The MS8606A can measure CDMA (IS-95, ARIB STD-T53) forward
and reverse transmission characteristics. It is ideal for measuring
transmitter characteristics including frequency, waveform quality (ρ),
timing error (τ), code domain power, transmitter power, occupied
bandwidth, neighboring spurious, etc.
The MS8606A can measure PDC transmission characteristic such as
transmission frequency and power, modulation accuracy, occupied
bandwidth, and adjacent channel power, in addition to the bit error
rate.
The built-in spectrum analyzer covers frequencies of 10 MHz to 3
GHz making it ideal for R&D. In addition, the general-purpose evaluation functions can be used to measure the adjacent channel power,
occupied bandwidth, and sideband noise of radio equipment.
The MS8606A has general-purpose analog measurement functions,
including frequency counter, power meter, FM/øM measurement, AF
oscillator and audio analyzer, making it perfect for FM radio transmission tests (AF oscillator and audio analyzer optional).
Features
•For CDMA, PDC measurement
•High-speed, high precision measurement
•Built-in spectrum analyzer and AF measurement function
CDMA modulation analysis
RADIO COMMUNICATIONS TEST INSTRUMENTS
DIGIT AL MOBILE RADIO TRANSMITTER TESTER
MS8606A
300 kHz to 3 GHz
GPIB
6
NNNNEEEEWW
WW
Code domain power measurement
Specifications
•MS8606A
Frequency range 300 kHz to 3 GHz
Max. input level MAIN connector: +40 dBm (10 W), AUX connector: +20 dBm (100 mW)
Input impedance 50 Ω, VSWR: ≤1.2 (≤2.2 GHz, MAIN connector), ≤1.3 (>2.2 GHz, MAIN connector)
Input connector N-type (MAIN connector), TNC-type (AUX connector)
Frequency: 10 MHz
Starting characteristics: ≤5 x 10
–8
/day (after 10 minutes of warm-up, compared to the frequency after 24-hour warm-up)
Reference oscillator Aging rate: ≤2 x 10
–8
/day, ≤1 x 10–7/year (compared to the frequency after 24-hour warm-up)
Temperature characteristics: ≤5 x 10
–8
(compared to the frequency at 25˚C)
External reference input: 10 or 13 MHz (±1 ppm), 2 to 5 Vp-p
Frequency range: 300 kHz to 3 GHz
Power meter Level range: 0 to +40 dBm
Measurement accuracy: ±10% (after zero calibration)
Frequency setting
Setting range: 0 to 3 GHz (band: 0), 10 MHz to 3 GHz (band: 1), Setting resolution: 1 Hz
Frequency accuracy
Display accuracy: ±(display frequency x reference frequency accuracy + span x span accuracy)
Normal marker: Same as display frequency accuracy
Delta marker: Same as span accuracy
Frequency span
Frequency Setting range: 0 Hz, 10 kHz to 3 GHz (band: 0); 0 Hz, 10 kHz to 2.99 GHz (band: 1)
Span accuracy: ±2.5%
RBW (resolution bandwidth)
Setting range: 300 Hz to 1 MHz (3 dB BW, 1-3 sequence)
Accuracy: ±2% (300 Hz to 300 kHz), ±10% (1 kHz)
Selectivity (60 dB : 3 dB): ≤5:1
VBW (video bandwidth): 3 Hz to 100 kHz (1-3 sequence), through
Side band noise: ≤–95 dBc/Hz (1 GHz, 10 kHz offset), ≤–115 dBc/Hz (1 GHz, 100 kHz offset)
