236 CAP 16 C237 CAP 16 C238 CAP 16 C239 CAP 16 C240 CAP 16 C241 CAP 16 C242 CAP 16 C243 CAP 16 C244 CAP 16 C245 CAP 9 C246 CAP 16 C247 CAP 12 C248 CAP 16 C249 CAP 16 C250 CAP 16 C251 CAP 16 C252 CAP 19 C253 CAP 19 C254 CAP 19 C255 CAP 20 C256 CAP 19 C257 CAP 5 C258 CAP 5 C259 CAP 16 C260 CAP 16 C261 CAP 16 C262 CAP 16 C263 CAP 16 C264 CAP 16 C265 CAP 16 C266 CAP 16 C267 CAP 16 C268 CAP 16 C269 CAP 19 C270 CAP 19 C271 CAP 19 C272 CAP 5 C273 CAP 5 C274 CAP 34 C275 CAP 5 C276 CAP 35 C277 CAP 16 C278 CAP 16 C279 CAP 16 C280 CAP 16 C281 CAP 16 C282 CAP 19 C283 CAP 5 C284 CAP 20 C285 CAP 34 C286 CAP 16 C287 CAP 16 C288 CAP 16 C289 CAP 16 C290 CAP 16 C291 CAP 16 C292 CAP 16 C293 CAP 16 C294 CAP 16 C295 CAP 16 C296 CAP 16 C297 CAP 16 C298 CAP 16 C299 CAP 19 C300 CAP 19 C301 CAP 19 C302 CAP 19 C303 CAP 19 C304 CAP 21 C305 CAP 19 C306 CAP 19 C307 CAP 19 C308 CAP 8 C309 CAP 16 C310 CAP 16 C311 CAP 19 C312 CAP 16 C313 CAP 16 C314 CAP 16 C315 CAP 16 C316 CAP 16 C317 CAP 16 C318 CAP 16 C319 CAP 16 C320 CAP 16 C321 CAP 16 C322 CAP 16 C323 CAP 16 C324 CAP 16 C325 CAP 16 C326 CAP 19 C327 CAP 21 C328 CAP 19 C329 CAP 19 C330 CAP 19 C331 CAP 19 C332 CAP 19 C333 CAP 19

C334 CAP 16 C335 CAP 16 C336 CAP 16 C337 CAP 16 C338 CAP 19 C339 CAP 21 C340 CAP 5 C341 CAP 5 C342 CAP 5 C343 CAP 5 C344 CAP 5 C345 CAP 5 C346 CAP 5 C347 CAP 5 C348 CAP 16 C349 CAP 16 C350 CAP 16 C351 CAP 16 C352 CAP 16 C353 CAP 14 C354 CAP 16 C355 CAP 16 C356 CAP 16 C357 CAP 16 C358 CAP 21 C359 CAP 21 C360 CAP 21 C361 CAP 21 C362 CAP 21 C363 CAP 21 C364 CAP 21 C365 CAP 16 C366 CAP 16 C367 CAP 16 C368 CAP 16 C369 CAP 16 C370 CAP 16 C371 CAP 16 C372 CAP 21 C373 CAP 21 C374 CAP 21 C375 CAP 16 C376 CAP 16 C377 CAP 16 C378 CAP 16 C379 CAP 21 C380 CAP 21 C381 CAP 21 C382 CAP 21 C383 CAP 21 C384 CAP 16 C385 CAP 16 C386 CAP 16 C387 CAP 16 C388 CAP 16 C389 CAP 16 C390 CAP 16 C391 CAP 16 C392 CAP 16 C393 CAP 16 C394 CAP 16 C395 CAP 16 C396 CAP 16 C397 CAP 16 C398 CAP 16 C399 CAP 16 C400 CAP 16 C401 CAP 16 C402 CAP 16 C403 CAP 16 C404 CAP 16 C405 CAP 16 C406 CAP 16 C407 CAP 16 C408 CAP 21 C409 CAP 21 C410 CAP 16 C411 CAP 21 C412 CAP 21 C413 CAP 21 C414 CAP 21 C415 CAP 21 C416 CAP 22 C417 CAP 16 C418 CAP 16 C419 CAP 14 C420 CAP 21 C421 CAP 21 C422 CAP 16 C423 CAP 16 C424 CAP 14 C425 CAP 21 C426 CAP 21 C427 CAP_P 34 C428 CAP 21 C429 CAP 21 C430 CAP_P 34 C431 CAP_P 34 C432 CAP_P 34 C433 CAP 14 C434 CAP 21 C435 CAP 21 C436 CAP 21 C437 CAP 21 C438 CAP 21 C439 CAP 34 C440 CAP 22 C441 CAP_P 34 C442 CAP 27 C443 CAP_P 34 C444 CAP_P 34 C445 CAP_P 34 C446 CAP 21 C447 CAP 21 C448 CAP 19 C449 CAP 22 C450 CAP 21 C451 CAP 19 C452 CAP 22 C453 CAP 27 C454 CAP 27 C455 CAP 34 C456 CAP 33 C457 CAP 27 C458 CAP 31 C459 CAP 34 C460 CAP 9 C461 CAP 32 C462 CAP 32 C463 CAP 32 C464 CAP 27 C465 CAP 27 C466 CAP 27 C467 CAP 17 C468 CAP 31 C469 CAP 25 C470 CAP 9 C471 CAP 27 C472 CAP 27 C473 CAP 19 C474 CAP 22 C475 CAP 27 C476 CAP 27 C477 CAP 27 C478 CAP 25 C479 CAP 9 C480 CAP 16 C481 CAP 11 C482 CAP 11 C483 CAP 19 C484 CAP 22 C485 CAP 32 C486 CAP 27 C487 CAP 27 C488 CAP 27 C489 CAP 11 C490 CAP 11 C491 CAP 27 C492 CAP 27 C493 CAP 27 C494 CAP 19 C495 CAP 32 C496 CAP 27 C497 CAP 27 C498 CAP 34 C499 CAP 35 C500 CAP 22 C501 CAP 27

