DUAL BAND HANDHELD RADIO
INSTRUCTION MANUAL
THANK YOU!
transceiver will provide you with reliable, clear and efficient communication service. The
transceiver introduces innovative DSP digital signal processing technology, high degree integration, it is
including kinds of professional function, best stability and great reliability as well as exterior smooth lines,
novel, fashionable, sturdy and durable.
The transceiver includes plenty of TX, RX channels, as well as UU,VV and UV standby modes which
are able to realize dual PTT functions. 51 groups of CTCSS encode/decode and 1 group of user-dened
CTCSS encode/decode, 1024 groups of DCS encode/decode, 5TONE/2TONE/DTMF encode/decode,
built-in radio functions, etc..It is a meticulous build functional and Multi frequency band radio for radio
amateur and commercial users.
Versions
Version A: Dual frequency, dual standby, dual display, dual band, single receive channel.
MODELS APPLY TO THIS MANUAL
AT-3318UV FM transceiver
AT-3318UV(Version A) programming software: QPS3318UV_USA
PROGRAM CAUTIONS
When programming the transceiver, read the factory initial data rst, then rewrite the frequency and
signaling etc., other wise errors may occur because of different frequency ranges involved.
CAUTIONS
transceiver is excellent designed with advanced technology. The following tips will be helpful for you in
performing your obligation under warranty and understanding the safety of transceiver usage.
Keep the transceiver and accessories away from children.
1.
2.Please do not try to open or modify the transceiver without permission, non-professionals operation may also cause
damage.
3.Please use assorted battery and charger to avoid damage.
4.Please use assorted antenna to ensure the communication distance.
5.Please avoid exposing the radio under the sunshine for a long time or storing it in too hot places. High temperature will
shorten the life of electronic devices.
6.Please avoid storing the radio in the dusty, dirty and damp areas.
7.Please keep the radio dry. Do not wash radio with ardent chemicals and detergents.
8.Do not transmit without antenna.
9.When using this transceiver, we recom mend transmitting for 1 minu te then receiving for 4 minutes. c ontinuously
transmitting for long time or working in high power will heat the back of the transceiver. Do not place the transceiver's hot
back close to any plastics.
10.If any abnormal smell or smoke coming from the transceiver, please turn off the power instantly and take off the battery
and its case. Then contact local
NOTE：
All the above tips apply for your
normally, please contact with local
If you use any accessories made by other companies,
operability and safety of the transceiver.
dealers.
transceivers' accessories. If any device can not operate
dealers.
company do es not guarantee th e