Maximum input level
Continuous average power: +40 dBm (MAIN connector), +20 dBm (AUX connector)
DC voltage: 0 V
Average noise level (at RBW: 1 kHz, VBW: 10 Hz):
≤–90 dBm (MAIN connector, 10 MHz to 1 GHz, input attenuator: 20 dB)
≤–90 dBm + f[GHz] (MAIN connector, >1 GHz, input attenuator: 20 dB)
≤–110 dBm (AUX connector, 10 MHz to 1 GHz, input attenuator: 0 dB)
≤–110 dBm + f[GHz] (AUX connector, >1 GHz, input attenuator: 0 dB)
Residual response: ≤–70 dBm (MAIN connector, input attenuator: 20 dB), ≤–90 dBm (AUX connector, input attenuator: 0 dB)
Total level accuracy
MAIN connector: ±1.5 dB (reference level: +10.1 to +40 dBm, at 0 to –50 dB of reference level)
Amplitude (at Band: 1) AUX connector: ±1.5 dB (reference level: –9.9 to +20 dBm, at 0 to –50 dB of reference level)
Reference level
Setting range: –50 to +50 dBm (MAIN connector), –75 to +30 dBm (AUX connector)
Setting resolution: 0.1 dB
Accuracy: ±0.5 dB (MAIN connector, +10.1 to +40 dBm), ±1.0 dB (MAIN connector, –50 to +10 dBm)
±0.5 dB (AUX connector, –9.9 to +20 dBm), ±1.0 dB (AUX connector, –75 to –10 dBm)
RBW switching error: ±0.1 dB (referenced to RBW: 3 kHz)
Frequency response: ±0.5 dB [referenced to 100 MHz, input attenuator: 30 dB (10 dB for AUX); temperature range: 18 to 28˚C]
Log linearity:
±0.5 dB (0 to –50 dB, RBW: ≤1 MHz), ±1.0 dB (0 to –70 dB, RBW: ≤30 kHz), ±1.0 dB (0 to –80 dB, RBW: ≤3 kHz)
*
10 MHz to 2.2 GHz, reference level: ≥0 dBm (MAIN connector); ≥–20 dBm (AUX connector)
2nd harmonic distortion: ≤–55 dBc (10 to 100 MHz), ≤–60 dBc (100 to 1500 MHz)
*
At mixer input level: –30 dBm
Setting range: 100 ms to 1000 s (frequency axis sweep), 100 ms to 1000 s (time axis sweep, RBW: ≤1 kHz)
10 ms to 1000 s (time axis sweep, RBW: 3 to 10 kHz), 1 ms to 1000 s (time axis sweep , ≥30 kHz)
Trigger switch: FREERUN, TRIGGERED
Trigger source: WIDE IF VIDEO (3 dB bandwidth: ≥20 MHz, trigger slope: RISE/FALL)
Sweep EXT (trigger level: TTL level, trigger slope: RISE/FALL)
Trigger delay
Setting range: 0 µs to 100 ms, Resolution: 2 µs
Gate delay, gate width
Setting range: 2 µs to 100 ms, Resolution: 2 µs
Marker
Signal search: PEAK→CF, PEAK→REF
Zone marker: NORMAL, DELTA
Marker→function: MARKER→CF, MARKER→REF, ZONE→SPAN
Peak search: PEAK, NEXT PEAK, NEXT RIGHT PEAK, NEXT LEFT PEAK
Measurement
Functions Noise power: dBm/Hz, dBm/ch
C/N: dBc/Hz, dBc/ch
Occupied bandwidth: Power N% method, X dB down method
Adjacent channel power
Reference measurement: Total power/reference level method,
Display method: Channel designate display 2 channels x 2, graphic display
Average power of burst signal: Average power within the specified time range of the time axis waveform
Number of data point: 501
Others
Detection mode: POS PEAK, NEG PEAK, SAMPLE
Display function: TRACE A, TRACE B, TRACE TIME
Storage function: NORMAL, VIEW, MAX HOLD, MIN HOLD, AVERAGE, CUMULATIVE, OVER WRITE
RADIO COMMUNICA TIONS TEST INSTRUMENTS
