Zoom DVD Home Theatre System User Manual

DVD HOME THEATER SYSTEM

VCR

JPG

FILES

OWNER'S MANUAL

Important Safety Instructions

WARNIN G

WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

WARNING:

CAUTION: TO PREVENT ELECTRIC SHOCK,

TO PREVENT FIRE OR SHOCK HAZARD, DO NO T EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

INVISIBLE LASER RADIATION

WHEN OPEN AND INTERLOCKS

The lightning flash with an arrowhead symbol, within the equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to cause an electric shock.

The exclamation point within the equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in this owner manual.

CAUTION

DEFEATED.

AVOID EXPOSURE TO BEAM

This product contains a low power laser device.

MATCH WIDE BLADE OF PLUG TO WIDE SLO T, FULLY INSERT .

The symbol for Class II (Double lnsulation)

On Placement

• The apparatus shall not be exposed to dripping or splashing.

• Do not use the Unit in places which are extremely hot, cold, dusty, or humid.

• Place the Unit on a flat and even surface.

• Do not restrict the air flow of the Unit by placing it in a place with poor air flow, by covering it with a cloth, or by placing it on carpeting.

FCC Information

This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesirable

operation.

On Safety

• When connecting or disconnecting the AC cord, grip the plug and not the cord itself. Pulling the cord may damage it and create a hazard.

• When you are not going to use the Unit for a long period of time, disconnect the AC power cord.

On Condensation

• When left in a heated room where it is warm and damp, water droplets or condensation may form inside the Unit. When there is condensation inside the Unit, the Unit may not function normally. Let the Unit stand for 1 to 2 hours before turning the power on, or gradually heat the room up and dry the Unit before use.

WARNING:

• Should any trouble occur, disconnect the AC power cord and refer servicing to a qualified technician.

• Do not place anything directly on the top of the Unit. Damage to the Unit can result.

Notes on Copyright

It is forbidden by law to copy, broadcast, show, broadcast on cable, play in public, rent copyrighted material without permission.

Apparatus Claims of U.S. Patent Nos. 4,631,603; 4,577,216; 4,819,098 and 4,907,093 licensed for limited viewing uses only.

DVD video discs are copy protected, and any recordings made from these discs will be distorted. This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only, unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

E - 1

Important Safety Instructions

1. Read Instructions - All the safety and operating instructions should be read before the appliance is

operated.

2. Retain Instructions - The safety and operating instructions should be retained for future reference.

3. Heed Warnings - All warnings on the appliance and in the operating instructions should be adhered to.

4. Follow Instructions - All operating and use instructions should be followed.

5. Water and Moisture - The appliance should not be used near water - for example, near a bathtub,

washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool, and the like.

6. Carts and Stands - The appliance should be used only with a cart or stand that is recommended by the manufacturer.

6A. An appliance and cart combination should be moved with care. Quick stops, excessive

force, and uneven surfaces may cause the appliance and cart combination to overturn.

7. Wall or Ceiling Mounting - The appliance should be mounted to a wall or ceiling only as recommended by the manufacturer.

8. Ventilation - The appliance should be situated so that its location or position does not interfere with its proper ventilation. For example, the appliance should not be situated on a bed, sofa, rug, or similar surface that may block the ventilation openings; or, placed in a built-in installation, such as a book case or cabinet, that may impede the flow of air through the ventilation openings.

9. Heat - The appliance should be situated away from heat sources such as radiators, heat registers, stoves, or other appliances (including amplifiers) that produce heat.

10. Power Sources - The appliance should be connected to a power supply only of the type described in the operating instructions or as marked on the appliance.

11. Grounding or Polarization - Precautions should be taken so that the grounding or polarization means of an appliance are not defeated.

12. Power-Cord Protection - Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance.

13. Cleaning - The appliance should be cleaned only as recommended by the manufacturer.

14. Power Lines - An outdoor antenna should be located away from power lines.

15. Outdoor Antenna Grounding - If an outside antenna is connected to the receiver, be sure the antenna system is grounded so as to provide some protection against voltage surges and built up static charges. Section 810 of the National Electrical Code, ANSI/NFPA No. 70, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode. See Figure 1.

