Xerox Versant 3100 Press Stock Library Manager

StockLibraryManagerSoftwareVersion8.0[0-9][0-9]

Stock Library Manager Help Version 3.0

March 2016

Xerox® Versant® 3100 Press

Stock Library Manager

1 Stock Library Manager Application....................................................	1-1
Stock Library Manager Overview...................................................................................	1-1
Desktop Shortcuts................................................................................................................	1-2
Backing Up / Transferring the Stock Library..............................................................	1-3

2 Logon.............................................................................................................	2-1
Logon Feature.......................................................................................................................	2-1
Logging on as Administrator...........................................................................................	2-1
3 Language......................................................................................................	3-1
Language Feature................................................................................................................	3-1
Changing Languages.........................................................................................................	3-1
4 System Settings.........................................................................................	4-1
System Settings Feature...................................................................................................	4-1
Accessing System Settings...............................................................................................	4-1
User Interface Tab...............................................................................................................	4-2
User Interface Overview......................................................................................	4-2
Selecting the Manage Stock Library Window Option..............................	4-3
Setting the Default Language...........................................................................	4-3
Changing the Administrator Password..........................................................	4-4
Setting the Date and Time..............................................................................................	4-4
System Tab.............................................................................................................................	4-5
System Overview.....................................................................................................	4-5
Enabling Auto Logoff............................................................................................	4-5
Tray Options Tab..................................................................................................................	4-6
Tray Options Overview..........................................................................................	4-6
Selecting the Option for Tray Properties Window Timeout...................	4-6
5 Managing Stocks for the Press.............................................................	5-1
Stock Management Overview.........................................................................................	5-1
Stock Library Feature..........................................................................................................	5-2
Layout of the Stock Library Feature................................................................	5-2
Accessing the Stock Library Feature...............................................................	5-4
Recommended Media List..................................................................................	5-5
Recommended Media List (RML) Overview....................................	5-5

Xerox® Versant® 3100 Press	i
Stock Library Manager

Table of Contents

Accessing the RML from the Stock Library Feature.....................	5-5
Accessing the RML from Tray Properties..........................................	5-6
Stock Library List.....................................................................................................	5-6
Stock Library List Overview....................................................................	5-6
Accessing the Stock Library List from the Stock Library
Feature................................................................................................	5-7
Accessing the Stock Library List from Tray Properties................	5-7
Downloading Current Media Information...................................................	5-7
Stock Properties Information..........................................................................................	5-8
Tray Properties Information..........................................................................................	5-10
Tray Properties......................................................................................................	5-10
Alignment Profile Library..................................................................................	5-12
Accessing Tray Properties.................................................................................	5-12
Matching the Tray and Stock Information................................................	5-13
Using the Stock Library Feature..................................................................................	5-14
Adding a Stock Entry (from the RML)..........................................................	5-14
Copying a Stock Entry........................................................................................	5-15
Creating a New Stock (from the Stock Library Feature).......................	5-15
Creating a New Stock (from Tray Properties)...........................................	5-16
Editing an Existing Stock in the Stock Library..........................................	5-17
Removing a Stock from the Stock Library..................................................	5-17

6 Test Print Option........................................................................................	6-1
Test Print Overview..............................................................................................................	6-1
Tips for Using the Test Print Option.............................................................................	6-2
Using the Test Print Option from Stock Properties.................................................	6-3
Using the Test Print Option from New Stock Setup...............................................	6-4
Using the Test Print Option from Advanced Stock Setup....................................	6-6

