Apple A1025 Schematic

ANGLES

3. ALL CRYSTALS & OSCILLATOR VALUES ARE IN HERTZ.

2. ALL CAPACITANCE VALUES ARE IN MICROFARADS.

1. ALL RESISTANCE VALUES ARE IN OHMS, 0.1 WATT +/- 5%.

DATE

APPD

ENG

DATE

APPD

CK

ECN

ZONE

REV

DO NOT SCALE DRAWING

X.XXX

X.XX

XX

DIMENSIONS ARE IN MILLIMETERS

THIRD ANGLE PROJECTION

D

SIZE

APPLICABLE

NOTED AS

MATERIAL/FINISH

NONE

SCALE

DESIGNER

MFG APPD

DESIGN CK

RELEASE

QA APPD

ENG APPD

DRAFTER

METRIC

OF

SHT

DRAWING NUMBER

TITLE

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

Apple Computer Inc.

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

DESCRIPTION OF CHANGE

?

11/11/03

303550

PRODUCTION RELEASED

46

1

051-6403

E

SCHEM,PBG4,MLB,P88

E

MPC7455 DATA / L3 CACHE INTERFACES

SYSTEM CLOCK GENERATOR & BOOTROM

FAN CONTROLLERS

MOBILITY M7_M9 POWER INTERFACES

MOBILITY M7_M9 VIDEO/CORE INTERFACES

MOBILITY M7_M9 AGP/MEMORY INTERFACES

MPC7455 MAXBUS INTERFACE

REVISION HISTORY (2 OF 2)

REVISION HISTORY (1 OF 2)

COMPONENT LOCATIONS (1 OF 2)

SIGNAL LOCATIONS

47

MICROPHONE AMP. / LINE IN AMP

SNAPPER (AUDIO) CONTROL INTERFACE

EXTERNAL DDR GRAPHICS RAM

46

45

44

43

38
39
40
41
42

37

26
27
28
29
30
31
32
33
34
35
36

25

24

23

L3 CACHE

KEYLARGO

CARDBUS INTERFACE

USB 2.0 HOST CONTROLLER INTERFACE

CPU CORE VOLTAGE POWER SUPPLY

INTERNAL CONNECTORS - MODEM, DVD,

PMU INTERFACE CONNECTIONS - KEYBOARD,

PMU INTERFACE

FIREWIRE INTERFACE

1.8V / 2.5V SYSTEM POWER SUPPLIES

3.3V / 5V SYSTEM POWER SUPPLY

DC JACK / BATTERY INTERFACES

PRIMARY STEP-DOWN REGULATOR / CHARGER

GIGABIT ETHERNET INTERFACE

HEADPHONE & SPEAKER DRIVERS

CARDSLOT, HARD DRIVE

SYSTEM BLOCK DIAGRAM (2 OF 2)

SYSTEM BLOCK DIAGRAM (1 OF 2)

TITLE PAGE AND CONTENTS

PCB NOTES AND HOLES

POWER BLOCK DIAGRAM

UNI-N DECOUPLING

UNI-N AGP INTERFACE

UNI-N PCI INTERFACE

UNI-N MAXBUS INTERFACE

UNI-N MEMORY INTERFACE / SO-DIMM CONNECTOR

UNI-N & CPU CONFIGURATION STRAPS

UNI-N MISCELLANEOUS INTERFACES

22

19

18

17

16

15

10
11
12
13
14

9

4

3

5
6
7
8

2

PAGE

1

CONTENTS PAGE CONTENTS

20
21

VIDEO CONNECTORS - LVDS, DVI, S-VIDEO

TRACKPAD, LEDS, DVI POWER SWITCH

SIGNAL CONSTRAINTS (1 OF 4)

SIGNAL CONSTRAINTS (2 OF 4)

SIGNAL CONSTRAINTS (3 OF 4)

SIGNAL CONSTRAINTS (4 OF 4)

EXTERNAL USB & BT INTERFACES

COMPONENT LOCATIONS (2 OF 2)

48

CR-1

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

2 46

E

051-6403

(XPC7455)

Apollo

System Clock

TI PCI1410A

16MB DDR

LCD Panel

Connector

G/MII

U53

U51U52

J11

U2/U7

U23

J14

U47

U22

J28

U11/U42

U10

U9

U4

U8U5

J2

J4J1

J17

(DDC TOO)

RGB

TMDS

DVI-I

183 MHZ

Port 4Port 3

32BITS

P.18

CardBus

Connector

Controller

CardBus

P.18

33MHZ
16/32 BITS

3.3V/5V

J5/J6

USB

P.30

Connector

Host

P.17

NEC USB 2.0

Controller

32BITS

P.10 P.7

P.10P.10

P.9

P.8

P.7 P.6

P.35-39

P.35

P.34

P.33P.33

P.12

P.15

P.13-14

P.24

P.7

P.23

P.19-21

P.28P.29

P.28P.29

P.31P.31P.31P.31

(INTERNAL MEM)

64BITS

2.5V

P.22

VMEM BUS

SDRAM

66MHZ

32BITS

1.5V/3.3V

AGP BUS

Connector

MEMORY

CH. B

MEMORY

ATI

64BIT DATA

32BIT ADDRESS

133MHZ

1.8V

MAXBUS

L3 Cache

Config

CPU PLL

(Expanded
View P.3)

Key Largo

32BITS64BITS

PCI BUS

SYSTEM BLOCK DIAGRAM

Power Supply

& Charger

Battery

COMPOSITE

S-Video

Connector

S-VIDEO

LVDS

EDID (I2C)

1M X 8

SMBUS

3.3V

Keyboard

Connector

PMU

SERIAL

Connector

I2C

5V

Trackpad

IMI C5005

BOOT ROM

3.3V

33MHZ

Upper 32 bits

64BITS

33/66MHZ

BOOTROM

pulled up

PCI

Mobility

MAXBUS

4X AGP

125MHZ

8BIT RX

3.3V

8BIT TX

ETHERNET

10/100/1000

I2C

I2C

CPU

Circuit

Fan

Connector

Connector

4 DATA PAIRS

64BITS

133MHZ

3.3V

MEMORY BUS

FIREWIRE

400 MB/S

UNI-N 1.5

SO-DIMM Connector

SDRAM DIMM 0
SDRAM DIMM 1

MEMORY

Inverter

Ethernet

2 DATA PAIRS

FireWire

Connector

@ 200MHz

PHY

Ethernet

1394 OHCI

PHY

50MHZ

8BIT TX/RX

3.3V

FireWire

CH. A

J21

J7

J16

64BIT DATA

L3 BUS

18BIT ADDRESS

1.5V

200 MHZ

M7_M9

P.23

CR-2

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

3 46

E

051-6403

Snapper

Optical

J8

J12

J3

J24

U37/U38

J27

J26

J25

U47

U53

P.26

P.26

P.27

P.25

P.32

P.32

P.32

P.30

P.30

P.34

P.16

BlueTooth

3.3V

33MHZ

PCI BUS

PMU

Largo

VIA

CSLOT

EIDE0

Key

USB1 D

SCC B

SCC A

(FIReworks)

I2C

I2S

SERIAL

USB0 B

USB0 A

USB1 C

EIDE/CSLOT

CardSlot

Connector

Connector

Ultra ATA/66

Connector

Audio Control

Speaker Amps

Headphone &

Connector

Headphone

MIC

USB Ports

SYSTEM BLOCK DIAGRAM

32BITS

Modem Board

Connector

P.32

J5/J6

P.32

Connector

Serial Debug

UIDE

NC

Mic/Line In

Preamps

U34/U43

Connector

Speaker & Mic

P.26

J19 J30

P.27

Line In

Connector

U58/U59

CR-3

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

4 46

E

051-6403

+1.41V

(+1.15V/+1.3V)

ATI M7_M9 DDR CORE AND I/O

ATI M7_M9 CORE

BACKUP BATTERY CIRCUIT CHARGES OFF PBUS
AND PREVENTS PBUS FROM DROPPING BELOW 6V
(UNTIL DRAINED)

& BOOST OUTPUT

CHARGER INPUT

BATTERY

BACKUP

BUCK

+3.3V

+5V

4S 2P LITHIUM ION

CHARGER

REGULATOR

ADAPTER

IN

AC

POWER SYSTEM ARCHITECTURE

PBUS

DCDC_EN

SLEEP

ON5

ON3

SD

DC/DC

SHDN

BACKLIGHT INVERTER

POWER BLOCK DIAGRAM

INPUT14_24V

MAIN 3V/5V

DC/DC CONVERTER

(MAX785)

(LTC1625)

CPU_VCORE

DCDC_EN

(MAX1717)

+5V

DC/DC

(LTC1773)

+1.25V

+1.8V

L3 I/O

L3 CORE

CPU I/O

MAX BUS INTERFACE

+2.5V

+1.8V

SHDN

(MAX1644)

DC/DC

(MAX1644)

SHDN

DC/DC

+5V

DCDC_EN

+3.3V

DCDC_EN

(LT1962)

LDO

CR-4

118R98

ZT7

118R98

ZT4

22R10

XH1

22R10

XH3

118R98

ZT5

SL1

SL-25X200

TH

140R118

ZT2

118R98

ZT1

235R156

ZT8

140R118

BS3

140R118

BS1

140R118

BS5

140R118

ZT3

140R118

ZT6

22R10

XH4

22R10

XH2

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

5

46

E

051-6403

LAYER COUNT: 10

PCB SPECS

THICKNESS : 1.2 MM / 0.047 IN

1/2 OZ CU THICKNESS: 0.7 MILS

1.0 OZ CU THICKNESS: 1.4 MILS

SIGNAL TRACE WIDTH: 4 MILS

IMPEDANCE : 50 OHMS +/- 10%

PREPREG THICKNESS: 3 - 6 MILS

SEE PCB CAD FILES FOR MORE SPECIFIC INFO.

20R10 TH Via

20R10 Buried Via

Micro Via (Blind)

SIGNAL (1/2 OZ)

SIGNAL (1/2 OZ)

SIGNAL (1/2 OZ)

GROUND (1/2 OZ)

SIGNAL (1/2 OZ)

SIGNAL (1/2 OZ)

SIGNAL (1/2 OZ)

CUT POWER PLANE(DEFAULT 5V)

CUT POWER PLANE(DEFAULT 3V)

GROUND (1/2 OZ)

POWER (1 OZ)

POWER (1 OZ)

10

7

8

9

3

2

1

6

4

5

BOARD STACK-UP AND CONSTRUCTION

HOLE & SLOT FOR BT CARRIER

BOARD INFORMATION

CPU HEATSINK MOUNTS

TIED TO CHGND1

CARDBUS CONN MOUNTS

BOARD HOLES

PCB BOARD STANDOFFS

DIELECTRIC: FR-4

1

1

1

1

1

CHGND5

CHGND4B

CHGND6

CHGND7

1

1

1

1

1

1 1

CHGND1

1

1

1

1

CR-5

HOLE_22R10D

HOLE_22R10A

HOLE_22R10D

HOLE_22R10A

5<>

5<>

5<>

5<>

MAX_CLKIN_VDD3

MAXPLLDVDMAXPLLAVD

MAXPLLAVS

UNI-N-1.5

SPARE1

MAXREF

INTERFACE

MAXBUS

BR_0
BG_0
BR_1
BG_1
TS

A_0
A_1
A_2
A_3
A_4
A_5
A_6
A_7
A_8
A_9
A_10
A_11
A_12
A_13
A_14
A_15
A_16
A_17
A_18
A_19
A_20
A_21
A_22
A_23
A_24
A_25
A_26
A_27
A_28
A_29
A_30
A_31

CI
GBL
TBST
TSIZ_0
TSIZ_1
TSIZ_2
TT_0
TT_1
TT_2
TT_3

WT
AACK

ARTRY
HIT_0
HIT_1

D_38
D_39
D_40
D_41
D_42
D_43
D_44
D_45
D_46
D_47
D_48
D_49
D_50
D_51
D_52
D_53
D_54
D_55
D_56
D_57
D_58
D_59
D_60
D_61
D_62
D_63

DBG_0

DBG_1
DRDY_0
DRDY_1

DTI_0

DTI_1

DTI_2

TEA

TA

D_37

D_0
D_1
D_2
D_3
D_4
D_5
D_6
D_7
D_8

D_9
D_10
D_11
D_12
D_13
D_14
D_15
D_16
D_17
D_18
D_19
D_20

D_22
D_23

D_21

D_24
D_25
D_26
D_27
D_28
D_29
D_30
D_31
D_32
D_33
D_34
D_35
D_36

QACK

SUSPENDACK

SUSPENDREQ

QREQ_0
QREQ_1

MAXCLK

TT_4

(1 OF 5)

PBGA-UNIN-1.5.1

U9

402

CERM

16V

20%

0.01uF

C638

805

CERM

10V

N20P80%

4.7uF

C607

+3V_MAIN

805

CERM

10V

N20P80%

4.7uF

C662

402

CERM

16V

20%

0.01uF

C637

+1_8V_SLEEP

402

MF

1/16W

5%

10K

R366

402

R430

MF

1/16W

1%

49.9

+1_8V_MAIN

402

MF

1/16W

5%

10K

R401

+1_8V_SLEEP

+1_8V_MAIN

402

MF

1/16W

5%

22

R481

402

MF

1/16W

5%

22

R440

402

MF

1/16W

5%

10K

R429

402

MF

1/16W

5%

10K

R415

402

MF

1/16W

5%

10K

R439

SM1

1/16W

5%

10K

RP4

SM1

1/16W

5%

10K

RP4

SM1

1/16W

5%

10K

RP4

SM1

1/16W

5%

10K

RP4

SM1

1/16W

5%

10K

RP2

SM1

1/16W

5%

10K

RP2

SM1

1/16W

5%

1K

RP3

SM1

1/16W

5%

1K

RP3

SM1

1/16W

5%

1K

RP3

SM1

1/16W

5%

1K

RP3

TABLE_ALT_ITEM

343S0347343S1303 U9

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

6

46

E

051-6403

PART NUMBER

ALTERNATE FOR

PART NUMBER

BOM OPTION

REF DES

COMMENTS:

TABLE_ALT_HEAD

UNI-N MAXBUS

UNI-N SECONDARY PROCESSOR SUPPORT

MAXBUS PULL-UPS

NC

NC

CRITICAL

AJ16

AH11

AE13

AJ11

AF13

AE12

AF12

AK10

AJ10

AD15

AE17

AK9

AE18

AB29

Y26

R7

AE15

AH14

AF16

AE8

AJ17

AE6

AE7

AF5

AH2

AH12

AK13

AJ14

AJ23

AJ21

AH21

AJ20

AF19

AH24

AH18

AD25

AH17

AJ18

AJ19

AE19

AK18

AF28

AK28

AD26

AF22

AB24

AC24

AF29

AF26

AG28

AJ26

AJ22

AK26

AF24

AK22

AK23

AE20

AH30

AK21

AD19

AH19

AJ24

AF20

AH22

AH20

AF18

AF21

AJ29

AH28

AK27

AE22

AJ27

AJ25

AF25

AD21

AD22

AH26

AH23

AH27

AE28

AH25

AJ30

AC25

AE25

AE26

AH29

AF23

AE29

AE21

AG29

AB25

AJ28

AH16

AK17

AH15

AE14

AH13

AD16

AJ15

AE16

AF14

AJ13

AF15

AF17

AK3

AD9

AJ3

AJ4

AJ2

AH5

AK5

AD10

AF6

AJ5

AF10

AF7

AH6

AF9

AF11

AD11

AJ6

AF8

AJ9

AH3

AH8

AJ7

AE11

AK8

AE10

AH7

AE9

AH9

AJ8

AH10

AH4

AK4

AJ12

AK14

2

1

2

1

2

1

2

1

21

1

2

21

21 21

21

21

21

81

54

72

63

54

63

81

72

63

54

CR-6

UNIN_DRDY_1_L_PU

UNIN_BR_1_L_PU

CPU_TS_L

CPU_TEA_L

CPU_TA_L

UNIN_HIT_1_L_PU

CPU_BR_L

CPU_HIT_0_L

CPU_ARTRY_L

CPU_DATA<21>

UNIN_SPARE_AB6

CPU_BG_L

CPU_BR_L

SYSCLK_UNIN

CPU_TS_L

UNIN_BR_1_L_PU

UNIN_HIT_1_L_PU

CPU_HIT_0_L

CPU_AACK_L
CPU_ARTRY_L

CPU_TT<3>

CPU_WT_L

CPU_TT<2>

CPU_TT<1>

CPU_TSIZ<2>
CPU_TT<0>

CPU_TSIZ<1>

CPU_TBST_L
CPU_TSIZ<0>

CPU_GBL_L

CPU_CI_L

CPU_ADDR<31>

CPU_ADDR<30>

CPU_ADDR<29>

CPU_ADDR<28>

CPU_ADDR<27>

CPU_ADDR<26>

CPU_ADDR<25>

CPU_ADDR<24>

CPU_ADDR<23>

CPU_ADDR<22>

CPU_ADDR<21>

CPU_ADDR<20>

CPU_ADDR<19>

CPU_ADDR<18>

CPU_ADDR<17>

CPU_ADDR<16>

CPU_ADDR<15>

CPU_ADDR<14>

CPU_ADDR<13>

CPU_ADDR<12>

CPU_ADDR<11>

CPU_ADDR<8>

CPU_ADDR<10>

CPU_ADDR<9>

CPU_ADDR<7>

CPU_ADDR<6>

CPU_ADDR<3>
CPU_ADDR<4>
CPU_ADDR<5>

CPU_ADDR<2>

CPU_ADDR<1>

CPU_ADDR<0>

CPU_QACK_L
UNIN_SUSPEND_REQ_L
UNIN_SUSPEND_ACK_L

CPU_QREQ_L
UNIN_QREQ_1_L_PD

CPU_TT<4>

UNIN_MAXBUS_REF

UNIN_QREQ_1_L_PD

+1_8V_UNIN_MAXPLL_MAIN

+3V_UNIN_MAXPLL_MAIN

CPU_DTI<1>

CPU_DTI<0>

CPU_TA_L

CPU_DTI<2>

CPU_TEA_L

CPU_DATA<59>

CPU_DATA<58>

CPU_DATA<61>

CPU_DATA<60>

CPU_DATA<62>
CPU_DATA<63>

CPU_DBG_L

CPU_DRDY_0_L
UNIN_DRDY_1_L_PU

CPU_DATA<49>

CPU_DATA<48>

CPU_DATA<51>

CPU_DATA<50>

CPU_DATA<54>

CPU_DATA<53>

CPU_DATA<52>

CPU_DATA<56>

CPU_DATA<55>

CPU_DATA<57>

CPU_DATA<37>
CPU_DATA<38>
CPU_DATA<39>
CPU_DATA<40>
CPU_DATA<41>

CPU_DATA<43>

CPU_DATA<42>

CPU_DATA<44>

CPU_DATA<46>

CPU_DATA<45>

CPU_DATA<47>

CPU_DATA<27>
CPU_DATA<28>

CPU_DATA<30>
CPU_DATA<31>

CPU_DATA<29>

CPU_DATA<33>

CPU_DATA<32>

CPU_DATA<36>

CPU_DATA<34>
CPU_DATA<35>

CPU_DATA<23>

CPU_DATA<22>

CPU_DATA<19>
CPU_DATA<20>

CPU_DATA<17>
CPU_DATA<18>

CPU_DATA<24>
CPU_DATA<25>
CPU_DATA<26>

CPU_DATA<16>

CPU_DATA<14>
CPU_DATA<15>

CPU_DATA<11>
CPU_DATA<12>
CPU_DATA<13>

CPU_DATA<9>
CPU_DATA<10>

CPU_DATA<7>
CPU_DATA<8>

CPU_DATA<6>

CPU_DATA<4>
CPU_DATA<5>

CPU_DATA<1>
CPU_DATA<2>
CPU_DATA<3>

CPU_DATA<0>

CPU_AACK_L

CPU_DBG_L

CPU_BG_L

CPU_QREQ_L

CPU_DRDY_0_L

40<>

40<>

6<

6<

13<

6<

13<

13<

12<

13<

40<>

13>

40<>

40<>

13<>

40<>

40<>

40<>

6<

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

13<

40<>

13<

13<

6<

13<

6<

40<>

40<>

40<>

40<>

40<>

40<>

6<

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

13>

6<>

6>

6>

13>

13>

6<>

14<>

13>

13>

40<>

13>

13>

40<>

13<>

13<>

13>

13<>

13<>

13>

13<>

13>

13>

13>

13<>

13>

13<>

13<>

13<>

13<>

13<>

13<>

13<>

13<>

13<>

13<>

13<>

13<>

13<>

13<>

13<>

13<>

13<>

13<>

13<>

13<>

13<>

13<>

13<>

13<>

13<>

13<>

13<>

13<>

13<>

13<>

13<>

13<>

40<>

34<>

34<>

13>

13<>

43<> 43<>

40<>

40<>

40<>

40<>

40<>

14<>

14<>

14<>

14<>

14<>

14<>

40<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

6>

6>

6>

13>

402

MF

1/16W

5%

22

R305

SD_EXT_R

BA_1

UNI-N-1.5

SDCKE_5

SDCKE_4

SDCKE_3

SDCKE_2

SDCKE_0
SDCKE_1

SDDQM_7

SDRAS
SDCAS

SDWE

SDDQM_6

SDDQM_0
SDDQM_1
SDDQM_2
SDDQM_3
SDDQM_4
SDDQM_5

SDCS_5

SDCS_0
SDCS_1
SDCS_2
SDCS_3
SDCS_4

BA_0

MEMORY

INTERFACE

RAMDATA_0
RAMDATA_1
RAMDATA_2
RAMDATA_3
RAMDATA_4
RAMDATA_5
RAMDATA_6
RAMDATA_7
RAMDATA_8
RAMDATA_9
RAMDATA_10
RAMDATA_11
RAMDATA_12
RAMDATA_13
RAMDATA_14
RAMDATA_15
RAMDATA_16
RAMDATA_17
RAMDATA_18
RAMDATA_19
RAMDATA_20
RAMDATA_21
RAMDATA_22
RAMDATA_23
RAMDATA_24
RAMDATA_25
RAMDATA_26
RAMDATA_27
RAMDATA_28
RAMDATA_29
RAMDATA_30
RAMDATA_31
RAMDATA_32
RAMDATA_33
RAMDATA_34
RAMDATA_35
RAMDATA_36
RAMDATA_37
RAMDATA_38
RAMDATA_39
RAMDATA_40
RAMDATA_41
RAMDATA_42
RAMDATA_43
RAMDATA_44
RAMDATA_45
RAMDATA_46
RAMDATA_47
RAMDATA_48
RAMDATA_49
RAMDATA_50
RAMDATA_51
RAMDATA_52
RAMDATA_53
RAMDATA_54
RAMDATA_55
RAMDATA_56
RAMDATA_57
RAMDATA_58
RAMDATA_59
RAMDATA_60
RAMDATA_61
RAMDATA_62
RAMDATA_63

RAD_1

RAD_0

RAD_2

RAD_10

RAD_9

RAD_8

RAD_7

RAD_6

RAD_5

RAD_4

RAD_3

RAD_12

RAD_11

ROMCS
ROMOE
ROMRW

SDRDCLK

(2 OF 5)

U9

PBGA-UNIN-1.5.1

402

R483

MF

1/16W

5%

0

+1_8V_MAIN

402

R476

MF

1/16W

5%

0

+3V_MAIN

SM

J16

STCK-SO

SM1

1/16W

RP33

22
5%

SM1

1/16W

RP32

22
5%

SM1

1/16W

RP34

10
5%

SM1

1/16W

RP30

22
5%

SM1

1/16W

RP29

22
5%

SM1

1/16W

RP35

22
5%

SM1

1/16W

RP28

22
5%

402

CERM

10V

20%

0.1uF

C800

402

CERM

10V

20%

0.1uF

C801

402

CERM

10V

20%

0.1uF

C802

402

CERM

10V

20%

0.1uF

C803

402

CERM

10V

20%

0.1uF

C804

402

CERM

10V

20%

0.1uF

C805

402

MF

1/16W

5%

10

R491

402

MF

1/16W

5%

10

R482

SM1

1/16W

RP31

10
5%

402

MF

1/16W

5%

22

R340

402

MF

1/16W

5%

22

R306

TABLE_5_ITEM

CRITICAL

?

516S0062

1

CONN,SODIMM,DUAL STACK,TOP IMPROVED

J16

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

7

46

E

051-6403

CRITICAL BOM OPTION

TABLE_5_HEAD

PART#

DESCRIPTION

QTY

REFERENCE DESIGNATOR(S)

CONNECTED TO EACH OF THE SEPARATE DIMMS.

THIS IS A STACKED DIMM CONNECTOR WITH A 2
MODULE CAPACITY. PINS THAT HAVE AN A/B ARE

PINS MARKED ’B’ GO TO THE BOTTOM MODULE.

PINS MARKED ’A’ GO TO THE TOP MODULE AND

UNI-N MEMORY

to avoid T bug in Uni-N

to avoid T bug in Uni-N

RC

RC

CS signals on higher outputs

CKE signals on higher outputs

DRIVER STRENGTH

SETS MEMORY

NC
NC

NC
NC

NC

NC
NC NC

NC

NC

NCNC

NC

(FPAR_AR0)
(FPAR_AR1)

(FPAR_AR2)
(FPAR_AR3) (FPAR_AR7)

(FPAR_AR6)

(FPAR_AR5)

(FPAR_AR4)

Memory Series Terminators

21

CRITICAL

R3

AC3

T7

AD3

T6

T3

T2

R2

R5

P1

P2

P3

G5

J7

J6

G6

K7

C2

D1

E3

D2

F5

C1

D3

AB5

F18

C20

B21

K3

J1

M7

AD2

AC2

AA5

AA6

J3

Y5

AA3

AB1

W7

AA1

Y2

W3

W2

V6

V1

H2

U5

U3

P5

N1

N2

N3

M5

N6

L3

K1

H3

M6

J2

H1

K5

J5

G2

G3

L6

AB3

AC1

F2

AB2

Y7

AA2

Y3

W5

Y6

W6

V5

V3

V2

H5

U6

U2

U1

T5

N5

M2

M3

L2

K2

L5

L7

E1

AF3

AD5

AC6

AG1

AF2

AE3

AC5

AF1

AG3

AH1

AG2

AE2

AA7

AE5

AD6

NO STUFF

2

1

2

1

OMIT

50

121

49

120

48

119

47

118

46

117

5

45

116

44

115

43

114

42

113

41

112

76

40

111

39

110

38

109

37

108

36

107

4

35

106

34

105

33

104

32

103

31

102

75

30

101

29

100

28

99

27

98

26

97

3

25

96

24

95

23

94

22

93

21

92

74A

20

91

19

90

18

89

17

88

16

87

2

15

86

14

85

13

84

12

83

11

82

73

10

81

9

80

142B141B

71B

8

74B

68B

62B

69B

61B

144

72

143

71A

142A

79

70

141A

69A

140

68A

139

67

138

66

137

7

65

136

64

135

63

134

62A

133

61A

132

78

60

131

59

130

58

129

57

128

56

127

6

55

126

54

125

53

124

52

123

51

122

77

1

154

153

5

6

7

8

4

3

2

1

5

6

7

8

4

3

2

1

5

6

7

8

4

3

2

1

5

6

7

8

4

3

2

1

5

6

7

8

4

3

2

1

5

6

7

8

4

3

2

1

5

6

7

8

4

3

2

1

2

1

2

1

2

1

2

1

2

1

2

1

21

21

5

6

7

8

4

3

2

1

21

21

CR-7

FMEMWE_L

FMA_AR<3>

FMA_AR<7>

FMA_AR<0>

MEMWE_L

RAD<3>

RAD<7>

RAD<0>

FSDCAS_L

RAD<2>

RAD<0>

CAS_DQM0_L

MEM_DATA<7>

RAD<11>

BA_0

RAD<12>

RAD<10>

FMA_AR<11>

FBA_0

FBA_1

RAD<6>

RAD<9>

RAD<5>

BA_1

RAD<8>

RAD<4>

RAD<1>

FMA_AR<12>

FMA_AR<6>

FMA_AR<9>

FMA_AR<5>

FMA_AR<2>

FMA_AR<8>

FMA_AR<4>

FMA_AR<1>

FMA_AR<10>

FRAS_CS3_L
FRAS_CS0_L

FRAS_CS1_L

FRAS_CS2_L

RAS_CS2_L

RAS_CS0_L

RAS_CS3_L

RAS_CS1_L

FRAM_CKE1_A

FRAM_CKE1_B

FRAM_CKE0_A
FRAM_CKE0_B

RAM_CKE0

RAM_CKE2

RAM_CKE3

RAM_CKE1

FCAS_DQM7_L

FCAS_DQM6_L

FCAS_DQM5_L

FCAS_DQM4_L

CAS_DQM7_L

CAS_DQM6_L

CAS_DQM5_L

CAS_DQM4_L

FCAS_DQM3_L

FCAS_DQM2_L

FCAS_DQM1_L

FCAS_DQM0_L

CAS_DQM3_L

CAS_DQM2_L

CAS_DQM1_L

MEM_EXT_R

UNI_ROM_CS_L

ROM_CS_L

UNI_ROM_RW_L

ROM_RW_L

UNI_ROM_OE_L

ROM_OE_L

RAD<11>

RAD<10>

RAD<9>

RAD<7>
RAD<8>

RAD<5>
RAD<6>

RAD<4>

RAD<2>
RAD<3>

RAD<1>

RAS_CS3_L

RAS_CS1_L
RAS_CS2_L

RAS_CS0_L

BA_1

BA_0

RAD<12>

CAS_DQM5_L

CAS_DQM7_L

CAS_DQM6_L

CAS_DQM3_L
CAS_DQM4_L

CAS_DQM0_L
CAS_DQM1_L
CAS_DQM2_L

SYSCLK_UNIN_RDCLK

MEMWE_L

SDCAS_L

SDRAS_L

MEM_DATA<0>
MEM_DATA<1>

MEM_DATA<6>

MEM_DATA<5>

MEM_DATA<4>

MEM_DATA<2>
MEM_DATA<3>

MEM_DATA<11>

MEM_DATA<10>

MEM_DATA<9>

MEM_DATA<7>
MEM_DATA<8>

MEM_DATA<16>

MEM_DATA<15>

MEM_DATA<14>

MEM_DATA<12>
MEM_DATA<13>

MEM_DATA<21>

MEM_DATA<20>

MEM_DATA<19>

MEM_DATA<17>
MEM_DATA<18>

MEM_DATA<26>

MEM_DATA<25>

MEM_DATA<24>

MEM_DATA<22>
MEM_DATA<23>

MEM_DATA<31>

MEM_DATA<30>

MEM_DATA<29>

MEM_DATA<27>
MEM_DATA<28>

MEM_DATA<36>

MEM_DATA<35>

MEM_DATA<34>

MEM_DATA<32>
MEM_DATA<33>

MEM_DATA<41>

MEM_DATA<40>

MEM_DATA<37>
MEM_DATA<38>
MEM_DATA<39>

MEM_DATA<46>

MEM_DATA<45>

MEM_DATA<44>

MEM_DATA<42>
MEM_DATA<43>

MEM_DATA<47>

MEM_DATA<52>

MEM_DATA<51>

MEM_DATA<50>

MEM_DATA<48>
MEM_DATA<49>

MEM_DATA<57>

MEM_DATA<56>

MEM_DATA<55>

MEM_DATA<53>
MEM_DATA<54>

MEM_DATA<62>

MEM_DATA<61>

MEM_DATA<60>

MEM_DATA<58>
MEM_DATA<59>

MEM_DATA<63>

UNIN_I2C_CLK1

MEM_DATA<13>

MEM_DATA<12>

MEM_DATA<1>

MEM_DATA<11>

MEM_DATA<10>

MEM_DATA<9>

MEM_DATA<8>

FMA_AR<2>

FMA_AR<1>

FMA_AR<0>

MEM_DATA<0>

FCAS_DQM1_L

FCAS_DQM0_L

MEM_DATA<6>

MEM_DATA<5>

MEM_DATA<4>

MEM_DATA<3>

MEM_DATA<2>

MEM_DATA<15>

MEM_DATA<14>

MEM_DATA<47>

MEM_DATA<46>

MEM_DATA<45>

MEM_DATA<44>

MEM_DATA<43>

MEM_DATA<42>

MEM_DATA<41>

MEM_DATA<40>

FMA_AR<5>

FMA_AR<4>

FMA_AR<3>

FCAS_DQM5_L

FCAS_DQM4_L

MEM_DATA<39>

MEM_DATA<38>

MEM_DATA<37>

MEM_DATA<36>

MEM_DATA<35>

MEM_DATA<34>

MEM_DATA<33>

MEM_DATA<32>

FRAM_CKE0_A

FSDCAS_LFSDRAS_L

FMEMWE_L

SYSCLK_DIMM0_A
SYSCLK_DIMM1_A

FRAM_CKE1_A
FRAM_CKE1_B

FRAS_CS0_L

FMA_AR<12>FRAS_CS2_L

FRAM_CKE0_B

MEM_DATA<48>
MEM_DATA<49>

MEM_DATA<51>

MEM_DATA<50>

MEM_DATA<52>
MEM_DATA<53>

MEM_DATA<55>

MEM_DATA<54>

FMA_AR<7>
FBA_0

FMA_AR<11>

FBA_1

FCAS_DQM6_L
FCAS_DQM7_L

MEM_DATA<56>
MEM_DATA<57>
MEM_DATA<58>
MEM_DATA<59>

MEM_DATA<60>
MEM_DATA<61>
MEM_DATA<62>
MEM_DATA<63>

MEM_DATA<17>

MEM_DATA<19>

MEM_DATA<18>

MEM_DATA<16>

MEM_DATA<21>

MEM_DATA<23>

MEM_DATA<22>

MEM_DATA<20>

FMA_AR<8>

FMA_AR<10>

FMA_AR<9>

FMA_AR<6>

FCAS_DQM2_L

MEM_DATA<24>

FCAS_DQM3_L

MEM_DATA<26>

MEM_DATA<28>

MEM_DATA<27>

MEM_DATA<25>

MEM_DATA<30>
MEM_DATA<31>

MEM_DATA<29>

FRAS_CS1_L
FRAS_CS3_L

SYSCLK_DIMM0_B
SYSCLK_DIMM1_B

UNIN_I2C_DATA0
UNIN_I2C_DATA1

UNIN_I2C_CLK0

RAM_CKE3

RAM_CKE2

RAM_CKE1

RAM_CKE0

SDCAS_L

FSDRAS_L

SDRAS_L

10<

10<

10<

10<

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

7<

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<> 40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

7<

7<

7<

7<

7<

7<

7<

7<

7<

7<

7<

7<

7<

7<

7<

7<

7<

7<

7<

7<

7<

7<

7<

7<

7<

7<

23<

7<

7<

7<

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

24<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

7<

7<

7<

40<>

7<

7<

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

7<

7<

7<

7<

7<

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

7<

7< 7<

7<

23<

23<

7<

7<

7<

7< 7<

7<

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

7<

7<

7<

7<

7<

7<

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

7<

7<

7<

7<

7<

40<>

7<

40<>

40<>

40<>

40<>

40<>

40<>

40<>

7<

7<

23<

23<

24<>

24<>

24<>

7<

7<

7<

7<

40<>

40<> 40<>

7<>

7<>

7<>

7<>

7>

7>

7>

7>

7<>

7>

40<>

7>

7<>

7>

7>

7>

7>

7<>

7<>

7<>

7>

7>

7>

7>

7>

7>

7>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7>

7>

7>

7>

7<>

7<>

7<>

7<>

7>

7>

7>

7>

7<>

7<>

7<>

7<>

7>

7>

7>

7>

7<>

7<>

7<>

7<>

7>

7>

7>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

10<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

40<>

40<>

40<>

7<>

40<>

40<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

40<>

40<>

40<>

40<>

40<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

40<>

40<> 40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<> 40<>

40<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

40<>

40<>

40<>

40<>

40<>

40<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

40<>

40<>

40<>

40<>

40<>

7<>

40<>

7<>

7<>

7<>

7<>

7<>

7<>

7<>

40<>

40<> 40<>

40<>

10<>

10<>

10<>

40<>

40<>

40<>

40<>

7>

7<>

7>

(3 OF 5)

UNI-N-1.5

AGP

INTERFACE

AGP_CLKIN_VDD3

AGPPLLAVD

AGPAD_STB1*

AGPAD_STB1

AGPAD_STB0*

AGPAD_STB0

AGPPLLAVS AGPPLLDVS

AGP_VREF

AGBU4RTAP

AGPSB_STB
AGPSB_STB*

AGPPLLDVD

AGPREQ

AGPGNT

AGPFRAME

AGPPAR

AGPCLK

AGPTRDY

AGPCBE_3

AGPCBE_2

AGPCBE_1

AGPCBE_0

AGPDEVSEL

AGPSTOP

AGPIRDY

AGPST_0

AGPTYPEDET

AGPPME

AGPWBF

AGPPIPE

AGPST_2

AGPST_1

AGPRBF

AGPAD_0
AGPAD_1

AGPAD_7

AGPAD_6

AGPAD_5

AGPAD_2

AGPAD_9
AGPAD_10
AGPAD_11

AGPAD_8

AGPAD_3

AGPAD_4

AGPAD_14
AGPAD_15

AGPAD_21

AGPAD_12

AGPAD_16
AGPAD_17

AGPAD_13

AGPAD_18
AGPAD_19
AGPAD_20

AGPAD_22

AGPAD_31

AGPAD_30

AGPAD_23
AGPAD_24
AGPAD_25
AGPAD_26
AGPAD_27
AGPAD_28
AGPAD_29

AGBSBA_2

AGPSBA_0
AGBSBA_1

AGBSBA_7

AGBSBA_6

AGBSBA_5

AGBSBA_4

AGBSBA_3

U9

PBGA-UNIN-1.5.1

805

CERM

10V

N20P80%

4.7uF

C608

+1_8V_MAIN

+3V_MAIN

805

CERM

10V

N20P80%

4.7uF

C657

402

CERM

10V

20%

0.1uF

C654

402

MF

1/16W

5%

10K

R283

402

MF

1/16W

5%

10K

R274

402

MF

1/16W

5%

10K

R273

402

MF

1/16W

5%

10K

R275

402

MF

1/16W

5%

10K

R276

402

MF

1/16W

5%

10K

R342

402

MF

1/16W

5%

10K

R466

402

MF

1/16W

5%

10K

R484

402

R442

MF

1/16W

1%

475

402

MF

1/16W

5%

10K

R419

402

MF

1/16W

5%

10K

R234

402

MF

1/16W

5%

10K

R443

402

MF

1/16W

5%

10K

R367

402

MF

1/16W

5%

10K

R441

402

MF

1/16W

5%

10K

R420

402

MF

1/16W

5%

10K

R372

402

MF

1/16W

5%

10K

R371

+1_5V_MAIN

402

MF

1/16W

5%

0

R487

402

MF

1/16W

5%

1K

R457

402

R446

MF

1/16W

1%

82.5

402

R456

MF

1/16W

1%

82.5

C595

470pF

402

CERM

50V

10%

402

R431

MF

1/16W

1%

4.99K

402

R458

MF

1/16W

1%

4.99K

C645

470pF

402

CERM

50V

10%

402

MF

1/16W

5%

22

R462

402

MF

1/16W

5%

22

R383

402

CERM

10V

20%

0.1uF

C705

+1_5V_MAIN

+1_5V_MAIN

+1_5V_MAIN

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

8

46

E

051-6403

ATI AGP I/O REFERENCE

(PLACE CLOSE TO UNI-N AGP BALLS)

AGP PULL-UPS

UNI-N AGP

CRITICAL

B3

B8

C8

E10

G9

F9

B4

F8

C5

A4

B5

C6

B6

C7

E6

B2

A3

C14

E13

C4

A7

G8

C3

E7

E5

B14

A14

E9

B15

B7

F6

C9

A8

E15

G14

C17

A18

B18

E17

C18

A19

G13

B9

E16

A9

C10

E11

B10

C11

B11

C12

B12

A12

C13

B19

B13

A13

F13

E14

C15

B16

G15

C16

A17

B17

C19

E18

F11

F7

G10

E12

F12

F15

F16

2

1

2

1

2

1

21

21

21

21

21

21

21

21

2

1

21

21

21

21

21

21

21

21

21

21

2

1

2

1

21

2

1

2

1

21

21 21

2

1

CR-8

AGP_DEVSEL_L

AGP_TRDY_L

AGP_RBF_L

AGP_PIPE_L_PU

AGP_FRAME_L

AGP_IRDY_L

AGP_STOP_L

AGP_WBF_L

AGP_AD_STB<1>

AGP_AD_STB_L<0>

AGP_SB_STB_L

AGP_GNT_L

UNI_AGP_TYPEDET_PD

AGP_AD_STB<0>

AGP_SB_STB

AGP_AD_STB_L<1>

AGP_REQ_L

UNI_AGP_PME_L_PD

ATI_AGP_VREF_H

ATI_AGP_VREF

ATI_AGP_VREF_L

UNI_AGP_TYPEDET_PD

UNI_AGP_PME_L_PD

AGP_WBF_L

AGP_RBF_L

AGP_PIPE_L_PU

AGP_ST<2>

AGP_ST<1>

AGP_ST<0>

AGP_CBE<3>

AGP_CBE<2>

AGP_CBE<1>

AGP_CBE<0>

AGP_DEVSEL_L

AGP_STOP_L

AGP_IRDY_L

AGP_TRDY_L

AGP_FRAME_L

AGP_PAR

CLK66M_UNIN_AGP

AGP_GNT_L

AGP_REQ_L

+3V_UNIN_AGPPLL_MAIN

AGP_U4RTAP

UNIN_AGP_VREF

AGP_AD_STB_L<1>

AGP_AD_STB<1>

AGP_AD_STB_L<0>

AGP_AD_STB<0>

AGP_SB_STB
AGP_SB_STB_L

AGP_SBA<6>
AGP_SBA<7>

AGP_SBA<5>

AGP_SBA<3>
AGP_SBA<4>

AGP_SBA<1>
AGP_SBA<2>

AGP_SBA<0>

AGP_AD<31>

AGP_AD<28>
AGP_AD<29>
AGP_AD<30>

AGP_AD<27>

AGP_AD<26>

AGP_AD<23>
AGP_AD<24>
AGP_AD<25>

AGP_AD<21>
AGP_AD<22>

AGP_AD<18>
AGP_AD<19>
AGP_AD<20>

AGP_AD<17>

AGP_AD<16>

AGP_AD<15>

AGP_AD<14>

AGP_AD<13>

AGP_AD<11>
AGP_AD<12>

AGP_AD<10>

AGP_AD<8>
AGP_AD<9>

AGP_AD<6>
AGP_AD<7>

AGP_AD<5>

AGP_AD<3>
AGP_AD<4>

+1_8V_UNIN_AGPPLL_MAIN

AGP_AD<1>

AGP_AD<0>

AGP_AD<2>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

8<

8<

8<

8<

8<

19<

8<

8<

8<

8<

8<

8<

19<>

19<>

40<>

19<>

19<>

19<>

19<>

19<>

19<>

40<>

19<>

19<>

19<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

8<

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

8<>

8<>

19>

8<>

8<>

8<>

8<>

8<>

8<>

8>

8<>

8<>

8<>

19<>

19>

19<

19<

19<

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19>

40<>

40<>

19<>

43<>

19<>

19<>

19<>

19<>

19<>

19<>

19>

19<>

19>

19>

19>

19>

19>

19>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

43<>

19<>

19<>

19<>

+3V_SLEEP

+3V_MAIN

SM1

1/16W

5%

10K

RP16

SM1

1/16W

5%

10K

RP16

SM1

1/16W

5%

10K

RP17

SM1

1/16W

5%

10K

RP16

SM1

1/16W

5%

10K

RP17

3_3V_PCIGNT_5

3_3V_PCIREQ_5

PCIREQ64

PCIPAR64

PCIACK64

5VBIAS2

5VBIAS1

PCIGNT_3
PCIGNT_4

PCIGNT_2

PCIGNT_0
PCIGNT_1

PCIREQ_0

PCIREQ_2
PCIREQ_3

PCIREQ_1

PCIREQ_4

PCI1CLK
PCI2CLK

PCIIRDY

PCIDEVSEL

PCISTOP

PCIPAR
PCIFRAME
PCITRDY

SPARE2

PCICBE_6

PCICBE_5

PCICBE_4

PCICBE_7

PCICBE_3

PCICBE_2

PCICBE_1

PCICBE_0

PCI

INTERFACE

PCIAD_63

PCIAD_62

PCIAD_53

PCIAD_52

PCIAD_54
PCIAD_55
PCIAD_56

PCIAD_58

PCIAD_57

PCIAD_59
PCIAD_60
PCIAD_61

PCIAD_44

PCIAD_42
PCIAD_43

PCIAD_46
PCIAD_47
PCIAD_48

PCIAD_45

PCIAD_49

PCIAD_51

PCIAD_50

PCIAD_34

PCIAD_32
PCIAD_33

PCIAD_39

PCIAD_37
PCIAD_38

PCIAD_36

PCIAD_35

PCIAD_41

PCIAD_40

PCIAD_22
PCIAD_23
PCIAD_24

PCIAD_27

PCIAD_26

PCIAD_25

PCIAD_29

PCIAD_28

PCIAD_30
PCIAD_31

PCIAD_14

PCIAD_13

PCIAD_12

PCIAD_16
PCIAD_17
PCIAD_18
PCIAD_19

PCIAD_15

PCIAD_20
PCIAD_21

PCIAD_11

PCIAD_3

PCIAD_2

PCIAD_4

PCIAD_9

PCIAD_8

PCIAD_7

PCIAD_5
PCIAD_6

PCIAD_10

PCIAD_1

PCIAD_0

UNI-N-1.5

(4 OF 5)

U9

PBGA-UNIN-1.5.1

+3V_MAIN

402

MF

1/16W

5%

1K

R341

402

MF

1/16W

5%

10K

R455

402

MF

1/16W

5%

10K

R314

SM

RP22

25V

1/32W

5%

10K

SM

RP15

25V

1/32W

5%

10K

SM

RP20

25V

1/32W

5%

10K

SM

RP21

25V

1/32W

5%

10K

SM

RP23

25V

1/32W

5%

10K

402

MF

1/16W

5%

10K

R272

402

R148

MF

1/16W

5%

0

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

9

46

E

051-6403

64-BIT PCI SUPPORT

PCI PULL-UPS

UNI-N PCI

NC

63

81

81

72

72

CRITICAL

H6

B27

E24

A28

F28

J24

G27

H26

E25

E30

J25

F29

K24

G28

J26

G29

H28

K25

H29

F24

J28

K26

K27

H30

J29

K28

L25

J30

L26

L27

C27

K29

K30

M25

L28

M26

L29

M27

N24

G20

B23

B28

A24

E21

C23

B24

F21

E22

G21

D23

C24

F22

A29

B25

D24

G22

C25

E23

B26

A27

D25

F23

C26

B29

E26

AA29

D28

C28

K6

E19

B22

F20

A23

F19

G25

E27

C22

C29

F3

E20

D20

A22

G19

C21

F25

F26

G18

F27

D30

H25

H24

E29

D29

G26

E28

C30

D19

N26

21

21

21

9

8

7

6

4

3

2

1

10

5

9

8

7

6

4

3

2

1

10

5

9

8

7

6

4

3

2

1

10

5

9

8

7

6

4

3

2

1

10

5

9

8

7

6

4

3

2

1

10

5

21

2

1

CR-9

PCI_AD<35>

PCI_AD<43>

PCI_AD<41>

PCI_AD<37>

PCI_AD<40>

PCI_AD<36>

PCI_AD<33>

PCI_AD<32>

PCI_AD<49>
PCI_AD<45>
PCI_AD<42>
PCI_AD<46>
PCI_AD<38>
PCI_AD<34>
PCI_AD<39>
PCI_AD<44>

PCI_CBE<6>
PCI_AD<59>
PCI_AD<57>

PCI_AD<63>
PCI_AD<50>
PCI_AD<53>
PCI_ACK64_L

PCI_REQ64_L

PCI_CBE<7>
PCI_PAR64
PCI_AD<61>
PCI_AD<52>
PCI_AD<60>
PCI_CBE<4>

+3V_PCI_64B_PU

PCI_AD<62>

PCI_AD<58>

PCI_AD<54>

PCI_AD<56>

PCI_AD<51>

PCI_AD<48>

PCI_AD<47>

PCI_CBE<5>

PCI_AD<55>

NEC_PCI_REQ_L

NEC_PCI_REQ_L

PCI_FRAME_L

PCI_DEVSEL_L

PCI_TRDY_L

UNI_PCI_REQ_L_PU

PCI_IRDY_L

PCI_STOP_L

KL_PCI_REQ_L

CBUS_PCI_REQ_L

MAIN_RESET_L

PCI_AD<63>

PCI_AD<62>

PCI_AD<60>
PCI_AD<61>

PCI_AD<58>
PCI_AD<59>

PCI_AD<57>

PCI_AD<56>

PCI_AD<55>

PCI_AD<54>

PCI_AD<53>

PCI_AD<52>

PCI_AD<51>

PCI_AD<50>

PCI_AD<49>

PCI_AD<47>
PCI_AD<48>

PCI_AD<46>

PCI_AD<45>

PCI_AD<44>

PCI_AD<42>
PCI_AD<43>

PCI_AD<41>

PCI_AD<40>

PCI_AD<39>

PCI_AD<38>

PCI_AD<37>

PCI_AD<36>

PCI_AD<35>

PCI_AD<34>

PCI_AD<32>
PCI_AD<33>

PCI_AD<30>
PCI_AD<31>

PCI_AD<29>

PCI_AD<28>

PCI_AD<27>

PCI_AD<26>

PCI_AD<25>

PCI_AD<24>

PCI_AD<23>

PCI_AD<22>

PCI_AD<20>
PCI_AD<21>

PCI_AD<19>

PCI_AD<17>
PCI_AD<18>

PCI_AD<16>

PCI_AD<15>

PCI_AD<14>

PCI_AD<13>

PCI_AD<12>

PCI_AD<11>

PCI_AD<9>
PCI_AD<10>

PCI_AD<8>

PCI_AD<7>

PCI_AD<6>

PCI_AD<5>

PCI_AD<4>

PCI_AD<2>
PCI_AD<3>

PCI_AD<1>

PCI_AD<0>

KL_PCI_REQ_L

CBUS_PCI_REQ_L

CLK66M_UNIN_PCI_INT

CLK33M_UNIN_PCI_EXT

PCI_DEVSEL_L

PCI_STOP_L

PCI_IRDY_L

PCI_TRDY_L

PCI_FRAME_L

PCI_PAR

PCI_CBE<2>

PCI_CBE<1>

PCI_CBE<0>

CBUS_PCI_GNT_L
NEC_PCI_GNT_L
UNI_PCI_GNT2_L_SPN
UNI_PCI_GNT3_L_SPN
UNI_PCI_GNT4_L_SPN
KL_PCI_GNT_L

PCI_CBE<7>

PCI_CBE<6>

PCI_CBE<4>
PCI_CBE<5>

PCI_CBE<3>

PCI_PAR64

PCI_REQ64_L
PCI_ACK64_L

UNI_PCI_REQ_L_PU

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

9<

9<

9<

9<

9<

18<>

18<>

18<>

18<>

18<>

23<>

23<>

23<>

23<>

23<>

23<>

23<>

23<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

17<>

17<>

17<>

17<>

17<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

16<>

16<>

16<>

16<>

16<>

17<

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

16<

17<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9>

9<>

9<>

9<>

9<>

9<>

9>

40<>

9<>

9<>

9<>

9>

43<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9>

9<>

17>

17>

9<>

9<>

9<>

9<>

9<>

16>

18>

34<>

9<

9<

9<

9<

9<

9<

9<

9<

9<

9<

9<

9<

9<

9<

9<

9<

9<

9<

9<

9<

9<

9<

9<

9<

9<

9<

9<

9<

9<

9<

9<

9<

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16>

18>

40<>

40<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

18<

17<

41<>

9<

9<

9<

9<

16<>

40<>

+1_8V_MAIN

402

MF

1/16W

5%

33

R184

402

MF

1/16W

5%

1K

R241

402

MF

1/16W

5%

10K

R194

402

MF

1/16W

5%

10K

R233

402

MF

1/16W

5%

10K

R206

ISDA0
ISCL1
ISDA1

ISCL0

TRSTN

TMS

TEI

TCK

TDO

TDI

MDC

MDIO

GBE_REFCLK

CRS

GTX_CLK

COL

RXD_5
RXD_6
RXD_7

RXD_3
RXD_4

RXD_2

RXD_1

RX_DV

TXD_7

TXD_6

RX_ER

TXD_5

TXD_4

RX_CLK

RXD_0

TEST

V2I X 2

TXD_0

TX_EN
TX_ER

TX_CLK

TXD_1
TXD_2
TXD_3

VDD_MAX X 23

GB ETHERNET

VDDC X 18

UNI-N-1.5

(5 OF 5)

VSS X 82

FIREWIRE

GPIO_1

GPIO_0

SPARE3

PHY_LREQ

PHY_LPS

PHY_DATA_0
PHY_DATA_1
PHY_DATA_2
PHY_DATA_3
PHY_DATA_4
PHY_DATA_5
PHY_DATA_6
PHY_DATA_7

PHY_SCLK

PHY_CTL_0
PHY_CTL_1

RESET

PURESET

MISC

VDD_RAM X 18

V3P X 5

VDD_MISC X 16

INTCLK

INTDATA
INTSYNC

V3I X 3

VDD_AGP X 11

V3AGP X 4

PBGA-UNIN-1.5.1

U9

+3V_MAIN

+3V_MAIN

402

MF

1/16W

5%

33

R195

402

MF

1/16W

5%

33

R242

402

MF

1/16W

5%

1K

R207

402

MF

1/16W

5%

10K

R307

+3V_MAIN

+1_5V_MAIN

SM1

1/16W

RP14

10K

5%

SM1

1/16W

RP19

33

5%

SM1

1/16W

RP13

33

5%

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

10 46

E

051-6403

UNI-N ETHERNET TERMINATION

UNI-N I2C PULL-UPS

UNI-N MISC I/O

TEST PULL-UPS

12

12

12

12

12

CRITICAL

AC27

Y24

Y1

W27

AB30

V18
V16
V14

V7

V4
U30
U24
U18
U16

U14

AA4

T18
T16
T14

T1
R18
R16
R14

R4
P27
P18

A26

P16
P14

P7
N18
N16
N14
M30
M24

M4

M1

A21

J27

J4

G30

G24

G17

G12

G7G1F4

D27

A16

D22

D18

D15

D12

D9

D6

B30

AK29

AK24

AK19

A11

AK15

AK11

AK6

AK1

AG25

AG22

AG19

AG16

AG13

AG10

A6

AG7

AG4

AF30

AF27

AE1

AD24

AD17

AD13

AD7

AD4

A1

H7G4F1

B1

AJ1

AE4

AD1

AC7

W4W1U7T4R1N7N4L1K4

AB4

G23

F30

D26

D21

AA30

AA27

A30

A25

V27

T30

T24

N27

L30

L24

H27

A20

AG9

AG6

AE30

AD27

AD23

AD18

AD14

AK30

AK25

AK20

AK16

AD8

AK12

AK7

AK2

AG30

AG27

AG24

AG21

AG18

AG15

AG12

AA24

D16

D13

D10

D7

D4

A15

A10

A5

G16

G11

A2

R17

R15

R13

P17

P15

P13

N17

N15

V17

V15

V13

U17

U15

U13

T17

T15

T13

N13

AE23

AD12

AB6

P6

R24

AB7

R6

R25

E8

F10

F14

F17

AD20

AE24

R30

T28

V24

U27

V30

V29

R26

T26

U29

T29

T27

AB26

AD29

B20

AD28

AC26

AC28

E2

W30

Y27

V25

W25

W24

W28

Y30

W26

Y29

V26

U26

AA26

Y25

N25

R29

R28

P29

P28

P25

N30

N29

P24

N28

P26

R27

P30

V28
U28

AB28

AB27
AC29

AD30

AC30

AA25

AA28

T25

M28

M29

U25

Y28
W29

12

12

12

12

5

6

7

8

4

3

2

1

5

6

7

8

4

3

2

1

5

6

7

8

4

3

2

1

CR-10

ENET_PHY_GTX_CLK

ENET_GTX_CLK

UNIN_I2C_DATA1

UNIN_I2C_CLK1

UNIN_I2C_DATA0

UNIN_JTAG_TEI

UNIN_I2C_CLK0

JTAG_ASIC_TMS
JTAG_ASIC_TRST_L

JTAG_ASIC_TCK

JTAG_KL_TDI

ENET_MDIO
ENET_MDC

ENET_CRS
ENET_COL

ENET_RXD<7>

ENET_GBE_REFCLK

ENET_RXD<6>

ENET_RXD<5>

ENET_RXD<2>

ENET_RXD<4>

ENET_RXD<3>

ENET_RXD<1>

ENET_RXD<0>

ENET_RX_ER

ENET_RX_DV

CLK_ENET_LINK_RX

CLK_ENET_LINK_TX

FW_TEST

PMU_PME_L

FW_C_LKON

CLK_UNIN_FW

FW_LINK_LREQ

FW_PHY_LPS

FW_LINK_CNTL<1>

FW_LINK_CNTL<0>

FW_LINK_DATA<6>
FW_LINK_DATA<7>

FW_LINK_DATA<5>

FW_LINK_DATA<4>

FW_LINK_DATA<1>

FW_LINK_DATA<3>

FW_LINK_DATA<2>

FW_LINK_DATA<0>

UNIN_PU_RESET_L

UNIN_RESET_L

MPIC_CLK

MPIC_SYNC_L

MPIC_DATA_L

FW_TEST

JTAG_ASIC_TRST_L

UNIN_JTAG_TEI

JTAG_ASIC_TCK

JTAG_ASIC_TMS

JTAG_ASIC_TDI

JTAG_ASIC_TDI

UNIN_I2C_CLK0
UNIN_I2C_DATA0
UNIN_I2C_CLK1
UNIN_I2C_DATA1

ENET_PHY_TXD<0>
ENET_PHY_TXD<1>
ENET_PHY_TXD<2>
ENET_PHY_TXD<3>

ENET_TX_D<3>

ENET_TX_D<2>

ENET_TX_D<1>

ENET_TX_D<0>

ENET_PHY_TXD<4>
ENET_PHY_TXD<5>
ENET_PHY_TXD<6>
ENET_PHY_TXD<7>

ENET_TX_D<4>
ENET_TX_D<5>
ENET_TX_D<6>
ENET_TX_D<7>

ENET_TX_ER

ENET_PHY_TX_ER

ENET_TX_EN

ENET_PHY_TX_EN

34<

10<

10<

10<

10<

17<

24<>

24<>

24<>

24<>

24<>

24<>

24<>

24<>

42<>

28<

42<>

42<>

28<

42<>

42<>

34<>

29<>

29<

29<

29<

29<

29<

29<

29<

29<

29<

29<

29<

41<>

16<

10<>

10<>

10<>

10<>

40<>

40<>

7<>

7<>

7<>

7<>

16<

28<>

42<>

28>

28>

42<>

40<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

28>

28>

40<>

40<>

10<

16>

16<>

40<>

42<>

29<

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

34<>

34<>

16>

16>

41<>

10<>

7<>

7<>

7<>

7<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

402

CERM

10V

20%

0.1uF

C619

402

CERM

10V

20%

0.1uF

C700

402

CERM

10V

20%

0.1uF

C681

402

CERM

10V

20%

0.1uF

C652

402

CERM

10V

20%

0.1uF

C677

402

CERM

10V

20%

0.1uF

C666

402

CERM

10V

20%

0.1uF

C701

402

CERM

10V

20%

0.1uF

C624

402

CERM

10V

20%

0.1uF

C648

402

CERM

10V

20%

0.1uF

C627

402

CERM

10V

20%

0.1uF

C717

402

CERM

10V

20%

0.1uF

C715

402

CERM

10V

20%

0.1uF

C714

402

CERM

10V

20%

0.1uF

C639

402

CERM

10V

20%

0.1uF

C682

402

CERM

10V

20%

0.1uF

C683

402

CERM

10V

20%

0.1uF

C663

402

CERM

10V

20%

0.1uF

C664

402

CERM

10V

20%

0.1uF

C703

402

CERM

10V

20%

0.1uF

C625

402

CERM

10V

20%

0.1uF

C620

402

CERM

10V

20%

0.1uF

C678

402

CERM

10V

20%

0.1uF

C704

402

CERM

10V

20%

0.1uF

C649

402

CERM

10V

20%

0.1uF

C722

402

CERM

10V

20%

0.1uF

C702

402

CERM

10V

20%

0.1uF

C650

402

CERM

10V

20%

0.1uF

C651

402

CERM

10V

20%

0.1uF

C641

402

CERM

10V

20%

0.1uF

C665

402

CERM

10V

20%

0.1uF

C679

402

CERM

10V

20%

0.1uF

C716

402

CERM

10V

20%

0.1uF

C640

402

CERM

10V

20%

0.1uF

C626

402

CERM

10V

20%

0.1uF

C653

402

CERM

10V

20%

0.1uF

C680

402

CERM

10V

20%

0.1uF

C576

402

CERM

10V

20%

0.1uF

C578

402

CERM

10V

20%

0.1uF

C577

402

CERM

10V

20%

0.1uF

C610

402

CERM

10V

20%

0.1uF

C628

402

CERM

10V

20%

0.1uF

C642

402

CERM

10V

20%

0.1uF

C713

402

CERM

10V

20%

0.1uF

C712

402

CERM

10V

20%

0.1uF

C265

402

CERM

10V

20%

0.1uF

C718

402

CERM

10V

20%

0.1uF

C299

402

CERM

10V

20%

0.1uF

C266

402

CERM

10V

20%

0.1uF

C333

402

CERM

10V

20%

0.1uF

C317

402

CERM

10V

20%

0.1uF

C348

402

CERM

10V

20%

0.1uF

C332

402

CERM

10V

20%

0.1uF

C380

402

CERM

10V

20%

0.1uF

C349

402

CERM

10V

20%

0.1uF

C296

402

CERM

10V

20%

0.1uF

C396

402

CERM

10V

20%

0.1uF

C297

402

CERM

10V

20%

0.1uF

C291

402

CERM

10V

20%

0.1uF

C457

402

CERM

10V

20%

0.1uF

C298

402

CERM

10V

20%

0.1uF

C456

402

CERM

10V

20%

0.1uF

C290

402

CERM

10V

20%

0.1uF

C246

402

CERM

10V

20%

0.1uF

C255

402

CERM

10V

20%

0.1uF

C548

402

CERM

10V

20%

0.1uF

C350

402

CERM

10V

20%

0.1uF

C334

402

CERM

10V

20%

0.1uF

C609

402

CERM

10V

20%

0.1uF

C245

402

CERM

10V

20%

0.1uF

C318

402

CERM

10V

20%

0.1uF

C549

402

CERM

10V

20%

0.1uF

C247

402

CERM

10V

20%

0.1uF

C229

805

CERM

16V

N20P80%

2.2uF

C661

805

CERM

16V

N20P80%

2.2uF

C287

805

CERM

16V

N20P80%

2.2uF

C497

805

CERM

16V

N20P80%

2.2uF

C409

402

CERM

10V

20%

0.1uF

C328

402

CERM

10V

20%

0.1uF

C623

402

CERM

10V

20%

0.1uF

C359

402

CERM

10V

20%

0.1uF

C244

402

CERM

10V

20%

0.1uF

C605

402

CERM

10V

20%

0.1uF

C329

402

CERM

10V

20%

0.1uF

C541

402

CERM

10V

20%

0.1uF

C557

402

CERM

10V

20%

0.1uF

C378

402

CERM

10V

20%

0.1uF

C264

402

CERM

10V

20%

0.1uF

C254

402

CERM

10V

20%

0.1uF

C636

402

CERM

10V

20%

0.1uF

C606

402

CERM

10V

20%

0.1uF

C330

402

CERM

10V

20%

0.1uF

C243

402

CERM

10V

20%

0.1uF

C448

402

CERM

10V

20%

0.1uF

C331

402

CERM

10V

20%

0.1uF

C540

402

CERM

10V

20%

0.1uF

C494

402

CERM

10V

20%

0.1uF

C711

402

CERM

10V

20%

0.1uF

C379

402

CERM

10V

20%

0.1uF

C288

402

CERM

10V

20%

0.1uF

C408

402

CERM

10V

20%

0.1uF

C447

402

CERM

10V

20%

0.1uF

C634

402

CERM

10V

20%

0.1uF

C425

402

CERM

10V

20%

0.1uF

C407

402

CERM

10V

20%

0.1uF

C495

402

CERM

10V

20%

0.1uF

C316

402

CERM

10V

20%

0.1uF

C575

402

CERM

10V

20%

0.1uF

C289

402

CERM

10V

20%

0.1uF

C406

402

CERM

10V

20%

0.1uF

C635

402

CERM

10V

20%

0.1uF

C496

402

CERM

10V

20%

0.1uF

C360

805

CERM

16V

N20P80%

2.2uF

C395

805

CERM

16V

N20P80%

2.2uF

C581

+3V_MAIN

805

CERM

16V

N20P80%

2.2uF

C410

805

CERM

16V

N20P80%

2.2uF

C579

402

CERM

10V

20%

0.1uF

C454

402

CERM

10V

20%

0.1uF

C543

402

CERM

10V

20%

0.1uF

C545

402

CERM

10V

20%

0.1uF

C547

402

CERM

10V

20%

0.1uF

C542

402

CERM

10V

20%

0.1uF

C453

402

CERM

10V

20%

0.1uF

C501

402

CERM

10V

20%

0.1uF

C546

402

CERM

10V

20%

0.1uF

C452

402

CERM

10V

20%

0.1uF

C504

402

CERM

10V

20%

0.1uF

C500

402

CERM

10V

20%

0.1uF

C499

402

CERM

10V

20%

0.1uF

C451

402

CERM

10V

20%

0.1uF

C503

402

CERM

10V

20%

0.1uF

C544

402

CERM

10V

20%

0.1uF

C502

402

CERM

10V

20%

0.1uF

C450

402

CERM

10V

20%

0.1uF

C449

805

CERM

16V

N20P80%

2.2uF

C498

+1_8V_MAIN

805

CERM

16V

N20P80%

2.2uF

C580

805

CERM

16V

N20P80%

2.2uF

C411

805

CERM

16V

N20P80%

2.2uF

C455

402

CERM

10V

20%

0.1uF

C507

402

CERM

10V

20%

0.1uF

C561

402

CERM

10V

20%

0.1uF

C644

402

CERM

10V

20%

0.1uF

C506

402

CERM

10V

20%

0.1uF

C643

402

CERM

10V

20%

0.1uF

C559

402

CERM

10V

20%

0.1uF

C594

402

CERM

10V

20%

0.1uF

C509

402

CERM

10V

20%

0.1uF

C611

402

CERM

10V

20%

0.1uF

C684

402

CERM

10V

20%

0.1uF

C685

402

CERM

10V

20%

0.1uF

C656

402

CERM

10V

20%

0.1uF

C706

+1_5V_MAIN

805

CERM

16V

N20P80%

2.2uF

C558

805

CERM

16V

N20P80%

2.2uF

C550

805

CERM

16V

N20P80%

2.2uF

C505

805

CERM

16V

N20P80%

2.2uF

C667

402

CERM

10V

20%

0.1uF

C510

402

CERM

10V

20%

0.1uF

C655

402

CERM

10V

20%

0.1uF

C560

402

CERM

10V

20%

0.1uF

C612

402

CERM

10V

20%

0.1uF

C582

402

CERM

10V

20%

0.1uF

C508

402

CERM

10V

20%

0.1uF

C613

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

11 46

E

051-6403

UNI-N BYPASSING

(18 0.1UF CAPS)