16. Nonuse Periods - The power cord of the appliance should be unplugged from the outlet when left unused for a long period of time.

17. Object and Liquid Entry - Care should be taken so that objects do not fall, and liquids are not spilled, into the enclosure through openings.

18. Damage Requiring Service - The appliance should be serviced by qualified service personnel when: A. The power-supply cord or the plug has been damaged; or B. Objects have fallen, or liquid has been spilled, into the appliance; or C. The appliance has been exposed to rain; or D. The appliance does not appear to operate normally or exhibits a marked change in performance; or E. The appliance has been dropped, or the enclosure damaged.

19. Servicing - The user should not attempt to service the appliance beyond that described in the operating instructions. All other servicing should be referred to qualified service personnel.

E - 2

Table of Contents

Important Safety Instruction ..................... 1-2

Disc Formats ................................................ 4

Before You Start ........................................... 5

Using the remote control .......................................... 5

Parts and Functions .................................. 6-9

Front Panel ................................................................. 6

Rear Panel....................................................................7

Subwoofer...................................................................7

Remote Control ...................................................... 8-9

Display .........................................................10

Front Panel Display ...................................................10

Display Information .................................................10

Setup ..................................................... 11-15

For better reception ................................................. 11

Connecting your TV ................................................. 11

Connecting a VCR .................................................... 12

Connecting another source .................................... 13

Connecting the speakers & subwoofer .................. 14

Positioning the speakers and subwoofer .............. 15

Mounting rear surround speakers .......................... 16

Turning on the Unit and TV ...................................... 16

Power cord connection ........................................... 16

Adjusting the Sound ............................. 17-18

Playing a Disc ........................................... 19

Playing Disc ............................................................. 19

Pausing playback (still mode) ............................... 19

Stopping playback ................................................. 19

To skip to a different track ...................................... 19

Fast Foward/Fast Reverse ..................................... 20

Slow-motion play ................................................... 20

Skip (Forward/Reverse) .......................................... 20

Zooming into an image ......................................... 20

Angle selection ....................................................... 21

Audio selection ....................................................... 21

Subtitle selection .................................................... 22

Special Functions ................................. 23-25

Display function (DVD) .......................................... 23

Locating a specific title ......................................... 24

Locating a specific title/chapter/track .................. 24

Locating a specific time ......................................... 25

Angle setting ........................................................... 25

Audio setting .......................................................... 25

Subtitle setting ....................................................... 25

CD / DVD programmable memory ............... 26

DVD programmable memory ................................. 26

Title/Chapter programmed playback ............. 26

CD programmable memory ................................... 26

Track programmed playback .......................... 26

Repeat Playback ................................... 27-28

Repeating a title/chapter (DVD) ............................ 27

Repeating a single track/whole disc (CD) ........... 27

Repeating a specific section (DVD) ...................... 28

Playing MP3 and Picture File Disc......... 29-30

Playing a MP3 file disc ............................................ 29

Playing a Picture file disc ....................................... 30

Playing a MP3/Picture file disc ............................... 30

Radio Operation ......................................... 31

Tuning into a station manually ............................... 31

FM Stereo ............................................................. 31

Weak FM stations ............................................... 31

To search for a station automatically ................ 31

Presetting stations ................................................... 31

Tuning into a preset station .................................... 31

Customizing the Function Settings ........ 32-40

LANGUAGE setting .................................................. 32

VIDEO setting ............................................................ 33

TV Shape .............................................................. 33

Video Output ....................................................... 34

Brightness ............................................................ 34

Edges .................................................................... 35

AUDIO setting ........................................................... 36

Digital Out ............................................................ 36

L/R speaker .......................................................... 36

Subwoofer ............................................................ 37

Surround Delay...................................................37

Center Delay........................................................38

Pink noise ........................................................... 38

RATING setting ......................................................... 39

Password/Rating ............................................... 39

Factory Set .......................................................... 40

Language Code List for Disc Language ....... 41

Maintenance ................................................ 42

Cleaning Disc .......................................................... 42

Cleaning the Unit ................................................... 42

Important Note ....................................................... 42

Trouble Shooting Guide ........................ 42-43

E - 3

Disc Formats

The Unit can playback.

