Zebra MC17, MC17A, MC17U, MC17T Quick Reference Manual

MC17/MC17A/
MC17T/MC17U

QUICK REFERENCE GUIDE

2 MC17/MC17A/MC17T/MC17U Mobile Computer

Zebra reserves the right to make changes to any
product to improve reliability, function, or design.

Zebra does not assume any product liability arising out
of, or in connection with, the application or use of any
product, circuit, or application described herein.

No license is granted, either expressly or by implication,
estoppel, or otherwise under any patent right or patent,
covering or relating to any combination, system,
apparatus, machine, material, method, or process in
which Zebra products might be used. An implied license
exists only for equipment, circuits, and subsystems
contained in Zebra products.

Software Support

Zebra wants to ensure that customers have the latest
release of entitled software at the time of product
purchase.

To confirm that your Zebra device shipped with the latest
release of entitled software, visit:
www.zebra.com/support. Check for the latest software
from Software Downloads > Product Line/Product > Go.

If your device does not have the latest entitled software
release as of your product purchase date, please e-mail
a request to Zebra at: [e-mail].

You must include the following essential device
information with your request:

•

Model number

•

Serial number

•

Proof of purchase

•

Title of the software download you are requesting.

If it is determined by Zebra that your device is entitled to
the latest software release, you will receive an e-mail
containing a link directing you to a Zebra Web site to
download the appropriate software.

Quick Reference Guide 3

Introduction

This Quick Reference Guide explains how to install and
charge the battery, scan bar codes, reset, maintain and
troubleshoot the mobile computer.

Unpacking

Carefully remove all protective material from around the
mobile computer and save the shipping container for
later storage and shipping.

Verify that you received all equipment listed below:

•

MC17 mobile computer

•

Lithium-ion battery (2400 mAh)

•

Quick Reference Guide.

Inspect the equipment for damage. If you are missing
any equipment or if you find any damaged equipment,
contact the Zebra Support immediately. See Service
Information on backcover for contact information.

Features

MC17

series

LED

Bezel

Display

Scroll Left key

Enter key

Scroll Right key

Scroll Down key

Scan key

Scroll Up key

4 MC17/MC17A/MC17T/MC17U Mobile Computer

Scan Exit Window

Access Cover

LED State

Speaker

Battery Cover

Power Connector

Description

Solid Red

Solid Green

Getting Started

In order to start using the mobile computer you must
install the battery and then charge it.

Installing the Battery

1.

Remove tape securing battery cover to handle.

2.

Remove screw from screw hole (under tape).

3.

Slide the battery cover toward the bottom of the
handle and then lift.

Scanner is enabled.

Bar code decode successful.

Screw Under Tape

Tape

Quick Reference Guide 5

4.

Ensure that

compartment is lying flat along the bottom of the
compartment, with its smoother side facing up, and
the rubber “fingers” straddling the screw boss.

5.

Ensure the wire latch is in the up position.

6.

Place the battery, rounded side down, in the
compartment. Using a non-metallic tool (if necessary),
guide the battery cable connector into the female battery
connector on the mobile computer.

the black rubber pad

Wire Latch

in

the

battery

The connector is keyed so it only fits one way.

7.

Press the connector down to ensure a positive
connection.

8.

Place wire latch down until just below top of the screw
boss.

Wire Latch

Screw Boss

9.

Place the battery cover onto the handle and slide it
as shown.

6 MC17/MC17A/MC17T/MC17U Mobile Computer

10.

Inspect the position of the battery cover with the main
housing. If the door is misaligned, remove battery
and black rubber pad and re-install.

Battery Door Properly

11.

Aligned

Secure the battery cover with the Torx screw using a
T8 Torx drive. Torque the screw to 3.3 ±0.2 Kgf-cm
(2.8 ±0.17 in-lb).

12.

After installing a new battery, wait approximately one
minute before inserting the mobile computer into a
cradle.

