TRAINERS / CONTROLLERS / SOFTWARE

DIGITAL I/O MODULE

KIT / ASSEMBLED

This trainer comes in kit form.
It provides all necessary fea­tures for experimentation and
prototyping of digital circuits.
This trainer includes 8-SPDT
toggle DIP switches, 8-LED indicators, clock conditioning circuit, two
pulse switches, and 26 screwless terminal blocks for easy circuit
connection. The kit comes with easy to follow instructions.

Part No. Price

3200DIGKIT $27.95
3200DIGASSMB 38.95

DIGITAL TRAINER

MODEL NO. DT3

KIT VERSION ONLY

This Digital Trainer comes in
kit for m and provides all the
functions necessary for digital
experimentation and prototyp­ing. The DT3's features include
8 binary switches (4 buffered), 8 LED indicators, a clock condi­tioning circuit, pulse switch with 0 to + 5V or + 5V to 0V output
and 7 board mounted tie blocks for easy circuit connections. The
kit comes with easy to follow assembly instructions.

Part No. Price

3200DT-3 $24.95

USB EXPERIMENT

INTERFACE BOARD

The K8055 interface board
features 5 digital input and
8 digital output channels.
There are also 2 analog
inputs and outputs with 8 bit
resolution. Number of inputs/
outputs can be expanded by connecting up to a maximum
of four cards the PC’s USB connectors. All communication
routines are contained in a Dynamic Link Library (DLL). Write
custom Windows (98SE, 2000, Me, XP0 applications in Delphi,
Visual Basic, C++ Builder or any other 32-bit Windows applica­tion development tool that supports calls to a DLL.

DIAGNOSTIC/TEST SOFTWARE:

— Separate output / input test
— Clear all / set all function
— Counter function on inputs

1 and 2
— Analog output set sliders
— Analog input bar-graph indicator
— Conversion time 20ms per

command

Part No. Description 1-4 5+

32VK8055 Kit Version $44.95 $39.95
32VKMV110 Assembled Version 72.00 65.00

SPECIFICATIONS:

5 digital inputs, 8 outputs
2 analog inputs and outputs
Power supply through USB
Diagnostic software with

DLL included

Requirements – Pent. CPU,

SB1.0, Windows 98SE,
CD ROM player & mouse

ANALOG-DIGITAL TRAINER

SINGLE BOARD

Compact, affordable
and practical. Offers all
the necessary features
for any curriculum
requiring electronic
lab training and
experimentation. Includes a
multiple output power supply,
signal generator, indepen­dent clocks, logic switches,
tri-state LED indicators,
frequency function and more. This is a powerful training and
prototyping tool. Comes complete with 12vdc adapter with din
connector to mate directly to board, plus operation manual.

• Portable: Easily transported. Large solderless breadboard area
(1,640 tie points)

• Power Supply: ±9V and +5V @ 500ma

• Digital: 16 tri-state multi-color LED indicatiors which remain in
a normally lit pattern which alerts user that the LED is function­ing (color then changes when in operation). Two independent
clocks, 16 logic switches, 2 momentary switches.

• Analog: Sine and Square wave generator. Variable amplitude,
variable offset, variable frequency to 20K

• Operation manual and power adapter (±12V) included

• Optional – 240 page circuit experiment and training book used
by leading technical colleges. Emphasizes the relationship
between design, analysis and testing. To fully utilize optional
Experiment Book including circuit analysis, some additional
hardware items (available from ELECTRONIX EXPRESS) and
software may be needed.

Part No. Description Price

01ADASM Single Board Analog-Digital Trainer $74.95
2700MJW70 140 Piece Jumper Wire Kit 4.50
31WI470144879 240 Page Experiment/Training Book 32.95

USB INTERFACE BOARD

USB Experimenter’s Board is
designed to introduce you to using
a USB interface in your hardware
designs. The Board is built around
a Cypress Cy7C63001A Universal
Serial Bus Microcontroller chip
which has been pre-programmed to
accept a variety of commands in a
relatively simple format. A Windows-based test program is sup­plied, as well as full documentation of the USB chip.
This board has 12 I/O lines: 4 output bits and 8 input bits. You
connect to the I/O bits using jumper wires (not included). In
addition, the board has 4 LEDs which can be jumpered to the
outputs and an 8-bit DIP switch that can be jumpered to the
inputs. The board is available as a kit or pre-assembled.

Part No. Description Price

3200USBKIT USB Kit $28.95
3200USBASM USB Assembled 33.95

Call Toll Free: 1 [phone]

• In NJ:

[phone]

• Fax:

[phone]

[phone]

71

73

Call Toll Free: 1 [phone]

• In NJ:

[phone]

• Fax:

[phone]

[phone]

Back to Catalog Download Main Page (http://www.elexp.com/a_print.htm)

Back to Catalog Download Main Page (http://www.elexp.com/a_print.htm)

TRAINERS

PROTO-BOARD® DESIGN
WORKSTATION SERIES

MODEL PB503 – Bench-Top Workstation
MODEL PB503C – Portable Unit
(Includes Rugged Carrying Case)
MODEL PB505 – Advanced Design;
Enhanced Features

• Multiple test equipment features in
one complete instrument.

• 100KHz function generator with
sine, square, triangle and TTL.

• Triple output power supply offers
5VDC xed plus two variable out­puts: ±1.3 to ±15VDC.

• Removable breadboard sections.

• 8 channel logic monitor.

• 8 selectable logic switches.

• Two digital pulsers, audio experi­mentation speaker.

• High and low buffered logic indica­tors.

