Getting Started with EDK

Summary

This document introduces the Xilinx

®

Embedded Development Kit (EDK). It contains the

following:

• “EDK Contents”

• “Requirements”

• “Supported Platforms”

• “Development Boards”

• “Installation on Windows”

• “Installation on Solaris”

• “Installation on Linux”

• “Third Party Tools”

• “Installation Directory Structure”

• “Documentation”

• “Other Information”

EDK Contents

Xilinx distributes EDK as a single, media-installable DVD image.

The components of EDK are:

• Hardware IP for the Xilinx embedded processors and their peripherals

• Drivers, Libraries, and a MicroKernel for Embedded Software Development

• Xilinx Platform Studio (XPS) tools

2 www.xilinx.com Getting Started with EDK

EDK 9.2i

R

• Software Development Kit (SDK), Eclipse-based IDE

• GNU Compiler and Debugger for C development for MicroBlaze™ and PowerPC

®

processors

• Documentation

• Sample projects

Except for the release notes and the EDK Concepts, Tools, and Techniques book, EDK does not

include printed documentation material. Refer to the “Documentation” section for a list of

documents available. Also not included but available as separate products are FPGA

development boards and the Xilinx FPGA implementation tools package, ISE™ 9.2i. Refer

to the “Requirements” and the “Development Boards” sections for further details.

Requirements

• Xilinx ISE 9.2i, Service Pack 3

The Xilinx FPGA design implementation tools, ISE 9.2i (WebPACK or Foundation), are

required to implement embedded designs generated with the XPS tools. Several EDK

tools use functionality delivered with tools contained in ISE 9.2i.

Note:

Updates to ISE 9.2i including service packs are available at:

http://www.xilinx.com/support/mysupport.htm.

• Development Board

To test your MicroBlaze processor or PowerPC processor system on an FPGA, you

must have access to a development board that contains a Xilinx FPGA and several

other components as well as standard download, configuration, and debug

connectors.

Operating system specific requirements:

• Solaris and Linux – Bash shell

Supported Platforms

Operating Systems

EDK is available for the following operating system platforms:

• Windows XP

• Solaris 2.9

• 32-bit Red Hat Enterprise Linux versions 3, 4, and 5

• 64-bit Red Hat Enterprise Linux, versions 4 and 5

Xilinx FPGA Families

EDK supports designing MicroBlaze embedded processor systems for several FPGA

families:

• Xilinx Spartan™-II FPGAs (XC2S50 or larger devices)

• Xilinx Spartan-IIE FPGAs

• Xilinx Spartan-3 FPGAs

• Xilinx Spartan-3E FPGAs

Getting Started with EDK www.xilinx.com 3

EDK 9.2i

Development Boards

R

• Xilinx Spartan-3A FPGAS

• Xilinx Spartan-3A DSP

• Xilinx Virtex™/E FPGAs (XCV50 or larger devices)

• Xilinx Virtex-II FPGAs (XC2V250 or larger devices)

• Xilinx Virtex-4 LX, FX, and SX FPGAs

• Xilinx Virtex-5 LX, LXT, and SXT FPGAs

EDK also supports designing MicroBlaze and PowerPC embedded processor systems for

the following:

• Xilinx Virtex-II Pro FPGAs

• Xilinx Virtex-4 FX FPGAs

Development Boards

Development boards are available from Xilinx and Xilinx partners. Xilinx boards that are

currently available include:

• Xilinx ML401

• Xilinx ML402

• Xilinx ML403

• Xilinx ML405

• Xilinx ML410

• Xilinx ML501

• Xilinx ML505

• Xilinx ML506

• Xilinx Spartan-3 Starter Kit

• Xilinx Spartan-3E Starter Board

• Xilinx Spartan-3E 1600E MicroBlaze Development Board

• Xilinx/Lyntech Spartan-3A DSP 3400

• Xilinx Spartan-3A Starter Kit

• Xilinx Spartan-3AN Starter Kit

• Xilinx AFX Board

Contact your local Avnet, Memec, Nu Horizons or other authorized distributor to obtain

any partner board.

Installation on Windows

This section summarizes the EDK installation process on the Windows platform.

Registration

You must have a software registration ID to install EDK. You can get one online at

http://www.xilinx.com/ise/embedded_design_prod/platform_studio.htm.

Log in and

provide software product information (including product ID). Xilinx will email the

software registration ID to the address you provided during login.

4 www.xilinx.com Getting Started with EDK

EDK 9.2i

R

Installing EDK

You must use an Administrator login when installing EDK on a Windows Platform. Xilinx

also recommends using an Administrator login when running EDK on Windows.

To install EDK on your Windows PC:

1. Insert the EDK Installation DVD into your PC. The installer opens automatically.

If the installation process does not start on its own, open Windows Explorer and

double-click setup.exe on the DVD.

The installation process prompts you to enter the registration ID.

2. Once you have entered the registration ID, continue to install the product.

Note:

If the environment variable XILINX_EDK is set, the default directory for installation is the

value of the variable %XILINX_EDK%. Otherwise, the default EDK installation directory is c:\EDK.

You can change this to any other directory.

Note: The destination directory name cannot contain spaces.

Environment Variables

The EDK installer creates or modifies the following variables on your machine. These

variables are added to the system settings.

♦ XILINX_EDK

Sets the value of this variable to the EDK installation directory.

♦ PATH

Prefixes the PATH environment variable with %XILINX_EDK%\bin\nt.

EDK tools require the Cygwin tools distributed by Red Hat. A copy of these tools is

distributed with the EDK installation. When you run XPS, the SDK IDE, or Xilinx Shell,

your registry is checked for the entry:

My Computer\HKEY_CURRENT_USER\SOFTWARE\Cygnus Solutions\Cygwin.

If a compatible version of Cygwin is found pre-installed on your machine, the EDK tools

use it. Otherwise, the registry is set up to point to the Cygwin tools distributed in the EDK

installation area.

Note:

When you install EDK, Cygwin installation files are copied to your system. Whether or not the

copied files are installed depends on the state of existing Cygwin installations on the machine. If you

already have Cygwin installed, and if the existing Cygwin installation meets requirements, EDK does

not install Cygwin (and the existing Cygwin installation is used). Otherwise, EDK installs Cygwin from

the installation area. For more information, refer to the “EDK Shell” Chapter in the Embedded System

Tools Reference Manual, available at http://www.xilinx.com/ise/embedded/edk_docs.htm

.

Network Installation

To install EDK for access on a network, perform the following steps.

1. Install the EDK software tools on a PC network server.

Make sure that your users know the location of the software tools and have access to

the installation directory, and that they have administrator privileges for the following

steps.

2. From the local client machine, browse to the following directory:

network_install_location\bin\nt and run setXenv.bat. Running this

program sets up the environment and registry settings needed to run the Xilinx tools

from the remote location.