UNI-N CORE DECOUPLING

MAXBUS INTERFACE DECOUPLING

AGP I/O DECOUPLING

(35 0.1UF CAPS)

(20 0.1UF CAPS)

(35 0.1UF CAPS)

SDRAM DECOUPLING

(9 0.1UF CAPS)

PCI DECOUPLING

1394/ETHERNET DECOUPLING

(29 0.1UF CAPS)

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

CR-11

402

R351

MF

1/16W

5%

0

402

R328

MF

1/16W

5%

0

402

R282

MF

1/16W

5%

10K

402

R365

MF

1/16W

5%

10K

402

R303

MF

1/16W

5%

10K

402

R325

MF

1/16W

5%

10K

+1_8V_SLEEP

402

R552

MF

1/16W

5%

47K

402

R517

MF

1/16W

5%

10K

402

R569

MF

1/16W

5%

47K

402

R399

MF

1/16W

5%

0

402

R398

MF

1/16W

5%

0

402

R397

MF

1/16W

5%

0

402

R396

MF

1/16W

5%

10K

G

D

S

SOT-363

2N7002DW

Q45

G

D

S

SOT-363

2N7002DW

Q45

04

SN74AUC1G04

SC70-5

U39

+1_8V_SLEEP

402

R254

MF

1/16W

5%

1K

402

MF

1/16W

5%

22

R220

402

MF

1/16W

5%

22

R232

402

MF

1/16W

5%

22

R240

402

R239

MF

1/16W

5%

10

402

R302

MF

1/16W

5%

10

402

R339

MF

1/16W

5%

10K

402

R304

MF

1/16W

5%

10K

402

R338

MF

1/16W

5%

10K

402

R296

MF

1/16W

5%

1K

+1_8V_SLEEP

+1_8V_SLEEP

S

D

G

Q42

2N7002

SM

SM

2N3904

Q41

402

MF

1/16W

5%

360K

R568

402

R268

MF

1/16W

5%

0

+3V_SLEEP

402

R269

MF

1/16W

5%

0

402

R270

MF

1/16W

5%

0

402

R350

MF

1/16W

5%

0

402

R352

MF

1/16W

5%

0

402

R293

MF

1/16W

5%

0

402

R294

MF

1/16W

5%

0

402

R326

MF

1/16W

5%

0

402

R295

MF

1/16W

5%

0

402

R327

MF

1/16W

5%

0

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

12 46

E

051-6403

Inverter Gate placement for

1.5V L3 bus interface setting

UNIN CPU BUS CONFIGURATION

UNIN_MAXBUS_REF

CPU_DATA<63>

(UNIN)

(UNIN)

SIGNAL

LOW

HIGH

LOW

HIGH

TIED

MAX BUS MODE

60X BUS MODE

2.5V INTERFACE

1.8V INTERFACE

APPLICATION

R01A R00A R10A R01B

CPU PLL CONFIG CIRCUITRY

HIGH SPEED 0 1
PLL DISABLE 1 X

R00B R10B R01C R00C R10C R01D R10DR00D

LOW SPEED 0 0

STATE ENCODING CPU_PLL_STOP_OC CPU_VCORE_HI_OC

R01E R00E R10E

CPU CONFIGURATION

CPU CONFIGURATION

CPU FREQUENCY CONFIGURATION

CORE FREQUENCY

(AT BUS FREQUENCY)

CPU_PLL_CFG

0 0000 00
0 0011 03
0 0100 04
0 0110 06
0 1000 08

0 1111 0F

0 0111 07

0 1010 0A

0 1110 0E

1 0111 17

1 1001 19

1 1010 1A

0 1001 09

0 1011 0B

0 1100 0C

0 0001 01

0 0010 02

0 0101 05

0 1101 0D

467

267

67

533
600

400

333

200
250
300
350
400
450

50

1467

1067

867

667
733
800

933
1000

1200
1333

550
600
650

500

1100

1000

900

800

750

700

1 1011 1B
1 0101 15
1 1100 1C
1 0001 11
1 1101 1D

1867

1733

2000
2133

1300
1400
1500
1600

1200 1600

MULTIPLIER

7.5X

9.0X

8.0X

5.0X

7.0X

6.5X

6.0X

5.5X

3.5X

4.0X

4.5X

2.5X

3.0X

1.0X

2.0X

0.0X

0.5X

16.0X

15.0X

14.0X

13.0X

12.0X

11.0X

10.0X

(Bus-to-Core)

100MHZ 133MHZ

PLL BYPASS

PLL OFF

(MHZ)

E ABCD HEX

(PROCESSOR)

CPU_EMODE0_L

SIGNAL

CPU_BUS_VSEL
(PROCESSOR)

CPU_L3_VSEL
(PROCESSOR)

2.5V INTERFACE

60X BUS MODE
MAX BUS MODE

APPLICATION

2.5V INTERFACE

1.8V INTERFACE

1.8V INTERFACE

CPU_HRESET_L or INT. PU

LOW

LOW

CPU_HRESET_L

CPU_HRESET_L

HIGH

TIED

CPU_BST

2

1

NO STUFF

2

1

2

1

2

1

2

1

2

1

2

1

212

1

NO STUFF

2

1

2

1

NO STUFF

2

1

2

1

4

5

3

1

2

6

NO STUFF

4

5

3

2

NO STUFF

2

1

2 1

NO STUFF

2 1

NO STUFF

2 1

2

1

2

1

NO STUFF

2

1

NO STUFF

2

1

2

1

2

1

2

1

3

2

3

1

21

2

1

NO STUFF

2

1

NO STUFF

2

1

NO STUFF

2

1

CPU_BTR

2

1

2

1

NO STUFF

2

1

NO STUFF

2

1

NO STUFF

2

1

NO STUFF

2

1

CR-12

CPU_PLL_FS00

PLL_STOP_L

CPU_HRESET_LCPU_EMODE0_L

CPU_BUS_VSEL

CPU_L3_VSEL

CPU_PLL_CFGEXT

CPU_PLL_CFG<3>

CPU_PLL_CFG<2>

CPU_PLL_CFG<1>

CPU_PLL_CFG<0>

CPU_PLL_FS01

CPU_PLL_FS10

CPU_PLL_STOP_BASE

CPU_VCORE_HI_OC

CPU_PLL_STOP_OC

UNIN_MAXBUS_REF
CPU_DATA<63>

CPU_L3_VSEL

CPU_HRESET_L

40<>

14<>

14<

34<>

12>

34<>

34<>

6<>

12<

34<>

+1_8V_SLEEP

402

MF

1/16W

5%

10K

R292

402

MF

1/16W

5%

10K

R349

402

MF

1/16W

5%

10K

R253

402

MF

1/16W

5%

10K

R416

402

MF

1/16W

5%

10K

R329

402

MF

1/16W

5%

10K

R324

402

MF

1/16W

5%

200

R255

402

MF

1/16W

5%

10K

R252

402

MF

1/16W

5%

1K

R271

402

MF

1/16W

5%

1K

R353

402

MF

1/16W

5%

10K

R301

402

CERM

10V

20%

0.1uF

C394

402

CERM

10V

20%

0.1uF

C347

402

CERM

10V

20%

0.1uF

C358

402

CERM

10V

20%

0.1uF

C593

402

CERM

10V

20%

0.1uF

C446

402

CERM

10V

20%

0.1uF

C631

402

CERM

10V

20%

0.1uF

C490

402

CERM

10V

20%

0.1uF

C445

402

CERM

10V

20%

0.1uF

C538

402

CERM

10V

20%

0.1uF

C491

402

CERM

10V

20%

0.1uF

C444

402

CERM

10V

20%

0.1uF

C442

402

CERM

10V

20%

0.1uF

C632

402

CERM

10V

20%

0.1uF

C602

402

CERM

10V

20%

0.1uF

C284

402

CERM

10V

20%

0.1uF

C603

+1_8V_SLEEP

402

CERM

10V

20%

0.1uF

C622

402

CERM

10V

20%

0.1uF

C601

402

R438

MF

1/16W

5%

470

402

CERM

10V

20%

0.1uF

C492

402

CERM

10V

20%

0.1uF

C493

402

CERM

10V

20%

0.1uF

C536

402

CERM

10V

20%

0.1uF

C539

402

CERM

10V

20%

0.1uF

C443

402

CERM

10V

20%

0.1uF

C537

402

R394

MF

1/16W

5%

470

CLK_OUT

AVDD
BVSEL

SYSCLK

PLL_CFG3

DTI1

DTI0

DRDY

DBG

PLL_CFG0
PLL_CFG1

PLL_CFG4

PLL_CFG2

DTI2

TRST

TMS

TDI
TDO

TCK

LSSD_MODE
L1_TSTCLK

DTI3

L2_TSTCLK

QACK

TEA

TA

QREQ

TBEN

CKSTP_IN

OVDD

CKSTP_OUT

INT
SMI

HRESET

SRESET

MCP

CHKS

PMON_IN

DX

BMODE1

BMODE0

PMON_OUT

IARTRY1

IARTRY0

EXT_QUAL

OSHD
SRW0
SRW1
WAIT

NC3

NC1

NC6

NC4
NC5

SPARE3

SPARE2

SPARE0
SPARE1

NC7

NC2

NC8
NC9

NC11

NC10

GND

VDD

BG

BR

A1

TS

HPR

A0

A6

A5

A4

A3

A2

A11

A9

A7
A8

A10

A12

A16

A15

A14

A13

A17
A18
A19
A20
A21
A22

A24
A25

A23

A26
A27

A32

A28

A30
A31

A29

AP0

A34
A35

A33

AP3
AP4

AP2

AP1

TT4

TT1
TT2
TT3

TT0

TBST

TSIZ2

ARTRY
SHD0

AACK

TSIZ0
TSIZ1

GBL
WT
CI

SHD1
HIT

SCVger

(1 OF 3)

U10

CBGA-483

402

MF

1/16W

5%

10K

R400

402

MF

1/16W

5%

470

R395

402

MF

1/16W

5%

10K

R291

402

MF

1/16W

5%

1K

R313

805

CERM

6.3V

20%

10uF

C441

805

CERM

16V

N20P80%

2.2uF

C573

805

CERM

6.3V

20%

10uF

C535

805

CERM

16V

N20P80%

2.2uF

C572

402

MF

1/16W

5%

10K

R281

402

MF

1/16W

5%

10K

R267

402

R221

MF

1/16W

5%

10

SM1

1/16W

5%

10K

RP1

SM1

1/16W

5%

10K

RP1

SM1

1/16W

5%

10K

RP1

SM1

1/16W

5%

10K

RP1

SM1

1/16W

5%

10K

RP2

SM1

1/16W

5%

10K

RP2

805

CERM

6.3V

20%

10uF

C865

805

CERM

6.3V

20%

10uF

C864

402

MF

1/16W

5%

33

R700

603

CERM

50V

5%

22pF

C878

402

CERM

10V

20%

0.1uF

C315

805

CERM

16V

N20P80%

2.2uF

C295

TABLE_ALT_ITEM

337S2636337S2827

CPU_BST

U10

N5R3.3

CRITICAL BOM OPTION

TABLE_5_HEAD

PART#

DESCRIPTION

QTY

REFERENCE DESIGNATOR(S)

TABLE_ALT_ITEM

337S2636337S2716

CPU_BST

U10

N5R3.3

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

13 46

E

051-6403

TABLE_ALT_ITEM

337S2635337S2715

CPU_BTR

U10

N5R3.3

PART NUMBER

ALTERNATE FOR

PART NUMBER

BOM OPTION

REF DES

COMMENTS:

TABLE_ALT_HEAD

TABLE_5_ITEM

CRITICAL

CPU_BTR

337S2635

1

IC,APOLLO,NODE 5,867MHZ,1.3V CORE,85C

U10

TABLE_5_ITEM

CRITICAL

CPU_BST

337S2636

1

IC,APOLLO,NODE 5,1GHZ,1.3V CORE,85C

U10

NC

NC

NC

NC

NC

NC

CPU INTERNAL PLL FILTERING

CPU_OVDD DECOUPLING NETWORK

CPU_VCORE DECOUPLING NETWORK

NC

NC

NC

NC
NC

NC
NC
NC

NC

NC
NC
NC

NC
NC
NC

NC

NC

RC glitch filter

MPC7455 MAXBUS

MPC7455 PULL-UPS

21

21

21

21

21

21

21

21

21

21

21

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

OMIT

L2

F8

L11L9K14

K12

K10

J15

J13

P14

P12

J11

P10

N15

N13

N11N9M14

M12

M10

L15

L13

J9

E1

A5

K8

F4

F1

D1

H3

L1

P5

C1

K4

T1

H1

E4

J7

B7

L3

N8

D6

F9

D8

G1

J8

H9

D3

A8

G8

L8

L4

Y1
K7

B4

E6

H8

D4

C2

F7

A2

G3F5E9E3D2

C10

AA15

AA4

Y19

Y17

Y10C7Y7Y5Y2

V13

V9V3U15

U11

U7

U5C5T3R4P7N3M5L7K3J5H7

G9

B3

B6

G2

F11

E11

E7

D11

D5

C11

B11

H11

G11

A11

B8

F6

J2

H4

J6

H10

H6

A3

F2

K2

L12

L10

K15

K13

AB1

AA17

AA5

Y20

Y15

K11

Y13

Y9Y3W7

V15

V12

V8V5V2

T13

K9

T9T7T4P3M6M3K5J3H5

G7

J14

G4

F10

E5E2D7C9C3B5B1

P15

J12

P13

P11

P9

N14

N12

N10

M13

M11

M9

L14

J10

M4

B9

A9

P6

U3

T5

P2

T6

V1

N1

K6

F3

R1

B10

G6

K1

C4

C6

R3

B2

T2

G5

H2

J1

L6

L5

U1

M1

A6

M2

A7

R2

C8

D9

G10

J4

D10

AA1

V4

N5

W3

W1

W2

U4

AA3

N7

M7

R6

P4

P1

E8

Y4

R5

U6

N6

W4

M8

P8

N2

U2

A10

N4

E10

21

21

21

21

2

1

2

1

21

21

1

2

63

72

54

81

72

81

2

1

2

1

21

2

1

2

1

2

1

CR-13

CPU_DRDY_0_L

CPU_DRDY_0_L_UF

CPU_SRESET_L

CPU_TT<0>

CPU_MCP_L

CPU_LSSD_MODE

CPU_SHD0_L

CPU_TBEN

CPU_SHD1_L

CPU_CHKS_L

CPU_AVDD

CPU_BUS_VSEL

CPU_CLKOUT_SPN
CPU_PLL_CFG<0>
CPU_PLL_CFG<1>

CPU_PLL_CFGEXT

CPU_PLL_CFG<2>
CPU_PLL_CFG<3>

CPU_DBG_L

CPU_EDTI

CPU_DTI<1>

CPU_DTI<0>

JTAG_CPU_TDI
JTAG_CPU_TDO_TP

CPU_DTI<2>

JTAG_CPU_TCK
JTAG_CPU_RST_L

JTAG_CPU_TMS

CPU_L1TSTCLK

CPU_LSSD_MODE

CPU_L2TSTCLK

CPU_TEA_L

CPU_TA_L

CPU_TBEN
CPU_QREQ_L
CPU_QACK_L

CHKSTP_OUT_L

MPIC_CPU_INT_L

CPU_CHKS_L

CPU_MCP_L

CPU_SMI_L

CPU_HRESET_L

CPU_SRESET_L

CPU_PMONIN_L

CPU_EMODE0_L
CPU_EMODE1_L

CPU_PULLDOWN

CPU_PULLUP

CPU_SRWX_L

CPU_BR_L
CPU_BG_L

CPU_TS_L

CPU_PULLDOWN

CPU_ADDR<2>

CPU_ADDR<0>
CPU_ADDR<1>

CPU_ADDR<3>
CPU_ADDR<4>
CPU_ADDR<5>
CPU_ADDR<6>
CPU_ADDR<7>

CPU_ADDR<10>

CPU_ADDR<9>

CPU_ADDR<8>

CPU_ADDR<12>

CPU_ADDR<11>

CPU_ADDR<15>

CPU_ADDR<14>

CPU_ADDR<13>

CPU_ADDR<17>

CPU_ADDR<16>

CPU_ADDR<20>

CPU_ADDR<19>

CPU_ADDR<18>

CPU_ADDR<22>

CPU_ADDR<21>

CPU_ADDR<25>

CPU_ADDR<23>
CPU_ADDR<24>

CPU_ADDR<27>

CPU_ADDR<26>

CPU_ADDR<28>
CPU_ADDR<29>
CPU_ADDR<30>
CPU_ADDR<31>

CPU_TT<1>

CPU_TT<4>

CPU_TT<3>

CPU_TT<2>

CPU_TSIZ<0>

CPU_TBST_L

CPU_TSIZ<1>

CPU_GBL_L

CPU_TSIZ<2>

CPU_AACK_L

CPU_WT_L
CPU_CI_L

CPU_ARTRY_L
CPU_SHD0_L
CPU_SHD1_L
CPU_HIT_0_L

CPU_VCORE_SLEEP

CPU_L2TSTCLK

CHKSTP_OUT_L

CPU_SRWX_L

CPU_PMONIN_L

CPU_EMODE1_L

CPU_PULLUP

CPU_HRESET_L

MPIC_CPU_INT_L

CPU_SMI_L

JTAG_CPU_TDI

JTAG_CPU_TMS

JTAG_CPU_TCK

JTAG_CPU_RST_L

CPU_EDTI

CPU_PULLDOWN

CPU_L1TSTCLK

SYSCLK_CPU

CPU_VCORE_SLEEP

6<

6<

6<

39<

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

43<>

13<

16<>

6<>

13<>

13<>

43<>

6>

6>

6>

6>

6>

6>

6<

6>

13<

16>

34<>

34<>

16<>

16<>

13<>

6<

6>

6<>

13<

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6>

6<>

6>

6>

6>

6<>

13<

13<

6<

13<>

13<>

16<>

34<>

16>

34<>

13<>

40<>

43<>

SCVger

(3 OF 3)

L3VSEL

L3CLK0
L3CLK1

L3CNTL1*

L3CNTL0*

L3ECHO_CLK0
L3ECHO_CLK1
L3ECHO_CLK2
L3ECHO_CLK3

GND

L3DP6

L3DP5

L3DP4

L3DP3

L3DP2

L3DP7

L3DP1

L3DP0

L3D63

L3D62

L3D61

L3D60

L3D59

L3D58

L3D57

L3D56

L3D53

L3D52

L3D51

L3D50

L3D49

L3D48

L3D47

L3D54
L3D55

L3D46

L3D42

L3D41

L3D40

L3D39

L3D38

L3D37

L3D36

L3D43
L3D44
L3D45

L3D32

L3D31

L3D30

L3D29

L3D28

L3D27

L3D26

L3D33
L3D34
L3D35

L3D25

L3D22

L3D21

L3D20

L3D19

L3D18

L3D17

L3D16

L3D23
L3D24

L3D15

L3D12

L3D11

L3D10

L3D9

L3D8

L3D7

L3D6

L3D13
L3D14

L3D5

L3D4

L3D3

L3D2

L3D1

L3D0

L3A15
L3A16
L3A17

L3A8
L3A9
L3A10
L3A11
L3A12
L3A13
L3A14

L3A7

L3A6

L3A5

L3A0

L3A4

L3A3

L3A2

L3A1

L3OVDD

CBGA-483

U10

D0
D1

D6
D7

D10

D5

D3
D4

D2

D9

D8

D11

D21

D12
D13
D14
D15
D16
D17
D18
D19
D20

D23
D24
D25
D26
D27
D28
D29
D30
D31

D22

D41

D40

D39

D32
D33
D34
D35
D36
D37
D38

D42

D44
D45
D46
D47
D48
D49
D50
D51

D43

D52

D60

D59

D58

D57

D61

D53
D54
D55
D56

D62

DP3
DP4

DP0

DP2

D63

DP1

DP7

DP6

DP5

SCVger

(2 OF 3)

CBGA-483

U10

603

MF

1/16W

5%

0

R696

603

MF

1/16W

5%

0

R697

402

R698

MF

1/16W

1%

10.7K

402

R699

MF

1/16W

1%

68.1K

805

CERM

10V

20%

1uF

C875

402

CERM

16V

20%

0.01uF

C876

+2_5V_SLEEP

+1_8V_SLEEP

805

CERM

6.3V

20%

10uF

C877

ADJ

BYP
GND

OUT

NC

NC

SHDN

IN

U62

LT1962-ADJ

MSOP

402

CERM

10V

20%

0.1uF

C882

402

CERM

10V

20%

0.1uF

C886

402

CERM

10V

20%

0.1uF

C881

402

CERM

10V

20%

0.1uF

C885

402

CERM

10V

20%

0.1uF

C880

402

CERM

10V

20%

0.1uF

C884

402

CERM

10V

20%

0.1uF

C879

402

CERM

10V

20%

0.1uF

C883

603

MF

1/16W

5%

0

R701

402

R702

MF

1/16W

5%

0

402

CERM

10V

20%

0.1uF

C888

402

CERM

10V

20%

0.1uF

C887

402

CERM

50V

20%

0.001uF

C50

402

CERM

50V

20%

0.001uF

C220

402

CERM

50V

20%

0.001uF

C321

402

CERM

50V

20%

0.001uF

C367

402

CERM

50V

20%

0.001uF

C384

402

CERM

50V

20%

0.001uF

C322

402

CERM

50V

20%

0.001uF

C305

402

CERM

50V

20%

0.001uF

C187

402

CERM

50V

20%

0.001uF

C219

402

CERM

50V

20%

0.001uF

C306

805

CERM

6.3V

20%

10uF

C366

805

CERM

6.3V

20%

10uF

C385

REFERENCE DESIGNATOR(S)

BOM OPTION

TABLE_5_HEAD

QTY

DESCRIPTION

PART#

TABLE_5_ITEM

1415_L3_GVDD

114S1074

1

RES,1/16W,10.7K OHM,0402,SMD

R698

TABLE_5_ITEM

1325_L3_GVDD

114S6343

1

RES,1/16W,6.34K OHM,0402,SMD

R698

TABLE_5_ITEM

1352_L3_GVDD

114S7503

1

RES,1/16W,7.5K OHM,0402,SMD

R698

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

14 46

E

051-6403

Additional CPU L3 I/O Decoupling

CPU L3 I/O Decoupling

Place 1 each near pins B15, D12, E19, F15, H17, K17, M19, R15, T17, V21 of processor

MPC7455 DATA/L3

NOTE: This rail is now positioned at 1.41V

spscifically for P59 processors.
L3 GVDD will need to be re-evaluated
for each project.

.

NC

NC

NC

NC
NC
NC
NC
NC

NC

NC

NC

NC

NC

NC

NC

NC

NC

NC

L3 I/O LDO Regulator

KEEP CLOSE TO REGULATOR

OMIT

A4

D18

D16

D14

D12

B21

B19

Y21

W19

V21

V17

U19

T21

T17

R19

R15

B17

P21

P17

N19

M21

M17

L19

K21

K17

J19

H21

B15

H17

H14

H12

G19

F21

F17

F15

F13

E19

D21

B13

E14

E18

P20

V18

A12

A15

E16

C20

P16

P22

AA22

AB19

U18

W20

T16

C12

E12

A13

G12

AA21

C13

E13

A14

C14

G13

C15

A16

A17

C16

E15

AB21

G14

A18

A19

C18

C19

A20

E17

G15

A21

G16

AA20

B22

D20

F18

C22

H16

E20

D22

G18

M15

R22

W18

P18

R20

T22

U22

T20

R18

M22

M20

M18

M16

U16

N22

N16

N20

N18

U20

T18

W22

V20

R16

Y22

AB20

AA19

L22

L20

C17

V22

K16

J18

H22

J20

J22

K18

K20

L16

F20

J16

E22

H18

G20

F22

G22

H20

K22

L18

AB22

W21

W17

V19

U21

U17

T19

T15

R21

R17

P19

N21

N17

M19

L21

L17

K19

J21

J17

H19

H15

H13

G21

G17

F19

F16

F14

F12

E21

D19

D17

D15

D13

C21

B20

B18

B16

B14

B12

A22

OMIT

AB5

U8

W5

R8

AA8

AB2

AB3

AA2

Y11

AA11

W16

W9

AB8

AA9

R9

AB14

R7

AB6

AB9

V6

AA12

W6

V16

AA14

W15

R13

U14

W14

AA18

Y16

AB18

Y18

AB17

AB16

AA16

AB10

W8

V14

AA7

Y8

AA6

AB7

Y6

AB4

T8

V7

U9

AA10

AB13

U10

R10

V10

W11

T10

W10

R11

T11

V11

Y12

R14

AB11

AA13

R12

AB12

W12

T12

U13

Y14

W13

U12

T14

AB15

NO STUFF

21

21

OMIT

2

1

L3_RC

2

1

L3_RC

2

1

L3_RC

2

1

L3_RC

2

1

L3_RC

5

1

7

6

8

4

3

2

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

NO_L3_RC

21

L3_RC

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

CR-14

+LT1962_SLEEP

L3_ADDR<6>

+1_5V_L3_VDDQ_SLEEP

LT1962_ADJ

LT1962_BYPASS

LT1962_SHDN_L

L3_CLK<1>

L3_CLK<0>

L3_CNTL<1>

L3_CNTL<0>

CPU_L3_VSEL

L3_ECHO_CLK<3>

L3_ECHO_CLK<2>

L3_ECHO_CLK<1>

L3_ECHO_CLK<0>

+1_5V_L3_VDDQ_SLEEP

CPU_DATA<63>

CPU_DATA<62>

CPU_DATA<60>
CPU_DATA<61>

CPU_DATA<59>

CPU_DATA<57>
CPU_DATA<58>

CPU_DATA<55>
CPU_DATA<56>

CPU_DATA<54>

CPU_DATA<53>

CPU_DATA<52>

CPU_DATA<50>
CPU_DATA<51>

CPU_DATA<49>

CPU_DATA<48>

CPU_DATA<47>

CPU_DATA<45>
CPU_DATA<46>

CPU_DATA<44>

CPU_DATA<43>

CPU_DATA<42>

CPU_DATA<41>

CPU_DATA<40>

CPU_DATA<39>

CPU_DATA<38>

CPU_DATA<37>

CPU_DATA<36>

CPU_DATA<35>

CPU_DATA<34>

CPU_DATA<32>
CPU_DATA<33>

CPU_DATA<31>

CPU_DATA<30>

CPU_DATA<29>

CPU_DATA<28>

CPU_DATA<27>

CPU_DATA<26>

CPU_DATA<25>

CPU_DATA<24>

CPU_DATA<23>

CPU_DATA<22>

CPU_DATA<21>

CPU_DATA<20>

CPU_DATA<19>

CPU_DATA<18>

CPU_DATA<16>
CPU_DATA<17>

CPU_DATA<14>
CPU_DATA<15>

CPU_DATA<13>

CPU_DATA<11>
CPU_DATA<12>

CPU_DATA<9>
CPU_DATA<10>

CPU_DATA<8>

CPU_DATA<7>

CPU_DATA<6>

CPU_DATA<4>
CPU_DATA<5>

CPU_DATA<3>

CPU_DATA<1>
CPU_DATA<2>

CPU_DATA<0>

L3_ADDR<1>

L3_ADDR<0>

L3_ADDR<3>

L3_ADDR<2>

L3_ADDR<4>
L3_ADDR<5>

L3_ADDR<7>
L3_ADDR<8>
L3_ADDR<9>
L3_ADDR<10>
L3_ADDR<11>
L3_ADDR<12>
L3_ADDR<13>
L3_ADDR<14>

L3_ADDR<16>

L3_ADDR<15>

L3_ADDR<17>

L3_DATA<0>
L3_DATA<1>

L3_DATA<3>

L3_DATA<2>

L3_DATA<4>
L3_DATA<5>
L3_DATA<6>
L3_DATA<7>
L3_DATA<8>
L3_DATA<9>

L3_DATA<11>

L3_DATA<10>

L3_DATA<12>

L3_DATA<14>

L3_DATA<13>

L3_DATA<17>

L3_DATA<15>
L3_DATA<16>

L3_DATA<18>
L3_DATA<19>
L3_DATA<20>
L3_DATA<21>
L3_DATA<22>

L3_DATA<24>

L3_DATA<23>

L3_DATA<27>

L3_DATA<25>
L3_DATA<26>

L3_DATA<28>
L3_DATA<29>
L3_DATA<30>
L3_DATA<31>
L3_DATA<32>
L3_DATA<33>
L3_DATA<34>
L3_DATA<35>

L3_DATA<37>

L3_DATA<36>

L3_DATA<38>
L3_DATA<39>
L3_DATA<40>
L3_DATA<41>
L3_DATA<42>

L3_DATA<44>

L3_DATA<43>

L3_DATA<45>

L3_DATA<47>

L3_DATA<46>

L3_DATA<48>
L3_DATA<49>
L3_DATA<50>
L3_DATA<51>
L3_DATA<52>
L3_DATA<53>

L3_DATA<55>

L3_DATA<54>

L3_DATA<58>

L3_DATA<56>
L3_DATA<57>

L3_DATA<59>
L3_DATA<60>

L3_DATA<63>

L3_DATA<62>

L3_DATA<61>

+1_5V_L3_VDDQ_SLEEP

+1_5V_L3_VDDQ_SLEEP

15<

15<

14<

14<

12<

15<

43<>

15<

15<

15<

15<

40<>

40<>

40<>

40<>

43<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

15<

15<

15<

15<

15<

15<

15<

15<

15<

15<

15<

15<

15<

15<

15<

15<

15<

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

43<>

43<>

43<>

41<>

14<>

40<>

40<>

41<>

41<>

12>

15<>

15<>

15<>

15<>

14<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

6<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

14<>

14<>

CQ*

NC

TDI

TCK

TDO

TMS

ZQ

VREF

VREF

LBO*

B1*

B2*

G*

A16

A14
A15

CK
CK*

A13

A12

A11

A10

A9

A4
A5
A6

A8

A7

A3

A0

A2

A1

DQPB
DQPC
DQPD

CQ

CQ

D30

D29

D31

DQPA

D25

D24

D26
D27
D28

D19
D20
D21
D22
D23

D18

D17

D16

D14
D15

D13

D12

D11

D10

D9

D8

D7

D6

D5

D4

D3

VDD

VDDQ

D0
D1
D2

SRAM_DDR_153PBGA

CQ*

A17
A18
A19

B3*

MODE

TEMPLATE

PBGA

U42

402

MF

1/16W

5%

470

R312

402

MF

1/16W

5%

470

R280

603

MF

1/16W

5%

0

R31

+2_5V_SLEEP

402

R418

MF

1/16W

1%

1K

402

R428

MF

1/16W

1%

1K

SM

RP24

25V

1/32W

5%

10K

402

CERM

10V

20%

0.1uF

C599

402

CERM

10V

20%

0.1uF

C393

402

R311

MF

1/16W

1%

1K

402

R290

MF

1/16W

1%

1K

402

CERM

10V

20%

0.1uF

C440

402

CERM

10V

20%

0.1uF

C424

402

CERM

10V

20%

0.1uF

C532

402

CERM

10V

20%

0.1uF

C616

402

CERM

10V

20%

0.1uF

C327

402

CERM

10V

20%

0.1uF

C672

402

CERM

10V

20%

0.1uF

C276

402

CERM

10V

20%

0.1uF

C60

402

CERM

10V

20%

0.1uF

C53

402

CERM

10V

20%

0.1uF

C51

402

CERM

10V

20%

0.1uF

C40

402

CERM

10V

20%

0.1uF

C617

402

CERM

10V

20%

0.1uF

C671

402

CERM

10V

20%

0.1uF

C314

402

CERM

10V

20%

0.1uF

C630

402

CERM

10V

20%

0.1uF

C673

402

CERM

10V

20%

0.1uF

C571

402

CERM

10V

20%

0.1uF

C676

402

CERM

10V

20%

0.1uF

C44

402

CERM

10V

20%

0.1uF

C533

402

R473

MF

1/16W

1%

249

402

CERM

10V

20%

0.1uF

C277

402

CERM

10V

20%

0.1uF

C275

402

CERM

10V

20%

0.1uF

C489

402

CERM

10V

20%

0.1uF

C280

402

CERM

10V

20%

0.1uF

C674

402

CERM

10V

20%

0.1uF

C621

402

CERM

10V

20%

0.1uF

C675

402

CERM

10V

20%

0.1uF

C556

402

CERM

10V

20%

0.1uF

C439

402

CERM

10V

20%

0.1uF

C346

805

CERM

16V

N20P80%

2.2uF

C687

805

CERM

6.3V

20%

10uF

C262

805

CERM

6.3V

20%

10uF

C688

805

CERM

16V

N20P80%

2.2uF

C18

805

CERM

16V

N20P80%

2.2uF

C690

805

CERM

16V

N20P80%

2.2uF

C17

805

CERM

6.3V

20%

10uF

C689

805

CERM

6.3V

20%

10uF

C263

402

MF

1/16W

5%

1K

R231

CQ*

NC

TDI

TCK

TDO

TMS

ZQ

VREF

VREF

LBO*

B1*

B2*

G*

A16

A14
A15

CK
CK*

A13

A12

A11

A10

A9

A4
A5
A6

A8

A7

A3

A0

A2

A1

DQPB
DQPC
DQPD

CQ

CQ

D30

D29

D31

DQPA

D25

D24

D26
D27
D28

D19
D20
D21
D22
D23

D18

D17

D16

D14
D15

D13

D12

D11

D10

D9

D8

D7

D6

D5

D4

D3

VDD

VDDQ

D0
D1
D2

SRAM_DDR_153PBGA

CQ*

A17
A18
A19

B3*

MODE

TEMPLATE

PBGA

U11

402

R472

MF

1/16W

1%

249

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

15 46

E

051-6403

CRITICAL BOM OPTION

TABLE_5_HEAD

PART#

DESCRIPTION

QTY

REFERENCE DESIGNATOR(S)

TABLE_5_ITEM

CRITICAL

L3_IC_2MB

333S0009

2

IC,SRAM,DDR,256KX36,250MHZ,153P BGA U11,U42

TABLE_5_ITEM

CRITICAL

L3_IC_1MB

333S0214

2

IC,SRAM,DDR,128KX36,250MHZ,153P BGA U11,U42

TABLE_5_ITEM

CRITICAL

300MHZ_L3_IC_1MB

333S0244

2

IC,SRAM,DDR,128KX36,300MHZ,153P BGA U11,U42

within a SRAM

within a SRAM

Data lines swappable

Data lines swappable

L3 CACHE

NC

NC

NC

NC

NC

NC

NC

NC

Split caps of same value evenly between SRAM chips

Split caps of same value evenly between SRAM chips

within a SRAM (except

Addr lines swappable

ADDR<0..1>)

Split caps of same value evenly between SRAM chips

Split caps of same value evenly between SRAM chips

OMIT

5A

1E6D4D9C1C9U6B

1U6T4T9R1R6P4P9N7N

3N4B1N9L7L3L1L6K4K9J7J

3J9A1J9G7G6G4G3G1G9E7E

3E

1A

5N

5E

2J8G2G8E2E8C2C

8A

8U2U8R2R8N2N8L2L8J

2A

4J6H4H6F5F4F6E

4E

7R3R5P6N4N6M5M4M6J

5J

5D

3U

6U

4U

5U

7U

6L

4L

5C

3M

3F

7F

7M

8B

9B

7K

8K

9K

9M

3K

2K

8P

1K

1M

2P

1P

2T

1T

3H

2H

1H

1F

9P

2D

1D

2B

1B

7H

8H

9H

9F

8D

9D

8T

9T

2M

8F

8M

2F

5H

5G

5L

5K

5B

4C

7C

4A

3C

3A

3T

4R

6R

3P

3D

7D

7B

3B

7A

7T

7P

6A

6C

5R

5T

L3_RC

21

L3_RC

21

L3_RC

21

L3_RC

2

1

L3_RC

2

1

L3_RC

9

8

7

6

4

3

2

1

10

5

L3_RC

2

1

L3_RC

2

1

L3_RC

2

1

L3_RC

2

1

L3_RC

2

1

L3_RC

2

1

L3_RC

2

1

L3_RC

2

1

L3_RC

2

1

L3_RC

2

1

L3_RC

2

1

L3_RC

2

1

L3_RC

2

1

L3_RC

2

1

L3_RC

2

1

L3_RC

2

1

L3_RC

2

1

L3_RC

2

1

L3_RC

2

1

L3_RC

2

1

L3_RC

2

1

L3_RC

2

1

L3_RC

2

1

L3_RC

2

1

L3_RC

2

1

L3_RC

2

1

L3_RC

2

1

L3_RC

2

1

L3_RC

2

1

L3_RC

2

1

L3_RC

2

1

L3_RC

2

1

L3_RC

2

1

L3_RC

2

1

L3_RC

2

1

L3_RC

2

1

L3_RC L3_RC L3_RC

2

1

L3_RC

2

1

L3_RC

2

1

L3_RCL3_RC

L3_RC

21

OMIT

5A

1E6D4D9C1C9U6B

1U6T4T9R1R6P4P9N7N

3N4B1N9L7L3L1L6K4K9J7J

3J9A1J9G7G6G4G3G1G9E7E

3E

1A

5N

5E

2J8G2G8E2E8C2C

8A

8U2U8R2R8N2N8L2L8J

2A

4J6H4H6F5F4F6E

4E

7R3R5P6N4N6M5M4M6J

5J

5D

3U

6U

4U

5U

7U

6L

4L

5C

3M

3F

7F

7M

8B

9B

7K

8K

9K

9M

3K

2K

8P

1K

1M

2P

1P

2T

1T

3H

2H

1H

1F

9P

2D

1D

2B

1B

7H

8H

9H

9F

8D

9D

8T

9T

2M

8F

8M

2F

5H

5G

5L

5K

5B

4C

7C

4A

3C

3A

3T

4R

6R

3P

3D

7D

7B

3B

7A

7T

7P

6A

6C

5R

5T

L3_RC

2

1

CR-15

JTAG_L3_TCK

JTAG_L3_TMS

JTAG_L3_TCK

L3_PULLDOWN<1>

L3_PULLDOWN<0>

L3_VDD_SLEEP

L3_PULLDOWN<1>

L3_PULLDOWN<1>

L3_ADDR<17>

L3_PULLDOWN<1>

L3_DATA<54>
L3_DATA<39>
L3_DATA<46>
L3_DATA<51>

L3_DATA<58>

L3_DATA<36>

L3_DATA<45>

L3_DATA<62>

L3_DATA<60>
L3_DATA<55>
L3_DATA<35>

L3_DATA<50>

L3_DATA<49>
L3_DATA<42>

L3_DATA<38>

L3_DATA<34>

L3_DATA<32>

L3_DATA<43>

L3_DATA<40>

L3_DATA<56>

L3_DATA<37>

L3_DATA<33>

L3_DATA<41>
L3_DATA<59>

L3_DATA<61>
L3_DATA<57>
L3_DATA<53>
L3_DATA<52>
L3_DATA<48>
L3_DATA<47>

L3_DATA<63>

L3_DATA<44>

L3_DQPA<1>

L3_DQPD<1>

L3_DQPC<1>

L3_DQPB<1>

L3_ECHO_CLK<2>

L3_ECHO_CLK<3>

L3_VDD_SLEEP

L3_ADDR<0>
L3_ADDR<1>
L3_ADDR<3>
L3_ADDR<6>
L3_ADDR<14>
L3_ADDR<8>
L3_ADDR<11>
L3_ADDR<9>
L3_ADDR<4>
L3_ADDR<5>
L3_ADDR<7>
L3_ADDR<13>
L3_ADDR<12>
L3_ADDR<10>
L3_ADDR<2>
L3_ADDR<15>
L3_ADDR<16>

L3_CLK_REF

L3_CLK<1>

L3_PULLDOWN<1>
L3_PULLDOWN<1>

L3_CNTL<0>

L3_CNTL<1>

L3_ZQ<1>

L3_VREF

JTAG_L3_TMS
JTAG_L3_SRAM2_TDI
JTAG_L3_TDO_TP

L3_PULLDOWN<0>

L3_PULLDOWN<0>

L3_ADDR<17>

L3_PULLDOWN<0>

L3_DATA<23>
L3_DATA<31>
L3_DATA<17>
L3_DATA<22>

L3_DATA<25>

L3_DATA<19>

L3_DATA<30>

L3_DATA<27>

L3_DATA<1>
L3_DATA<0>
L3_DATA<5>

L3_DATA<12>

L3_DATA<4>
L3_DATA<6>

L3_DATA<15>

L3_DATA<26>

L3_DATA<3>

L3_DATA<8>

L3_DATA<10>

L3_DATA<2>

L3_DATA<13>

L3_DATA<9>

L3_DATA<14>
L3_DATA<7>

L3_DATA<18>
L3_DATA<20>
L3_DATA<21>
L3_DATA<16>
L3_DATA<29>
L3_DATA<11>

L3_DATA<28>

L3_DATA<24>

L3_DQPA<0>

L3_DQPD<0>

L3_DQPC<0>

L3_DQPB<0>

L3_ECHO_CLK<0>

L3_ECHO_CLK<1>

L3_VDD_SLEEP

L3_ADDR<0>
L3_ADDR<1>
L3_ADDR<6>
L3_ADDR<12>
L3_ADDR<10>
L3_ADDR<2>
L3_ADDR<11>
L3_ADDR<13>
L3_ADDR<4>
L3_ADDR<7>
L3_ADDR<5>
L3_ADDR<9>
L3_ADDR<3>
L3_ADDR<14>
L3_ADDR<8>
L3_ADDR<15>
L3_ADDR<16>

L3_CLK_REF

L3_CLK<0>

L3_PULLDOWN<0>
L3_PULLDOWN<0>

L3_CNTL<0>

L3_CNTL<1>

L3_ZQ<0>

L3_VREF

JTAG_L3_TDI_TP
JTAG_L3_SRAM2_TDI
JTAG_L3_TCK

L3_VDD_SLEEP

L3_DQPD<1>

L3_DQPC<1>

L3_DQPB<1>

L3_DQPA<1>

L3_DQPD<0>

L3_DQPA<0>
L3_DQPB<0>
L3_DQPC<0>

L3_CLK_REF

L3_VREF

L3_VDD_SLEEP

+1_5V_L3_VDDQ_SLEEP

+1_5V_L3_VDDQ_SLEEP

+1_5V_L3_VDDQ_SLEEP

+1_5V_L3_VDDQ_SLEEP

+1_5V_L3_VDDQ_SLEEP

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

14<

14<

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

40<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

14<

14<

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

40<>

41<>

41<>

43<>

43<>

43<>

43<>

43<>

43<>

14>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

15<

15<

15<

15<

40<>

40<>

43<>

14>

14>

14>

14>

14>

14>

14>

14>

14>

14>

14>

14>

14>

14>

14>

14>

14>

14>

14>

14>

15>

14>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

14<>

15<

15<

15<

15<

40<>

40<>

43<>

14>

14>

14>

14>

14>

14>

14>

14>

14>

14>

14>

14>

14>

14>

14>

14>

14>

14>

14>

14>

15<

43<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

15<>

43<>

14<>

14<>

14<>

14<>

14<>

805

CERM

16V

N20P80%

2.2uF

C139

402

CERM

10V

20%

0.1uF

C153

402

R68

MF

1/16W

5%

22

402

R67

MF

1/16W

5%

22

402

R71

MF

1/16W

5%

22

+3V_MAIN

+3V_MAIN

+3V_MAIN

SM1

1/16W

RP11

10K
5%

402

MF

1/16W

5%

10K

R113

402

MF

1/16W

5%

10K

R73

805

CERM

10V

N20P80%

4.7uF

C782

+3V_MAIN

+3V_MAIN

+3V_SLEEP

402

MF

1/16W

5%

47

R111

402

MF

1/16W

5%

22

R578

402

MF

1/16W

5%

100K

R603

402

MF

1/16W

5%

100K

R604

+3V_MAIN

SM1

1/16W

RP9

10K
5%

+3V_MAIN

402

MF

1/16W

5%

10K

R107

402

MF

1/16W

5%

10

R70

402

CERM

10V

20%

0.1uF

C155

402

MF

1/16W

5%

10K

R100

+3V_SLEEP

402

MF

1/16W

5%

15K

R105

402

MF

1/16W

5%

15K

R109

SM1

1/16W

RP8

10K
5%

SM1

1/16W

RP7

10K
5%

SM1

1/16W

RP10

10K
5%

402

CERM

16V

20%

0.01uF

C783

402

MF

1/16W

5%

22

R106

402

MF

1/16W

5%

22

R110

UIDE_DMAACK

UIDE_INT

UIDE_DMAREQ

UIDE_RD

UIDE_WR

UIDE_RST

UIDE_CS3FX

UIDE_CS1FX

UIDE_IOCHRDY

UIDE_DA2

UIDE_DA1

UIDE_DA0

UIDE_DD15

UIDE_DD14

UIDE_DD13

UIDE_DD12

UIDE_DD11

UIDE_DD10

UIDE_DD9

UIDE_DD8

UIDE_DD7

UIDE_DD6

UIDE_DD5

UIDE_DD4

UIDE_DD3

UIDE_DD2

UIDE_DD1

UIDE_DD0

DIR_245

DEVCS4
PRAMCS

DEVCS2
DEVCS3

UIDE_PLL_AVDD

PCIAD0

PCIIDSEL

PCIIDESEL_USB1

PCIIDESEL_USB0

EIDE0_RST

EIDE0_WR

EIDE0_RD
EIDE0_DMAACK
EIDE0_DMAREQ

EIDE0_INT

ARBCRITICAL
PCIRST

PCIGNT

PCIREQ

PCIPAR

PCIC_BE2
PCIC_BE3

PCISTOP

PCIFRAME
PCITRDY
PCIIRDY

PCIDEVSEL

PCIC_BE1

PCIC_BE0

PCIAD24
PCIAD25
PCIAD26
PCIAD27

PCIAD30
PCIAD31

PCIAD28
PCIAD29

PCIAD23

PCIAD21
PCIAD22

PCIAD14
PCIAD15
PCIAD16

PCIAD19
PCIAD20

PCIAD17
PCIAD18

PCIAD13

PCIAD9

PCIAD8

PCIAD7

PCIAD6

PCIAD5

PCIAD4

PCIAD3

PCIAD10
PCIAD11
PCIAD12

PCIAD2

PCIAD1

EIDE1_RD

EIDE1_DMAREQ

EIDE1_DMAACK

EIDE1_INT

EIDE_CS3FX

EIDE1_RST

EIDE1_WR

EIDE_CS1FX

EIDE_DA0
EIDE_DA1
EIDE_DA2

EIDE_DD14
EIDE_DD15

EIDE_IOCHRDY

IOA4

IOA3

EIDE_DD13

EIDE_DD4

EIDE_DD3

EIDE_DD10

EIDE_DD7

EIDE_DD9

EIDE_DD8

EIDE_DD12

EIDE_DD11

EIDE_DD6

EIDE_DD5

EIDE_DD0
EIDE_DD1
EIDE_DD2

PCICLK

(1 OF 2 )

PCI_IO_RAIL

U53

KEYLARGO-17X17

BGA

INTERRUPTS

(2 OF 2)

TEST

VIA

SCC B/IR/I2S

AGND GND

TRST

TDI

TMS

TDO
TCK

IIC

IIC_DAT

IIC_CLK

VIA_TREQ

VIA_BYTEACK

VIA_DAT

VIA_TIP

VIA_CLK

AUDIO/I2S

AUD_DTI

AUD_DTO

AUD_SYNC
AUD_BITCLK
AUD_CLKOUT

CRDSLT_IOWAIT

CRDSLT_IORD

CRDSLT_IOWR

IOA12

IOA11

IOA10

IOA9

IOA8

IOA7

IOA6

IOA5

USB_VDD
USB_VSS

USB_VD1+

USB_VD1-

USB_VD3-

USB_VD3+

USB_VD2+

USB_VD2­USB_PWRON0

USB_PWRFLT0

USB_VD4+

USB_VD4­USB_PWRON1

USB_PWRFLT1

TRXCB_LOF

GPIOB_FIR

RXDB_RXD1

CLOCKS

PME

RXDA_DTI

DTRA

RTSA_MCLK

TXDA_DTO

AVDD

GPIOA_SYNC

RTSB_SDMODE

TXDB_TXD

TRXCA_BITCLK

USB

CARDSLOT

VDD 3.3V

GPIO1

GPIO0

GPIO3
GPIO4

PURPOSE

I/O’S

GENERAL

GPIO5

GPIO9
GPIO10

GPIO8

GPIO11

GPIO7

GPIO12

GPIO16

GPIO15

GPIO14

GPIO13

EXTINT0
EXTINT1
EXTINT2
EXTINT3
EXTINT4
EXTINT5
EXTINT6

GPIO6

EXTINT7

IO_CLK_STOP

MPIC_SYNC

MPIC_CLK

EXTINT17

EXTINT16

EXTINT15

EXTINT14

EXTINT13

EXTINT12

EXTINT11

EXTINT10

EXTINT9

EXTINT8

PENDPROCINT

PROCSLEEPREQ

MPIC_DAT
MPIC_CPU0INT

PLL_CLK

SCC A/I2S 1

MPIC

GPIO2/CPWM/DTRB

CREF

PLL_EN
WATCHDOG

CREF2

BGA

KEYLARGO-17X17

U53

SM1

1/16W

RP37

10K
5%

+3V_MAIN

402

MF

1/16W

5%

22

R103

603

MF

1/16W

5%

0

R570

402

MF

1/16W

5%

100K

R714

402

MF

1/16W

5%

22

R97

402

R102

MF

1/16W

5%

15K

402

R96

MF

1/16W

5%

15K

402

MF

1/16W

5%

22

R98

402

MF

1/16W

5%

22

R120

402

MF

1/16W

5%

47

R115

402

MF

1/16W

5%

10

R85

402

MF

1/16W

5%

47

R116

402

MF

1/16W

5%

47

R114

402

CERM

10V

20%

0.1uF

C149

402

CERM

10V

20%

0.1uF

C150

402

CERM

10V

20%

0.1uF

C134

805

CERM

16V

N20P80%

2.2uF

C126

402

CERM

10V

20%

0.1uF

C133

402

CERM

10V

20%

0.1uF

C131

402

CERM

10V

20%

0.1uF

C144

805

CERM

16V

N20P80%

2.2uF

C763

805

CERM

16V

N20P80%

2.2uF

C780

805

CERM

16V

N20P80%

2.2uF

C764

402

CERM

10V

20%

0.1uF

C132

805

CERM

16V

N20P80%

2.2uF

C781

805

CERM

16V

N20P80%

2.2uF

C154

XW20

SM

402

CERM

50V

20%

0.001uF

C743

OE

GND

OUT

VCC

OSC

18.4320M

G2

402

R546

MF

1/16W

5%

100K

805

CERM

16V

N20P80%

2.2uF

C748

SM

L60

FERR-EMI-100-OHM

402

R91

MF

1/16W

5%

10K

402

R86

MF

1/16W

5%

10K

SM

L57

FERR-EMI-100-OHM

402

MF

1/16W

5%

82

R119

402

MF

1/16W

5%

82

R117

402

MF

1/16W

5%

82

R118

603

CERM

50V

5%

10pF

C158

402

MF

1/16W

5%

10

R112

402

MF

1/16W

5%

10

R84

805

CERM

16V

N20P80%

2.2uF

C143

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

16 46

E

051-6403

PART NUMBER

ALTERNATE FOR

PART NUMBER

BOM OPTION

REF DES

COMMENTS:

TABLE_ALT_HEAD

TABLE_ALT_ITEM

343S0008343S0272

U53

REV D CHANGE: ALTERNATE ADDITION

NC

NC

NC
NC

NC

NC

supported this is okay here

Since only one CPU is

I/O plane, not +3V_MAIN.

should be pulled up to CPU

NOTE: CPU1_INT_L_PU, CPU1_SRESET_L_PU

PLACE CREF CAP AT CRYSTAL GROUND

KEYLARGO

1

2

1

2

1

2

1

2

1

2

1
2
3
4

8
7
6
5

2 1

2 1

1

2

1 2

2 1

1 2

1 2

1
2
3
4

8
7
6
5

2 1

1 2

1

2

2 1

1 2

1 2

1
2
3
4

8
7
6
5

1
2
3
4

8
7
6
5

1
2
3
4

8
7
6
5

1

2

1 2

1 2

P1

E15
D16
E13

D15

F16
F13
E16

J15

J16
H13

F15
F14
F10

H12

J13
H16

G14
G15

G13
G11
H15

J14
K15

L14
M16
L13
L12
M15
M12

K12
K16
J12
L16
K11
K14
L15
K13

G12

G16
H14

T15
R14

P11
R11
T11
R10
P10
N10

M8
T8
N8
P8

T14

R7
T7
P7
N7
L7
N6
T5
R5
M6
N5

P12

T4
R4

R13
N12
T13
R12
T12
N11

R3

M11
M10

R8
P6

P9

M9

T3

T6
M7

R6

N9

T10

P5

T2

R9

T9

P4

E12

B11
C11

B12
A12
D11

D10
A10

C8
E7
B8
A7
C7
D7

E10
B10
E9
D9
A9
E8
B9
A8

C10
C9
A11

D8

B3

A13

B7
D12

CRITICAL

L2

A4
A1

D6

B5

D5

M2L1M1

F12
P16

A15

L4
A2

H1

K5
N1

M13
N15

E3
C2
D3
D4
C3
C5

M5

M4
N16
M14
T16
R16
P15

A3

J10

H7

K9J9H9G9K8J8H8

G8

C15
B16

A14
C12
B13

A6

B6

C6

E6

E11
D14
D13
C14
B15
A16
C13
B14

G2

J5

C16
E14

K1
J4
G3

A5
B2
B4
B1
C4

R1

R2

N2

T1

P3

N4

L5

L3

P2

N3

H3

H2

G1

J1

N13

R15
P14

N14
P13

G4

J3

H5

H4

F5

G5

F3

G6

D2
D1
E4
F4

E2
F2
E1
F1

E5
C1

L11

L6L8L9

J11

H11

F11F9F8F6H6

J6

K4

K2

K3

K6

J2

M3

CRITICAL

1
2
3
4

8
7
6
5

1 2

1 2

1 2

1 2

121

2

1 2

1 2

1 2

1 2

1 2

1 2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1 2

1

2

7

1 8

14 CRITICAL

1

2

NO STUFF

1

2

1 2

1

2

1

2

1 2

1 2

1 2

1 2

1

2

1 2

1 2

1

2

CR-16

AUDIO_RESET_L

KL_IRDA_RXD_L

+3V_KL

+3V_KL_AVDD4

UIDE_INTRQ

SND_AMP_MUTE_L

SND_HP_MUTE_L

MODEM_HOOK_PU

COMM_RESET_L

MB_PWREN_L
CPU_PMONIN_L
KL_FW_PWREN

MB2_IDE_OE_PU
CSLOT_ADDR<13>
CSLOT_ADDR<14>
CSLOT_RESET
KL_ENET_RST_L

CPU1_INT_L_PU
AUDIO_RESET_L

AGP_ATI_INT_L

COMM_RING_DET_L

CSLOT_ADDR<15>

CBUS_INT_L

CSLOT_IRQ_L

CSLOT_REG_L

MB_IRQ_PU
PMU_KL_NMI

FW_C_LKON

EXTINT6_UNUSED_L

PMU_INT_L

SND_LIN_SENSE

CPU_SRESET_L

ENET_ENERGY_DET

KL_DEV_IN_L
SND_HP_SENSE
KL_DEV_ID<1>
NEC_PCI_INT_L

MPIC_CPU_INT_L

MPIC_SYNC_L

MPIC_CLK

MPIC_DATA_L

FW_PHY_PD
UATA_DET_PD
EIDE_DET_PU

CLK18M_KL_PLL

KL_WATCHDOG_L

KL_PLL_EN

KL_CREF2

PMU_PME_L

KL_PEND_PROC_INT

KL_PROC_SLEEP_REQ_L

KL_SUSPEND_REQ_L

CSLOT_ADDR<5>
CSLOT_ADDR<6>
CSLOT_ADDR<7>
CSLOT_ADDR<8>
CSLOT_ADDR<9>
CSLOT_ADDR<10>
CSLOT_ADDR<11>
CSLOT_ADDR<12>

USB_OC_CD_L

USB_PWREN_CD_L

USB_DCM

USB_DCP

USB_OC_AB_L

USB_PWREN_AB_L

USB_DAM

USB_DAP

COMM_TXD_L
COMM_RTS_L
COMM_DTR_L

KL_AGND

+3V_KL_OSC_SLEEP

KL_OSC_EN

KL_AGND

PMU_TO_KL

PMU_CLK

PMU_FROM_KL

PMU_REQ_L
PMU_ACK_L

KL_I2C_DATA

KL_I2C_CLK

JTAG_ASIC_TMS

JTAG_ASIC_TCK

JTAG_ENET_TDI

JTAG_KL_TDI

JTAG_ASIC_TRST_L

SND_TO_KL

CSLOT_IOWAIT_L

CSLOT_IORD_L

KL_CSLOT_IORD_L

CSLOT_IOWR_L

KL_CSLOT_IOWR_L

KL_SND_TO_AUDIO

KL_SND_SCLK

SND_CLKOUT

KL_SND_CLKOUT

SND_SYNC

KL_SND_SYNC

SND_SCLK

SND_TO_AUDIO

CLK18M_KL_UF

KL_CREF

+3V_KL_AVDD3

+3V_KL_AVDD2

KL_AGND

+3V_KL_AVDD1

KL_I2C_DATA

KL_I2C_CLK

PMU_REQ_L

COMM_RING_DET_L
KL_PLL_EN
AGP_ATI_INT_L
PMU_INT_L

BT_USB_DM

BT_USB_DP

USB_DDM

USB_DDP

MODEM_USB_DP

MODEM_USB_DM

USB_DBM

USB_DBP

BT_USB_DM

BT_USB_DP

HD_IOCHRDY

HD_DMARQ

HD_INTRQ

UIDE_DMACK_L
UIDE_DMARQ

UIDE_RST_L
UIDE_DIOW_L
UIDE_DIOR_L

UIDE_CS3FX_L

UIDE_CS1FX_L

UIDE_ADDR<2>

UIDE_ADDR<1>

UIDE_ADDR<0>

UIDE_DATA<15>

UIDE_DATA<14>

UIDE_DATA<13>

UIDE_DATA<12>

UIDE_DATA<11>

UIDE_DATA<8>
UIDE_DATA<9>
UIDE_DATA<10>

UIDE_DATA<7>

UIDE_DATA<6>

UIDE_DATA<3>
UIDE_DATA<4>
UIDE_DATA<5>

KL_DIR_245_SPN

UIDE_DATA<2>

UIDE_DATA<1>

UIDE_DATA<0>

KL_DEVCS4_SPN

KL_DEVCS3_SPN

CSLOT_CE2_L

CSLOT_CE1_L

PCI_AD<0>

EIDE0_DMARQ
EIDE0_INT

EIDE0_DMACK_L

EIDE0_RD_L

EIDE0_WR_L

EIDE0_RST_L

CLK33M_KL_PCI

COMM_SHUTDOWN

PCI_DEVSEL_L

PCI_STOP_L

PCI_IRDY_L

PCI_TRDY_L

PCI_FRAME_L

IO_RESET_L

KL_PCI_GNT_L

KL_PCI_REQ_L

PCI_PAR

PCI_CBE<3>

PCI_CBE<2>

PCI_CBE<1>

PCI_CBE<0>

PCI_AD<31>

PCI_AD<30>

PCI_AD<29>

PCI_AD<27>
PCI_AD<28>

PCI_AD<26>

PCI_AD<21>
PCI_AD<22>

PCI_AD<20>

PCI_AD<19>

PCI_AD<18>

PCI_AD<16>
PCI_AD<17>

PCI_AD<15>

PCI_AD<14>

PCI_AD<13>

PCI_AD<11>
PCI_AD<12>

PCI_AD<10>

PCI_AD<9>

PCI_AD<8>

PCI_AD<6>
PCI_AD<7>

PCI_AD<5>

PCI_AD<4>

PCI_AD<3>

PCI_AD<2>

PCI_AD<1>

EIDE_CS3FX_L

EIDE_CS1FX_L

EIDE_IOCHRDY

CSLOT_ADDR<4>

EIDE_ADDR<2>
CSLOT_ADDR<3>

EIDE_ADDR<1>

EIDE_ADDR<0>

EIDE_DATA<13>

EIDE_DATA<15>

EIDE_DATA<14>

EIDE_DATA<11>
EIDE_DATA<12>

EIDE_DATA<8>

EIDE_DATA<10>

EIDE_DATA<9>

EIDE_DATA<6>
EIDE_DATA<7>

EIDE_DATA<5>

EIDE_DATA<4>

EIDE_DATA<3>

EIDE_DATA<0>
EIDE_DATA<1>
EIDE_DATA<2>

EIDE1_INT_PD

PCI_AD<23>
PCI_AD<24>
PCI_AD<25>

EIDE1_DMAREQ_PD

KL_USB0_PCI_IDSEL
KL_USB1_PCI_IDSEL

KL_PCI_IDSEL

UIDE_IOCHRDY

COMM_TRXC

COMM_GPIO_L

COMM_RXD

KL_IRDA_LOF

KL_IRDA_FIR_L

MB_PWREN_L

PMU_KL_NMI

EIDE_DET_PU

+3V_KL_USB

KL_IRDA_RXD_L
KL_IRDA_FIR_L
KL_IRDA_LOF

USB_PWREN_CD_L
USB_OC_CD_L
USB_OC_AB_L
USB_PWREN_AB_L

KL_FW_PWREN

MB_IRQ_PU
EXTINT6_UNUSED_L

UATA_DET_PD
MODEM_HOOK_PU

MB2_IDE_OE_PU

CPU1_INT_L_PU

CBUS_INT_L
KL_DEV_IN_L
KL_DEV_ID<1>
NEC_PCI_INT_L

23<

9<

9<

9<

9<

40<>

40<>

40<>

40<>

40<>

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

34<

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

23<>

23<>

23<>

23<>

23<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

16<

17<

16<

16<

32<>

32<>

34<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

29<

42<>

42<>

42<>

25<

16<

34<>

42<>

16<

42<>

42<>

16<

29<>

16<

16<

41<>

41<>

34<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

30<

30<

30<

30<

43<>

16<

16<

32<>

32<>

42<>

42<>

42<>

43<>

25<>

25<>

34<>

32<>

19>

34<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

42<>

42<>

17<>

32<

32<

32<

32<

17<>

17<>

17<>

17<>

41<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

32<

32<

42<>

32<

42<>

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

17<>

34<>

18<>

17>

16<>

43<>

43<>

42<>

26<

26<

16<

32<>

16<

13<

16<

16<

32<>

32<>

32<>

28<

16<

16<

19>

32<>

32<>

18<>

32<>

32<>

16<

34<>

10<>

16<

34<>

27<

13<

28<>

16<

26<

16<

17>

13<

10<>

10<>

10<>

29<

16<

16<

40<>

34<>

10>

34<>

34<>

34<>

32<>

32<>

32<>

32<>

32<>

32<>

32<>

32<>

16<

42<>

42<>

16<

42<>

42<>

32<>

32<>

32<>

16<>

43<>

43<>

34<>

34<>

34<>

34<>

34<>

25<>

25<>

28<

10>

32<>

32<>

32<>

40<>

25<>

25<>

40<>

43<>

43<>

16<>

43<>

16<>

16<>

16>

16<>

16<>

16<>

30<>

30<>

42<>

42<>

32<>

32<>

42<>

42<>

30<>

30<>

32<>

32<>

32<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

32<>

32<>

9<>

42<>

42<>

42<>

42<>

42<>

42<>

40<>

32<>

9<>

9<>

9<>

9<>

34<>

9>

9<

9<>

9>

9>

9>

9>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

42<>

42<>

42<>

32<>

42<>

32<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

9<>

32<>

32<>

32<>

16<

16<

16<>

16<>

16<>

43<>

16<>

16<>

16>

16>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

402

R87

MF

1/16W

5%

22

+3V_MAIN

+3V_MAIN

603

R83

MF

1/16W

5%

0

402

MF

1/16W

5%

0

R88

SCK/TCLK

SOT/TOUT

IRO2

IRO1

A20S

IRI2

IRI1

LEGC

CRUN

SMI

PME

PCLK

INTC

INTB

INTA

PIN_EN

VCCRST

VBBRST

SERR

PERR

GNT

REQ

STOP

TRDY

IRDY

PAR

CBE3

CBE2

CBE1

CBE0

AD31

AD30

AD29

AD28

FRAME

IDSEL
DEVSEL

AD27

AD26

AD25

AD24

AD23

AD22

AD21

AD20

AD19

AD18

AD17

AD16

AD15

AD14

AD13

AD12

AD11

AD10

AD9

AD8

AD7

AD3
AD4
AD5
AD6

AD2

AD0
AD1

NTEST1
NTEST2

SIN/TIN

SELCLK

TEST

SRCLK
SRDTA
SRMOD

SMC

AMC

TEB

RREF

OCI1
OCI2
OCI3
OCI4
OCI5

PPON1
PPON2
PPON3
PPON4
PPON5

PC2

PC1

RSDM2

RSDP2

RSDM3

RSDP3

RSDM4

RSDP4

RSDM5

RSDP5

DP5

DM5

DP4

DM4

DP3

DM3

DP2

DM2

RSDP1

CLKSEL

RSDM1

XT1/SCLK

DM1
DP1

XT2

NC1
NC2
NC3
NC4
NC5
NC6

SELDAT

NANDTEST

AVSS(R)

AVSS

VSS

VDD_PCI

VDD

AVDD

U51

NEC_uPD720100_USB2

FBGA

402

MF

1/16W

1%

9.09K

R69

SM

L59

FERR-EMI-100-OHM

402

CERM

50V

5%

15pF

C157

Y6

SM-1

30.0000M

402

CERM

50V

5%

15pF

C156

402

R108

MF

1/16W

5%

100

SM

L58

FERR-EMI-100-OHM

402

1%

36

R79

402

1%

36

R78

402

1%

36

R89

402

1%

36

R90

402

MF

1/16W

5%

4.7K

R57

402

CERM

10V

20%

0.1uF

C111

402

CERM

10V

20%

0.1uF

C141

402

CERM

10V

20%

0.1uF

C127

402

CERM

10V

20%

0.1uF

C146

402

CERM

10V

20%

0.1uF

C135

402

CERM

10V

20%

0.1uF

C123

402

CERM

10V

20%

0.1uF

C110

402

CERM

10V

20%

0.1uF

C112

402

CERM

10V

20%

0.1uF

C122

402

CERM

10V

20%

0.1uF

C140

402

CERM

10V

20%

0.1uF

C136

805

CERM

6.3V

20%

10uF

C778

402

R56

MF

1/16W

1%

1.27K

805

CERM

6.3V

20%

10uF

C776

805

CERM

6.3V

20%

10uF

C775

402

CERM

10V

20%

0.1uF

C130

402

CERM

10V

20%

0.1uF

C128

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

17 46

E

051-6403

NC

(PCI_AD<27>)