• Add i t i o n al Fea t u r e s (Model
PB505) – Larger breadboard area,
low voltage (12.5VAC), AC supply,
built in logic probe, BCD to 7 seg­ment decoder/display, compatible
with optional trainer boards.

Part No. Description Price

01PB503 Design Workstation – $290.00
Bench Style

01PB503C Design Workstation – 333.00
With Case

01PB505 Advanced Circuit Design 437.00
Trainer

MODEL PB-503

MODEL PB-503C

MODEL PB-505

MICROWAVE TRAINING SYSTEM

SOLID STATE / KLYSTRON TRAINER

MODEL LRL 550B-SS

Best value for hands-on microwave training. 22 microwave com­ponents per trainer. Features dual power source facilitating both
Klystron and solid state microwave instruction within a single
system. Includes both a Klystron “Tube-to-Waveguide” mount
for use with the 2K25 Klystron, and a Solid State Oscillator,
enabling selection of either a Klystron or Solid State Signal
source for experiments.

• 22 rugged microwave components

• 24 snap-fast waveguide clips for fast assembly time

• RG-52/U brass and copper waveguide construction with UG­39/U cover anges

• Nickel plated components for durability

• Includes complete course in microwave theory supported by
training manual with fteen experiments

• Instructor can utilize standard lesson plan or create many other
demonstrations with components provided

• Solid State Oscillator for simple one-step conversion between
Klystron and Solid State modes with no additional wiring, power
sources or adjustments

• 220V 50Hz version available for export for an additional
charge

Part No. Description Price

01LRL550BSS Microwave Training System $4,200.00
01LRL575SC Storage Case for Microwave 185.00
Training System Components

MATRIX EDUCATION SERIES

“C” FOR PICmicro® MICROCONTROLLERS CD ROM

The C for PICmicro microcontrollers CD ROM is designed for students and professionals who
need to learn how to use C to program embedded microcontrollers. It also provides all the
software tools needed to actually program a PIC16F84 – including a full C compiler and device
programmer that is compatible with the Matrix PICmicro development board. Although the course
focuses on the use of the PIC series of microcontrollers, this CD ROM will provide a relevant

background in C programming for any microcontroller. The CD ROM assumes no previous
experience of C programming – the only assumed knowledge is an
ability to use a web browser and an understanding of basic digital
electronics. In addition to the required underpinning knowledge PIC­C includes 9 complete projects, each of which has up to 5 subsec­tions, that take users through the material in a relevant context.

72

ELECTRONIX EXPRESS / RSR

Part No. Description Price

01ELPCCST3 “C” PICmicro® Student Vers. $68.00
01ELPCCSI3 “C” PICmicro® Single User Vers. 115.00
01ELPCC103 “C” PICmicro® 10 User Vers. 345.00

• 365 Blair Road, Avenel, NJ 07001

Back to Catalog Download Main Page (http://www.elexp.com/a_print.htm)

TELECOMMUNICATIONS TRAINER

HANDS-ON TELEPHONY, LAN, CATV, FIBER OPTIC EXPERIENCE

MODEL TCM-200

TELECOMMUNICATIONS

skills are necessary to
succeed today. “TCM-200”
introduces you to telephony,
cabling, LAN and CATV with
one self-contained unit. A
comprehensive workbook
walks you through the world
of telecommunications from
the very basic fundamentals of
electronics to networks. Priced
under $225.00, the TCM-200’s
innovative design covers more
material in less time than units
costing thousands of dollars
more. The TCM-200 delivers
the platform to teach the skills
your students need FOR

TODAY AND TOMORROW.

* Tools, workbook, supplies and meter available at additional cost

$

TRAINER

95

220

Tool Kit Includes:

• Punch-Down Tool – Im­pact type w/blades for 66
& 110 punch down blocks

• Crimping Tool – Deluxe
ratchet type with four
different dies

• Wire Strippers – (3) for

Component and Supplies Kit

Tool Kit

Part No. Description Price

01TCM200 T-Comm Trainer $220.95
(TCM-200)
3300TCOM200 Lab Manual / 34.95
Work Book
3200TCOMCSK200 Component and 39.95
Supplies Kit
3200TCOMTK Tool Kit 119.95

coax cable, data / phone
cable and hook-up wire

• Long nose plier

• Diagonal cutter

• Screwdrivers (2)

• Magnier – lighted

• Telephone Set

• Tool Box

66 PUNCH DOWN BLOCK .......................... 25x4 Split Punch Down Block for hands-on training

TYPE 110 PUNCH DOWN BLOCK............. For hands-on training with telephone cabling. These

DIAL TONE......................................................“TONE ON-OFF” switch to supply tone selected

RING SIGNAL................................................. Push-button switch to supply 80VAC, 20Hz ring

RJ-11 CONNECTORS ................................... Use 2 or more telephones for full-duplex communica-

RJ-45 CONNECTORS ...................................Use for testing various LAN cables.

CABLE TEST................................................... Use with interchangeable PC Boards to test data

PROTOTYPING AREA................................... 480 tie-point breadboard.

5V & 12V DC POWER SUPPLY
BNC CONNECTOR & F CONNECTOR

1KHZ TONE ............................................ Fixed frequency 1KHz TTL clock signal

For prototype circuits built on breadboard.

with telephone cabling.

are congured for use in conjunction with and sepa­rately from the 66 Block

by “TONE SELECT” switch to RJ11 type J1, J2,
J3 and 110 block type PB5, PB6 and PB7.

signal to J5, PB5, PB6 and PB7.

tion to simulate a local loop and CO. Use connected
Type 110 connectors to test ring, dial, ringback and
busy tone signals.

cables with various pin-out standards. The test
results are indicated by 4 LED’s.