Charging the Battery

Before using the mobile computer, charge the battery.

1.

Ensure the Charging cradle, p/n PSS-3CR01-00R or
PSS-3CR01-NLR, is connected to the appropriate
power source. Refer to the MC17 Product Reference
Guide for detailed information.

2.

Insert the mobile computer into the cradle.

Red Charging LED
Location

Quick Reference Guide 7

3.

The mobile computer starts to charge automatically.
The mobile computer fully charges in approximately
five hours. While charging, a red charging LED can
be seen through the front panel of the cradle behind
the mobile computer. Refer to the MC17 Product
Reference Guide for specific charging profile
information.

Manual Release of Mobile Computer from Charging
Cradle

The Charging cradle, p /n PSS-3CR01-00R, contains a
locking mechanism that locks the mobile computer into
the cradle. The mobile computer releases from the
cradle via a software command to the cradle. If the
mobile computer does not have the capability to un-lock
the cradle, un-lock it manually using the optional
dispenser (cradle) key, (p/n PSS-3KY01-00R).

1.

Hold the key with hook end pointing to the right.

2.

Insert the key straight into the slot, only to the point
where bend stops on the lip of the slot.

3.

Slide the key to the right until the handle is centered
in the slot.

4.

Rotate the key 90 degrees (1/4 turn)
counterclockwise.

5.

Keeping the handle of the key all the way to the right
in the slot, press the key into the slot. The end of the
key should press on a small spring loaded tab within
the cradle.

8 MC17/MC17A/MC17T/MC17U Mobile Computer

6.

While holding the key down, lift the mobile computer
out of the cradle.

Scanning

To scan bar codes:

1.

Launch a scanning application.

2.

Press the scan key and aim the mobile computer at a
bar code.

The LED turns red to indicate the scanner is on.

3.

Adjust the aim so that the thin, red laser beam covers
the entire length of the bar code.

Correct

Incorrect

012345

4.

If the decode is successful the LED turns green. The
terminal beeps if programmed accordingly.

Scanning Tips

•

For larger bar codes, hold the mobile computer
farther away from the bar code.

•

For bar codes with bars that are closer together, hold
the mobile computer closer to the bar code.

•

The optimal scanning distance varies with bar code
density, but 10 to 25 cm (4 to 10 inches) generally
works. Practice to determine what distances to work
within.

•

Position the scanner at an angle to the bar code. If
the mobile computer is perpendicular to the bar code
being scanned, light can bounce back into the
scanner’s exit window and prevent a successful
decode.

012345

Quick Reference Guide 9

Resetting the Mobile Computer

Warm Boot

A warm boot restarts the mobile computer by closing all
running programs.

Press and simultaneously hold the Up Arrow and the
Down Arrow keys for 10 seconds and then press the
Scan key. Release the Up Arrow and the Down Arrow
keys. Wait one second and then release the Scan key.

Cold Boot

A cold boot restarts the mobile computer and erases all
user stored records and entries that are not saved in
flash memory (Application and Platform folders). Never

perform a cold boot unless a warm boot does not solve
the problem.

Press and simultaneously hold the Up Arrow and Down
Arrow keys for 10 seconds and then press and hold the
Scan key. Release the Up and Down Arrow keys and
continue to hold the Scan key until the display turns off.
Release the Scan key.

Maintenance

•

Protect the mobile computer from temperature
extremes.

•

Do not store or use the mobile computer in any
location that is extremely dusty, damp, or wet.

•

Use a soft lens cloth to clean the mobile computer. If
the surface of the mobile computer screen becomes
soiled, clean it with a soft cloth moistened with a
diluted window-cleaning solution.

•

Periodically replace the rechargeable battery to
ensure maximum battery life and product
performance. Battery life depends on individual
usage patterns. Refer to the MC17 Product
Reference Guide for more information.

•

Take care not to scratch the bezel of the mobile
computer. Replacement standard and custom Bezel
Kits are available, p/n KT-098273-XXR.