NC
NC
NC
NC
NC
NC

NC

NC

OD

OD

OD

OD

OD

OD

IPD

OUT

OUT

OUT

OUT

IPD

IPD

IPD

IPD

IPD

IPD

IPD

IPD

IPD

NC

NC

NC

NC

NC

NC

NC

NC

NC

NC

NC

NC

NC

NC

NC

NC

NC

USB 2.0

OUT

(NANDTEST output)

(NEC_USB_DCP)

(NEC_USB_DDM)
(NEC_USB_DDP)

Low/Full/High Speed (External)

Low/Full/High Speed (External)

(NEC_USB_DCM)

NC

NC

NC

NC

NC

Low/Full Speed Only

Low/Full Speed Only

NEC_USB

2

1

NEC_USB

2

1

NEC_USB

21

NEC_USB

C14

C15

C2

A13

U14

T17

U12

T1

L1

D10

J14

K14

P9P8H4

C9

E15

G15C1L15

N15

R12

R9

B6

B16

C16

R16

T2

R2

B1

D8U5J1

B3

B15

T15

T3

A9

B17

G17

L17

D9

C13

J4

F15

M15

R15

R13

M3

F3

U9

B12

A10

J2

A14

U11

J3

U6

T6

R6

D3

C12

D1
C3

K1

T14

T16

R10

R14

C17

E17

L16

N16

T12

E16

F17

N17

P16

H15

A6

R11

T10

U10

P10

R7

C10

A7

K4

B9

J16

J17

K3 U7

R8

U8

T8

T7

B14

A16

D17

J15

A2

R17

U16

U15

U3

A15

B13

A11

C11

B11

A12

H3

B8

C8

A8

B2

C7

H2

T13

D16

F16

M17

P15

U13

D15

G16

M16

P17

H1

R5

T11

A3

G1

K2

P1

H17

H16

K16

K17

H14

K15

T9

N2

P3

P2

R1

U2

T4

B7

C6

U4

A5

C5

B5

C4

A4

B4

D2

E2

E3

E1

R3

F2

F1

G2

G3

L3

M1

L2

M2

N1

N3

R4

T5

B10

NEC_USB

21

NEC_USB

21

NEC_USB

2

1

CRITICAL

NEC_USB

21

NEC_USB

2

1

NEC_USB

2

1

NEC_USB

21

NEC_USB

21

NEC_USB

21

NEC_USB

21

NEC_USB

21

NEC_USB

21

NEC_USB

2

1

NEC_USB

2

1

NEC_USB

2

1

NEC_USB

2

1

NEC_USB

2

1

NEC_USB

2

1

NEC_USB

2

1

NEC_USB

2

1

NEC_USB

2

1

NEC_USB

2

1

NEC_USB

2

1

NEC_USB

NEC_USB

2

1

NEC_USBNEC_USBNEC_USB

2

1

NEC_USB

2

1

CR-17

NEC_AVSS

NEC_AVDD

NEC_OCI_UNUSED

NEC_OCI<4>

NEC_OCI<3>

NEC_PPON1_TP

NEC_PPON<3>
NEC_PPON<4>

NEC_RSDDM

NEC_USB_DDM

NEC_RSDDP

NEC_USB_DDP

NEC_RSDCP

NEC_USB_DCP

NEC_RSDCM

NEC_USB_DCM

NEC_XT2

NEC_NANDTEST_TP

NEC_AVSS

PMU_PME_L

MAIN_RESET_L

NEC_SMI_L_SPN

NEC_PME_L
MAIN_RESET_L

IO_RESET_L

CLK33M_NEC

PCI_SERR_L

PCI_PERR_L

NEC_PCI_GNT_L

NEC_PCI_REQ_L

PCI_DEVSEL_L

PCI_STOP_L

PCI_TRDY_L

PCI_IRDY_L

PCI_FRAME_L

PCI_PAR

PCI_CBE<3>

PCI_CBE<2>

PCI_CBE<1>

PCI_CBE<0>

PCI_AD<31>

PCI_AD<30>

PCI_AD<28>
PCI_AD<29>

PCI_AD<25>
PCI_AD<26>

PCI_AD<24>

PCI_AD<23>

PCI_AD<20>

PCI_AD<22>

PCI_AD<21>

PCI_AD<19>

PCI_AD<18>

PCI_AD<17>

PCI_AD<16>

PCI_AD<15>

PCI_AD<14>

PCI_AD<13>

PCI_AD<12>

PCI_AD<11>

PCI_AD<10>

PCI_AD<9>

PCI_AD<8>

PCI_AD<7>

PCI_AD<6>

PCI_AD<5>

PCI_AD<2>
PCI_AD<3>
PCI_AD<4>

PCI_AD<0>
PCI_AD<1>

NEC_RREF

NEC_IDSEL

NEC_PCI_INT_L

NEC_CRUN_L

PCI_AD<27>

NEC_XT1

NEC_XT2_R

+3V_NEC_VDD

NEC_AVSS

NEC_PPON2_TP

NEC_PPON5_TP

+3V_NEC_VDD

9<

9<

9<

9<

9<

40<>

40<>

40<>

40<>

40<>

40<>

40<>

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

23<>

23<>

23<>

23<>

23<>

23<>

23<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

23<>

34<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

30<

30<

30<

30<

16>

34<>

34<>

18<

18<

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<

16<>

43<>

43<>

30<

30<

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

43<>

10>

9<>

9<>

34<>

40<>

18>

18<>

9>

9<

9<>

9<>

9<>

9<>

9<>

9<>

9>

9>

9>

9>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

16<>

9<>

43<>

43<>

43<>

805

CERM

16V

N20P80%

1.0uF

C88

+3V_MAIN +5V_MAIN

+3V_MAIN

805

CERM

10V

20%

1uF

C147

SM

M-ST-55055

J11

402

CERM

10V

20%

0.1uF

C115

805

CERM

10V

N20P80%

4.7uF

C87

805

CERM

10V

N20P80%

4.7uF

C779

1206

CERM

16V

N20P80%

3.3uF

C116

+3V_MAIN

402

MF

1/16W

1%

10K

R51

402

MF

1/16W

1%

10K

R52

402

MF

1/16W

1%

10K

R72

402

MF

1/16W

5%

39K

R591

D15__CAD8

D10_CAD31

D14_RSVD

D13_CAD6

D12_CAD4

D11_CAD2

D4_CAD1

D3_CAD0

D2_RSVD

D1_CAD29

D0_CAD27

D7_CAD7

D8_CAD28

D5_CAD3
D6_CAD5

D9_CAD30

A25_CAD19

A11_CAD12

A12_CC_BE2

A14_CPERR
A15_CIRDY

A17_CAD16

A20_CSTOP

A21_CDEVSEL

A22_CTRDY

A23_CFRAME

A24_CAD17

A8_CC_BE1

A19_CBLOCK

A18_RSVD

A16_CCLK

A10_CAD9

A13_CPAR

A6_CAD20
A7_CAD18

A9_CAD14

A5_CAD21

BVD1_STSCHG_RI_CS

BVD2_SPKR_CAUDIO

INPACK_CREQ

RDY_IREQ_CINT

WAIT_CSERR

CE1_CC_BE0

CE2_CAD10

REG_CC_BE3

WP_IOIS16_CCLKRU

RESET_CRST

A0_CAD26
A1_CAD25
A2_CAD24
A3_CAD23
A4_CAD22

OE_CAD11

VS1_CVS1
VS2_CVS2

WE_CGNT

IOWR_CAD15

IORD_CAD13

CD2_CCD2

VPPD1

VPPD0

VCCD1

VCCD0

CD1_CCD1

VCCCB2

VCCCB1

AD31

AD28
AD29
AD30

AD27

AD20
AD21
AD22
AD23
AD24
AD25
AD26

AD19

AD18

AD17

AD10
AD11
AD12
AD13
AD14
AD15
AD16

AD7
AD8
AD9

AD0

VCCI

AD1
AD2
AD3
AD4
AD5
AD6

VCCP2

VCCP1

MFUNC3

MFUNC6

MFUNC5

MFUNC4

GRST

SPKROUT

SUSPEND

MFUNC1
MFUNC2

GNT
PCLK

MFUNC0_INTA

RI_OUT_PME

TRDY

STOP

FRAME

IRDY

SERR

IDSEL

PERR

DEVSEL

REQ

PRST

PAR

C_BE3

C_BE2

C_BE1

C_BE0

GND

VCC

PCI1410AGGU

U52

BGA

SM

RP48

25V

1/32W

5%

10K

402

R104

MF

1/16W

1%

10K

402

CERM

10V

20%

0.1uF

C148

402

CERM

50V

20%

0.001uF

C103

TPS2211

OC

AVPP

AVCC2

AVCC1

AVCC0

GND

SHTDWN

VCCD0
VCCD1
VPPD0
VPPD1

V_5_2

V_5_1

V_3_2

V_3_1

V_12

SSOI

U54

402

CERM

10V

20%

0.1uF

C138

402

CERM

50V

20%

0.001uF

C152

402

CERM

10V

20%

0.1uF

C125

402

CERM

50V

20%

0.001uF

C107

402

CERM

10V

20%

0.1uF

C137

402

CERM

50V

20%

0.001uF

C118

402

CERM

10V

20%

0.1uF

C108

402

CERM

50V

20%

0.001uF

C121

402

CERM

10V

20%

0.1uF

C106

402

CERM

50V

20%

0.001uF

C129

402

CERM

10V

20%

0.1uF

C104

402

CERM

50V

20%

0.001uF

C142

402

MF

1/16W

5%

47

R55

402

CERM

10V

20%

0.1uF

C117

402

CERM

50V

20%

0.001uF

C105

402

CERM

10V

20%

0.1uF

C114

402

R61

MF

1/16W

5%

22

402

MF

1/16W

5%

47

R62

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

18 46

E

051-6403

NC

NC

NC

C88 AND C147 USED AS GLITCH FILTERS

PCI1410 PULL-UPS

PC CARD/CARDBUS CONNECTOR

CARDBUS

PC CARD/CARDBUS PULL-UPS

NO STUFF

2

1

NO STUFF

2

1

CRITICAL

80
79
78
77
76
75
74
73
72
71
70
69
68
67
66
65
64
63
62
61
60
59
58
57
56
55
54
53
52
51
50
49
48
47
46
45
44
43
42
41 40

39

38

37

36

35

34

33

32

31

30

29

28

27

26

25

24

23

22

21

20

19

18

17

16

15

14

13

12

11

10

9

8

7

6

5

4

3

2

1

2

1

2

1

2

1

2

1

21

21

21

21

D5

C11

A5

D9

C6

M12

N12

N4

G1

L9

M13

N13

A7

G13

B4C8

D12H11

L6K2F3

K3

L11

L2

M9

M1

L8

B9

A1

B7

D6

G4

L3

H1

M2

G10

M11

N11

L10

N10

K9

N9

K8

K1

F10

F13

B8

F4

M10

B1

B6

C10F12K11

M8L4H2D3

J4

L1

C3

A3

H10

J12

J10

K12

L13

A2

B3

H12

J13

J11

K13

K10

B2

C4

E1

J3

N1

N5

G11

H13

A4

L12

B5

C5

L5

M5

K6

M6

N6

M7

C2

C1

N7

D4

D2

D1

E4

E3

E2

F2

F1

G2

G3

L7

H3

H4

J1

J2

N2

M3

N3

K4

M4

K5

K7

N8

E13

E11

B10

C9

A9

D8

A8

C7

A10

D10

B11

A13

B13

C12

D7

D11

E10

E12

B12

A12

C13

D13

A11

F11

G12

A6

9

8

7

6

4

3

2

1

10

5

2

1

2

1

2

1

6

5

4

3

9

14

15

2

1

16

87

10

13

12

11

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

21

2

1

2

1

2

1

2

1

21

CR-18

CBUS_WP_L

+VCC_CBUS_SW

CBUS_PCI_RESET_L

CBUS_ADDR_16_UF

CBUS_VS2

CBUS_VS1

+VCC_CBUS_SW

CBUS_DATA<9>

CBUS_DATA<8>

CBUS_DATA<7>

CBUS_DATA<6>

CBUS_DATA<5>

CBUS_DATA<4>

CBUS_DATA<3>

CBUS_DATA<2>

CBUS_DATA<1>

CBUS_DATA<15>

CBUS_DATA<14>

CBUS_DATA<13>

CBUS_DATA<12>

CBUS_DATA<11>

CBUS_DATA<10>

CBUS_DATA<0>

CBUS_ADDR<9>

CBUS_ADDR<7>

CBUS_ADDR<6>

CBUS_ADDR<5>

CBUS_ADDR<4>

CBUS_ADDR<3>

CBUS_ADDR<2>

CBUS_ADDR<25>

CBUS_ADDR<24>

CBUS_ADDR<1>

CBUS_ADDR<18>

CBUS_ADDR<17>

CBUS_ADDR<13>

CBUS_ADDR<11>

CBUS_ADDR<10>

CBUS_ADDR<0>

CBUS_VPPD1

CBUS_VPPD0

CBUS_VCCD0_L
CBUS_VCCD1_L

CBUS_DET_1_L
CBUS_DET_2_L
CBUS_IORD_L
CBUS_IOWR_L
CBUS_OE_L
CBUS_CE1_L

CBUS_WE_L

CBUS_RESET_L

CBUS_READY

CBUS_REG_L
CBUS_BVD1_L
CBUS_BVD2_L
CBUS_WP_L
CBUS_CE2_L
CBUS_INPACK_L
CBUS_WAIT_L

CBUS_ADDR<8>

CBUS_ADDR<12>

CBUS_ADDR<14>
CBUS_ADDR<15>

CBUS_ADDR<19>
CBUS_ADDR<20>
CBUS_ADDR<21>
CBUS_ADDR<22>
CBUS_ADDR<23>

PCI_SERR_L

CBUS_SUSPEND_PU

PCI_PERR_L

CBUS_OE_L

CBUS_ADDR<10>

CBUS_CE1_L

CBUS_DATA<7>

CBUS_DATA<6>

CBUS_DATA<5>

CBUS_DATA<4>

CBUS_DATA<3>

CBUS_DATA<15>

CBUS_DATA<14>

CBUS_DATA<13>

CBUS_DATA<12>

CBUS_DATA<11>

CBUS_CE2_L

CBUS_ADDR<20>

CBUS_ADDR<19>

CBUS_ADDR<18>

CBUS_ADDR<17>

CBUS_IOWR_L

CBUS_IORD_L

CBUS_VS1

CBUS_ADDR<21>

CBUS_RESET_L

CBUS_VS2

CBUS_ADDR<25>

CBUS_ADDR<24>

CBUS_ADDR<23>

CBUS_ADDR<22>

CBUS_DATA<10>

CBUS_DATA<9>

CBUS_DATA<8>

CBUS_BVD1_L

CBUS_BVD2_L

CBUS_REG_L

CBUS_INPACK_L

CBUS_WAIT_L

CBUS_DATA<0>

CBUS_WP_L

CBUS_DATA<1>
CBUS_DATA<2>

CBUS_ADDR<2>

CBUS_ADDR<3>

CBUS_ADDR<1>
CBUS_ADDR<0>

CBUS_ADDR<7>
CBUS_ADDR<6>
CBUS_ADDR<5>
CBUS_ADDR<4>

CBUS_ADDR<16>

+VPP_CBUS_SW

CBUS_ADDR<15>
CBUS_ADDR<12>

CBUS_ADDR<14>
CBUS_WE_L

+VCC_CBUS_SW

CBUS_READY

CBUS_ADDR<11>

CBUS_ADDR<8>

CBUS_ADDR<9>

CBUS_ADDR<13>

CBUS_DET_1_L

+VPP_CBUS_SW

+VCC_CBUS_SW

CBUS_DET_2_L

CBUS_ADDR<16>

CBUS_PCI_IDSEL

IO_RESET_L

PCI_PERR_L

PCI_SERR_L

PCI_FRAME_L

PCI_IRDY_L

PCI_PAR

CBUS_MFUNC1_PD
CBUS_MFUNC2_PD
CBUS_MFUNC3_PD
CBUS_MFUNC4_PD
CBUS_MFUNC5_PD
CBUS_MFUNC6_PD

CBUS_SUSPEND_PU

CBUS_INT_L

CBUS_PCI_GNT_L

CBUS_PCI_REQ_L

PCI_DEVSEL_L

PCI_TRDY_L

PCI_STOP_L

CLK33M_CBUS

PCI_AD<26>

PCI_AD<0>
PCI_AD<1>

PCI_CBE<3>

PCI_CBE<2>

PCI_CBE<1>

PCI_CBE<0>

PCI_AD<10>
PCI_AD<11>
PCI_AD<12>
PCI_AD<13>
PCI_AD<14>
PCI_AD<15>
PCI_AD<16>
PCI_AD<17>
PCI_AD<18>
PCI_AD<19>

PCI_AD<2>

PCI_AD<20>
PCI_AD<21>
PCI_AD<22>
PCI_AD<23>
PCI_AD<24>
PCI_AD<25>

PCI_AD<9>

PCI_AD<8>

PCI_AD<7>

PCI_AD<6>

PCI_AD<5>

PCI_AD<4>

PCI_AD<31>

PCI_AD<30>

PCI_AD<3>

PCI_AD<29>

PCI_AD<28>

PCI_AD<27>

+VPP_CBUS_SW

TPS2211_SHDN_L_PU

CBUS_MFUNC6_PD

CBUS_MFUNC5_PD

CBUS_MFUNC4_PD

CBUS_MFUNC1_PD
CBUS_MFUNC2_PD
CBUS_MFUNC3_PD

9<

9<

9<

9<

9<

40<>

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

23<

40<>

40<>

23<

23<

23<

23<

23<

23<

40<>

40<>

23<

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

23<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

23<>

23<>

40<>

40<>

40<>

40<>

40<>

40<>

23<>

23<>

40<>

23<>

23<>

23<>

18<

18<

18<

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

43<>

43<>

18>

18<>

43<>

43<>

43<>

43<>

18<

18<

16<>

16<>

16<>

16<

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

43<>

18<> 18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

17>

17<>

18>

18>

18>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18>

18>

18>

18>

18>

18>

18>

18<>

18>

18>

18<>

18>

18>

18>

18>

18<>

18<>

18<>

18<

18<

18>

18<

18<

18<>

18<

18<>

18<>

18>

18>

18>

18>

18>

18>

18>

18>

18<

18<>

18>

18>

18>

18>

18<>

18<

18>

18>

18>

18>

18<

18<>

18<>

18<

18<>

34<>

17<>

17>

9<>

9<>

9<>

18<

18<

18<

18<

18<

18<

16<>

9>

9<

9<>

9<>

9<>

40<>

9<>

9<>

9<>

9>

9>

9>

9>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

402

MF

1/16W

5%

47

R403

402

MF

1/16W

5%

1K

R402

402

R223

MF

1/16W

1%

4.99K

402

R222

MF

1/16W

1%

4.99K

402

R210

MF

1/16W

1%

82.5

402

R211

MF

1/16W

1%

82.5

C267

470pF

402

CERM

50V

10%

C268

470pF

402

CERM

50V

10%

402

R162

MF

1/16W

1%

10K

402

CERM

10V

20%

0.1uF

C213

402

R161

MF

1/16W

1%

10K

402

MF

1/16W

5%

10K

R256

402

MF

1/16W

1%

45.3

R208

402

MF

1/16W

5%

10K

R404

402

MF

1/16W

5%

1K

R384

+1_5V_MAIN

+3V_MAIN

402

MF

1/16W

5%

10K

R370

402

MF

1/16W

5%

10K

R405

402

MF

1/16W

5%

4.7K

R152

402

R151

MF

1/16W

1%

45.3

402

R143

MF

1/16W

1%

121

402

R150

MF

1/16W

1%

121

402

R687

MF

1/16W

5%

10K

402

R703

MF

1/16W

5%

470K

402

MF

1/16W

5%

0

R227

402

MF

1/16W

5%

0

R235

402

MF

1/16W

5%

0

R259

DMINUS

DPLUS

QSB1

QSB0

(1 OF 6)

RAGE_MOBILITY

AGP_BUSYB

AD_STBB1

AD_STBB0

AD_STB0

AGPTEST

AGPREF

AD_STB1

ST0
ST1
ST2

SBA5

SBA6

SBA2

SBA3

SBA4

SB_STBB

STP_AGPB

RBFB

SB_STB

SBA1
SBA0

AD30

AD31

AD29
AD28
AD27
AD26
AD25
AD24

AD17

AD14

AD15

AD23
AD22

AD19

AD20

AD21

AD16

AD18

AD6
AD5
AD4

AD13

AD11

AD12

AD10
AD9
AD8
AD7

AD3

CBEB1

CBEB2

CBEB3

AD0

AD1

AD2

CBEB0
PCICLK

FRAMEB

PAR

IRDYB
TRDYB

WBF/SERRB

RSTB

INTAB

GNTB

REQB

DEVSELB

STOPB

QSB2
QSB3
QSB4
QSB5
QSB6

WEBB

CSBB1

CSBB0

CASBB

RASBB

QSB7

CKEB

VREF

QSA6

QSA5

QSA4

QSA3

QSA2

QSA1

QSA0

CSAB1

CSAB0

WEAB

CASAB

RASAB

QSA7

CKEA

CLKB0

CLKBB0

CLKBB1
CLKBFB

MEMTEST

CLKB1

CLKA0
CLKAB0

CLKAB1
CLKAFB

MEMVMODE1

MEMVMODE0

CLKA1

STEREO_SYNC

SBA7

BGA

32MB

M9-CSP32A13

U4

RAGE_MOBILITY

DQA20

DQA22

DQA21

DQA19

DQA18

DQA14
DQA15
DQA16

DQA11

DQA13

DQA12

DQA17

DQA8
DQA9
DQA10

DQA6
DQA7

DQA1

DQA0

DQA4

DQA3

DQA2

DQA5

AA13

AA12

AA8

AA7

AA6

AA5

AA4

AA3

AA2

AA9
AA10
AA11

AA1

AA0

DQB21

DQB20

DQB23

DQB22

DQB19

DQB18

DQB14
DQB15
DQB16
DQB17

DQB11

DQB13

DQB12

DQB8
DQB9

DQB10

DQB6
DQB7

DQB1

DQB0

DQB4

DQB3

DQB2

DQB5

AB13

AB12

AB8

AB7

AB6

AB5

AB4

AB3

AB2

AB9
AB10
AB11

AB1

AB0

DQA29
DQA30

DQA28

DQA25

DQA24

DQA23

DQA27

DQA26

DQB29
DQB30

DQB28

DQB27

DQB25

DQB24

DQB26

DQMAB5
DQMAB6
DQMAB7

DQA60

DQA63
DQMAB0

DQMAB1
DQMAB2
DQMAB3
DQMAB4

DQA61
DQA62

DQA59

DQA52

DQA51

DQA50

DQA49

DQA55

DQA54

DQA53

DQA58

DQA57

DQA56

DQA41

DQA40

DQA39

DQA46

DQA45

DQA44

DQA43

DQA42

DQA48

DQA47

DQA36
DQA37

DQA33

DQA32

DQA31

DQA35

DQA34

DQA38

DQMBB5
DQMBB6
DQMBB7

DQB60

DQB63

DQMBB0
DQMBB1
DQMBB2
DQMBB3
DQMBB4

DQB61
DQB62

DQB59

DQB52

DQB51

DQB50

DQB49

DQB55

DQB54

DQB53

DQB58

DQB57

DQB56

DQB41

DQB40

DQB39

DQB46

DQB45

DQB44

DQB43

DQB42

DQB48

DQB47

DQB36
DQB37

DQB33

DQB32

DQB31

DQB35

DQB34

DQB38

(2 OF 6)

U4

M9-CSP32A13

32MB

BGA

(6 OF 6)

RAGE_MOBILITY

VSS

BGA

32MB

M9-CSP32A13

U4

TABLE_5_ITEM

CRITICAL ATI_M9338S0090

1

IC,MOBILTY_M9_CSP32,768,BGA

U4

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

19 46

E

051-6403

CRITICAL BOM OPTION

TABLE_5_HEAD

PART#

DESCRIPTION

QTY

REFERENCE DESIGNATOR(S)

TABLE_5_ITEM

CRITICAL ATI_M7338S0033

1

IC,MOBILTY_M7,GRPHCS,696,BGA

U4

M9 EXTRA GND

NC

NC

NC
NC

NC

NC

NC

NC

NC

NC

NC

NC

NC

NC

NC

NC

NC

NC

NC

NC

NC

NC

NC
NC

NC

NC

NC
NC

NC

NC

NC

NC

NC

NC
NC

NC

NC
NC
NC
NC

NC

NC

NC
NC

NC

NC

NC
NC
NC

NC

NC

NC

NC

NC

NC

NC

NC

NC
NC
NC
NC

NC

NC

NC

NC

NC

NC

NC
NC

NC

NC

NC

NC

NC

NC

NC

NC

NC

NC

NC
NC

NC

NC
NC

NC

NC

(4Mx32 only)

pins see valid logic levels prior to reset.

during startup. R402 << R687 to ensure all

prevent ATI from contending with the PMU

to turn off AGP differential drivers.
However, I/O pins can be (and are) driven
immediately after power up. These resistors

NC

NC

NC

NC

NC
NC
NC
NC
NC

NC
NC
NC
NC
NC
NC

NC

MOBILITY AGP & MEM

UNI-N AGP I/O REFERENCE

(PLACE CLOSE TO ATI AGP BALLS)

SETUP FOR 2.5V MEMORY I/O

SUS_STAT_L can be driven low in sleep

ATI PULL-UPS

NC

EXTERNAL MEMORY

M7-CSP16

ATI DDR I/O REFERENCE

21

21

2

1

2

1

2

1

2

1

21

21

2

1

2

1

2

1

21

12

NO STUFF

21

12

21

NO_ATI_SS

21

21

2

1

NO STUFF

2

1

NO STUFF

2

1

2

1

ATI_SS

2

1

ATI_M9

21

ATI_M7

21

21

OMIT

R4

A18

AE27

D8

T28

AG29

T27

AJ28

AE29

AF28

AF30

AD28

AC29

AC28
AB29
AC27
AC30
AD27
AD30
AE28
AD29

AH30

AF29

AE30

P4

B18

AC4

AB2

V4

U2

E2

G4

A3

C5

A10

C11

A15

C16

C26

B29

G27

G29

AG30

R28

B6

B7 C8

T30

AH29

AF27

U27

AC10
AC11

T29

P3

P2

B19

C19

M2

L1

L2

K1

K2

A21

A22

B22

A23

B23

P1

D19

W28
U29
R30
N27

R3

A19

AG28

K29

K30

Y29

W29

M28

N29

N28
N30
M30
M27
M29
L28

AB30
AB27

L30

AA29
AB28
AA30
AA27

Y30

AA28

W30
W27
V30
V28

L27

V29
V27
U30
U28
R27
R29
P28
P30
P27
P29

L29
K28

OMIT

AC3

AB1

V3

U1

E1

G3

B3

D5

B10

D11

B15

D16

D26

B30

G28

G30

B5

A5

D3

AE4

AE3

AD4

AD3

C3

AB4

AB3

AA4

AA3

AD2

AD1

AC2

AC1

AA2

AA1

D4

Y2

Y1

Y4

Y3

W4

W3

U4

U3

T4

T3

C4

W2

W1

V2

V1

T2

T1

R2

R1

G2

G1

D6

F2

F1

D2

D1

C2

C1

J4

J3

H4

H3

C6

F4

F3

E3

E4

B1

A1

B2

A2

B4

A4

D7

C7

J27

J28

E29

A8

B8

A9

B9

E30

A11

B11

A12

B12

C9

D9

C10

D10

C12

D12

F29

C13

D13

A13

B13

A14

B14

A16

B16

A17

B17

F30

C14

D14

C15

D15

C17

D17

C18

D18

C24

D24

H29

C25

D25

C27

D27

C28

D28

B28

A28

A29

A30

H30

C29

C30

D29

D30

E27

E28

F27

F28

H27

H28

J29

J30

M4

L3

M3

L4

K3

K4

J1

J2

N3

N4

N1

N2

H1

H2

D22

C20

D20

C21

D21

C22

A25

B25

B27

A27

D23

C23

A26

B26

OMIT

AD24

AD23

AD22

AD21

AD20

AD19

AD18

AD17

AD16

AD15

AD14

AD13

AD12

AD11

AD10

AD9

AD8

AD7

AC24

AC23

AC8

AC7

AB24

AB7

AA24

AA7

Y24

Y7

W24

W7

V24

V7

U24

U7

T24

T7

R24

R7

P24

P7

N24

N7

M24

M7

L24

L7

K24

K7

J24

J7

H24

H23

H8

H7

G24

G23

G22

G21

G20

G19

G18

G17

G16

G15

G14

G13

G12

G11

G10

G9

G8

G7

CR-19

ATI_SSIN_PU

ATI_AUXWIN_PU

AGP_AD<31>

AGP_AD_STB<0>

AGP_SUS_STAT_L_PU

AGP_AD_STB_L<0>

AGP_AD_STB<1>

AGP_BUSY_L_PU

AGP_AD_STB_L<1>

ATI_AGP_TEST

ATI_AGP_VREF

AGP_ST<0>
AGP_ST<1>
AGP_ST<2>

AGP_SBA<6>
AGP_SBA<5>

AGP_SBA<2>

AGP_SBA<4>
AGP_SBA<3>

AGP_SBA<0>

AGP_SBA<1>

AGP_RBF_L

AGP_SB_STB
AGP_SB_STB_L

AGP_AD<30>
AGP_AD<29>
AGP_AD<28>
AGP_AD<27>

AGP_AD<24>

AGP_AD<25>

AGP_AD<26>

AGP_AD<22>

AGP_AD<23>

AGP_AD<21>
AGP_AD<20>
AGP_AD<19>
AGP_AD<18>
AGP_AD<17>
AGP_AD<16>

AGP_AD<14>

AGP_AD<15>

AGP_AD<13>
AGP_AD<12>
AGP_AD<11>

AGP_AD<9>

AGP_AD<10>

AGP_AD<8>
AGP_AD<7>
AGP_AD<6>
AGP_AD<5>
AGP_AD<4>

AGP_AD<2>

AGP_AD<3>

AGP_AD<1>

AGP_CBE<3>

AGP_AD<0>

AGP_CBE<1>

AGP_CBE<2>

CLK66M_AGP_ATI

AGP_CBE<0>

AGP_FRAME_L

AGP_TRDY_L

AGP_IRDY_L

AGP_DEVSEL_L

AGP_STOP_L

AGP_PAR

AGP_GNT_L

AGP_REQ_L

AGP_ATI_INT_L
AGP_ATI_RESET_L

ATI_VMEM_QS<1>

ATI_VMEM_QS<0>

ATI_VMEM_QS<2>
ATI_VMEM_QS<3>

ATI_VMEM_QS<6>

ATI_VMEM_QS<5>

ATI_VMEM_QS<4>

ATI_VMEM_QS<7>

ATI_VMEM_RASB_L

ATI_VMEM_WE_L

ATI_VMEM_CASB_L

ATI_VMEM_CSB_L

ATI_VMEM_CKEB

ATI_VMEM_CLKB<0>
ATI_VMEM_CLKB_L<0>

ATI_VMEM_CLKB<1>
ATI_VMEM_CLKB_L<1>

ATI_MEMTEST

ATI_CLKA<0>
ATI_CLKA_L<0>

ATI_CLKA_L<1>

ATI_CLKA<1>

ATI_MEMVMODE<0>
ATI_MEMVMODE<1>

AGP_SUS_STAT_L_PU

AGP_SBA<7>

AGP_WBF_L

AGP_WBF_F

+2_5V_ATI_VDDR

IO_RESET_L

ATI_SS_PU

ATI_TESTEN

ATI_AGP_TEST

AGP_BUSY_L_PU

AGP_STP_L

SYSTEM_CLK_EN

+1_8V_ATI_VDDC18

UNIN_AGP_VREF_H

UNIN_AGP_VREF_L

UNIN_AGP_VREF

ATI_MEMVMODE<0>

ATI_MEMVMODE<1>

ATI_CLKA<0> ATI_CLKA<1>

ATI_CLKA_L<0> ATI_CLKA_L<1>

ATI_VMEM_DATA<32>

ATI_VMEM_DATA<31>

ATI_VMEM_DATA<33>

ATI_VMEM_DATA<35>

ATI_VMEM_DATA<34>

ATI_VMEM_DATA<37>

ATI_VMEM_DATA<36>

ATI_VMEM_DATA<38>

ATI_VMEM_DATA<40>

ATI_VMEM_DATA<39>

ATI_VMEM_DATA<41>
ATI_VMEM_DATA<42>
ATI_VMEM_DATA<43>
ATI_VMEM_DATA<44>
ATI_VMEM_DATA<45>
ATI_VMEM_DATA<46>

ATI_VMEM_DATA<48>

ATI_VMEM_DATA<47>

ATI_VMEM_DATA<50>

ATI_VMEM_DATA<49>

ATI_VMEM_DATA<51>

ATI_VMEM_DATA<53>

ATI_VMEM_DATA<52>

ATI_VMEM_DATA<55>

ATI_VMEM_DATA<54>

ATI_VMEM_DATA<56>

ATI_VMEM_DATA<58>

ATI_VMEM_DATA<57>

ATI_VMEM_DATA<59>
ATI_VMEM_DATA<60>
ATI_VMEM_DATA<61>
ATI_VMEM_DATA<62>
ATI_VMEM_DATA<63>

ATI_VMEM_DQMB<0>
ATI_VMEM_DQMB<1>
ATI_VMEM_DQMB<2>

ATI_VMEM_DQMB<4>

ATI_VMEM_DQMB<3>

ATI_VMEM_DQMB<5>
ATI_VMEM_DQMB<6>
ATI_VMEM_DQMB<7>

ATI_VMEM_DATA<25>

ATI_VMEM_DATA<24>

ATI_VMEM_DATA<26>
ATI_VMEM_DATA<27>

ATI_VMEM_DATA<29>

ATI_VMEM_DATA<28>

ATI_VMEM_DATA<30>

ATI_VMEM_ADDR<0>
ATI_VMEM_ADDR<1>
ATI_VMEM_ADDR<2>
ATI_VMEM_ADDR<3>
ATI_VMEM_ADDR<4>

ATI_VMEM_ADDR<6>

ATI_VMEM_ADDR<5>

ATI_VMEM_ADDR<7>
ATI_VMEM_ADDR<8>
ATI_VMEM_ADDR<9>
ATI_VMEM_ADDR<10>
ATI_VMEM_ADDR<11>
ATI_VMEM_ADDR<12>
ATI_VMEM_ADDR<13>

ATI_VMEM_DATA<0>

ATI_VMEM_DATA<2>

ATI_VMEM_DATA<1>

ATI_VMEM_DATA<3>
ATI_VMEM_DATA<4>
ATI_VMEM_DATA<5>

ATI_VMEM_DATA<7>

ATI_VMEM_DATA<6>

ATI_VMEM_DATA<9>

ATI_VMEM_DATA<8>

ATI_VMEM_DATA<10>

ATI_VMEM_DATA<12>

ATI_VMEM_DATA<11>

ATI_VMEM_DATA<13>
ATI_VMEM_DATA<14>
ATI_VMEM_DATA<15>

ATI_VMEM_DATA<17>

ATI_VMEM_DATA<16>

ATI_VMEM_DATA<20>

ATI_VMEM_DATA<18>
ATI_VMEM_DATA<19>

ATI_VMEM_DATA<21>
ATI_VMEM_DATA<22>
ATI_VMEM_DATA<23>

+1_25V_ATI_VREF

8<

8<

8<

8<

8<

8<

8<

8<

8<

8<

8<

40<> 40<>

40<>

40<>

40<>

8<

8<

8<

8<

8<

8<

8<

8<

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

8<

16<

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

22<

22<

22<

22<

22<

22<

22<

22<

22<

8<

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

22<

22<

22<

22<

22<

22<

22<

22<

41<>

41<>

41<>

41<>

41<>

41<>

41<>

22<

22<

22<

22<

22<

22<

22<

22<

22<

22<

22<

41<>

22<

22<

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

20<>

8<> 8<>

8<>

8<>

19<

8<>

8>

8>

8>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

8<>

8<>

8<>

8<>

8<>

8<>

8<>

8<>

8<>

8<>

8<>

8<>

8<>

8<>

8<>

8<>

8<>

8<>

8<>

8<>

8<>

8<>

8<>

8<>

8<>

8<>

8<>

8<>

8<>

8<>

8<>

8<>

8<>

8<>

8<>

8<>

40<>

8<>

8<>

8<>

8<>

8<>

8<>

8<>

8>

40<>

16<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

41<>

41<>

41<>

41<>

41<>

42<>

42<>

42<>

42<>

19<

19<

19<

19<

40<>

43<>

34<>

19>

34<>

19<> 19<>

19<> 19<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

22<>

41<>

41<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

22<>

43<>

32

U28

SM

74AHC1G32

402

CERM

10V

20%

0.1uF

C432

+5V_MAIN

C20

330uF

20%

6.3V
TANT

SMD

C52

330uF

20%

6.3V
TANT
SMD

805

CERM

10V

20%

1uF

C567

402

CERM

10V

20%

0.1uF

C566

1206

CERM

6.3V

20%

10uF

C481

402

CERM

10V

20%

0.1uF

C473

402

MF

1/16W

5%

33

R185

1206

CERM

6.3V

20%

10uF

C270

1206

CERM

6.3V

20%

10uF

C221

402

CERM

10V

20%

0.1uF

C474

402

CERM

10V

20%

0.1uF

C399

402

CERM

10V

20%

0.1uF

C300

402

CERM

10V

20%

0.1uF

C239

402

CERM

10V

20%

0.1uF

C258

402

CERM

10V

20%

0.1uF

C269

402

CERM

10V

20%

0.1uF

C382

402

CERM

10V

20%

0.1uF

C460

+3V_MAIN

402

CERM

10V

20%

0.1uF

C236

402

CERM

10V

20%

0.1uF

C428

402

CERM

10V

20%

0.1uF

C478

402

CERM

10V

20%

0.1uF

C256

402

CERM

10V

20%

0.1uF

C426

402

CERM

16V

20%

0.01uF

C271

402

CERM

16V

20%

0.01uF

C398

402

CERM

16V

20%

0.01uF

C524

402

CERM

16V

20%

0.01uF

C233

402

CERM

16V

20%

0.01uF

C397

402

MF

1/16W

5%

33

R159

402

CERM

16V

20%

0.01uF

C477

402

CERM

16V

20%

0.01uF

C364

402

CERM

16V

20%

0.01uF

C415

402

CERM

16V

20%

0.01uF

C335

402

CERM

16V

20%

0.01uF

C248

402

R315

MF

1/16W

5%

10K

402

R284

MF

1/16W

5%

10K

402

R308

MF

1/16W

5%

10K

402

R297

MF

1/16W

5%

10K

402

R360

MF

1/16W

5%

10K

402

R357

MF

1/16W

5%

10K

402

R358

MF

1/16W

5%

10K

402

R359

MF

1/16W

5%

10K

402

R298

MF

1/16W

5%

10K

402

R309

MF

1/16W

5%

10K

402

R285

MF

1/16W

5%

10K

402

R316

MF

1/16W

5%

10K

402

R331

MF

1/16W

5%

10K

1210

FF

1/4W

5%

0

R3

402

R422

MF

1/16W

5%

10K

+3V_MAIN

402

R608

MF

1/16W

5%

10K

+3V_MAIN

G

D

S

SOT-363

2N7002DW

Q52

G

D

S

SOT-363

2N7002DW

Q52

402

MF

1/16W

5%

0

R610

402

R609

MF

1/16W

5%

470K

+3V_MAIN

402

R611

MF

1/16W

5%

470K

402

R664

MF

1/16W

5%

0

402

MF

1/16W

5%

33

R667

XIN/CLKIN

SSCLK

VSS

S0

S1

FRSEL

XOUT

VDD

SOI

CY25811

U46

402

R690

MF

1/16W

5%

0

402

R692

MF

1/16W

5%

0

402

R691

MF

1/16W

5%

0

402

R693

MF

1/16W

5%

0

402

MF

1/16W

5%

330

R705

402

MF

1/16W

5%

330

R706

402

MF

1/16W

5%

330

R707

402

CERM

50V

10%

470pF

C892

402

CERM

50V

10%

470pF

C893

402

MF

1/16W

5%

22

R448

402

R447

MF

1/16W

1%

150

402

MF

1/16W

1%

49.9

R708

402

MF

1/16W

1%

49.9

R715

VSS

VSS

VSS

VSS

VSS

(3 OF 6)

RAGE_MOBILITY

ZV_LCDDATA0
ZV_LCDDATA1

ROMCSB

SSIN

TESTEN

XTALOUT

SSOUT

TXCLK_LP

TXCLK_LN

TXOUT_L3P

XTALIN

TXCP

TX0P
TX1M

TXCM

TX2M

TX1P

TX2P

TX0M

GPIO13
GPIO14

GPIO9

GPIO11

GPIO10

GPIO12

GPIO8

TXOUT_U1N

TXOUT_U0N
TXOUT_U0P

CRT2DDCCLK
CRT2DDCDAT

TXOUT_U1P
TXOUT_U2N

TXCLK_UP

TXOUT_U3N

TXOUT_L1P

TXOUT_L1N

TXOUT_L0P

TXOUT_L0N

TXOUT_U2P

TXCLK_UN

TXOUT_U3P

TXOUT_L2N
TXOUT_L2P
TXOUT_L3N

GPIO4

GPIO3

GPIO2

GPIO6
GPIO7

GPIO5

GPIO1

GPIO0

ZV_LCDCNTL3

ZV_LCDCNTL2

ZV_LCDDATA19

ZV_LCDDATA18

ZV_LCDDATA17

ZV_LCDDATA23

ZV_LCDDATA22

ZV_LCDCNTL1

ZV_LCDCNTL0

ZV_LCDDATA20
ZV_LCDDATA21

AUXWIN

VGADDCCLK

BLONB

COMP_B

DIGON

VGADDCDATA

DVIDDCCLK

DVIDDCDATA

HPD

C_R

ZV_LCDDATA16

ZV_LCDDATA11

ZV_LCDDATA10

ZV_LCDDATA9

ZV_LCDDATA8

ZV_LCDDATA7

ZV_LCDDATA12
ZV_LCDDATA13
ZV_LCDDATA14
ZV_LCDDATA15

ZV_LCDDATA6

ZV_LCDDATA2
ZV_LCDDATA3
ZV_LCDDATA4
ZV_LCDDATA5

VSYNC

V2SYNC

HSYNC

H2SYNC

RSET

R2SET

Y_G

B

R
G

GPIO15
GPIO16

M9-CSP32A13

32MB

BGA

U4

(DIE)

VSS

(DIE)

VSS

VDDC

VDDC18

RAGE_MOBILITY

(5 OF 6)

U4

M9-CSP32A13

32MB

BGA

402

R463

MF

1/16W

1%

182

805

CERM

10V

N20P80%

4.7uF

C708

402

CERM

10V

20%

0.1uF

C707

OE

GND

OUT

VCC

OSC

SM-1

27.0000M

G1

SM

L52

FERR-EMI-100-OHM

402

R477

MF

1/16W

5%

100K

+3V_MAIN

402

R330

MF

1/16W

5%

10K

+3V_SLEEP

805

CERM

10V

N20P80%

4.7uF

C512

402

CERM

10V

20%

0.1uF

C565

+3V_SLEEP

SM

L50

FERR-EMI-100-OHM

402

CERM

10V

20%

0.1uF

C320

402

CERM

10V

20%

0.1uF

C257

1206

CERM

16V

N20P80%

10uF

C413

402

CERM

10V

20%

0.1uF

C352

402

CERM

10V

20%

0.1uF

C427

+1_8V_MAIN

603

R343

MF

1/16W

5%

0

C414

22uF

20%
10V
TANT
SMB

+3V_MAIN

BG

GND

SENSE TG

SW

RUN_SS

VFB

SYNC_FCB

ITH

VIN

U14

LTC1773

MSOP

SM-2

FDS6680

Q4

S2

GATE

S1

S3 D4

D3
D2

D1

Q5

SI4435DY

SOI

402

CERM

50V

5%

47pF

C587

1206

MF

1/4W

1%

0.02

R35

XW16

SM

32

U32

SM

74AHC1G32

XW12

SM

402

R437

MF

1/16W

5%

4.7K

402

R214

MF

1/16W

1%

32.4K

402

R213

MF

1/16W

1%

57.6K

402

R212

MF

1/16W

5%

0

402

CERM

50V

5%

100pF

C274

402

CERM

50V

20%

0.001uF

C273

SM-3

L6

3.3uH

C21

330uF

20%

6.3V
TANT
SMD

402

R408

MF

1/16W

5%

0

402

R385

MF

1/16W

5%

0

603

CERM

50V

5%

680pF

C586

1206

CERM

6.3V

20%

10uF

C526

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

20 46

E

051-6403

REFERENCE DESIGNATOR(S)

BOM OPTION

TABLE_5_HEAD

QTY

DESCRIPTION

PART#

TABLE_5_ITEM

155S0134

2

FLTR,EMI,FERR BEAD,0.1A,0402,SMD

R185,R159

TMDS TERMINATION

Keep close to ATI chip

VGA SYNC BUFFERS

NC

NC

SPREAD SPECTRUM SUPPORT

NC

NC

NC

Crystal input remains at

1.8V (not core voltage).

NC

NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC

(+1_8V_ATI_VDDC18)

NC

NC
NC
NC

NC

NC
NC
NC
NC

NC

NC

PLACE THESE PARTS CLOSE TO ATI CHIP

NC
NC

NC

NC

NC

NC

it may be cut between the caps.

as a 4 mil surface trace so that

TMDS_CLK_CMT should be routed

must be hooked up as drawn here.

This clock termination network

NC

NC

M7/M9 I/O - 1.8V

5

4

2

1

3

2

1

2

1

2

1

2

1

2

1

2

1

2

1

OMIT

21

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

OMIT

21

2

1

2

1

2

1

2

1

2

1

NO STUFF

2

1

NO STUFF

2

1

NO STUFF

2

1

NO STUFF

2

1

NO STUFF

2

1

NO STUFF

2

1

NO STUFF

2

1

NO STUFF

2

1

NO STUFF

2

1

NO STUFF

2

1

NO STUFF

2

1

NO STUFF

2

1

NO STUFF

2

1

21

2

1

NO STUFF

2

1

NO STUFF

4

5

3

NO STUFF

1

2

6

NO STUFF

21

NO STUFF

2

1

NO STUFF

2

1

ATI_SS

2

1

ATI_SS

21

ATI_SS CRITICAL

8

1

2

7

5

3
4

6

NO STUFF

2

1

NO STUFF

2

1

ATI_SS

2

1

ATI_SS

2

1

21

21

21

2

1

2

1

21

2

1

21 21

OMIT

AK7

AJ7

AH7

AG7

AK6

AJ6

AH6

AH11

AG11

AK10

AJ10

AG6

AH10

AG10

AK9

AJ9

AH9

AG9

AK8

AJ8

AH8

AG8

AK5

AJ5

AG5

AH5

AK4

AJ4

AK23

AJ30

AJ29

AG27

B21

A20

A24

B20

B24

AH28

AH27

AG25

AG22

AH22

AG20

AH20

AG19

AH19

AG18

AH18

AJ20

AK20

AJ18

AK18

AJ17

AK17

AJ16

AK16

AK12

AJ12

AG21

AH21

AJ19

AK19

AK15

AJ15

AK14

AJ14

AK13

AJ13

AH24

AJ25AJ26

AK25

AE5

AJ24

AK28

AG26

AF11

AG24

AF3

AG3

AH1

AF4

AJ1

AH2

AH3

AK1

M1

AE1

AE2

AF1

AG1

AF2

AG2

AK2

AJ2

AK27

AE12

AF12

AE13

AK24

AH26

AH25

AK22

AF13

AK26

AJ27

OMIT

Y19
W19
V19
U19
T19
R19
P19
N19
M19
L19

Y10

Y18
W18
V18
U18 T18

R18

P18

N18

M18

L18

W10

Y17

W17

V17

U17

T17

R17

P17

N17

M17

L17

V10

Y16

W16

V16

U16

T16

R16

P16

N16

M16

L16

U10

Y15

W15

V15

U15

T15

R15

P15

N15

M15

L15

T10

Y14

W14

V14

U14

T14

R14

P14

N14

M14

L14

R10

Y13

W13

V13

U13

T13

R13

P13

N13

M13

L13

P10

Y12

W12

V12

U12

T12

R12

P12

N12

M12

L12

N10

Y11

W11

V11

U11

T11

R11

P11

N11

Y21
W21
V21
U21
T21
R21
P21
N21
M21
L21

M11

Y20
W20
V20
U20
T20
R20
P20
N20
M20
L20

L11

M10

L10

U6

P6

H6

G6

F6

AD26

W26

AF5

AF25

AC25

W25

V25

P25

N25

M25

F25

AE24

F24

AH4

F23

AE18

F18

AE17

AF15

AE15

AF14

AE14

F14

F13

AG4

AE11

AB25

R25

G25

F17

F12

AB6

T6

L6

F11

AE10

F10

F7

AE6

AD6

AC6

W6

V6

AK3

AJ3

2

1

2

1

2

1

CRITICAL 14

81

7

21

NO STUFF

2

1

NO STUFF

2

1

ATI_SS

2

1

ATI_SS

2

1

ATI_SS

21

2

1

2

1

2

1

2

1

2

1

2

1

2

1

8

4

7

3

10

9

2

1

5

6

CRITICAL

321

4

8765

CRITICAL

3
2
1

4

8
7
6
5

2

1

21

2

1

5

4

2

1

3

21

2

1

2

1

2

1

2

1

2

1

NO STUFF

2

1

CRITICAL

21

2

1

NO STUFF

2

1

2

1

2

1

2

1

CR-20

ATI_SSIN_PU

ATI_TESTEN

TMDS_CLKP

TMDS_CLKN

TMDS_DP<2>

TMDS_DN<2>

TMDS_DP<1>

TMDS_DN<0>

TMDS_DN<1>

TMDS_DP<0>

ATI_GPIO13_SPN
HPD_PWR_SNS_EN

ATI_GPIO11_SPN
ATI_GPIO12_SPN

ATI_GPIO10_SPN

ATI_GPIO8_SPN
ATI_GPIO9_SPN

ATI_GPIO7_SPN

ATI_BUS_CFG<2>

ATI_BUS_CFG<1>

ATI_BUS_CFG<0>

ATI_X1CLK_SKEW<1>

ATI_AGP_FBSKEW<1>

ATI_AGP_FBSKEW<0>

ATI_X1CLK_SKEW<0>

ATI_LCDCNTL3_TP

ATI_LCDCNTL2_TP

ATI_LCDCNTL1_TP

ATI_LCDCNTL0_TP

ATI_SLAVE_VIP

CLKLVDS_N

LVDS_L3P_SPN

CLKLVDS_P

LVDS_L3N_SPN

LVDS_L2P

LVDS_L1P
LVDS_L2N

LVDS_L1N

LVDS_L0P

LVDS_L0N

ATI_DVI_DDC_DATA

LVDS_DDC_DATA

ATI_DVI_DDC_CLK

LVDS_DDC_CLK

ATI_AUXWIN_PU

ATI_INV_ON_L

ATI_HPD

ATI_DIGON

ATI_C
ATI_COMP

ATI_R2SET

ATI_RSET

ATI_Y

ATI_HSYNC

ATI_VSYNC

ATI_B

ATI_R

ATI_G

ATI_VCORE_CNTL_L

+1_2V_ATI_VDDC

ATI_SS_PU

TMDS_CLKP

TMDS_CLK_CMT

TMDS_CLKN

CLK27M_ATI_UF

CLK27M_ATIMEM_US

+1_2V_ATI_VCORE

ATI_VSYNC

ATI_HSYNC

ATI_VSYNC_BUF

VGA_VSYNC

ATI_HSYNC_BUF

VGA_HSYNC

CLK27M_ATI_UF

ATI_OSC_OE

+3V_ATI_OSC_SLEEP

+1_2V_ATI_VCORE

ATI_VCORE_VFB

ATI_VCORE_TG

ATI_VCORE_L_SW

ATI_VCORE_BG

ATI_VCORE_SENSE

ATI_VCORE_RUN_SS

ATI_VCORE_VIN

ATI_VCORE_SYNC_FCB

ATI_VCORE_ITH

ATI_VCORE_ITH_RC

ATI_VCORE_FB_SW

ATI_VCORE_FB_SW

ATI_VCORE_AGND

ATI_VCORE_CNTL_L

ATI_VCORE_CNTL

CLK27M_ATIMEM_SS

+3V_ATI_SS

+3V_ATI_SS

+3V_ATI_SS

CY811_S1

CY811_S0

TMDS_DN<2> TMDS_DP<2>

TMDS_DP<1>TMDS_DN<1>

TMDS_DN<0> TMDS_DP<0>

CLK27M_ATI_LS1_8

CLK27M_ATI

+1_8V_ATI_VDDC18

31<

31<

31<

31<

31<

31<

20<

20<

20<

20<

20<

20<

20<

20<

42<> 42<>

42<>

42<>

42<>

42<>

42<> 42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

31<> 31<>

31<> 31<>

31<>

31<>

31<> 31<>

31<>

31<>

31<>

31<>

31<>

31<>

31<>

31<>

33<>

31<>

31<>

31<>

31<>

31<>

31<>

31<>

31<>

31<>

31<>

31<>

31<>

19<

31<

31<>

31<>

31<

31<

21<

21<

31<

20<

20<

31<

31<

31<

20<>

43<>

20> 20>

40<>

43<>

20<>

20<>

31<>

31<>

40<>

43<>

43<>

20<>

20<

20<>

40<>

43<>

43<>

43<>

20> 20>

20> 20>

20> 20>

40<>

1206

CERM

16V

N20P80%

10uF

C470

1206

CERM

16V

N20P80%

10uF

C272

1206

CERM

16V

N20P80%

10uF

C363

SHDN BYP

GND

OUT

IN

SYM_VER1

SOT-23

LTC1761ES5-1.8

U45

SHDN BYP

GND

OUT

IN

SYM_VER1

SOT-23

LTC1761ES5-1.8

U24

402

CERM

10V

20%

0.1uF

C525

1206

CERM

16V

N20P80%

10uF

C206

+1_8V_MAIN

402

CERM

10V

20%

0.1uF

C180

+2_5V_MAIN

SYM_VER2

GND

OUT

IN

BYP ADJ

SOT-23-1

LTC1761ES5-BYP

U41

402

R369

MF

1/16W

1%

200K

402

R368

MF

1/16W

1%

45.3K

402

CERM

10V

20%

0.1uF

C511

603

MF

1/16W

5%

0

R407

402

R435

MF

1/16W

1%

499

402

R406

MF

1/16W

1%

715

402

CERM

10V

20%

0.1uF

C472

1206

CERM

16V

N20P80%

3.3uF

C459

603

MF

1/16W

5%

0

R355

+2_5V_MAIN

603

MF

1/16W

5%

0

R436

402

CERM

16V

20%

0.01uF

C412

402

CERM

16V

20%

0.01uF

C362

402

CERM

16V

20%

0.01uF

C319

402

CERM

16V

20%

0.01uF

C302

402

CERM

10V

20%

0.1uF

C336

603

MF

1/16W

5%

0

R354

402

CERM

16V

20%

0.01uF

C303

402

CERM

10V

20%

0.1uF

C237

402

CERM

16V

20%

0.01uF

C231

402

CERM

10V

20%

0.1uF

C234

402

CERM

10V

20%

0.1uF

C304

1206

CERM

16V

N20P80%

10uF

C205

402

CERM

16V

20%

0.01uF

C235

+2_5V_MAIN

805

R196

FF

1/10W

5%

0

+2_5V_MAIN

1206

CERM

16V

N20P80%

10uF

C361

+1_5V_MAIN

402

CERM

10V

20%

0.1uF

C208

402

CERM

16V

20%

0.01uF

C238

+1_8V_MAIN

402

MF

1/16W

5%

0

R421

402

MF

1/16W

5%

0

R417

402

CERM

10V

20%

0.1uF

C520

402

CERM

10V

20%

0.1uF

C553

1206

CERM

16V

N20P80%

3.3uF

C584

1206

CERM

16V

N20P80%

3.3uF

C562

402

CERM

10V

20%

0.1uF

C519

402

MF

1/16W

5%

0

R356

402

CERM

10V

20%

0.1uF

C209

402

CERM

10V

20%

0.1uF

C210

402

CERM

10V

20%

0.1uF

C212

402

CERM

10V

20%

0.1uF

C858

402

CERM

10V

20%

0.1uF

C859

402

CERM

10V

20%

0.1uF

C860

402

CERM

10V

20%

0.1uF

C861

402

CERM

10V

20%

0.1uF

C862

805

FF

1/10W

5%

0

R160

402

R209

MF

1/16W

5%

100

VDDR4

VDDR3

DVOMODE

VDDR1

TXVSSR1
TXVSSR2
TXVSSR3

LVDDR_18_25

TXVDDR2

TXVDDR1

TXVDDR0

TXVDDR3

MPVDD

TPVDD

LPVDD

LVDDR_18_25

LVDDR_18
LVDDR_18

VDDM

LVSSR3

LVSSR2

LVSSR1

LVSSR0

MPVSS

TPVSS

LPVSS

VDDP

VDDRH1

VDDRH0

A2VDDDI

AVDDDI

A2VDDQ

AVDD0
AVDD1

PVDD

A2VDD1

A2VDD0

VDDR1

VSSRH1

VSSRH0

A2VSSN1

A2VSSDI

AVSSDI

A2VSSN0

A2VSSQ
AVSSN0
AVSSN1

AVSSQ

PVSS

RAGE_MOBILITY

(4 OF 6)

U4

M9-CSP32A13

32MB

BGA

1206

CERM

16V

N20P80%

3.3uF

C583

402

CERM

10V

20%

0.1uF

C301

402

CERM

10V

20%

0.1uF

C458

402

CERM

10V

20%

0.1uF

C232

402

CERM

10V

20%

0.1uF

C552

402

CERM

10V

20%

0.1uF

C211

402

CERM

10V

20%

0.1uF

C214

402

CERM

10V

20%

0.1uF

C381

402

CERM

10V

20%

0.1uF

C351

402

CERM

10V

20%

0.1uF

C230

402

CERM

10V

20%

0.1uF

C292

+2_5V_MAIN

402

CERM

16V

20%

0.01uF

C563

402

CERM

16V

20%

0.01uF

C551

+2_5V_MAIN

402

CERM

16V

20%

0.01uF

C179

402

CERM

16V

20%

0.01uF

C196

1206

CERM

16V

N20P80%

10uF

C240

1206

CERM

16V

N20P80%

10uF

C293

402

CERM

10V

20%

0.1uF

C523

402

CERM

10V

20%

0.1uF

C479

402

CERM

10V

20%

0.1uF

C522

402

CERM

10V

20%

0.1uF

C480

402

CERM

10V

20%

0.1uF

C195

+3V_MAIN

402

CERM

16V

20%

0.01uF

C521

402

CERM

50V

5%

100pF

C554

402

CERM

16V

20%

0.01uF

C476

1206

CERM

16V

N20P80%

10uF

C564

402

CERM

10V

20%

0.1uF

C475

+1_8V_MAIN

1206

CERM

16V

N20P80%

10uF

C614

402

CERM

10V

20%

0.1uF

C585

402

CERM

10V

20%

0.1uF

C471

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

21 46

E

051-6403

MISC IO - 3.3V

IADJ = 30NA AT 25C

VOUT = 1.22(1 + R2/R1) + IADJ*R2

ONE SET OF 10UF,0.1UF,0.01UF

(+1_8V_ATI_LVDDR)

(+1_8V_ATI_MPVDD)

(UPPER LEFT)

(UPPER RIGHT)

AGP 4X I/O - 1.5V

(+VCORE_ATI_VDDM)

(+1_5V_MAIN)

FOR PVDD AND LPVDD

(+1_8V_ATI_A2VDDQ)

(+2_5V_ATI_A2VDD)

(+1_8V_ATI_AVDD)

(+1_8V_ATI_PVDD)

(+3V_MAIN)

(+2_5V_ATI_VDDR)

MEMORY I/O - 2.5V

SHARE THESE CAPS WITH VDDQM IN LOWER LEFT

MOBILITY POWER

MEMORY CORE - 2.5V

2

1

2

1

2

1

CRITICAL

3

51

2

4

CRITICAL

3

51

2

4

2

1

2

1

2

1

CRITICAL

51

2

3 4

2

1

2

1

2

1

21

1

2

2

1

2

1

2

1

12

21

2

1

2

1

2

1

2

1

2

1

21

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

21

21

2

1

2

1

2

1

2

1

2

1

21

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

12

2

1

OMIT

M6

F20

N6

F19

AE8

AF7

AE7

AF6

AE25

AD25

AF10

AF9

AE9

AF8

AF26

AE26

R5

P5

N5

M5

L5

H26

G26

E25

E24

E23

E22

E21

E17

E16

K5

E15

E14

E11

E10

E9

E8

E7

J26

J25

H25

J5

F22

F21

F16

F15

F9

F8

AA6

Y6

R6

K6

H5

J6

AD5

AC5

AB5

AA5

Y5

W5

V5

U5

T5

G5

F5

N26

M26

L26

K26

AA25

Y25

U25

Y28

Y27

T25

K27

AC26

AB26

AA26

Y26

V26

U26

T26

R26

P26

L25

K25

F26

E26

E20

E19

E18

E13

E12

E6

E5

AH15

AH14

AH13

AG15

AG14

AG13

AG12

AJ11AK11

AK30AK29

A6A7

AF18

AH17

AG17

AH16

AF17

AG16

AF16

AE16

AJ21AK21

AH12

AF22

AE23

AE22

AG23

AH23

AF24

AF23

AJ22

AE20

AE19

AF19

AJ23

AF20

AF21

AE21

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

CR-21

+VCORE_ATI_VDDM

ATI_R2SET

+2_5V_ATI_VDDR

+2_5V_ATI_VDDR

+1_8V_ATI_AVDDDI
+1_8V_ATI_A2VDDDI

+2_5V_ATI_A2VDD

+1_8V_ATI_PVDD

ATI_RSET

+1_8V_ATI_AVDD

+1_8V_ATI_PVDD

ATI_PVDD_BYP

1_5V_AGP_ADJ

1_5V_AGP_BYP

+1_8V_ATI_LVDDR

+1_8V_ATI_MPVDD

ATI_MPVDD_BYP

+1_8V_ATI_A2VDDQ

+1_8V_ATI_A2VDDDI

+1_8V_ATI_AVDDDI

+3V_ATI_VDDR3

+2_5V_ATI_VDDR

43<>

21<

43<>

20>

43<>

43<>

43<>

43<>

43<>

21<>

20>

43<>

43<>

43<>

43<>

43<>

43<>

43<>

43<>

43<>

1206

CERM

6.3V

20%

10uF

C241

402

CERM

16V

20%

0.01uF

C200

402

CERM

10V

20%

0.1uF

C198

402

CERM

16V

20%

0.01uF

C251

402

CERM

10V

20%

0.1uF

C250

402

CERM

10V

20%

0.1uF

C249

402

CERM

16V

20%

0.01uF

C199

402

CERM

10V

20%

0.1uF

C197

402

CERM

16V

20%

0.01uF

C222

1206

CERM

6.3V

20%

10uF

C215

402

CERM

10V

20%

0.1uF

C340

402

CERM

10V

20%

0.1uF

C339

402

CERM

16V

20%

0.01uF

C338

402

CERM

16V

20%

0.01uF

C429

402

CERM

10V

20%

0.1uF

C431

402

CERM

10V

20%

0.1uF

C337

402

CERM

16V

20%

0.01uF

C430

402

CERM

16V

20%

0.01uF

C383

1206

CERM

6.3V

20%

10uF

C400

1206

CERM

6.3V

20%

10uF

C365

402

R187

MF

1/16W

1%

121

402

R332

MF

1/16W

1%

121

CK

CK

CKE

RFU3

RFU2

RFU1

MCL

DQ31

NC

BA1

DQ26
DQ27
DQ28
DQ29
DQ30

DQ25

DQ24

DQ21
DQ22
DQ23

DQ19
DQ20

DQ14

DQ16
DQ17
DQ18

DQ15

DQ13

DQ12

DQ11

DQ9

DQ10

DQ8

DQ4

DQ6

DQ5

DQ7

DQ3

DQ2

DQ1

DQ0

CS
RAS
CAS
WE

BA0

DM3

DQS3

DM2

DM1

DM0

DQS2

A10
DQS0

A9

DQS1

A8

A4
A5
A6
A7

A3

A2

A1

A0

(1 OF 2)

BGA

SDRAM_DDR_2MX32

U2

VSSQ

VSS_THERM

VSS

VDDQ

VREF

VDD

(2 OF 2)

U2

SDRAM_DDR_2MX32

BGA

CK

CK

CKE

RFU3

RFU2

RFU1

MCL

DQ31

NC

BA1

DQ26
DQ27
DQ28
DQ29
DQ30

DQ25

DQ24

DQ21
DQ22
DQ23

DQ19
DQ20

DQ14

DQ16
DQ17
DQ18

DQ15

DQ13

DQ12

DQ11

DQ9

DQ10

DQ8

DQ4

DQ6

DQ5

DQ7

DQ3

DQ2

DQ1

DQ0

CS
RAS
CAS
WE

BA0

DM3

DQS3

DM2

DM1

DM0

DQS2

A10
DQS0

A9

DQS1

A8

A4
A5
A6
A7

A3

A2

A1

A0

(1 OF 2)

BGA

SDRAM_DDR_2MX32

U7

VSSQ

VSS_THERM

VSS

VDDQ

VREF

VDD

(2 OF 2)

U7

SDRAM_DDR_2MX32

BGA

TABLE_5_ITEM

CRITICAL

M7_VMEM_16MB

333S0108

2

IC,SDRAM,DDR,2MX32,222MHZ,144P FBGA

U2,U7

TABLE_5_ITEM

CRITICAL

M9_VMEM_32MB_HYNIX

333S0234

2

IC,SDRAM,DDR,4MX32,250MHZ,153P BGA

U2,U7

TABLE_5_ITEM

CRITICAL

M9_VMEM_32MB_SAMSUNG

333S0235

2

IC,SDRAM,DDR,4MX32,222MHZ,144P FBGA

U2,U7

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

22 46

E

051-6403

CRITICAL BOM OPTION

TABLE_5_HEAD

PART#

DESCRIPTION

QTY

REFERENCE DESIGNATOR(S)

NC
NC
NC
NC
NC

NC

NC

NC
NC

NC

NC

NC

NC
NC
NC
NC

NC

NC
NC

NC

NC

NC

EXT VIDEO MEM

Keep close to memory

Keep close to memory

Keep close to memory

Keep close to memory

DATA LINES SWAPPABLE ONLY WITHIN SDRAM BYTE LANE.
BYTE LANE IS SWAPPABLE, IF NECESSARY. CONTACT DESIGNER.