50 Ohm / 75 Ohm Terminated for cable assembly

instruction and prototyping use with RG58 and
RG59 and RG6 cable.

.

Call Toll Free: 1 [phone]

• In NJ:

[phone]

• Fax:

[phone]

[phone]

73

75

Call Toll Free: 1 [phone]

• In NJ:

[phone]

• Fax:

[phone]

[phone]

Back to Catalog Download Main Page (http://www.elexp.com/a_print.htm)

TRAINERS

Back to Catalog Download Main Page (http://www.elexp.com/a_print.htm)

PLDT-2 PROGRAMMABLE

LOGIC DEVICE PROTOTYPING BOARDS

WHY USE OLD, OBSOLETE TTL GATES TO IMPLEMENT
COMPLEX LOGIC & STATE MACHINE DESIGNS?

with the ALTERA® EPM7128SLC™ CPLD

User design software available from the chip manufacturer.* Then down­load your design from the PC with the parallel port cable (included). each
comes with a user’s manual containing a complete description of the
board together with Lab experiments, power supply and cable.

Design software is available at the following chip manufacturer websites:

*

For the Altera chip: http://www.altera.com. You can also go to the PLDT

page on the Electronix Express website at http://www.elexp.com/tst_pldt.htm
which has links directly to the software pages.

HAS THE ON-BOARD I/O CAPABILITY YOU NEED:

• DIP Switches

• De-bounced Momentary Switches

• LEDs

• 7-Segment Displays

• Numerous Connectors for
Jumper-Wires and Ribbon Cables

ACCESSORY KIT (32RSRFPGAACC)

INCLUDES: 1 RSR MB-102 Breadboard with Wire Kit

1 RSR LP-610 Logic Probe
50 Breadboarding Pins

Part No. Description Price

01PLDT2 PLDT-2 Board $79.00
31CPLD CPLD Programming Lab Manual 58.00
31P0130453056 Experiments In Digital 60.75
Fundamentals With VHDL
311401840302 Digital Design With CPLD 140.80
Applications & VHDL, 2Ed.
32RSRFPGAACC Accessory Kit 19.95

CPLD PROGRAMMING & DIGITAL
LOGIC SIMULATION

A lab manual to accompany any digital electronics textbook. This lab
manual can help you learn how to use Max+plusII software by Altera
Corporation. This manual starts with fundamentals of logic gates, then
progresses to MSI devices, latches and ip ops. Then it moves on to clock depen­dent circuits including counters and registers, memory addressing, and converters.

Provides laboratory exercises that support Digital Fundamentals
with VHDL by Tom Floyd. The manual supports the PLDT-2 and
PLDT-3 boards from RSR Electronics, as well as the DeVry Uni­versity board, and the Altera University Program board.

DIGITAL DESIGN WITH CPLD
APPLICATIONS & VHDL, 2ED

2nd edition; 896 pages. Updated Altera’s Quartus II software and
Lab.Source CD included with book. Thorough coverage of basic
techniques and fundamentals to advanced principles.

–

By Steve Waterman

ONLY

$

00

79

Power Supply and

Cable Included

Breadboard Optional

PLDT-3 PROGRAMMABLE

LOGIC DEVICE PROTOTYPING BOARDS

WHY USE OLD, OBSOLETE TTL GATES TO IMPLEMENT
COMPLEX LOGIC & STATE MACHINE DESIGNS?

with the XILINX® XC95108™ CPLD

User design software available from the chip manufac­turer.* Then down-load your design from the PC with the
parallel port cable (included). EACH comes with a user’s
manual containing a complete description of the board
together with Lab experiments, power supply and cable.

HAS THE ON-BOARD I/O CAPABILITY YOU NEED:

• DIP Switches

• De-bounced Momentary
Switches

• LEDs

* Design software is available at the following chip manufacturer website: For the

Xilinx chip: http://www.xilinx.com

You can also go to the PLDT page on the Electronix Express website at http;/

/www.elexp.com/tst_pldt3.htm which has links directly to the software pages.

• 7-Segment Displays

• Numerous Connectors for
Jumper-Wires and Ribbon
Cables

ACCESSORY KIT (32RSRFPGAACC)

INCLUDES: 1 RSR MB-102 Breadboard with Wire Kit

1 RSR LP-610 Logic Probe
50 Breadboarding Pins

DIGITAL ELECTRONICS LABORATORY EXPERIMENTS

USING THE XILINX® XC95108™ CPLD WITH XILINX®
FOUNDATION DESIGN AND SIMULATION SOFTWARE

This digital laboratory manual by James Stewart and Chao­Ying Wang, published by Prentice Hall, allows introductory
digital electronics students to use the Xilinx® software early
in the course. Features of this manual include:

• A step-by-step introduction to Xilinx® software.

• Class-tested laboratory experiments guaranteed to work.

• More than one experiment for most typical areas to allow for
greater exibility in the laboratory environment.

Part No. Description Price

01PLDT3 PLDT-3 Board $79.00
31DELE Digital Electronics Laboratory Experiments 56.50

32RSRFPGAACC Accessory Kit

ONLY

$

00

79

Power Supply and

Cable Included

19.95

74

ELECTRONIX EXPRESS / RSR

• 365 Blair Road, Avenel, NJ 07001

Back to Catalog Download Main Page (http://www.elexp.com/a_print.htm)

TRAINERS / SOFTWARE

T-REX C1 DEVELOPMENT KIT

FPGA DEVELOPMENT BOARD W/BUILT IN USB PORT

This Development Board provides a complete, low cost multimedia platform featuring Altera Cyclone (EP1C6Q248C8) FPGA device. With the built-in USB blaster circuits, this
TR1 development board has many multimedia features for users to develop advanced video, audio, memory and storage applications using the most popular components in
consumer electronic products such as DVD and VCD players. Also includes a C++ program and controller IPs for peripheral controls to allow users to build up advanced ap­plications in shortest timeframe. Users can use either the USB blaster link or RS-232 link to control the board.