Bezel Replacement

The plastic bezel can be replaced with a new or
customer specific bezel.

10 MC17/MC17A/MC17T/MC17U Mobile Computer

1.

Place the mobile
computer on a
desktop with the
display facing
down.

2.

Using a T6 Torx
drive, remove two
screws securing
the bezel to the
housing.

3.

Align the
replacement bezel
on the housing.

4.

Using a T6 Torx
drive, secure the bezel to the housing using the two
Torx screws.

5.

Torque the screws to 2.5 ± 0.2 kgf-cm (2.17 ± 0.17
in-lbs.).

Troubleshooting

Problem

Mobile
computer
does not turn
on.

Recharge­able battery
did not
charge.

Cause

Battery not
charged.

Battery not
installed
properly.

The system is
not respond­ing.

Mobile Com­puter is in a
critical sus­pend state due
to low battery.

Battery failed. Replace battery. If the mobile

Mobile com­puter removed
from cradle
while battery
was charging.

Charge or replace the battery.

Install the battery properly.
See Installing the Battery on
page 4.

Perform a warm boot. If the
mobile computer still does not
turn on, perform a cold boot.

Place the mobile computer in
the Charging cradle. The
mobile computer re-boots and
begins charging.
Depending on how depleted
the battery is, the mobile com­puter may take up to five min­utes before it turns on.

computer still does not oper­ate, perform a warm boot. See

Resetting the Mobile Com­puter on page 9.

Insert mobile computer in cra­dle. The battery fully charges
in approximately five hours.

Solution

Quick Reference Guide 11

Problem

Mobile com­puter shuts
off.

The mobile
computer
does not
accept scan
input.

Battery is
depleted.

Battery is not
connected
properly.

The system is
not respond­ing.

Scanning
application is
not loaded.

Unreadable
bar code.

Distance
between exit
window and
bar code is
incorrect.

Mobile com­puter is not pro­grammed for
the bar code.

Cause

Solution

Recharge the battery.

Connect the battery properly.
See Installing the Battery on
page 4.

Warm boot the mobile com­puter.

Launch a scanning application
on the mobile computer. See
the system administrator.

Ensure the symbol is not
defaced.

Position the mobile computer
within proper scanning range.

Program the mobile computer
to accept the type of bar code
being scanned. Ensure that
the bar code parameters are
set properly for the bar code
being scanned.

Ergonomic Recommendations

CAUTION

•

Reduce or eliminate repetitive motion

•

Maintain a natural position

•

Reduce or eliminate excessive force

•

Keep objects that are used frequently within easy
reach

•

Perform tasks at correct heights

•

Reduce or eliminate vibration

•

Reduce or eliminate direct pressure

•

Provide adjustable workstations

•

Provide adequate clearance

•

Provide a suitable working environment

•

Improve work procedures.

Regulatory Information

This guide applies to the following model numbers:
MC1770, MC1790.

In order to avoid or minimize the potential
risk of ergonomic injury follow the
recommendations below. Consult with your
local Health & Safety Manager to ensure
that you are adhering to your company’s
safety programs to prevent employee injury.

12 MC17/MC17A/MC17T/MC17U Mobile Computer

All Zebra devices are designed to be compliant with
rules and regulations in locations they are sold and will
be labeled as required.

Local language translations are available at the
following web site: http://www.zebra.com/support.

Any changes or modifications to Zebra equipment, not
expressly approved by Zebra, could void the user's
authority to operate the equipment.

CAUTION

Radio Modules

The device contain approved radio module(s). These
module(s) are identified below.

•

WLAN SDIO Radio Module, Model: 21-92955.

Wireless Device Country Approvals

Regulatory markings, subject to certification, are applied
to the device signifying the radio(s) are approved for use
in the following countries: United States, Canada,

Japan, China, S. Korea, Australia and Europe 1.