C502 CAP 27 C503 CAP 27 C504 CAP 27 C505 CAP 27 C506 CAP 27 C507 CAP 34 C508 CAP 33 C509 CAP 32 C510 CAP 32 C511 CAP 27 C512 CAP 34 C513 CAP 25 C514 CAP 19 C515 CAP 19 C516 CAP 33 C517 CAP 27 C518 CAP 34 C519 CAP 35 C520 CAP 27 C521 CAP 34 C522 CAP 11 C523 CAP 11 C524 CAP 11 C525 CAP 11 C526 CAP 11 C527 CAP 11 C528 CAP 29 C529 CAP 34 C530 CAP 11 C531 CAP 35 C532 CAP 33 C533 CAP 33 C534 CAP 33 C535 CAP 32 C536 CAP 32 C537 CAP 32 C538 CAP 28 C539 CAP 28 C540 CAP 28 C541 CAP 28 C542 CAP 11 C543 CAP 21 C544 CAP 35 C545 CAP 33 C546 CAP 28 C547 CAP 31 C548 CAP 11 C549 CAP 11 C550 CAP 11 C551 CAP 11 C552 CAP 22 C553 CAP 32 C554 CAP 32 C555 CAP 27 C556 CAP 29 C557 CAP 31 C558 CAP 30 C559 CAP 35 C560 CAP 33 C561 CAP 28 C562 CAP 31 C563 CAP 31 C564 CAP 31 C565 CAP 11 C566 CAP 33 C567 CAP 33 C568 CAP 32 C569 CAP 32 C570 CAP 28 C571 CAP 28 C572 CAP 31 C573 CAP 11 C574 CAP 30 C575 CAP 35 C576 CAP 33 C577 CAP 28 C578 CAP 31 C579 CAP 31 C580 CAP 35 C581 CAP 35 C582 CAP 35 C583 CAP 33 C584 CAP 32 C585 CAP 32 C586 CAP 28 C587 CAP 28 C588 CAP 29 C589 CAP 11 C590 CAP 33 C591 CAP 28 C592 CAP 31 C593 CAP 31 C594 CAP 11 C595 CAP 11 C596 CAP 11 C597 CAP 11 C598 CAP 33 C599 CAP 32 C600 CAP 31 C601 CAP 11 C602 CAP 11 C603 CAP 35 C604 CAP 32 C605 CAP 28 C606 CAP 29 C607 CAP 29 C608 CAP 31 C609 CAP 33 C610 CAP 33 C611 CAP 33 C612 CAP 33 C613 CAP 32 C614 CAP 28 C615 CAP 31 C616 CAP 31 C617 CAP 31 C618 CAP 31 C619 CAP 31 C620 CAP 33 C621 CAP 31 C622 CAP 31 C623 CAP 33 C624 CAP 31 C625 CAP 32 C626 CAP 32 C627 CAP 28 C628 CAP 28 C629 CAP 28 C630 CAP 31 C631 CAP 31 C632 CAP 31 C633 CAP 31 C634 CAP 28 C635 CAP 28 C636 CAP 23 C637 CAP 23 C638 CAP 23 C639 CAP 33 C640 CAP 28 C641 CAP 28 C642 CAP 28 C643 CAP 30 C644 CAP 32 C645 CAP 28 C646 CAP 28 C647 CAP 21 C648 CAP 23 C649 CAP 26 C650 CAP 28 C651 CAP 25 C652 CAP 31 C653 CAP 28 C654 CAP 23 C655 CAP 23 C656 CAP 23 C657 CAP 26 C658 CAP 31 C659 CAP 33 C660 CAP 23 C661 CAP 26 C662 CAP 33 C663 CAP 23 C664 CAP 30 C665 CAP 26 C666 CAP 30 C667 CAP 26 C668 CAP 25 C669 CAP 22

C670 CAP 23 C671 CAP 21 C672 CAP 21 C673 CAP 23 C674 CAP 34 C675 CAP 23 C676 CAP 22 C677 CAP 35 C678 CAP 25 C679 CAP 34 C680 CAP 34 C681 CAP 25 C682 CAP 34 C683 CAP 35 C684 CAP 22 C685 CAP 22 C686 CAP 14 C687 CAP 34 C688 CAP 25 C689 CAP 34 C690 CAP 25 C691 CAP 14 C692 CAP 14 C693 CAP 34 C694 CAP_P 33 C695 CAP 34 C696 CAP 22 C697 CAP 33 C698 CAP 14 C699 CAP 34 C700 CAP 33 C701 CAP 21 C702 CAP 22 C703 CAP 22 C704 CAP 21 C705 CAP 35 C706 CAP 22 C707 CAP 22 C708 CAP 19 C709 CAP 35 C710 CAP 22 C711 CAP 25 C712 CAP 22 C713 CAP 22 C714 CAP 22 C715 CAP 21 C716 CAP 21 C717 CAP 22 C718 CAP 22 C719 CAP_P 19 C720 CAP_P 19 C721 CAP_P 19 C722 CAP 21 C723 CAP 35 C724 CAP 22 C725 CAP 21 C726 CAP 35 C727 CAP 10 C728 CAP_P 34 C729 CAP_P 34 C730 CAP_P 34 C731 CAP_P 34 C732 CAP_P 34 C733 CAP_P 34 C734 CAP_P 34 C735 CAP 10 C736 CAP 10 C737 CAP 10 C738 CAP 10 C739 CAP 22 C740 CAP 35 C741 CAP 10 C742 CAP 10 C743 CAP 10 C744 CAP 22 C745 CAP_P 35 C746 CAP 22 C747 CAP 10 C748 CAP 10 C749 CAP 22 C750 CAP_P 32 C751 CAP_P 35 C752 CAP 10 C753 CAP 10 C754 CAP 27 C755 CAP 27 C756 CAP_P 33 C757 CAP 31 C758 CAP_P 32 C759 CAP 33 C760 CAP 33 C761 CAP 11 C762 CAP 19 C763 CAP 33 C764 CAP 34 C765 CAP_P 32 C766 CAP 19 C767 CAP 25 C768 CAP 34 C769 CAP_P 32 C770 CAP 33 C771 CAP 31 C772 CAP 31 C773 CAP 17 C774 CAP 29 C775 CAP 31 C776 CAP 17 C777 CAP 28 C778 CAP 28 C779 CAP 33 C780 CAP_P 35 C781 CAP 29 C782 CAP_P 35 C783 CAP 17 C784 CAP 29 C785 CAP 33 C786 CAP 29 C787 CAP 32 C788 CAP_P 35 C789 CAP 17 C790 CAP 17 C791 CAP 17 C792 CAP 29 C793 CAP_P 32 C794 CAP_P 32 C795 CAP 17 C796 CAP 17 C797 CAP 17 C798 CAP 17 C799 CAP_P 32 C800 CAP 33 C801 CAP 32 C802 CAP 31 C803 CAP 29 C804 CAP 28 C805 CAP 29 C806 CAP 33 C807 CAP 29 C808 CAP 28 C809 CAP 35 C810 CAP 28 C811 CAP 33 C812 CAP 30 C813 CAP 17 C814 CAP 23 C815 CAP 23 C816 CAP 23 C817 CAP 31 C818 CAP_P 28 C819 CAP_P 32 C820 CAP_P 32 C821 CAP_P 32 C822 CAP_P 32 C823 CAP_P 33 C824 CAP_P 31 C825 CAP_P 33 C826 CAP 33 C827 CAP 30 C828 CAP 23 C829 CAP 26 C830 CAP 26 C831 CAP 30 C832 CAP 30 C833 CAP 26 C834 CAP 26 C835 CAP 30 C836 CAP 26 C837 CAP 26