FPGA development board

• Altera EP1C6Q240C8

• Altera EP1S Serial Congu­ration Device

• Built-in USB Blaster pro­gramming circuitry.

• Support both JTAG and AS
mode programming

• Option to power via univer­sal serial bus (USB)

• Eight LEDs

• Eight Schmitt-trigger de­bounced push buttons

• 1MByte Flash Memory

• 8MByte SDRAM (1M x 4 x

16)

• CF Card Socket (True IDE
mode)

• 16-bit CD-quality Audio
DAC with line-out connector

• TV Encoder with TV Out
jack

• RS-232 Transceiver with
9-pin connector

Part No. 01FPGA1 • Price: $159.00

• VGA DAC (4-bit resistor
network) with VGA-out
connector

• PS2 Keyboard/mouse
connector

• 4-bit DIP switches

• 4-bit 7-SEG display
module

• Two-40 pin expansion
slots.

Cables and accessories

• USB A->B cable (for
both USB-blaster
programming and the
TREX C1 API controll)

• 7.5V DC Power Supply

• Quartus® II Web Edition
design software

Reference designs and

C++ applications

• Lab manual for using
the C++

• Lab Manuals for using
the reference designs

9V DC Power

Supply

Connector

Power ON/

OFF Switch

8 User LEDs

50Mhz OSC

USB
Port

8 Push-button

Switches

8MByte
SDRAM

VGA

OutTVOut

PS2
Port

RS232

Port

4-Digit 7-Seg. Display

Expansion Headers
(with Protection
Resistors)

Altera Cyclone 1C6
240-pin TQFP

1MByte Flash Memory
(under the CF card)

FPGA BOARD WITH USB PORT

• Provides means of learning
and prototyping digital logic, computer systems
and FPGA code. This board provides a com­plete low cost platform using Altera Cyclone
II (EP2C8) chip connected to various LEDs,
switches and 7-segment displays. One can use
web edition of Altera Quartus II to design FPGA
code using Verilog HDL, VHDL as well as other
design methods

• USB port for transferring FPGA to chip congura­tions

• 8 red LEDs, 8 green LEDs

• 2 sets of 4 SPDT switches

• 2 debounced, 4 non-debounced switches

• 40 pin and 2 DB-9 I/O connectors for interfacing

• 24MHz clock; can be multiplied or divided using
interal PLL

FPGA ALTERA BOARD WITH USB

Provides ideal vehicle for advanced design proto­typing in the multimedia, storage, and networking.
The board offers a rich set of features that make
it suitable for use in a laboratory environment for
university and college courses, for a variety of
design projects, as well as for the development of
sophisticated digital systems. Altera provides a suite
of supporting materials for the DE1 board, including
tutorials, "ready-to-teach" laboratory exercises, and
illustrative demonstrations.
Altera DE1: Available on the Altera website (http://
university.altera.com/materials/unv-dev-edu-boards.html)

FEATURES

DE1 board provides users many features to enable
various multimedia project development. Component
selection was made according to the most popular design in volume production mul­timedia products. The DE1 platform allows users to quickly understand all the insight
tricks to design projects for industry.

• Altera Cyclone II 2C20 FPGA with 20000
LEs

• Alt era Seri al Co nfi gur ati on de ivi ces
(EPCS4) for Cyclone II 2C20

• USB Blaster built in on board for pro­gramming and user API controlling

• JTAG Mode and AS Mode are supported

• 8Mbyte (1M x 4 x 16) SDRAM

• 4Mbyte Flash Memory

• 512Kbyte(256Kx16) SRAM

• SD Card Socket

• 4 Push-button switches

• 10 DPDT switches

• 8 Green User LEDs

• 10 Red User LEDs

• 4 Seven-segment LED displays

• 50MHz oscillator ,24MHz oscillato r
,27MHz oscillator and external clock
sources

• 24-bit CD-Quality Audio CODEC with line­in, line-out, and microphone-in jacks

• VGA DAC (4-bit R-2R per channel) with
VGA out connector

• RS-232 Transceiver and 9-pin connector

• PS/2 mouse/keyboard connector

• Two 40-pin Expansion Headers

• DE1 Lab CD-ROM which contains
many examples with source code

NEW!

Part No. 01FPGA4 • Price: $149.00

Call Toll Free: 1 [phone]

Part No. 01FPGA2 • Price: $170.00

• In NJ:

[phone]

• Fax:

[phone]

[phone]

75

77

Call Toll Free: 1 [phone]

• In NJ:

[phone]

• Fax:

[phone]

[phone]

Back to Catalog Download Main Page (http://www.elexp.com/a_print.htm)

Back to Catalog Download Main Page (http://www.elexp.com/a_print.htm)

SOFTWARE AND PROGRAMMERS

ELECTRONIC PROJECTS

PLATFORM: WINDOWS 3.1/95/98/NT; FORMAT: CD ROM

• 10 projects to build

• Component lists – also included as separate
les for easy access

• Fully functional schematic design and PCB layout
software included on the CD (CAD Pack)

• Component and general construction guides

• Project specic construction and testing

The projects on this CD are as follows:

• Lig ht, He at and
Moisture Sensor

• Logic Probe

• NE555 Timer

P

art No. Description Price

01ELEPSST Electronic Projects – Student Ver. $59.00
01ELEPSSI Electronic Projects – Single User 93.00
01ELEPS10 Electronic Projects – 10 User 192.00

• Egg Timer

• Dice Machine

• Bike Alarm

• Stereo Mixer

ELECTRONIC

• Power Amplier

• Sou nd Ac tivate d
Switch

• Reaction Tester

PROTOLAB™ CIRCUIT SIMULATION SOFTWARE

CREATE AND ANALYZE CIRCUITS INSTANTLY ON YOUR PC!