7 Advanced Stock Setup Feature............................................................	7-1
Advanced Stock Setup Overview...................................................................................	7-1
Tips for Using the Advanced Stock Setup Feature.................................................	7-2
Advanced Stock Setup Options......................................................................................	7-3
Alignment Profile Library..................................................................................	7-10
Fold Adjustment Profile Library......................................................................	7-10
Creating / Modifying Advanced Stock Setup Options........................................	7-11
Secondary Transfer Voltage Adjustment Overview.............................................	7-13
Secondary Transfer Voltage Adjustment Test Print
Information.................................................................................................	7-14

ii	Xerox® Versant® 3100 Press
	Stock Library Manager

Table of Contents

Auto and Manual Test Print Screen 1 (Secondary Transfer
Voltage Adjustment)..................................................................	7-14
Auto and Manual Test Print Screen 2 (Secondary Transfer
Voltage Adjustment)..................................................................	7-14
Using the Auto Adjustment Option (Secondary Transfer Voltage
Adjustment).................................................................................................	7-15
UsingtheManualAdjustmentOption(SecondaryTransferVoltage
Adjustment).................................................................................................	7-16

8 Correcting Paper Curl...............................................................................	8-1
Paper Curl Correction Overview......................................................................................	8-1
Automatic Paper Curl Correction.....................................................................	8-2
Paper Curl Correction (Advanced Stock Setup)........................................................	8-4
Paper Curl Correction Test Print......................................................................................	8-5
Types A, B, and C.....................................................................................................	8-6
Custom Curl Correction........................................................................................	8-6
Test Print Button (Paper Curl Correction)......................................................	8-7
Recommended Order for Using Paper Curl Correction Test Print
Options.............................................................................................................	8-8
Correcting the Paper Curl..................................................................................................	8-8

9 Profiles...........................................................................................................	9-1
Profiles Overview..................................................................................................................	9-1
Entering / Exiting Profiles..................................................................................................	9-2
10 Alignment Profiles...............................................................................	10-1
Alignment Overview.........................................................................................................	10-1
Alignment Information.....................................................................................	10-2
Alignment Tips......................................................................................................	10-3
Alignment Options............................................................................................................	10-4
Registration............................................................................................................	10-4
Perpendicularity....................................................................................................	10-5
Skew..........................................................................................................................	10-5
Magnification........................................................................................................	10-5
Front and Black Print Density Levels............................................................	10-5
Automatic Alignment Information............................................................................	10-6
Alignment Procedures.....................................................................................................	10-7
Pre-alignment Procedure..................................................................................	10-7
Auto Alignment Procedure...............................................................................	10-7
Using Manual Test Print for an Alignment Profile..................................	10-8
Creating / Editing an Alignment Profile...................................................	10-11

Xerox® Versant® 3100 Press	iii
Stock Library Manager

Table of Contents

11 Fold Adjustment Profiles...................................................................	11-1
Fold Adjustment Overview.............................................................................................	11-1
Fold Types...............................................................................................................	11-2
Optional Trimming with a Fold Adjustment Profile...............................	11-3
Fold Adjustment Procedures.........................................................................................	11-3
Bi-Fold Single Sheet Adjustment Procedure..............................................	11-4
Bi-Fold Multiple Sheets Adjustment Procedure.......................................	11-6
Bi-Fold Multiple Sheets Stapled Adjustment Procedure.......................	11-8
C-Fold Adjustment Procedure.......................................................................	11-10
Z-Fold Adjustment Procedure.......................................................................	11-11
Z-Fold Half-Sheet Adjustment Procedure................................................	11-12

iv	Xerox® Versant® 3100 Press
	Stock Library Manager

Stock Library Manager

Application

Stock Library Manager Overview

Important

Access the Stock Library Manager application on the print server; it cannot be accessed from the press.

Note

Information shown on the main Stock Library Manager window may vary depending on system configuration.

Use the Stock Library Manager application to:

1.Logon / Logoff as Administrator

2.Change the Language that is displayed on the Stock Library Manager application

3.Manage Profiles that are associated with stocks (including creating, editing, and deleting profiles); profiles include alignment, folder adjustment (optional), and third-party finishing devices (optional)

Xerox® Versant® 3100 Press	1-1
Stock Library Manager

Stock Library Manager Application

4.Manage stocks that the press uses, including assigning specific stocks to feeder trays, and adding, copying, editing, creating, and deleting stocks from the Stock Library list

5.Choose specific System Settings options associated with stocks and feeder trays. The System Settings feature is available only when logged on as Administrator

6.ViewTrayProperties,assignaspecificstocktoatray,andsetavarietyofparameters for that assigned stock

Note

The appearance of the Stock Library feature on the main window of the Stock Library Manager application is dependent on how the administrator sets this feature in System Settings (while logged on in the Administrator mode). If the Stock Library feature is not displayed on the Stock Library Manager main window, then the administrator has restricted its access to administrators only. In this case, contact your administrator for more information.