C838 CAP 26 C839 CAP 26 C840 CAP 26 C841 CAP 26 C842 CAP 26 C843 CAP 26 C844 CAP 26 C845 CAP 26 C846 CAP 25 C847 CAP 21 C848 CAP 21 C849 CAP 21 C850 CAP 21 C851 CAP 21 C852 CAP 21 C853 CAP 21 C854 CAP 21 C855 CAP 21 C856 CAP 21 C857 CAP 21 C858 CAP 21 C859 CAP 21 C860 CAP 21 C861 CAP 21 C862 CAP 21 C863 CAP 21 C864 CAP 21 C865 CAP 21 C866 CAP 21 C867 CAP 21 C868 CAP 21 C869 CAP 21 C870 CAP 21 C871 CAP 21 C872 CAP 21 C873 CAP 21 C874 CAP 21 C875 CAP 21 C876 CAP 21 C877 CAP 21 C878 CAP 21 C879 CAP 21 C880 CAP 21 C881 CAP 21 C882 CAP 19 C883 CAP 31 C884 CAP_P 34 C885 CAP_P 34 C886 CAP 35 C887 CAP 35 C888 CAP 35 C889 CAP 21 C890 CAP 35 C891 CAP 35 C892 CAP 35 C893 CAP 35 C894 CAP 35 C895 CAP 25 C896 CAP 25 C897 CAP 25 C898 CAP 25 C899 CAP 25 C900 CAP 25 C901 CAP 25 C902 CAP 19 C903 CAP 25 C904 CAP 25 C905 CAP 25 C906 CAP 31 C907 CAP 35 C908 CAP 35 C909 CAP 5 D1 DIODE 27 D2 DIODE_SCHOT 34 D3 DIODE_SCHOT 32 D4 DIODE 32 D5 DIODE_SCHOT 19 D6 DIODE_SCHOT 33 D7 DIODE_SCHOT 32 D8 ZENER 29 D9 DIODE 31 D10 DIODE 31 D11 DIODE_SCHOT 32 D12 DIODE_DUAL_6P 29 D13 DIODE_SCHOT 33 D14 DIODE_SCHOT_3P2 28 D15 DIODE_DUAL_6P 29 D16 DIODE 33 D17 DIODE_SCHOT 32 D18 DIODE 32 D19 DIODE_SCHOT 32 D20 DIODE_SCHOT 28 D21 DIODE_SCHOT 22 D22 DIODE_SCHOT 33 D23 DIODE_SCHOT 35 D24 DIODE_SCHOT 19 D25 DIODE 34 D26 DIODE_DUAL_6P 29 D27 DIODE_SCHOT 32 D28 DIODE_DUAL_6P 29 D29 DIODE_SCHOT 29 D30 DIODE_SCHOT 31 D33 DIODE_SCHOT 35 D34 DIODE_SCHOT 33 DP1 DPAK3P 19 DP2 DPAK3P 34 DP3 DPAK3P 35 DP4 DPAK3P 31 DP5 DPAK3P 29 DP6 DPAK3P 19 DP7 DPAK3P 21 F1 FUSE 22 F2 FUSE 29 F3 FUSE 31 F4 FUSE 31 F5 FUSE 29 FL1 FILTER_LC 22 FL2 FILTER_LC 22 FL3 FILTER_LC 22 G1 OSC 28 G2 OSC 18 J1 CON_F1ST_S2MT_SM 14 J2 CON_3RTSM_125 25 J3 CON_F14RT_S2MT_SM 24 J4 CON_3RTSM_125 25 J5 CON_12 34 J6 CON_F30RT_S2MT_SM 22 J7 CON_4RT_WRIB 22 J8 CON_F16ST_D_SMA 25 J9 CON_M80ST_D4MT_SM 17 J10 CON_M50SM_5MM 24 J11 CON_F14RT_S2MT_SM 32 J12 CON_F30ST_D_SM 25 J13 CON_M50SM_5MM 24 J14 CON_F30RT_T6MT_TH1 22 J15 CON_F5RT_MINIDIN_TH 22 J16 CON_10STSM_5087 25 J17 CON_RJ45_SHORT_4MT_TH 27 J18 CON_M8RT_S_SM 31 J19 CON_F200RT_DDRDIMM_SM1 11 J20 CON_F80ST_D4MT_SM 24 J22 CON_F200RT_DDRDIMM_SM2 11 J23 CON_F6RT_S4MT_TH1 29 J24 CON_F40RT_S2MT_SM 23 J25 CON_M8RT_S_SM 31 J26 CON_F9RT_1394B_S6MT_SMA 29 L1 IND 14 L2 IND 18 L3 IND 18 L4 IND 18 L5 IND 27 L6 IND 22 L7 IND 28 L8 IND 31 L9 IND 31 L10 IND 31 L11 IND 23 L12 IND 31 L13 IND 20 L14 IND 20 L15 IND 20 L16 IND 21 L18 IND 14 L21 FILTER_4P 22 L22 IND 14 L23 IND 22 L24 IND 19 L25 IND 22