Release 4.0

Protolab™, a total computer-simulated, elec­tronics laboratory including free built-in test instru­ments and tools to build and test actual circuits.

• Easy-to-use interface: Create AC&DC
circuits moments after installation with
ProtoLab's easy "click & drag" component placement and on-line help

• Choose from a complete list of active and passive components

• Five virtual instruments allow for instant, accurate circuit analysis: Volt­meter, Ammeter, Wattmeter, Oscilloscope, Ohmmeter

• Pre-designed circuit library included

SYSTEM REQUIREMENTS:

• IBM/PC 386 or compatible
with 4MB RAM

• SVGA video

Part No. 01PL300-0007 • Price: $49.95

• Windows 3.1 or Windows 95

• Mouse

• 31/2 oppy drive

CIRCUITS AND COMPONENTS – VER. 2

PLATFORM: WINDOWS 95/98/NT/2000/ME; FORMAT: CD ROM

• Highly interactive virtual labs. Clear circuit simulation.

• Spoken text caters to students with low reading ability.

• Thorough assessment – multiple choice, worksheets,
fault nding circuits, written exam questions and as­signments.

• Flexible resources – stand alone, in front of class,
class activity on a network, revision/remediation.

• Browser based – Intranet ready.

• Teachers’ notes and editable worksheets included on CD.

• Multi Sim® / Electronics Workbench® circuits provided.

Part No. Description Price

01ELECCST2 Electronic Circ. & Comp – Student / Home User $59.00
01ELECCSI2 Electronic Circ. & Comp – Single User 93.00
01ELECC102 Electronic Circ. & Comp – 10 User Ver. 192.00

ANALOG ELECTRONICS

PLATFORM: WINDOWS 3.1/95/98/NT; FORMAT: CD ROM

• Virtual labs

• SPI CE® simula tion of
over 50 editable circuits

• Desig n parame ters for

Part No. Description Price

01ELANAST2 Analog Electronics – Student Ver. $59.00
01ELANASIN2 Analog Electronics – Single User 93.00
01ELANA102 Analog Electronics – 10 User Ver. 192.00

circuits included

• Complete hi-
amplier case study

• Editable worksheets

DIGITAL ELECTRONICS

PLATFORM: WINDOWS 3.1/95/98/NT; FORMAT: CD ROM

• Virtual labs

• Full audio commentary

• Over 20 links to pre-de­signed Electronics Work-

Digital Electronics provides a broad introduction to the principles and
practice of digital electronics, including logic gates, combinational and se­quential logic circuits, clocks, counters, shift registers, and displays. The CD
ROM also provides an introduction to microprocessor based systems.

Part No. Description Price

01ELDIGST2 Digital Electronics – Student User $59.00
01ELDIGSI2 Digital Electronics – Single User 93.00
01ELDIG102 Digital Electronics – 10 User License 192.00

bench® circuits
and crocodile clips

• Teachers’ notes

• Editable worksheets

PIC WRITER – HANDHELD

SERIAL PROGRAMMER COMPATIBLE WITH
MICROCHIP® MPLAB DEVELOPMENT SOFTWARE

Low cost programmer supports many devices from PIC
family. Operates with PC-compatible host system run­ning Windows 3.X/ME/NT/2000/XP. Reads, programs,
veries EPROM and EEPROM program and data mem­ory. MPLAB Project support to automatically download
object le to PSTART. Complete with RS-232 cable, 9V
universal power adapter. Includes MPLAB Development Software (CDROM).

LP-PICD is manufactured under license from MICROCHIP

Part No. 01LPPSTART • Price $205.00

ASSEMBLY FOR

PICmicro® MICROCONTROLLERS CD ROM

• Virtual PIC allows full on-screen simulation programs

• Over 80 exercises

• Over 30 full working programs

• On-screen challenges

• Includes shareware assembler and send programs
The PICtutor is designed to teach users of all levels how to write as-

sembler programs for the PIC series of microcontrollers. The CD ROM’s
39 tutorial sections guide the complete beginner through PIC architecture,
commands and programming techniques up to advanced programming
techniques including discussion and examples of watchdog timers, inter­rupts and sleep modes. Over 80 exercises and challenges are provided.

Part No. Description Price

01PICST2 Assembly for PICmicro / Student Ver. $59.00
01PICSI2 Assembly for PICmicro / Single User 125.00
01PIC102 Assembly for PICmicro / 10 User 375.00

PICMICRO

MCU DEVELOPMENT SOLUTION

• Low cost solution with USB interface • Fully com­patible with E-Blocks™ • No power supply required

This consists of a USB Lite PICMicro MCU programmer, an LED block (8
LEDs), and a switch block (8 switches), a USB cable and CD ROM. It is
supplied with PIC16F88 device which provides 15 I/O lines. Lite program­mer is compatible with several 18 pin PICMicro devices. A simple patch
wire (not included) or external supply is required for switch board.