Please refer to the Zebra Declaration of Conformity
(DoC) for details of other country markings. This is
available at http://www.zebra.com/doc.

Note1: For 2.4GHz Products: Europe includes, Austria,
Belgium, Bulgaria, Czech Republic, Cyprus, Denmark,
Estonia, Finland, France, Germany, Greece, Hungary,
Iceland, Ireland, Italy, Latvia, Liechtenstein, Lithuania,
Luxembourg, Malta, Netherlands, Norway, Poland,
Portugal, Romania, Slovak Republic, Slovenia, Spain,
Sweden, Switzerland and the United Kingdom.

Operation of the device without regulatory approval
is illegal.

Country Roaming

This device incorporates the International Roaming
feature (IEEE802.11d) which will ensure the product
operates on the correct channels for the particular
country of use.

Only use Zebra approved and UL Listed
accessories, battery packs and battery
chargers.

Do NOT attempt to charge damp/wet mobile
computers or batteries. All components
must be dry before connecting to an
external power source.

Quick Reference Guide 13

Ad-hoc Operation (2.4 GHz band)

Ad-Hoc operation is limited to Channels 1-11 (2412­2462 MHz).

Frequency of Operation - IC

5 GHz Only

The use in the UNII (Unlicensed National Information
Infrastructure) band 1 5150-5250 MHz band is restricted
to Indoor Use Only; any other use will make the
operation of this device illegal.

2.4 GHz Only

The available channels for 802.11 b/g operation in the
US are Channels 1 to 11. The range of channels is
limited by firmware.

Warnings for Use of Wireless

Devices

Please observe all warning notices with regard to the
usage of wireless devices.

Pacemakers

Pacemaker manufacturers recommended that a
minimum of 15 cm (6 inches) be maintained between a
handheld wireless device and a pacemaker to avoid
potential interference with the pacemaker. These
recommendations are consistent with independent
research and recommendations by Wireless Technology
Research.

Persons with Pacemakers

•

Should ALWAYS keep the device more than 15 cm (6
inches) from their pacemaker when turned ON

•

Should not carry the device in a breast pocket

•

Should use the ear furthest from the pacemaker to
minimize the potential for interference.

•

If you have any reason to suspect that interference is
taking place, turn OFF your device.

Other Medical Devices

Please consult your physician or the manufacturer of the
medical device, to determine if the operation of your
wireless product may interfere with the medical device.

14 MC17/MC17A/MC17T/MC17U Mobile Computer

RF Exposure Guidelines

Safety Information

Reducing RF Exposure - Use Properly

Only operate the device in accordance with the
instructions supplied.

International

The device complies with Internationally recognized
standards covering human exposure to electromagnetic
fields from radio devices.

EU

Handheld Devices

To comply with EU RF exposure requirements, this
device must be operated in the hand with a minimum
separation distance of 20 cm or more from a person’s
body. Other operating configurations should be avoided.

US and Canada

Co-located statement

To comply with FCC RF exposure compliance
requirement, the antenna used for this transmitter must
not be co-located or operating in conjunction with any
other transmitter/antenna except those already
approved in this filling.

Handheld Devices (that cannot be body worn in a belt
clip/holster)

To comply with FCC RF exposure requirements, this
device must be operated in the hand with a minimum
separation distance of 20 cm or more from a person's
body. Other operating configurations should be avoided.

Laser Devices

Complies with 21CFR1040.10 AND 1040.11 Except For
Deviations Pursuant To Laser Notice NO. 50, dated
June 24, 2007 and IEC 60825-1 (Ed. 2.0), EN60825-1:

2007. The laser classification is marked on one of the
labels on the device.

Class 1 Laser devices are not considered to be
hazardous when used for their intended purpose. The
following statement is required to comply with US and
international regulations:

Quick Reference Guide 15

Caution: Use of controls, adjustments or performance of
procedures other than those specified herein may result
in hazardous laser light exposure.