L26 IND 22 L27 IND 22 L28 IND 22 L29 IND 22 L30 IND_3P 19 L31 IND 22 L32 IND 22 L33 IND 22 L34 IND 27 L35 IND 35 L36 IND_3P 34 L37 IND_3P 32 L38 IND 33 L39 IND 29 L40 IND 29 L41 IND 33 L42 IND 31 L43 FILTER_4P 29 L44 FILTER_4P 29 L45 IND 35 L46 IND 23 L47 IND 23 L48 IND 23 L49 IND 23 L50 IND 29 L51 IND 28 L52 IND 23 L53 IND 31 L54 IND 26 L55 IND 21 L56 IND 21 L57 IND 21 L58 IND 21 L59 IND 21 L60 IND 21 L61 IND 21 L62 IND 21 L63 IND 21 L64 IND 21 L65 IND 21 L66 IND 21 L67 IND 21 L68 IND 21 L69 IND 21 L70 FILTER_4P 29 L71 FILTER_4P 29 L72 FILTER_4P 22 L73 FILTER_4P 22 L74 FILTER_4P 22 L75 IND 35 L76 IND 25 L77 IND 25 L78 IND 25 L79 IND 25 L80 IND 25 L81 IND 25 L82 IND 25 PD1 PHOTODIODE_2P 23 Q1 TRA_2N7002DW 7 Q2 TRA_2N7002DW 7 Q3 TRA_2N7002 7 Q4 TRA_2N3904 7 Q5 TRA_2N3904 19 Q6 TRA_2N3904 19 Q7 TRA_FDG6324L 22 Q8 TRA_2N7002 22 Q9 TRA_2N7002DW 33 Q10 TRA_2N7002DW 31 Q11 TRA_SI3443DV 22 Q12 TRA_2N3904 34 Q13 TRA_SI4435DY 31 Q14 TRA_FDG6324L 32 Q15 TRA_2N7002DW 27 Q16 TRA_SI4435DY 31 Q17 TRA_2N3904 34 Q19 TRA_2N7002 35 Q20 TRA_2N7002DW 31 Q21 TRA_2N7002DW 31 Q22 TRA_2N7002 30 Q23 TRA_2N7002DW 33 Q24 TRA_SI4435DY 31 Q25 TRA_2N7002DW 29 33 Q26 TRA_2N7002DW 25 Q27 TRA_2N7002DW 31 Q28 TRA_SI3443DV 33 Q29 TRA_2N7002DW 31 Q30 TRA_2N7002DW 31 Q31 TRA_2N7002DW 25 Q32 TRA_SI3443DV 33 Q33 TRA_2N3906 23 Q35 TRA_2N7002DW 22 23 Q36 TRA_SI3446DV 25 Q37 TRA_SI3446DV 25 Q38 TRA_2N7002DW 22 Q39 TRA_2N3904 25 Q40 TRA_TP0610 22 Q41 TRA_2N7002DW 22 Q42 TRA_2N3904 22 Q43 TRA_SI3443DV 33 Q44 TRA_2N3904 22 Q45 TRA_TP0610 22 Q46 TRA_SI3446DV 35 Q47 TRA_2N3904 25 Q48 TRA_SI7892DP 19 Q49 TRA_SI7860DP 34 Q50 TRA_SI7860DP 34 Q51 TRA_SI7860DP 19 Q52 TRA_SI4888DY 33 Q53 TRA_IRF7832 34 Q54 TRA_IRF7832 34 Q55 TRA_IRF7832 34 Q56 TRA_IRF7811W 35 Q57 TRA_IRF7805 35 Q58 TRA_2N7002DW 29 Q59 TRA_IRF7805 32 Q60 TRA_IRF7811W 32 Q61 TRA_SI4888DY 33 Q62 TRA_2N3904 25 Q63 TRA_IRF7805 31 Q64 TRA_IRF7811W 31 Q65 TRA_2N7002DW 31 Q66 TRA_2N3904 25 Q67 TRA_NDS9407 29 Q68 TRA_IRF7811W 35 Q69 TRA_IRF7805 35 Q71 TRA_SI4888DY 33 Q72 TRA_SI4888DY 33 Q73 TRA_2N3906 23 Q74 TRA_2N3906 23 Q75 TRA_2N7002DW 23 Q76 TRA_SUD45P03 31 Q77 TRA_SI3446DV 19 Q78 TRA_2N7002DW 25 Q79 TRA_2N7002DW 33 Q80 TRA_2N7002DW 19 Q81 TRA_2N7002DW 33 Q82 TRA_2N7002DW 35 Q83 TRA_2N7002DW 35 Q84 TRA_SI6467BDQ 35 Q85 TRA_SI6467BDQ 35 Q86 TRA_2N7002DW 34 Q87 TRA_2N7002DW 25 R1 RES 22 R2 RES 7 R3 RES 7 R4 RES 7 R5 RES 7 R6 RES 23 R7 RES 14 R8 RES 24 R9 RES 7 R10 RES 7 R11 RES 7 R12 RES 7 R13 RES 7 R14 RES 7 R15 RES 7 R16 RES 7 R17 RES 7 R18 RES 7 R19 RES 7 R20 RES 7 R21 RES 7 R22 RES 7 R23 RES 7 R24 RES 7 R25 RES 7 R26 RES 7