Part No. 01EB263 • Price: $152.95

®

76

ELECTRONIX EXPRESS / RSR

• 365 Blair Road, Avenel, NJ 07001

Back to Catalog Download Main Page (http://www.elexp.com/a_print.htm)

SOFTWARE AND PROGRAMMERS

E-BLOCK™ SYSTEM

The E-Block™ System consists of small circuit boards each of which contains electronics that you would typically nd in an
Electronic System. The E-Blocks™ range consists of around 150 separate items which can be combined to make a variety of
systems offering a wide range of learning opportunities. Select a Programmer Board, add a number of peripheral boards,
combine with a range of software utilities including “Flow Code” to develop a fully functional electronic system.

PROGRAMMING BOARDS

PICMICRO DEVELOPMENT BOARD VER. 3

This is an ideal platform for
learning how PICmicros are
programmed and also for project
work. This board programs a
range of 8, 14, 18, 28 and 40
pin devices from the 12, 16 and
18 series PIC micro ranges. The
on-board LED’s, switches and displays can be used in CD
ROM based courses or with Microchip’s MPLAB software. The
board also has two E-Blocks parts (on ports C and D) which
makes it compatible with a large range of E-blocks add-ons
and sensors.

Features:

• USB Connector

• Single bit audio output

• 2 line LCD display

• Onboard sensors

• Quad 7 segment displays

Part No. 01HP488 • Price: $285.00

PICMICRO MULTIPROGRAMMER

This programmer connects to your PC via
USB to provide you with a low cost and
exible PIC microcontroller programmer.
This board can be used with Assembly,
C or Flowcode programming utilities
provided by Matrix Multimedia. This board
will programm most 8, 14, 18, 28 and
40 pin ash PIC micro devices using the
exible programming software provided and
provided “clean” access to all I/O lines. The
board has 5 E-blocks parts to which you can connect a
variety of peripheral boards.

Part No. 01EB006 • Price: $115.00

FLOWCODE / PICMICRO

PLATFORM WIN95/98/ME/NT/2000/XP

Flowcode is a ver y high level language
programming system for PICmicro® micro­controllers based on owcharts. Flowcode
allows students to design complex robotics
and control systems in a matter of minutes.
Flowcode is a powerful language that uses
macros to facilitate the control of complex
devices like 7-segment displays, motor con­trollers, and LCD displays. The use of macros allows students to
control highly complex electronic devices without getting bogged
down in understanding the programming involved.

Part No. Description Price

01TEFLCST2 Flowcode Student Ver. $79.00
01TEFLCSI2 Flowcode Single User 182.00
01TEFLC102 Flowcode 10 Users 550.00

PERIPHERAL BOARDS

LED BOARD

It has 8 LEDs which shows the status of each bit on
the port

LCD BOARD

This E-block contains a 16 character 2 line alphanu­meric LCD display on a 5 wire serial bus.

SWITCH BOARD

This E-block contains 8 push-to-make switches. Connec­tors allow this board to be used in bus conguration.

PROTOTYPE BOARD

It contains a small breadboard for developing circuits
and projects. Connectors for two E-block ports allow
prototype wires and leads to be connected to the rows
and columns on the prototype board.

SENSOR BOARD

This board contains a variable resistor and a simple
light sensor which can be used for simple analog ex­periments. It also contains sockets which allow users to
interface with many other sensors.

BLUETOOTH BOARD

This board allows you to add Bluetooth capability to any
microcontroller with UART functionality.

INTERNET BOARD

This board adds Ethernet functionality to a microproces­sor with the need for developing a TCP-IP software stack.

VOICE CODEC BOARD

This audio coder-decoder board allows students to inves­tigate Bluetooth systems that use audio. It is based on
MC145483 linear 13 bit CODEC which allows voice digiti­zation and reconstruction as well as pre and post ltering.

MOTORS BOARD

This board is based on L298 device which can drive
two motors operating up to 46 V @ 4A each. It can be
used in a variety of motor control congurations includ­ing PID control.

OPTO-ISOLATOR BOARD

This Opto-Isolator Board allows you to add 4 separate
optically isolated inputs to your E-blocks system. This is
ideal for developing industrial control systems like PLCs
(programmable Logic Controllers) where electrical sys­tems need to be isolated from one another.

KEYPAD BOARD

A simple 4 x 3 keyboard that allows data entry into bus
based systems.

Part No. Description Price

01EB004 LED Board $22.00
01EB005 LCD Board 32.00
01EB007 Switch Board 22.00
01EB016 Prototype Board 32.00
01EB003 Sensor Board 26.00
01EB024 Bluetooth Board 210.00

Part No. Description Price

01EB023 Internet Board $120.00
01EB032 Voice CODEC Board 210.00
01EB022 Motor Board 95.00
01EB035 Opto-Isolator Board 54.00
01EB014 Keypad Board 26.00

Call Toll Free: 1 [phone]

• In NJ:

[phone]

• Fax:

[phone]

[phone]

77

79

Call Toll Free: 1 [phone]

• In NJ:

[phone]

• Fax:

[phone]

[phone]

Back to Catalog Download Main Page (http://www.elexp.com/a_print.htm)

Back to Catalog Download Main Page (http://www.elexp.com/a_print.htm)

PROGRAMMERS / TRAINERS

PC BASED UNIVERSAL

HANDY UNIVERSAL WRITER

MODEL LP-48

This advanced, portable unit is competitively
priced and supports: EPROMs, EEPROMs,
FLASH EPROMs, Serial E/EPROMs, NV
RAMs, Micro-Controllers, DSP, PLDs...

• Comes complete with USB cable, CD-ROM soft­ware and power adapter

• 48 Pin ZIF socket accepts DIP devices up to 48
pins, and both 200-600 mil width

• Fast programming – takes only 30 seconds for 16M bit FLASH memory
device

• Easy to operate software with automatic processing function

• Supports low voltage components

• System Requirements: Windows (9X/ME/2000/NT/XP. Pentium II, min.
32 MB RAM but 64 MB recommended, 30MB free drive hard drive
space.