Class 2 laser scanners use a low power, visible light
diode. As with any very bright light source, such as the
sun, the user should avoid staring directly into the light
beam. Momentary exposure to a Class 2 laser is not
known to be harmful.

Scanner Labeling

COMPLIES WITH 21CFR1040.10 AND 1040.11 EXCEPT FOR
DEVIATIONS PURSUANT TO LASER NOTICE No. 50, DATED
JUNE 24, 2007 AND IEC 60825-1 (Ed. 2.0), EN60825-1: 2007.

Taiwan - Recycling

Waste Disposal Act are required to indicate the
recycling marks on the batteries used in sales, giveaway
or promotion. Contact a qualified Taiwanese recycler for
proper battery disposal.

Radio Frequency Interference
Requirements-FCC

15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However there is no guarantee that
interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio
or television reception, which can be determined by
turning the equipment off and on, the user is

EPA (Environmental Protection
Administration) requires dry battery
producing or importing firms in
accordance with Article 15 of the

Note: This equipment has been tested
and found to comply with the limits for a
Class B digital device, pursuant to Part

16 MC17/MC17A/MC17T/MC17U Mobile Computer

encouraged to try to correct the interference by one or
more of the following measures:

•

Reorient or relocate the receiving antenna

•

Increase the separation between the equipment and
receiver

•

Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected

•

Consult the dealer or an experienced radio/TV
technician for help.

Radio Transmitters (Part 15)

This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired
operation.

Radio Frequency Interference Requirements - Canada

This Class B digital apparatus complies with Canadian
ICES-003. Cet appareil numérique de la classe B est
conforme à la norme NMB-003 du Canada.

Radio Transmitters

This device complies with RSS 210 of Industry &
Science Canada. Operation is subject to the following
two conditions: (1) this device may not cause harmful
interference and (2) this device must accept any
interference received, including interference that may
cause undesired operation.

Label Marking: The Term “IC:” before the radio
certification only signifies that Industry Canada technical
specifications were met.

For RLAN Devices

The use of 5 GHz RLAN’s, for use in Canada, have the
following restrictions:

•

Restricted Band 5.60 – 5.65 GHz

Marking and European Economic

Area (EEA)

The use of 2.4GHz RLAN's, for use through the EEA,
have the following restrictions:

Quick Reference Guide 17

•

Maximum radiated transmit power of 100 mW
EIRP in the frequency range 2.400 -2.4835 GHz

Statement of Compliance

Zebra, hereby, declares that this device is in
compliance with the essential requirements and other
relevant provisions of Directive 1999/5/EC and
2011/65/EU. A Declaration of Conformity may be
obtained from http://www.zebra.com/doc/.

Japan (VCCI) - Voluntary Control Council
for Interference

この装置は、情報処理装置等電波障害自主規制協議会

（ＶＣＣＩ）の基準に基づくクラス B 情報技術装置で

す。この装置は、家庭環境で使用することを目的とし
ていますが、この装置がラジオやテレビジョン受信機
に近接して使用されると、受信障害を引き起こすこと
があります。 取扱説明書に従って正しい取り扱いをし
て下さい。

This is a Class B product based on the standard of the
Voluntary Control Council for Interference from
Information Technology Equipment (VCCI). If this is
used near a radio or television receiver in a domestic
environment, it may cause radio interference. Install
and use the equipment according to the instruction
manual.

Other

Countries

Australia

Use of 5GHz RLAN’s in Australia is restricted in the
following band 5.50 – 5.65GHz.

Brazil

Declarações Regulamentares para MC1770 / MC1790.

Nota: A marca de certificação se aplica ao

Transceptor,
modelo MC1770 / MC1790. Este equipamento opera
em carácter secundário, isto é, não tem direito a
proteção contra interferência prejudicial, mesmo de
estações do mesmo tipo, e não pode causar
interferência a sistemas operando em carácter
primário.