DVDs [8cm(3")/12cm(5”) disc]

Audio CDs [12cm(5”) disc]

Region Management Information

Region Management Information: This Unit is designed and manufactured to respond to the Region Management Information that is encoded on DVD discs. If the Region number printed on the DVD disc does not correspond to the Region number of this Unit, this Unit cannot play that disc.

The region number of this Unit is 1.

Disc Function or Operation that is Not Available

When the symbol appears on the TV screen, it indicates that the function or operation attempted is not available at that time. This occurs because the DVD disc manufacturer determines the specific functions. Certain functions may not be available on some discs. Be sure to read the documentation provided with the DVD.

Compatible

Icons Used on DVDs

Sample lcons

1. English

2. French

1. English

2. French

Language selections for audio Language selections for subtitles

Screen aspect ratio

Multiple camera angles Region code indicator

Notes:

• This Unit supports 2-channel (L/R) audio and 5.1ch (Multi-channel) MPEG Audio 1/2 (only when the DIGITAL AUDIO OUT coaxial jack is used for connection). It does not support 7.1 channel MPEG Audio Version 2.0.

• When playing back a CD-G (Graphics) or CD EXTRA disc, the audio portion will be played, but the graphic images will not be shown.

Title, Chapter and Tracks

• DVDs are divided into “titles” and “chapters”. If the disc has more than one movie on it, each movie would be a separate “title”. “Chapters” are sections of titles.

• Audio CDs are divided into “tracks”. A “track” is usually one song on an Audio CD.

Note :

• Numbers identify each title, chapter, and track on a disc. Most discs have these numbers recorded on them, but some do not.

Chapter 1 Chapter 1Chapter 2 Chapter 2Chapter 3

Track 1 Track 2 Tra ck 3 Tra ck 4 Track 5

Notes on Unauthorized Discs

You may not be able to play back some DVD discs on this Unit if they were purchased from outside your geographic area or made for business purposes.

E - 4

Before Y ou Start

Using the Remote Control

• Point the Remote Control at the REMOTE SENSOR located on the Unit.

• When there is a strong ambient light source, the performance of the infrared REMOTE SENSOR may be degraded, causing unreliable operation.

• The recommended effective distance for remote operation is about 16 feet (5 meters).

To install Batteries

1.Open the battery door.

Battery Replacement

When batteries become weak, the operating distance of the Remote Control is greatly reduced and you will need to replace the batteries.

2. Insert two "AA" or UM-3 size batteries.

Notes:

• If the Remote Control is not going to be used for a long time, remove the batteries to avoid damage caused by battery leakage corrosion.

• Do not mix old and new batteries. Do not mix ALKALINE, standard (CARBON-ZINC) or rechargeable (NICKEL-CADMIUM) batteries.

E - 5

Front Panel

Parts and Functions

12 64357

1) POWER button

Turn the power on or off.

2) 5 Disc tray

Open or close tray by pushing OPEN/CLOSE button. Place discs on the disc trays, label side up.

3) Display window

Display system information.

PRO LOGIC indicator

When DOLBY PRO LOGIC sound is selected in AV_IN mode, the light will illuminate.

5) 3 STEREO indicator

When 3 STEREO sound is selected in AV_IN mode, the light will illuminate.

10) VOLUME control

OPEN/CLOSE button

Use to open and close the disc tray.

PLAY button

Press to start or resume playback.

PAUSE button

Press to pause playback. Each time you press the PAUSE button the picture advances one frame. Press the PLAY button to resume playback.

STOP button

Stop playing a disc.

Change the loudness of the sound from the speakers connected to the Unit.

111213141516171819

11) DISPLAY button

12) AV2 button

13) SKIP/SEARCH buttons

Press SKIP/SEARCH chapters/tracks.

Press SKIP/SEARCH button to advance to chapters / tracks. Press and hold SKIP/SEARCH

button to begin fast scan. Four speeds are

available. Scan all available radio stations.

14) AV1 button

15) TUNER button

16) DVD button

17) DISC (1-5) select button 18 ) VIDEO IN (AV2) 19 ) AUDIO IN (L/R) jacks (AV2) 20 ) Remote sensor

Accept the remote control unit signals.