BYTE LANE IS SWAPPABLE, IF NECESSARY. CONTACT DESIGNER.

DATA LINES SWAPPABLE ONLY WITHIN SDRAM BYTE LANE.

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

OMIT

L3

M7

M10

L9

M2

N3

M4

M3

L13

L12

H11

H4

C11

C4

M13

B13

H2

H13

B2

K12

K13

E2

D2

D3

C2

B8

C9

B5

B9

B10

C13

D12

D13

E13

K3

K2

J2

J3

B6

G2

G3

F2

F3

F12

F13

G12

G13

J12

J13

C6

B7

B12

H3

H12

B3

N2

N12

M12

M11

L2

M5

N4

M8

N11

N10

N9

M9

N8

N7

M6

L6

N6

N5

OMIT

H7

H6

G9

G8

G7

G6

F9

F8

J9

J8

J7

J6

H9

H8

F7

F6

E9

E6

D11

D10

D9

D6

D5

D4

K10

K5

J10

J5

H10

H5

G10

G5

F10

F5

B11

B4

L10

L5

K9

K8

K7

K6

E10

E8

E7

E5

N13

F11

F4

E12

E3

C12

C10

C8

C7

K11

K4

J11

J4

G11

G4

C5

C3

L11

L8

L7

L4

E11

E4

D8

D7

OMIT

L3

M7

M10

L9

M2

N3

M4

M3

L13

L12

H11

H4

C11

C4

M13

B13

H2

H13

B2

K12

K13

E2

D2

D3

C2

B8

C9

B5

B9

B10

C13

D12

D13

E13

K3

K2

J2

J3

B6

G2

G3

F2

F3

F12

F13

G12

G13

J12

J13

C6

B7

B12

H3

H12

B3

N2

N12

M12

M11

L2

M5

N4

M8

N11

N10

N9

M9

N8

N7

M6

L6

N6

N5

OMIT

H7

H6

G9

G8

G7

G6

F9

F8

J9

J8

J7

J6

H9

H8

F7

F6

E9

E6

D11

D10

D9

D6

D5

D4

K10

K5

J10

J5

H10

H5

G10

G5

F10

F5

B11

B4

L10

L5

K9

K8

K7

K6

E10

E8

E7

E5

N13

F11

F4

E12

E3

C12

C10

C8

C7

K11

K4

J11

J4

G11

G4

C5

C3

L11

L8

L7

L4

E11

E4

D8

D7

CR-22

ATI_VMEM_DQMB<4>

ATI_VMEM_DQMB<5>

ATI_VMEM_QS<4>

ATI_VMEM_QS<5>
ATI_VMEM_QS<6>

ATI_VMEM_DQMB<6>

ATI_VMEM_DQMB<7>

ATI_VMEM_QS<7>

ATI_VMEM_DATA<46>

ATI_VMEM_DATA<45>

ATI_VMEM_DATA<47>

ATI_VMEM_DATA<43>
ATI_VMEM_DATA<44>

ATI_VMEM_DATA<42>

ATI_VMEM_DATA<41>

ATI_VMEM_DATA<40>

ATI_VMEM_DATA<33>

ATI_VMEM_DATA<37>

ATI_VMEM_DATA<35>
ATI_VMEM_DATA<36>

ATI_VMEM_DATA<38>
ATI_VMEM_DATA<39>

ATI_VMEM_DATA<34>

ATI_VMEM_DATA<32>

ATI_VMEM_DQMB<2>

ATI_VMEM_DQMB<3>

ATI_VMEM_QS<2>

ATI_VMEM_QS<3>

ATI_VMEM_DQMB<1>

ATI_VMEM_DQMB<0>

ATI_VMEM_QS<1>

ATI_VMEM_QS<0>

ATI_VMEM_DATA<22>
ATI_VMEM_DATA<23>

ATI_VMEM_DATA<21>

ATI_VMEM_DATA<20>

ATI_VMEM_DATA<19>

ATI_VMEM_DATA<18>

ATI_VMEM_DATA<16>
ATI_VMEM_DATA<17>

ATI_VMEM_DATA<24>
ATI_VMEM_DATA<25>

ATI_VMEM_DATA<27>
ATI_VMEM_DATA<28>

ATI_VMEM_DATA<26>

ATI_VMEM_DATA<29>
ATI_VMEM_DATA<30>
ATI_VMEM_DATA<31>

ATI_VMEM_ADDR<11>

ATI_VMEM_ADDR<11>

ATI_VMEM_ADDR<12>

ATI_VMEM_CLKB_L<1>

ATI_VMEM_CLKB<1>

ATI_VMEM_CLKB<0>

ATI_VMEM_CLKB_L<0>

+VCORE_ATI_VDDM

+2_5V_ATI_VDDR

+2_5V_ATI_VDDR

ATI_VMEM_CKEB

ATI_VMEM_CLKB_L<0>

ATI_VMEM_CLKB<0>

ATI_VMEM_DATA<6>
ATI_VMEM_DATA<7>

ATI_VMEM_DATA<4>

ATI_VMEM_DATA<3>

ATI_VMEM_DATA<5>

ATI_VMEM_DATA<1>
ATI_VMEM_DATA<2>

ATI_VMEM_DATA<0>

ATI_VMEM_WE_L

ATI_VMEM_RASB_L

ATI_VMEM_CSB_L

ATI_VMEM_CASB_L

ATI_VMEM_ADDR<13>

ATI_VMEM_ADDR<10>

ATI_VMEM_ADDR<8>
ATI_VMEM_ADDR<9>

ATI_VMEM_ADDR<6>
ATI_VMEM_ADDR<7>

ATI_VMEM_ADDR<3>

ATI_VMEM_ADDR<5>

ATI_VMEM_ADDR<4>

ATI_VMEM_ADDR<2>

ATI_VMEM_ADDR<1>

ATI_VMEM_ADDR<0>

ATI_VMEM_CKEB

ATI_VMEM_CLKB_L<1>

ATI_VMEM_CLKB<1>

ATI_VMEM_DATA<63>

ATI_VMEM_ADDR<12>

ATI_VMEM_DATA<62>

ATI_VMEM_DATA<61>

ATI_VMEM_DATA<58>

ATI_VMEM_DATA<60>

ATI_VMEM_DATA<59>

ATI_VMEM_DATA<57>

ATI_VMEM_DATA<56>

ATI_VMEM_WE_L

ATI_VMEM_RASB_L

ATI_VMEM_CSB_L

ATI_VMEM_CASB_L

ATI_VMEM_ADDR<13>

ATI_VMEM_ADDR<10>

ATI_VMEM_ADDR<8>
ATI_VMEM_ADDR<9>

ATI_VMEM_ADDR<6>
ATI_VMEM_ADDR<7>

ATI_VMEM_ADDR<3>

ATI_VMEM_ADDR<5>

ATI_VMEM_ADDR<4>

ATI_VMEM_ADDR<2>

ATI_VMEM_ADDR<1>

ATI_VMEM_ADDR<0>

+VCORE_ATI_VDDM

+2_5V_ATI_VDDR

+1_25V_ATI_VREF

+VCORE_ATI_VDDM

ATI_VMEM_DATA<8>
ATI_VMEM_DATA<9>
ATI_VMEM_DATA<10>

ATI_VMEM_DATA<12>

ATI_VMEM_DATA<11>

ATI_VMEM_DATA<15>

ATI_VMEM_DATA<13>
ATI_VMEM_DATA<14>

ATI_VMEM_DATA<49>

ATI_VMEM_DATA<48>

ATI_VMEM_DATA<50>
ATI_VMEM_DATA<51>
ATI_VMEM_DATA<52>

ATI_VMEM_DATA<54>
ATI_VMEM_DATA<55>

ATI_VMEM_DATA<53>

+1_25V_ATI_VREF

+VCORE_ATI_VDDM

+2_5V_ATI_VDDR

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

22<>

22<>

41<>

42<>

42<>

42<>

42<>

41<>

42<>

42<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

42<>

42<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

41<>

19>

19>

19<>

19<>

19<>

19>

19>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19>

19>

19<>

19<>

19>

19>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19>

19>

19>

19<>

19<>

19<>

19<>

43<>

43<>

43<>

19>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19>

19>

19>

19>

19>

19>

19>

19>

19>

19>

19>

19>

19>

19>

19>

19>

19>

19<>

19<>

19<>

19>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19>

19>

19>

19>

19>

19>

19>

19>

19>

19>

19>

19>

19>

19>

19>

19>

43<>

43<>

43<>

43<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

19<>

43<>

43<>

43<>

Y1

SM

14.31818M

402

CERM

50V

5%

15pF

C727

402

CERM

50V

5%

15pF

C734

1206

CERM

16V

N20P80%

10uF

C744

1206

CERM

16V

N20P80%

10uF

C78

402

R490

MF

1/16W

5%

47

805

CERM

10V

N20P80%

4.7uF

C96

_STP

CPSD

VDD3V66

S1/48M1_USB

S0/48M0_DOT

S2/TEST

PD
SCLK
SDATA

XIN
XOUT

CPU_STP

PCI_STP

VDDS1

VDDS0

VDD2

AVDD

VDDP

VDDR

VDDCPU0

VDDCPU1

VDD0

VSS4

VSS3

VSS2

VSS1

VSS0

VSS6

VSS5

PCI_5
PCI_6

PCI_4

PCI_3

PCI_2

PCI_1

PCI_0

3V662

3V661

3V660

VSS7

AVSS

VSS8

CPU0

SDRAM1

SDRAM0

CPU1

SDRAM2
SDRAM3

DCLK

TSSOP

U22

C5005

+3V_SLEEP

402

MF

1/16W

5%

24

R545

402

R46

MF

1/16W

5%

10K

805

CERM

10V

N20P80%

4.7uF

C99

402

CERM

10V

20%

0.1uF

C97

402

R512

MF

1/16W

5%

10K

402

MF

1/16W

5%

22

R506

402

R528

MF

1/16W

5%

0

402

MF

1/16W

5%

0

R529

402

MF

1/16W

5%

0

R500

F-ST-SM

U.FL-R_SMT

J23

402

CERM

50V

20%

0.001uF

C100

402

CERM

10V

20%

0.1uF

C86

402

CERM

10V

20%

0.1uF

C89

+3V_MAIN

402

CERM

10V

20%

0.1uF

C90

+5V_MAIN

805

CERM

10V

N20P80%

4.7uF

C109

FEPR-1MX8

VCCVPP

DQ7

DQ4

DQ3

DQ2

DQ5
DQ6

DQ1

DQ0

GND

PWD

WP

WE

OE

CE

A19

A18

A17

A20

A16

A15

A14

A13

A12

A11

A10

A7
A8
A9

A5

A4

A3

A2

A6

A1

A0

U23

110

TSOP

+3V_MAIN

402

R49

MF

1/16W

5%

10K

402

MF

1/16W

5%

10

R50

402

CERM

10V

20%

0.1uF

C91

402

CERM

10V

20%

0.1uF

C93

402

CERM

10V

20%

0.1uF

C94

SM

L55

FERR-250-OHM

402

CERM

10V

20%

0.1uF

C98

402

MF

1/16W

5%

10

R541

402

CERM

50V

20%

0.001uF

C95

SM

L56

FERR-250-OHM

402

CERM

50V

20%

0.001uF

C92

402

R509

MF

1/16W

5%

10K

402

MF

1/16W

5%

10

R542

402

R508

MF

1/16W

5%

10K

402

R510

MF

1/16W

5%

10K

402

R511

MF

1/16W

5%

10K

402

MF

1/16W

5%

39

R540

402

MF

1/16W

5%

10

R543

+3V_SLEEP

+1_8V_SLEEP

402

CERM

10V

20%

0.1uF

C74

402

CERM

10V

20%

0.1uF

C75

402

CERM

10V

20%

0.1uF

C76

402

CERM

10V

20%

0.1uF

C73

402

MF

1/16W

5%

33

R539

402

CERM

10V

20%

0.1uF

C77

402

MF

1/16W

5%

33

R503

402

MF

1/16W

5%

47

R502

402

MF

1/16W

5%

22

R505

402

MF

1/16W

5%

47

R504

402

MF

1/16W

5%

22

R501

402

MF

1/16W

5%

22

R507

402

MF

1/16W

5%

10

R544

402

CERM

50V

20%

0.001uF

C784

805

CERM

16V

N20P80%

2.2uF

C79

SM

L12

FERR-EMI-100-OHM

TABLE_11_HEAD

CRITICAL

P59_ROM

??

40P TSOP

FEPR_1MX8

1 ? ?

IC,FLASH,1Mx8,3.3V,PROGRAMMED

341S1045

U23

TABLE_11_HEAD

CRITICAL

P88_ROM

??

40P TSOP

FEPR_1MX8

1 ? ?

IC,FLASH,1Mx8,3.3V,PROGRAMMED

341S1192

U23

TABLE_11_HEAD

REFERENCE DESIGNATOR(S)

QTY

DESCRIPTION

VALUE VOLT. WATT.

TOL.PART #

PACKAGE

DEVICE BOM OPTIONCRITICAL

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

23 46

E

051-6403

PART NUMBER

ALTERNATE FOR

PART NUMBER

BOM OPTION

REF DES

COMMENTS:

TABLE_ALT_HEAD

TABLE_ALT_ITEM

197S0602197S0702 Y1

NC
NC
NC

14.318

14.318

14.318

REF

Hi-Z

48M1

Hi-Z

Low

48

Low

Hi-Z

48M0

Low

48

48

33.41

Hi-Z

33.34

33.34
XIN/6 XIN/2 XIN XIN

14.318

14.318

14.318

48

Low
Low

33.31

33.31

33.29 Low
48
48

PCI(0:6)

66.68

66.68

66.82

Hi-Z

3V66(0:2)SDRAM(0:3)

100.23

100.02

100.02100.02

100.02

100.23

Hi-Z

CPU(0,1)

Hi-Z

XIN/2 XIN/2 XIN/3

66.63

66.58

66.63133.25

133.25

133.16

133.25

133.16

133.25

Allows PMU to control bus speed.

INTERNAL CAPACITANCE(32/2) OF THE PLL AT 16PF.

PLACE CLOSE TO C5005 (U44) GROUND

PLACE OSCILLATOR CLOSE TO PLL.
LOAD CAPACITANCE IS MATCHED TO THE

J23 USED FOR CLOCK
FREQUENCY INJECTION

0S10

S0

1

0 1

0
11

0

S2

0
0
0
1 00

0 1
1 0

11

1

1

1

SYSTEM CLOCK GENERATOR

SYSTEM CLOCK GENERATOR

/ BOOTROM

FLASH ROM

CRITICAL

21

NO STUFF

2

1

NO STUFF

2

1

2

1

2

1

NO STUFF

2

1

2

1

CRITICAL

3

2

46434238322015

54

3530 48 16 4540

9231

33

34

36

37

26

27

29

22

21

28

10

19

18

17

14

13

12

11

31

39

44

41

47

24

25

8

7

6

21

NO_BUS_STEP

2

1

2

1

2

1

NO STUFF

2

1

NEC_USB

21

BUS_STEP

2

1

BUS_STEP

21

21

NO STUFF

1

2

3

2

1

2

1

2

1

2

1

2

1

OMIT

12

9

11 3130

10

24

3923

35

34

33

32

28

27

26

25

22

7

8

14

15

16

17

18

38

19

37

13

40

1

2

3

4

5

6

36

20

21

2

1

21

2

1

2

1

2

1

21

2

1

21

2

1

21

2

1

NO STUFF

2

1

21

2

1

2

1

NO STUFF

2

1

21

21

2

1

2

1

2

1

2

1

21

2

1

21

21

21

21

21

21

21

2

1

2

1

21

CR-23

ROM_WP_L
UNIN_RESET_L

ROM_RW_L

ROM_OE_L

PCI_AD<20>

PCI_AD<19>

PCI_AD<18>

PCI_AD<17>

PCI_AD<16>

ROM_CS_L

PCI_AD<13>

PCI_AD<9>

PCI_AD<8>

PCI_AD<7>

PCI_AD<6>

PCI_AD<15>

PCI_AD<14>

PCI_AD<12>

PCI_AD<11>

PCI_AD<10>

PCI_AD<31>

PCI_AD<30>

PCI_AD<5>

PCI_AD<4>

PCI_AD<3>

PCI_AD<2>

PCI_AD<1>

PCI_AD<0>

PCI_AD<29>

PCI_AD<28>

PCI_AD<27>

PCI_AD<26>

PCI_AD<25>

PCI_AD<24>

PLL_VCC_CPU0

+3V_IMI_SLEEP

CLK14M_IMI_XIN

PLL_SDRAM_CPU1

CLK14M_SERIES

CPU_VCORE_HI_OC

FBSEL2

CLK14M_IMI_XOUT

KL_CREF2

IMI_CPUSD_STP_L

FBSEL1

FBSEL0

PMU_I2C_CLK

SYSTEM_CLK_EN

PMU_I2C_DATA

CPU_CLK_EN

PLL_AVDD

CLK33M_CBUS_UF
CLK33M_NEC_UF

CLK33M_UNIN_PCI_EXT_UF
CLK33M_KL_UF

CLK66M_AGP_UF

CLK66M_UNIN_AGP_UF

CLK66M_UNIN_PCI_INT_UF

SYSCLK_CPU_UF
SYSCLK_UNIN_UF

SYSCLK_DIMM0_A_UF
SYSCLK_DIMM0_B_UF
SYSCLK_DIMM1_A_UF
SYSCLK_DIMM1_B_UF
SYSCLK_UNIN_RDCLK_UF

CPU_CLK_EN

CLK33M_NEC

CLK33M_CBUS

CLK33M_KL_PCI

CLK66M_AGP_ATI

CLK33M_UNIN_PCI_EXT

CLK66M_UNIN_AGP

CLK66M_UNIN_PCI_INT

SYSCLK_DIMM1_B

SYSCLK_UNIN_RDCLK

SYSCLK_DIMM0_B

SYSCLK_UNIN

SYSCLK_DIMM1_A

SYSCLK_DIMM0_A

SYSCLK_CPU

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

18<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

17<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

16<>

40<>

40<>

40<>

40<>

40<>

34<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

9<>

43<>

43<>

40<>

43<>

34<>

40<>

34<>

34<>

34<>

34<>

43<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

34<>

40<>

40<>

40<>

40<>

40<>

40<>

40<>

7<>

7>

7<>

40<>

7<>

7<>

40<>

MBR0540

D17

SM

402

R205

MF

1/16W

5%

470K

TSOP

Q28

SI3443DV

+5V_SLEEP

402

R716

MF

1/16W

5%

470K

TSOP

Q61

SI3443DV

+3V_SLEEP

TSOP

Q25

SI3443DV

MBR0540

D29

SM

402

R717

MF

1/16W

5%

470K

TSOP

Q62

SI3443DV

+3V_MAIN

402

CERM

10V

20%

0.1uF

C83

OS

SCL

SDA

GND

VDD

DS1775

U20

SOT23-5

+3V_MAIN

+5V_SLEEP

402

R719

MF

1/16W

5%

0

402

R718

MF

1/16W

5%

0

OS

SCL

SDA

GND

VDD

DS1775

U55

SOT23-5

+3V_MAIN

402

CERM

10V

20%

0.1uF

C807

+3V_MAIN

OS

SCL

SDA

GND

VDD

DS1775

U56

SOT23-5-RX

402

R193

MF

1/16W

5%

470K

402

CERM

10V

20%

0.1uF

C808

402

CERM

10V

20%

0.1uF

C84

OS

SCL

SDA

GND

VDD

DS1775

U21

SOT23-5-RX

+3V_MAIN

402

CERM

10V

20%

0.1uF

C54

+3V_SLEEP

OS

SCL

SDA

GND

VDD

DS1775

U15

SOT23-5

+3V_MAIN

402

CERM

10V

20%

0.1uF

C55

OS

SCL

SDA

GND

VDD

DS1775

U16

SOT23-5-RX

+5V_MAIN

VSS

VCC

P1_7

P1_6

P1_5

P1_4

P1_3

P1_2

P1_1

P1_0

SMP

XRES
P0_0

P0_1
P0_2
P0_3
P0_4
P0_5
P0_6
P0_7

SSOP

CY8C26233

U13

V+ VO
GND

NC

GND

SC70-5

LM20

U29

SM-2MT

J9

+5V_MAIN

+5V_MAIN

+5V_MAIN

SM-2MT

J31

V+ VO
GND

NC

GND

SC70-5

LM20

U35

V+ VO
GND

NC

GND

SC70-5

LM20

U38

402

R257

MF

1/16W

5%

1K

402

R258

MF

1/16W

5%

1K

402

CERM

10V

20%

0.1uF

C42

402

CERM

10V

20%

0.1uF

C31

402

CERM

10V

20%

0.1uF

C30

402

MF

1/16W

5%

0

R286

402

CERM

10V

20%

0.1uF

C39

805

R277

FF

1/10W

5%

0

+3V_MAIN

402

R345

MF

1/16W

5%

10K

805

R347

FF

1/10W

5%

0

+5V_SLEEP

805

CERM

10V

20%

1uF

C253

805

CERM

10V

20%

1uF

C894

402

MF

1/16W

5%

0

R317

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

24 46

E

051-6403

CRITICAL BOM OPTION

TABLE_5_HEAD

PART#

DESCRIPTION

QTY

REFERENCE DESIGNATOR(S)

TABLE_5_ITEM

P88_FAN

341S1189

1

IC,MCU,PGRMD,CY8C26233,CP6099AMT

U13

P88 FAN CIRCUIT: P88_FAN + P88_P59_FAN_2

P59 DUAL FAN : P59_BOTH + P59_FAN_2 + P88_P59_FAN_2 + P59_PS_TEMP_SNS

P59 SINGLE FAN : P59_BOTH + P59_FAN_1 + P59_PS_TEMP_SNS

CYPRESS PSOC CONTROLLER

FAN2_ON_HIGH_L

FAN1_ON_HIGH_L

DUAL FAN CIRCUIT

NOTE: FAN IS POWERED AT

3.0V IN LOW-SPEED MODE AND

5.0V IN HIGH-SPEED MODE.

NEAR ATI GRAPHICS CHIP.

IMPORTANT: THESE SENSORS WILL USE SAME I2C ADDRESSES SO ONLY

ONE GROUP (ATI OR PS) CAN BE STUFFED AT A TIME!

IN POWER SUPPLY AREA.

NOTE: PLACE THESE SENSORS

NOTE:PLACE THE SENSORS

NEAR THE CPU (U10)

NOTE: PLACE THESE SENSORS

FAN CIRCUIT OPTION

NOTE: FAN IS POWERED AT

5.0V IN HIGH-SPEED MODE.

3.0V IN LOW-SPEED MODE AND

DUAL-SPEED FAN CIRCUIT

NC

NC

NC

NC

NC

NC

NOTE: PLACE NEAR POWER SUPPLY

NC

NOTE: PLACE NEAR ATI

NC

NOTE: PLACE NEAR CPU (U10)

PCB TEMPERATURE SENSORS

P59_BOTH

21

P59_BOTH

2

1

P59_BOTH

4

3 6

5
2
1

P88_P59_FAN_2

2

1

P88_P59_FAN_2

4

3 6

5
2
1

CHGND1

4

3 6

5
2
1

P59_FAN_2

21

P59_FAN_2

2

1

P59_FAN_2

4

3 6

5
2
1

P59_BOTH

2

1

P59_BOTH

4

5

1

3

2

P59_FAN_1

2

1

P59_FAN_1

2

1

P59_PS_TEMP_SNS

4

5

1

3

2

P59_PS_TEMP_SNS

2

1

P59_PS_TEMP_SNS

4

5

1

3

2

2

1

P59_PS_TEMP_SNS

2

1

P59_BOTH

2

1

P59_BOTH

4

5

1

3

2

P59_ATI_TEMP_SNS

2

1

P59_ATI_TEMP_SNS

4

5

1

3

2

P59_ATI_TEMP_SNS

2

1

P59_ATI_TEMP_SNS

4

5

1

3

2

OMIT

15

10

20

5

6

14

7

13

8

12

9

11

1

19

2

18

3

17

4

16

P88_FAN

34

1

5

2

CRITICAL

3

2

1

5

4

CRITICAL

P88_P59_FAN_2

3

2

1

5

4

P88_FAN

34

1

5

2

P88_FAN

34

1

5

2

2

1

2

1

P88_FAN

2

1

P88_FAN

2

1

P88_FAN

2

1

P88_FAN

21

P88_FAN

2

1

P88_FAN

2

1

2

1

NO STUFF

2

1

2

1

P88_P59_FAN_2

2

1

P88_FAN

21

CR-24

FEEDBACK_2_F

CPU_TEMP

GND_REF

ATI_TEMP

GND_REF

PS_TEMP

GND_REF

UNIN_I2C_DATA1

FAN_2

UNIN_I2C_CLK1

FAN_1

FEEDBACK_1

GND_REF

CPU_TEMP

PS_TEMP

ATI_TEMP

UNIN_I2C_DATA0

UNIN_I2C_CLK0

FEEDBACK_1

FAN_PWR_LOW

FAN2_PWR_LOW

FAN_2

FAN2_ON_LOW_L

UNIN_I2C_CLK0

UNIN_I2C_DATA0

UNIN_I2C_DATA1

UNIN_I2C_CLK1

FEEDBACK_2

PMU_TEMP_F

PMU_TEMP

FAN1_ON_LOW_L

CY_VCC

FAN2_PWR

FAN_PWR

FAN_1

FEEDBACK_2

FEEDBACK_2_F

SCLK_CYP

XRES_CPY_SPN

7<>

7<>

7<>

7<> 7<>

7<>

7<>

7<>

10<>

10<>

10<>

10<> 10<>

10<>

10<>

10<>

24<>

24<>

24<>

24<> 24<>

24<>

24<>

24<>

24<

24<>

24<>

24<>

24<>

24<>

24<>

10<

24<>

10<

24<>

24<>

24<

24<

24<

24<

10<

10<

24<> 43<>

43<>

24<>

10<

10<

10<

10<

24<

34<>

43<>

43<>

24<>

24<> 24<>

SHUT

PLUS5VTAP

LP2951

ERR

FDBK

GND

SENSE

OUT

IN

VR1

SOI

402

R38

MF

1/16W

1%

100K

402

R58

MF

1/16W

1%

60.4K

402

MF

1/16W

5%

10

R64

402

CERM

16V

20%

0.01UF

C777

805

CERM

10V

N20P80%

4.7UF

C770

402

CERM

16V

20%

0.01UF

C774

805

CERM

10V

N20P80%

4.7UF

C151

805

CERM

10V

20%

1UF

C119

402

CERM

10V

20%

0.1UF

C120

402

CERM

10V

20%

0.1UF

C145

805

FF

1/10W

1%

5.11

R617

C811

1UF

805

CERM

10V

20%

C799

0.01UF

402

CERM

16V

20%

402

R59

MF

1/16W

5%

10K

402

R63

MF

1/16W

5%

10K

402

CERM

10V

20%

0.1UF

C113

+5V_SLEEP

XTLIN0

XTIN1/MCLK

AINRP

AINRM

AINLP

AINLM

LINA
LINB

RINA
RINB

AOUTR

AOUTL

SDIN2

SDIN1

SDOUT0
SDOUT1
SDOUT2

GPI1

GPI0

GPI2

GPI4
GPI5

GPI3

IFM/S
ALLPASS

CS1

CAP_PLL
CLKSEL

VREFP

VREFM

PWR_DN
RESET

TEST

DVDD AVDD

NC0
NC1

AVSS

(REF)

AVSSDVSS

MCLKO

SDA

VRFILT

INPA

SCL

SCLK/O

VCOM

LRCLK/O

U57

TAS3004

PQFP

805

CERM

50V

5%

1200pF

C810

805

CERM

50V

5%

1200pF

C798

402

CERM

10V

20%

0.1UF

C809

C812

10UF

20%

6.3V
TANT
SMA

402

CERM

10V

20%

0.1UF

C813

402

CERM

10V

20%

0.1UF

C815

C814

22UF

10%

6.3V
TANT
SMA

603

MF

1/16W

5%

2.2

R616

603

MF

1/16W

5%

2.2

R615

805

CERM

6.3V

20%

10UF

C797

603

MF

1/16W

1%

24.9K

R228

402

R618

MF

1/16W

5%

0

402

R619

MF

1/16W

5%

0

603

MF

1/16W

1%

24.9K

R614

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

25 46

E

051-6403

(PD at KL)

SNAPPER (AUDIO CODEC W/ EQ)

SNAPPER CONTROL

NC

NC

NC

NC

NC
NC

NC
NC
NC

NC

NC

NC

NC

NC

NC

NC

PLACE VR1 CLOSE TO TASC3004

PLACE THESE CAPS NEAR TAS3004C

3V AUDIO POWER SUPPLY

3

2

6

18

4

7

5

2

1

2

1

21

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2 1

2 1

2 1

2

1

NO STUFF

2

1

1

2

13
14

2

44

45

38

9

24

26

25

23

22

16

20

15

41

40

6

8

36

34

12

19

48

1

5

21

33

32

31

30

29

28

18

17

7

11

10

34

35

37

39

27

42

43

47

46

2

1

2

1

2

1

2

1

2

1

2

1

2

1

21

21

2

1

21

2

1

NO STUFF

2

1

21

CR-25

SNDOUT0_FB

AUDIO_RESET_L

+AUD3V

PWR3V_STAR_GND

AUD3V_FDBK

+AUD3V

VREFP

VREFM

CS_1

TI_CAP

TI_AVSS

TI_CAP_PLL

AIN_R_P

AIN_R_M

PWR3V_STAR_GND

LINE_IN_B

SND_CLKOUT

AIN_L_M
AIN_L_P

LINE_IN_L

LINE_IN_R
MIC_IN

AOUTR

AOUTL

SND_TO_AUDIO

TAS_SNDOUT0

FIL_DIG3V

FIL_AUD3V

PWR3V_STAR_GND

KL_I2C_DATA

TI_VRFILT

KL_I2C_CLK

SND_SCLK

TI_VCOM

SND_SYNC

PWR3V_STAR_GND

SND_TO_KL

16<

16<

43<>

43<>

43<>

43<>

32<>

32<>

43<>

16<>

43<>

26<>

43<>

26<>

26<>

40<>

26<

26<

43<>

43<>

26<>

16<>

16<>

16<

16<

26<>

402

CERM

10V

20%

0.1uF

C368

C369

100pF

402

CERM

50V

5%

C8

100pF

402

CERM

50V

5%

805

CERM

50V

20%

0.1uF

C416

C7

0.1uF

402

CERM

10V

20%

C402

0.1uF

402

CERM

10V

20%

402

MF

1/16W

1%

20K

R5

402

MF

1/16W

1%

20K

R300

402

MF

1/16W

5%

36K

R6

402

MF

1/16W

5%

36K

R299

SM-2MT

J19

F-RT

TH

J8

SM

L24

400-OHM-EMI

SM

L28

400-OHM-EMI

SM

L37

400-OHM-EMI

402

CERM

50V

5%

100pF

C201

SM-1

L36

400-OHM-EMI

402

CERM

50V

5%

100pF

C173

402

CERM

50V

5%

100pF

C183

SM-1

L25

400-OHM-EMI

402

MF

1/16W

5%

100K

R146

402

CERM

50V

20%

0.001uF

C182

SM-1

L41

400-OHM-EMI

402

R166

MF

1/16W

1%

10K

C242

47uF

SMD-1

TANT

6.3V

20%

C294

47uF

SMD-1

TANT

6.3V

20%

S

D

G

Q33

2N7002

SM

402

R411

MF

1/16W

5%

100K

402

R388

MF

1/16W

5%

100K

402

MF

1/16W

5%

24

R154

SM

L27

400-OHM-EMI

402

MF

1/16W

5%

100K

R225

C435

0.47uF

805

CERM

16V

20%

C589

0.47uF

805

CERM

16V

20%

402

MF

1/16W

1%

20K

R361

402

MF

1/16W

1%

32.4K

R376

402

MF

1/16W

1%

32.4K

R377

402

MF

1/16W

1%

20K

R375

+5V_MAIN

+5V_MAIN

402

CERM

16V

20%

0.01uF

C466

805

CERM

10V

N20P80%

4.7uF

C590

D19

BAS40-4

SOT23

IN1

IN2

CBYPASS

OUT2

MUTE

SVCC

OUT1

VCC

GND

BIAS

MAX4298

SOI

U43

XW3

SM

XW2

SM

XW4

SM

XW13

SM

50R28

ZH1

402

MF

1/16W

5%

24

R145

XW14

SM

XW17

SM

+5V_SLEEP

402

R153

MF

1/16W

1%

10K

SOT23

15V

D11

OUT_B-

VDD

VDD1

SHUTDOWN
HP_IN

IN_A+

IN_A-

IN_B+

IN_B-

OUT_A­OUT_A+

OUT_B+

GND2

GND

GND1

BYPASS

NC

TSSOP

LM4863

U34

402

R229

MF

1/16W

5%

100K

S

D

G

Q3

2N7002

SM

402

R236

MF

1/16W

5%

100K

+5V_MAIN

SM-1

L51

400-OHM-EMI

C43

330uF

20%

6.3V
TANT

SMD

XW5

SM

C14

100pF

402

CERM

50V

5%

C15

100pF

402

CERM

50V

5%

805

CERM

10V

20%

1uF

C465

805

CERM

10V

20%

1uF

C515

805

CERM

10V

N20P80%

4.7uF

C386

402

CERM

10V

20%

0.1uF

C857

XW29

SM

402

R683

MF

1/16W

1%

24.9K

402

R684

MF

1/16W

1%

100K

SM

U61

LMC7211

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

26 46

E

051-6403

NC

NC

NC

NC

NC

AUDIO STAR GROUND

BOOMER SPEAKER AMP

PLACE L’s & C’s NEAR CONNECTOR

SPEAKER/MIC CONNECTOR

HEADPHONE CONNECTOR

HEADPHONE/SPEAKERS

HEADPHONE AMP

HEADPHONE DETECTION

2

1

21

21

2

1

21

21

21

21

21

21

CRITICAL

6

5

4

3

2

1

8

7

CRITICAL

4

3

2

1

6

5

21

21

21

2

1

21

2

1

2

1

CHGND3

21

21

2

1

21

2

1

21

21

2

1

3

2

1

2

1

21

21

21

21

21

21

21

21

21

2

1

2

1

3

2

1

CRITICAL

10

5

9

1

68

3

27

4

21

21

21

21

1

21

21

21

1

2

3

2

1

17

4

1

16
18

5
3

12

11

10

9

15
13

6
8

20

19

7

2

14

2

1

2

1

3

1

2

12

2

1

21

21

21

212

1

2

1

2

1

21

2

1

2

1

2

5

1

3

4

CR-26

HP_SENSE_NEG_INPUT

HP_DET

HP_SENSE_POS_INPUT

SND_HP_SENSE

HP_DET_CONN

BOOMER_STAR_GND

HP_AMP_SVCC_STAR_GND

BOOMER_STAR_GND

SPKR_STAR_GND

PWR4V_STAR_GND

PWR3V_STAR_GND

SPKR_STAR_GND

MIC_STAR_GND

LINE_OUT_STAR_GND

MAX4298_IN1

LINE_OUT_L

MAX4298_IN2

LINE_OUT_R

AOUTR

AOUTR_FILTER

AOUTL

AOUTL_FILTER

HP_AMP_SVCC_STAR_GND

MAX4298_SVCC

LINE_OUT_STAR_GND

4863_SHDN

MAX4298_VCC

T_FILTR_OUT_L

T_FILTR_OUT_R

FILTER2_OUT_L

FILTER2_OUTR

FILTER_OUT_L

LINE_OUT_STAR_GND

T_FILTR_RL

FILTER_OUT_R

LINE_OUT_STAR_GND

MAX4298_CBYPASS

MAX4298_BIAS

MAX4298_MUTE

SND_HP_MUTE_L

MIC_HIGH
MIC_LOW

4863_BYPASS

SCREAMER_OUT_CR_F

AOUTR_BOOMER

AOUTR

TI_AVSS

AUDIO_OUT_R

AUDIO_OUT_L

ACOUT

AOUTL_BOOMER

AOUTL

SCREAMER_OUT_CL_F

SND_AMP_MUTE_L

L_SPKR_POS

L_SPKR_NEG

R_SPKR_POS

R_SPKR_NEG

26<

26<

43<>

43<>

27<

25<

26<

43<>

26<

43<> 43<>

43<> 43<>

25<

16<>

43<>

43<>

26<>

26<>

43<>

43<>

43<>

27<>

43<>

25>

25>

26<>

43<>

26<>

43<>

26<> 26<>

16<>

27<

27<>

25>

43<>

25>

16<>

C840

4.7uF

1210

CERM

25V

20%

C842

4.7uF

1210

CERM

25V

20%

C841

10uF

1206

CERM

6.3V

20%

V-

V+

TLV2362

U58

SOI

V-

V+

TLV2362

U58

SOI

402

R180

MF

1/16W

1%

49.9K

402

R226

MF

1/16W

1%

20K

402

CERM

10V

20%

0.1UF

C796

SHUT

PLUS5VTAP

LP2951

ERR

FDBK

GND

SENSE

OUT

IN

VR2

SOI

805

CERM

16V

N20P80%

1.0uF

C839

+5V_SLEEP

402

MF

1/16W

5%

4.7

R653

V-

V+

TLV2362

U59

SOI

402

MF

1/16W

5%

9.1K

R661

402

MF

1/16W

5%

470K

R662

C855

22pF

603

CERM

50V

5%

402

R638

MF

1/16W

5%

200

C856

0.47UF

805

CERM

16V

20%

SM

L79

1000-OHM-EMI

SM

L78

1000-OHM-EMI

SM

L76

1000-OHM-EMI

SM

L77

1000-OHM-EMI

C844

120PF

402

CERM

50V

5%

C847

0.47UF

805

CERM

16V

20%

V-

V+

TLV2362

U59

SOI

402

R655

MF

1/16W

5%

2.2K

402

MF

1/16W

5%

330

R656

402

R657

MF

1/16W

5%

47K

C852

0.1UF

402

CERM

10V

20%

C849

2.2UF

20%
16V
TANT
SMA

402

MF

1/16W

5%

4.7

R654

C843

120PF

402

CERM

50V

5%

402

MF

1/16W

1%

27.4K

R645

402

MF

1/16W

1%

10.7K

R651

SM

2N3904

Q53

SM

2N3904

Q54

402

R658

MF

1/16W

5%

12K

402

R660

MF

1/16W

5%

33K

XW28

SM

C845

2.2UF

20%
16V

TANT

SMA

C848

0.47UF

805

CERM

16V

20%

402

R659

MF

1/16W

5%

12K

402

CERM

50V

5%

100pF

C838

402

CERM

50V

5%

100pF

C837

402

CERM

50V

5%

100pF

C836

402

CERM

50V

5%

100pF

C835

TH1

F-RT-3050100

J30

402

R17

MF

1/16W

5%

47K

402

CERM

16V

20%

0.01uF

C23

402

CERM

50V

20%

0.001uF

C19

402

R15

MF

1/16W

5%

470K

402

CERM

16V

20%

0.01uF

C850

402

CERM

16V

20%

0.01uF

C846

402

MF

1/16W

5%

47K

R16

+5V_SLEEP

805

CERM

10V

N20P80%

4.7uF

C853

402

CERM

50V

10%

470pF

C851

805

CERM

10V

N20P80%

4.7uF

C854

SM

L80

1000-OHM-EMI

402

MF

1/16W

1%

10.7K

R649

402

MF

1/16W

1%

10.7K

R650

402

MF

1/16W

1%

10.7K

R652

402

MF

1/16W

1%

27.4K

R646

402

MF

1/16W

1%

27.4K

R647

402

MF

1/16W

1%

27.4K

R648

402

R642

MF

1/16W

1%

100K

402

R643

MF

1/16W

1%

100K

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

27 46

E

051-6403

LINE IN

CONNECTOR

LINE IN AMPLIFIER

4V AUDIO POWER SUPPLY

Span ground moat using L80

MIC & LINE-IN INPUTS

NCNC

NC

MICROPHONE AMPLIFIER

21

21

21

CRITICAL

8

4

7

6

5

CRITICAL

8

4

1

2

3

2

1

2

1

1

23

2

6

18

4

7

5

2

1

21

CRITICAL

8

4

1

2

3

21 21

21

2

1

21

CHGND2

21

21

21

21

2 1

2 1

CRITICAL

8

4

7

6

5

2

1

21

2

1

21

2

1

21

2 1

21

21

2

3

1

2

3

1

2

1

2

1

MIC_STAR_GND

21

2

1

2 1

2

1

2

1

2

1

2

1

2

1

CRITICAL

4

3

2

1

6

5

2

1

2

1

2

1

2

1

2

1

2

1

21

2

1

2

1

2

1

21

21

21

21

21

21

21

2

1

1

2

CR-27

SOI
TLV2362

MIC_DIFF_IN

MIC_GAINED

AUDIO_REF

MIC_HIGH

MIC_DIVIDER

MIC_LOW

+AUD4V

PWR4V_STAR_GND

AUDIO_REF_2V

AUDIO_REF_3V

MIC_POLA

+AUD4V_F2

PWR4V_STAR_GND

+AUD4V_F1

LINE_IN_L

SUDO_L

SUDO_GND

MIC_GALVA

MIC_IN

PWR4V_STAR_GND

AUD4V_FDBK

+AUD4V

LIN_DET_EMI

RCH_GALVA

SUDO_R_M

GND_GALVA

LCH_GALVA

SUDO_L_P

SUDO_L_M

SUDO_R

SUDO_R_P

LINE_IN_R

PWR4V_STAR_GND

SND_LIN_SENSE

LIN_DET

LIN_DET_EMI

LIN_GND

LIN_RCH

LIN_SNS

LIN_LCH

LCH_HZ

GND_HZ

RCH_HZ

43<>

43<>

43<>

43<>

43<>

26<>

26<>

26<>

43<>

26<>

43<>

26<>

43<>

26<>

43<>

26<>

16<>

402

R246

MF

1/16W

1%

49.9

402

R247

MF

1/16W

1%

49.9

402

R244

MF

1/16W

1%

49.9

402

R245

MF

1/16W

1%

49.9

402

MF

1/16W

5%

33

R392

402

CERM

10V

20%

0.1uF

C422

402

CERM

10V

20%

0.1uF

C390

402

CERM

10V

20%

0.1uF

C488

402

CERM

16V

20%

0.01uF

C377

402

CERM

10V

20%

0.1uF

C531

1808

CERM

3KV

10%

100pF

C175

402

CERM

16V

20%

0.01uF

C487

402

CERM

10V

20%

0.1uF

C468

805

CERM

6.3V

20%

10uF

C423

TH-2MT

J2

402

R250

MF

1/16W

1%

49.9

402

R248

MF

1/16W

1%

49.9

402

R251

MF

1/16W

1%

49.9

402

R249

MF

1/16W

1%

49.9

SM1

1/16W

5%

33

RP6

SM1

1/16W

5%

33

RP5

402

CERM

16V

20%

0.01uF

C421

402

CERM

16V

20%

0.01uF

C419

402

CERM

16V

20%

0.01uF

C486

SM

L48

FERR-EMI-600-OHM

402

CERM

10V

20%

0.1uF

C374

402

MF

1/16W

5%

33

R391

XFR-ENET-1000BT

SM

T1

402

CERM

50V

20%

0.001uF

C323

402

CERM

50V

20%

0.001uF

C326

402

CERM

50V

20%

0.001uF

C325

402

CERM

50V

20%

0.001uF

C324

402

MF

1/16W

5%

33

R393

402

R323

MF

1/16W

5%

470K

805

CERM

10V

20%

1uF

C35

+3V_MAIN

402

R445

MF

1/16W

5%

10K

402

R135

MF

1/16W

5%

75

402

R134

MF

1/16W

5%

75

402

R133

MF

1/16W

5%

75

402

R132

MF

1/16W

5%

75

+3V_MAIN

+2_5V_MAIN

+1_8V_MAIN

G

D

S

SOT-363

2N7002DW

Q34

G

D

S

SOT-363

2N7002DW

Q34

O_VDD

NC

AGND

AVDDL

AVDD

2.5V_EN

REGSUP2

XTALVDD

PLLGND

PLLVDD

BIASVDD

RDAC

DVDD

LVDD

DGND

REGSEN1
REGSUP1

REGSEN2

(1 OF 2)

BGA

BCM5421

U8

TXC
TX_EN
TX_ER

TXD7

TXD6

TXD0
TXD1

TXD2
TXD3
TXD4
TXD5

GTX_CLK
CRS
COL

RXC

RXD0
RXD1

RXD2
RXD3
RXD4

RX_DV
RX_ER

RXD5
RXD6

PHYA0

RXD7

PHYA1
PHYA2
PHYA3
PHYA4

FDX
HUB
ER
ANEN/SLAVE

EN_10B

WIRESPD
RGMIIEN

RBC0

MANMS

RBC1

RESET

CLK125
XTALI

XTALO

MDC

MDIO

TRST

TDI

TEST0

TEST1

TCK

SPD0

F1000

FDXLED
XMTLED

RCVLED

INTR

LINK1
LINK2

TRD0+
TRD0-

TRD1+
TRD1­TRD2+
TRD2­TRD3+
TRD3-

(2 OF 2)

LOWPWR

TMS

TDO

QUALITY

U8

BCM5421

BGA

603

CERM

50V

10%

33pF

C570

Y5

SM-2

25.0000M

603

CERM

50V

10%

33pF

C530

402

R382

MF

1/16W

5%

4.7K

402

MF

1/16W

1%

1.24K

R33

805

CERM

10V

20%

1uF

C467

402

CERM

50V

20%

0.001uF

C436

402

CERM

16V

20%

0.01uF

C469

402

CERM

16V

20%

0.01uF

C438

402

CERM

10V

20%

0.1uF

C485

805

CERM

10V

N20P80%

4.7uF

C392

805

CERM

10V

N20P80%

4.7uF

C518

603

MF

1/16W

5%

1

R322

603

R279

MF

1/16W

5%

0

603

R288

MF

1/16W

5%

0

402

CERM

16V

20%

0.01uF

C376

402

CERM

10V

20%

0.1uF

C391

805

CERM

6.3V

20%

10uF

C356

402

CERM

16V

20%

0.01uF

C375

402

CERM

10V

20%

0.1uF

C357

1N914

SOT23

D21

603

MF

1/16W

5%

0

R380

603

MF

1/16W

5%

0

R289

603

MF

1/16W

5%

0

R278

SM1

1/16W

5%

33

RP6

SM1

1/16W

5%

33

RP6

SM1

1/16W

5%

33

RP6

SM1

1/16W

5%

33

RP5

SM1

1/16W

5%

33

RP5

SM1

1/16W

5%

33

RP5

402

CERM

16V

20%

0.01uF

C867

402

CERM

10V

20%

0.1uF

C866

402

CERM

10V

20%

0.1uF

C420

805

CERM

6.3V

20%

10uF

C437

402

MF

1/16W

5%

1K

R713

402

R381

MF

1/16W

5%

1.5K

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

28 46

E

051-6403

PART NUMBER

ALTERNATE FOR

PART NUMBER

BOM OPTION

REF DES

COMMENTS:

TABLE_ALT_HEAD

TABLE_ALT_ITEM

197S0603197S0703 Y5

TX to RX group line spacing should be 8 mils

IDDQ (SLEEP) LOGIC

WHEN ASLEEP ON BATTERY

PLACES PHY IN IDDQ MODE

PLACE NEAR PHY PIN H3

PLACE NEAR PHY PINS J3,J4

PLACE NEAR PHY PINS A5,A6

PLACE ALL SERIES RES CLOSE TO PHY

NC-IPD

NC

NC

NC-IPD
NC-IPD

NC-IPD

NC-IPU

NC-IPU

NC-IPD

NC-IPD

NC-IPD

NC-IPD

NC-IPD

NC-IPD

NC-IPD

NC-IPU

NC-IPD

NC

NC

NC

NC

NC

Short shielded RJ-45

NC

NC
NC

PUT CRYSTAL CIRCUIT CLOSE TO PHY

ETHERNET

1. Decoupling caps

MDI pairs and all RJ45 pairs

parallel, matched lengths, with minimum

Ethernet routing priority:

via count, and short if possible

All differential signals should be close,

Must maintain 50-ohms trace impedance on all

2. TX SERIES TERMINATION - LOCATE NEAR LINK

3. RX SERIES TERMINATION - LOCATE NEAR PHY

PLACE NEAR PHY PIN J1

CLOSE TO PIN 1 4 7 10

PLACE NEAR PHY PIN E1

PLACE CAPS CLOSE TO TRANSFORMER

PLACE RESISTORS CLOSE TO PHY

Sandwich each RJ45 pair between chassis grounds

NC
NC

PLACE NEAR PHY PINS D1,C1

PLACE NEAR PHY PIN F3

PLACE NEAR PHY PINS D10,C10

PLACE NEAR PHY PINS G1,J2,J8

PLACE NEAR PHY PINS H2,G3

2

1

2

1

2

1

2

1

21

CHGND1

2

1

2

1

2

1

2

1

2

1

CHGND1

2

1

2

1

2

1

2

1

CRITICAL

8

7

6

5

4

3

2

1

9

10

2

1

2

1

2

1

2

1

72

81

2

1

2

1

2

1

12

2

1

21

CRITICAL

24

21

18

15

22

19

16

13

23

20

17

14

3

6

9

12

2

5

8

11

1

4

7

10

2

1

2

1

2

1

2

1

21

2

1

2

1

2

1

2

1

2

1

2

1

2

1

4

5

3

1

2

6

G1

H2

G3

H3

F3

H1

E1
E2

A6

A5

F9

F7

C10

C1

D10

D1

D9

D2

C9

C2

J1

J4

J3

J8

J2

J7

J6

J5

H5

F2

F1

H7

F6

A9

A8

A10

B10

B9

B8

B7

B6

C8

C7

C6

E10

K7

K8

K6

K5

K3

K4

K2

K1

D8

H9

H8

F10

D6

D7

H4

A1

B2

B3

B4

B5

C5

C4

C3

D3

D4

A2

E8

E4

H6

A3

A4

E7

K9

K10

J9

J10

H10

F4

E3

F8

F5

G6

G7

G10

E6

A7 G8

E9

G4

G2

G5

E5
D5

B1

G9

2

1

CRITICAL

21

2

1

2

1

21

2

1

2

1

2

1

2

1

2

1

2

1

2

1

21

2_5V_ENET_CTAP

2

1

1_8V_ENET_CTAP

2

1

2

1

2

1

2

1

2

1

2

1

3

1

21

21

21

81

54

63

72

54

63

2

1

2

1

2

1

2

1

2 1

2

1

CR-28

KL_ENET_RST_L

+1_8V_ENET

AC_IN

+3V_ENET

ENET_AVDDL

ENET_DVDDL

+ENET_CTAP

+1_8V_ENET+2_5V_ENET

ENET_AVDDL

ENET_PLLVDD

+2_5V_ENET

ENET_AVDD

+3V_ENET

CLK_ENET_LINK_TX

ENET_GBE_REFCLK

RJ45_DN<3>

RJ45_DN<2>
RJ45_DP<3>

RJ45_DP<2>

RJ45_DN<1>

RJ45_DN<0>
RJ45_DP<1>

RJ45_DP<0>

RJ45_C0_PD

RJ45_C1_PD

RJ45_C2_PD

RJ45_C3_PD

ENET_CTAP_CHGND

SLEEP_L_LS5

ENET_PWR_EN_L

ENET_AVDDL

ENET_DVDDL
+1_8V_ENET

ENET_DVDDL

ENET_DVDDL

ENET_DVDDL
ENET_DVDDL

+1_8V_ENET

ENET_PLLVDD

ENET_AVDD

ENET_RDAC

ENET_AVDDL

+2_5V_ENET

+2_5V_ENET

+2_5V_ENET

+3V_ENET

IO_RESET_L

+3V_ENET

JTAG_ASIC_TRST_L

ENET_PHY_TXD<7>

ENET_PHY_TXD<6>

ENET_PHY_TXD<5>

ENET_PHY_TXD<4>

ENET_PHY_TXD<3>

ENET_PHY_TXD<2>

ENET_PHY_TXD<1>

ENET_PHY_TXD<0>

CLKENET_PHY_TX

MDI_M<3>

MDI_P<3>

MDI_M<2>

MDI_P<2>

MDI_M<1>

MDI_P<1>

MDI_M<0>

MDI_P<0>

ENET_ENERGY_DET

JTAG_ASIC_TCK
JTAG_ENET_TDI

ENET_MDC

ENET_PHY_TX_EN
ENET_PHY_TX_ER

ENET_PHY_GTX_CLK
ENET_CRS
ENET_COL

ENET_RX_DV
ENET_RX_ER

ENET_WIRESPEED_EN

ENET_PWR_EN_L

JTAG_ASIC_TMS

JTAG_ASIC_TDO_SPN

CLK25M_ENET_XOUT

ENET_PHY_GBE_REFCLK

CLK25M_ENET_XIN

ENET_MDIO

ENET_PHY_RXD<0>

ENET_RXD<2>

ENET_RXD<0>

CLKENET_PHY_RX

CLK_ENET_LINK_RX

ENET_RXD<1>

ENET_RXD<3>

ENET_RXD<5>

ENET_RXD<7>

ENET_PHY_RXD<7>

ENET_PHY_RXD<5>

ENET_RXD<6>

ENET_PHY_RXD<6>

ENET_RXD<4>

ENET_PHY_RXD<4>

ENET_PHY_RXD<3>

ENET_PHY_RXD<2>

ENET_PHY_RXD<1>

ENET_RST_L

35<

40<>

39<>

42<>

10<

10<

10<

10<

42<>

16<>

43<>

34<

43<>

43<>

43<>

43<>

43<> 43<>

43<>

43<>

43<>

43<>

43<>

40<>

10>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

37<>

28<

43<>

43<>

43<>

43<>

43<>

43<>

43<>

43<>

43<>

43<>

43<>

43<>

43<>

43<>

43<>

34<>

43<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

40<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

16<>

16>

10>

42<>

42<>

40<>

42<>

42<>

42<>

42<>

28<>

40<>

10<>

42<>

42<>

42<>

40<>

40<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

805

CERM

10V

20%

1uF

C355

805

CERM

50V

5%

220pF

C260

VGND

VP

TPI#

TPI

TPO#

TPO

TH-1

J7

402

R201

MF

1/16W

1%

56.2

402

R199

MF

1/16W

1%

4.99K

402

R200

MF

1/16W

1%

56.2

402

R203

MF

1/16W

1%

56.2

402

R202

MF

1/16W

1%

56.2

603

CERM

50V

20%

0.01uF

C186

603

CERM

50V

20%

0.01uF

C174

SM

FL1

402

CERM

10V

20%

0.1uF

C28

402

CERM

10V

20%

0.1uF

C373

402

CERM

10V

20%

0.1uF

C344

402

CERM

10V

20%

0.1uF

C345

402

CERM

10V

20%

0.1uF

C313

402

CERM

10V

20%

0.1uF

C389

603

CERM

50V

5%

22pF

C261

603

CERM

50V

5%

22pF

C404

402

MF

1/16W

5%

22

R183

402

MF

1/16W

5%

22

R192

402

MF

1/16W

5%

22

R181

SM1

1/16W

RP18

22
5%

SM1

1/16W

RP12

22
5%

Y4

SM-2

24.576M

10BQ040

D1

SM

402

R171

MF

1/16W

5%

470K

402

CERM

16V

20%

0.01uF

C203

402

R157

MF

1/16W

5%

330K

S

D

G

Q22

2N7002

SM

Q2

SOI

NDS9407

805

CERM

10V

20%

1uF

C387

805

CERM

10V

20%

1uF

C353

402

R321

MF

1/16W

5%

1K

402

R320

MF

1/16W

5%

10K

402

R25

MF

1/16W

5%

10K

402

R27

MF

1/16W

5%

10K

402

MF

1/16W

5%

22

R34

402

MF

1/16W

5%

10K

R189

+3V_MAIN

+PBUS

SM

L26

FERR-250-OHM

PC2

PC1

PC0

TESTM

D7

D6

D5

D4

D3

D2

D1

D0

CTL1

CTL0

SYSCLK

PLLVDD

LREQ

LPS

ISO

RESET

SM

SE

PD

XO

XI

CPS

FILTER1

FILTER0

DGND3

DGND2

DGND1

AGND3

AGND2

AGND1

DVDD3

DVDD2

DVDD1

AVDD2

AVDD1

PLLGND

C_LKON

TPB-

TPB+

TPA-

TPA+

TPBIAS

R1

R0

TSB41AB1

FLAS

U5

402

CERM

10V

20%

0.1uF

C29

402

CERM

50V

20%

0.001uF

C388

402

CERM

50V

20%

0.001uF

C403

SM

L49

FERR-EMI-100-OHM

402

R238

MF

1/16W

5%

1K

402

R23

MF

1/16W

1%

422K

402

CERM

10V

20%

0.1uF

C354

402

R204

MF

1/16W

1%

6.34K

603

CERM

50V

5%

12pF

C309

603

CERM

50V

5%

12pF

C310

603

CERM

50V

5%

12pF

C312

603

CERM

50V

5%

12pF

C311

10BQ040

D25

SM

805

FF

1/10W

5%

0

R704

D27

SOT-363

BAV99DW

D27

SOT-363

BAV99DW

D28

SOT-363

BAV99DW

D28

SOT-363

BAV99DW

SM

0.9AMP-33V

F2

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

29 46

E

051-6403

PART NUMBER

ALTERNATE FOR

PART NUMBER

BOM OPTION

REF DES

COMMENTS:

TABLE_ALT_HEAD

TABLE_ALT_ITEM

197S0606197S0706 Y4

REFERENCE DESIGNATOR(S)

BOM OPTION

TABLE_5_HEAD

QTY

DESCRIPTION

PART#

TABLE_5_ITEM

740S0527

1

OVERCURRENT PROTECTOR,0.75A,30V,SMB

F2

Allows sleep/shutdown charging
of peripherals when on adapter

PORT POWER SWITCH

to FW PHY..

PLLVDD (U5 PIN 40)

PLACE C354 CLOSE TO

CLEAR OUT ALL PLANES UNDER TRANSFORMERS

NC

PWR CLASS = 000
(REQUIRES NO PWR/PROVIDES NO PWR)
(PC0 IS MSB, PC2 IS LSB)

KEEP FW_CLK SERIES R CLOSE TO PHY

KEEP CAPS CLOSE TO PHY POWER PINS.

FIREWIRE

KEEP FW_LREQ SERIES R CLOSE TO LINK

Keep 12 pF caps close

Diodes for transient protection

2

1

2

1

CRITICAL

1

2

5

6

3

4

987

2

1

2

1

2

1

212

1

2

1

2

1

8

7

6

54

3

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

21

21

21

5

6

7

8

4

3

2

1

5

6

7

8

4

3

2

1

CHGND1

CHGND1

CRITICAL

21

21

2

1

2

1

2

1

2

1

3

3
2
1

4

8
7
6
5

2

1

2

1

2

1

2

1

2

1

2

1

21

21

21

43

42 31

27

28

29

30

22

1

24

23

37

34

33

40 41

12

18

17

16

48

13

19

39

38

45

44

21

47

46

14

11

10

9

8

7

6

5

4

15

3

2

20

35

25

36

32

26

2

1

2

1

2

1

21

1

2

2

1

2

1

2

1

2

1

2

1

2

1

2

1

21

21

6

2

1

3

5

4

6

2

1

3

5

4

OMIT

21

CR-29

+PBUS_FW_SW

FW_TPO1N

+3V_FW_VDD

FW_TPO1P

+3V_FW_VDD

FW_TPI1P

FW_TPI1N

+3V_FW_VDD

+3V_FW_VDD

+FW_VP_UF

CLK24M_FW_XIN
CLK24M_FW_XOUT

FW_PHY_CPS

FW_F0
FW_F1 FW_R1

FW_R0

FW_C_LKON

FW_PHY_PD

FW_PHY_LPS

FW_PHY_SE

FW_PHY_RST_L

FW_PHY_LREQ

FW_LINK_LREQ

CLK_PHY_FW

CLK_UNIN_FW

FW_PHY_CNTL<1>

FW_LINK_CNTL<1>

FW_PHY_CNTL<0>

FW_LINK_CNTL<0>

FW_LINK_DATA<4>
FW_LINK_DATA<5>
FW_LINK_DATA<6>
FW_LINK_DATA<7>

FW_PHY_DATA<4>
FW_PHY_DATA<5>
FW_PHY_DATA<6>
FW_PHY_DATA<7>

FW_LINK_DATA<0>
FW_LINK_DATA<1>
FW_LINK_DATA<2>
FW_LINK_DATA<3>

FW_PHY_DATA<0>
FW_PHY_DATA<1>
FW_PHY_DATA<2>
FW_PHY_DATA<3>

+3V_FW_VDD

FW_VP

FW_TPI1P

FW_TPI1N

FW_TPO1P

FW_TPO1N

FW_TPA0P
FW_TPA0N

FW_TPB0N

FW_TPB0P

FW_TPB0

FW_BIAS0

+FW_VP_FUSE

PWRBUS_14_24V

FW_VGND

FW_PWREN_L

FW_PWR_GATE

FW_PWREN

KL_FW_PWREN

29<>

29<>

29<>

29<>

36<>

29<>

43<>

29<>

43<>

29<>

29<>

43<>

43<>

10<>

10>

10<>

10<>

10<>

10<>

10<>

10<>

10<>

10<>

10<>

10<>

29<>

29<>

29<>

29<>

29<>

43<>

43<>

42<>

29<

42<>

29<

42<>

42<>

29<

29<

43<>

16<>

16<>

10>

42<>

42<>

40<>

40<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

43<>

43<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

43<>

36<

43<>

16<>

+5V_MAIN

TH-2MT

J6

TH-2MT

J5

C167

0.01uF

603

CERM

50V

20%

C164

0.01uF

603

CERM

50V

20%

C171

0.01uF

603

CERM

50V

20%

C168

0.01uF

603

CERM

50V

20%

402

CERM

10V

20%

0.1uF

C204

805

CERM

10V

20%

1uF

C191

C10

47uF

20%
10V
TANT
SMC

C11

47uF

20%
10V
TANT
SMC

SYM_VER-1

L30

90-OHM

SM1

SYM_VER-1

L31

90-OHM

SM1

402

MF

1/16W

5%

0

R12

402

MF

1/16W

5%

0

R11

402

MF

1/16W

5%

0

R9

402

MF

1/16W

5%

0

R10

SM-2MT

J3

+3V_MAIN

402

R217

MF

1/16W

5%

10K

+3V_MAIN

402

R218

MF

1/16W

5%

10K

402

CERM

10V

20%

0.1uF

C279

402

5%

27K

R219

402

CERM

10V

20%

0.1uF

C278

402

5%

27K

R216

402

R190

MF

1/16W

5%

10K

402

R191

MF

1/16W

5%

10K

ENB

OUTB

OUTA

GND

FLGA

ENA

IN

FLGB

U31

LM3526

SOI

S

D

G

Q59

2N7002

SM

TSOP

Q60

SI3443DV

402

R711

MF

1/16W

5%

470K

402

R712

MF

1/16W

5%

470K

SM

L3

30-OHM-EMI

603

CERM

50V

5%

12pF

C170

603

CERM

50V

5%

12pF

C166

603

CERM

50V

5%

12pF

C169

603

CERM

50V

5%

12pF

C165

SM

L1

30-OHM-EMI

SM

L4

30-OHM-EMI

SM

L2

30-OHM-EMI

402

R172

MF

1/16W

5%

15K

402

R175

MF

1/16W

5%

15K

402

R176

MF

1/16W

5%

15K

402

R179

MF

1/16W

5%

15K

402

MF

1/16W

5%

24

R174

402

MF

1/16W

5%

24

R173

402

MF

1/16W

5%

24

R178

402

MF

1/16W

5%

24

R177

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

30 46

E

051-6403

USB & BT CONN

(GND)

BLUETOOTH INTERFACE

(+5V_USB_VDD_B)

(+5V_USB_VDD_A)

(TOWARDS ETHERNET CONNECTOR)

USB PORT 2

(TOWARDS FAN)

USB PORT 1

USB PORTS

(D-)
(D+)

(GND)

(D-)
(D+)

Keep stubs short!