18 MC17/MC17A/MC17T/MC17U Mobile Computer

Mexico - Restrict Frequency Range to: 2.450 - 2.4835
GHz.

Taiwan -

射性電機管理辦法 第十二條

經型式認證合格之低功率射頻電機，非經許可，公司、商號
或使用者均不得擅自變更頻率、加大功率或變更原設計之特
性及功能。

第十四條 低功率射頻電機之使用不得影響飛航安全及干擾合
法通信；

經發現有干擾現象時，應立即停用，並改善至無干擾時方得
繼續使用。

前項合法通信，指依電信規定作業之無線電通信。 低功率射
頻電機須忍受合法通信或工業、科學及醫療用電波

輻射性電機設備之干擾。

在 5.25-5.35 秭赫頻帶內操作之無線資訊傳輸設備，限
於室內使用。

Korea

당해 무선설비는 운용 중 전파혼신 가능성이 있음
당해 무선설비 는전파혼 신 가능성이 있으므로

인명안전과 관련된 서비스는 할 수 없습니다 .

Battery Information

Zebra rechargeable battery packs are designed and
constructed to the highest standards within the industry.

However, there are limitations to how long a battery can
operate or be stored before needing replacement. Many
factors affect the actual life cycle of a battery pack, such
as heat, cold, harsh environmental conditions and
severe drops.

When batteries are stored over six (6) months, some
irreversible deterioration in overall battery quality may
occur. Store batteries discharged in a dry, cool place,
removed from the equipment to prevent loss of capacity,
rusting of metallic parts and electrolyte leakage. When
storing batteries for one year or longer, they should be
charged and discharged at least once a year. If an
electrolyte leakage is observed, avoid any contact with
affected area and properly dispose of the battery.
Batteries must be charged within the 32° to 104° F (0° to
+40° C) ambient temperature range.

臺灣

低功率電波輻

Quick Reference Guide 19

Replace the battery when a significant loss of run time is
detected.

Standard warranty period for all Zebra batteries is one
year, regardless if the battery was purchased separately
or included as part of the mobile computer. For more
information on Zebra batteries, please visit:
http://www.zebra.com/batterybasics

20 MC17/MC17A/MC17T/MC17U Mobile Computer

Battery Pack Information

CAUTION

Danger of explosion if battery is incorrectly
replaced. Replace only with the same or
equivalent type recommended by the
manufacturer. Dispose of used batteries
according to the manufacturer’s instructions.

This device is equipped with a removable and
rechargeable Lithium polymer battery. When a
replacement is needed, please request the dealer from
whom your device was purchased to assist you. Use
only manufacturer approved batteries.

Battery Pack Reminders

•

The area in which the units are charged should be
clear of debris and combustible materials or
chemicals. Particular care should be taken where the
device is charged in a non commercial environment.

•

Follow battery usage, storage, and charging
guidelines found in the user's guide.

•

Improper battery use may result in a fire, explosion,
or other hazard.

•

To charge the mobile device battery, the battery and
charger temperatures must be between +32 ºF and
+104 ºF (0 ºC and +40 ºC)

•

Do not use incompatible batteries and chargers. Use
of an incompatible battery or charger may present a
risk of fire, explosion, leakage, or other hazard. If you
have any questions about the compatibility of a
battery or a charger, contact Zebra support.

•

Do not disassemble or open, crush, bend or deform,
puncture, or shred.

•

Severe impact from dropping any battery-operated
device on a hard surface could cause the battery to
overheat.

•

Do not short circuit a battery or allow metallic or
conductive objects to contact the battery terminals.

•

Do not modify or remanufacture, attempt to insert
foreign objects into the battery, immerse or expose to
water or other liquids, or expose to fire, explosion, or
other hazard.

•

Do not leave or store the equipment in or near areas
that might get very hot, such as in a parked vehicle or
near a radiator or other heat source. Do not place
battery into a microwave oven or dryer.

•

Battery usage by children should be supervised.