R27 RES 7 R28 RES 14 R29 RES 14 R30 RES 24 R31 RES 24 R32 RES 24 R33 RES 7 R34 RES 13 R35 RES 24 R36 RES 24 R37 RES 18 R38 RES 18 R39 RES 23 R40 RES 23 R41 RES 20 R42 RES 25 R43 RES 18 R44 RES 18 R45 RES 18 R46 RES 18 R47 RES 7 R48 RES 7 R49 RES 14 R50 RES 14 R51 RES 13 R52 RES 13 R53 RES 18 R54 RES 18 R55 RES 18 R56 RES 26 R57 RES 5 R58 RES 5 R59 RES 5 R60 RES 5 R61 RES 5 R62 RES 23 R63 RES 24 R64 RES 24 R65 RES 5 R66 RES 20 R67 RES 14 R68 RES 24 R69 RES 24 R70 RES 18 R71 RES 24 R72 RES 5 R73 RES 5 R74 RES 24 R75 RES 24 R76 RES 24 R77 RES 12 R78 RES 26 R79 RES 5 R80 RES 14 R81 RES 24 R82 RES 12 R83 RES 26 R84 RES 26 R85 RES 5 R86 RES 5 R87 RES 5 R88 RES 20 R89 RES 14 R90 RES 14 R91 RES 14 R92 RES 13 R93 RES 24 R94 RES 24 R95 RES 24 R96 RES 26 R97 RES 5 R98 RES 5 R99 RES 20 R100 RES 14 R101 RES 24 R102 RES 14 R103 RES 12 R104 RES 18 R105 RES 18 R106 RES 5 R107 RES 5 R108 RES 5 R109 RES 5 R110 RES 20 R111 RES 14 R112 RES 12 R113 RES 14 R114 RES 14 R115 RES 14 R116 RES 24 R117 RES 13 R118 RES 18 R119 RES 18 R120 RES 5 R121 RES 8 R122 RES 8 R123 RES 8 R124 RES 13 R125 RES 14 R126 RES 18 R127 RES 18 R128 RES 5 R129 RES 5 R130 RES 5 R131 RES 8 R132 RES 8 R133 RES 8 R134 RES 8 R135 RES 8 R136 RES 8 R137 RES 8 R138 RES 18 R139 RES 5 R140 RES 8 R141 RES 8 R142 RES 8 R143 RES 8 R144 RES 8 R145 RES 13 R146 RES 12 R147 RES 12 R148 RES 5 R149 RES 7 R150 RES 8 R151 RES 8 R152 RES 8 R153 RES 8 R154 RES 13 R155 RES 14 R156 RES 14 R157 RES 12 R158 RES 18 R159 RES 18 R160 RES 5 R161 RES 8 R162 RES 8 R163 RES 8 R164 RES 8 R165 RES 8 R166 RES 8 R167 RES 8 R168 RES 14 R169 RES 12 R170 RES 12 R171 RES 12 R172 RES 18 R173 RES 18 R174 RES 8 R175 RES 8 R176 RES 8 R177 RES 8 R178 RES 8 R179 RES 8 R180 RES 12 R181 RES 18 R182 RES 8 R183 RES 8 R184 RES 8 R185 RES 12 R186 RES 12 R187 RES 12 R188 RES 18 R189 RES 18 R190 RES 35 R191 RES 9 R192 RES 12 R193 RES 12 R194 RES 12

R195 RES 18 R196 RES 8 R197 RES 8 R198 RES 9 R199 RES 9 R200 RES 18 R201 RES 18 R202 RES 20 R203 RES 19 R204 RES 20 R205 RES 20 R206 RES 5 R207 RES 8 R208 RES 8 R209 RES 12 R210 RES 20 R211 RES 20 R212 RES 20 R213 RES 22 R214 RES 20 R215 RES 8 R216 RES 12 R217 RES 12 R218 RES 20 R219 RES 20 R220 RES 20 R221 RES 19 R222 RES 20 R223 RES 19 R224 RES 20 R225 RES 8 R226 RES 8 R227 RES 8 R228 RES 19 R229 RES 19 R230 RES 12 R231 RES 20 R232 RES 20 R233 RES 20 R234 RES 19 R235 RES 20 R236 RES 19 R237 RES 20 R238 RES 9 R239 RES 10 R240 RES 19 R241 RES 5 R242 RES 10 R243 RES 10 R244 RES 14 R245 RES 19 R246 RES 19 R247 RES 19 R248 RES 19 R249 RES 19 R250 RES 9 R251 RES 21 R252 RES 10 R253 RES 19 R254 RES 19 R255 RES 21 R256 RES 19 R257 RES 19 R258 RES 19 R259 RES 19 R260 RES 19 R261 RES 19 R262 RES 19 R263 RES 19 R264 RES 14 R265 RES 19 R266 RES 19 R267 RES 34 R268 RES 21 R269 RES 19 R270 RES 19 R271 RES 19 R272 RES 19 R273 RES 19 R274 RES 19 R275 RES 5 R276 RES 5 R277 RES 14 R278 RES 14 R279 RES 21 R280 RES 5 R281 RES 14 R282 RES 5 R283 RES 5 R284 RES 21 R285 RES 14 R286 RES 26 R287 RES 15 R288 RES 34 R289 RES 34 R290 RES 34 R291 RES 14 R292 RES 34 R293 RES 25 R294 RES 19 R295 RES 25 R296 RES 33 R297 RES 34 R298 RES 33 R299 RES 21 R300 RES 33 R301 RES 34 R302 RES 34 R303 RES 34 R304 RES 34 R305 RES 34 R306 RES 19 R307 RES 19 R308 RES 33 R309 RES 33 R310 RES 33 R311 RES 19 R312 RES 34 R313 RES 34 R314 RES 34 R315 RES 34 R316 RES 19 R317 RES 22 R318 RES 34 R319 RES 27 R320 RES 22 R321 RES 34 R322 RES 34 R323 RES 34 R324 RES 34 R325 RES 34 R326 RES 34 R327 RES 34 R328 RES 34 R329 RES 34 R330 RES 34 R331 RES 34 R332 RES 19 R333 RES 27 R334 RES 27 R335 RES 27 R336 RES 34 R337 RES 34 R338 RES 9 R339 RES 19 R340 RES 19 R341 RES 19 R342 RES 22 R343 RES 27 R344 RES 27 R345 RES 27 R346 RES 27 R347 RES 27 R348 RES 17 R349 RES 34 R350 RES 33 R351 RES 19 R352 RES 19 R353 RES 27 R354 RES 27 R355 RES 27 R356 RES 34 R357 RES 9 R358 RES 31 R359 RES 32 R360 RES 32 R361 RES 27 R362 RES 27