May place pullups near USB
controller for +3V_MAIN connection

USB CURRENT LIMITER

CRITICAL

4

3

2

1

6

5

CRITICAL

4

3

2

1

6

5

CHGND1

21

21

21

21

2

1

2

1

2

1

2

1

NEC_USB

3

21

4

NEC_USB

3

21

4

NEC_USB

21

NEC_USB

21

NEC_USB

21

NEC_USB

21

CRITICAL

P49_SUPPORT

4

3

2

1

6

5

NEC_USB

2

1

NEC_USB

2

1

NEC_USB

2

1

NEC_USB

21

NEC_USB

2

1

NEC_USB

21

KEYLARGO_USB

2

1

KEYLARGO_USB

2

1

CRITICAL

5

8

7

6

3

2

4

1

2

1

3

4

36

5

2

1

2

1

2

1

KEYLARGO_USB

21

KEYLARGO_USB

2

1

KEYLARGO_USB

2

1

KEYLARGO_USB

2

1

CHGND1

KEYLARGO_USB

2

1

KEYLARGO_USB

21

KEYLARGO_USB

21

KEYLARGO_USB

21

2

1

2

1

2

1

2

1

KEYLARGO_USB

21

KEYLARGO_USB

21

KEYLARGO_USB

21

KEYLARGO_USB

21

CR-30

+5V_USB_VDD_SW

USB_SW_ENABLE_L

NEC_OCI<3>

NEC_OCI<4>

NEC_OCI_UF<3>

NEC_OCI_UF<4>

NEC_PPON<3>

NEC_PPON<4>

+5V_USB_VDD_A

+5V_USB_VDD_B

USB_SW_ENABLE

USB_D1M

USB_D1P

USB_D2M

USB_D2P

USB_D1M_EMI

USB_D1P_EMI

USB_D2P_EMI

USB_D2M_EMI

NEC_USB_DCM

NEC_USB_DDP

NEC_USB_DDM

NEC_USB_DCP

USB_DCP

USB_DCM

USB_DAP

USB_DAM

BT_USB_DP

BT_USB_DM

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

16<

16<

43<>

17>

17>

43<>

43<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

17<>

17<>

17<>

17<>

16<>

16<>

16<>

16<>

42<>

42<>

TH-2MT

J1

402

CERM

50V

20%

0.001uF

C224

402

CERM

50V

20%

0.001uF

C2

SM

L43

FERR-250-OHM

J17

F-RT-20143

SM

402

R170

MF

1/16W

5%

100K

402

R169

MF

1/16W

5%

100K

+3V_SLEEP

402

CERM

50V

20%

0.001uF

C223

402

CERM

50V

20%

0.001uF

C6

+5V_MAIN

402

R7

MF

1/16W

5%

100K

+3V_MAIN

TSOP

Q23

SI3443DV

C225

2200pF

603

CERM

50V

5%

402

MF

1/16W

5%

100K

R8

J21

M-ST-5087

SM

402

CERM

50V

20%

0.001uF

C709

402

CERM

50V

20%

0.001uF

C719

402

CERM

50V

20%

0.001uF

C59

1206

CERM

16V

N20P80%

10uF

C723

SM

L54

400-OHM-EMI

SM

L10

FERR-1K-OHM-EMI

SM

L53

400-OHM-EMI

+PBUS

+3V_PMU

402

CERM

10V

20%

0.1uF

C1

G2

D2

S2

SC70-6

FDG6324L

Q1

G1

S1

D1

Q1

FDG6324L

SC70-6

SM

L33

0.068uH

805

CERM

50V

5%

3.3pF

C192

805

CERM

50V

5%

3.3pF

C194

805

CERM

50V

5%

3.3pF

C193

SM

L35

0.068uH

603

CERM

50V

+/-0.25pF

4.7pF

C5

SM

L34

0.068uH

603

CERM

50V

+/-0.25pF

4.7pF

C3

SM

L38

0.068uH

603

CERM

50V

+/-0.25pF

4.7pF

C4

SM

L40

0.068uH

402

R434

MF

1/16W

1%

75

SM

L39

0.068uH

402

R433

MF

1/16W

1%

75

402

R432

MF

1/16W

1%

75

402

MF

1/16W

5%

330

R142

402

MF

1/16W

5%

330

R136

402

MF

1/16W

5%

330

R121

402

MF

1/16W

5%

330

R129

402

R167

MF

1/16W

5%

10K

402

R168

MF

1/16W

5%

10K

G

SD

SOT-363

2N7002DW

Q21

+3V_SLEEP

G

SD

SOT-363

2N7002DW

Q21

402

R186

MF

1/16W

5%

100K

402

CERM

50V

5%

100pF

C189

402

R149

MF

1/16W

5%

4.7K

402

R137

MF

1/16W

5%

4.7K

402

CERM

50V

5%

100pF

C188

603

CERM

50V

20%

0.01uF

C163

SM-1

L32

400-OHM-EMI

J4

74320

F-RT-TH

02

U1

SC70

74AHC1G02

G

SD

SOT-363

2N7002DW

Q50

SM

0.5AMP-13.2V

F3

+5V_SLEEP

MBR0530

D24

SM

402

CERM

50V

5%

100pF

C868

G

D

S

SOT-363

2N7002DW

Q56

402

R668

MF

1/16W

5%

100K

402

MF

1/16W

5%

100

R679

402

MF

1/16W

5%

100

R680

402

MF

1/16W

5%

100

R681

C889

22pF

402

CERM

50V

5%

402

MF

1/16W

5%

0

R710

402

MF

1/16W

5%

0

R709

SYM_VER-2

L7

165-OHM

SM

603

CERM

50V

20%

0.01uF

C162

805

CERM

50V

5%

82pF

C172

SM

L22

10-OHM-EMI

SM

L23

FERR-EMI-100-OHM

SM

L19

FERR-EMI-100-OHM

805

CERM

50V

5%

82pF

C159

805

CERM

50V

5%

82pF

C161

603

CERM

50V

20%

0.01uF

C160

SM

L21

FERR-EMI-100-OHM

SM

L20

10-OHM-EMI

805

CERM

50V

5%

82pF

C177

805

CERM

50V

5%

82pF

C178

402

R125

MF

1/16W

1%

75

805

CERM

50V

5%

82pF

C176

402

R123

MF

1/16W

1%

75

402

R124

MF

1/16W

1%

75

REFERENCE DESIGNATOR(S)

BOM OPTION

TABLE_5_HEAD

QTY

DESCRIPTION

PART#

TABLE_5_ITEM

152S0092

3

IND,0.1UH,+/-10,15MA,SMD

L33,L34,L35

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

31 46

E

051-6403

TMDS EMC SUPRESSION

TMDS TERMINATION

NC

NC
NC

POWER SWITCHES

Panel has 2K pull-ups

Isolation required for DVI power switch

Place these resistors
close to Mobility chip

ANALOG FILTERING

no-panel case (development)

100K pull-ups are for

VIDEO CONNECTORS

S-VIDEO/COMP OUT INTERFACE

before tying it into the GND plane

Route this GND trace to Mobility chip

before tying it into the GND plane

Route this GND trace to Mobility chip

Place these resistors
close to Mobility chip

NC

LVDS INTERFACE

(LVDS DDC POWER)

INVERTER INTERFACE

NC

(DDC POWER)

TMDS_DP<3>

TMDS_DN<4>
TMDS_DN<3>
TMDS_DP<4>

NC
NC
NC

NC

NC

NC

TMDS_DN<5>

TMDS_DP<5>

3V LEVEL SHIFTERS

NOTE: Pulldown for DVI_HPD provided by DVI power switch interface

(55mA requirement per DVI spec)

DVI DDC CURRENT LIMIT

EXTERNAL VIDEO (DVI) INTERFACE

LCD INTERFACE

EMI Filter

Place near C5A/B

Place near 3/11/19

CRITICAL

7

6 5

4 3
2 1

98

2

1

2

1

21

CHGND4B

CRITICAL

9

8

7

6

5

4

3

20

2

19

18

17

16

15

14

13

12

11

10

1

24

23

2

1

2

1

2

1

CHGND4A

2

1

CHGND4B

2

1

4

3 6

5
2
1

21

21

CRITICAL

9
8
7
65

4

3

2

10

1

2

1

CHGND7

2

1

2

1

2

1

12

12

21

2

1

CRITICAL

4

3
2

6

1

5

6

OMIT

21

2

1

2

1

2

1

OMIT

21

2

1

OMIT

21

2

1

21

2

1

21

2

1

21

2

1

2

1

2 1

2 1

2 1

2 1

2

1

2

1

1

2

6

4

5

3

2

1

2

1

2

1

2

1

2

1

2

1

CHGND2

21

CRITICAL

9

8

7

6

5

4

3

24

23

22

21

20

2

19

18

17

16

15

14

13

12

11

10

1

32

31

C5B C5A

C4

C3

C2

C1

5

4

2

1

3

4

5

3

CRITICAL

21

21

2

1

4

5

3

2

1

21

21

21

21

21

21

4

32

1

2

1

2

1

21

21

21

CHGND2

CHGND2

2

1

2

1

2

1

21

21

2

1

2

1

2

1

2

1

2

1

2

1

CR-31

TMDS_CLKN_F

TMDS_CLKP_F

TMDS_CLKP

TMDS_CLKN

TMDS_CLKP_FTMDS_CLKN_F

+5V_IO_SLEEP

BRIGHT_INV_BUF

VGA_HSYNC

VGA_B

VGA_G

VGA_R

TMDS_DN<2>

TMDS_DP<1>

TMDS_DN<0>

TMDS_DP<0> TMDS_DP<2>

TMDS_CLKP_F

TMDS_CLKN_F

VGA_VSYNC

TMDS_DN<1>

ATI_INV_ON_L

+5V_INV_UF_SW

LVDS_DDC_CLK
LVDS_DDC_DATA

+3V_LCD_SW

+3V_LCD

LVDS_L0N
LVDS_L0P

LVDS_L1N
LVDS_L1P

LVDS_L2N
LVDS_L2P

CLKLVDS_N
CLKLVDS_P

ATI_COMP

ATI_C

ATI_Y

TV_GND2

TV_COMP

TV_C

TV_GND1

TV_Y

ATI_DIGON

+PBUS_INV

+5V_INV_SW

BRIGHT_INV

ATI_DVI_DDC_CLK

ATI_DVI_DDC_DATA

ATI_HPD

VGA_B

VGA_G

VGA_R

ATI_B_FILTR

ATI_B

ATI_G_FLTR

ATI_R_FILTR

ATI_G

ATI_R

TMDS_DN<0> TMDS_DP<0>

TMDS_DN<1> TMDS_DP<1>

TMDS_DN<2> TMDS_DP<2>

ATI_DIGON_L

LCD_PWREN_L

ATI_DIGON

LCD_DIGON_L

DVI_DDC_CLK

DVI_DDC_DATA_F

DVI_HPD

DVI_HPD_F

DVI_DDC_CLK_F

+5V_DDC_SLEEP

+5V_DDC_ISO

DVI_DDC_DATA

31<

31<

31<

31<

31<

31<

20<

20<

20<

20<

20<

20< 20<

20<

42<> 42<>

42<> 42<>

42<> 42<>

31<

31<

42<>

42<>

42<>

42<>

42<>

42<> 42<>

31<

31<

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

31<>

31<> 31<>

31<> 31<>

31<> 31<>

31<>

31<>

31<>

20>

20>

31<> 31<>

43<>

20<

31<

31<

31<

20>

20>

20>

20> 20>

31<>

31<>

20<

20>

20>

43<>

20<>

20<>

43<> 43<>

20>

20>

20>

20>

20>

20>

20>

20>

20>

20>

20>

43<>

43<>

20>

43<>

43<>

20<>

20<>

20<

31<>

31<>

31<>

20>

20>

20>

20> 20>

20> 20>

20> 20>

20>

33<>

33<

43<>

SM1

1/16W

RP38

10K

5%

402

R534

MF

1/16W

5%

470

+5V_SLEEP

J25

SM-M

402

MF

1/16W

5%

33

R75

1206

CERM

16V

N20P80%

10uF

C771

402

CERM

10V

20%

0.1uF

C765

402

R571

MF

1/16W

5%

10K

402

CERM

10V

20%

0.1uF

C752

1206

CERM

16V

N20P80%

10uF

C751

SM-M

J27

402

R593

MF

1/16W

5%

10K

402

MF

1/16W

5%

33

R594

SM1

1/16W

RP51

33
5%

SM1

1/16W

RP54

33
5%

402

R595

MF

1/16W

5%

10K

402

MF

1/16W

5%

22

R597

SM1

1/16W

RP39

10K

5%

402

MF

1/16W

5%

22

R598

402

MF

1/16W

5%

22

R600

402

MF

1/16W

5%

33

R605

SM1

1/16W

RP52

33
5%

SM1

1/16W

RP47

33
5%

SM1

1/16W

RP53

33
5%

+5V_SLEEP

402

R80

MF

1/16W

5%

10K

402

R81

MF

1/16W

5%

10K

402

R82

MF

1/16W

5%

10K

SM-M

J26

402

R66

MF

1/16W

5%

100K

SM1

1/16W

RP45

33
5%

402

R65

MF

1/16W

5%

20K

402

R74

MF

1/16W

5%

10K

402

MF

1/16W

5%

22

R93

402

MF

1/16W

5%

82

R92

402

MF

1/16W

5%

82

R101

402

R601

MF

1/16W

5%

100K

402

MF

1/16W

5%

22

R76

402

MF

1/16W

5%

82

R99

402

MF

1/16W

5%

22

R95

402

MF

1/16W

5%

33

R94

402

MF

1/16W

5%

33

R77

SM1

1/16W

RP42

33
5%

SM1

1/16W

RP40

33
5%

SM1

1/16W

RP46

33
5%

SM1

1/16W

RP44

33
5%

SM1

1/16W

RP49

33
5%

SM1

1/16W

RP55

33
5%

J12

M-ST-5087

SM

+5V_MAIN

J24

M-ST-5087

SM

402

R599

MF

1/16W

5%

10K

+5V_MAIN

+3V_MAIN

+5V_MAIN

SM1

1/16W

RP43

33
5%

SM1

1/16W

RP41

33
5%

SM1

1/16W

RP50

33
5%

402

R596

MF

1/16W

5%

20K

402

R602

MF

1/16W

5%

10K

+3V_SLEEP

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

32 46

E

051-6403

CLOSE TO KEY LARGO

Card Detect #1

Voltage Sense #1

(CARD STATUS CHANGED)

(INPUT PORT ACK)

(SPEAKER)

(VOLTAGE SENSE #2)

(ADDR<16>)

(IOCS16_L)

NC

PIN 32 NOT USED

PIN 30 NOT USED

PLACE TERMINATORS NEAR KEY LARGO

Place resistor packs

CARDSLOT (WIRELESS) INTERFACE

CARDSLOT/EIDE SERIES TERMINATION

INTERNAL HARD DRIVE INTERFACE

NC

NCNC

INTERNAL I/O CONNECTORS

NC

NC

NC

NC

NC

NC

PLEASE PLACE THESE TERMINATORS CLOSE TO KEYLARGO AND MINIMIZE THE LENGTH OF THE T

THESE LINES ARE SHARED BETWEEN THE CARDSLOT AND EIDE INTERFACES

NC

Place near Key Largo

May repin connector as necessary

SERIAL DEBUG INTERFACE

May repin connector as necessary

Place near pin 4 of modem connector

MODEM BOARD INTERFACE

OPTICAL DRIVE INTERFACE

567

8

432

1

2

1

CRITICAL

M70SM_5MM

9

8

70

7

69
68
67
66
65
64
63
62
61
60

6

59
58
57
56
55
54
53
52
51
50

5

49
48
47
46
45
44
43
42
41
40

4

39
38
37
3635

34

33

32

31

30

3

29

28

27

26

25

24

23

22

21

20

2

19

18

17

16

15

14

13

12

11

10

1

21

2

1

2

1

2

1

2

1

2

1

CRITICAL

M50SM_5MM

9
8
7
6

50

5

49

48

47

46

45

44

43

42

41

40

4

39

38

37

36

35

34

33

32

31

30

3

29

28

27

2625
24
23
22
21
20

2

19
18
17
16
15
14
13
12
11
10

1

2

1

21

5

6

7

8

4

3

2

1

5

6

7

8

4

3

2

1

2

1

21

567

8

432

1

21

21

12

5

6

7

8

4

3

2

1

5

6

7

8

4

3

2

1

5

6

7

8

4

3

2

1

2

1

2

1

2

1

CRITICAL

9

8

7

6

50

5

49
48
47
46
45
44
43
42
41
40

4

39
38
37
36
35
34
33
32
31
30

3

29
28
27
2625

24

23

22

21

20

2

19

18

17

16

15

14

13

12

11

10

1

2

1

5

6

7

8

4

3

2

1

2

1

2

1

21

21

21

2

1

21

21

21

21

21

5

6

7

8

4

3

2

1

5

6

7

8

4

3

2

1

5

6

7

8

4

3

2

1

5

6

7

8

4

3

2

1

5

6

7

8

4

3

2

1

5

6

7

8

4

3

2

1

CRITICAL

SERIAL_DEBUG

9
8
7
65

4

3

2

10

1

CRITICAL

9
8
7
65

4

3

2

10

1

2

1

5

6

7

8

4

3

2

1

5

6

7

8

4

3

2

1

5

6

7

8

4

3

2

1

2

1

2

1

CR-32

EIDE_ADDR_<0>

EIDE_CS1FX_L_OPU

EIDE_ADDR<0>

EIDE_CS1FX_L

EIDE_ADDR_<2>

EIDE_ADDR_<1>

EIDE_ADDR<2>

EIDE_ADDR<1>

CSLOT_RESET

CSLOT_IOWAIT_L

CSLOT_REG_L

COMM_GPIO_L

COMM_RXD

COMM_RTS_L

COMM_DTR_L

COMM_TRXC

COMM_TXD_L

COMM_RESET_L

KL_I2C_DATA
MODEM_USB_DP
MODEM_USB_DM

COMM_SHUTDOWN

COMM_RING_DET_L

KL_I2C_CLK

EIDE_DATA<7>

UIDE_DIOW_L

HD_DIOW_L

UIDE_DIOR_L

HD_DIOR_L

UIDE_CS3FX_L

HD_CS3_L

UIDE_ADDR<1>
UIDE_ADDR<2>
UIDE_CS1FX_L

HD_ADDR<2>

HD_ADDR<1>

HD_CS1_L

HD_ADDR<0>

UIDE_ADDR<0>

UIDE_RST_L HD_RESET_L

UIDE_DMACK_L

HD_DMACK_L

UIDE_DATA<7>

EIDE0_RST_L

EIDE0_RST_L_OPU

EIDE0_INT

EIDE0_INTR

EIDE0_WR_L

EIDE0_WR_L_OPU

EIDE0_DMACK_L

EIDE0_DMA_ACK_L

EIDE_IOCHRDY

EIDE_IO_CHRDY

EIDE0_RD_L

EIDE0_READ_L

EIDE0_DMARQ

EIDE0_DMA_RQ

EIDE_CS3FX_L

EIDE_CS3FX_L_OPU

HD_DATA<15>

HD_DATA<14>

HD_DATA<13>

HD_DATA<12>

UIDE_DATA<15>

UIDE_DATA<14>

UIDE_DATA<13>

UIDE_DATA<12>

HD_DATA<7>

HD_DATA<6>

HD_DATA<5>

HD_DATA<4>

UIDE_DATA<6>

UIDE_DATA<5>

UIDE_DATA<4>

HD_DATA<11>

HD_DATA<10>

HD_DATA<9>

HD_DATA<8>

UIDE_DATA<11>

UIDE_DATA<10>

UIDE_DATA<9>

UIDE_DATA<8>

HD_DATA<3>

HD_DATA<2>

HD_DATA<1>

HD_DATA<0>

UIDE_DATA<3>

UIDE_DATA<2>

UIDE_DATA<1>

UIDE_DATA<0>

HD_DMARQ

HD_INTRQ

HD_DATA<13>

+5V_HD_SLEEP

HD_CS1_L

HD_ADDR<0>

HD_IOCHRDY

HD_DIOR_L

HD_DATA<0>

HD_DATA<1>

HD_DATA<2>

HD_DATA<3>

HD_DATA<4>

HD_DATA<5>

HD_DATA<6>

HD_DATA<7>

HD_RESET_L

HD_CS3_L

HD_ADDR<2>

HD_DATA<15>

HD_DATA<14>

HD_DATA<12>

HD_DATA<11>

HD_DATA<10>

HD_DATA<9>

HD_DATA<8>

HD_ADDR<1>

HD_DMACK_L

HD_DIOW_L

EIDE_DATA<5>

EIDE_DATA<4>

EIDE_DATA<6>

EIDE_DB_<5>

EIDE_DB_<4>

EIDE_DB_<7>

EIDE_DB_<6>

EIDE_DATA<3>

EIDE_DATA<0>

EIDE_DATA<1>

EIDE_DATA<2>

EIDE_DB_<3>

EIDE_DB_<0>

EIDE_DB_<1>

EIDE_DB_<2>

EIDE_DB_<15>

EIDE_DB_<13>

EIDE_DB_<14>

EIDE_DB_<12>

EIDE_DATA<15>

EIDE_DATA<13>

EIDE_DATA<14>

EIDE_DATA<12>

EIDE_DB_<11>

EIDE_DB_<9>

EIDE_DB_<10>

EIDE_DB_<8>

EIDE_DATA<11>

EIDE_DATA<9>

EIDE_DATA<10>

EIDE_DATA<8>

EIDE_CS3FX_L

CSLOT_CS3FX_L

CSLOT_CS1FX_L

CSLOT_ADDR<1>

CSLOT_ADDR<2>

CSLOT_ADDR<0>

EIDE_CS1FX_L

EIDE_ADDR<1>

EIDE_ADDR<2>

EIDE_ADDR<0>

CSLOT_DATA<12>

CSLOT_DATA<14>

CSLOT_DATA<13>

CSLOT_DATA<15>

EIDE_DATA<12>

EIDE_DATA<14>

EIDE_DATA<13>

EIDE_DATA<15>

CSLOT_DATA<8>

CSLOT_DATA<10>

CSLOT_DATA<9>

CSLOT_DATA<11>

EIDE_DATA<8>

EIDE_DATA<10>

EIDE_DATA<9>

EIDE_DATA<11>

CSLOT_DATA<5>

CSLOT_DATA<4>

CSLOT_DATA<7>

CSLOT_DATA<6>

EIDE_DATA<5>

EIDE_DATA<4>

EIDE_DATA<7>

EIDE_DATA<6>

CSLOT_DATA<3>

CSLOT_DATA<0>

CSLOT_DATA<1>

CSLOT_DATA<2>

EIDE_DATA<3>

EIDE_DATA<0>

EIDE_DATA<1>

EIDE_DATA<2>

EIDE0_DMA_RQ

EIDE_ADDR_<0>

EIDE_DB_<8>
EIDE_DB_<9>
EIDE_DB_<10>

EIDE_DB_<14>
EIDE_DB_<15>

EIDE0_READ_L

EIDE0_DMA_ACK_L

EIDE_ADDR_<2>
EIDE_CS3FX_L_OPU

EIDE0_RST_L_OPU

EIDE_DB_<7>
EIDE_DB_<6>
EIDE_DB_<5>
EIDE_DB_<4>
EIDE_DB_<3>
EIDE_DB_<2>
EIDE_DB_<1>
EIDE_DB_<0>

EIDE0_WR_L_OPU

EIDE_IO_CHRDY
EIDE0_INTR
EIDE_ADDR_<1>

EIDE_CS1FX_L_OPU

EIDE_DB_<11>
EIDE_DB_<12>
EIDE_DB_<13>

+5V_TOL

CSLOT_DATA<10>

CSLOT_DATA<9>

CSLOT_DATA<8>

CSLOT_IOWR_L

CSLOT_IORD_L

CSLOT_CE2_L

CSLOT_DATA<15>

CSLOT_DATA<14>

CSLOT_DATA<13>

CSLOT_DATA<12>

CSLOT_DATA<11>

CSLOT_DATA<2>

CSLOT_DATA<1>

CSLOT_DATA<0>

CSLOT_ADDR<0>

CSLOT_ADDR<1>

CSLOT_ADDR<2>

CSLOT_ADDR<3>

CSLOT_ADDR<4>

CSLOT_ADDR<5>

CSLOT_ADDR<6>

CSLOT_ADDR<7>

CSLOT_ADDR<12>

CSLOT_ADDR<15>

CSLOT_IRQ_L

CSLOT_CS3FX_L

CSLOT_ADDR<14>

CSLOT_ADDR<13>

CSLOT_ADDR<8>

CSLOT_ADDR<9>

CSLOT_ADDR<11>

CSLOT_CS1FX_L

CSLOT_ADDR<10>

CSLOT_CE1_L

CSLOT_DATA<7>

CSLOT_DATA<6>

CSLOT_DATA<5>

CSLOT_DATA<4>

CSLOT_DATA<3>

16<

16<

16<

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

16<

42<>

25<>

16<

16<

34<>

25<>

42<>

42<> 42<>

42<> 42<>

42<> 42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<> 42<>

42<> 42<>

42<> 42<>

42<>

42<> 42<>

42<>

42<> 42<>

42<> 42<>

42<>

42<> 42<>

42<>

42<> 42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

16<

16<

32<

43<>

32<

32<

16<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<> 42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

16<

16<

42<>

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

32<

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

32<

42<>

42<>

42<>

42<>

42<>

32<

42<>

42<>

32<

32<

32<

32<

32<

32<>

32<>

16>

16>

32<>

32<>

16>

16>

16<>

42<>

16<>

16<>

16<

16>

16>

16<>

16>

16<>

16<>

42<>

42<>

16>

16<>

16<>

16<>

16>

32<>

16>

32<>

16>

32<>

16>

16>

16>

32<>

32<>

32<>

32<>

16>

16>

32<>

16>

32<>

16<>

16>

32<>

42<> 32<>

16>

32<>

16>

32<>

42<> 32<>

16>

32<>

42<> 32<>

16>

32<>

32<>

32<>

32<>

32<>

16<>

16<>

16<>

16<>

32<>

32<>

32<>

32<>

16<>

16<>

16<>

32<>

32<>

32<>

32<>

16<>

16<>

16<>

16<>

32<>

32<>

32<>

32<>

16<>

16<>

16<>

16<>

42<>

42<>

42<>

37<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

16<>

16<>

16<>

32<>

32<>

32<>

32<>

16<>

16<>

16<>

16<>

32<>

32<>

32<>

32<>

32<>

32<>

32<>

32<>

16<>

16<>

16<>

16<>

32<>

32<>

32<>

32<>

16<>

16<>

16<>

16<>

16>

32<>

32<>

32<>

32<>

32<>

16>

16>

16>

16>

32<>

32<>

32<>

32<>

16<>

16<>

16<>

16<>

32<>

32<>

32<>

32<>

16<>

16<>

16<>

16<>

32<>

32<>

32<>

32<>

16<>

16<>

16<>

16<>

32<>

32<>

32<>

32<>

16<>

16<>

16<>

16<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

16>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

42<>

16>

16>

16>

16>

16>

16>

16<>

16<>

42<>

16<>

16<>

16>

16>

16>

42<>

16>

16>

42<>

42<>

42<>

42<>

42<>

402

R163

MF

1/16W

5%

100

+5V_MAIN

402

R164

MF

1/16W

5%

2.2K

2N3906

SM

Q24

J18

SM-2MT

L42

400-OHM-EMI

SM

603

CERM

50V

10%

470pF

C259

+3V_MAIN

402

R138

MF

1/16W

5%

470K

402

MF

1/16W

5%

4.7K

R165

+3V_MAIN

2N3906

SM

Q48

2N3906

SM

Q49

402

R585

MF

1/16W

5%

200

402

R589

MF

1/16W

5%

200

J10

SM-2MT

SM

L44

400-OHM-EMI

SOT23

15V

D14

+3V_PMU

402

MF

1/16W

5%

100K

R590

J28

M-ST-5087

SM

402

CERM

50V

20%

0.001uF

C788

402

CERM

50V

20%

0.001uF

C787

402

CERM

50V

20%

0.001uF

C786

SM

L63

400-OHM-EMI

SM

L62

400-OHM-EMI

SM

L61

400-OHM-EMI

402

CERM

50V

20%

0.001uF

C785

402

R586

MF

1/16W

5%

0

402

MF

1/16W

5%

0

R587

+5V_SLEEP

402

CERM

50V

20%

0.001uF

C790

402

CERM

50V

20%

0.001uF

C789

+3V_MAIN

SM

L67

400-OHM-EMI

SM

L66

400-OHM-EMI

SM

L65

400-OHM-EMI

SM

RP25

25V

1/32W

5%

10K

SM

RP26

25V

1/32W

5%

10K

G

D

S

SOT-363

2N7002DW

Q20

G

D

S

SOT-363

2N7002DW

Q20

J14

SM

402

CERM

10V

20%

0.1uF

C26

402

MF

1/16W

1%

10K

R18

SM

U37

LMC7211

402

R122

MF

1/16W

1%

68.1K

+3V_SLEEP

402

R182

MF

1/16W

1%

100K

SM

2N3904

Q55

G S

D

SM

Q32

TP0610

SM

2N3904

Q26

402

MF

1/16W

5%

10K

R30

402

MF

1/16W

5%

10K

R224

402

R29

MF

1/16W

1%

10K

G

D

S

SOT-363

2N7002DW

Q50

402

R612

MF

1/16W

5%

100K

402

R663

MF

1/16W

5%

330

402

MF

1/16W

5%

22

R677

402

CERM

50V

5%

100pF

C873

402

MF

1/16W

5%

1K

R678

402

R720

MF

1/16W

5%

330

402

MF

1/16W

5%

0

R319

402

R334

MF

1/16W

5%

0

402

R333

MF

1/16W

5%

0

402

MF

1/16W

5%

0

R336

402

MF

1/16W

5%

0

R335

402

R344

MF

1/16W

5%

0

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

33 46

E

051-6403

DVI POWER SWITCH

system is shutdown or asleep..

Power key detect path when

device path into DDC_CLK.

M7 during shutdown. When
power key on remote device

DDC_CLK is isolated from

is pressed, 5V will be driven
into DDC_CLK. Since host rails
will be low, TP0610 will turn
on, driving SOFT_PWR_ON_L low.
As host rails rise, TP0610
will turn off, as will remote

Isolation will be disabled as well.

(which happens when
unit has AC power
but is in shutdown).

Pulldown prevents
3904 from turning
on when FW device
pumps up 3V rails

Pulldown prevents
on when DVI monitor

3904 from turning
has active, self­pullup.

powered DDC clock

NOTE: CURRENT RETURN PATH IS VIA CHGND1, Rxx, AND Lxx AT DC JACK

NOTE: KEEP L42 CLOSE TO C259

KEYBOARD INTERFACE

NC

KEYBOARD PULLUPS

POWER BUTTON INTERFACE

Place discretes close to connector

TRACKPAD/SLEEP SWITCH INTERFACE

PMU INTERFACES

SLEEP LED

NOTE: CHASSIS GND CONNECTION FOR LED IMPLIES
THAT THE SLEEP LED WILL ONLY WORK WHEN
INSTALLED IN A FULLY ASSEMBLED SYSTEM.

NC

(MOVED TO INVERTER)

CHARGE LED SUPPORT

Power key detect path
when system is running.
HPD normally driven to

3.3V. When power key
on remote device pressed,
HPD will be driven to 5V.
Comparator enabled by M7
GPIO.

2

1

2

1

2

3

1

CRITICAL

2

1

4

3

2

1

2

1

2

1

21

CHGND4A

2

3

1

2

3

1

2

1

2

1

CRITICAL

2

1

4

3

CHGND1

21

3

2

1

21

CRITICAL

9
8
7
65

4

3

2

10

1

2

1

CHGND6

2

1

2

1

21

21

21

2

1

2

1

12

2

1

2

1

21

21

21

9

8

7

6

4

3

2

1

10

5

9

8

7

6

4

3

2

1

10

5

1

2

6

4

5

3

CRITICAL

9

87

65

4

30

3

29

2827

2625

2423

2221

20

2

19

1817

1615

1413

1211

10

1

2

1

21

2

5

1

3

4

2

1

HPD_REF_EN_L

2

1

2

3

1

2

1

3

2

3

1

21

21

2

1

1

2

6

2

1

2

1

21

2

1

21

2

1

NO STUFF

21

2

1

2

1

NO STUFF

21

NO STUFF

21

2

1

CR-33

+3V_HE_F

PMU_SLEEP_LED_L

SLEEP_LED_SW

SPO_ESD_F

SOFT_PWR_ON_L

SLEEP_LED

SLEEP_LED_UF

SLEEP_LED_L SLEEP_LED_I

PMU_LID_CLOSED_L

LID_CLOSED_L

TPAD_TXD TPAD_F_TXD

TPAD_RXD TPAD_F_RXD

+3V_HALL_EFFECT

+5V_TPAD_SLEEP

TPAD_GND

KBD_ID

KBD_X<4>

KBD_X<5>

KBD_X<6>

KBD_X<7>

KBD_X<0>

KBD_X<3>
KBD_X<2>
KBD_X<1>

CAPSLOCK_LED_L

CAPSLOCK_LED

KBD_SHIFT_L

KBD_FUNCTION_L

KBD_OPTION_L

KBD_X<8>

KBD_CONTROL_L
KBD_COMMAND_L
KBD_X<9>

NUMLOCK_LED_L

NUMLOCK_LED

KBD_SHIFT_L

KBD_COMMAND_L

KBD_FUNCTION_L

KBD_JIS

KBD_Y<6>

KBD_Y<5>

KBD_Y<3>

KBD_Y<1>

KBD_X<9>

KBD_X<7>

KBD_X<5>

KBD_NUMLOCK_LED

KBD_X<3>

KBD_X<1>

KBD_ID

KBD_Y<7>

KBD_Y<4>

KBD_Y<2>

KBD_Y<0>

KBD_X<8>

KBD_X<6>

KBD_X<4>

KBD_X<2>

KBD_OPTION_L
KBD_X<0>

KBD_CONTROL_L

KBD_CAPSLOCK_LED

KBD_INTL

DVI_TURN_ON_BASE

DVI_DDC_CLK

DVI_TURN_ON

DVI_PWR_EN_L

+5V_IO_SLEEP

SOFT_PWR_ON_L

HPD_PWR_SW_BASE

HPD_4V_REF

DVI_HPD_DIV

DVI_HPD

SLEEP_LED_SW_L

HPD_PWR_SNS_EN

HPD_PWR_SW_OPT

HPD_REF_EN_L_OPT2

HPD_PWR_SW

HPD_REF_EN_L_OPT

39<>

34<>

34<>

34<>

34<>

34<>

34<>

34<>

34<>

34<>

34<>

34<>

34<>

34<>

34<>

34<>

34<>

33<

33<

33<

33<

33<

33<

33<

33<

33<

33<

33<

33<

33<

33<

33<

33<

39<>

34<>

34<>

34<> 34<>

34<>

43<> 43<>

43<>

33<>

33<>

33<>

33<>

33<>

33<>

33<>

33<>

33<>

33<>

33<>

33<>

33<>

33<>

33<>

33<>

34<>

34<>

34<>

34<>

34<>

34<>

34<>

34<>

34<>

34<>

34<>

34<>

34<>

34<>

34<>

34<>

34<>

34<>

34<>

34<>

34<>

34<>

34<>

34<>

31<> 43<>

34<>

31<>

20<>

402

R563

MF

1/16W

5%

0

402

MF

1/16W

5%

10M

R547

402

MF

1/16W

5%

10K

R494

402

MF

1/16W

5%

1K

R562

402

MF

1/16W

5%

1K

R498

402

MF

1/16W

5%

10M

R548

402

R565

MF

1/16W

5%

0

402

R130

MF

1/16W

5%

1K

402

MF

1/16W

5%

2.2K

R474

402

MF

1/16W

5%

4.7

R523

402

MF

1/16W

5%

2.2K

R470

402

CERM

10V

20%

0.1uF

C181

603

CERM

50V

5%

12pF

C753

402

CERM

10V

20%

0.1uF

C757

402

CERM

10V

20%

0.1uF

C629

603

CERM

50V

5%

12pF

C756

603

CERM

50V

5%

12pF

C766

603

CERM

50V

5%

12pF

C754

402

CERM

10V

20%

0.1uF

C736

Y3

SM

10.00M

Y2

SM-1

32.768K

VCC

GND

RESET

MAX6328

U25

SOT23

P86_XCOUT

AVSS

VSS

XIN
RESET

VREF

CNVSS

BYTE
XOUT

AVCC

P50_WRL_WR

P51_WRH_BHE

P52_RD

P65_CLK1
P66_RXD1
P67_TXD1

P74_TA2OUT_W

P75_TA2IN_W

P60_CTS0_RTS0

P57_RDY_CLKOUT

P56_ALE

P55_HOLD

P54_HLDA

P53_BCLK

P61_CLK0
P62_RXD0
P63_TXD0

P70_TXD2_SDA_TA0OUT

P72_CLK2_TA1OUT_V

P73_CTS2_RTS2_TA1IN_V

P100_AN0

P90_TB0IN_CLK3
P91_TB1IN_SIN3

P92_TB2IN_SOUT3

P93_DA0_TB3IN
P94_DA1_TB4IN

P95_ANEX0_CLK4

P96_ANEX1_SOUT4

P97_ADTRG_SIN4

P87_XCIN

P85_NMI

P84_INT2

P83_INT1

P82_INT0

P81_TA4IN_U

P80_TA4OUT_U

P77_TA3IN

P76_TA3OUT

P107_AN7_KI3

P106_AN6_KI2

P105_AN5_KI1

P104_AN4_KI0

P103_AN3

P102_AN2

P101_AN1

P64_CTS1_RTS1_CTS0_CLKS1

P71_RXD2_SCL_TA0IN_TB5IN

VCC

P01_D1

P00_D0

P02_D2
P03_D3
P04_D4
P05_D5
P06_D6
P07_D7

P10_D8

P11_D9
P12_D10
P13_D11

P21_A1_D1_D0

P22_A2_D2_D1

P23_A3_D3_D2

P24_A4_D4_D3

P25_A5_D5_D4

P14_D12

P17_D15_INT5

P15_D13_INT3
P16_D14_INT4

P20_A0_D0

P27_A7_D7_D6

P26_A6_D6_D5

P30_A8_D7

P31_A9
P32_A10
P33_A11
P34_A12
P35_A13
P36_A14
P37_A15

P45_CS1
P46_CS2
P47_CS3

P44_CS0

P43_A19

P40_A16
P41_A17
P42_A18

FLAS

U47

M16C62

402

R144

MF

1/16W

5%

100K

+3V_PMU

1206

CERM

16V

N20P80%

10uF

C596

402

MF

1/16W

5%

0

R564

402

MF

1/16W

5%

10K

R525

402

MF

1/16W

5%

10K

R531

+5V_SLEEP

+3V_MAIN

402

MF

1/16W

5%

10K

R555

402

MF

1/16W

5%

100K

R556

+3V_SLEEP

402

MF

1/16W

5%

470K

R554

402

MF

1/16W

5%

470K

R561

402

MF

1/16W

5%

10K

R515

402

MF

1/16W

1%

100K

R518

+3V_PMU

402

MF

1/16W

5%

10K

R516

402

MF

1/16W

5%

10K

R489

402

MF

1/16W

5%

10K

R549

402

MF

1/16W

5%

10K

R519

402

MF

1/16W

5%

100K

R530

402

MF

1/16W

5%

100K

R488

402

MF

1/16W

5%

10K

R524

402

MF

1/16W

5%

100K

R495

402

MF

1/16W

5%

100K

R499

402

MF

1/16W

5%

470K

R464

402

MF

1/16W

5%

100K

R451

402

MF

1/16W

5%

10K

R452

+3V_PMU

402

MF

1/16W

5%

1K

R572

402

MF

1/16W

5%

10K

R579

SM1

1/16W

5%

100K

RP36

SM1

1/16W

5%

100K

RP36

SM1

1/16W

5%

100K

RP36

SM1

1/16W

5%

100K

RP36

SM1

S2

402

R373

MF

1/16W

1%

402K

+3V_PMU

402

MF

1/16W

1%

100K

R374

SM1

1/16W

5%

7.5K

RP27

SM1

1/16W

5%

7.5K

RP27

SM1

1/16W

5%

7.5K

RP27

SM1

1/16W

5%

7.5K

RP27

402

MF

1/16W

1%

147K

R386

+3V_PMU

+3V_PMU

REFERENCE DESIGNATOR(S)

BOM OPTION

TABLE_5_HEAD

QTY

DESCRIPTION

PART#

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

34 46

E

051-6403

TABLE_5_ITEM

MAX6326_PP116S1473

1

RES, 4.7K, 5%, 1/16W, MF, 402

R564

TABLE_5_ITEM

341S1008

1

PMU,SW Image 81

U47

TABLE_ALT_ITEM

705S0040705S0051 S2

PART NUMBER

ALTERNATE FOR

PART NUMBER

BOM OPTION

REF DES

COMMENTS:

TABLE_ALT_HEAD

PART NUMBER

ALTERNATE FOR

PART NUMBER

BOM OPTION

REF DES

COMMENTS:

TABLE_ALT_HEAD

TABLE_ALT_ITEM

353S0255353S0809 MAX6326_PP

U25

MAX809S

TABLE_5_ITEM

ND_Q11116S1000

1

RES,1/16W,0 OHM,0402,SMD

R374

REFERENCE DESIGNATOR(S)

BOM OPTION

TABLE_5_HEAD

QTY

DESCRIPTION

PART#

TABLE_ALT_ITEM

197S0604197S0704 Y3

Alt crystal size

PART NUMBER

ALTERNATE FOR

PART NUMBER

BOM OPTION

REF DES

COMMENTS:

TABLE_ALT_HEAD

REFERENCE DESIGNATOR(S)

BOM OPTION

TABLE_5_HEAD

QTY

DESCRIPTION

PART#

TABLE_5_ITEM

MAX6326_PP353S0255

1

IC, MAX6326 RESET, 2.63V, SOT23-3

U25

TABLE_5_ITEM

ND_Q11114S1005

1

RES,1/16W,100K OHM,0402,SMD

R518

TABLE_5_ITEM

D_Q11

114S1215

1

RES,1/16W,121K OHM,0402,SMD

R386

TABLE_5_ITEM

D_Q11

114S7324

1

RES,1/16W,73.2K OHM,0402,SMD

R374

TABLE_5_ITEM

D_Q11

114S2875

1

RES,1/16W,287K OHM,0402,SMD

R373

A29 & Q11 ADAPTOR OPTION

operation of the device otherwise. C257 helps

to PMU. R324 limits current (3.3mA) during

UNDERVOLTAGE RESET CIRCUIT

debounce switch chatter. All resets thus look

reset but provides enough current for proper

Placing switch on input to reset supervisor
guarantees consistent and valid reset levels

PMU RESET SWITCH

Keep crystal subcircuit close to PMU.

NC

NC

NC

NC

NC

NC

NC

(CHARGE_I)

NC

Keep crystal subcircuit close to PMU.

(PMU_AP)

reset. MLB will have a pull-up

have a pulldown for coming out of

CPU_VCORE_HI_OC/PMU_AP should

to +3V_MAIN or +3V_SLEEP, which
will act as our pulldown since
both are off during PMU reset.

(open-drain) as well as MAX6326 (push-pull)

NOTE: PMU Undervoltage circuit supports MAX6328

PMU Interface

R316 IS NO STUFFED FOR MAX6326_PP!!!

like a Power-On Reset to the supervisor.

A29 & Q11 ADAPTOR OPTION

2

1

NO STUFF

21

21

21

21

NO STUFF

21

2

1

2

1

21

21

21

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

CRITICAL

21

CRITICAL

41

MAX6328_OC

3

2

1

OMIT

11
13

6212

96

6014

10

98

99

100

1

2

3

4

5

8

9

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

48

49

50

51

52

53

54

55

56

57

58

59

61

63

64

65

66

67

68

69

70

71

72

73

74

75

76

77

78

87

88

89

90

91

92

93

95

79

80

81

82

83

84

85

86

7

6

94

97

MAX6328_OC

2

1

2

1

MAX6328_OC

12

12

12

12

12

21

12

P59_BOTH

12

OMIT

12

12

12

12

12

12

21

21

21

12

21

21

21

12

12

54

63

72

81

CRITICAL

43

21

OMIT

2

1

OMIT

21

54

63

81

72

OMIT

21

CR-34

PMU_AC_DET_UF

PMU_BATT1_DET_L_PU

AC_IN

ADAPTER_DET

+5_5V_RAW

ADAPTER_DET

PMU_AC_DET

PMU_AC_IN

PMU_BATT0_DET_L

PMU_BATT_DET_LPMU_RESET_L_SW

PMU_EPM

PMU_RESET_BUTTON_L

PMU_NMI_L

PMU_NMI_BUTTON_L

PMU_POWERUP_OK

PMU_LID_CLOSED_L

TPAD_TXD

TPAD_RXD

PMU_PME_L

POWER_VALID

PMU_BYTE

PMU_CNVSS

KL_SUSPEND_REQ_L

IO_RESET_L

PMU_POWER_UP_L

UNIN_SUSPEND_REQ_L

SLEEP

SOFT_PWR_ON_L

CHARGE_LED_L

PMU_OOPS

PMU_TEMP

UNIN_RESET_L

UNIN_PU_RESET_L

UNIN_SUSPEND_REQ_L

SLEEP
KL_SUSPEND_REQ_L
UNIN_SUSPEND_ACK_L

CPU_PLL_STOP_OC

PMU_INT_L
KBD_ID

KBD_SHIFT_L
KBD_OPTION_L
KBD_FUNCTION_L

KBD_COMMAND_L
KBD_CONTROL_L

IO_RESET_L

KBD_X<8>
KBD_X<9>

KBD_X<6>
KBD_X<7>

KBD_X<3>
KBD_X<4>
KBD_X<5>

KBD_X<1>
KBD_X<2>

KL_WATCHDOG_L

KBD_X<0>

PMU_BACKUP_SELECT_SPN
SOFT_PWR_ON_L
COMM_RING_DET_L

CHARGE_LED_L
PMU_POWER_UP_L

KBD_Y<5>
KBD_Y<6>
KBD_Y<7>

KBD_Y<3>
KBD_Y<4>

KBD_Y<2>

KBD_Y<0>
KBD_Y<1>

PMU_SMB_DATA

PMU_SMB_CLK

PMU_I2C_DATA

PMU_I2C_CLK

PMU_TEMP

PMU_POWERUP_OK

KL_PROC_SLEEP_REQ_L

PMU_BATT1_DET_L_PU

PMU_NMI_L

KL_PEND_PROC_INT

PMU_PME_L

POWER_VALID

CPU_SMI_L

PMU_SLEEP_LED_L

PMU_CHRG_BATT_0

PMU_CHARGE_V

CPU_CLK_EN

SYSTEM_CLK_EN

TPAD_TXD

TPAD_RXD

PMU_NMI_BUTTON_L

PMU_RESET_BUTTON_L

PMU_LID_CLOSED_L

PMU_REQ_L

PMU_CLK

PMU_ACK_L

PMU_TO_KL

PMU_FROM_KL

CPU_HRESET_L

UNIN_PU_RESET_L

PMU_EPM

PMU_KL_NMI

MAIN_RESET_L

UNIN_RESET_L

CPU_VCORE_HI_OC

PMU_BYTE

PMU_CNVSS

+3V_PMU_AVCC

+3V_PMU_AVCC

CLK32K_PMU_XOUT

CLK32K_PMU_XOUT_UF

CLK32K_PMU_XIN

PMU_NUMLOCK_LED_L

NUMLOCK_LED_L

PMU_CAPSLOCK_LED_L

CAPSLOCK_LED_L

PMU_RESET_L

PMU_RESET_UF_L

CLK10M_PMU_XIN

CLK10M_PMU_XOUT

CLK10M_PMU_XOUT_UF

PMU_I2C_CLK

PMU_I2C_DATA

PMU_OOPS

PMU_BATT_DET_L

PMU_SMB_DATA

PMU_SMB_CLK

34< 28<

38<

19<

34<

34<>

37<

18<

34<

16<

17<

34<

39<

16>

37<>

39<>

35<>

34<

34<

34<

16<

33<

33<

33<

33<

33<

33<

17<

33<

33<

33<

33<

33<

33<

33<

33<

33<

33<

33<

32<>

34<

37<

35<

35<

34<

34<

34<

16>

23<

34<

34<

34<

16<

13<

34<

16<

17<

23<

23<

43<>

34<

34<>

28<>

35<>

43<>

35<>

39<>

34<>

34<>

34<>

34<>

34<>

34<>

34<>

34<>

10>

34<>

34<>

34<>

34<>

34<>

34<>

34<>

34<>

34<>

34<>

34<>

34<>

6<

37<>

16<

6>

12<>

16<>

33<>

33<>

33<>

33<>

33<>

33<>

16<

33<>

33<>

33<>

33<>

33<>

33<>

33<>

33<>

33<>

16>

33<>

39<>

16<>

35<>

34<

33<>

33<>

33<>

33<>

33<>

33<>

33<>

33<>

34<

34<

23<

23<

24<

34<

16<

34<

34<

16>

10>

34<

13<

33<>

35<>

36<

23<

19<

33<

33<

34<

34<

33<

16>

16<

16<

16<>

16<>

12<

10<

34<

16<>

9<>

10<

12<

34<>

43<>

34<>

34<>

34<

34<>

34<>

402

R450

MF

1/16W

1%

665K

603

CERM

16V

5%

0.047uF

C615

G2

S1

S2

D2

G1

D1

Q8

SM

FDS6975

402

R42

MF

1/16W

5%

470K

402

MF

1/16W

1%

10K

R449

402

R43

MF

1/16W

5%

330K

402

CERM

16V

20%

0.01uF

C64

2512

FF

1W

5%

100

R54

30BQ040

D8

SM

2512

FF

1W

5%

100

R48

2512

FF

1W

5%

100

R60

402

R492

MF

1/16W

1%

39.2K

S2

GATE

S1

S3D4

D3
D2

D1

Q12

SI4435DY

SOI

S

D

G

Q43

2N7002

SM

+3V_PMU

402

CERM

16V

20%

0.01uF

C731

603

R514

FF

1/16W

.5%

100K

SM

U49

LMC7211

603

R493

FF

1/16W

.5%

100K

SM

L18

FERR-EMI-100-OHM

SM

L17

FERR-EMI-100-OHM

SM

L16

FERR-50-OHM

SM

L64

FERR-50-OHM

402

R522

MF

1/16W

1%

665K

+3V_PMU

TH

M-ST

J15

603

R521

FF

1/16W

.5%

100K

S2

GATE

S1

S3 D4

D3
D2

D1

Q30

SI4435DY

SOI

G

D

S

SOT-363

2N7002DW

Q35

G

D

S

SOT-363

2N7002DW

Q35

G2

D2

S2

SC70-6

FDG6324L

Q31

SOT-363

BAS16TW

DP5

G1

S1

D1

Q31

FDG6324L

SC70-6

402

R128

MF

1/16W

1%

97.6K

402

R592

MF

1/16W

5%

470K

402

R513

MF

1/16W

1%

35.7K

603

CERM

50V

20%

0.01uF

C25

C216

0.01uF

603

CERM

50V

20%

603

CERM

16V

5%

0.047uF

C806

402

R669

MF

1/16W

5%

470K

402

CERM

16V

20%

0.01uF

C869

402

R670

MF

1/16W

5%

330K

G

D

S

SOT-363

2N7002DW

Q57

G

D

S

SOT-363

2N7002DW

Q57

402

MF

1/16W

5%

0

R676

805

CERM

50V

20%

0.1uF

C341

SM

B540C

D2

S1A-13

SMA

D26

53780

F-RT-SM

J20

DP3

BAS40TW

SOT-363

DP3

BAS40TW

SOT-363

402

MF

1/16W

5%

0

R410

402

CERM

16V

20%

0.01uF

C185

402

MF

1/16W

5%

1M

R127

SM

U26

LMC7211

402

R131

MF

1/16W

1%

10K

S

D

G

Q29

2N7002

SM

402

CERM

16V

20%

0.01uF

C184

+3V_PMU

402

MF

1/16W

5%

1M

R140

402

R126

MF

1/16W

1%

100K

SM

U27

LMC7211

402

CERM

10V

20%

0.1uF

C190

402

R141

MF

1/16W

1%

57.6K

402

R147

MF

1/16W

1%

10K

402

R237

MF

1/16W

1%

10K

402

R139

MF

1/16W

1%

102K

402

R262

MF

1/16W

5%

470K

402

R261

MF

1/16W

5%

470K

402

R243

MF

1/16W

5%

330K

402

R348

MF

1/16W

5%

330K

+3V_PMU

+3V_PMU

402

R496

MF

1/16W

5%

10K

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

35 46

E

051-6403

ADAPTER & BATTERY INTERFACES

DC INRUSH LIMITER

GREATER THAN 13.5V DETECT

BATTERY SWITCH

DC POWER SEQUENCING

-> TO SYSTEM
<- FROM CHARGER

-> TO CHARGER

DC POWER INPUT

BATTERY CONNECTOR

LOW-VOLTAGE CHARGE LIMITER

(POWER JACK, ETC. ON DC INPUT BOARD)

2

1

2

1

314

2

6

5

8

7

2

1

12

2

1

2

1

12

21

12

12

2

1

3
2
1

4

8
7
6
5

2

1

3

2

1

2

1

2

5

1

3

4

2

1

21

21

12

12

2

1

CRITICAL

6
5
4
3
2
1

2

1

3
2
1

4

8
7
6
5

4

5

3

1

2

6

CRITICAL

4

3
2

6

4 3

1

5

6

2

1

2

1

1

2

2

1

21

CHGND1

CHGND1

2

1

2

1

2

1

2

1

1

2

6

4

5

3

NO STUFF

12

2

1

21

NO STUFF

2

1

CRITICAL

8

7

6

5

4

3

2

1

10

9

43

6 1

21

2

1

21

2

5

1

3

4

2

1

2

1

3

2

1

21

2

1

2

5

1

3

4

NO STUFF

2

1

1

2

1

2

1

2

1

2

1

2

1

2

1

2

2

1

2

1

CR-35

GTR_THAN_13_0V

RUN/SS

CHARGE_LED_L

ZENER_GTR_THAN_18V

BATT_FET_SW

BATT_RES

BATT_ENABLE_L

CHRG_DSCHG_L

BATT_FET_GATE

BATT_FET2_GATE

ADAPTER_PWR_SW

BATT_OK

BATT_NEG

PMU_BATT_DET_L

BATT_DATA

BATT_CLK

BATT_IN_PD

BATT_POS

BATT_POS_F

PMU_SMB_DATA

PMU_SMB_CLK

BATT_OK_REF

BATT_V_GOOD

BYPASS_R_L

BYPASS_R_GATE

BATT_RC

BATT_FET_DRAIN

BATT_LINE

PMU_CHRG_BATT_0

+ADAPTER_SW

AC_ENABLE_L

AC_IN

13_5V_DET

PBUS_DIV

1V20_REF

1V20_REF

INPUT14_24V_SW

3V_PMU_CHGR

PMU_CHRG_EN_L

AC_ENABLE_GATE

+ADAPTER

ADAPTER_DET

34<

43<>

36<

43<>

43<>

37<

36<>

34<>

36<>

43<>

43<>

43<>

43<>

37<>

34<>

34<>

43<>

34<>

36<>

28<>

43<>

36<>

43<>

34<

C13

220uF

20%
25V
ELEC
SM

402

R188

MF

1/16W

1%

2.61K

402

R379

MF

1/16W

1%

15.8K

SM

MBRS140T3

D5

603

R469

FF

1/16W

0.1%

49.3K

805

R459

MF

1/10W

.1%

100K

603

R467

MF

1/16W

1%

150

C124

100uF

20%
35V
ELEC
SM-1

603

R414

MF

1/16W

5%

1

603

R310

FF

1/16W

0.1%

42.2K

C343

0.1uF

402

CERM

10V

20%

402

R363

MF

1/16W

1%

20.5K

+PBUS

SOI

SI4410DY

Q6

402

R198

MF

1/16W

5%

3.3K

D16

1N5248B

SOT23

SM-2MT

J13

SOT-363

BAS16TW

DP2

SOT-363

BAS16TW

DP2

SOT-363

BAS16TW

DP5

402

R41

MF

1/16W

1%

4.99K

402

MF

1/16W

1%

10K

R263

402

MF

1/16W

1%

1K

R378

C517

0.1uF

402

CERM

10V

20%

C36

100uF

20%
35V
ELEC
SM-1

S

D

G

Q40

2N7002

SM

S

D

G

Q44

2N7002

SM

603

R266

MF

1/16W

0.1%

2.21K

805

CERM

10V

N20P80%

4.7uF

C874

402

MF

1/16W

5%

100K

R685

402

R686

MF

1/16W

5%

470K

G1

S1

D1

Q58

FDG6324L

SC70-6

G2

D2

S2

SC70-6

FDG6324L

Q58

SOT-363

BAS16TW

DP2

+5V_MAIN

Q7

IRF7822

SM

402

CERM

10V

20%

0.1uF

C890

805

CERM

16V

20%

0.47uF

C891

402

CERM

50V

10%

0.0022uF

C401

402

MF

1/16W

5%

0

R346

402

R362

MF

1/16W

1%

4.32K

402

R387

MF

1/16W

1%

10.2K

402

MF

1/16W

1%

499K

R389

402

R390

MF

1/16W

5%

10K

603

R409

MF

1/16W

1%

53.6K

G

D

S

SOT-363

2N7002DW

Q63

G

D

S

SOT-363

2N7002DW

Q63

+3V_PMU

402

CERM

10V

20%

0.1uF

C433

SM

U44

LMC7211

805

R468

MF

1/10W

0.1%

11.3K

2512

MF

1W

1%

0.025

R1

GND

OUT

PG

RS-V+RS+

NC2

NC1

SOI

MAX4172

U3

603

CERM

50V

20%

0.01uF

C22

SM-2

5AMP-125V

F1

C37

100uF

20%

35V
ELEC
SM-1

1812

CERM

50V

20%

1.5uF

C308

1812

CERM

50V

20%

1.5uF

C484

603

MF

1/16W

5%

0

R444

1812

CERM

50V

20%

1.5uF

C307

1812

CERM

50V

20%

1.5uF

C483

1812

CERM

50V

20%

1.5uF

C371

1812

CERM

50V

20%

1.5uF

C417

402

CERM

16V

20%

0.01uF

C749

402

R553

MF

1/16W

5%

330K

603

R287

MF

1/16W

1%

82.5K

S2

GATE

S1

S3D4

D3
D2

D1

Q17

SI4435DY

SOI

402

R560

MF

1/16W

5%

470K

805

CERM

16V

20%

0.33uF

C49

1812

CERM

25V

20%

4.7uF

C85

1812

CERM

25V

20%

4.7uF

C102

MBR0540

D4

SM

C63

4.7uF

20%
10V
TANT
SMB

EXTVCC

LTC1625

BG

VOSENSE

TG

INTVCC

FCB

ITH

VPROG

RUN/SS

SYNC

VIN
TK

PGNDSGND

SW

BOOST

SSOP

U17

603

CERM

25V

5%

4700pF

C597

603

CERM

50V

10%

470pF

C61

805

CERM

50V

20%

0.1uF

C569

603

CERM

25V

5%

4700pF

C65

1812

CERM

50V

20%

1.5uF

C372

1812

CERM

50V

20%

1.5uF

C418

S

D

G

Q27

2N7002

SM

2512

MF

1W

1%

0.025

R20

GND

OUT

PG

RS-

V+

RS+

NC2

NC1

SOI

MAX4172

U30

603

CERM

50V

20%

0.01uF

C202

603

MF

1/16W

1%

150

R427

402

MF

1/16W

1%

1K

R264

402

MF

1/16W

1%

10K

R265

402

CERM

10V

20%

0.1uF

C342

LMC6462

SOI

U40

LMC6462

SOI

U40

603

R337

FF

1/16W

0.1%

42.2K

402

R497

MF

1/16W

5%

330K

603

CERM

16V

5%

0.047uF

C735

SM-2

L11

15uH

REFERENCE DESIGNATOR(S)

BOM OPTION

TABLE_5_HEAD

QTY

DESCRIPTION

PART#

TABLE_5_ITEM

M_S_G

110S8254

1

RES,82.5K,1%,1/16W,MF,402

R287

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

36 46

E

051-6403

CRITICAL BOM OPTION

TABLE_5_HEAD

PART#

DESCRIPTION

QTY

REFERENCE DESIGNATOR(S)

TABLE_5_ITEM

CRITICAL376S0254

1

XSTR,MOSFET,N-CH,30V,.0135 OHM,10A,8P,SO

Q6

TABLE_5_ITEM

CRITICAL376S0104

1

XSTR,FET,N-CH,30V,14A,.012 OHM,8P,SOIC

Q7

TABLE_5_ITEM

S_B_G

103S0559

1

RES,37.4K,0.1%,1/16W,MF,402

R287

FOR 15V AIRLINE ADAPTER

ADJUSTS CURRENT LIMIT

VS. 24V WALL ADAPTER

TO/FROM BACKUP BATTERY <->

PRIMARY REGULATOR

BATTERY CHARGING CURRENT LIMIT

-> TO SYSTEM

ADAPTER CURRENT LIMIT

CONNECT LTC1625 TK PIN AT TOP-SIDE FET

KEEP VIN/TK LOOP SHORT

FROM BATTERY ->

TO BATTERY <-

-> FROM ADAPTER

PBUS hold-up caps

been brought up. This will improve efficiency of LTC1625 since external
switcher is used instead of internal LDO.