Related Topics:

Logon Feature

Language Feature

System Settings Feature

Stock Management Overview

Layout of the Stock Library Feature

Tray Properties

Advanced Stock Setup Overview

Profiles Overview

Desktop Shortcuts

Two desktop / shortcut icons are provided on the print server for easy and quick access totheStockLibraryManagerapplicationandtothecustomizedStockLibrarylist. During the installation of the Stock Library Manager application, two icons are created on the print server's desktop. These icons are shortcuts to the following items:

•Stock Library Manager application: This shortcut icon allows the user to quickly and easily open and start the application (if it is not already running)

•Stock Library Manager Profiles folder: This shortcut icon displays as a folder on the print server's desktop and allows the user to access the customized Stock Library list.

To use the desktop shortcuts, perform the following steps: 1. Acess the desktop of the print server.

1-2	Xerox® Versant® 3100 Press
	Stock Library Manager

Stock Library Manager Application

2.Locatethetwoicons(StockLibraryManagerapplicationandStockLibraryManager Profiles).

3.To open / access either the Stock Library Manager application or the Stock Library Manager Profiles folder, double click on the desired icon.

Depending on which icon is selected, either the Stock Library Manager application opens or the folder containing the Stock Library list opens.

Backing Up / Transferring the Stock

Library

Stocks that are created / copied and stored in the Stock Library list may be backed up and / or transferred to another Stock Library Manager application. This is accomplished by using an external USB flash drive.

Important

The Stock Library Manager application resides on the print server that is connected to the press. It can be accessed only from the print server; it cannot be accessed from the press.

1.Insert the USB flash drive into a USB port on the print server's computer.

2.From the print server's desktop, open the Stock Library Manager Profiles folder; it is the shortcut icon on the desktop.

3.Browse to the stock directory.

Stocks that were created / copied and stored in the library are distinguished by the

.stock extension.

4.Select all the files in the stock directory with the .stock extension.

5.Select Edit > Copy (or Ctrl > C).

6.Open the directory of the USB flash drive.

7.Select Edit > Paste (or Ctrl > V).

The files are copied onto the USB flash drive.

8.Close both directories.

9.Remove the USB flash drive from the print server's computer.

The .stock files can remain on the USB flash drive as a backup copy.

10.Choose one of the following:

•Store the USB flash drive in a safe, secure location.

•Copy the files onto a different print server's Stock Library Manager application; go to the next step.

11.Copy the files onto a different print server's Stock Library Manager application by performing the following steps:

a)Insert the USB flash drive into a USB port on the second print server's computer.

Xerox® Versant® 3100 Press	1-3
Stock Library Manager

Stock Library Manager Application

b)Open the directory of the USB flash drive and browse to the folder containing the backed-up files.

c)Select all the files with the .stock extension.

d)Select Edit > Copy (or Ctrl > C).

e)Fromthesecondprintserver'sdesktop,openthe StockLibraryManagerProfiles folder.

f)Select Edit > Paste (or Ctrl > V).

The files are copied into the Stock Library Manager Profiles folder.

g)Close both directories.

h)Remove the USB flash drive from the print server's computer.

12.Store the USB flash drive in a safe, secure location.

1-4	Xerox® Versant® 3100 Press
	Stock Library Manager

Logon

Logon Feature

There are three user levels:

•Operator: This is the default level and is sufficient for most Stock Library Manager functions.

•Administrator: This level allows you to customize the system defaults for specific Stock Library Manager features and options.