8 7

2 1

7 6

R363 RES 31 R364 RES 31 R365 RES 31 R366 RES 34 R367 RES 33 R368 RES 33 R369 RES 33 R370 RES 27 R371 RES 27 R372 RES 27 R373 RES 17 R374 RES 31 R375 RES 31 R376 RES 34 R377 RES 33 R378 RES 33 R379 RES 32 R380 RES 27 R381 RES 27 R382 RES 27 R383 RES 31 R384 RES 34 R385 RES 34 R386 RES 9 R387 RES 9 R388 RES 19 R389 RES 19 R390 RES 19 R391 RES 22 R392 RES 32 R393 RES 27 R394 RES 31 R395 RES 31 R396 RES 31 R397 RES 34 R398 RES 34 R399 RES 15 R400 RES 22 R401 RES 32 R402 RES 32 R403 RES 27 R404 RES 27 R405 RES 25 R406 RES 27 R407 RES 34 R408 RES 34 R409 RES 9 R410 RES 19 R411 RES 24 R412 RES 32 R413 RES 27 R414 RES 31 R415 RES 34 R416 RES 19 R417 RES 35 R418 RES 35 R419 RES 35 R420 RES 35 R421 RES 35 R422 RES 35 R423 RES 35 R424 RES 35 R425 RES 35 R426 RES 32 R427 RES 27 R428 RES 27 R429 RES 34 R430 RES 19 R431 RES 33 R432 RES 32 R433 RES 32 R434 RES 34 R435 RES 27 R436 RES 28 R437 RES 28 R438 RES 27 R439 RES 9 R440 RES 11 R441 RES 24 R442 RES 24 R443 RES 32 R444 RES 28 R445 RES 28 R446 RES 28 R447 RES 28 R448 RES 34 R449 RES 11 R450 RES 35 R451 RES 19 R452 RES 24 R453 RES 29 R454 RES 31 R455 RES 35 R456 RES 33 R457 RES 33 R458 RES 24 R459 RES 28 R460 RES 31 R461 RES 35 R462 RES 33 R463 RES 33 R464 RES 28 R465 RES 27 R466 RES 31 R467 RES 33 R468 RES 32 R469 RES 28 R470 RES 28 R471 RES 28 R472 RES 29 R473 RES 31 R474 RES 31 R475 RES 30 R476 RES 30 R477 RES 33 R478 RES 28 R479 RES 35 R480 RES 35 R481 RES 33 R482 RES 33 R483 RES 32 R484 RES 28 R485 RES 28 R486 RES 28 R487 RES 31 R488 RES 31 R489 RES 31 R490 RES 31 R491 RES 30 R492 RES 30 R493 RES 35 R494 RES 28 R495 RES 28 R496 RES 28 R497 RES 31 R498 RES 31 R499 RES 31 R500 RES 9 R501 RES 30 R502 RES 30 R503 RES 30 R504 RES 30 R505 RES 30 R506 RES 33 R507 RES 33 R508 RES 32 R509 RES 28 R510 RES 28 R511 RES 31 R512 RES 31 R513 RES 30 R514 RES 33 R515 RES 33 R516 RES 28 R517 RES 30 R518 RES 30 R519 RES 33 R520 RES 33 R521 RES 32 R522 RES 28 R523 RES 33 R524 RES 28 R525 RES 28 R526 RES 31 R527 RES 25 R528 RES 33 R529 RES 33 R530 RES 26

R531 RES 26 R532 RES 23 R533 RES 23 R534 RES 23 R535 RES 30 R536 RES 30 R537 RES 25 R538 RES 33 R539 RES 33 R540 RES 26 R541 RES 32 R542 RES 31 R543 RES 31 R544 RES 30 R545 RES 26 R546 RES 28 R547 RES 28 R548 RES 31 R549 RES 31 R550 RES 23 R551 RES 26 R552 RES 23 R553 RES 25 R554 RES 26 R555 RES 28 R556 RES 28 R557 RES 28 R558 RES 31 R559 RES 31 R560 RES 31 R561 RES 31 R562 RES 30 R563 RES 28 R564 RES 28 R565 RES 31 R566 RES 31 R567 RES 31 R568 RES 23 R569 RES 30 R570 RES 31 R571 RES 31 R572 RES 30 R573 RES 30 R574 RES 28 R575 RES 28 R576 RES 28 R577 RES 28 R578 RES 31 R579 RES 31 R580 RES 31 R581 RES 23 R582 RES 23 R583 RES 30 R584 RES 30 R585 RES 30 R586 RES 26 R587 RES 23 R588 RES 31 R589 RES 33 R590 RES 26 R591 RES 26 R592 RES 30 R593 RES 30 R594 RES 30 R595 RES 30 R596 RES 30 R597 RES 30 R598 RES 23 R599 RES 31 R600 RES 26 R601 RES 24 R602 RES 24 R603 RES 24 R604 RES 14 R605 RES 23 R606 RES 23 R607 RES 35 R608 RES 14 R609 RES 14 R610 RES 35 R611 RES 35 R612 RES 24 R613 RES 24 R614 RES 14 R615 RES 23 R616 RES 35 R617 RES 23 R618 RES 23 R619 RES 23 R620 RES 25 R621 RES 13 R622 RES 14 R623 RES 25 R624 RES 13 R625 RES 14 R626 RES 13 R627 RES 35 R628 RES 25 R629 RES 13 R630 RES 13 R631 RES 14 R632 RES 14 R633 RES 27 R634 RES 14 R636 RES 14 R638 RES 14 R639 RES 8 R640 RES 8 R641 RES 8 R642 RES 8 R643 RES 8 R644 RES 8 R645 RES 8 R646 RES 8 R647 RES 8 R649 RES 22 R650 RES 22 R651 RES 8 R652 RES 8 R653 RES 8 R654 RES 8 R655 RES 22 R656 RES 14 R657 RES 8 R658 RES 8 R659 RES 8 R660 RES 8 R661 RES 22 R662 RES 22 R663 RES 22 R664 RES 8 R665 RES 8 R666 RES 8 R667 RES 8 R668 RES 8 R669 RES 8 R670 RES 22 R671 RES 22 R672 RES 35 R673 RES 8 R674 RES 8 R675 RES 8 R676 RES 8 R677 RES 8 R678 RES 8 R679 RES 25 R680 RES 22 R681 RES 22 R682 RES 14 R683 RES 8 R684 RES 8 R685 RES 8 R686 RES 22 R688 RES 22 R689 RES 25 R690 RES 22 R691 RES 22 R692 RES 25 R693 RES 5 R694 RES 22 R695 RES 25 R696 RES 22 R697 RES 33 R698 RES 14 R699 RES 14 R700 RES 22 R701 RES 14 R702 RES 5