Provides power to LTC1625 if on an adapter and after all rails have

ADDITIONAL POWER LIMITING CIRCUIT FOR P88 DVT2

2

1

1

2

1

2

2

1

1

2

1

2

1

2

2

1

1

2

1

2

21

1

2

OMIT

CRITICAL

321

4

8765

2

1

3

1

CRITICAL

3

2

1

5

4

61

4 3

61

1

2

12

12

12

2

1

2

1

3

2

1

3

1

2

2

1

21

2

1

CRITICAL

1

5

6

CRITICAL

4

3
2

6

5 2

OMIT

CRITICAL

321

4

8765

2

1

2

1

NO STUFF

2

1

21

M_S_G

2

1

M_S_G

2

1

M_S_G

21

M_S_G

2

1

M_S_G

2

1

M_S_G

1

2

6

M_S_G

4

5

3

M_S_G

2

1

M_S_G

2

5

1

3

4

2

1

CRITICAL

12

8

2 1

7

6 4

3

5

2

1

12

2

1

2

1

2

1

21

2

1

2

1

2

1

2

1

2

1

2

1

OMIT

2

1

3
2
1

4

8
7
6
5

2

1

2

1

2

1

2

1

21

2

1

8

7

16
15 13

2

14

639

5

11

4

1

12

10

2

1

2

1

2

1

2

1

2

1

2

1

2

1

3

CRITICAL

21

8

21

7

64

3

5

2

1

2 1

21

21

2

1

8

4

7

5

6

8

4

1

3

2

2

1

2

1

2

1

21

CR-36

1_02V_AUX

GTR_THAN_13V_RC

GTR_THAN_13_0V

EXTVCC_EN_L

LTC1625_EXTVCC

LTC1625_EXTVCC

1625_SGND

3V_PMU_CHGR

PMU_CHARGE_V

ITH_1625

ICHRG_REG

ADAPTER_I_REG

PWR_STABLE_DELAY

GTR_THAN_13_0V

1_02V_AUX

IAC_FB

IINX0_62

IAC_RC_COMP

INPUT14_24V_SW

1625_VIN

COMP_RC

RUN/SS

1625_VFB

CHGR_OUT

PBUS_DIV1

IBATT_SERVO

IBATTX0_65

BATT_ISNSBATT_LINE

PWRBUS_14_24V

BF_FET_G

IBATT_FB

3V_PMU_CHGR

IBATT_RC_COMP

BBATT_ENABLE

_VCHRG

FET_DRAIN

1625_COMP

ZENER_GTR_THAN_18V

+ADAPTER_SW

CURRENT_ADJ

PWRBUS_14_24V

1625_TG

CHGR_VSW

1625_BST_F

1625_BG

1625_BST

1625_INTVCC

PMU_AC_DET_UF

43<>

43<>

43<>

36<

36<>

36<

43<>

36<>

36<>

43<>

36<>

36<>

43<>

43<>

35<>

43<>

36<>

43<>

35<>

34<>

35<>

43<>

43<>

43<>

43<>

35<>

29<>

35<>

37<

35<>

35<>

29<>

43<>

43<>

1206

CERM

16V

N20P80%

3.3uF

C659

402

R535

MF

1/16W

5%

470K

402

CERM

16V

20%

0.01uF

C767

402

MF

1/16W

5%

100K

R573

402

MF

1/16W

5%

100K

R527

XW9

SM

XW6

SM

+3V_PMU

VTAP

IN

OUT

SENSE

GND

FDBK

ERR

LP2951

SHUT

SOI-3.3V

U18

603

R364

MF

1/16W

5%

1

805

CERM

10V

N20P80%

4.7uF

C529

402

CERM

10V

20%

0.1uF

C46

SOT23

1N914

D3

603

CERM

50V

10%

470pF

C38

402

R32

MF

1/16W

1%

348K

402

R24

MF

1/16W

1%

100K

402

CERM

10V

20%

0.1uF

C41

SHUT

PLUS5VTAP

LP2951

ERR

FDBK

GND

SENSE

OUT

IN

U6

SOI

MBR0540

D18

SM

805

CERM

50V

20%

0.1uF

C370

MBR0540

D15

SM

MBR0540

SM

D6

MBR0540

SM

D13

1210

FF

1/4W

5%

390

R230

402

R588

MF

1/16W

5%

470K

XW19

SM

G

D

S

SOT-363

2N7002DW

Q39

G

D

S

SOT-363

2N7002DW

Q39

G

D

S

SOT-363

2N7002DW

Q46

G

D

S

SOT-363

2N7002DW

Q46

C101

330uF

20%

6.3V
TANT
SMD

G2

D2

S2

SC70-6

FDG6324L

Q47

G1

S1

D1

Q47

FDG6324L

SC70-6

1N914

SOT23

D20

1N914

SOT23

D22

C759

150uF

20%

6.3V
TANT

SMD-1

C660

4700pF

603

CERM

25V

5%

C758

150uF

20%

6.3V
TANT
SMD-1

C760

150uF

20%

6.3V
TANT

SMD-1

C528

150uF

20%

6.3V
TANT
SMD-1

C710

150uF

20%

6.3V
TANT
SMD-1

C598

150uF

20%

6.3V
TANT

SMD-1

C646

150uF

20%

6.3V
TANT

SMD-1

L14

SM1

8.0uH

603

R28

MF

1/16W

5%

1

805

CERM

10V

N20P80%

4.7uF

C47

+PBUS

402

R478

MF

1/16W

5%

22

402

MF

1/16W

5%

1K

R694

402

R695

MF

1/16W

5%

470K

MBRS130T3

SM

D7

2512

MF

1W

2%

0.015

R53

C58

330uF

20%

6.3V
TANT

SMD

2512

MF

1W

2%

0.015

R40

805

CERM

50V

20%

0.1uF

C669

SM-5

L13

10uH

MBRS130T3

SM

D9

SOI

FDS6612A

Q14

GND5

GND4

GND3

GND2

GND1

GND0

SYNC

REF

SS3

SHDN
SS5

ON3

ON5

VL

DL5

LX5

CS5

BST5

DH5

VPLUS

FB5

PGND

CS3

FB3

DL3

DH3

LX3

BST3

MAX785

SSOI

U48

805

CERM

50V

20%

0.1uF

C668

1812

CERM

25V

20%

4.7uF

C728

1812

CERM

25V

20%

4.7uF

C732

1812

CERM

25V

20%

4.7uF

C729

1812

CERM

25V

20%

4.7uF

C733

402

R532

MF

1/16W

5%

0

402

MF

1/16W

5%

0

R526

402

CERM

50V

20%

0.001uF

C739

805

CERM

16V

N20P80%

1.0uF

C740

402

CERM

16V

20%

0.01uF

C730

+5V_MAIN

+3V_MAIN

+PBUS

SM

FDS6680A

Q9

SM

FDS6680A

Q16

SOI

FDS6612A

Q13

+PBUS

C80

100uF

20%
10V
TANT
SMD-3

+5V_SLEEP

C81

100uF

20%
10V
TANT
SMD-3

TSOP

Q10

SI3443DV

C67

0.01uF

402

CERM

16V

20%

+5V_MAIN

402

MF

1/16W

5%

100K

R45

TSOP

Q11

SI3443DV

C68

0.1uF

402

CERM

10V

20%

1206

CERM

16V

N20P80%

10uF

C724

402

MF

1/16W

5%

100K

R44

402

R475

MF

1/16W

5%

100K

402

CERM

16V

20%

0.01uF

C686

402

MF

1/16W

5%

100K

R465

+3V_SLEEP

805

CERM

50V

20%

0.1uF

C658

+5V_MAIN

402

R460

MF

1/16W

5%

100K

402

MF

1/16W

5%

100K

R486

TSOP

Q36

SI3443DV

C670

2200pF

603

CERM

50V

5%

+3V_MAIN

C62

100uF

20%
10V
TANT
SMD-3

402

MF

1/16W

5%

100K

R485

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

37 46

E

051-6403

PROVIDES PATH TO
+3V_PMU FROM BACKUP
BATTERY WHEN PRESENT

ADAPTER OR BATTERY

BOOTSTRAP SYSTEM FROM

X

0

1

1
0

0

SLEEP

PMU_POWER_UP_L

DCDC_EN

DCDC_EN TRUTH TABLE

0

11Run

Sleep
Shutdown

State

(PS_LX_3V)

ROUTE AS PAIR SHORT TRACE

ROUTE AS PAIR SHORT TRACE

NOTE: Place Rsense RC filter

(PS_LX_5V)

3.3V/5V SUPPLIES

+5V_SLEEP LOADS

+3V_SLEEP LOADS

SLEEP LEVEL SHIFTER (3V -> 5V)

2) Headphone amplifier

3) Modem - call progress ADC

4) DVD ROM

5) CardSlot - 5V tolerance

6) Trackpad

1) Fan - High speed supply

1) CPU PLL Config Control

2) Fan - Low speed supply

3) KeyLargo - IIC Pull-ups & Oscillator

4) CardBus - Card detect pull-ups

5) Mobility Radeon - Oscillator

6) C5005 - Core, I/O

7) IRDA - VCC, LEDA, FIR_SEL pull-up

8) LVDS DDC Pull-ups

9) VGA MonID Level Shifters & Pull-ups

10) CardSlot

11) PMU - IIC Pull-ups

PMU SUPPLY

NC

NC

(R478/C660) close to MAX785 pins

2

1

2

1

2

1

21

21

2

1

2

1

6

3

2

18

4

7

5

2

1

2

1

2

1

31

2

1

2

1

2

1

2

1

3

2

6

18

4

7

5

21

2

1

21

2

1

2

1

21

2

1

OMIT

21

4

5

3

1

2

6

1

2

6

4

5

3

2

1

CRITICAL

4

3
2

6

CRITICAL

1

5

6

3

1

3

1

2

1

21

2

1

2

1

2

1

2

1

2

1

2

1

3

1 2

2

1

2

1

2

1

21

2

1

2

1

21

2

1

21

2

1

2

1

321

4

8765

23

22

11

14

2

12

10

20

13

3

17

26

9

8

7

6

5

4

21

28

19

24

16

27

15

1

18

25

2

1

2

1

2

1

2

1

2

1

2

1

NO STUFF

21

2

1

2

1

NO STUFF

2

1

321

4

8765

321

4

8765

321

4

8765

2

1

2

1

4

3 6

5
2
1

21

21

4

3 6

5
2
1

21

2

1

21

2

1

2

1

21

2

1

2

1

21

4

3 6

5
2
1

12

2

1

21

CR-37

BBATT_ENABLE_ESD

BBATT_ENABLE

+5V_RSNS

PS_LX_5V

SLEEP_L_LS5

SLEEP_LS5_EN_L

3V_SLEEP_PWREN_L

SLEEP

+5V_HD_SLEEP

5V_HD_PWREN

5V_SLEEP_PWREN

PS_NGATE_5V

PS_PGATE_5V

PS_FB_5V

PS_CS_5V

MAX785_EN

PS_FB_3V
PS_CS_3V

PS_PGATE_3V

PS_LX_3V

PS_NGATE_3V

DCDC_EN

PMU_POWER_UP_L

SLEEP

DCDC_EN_L

PS_SYNC

PS_SS_3V
PS_REF

PS_SS_5V

3V_PMU_SENSE

3V_PMU_VTAP

FB_5_5V_BU

+ADAPTER_ILIM

+ADAPTER

MAX785_GND

SLEEP_L_LS5_EN_L

SLEEP_LS5

+BBATT_BYPASS

BBATT_EN_L

PS_VL

PS_BST_5V

PS_BST_3V

+5_5V_BU

+3V_PMU_ESR

+5_5V_ESR

+5_5V_RAW

+ADAPTER_OR_BATT

BATT_POS_F

38< 37<

39<>

37<>

43<>

39<>

34<

43<>

43<>

36<>

43<>

43<>

28<>

34<>

32<>

43<>

43<>

38<>

34<>

34<>

35<>

43<>

43<> 43<>

35<>

SM-1

L5

5uH

603

MF

1/16W

5%

0

R215

+2_5V_MAIN

2512

MF

1W

2%

0.015

R37

SM-1

L9

5uH

402

R2

MF

1/16W

1%

64.9K

402

R4

MF

1/16W

1%

49.9K

805

CERM

10V

20%

1uF

C207

402

CERM

16V

20%

0.01uF

C12

603

MF

1/16W

5%

0

R155

+5V_MAIN

1812

CERM

25V

20%

4.7uF

C217

MAX1644

FB

SS

REF

GND

PGND2

PGND1

TOFF

COMP

VCC
FBSEL
SHDN
REF

LX3

LX2

LX1

IN2

IN1

U33

SSOI-B

805

CERM

10V

N20P80%

4.7uF

C226

1812

CERM

25V

20%

4.7uF

C218

603

CERM

50V

10%

470pF

C9

402

R156

MF

1/16W

1%

200K

402

R197

MF

1/16W

5%

10

402

R14

MF

1/16W

5%

100K

402

CERM

16V

20%

0.01uF

C16

+1_8V_SLEEP

+1_8V_MAIN

1206

CERM

16V

N20P80%

10uF

C57

C56

2200pF

603

CERM

50V

5%

402

MF

1/16W

5%

100K

R39

SI3447DV

U19

TSOP

SOT-363

BAS16TW

DP1

SOT-363

BAS16TW

DP1

SI3447DV

U12

TSOP

1206

CERM

16V

N20P80%

10uF

C45

C48

2200pF

603

CERM

50V

5%

402

MF

1/16W

5%

100K

R36

+2_5V_MAIN

+2_5V_SLEEP

C482

220uF

20%
4V
TANT
SM

C568

220uF

20%
4V
TANT
SM

C227

330uF

20%

2.5V
TANT
SM

402

CERM

50V

10%

470pF

C871

402

CERM

50V

10%

470pF

C872

402

R318

MF

1/16W

1%

2.61K

1812

CERM

25V

20%

4.7uF

C34

402

R158

MF

1/16W

1%

32.4K

402

R21

MF

1/16W

1%

49.9K

2512

MF

1W

2%

0.015

R13

1812

CERM

25V

20%

4.7uF

C24

402

R19

MF

1/16W

5%

10

805

CERM

10V

N20P80%

4.7uF

C228

805

CERM

10V

20%

1uF

C252

402

R26

MF

1/16W

5%

100K

402

R22

MF

1/16W

1%

182K

603

CERM

50V

10%

470pF

C32

402

CERM

16V

20%

0.01uF

C27

402

CERM

16V

20%

0.01uF

C33

+1_8V_MAIN

MAX1644

FB

SS

REF

GND

PGND2

PGND1

TOFF

COMP

VCC
FBSEL
SHDN
REF

LX3

LX2

LX1

IN2

IN1

U36

SSOI-B

+3V_MAIN

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

38 46

E

051-6403

2) Mobility Radeon - AVDDs

1) L3 Core

+2_5V_SLEEP LOADS

2) CPU JTAG & MaxBus Pull-ups

4) C5005 VDDCPU0

1) MPC7450 - MaxBus I/O, L3 I/O

3) CPU PLL Config Straps

+1_8V_SLEEP LOADS

1.8V/2.5V SUPPLIES

+2_5V_MAIN LOADS

2) Gigabit Ethernet - AVDDL

+1_8V_MAIN LOADS

1) Uni-N - Core, PLL DVDDs, MaxBus I/O

3) Gigabit Ethernet - DVDDH

1) Mobility Radeon - AVDDs, DDR I/O and core

2.5V SWITCHER

1.8V SWITCHER

21

12

21

21

2

1

2

1

2

1

2

1

12

2

1

12

7 5

1

10

15

13

16

14

3

4

2

9

11

8

6

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

12

21

4

3 6

5
2
1

6 1

4 3

L3_RC

4

3 6

5
2
1

L3_RC

2

1

L3_RC

21

L3_RC

21

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

21

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

12

7 5

1

10

15

13

16

14

3

4

2

9

11

8

6

CR-38

1_8V_FB

1_8V_GND

2_5V_LX_M

1_8V_SHDN_L

1_8V_TOFF

MAX1644_VCC

1_8V_SS

1_8V_REF

DCDC_EN

1_8V_COMP

1_8V_LX

2_5V_SHDN_L

DCDC_EN

2_5V_MAX1644_VCC

2_5V_TOFF

2_5V_COMP

2_5V_SS

2_5V_REF

1_8V_LX_F

SLEEP

1_8V_SLEEP_PWREN_L

2_5V_SLEEP_PWREN_L

SLEEP

2_5V_GND

2_5V_LX

2_5V_LX_F

2_5V_FB

39<>

39<>

38<>

38<>

37<>

37<>

37<>

43<>

37<>

43<>

34<>

34<>

43<>

43<>

402

R471

MF

1/16W

5%

100K

+5V_MAIN

402

R461

MF

1/16W

5%

100K

+1_8V_SLEEP

SM

2N3904

Q37

SM

2N3904

Q38

402

R454

MF

1/16W

5%

10K

XW8

SM

C70

1000uF

20%

2.5V
TANT
SM

XW7

SM

C72

1000uF

20%

2.5V
TANT

SM

1210

CERM

25V

20%

4.7uF

C761

1210

CERM

25V

20%

4.7uF

C747

1210

CERM

25V

20%

4.7uF

C738

1210

CERM

25V

20%

4.7uF

C726

+PBUS

SM

D23

MBR0530

805

CERM

16V

N20P80%

1.0uF

C773

+5V_MAIN

402

R584

MF

1/16W

5%

20

C66

1000uF

20%

2.5V
TANT
SM

C71

1000uF

20%

2.5V
TANT
SM

L15

SM1

1.5uH

MBRS340T3

SM

D10

C69

1000uF

20%

2.5V
TANT

SM

402

R582

MF

1/16W

5%

100K

603

CERM

16V

20%

0.1uF

C82

D0
D1
D2
D3
D4

SKP/SDN

VCC VDD

V+

ILIM

FBS

GNDS
A/B

REF

TON
CC

BST

DH

LX
DL

GND

VGATE

FB

TIME

MAX1717

U50

QSOP

402

MF

1/16W

5%

100

R536

XW21

SM

402

CERM

50V

20%

0.001uF

C745

402

R533

MF

1/16W

5%

390K

805

CERM

16V

N20P80%

1.0uF

C772

402

R557

MF

1/16W

5%

0

805

CERM

50V

10%

220pF

C750

402

R575

MF

1/16W

1%

27.4K

805

CERM

16V

N20P80%

1.0uF

C755

402

R580

MF

1/16W

1%

24.9K

402

CERM

16V

20%

0.01uF

C741

402

R538

MF

1/16W

5%

0

402

R550

MF

1/16W

5%

0

402

R558

MF

1/16W

5%

470K

402

R566

MF

1/16W

5%

0

XW10

SM

603

R574

MF

1/16W

1%

1.62K

603

R576

MF

1/16W

1%

162K

SOT-363

BAS16TW

DP4

SOT-363

BAS16TW

DP4

SOT-363

BAS16TW

DP4

402

R581

MF

1/16W

1%

66.5K

402

CERM

25V

10%

0.0047uF

C742

402

CERM

25V

10%

0.0047uF

C768

1210

R583

MF

1/4W

5%

2.2

805

FF

1/10W

5%

2.2

R47

1210

CERM

25V

20%

4.7uF

C762

1210

CERM

25V

20%

4.7uF

C746

1210

CERM

25V

20%

4.7uF

C725

1210

CERM

25V

20%

4.7uF

C737

1210

CERM

25V

20%

4.7uF

C692

1210

CERM

25V

20%

4.7uF

C691

1210

CERM

25V

20%

4.7uF

C721

1210

CERM

25V

20%

4.7uF

C720

805

CERM

6.3V

20%

10uF

C694

805

CERM

6.3V

20%

10uF

C695

805

CERM

6.3V

20%

10uF

C696

805

CERM

6.3V

20%

10uF

C697

805

CERM

6.3V

20%

10uF

C604

805

CERM

6.3V

20%

10uF

C693

805

CERM

6.3V

20%

10uF

C699

805

CERM

6.3V

20%

10uF

C633

805

CERM

6.3V

20%

10uF

C282

805

CERM

6.3V

20%

10uF

C698

805

CERM

6.3V

20%

10uF

C618

805

CERM

6.3V

20%

10uF

C281

805

CERM

6.3V

20%

10uF

C283

805

CERM

6.3V

20%

10uF

C285

805

CERM

6.3V

20%

10uF

C286

805

CERM

6.3V

20%

10uF

C600

805

CERM

6.3V

20%

10uF

C534

805

CERM

6.3V

20%

10uF

C405

805

CERM

6.3V

20%

10uF

C647

805

CERM

6.3V

20%

10uF

C574

Q15

IRF7805

SM

Q18

FDS6672A

SM

Q19

FDS6672A

SM

M-ST-SM-52465-1217

J22

402

MF

1/16W

1%

2.05K

R479

402

MF

1/16W

1%

100

R480

603

CERM

50V

10%

0.0022uF

C769

2512

MF

1W

1%

0.002

R613

C863

1000uF

20%

2.5V
TANT

SM

402

R260

MF

1/16W

5%

470K

402

R537

MF

1/16W

5%

470K

402

R559

MF

1/16W

5%

470K

402

R577

MF

1/16W

5%

470K

402

R567

MF

1/16W

5%

0

402

R551

MF

1/16W

5%

0

Q51

IRF7805

SM

402

R520

MF

1/16W

1%

100K

TABLE_5_ITEM

P88_VCORE_OFFSET

110S1625

1

RES,MF,1/16W,162K OHM,1,0603,SMD

R576

TABLE_5_ITEM

P59_VCORE_OFFSET

110S1625

1

RES,MF,1/16W,162K OHM,1,0603,SMD

R576

TABLE_5_ITEM

152S0091

1

IND,1.4UF,20,W/W PWR,SHLD,20.4A,SMD

L15

TABLE_5_ITEM

CRITIAL

P88_SENSE

107S0023

1

RES,FILM,1W,0.001 OHM,2512,SMD

R613

CRITICAL BOM OPTION

TABLE_5_HEAD

PART#

DESCRIPTION

QTY

REFERENCE DESIGNATOR(S)

TABLE_5_ITEM

CRITICAL

P59_SENSE

107S0019

1

RES,FILM,1W,0.002 OHM,2512,SMD

R613

TABLE_5_ITEM

P88_VCORE_OFFSET

110S3013

1

RES,MF,1/16W,3.01K OHM,1,0603,SMD

R574

REFERENCE DESIGNATOR(S)

BOM OPTION

TABLE_5_HEAD

QTY

DESCRIPTION

PART#

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

39 46

E

051-6403

TABLE_5_ITEM

P59_VCORE_OFFSET

110S1623

1

RES,MF,1/16W,1.62K OHM,1,0603,SMD

R574

Keep trace fat and short!!

<D1><D4>

PIN OF 1000uF CAP
CLOSEST TO CPU

PLACE THIS SHORT AT

Keep trace fat and short!!

Keep trace fat and short!!

D<4..0>

A/B_ =

0

1

1

0

0

0

1

1

Hi/Fast Lo/Slow

<= 1K PD

>= 100K PD

>= 100K PU

<= 1K PU

FOR V-STEP:

Fmax Test Connections

NC (RFU)

Keep trace fat (40-100 mils) and short!!

NC

VCORE SUPPLY

B

pull-downs are <=1K, V = V .

If all pull-ups are >=100K and all

>=100K-ohm -> 1

When A/B_ is high (fast): D4-D0 read as-is
When A/B_ is low (slow): <=1K-ohm -> 0

VCORE POWER SEQUENCING

CPU core follows CPU I/O voltage
(approx. 7ms delay)

<D0><D2>

A

to pins 15 & 12!!

This allows for an offset to the ground sense to adjust the output voltage.

Connect MAX1717 GND pin 13
to GND at bottom-side FET

GROUND SENSE VOLTAGE DIVIDER

ROUTE AS DIFFERENTIAL PAIR

(VCORE_GNDSNS)

(VCORE_SNS)

<D3>

D4=0 D4=1

NO CPUNO CPU

V

DAC

1.30

1.35

1.65

1.55

1.40

1.60

1.50

1.45

1.70

2.00

1.95

1.80

1.85

1.90

1.75 1.150

1.175

1.200

1.225

1.250

1.275

1.125

0.975

1.000

1.025

1.050

1.075

1.100

0.950

0.925

D1 D0D2D3

0

1

0

0

0

0

1

1
0
1

0

1

01

0

0

0

1

1

0

1

0
1
0

1

1

0

1

0

1

0

0

0

0

0

0

0

0

10

0

1

1

0
0
0

1

1
1
1

1

0

1 101

0

111

1
1 1

1

OUTPUT VOLTAGE

Vref = 2.0V, hence Voffset = 2.0V * (R574 / R576) and Vcore = Vdac + Voffset.

NOTE: R576 NO STUFFed for no offset case

Place C773 close

2

1

2

1

2

3

1

2

3

1

2

1

21

CRITICAL

2

1

21

CRITICAL

2

1

CRITICAL

2

1

CRITICAL

2

1

CRITICAL

2

1

CRITICAL

2

1

CRITICAL

2

1

2

1

2

1

CRITICAL

2

1

CRITICAL

2

1

CRITICAL

OMIT

3

2 1

CRITICAL

2

1

CRITICAL

2

1

2

1

2

1

CRITICAL

12

15

7

1

8

3

2

9

23

10
11

13

5

4

14

24

17

18

19

20

21

6

22

16

21

21

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

2

1

NO STUFF

2

1

NO STUFF

2

1

NO STUFF

2

1

NO STUFF

2

1

21

OMIT

2

1

VCORE_OFFSET

2

1

5 2

4 3

6 1

2

1

NO STUFF

2

1

2

1

NO STUFF

2

1

2 1

CRITICAL

2

1

CRITICAL

2

1

CRITICAL

2

1

CRITICAL

2

1

CRITICAL

2

1

CRITICAL

2

1

CRITICAL

2

1

CRITICAL

2

1

CRITICAL

2

1

CRITICAL

2

1

CRITICAL

2

1

CRITICAL

2

1

CRITICAL

2

1

CRITICAL

2

1

CRITICAL

2

1

CRITICAL

2

1

CRITICAL

2

1

CRITICAL

2

1

CRITICAL

2

1

CRITICAL

2

1

CRITICAL

2

1

CRITICAL

2

1

CRITICAL

2

1

CRITICAL

2

1

CRITICAL

2

1

CRITICAL

2

1

CRITICAL

2

1

CRITICAL

2

1

CRITICAL

321

4

8765

CRITICAL

321

4

8765

CRITICAL

321

4

8765

NO STUFF

3

2

1

7

8

9

10

11

6

5

4

12

NO STUFF

21

NO STUFF

21

NO STUFF

2

1

OMIT

CRITICAL

21

CRITICAL

2

1

NO STUFF

2

1

2

1

2

1

2

1

2

1

2

1

CRITICAL

321

4

8765

2

1

CR-39

VCORE_SNS

VCORE_VCC

CPU_VCORE_SNUB

VCORE_BOOST

VCORE_BST

VCORE_CC

VCORE_TON

VCORE_GNDDIV

VCORE_D2
VCORE_D3

CPU_VCORE_HI_OC

VCORE_GND

VCORE_TIME

VCORE_FB

VCORE_VGATE

CPU_VCORE_SEQ

CPU_VCORE_SEQ_L

CPU_VCORE_PWR_SEQ

SLEEP_L_LS5

DCDC_EN

VCORE_REF

VCORE_GNDA

VCORE_SHDN_L

VCORE_ILIM

VCORE_DL

CPU_VCORE_SLEEP

VCORE_D1

VCORE_D0
VCORE_D1
VCORE_D2

VCORE_D4

VCORE_D3

PMU_RESET_L_SW
SOFT_PWR_ON_L

VCORE_GNDDIV_TEST

VCORE_GNDDIV

VCORE_GNDSNS_TEST

VCORE_GNDSNS

CPU_VCORE_SLEEP

VCORE_VSENSE

VCORE_GNDSNS

VCORE_D4

VCORE_D0

VCORE_LX

VCORE_VPLUS

VCORE_DH

34<

37<>

38<>

43<>

33<

43<>

43<>

39<

43<>

43<>

43<>

43<>

43<>

43<>

39<>

39<>

34<>

43<>

43<>

43<>

43<>

28<>

37<>

43<>

43<>

43<>

13<>

39<>

39<

39<

39<

39<

39<

34<>

34<>

43<>

39<>

13<>

43<>

39<>

39<>

43<>

43<>

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

40 46

E

051-6403

MAX EXPOSED LENGTH

See differential area for SDRAM clks

ATI EXT
SDRAM

FIREWIRE

M7

MOBILITY

OSCS

CRYSTALS/

ETHERNET

MEMORY

MAIN

MAXBUS

SIG_NAME

GROUP

DELAY_RULE MAX_VIAS

MAX_EXPOSED_LENGTH

DIGITAL SIGNALS

STUB_LENGTH

NET_SPACING_TYPE

NO_TEST

MIN_DAISY_CHAIN

PULSE_PARAM

GROUP

(C5005)

CLOCK CKT

SIG_NAME DELAY_RULE MAX VIAS

CLOCK LINE CONSTRAINTS

STUB_LENGTH

NET_SPACING_TYPE

PULSE PARAM

SIGNAL CONSTRAINTS - PAGE 1

AGP BYTES 0-1

AGP BYTES 2-3

AGP SIDEBAND

AGP CONTROL

PCI

L3 CACHE

CR-40

200

TRUE

CPU_WT_L

::560:3080

8

::4000:11000

33 MHz

MIN_DAISY_CHAIN

PCI_TRDY_L

3

133 MHz

200

SYSCLK_CPU

10 MIL SPACING

::6850:7100

250

::560:3080

CPU_TEA_L

200

8

::1800:2400

33 MHz

200

CLK33M_KL_PCI

10 MIL SPACING

4

500

33 MHz

200

:::200

CLK33M_UNIN_PCI_EXT_UF

::2600:3200

33 MHz

200

CLK33M_UNIN_PCI_EXT

10 MIL SPACING

4

500

66 MHz

200

CLK66M_AGP_ATI

10 MIL SPACING

4

::3000:3500

500

66 MHz

200

CLK66M_AGP_UF

:::200

66 MHz

200

CLK66M_UNIN_AGP

10 MIL SPACING

4

::2500:3000

500

66 MHz

200

CLK66M_UNIN_AGP_UF

:::200

66 MHz

200

CLK66M_UNIN_PCI_INT

10 MIL SPACING

4

::2500:3000

500

66 MHz

200

CLK66M_UNIN_PCI_INT_UF

:::200

33 MHz

200

:::200

CLK33M_KL_UF

4

33 MHz

10 MIL SPACING

200

CLK33M_CBUS

::2400:2900

500

::3000:4750

133 MHz

200

3

10 MIL SPACING

SYSCLK_DIMM0_A

250

133 MHz

:::150

SYSCLK_DIMM0_B_UF

133 MHz

:::150

SYSCLK_DIMM1_A_UF

::3000:4750

133 MHz

200

3

10 MIL SPACING

SYSCLK_DIMM1_A

250

133 MHz

:::150

SYSCLK_DIMM1_B_UF

133 MHz

:::150

SYSCLK_DIMM0_A_UF

MEM_EXT_R

:::500

::2000:5200

200

FRAM_CKE0_B

8

200

RAM_CKE2

:::600

200

RAM_CKE1

:::600

200

FRAM_CKE1_A

::2000:3880

8

200

MEMWE_L

:::1000

CAS_DQM2_L

:::500

FSDCAS_L

200

::2000:3980

8

FMEMWE_L

200

::2000:3480

8

SDCAS_L

200

:::500

FSDRAS_L

200

::2000:3980

8

SDRAS_L

200

:::500

::1680:4372

FCAS_DQM7_L

200

8

CAS_DQM5_L

:::500
::1680:4372

FCAS_DQM5_L

200

8

FBA_0

200

::2000:3480

8

FBA_1

200

::2000:3480

8

CAS_DQM7_L

:::500

::1680:4372

FCAS_DQM6_L

200

8

CAS_DQM6_L

:::500

::1680:4372

FCAS_DQM4_L

200

8

CAS_DQM4_L

:::500

::1680:4372

FCAS_DQM3_L

200

8

CAS_DQM3_L

:::500

::1680:4372

FCAS_DQM2_L

200

8

::1680:4372

FCAS_DQM1_L

200

8

CAS_DQM1_L

:::500

::1680:4372

FCAS_DQM0_L

200

8

CAS_DQM0_L

:::500

FRAS_CS3_L

200

::2000:3980

8

FRAS_CS2_L

200

::2000:3980

8

RAS_CS2_L

:::500

FRAS_CS1_L

200

::2000:3980

8

RAS_CS0_L

:::500

::2000:4872

133 MHz

MEM_DATA<63..0>

200

8

::1680:3880

FMA_AR<12..0>

200

8

133 MHz

RAD<12..0>

:::600

BA_1

:::1000

BA_0

:::1000

FRAS_CS0_L

200

::2000:3980

8

RAS_CS1_L

:::500

CPU_QACK_L

TRUE

CPU_TBST_L

TRUE

::560:3080

CPU_ARTRY_L

200

8

::560:3080

CPU_DTI<2..0>

TRUE

200

8

CPU_TSIZ<2..0>

TRUE

::560:3080

CPU_TT<4..0>

TRUE

200

8

::560:3080

CPU_TA_L

200

8

::560:3080

CPU_GBL_L

TRUE

200

8

::560:3080

CPU_TS_L

200

8

::560:3080

CPU_CI_L

TRUE

200

8

::560:3080

CPU_AACK_L

TRUE

200

8

::560:3080

CPU_DBG_L

200

8

133 MHz

::560:3080

CPU_DATA<63>

200

8

133 MHz

::560:3080

CPU_DATA<62..0>

TRUE

200

8

133 MHz

::560:3080

CPU_ADDR<31..0>

TRUE

200

8

200

FRAM_CKE0_A

::2000:3880

8

::2000:5200

200

FRAM_CKE1_B

8

200

RAM_CKE0

:::600

200

RAM_CKE3

:::600

66 MHz

AGP_SB_STB

8 MIL SPACING

90

U4.AC29:U9.F9:1450:1700

500

8

66 MHz

AGP_SB_STB_L

8 MIL SPACING

90

U4.AD28:U9.G9:1450:1700

500

8

66 MHz

AGP_RBF_L

490

U4.AE30:U9.E6:900:1450

8

66 MHz

AGP_GNT_L

490

U4.AF27:U9.E9:900:1400

8

66 MHz

AGP_REQ_L

490

U4.AF29:U9.C4:900:1400

8

66 MHz::900:1400

AGP_PAR

490

8

66 MHz

AGP_STOP_L

490

U4.T27:U9.E13:900:1400

8

66 MHz

AGP_DEVSEL_L

490

U4.T29:U9.B7:900:1400

8

66 MHz

AGP_TRDY_L

490

U4.T28:U9.C14:900:1400

8

66 MHz

AGP_IRDY_L

490

U4.T30:U9.A14:850:1400

8

66 MHz

AGP_FRAME_L

490

U4.U27:U9.B15:900:1400

8

66 MHz::950:1450

AGP_SBA<7..0>

100

6

66 MHz

AGP_AD_STB_L<1>

8 MIL SPACING

90

U4.Y29:U9.E12:1350:1600

500

8

66 MHz

AGP_AD_STB<1>

8 MIL SPACING

90

U4.W29:U9.F12:1350:1600

500

8

::900:1600 66 MHz

AGP_CBE<3..2>

100

6

::650:1350 66 MHz

AGP_AD<31..16>

100

6

66 MHz

AGP_AD_STB_L<0>

8 MIL SPACING

90

U4.M28:U9.F15:1350:1600

500

8

66 MHz

AGP_AD_STB<0>

8 MIL SPACING

90

U4.N29:U9.F16:1350:1600

500

8

::900:1600 66 MHz

AGP_CBE<1..0>

100

6

::650:1350 66 MHz

AGP_AD<15..0>

100

6

::4000:11000

33 MHz

MIN_DAISY_CHAIN

PCI_FRAME_L

::4000:11000

33 MHz

MIN_DAISY_CHAIN

PCI_IRDY_L

::4000:11000

PCI_CBE<3..0>

33 MHz

MIN_DAISY_CHAIN

::4000:11000

PCI_AD<31..0>

33 MHz

MIN_DAISY_CHAIN

::4000:11000

33 MHz

MIN_DAISY_CHAIN

PCI_DEVSEL_L

::4000:11000

33 MHz

MIN_DAISY_CHAIN

PCI_STOP_L

::4000:11000

33 MHz

MIN_DAISY_CHAIN

PCI_PAR

:::300 33 MHz

MIN_DAISY_CHAIN

PCI_PAR64

200

CPU_BG_L

::560:3080

8

RAS_CS3_L

:::500

33 MHz

CLK33M_CBUS_UF

:::200

200

33 MHz:::200

CLK33M_NEC_UF

200

::1000:1500

10 MIL SPACING

33 MHz

4

CLK33M_NEC

200

500

ENET_GBE_REFCLK

::5500:6000

200

4

500

125 MHz

ENET_PHY_GBE_REFCLK

:::300

125 MHz

::5000:5500

ENET_PHY_GTX_CLK

4

200

500

125 MHz

:::200

ENET_GTX_CLK

125 MHz

CLKENET_PHY_RX

:::200

125 MHz

CLK_ENET_LINK_RX

::5500:6000

4

200

500

125 MHz

:::400

CLKENET_PHY_TX

25 MHz

::5500:5800

CLK_ENET_LINK_TX

4

200

500

25 MHz

::300:636

CLK14M_IMI_XIN
CLK14M_IMI_XOUT

::300:636

200

4

SND_CLKOUT

500

CLK18M_KL_PLL

200

4

CLK27M_ATI_UF

200

:::200

:::200

200

CLK18M_KL_UF

200

:::200

CLK27M_ATIMEM_SS

CLK_PHY_FW

:::200 49.152 MHz

200

4

CLK_UNIN_FW

::5300:6500

500

49.152 MHz

::1288:1512

NO_TEST=TRUE

200 MHz10 MIL SPACING

200

L3_ECHO_CLK<2..3>

250

4

::1288:1512

NO_TEST=TRUE

200 MHz10 MIL SPACING

200

L3_CLK<1>

250

4

::1008:1232

NO_TEST=TRUE

200 MHz10 MIL SPACING

200

L3_ECHO_CLK<0..1>

250

4

::1008:1232

NO_TEST=TRUE

10 MIL SPACING

200

L3_CLK<0>

250

200 MHz

4

SYSCLK_CPU_UF

133 MHz

:::150

133 MHz

SYSCLK_UNIN_RDCLK_UF

:::150

:::150

SYSCLK_UNIN_UF

133 MHz

::3000:4750

SYSCLK_DIMM1_B

10 MIL SPACING

3

200

133 MHz

250

133 MHz

200

SYSCLK_UNIN

10 MIL SPACING

3

::1500:1750

250

200

3

133 MHz

SYSCLK_UNIN_RDCLK

10 MIL SPACING

::5600:5880

250

::3000:4750

133 MHz

200

3

10 MIL SPACING

SYSCLK_DIMM0_B

250

CLK27M_ATI

4

200

500

23C2< 23B2<

23C1<>

7D8<>

18C7<>

7D3<>

18B7<>

7D2<>

17D7<>

7C8<>

17C8<>

7C3<>

14D8<>

17C7<>

7C2<>

14C8<>

17B7<>

7B8<>

7C4<

14B8<>

16D8<>

9D2<

7B3<>

7B4<

14A8<>

9D2<

9D2<

18B7<>

16C8<>

9D2<

9D2<

18B7<>

7B2<>

7C3<>

7C5<

6D3<>

13C7<>

8B5<

19D7<>

18B7<>

18B7<>

17B7<>

16B8<>

18B7<>

18B7<>

18B7<>

17B7<>

13B3<

7A8<>

7C2<>

7B5<

6C2<

13B3<

6D2<

13A7<

13C3<

12A3<

6C3<>

13B7<>

8C2<

8C2<

8D2<

19B7<

8C7<

8D2<

8D2<

8D2<

8D2<

8D2<

19C5>

8C2<

8C2<

19C7<>

8C2<

8C2<

19C7<>

17B7<>

17B7<>

16B8<>

9D4<>

17B7<>

17B7<>

17B7<>

6C2<

13A7>

16B8<>

23C3<

6D2<

23B3<

23B3<

23B3<

23B3<

23C3<

23B3<

23C3<

23C3<

7B4<

7B5<

7B5<

7B4<

7C5<

7D5<

7B4<

7C4<

7B5<

7B4<

7B5<

7C4<

7D5<

7D4<

7B4<

7C4<

7C5<

7D4<

7D5<

7D4<

7D5<

7D4<

7D5<

7D4<

7D4<

7D5<

7D4<

7D5<

7C4<

7C4<

7C5<

7C4<

7C5<

7A3<>

7B3<>

7D6>

7C5<

7B5<

7C4<

7C5<

13B3<

13A7>

13A7<>

13C3<

13A7>

13A7<>

6D2<

13A7<>

13C7>

13A7>

6C2<

6C2<

14A8<>

6B3<>

6C7<>

7B4<

7B4<

7B5<

7B5<

19C5<>

19C5<>

8B7<

8B2<

8B2<

19B7>

19B7<>

19B7<>

19B7<>

19B7<>

19B7<>

19C5<>

19D5<>

19D5<>

19B7<>

8C5<>

19D5<>

19D5<>

19B7<>

8D5<>

16B8<>

16B8<>

9C5>

9C4<>

16B8<>

16B8<>

16B8<>

9B7<

13C7>

7C5<

23B3<

28A7<

28B6<

28B7<

28C7<

25B4<

20B7<

29B7<

14B3<

15C3<

14B3<

15C6<

23C3<

23C3<

23C3<

23C3<

6B7>

9C5<>

13C3<

6A3>

16A8<

23B5<

9C5<

19B7<

23B5<

8C7<

23B5<

9C5<

23B5<

23B5<

18A7<

7C3<>

23B5<

23B5<

7C3<>

23B5<

23B5<

7B7<>

7C2<>

7B6>

7B6>

7C2<>

7B6>

7C6>

7C2<>

7C3<>

7C6>

7C3<>

7C6>

7B2<>

7C6>

7C2<>

7B2<>

7B2<>

7C6>

7B2<>

7C6>

7C2<>

7C6>

7B3<>

7C6>

7B3<>

7C3<>

7C6>

7C3<>

7C6>

7B3<>

7C3<>

7C6>

7B3<>

7C6>

7A2<>

7B2<>

7C6>

7C6>

7C6>

7C3<>

7C6>

6A7>

6B7<>

6B7<>

6A3>

6B7<>

6B7<>

6A3>

6B7>

6C7<>

6B7>

6B7>

6A3>

6A3<>

6A3<>

6B7<>

7C2<>

7C2<>

7B6>

7B6>

8B5<>

8B5<>

19C5>

8C7>

19B7<>

8C7<>

8C7<>

8C7<>

8C7<>

8C7<>

8C7<>

19C5>

8B5<>

8B5<>

8B7<>

8B5<>

8B5<>

8B5<>

8B7<>

8C5<>

9C5<>

9C5<>

9B5>

9B4<>

9C5<>

9C5<>

9C5<>

9B5<

6D7>

7C6>

23B5<

23B5<

17B7<

10B6>

28A6<>

10B7<

10B6<>

28B6<>

10C6<

28C6<>

10C6<

23B6<>

23B6<>

16A1<

16B4<

20A8<

16A4<

20A7<>

29B6<>

10B2<

15B1<>

14C3>

15B4<>

14C3>

23B5<

23B5<

23B5<

7B2<>

6D7<

7B6>

7B2<>

20B6<

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

41 46

E

051-6403

RATS_SCHEDULE

GROUP

NO_TEST

PULSE_PARAMSTUB_LENGTH

MAX_VIAS

MAX_EXPOSED_LENGTH

DELAY_RULE

Digital Signals (cont’d)

SIG_NAME

SIGNAL CONSTRAINTS - PAGE 2

L3 CACHE

SDRAM

EXT ATI

CR-41

MIN_DAISY_CHAIN

::280:3360

ATI_VMEM_ADDR<0..13>

::1400:1680

TRUE

L3_ADDR<0..17>

KL_PCI_GNT_L

TRUE

U45.C7:J23.14:3300:4900

1500

MPIC_DATA_L

TRUE

MPIC_CLK

TRUE

ATI_VMEM_QS<0..7>

::400:1000

ATI_VMEM_DQMB<0..7>

::400:1000

ATI_VMEM_DATA<0..63>

::400:1000

MIN_DAISY_CHAIN

::280:3360

ATI_VMEM_CKEB

MIN_DAISY_CHAIN

::280:3360

ATI_VMEM_CSB_L

MIN_DAISY_CHAIN

::280:3360

ATI_VMEM_RASB_L

MIN_DAISY_CHAIN

::280:3360

ATI_VMEM_CASB_L

MIN_DAISY_CHAIN

::280:3360

ATI_VMEM_WE_L

TRUE

L3_DATA<32..63>

::840:1600

TRUE

L3_DATA<0..31>

::560:1320

::1400:1680

TRUE

L3_CNTL<0..1>

U45.B6:J23.47:3293:4900

1500

U45.T18:J23.44:3032:4900

1500

U45.T17:J23.46:2688:4900

1500

U45.U20:J23.16:3300:4900

1500

::3300:5112

1500

::3300:4900

1500

::3300:4900

1500

::3400:3700

::3565:4900

6

::1800:2000
::200:300
::5100:6600

::1700:2223

:::350

:::600

6

::4600:5700

::4097:5000

:::500

6

::4700:5300

6

::5100:5500

:::500

6

::4700:5300

6

::4000:4775

4 MIL SPACING

R168.2:J24.7:1000:2200

4 MIL SPACING

R624.2:J24.8:300:500

4 MIL SPACING

::300:500

4 MIL SPACING

::300:500

4 MIL SPACING

R169.2:J24.12:1000:2032

4 MIL SPACING

R611.2:J24.9:1000:2105

4 MIL SPACING

::300:500

4 MIL SPACING

::300:500

4 MIL SPACING

R632.2:J24.25:300:500

4 MIL SPACING

::300:500

4 MIL SPACING

::300:503

4 MIL SPACING

::300:500

200

6

1500

4 MIL SPACING

U45.D10:R611.1:300:506

200

6

1500

4 MIL SPACING

::300:500

200

6

1500

4 MIL SPACING

::1000:2096

200

6

1500

4 MIL SPACING

::1000:2602

200

6

1500

4 MIL SPACING

::1000:1800

200

6

1500

4 MIL SPACING

::1000:2012

200

6

1500

4 MIL SPACING

::1000:1936

200

6

1500

4 MIL SPACING

::1000:2259

200

6

1500

4 MIL SPACING

::1000:2149

200

6

1500

4 MIL SPACING

::1000:1800

200

6

1500

4 MIL SPACING

TRUE

::1000:1800

200

6

1500

4 MIL SPACING

TRUE

::1000:1800

200

6

1500

4 MIL SPACING

::1000:1800

200

6

1500

4 MIL SPACING

U45.C10:RP36.4:1000:1800

6

200

1500

4 MIL SPACING

TRUE::974:1800

200

6

1500

4 MIL SPACING

::1000:1800

200

6

1500

::5200:6800

1500

::5200:6800

1500

::5200:6800

1500

::5200:6800

1500

::5200:6800

1500

::5200:6800

1500

::5200:6800

1500

::5200:6800

1500

::5200:6800

1500

::5200:6800

1500

::5200:6800

1500

U45.A6:J23.13:3300:4900

1500

22C8< 22C4<

22C7<>

22B8<

22C3<>

22B4<

15D6<

22C8<

22B7<>

22B7<>

15D3<

22C8<>

22C4<

22B3<>

15D1<>

15D4<>

22B3<>

15C6<

22C4<>

22B8<

19C3<>

22B8<

22B8<

22B8<

22B8<

22B8<

15C1<>

15C4<>

15C6<

19D3>

15C3<

16B8<

16B4<

16B4>

19B5<>

22B4<

19B3<>

22B4<

22B4<

22B4<

22B4<

22B4<

14B6<>

14C6<>

15C3<

19C3>

14D6>

9C5>

10C2<>

10C2<>

19A5<>

19A3>

19A3<>

19A5>

19A5>

19A5>

19A5>

19A5>

14A6<>

14B6<>

14C3>

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

42 46

E

051-6403

DELAY_RULE used as these could not
be routed as true differential pairs.

DELAY_RULE used as these could not
be routed as true differential pairs.

PULSE_PARAM

TMDS

LVDS

USB

USB 2.0

ATI DDR
MEM CLKS

SIGNAL CONSTRAINTS - PAGE 3

NET_SPACING_TYPE

NO_TEST

PULSE_PARAMSTUB_LENGTH

MAX_VIAS

MAX_EXPOSED_LENGTH

DELAY_RULE

Digital Signals (cont’d)