222
Spectrum analyzer
Continued on next page
223
Power measurement (wide band)
Frequency range: 300 kHz to 3 GHz
Level range: 0 to +40 dBm (MAIN connector)
Accuracy: ±10% (after zero point calibration)
Power measurement (narrow band)
Frequency range: 10 MHz to 3 GHz
Input level: 0 to +40 dBm (MAIN connector), –40 to +20 dBm (AUX connector)
Accuracy: ±10% (MAIN connector, after calibration with internal wide band power meter)
±1 dB (AUX connector, reference level: ≥–12 dBm, after calibration)
Linearity: ±0.3 dB (0 to –30 dB)
Frequency measurement
Frequency range: 10 MHz to 3 GHz
Input level: –15 to +40 dBm (MAIN connector), –40 to +20 dBm (AUX connector)
Resolution: 1 Hz
Accuracy: ±(reference oscillator accuracy + 10 Hz)
*
IF frequency counting (bandwidth: ±30 kHz)
FM measurement
Frequency range: 10 MHz to 3 GHz
RF analyzer Input level: –15 to +40 dBm (MAIN connector), –40 to +20 dBm (AUX connector)
Deviation: 0 to 20 kHz
Demodulation frequency: 30 Hz to 20 kHz
Accuracy: 1% of indicated value + residual FM (demodulation frequency: 1 kHz)
Frequency response: ±0.5 dB (demodulation frequency: referenced to 1 kHz)
Residual FM: 8 Hz-rms (demodulation frequency: 0.3 to 3 kHz)
Distortion: 0.3% (demodulation frequency: 1 kHz, demodulation bandwidth: 0.3 to 3 kHz, deviation: 5 kHz)
Filters (3 dB cut-off): HPF (50 Hz, 300 Hz), LPF (3 kHz, 15 kHz)
øM measurement
Frequency range: 10 MHz to 3 GHz
Input level: –15 to +40 dBm (MAIN connector), –40 to +20 dBm (AUX connector)
Deviation: 0 to 10 rad
Demodulation frequency: 300 Hz to 3 kHz
Accuracy: 1% of indicated value + residual øM (demodulation frequency: 1 kHz)
Frequency response: ±0.5 dB (demodulation frequency: referenced to 1 kHz)
Residual øM: 0.01 rad-rms (demodulation bandwidth: 0.3 to 3 kHz)
Distortion: 0.5% (demodulation frequency: 1 kHz, demodulation bandwidth: 0.3 to 3 kHz, deviation: 5 rad)
Filters (3 dB cut-off): HPF (50 Hz, 300 Hz), LPF (3 kHz, 15 kHz)
Display: Color TFT-LCD, 7.8”, 640 x 480 dots
Hard copy: Enables data hard copy of the display through a parallel interface (printer: ESC/P compatible printer)
Others
GPIB: This equipment is specified as a device, can be controlled from external controller (excluding power switch).
Interface functions: SH1, AH1, T6, L4, SR1, RL1, PP0, DC1, DT1, C0, E2
Parallel interface: Conform to the Centronics. Outputs printing data to printer. D-sub 25-pin connector (female)
RS-232C: All functions except power switch controlled by external controller (baud rate: 1200, 2400, 4800, 9600 bps)
Dimensions and mass 426(W) x 221.5(H) x 451(D) mm, ≤22 kg
Power 100 to 120/200 to 240 Vac (–15%/+10%, max. voltage: 250 V, automatic voltage switch system), 47.5 to 63 Hz, ≤300 VA
Operating temperature 0˚ to 50˚C
RADIO COMMUNICA TIONS TEST INSTRUMENTS
6
Analog measurement
•Option 01: AF measurement
The following items have been added to the standard analog measurement items.