STANDBY indicator

21)

When the Unit is turned on by pressing the POWER button, the light will illuminate. If you press the power button on the remote control, the Unit will turn on.

button to go back to previous

Note:

Screen saver - If no button is pressed within 2 minutes, the screen save function will activate, If you want to return to the normal screen, press any button.

(Continued on next page)(Continued on next page)

(Continued on next page)

E - 6

(Continued on next page)(Continued on next page)

Rear Panel

Parts and Functions

2322

Sub-Woofer

RLL

Front Panel

2425

Rear Panel

22) AM LOOP ANTENNA terminal

23) FM ANTENNA jacks

24) Power cord

25) DIGITAL AUDIO OUT jack

26) AUDIO OUT jack (SUB-WOOFER)

27) S-VIDEO (DVD) output jack

28) VIDEO OUT jack

29) AUDIO OUT (L/R) jacks

30) VIDEO IN (VCR) jack (AV1)

31) AUDIO IN (L/R) jacks (AV1)

32) Front speaker (R) terminals

33) AUDIO IN 5.1CH jack

34) Rear speaker (R) terminals

35) Center speaker terminals

36) Rear speaker (L) terminals

37) Front speaker (L) terminals

38) Power cord

39) POWER indicator

E - 7

(Continued on next page)(Continued on next page)

(Continued on next page)

(Continued on next page)(Continued on next page)

Remote Control

MEMORY

DIMMER DISC 1

PRO LOGIC

7 8

SETUP MENU

9 10

SLOW SLOW

11 12

STOP

14 15 16

CLEAR

ANGLE SUBTITLE FM M O DE BAND

17 18

Parts and Functions

OPEN/

2.1 CH5.1 CH

DISC 2

DISC 5

PAUS E

A-B DISC

REPEAT

GOTO

SOUND

DISC 3

FUNCTION

RETURN

DISC 4

VOLUM E

ENTER

PLAY

TUNING NEXT

DISPLAY ZOOM AUDIO

1) Power button

Turns the Unit on and puts it in standby mode.

2) RETURN button

Return to the normal operation after using the SETUP menu.

3) Number (0 - 9) and (+10) buttons

Use when creating programs, and entering a parental level password. To select numbers over 9, press +10 button and then the second no. for example, to enter 18, press +10 and then 8.

4) 5.1 Ch button

Switch speaker output to 5.1 channel mode. (All speakers + subwoofer)

5) MEMORY button

Enter the number of a selected chapter or track. Enter the number of a selected station.

6) DIMMER button

Adjust the brightness of the front panel display to the level you prefer.

PRO LOGIC button

In AV_IN mode, switches to Dolby Pro Logic mode for VHS tapes encoded with Dolby Pro Logic.

8) VOLUME (+ / -) buttons

Adjust the volume.

9) SETUP button

Selects the SET UP menu screen.

10) / CURSOR buttons

Use to highlight selections on a menu screen and adjust certain settings.

11) SLOW button

Perform slow reverse playback of DVDs.

TUNING buttons

12)

: Fast reverse playback. : Fast forward playback. TUNING : Scan all available radio stations.

13) STOP button

Stop playback.

14) PREV button

Move reverse through titles, chapters or tracks on a disc. Tune to the presetted stations.

15) CLEAR button

Clear input selections and cancel certain playback functions.

16) DISPLAY (DISP) button

Change disc status information displayed on the TV.

17) ANGLE button

Switch the camera angle of the video presentation when scenes with multiple camera angles are recorded on a DVD.

18) SUBTITLE button

.....

Select one of the subtitle languages programmed on a DVD.

E - 8

(Continued on next page)(Continued on next page)

(Continued on next page)

(Continued on next page)(Continued on next page)

Remote Control

FUNCTION

RETURN

MEMORY

DIMMER

PRO LOGIC

SETUP MEN U

SLOW SLOW

STOP

CLEAR

DISPLAY ZOOM AUDIO

ANGLE SUBTITLE FM M ODE BAND

2.1 CH5.1 CH

DISC 1

DISC 2

DISC 4

DISC 5

VOLUME

ENTER

PLAY

TUNING NEXT

A-B DISC

REPEAT

OPEN/

GOTO

SOUND

DISC 3

PAUS E

Parts and Functions

19) FUNCTION button

20 21

22 23

25 26

27 28

29 30

31 32

33 34

Display the FUNCTION screen where you can check or change various setting.