R703 RES 22 R704 RES 22 R705 RES 22 R706 RES 22 R707 RES 14 R708 RES 14 R709 RES 35 R710 RES 25 R711 RES 19 R712 RES 35 R713 RES 25 R714 RES 22 R715 RES 35 R716 RES 25 R717 RES 25 R718 RES 22 R719 RES 25 R720 RES 14 R721 RES 21 R722 RES 21 R723 RES 25 R724 RES 22 R725 RES 25 R726 RES 25 R727 RES 35 R728 RES 21 R729 RES 21 R730 RES 24 R731 RES 33 R732 RES 34 R733 RES 27 R734 RES 31 R735 RES 27 R736 RES 29 R737 RES 29 R738 RES 31 R739 RES 31 R740 RES 28 R741 RES 29 R742 RES 31 R743 RES 29 R744 RES 31 R745 RES 24 R746 RES 31 R747 RES 31 R748 RES 31 R749 RES 31 R750 RES 17 R751 RES 29 R752 RES 29 R753 RES 17 R754 RES 31 R755 RES 31 R756 RES 17 R757 RES 17 R758 RES 28 R759 RES 28 R760 RES 28 R761 RES 28 R762 RES 17 R763 RES 31 R764 RES 17 R765 RES 30 R766 RES 17 R767 RES 17 R768 RES 30 R769 RES 30 R770 RES 23 R771 RES 23 R772 RES 23 R773 RES 23 R774 RES 31 R775 RES 28 R776 RES 23 R777 RES 23 R778 RES 30 R779 RES 29 R781 RES 28 R782 RES 30 R783 RES 26 R784 RES 26 R785 RES 30 R786 RES 30 R787 RES 30 R788 RES 30 R789 RES 26 R790 RES 26 R791 RES 26 R792 RES 26 R793 RES 26 R794 RES 26 R795 RES 26 R796 RES 26 R797 RES 35 R798 RES 35 R799 RES 35 R800 RES 35 R801 RES 35 R802 RES 35 R803 RES 35 R804 RES 19 R805 RES 34 R806 RES 34 R807 RES 34 R808 RES 34 R809 RES 34 R810 RES 35 R811 RES 25 R812 RES 25 R813 RES 25 R814 RES 25 RP1 RPAK4P 14 RP2 RPAK4P 24 RP3 RPAK4P 24 RP4 RPAK4P 24 RP5 RPAK4P 24 RP6 RPAK4P 14 RP7 RPAK4P 14 RP8 RPAK4P 14 RP9 RPAK4P 24 RP10 RPAK4P 24 RP11 RPAK4P 24 RP12 RPAK4P 13 RP13 RPAK4P 24 RP14 RPAK4P 13 RP15 RPAK4P 13 RP16 RPAK4P 13 RP17 RPAK4P 12 RP18 RPAK4P 12 RP19 RPAK4P 12 RP20 RPAK4P 12 RP21 RPAK4P 8 RP22 RPAK4P 12 RP23 RPAK4P 8 RP24 RPAK4P 8 14 RP25 RPAK4P 9 RP26 RPAK4P 9 RP27 RPAK2P 20 RP28 RPAK2P 20 RP29 RPAK4P 14 RP30 RPAK4P 9 RP31 RPAK4P 9 RP32 RPAK2P 20 RP33 RPAK4P 9 RP34 RPAK4P 9 RP35 RPAK4P 9 RP36 RPAK4P 9 RP37 RPAK4P 28 RP38 RPAK4P 28 RP39 RPAK10P2C 17 RP40 RPAK4P 30 RP41 RPAK4P 30 RP42 RPAK10P2C 23 RP43 RPAK10P2C 23 RP44 RPAK4P 25 RP45 RPAK4P 26 RP46 RPAK4P 14 RP47 RPAK4P 14 RP48 RPAK4P 14 RP49 RPAK4P 24 RP50 RPAK4P 24 RP51 RPAK4P 14 RP52 RPAK4P 23 26 RP53 RPAK4P 23 RP54 RPAK4P 26 RP55 RPAK4P 26 RP56 RPAK4P 14 RP57 RPAK2P 20