Quick Reference Guide 21

•

Please follow local regulations to promptly dispose of
used re-chargeable batteries.

•

Do not dispose of batteries in fire.

•

Seek medical advice immediately if a battery has
been swallowed.

•

In the event of a battery leak, do not allow the liquid
to come in contact with the skin or eyes. If contact
has been made, wash the affected area with large
amounts of water and seek medical advice.

•

If you suspect damage to your equipment or battery,
contact Zebra support to arrange for inspection.

Use with Hearing Aids

When some wireless devices are used near some
hearing devices (hearing aids and cochlear implants),
users may detect a buzzing, humming, or whining noise.
Some hearing devices are more immune than others to
this interference noise, and wireless devices also vary in
the amount of interference they generate. In the event of
interference you may want to consult your hearing aid
supplier to discuss solutions.

Waste Electrical and Electronic
Equipment (WEEE)

English: For EU Customers: All products at the end of their

life must be returned to Zebra for recycling. For information
on how to return product, please go to:
http://www.zebra.com/weee.
Français: Clients de l'Union Européenne : Tous les produits
en fin de cycle de vie doivent être retournés à Zebra pour
recyclage. Pour de plus amples informations sur le retour de
produits, consultez : http://www.zebra.com/weee.
Español: Para clientes en la Unión Europea: todos los
productos deberán entregarse a Zebra al final de su ciclo de
vida para que sean reciclados. Si desea más información
sobre cómo devolver un producto, visite:
http://www.zebra.com/weee.
Bulgarish: За клиенти от ЕС: След края на полезния им
живот всички продукти трябва да се връщат на Zebra за
рециклиране. За информация относно връщането на
продукти, моля отидете на адрес:
http://www.zebra.com/weee.
Deutsch: Für Kunden innerhalb der EU: Alle Produkte
müssen am Ende ihrer Lebensdauer zum Recycling an
Zebra zurückgesandt werden. Informationen zur
Rücksendung von Produkten finden Sie unter
http://www.zebra.com/weee.

Quick Reference Guide 21

Italiano: per i clienti dell'UE: tutti i prodotti che sono giunti al
termine del rispettivo ciclo di vita devono essere restituiti a
Zebra al fine di consentirne il riciclaggio. Per informazioni
sulle modalità di restituzione, visitare il seguente sito Web:
http://www.zebra.com/weee.
Português: Para clientes da UE: todos os produtos no fim
de vida devem ser devolvidos à Zebra para reciclagem. Para
obter informações sobre como devolver o produto, visite:
http://www.zebra.com/weee.
Nederlands: Voor klanten in de EU: alle producten dienen
aan het einde van hun levensduur naar Zebra te worden
teruggezonden voor recycling. Raadpleeg
http://www.zebra.com/weee voor meer informatie over het
terugzenden van producten.
Polski: Klienci z obszaru Unii Europejskiej: Produkty
wycofane z eksploatacji nale¿y zwróciæ do firmy Zebra w
celu ich utylizacji. Informacje na temat zwrotu produktów
znajduj¹ siê na stronie internetowej
http://www.zebra.com/weee.
Čeština: Pro zákazníky z EU: Všechny produkty je nutné po
skonèení jejich životnosti vrátit spoleènosti Zebra
k recyklaci. Informace o zpùsobu vrácení produktu najdete
na webové stránce: http://www.zebra.com/weee.
Eesti: EL klientidele: kõik tooted tuleb nende eluea lõppedes
tagastada taaskasutamise eesmärgil Zebra'ile.
Lisainformatsiooni saamiseks toote tagastamise kohta
külastage palun aadressi: http://www.zebra.com/weee.
Magyar: Az EU-ban vásárlóknak: Minden tönkrement
terméket a Zebra vállalathoz kell eljuttatni újrahasznosítás
céljából. A termék visszajuttatásának módjával kapcsolatos
tudnivalókért látogasson el a http://www.zebra.com/weee
weboldalra.