Input impedance: 600 Ω/100 kΩ (unbalanced, BNC connector)
Filters
HPF: 400 Hz (for tone rejection), De-emphasis: 750 µs, Weighting filter: ITU-T P.53, C-Message
AF Level measurement
Audio analyzer Frequency range: 30 Hz to 20 kHz, Level range: 1 mVrms to 30 Vrms, Accuracy: ±0.5 dB
Distortion measurement
Frequency range: 100 Hz to 5 kHz, Level range: 30 mVrms to 30 Vrms, Accuracy: ±1 dB (frequency: 1 kHz, distortion factor: 1%)
AF frequency measurement
Frequency range: 30 Hz to 20 kHz, Level range: 30 mVrms to 30 Vrms, Accuracy: ±0.1 Hz
Frequency
Frequency range: 20 Hz to 20 kHz, Setting resolution: 0.1 Hz, Accuracy: Same as reference oscillator
Output
Level range: 0.1 mVrms to 3.0 Vrms (EMF, main output impedance: 600 Ω)
0.1 mVrms to 0.3 Vrms (EMF, main output impedance: 50 Ω)
Setting resolution: 1 µ V (output level: <4 mV), 10 µ V (output level: ≤40 mV),
100 µV (output level: ≤0.4 V), 1 mV (output level: ≤3 V)
Accuracy (bandwidth: <30 kHz)
AF generator Unbalanced output: ±0.5 dB (frequency: 1 kHz, output level: ≥1 mV), ±1 dB (frequency: 20 Hz to 20 kHz, output level: ≥1 mV)
Floating output: ±2 dB (frequency: 1 kHz, output level: ≥1 mV)
Output impedance
Main output: 600 Ω, 50 Ω (unbalanced, BNC-type)
Microphone input: 600 Ω (floating, DUT interface)
Distortion: <–50 dBc (bandwidth: <30 kHz, demodulation frequency: 1 kHz, output level: 1 V)
<–45 dBc (bandwidth: <30 kHz, demodulation frequency: 20 Hz to 20 kHz, output level: 1 V)
Noise generator: White noise passed through a weighting filter (conforming to ITU-T Rec. G.227)
Deviation: 0 to 40 kHz (4/40 kHz range)
FM demodulation output
Demodulation frequency: 50 Hz to 10 kHz
Output level: 4 Vpeak (EMF, at full-scale range)
Output impedance: 600 Ω
Mass ≤1 kg
RADIO COMMUNICA TIONS TEST INSTRUMENTS
224
• MX860601A CDMA Measurement Software
All specifications are guaranteed after the Adjust Range key and Calibration key are pressed.
Frequency range: 10 MHz to 2.2 GHz
Input level: –10 to +40 dBm (average power during burst on, MAIN connector)
Modulation/frequency
Carrier frequency accuracy: ±10 Hz
measurement
Waveform quality (ρ)
Measurement accuracy: <0.001
Modulation accuracy
Residual vector error: <3.0%
Frequency range: 10 MHz to 2.2 GHz
Input level: +10 to +40 dBm (MAIN connector)
Code domain analysis
Carrier frequency accuracy: ±10 Hz
Code domain power measurement accuracy: ±0.1 dB (at –7 dBc)
Waveform quality (ρ)
Measurement accuracy: <0.001
Frequency range: 10 MHz to 2.2 GHz
Input level:
+10 to +40 dBm (average power during burst on, MAIN connector), 0 to +40 dBm (continuous signal, MAIN connector)
Amplitude measurement
–20 to +20 dBm (average power during burst on, AUX connector), –30 to +20 dBm (continuous signal, AUX connector)
Transmitter power accuracy: ±10% (MAIN connector), ±1 dB (AUX connector, reference level: ≥–12 dBm, 18˚ to 28˚C)
Burst analysis: Rise/fall edge characteristics and on/off ratio analysis function
Frequency range: 20 MHz to 2.2 GHz
Occupied bandwidth Input level: 0 to +40 dBm (average power during burst on, MAIN connector),
measurement –20 to +20 dBm (average power during burst on, AUX connector)
Measurement system: Spectrum analyzer or FFT method
Frequency range: 20 MHz to 2.2 GHz
Neighboring spurious
Input level: +10 to +40 dBm (average power during burst on, MAIN connector),
measurement
–20 to +20 dBm (average power during burst on, AUX connector)
Measurement system: Spectrum analyzer method
Measurement range: ≥50 dB (900 kHz offset), ≥60 dB (1.98 MHz offset)
• MX860602A PDC Measurement Software
All specifications are guaranteed after the Adjust Range key and Calibration key are pressed.