GROUP

SIG_NAME

CARDSLOT

EIDE / DVD

ETHERNET MII

ULTRA ATA/66

EIDE / KEYLARGO

EIDE / CARDSLOT

MAX_VIAS

MAX_EXPOSED_LENGTH

MATCHED_DELAY

MIN_LINE_WIDTH

Differential Signals

GROUP

SIG_NAME

DIFFERENTIAL_PAIR

FIREWIRE

ETHERNET

FIREWIRE MII

CR-42

::5100:6000

ENET_MDIO

6

::4500:5700

6

ENET_PHY_TXD<7..0>

ENET_TX_EN

:::500

6

ENET_PHY_TX_EN

::4700:5300

ENET_TX_ER

:::500
::4680:5300

6

ENET_PHY_TX_ER

ENET_TX_D<7..0>

:::600

TRUE

::4700:5300

ENET_RX_ER

TRUE

ENET_RX_DV

::4700:5300

::2400:4400

FW_LINK_CNTL<1..0>

::2400:4400

FW_PHY_CNTL<1..0>

:::500

FW_LINK_LREQ

::4800:7300

FW_PHY_LREQ

::2300:4300

FW_PHY_DATA<7..0>

183 MHZ

ATI_VMEM_CLKB<0>

ATI_VMEM_CLKB0

ATI_VMEM_CLKB0:::100

250

DELAY_RULE=::700:1008

FW_TPO1:::4%

FW_TPO1N

FW_TPO1

FW_TPO1:::4%

FW_TPO1P

FW_TPO1

FW_TPI1:::4%

FW_TPI1P

FW_TPI1

FW_TPI1:::4%

FW_TPI1N

FW_TPI1

ENET_TRD3:U8.K8:T1.3:100

ENET_TRD3

MDI_P<3>

5

DELAY_RULE=T1.19:J2.4:206:206.5

RJ45_DP<2>

5

ENET_TRD3:U8.K7:T1.2:100

ENET_TRD3

MDI_M<3>

5

RJ45_DP3:T1.22:J2.7:100

RJ45_DP3

RJ45_DP<3>

5

RJ45_DP3:T1.23:J2.8:100

RJ45_DP3

RJ45_DN<3>

5

DELAY_RULE=T1.20:J2.5:337:338

RJ45_DN<2>

5

ENET_TRD2:U8.K6:T1.5:100

ENET_TRD2

MDI_M<2>

5

ENET_TRD2:U8.K5:T1.6:100

ENET_TRD2

MDI_P<2>

5

ENET_TRD0:U8.K1:T1.12:100

ENET_TRD0

MDI_P<0>

5

ENET_TRD0:U8.K2:T1.11:100

ENET_TRD0

MDI_M<0>

5

RJ45_DP0:T1.14:J2.2:100

RJ45_DP0

RJ45_DN<0>

5

DELAY_RULE=T1.17:J2.6:213:213.5

RJ45_DN<1>

5

ENET_TRD1:U8.K3:T1.8:100

ENET_TRD1

MDI_M<1>

5

RJ45_DP0:T1.13:J2.1:100

RJ45_DP0

RJ45_DP<0>

5

ENET_TRD1:U8.K4:T1.9:100

ENET_TRD1

MDI_P<1>

5

FW_TPB0:::4%

FW_TPB0P

FW_TPB0

500

FW_TPB0:::4%

FW_TPB0N

FW_TPB0

500

FW_TPA0:::4%

FW_TPA0P

FW_TPA0

500

U53.C6:J25.47:1800:5500

CSLOT_RESET

33 MHZ

U53.M13:J25.44:1800:5500

CSLOT_REG_L

33 MHZ

U53.P16:J25.46:1800:5500

CSLOT_IOWAIT_L

33 MHZ

U53.N15:J25.16:1800:5500

CSLOT_IRQ_L

33 MHZ

::1800:5500

CSLOT_ADDR<12..3>

33 MHZ

::1800:5500

CSLOT_CE1_L

33 MHZ

::1800:5500

CSLOT_CE2_L

33 MHZ

:::400

ENET_PHY_RXD<7..0>

::4097:5000

ENET_RXD<7..0>

R118.2:J27.7:1000:2200

HD_INTRQ

66 MHZ

R600.2:J27.8:300:500

HD_DMACK_L

66 MHZ

HD_CS1_L

66 MHZ

::300:600
::300:500

HD_CS3_L

66 MHZ

R117.2:J27.12:1000:2032

HD_DMARQ

66 MHZ

R119.2:J27.9:1000:2105

HD_IOCHRDY

66 MHZ

::300:500

HD_DIOR_L

66 MHZ

::300:500

HD_DIOW_L

66 MHZ

R594.2:J27.25:300:500

HD_RESET_L

66 MHZ

HD_ADDR<2..0>

66 MHZ

::300:600

HD_DATA<15..0>

66 MHZ

::300:600

:::500

UIDE_INTRQ

200

6

66 MHZ

U53.D8:R119.1:300:506

200

6

UIDE_IOCHRDY

66 MHZ

:::500

200

6

UIDE_DMARQ

66 MHZ

::1000:2096

200

UIDE_DIOR_L

6

66 MHZ

::950:2500

200

UIDE_ADDR<2..0>

6

66 MHZ

::1000:2300

200

UIDE_RST_L

6

66 MHZ

::1000:2012

200

UIDE_DIOW_L

6

66 MHZ

::1000:1936

200

UIDE_DMACK_L

6

66 MHZ

::1000:2259

200

UIDE_CS3FX_L

6

66 MHZ

::750:2000

200

UIDE_CS1FX_L

6

66 MHZ

::1000:2500

200

6

UIDE_DATA<12>

66 MHZ

::1000:2500

200

UIDE_DATA<15..13>

6

66 MHZ

::1000:2500

200

6

UIDE_DATA<11..9>

66 MHZ

::1000:2500

UIDE_DATA<8>

200

6

66 MHZ

U53.E8:RP51.4:1000:2500

6

UIDE_DATA<7>

200

66 MHZ

::1000:2500

200

6

UIDE_DATA<6..1>

66 MHZ

::1000:2500

200

6

UIDE_DATA<0>

66 MHZ

::2700:4400

33 MHZ

EIDE_CS3FX_L_OPU

::2700:4400

33 MHZ

EIDE_CS1FX_L_OPU

::2700:5200

EIDE0_READ_L

33 MHZ

::2700:4400

EIDE_DB_<15..0>

33 MHZ

::2700:4400

EIDE_IO_CHRDY

33 MHZ

::2700:4400

33 MHZ

EIDE0_RST_L_OPU

::2700:4400

EIDE_ADDR_<2..0>

33 MHZ

::2700:5200

33 MHZ

EIDE0_WR_L_OPU

::2700:4400

EIDE0_INTR

33 MHZ

::2700:4400

EIDE0_DMA_ACK_L

33 MHZ

::2700:4400

EIDE0_DMA_RQ

33 MHZ

:::700

EIDE_CS3FX_L

33 MHZ

::1800:5500

CSLOT_IORD_L

33 MHZ

::1800:5500

CSLOT_CS3FX_L

33 MHZ

U53.B6:J25.14:1800:5500

CSLOT_ADDR<14>

33 MHZ

::1800:5500

CSLOT_CS1FX_L

33 MHZ

::1800:5500

CSLOT_DATA<15..0>

33 MHZ

:::500

EIDE0_INT

33 MHZ

:::700

KL_CSLOT_IOWR_L

33 MHZ

:::700

KL_CSLOT_IORD_L

33 MHZ

:::500

EIDE0_DMARQ

33 MHZ

:::500

EIDE0_DMACK_L

33 MHZ

:::700

EIDE0_RST_L

33 MHZ

:::700

EIDE_IOCHRDY

33 MHZ

:::700

EIDE0_RD_L

33 MHZ

:::800

EIDE_CS1FX_L

33 MHZ

:::800

EIDE_ADDR<2..0>

33 MHZ

:::700

EIDE0_WR_L

33 MHZ

::1800:5500

CSLOT_ADDR<2..0>

33 MHZ

U53.C2:J25.20:1800:5500

CSLOT_ADDR<15>

33 MHZ

U53.A6:J25.13:1800:5500

CSLOT_ADDR<13>

33 MHZ

::1800:5500

CSLOT_IOWR_L

33 MHZ

:::1100

EIDE_DATA<15..0>

33 MHZ

183 MHZ

ATI_VMEM_CLKB_L<1>

ATI_VMEM_CLKB1

ATI_VMEM_CLKB1:::100

250

DELAY_RULE=::700:1008

183 MHZ

ATI_VMEM_CLKB_L<0>

ATI_VMEM_CLKB0

ATI_VMEM_CLKB0:::100

250

DELAY_RULE=::700:1008

183 MHZ

ATI_VMEM_CLKB<1>

ATI_VMEM_CLKB1

ATI_VMEM_CLKB1:::100

250

DELAY_RULE=::700:1008

DELAY_RULE=U51.D16:R90.2::500

NEC_USB_DD

NEC_USB_DD:::150

NEC_USB_DDP

USB_D2_EMI:L3.2:J6.3:200

USB_D2P_EMI

USB_D2_EMI

DELAY_RULE=:::500

NEC_RSDCM

NEC_RSDC

NEC_RSDC:::150

NEC_RSDD

NEC_RSDD:::150

DELAY_RULE=:::500

NEC_RSDDP

DELAY_RULE=U51.D15:R89.2::500

NEC_USB_DD

NEC_USB_DD:::150

NEC_USB_DDM

DELAY_RULE=:::500

NEC_RSDCP

NEC_RSDC

NEC_RSDC:::150

DELAY_RULE=U51.G16:R79.2::500

NEC_USB_DCM

NEC_USB_DC

NEC_USB_DC:::150

DELAY_RULE=U51.F16:R78.2::500

NEC_USB_DCP

NEC_USB_DC

NEC_USB_DC:::150
NEC_RSDD:::150

DELAY_RULE=:::500

NEC_RSDDM

NEC_RSDD

USB_DD:::200

USB_DD

USB_DDP

USB_DCP

USB_DC

USB_DC:::200

USB_DCM

USB_DC

USB_DC:::200

USB_DAM

USB_DA

USB_DA:::200

BT_USB_D

BT_USB:::200

BT_USB_DP

BT_USB_DM

BT_USB_D

BT_USB:::200

USB_DD:::200

USB_DD

USB_DDM

MODEM_USB:::200

MODEM_USB_D

MODEM_USB_DM

MODEM_USB:::200

MODEM_USB_D

MODEM_USB_DP

USB_D1:R177.2:L2.1:200

USB_D1

USB_D1M

USB_D1:R178.2:L1.1:200

USB_D1

USB_D1P

USB_D1_EMI:L2.2:J5.2:200

USB_D1_EMI

USB_D1M_EMI

USB_D1_EMI:L1.2:J5.3:200

USB_D1_EMI

USB_D1P_EMI

USB_D2:R173.2:L4.1:200

USB_D2

USB_D2M

USB_D2:R174.2:L3.1:200

USB_D2

USB_D2P

USB_D2_EMI:L4.2:J6.2:200

USB_D2_EMI

USB_D2M_EMI

USB_DBM

USB_DB

USB_DB:::200

USB_DBP

USB_DB

USB_DB:::200

USB_DAP

USB_DA

USB_DA:::200

LVDS:::110

LVDS_L0

LVDS_L0P

LVDS:::110

LVDS_L0

LVDS_L0N

LVDS:::110

LVDS_L2

LVDS_L2N

LVDS:::110

LVDS_L2

LVDS_L2P

LVDS:::110

LVDS_L1

LVDS_L1P

LVDS:::110

LVDS_L1

LVDS_L1N

LVDS:::110

4

CLKLVDS

CLKLVDS_N

500

LVDS:::110

4

500

CLKLVDS

CLKLVDS_P

CLKTMDS:::100

4

500

CLKTMDS

TMDS_CLKP

CLKTMDS:::100

4

500

CLKTMDS

TMDS_CLKN

TMDS_D1:::100

TMDS_DN<1>

TMDS_D1

TMDS_D1:::100

TMDS_DP<1>

TMDS_D1

TMDS_D2:::100

TMDS_DP<2>

TMDS_D2

TMDS_D2:::100

TMDS_DN<2>

TMDS_D2

TMDS_D0:::100

TMDS_DN<0>

TMDS_D0

TMDS_D0:::100

TMDS_DP<0>

TMDS_D0

FW_TPA0:::4%

FW_TPA0N

FW_TPA0

500

::2500:4500

FW_LINK_DATA<7..0>

6

TRUE

ENET_MDC

::4000:4775

6

ENET_COL

TRUE

ENET_CRS

TRUE

DELAY_RULE=T1.16:J2.3:414.5:415

RJ45_DP<1>

5

32C8< 32C7<

32D8<

32B8<

32D7<

32C8<

28C6<

32B6<>

32D6<>

32C7<

31D7<

31D6<

31D6<

31D7<

31D7<

31D6<

28B6<

22B8<

32C6<>

32D3<

32D3<

32B5<>

32B7<

32C8<

32D5<>

32C8<

32C8<

32B7<

22B4<

22B8<

22B4<

16D1<

16D1<

20D3<

20D4<

20D7<

20D6<

20D6<

20D7<

20D7<

20D6<

29B7<

28A5<>

10C7<

28C6<

28C6<

10B6<

10C6<

29B7<

29B7<

22A8<

29B2<>

29B2<>

29B2<>

29B2<>

32C5<>

32C5<>

16B2<

32C6<>

16C6>

32C6<>

32C5<>

28B7<

16A5<

32C3<

32D3<

32C3<

16A5<

16A5<

32C3<

32C3<

32C3<

32C2<>

32D2<>

32C4<

32D4<

32C4<

32C4<

32C4<

32C4<

32D4<

32D4<

32D4<

32D4<

32D4<

32D4<

32D4<

32D4<

32B7<

32B7<

32A7<

32A6<>

32A7<

32A7<

32A6<>

32A7<

32A7<

32B7<

32B7<

32B8<

16B1<

32C7<

32C6<>

32C7<

32C6<>

32A8<

32B8<

32B8<

32A8<

32A8<

32A8<

32B8<

32B8<

32A8<

32C7<

32C6<>

32C6<>

16B1<

16D6<>

22A4<

22A8<

22A4<

30A8<

30A8<

30C8<

30B8<

30B8<

30B8<

30B8<

16C1<

16C1<

16B1<

16B1<

30B8<

31B5<>

31B5<>

31B5<>

31B5<>

31B5<>

31B5<>

31B5<>

31B5<>

31D6<>

31D6<>

31D4<>

31D4<>

31D4<>

31D4<>

31D5<>

31D5<>

10C2<>

28A4<

10B6<

10B6<

10B6<>

10B7<

10C6<>

10C7<

10C6<>

10C7<

10C6<>

28B6>

28B6>

10B2<>

29B6<>

10B2>

29B6<

29B6<>

19A5<>

29A3<>

29A3<>

29A3<>

29A3<>

28B5<>

28C2<>

28B5<>

28B2<>

28B2<>

28B2<>

28C5<>

28C5<>

28C5<>

28C5<>

28C2<>

28C2<>

28C5<>

28C2<>

28C5<>

29B4<>

29B4<>

29B4<>

16C4<>

16B4<>

32C5<>

16B4<>

16B2>

16B6>

16B6>

28B6<>

10B6<

32C2<>

32C2<>

32C2<>

32C1<>

32D2<>

32C2<>

32C2<>

32C2<>

32D2<>

32C1<>

32D1<>

16A6<

16A6<

16A6<

16A6>

16A6>

16A6>

16A6>

16A6>

16A6>

16A6>

16A6<>

16A6<>

16A6<>

16A6<>

16B6<>

16B6<>

16B6<>

32A6<>

32A5<>

32A6<>

32A5<>

32A5<>

32B5<>

32A5<>

32A5<>

32A5<>

32A6<>

32A6<>

16C6>

32C5<>

32C6<>

16C4<>

32C6<>

32C5<>

16B6<

16B3<>

16B3<>

16B6<

16B6>

16C6>

16C6<

16B6>

16C6>

16C6>

16B6>

32C6<>

16B4<>

16C4<>

32C5<>

16C6<>

19A5<>

19A5<>

19A5<>

17C3<>

30B5<>

17C5<>

17C5<>

17C3<>

17C5<>

17C3<>

17C3<>

17C5<>

16B3<>

16B2<>

16B2<>

16C2<>

30C2<>

30C2<>

16B3<>

32A3<>

32B3<>

30B7<>

30B7<>

30B5<>

30B5<>

30B7<>

30B7<>

30B5<>

16C3<>

16C3<>

16C2<>

20B5>

20B5>

20B5>

20B5>

20B5>

20B5>

20B5>

20B5>

20B6>

20B6>

20B6>

20B6>

20B6>

20B6>

20B6>

20B6>

29B4<>

10B2<>

10B6>

28B6>

28B6>

28C2<>

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

43 46

E

051-6403

CARDBUS

SIGNAL CONSTRAINTS - PAGE 4

MAIN/SLEEP

SIG_NAME

GROUP

VOLTAGE

POWER NET CONSTRAINTS

MIN_LINE_WIDTH MIN_NECK_WIDTH

ADAPTER/
BATTERY

POWER

SUPPLIES

BACKUP

MISC

FW

AUDIO

ETHERNET

IMI C5005

MOBILITY

KEY LARGO

RADEON

CPU

UNIN

GROUP

SIG_NAME

VOLTAGE MIN_LINE_WIDTH MIN_NECK_WIDTH

MIN_NECK_WIDTHMIN_LINE_WIDTHVOLTAGE

SIG_NAME

GROUP

NEC

L3 CACHE

CHGND1

CHGND5

CHGND2

CHGND3

CHGND4A

CHGND4B

CHGND6

CHGND7

CR-43

VOLTAGE=2.5V

MIN_NECK_WIDTH=10

L3_VDD_SLEEP

MIN_LINE_WIDTH=20

MIN_NECK_WIDTH=10

+LT1962_SLEEP

VOLTAGE=1.8V

MIN_LINE_WIDTH=25

+3V_PCI_64B_PU

MIN_LINE_WIDTH=10

VOLTAGE=3.3V

MIN_NECK_WIDTH=10

VOLTAGE=1.8V

MIN_LINE_WIDTH=25

+1_8V_UNIN_AGPPLL_MAIN

MIN_NECK_WIDTH=10

MIN_NECK_WIDTH=10

CPU_VCORE_SLEEP

VOLTAGE=1.4V

MIN_LINE_WIDTH=25

MIN_NECK_WIDTH=10

CPU_AVDD

MIN_LINE_WIDTH=25

VOLTAGE=1.4V

MIN_NECK_WIDTH=10

+ENET_CTAP

VOLTAGE=1.8V

MIN_LINE_WIDTH=25

VOLTAGE=1.2V

ENET_PLLVDD

MIN_LINE_WIDTH=10

MIN_NECK_WIDTH=12

+FW_VP_UF

MIN_LINE_WIDTH=100

VOLTAGE=33V

VOLTAGE=16.8V

MIN_LINE_WIDTH=100

+PBUS_FW_SW

MIN_NECK_WIDTH=12

MIN_NECK_WIDTH=12

FW_VP

MIN_LINE_WIDTH=100

VOLTAGE=33V
VOLTAGE=3.3V

MIN_LINE_WIDTH=25

+3V_FW_VDD

MIN_NECK_WIDTH=10

MIN_NECK_WIDTH=12

+FW_VP_FUSE

MIN_LINE_WIDTH=100

VOLTAGE=33V

VOLTAGE=0V

MIN_LINE_WIDTH=100

FW_VGND

MIN_NECK_WIDTH=12

VOLTAGE=1.2V

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

ENET_AVDD

MIN_LINE_WIDTH=25

ENET_DVDDL

MIN_NECK_WIDTH=10

VOLTAGE=1.2V

MIN_NECK_WIDTH=10

VOLTAGE=5V

MIN_LINE_WIDTH=25

+AUD4V

VOLTAGE=3.3V

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

MIN_NECK_WIDTH=12

MIN_LINE_WIDTH=100

VOLTAGE=33V

VOLTAGE=16.8V

MIN_LINE_WIDTH=100

MIN_NECK_WIDTH=12

MIN_LINE_WIDTH=10

VOLTAGE=3.3V

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=1.5V

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=1.8V

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=2.5V

VOLTAGE=1.8V

MIN_LINE_WIDTH=15 MIN_NECK_WIDTH=10

VOLTAGE=3.3V

MIN_LINE_WIDTH=15 MIN_NECK_WIDTH=10

VOLTAGE=3.3V

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

VOLTAGE=3.3V

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=3.3V

MIN_NECK_WIDTH=12

MIN_LINE_WIDTH=100

VOLTAGE=33V
VOLTAGE=3.3V

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

MIN_NECK_WIDTH=12

MIN_LINE_WIDTH=100

VOLTAGE=33V

VOLTAGE=0V

MIN_LINE_WIDTH=100

MIN_NECK_WIDTH=12

MIN_NECK_WIDTH=10

VOLTAGE=0V

MIN_LINE_WIDTH=25

MIN_NECK_WIDTH=10

VOLTAGE=0V

MIN_LINE_WIDTH=25

MIN_NECK_WIDTH=10

VOLTAGE=0V

MIN_LINE_WIDTH=25

MIN_LINE_WIDTH=25

VOLTAGE=0V

MIN_NECK_WIDTH=10

MIN_LINE_WIDTH=25

VOLTAGE=0V

MIN_NECK_WIDTH=10

MIN_LINE_WIDTH=25

VOLTAGE=0V

MIN_NECK_WIDTH=10

MIN_LINE_WIDTH=25

VOLTAGE=0V

MIN_NECK_WIDTH=10
MIN_NECK_WIDTH=10

VOLTAGE=0V

MIN_LINE_WIDTH=25

VOLTAGE=1.8V

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=10

VOLTAGE=1.8V

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=10

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=15

VOLTAGE=1.8V

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=10

VOLTAGE=1.8V
VOLTAGE=1.8V

MIN_LINE_WIDTH=10 MIN_NECK_WIDTH=10

VOLTAGE=1.25V

MIN_LINE_WIDTH=10

VOLTAGE=1.8V

MIN_LINE_WIDTH=10 MIN_NECK_WIDTH=10

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

VOLTAGE=1.5V

MIN_LINE_WIDTH=25

VOLTAGE=5V

MIN_NECK_WIDTH=10

MIN_NECK_WIDTH=10

VOLTAGE=3.3V

MIN_LINE_WIDTH=25
MIN_LINE_WIDTH=25

VOLTAGE=3.3V

MIN_NECK_WIDTH=10
MIN_NECK_WIDTH=10

VOLTAGE=3.3V

MIN_LINE_WIDTH=25
MIN_LINE_WIDTH=25

VOLTAGE=3.3V

MIN_NECK_WIDTH=10

MIN_NECK_WIDTH=10

VOLTAGE=5V

MIN_LINE_WIDTH=25

MIN_LINE_WIDTH=25

VOLTAGE=3.3V

MIN_NECK_WIDTH=10

MIN_LINE_WIDTH=25

VOLTAGE=0V

MIN_NECK_WIDTH=10

MIN_NECK_WIDTH=10

+1_5V_L3_VDDQ_SLEEP

VOLTAGE=1.5V

MIN_LINE_WIDTH=25

MIN_NECK_WIDTH=10

NEC_AVSS

VOLTAGE=0V

MIN_LINE_WIDTH=15

VOLTAGE=3.3V

MIN_NECK_WIDTH=10

NEC_AVDD

MIN_LINE_WIDTH=15

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=3.3V

+3V_NEC_VDD

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=3.3V

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=3.3V

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=10

VOLTAGE=3.3V

VOLTAGE=2.5V

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

VOLTAGE=1.8V

MIN_LINE_WIDTH=10 MIN_NECK_WIDTH=10

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=2.5V

MIN_LINE_WIDTH=10

VOLTAGE=2.5V

VOLTAGE=3.3V

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=3.3V

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=3.3V

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=3.3V

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=5V

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=0V

VOLTAGE=3.3V

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

VOLTAGE=5V

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

VOLTAGE=1.5V

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

VOLTAGE=1.2V

+1_2V_ATI_VDDC

+3V_KL_AVDD1

VOLTAGE=3.3V

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

MIN_NECK_WIDTH=10

+3V_KL_USB

MIN_LINE_WIDTH=25

VOLTAGE=3.3V

MIN_NECK_WIDTH=10

+3V_KL_OSC_SLEEP

MIN_LINE_WIDTH=25

VOLTAGE=3.3V

+3V_KL_AVDD4

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=3.3V

+3V_KL_AVDD3

VOLTAGE=3.3V

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

+2_5V_ATI_A2VDD

MIN_LINE_WIDTH=10

VOLTAGE=2.5V

MIN_NECK_WIDTH=10

+2_5V_ATI_VDDR

MIN_LINE_WIDTH=25

VOLTAGE=2.5V
VOLTAGE=1.8V

+1_8V_ATI_LVDDR

MIN_LINE_WIDTH=10 MIN_NECK_WIDTH=10

VOLTAGE=3.3V

MIN_LINE_WIDTH=10

+3V_ATI_SS

MIN_NECK_WIDTH=10

MIN_NECK_WIDTH=10

+3V_KL

MIN_LINE_WIDTH=25

VOLTAGE=3.3V

+3V_KL_AVDD2

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=3.3V

MIN_NECK_WIDTH=10

+3V_UNIN_MAXPLL_MAIN

MIN_LINE_WIDTH=25

VOLTAGE=3.3V
VOLTAGE=3.3V

MIN_LINE_WIDTH=25

+3V_UNIN_AGPPLL_MAIN

MIN_NECK_WIDTH=10
MIN_NECK_WIDTH=10

+1_8V_UNIN_MAXPLL_MAIN

MIN_LINE_WIDTH=25

VOLTAGE=1.8V

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

VOLTAGE=1.2V

+1_2V_ATI_VCORE

VOLTAGE=1.8V

MIN_LINE_WIDTH=10

+1_8V_ATI_A2VDDQ

MIN_NECK_WIDTH=10

VOLTAGE=1.25V

MIN_LINE_WIDTH=10

+1_25V_ATI_VREF

VOLTAGE=1.8V

MIN_LINE_WIDTH=10

+1_8V_ATI_PVDD

MIN_NECK_WIDTH=10

MIN_NECK_WIDTH=10

+1_8V_ATI_MPVDD

MIN_LINE_WIDTH=10

VOLTAGE=1.8V

MIN_NECK_WIDTH=10

+1_8V_ATI_AVDD

MIN_LINE_WIDTH=15

VOLTAGE=1.8V

VOLTAGE=1.8V

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=10

+1_8V_ATI_AVDDDI

VOLTAGE=1.8V

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=10

+1_8V_ATI_A2VDDDI

MIN_NECK_WIDTH=10

+3V_ENET

MIN_LINE_WIDTH=25

VOLTAGE=3.3V

VOLTAGE=3.3V

MIN_LINE_WIDTH=25

+3V_IMI_SLEEP

MIN_NECK_WIDTH=10

VOLTAGE=3.3V

MIN_LINE_WIDTH=25

PLL_SDRAM_CPU1

MIN_NECK_WIDTH=10

VOLTAGE=3.3V

MIN_LINE_WIDTH=15

PLL_AVDD

MIN_NECK_WIDTH=10

VOLTAGE=1.8V

MIN_LINE_WIDTH=15

PLL_VCC_CPU0

MIN_NECK_WIDTH=10

+2_5V_ENET

MIN_LINE_WIDTH=25

VOLTAGE=2.5V

MIN_NECK_WIDTH=10
MIN_NECK_WIDTH=10

+1_8V_ENET

MIN_LINE_WIDTH=25

VOLTAGE=1.8V

ENET_AVDDL

VOLTAGE=1.2V

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

MIN_NECK_WIDTH=10

+ADAPTER_UF

MIN_LINE_WIDTH=50

VOLTAGE=24V

VCORE_GNDDIV

VOLTAGE=0V

MIN_LINE_WIDTH=8

VOLTAGE=0V

VCORE_GNDSNS

MIN_LINE_WIDTH=8

VOLTAGE=1.4V

VCORE_SNS

MIN_LINE_WIDTH=8

MIN_LINE_WIDTH=8

VCORE_VGATE

VOLTAGE=0V

VCORE_GND

MIN_LINE_WIDTH=30

MIN_LINE_WIDTH=8

VCORE_TIME

VOLTAGE=1.4V

MIN_LINE_WIDTH=8

VCORE_FB

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=16.8V

BATT_FET_SW

MIN_NECK_WIDTH=10

BATT_ISNS

MIN_LINE_WIDTH=25

VOLTAGE=16.8V

MIN_NECK_WIDTH=10

BATT_LINE

MIN_LINE_WIDTH=25

VOLTAGE=16.8V

MIN_NECK_WIDTH=10

BATT_POS_F

MIN_LINE_WIDTH=25

VOLTAGE=16.8V

1625_INTVCC

MIN_LINE_WIDTH=10

VOLTAGE=5.3V

MIN_NECK_WIDTH=10

BATT_POS

MIN_LINE_WIDTH=25

VOLTAGE=16.8V

MIN_NECK_WIDTH=10

BATT_RES

MIN_LINE_WIDTH=25

VOLTAGE=16.8V

3V_PMU_CHGR

MIN_LINE_WIDTH=10

VOLTAGE=3.3V

VOLTAGE=24V

MIN_LINE_WIDTH=50

+ADAPTER_SW

MIN_NECK_WIDTH=10
MIN_NECK_WIDTH=10

INPUT14_24V_SW

MIN_LINE_WIDTH=25

VOLTAGE=24V
VOLTAGE=24V

MIN_LINE_WIDTH=25

PWRBUS_14_24V

MIN_NECK_WIDTH=10

VOLTAGE=24V

1625_VIN

MIN_LINE_WIDTH=10

MIN_NECK_WIDTH=10

+ADAPTER

MIN_LINE_WIDTH=50

VOLTAGE=24V

VOLTAGE=16.8V

CHGR_OUT

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=10

VOLTAGE=16.8V

MIN_LINE_WIDTH=25

CHGR_VSW

MIN_NECK_WIDTH=10

+5_5V_RAW

VOLTAGE=5.5V

MIN_LINE_WIDTH=10

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

1625_SGND

VOLTAGE=0V

MIN_LINE_WIDTH=10

VOLTAGE=5V

PS_VL

MIN_NECK_WIDTH=10

/+PBUS

MIN_LINE_WIDTH=25

VOLTAGE=16.8V

MIN_NECK_WIDTH=10

/+5V_SLEEP

MIN_LINE_WIDTH=25

VOLTAGE=5V

VOLTAGE=5V

MIN_LINE_WIDTH=25

/+5V_MAIN

MIN_NECK_WIDTH=10

MIN_NECK_WIDTH=10

VOLTAGE=3.3V

MIN_LINE_WIDTH=25

/+3V_MAIN

MIN_NECK_WIDTH=10

VOLTAGE=3.3V

MIN_LINE_WIDTH=25

/+3V_SLEEP
/+3V_PMU

MIN_NECK_WIDTH=10

VOLTAGE=3.3V

MIN_LINE_WIDTH=25

MIN_NECK_WIDTH=6

/GND

MIN_LINE_WIDTH=25

VOLTAGE=0V

/CHGND1

VOLTAGE=0V

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=12

VOLTAGE=0V

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=12

/CHGND2

/CHGND3

MIN_NECK_WIDTH=12MIN_LINE_WIDTH=25

VOLTAGE=0V

/CHGND4A

MIN_NECK_WIDTH=12MIN_LINE_WIDTH=25

VOLTAGE=0V

/CHGND4B

MIN_NECK_WIDTH=12MIN_LINE_WIDTH=25

VOLTAGE=0V

VOLTAGE=0V

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=12

/CHGND5

/CHGND6

MIN_NECK_WIDTH=12MIN_LINE_WIDTH=25

VOLTAGE=0V

/CHGND7

MIN_NECK_WIDTH=12MIN_LINE_WIDTH=25

VOLTAGE=0V

VOLTAGE=5V

MIN_LINE_WIDTH=25

PS_LX_5V

MIN_NECK_WIDTH=10

MIN_NECK_WIDTH=10

2_5V_LX

VOLTAGE=2.5V

MIN_LINE_WIDTH=25
MIN_LINE_WIDTH=25

VOLTAGE=2.5V

2_5V_LX_F

MIN_NECK_WIDTH=10
MIN_NECK_WIDTH=10

1_8V_LX

VOLTAGE=1.8V

MIN_LINE_WIDTH=25

MIN_NECK_WIDTH=10

1_8V_LX_F

VOLTAGE=1.8V

MIN_LINE_WIDTH=25

MIN_NECK_WIDTH=10

PS_CS_3V

MIN_LINE_WIDTH=25

VOLTAGE=3.3V

MIN_NECK_WIDTH=10

PS_LX_3V

MIN_LINE_WIDTH=25

VOLTAGE=3.3V

VOLTAGE=5V

+5V_RSNS

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=10

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=20

VOLTAGE=5V

VCORE_VCC

VOLTAGE=1.4V

MIN_NECK_WIDTH=10

VCORE_LX

MIN_LINE_WIDTH=200

MIN_LINE_WIDTH=20

VCORE_DL

MIN_NECK_WIDTH=10

VOLTAGE=5V

MIN_LINE_WIDTH=15

VCORE_BOOST

MIN_NECK_WIDTH=10

MIN_LINE_WIDTH=8

VCORE_ILIM

MIN_LINE_WIDTH=8

VCORE_REF

VOLTAGE=5V

MIN_LINE_WIDTH=8

VCORE_TON

MIN_LINE_WIDTH=8

VCORE_CC

MIN_NECK_WIDTH=10

VCORE_DH

MIN_LINE_WIDTH=20

MIN_NECK_WIDTH=10

+VCORE_ATI_VDDM

MIN_LINE_WIDTH=25

VOLTAGE=2.5V

VOLTAGE=3.3V

MIN_LINE_WIDTH=10

+3V_ATI_OSC_SLEEP

MIN_NECK_WIDTH=10

+3V_ATI_VDDR3

MIN_LINE_WIDTH=15

VOLTAGE=3.3V

MIN_NECK_WIDTH=10

VOLTAGE=0V

MIN_LINE_WIDTH=25

KL_AGND

MIN_NECK_WIDTH=10

MIN_NECK_WIDTH=10

+VCC_CBUS_SW

MIN_LINE_WIDTH=25

VOLTAGE=3.3V

MIN_NECK_WIDTH=10

+VPP_CBUS_SW

MIN_LINE_WIDTH=25

VOLTAGE=5V

MIN_NECK_WIDTH=10

BATT_NEG

MIN_LINE_WIDTH=25

VOLTAGE=0V

MIN_NECK_WIDTH=6

/+1_8V_MAIN

MIN_LINE_WIDTH=25

VOLTAGE=1.8V
VOLTAGE=1.8V

MIN_LINE_WIDTH=25

/+1_8V_SLEEP

MIN_NECK_WIDTH=10
MIN_NECK_WIDTH=10

/+1_5V_MAIN

MIN_LINE_WIDTH=25

VOLTAGE=1.5V

MIN_NECK_WIDTH=10

/+2_5V_MAIN

MIN_LINE_WIDTH=25

VOLTAGE=2.5V

/+2_5V_SLEEP

MIN_NECK_WIDTH=10MIN_LINE_WIDTH=25

VOLTAGE=2.5V

MAX4298_VCC

MIN_NECK_WIDTH=10

VOLTAGE=5V

MIN_LINE_WIDTH=25

MIN_NECK_WIDTH=10

VOLTAGE=5V

MIN_LINE_WIDTH=25

MAX4298_SVCC

BOOMER_STAR_GND

MIN_LINE_WIDTH=25

VOLTAGE=0V

MIN_NECK_WIDTH=10

HP_AMP_SVCC_STAR_GND

MIN_LINE_WIDTH=25

VOLTAGE=0V

MIN_NECK_WIDTH=10

FIL_AUD3V

MIN_NECK_WIDTH=10

VOLTAGE=3.3V

MIN_LINE_WIDTH=25

MIN_LINE_WIDTH=25

VOLTAGE=3.3V

MIN_NECK_WIDTH=10

+AUD4V_F2

MIN_LINE_WIDTH=25

VOLTAGE=3.3V

MIN_NECK_WIDTH=10

+AUD3V

MIN_LINE_WIDTH=25

VOLTAGE=3.3V

MIN_NECK_WIDTH=10

FIL_DIG3V

MIN_NECK_WIDTH=10

VOLTAGE=3.3V

MIN_LINE_WIDTH=25

+AUD4V_F1

TI_AVSS

MIN_NECK_WIDTH=10

VOLTAGE=0V

MIN_LINE_WIDTH=25

MIC_STAR_GND

MIN_NECK_WIDTH=10

VOLTAGE=0V

MIN_LINE_WIDTH=25

MIN_LINE_WIDTH=25

VOLTAGE=0V

MIN_NECK_WIDTH=10

PWR4V_STAR_GND

SPKR_STAR_GND

MIN_NECK_WIDTH=10

VOLTAGE=0V

MIN_LINE_WIDTH=25

LINE_OUT_STAR_GND

MIN_NECK_WIDTH=10

VOLTAGE=0V

MIN_LINE_WIDTH=25

MIN_NECK_WIDTH=10

VOLTAGE=0V

MIN_LINE_WIDTH=25

PWR3V_STAR_GND

VOLTAGE=5.5V

MIN_LINE_WIDTH=10

+5_5V_BU

VOLTAGE=5.5V

MIN_LINE_WIDTH=10

LTC1625_EXTVCC

MIN_NECK_WIDTH=10

VOLTAGE=5V

+5V_DDC_SLEEP

MIN_LINE_WIDTH=15

VOLTAGE=5V

MIN_NECK_WIDTH=10

+5V_USB_VDD_B

MIN_LINE_WIDTH=15

MIN_NECK_WIDTH=10

VOLTAGE=5V

+5V_USB_VDD_A

MIN_LINE_WIDTH=15

+5V_USB_VDD_SW

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

VOLTAGE=5V

+PBUS_INV

VOLTAGE=16.8V

MIN_LINE_WIDTH=25 MIN_NECK_WIDTH=10

MIN_NECK_WIDTH=10

+5V_HD_SLEEP

MIN_LINE_WIDTH=25

VOLTAGE=5V

MIN_LINE_WIDTH=25

+5V_INV_UF_SW

MIN_NECK_WIDTH=10

VOLTAGE=5V

VOLTAGE=5V

MIN_LINE_WIDTH=25

+5V_INV_SW

MIN_NECK_WIDTH=10

MIN_LINE_WIDTH=25

+5V_IO_SLEEP

MIN_NECK_WIDTH=10

VOLTAGE=5V

+5V_TPAD_SLEEP

VOLTAGE=5V

MIN_LINE_WIDTH=10

MIN_LINE_WIDTH=25

VOLTAGE=0V

TV_GND2

TPAD_GND

VOLTAGE=0V

MIN_LINE_WIDTH=10

TV_GND1

MIN_LINE_WIDTH=25

VOLTAGE=0V

+3V_PMU_AVCC

VOLTAGE=3.3V

MIN_LINE_WIDTH=10

MIN_LINE_WIDTH=10

VOLTAGE=3.3V

+3V_HALL_EFFECT
+3V_LCD

MIN_LINE_WIDTH=12

VOLTAGE=3.3V

MIN_NECK_WIDTH=10
MIN_NECK_WIDTH=10

+3V_LCD_SW

MIN_LINE_WIDTH=25

VOLTAGE=3.3V

FAN_PWR_LOW

VOLTAGE=3.3V

MIN_LINE_WIDTH=15 MIN_NECK_WIDTH=10

FAN_PWR

VOLTAGE=5V

MIN_LINE_WIDTH=15 MIN_NECK_WIDTH=10

FAN2_PWR

VOLTAGE=5V

MIN_LINE_WIDTH=15 MIN_NECK_WIDTH=10

FAN2_PWR_LOW

VOLTAGE=3.3V

MIN_LINE_WIDTH=15 MIN_NECK_WIDTH=10

15D4< 15D1<

22D8<

15B8<

22D4<

15B5<

22C6<

15D7<

15B2<

22C2<

28D6<

22D8<

27D4<

25D4<

15D6<

39D2< 14C3<

21C4<

28D5<

22D4<

18D1<

27C1<

26C5<

25C7<

15D3<

39C1<

29D4<

28D6<

14B3<

17D7<

21C2<

22B6<

28D6<

28D3<

28D1<

28D5<

36D6<>

22C6<

16D6<

18D3<>

18D3<>

27B4<

26C4<

25C5<

15A8<

13D3<

28D3<

29A3<>

28D4<

28D4<

27D3<

14D6<>

17B4<

17D7<

21B5<

20A8<

20C4<

22B2<

21A5<

21D7<

21C7<

28B6<

28D2<

28C7<

28D2<

39B5<

39A5<

36D5<

37A8<>

36C7<>

36B8<>

36C8<

37A7<

22C2<

16D3<

18B3<>

18B3<>

26B5<

26B5<

25C6<

25A4<

27B2<>

27A4<

26A8<

26B8<

25A4<

34D2<

36C6<

37D1<>

33A8<

34B6<

15A6<

14D3<

9D8<

8D6<

13D8<>

13D4<>

28C1<>

28C5<

29D5<

29D6<>

29B2<>

29A2<>

29C5<>

29B2<>

28C5<

28C6<

27B4<

14D1<>

17A5<

17D6<

17B3<

20C4<

16D3<

16C1<>

16A5<

16D6<

16D3<

21D5<

19B7<

21A6<

20A7<

16D5<

16D3<

6D5<

8D6<

6D5<

20B3<

21C6<

19B7<

21D7<>

21A6<>

21D6<

21C4<

21C4<

28A4<

23C7<

23C7<

23C5<

23C5<

28C5<

28C6<

28C6<

39A5<

39A1<>

39A1<>

39B4<>

39B5<>

39B4<>

39B5<

35B4<>

36D4<

35B2<>

35B7<>

36C4<>

35B8<

35B6<>

35C1<>

35D4<>

35D2<

36C5<

35D6<>

36B2<>

36B4<>

37A5<

36B6<

37D7<

37D5<>

38D6<

38D5<

38B6<

38B5<

37C6<

37B5<>

37D4<>

39C6<

39B5<>

39B5<>

39C4<>

39C6<>

39B6<>

39B6<

39B6<>

39B5<>

21B7<

20B7<

21B3<

16A5<>

18B1<>

18B1<>

35B8<

26C7<>

26C6<>

26A3<>

26A4<>

25D4<

27D4<

25B5<

25C4<

27D5<

26B3<>

26B3<>

26A3<>

26B3<>

26B3<>

26A3<>

37A4<>

36A3<>

31D4<>

30C5<>

30C5<>

30D5<>

31A7<>

32D1<>

31A7<>

31A7<>

31D5<

33D7<>

31A1<>

33C6<>

31B1<>

34D5<>

33D6<>

31B5<>

31B6<>

24C2<>

24D1<>

24B1<>

24B1<>

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

44 46

E

051-6403

46

*** Signal Cross-Reference ***

--- for the entire design --

+1_2V_ATI_VCORE 43C4<> 20B3< 20C4<
+1_2V_ATI_VDDC 43C4<> 20C4<
+1_5V_L3_VDDQ_SLEEP 14D1<> 14D6<> 43D1<> 14B3<

14C3< 15B2< 15B5< 15B8< 15D1< 15D4<
+1_8V_ATI_A2VDDDI 43C4<> 21C4< 21C7<
+1_8V_ATI_A2VDDQ 43C4<> 21C6<
+1_8V_ATI_AVDD 43C4<> 21D6<
+1_8V_ATI_AVDDDI 43C4<> 21C4< 21D7<
+1_8V_ATI_LVDDR 43C4<> 21A6<
+1_8V_ATI_MPVDD 21A6<> 43C4<>
+1_8V_ATI_PVDD 21D7<> 43C4<> 21A5<
+1_8V_ATI_VDDC18 19A8< 20C3<
+1_8V_ENET 43B4<> 28C6< 28C7< 28D1<
+1_8V_UNIN_AGPPLL_MAIN 43D4<> 8D6<
+1_8V_UNIN_MAXPLL_MAIN 43D4<> 6D5<
+1_25V_ATI_VREF 43C4<> 19B7< 22B2< 22B6<
+2_5V_ATI_A2VDD 43C4<> 21D5<
+2_5V_ATI_VDDR 43C4<> 19B7< 21B5< 21C2< 21C4<

22C2< 22C6< 22D4< 22D8<
+2_5V_ENET 43C4<> 28C5< 28D2< 28D3< 28D5<

28D6<
+3V_ATI_OSC_SLEEP 43C4<> 20B7<
+3V_ATI_SS 43C4<> 20A7< 20A8<
+3V_ATI_VDDR3 43C4<> 21B3<
+3V_ENET 43C4<> 28A4< 28B6< 28D6<
+3V_FW_VDD 29A2<> 29A3<> 43B4<> 29D4<
+3V_HALL_EFFECT 33D6<> 43A6<>
+3V_HE_F 33D6<
+3V_IMI_SLEEP 43C4<> 23C7<
+3V_KL 43D4<> 16D5<
+3V_KL_AVDD1 43D4<> 16D3<
+3V_KL_AVDD2 43D4<> 16D3<
+3V_KL_AVDD3 43D4<> 16D3<
+3V_KL_AVDD4 43D4<> 16D6<
+3V_KL_OSC_SLEEP 43D4<> 16A5<
+3V_KL_USB 16C1<> 43D4<>
+3V_LCD 31B5<> 43A6<>
+3V_LCD_SW 31B6<> 43A6<>
+3V_NEC_VDD 43D1<> 17B3< 17D7<
+3V_PCI_64B_PU 43D4<> 9D8<
+3V_PMU_AVCC 34D5<> 43A6<> 34B6<
+3V_PMU_ESR 37A3<
+3V_UNIN_AGPPLL_MAIN 43D4<> 8D6<
+3V_UNIN_MAXPLL_MAIN 43D4<> 6D5<
+5V_DDC_ISO 31D3<>
+5V_DDC_SLEEP 31D4<> 43A6<>
+5V_HD_SLEEP 32D1<> 37D1<> 43B6<>
+5V_INV_SW 31A7<> 43B6<>
+5V_INV_UF_SW 31A7<> 43B6<>
+5V_IO_SLEEP 43B6<> 31D5< 33A8<
+5V_RSNS 37D4<> 43C6<>
+5V_TOL 32B5<>
+5V_TPAD_SLEEP 33D7<> 43A6<>
+5V_USB_VDD_A 30C5<> 43A6<>
+5V_USB_VDD_B 30C5<> 43A6<>
+5V_USB_VDD_SW 30D5<> 43A6<>
+5_5V_BU 37A4<> 43C6<> 34D2<
+5_5V_ESR 37A4<
+5_5V_RAW 43C6<> 37A5<
+ADAPTER 35D6<> 43D6<> 37A7<
+ADAPTER_ILIM 37A7<>
+ADAPTER_OR_BATT 37A6<>
+ADAPTER_SW 35D4<> 36B8<> 43D6<>
+ADAPTER_UF 43D6<>
+AUD3V 43B4<> 25B5< 25C6<
+AUD4V 43B4<> 27B4< 27D3<
+AUD4V_F1 43B4<> 27D5<
+AUD4V_F2 43B4<> 27D4<
+BBATT_BYPASS 37A6<>
+ENET_CTAP 28C1<> 43B4<>
+FW_VP_FUSE 29C5<> 43B4<>
+FW_VP_UF 43B4<> 29D5<
+LT1962_SLEEP 43D1<> 14D3<
+PBUS_FW_SW 29D6<> 43B4<>
+PBUS_INV 31A7<> 43B6<>
+VCC_CBUS_SW 18B1<> 18B3<> 18D3<> 43D4<> 18D1<
+VCORE_ATI_VDDM 43C4<> 21B7< 22C2< 22C6< 22D4<

22D8<
+VPP_CBUS_SW 18B1<> 18B3<> 18D3<> 43D4<>
/+1_5V_MAIN 43D6<>
/+1_8V_MAIN 43D6<>
/+1_8V_SLEEP 43D6<>
/+2_5V_MAIN 43D6<>
/+2_5V_SLEEP 43D6<>
/+3V_MAIN 43D6<>
/+3V_PMU 43D6<>
/+3V_SLEEP 43D6<>
/+5V_MAIN 43D6<>
/+5V_SLEEP 43D6<>
/+PBUS 43D6<>
/CHGND1 43A4>
/CHGND2 43A4>
/CHGND3 43A4>
/CHGND4A 43A4>
/CHGND4B 43A4>
/CHGND5 43A4>
/CHGND6 43A4>
/CHGND7 43A4>
/GND 43A4>
1V20_REF 35C4< 35C6<
1_02V_AUX 36B6< 36B7<
1_5V_AGP_ADJ 21C7<
1_5V_AGP_BYP 21C8<>
1_8V_COMP 38A7<
1_8V_FB 38B6<
1_8V_GND 38A8<
1_8V_LX 43B6<> 38B6<
1_8V_LX_F 43B6<> 38B5<
1_8V_REF 38A6<
1_8V_SHDN_L 38B7<>
1_8V_SLEEP_PWREN_L 38B3<>
1_8V_SS 38A6<
1_8V_TOFF 38A7<
2_5V_COMP 38C7<
2_5V_FB 38C6<
2_5V_GND 38C8<
2_5V_LX 43C6<> 38D6<
2_5V_LX_F 43B6<> 38D5<
2_5V_LX_M 38D5<
2_5V_MAX1644_VCC 38C7<
2_5V_REF 38C6<
2_5V_SHDN_L 38C7<>
2_5V_SLEEP_PWREN_L 38C3<>
2_5V_SS 38C6<
2_5V_TOFF 38C7<
3V_PMU_CHGR 35C1<> 36C7<> 36D6<> 43C6<>
3V_PMU_SENSE 37A4<
3V_PMU_VTAP 37A4<
3V_SLEEP_PWREN_L 37A3<>
5V_HD_PWREN 37D2<>
5V_SLEEP_PWREN 37C2<>
13_5V_DET 35C4<
1625_BG 36B4<>
1625_BST 36C4<>
1625_BST_F 36C4<
1625_COMP 36C5<
1625_INTVCC 36C4<> 43C6<>
1625_SGND 43C6<> 36B6<
1625_TG 36C4<>
1625_VFB 36B4<>
1625_VIN 43C6<> 36C5<
4863_BYPASS 26A7<
4863_SHDN 26A7<
ACOUT 26C2<>
AC_ENABLE_GATE 35D4<>
AC_ENABLE_L 35C4<
AC_IN 28A8<> 34B3< 35C5<
ADAPTER_DET 35D7<> 34B3< 34D3<
ADAPTER_I_REG 36B6<>
ADAPTER_PWR_SW 35A3<>
AGP_AD<31..0> 8B5<> 8C5<> 8D5<> 19C7<> 19D7<>

40A5<> 40B5<>
AGP_AD_STB<1..0> 8B5<> 19D5<> 40A5<> 40B5<> 8C2<
AGP_AD_STB_L<1..0> 8B5<> 19D5<> 40A5<> 40B5<> 8C2<
AGP_ATI_INT_L 16C4<> 19B7> 16C5<
AGP_ATI_RESET_L 19B7<
AGP_BUSY_L_PU 19D5> 19D7<
AGP_CBE<3..0> 8B7<> 19B7<> 40A5<> 40B5<>
AGP_DEVSEL_L 8C7<> 19B7<> 40A5<> 8D2<
AGP_FRAME_L 8C7<> 19B7<> 40A5<> 8D2<
AGP_GNT_L 8C7> 40A5<> 8B2< 19B7<
AGP_IRDY_L 8C7<> 19B7<> 40A5<> 8D2<
AGP_PAR 8C7<> 19B7> 40A5<>
AGP_PIPE_L_PU 8B7< 8C2<
AGP_RBF_L 19C5> 40A5<> 8B7< 8D2<

AGP_REQ_L 19B7<> 40A5<> 8B2< 8C7<
AGP_SBA<7..0> 19C5> 19C5<> 19C5> 40A5<> 8B5<
AGP_SB_STB 8B5<> 19C5<> 40A5<> 8C2<
AGP_SB_STB_L 8B5<> 19C5<> 40A5<> 8C2<
AGP_ST<2..0> 8B7> 19C5<
AGP_STOP_L 8C7<> 19B7<> 40A5<> 8D2<
AGP_STP_L 19C5<
AGP_SUS_STAT_L_PU 19C5< 19D7<
AGP_TRDY_L 8C7<> 19B7<> 40A5<> 8D2<
AGP_U4RTAP 8A6<
AGP_WBF_F 19B7<>
AGP_WBF_L 8B7< 8C2< 19B7<
AIN_L_M 25C4<
AIN_L_P 25C4<
AIN_R_M 25C4<
AIN_R_P 25C4<
AOUTL 25C2> 26B8< 26D7<
AOUTL_BOOMER 26B8<
AOUTL_FILTER 26D7<
AOUTR 25C2> 26A8< 26D7<
AOUTR_BOOMER 26A7<
AOUTR_FILTER 26D7<
ATI_AGP_FBSKEW<1..0> 20C6<>
ATI_AGP_TEST 19C7< 19D5<
ATI_AGP_VREF 8B3< 19D5<
ATI_AGP_VREF_H 8C3<
ATI_AGP_VREF_L 8B3<
ATI_AUXWIN_PU 20C5<> 19D7<
ATI_B 20D5> 31C8<
ATI_BUS_CFG<2..0> 20C6<>
ATI_B_FILTR 31C7<
ATI_C 20C5> 31B4<
ATI_CLKA<1..0> 19A7<> 19A6<
ATI_CLKA_L<1..0> 19A7<> 19A6<
ATI_COMP 20C5> 31B4<
ATI_DIGON 20C5> 31A8<> 31B8<>
ATI_DIGON_L 31A8<>
ATI_DVI_DDC_CLK 20C5<> 31C1<>
ATI_DVI_DDC_DATA 20C5<> 31C1<>
ATI_G 20D5> 31C8<
ATI_GPIO7_SPN 20C6<>
ATI_GPIO8_SPN 20C6<>
ATI_GPIO9_SPN 20C6<>
ATI_GPIO10_SPN 20B6<>
ATI_GPIO11_SPN 20B6<>
ATI_GPIO12_SPN 20B6<>
ATI_GPIO13_SPN 20B6<>
ATI_G_FLTR 31C7<
ATI_HPD 31C1<> 20C5<
ATI_HSYNC 20D5<> 20D7<
ATI_HSYNC_BUF 20C8<>
ATI_INV_ON_L 20C5> 31A8<
ATI_LCDCNTL0_TP 20C6<>
ATI_LCDCNTL1_TP 20C6<>
ATI_LCDCNTL2_TP 20C6<>
ATI_LCDCNTL3_TP 20C6<>
ATI_MEMTEST 19A6<>
ATI_MEMVMODE<1..0> 19A7<
ATI_MPVDD_BYP 21A6<>
ATI_OSC_OE 20B8<
ATI_PVDD_BYP 21D7<>
ATI_R 20D5> 31C8<
ATI_R2SET 20D5> 21D5<
ATI_RSET 20D5> 21D6<
ATI_R_FILTR 31C7<
ATI_SLAVE_VIP 20C6<>
ATI_SSIN_PU 19D7< 20B6<
ATI_SS_PU 19D8< 20A6<
ATI_TEMP 24C8<> 24B7<
ATI_TESTEN 19C7< 20B6<
ATI_VCORE_AGND 20A4<>
ATI_VCORE_BG 20A4<>
ATI_VCORE_CNTL 20A6<>
ATI_VCORE_CNTL_L 20A6<> 20B6<>
ATI_VCORE_FB_SW 20A7<> 20A3<
ATI_VCORE_ITH 20A5<
ATI_VCORE_ITH_RC 20A6<
ATI_VCORE_L_SW 20A5<>
ATI_VCORE_RUN_SS 20A5<
ATI_VCORE_SENSE 20A5<>
ATI_VCORE_SYNC_FCB 20A5<
ATI_VCORE_TG 20A4<>
ATI_VCORE_VFB 20A4<
ATI_VCORE_VIN 20A5<>
ATI_VMEM_ADDR<13..0> 19C3> 19D3> 22B3<> 22B7<>

41D5<> 22B4< 22B8< 22C4< 22C8<
ATI_VMEM_CASB_L 19A5> 41D5<> 22B4< 22B8<
ATI_VMEM_CKEB 19A5> 41D5<> 22B4< 22B8<
ATI_VMEM_CLKB<1..0> 19A5<> 42A2<> 22A4< 22A8< 22B4<

22B8<
ATI_VMEM_CLKB_L<1..0> 19A5<> 42A2<> 22A4< 22A8<

22B4< 22B8<
ATI_VMEM_CSB_L 19A5> 41D5<> 22B4< 22B8<
ATI_VMEM_DATA<63..0> 19A3<> 19B3<> 19C3<> 22B3<>

22B7<> 22C3<> 22C7<> 41D5<>
ATI_VMEM_DQMB<7..0> 19A3> 41D5<> 22B4< 22B8< 22C4<

22C8<
ATI_VMEM_QS<7..0> 19A5<> 19B5<> 22C4<> 22C8<>

41D5<>
ATI_VMEM_RASB_L 19A5> 41D5<> 22B4< 22B8<
ATI_VMEM_WE_L 19A5> 41D5<> 22B4< 22B8<
ATI_VSYNC 20D5<> 20D7<
ATI_VSYNC_BUF 20D8<>
ATI_X1CLK_SKEW<1..0> 20C6<>
ATI_Y 20C5> 31B4<
AUD3V_FDBK 25C6<
AUD4V_FDBK 27B5<
AUDIO_OUT_L 26C2<
AUDIO_OUT_R 26C2<
AUDIO_REF 27C3<
AUDIO_REF_2V 27C2<
AUDIO_REF_3V 27C2<
AUDIO_RESET_L 16C4<> 16C5< 25B4<
BATT_CLK 35B8<
BATT_DATA 35B8<
BATT_ENABLE_L 35A3<>
BATT_FET2_GATE 35B4<>
BATT_FET_DRAIN 35A3<>
BATT_FET_GATE 35B3<>
BATT_FET_SW 35B4<> 43C6<>
BATT_IN_PD 35B7<
BATT_ISNS 43C6<> 36D4<
BATT_LINE 35B2<> 43C6<> 36D5<
BATT_NEG 43C6<> 35B8<
BATT_OK 35A7<
BATT_OK_REF 35A7<
BATT_POS 43C6<> 35B8<
BATT_POS_F 35B7<> 37A8<> 43C6<>
BATT_RC 35A2<>
BATT_RES 35B6<> 43C6<>
BATT_V_GOOD 35A6<
BA_0 7C6> 40C5<> 7B5<
BA_1 7C6> 40C5<> 7C5<
BBATT_ENABLE 36C2<> 37A8<
BBATT_ENABLE_ESD 37A7<>
BBATT_EN_L 37A7<>
BF_FET_G 36B2<>
BOOMER_STAR_GND 26A3<> 43A4<> 26B5<
BRIGHT_INV 31A7<>
BRIGHT_INV_BUF 31A7<>
BT_USB_DM 30C2<> 42B2<> 16C1< 16D1<
BT_USB_DP 30C2<> 42B2<> 16C1< 16D1<
BYPASS_R_GATE 35A5<>
BYPASS_R_L 35A5<
CAPSLOCK_LED 33D3<
CAPSLOCK_LED_L 33D2< 34C7<
CAS_DQM0_L 7C6> 40C5<> 7D5<
CAS_DQM1_L 7C6> 40C5<> 7D5<
CAS_DQM2_L 7C6> 40C5<> 7D5<
CAS_DQM3_L 7C6> 40C5<> 7D5<
CAS_DQM4_L 7C6> 40C5<> 7D5<
CAS_DQM5_L 7C6> 40C5<> 7D5<
CAS_DQM6_L 7C6> 40B5<> 7D5<
CAS_DQM7_L 7C6> 40B5<> 7C5<
CBUS_ADDR<25..0> 18A4> 18B1<> 18B2<> 18B4> 18C1<>

18B4<
CBUS_ADDR_16_UF 18B5<>
CBUS_BVD1_L 18B2<> 18C4<
CBUS_BVD2_L 18B2<> 18C4<
CBUS_CE1_L 18C1<> 18C4>
CBUS_CE2_L 18C2<> 18C4>
CBUS_DATA<15..0> 18A2<> 18A4<> 18B1<> 18B2<> 18C1<>

18C2<>
CBUS_DET_1_L 18C2<> 18C4<
CBUS_DET_2_L 18A2<> 18C4<
CBUS_INPACK_L 18B2<> 18C4<
CBUS_INT_L 16B4<> 18A7<> 16B5<
CBUS_IORD_L 18C2<> 18C4>

CBUS_IOWR_L 18B2<> 18C4>
CBUS_MFUNC1_PD 18A7<> 18D7<
CBUS_MFUNC2_PD 18A7<> 18C7<
CBUS_MFUNC3_PD 18A7<> 18C7<
CBUS_MFUNC4_PD 18A7<> 18C7<
CBUS_MFUNC5_PD 18A7<> 18C7<
CBUS_MFUNC6_PD 18A7<> 18C7<
CBUS_OE_L 18C1<> 18C4>
CBUS_PCI_GNT_L 9C5> 18A7<
CBUS_PCI_IDSEL 18B7<
CBUS_PCI_REQ_L 18A7> 9C2< 9D5<
CBUS_PCI_RESET_L 18B7<
CBUS_READY 18B1<> 18C4<
CBUS_REG_L 18B2<> 18C4>
CBUS_RESET_L 18B2<> 18C4>
CBUS_SUSPEND_PU 18A7< 18D7<
CBUS_VCCD0_L 18C5<
CBUS_VCCD1_L 18C5<
CBUS_VPPD0 18C5<
CBUS_VPPD1 18C5<
CBUS_VS1 18C2<> 18C4<>
CBUS_VS2 18B2<> 18C4<>
CBUS_WAIT_L 18B2<> 18C4<
CBUS_WE_L 18B1<> 18C4>
CBUS_WP_L 18A1<> 18C4< 18D2<
CHARGE_LED_L 34C6<> 35D7<> 34D7<
CHGR_OUT 36B2<> 43C6<>
CHGR_VSW 36B4<> 43C6<>
CHKSTP_OUT_L 13B3<> 13C2<
CHRG_DSCHG_L 35A4<>
CLK10M_PMU_XIN 34B6<
CLK10M_PMU_XOUT 34B6<
CLK10M_PMU_XOUT_UF 34B7<
CLK14M_IMI_XIN 23B6<> 40C1<>
CLK14M_IMI_XOUT 23B6<> 40C1<>
CLK14M_SERIES 23B7<
CLK18M_KL_PLL 40C1<> 16B4<
CLK18M_KL_UF 40C1<> 16A4<
CLK24M_FW_XIN 29C6<>
CLK24M_FW_XOUT 29C6<>
CLK25M_ENET_XIN 28A6<
CLK25M_ENET_XOUT 28A6<>
CLK27M_ATI 40C1<> 20B6<
CLK27M_ATIMEM_SS 20A7<> 40B1<>
CLK27M_ATIMEM_US 20A8<
CLK27M_ATI_LS1_8 20B7<
CLK27M_ATI_UF 40C1<> 20A8< 20B7<
CLK32K_PMU_XIN 34B3<>
CLK32K_PMU_XOUT 34B3<>
CLK32K_PMU_XOUT_UF 34B2<>
CLK33M_CBUS 40C1<> 18A7< 23B3<
CLK33M_CBUS_UF 40C1<> 23B5<
CLK33M_KL_PCI 40C1<> 16A8< 23B3<
CLK33M_KL_UF 40C1<> 23B5<
CLK33M_NEC 40C1<> 17B7< 23B3<
CLK33M_NEC_UF 40C1<> 23B5<
CLK33M_UNIN_PCI_EXT 40C1<> 9C5< 23B3<
CLK33M_UNIN_PCI_EXT_UF 40C1<> 23B5<
CLK66M_AGP_ATI 40D1<> 19B7< 23B3<
CLK66M_AGP_UF 40D1<> 23B5<
CLK66M_UNIN_AGP 40D1<> 8C7< 23B3<
CLK66M_UNIN_AGP_UF 40D1<> 23B5<
CLK66M_UNIN_PCI_INT 40C1<> 9C5< 23C3<
CLK66M_UNIN_PCI_INT_UF 40D1<> 23B5<
CLKENET_PHY_RX 28B6<> 40B1<>
CLKENET_PHY_TX 28C6<> 40B1<>
CLKLVDS_N 20B5> 31B5<> 42C2<>
CLKLVDS_P 20B5> 31B5<> 42C2<>
CLK_ENET_LINK_RX 40B1<> 10C6< 28B7<
CLK_ENET_LINK_TX 40B1<> 10C6< 28C7<
CLK_PHY_FW 29B6<> 40B1<>
CLK_UNIN_FW 40B1<> 10B2< 29B7<
COMM_DTR_L 16C2> 32B2<>
COMM_GPIO_L 16C2<> 32B3<>
COMM_RESET_L 16C4<> 32A3<>
COMM_RING_DET_L 16C4<> 32B4<> 34C6<> 16C5<
COMM_RTS_L 16C2> 32B2<>
COMM_RXD 32B2<> 16C2<
COMM_SHUTDOWN 16B8> 32A4<>
COMM_TRXC 16C2<> 32B3<>
COMM_TXD_L 16C2> 32B3<>
COMP_RC 36B6<
CPU1_INT_L_PU 16C4<> 16B5<
CPU_AACK_L 6B7> 40D5<> 6C2< 13A7<
CPU_ADDR<31..0> 6B7<> 6C7<> 13B7<> 13C7<> 40D5<>
CPU_ARTRY_L 6B7<> 13A7<> 40D5<> 6C2<
CPU_AVDD 13D4<> 43D4<>
CPU_BG_L 6D7> 13C7> 40D5<> 6C2<
CPU_BR_L 13C7> 6C2< 6D7<
CPU_BUS_VSEL 12A6< 13C3<
CPU_CHKS_L 13B3< 13D2<
CPU_CI_L 6B7> 13A7> 40D5<>
CPU_CLKOUT_SPN 13C3>
CPU_CLK_EN 34C4<> 23B6< 23C4<
CPU_DATA<63..0> 6A3<> 6B3<> 6C3<> 6D3<> 14A8<>

14B8<> 14C8<> 14D8<> 40D5<> 12A3<
CPU_DBG_L 6A3> 40D5<> 6C2< 13C3<
CPU_DRDY_0_L 6A3< 6C2< 13C3<
CPU_DRDY_0_L_UF 13C4<>
CPU_DTI<2..0> 6A3> 40D5<> 13C3<
CPU_EDTI 13A2< 13C3<
CPU_EMODE0_L 12A6< 13A3<
CPU_EMODE1_L 13A3< 13C2<
CPU_GBL_L 6B7> 13A7<> 40D5<>
CPU_HIT_0_L 13A7> 6B7< 6C2<
CPU_HRESET_L 34C4<> 12A5< 13B3< 13C2<
CPU_L1TSTCLK 13B2< 13B3<
CPU_L2TSTCLK 13B3< 13D2<
CPU_L3_VSEL 12A4> 12A6< 14C3<
CPU_LSSD_MODE 13B3< 13D2<
CPU_MCP_L 13B3< 13D2<
CPU_PLL_CFG<3..0> 12D3< 13C3<
CPU_PLL_CFGEXT 12D3< 13C3<
CPU_PLL_FS00 12C3<>
CPU_PLL_FS01 12C3<
CPU_PLL_FS10 12C3<
CPU_PLL_STOP_BASE 12C7<
CPU_PLL_STOP_OC 12C8<> 34B6<>
CPU_PMONIN_L 16C4<> 13B3< 13C2<
CPU_PULLDOWN 13C7<> 13A2< 13A3<
CPU_PULLUP 13A3< 13C2<
CPU_QACK_L 6A7> 40D5<> 13B3<
CPU_QREQ_L 13B3> 6A7< 6C2<
CPU_SHD0_L 13A7<> 13D2<
CPU_SHD1_L 13A7<> 13D2<
CPU_SMI_L 34C4<> 13B2< 13B3<
CPU_SRESET_L 16C4<> 13B3< 13C2<
CPU_SRWX_L 13A3< 13C2<
CPU_TA_L 6A3> 40D5<> 6D2< 13B3<
CPU_TBEN 13B3< 13D2<
CPU_TBST_L 6B7<> 13A7> 40D5<>
CPU_TEA_L 6A3> 40D5<> 6D2< 13B3<
CPU_TEMP 24C8<> 24B7<
CPU_TSIZ<2..0> 6B7<> 13A7> 40D5<>
CPU_TS_L 6C7<> 13C7> 40D5<> 6D2<
CPU_TT<4..0> 6B7<> 13A7<> 40D5<>
CPU_VCORE_HI_OC 34D4<> 12B8< 23B6< 39C6<
CPU_VCORE_PWR_SEQ 39D8<>
CPU_VCORE_SEQ 39D8<
CPU_VCORE_SEQ_L 39D8<
CPU_VCORE_SLEEP 13D8<> 43D4<> 13D3< 39C1< 39D2<
CPU_VCORE_SNUB 39B3<
CPU_WT_L 6B7> 13A7> 40D5<>
CSLOT_ADDR<15..0> 16B2> 16B4<> 16C4<> 16C6> 32C6<>

42C5<> 42D5<> 32C7<
CSLOT_CE1_L 16B6> 32C6<> 42C5<>
CSLOT_CE2_L 16B6> 32C5<> 42C5<>
CSLOT_CS1FX_L 32C6<> 42D5<> 32C7<
CSLOT_CS3FX_L 32C6<> 42D5<> 32C7<
CSLOT_DATA<15..0> 32C5<> 32C6<> 32D5<> 32D6<>

42D5<> 32D7<
CSLOT_IORD_L 32C5<> 42D5<> 16B1<
CSLOT_IOWAIT_L 32C5<> 42C5<> 16B2<
CSLOT_IOWR_L 32C5<> 42C5<> 16B1<
CSLOT_IRQ_L 16B4<> 32C6<> 42C5<>
CSLOT_REG_L 16B4<> 32C5<> 42C5<>
CSLOT_RESET 16C4<> 32C5<> 42C5<>
CS_1 25B4<
CURRENT_ADJ 36B7<
CY811_S0 20A7<
CY811_S1 20A8<
CY_VCC 24D7<
DCDC_EN 37D7<> 38B8<> 38C8<> 39C7<>
DCDC_EN_L 37D7<>
DVI_DDC_CLK 31C4<> 33A8<>
DVI_DDC_CLK_F 31C3<>
DVI_DDC_DATA 31C4<>
DVI_DDC_DATA_F 31C3<>

DVI_HPD 31C4<> 33B8<
DVI_HPD_DIV 33B8<
DVI_HPD_F 31C2<>
DVI_PWR_EN_L 33A8<>
DVI_TURN_ON 33A8<>
DVI_TURN_ON_BASE 33A7<
EIDE0_DMACK_L 16B6> 42D5<> 32B8<
EIDE0_DMARQ 42D5<> 16B6< 32B8<
EIDE0_DMA_ACK_L 32A6<> 42C5<> 32B7<
EIDE0_DMA_RQ 32A6<> 42C5<> 32B7<
EIDE0_INT 42D5<> 16B6< 32A8<
EIDE0_INTR 32A5<> 42C5<> 32A7<
EIDE0_RD_L 16B6> 42D5<> 32A8<
EIDE0_READ_L 32A6<> 42C5<> 32A7<
EIDE0_RST_L 16C6> 42D5<> 32A8<
EIDE0_RST_L_OPU 32B5<> 42C5<> 32A7<
EIDE0_WR_L 16B6> 42D5<> 32A8<
EIDE0_WR_L_OPU 32A5<> 42C5<> 32A7<
EIDE1_DMAREQ_PD 16B6<
EIDE1_INT_PD 16B6<
EIDE_ADDR<2..0> 16C6> 42D5<> 32B8< 32C8<
EIDE_ADDR_<2..0> 32A5<> 32A6<> 42C5<> 32B7<
EIDE_CS1FX_L 16C6> 42D5<> 32B8< 32C8<
EIDE_CS1FX_L_OPU 32A5<> 42C5<> 32B7<
EIDE_CS3FX_L 16C6> 42D5<> 32B8< 32C8<
EIDE_CS3FX_L_OPU 32A6<> 42C5<> 32B7<
EIDE_DATA<15..0> 16C6<> 16D6<> 42D5<> 32B7< 32C7<

32C8< 32D8<

EIDE_DB_<15..0> 32A5<> 32A6<> 32B5<> 32B6<> 42C5<>

32B8< 32C7< 32C8<
EIDE_DET_PU 16C4<> 16C5<
EIDE_IOCHRDY 42D5<> 16C6< 32A8<
EIDE_IO_CHRDY 32A5<> 42C5<> 32A7<
ENET_AVDD 43B4<> 28C5< 28D4<
ENET_AVDDL 43C4<> 28C6< 28D2< 28D5<
ENET_COL 28B6> 42A5<> 10B6<
ENET_CRS 28B6> 42A5<> 10B6<
ENET_CTAP_CHGND 28B1<
ENET_DVDDL 43B4<> 28C6< 28D4< 28D6<
ENET_ENERGY_DET 16B4<> 28B4<>
ENET_GBE_REFCLK 10B6> 40B1<> 28A7<
ENET_GTX_CLK 10B6<> 40B1<>
ENET_MDC 10B6> 42A5<> 28A4<
ENET_MDIO 10B6<> 28A5<> 42A5<>
ENET_PHY_GBE_REFCLK 28A6<> 40B1<>
ENET_PHY_GTX_CLK 40B1<> 10B7< 28B6<
ENET_PHY_RXD<7..0> 28B6<> 42A5<>
ENET_PHY_TXD<7..0> 42A5<> 10B7< 10C7< 28B6< 28C6<
ENET_PHY_TX_EN 42A5<> 10C7< 28C6<
ENET_PHY_TX_ER 42A5<> 10C7< 28C6<
ENET_PLLVDD 43B4<> 28C5< 28D3<
ENET_PWR_EN_L 28A7<> 28A6<
ENET_RDAC 28D5<>
ENET_RST_L 28A7<
ENET_RXD<7..0> 42A5<> 10B6< 28B7<
ENET_RX_DV 28B6> 42A5<> 10C6<
ENET_RX_ER 28B6> 42A5<> 10B6<
ENET_TX_D<7..0> 10C6<> 42A5<>
ENET_TX_EN 10C6<> 42A5<>
ENET_TX_ER 10C6<> 42A5<>
ENET_WIRESPEED_EN 28A6<
EXTINT6_UNUSED_L 16B4<> 16C5<
EXTVCC_EN_L 36A4<>
FAN1_ON_LOW_L 24C5<>
FAN2_ON_LOW_L 24B3<>
FAN2_PWR 24B1<> 43A6<>
FAN2_PWR_LOW 24B1<> 43A6<>
FAN_1 24C7<> 24D3<>
FAN_2 24B3<> 24C7<>
FAN_PWR 24D1<> 43A6<>
FAN_PWR_LOW 24C2<> 43A6<>
FBA_0 7B2<> 40C5<> 7B4<
FBA_1 7B2<> 40C5<> 7C4<
FBSEL0 23B5<
FBSEL1 23B5<
FBSEL2 23B6<
FB_5_5V_BU 37A5<
FCAS_DQM0_L 7C3<> 40C5<> 7D4<
FCAS_DQM1_L 7C3<> 40C5<> 7D4<
FCAS_DQM2_L 7B3<> 40C5<> 7D4<
FCAS_DQM3_L 7B3<> 40C5<> 7D4<
FCAS_DQM4_L 7C2<> 40C5<> 7D4<
FCAS_DQM5_L 7C2<> 40B5<> 7D4<
FCAS_DQM6_L 7B2<> 40B5<> 7D4<
FCAS_DQM7_L 7B2<> 40B5<> 7C4<
FEEDBACK_1 24C1<> 24C7<>
FEEDBACK_2 24B1<> 24C6<
FEEDBACK_2_F 24C7<>
FET_DRAIN 36B2<
FILTER2_OUTR 26C4<
FILTER2_OUT_L 26C4<
FILTER_OUT_L 26C5<
FILTER_OUT_R 26C5<
FIL_AUD3V 43B4<> 25D4<
FIL_DIG3V 43B4<> 25C4<
FMA_AR<12..0> 7B2<> 7B3<> 7C2<> 7C3<> 40C5<> 7B4<

7C4<
FMEMWE_L 7C3<> 40B5<> 7C4<
FRAM_CKE0_A 7C2<> 40B5<> 7B4<
FRAM_CKE0_B 7C2<> 40B5<> 7B4<
FRAM_CKE1_A 7C2<> 40B5<> 7B4<
FRAM_CKE1_B 7C2<> 40B5<> 7B4<
FRAS_CS0_L 7C3<> 40C5<> 7C4<
FRAS_CS1_L 7B3<> 40C5<> 7C4<
FRAS_CS2_L 7C3<> 40C5<> 7C4<
FRAS_CS3_L 7B3<> 40C5<> 7C4<
FSDCAS_L 7C2<> 40B5<> 7B4<
FSDRAS_L 7C3<> 40B5<> 7B4<
FW_BIAS0 29B4<>
FW_C_LKON 10B2<> 16B4<> 29B4<>
FW_F0 29C5<>
FW_F1 29C5<>
FW_LINK_CNTL<1..0> 10B2<> 42A5<> 29B7<
FW_LINK_DATA<7..0> 10B2<> 10C2<> 42A5<> 29B7<
FW_LINK_LREQ 10B2> 42A5<> 29B7<
FW_PHY_CNTL<1..0> 29B6<> 42A5<>
FW_PHY_CPS 29C5<
FW_PHY_DATA<7..0> 29B6<> 42A5<>
FW_PHY_LPS 10B2> 29B6<
FW_PHY_LREQ 42A5<> 29B6<
FW_PHY_PD 16C4<> 29B6<
FW_PHY_RST_L 29B6<
FW_PHY_SE 29B6<
FW_PWREN 29C7<
FW_PWREN_L 29C6<
FW_PWR_GATE 29D7<>
FW_R0 29C4<>
FW_R1 29C4<>
FW_TEST 10B2<> 10A7<
FW_TPA0N 29B4<> 42D2<>
FW_TPA0P 29B4<> 42C2<>
FW_TPB0 29B2<
FW_TPB0N 29B4<> 42C2<>
FW_TPB0P 29B4<> 42C2<>
FW_TPI1N 29A3<> 29B2<> 42C2<>
FW_TPI1P 29A3<> 29B2<> 42C2<>
FW_TPO1N 29A3<> 29B2<> 42C2<>
FW_TPO1P 29A3<> 29B2<> 42C2<>
FW_VGND 29B2<> 43B4<>
FW_VP 29B2<> 43B4<>
GND_GALVA 27C5<
GND_HZ 27C6<
GND_REF 24C8<> 24A8< 24B8<
GTR_THAN_13V_RC 36A5<>
GTR_THAN_13_0V 35C2<> 36A5<> 36B1<>
HD_ADDR<2..0> 32C1<> 32C2<> 42B5<> 32D3<
HD_CS1_L 32C2<> 42B5<> 32D3<
HD_CS3_L 32C1<> 42B5<> 32C3<
HD_DATA<15..0> 32D1<> 32D2<> 42B5<> 32D3<
HD_DIOR_L 32C2<> 42B5<> 32C3<
HD_DIOW_L 32C2<> 42B5<> 32C3<
HD_DMACK_L 32C2<> 42B5<> 32C3<
HD_DMARQ 32D2<> 42B5<> 16A5<
HD_INTRQ 32C2<> 42B5<> 16A5<
HD_IOCHRDY 32C2<> 42B5<> 16A5<
HD_RESET_L 32D2<> 42B5<> 32C3<
HOLE_22R10A 5B2<> 5C3<>
HOLE_22R10D 5B2<> 5C3<>
HPD_4V_REF 33B7<
HPD_PWR_SNS_EN 20B6<> 33A8<>
HPD_PWR_SW 33B6<
HPD_PWR_SW_BASE 33A6<
HPD_PWR_SW_OPT 33A6<
HPD_REF_EN_L 33B7<
HPD_REF_EN_L_OPT 33B7<>
HPD_REF_EN_L_OPT2 33A7<>
HP_AMP_SVCC_STAR_GND 26A4<> 43A4<> 26B5<
HP_DET 26D3<

HP_DET_CONN 26C2<
HP_SENSE_NEG_INPUT 26D3<
HP_SENSE_POS_INPUT 26D4<
IAC_FB 36C7<
IAC_RC_COMP 36C6<
IBATTX0_65 36D4<>
IBATT_FB 36D5<
IBATT_RC_COMP 36D6<
IBATT_SERVO 36D5<
ICHRG_REG 36C6<>
IINX0_62 36C7<>
IMI_CPUSD_STP_L 23C4<
INPUT14_24V_SW 43D6<> 35D2< 36C8<
IO_RESET_L 34C6<> 16B8< 17B7< 18B7< 19B7<

28A7< 34D7<
ITH_1625 36D6<>
JTAG_ASIC_TCK 10A7< 10B6< 16A2< 28A4<
JTAG_ASIC_TDI 10A7< 10B6<
JTAG_ASIC_TDO_SPN 28A4>
JTAG_ASIC_TMS 10A7< 10B6< 16A2< 28A4<
JTAG_ASIC_TRST_L 10A7< 10B6< 16A2< 28A4<
JTAG_CPU_RST_L 13B2< 13B3<
JTAG_CPU_TCK 13B2< 13C3<
JTAG_CPU_TDI 13B2< 13C3<
JTAG_CPU_TDO_TP 13C3>
JTAG_CPU_TMS 13B2< 13C3<
JTAG_ENET_TDI 16A2> 28A4<
JTAG_KL_TDI 10B6> 16A2<
JTAG_L3_SRAM2_TDI 15B6> 15B3<
JTAG_L3_TCK 15B3< 15B6< 15C7<
JTAG_L3_TDI_TP 15B6<
JTAG_L3_TDO_TP 15B3>
JTAG_L3_TMS 15B3< 15B6<
KBD_CAPSLOCK_LED 33C3<>
KBD_COMMAND_L 33C4<> 34C6<> 33C2<
KBD_CONTROL_L 33C3<> 34C6<> 33C2<
KBD_FUNCTION_L 33C4<> 34B6<> 33C2<
KBD_ID 33C4<> 34B6<> 33D2<
KBD_INTL 33C3<>
KBD_JIS 33C4<>
KBD_NUMLOCK_LED 33C4<>
KBD_OPTION_L 33C3<> 34B6<> 33C2<
KBD_SHIFT_L 33C4<> 34C6<> 33C2<
KBD_X<9..0> 33C3<> 33C4<> 34C6<> 33C2< 33D2<
KBD_Y<7..0> 33C3<> 33C4<> 34C6<> 34D6<>
KL_AGND 16A5<> 43D4<> 16D3< 16D6<
KL_CREF 16B4<
KL_CREF2 16B4< 23B6<
KL_CSLOT_IORD_L 16B3<> 42D5<>
KL_CSLOT_IOWR_L 16B3<> 42D5<>
KL_DEVCS3_SPN 16B6>
KL_DEVCS4_SPN 16B6>
KL_DEV_ID<1..1> 16B4<> 16B5<
KL_DEV_IN_L 16B4<> 16B5<
KL_DIR_245_SPN 16B6>
KL_ENET_RST_L 16C4<> 28A7<
KL_FW_PWREN 16C4<> 16C5< 29C7<
KL_I2C_CLK 16A2<> 25B2<> 32B4<> 16D1<
KL_I2C_DATA 16A2<> 25B2<> 32B3<> 16D1<
KL_IRDA_FIR_L 16C2<> 16C2<
KL_IRDA_LOF 16C2<> 16C2<
KL_IRDA_RXD_L 16C2<
KL_OSC_EN 16A5<
KL_PCI_GNT_L 9C5> 41D5<> 16B8<
KL_PCI_IDSEL 16B8<
KL_PCI_REQ_L 16B8> 9C2< 9C5<
KL_PEND_PROC_INT 16B4> 34C4<>
KL_PLL_EN 16A4< 16C5<
KL_PROC_SLEEP_REQ_L 34B4<> 16B4<
KL_SND_CLKOUT 16B3<>
KL_SND_SCLK 16B3<>
KL_SND_SYNC 16B3<>
KL_SND_TO_AUDIO 16B3<>
KL_SUSPEND_REQ_L 34B6<> 16B4< 34D7<
KL_USB0_PCI_IDSEL 16B8<
KL_USB1_PCI_IDSEL 16B8<
KL_WATCHDOG_L 16A4> 34C6<>
L3_ADDR<17..0> 14D6> 41D5<> 15C3< 15C6< 15D3<

15D6<
L3_CLK<1..0> 14C3> 40B1<> 15C3< 15C6<
L3_CLK_REF 15B6< 15C3< 15C6<
L3_CNTL<1..0> 14C3> 41D5<> 15C3< 15C6<
L3_DATA<63..0> 14A6<> 14B6<> 14C6<> 15C1<> 15C4<>

15D1<> 15D4<> 41D5<>
L3_DQPA<1..0> 15C1<> 15C4<> 15C7<
L3_DQPB<1..0> 15C1<> 15C4<> 15C7<
L3_DQPC<1..0> 15C1<> 15C4<> 15C7<
L3_DQPD<1..0> 15C1<> 15C4<> 15C7<
L3_ECHO_CLK<3..0> 15B1<> 15B4<> 40B1<> 14B3<
L3_PULLDOWN<1..0> 15B1< 15B4< 15C3< 15C6< 15C7<
L3_VDD_SLEEP 43D1<> 15A6< 15A8< 15D3< 15D6<

15D7<
L3_VREF 15B7< 15C3< 15C6<
L3_ZQ<1..0> 15C3< 15C6<
LCD_DIGON_L 31B8<>
LCD_PWREN_L 31B7<>
LCH_GALVA 27D5<
LCH_HZ 27D6<
LID_CLOSED_L 33D6<>
LINE_IN_B 25C4<
LINE_IN_L 25C4< 27D4<
LINE_IN_R 25C4< 27C4<
LINE_OUT_L 26C5<>
LINE_OUT_R 26C5<>
LINE_OUT_STAR_GND 26B3<> 43B4<> 26B8< 26C4< 26C5<
LIN_DET 27B7<
LIN_DET_EMI 27B8< 27D7<
LIN_GND 27C8<>
LIN_LCH 27C8<>
LIN_RCH 27C8<>
LIN_SNS 27C8<>
LT1962_ADJ 14D2<
LT1962_BYPASS 14D2<>
LT1962_SHDN_L 14C3<>
LTC1625_EXTVCC 36A3<> 43C6<> 36C6<
LVDS_DDC_CLK 20C5<> 31A6<>
LVDS_DDC_DATA 20C5<> 31A6<>
LVDS_L0N 20B5> 31B5<> 42C2<>
LVDS_L0P 20B5> 31B5<> 42C2<>
LVDS_L1N 20B5> 31B5<> 42C2<>
LVDS_L1P 20B5> 31B5<> 42C2<>
LVDS_L2N 20B5> 31B5<> 42C2<>
LVDS_L2P 20B5> 31B5<> 42C2<>
LVDS_L3N_SPN 20B5>
LVDS_L3P_SPN 20B5>
L_SPKR_NEG 26A6<>
L_SPKR_POS 26B6<>
MAIN_RESET_L 9A5<> 34D4<> 17A7<
MAX785_EN 37C7<
MAX785_GND 37C7<>
MAX1644_VCC 38B7<
MAX4298_BIAS 26C7<>
MAX4298_CBYPASS 26C7<>
MAX4298_IN1 26D6<
MAX4298_IN2 26D6<
MAX4298_MUTE 26C7<
MAX4298_SVCC 26C6<> 43B4<>
MAX4298_VCC 26C7<> 43B4<>
MB2_IDE_OE_PU 16C4<> 16B5<
MB_IRQ_PU 16B4<> 16C5<
MB_PWREN_L 16C4<> 16C5<
MDI_M<3..0> 28B5<> 28C5<> 42D2<>
MDI_P<3..0> 28B5<> 28C5<> 42D2<>
MEMWE_L 7B6> 40B5<> 7C5<
MEM_DATA<63..0> 7A2<> 7A3<> 7A8<> 7B2<> 7B3<> 7B8<>

7C2<> 7C3<> 7C8<> 7D2<> 7D3<> 7D8<>

40C5<>
MEM_EXT_R 7B7<> 40B5<>
MIC_DIFF_IN 27B2<
MIC_DIVIDER 27B2<
MIC_GAINED 27B1<>
MIC_GALVA 27B2<
MIC_HIGH 26A5<> 27B3<
MIC_IN 25C4< 27B1<
MIC_LOW 26A5<> 27B3<>
MIC_POLA 27C3<
MIC_STAR_GND 26B3<> 27B2<> 43B4<>
MODEM_HOOK_PU 16C4<> 16B5<
MODEM_USB_DM 32A3<> 42B2<> 16B1<
MODEM_USB_DP 32B3<> 42B2<> 16B1<
MPIC_CLK 10C2<> 16B4> 41C5<>
MPIC_CPU_INT_L 16B4> 13B2< 13B3<
MPIC_DATA_L 10C2<> 41C5<> 16B4<
MPIC_SYNC_L 10C2<> 16B4>
NEC_AVDD 43D1<> 17D6<
NEC_AVSS 43D1<> 17A5< 17B4< 17D7<
NEC_CRUN_L 17A7<>
NEC_IDSEL 17B7<

NEC_NANDTEST_TP 17A5<
NEC_OCI<4..3> 17B5< 30C8<
NEC_OCI_UF<4..3> 30C6<>
NEC_OCI_UNUSED 17B5<
NEC_PCI_GNT_L 9C5> 17B7<
NEC_PCI_INT_L 16B4<> 17B7> 16B5<
NEC_PCI_REQ_L 17B7> 9C2< 9D5<
NEC_PME_L 17A7<>
NEC_PPON1_TP 17B5>
NEC_PPON2_TP 17B5>
NEC_PPON5_TP 17B5>
NEC_PPON<4..3> 17B5> 30C8<
NEC_RREF 17B5<>
NEC_RSDCM 17C5<> 42B2<>
NEC_RSDCP 17C5<> 42B2<>
NEC_RSDDM 17C5<> 42B2<>
NEC_RSDDP 17C5<> 42B2<>
NEC_SMI_L_SPN 17A7>
NEC_USB_DCM 17C3<> 42B2<> 30C8<
NEC_USB_DCP 17C3<> 42B2<> 30B8<
NEC_USB_DDM 17C3<> 42A2<> 30A8<
NEC_USB_DDP 17C3<> 42A2<> 30A8<
NEC_XT1 17D5<
NEC_XT2 17D5<>
NEC_XT2_R 17D4<
NUMLOCK_LED 33D5<
NUMLOCK_LED_L 33D5< 34C7<
PBUS_DIV 35C6<
PBUS_DIV1 36B2<
PCI_ACK64_L 9B5< 9B7<
PCI_AD<63..0> 9A4<> 9B4<> 9C4<> 9D4<> 16B8<>

16C8<> 16D8<> 17B7<> 17C7<> 17C8<>
17D7<> 18B7<> 18C7<> 23C1<> 40A5<>
9A7< 9B7< 9C7< 9D7< 23B2< 23C2<

PCI_CBE<7..0> 9B5> 9C5> 16B8<> 17B7<> 18B7<>

40A5<> 9A7< 9B7< 9C7<

PCI_DEVSEL_L 9C5<> 16B8<> 17B7<> 18B7<> 40A5<>

9D2<

PCI_FRAME_L 9C5<> 16B8<> 17B7<> 18B7<> 40A5<>

9D2<

PCI_IRDY_L 9C5<> 16B8<> 17B7<> 18B7<> 40A5<>

9D2<
PCI_PAR 9C5<> 16B8<> 17B7<> 18B7<> 40A5<>
PCI_PAR64 40A5<> 9B5< 9B7<
PCI_PERR_L 17B7<> 18B7<> 18D7<
PCI_REQ64_L 9B5< 9B7<
PCI_SERR_L 17B7> 18B7> 18D7<
PCI_STOP_L 9C5<> 16B8<> 17B7<> 18B7<> 40A5<>