•Customer Engineer: This level allows the Customer Service Engineer (CSE) to logon andperformvariousmaintenance/upgradestotheStockLibraryManagerapplication.

TheupperrightcorneroftheStockLibraryManagermainwindowdisplaysthelogged-on user level.

Note

Logging on as Administrator affects only the Stock Library Manager application. While logged on you are Administrator only for this application. You are not Administrator for any other applications on the print server.

Logging on as Administrator

1.Select Logon from the main window of the Stock Library Manager application. The Logon window opens.

2.From the Logon screen select Administrator from the drop-down menu.

3.Enter the Administrator password.

The default password is five ones (11111).

Xerox® Versant® 3100 Press	2-1
Stock Library Manager

Logon

Note

For security reasons, only asterisks are displayed on the screen.

4.Select OK.

Note

It is recommended that you change the Administrator password as soon as possible after installing the machine in order to prevent unauthorized access to the Administrator mode.

5.To exit the Administrator mode, select Logoff on the Stock Library Manager main window.

Related Topics:

Changing the Administrator Password

2-2	Xerox® Versant® 3100 Press
	Stock Library Manager

Language

Language Feature

UsetheLanguagefeaturetoswitchfromthecurrentlydisplayedlanguagetoadifferent language. The language selected here affects only the Stock Library Manager application; it does not affect any other applications on the print server.

Note

Thenumberoflanguagesavailableonyoursystemdependsonwhatwasinstalledduring the initial installation process.

Related Topics:

Changing Languages

Setting the Default Language

Changing Languages

To change the language, use the following procedure.

1.Select Language from the Stock Library Manager on the print server. The Language window opens.

2.Do one of the following:

•Select the desired language, or

•Select Cancel to close without changing the language and to return to the main Stock Library Manager window.

Xerox® Versant® 3100 Press	3-1
Stock Library Manager

Language

Important

If a language is selected, the Stock Library Manager displays the new language and the Language window closes; no further confirmation is required. This new language remains displayed until either a different language is selected or the Stock Library Manager application on the print server is exited (closed) and restarted.

Related Topics:

System Settings Feature

Logging on as Administrator

Setting the Default Language

3-2	Xerox® Versant® 3100 Press
	Stock Library Manager

System Settings

System Settings Feature

UseSystemSettingstomakechangestovariousfeaturesandoptionsthatareassociated with the Stock Library Manager.

Note

System Settings is available only when you are logged on as the Administrator.

Related Topics:

User Interface Overview

System Overview

Tray Options Overview

Logging on as Administrator

Accessing System Settings

Setting the Date and Time

Accessing System Settings

1.From the main window of the Stock Library Manager application, logon as Administrator.

2.Select System Settings.

The System Settings window opens.

3.ToexitSystemSettingsandreturntothemainStockLibraryManagerwindow,select either OK or Cancel.

Xerox® Versant® 3100 Press	4-1
Stock Library Manager

System Settings

4.To exit the Administrator mode, select Logoff on the Stock Library Manager main window.

Related Topics:

Logging on as Administrator

User Interface Tab

User Interface Overview

The User Interface tab allows you to make changes to the following:

•Select how the Stock Library feature is displayed on the Stock Library Manager main window (on the print server):

-The administrator may choose whether or not the Stock Library feature is available while logged on as Operator.

-By default, the Stock Library feature is always displayed on the Stock Library Manager,whichmeansthatboththeOperatorandtheAdministratorhaveaccess to the Stock Library at all times.

-If it is restricted, then access to the Stock Library is available only when logged on as Administrator.

•Choose a Default Language:

-Use this feature to set the primary, default language for the Stock Library Manager. This language is displayed when the Stock Library Manager is initially launched and whenever it is rebooted.

-The number of languages available depends on which language files were installed during the initial installation process.

•Change the Administrator password:

-The default password is five ones (11111).

-Use numbers only for creating your new password. Other characters are not allowed(includingalphacharacters/lettersandsymbolssuchas!*&). Apassword of 4-12 numbers may be entered.