RP58 RPAK2P 20 RP59 RPAK2P 20 RP60 RPAK2P 20 RP61 RPAK2P 20 SH1 SHLD_3P_EMI 4 SP1 SPKR_CLIP_P84 4 SP2 SPKR_CLIP_P84 4 SP3 SPKR_CLIP_P84 4 SP4 SPKR_CLIP_P84 4 SP5 SPKR_CLIP_P84 4 SP6 SPKR_CLIP_P84 4 T1 XFR_ENET_1000BT 27 U1 SN74AUC1G04 7 U2 SN74AUC1G08 23 U3 ADT7460 25 U4 SN74AUC1G08 23 U5 SIL1162 20 U6 FAN2558 5 U7 VREG_LT1962 14 U9 CBTV4020 10 U10 CBTV4020 10 U11 PI3B3257 34 U12 CBTV4020 10 U13 CBTV4020 10 U14 LTC3405 27 U15 COMPARATOR_LMC7211 31 U16 LTC1778 19 U17 FEPR_1MX8 9 U18 LTC1625 32 U19 PWR_CNTRL_TPS2211 17 U20 MAX1717 34 U21 COMPARATOR_LMC7211 32 U22 MAX1715 35 U23 AMP_MAX4172 31 U24 7432 22 30 U25 VREG_LP2951 32 U26 PCI1510GGU 17 U27 COMPARATOR_LMC7211 30 U28 LTC3707 33 U29 TSB81BA3A 28 U30 VREG_LP2951 32 U31 MAX1772 31 U32 EEPROM_16KX8_M24128B 23 U33 M16C62 30 U34 VREG_LM2594 28 U35 MAX1916 23 U36 LTC1761 28 U37 VREG_LT1962 28 U38 COMPARATOR_LMC7211 31 U39 UPD720101_FBGA 26 U40 OPAMP_MAX4236EUTT 23 U42 CLK_GEN_CY28512 14 U43 APOLLO_MPC7447A_360 5 6 U44 RAGE_MBLTY_M11_CSP64_667 18 19 21 U45 INTREPID 8 9 12 13 14 15 U46 COMPARATOR_LMC7211 22 U47 CLK_GEN_CY25811 18 U49 TRANSCEIVER_88E1111 27 U50 OPAMP_LMC7111 31 U51 MAX6804 30 U52 FEPR_256KX8_ST72264_BGA 23 U54 VREG_MM1571J 21 U55 VREG_MM1571J 21 U56 741G32 22 U57 741G32 22 U58 LTC3412 35 XW1 SHORT 35 XW2 SHORT 19 XW3 SHORT 34 XW4 SHORT 32 XW5 SHORT 34 XW6 SHORT 35 XW7 SHORT 34 XW8 SHORT 33 XW9 SHORT 25 XW11 JUMPER 35 XW12 SHORT 22 XW13 SHORT 22 XW15 SHORT 34 XW19 SHORT 31 XW20 SHORT 19 XW21 SHORT 19 XW22 SHORT 19 XW23 SHORT 19 XW24 SHORT 19 XW27 SHORT 21 XW28 SHORT 21 XW29 SHORT 21 XW30 SHORT 21 XW31 SHORT 5 Y1 CRYSTAL 14 Y3 CRYSTAL 27 Y4 CRYSTAL 23 Y5 CRYSTAL 26 Y6 CRYSTAL 30 Y7 CRYSTAL_4PIN 30 ZT1 HOLE_VIA 4 ZT2 MTGHOLE 4 ZT3 HOLE_VIA 4 ZT4 MTGHOLE 4 ZT5 MTGHOLE 4 ZT6 MTGHOLE 4 ZT7 HOLE_VIA 4 ZT8 HOLE_VIA 4 ZT9 HOLE_VIA 4 ZT10 MTGHOLE 4 ZT11 MTGHOLE 4 ZT12 HOLE_VIA 4 ZT13 HOLE_VIA 4 ZT14 HOLE_VIA 4 ZT15 HOLE_VIA 4 ZT16 MTGHOLE 4 ZT17 HOLE_VIA 4 ZT18 HOLE_VIA 4 ZT19 HOLE_VIA 4 ZT20 HOLE_VIA 4 ZT21 HOLE_VIA 4 ZT22 HOLE_VIA 4 ZT23 HOLE_VIA 4 ZT24 HOLE_VIA 4 ZT25 HOLE_VIA 4 ZT26 HOLE_VIA 4 ZT27 HOLE_VIA 4 ZT28 HOLE_VIA 4 ZT29 HOLE_VIA 4 ZT30 HOLE_VIA 4 ZT31 HOLE_VIA 4 ZT32 HOLE_VIA 4 ZT33 HOLE_VIA 4 ZT34 HOLE_VIA 4 ZT35 HOLE_VIA 4 ZT36 HOLE_VIA 4 ZT37 HOLE_VIA 4 ZT38 HOLE_VIA 4 ZT39 HOLE_VIA 4 ZT40 HOLE_VIA 4 ZT41 HOLE_VIA 4 ZT42 HOLE_VIA 4 ZT43 HOLE_VIA 4 ZT44 HOLE_VIA 4 ZT45 HOLE_VIA 4 ZT46 HOLE_VIA 4 ZT47 HOLE_VIA 4 ZT48 HOLE_VIA 4 ZT49 HOLE_VIA 4 ZT50 HOLE_VIA 4 ZT51 HOLE_VIA 4 ZT52 HOLE_VIA 4 ZT53 HOLE_VIA 4 ZT54 HOLE_VIA 4 ZT55 HOLE_VIA 4 ZT56 HOLE_VIA 4 ZT57 HOLE_VIA 4 ZT58 HOLE_VIA 4 ZT59 HOLE_VIA 4 ZT60 HOLE_VIA 4 ZT61 HOLE_VIA 4 ZT62 HOLE_VIA 4 ZT63 HOLE_VIA 4 ZT64 HOLE_VIA 4 ZT65 HOLE_VIA 4 ZT66 HOLE_VIA 4 ZT67 HOLE_VIA 4 ZT68 HOLE_VIA 4 ZT69 HOLE_VIA 4 ZT70 HOLE_VIA 4 ZT71 HOLE_VIA 4 ZT72 HOLE_VIA 4

ZT73 HOLE_VIA 4 ZT74 HOLE_VIA 4 ZT75 HOLE_VIA 4 ZT76 HOLE_VIA 4 ZT77 HOLE_VIA 4 ZT78 HOLE_VIA 4 ZT79 HOLE_VIA 4 ZT80 HOLE_VIA 4 ZT81 HOLE_VIA 4 ZT82 HOLE_VIA 4 ZT83 MTGHOLE 4

Apple A1085 Schematic

Specifications and Main Features

Frequently Asked Questions

User Manual