9D2<
PCI_TRDY_L 9C5<> 16B8<> 17B7<> 18B7<> 40A5<>

9D2<
PLL_AVDD 43C4<> 23C5<
PLL_SDRAM_CPU1 43C4<> 23C7<
PLL_STOP_L 12C7<>
PLL_VCC_CPU0 43C4<> 23C5<
PMU_ACK_L 34C4<> 16A2<
PMU_AC_DET 34B4<>
PMU_AC_DET_UF 34B3< 36A8<
PMU_AC_IN 34B4<>
PMU_BACKUP_SELECT_SPN 34C6<>
PMU_BATT0_DET_L 34B4<>
PMU_BATT1_DET_L_PU 34B4<> 34C2<
PMU_BATT_DET_L 34B3< 34D2< 35B7<
PMU_BYTE 34B6< 34C7<
PMU_CAPSLOCK_LED_L 34C6<>
PMU_CHARGE_V 34C4<> 36A3<
PMU_CHRG_BATT_0 34C4<> 35A3<>
PMU_CHRG_EN_L 35C2<>
PMU_CLK 34C4<> 16A2<
PMU_CNVSS 34B6< 34C7<
PMU_EPM 34D4<> 34D2<
PMU_FROM_KL 16B2<> 34C4<>
PMU_I2C_CLK 34B4<> 23B6< 34C2<
PMU_I2C_DATA 34B4<> 23B6< 34C2<
PMU_INT_L 16C4<> 34B6<> 16B5<
PMU_KL_NMI 16B4<> 34D4<> 16C5<
PMU_LID_CLOSED_L 34C4<> 33D5< 34B2<
PMU_NMI_BUTTON_L 34C4<> 34D2<
PMU_NMI_L 34C4<> 34D2<
PMU_NUMLOCK_LED_L 34C6<>
PMU_OOPS 34B4<> 34B2<
PMU_PME_L 10B2> 16B4> 34C4<> 17A8< 34B2<
PMU_POWERUP_OK 34B4<> 34D2<
PMU_POWER_UP_L 34C6<> 34D7< 37D8<
PMU_REQ_L 16A2> 34C4<> 16C5<
PMU_RESET_BUTTON_L 34C4<> 34D2<
PMU_RESET_L 34B6<
PMU_RESET_L_SW 34B7<> 39A4<>
PMU_RESET_UF_L 34B7<
PMU_SLEEP_LED_L 33A5<> 34C4<>
PMU_SMB_CLK 34B4<> 34C2< 35B7<
PMU_SMB_DATA 34B4<> 34C2< 35B7<
PMU_TEMP 34B4<> 24C6< 34B2<
PMU_TEMP_F 24C7<>
PMU_TO_KL 16B2<> 34C4<>
POWER_VALID 34C4<> 34B2<
PS_BST_3V 37C6<
PS_BST_5V 37C6<
PS_CS_3V 43C6<> 37C6<
PS_CS_5V 37C6<
PS_FB_3V 37C6<>
PS_FB_5V 37C6<>
PS_LX_3V 37B5<> 43C6<>
PS_LX_5V 37D5<> 43C6<>
PS_NGATE_3V 37C6<>
PS_NGATE_5V 37C6<>
PS_PGATE_3V 37C6<>
PS_PGATE_5V 37C6<>
PS_REF 37C7<
PS_SS_3V 37C7<
PS_SS_5V 37C7<
PS_SYNC 37C7<
PS_TEMP 24C8<> 24A7<
PS_VL 43C6<> 37D7<
PWR3V_STAR_GND 26A3<> 43B4<> 25A4< 25C5< 25C7<

25D4<
PWR4V_STAR_GND 26A3<> 43B4<> 27A4< 27B4< 27C1<

27D4<
PWRBUS_14_24V 29D6<> 36C7<> 43D6<> 36D5<
PWR_STABLE_DELAY 36B1<>
RAD<12..0> 7C6> 7D6> 40C5<> 7B5< 7C5<
RAM_CKE0 7B6> 40B5<> 7B5<
RAM_CKE1 7B6> 40B5<> 7B5<
RAM_CKE2 7B6> 40B5<> 7B5<
RAM_CKE3 7B6> 40B5<> 7B5<
RAS_CS0_L 7C6> 40C5<> 7C5<
RAS_CS1_L 7C6> 40C5<> 7C5<
RAS_CS2_L 7C6> 40C5<> 7C5<
RAS_CS3_L 7C6> 40C5<> 7C5<
RCH_GALVA 27C5<
RCH_HZ 27C6<
RJ45_C0_PD 28C2<>
RJ45_C1_PD 28C2<>
RJ45_C2_PD 28B2<>
RJ45_C3_PD 28B2<>
RJ45_DN<3..0> 28B2<> 28C2<> 42D2<>
RJ45_DP<3..0> 28B2<> 28C2<> 42D2<>
ROM_CS_L 7B6< 23B2<
ROM_OE_L 7A6< 23B2<
ROM_RW_L 7A6< 23B2<
ROM_WP_L 23B2<
RUN/SS 35D1< 36C5<
R_SPKR_NEG 26A6<>
R_SPKR_POS 26A6<>
SCREAMER_OUT_CL_F 26B7<
SCREAMER_OUT_CR_F 26A7<
SDCAS_L 7C6> 40B5<> 7B5<
SDRAS_L 7C6> 40B5<> 7B5<
SLEEP 34B6<> 37C8<> 34D7< 37B3< 38B3<

38C3<
SLEEP_LED 33A4<>
SLEEP_LED_I 33B3<
SLEEP_LED_L 33B4<
SLEEP_LED_SW 33B5<>
SLEEP_LED_SW_L 33B5<>
SLEEP_LED_UF 33B3<
SLEEP_LS5 37D3<>
SLEEP_LS5_EN_L 37B2<>
SLEEP_L_LS5 28A8<> 37B2<> 39C7<>
SLEEP_L_LS5_EN_L 37B3<>
SNDOUT0_FB 25C3<
SND_AMP_MUTE_L 16C4<> 26A8<
SND_CLKOUT 40C1<> 16A1< 25B4<
SND_HP_MUTE_L 16C4<> 26C8<
SND_HP_SENSE 16B4<> 26D5<
SND_LIN_SENSE 16B4<> 27B6<
SND_SCLK 25B2<> 16B1<
SND_SYNC 25B2<> 16B1<

SND_TO_AUDIO 16B1< 25C4<
SND_TO_KL 16B2< 25C2<
SOFT_PWR_ON_L 34C6<> 39A4<> 33A6< 33B2< 34D7<
SPKR_STAR_GND 26B3<> 43B4<> 26A8<
SPO_ESD_F 33B2<>
SUDO_GND 27C5<>
SUDO_L 27D4<>
SUDO_L_M 27D5<
SUDO_L_P 27D5<
SUDO_R 27C4<>
SUDO_R_M 27C5<
SUDO_R_P 27C5<
SYSCLK_CPU 40D1<> 13C3< 23C3<
SYSCLK_CPU_UF 40D1<> 23B5<
SYSCLK_DIMM0_A 7C3<> 40D1<> 23C3<
SYSCLK_DIMM0_A_UF 40D1<> 23B5<
SYSCLK_DIMM0_B 7B2<> 40D1<> 23C3<
SYSCLK_DIMM0_B_UF 40D1<> 23B5<
SYSCLK_DIMM1_A 7C3<> 40D1<> 23C3<
SYSCLK_DIMM1_A_UF 40D1<> 23B5<
SYSCLK_DIMM1_B 7B2<> 40D1<> 23C3<
SYSCLK_DIMM1_B_UF 40D1<> 23B5<
SYSCLK_UNIN 40D1<> 6D7< 23C3<
SYSCLK_UNIN_RDCLK 7B6> 40D1<> 23C3<
SYSCLK_UNIN_RDCLK_UF 40D1<> 23B5<
SYSCLK_UNIN_UF 40D1<> 23B5<
SYSTEM_CLK_EN 34C4<> 19C4< 23B6<
TAS_SNDOUT0 25C2<>
TI_AVSS 26B3<> 43B4<> 25A4<
TI_CAP 25B4<
TI_CAP_PLL 25B4<
TI_VCOM 25B3<>
TI_VRFILT 25B3<>
TMDS_CLKN 20B6> 31D6<> 42C2<> 20D4<
TMDS_CLKN_F 31C5<> 31D5<> 31D7<
TMDS_CLKP 20B6> 31D6<> 42C2<> 20D3<
TMDS_CLKP_F 31C5<> 31D5<> 31D6<
TMDS_CLK_CMT 20D4<
TMDS_DN<2..0> 20B6> 31D4<> 31D5<> 42C2<> 20D7<

31D7<

TMDS_DP<2..0> 20B6> 31D4<> 31D5<> 42C2<> 20D6<

31D6<
TPAD_F_RXD 33C7<>
TPAD_F_TXD 33D7<>
TPAD_GND 33C6<> 43A6<>
TPAD_RXD 34C4<> 33C8< 34B2<
TPAD_TXD 34C4<> 33D8< 34B2<
TPS2211_SHDN_L_PU 18D5<
TV_C 31B1<>
TV_COMP 31B1<>
TV_GND1 31B1<> 43A6<>
TV_GND2 31A1<> 43A6<>
TV_Y 31B1<>
T_FILTR_OUT_L 26C3<
T_FILTR_OUT_R 26C3<
T_FILTR_RL 26C3<
UATA_DET_PD 16C4<> 16B5<
UIDE_ADDR<2..0> 16A6> 42B5<> 32D4<
UIDE_CS1FX_L 16A6> 42B5<> 32D4<
UIDE_CS3FX_L 16A6> 42B5<> 32C4<
UIDE_DATA<15..0> 16A6<> 16B6<> 42B5<> 42C5<> 32D4<
UIDE_DIOR_L 16A6> 42B5<> 32C4<
UIDE_DIOW_L 16A6> 42B5<> 32C4<
UIDE_DMACK_L 16A6> 42B5<> 32C4<
UIDE_DMARQ 42B5<> 16A6<
UIDE_INTRQ 42B5<> 16A6<
UIDE_IOCHRDY 42B5<> 16A6<
UIDE_RST_L 16A6> 42B5<> 32C4<
UNIN_AGP_VREF 8A5< 19B7<
UNIN_AGP_VREF_H 19C7<
UNIN_AGP_VREF_L 19B7<
UNIN_BR_1_L_PU 6B2< 6C7<
UNIN_DRDY_1_L_PU 6A3< 6B2<
UNIN_HIT_1_L_PU 6A7< 6B2<
UNIN_I2C_CLK0 7A2<> 10B6<> 24B4<> 24B6<> 10D7<
UNIN_I2C_CLK1 7A2<> 10A6<> 24C7<> 24D6<> 10D7<
UNIN_I2C_DATA0 7A3<> 10B6<> 24B4<> 24B6<> 10D7<
UNIN_I2C_DATA1 7A3<> 10A6<> 24C7<> 24D6<> 10D7<
UNIN_JTAG_TEI 10A7< 10B6<
UNIN_MAXBUS_REF 6A7< 12A3<
UNIN_PU_RESET_L 34C4<> 10C2< 34A2<
UNIN_QREQ_1_L_PD 6A7< 6B2<
UNIN_RESET_L 34D4<> 10C2< 23B2< 34A2<
UNIN_SPARE_AB6 6A7<
UNIN_SUSPEND_ACK_L 6A7> 34B6<>
UNIN_SUSPEND_REQ_L 34B6<> 6A7< 34C7<
UNI_AGP_PME_L_PD 8B2< 8B7<
UNI_AGP_TYPEDET_PD 8B2< 8B7<
UNI_PCI_GNT2_L_SPN 9C5>
UNI_PCI_GNT3_L_SPN 9C5>
UNI_PCI_GNT4_L_SPN 9C5>
UNI_PCI_REQ_L_PU 9C2< 9C5<
UNI_ROM_CS_L 7A7<>
UNI_ROM_OE_L 7A7<>
UNI_ROM_RW_L 7A7<>
USB_D1M 30B7<> 42B2<>
USB_D1M_EMI 30B5<> 42B2<>
USB_D1P 30B7<> 42B2<>
USB_D1P_EMI 30B5<> 42B2<>
USB_D2M 30B7<> 42B2<>
USB_D2M_EMI 30B5<> 42B2<>
USB_D2P 30B7<> 42B2<>
USB_D2P_EMI 30B5<> 42B2<>
USB_DAM 16C2<> 42C2<> 30B8<
USB_DAP 16C2<> 42B2<> 30B8<
USB_DBM 16C3<> 42B2<>
USB_DBP 16C3<> 42B2<>
USB_DCM 16B2<> 42B2<> 30B8<
USB_DCP 16B2<> 42B2<> 30B8<
USB_DDM 16B3<> 42B2<>
USB_DDP 16B3<> 42B2<>
USB_OC_AB_L 16C2< 16D1<
USB_OC_CD_L 16B2< 16D1<
USB_PWREN_AB_L 16C2> 16D1<
USB_PWREN_CD_L 16B2> 16D1<
USB_SW_ENABLE 30D6<
USB_SW_ENABLE_L 30D5<>
VCORE_BOOST 39C4<> 43B6<>
VCORE_BST 39C5<>
VCORE_CC 39B6<> 43B6<>
VCORE_D0 39A3<> 39B6<
VCORE_D1 39A3<> 39B6<
VCORE_D2 39A3<> 39B6<
VCORE_D3 39A3<> 39B6<
VCORE_D4 39A3<> 39B6<
VCORE_DH 39B5<> 43B6<>
VCORE_DL 39B5<> 43B6<>
VCORE_FB 43B6<> 39B5<
VCORE_GND 39B5<> 43B6<>
VCORE_GNDA 39B6<>
VCORE_GNDDIV 43B6<> 39A5< 39B5<
VCORE_GNDDIV_TEST 39A4<>
VCORE_GNDSNS 39A1<> 43B6<> 39A5<
VCORE_GNDSNS_TEST 39A4<>
VCORE_ILIM 39C6<> 43B6<>
VCORE_LX 39B5<> 43B6<>
VCORE_REF 39B6<> 43B6<>
VCORE_SHDN_L 39C6<>
VCORE_SNS 39A1<> 43B6<>
VCORE_TIME 39B4<> 43B6<>
VCORE_TON 43B6<> 39B6<
VCORE_VCC 43B6<> 39C6<
VCORE_VGATE 39B4<> 43B6<>
VCORE_VPLUS 39C5<>
VCORE_VSENSE 39B3<>
VGA_B 31C5<> 31C6<
VGA_G 31C4<> 31C6<
VGA_HSYNC 31C5<> 20C8<
VGA_R 31C4<> 31C6<
VGA_VSYNC 31C4<> 20D8<
VREFM 25B4<
VREFP 25B4<
ZENER_GTR_THAN_18V 35A4<> 36B8<>
_VCHRG 36B3<

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

45 46

E

051-6403

47

*** Unit Cross-Reference ***

--- for the entire design --

BS1 MTGHOLE 5B3
BS3 MTGHOLE 5B2
BS5 MTGHOLE 5B2
C1 CAP 31A8
C2 CAP 31B5
C3 CAP 31C7
C4 CAP 31C7
C5 CAP 31C7
C6 CAP 31B5
C7 CAP 26A8
C8 CAP 26A6
C9 CAP 38C7
C10 CAP_P 30C5
C11 CAP_P 30C5
C12 CAP 38C6
C13 CAP_P 36D3
C14 CAP 26D6
C15 CAP 26D6
C16 CAP 38C8
C17 CAP 15A5
C18 CAP 15B1
C19 CAP 27B7
C20 CAP_P 20A3
C21 CAP_P 20A3
C22 CAP 36D5
C23 CAP 27B3
C24 CAP 38B7
C25 CAP 35D6
C26 CAP 33B6
C27 CAP 38A6
C28 CAP 29B6
C29 CAP 29C5
C30 CAP 24C8
C31 CAP 24C8
C32 CAP 38B7
C33 CAP 38A7
C34 CAP 38B7
C35 CAP 28D4
C36 CAP_P 36D2
C37 CAP_P 36C3
C38 CAP 37A5
C39 CAP 24D8
C40 CAP 15B3
C41 CAP 37A5
C42 CAP 24C8
C43 CAP_P 26C5
C44 CAP 15B4
C45 CAP 38C3
C46 CAP 37A4
C47 CAP 37A5
C48 CAP 38C3
C49 CAP 36C4
C50 CAP 14B2
C51 CAP 15A8
C52 CAP_P 20A6
C53 CAP 15A7
C54 CAP 24B5
C55 CAP 24B5
C56 CAP 38B2
C57 CAP 38B3
C58 CAP_P 37B4
C59 CAP 31A6
C60 CAP 15A7
C61 CAP 36B5
C62 CAP_P 37B3
C63 CAP_P 36B4
C64 CAP 35B3
C65 CAP 36B6
C66 CAP_P 39B1
C67 CAP 37D2
C68 CAP 37D2
C69 CAP_P 39B2
C70 CAP_P 39B1
C71 CAP_P 39B2
C72 CAP_P 39B1
C73 CAP 23C7
C74 CAP 23C6
C75 CAP 23C6
C76 CAP 23C7
C77 CAP 23C7
C78 CAP 23C8
C79 CAP 23C7
C80 CAP_P 37D2
C81 CAP_P 37C2
C82 CAP 39B4
C83 CAP 24D5
C84 CAP 24C5
C85 CAP 36B3
C86 CAP 23C1
C87 CAP 18B2
C88 CAP 18C2
C89 CAP 23C1
C90 CAP 23C2
C91 CAP 23C5
C92 CAP 23C6
C93 CAP 23C7
C94 CAP 23C5
C95 CAP 23C5
C96 CAP 23C6
C97 CAP 23C6
C98 CAP 23C6
C99 CAP 23C7
C100 CAP 23C1
C101 CAP_P 37C4
C102 CAP 36B3
C103 CAP 18D5
C104 CAP 18D7
C105 CAP 18D7
C106 CAP 18D6
C107 CAP 18D5
C108 CAP 18D6
C109 CAP 23C2
C110 CAP 17B3
C111 CAP 17B3
C112 CAP 17B3
C113 CAP 25C6
C114 CAP 18B3
C115 CAP 18B2
C116 CAP 18B3
C117 CAP 18D7
C118 CAP 18D6
C119 CAP 25B5
C120 CAP 25B4
C121 CAP 18D6
C122 CAP 17B3
C123 CAP 17B3
C124 CAP_P 36B2
C125 CAP 18D5
C126 CAP 16D2
C127 CAP 17B2
C128 CAP 17D6
C129 CAP 18D6
C130 CAP 17D6
C131 CAP 16D4
C132 CAP 16D5
C133 CAP 16D4
C134 CAP 16D4
C135 CAP 17B2
C136 CAP 17B2
C137 CAP 18D6
C138 CAP 18D5
C139 CAP 16D2
C140 CAP 17B2
C141 CAP 17B2
C142 CAP 18D7
C143 CAP 16D2
C144 CAP 16D5
C145 CAP 25B4
C146 CAP 17B2
C147 CAP 18A2
C148 CAP 18D5
C149 CAP 16D3
C150 CAP 16D4
C151 CAP 25D4
C152 CAP 18D5
C153 CAP 16D3
C154 CAP 16D7
C155 CAP 16C2
C156 CAP 17D4
C157 CAP 17D5
C158 CAP 16A6
C159 CAP 31B2
C160 CAP 31A2
C161 CAP 31B2
C162 CAP 31B2

C163 CAP 31C4
C164 CAP 30B4
C165 CAP 30B5
C166 CAP 30B5
C167 CAP 30B4
C168 CAP 30B4
C169 CAP 30B5
C170 CAP 30A5
C171 CAP 30B4
C172 CAP 31B2
C173 CAP 26C3
C174 CAP 29B2
C175 CAP 28B2
C176 CAP 31B3
C177 CAP 31B3
C178 CAP 31B3
C179 CAP 21A5
C180 CAP 21A6
C181 CAP 34B7
C182 CAP 26C2
C183 CAP 26C3
C184 CAP 35D5
C185 CAP 35D3
C186 CAP 29B2
C187 CAP 14B2
C188 CAP 31C3
C189 CAP 31C4
C190 CAP 35C4
C191 CAP 30D5
C192 CAP 31C6
C193 CAP 31C6
C194 CAP 31C6
C195 CAP 21A6
C196 CAP 21A5
C197 CAP 22D7
C198 CAP 22D7
C199 CAP 22D6
C200 CAP 22D7
C201 CAP 26C3
C202 CAP 36C8
C203 CAP 29D7
C204 CAP 30D5
C205 CAP 21C3
C206 CAP 21A6
C207 CAP 38C6
C208 CAP 21C1
C209 CAP 21B5
C210 CAP 21B5
C211 CAP 21B6
C212 CAP 21B5
C213 CAP 19A7
C214 CAP 21B6
C215 CAP 22D7
C216 CAP 35C7
C217 CAP 38D7
C218 CAP 38D7
C219 CAP 14A2
C220 CAP 14B2
C221 CAP 20C4
C222 CAP 22D7
C223 CAP 31A5
C224 CAP 31A5
C225 CAP 31B7
C226 CAP 38C7
C227 CAP_P 38B5
C228 CAP 38A7
C229 CAP 11B3
C230 CAP 21B5
C231 CAP 21C2
C232 CAP 21B6
C233 CAP 20B4
C234 CAP 21C2
C235 CAP 21C2
C236 CAP 20B4
C237 CAP 21C2
C238 CAP 21C2
C239 CAP 20C3
C240 CAP 21B3
C241 CAP 22D7
C242 CAP_P 26C5
C243 CAP 11C5
C244 CAP 11C7
C245 CAP 11B2
C246 CAP 11B3
C247 CAP 11B3
C248 CAP 20B2
C249 CAP 22D6
C250 CAP 22D6
C251 CAP 22D6
C252 CAP 38A6
C253 CAP 24C1
C254 CAP 11C7
C255 CAP 11B3
C256 CAP 20B3
C257 CAP 20C3
C258 CAP 20C3
C259 CAP 33A4
C260 CAP 29B3
C261 CAP 29C6
C262 CAP 15B2
C263 CAP 15A6
C264 CAP 11C6
C265 CAP 11C2
C266 CAP 11C3
C267 CAP 19C8
C268 CAP 19B8
C269 CAP 20B4
C270 CAP 20C4
C271 CAP 20B4
C272 CAP 21B7
C273 CAP 20A3
C274 CAP 20A3
C275 CAP 15A3
C276 CAP 15A7
C277 CAP 15A3
C278 CAP 30C8
C279 CAP 30C7
C280 CAP 15A3
C281 CAP 39C1
C282 CAP 39D2
C283 CAP 39C2
C284 CAP 13D5
C285 CAP 39C2
C286 CAP 39C2
C287 CAP 11C8
C288 CAP 11C7
C289 CAP 11C7
C290 CAP 11B3
C291 CAP 11B4
C292 CAP 21B6
C293 CAP 21B2
C294 CAP_P 26C5
C295 CAP 13D4
C296 CAP 11B3
C297 CAP 11B3
C298 CAP 11B2
C299 CAP 11C3
C300 CAP 20C3
C301 CAP 21C6
C302 CAP 21C6
C303 CAP 21C1
C304 CAP 21C3
C305 CAP 14B2
C306 CAP 14A2
C307 CAP 36C2
C308 CAP 36C2
C309 CAP 29B4
C310 CAP 29B4
C311 CAP 29B3
C312 CAP 29B3
C313 CAP 29C4
C314 CAP 15A3
C315 CAP 13D4
C316 CAP 11C7
C317 CAP 11C4
C318 CAP 11B3
C319 CAP 21C6
C320 CAP 20C3
C321 CAP 14B2
C322 CAP 14B2
C323 CAP 28C2
C324 CAP 28C1
C325 CAP 28C2
C326 CAP 28C2
C327 CAP 15A6
C328 CAP 11C6
C329 CAP 11C7
C330 CAP 11C7

C331 CAP 11C6
C332 CAP 11B2
C333 CAP 11C3
C334 CAP 11B2
C335 CAP 20C3
C336 CAP 21C2
C337 CAP 22D3
C338 CAP 22D3
C339 CAP 22D2
C340 CAP 22D2
C341 CAP 35D5
C342 CAP 36C7
C343 CAP 36C6
C344 CAP 29C3
C345 CAP 29C3
C346 CAP 15A4
C347 CAP 13D5
C348 CAP 11B2
C349 CAP 11B3
C350 CAP 11B4
C351 CAP 21C6
C352 CAP 20C4
C353 CAP 29C4
C354 CAP 29C5
C355 CAP 29B3
C356 CAP 28C7
C357 CAP 28C8
C358 CAP 13D6
C359 CAP 11C7
C360 CAP 11C6
C361 CAP 21C6
C362 CAP 21C6
C363 CAP 21A6
C364 CAP 20B3
C365 CAP 22D3
C366 CAP 14A2
C367 CAP 14B1
C368 CAP 26B6
C369 CAP 26B6
C370 CAP 37A6
C371 CAP 36C2
C372 CAP 36C3
C373 CAP 29C4
C374 CAP 28D4
C375 CAP 28C7
C376 CAP 28C7
C377 CAP 28D7
C378 CAP 11C6
C379 CAP 11C7
C380 CAP 11B2
C381 CAP 21C6
C382 CAP 20B4
C383 CAP 22D3
C384 CAP 14B1
C385 CAP 14A1
C386 CAP 26B6
C387 CAP 29C4
C388 CAP 29C3
C389 CAP 29C4
C390 CAP 28D8
C391 CAP 28C7
C392 CAP 28D6
C393 CAP 15B7
C394 CAP 13D5
C395 CAP 11D4
C396 CAP 11B3
C397 CAP 20B3
C398 CAP 20B4
C399 CAP 20C3
C400 CAP 22D3
C401 CAP 36B4
C402 CAP 26B8
C403 CAP 29C4
C404 CAP 29C6
C405 CAP 39C2
C406 CAP 11C7
C407 CAP 11C6
C408 CAP 11C7
C409 CAP 11C8
C410 CAP 11D4
C411 CAP 11D8
C412 CAP 21C5
C413 CAP 20D4
C414 CAP_P 20D4
C415 CAP 20C3
C416 CAP 26A7
C417 CAP 36C2
C418 CAP 36C3
C419 CAP 28D7
C420 CAP 28C8
C421 CAP 28D7
C422 CAP 28D8
C423 CAP 28D3
C424 CAP 15A7
C425 CAP 11C6
C426 CAP 20B3
C427 CAP 20C4
C428 CAP 20B3
C429 CAP 22D3
C430 CAP 22D3
C431 CAP 22D3
C432 CAP 20A5
C433 CAP 36A7
C435 CAP 26D7
C436 CAP 28D3
C437 CAP 28C8
C438 CAP 28D3
C439 CAP 15A4
C440 CAP 15A8
C441 CAP 13D8
C442 CAP 13D7
C443 CAP 13D7
C444 CAP 13D6
C445 CAP 13D6
C446 CAP 13D5
C447 CAP 11C7
C448 CAP 11C5
C449 CAP 11D7
C450 CAP 11D7
C451 CAP 11D6
C452 CAP 11D6
C453 CAP 11D6
C454 CAP 11D5
C455 CAP 11D8
C456 CAP 11B2
C457 CAP 11B2
C458 CAP 21C5
C459 CAP 21D5
C460 CAP 20B4
C465 CAP 26C7
C466 CAP 26C7
C467 CAP 28D3
C468 CAP 28D3
C469 CAP 28D4
C470 CAP 21D7
C471 CAP 21D6
C472 CAP 21D5
C473 CAP 20C4
C474 CAP 20C4
C475 CAP 21A6
C476 CAP 21A5
C477 CAP 20B3
C478 CAP 20B3
C479 CAP 21B2
C480 CAP 21B2
C481 CAP 20A6
C482 CAP_P 38C5
C483 CAP 36C2
C484 CAP 36C2
C485 CAP 28D4
C486 CAP 28D7
C487 CAP 28D7
C488 CAP 28D7
C489 CAP 15A3
C490 CAP 13D7
C491 CAP 13D6
C492 CAP 13D6
C493 CAP 13D7
C494 CAP 11C6
C495 CAP 11C6
C496 CAP 11C6
C497 CAP 11C8
C498 CAP 11D8
C499 CAP 11D6
C500 CAP 11D6
C501 CAP 11D5
C502 CAP 11D7
C503 CAP 11D7

C504 CAP 11D6
C505 CAP 11B8
C506 CAP 11A5
C507 CAP 11B5
C508 CAP 11B6
C509 CAP 11A6
C510 CAP 11A7
C511 CAP 21C8
C512 CAP 20A7
C515 CAP 26C6
C517 CAP 36D6
C518 CAP 28D6
C519 CAP 21C6
C520 CAP 21D8
C521 CAP 21B3
C522 CAP 21B2
C523 CAP 21B2
C524 CAP 20B4
C525 CAP 21D7
C526 CAP 20A6
C528 CAP_P 37B4
C529 CAP 37A3
C530 CAP 28A6
C531 CAP 28D7
C532 CAP 15A7
C533 CAP 15A4
C534 CAP 39C1
C535 CAP 13D7
C536 CAP 13D7
C537 CAP 13D6
C538 CAP 13D7
C539 CAP 13D6
C540 CAP 11C6
C541 CAP 11C6
C542 CAP 11D5
C543 CAP 11D5
C544 CAP 11D6
C545 CAP 11D5
C546 CAP 11D6
C547 CAP 11D5
C548 CAP 11B3
C549 CAP 11B3
C550 CAP 11A8
C551 CAP 21D5
C552 CAP 21D6
C553 CAP 21C8
C554 CAP 21A5
C556 CAP 15A4
C557 CAP 11C6
C558 CAP 11B8
C559 CAP 11A6
C560 CAP 11A7
C561 CAP 11A5
C562 CAP 21C8
C563 CAP 21D5
C564 CAP 21D6
C565 CAP 20A7
C566 CAP 20A5
C567 CAP 20A5
C568 CAP_P 38D5
C569 CAP 36B6
C570 CAP 28A6
C571 CAP 15B4
C572 CAP 13D7
C573 CAP 13D8
C574 CAP 39C2
C575 CAP 11C7
C576 CAP 11C2
C577 CAP 11C2
C578 CAP 11C2
C579 CAP 11D4
C580 CAP 11D8
C581 CAP 11D4
C582 CAP 11A6
C583 CAP 21C7
C584 CAP 21D8
C585 CAP 21D6
C586 CAP 20A5
C587 CAP 20A6
C589 CAP 26D7
C590 CAP 26C7
C593 CAP 13D5
C594 CAP 11B6
C595 CAP 8C3
C596 CAP 34D6
C597 CAP 36B5
C598 CAP_P 37B3
C599 CAP 15B7
C600 CAP 39C1
C601 CAP 13D5
C602 CAP 13D6
C603 CAP 13D5
C604 CAP 39D2
C605 CAP 11C7
C606 CAP 11C7
C607 CAP 6D5
C608 CAP 8D6
C609 CAP 11B2
C610 CAP 11C3
C611 CAP 11A6
C612 CAP 11A7
C613 CAP 11B6
C614 CAP 21D7
C615 CAP 35A2
C616 CAP 15A7
C617 CAP 15A3
C618 CAP 39C1
C619 CAP 11D4
C620 CAP 11D2
C621 CAP 15A3
C622 CAP 13D6
C623 CAP 11C6
C624 CAP 11D2
C625 CAP 11D2
C626 CAP 11C4
C627 CAP 11D2
C628 CAP 11C3
C629 CAP 34D6
C630 CAP 15B3
C631 CAP 13D5
C632 CAP 13D5
C633 CAP 39D2
C634 CAP 11C6
C635 CAP 11C5
C636 CAP 11C7
C637 CAP 6D6
C638 CAP 6D5
C639 CAP 11D3
C640 CAP 11C3
C641 CAP 11C2
C642 CAP 11C3
C643 CAP 11B6
C644 CAP 11B5
C645 CAP 8B3
C646 CAP_P 37B4
C647 CAP 39C2
C648 CAP 11D1
C649 CAP 11D3
C650 CAP 11C2
C651 CAP 11C2
C652 CAP 11D3
C653 CAP 11C1
C654 CAP 8D6
C655 CAP 11A7
C656 CAP 11B7
C657 CAP 8D6
C658 CAP 37D6
C659 CAP 37D6
C660 CAP 37C4
C661 CAP 11C8
C662 CAP 6D6
C663 CAP 11D4
C664 CAP 11D1
C665 CAP 11C3
C666 CAP 11D2
C667 CAP 11A8
C668 CAP 37C6
C669 CAP 37D5
C670 CAP 37A2
C671 CAP 15B3
C672 CAP 15A6
C673 CAP 15A3
C674 CAP 15A3
C675 CAP 15A4
C676 CAP 15A4
C677 CAP 11D3
C678 CAP 11D3
C679 CAP 11C3

C680 CAP 11C1
C681 CAP 11D3
C682 CAP 11D3
C683 CAP 11D3
C684 CAP 11B7
C685 CAP 11B7
C686 CAP 37B1
C687 CAP 15B1
C688 CAP 15B2
C689 CAP 15A5
C690 CAP 15A5
C691 CAP 39C3
C692 CAP 39C3
C693 CAP 39D1
C694 CAP 39D2
C695 CAP 39D2
C696 CAP 39D1
C697 CAP 39D1
C698 CAP 39D2
C699 CAP 39D1
C700 CAP 11D3
C701 CAP 11D2
C702 CAP 11D4
C703 CAP 11D2
C704 CAP 11D3
C705 CAP 8D5
C706 CAP 11B7
C707 CAP 20B7
C708 CAP 20B7
C709 CAP 31A6
C710 CAP_P 37B3
C711 CAP 11C6
C712 CAP 11C4
C713 CAP 11C3
C714 CAP 11D3
C715 CAP 11D2
C716 CAP 11C3
C717 CAP 11D2
C718 CAP 11C3
C719 CAP 31A6
C720 CAP 39C4
C721 CAP 39C3
C722 CAP 11D3
C723 CAP 31A6
C724 CAP 37C2
C725 CAP 39C3
C726 CAP 39D4
C727 CAP 23B7
C728 CAP 37C4
C729 CAP 37D5
C730 CAP 37C7
C731 CAP 35A6
C732 CAP 37C5
C733 CAP 37D5
C734 CAP 23B6
C735 CAP 36B1
C736 CAP 34D5
C737 CAP 39C3
C738 CAP 39D3
C739 CAP 37C7
C740 CAP 37C7
C741 CAP 39B7
C742 CAP 39C4
C743 CAP 16A4
C744 CAP 23C5
C745 CAP 39B4
C746 CAP 39C3
C747 CAP 39D3
C748 CAP 16A5
C749 CAP 36B1
C750 CAP 39B6
C751 CAP 32A4
C752 CAP 32A3
C753 CAP 34A6
C754 CAP 34A7
C755 CAP 39B6
C756 CAP 34B3
C757 CAP 34D5
C758 CAP_P 37C3
C759 CAP_P 37D3
C760 CAP_P 37D3
C761 CAP 39D3
C762 CAP 39C4
C763 CAP 16D4
C764 CAP 16D5
C765 CAP 32A3
C766 CAP 34B2
C767 CAP 37C7
C768 CAP 39B3
C769 CAP 39B3
C770 CAP 25C4
C771 CAP 32A2
C772 CAP 39C5
C773 CAP 39C5
C774 CAP 25D3
C775 CAP 17D6
C776 CAP 17D5
C777 CAP 25C3
C778 CAP 17B3
C779 CAP 18D3
C780 CAP 16D4
C781 CAP 16D5
C782 CAP 16C1
C783 CAP 16C2
C784 CAP 23B6
C785 CAP 33C7
C786 CAP 33C7
C787 CAP 33D7
C788 CAP 33C7
C789 CAP 33C6
C790 CAP 33D6
C796 CAP 27B5
C797 CAP 25C7
C798 CAP 25C5
C799 CAP 25B4
C800 CAP 7D2
C801 CAP 7C2
C802 CAP 7C2
C803 CAP 7B2
C804 CAP 7B2
C805 CAP 7A2
C806 CAP 35A7
C807 CAP 24B4
C808 CAP 24B4
C809 CAP 25C4
C810 CAP 25C4
C811 CAP 25B4
C812 CAP_P 25B2
C813 CAP 25B2
C814 CAP_P 25B2
C815 CAP 25B2
C835 CAP 27C7
C836 CAP 27C7
C837 CAP 27C7
C838 CAP 27D7
C839 CAP 27B6
C840 CAP 27D6
C841 CAP 27C6
C842 CAP 27C6
C843 CAP 27C5
C844 CAP 27D5
C845 CAP_P 27D4
C846 CAP 27D4
C847 CAP 27C4
C848 CAP 27D4
C849 CAP_P 27C3
C850 CAP 27C3
C851 CAP 27B3
C852 CAP 27B2
C853 CAP 27C2
C854 CAP 27C2
C855 CAP 27B1
C856 CAP 27C1
C857 CAP 26D4
C858 CAP 21C3
C859 CAP 21C2
C860 CAP 21C2
C861 CAP 21C2
C862 CAP 21C1
C863 CAP_P 39B2
C864 CAP 13D8
C865 CAP 13D7
C866 CAP 28C8
C867 CAP 28C8
C868 CAP 31C3
C869 CAP 35B4
C871 CAP 38D6
C872 CAP 38B6

C873 CAP 33A8
C874 CAP 36A4
C875 CAP 14D3
C876 CAP 14D2
C877 CAP 14D1
C878 CAP 13C3
C879 CAP 14C2
C880 CAP 14C2
C881 CAP 14C2
C882 CAP 14C1
C883 CAP 14C2
C884 CAP 14C2
C885 CAP 14C2
C886 CAP 14C1
C887 CAP 14B2
C888 CAP 14B2
C889 CAP 31D7
C890 CAP 36C5
C891 CAP 36B7
C892 CAP 20D4
C893 CAP 20D4
C894 CAP 24A1
D1 DIODE_SCHOT 29D6
D2 DIODE 35D3
D3 DIODE 37A4
D4 DIODE_SCHOT 36C4
D5 DIODE 36B3
D6 DIODE_SCHOT 37A4
D7 DIODE_SCHOT 37C4
D8 DIODE_SCHOT 35B6
D9 DIODE_SCHOT 37B5
D10 DIODE_SCHOT 39B3
D11 ZENER_MMBZ15VDLT1 26C2
D13 DIODE_SCHOT 37A7
D14 ZENER_MMBZ15VDLT1 33B2
D15 DIODE_SCHOT 37A7
D16 ZENER 36B7
D17 DIODE_SCHOT 24C2
D18 DIODE_SCHOT 37B6
D19 DIODE_SCHOT_3P 26C6
D20 DIODE 37D5
D21 DIODE 28A7
D22 DIODE 37D6
D23 DIODE_SCHOT 39C4
D24 DIODE_SCHOT 31D4
D25 DIODE_SCHOT 29D5
D26 DIODE 35B4
D27 DIODE_DUAL_6P 29A3 29B3
D28 DIODE_DUAL_6P 29A2 29B2
D29 DIODE_SCHOT 24B1
DP1 DPAK3P 38B8 38C8
DP2 DPAK3P 36A5 36B6 36D6
DP3 DPAK3P_SCHOT 35A2 35A3
DP4 DPAK3P 39C7 39D7
DP5 DPAK3P 35D2 36B1
F1 FUSE 36D4
F2 FUSE 29D5
F3 FUSE 31D5
FL1 FILTER_CHOKE_DUAL 29C2
G1 OSC 20B7
G2 OSC 16A4
J1 CON_F7RT_MINIDIN 31B1
J2 CON_RJ45_SHORT 28C1
J3 CON_4RT_WRIB 30C2
J4 CON_F30RT_T2MT_TH1 31D5
J5 CON_F4RT_USBKINK 30B3
J6 CON_F4RT_USBKINK 30B3
J7 CON_FWVERT_SKT 29C1
J8 CON_F4RT_SDOUT 26C2
J9 CON_M3SM_WRIB 24C1
J10 CON_2RTSM_125 33B1
J11 CON_M80STSM_55055 18C2
J12 CON_10STSM_5087 32B2
J13 CON_M3SM_WRIB 36D2
J14 CON_F30SM_LPS_J3_PCT 33D4
J15 CON_M6ST_BTRY 35B8
J16 CON_152SM_STCKSO 7D3
J17 CON_F20RTSM_20143 31B4
J18 CON_2RTSM_125 33A3
J19 CON_6RTSM_125 26B5
J20 CON_F8RT_S2MT_SM 35D7
J21 CON_10STSM_5087 31A6
J22 CON_12 39A4
J23 CON_F1ST_S2MT_SM 23B8
J24 CON_10STSM_5087 32B3
J25 CON_M70SM_5MM 32D5
J26 CON_M50SM_5MM 32B5
J27 CON_M50SM_5MM 32D2
J28 CON_10STSM_5087 33D7
J30 CON_F4RT_S2MT_TH1 27C8
J31 CON_M3SM_WRIB 24B1
L1 IND 30B5
L2 IND 30B5
L3 IND 30B5
L4 IND 30B5
L5 IND 38B6
L6 IND 20B3
L7 FILTER_4P 31D6
L9 IND 38D6
L10 IND 31B7
L11 IND 36C3
L12 IND 23C8
L13 IND 37B4
L14 IND_3P 37D4
L15 IND_3P 39C2
L16 IND 35B7
L17 IND 35B7
L18 IND 35B7
L19 IND 31B2
L20 IND 31B3
L21 IND 31B2
L22 IND 31C2
L23 IND 31B2
L24 IND 26C3
L25 IND 26C4
L26 IND 29D3
L27 IND 26D3
L28 IND 26C3
L30 FILTER_4P 30C5
L31 FILTER_4P 30A5
L32 IND 31D4
L33 IND 31C6
L34 IND 31C6
L35 IND 31C6
L36 IND 26C4
L37 IND 26C3
L38 IND 31C7
L39 IND 31C7
L40 IND 31C7
L41 IND 26C4
L42 IND 33B4
L43 IND 31B5
L44 IND 33B2
L48 IND 28D4
L49 IND 29D4
L50 IND 20A8
L51 IND 26C7
L52 IND 20B8
L53 IND 31A7
L54 IND 31A7
L55 IND 23C7
L56 IND 23D6
L57 IND 16A5
L58 IND 17A5
L59 IND 17D7
L60 IND 16C1
L61 IND 33C8
L62 IND 33D8
L63 IND 33D8
L64 IND 35B7
L65 IND 33C6
L66 IND 33D6
L67 IND 33D6
L76 IND 27C8
L77 IND 27C8
L78 IND 27D7
L79 IND 27D7
L80 IND 27C8
Q1 TRA_FDG6324L 31A7
Q2 TRA_NDS9407 29D7
Q3 TRA_2N7002 26A7
Q4 TRA_FDS6680 20A3
Q5 TRA_SI4435DY 20B4
Q6 TRA_SI4410DY 36C3
Q7 TRA_IRF7822 36B3
Q8 TRA_FDS6975 35B3
Q9 TRA_FDS6680 37C5
Q10 TRA_SI3443DV 37D2

Q11 TRA_SI3443DV 37C2
Q12 TRA_SI4435DY 35B6
Q13 TRA_FDS6612A 37D5
Q14 TRA_FDS6612A 37C5
Q15 TRA_IRF7805 39C4
Q16 TRA_FDS6680 37B5
Q17 TRA_SI4435DY 36C2
Q18 TRA_FDS6672A 39B4
Q19 TRA_FDS6672A 39B3
Q20 TRA_2N7002DW 33A5 33B4
Q21 TRA_2N7002DW 31C2 31D2
Q22 TRA_2N7002 29C7
Q23 TRA_SI3443DV 31B7
Q24 TRA_2N3906 33B4
Q25 TRA_SI3443DV 24D2
Q26 TRA_2N3904 33A7
Q27 TRA_2N7002 36B7
Q28 TRA_SI3443DV 24C2
Q29 TRA_2N7002 35C4
Q30 TRA_SI4435DY 35D4
Q31 TRA_FDG6324L 35C2
Q32 TRA_TP0610 33A8
Q33 TRA_2N7002 26C7
Q34 TRA_2N7002DW 28A7 28A8
Q35 TRA_2N7002DW 35A3
Q36 TRA_SI3443DV 37B2
Q37 TRA_2N3904 39D7
Q38 TRA_2N3904 39D7
Q39 TRA_2N7002DW 37B1 37B2
Q40 TRA_2N7002 36B3
Q41 TRA_2N3904 12C6
Q42 TRA_2N7002 12C7
Q43 TRA_2N7002 35A6
Q44 TRA_2N7002 36B2
Q45 TRA_2N7002DW 12C7
Q46 TRA_2N7002DW 37C7 37D7
Q47 TRA_FDG6324L 37A6 37A7
Q48 TRA_2N3906 33D4
Q49 TRA_2N3906 33D3
Q50 TRA_2N7002DW 31C2 33A7
Q51 TRA_IRF7805 39C3
Q52 TRA_2N7002DW 20A6 20A7
Q53 TRA_2N3904 27C2
Q54 TRA_2N3904 27C2
Q55 TRA_2N3904 33A5
Q56 TRA_2N7002DW 31B8
Q57 TRA_2N7002DW 35A4
Q58 TRA_FDG6324L 36A4 36B4
Q59 TRA_2N7002 30D6
Q60 TRA_SI3443DV 30D6
Q61 TRA_SI3443DV 24B2
Q62 TRA_SI3443DV 24A2
Q63 TRA_2N7002DW 36A6
R1 RES 36D4
R2 RES 38D5
R3 RES 20C4
R4 RES 38C5
R5 RES 26A7
R6 RES 26A6
R7 RES 31A8
R8 RES 31B8
R9 RES 30A7
R10 RES 30A7
R11 RES 30B7
R12 RES 30C7
R13 RES 38B5
R14 RES 38C8
R15 RES 27C7
R16 RES 27B7
R17 RES 27B4
R18 RES 33B8
R19 RES 38B8
R20 RES 36C8
R21 RES 38B5
R22 RES 38A7
R23 RES 29C5
R24 RES 37A5
R25 RES 29B4
R26 RES 38B7
R27 RES 29A5
R28 RES 37A5
R29 RES 33B8
R30 RES 33A7
R31 RES 15D8
R32 RES 37A5
R33 RES 28D4
R34 RES 29B6
R35 RES 20A5
R36 RES 38C3
R37 RES 38D5
R38 RES 25C6
R39 RES 38B3
R40 RES 37B4
R41 RES 36B5
R42 RES 35B3
R43 RES 35B3
R44 RES 37C3
R45 RES 37D3
R46 RES 23C6
R47 RES 39C4
R48 RES 35B6
R49 RES 23B2
R50 RES 23C6
R51 RES 18D8
R52 RES 18D8
R53 RES 37D4
R54 RES 35B6
R55 RES 18B4
R56 RES 17B7
R57 RES 17B4
R58 RES 25C6
R59 RES 25B5
R60 RES 35B6
R61 RES 18B7
R62 RES 18B7
R63 RES 25B5
R64 RES 25C2
R65 RES 32A6
R66 RES 32B6
R67 RES 16B8
R68 RES 16B8
R69 RES 17C4
R70 RES 16D2
R71 RES 16B8
R72 RES 18D8
R73 RES 16C5
R74 RES 32B6
R75 RES 32C7
R76 RES 32B7
R77 RES 32A7
R78 RES 17C4
R79 RES 17C4
R80 RES 32B5
R81 RES 32B5
R82 RES 32A5
R83 RES 17D7
R84 RES 16D2
R85 RES 16D2
R86 RES 16B6
R87 RES 17B7
R88 RES 17A7
R89 RES 17C4
R90 RES 17C4
R91 RES 16B6
R92 RES 32A7
R93 RES 32A7
R94 RES 32B7
R95 RES 32B7
R96 RES 16B2
R97 RES 16B2
R98 RES 16B2
R99 RES 32B7
R100 RES 16D1
R101 RES 32A7
R102 RES 16B1
R103 RES 16C2
R104 RES 18D4
R105 RES 16D1
R106 RES 16C2
R107 RES 16D1
R108 RES 17D4
R109 RES 16D1
R110 RES 16C2
R111 RES 16A2
R112 RES 16D7
R113 RES 16C5
R114 RES 16B2
R115 RES 16B2

R116 RES 16B2
R117 RES 16A6
R118 RES 16A6
R119 RES 16A6
R120 RES 16B2
R121 RES 31D7
R122 RES 33B7
R123 RES 31B3
R124 RES 31B3
R125 RES 31B3
R126 RES 35C5
R127 RES 35C3
R128 RES 35D3
R129 RES 31D7
R130 RES 34C7
R131 RES 35C3
R132 RES 28B1
R133 RES 28B1
R134 RES 28B2
R135 RES 28B2
R136 RES 31D7
R137 RES 31D3
R138 RES 33B5
R139 RES 35C6
R140 RES 35C5
R141 RES 35C5
R142 RES 31D7
R143 RES 19A7
R144 RES 34B7
R145 RES 26C4
R146 RES 26D3
R147 RES 35C6
R148 RES 9D8
R149 RES 31C3
R150 RES 19A6
R151 RES 19A5
R152 RES 19A7
R153 RES 26C5
R154 RES 26C4
R155 RES 38C5
R156 RES 38C7
R157 RES 29D7
R158 RES 38B5
R159 RES 20D7
R160 RES 21C1
R161 RES 19A7
R162 RES 19B7
R163 RES 33B4
R164 RES 33B4
R165 RES 33B4
R166 RES 26C5
R167 RES 31D1
R168 RES 31D2
R169 RES 31B5
R170 RES 31B5
R171 RES 29C7
R172 RES 30A6
R173 RES 30B7
R174 RES 30B7
R175 RES 30A6
R176 RES 30A6
R177 RES 30B7
R178 RES 30B7
R179 RES 30A7
R180 RES 27B5
R181 RES 29C7
R182 RES 33B7
R183 RES 29B6
R184 RES 10C6
R185 RES 20D7
R186 RES 31D1
R187 RES 22A7
R188 RES 36C5
R189 RES 29C7
R190 RES 30C7
R191 RES 30C7
R192 RES 29B7
R193 RES 24D2
R194 RES 10A8
R195 RES 10C6
R196 RES 21B7
R197 RES 38D8
R198 RES 36B7
R199 RES 29B3
R200 RES 29B3
R201 RES 29B3
R202 RES 29C3
R203 RES 29C3
R204 RES 29C4
R205 RES 24C3
R206 RES 10A8
R207 RES 10A8
R208 RES 19C7
R209 RES 21C5
R210 RES 19C8
R211 RES 19B8
R212 RES 20A3
R213 RES 20A3
R214 RES 20A3
R215 RES 38A5
R216 RES 30C7
R217 RES 30C7
R218 RES 30C7
R219 RES 30C7
R220 RES 12B5
R221 RES 13D4
R222 RES 19C8
R223 RES 19B8
R224 RES 33A6
R225 RES 26D3
R226 RES 27B5
R227 RES 19D7
R228 RES 25C5
R229 RES 26A7
R230 RES 37B7
R231 RES 15C8
R232 RES 12A5
R233 RES 10A8
R234 RES 8C1
R235 RES 19D7
R236 RES 26B7
R237 RES 35D6
R238 RES 29A6
R239 RES 12A6
R240 RES 12A6
R241 RES 10A8
R242 RES 10B6
R243 RES 35D5
R244 RES 28C4
R245 RES 28C4
R246 RES 28C4
R247 RES 28C3
R248 RES 28C3
R249 RES 28C3
R250 RES 28C3
R251 RES 28C3
R252 RES 13D1
R253 RES 13D1
R254 RES 12B6
R255 RES 13B1
R256 RES 19A7
R257 RES 24D1
R258 RES 24B1
R259 RES 19B7
R260 RES 39B8
R261 RES 35D4
R262 RES 35C5
R263 RES 36D5
R264 RES 36C7
R265 RES 36B7
R266 RES 36B7
R267 RES 13C1
R268 RES 12D7
R269 RES 12D7
R270 RES 12D6
R271 RES 13C1
R272 RES 9C1
R273 RES 8D1
R274 RES 8D1
R275 RES 8D1
R276 RES 8D1
R277 RES 24D7
R278 RES 28C8
R279 RES 28D1
R280 RES 15C7
R281 RES 13C1
R282 RES 12D7
R283 RES 8D1

R284 RES 20C7
R285 RES 20C7
R286 RES 24C6
R287 RES 36B7
R288 RES 28D1
R289 RES 28D8
R290 RES 15B7
R291 RES 13C1
R292 RES 13D1
R293 RES 12D5
R294 RES 12D5
R295 RES 12D5
R296 RES 12A3
R297 RES 20C7
R298 RES 20C7
R299 RES 26B6
R300 RES 26B7
R301 RES 13B1
R302 RES 12A6
R303 RES 12D5
R304 RES 12B3
R305 RES 7B6
R306 RES 7A6
R307 RES 10A8
R308 RES 20C7
R309 RES 20C7
R310 RES 36B7
R311 RES 15B7
R312 RES 15C8
R313 RES 13C1
R314 RES 9C1
R315 RES 20C8
R316 RES 20C8
R317 RES 24C7
R318 RES 38C5
R319 RES 33B7
R320 RES 29B5
R321 RES 29B5
R322 RES 28D2
R323 RES 28B4
R324 RES 13B1
R325 RES 12D5
R326 RES 12D5
R327 RES 12D4
R328 RES 12D4
R329 RES 13B1
R330 RES 20C8
R331 RES 20C8
R332 RES 22A3
R333 RES 33B7
R334 RES 33A7
R335 RES 33A6
R336 RES 33B6
R337 RES 36C7
R338 RES 12A3
R339 RES 12B3
R340 RES 7A6
R341 RES 9C1
R342 RES 8D1
R343 RES 20D4
R344 RES 33A6
R345 RES 24D6
R346 RES 36C4
R347 RES 24D7
R348 RES 35C3
R349 RES 13D1
R350 RES 12D6
R351 RES 12D6
R352 RES 12D6
R353 RES 13D1
R354 RES 21D7
R355 RES 21D6
R356 RES 21B2
R357 RES 20C6
R358 RES 20C6
R359 RES 20C7
R360 RES 20C7
R361 RES 26D7
R362 RES 36A8
R363 RES 36D5
R364 RES 37A3
R365 RES 12D6
R366 RES 6B1
R367 RES 8C1
R368 RES 21C7
R369 RES 21C7
R370 RES 19D8
R371 RES 8B1
R372 RES 8B1
R373 RES 34B3
R374 RES 34B3
R375 RES 26D7
R376 RES 26D6
R377 RES 26D6
R378 RES 36D5
R379 RES 36C5
R380 RES 28D8
R381 RES 28A4
R382 RES 28A6
R383 RES 8D5
R384 RES 19C8
R385 RES 20A5
R386 RES 34D3
R387 RES 36A8
R388 RES 26C7
R389 RES 36A7
R390 RES 36A6
R391 RES 28A7
R392 RES 28B7
R393 RES 28C6
R394 RES 13D8
R395 RES 13A1
R396 RES 12D4
R397 RES 12D4
R398 RES 12D4
R399 RES 12D4
R400 RES 13A1
R401 RES 6C1
R402 RES 19C5
R403 RES 19B7
R404 RES 19D8
R405 RES 19D8
R406 RES 21C5
R407 RES 21A6
R408 RES 20A5
R409 RES 36A6
R410 RES 35D2
R411 RES 26C7
R414 RES 36C6
R415 RES 6C1
R416 RES 13C1
R417 RES 21C8
R418 RES 15B8
R419 RES 8C1
R420 RES 8C1
R421 RES 21D8
R422 RES 20C6
R427 RES 36C6
R428 RES 15B8
R429 RES 6C1
R430 RES 6A7
R431 RES 8C4
R432 RES 31C7
R433 RES 31C8
R434 RES 31C8
R435 RES 21D6
R436 RES 21C7
R437 RES 20A5
R438 RES 13D6
R439 RES 6C1
R440 RES 6D4
R441 RES 8C1
R442 RES 8A5
R443 RES 8C1
R444 RES 36B5
R445 RES 28B7
R446 RES 8C3
R447 RES 20B6
R448 RES 20B6
R449 RES 35A3
R450 RES 35A2
R451 RES 34D8
R452 RES 34D8
R454 RES 39D8
R455 RES 9C1
R456 RES 8B3
R457 RES 8B1
R458 RES 8B4

D

SIZE

OF

SHT

DRAWING NUMBER

NOTICE OF PROPRIETARY PROPERTY

I TO MAINTAIN THE DOCUMENT IN CONFIDENCE

III NOT TO REVEAL OR PUBLISH IN WHOLE OR PART

II NOT TO REPRODUCE OR COPY IT

AGREES TO THE FOLLOWING

PROPERTY OF APPLE COMPUTER, INC. THE POSSESSOR

THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY

1

2

3

4

5

67

8

12

3

4

5

6

78

B

C

D

A

B

C

D

A

REV.

APPLE COMPUTER INC.

SCALE

NONE

46 46

E

051-6403

48

R459 RES 36B2
R460 RES 37C2
R461 RES 39D7
R462 RES 8D7
R463 RES 20B6
R464 RES 34D8
R465 RES 37B2
R466 RES 8C1
R467 RES 36A2
R468 RES 36B2
R469 RES 36B2
R470 RES 34C6
R471 RES 39D7
R472 RES 15B3
R473 RES 15B6
R474 RES 34C6
R475 RES 37C1
R476 RES 7B6
R477 RES 20B8
R478 RES 37D4
R479 RES 39A4
R480 RES 39A4
R481 RES 6D6
R482 RES 7B4
R483 RES 7B6
R484 RES 8C1
R485 RES 37B3
R486 RES 37B3
R487 RES 8B1
R488 RES 34B1
R489 RES 34D1
R490 RES 23B7
R491 RES 7B5
R492 RES 35B6
R493 RES 35A6
R494 RES 34B3
R495 RES 34A1
R496 RES 35A3
R497 RES 36B1
R498 RES 34B3
R499 RES 34B1
R500 RES 23B7
R501 RES 23C3
R502 RES 23B3
R503 RES 23B3
R504 RES 23B3
R505 RES 23B3
R506 RES 23B3
R507 RES 23B3
R508 RES 23B4
R509 RES 23B4
R510 RES 23A4
R511 RES 23A4
R512 RES 23B6
R513 RES 35A6
R514 RES 35A6
R515 RES 34B1
R516 RES 34D1
R517 RES 12C7
R518 RES 34D2
R519 RES 34D1
R520 RES 39D7
R521 RES 35A7
R522 RES 35A7
R523 RES 34D5
R524 RES 34B1
R525 RES 34C1
R526 RES 37C7
R527 RES 37D7
R528 RES 23C5
R529 RES 23B6
R530 RES 34D1
R531 RES 34B1
R532 RES 37C7
R533 RES 39B5
R534 RES 32C4
R535 RES 37D7
R536 RES 39B4
R537 RES 39B7
R538 RES 39B7
R539 RES 23C3
R540 RES 23C3
R541 RES 23C3
R542 RES 23C3
R543 RES 23C3
R544 RES 23C3
R545 RES 23C3
R546 RES 16A5
R547 RES 34B3
R548 RES 34B7
R549 RES 34D1
R550 RES 39B7
R551 RES 39B7
R552 RES 12C8
R553 RES 36B2
R554 RES 34D1
R555 RES 34B1
R556 RES 34B1
R557 RES 39C6
R558 RES 39B8
R559 RES 39B8
R560 RES 36B1
R561 RES 34D1
R562 RES 34B3
R563 RES 34B2
R564 RES 34B6
R565 RES 34B7
R566 RES 39B8
R567 RES 39B8
R568 RES 12C7
R569 RES 12C7
R570 RES 16D5
R571 RES 32A3
R572 RES 34C8
R573 RES 37D8
R574 RES 39B5
R575 RES 39C6
R576 RES 39B5
R577 RES 39B8
R578 RES 16A4
R579 RES 34C8
R580 RES 39B6
R581 RES 39B7
R582 RES 39C5
R583 RES 39B3
R584 RES 39C5
R585 RES 33D3
R586 RES 33C3
R587 RES 33D4
R588 RES 37A7
R589 RES 33D4
R590 RES 33D2
R591 RES 18D2
R592 RES 35B8
R593 RES 32D2
R594 RES 32C3
R595 RES 32D4
R596 RES 32C2
R597 RES 32C3
R598 RES 32C3
R599 RES 32D2
R600 RES 32C3
R601 RES 32D2
R602 RES 32C2
R603 RES 16C5
R604 RES 16C5
R605 RES 32C3
R608 RES 20B6
R609 RES 20A6
R610 RES 20A6
R611 RES 20A6
R612 RES 33A7
R613 RES 39C2
R614 RES 25C5
R615 RES 25D4
R616 RES 25D4
R617 RES 25B4
R618 RES 25B4
R619 RES 25C2
R638 RES 27C7
R642 RES 27D6
R643 RES 27C6
R645 RES 27D5
R646 RES 27C5
R647 RES 27C5
R648 RES 27C5
R649 RES 27C5
R650 RES 27C5

R651 RES 27D4
R652 RES 27C4
R653 RES 27D4
R654 RES 27D3
R655 RES 27B3
R656 RES 27B3
R657 RES 27B2
R658 RES 27D2
R659 RES 27C2
R660 RES 27C2
R661 RES 27B2
R662 RES 27B2
R663 RES 33A8
R664 RES 20A8
R667 RES 20A7
R668 RES 31B8
R669 RES 35B4
R670 RES 35B4
R676 RES 35B3
R677 RES 33D5
R678 RES 33A8
R679 RES 31C3
R680 RES 31C3
R681 RES 31C3
R683 RES 26D4
R684 RES 26D4
R685 RES 36A5
R686 RES 36A4
R687 RES 19C5
R690 RES 20A8
R691 RES 20A8
R692 RES 20A7
R693 RES 20A7
R694 RES 37A8
R695 RES 37A7
R696 RES 14D3
R697 RES 14D3
R698 RES 14D2
R699 RES 14D2
R700 RES 13C3
R701 RES 14D2
R702 RES 14D3
R703 RES 19D8
R704 RES 29B2
R705 RES 20D6
R706 RES 20D6
R707 RES 20D6
R708 RES 20D4
R709 RES 31C4
R710 RES 31C5
R711 RES 30D6
R712 RES 30D6
R713 RES 28A7
R714 RES 16C5
R715 RES 20D3
R716 RES 24B2
R717 RES 24B2
R718 RES 24C3
R719 RES 24C3
R720 RES 33A6
RP1 RPAK4P 13B1 13C1
RP2 RPAK4P 6D1 13D1
RP3 RPAK4P 6B1 6B1 6C1 6D1
RP4 RPAK4P 6B1 6C1
RP5 RPAK4P 28B6 28B6 28B7
RP6 RPAK4P 28B6 28B6 28B7
RP7 RPAK4P 16C5
RP8 RPAK4P 16C5
RP9 RPAK4P 16D1
RP10 RPAK4P 16B5
RP11 RPAK4P 16B5
RP12 RPAK4P 29B6
RP13 RPAK4P 10C6
RP14 RPAK4P 10D8
RP15 RPAK10P2C 9C8
RP16 RPAK4P 9D1
RP17 RPAK4P 9D1
RP18 RPAK4P 29B6
RP19 RPAK4P 10C6
RP20 RPAK10P2C 9C8
RP21 RPAK10P2C 9B8
RP22 RPAK10P2C 9D8
RP23 RPAK10P2C 9B8
RP24 RPAK10P2C 15D8
RP25 RPAK10P2C 33D2
RP26 RPAK10P2C 33C2
RP27 RPAK4P 34C1
RP28 RPAK4P 7C5
RP29 RPAK4P 7C5
RP30 RPAK4P 7C5
RP31 RPAK4P 7C5
RP32 RPAK4P 7D5
RP33 RPAK4P 7D5
RP34 RPAK4P 7C5
RP35 RPAK4P 7B5
RP36 RPAK4P 34D8
RP37 RPAK4P 16C1
RP38 RPAK4P 32D5
RP39 RPAK4P 32D6
RP40 RPAK4P 32C7
RP41 RPAK4P 32D7
RP42 RPAK4P 32C7
RP43 RPAK4P 32D7
RP44 RPAK4P 32B7
RP45 RPAK4P 32D7
RP46 RPAK4P 32C7
RP47 RPAK4P 32D7
RP48 RPAK10P2C 18D8
RP49 RPAK4P 32B7
RP50 RPAK4P 32C7
RP51 RPAK4P 32D3
RP52 RPAK4P 32D3
RP53 RPAK4P 32D3
RP54 RPAK4P 32D3
RP55 RPAK4P 32D3
S2 SWI_4W219SM_H63 34B8
SL1 SLOT 5B3
T1 XFR_ENET_1000BT 28B2
U1 74AHC1G02 31A8
U2 SDRAM_DDR_2MX32 22C5 22C7
U3 AMP_MAX4172 36D4
U4 RAGE_MBLTY_M9_CSP32A13 19D1 19D3 19D6 20D2

20D5 21B4
U5 TSB41AB1 29C5
U6 VREG_LP2951 37A6
U7 SDRAM_DDR_2MX32 22C1 22C4
U8 TRANSC_ENET_BCM5421BGA100 28C5 28D5
U9 UNI_N_658P 6C5 7D7 8C6 9D4 10D4
U10 SCVGER483 13C5 14D4 14D7
U11 SRAM_DDR_153PBGA 15D2
U12 TRA_SI3447DV 38C3
U13 CY8C26233 24C7
U14 LTC1773 20A4
U15 DS1775 24B5
U16 DS1775 24B5
U17 LTC1625 36C5
U18 VREG_LP2951 37A4
U19 TRA_SI3447DV 38B3
U20 DS1775 24D5
U21 DS1775 24C5
U22 CLK_GEN_C5005 23B5
U23 FEPR_1MX8 23C2
U24 LTC1761 21A7
U25 MAX6328 34B7
U26 COMPARATOR_LMC7211 35C3
U27 COMPARATOR_LMC7211 35C5
U28 741G32 20C7
U29 TEMP_SENS_LM20 24B7
U30 AMP_MAX4172 36C8
U31 LM3526 30C5
U32 741G32 20D7
U33 MAX1644 38D6
U34 AUDIO_LM4863 26A6
U35 TEMP_SENS_LM20 24B7
U36 MAX1644 38B6
U37 COMPARATOR_LMC7211 33B6
U38 TEMP_SENS_LM20 24A7
U39 SN74AUC1G04 12B4
U40 OPAMP_LMC6462 36B7 36D6
U41 LTC1761 21C7
U42 SRAM_DDR_153PBGA 15D5
U43 MAX4298 26C6
U44 COMPARATOR_LMC7211 36A7
U45 LTC1761 21D7
U46 CLK_GEN_CY25811 20A8
U47 M16C62 34D5
U48 MAX785 37C6
U49 COMPARATOR_LMC7211 35A6

U50 MAX1717 39C5
U51 UPD720100_FBGA 17C6
U52 PCI1410AGGU 18C6
U53 KEYLARGO_17X17 16C3 16C7
U54 PWR_CNTRL_TPS2211 18D4
U55 DS1775 24B3
U56 DS1775 24B3
U57 TAS3004 25C3
U58 OPAMP_TLV2362 27C5 27D5
U59 OPAMP_TLV2362 27C1 27C4
U61 COMPARATOR_LMC7211 26D4
U62 VREG_LT1962 14D2
VR1 VREG_LP2951 25D7
VR2 VREG_LP2951 27B5
XH1 MTGHOLE 5C2
XH2 MTGHOLE 5C2
XH3 MTGHOLE 5C2
XH4 MTGHOLE 5C2
XW2 SHORT 26B3
XW3 SHORT 26B3
XW4 SHORT 26B3
XW5 SHORT 26A3
XW6 SHORT 37B4
XW7 SHORT 39B1
XW8 SHORT 39C2
XW9 SHORT 37C4
XW10 SHORT 39B4
XW12 SHORT 20A4
XW13 SHORT 26B3
XW14 SHORT 26A3
XW16 SHORT 20A5
XW17 SHORT 26A3
XW19 SHORT 37C6
XW20 SHORT 16A3
XW21 SHORT 39B4
XW28 SHORT 27B2
XW29 SHORT 26A3
Y1 CRYSTAL 23B6
Y2 CRYSTAL_4PIN 34B3
Y3 CRYSTAL 34B7
Y4 CRYSTAL 29C6
Y5 CRYSTAL 28A6
Y6 CRYSTAL 17D4
ZH1 MTGHOLE 26B3
ZT1 MTGHOLE 5B3
ZT2 MTGHOLE 5D2
ZT3 MTGHOLE 5D3
ZT4 MTGHOLE 5C2
ZT5 MTGHOLE 5D1
ZT6 MTGHOLE 5D3
ZT7 MTGHOLE 5D1
ZT8 MTGHOLE 5D2