-ChangingthedefaultAdministratorpasswordisrecommendedinordertoprevent unauthorized access to the Administrator mode.

Related Topics:

Selecting the Manage Stock Library Window Option

Setting the Default Language

Changing the Administrator Password

4-2	Xerox® Versant® 3100 Press
	Stock Library Manager

System Settings

Selecting the Manage Stock Library Window Option

Use this procedure to select how the Stock Library feature is displayed on the Stock Library Manager (at the print server).

1.From the main window of the Stock Library Manager application, logon as Administrator.

2.Select System Settings.

3.From System Settings > User Interface, select the desired setting for the Manage Stock Library Window feature. Select one of two choices:

•Allow Casual User Access: This is the default setting. With this selection, all user modes (operator and administrator) have access to the Stock Library, and the Stock Library feature is always displayed on the Stock Library Manager.

•Restrict Casual User Access: With this selection, when the Operator is logged on, the Stock Library feature is no longer displayed on the Stock Library Manager. Access to the Stock Library feature is available only to the administrator and is displayed on the Stock Library Manager only when the Administrator is logged on.

4.SelectOK tosaveanychanges,closeSystemSettings,andreturntotheStockLibrary Manager main window.

5.To exit the Administrator mode, select Logoff on the Stock Library Manager main window.

Related Topics:

User Interface Overview

Logging on as Administrator

Accessing System Settings

Setting the Default Language

1.From the main window of the Stock Library Manager application, logon as Administrator.

2.Select System Settings.

3.From System Settings > User Interface, select the Default Language from the pull-down menu.

4.SelectOK tosaveanychanges,closeSystemSettings,andreturntotheStockLibrary Manager main window.

5.To exit the Administrator mode, select Logoff on the Stock Library Manager main window.

Related Topics:

User Interface Overview

Xerox® Versant® 3100 Press	4-3
Stock Library Manager

System Settings

Logging on as Administrator

Accessing System Settings

Changing the Administrator Password

1.From the main window of the Stock Library Manager application, logon as Administrator.

2.Select System Settings.

3.From System Settings > User Interface, select Change Password. The Change Password window opens.

Tip

Use numbers only for creating your new password. Other characters are not allowed (including alpha characters / letters and symbols such as !*&). A password of 4-12 numbers may be entered.

4.From the Change Password window, perform the following:

a)Enter the old (current) password.

b)Enter a new password.

c)Reenter the new password in the Confirm New Password area.

d)Select OK.

Note

For security reasons, only asterisks are displayed on the screen.

5.SelectOK tosaveanychanges,closeSystemSettings,andreturntotheStockLibrary Manager main window.

6.To exit the Administrator mode, select Logoff on the Stock Library Manager main window.

Related Topics:

User Interface Overview

Logging on as Administrator

Accessing System Settings

Setting the Date and Time

Use this feature to set the date and time for the Stock Library Manager application.

1.From the main window of the Stock Library Manager application, logon as Administrator.

2.Select System Settings.

3.From the System Settings window, select the Date / Time tab.

4-4	Xerox® Versant® 3100 Press
	Stock Library Manager

System Settings

4.Select the desired Date Format you wish to use:

•MM/DD/YYYY (Month / Day / Year)

•DD/MM/YYYY (Day / Month / Year)

•YYYY/MM/DD (Year / Month / Day)

5.Select the desired Time Format you wish to use:

•12-Hour Display

•24-Hour Display

6.SelectOK tosaveanychanges,closeSystemSettings,andreturntotheStockLibrary Manager main window.

7.To exit the Administrator mode, select Logoff on the Stock Library Manager main window.

Related Topics:

Accessing System Settings

System Tab

System Overview

Important

Changes should not be made to the print server-specific information. Any changes to these settings will cause the Stock Library Manager to stop communicating with the press.

From the System tab, the user can do the following:

•View specific print server information including:

-IP Address / Host Name,

-Community Name, and

-Port Number

•Make changes to the Auto Logoff option: This feature automatically logs off the Administrator mode after a set period of time when no action is taken from any of the administrator functions. When Auto Logoff occurs, the Stock Library Manager is returned to Operator mode.