• Optional Accessories:

IC Adaptors: SOP, TSOP, SSOP, VSOP, SDIP, PLCC, QFP, µBGA.

Approximately 2 weeks delivery on adapters

Part No. 01LP48 • Price: $650.00

PROGRAMMER

USB INTERFACE – MODEL 844USB

Great common device programmer.
Reads, copies and programs IC’s via
USB computer interface

• 40 pin dual-in-line zif socket accepts both
300 and 600 mil devices up to 40 pins.

• In circuit serial programming (ISP) capability.

• Easy-to-Use. Windows 95/98/ME/NT/2000/XP compatible.

Part No. 01BK844USB • Price: $450.00

PIC PROGRAMMER BOARD KIT

This board can program a wide range of
Microchip® PIC™ microcontrollers
Suitable for the programming of the
"VM142" mini PLC microcontroller

• Onboar d config urable 40 pin. ZIF
socket

• Microcontroller selection using patch
jumper

• Easy to use programming
PICprog2006™ software included

• SUBD connector set included

• Minimum system requirements:

SPECIFICATIONS

• Power supply (required): 15V DC, min. 300mA adapter

• Serial port connector: 9 p. SUBD

• Dimensions: 132x65x20mm / 5,23 x 2,57 x 0,79"

• Currently supported controllers:
— PIC10F200
— PIC12C508A,PIC12CE518
— PIC12F629,PIC12F675
— PIC16F54
— PIC16F84A
— PIC16F870,PIC16F871,PIC16F

872,PIC16F873,PIC16F874

Part No. 32VK8076 • Price: $41.95

• IBM Compatible PC, Pen­tium or better

• Windows™ NT/2000/XP

• CDROM drive

• Free s eria l RS 232 port
required

— PIC16F876,PIC16F877
— PIC16F627,PIC16F627A,

PIC16F628,PIC16F628A

— PIC16F648A

PIC16F630,PIC16F676

— PIC18F2550,...

PROGRAMMER AND TESTER

SUPPORTS OVER 12,000 DEVICES

WINDOWS VERSION

MODEL ALL-11C2

BUSY LED

Indicates
Programmer
Operation Is

GOOD LE D

LED ON indic at es

An Operation W as

Performed OK

• Supports over 12,000 IC’s including expansive array of EPROM,
EEPROM, Flash, Serial PROM, BPROM, MPU/MCU/DSP, micro­controllers from Atmel, Dallas, Hitachi, Intel, Microchip, Mitsubishi,
Motorola, NEC, Philips, TI, Toshiba, WSI, Zilog and others.

• Supports PAL, GAL, PEEL, EPLD, EPL, FPGA, CPLD from
Altera, AMD, Atmel, Lattice, Lucent Technologies, Motorola, TI,
Xilinx, etc.

• Nearly all devices with 8-40 pins can be programmed directly
by the 40 pin ZIF socket. Adapters and converters are available
to support nearly every type of IC package including PLCC,
SOP, TSOP, QFP, TQFP, PGA, AOJ and many more.

• Can test logic IC’s, SIP/SIMM, performs functional vector tests
on programmable logic devices as fast as 4ns.

• Programs single device only.

• Connects to PC via high speed parallel interface.

• Includes a high speed CPU and expandable to 128M memory
buffer.

• Compact SMT design weights only 4.4 lb.

• Free online software updates and support.

• INCLUDES: Programmer with 40 pin ZIF socket, interface
cable, software, user manual and power supply.

MODEL ALL-11P3

• All features as in Model ALL-11C2.

• Consists of universal base and exchangeable pack option:

— 40 pin ZIF socket (included)
— Optional gang programmer available

• High speed parallel port and USB connects the programmer
to any desktop to laptop PC running Windows 95/98/NT/2000/
XP.

SYSTEM REQUIREMENTS (BOTH ALL-11P3 AND ALL-11C2):
486/Pentium or compatible with minimum 32MB extended

memory. 5 MB minimum free hard disk space. Windows 95/98/
NT/2000/XP.

Part No. Price

01ALL-11C2 $875.00
01ALL-11P3 1,075.00

40 PIN ZIF SOCKET

YES Key

Allows One Key

Operation For

Mass Production

78

ELECTRONIX EXPRESS / RSR

• 365 Blair Road, Avenel, NJ 07001

Back to Catalog Download Main Page (http://www.elexp.com/a_print.htm)

PROGRAMMERS

PROGRAMMERS

NEW!

SUPERPRO 48 PIN – USB

MODELS 280U / 580U / 3000U

580U

3000U

• High speed, low cost

• Supports EPROM, EEPROM, FLASH, FPGA, CPLD, SPLD,
µController MCU, Standard Logic

• Overcurrent / overvoltage protection

• Software supports Windows

• Includes power adapter, manual, program CD and USB cable

MODEL 3000U

• Reliable programming of low voltage devices down to 1.5V

• 42,000+ devices

Part No.