Frequency range: 10 MHz to 2.2 GHz
Input level: –10 to +40 dBm (average power during burst on, MAIN connector),
–30 to +15 dBm (average power during burst on, AUX connector)
Carrier frequency accuracy: ±(reference oscillator accuracy + 1 Hz)
Modulation/frequency Modulation accuracy
measurement Measurement range: 0 to 12.5%, Accuracy: ±(2% of indicated value + 0.5%)
Origin offset accuracy: ±0.5 dB (relative to signal of –30 dBc)
Transmission rate
Measurement range: 42 kbps ±100 ppm, Accuracy: ±1 ppm
Waveform display: Constellation display
Frequency range: 10 MHz to 2.2 GHz
Input level: +10 to +40 dBm (average power during burst on, MAIN connector),
–40 to +20 dBm (average power during burst on, AUX connector)
Transmitter power accuracy: ±10% (MAIN connector), ±1 dB (AUX connector, reference level: ≥–12 dBm, 18˚ to 28˚C)
Amplitude measurement Carrier-off power measurement: ≥65 dB (normal mode, compared to average power during burst on)
≥95 dB (wide dynamic range mode, compared to average power during burst on: 3 W)
*
Measured limit determined by average noise level (≤–60 dBm, 100 MHz to 2.1 GHz)
Rise/fall edge characteristics: Displays waveform while synchronizing modulated data of measured signal, displays limit line,
rise/fall edge time measurement (measured at 100 kHz bandwidth)
Frequency range: 10 MHz to 2.2 GHz
Occupied bandwidth
Input level: +5 to +40 dBm (average power during burst on, MAIN connector),
–15 to +20 dBm (average power during burst on, AUX connector)
measurement
Standard mode: Displays calculation result after measured signal with sweep-type spectrum analyzer
High speed mode: Displays calculation result after analyzing signal (one burst) with FFT
Frequency range: 10 MHz to 2.2 GHz
Input level: +5 to +40 dBm (average power during burst on, MAIN connector),
Adjacent channel power –15 to +20 dBm (average power during burst on, AUX connector)
measurement Standard mode: Displays calculation result after measured signal with sweep-type spectrum analyzer
High speed mode: Displays calculation result after analyzing signal (one burst) with spectrum analyzer emulation
Measurement range: ≥60 dB (50 kHz offset), ≥65 dB (100 kHz offset)
Measurement item: Transmission frequency, modulation accuracy, origin offset, transmission rate, transmitter power, leakage
power during carrier-off, pass/fail decision for specifications of transmitter output time response, occupied
bandwidth, adjacent channel power
Batch measurement Measurement time:
function ≤1.5 s (amplitude measurement: normal mode; occupied bandwidth and adjacent channel power measurements: high-speed
mode)
≤2 s (amplitude measurement: wide dynamic range mode; occupied bandwidth and adjacent channel power measurement:
high-speed mode)
Measurement pattern: PN9, PN15
Error rate measurement Number of measurement bit: 10
2
, 2556, 103, 104, 105, ∞
Input level: TTL (NRZ), Input terminal: BNC-type (rear panel) or DUT interface (front panel)
225
Ordering information
Please specify model/order number, name and quantity when ordering.
Model/Order No.
Name
Mainframe
MS8606A Digital Mobile Radio Transmitter Tester
Standard accessories
J0576B Coaxial cord (N-P•5D-2W•N-P), 1 m: 1 pc
J0768 Coaxial adaptor (N-J•TNC-P) : 1 pc
J0017F Power cord, 2.6 m: 1 pc
F0014 Fuse, 6.3 A: 2 pcs
Options
MS8606A-01 AF measurement (audio analyzer, AF oscillator)
MX860601A CDMA Measurement Software
MX860602A PDC Measurement Software
Peripherals
MT8801B Radio Communication Analyzer
MS8604A Digital Mobile Radio Transmitter Tester
MD1620C Signalling Tester
MD6420A Data Transmission Analyzer
MS2602A Spectrum Analyzer
MG3670B/C Digital Modulation Signal Generator
MG3671A/B Digital Modulation Signal Generator
Optional accessories
J0127C Coaxial cord (BNC-P•RG-58A/U•BNC-P), 0.5 m
J0769 Coaxial adaptor (BNC-J•TNC-P)
J0040 Coaxial adaptor (N-P•BNC-J)
MN1607A Coaxial Switch (DC to 3 GHz, 50 Ω, external controllable)
MA1612A Four-Point Junction Pad (5 to 3000 MHz)
J0395
Fixed attenuator for high power (30 dB, 30 W, DC to 8 GHz)
J0007 GPIB cable, 1 m
J0008 GPIB cable, 2 m
B0329D Front cover (1MW5U)
B0331D Front handle (2 pcs/1 set)
B0332 Joint prate (4 pcs/set)
B0333D Rack mount kit
B0334D Carrying case (hard type)
RADIO COMMUNICA TIONS TEST INSTRUMENTS
6
Loading...