Enabling Auto Logoff

1.From the main window of the Stock Library Manager application, logon as Administrator.

Xerox® Versant® 3100 Press	4-5
Stock Library Manager

System Settings

2.Select System Settings.

3.Select the System tab.

4.To enable Auto Logoff, select the check-box to the left of it.

5.Use the up or down arrow buttons to change the time. The range available is 1-60 minutes.

6.SelectOK tosaveanychanges,closeSystemSettings,andreturntotheStockLibrary Manager main window.

7.To exit the Administrator mode, select Logoff on the Stock Library Manager main window.

Related Topics:

System Overview

Logging on as Administrator

Accessing System Settings

Tray Options Tab

Tray Options Overview

From the Tray Options tab, the user may set the Tray Properties Window Timeout option.

Use the Tray Properties Window Timeout to set whether or not the tray properties window automatically closes if no changes were made to it; there are two choices:

•Never: The window always remains open, unless you manually close it, or

•A timeout period between 1-240 minutes: If this is set, you do not need to manually close the window. It will close automatically once the preset time is reached.

Related Topics:

Selecting the Option for Tray Properties Window Timeout

Logging on as Administrator

Accessing System Settings

Selecting the Option for Tray Properties Window Timeout

1.From the main window of the Stock Library Manager application, logon as Administrator.

2.Select System Settings.

3.Select the Tray Options tab.

4.Select the desired Tray Properties Timeout Window option.

4-6	Xerox® Versant® 3100 Press
	Stock Library Manager

System Settings

5.SelectOK tosaveanychanges,closeSystemSettings,andreturntotheStockLibrary Manager main window.

6.To exit the Administrator mode, select Logoff on the Stock Library Manager main window.

Related Topics:

Tray Options Overview

Logging on as Administrator

Accessing System Settings

Xerox® Versant® 3100 Press	4-7
Stock Library Manager

System Settings

4-8	Xerox® Versant® 3100 Press
	Stock Library Manager

Managing Stocks for the Press

Stock Management Overview

Important

Access the Stock Library Manager application on the print server; it cannot be accessed from the press.

Note

Use the Stock Library feature to manage stocks for the press. The Stock Library feature allows the user to do the following:

•Assign specific stocks to feeder trays

•Add new stocks to the customized Stock Library list from the Recommended Media List (RML)

•Copy RML stocks and customize the stock properties as required

•Copy an existing stock and customize the stock properties as required

•Edit the attributes of existing stocks

•Create and save new stocks

Xerox® Versant® 3100 Press	5-1
Stock Library Manager

Managing Stocks for the Press

•Change the order stocks are shown by moving a stock up / down in the Stock Library list

•Remove / delete a stock entry

Once a stock type is defined, named, and saved, it can be easily referenced from the Stock Library list. A saved stock can be quickly selected and used for a desired paper tray or print job.

Related Topics:

Layout of the Stock Library Feature

Tray Properties

Desktop Shortcuts

Accessing the Stock Library Feature

Stock Library Feature

Layout of the Stock Library Feature

1. Recommended Media List (RML) Drop-down Menu

Select the desired list from the drop-down menu. The default list is the one Xerox providesandiscalledRecommendedMediaList;thisalsomaybetheonlylistavailable. If the user works with various paper companies, these paper companies may provide their own media lists to the customer. If other media lists are loaded into the Stock Library Manager application, then they will be available from this drop-down menu. Once a list is selected, it becomes the default RML until a new one is selected.

5-2	Xerox® Versant® 3100 Press
	Stock Library Manager

Managing Stocks for the Press

2. Recommended Media List (RML)

This area displays a list of all the default, preprogrammed stocks that are available for the press. The default list is the one provided by Xerox. Columns can be resized and rearranged to the user's preference; for example, move the Weight column to the left

orimmediaterightofthe Type columnbyhighlightinganddraggingitwiththemouse.