01XL280U
01XL580U
01XL3000U

Description

Model 280U (21,000_ Devices)
Model 580U (31,000+ Devices)

Model 3000U (42,000_ Devices)

®

98/ME/NT/XP

$585.00

735.00
1,085.00

Price

PROGRAMMER UNIVERSAL

•

Low cost USB 2.0 with Windows
support and low voltage capability

•

Extremely portable

• Sup por ts dev ices tha t includ e
EPROMs, Flash, PIC, AVR GAL,
CPLD, PEEL, PALCE, EPLD, Mi
crocontrollers

•

48 pin zif socket with universal pin
driver

• Accepts most compiler outputs in JDEC format including ABEL,
CUPL, PALASM, TANGO PLD, OrCADPLD, PLD Designer and
ISDATA

• Features test vector capability and multiarray fuse map editor

• Test TTL/CMOS logic IC's and DRAM devices

•

Supports Windows Vista/XP/2000/NT/9X/ME

•

Suppor t Devices: 17,000+

VP280)

• Go to our website at http://www.elexp.com/tst_v190.htm
complete device support list

• Power adapter

• Dimensions: 166 x 98 x 23mm; Wt. 10 oz.

Part No.

01VP190
01VP280
01VP480
16DVP

; 5,000+ (Model VP190)

(optional)

Description

Model VP190
Model VP280

Model VP480

DC Voltage Adapter

-

(Model VP480); 7,000+

NEW!

(Model

for

Price

$195.00

235.00

445.00

15.00

UNIVERSAL PROGRAMMERS

PROGRAMMERS 40 PIN

•

Supports 3400+ devices,
including most E(E)PROM,
Series E(E)Prom & Flash

• Progra ms GAL s, PEE Ls,
PALCE, Microcontroller s,
P I C 1 6 C x x / 1 7 C X X ,
COP87XX, and PSD3XX

• Tests TTLCMOS Test, Mem
ory Test, Vector Test, Test
Pattern Edit, Auto Identify
TTL/CMOS Device

•

Features a universal ZIF socket that accepts up to 40 pins

•

Supports Windows® 9x/NT/2000/XP

•

Size: 7.8"Lx5.5"Wx0.8"H

•

Printer Port Interfact

• Weight: 4.0 lbs.

•

Includes Power adapter, parallel cable, manual and CD-ROM
software

Part No.

01XLSP-Z • Price: $248.00

-

NEW!

MODELS 848A, 866B

Model 848A

• Windows 2000/95/98/ME/NT compatible

• Parallel port interface (Model 866B

interface)

•

Includes ZIF socket for DIP IC’s. 48 pin ZIF
pin ZIF

• Optional adapters available for PLCC, SOIC, TSOP, TQFP,
SSOP, PSOP, QFP (Model 866B)

• EPROM, EEPROM, Flash, NVRAM and serial EEPROM capa
bility

• USB interface (Model 866B Only)

Part No.

01BK848
01BK866

(Model 848A)

$259.00

Price

895.00

offers both parallel and USB

Model 866B

(Model 866B)

; 32

-

Call Toll Free: 1 [phone]

• In NJ:

[phone]

• Fax:

[phone]

[phone]

79

TRAINERS

Back to Catalog Download Main Page (http://www.elexp.com/a_print.htm)

FPGA BOARD WITH
USB PORT

• Provides means of learning and prototyping
digital logic, computer systems and FPGA code. This board
provides a complete low cost platform using Altera Cyclone
II (EP2C8) chip connected to various LEDs, switches and 7­segment displays. One can use web edition of Altera Quartus
II to design FPGA code using Verilog HDL, VHDL as well as
other design methods

• USB port for transferring FPGA to chip congurations

• 8 red LEDs, 8 green LEDs

• 2 sets of 4 SPDT switches

• 2 debounced, 4 non-debounced switches

• 40 pin and 2 DB-9 I/O connectors for interfacing

• 24MHz clock; can be multiplied or divided using interal PLL

PORTABLE RADIO TELESCOPE

MODEL RTL-11

Have hours of fun learning
about the wonders of Radio
Astronomy. Make a study of
the principles of microwave
radiometry through the use
of RTL-11. This simple instru­ment is easy to assemble
and operate. It is capable of
detecting solar radio noise
at approximately 11-12 GHz
as determined by satellite re­ceiver LNB (low noise block
converter).

RTL-11 can be used to:

• Demonstrate remote measurement of temperature of various
objects

• Demonstrate that the human body or hand generates solar
radio noise

• One can use a data logger connected to radio telescope output.
The solar noise magnitude can later be plotted vs. time on a
PC

• Other than astronomical applications can be found as various
objects absorb, radiate, or reect microwaves in a manner dif­ferent from that at visible light

RTL-11 includes:

• Parabolic dish (32 cm)

• 11 GHz LNB

• F-F coaxial cable (2 ft. long)

• IF in-line amplier

* Tripod Not included

• F/F male/male adapter

• Indicator box

• AC/DC wall adapter

• Instruction manual

Tripod Not

Included

Part No. 01FPGA4 • Price: $149.00

Part No. 01RTL-11 • Price: $350.00

PC BOARD DESIGN AND FABRICATION KIT

This kit includes PCB layout software plus material and instruc­tions to make your own printed circuit boards. No dark room
processing needed.

Included in Kit:

• Board Creator Software

• Press-N-Peel image transfer lm

• Etching solution

• Copper clad boards

• Software manual

• Complete instructions for making PC boards

• More than 100 hobby circuits on CD

Features of the Board Creator Software included in this kit

• Boards up to 10’ x 8’ up to 6 layers with 8 masks each

• Built-in print queue up to 10 masks

• User selectable cursor layout grid up to 1 mil resolution. Items
not limited to grid

Part No. 32AMSPCBDFKIT • Price: $145.00

• Full surface mount device support

• Multiple line widths, from 0.001 to 0.255 inches wide

• Up to 10 different pad shapes and sizes

• Locates and displays errors on-screen

80

ELECTRONIX EXPRESS / RSR

• 365 Blair Road, Avenel, NJ 07001