20) OPEN / CLOSE button

Use to open or close the disc tray.

21) GOTO button

Skip directly to a specific location on a DVD disc.

22) 2.1 CH button

Switch speaker outputs to 2.1 channel. (Front left/ right speakers + subwoofer)

23) SOUND button

Selects sound balance and tone controls for adjustment with the cursor buttons.

24 ) DISC (1-5) select buttons

/ CURSOR buttons

25)

Use to highlight selections on a menu screen and make adjust certain settings.

26) MENU button

Open and close DVD's menu.

27) ENTER button

Confirm selections on a menu screen.

28 ) SLOW

button

Perform slow forward playback of DVDs.

29)

PLAY button

Start playback.

PAUSE button

30)

Pause playback, frame advance.

31 ) NEXT

button

Move forward through titles, chapters or tracks on a disc.

Tune to the presetted stations.

32) AUDIO button

Select one of the audio soundtracks programmed on a DVD or selects the audio output mode on a AUDIO CD.

33) ZOOM button

Zoom into an image.

34) BAND/REPEAT-DISC button

Switch between AM or FM. Repeat chapter or title of a DVD. Repeat single track or whole CD.

35) FM MODE / REPEAT A - B button

Set FM MODE to FM STEREO for FM stereo sound or to FM MONO for mono sound.

Perform point-to-point repeat playback on a DVD or CD.

E - 9

Front Panel Display

Display

CD indicator

Displayed during CD playback.

STEREO indicator

Tune into a station. "((ST))" will appear

REPEAT 1 playback indicator

Displayed during repeat playback.

TUNER indicator

Displayed during TUNER

mode. when an FM broadcast is in stereo.

Disc holder indicators

The number will blink when a certain disc is

Main display section

playing.

Indicates the operation status of the disc and Unit.

Display Information

The DVD displays the information shown below on the TV screen and on the Unit's DVD display depending on the operation status.

Display Examples

If no disc is loaded when the Main Unit is switched on.

Tray open

TV Screen

No Disc

Open

Unit Display

Remarks

" appears when the tray is closed and:

1)There is no disc in the tray.

2) The disc type is not playable in this Unit.

3) The disc is not loaded correctly (upside-down, etc.)

Tray closed Loading Stopped

Playing Paused

Fast forward Fast reverse Slow

Repeat A - B

Stop

Play

Pause

x 2

x 1/2

A -

A-B

The display changes to show other indicators (total time, etc.)

Freezes the image on the screen or pauses audio playback. The display changes to show other indicators (total

time, etc.) Does not function for Audio CDs. Repeat a specific section.

The operation is not permitted by the DVD Unit or the disc.

Region (Local) Number Error Indicator

If the region (local) number of the disc that you attempt to play differs from the region number of the Unit, "Invalid Region" appears on the TV screen. (The disc cannot be played).

E - 10

Setup

For better reception

Connect FM antenna (included) to the FM ANTENNA jacks.

Connect the loop antenna (included) to the AM LOOP ANTENNA terminals.

A.Connecting your TV

The Unit can be connected to your TV in several different ways, depending on the design of your TV.

RCA Audio/Video Jacks

Use the included Audio/Video cable.

1. Connect the VIDEO OUT and left/ right AUDIO OUT jacks to the VIDEO and left/right AUDIO IN jacks on your TV.

AM(MW) LOOP ANTENNA (SUPPLIED)

RLL

DVD Unit

To AUDIO OUT

(white)

(red)

To VID EO

OUT

(yellow)

(white)

FM antenna

To wall outlet

VIDEO IN

AUDIO IN

To AUDIO INTo VID EO I N

(red)

S-Video Jack

Use an S-Video cable (sold

DVD Uni t

separately) and the Audio/Video cable (included).

1. Use an S-Video cable to connect

the S-VIDEO (DVD) jack on your

Unit to the S-VIDEO IN jack on your TV.