Columns include the following stock information: Name, Size, Type, Weight, Coating, Color, Modulus, Hole Punched, and Comment.

3. Stock Library List

This area displays a list of all the various stocks that were either created by the user or copied / edited from either the Stock Library list or from the Recommended Media List. The Stock Library list displays stocks that are specific to your press. Columns can be resized and rearranged to the user's preference (same as the RML).

Columns include the following stock information: Name, Size, Type, Weight, Coating, Color, Modulus, Hole Punched, Last Updated, and Comment.

Note

The Last Updated column reflects the most recent date and time when a stock was edited / changed.

4. Default Layout (Stock Library List)

Select this option to return the Stock Library list to its original layout.

5. Properties (Stock Library List)

Allows the user to view and / or change the properties of stocks listed in the Stock Library list. The stock name cannot be edited / changed.

6. Create New

Allows the user to create and save a new stock to the Stock Library list.

7. Copy (Stock Library List)

Allows the user to copy an existing stock from the Stock Library list, edit the stock properties, and save it to the Stock Library as a new stock.

8. Help

Select this to get online help information about the Stock Library feature.

9. Remove

Allows the user to delete (remove) a stock from the Stock Library list.

10. Add to Stock Library

Allows the user to add a stock from the RML to the Stock Library list.

11. Copy (RML)

Allows the user to copy an existing stock from the RML, edit the stock properties, and save it to the Stock Library list as a new stock.

12. Properties (RML)

Allows the user to view the properties of stocks listed in the RML. Properties of a stock in the RML cannot be changed.

Xerox® Versant® 3100 Press	5-3
Stock Library Manager

Managing Stocks for the Press

13. Default Layout (RML)

Select this option to return the RML view to its original layout.

14. Sorting

Select either Use Columns or Sort Manually.

•Use Columns: Select this option to automatically sort the stocks alphabetically by the Name column.

•SortManually:Selectthisoptionmanuallymoveitemsaroundwithinacolumn(any column). This option is used in conjunction with the Up / Down buttons.

Tip

Regardless of the Sorting selection, columns can be moved and arranged in any order you desire; for example, move the Weight column to the right of the Coating column.

15. Up / Down Buttons

Use this option in conjunction with the Sort Manually option to move items within a column up or down in the Stock Library list.

16. Close

Closes and exits the Stock Library feature, and returns the user to the Stock Library Manager main window.

Related Topics:

Recommended Media List (RML) Overview

Stock Library List Overview

Accessing the Stock Library Feature

Note

1.Choose one of the following:

•From the Stock Library Manager main window, select the Stock Library button.

•If the Stock Library button is not displayed, perform the following:

1.Logon as Administrator.

2.Select Stock Library.

5-4	Xerox® Versant® 3100 Press
	Stock Library Manager

Managing Stocks for the Press

The Stock Library feature opens and displays the Manage Stock Library window.

2.Select Close to return to the Stock Library Manager main window. If logged on as Administrator, select Logoff.

Related Topics:

System Settings Feature

Desktop Shortcuts

Logging on as Administrator

Recommended Media List

Recommended Media List (RML) Overview

The Recommended Media List (RML) displays a list of all the default, preprogrammed stocks that are available for the press. The default RML is provided by Xerox.

Multiple RMLs may be available with your press, or the default Xerox list may be the only list available. For example, if the user works with various paper companies, these paper companies may provide their own media lists to the customer. These lists can be loaded into the Stock Library Manager, and are then available for selection.

When accessing the RML for the first time, the RML window is empty and Not Selected is displayed in the drop-down menu.

Selecting a list from the drop-down menu populates the RML window. Once a list is selected, it becomes the default RML until a new one is selected.

From the RML window columns can be resized and rearranged to the user's preference; forexample,movethe Weight columntotheleftorimmediaterightofthe Type column by highlighting and dragging it with the mouse.

Note

The RML can be accessed either from the Stock Library feature or from Tray Properties.