Românesc: Pentru clienţii din UE: Toate produsele, la sfârşitul

duratei lor de funcţionare, trebuie returnate la
reciclare. Pentru informaţii despre returnarea produsului,
accesaţi:

http://www.zebra.com/weee.

Slovenski: Za kupce v EU: vsi izdelki se morajo po poteku
življenjske dobe vrniti podjetju Zebra za reciklažo. Za
informacije o vraèilu izdelka obišèite:
http://www.zebra.com/weee.
Svenska: För kunder inom EU: Alla produkter som uppnått sin
livslängd måste returneras till Zebra för återvinning.
Information om hur du returnerar produkten finns på
http://www.zebra.com/weee.
Suomi: Asiakkaat Euroopan unionin alueella: Kaikki tuotteet
on palautettava kierrätettäväksi Zebra-yhtiöön, kun tuotetta
ei enää käytetä. Lisätietoja tuotteen palauttamisesta on
osoitteessa http://www.zebra.com/weee.

Zebra

pentru

22 MC17/MC17A/MC17T/MC17U Mobile Computer

Dansk: Til kunder i EU: Alle produkter skal returneres til
Zebra til recirkulering, når de er udtjent. Læs oplysningerne
om returnering af produkter på: http://www.zebra.com/weee.
Ελληνικά: Για πελάτες στην Ε.Ε.: Όλα τα προϊόντα, στο
τέλος της διάρκειας ζωής τους, πρέπει να επιστρέφονται
στην Zebra για ανακύκλωση. Για περισσότερες πληροφορίες
σχετικά µε την επιστροφή ενός προϊόντος, επισκεφθείτε τη
διεύθυνση http://www.zebra.com/weee στο ∆ιαδίκτυο.
Malti: Għal klijenti fl-UE: il-prodotti kollha li jkunu waslu
fl-aħħar tal-ħajja ta' l-użu tagħhom, iridu jiġu rritornati għand
Zebra għar-riċiklaġġ. Għal aktar tagħrif dwar kif għandek
tirritorna l-prodott, jekk jogħġbok żur:
http://www.zebra.com/weee.
Slovenski: Za kupce v EU: vsi izdelki se morajo po poteku
življenjske dobe vrniti podjetju zebra za reciklažo. Za
informacije o vračilu izdelka obiščite:
http://www.zebra.com/weee.
Slovenčina: Pre zákazníkov z krajín EU: Všetky výrobky
musia byť po uplynutí doby ich životnosti vrátené spoločnosti
Zebra na recykláciu. Bližšie informácie o vrátení výrobkov
nájdete na: http://www.zebra.com/weee.
Lietuvių: ES vartotojams: visi gaminiai, pasibaigus jų
eksploatacijos laikui, turi būti grąžinti utilizuoti į kompaniją
„Zebra“. Daugiau informacijos, kaip grąžinti gaminį, rasite:
http://www.zebra.com/weee.
Latviešu: ES klientiem: visi produkti pēc to kalpošanas
mūža beigām ir jānogādā atpakaļ zebra otrreizējai
pārstrādei. Lai iegūtu informāciju par produktu nogādāšanu
Zebra, lūdzu, skatiet: http://www.zebra.com/weee.

Quick Reference Guide 23

Service Information

If you have a problem using the equipment, contact your
facility’s Technical or Systems Support.

If there is a problem with the equipment, they will contact
Zebra Global Customer Support for your region. Contact
information is available at: http://www.zebra.com/support.

For the latest version of this guide go to:
http://www.zebra.com/support

Zebra Technologies Corporation
Lincolnshire, IL U.S.A.
http://www.zebra.com

Zebra and the stylized Zebra head are trademarks of ZIH Corp., registered
in many jurisdictions worldwide. All other trademarks are the property of
their respective owners.

©2015 ZIH Corp and/or its affiliates. All rights reserved.

72-100298-07 Revision A - May 2015