AUDIO IN

Coaxial Antenna Jack

Some TVs do not have an RCA or S-Video jack, they only have a coaxial antenna jack. In order to connect this Unit to these TVs, you must purchase an RF modulator (available in the Audio/Video department of most electronics retailers or at http://www.18002526123.com) and follow the instructions included with it.

(continued to next page)(continued to next page)

(continued to next page)

E - 11

(continued to next page)(continued to next page)

Setup

B. Connecting a VCR

1.Using the supplied Audio/Video cable, connect the y ellow plug from VIDEO OUT jack on your Unit to VIDEO IN

jack on your TV, connect the left and right AUDIO OUT jacks on your Unit to AUDIO IN jacks on your TV. If you want the sound come from the speakers of the Main Unit, you need not to connect these left and right Audio cable from the Main Unit to your TV.

2.Using the Video cable (not supplied), connect the VIDEO IN (VCR) jack on your Unit to VIDEO OUT jac k on y our

VCR.

3.Using the Audio cable (not supplied), connect the left/right A UDIO IN jacks on your Unit to the AUDIO OUT jacks

on your VCR.

To AUDIO IN

DVD Unit

(white)

(red)

To AUDIO OUT

(red)

VCR

AUDIO OUT

To VID EO I N

(yellow)

To AUDIO OUT

(white)

(red)

To VID EO

OUT

(yellow)

(white)

To VIDEO OUT

(yellow)

To VID EO I N

(yellow)

(white)

To AUDIO IN

(red)

VIDEO IN

AUDIO IN

Watching a DVD

1. Turn on the Unit, use the FUNCTION button on the remote control or DVD button on the front panel to select

"DVD".

2.Turn on your TV and follow the instructions included with it to select the VIDEO input which corresponds to the

VIDEO IN jack you connected to the Unit to.

Watching a Videotape

1. Tur n on the Unit, use the FUNCTION button on the remote control or AV1, AV2 buttons on the front panel to

select "A V_IN".

2.Turn on your TV and follow the instructions included with it to select the VIDEO input which corresponds to the

VIDEO IN jack that is connected to the Unit.

3. Tur n on the VCR and follow the instructions included with it to play the videotape.

Note:

• If you have a mono VCR, the volume le v el from the speak ers will be low. To avoid this , connect the left/right audio

out from the Unit to the left/right audio inputs on your TV using the included A/V cable.

(continued to next page)(continued to next page)

(continued to next page)

E - 12

(continued to next page)(continued to next page)

Setup

C. Connecting another source

Using the supplied Audio/Video cable, connect ONLY the left and right AUDIO OUT jack on your Unit to the AUDIO IN jack or use a coaxial digital Audio cable (not supplied) to connect to the coaxial in jack on your another equipment. Do not connect the yellow video plug.

Listening to another audio equipment

1. Turn on the Unit.

2.Turn on your audio equipment and follow the instructions included with it to select the AUDIO IN or DIGITAL IN

function.

Analogue connection

DVD Unit

Amplif ier of st ere o

system, etc. (not included)

Digital connection

DVD Unit

To AUDIO OU T

(white)

(red)

(yellow)

To AUDIO IN

(white) (red) (yellow)

Audio equipm ent with

digital audio input jack

AUDIO IN

COAXIAL

Notes:

• If the external equipment is a television and this audio system is closed to it, you may experience interference

if the tuner function is selected while the television is working.

• When you have selected TUNER function, sound will ONLY come from the front left, right speakers and subw oofer .

• While VCR connect to DVD Unit, for some VCR has stereo, mono, L or R etc. different mode can be selected,

make sure always set your VCR at stereo moce, otherwise the active speakers may different from E-18 "The following tables show which speakers are working in various modes" information.

• Due to copyright protection, DVD movies cannot be copied. If you copy a DVD movie onto a videotape, the

resulting copy will be unclear, with poor sound quality. This is NOT caused by a defective DVD system.

• When playing VCR, press the FUNCTION button on the remote control or AV1, AV2 buttons on the front panel

to AV_IN mode, all speakers will be activated about few seconds later.

(continued to next page)(continued to next page)

(continued to next page)

E - 13

(continued to next page)(continued to next page)

+ 30 hidden pages