Related Topics:

Layout of the Stock Library Feature

Tray Properties

Accessing the RML from the Stock Library Feature

Accessing the RML from Tray Properties

Accessing the RML from the Stock Library Feature

1. From the Stock Library Manager main window, select the Stock Library button.

Xerox® Versant® 3100 Press	5-5
Stock Library Manager

Managing Stocks for the Press

The Manage Stock Library window opens and displays the RML at the top.

2.From the drop-down menu, select the desired list to display.

3.Select Close to return to the Stock Library Manager main window.

Related Topics:

Recommended Media List (RML) Overview

Layout of the Stock Library Feature

Accessing the Stock Library Feature

Accessing the RML from Tray Properties

1.Click on a tray from the Stock Library Manager main window. The Tray Properties window opens.

2.Select the Recommended Media List button. The Recommended Media List window opens.

3.From the drop-down menu, select the desired list to display.

4.Close (and save) by selecting Cancel or the x in the upper right corner of the window.

5.From Tray Properties, select either OK or Cancel.

Tray Properties closes and the Stock Library Manager main window is displayed.

Related Topics:

Recommended Media List (RML) Overview

Tray Properties

Accessing the Stock Library Feature

Stock Library List

Stock Library List Overview

The Stock Library list contains the names of all the various stocks that are specific to your press.

The Stock Library list is available either through the Tray Properties window or from

Stock Library Manager > Stock Library.

Related Topics:

Layout of the Stock Library Feature

Tray Properties

Accessing the Stock Library List from the Stock Library Feature

Accessing the Stock Library List from Tray Properties

Accessing the Stock Library Feature

5-6	Xerox® Versant® 3100 Press
	Stock Library Manager

Managing Stocks for the Press

Accessing the Stock Library List from the Stock Library Feature

1.From the Stock Library Manager main window, select the Stock Library button. TheManageStockLibrarywindowopensanddisplaystheStockLibrarylistunderneath the RML.

2.Select Close to return to the Stock Library Manager main window.

Related Topics:

Stock Library List Overview

Layout of the Stock Library Feature

Accessing the Stock Library Feature

Accessing the Stock Library List from Tray Properties

1.Click on a tray from the Stock Library Manager main window. The Tray Properties window opens.

2.Select the Stock Library button. The Stock Library list opens.

3.Close by selecting Cancel or the x in the upper right corner of the window.

4.From Tray Properties, select either OK or Cancel.

Tray Properties closes and the Stock Library Manager main window is displayed.

Related Topics:

Stock Library List Overview

Tray Properties

Accessing the Stock Library Feature

Downloading Current Media Information

Forcurrentstock/paperguidelinesgoto www.xerox.com anddownloadtheappropriate list for your press.

Xerox® Versant® 3100 Press	5-7
Stock Library Manager

Managing Stocks for the Press

Stock Properties Information

Stock Properties displays all the attributes that are assigned to a specific stock. These attributes include the following:

1. Stock Details

Thisareadisplaysthecurrentstockinformationthatisassociatedwiththestockname; information includes the paper size, type, weight, color, orientation of the paper (LEF or SEF), and more.

2. Size

Select the desired stock size from the drop-down menu. If Custom is selected, enter thecustomerstocksizeinformation(width,height,andinchesormillimeters)andselect

OK.

3. Color

Select the desired color for the stock from the drop-down menu. If Custom is selected, enter the customer color information, select Add Color and Close.

4. Weight (g/m2)

Select the weight of the stock by using the scroll up / down arrows or by clicking inside the field and typing the weight.

5. Long Edge Feed / Short Edge Feed (LEF / SEF)

Indicates the orientation direction that the stock will be loaded in a tray.

6. Help

Select this button to open the Help window and obtain information about the stock properties and the Stock Library Manager application.

7. Name

Enter the desired name of the stock. Alpha / numeric characters may be used, as well as symbols, with the exception of / (slash).

5-8	Xerox® Versant® 3100 Press
	Stock Library Manager

+ 78 hidden pages
